Towards Readability-Aware Recommendations of Source Code Snippets

Athanasios Michailoudis

, Themistoklis Diamantopoulos

and Andreas Symeonidis

Electrical and Computer Engineering Dept., Aristotle University of Thessaloniki, Thessaloniki, Greece

Keywords:

Snippet Mining, API Usage Mining, Code Readability.

Abstract:

Nowadays developers search online for reusable solutions to their problems in the form of source code snip-

pets. As this paradigm can greatly reduce the time and effort required for software development, several

systems have been proposed to automate the process of ﬁnding reusable snippets. However, contemporary

systems also have certain limitations; several of them do not support queries in natural language and/or they

only output API calls, thus limiting their ease of use. Moreover, the retrieved snippets are often not grouped

according to the APIs/libraries used, while they are only assessed for their functionality, disregarding their

readability. In this work, we design a snippet mining methodology that receives queries in natural language

and retrieves snippets, which are assessed not only for their functionality but also for their readability. The

snippets are grouped according to their used API calls (libraries), thus enabling the developer to determine

which solution is best ﬁtted for his/her own source code, and making sure that it will be easily integrated and

maintained. Upon providing a preliminary evaluation of our methodology on a set of different programming

queries, we conclude that it can be effective in providing reusable and readable source code snippets.

1 INTRODUCTION

The evolution of the Internet and the open-source

community has greatly inﬂuenced the way software

is developed. As more and more software projects

are hosted online in platforms like GitHub, develop-

ers follow a component-based software engineering

paradigm, where they search for reusable snippets and

integrate it into their own source code. This practice

of reuse, when performed effectively, can have signif-

icant beneﬁts both for the development time and effort

and for the quality of the produced source code.

However, reusing existing code snippets is not al-

ways straightforward. The developer ﬁrst has to leave

the IDE, form a suitable query in a search engine,

locate potential candidate snippets out of a possibly

large pool and carefully assess whether they cover

his/her functional criteria. After that he/she has to

choose the snippet to reuse, and understand its work-

ings before integrating it into his/her own source code.

As a result, several systems aspire to automate this

process, focusing on the areas of API usage mining

and/or snippet mining. API usage mining systems are

tailored to speciﬁc APIs/libraries and focus on pro-

https://orcid.org/0009-0007-9824-0975

https://orcid.org/0000-0002-0520-7225

https://orcid.org/0000-0003-0235-6046

viding sequences of API calls extracted from source

code examples (Xie and Pei, 2006; Wang et al., 2013;

Fowkes and Sutton, 2016; Montandon et al., 2013;

Kim et al., 2010; Moreno et al., 2015; Katirtzis et al.,

2018), while the more generic snippet mining sys-

tems target common programming queries (e.g. open-

ing and reading a ﬁle) and are often connected to code

search engines (Wightman et al., 2012; Brandt et al.,

2010; Wei et al., 2015; Diamantopoulos et al., 2018).

Both types of systems are effective in various sce-

narios, however they also have signiﬁcant limitations.

Some systems may have a limited dataset and/or

methodology, not allowing them to accept queries in

natural language. In addition, certain systems pro-

duce API calls instead of ready-to-use code, whereas

the ones that produce snippets do not always take into

account the different APIs/implementations. Finally,

and more importantly, contemporary systems focus

only on the functional aspect of reuse, not considering

the readability of the code, thus providing solutions

that may be hard to integrate and/or maintain.

In this work, we present a snippet mining sys-

tem that covers the functional criteria posed by the

developer, while also assessing the readability of the

retrieved source code. Our system receives queries

in natural language and employs the CodeSearchNet

dataset (Husain et al., 2019), which offers clean pairs

688

Michailoudis, A., Diamantopoulos, T. and Symeonidis, A.

Towards Readability-Aware Recommendations of Source Code Snippets.

DOI: 10.5220/0012145500003538

In Proceedings of the 18th International Conference on Software Technologies (ICSOFT 2023), pages 688-695

ISBN: 978-989-758-665-1; ISSN: 2184-2833

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

of documentation strings and method snippets. More-

over, we build a model that assesses snippet readabil-

ity based on static analysis metrics. Finally, we ex-

tract the API calls of the snippets to detect groups

of different implementations, thus allowing the devel-

oper to choose the desired source code.

The rest of this paper is organized as follows. Sec-

tion 2 reviews current research in the areas of API us-

age mining and snippet mining. Our methodology for

recommending readable snippets is presented in Sec-

tion 3. Section 4 evaluates our methodology on a set

of programming queries, and ﬁnally Section 5 con-

cludes this paper and provides ideas for future work.

2 RELATED WORK

As already mentioned, our work lies in the area of rec-

ommender systems for efﬁcient code reuse. In most

cases, such systems work in one of two ways: ei-

ther by identifying and mining API calls from exist-

ing source code to recommend similar methods or by

mining and retrieving more generic code snippets as

solutions to queries given in natural language.

Regarding API usage mining, MAPO (Xie and

Pei, 2006) is a system that employs frequent sequence

mining to extract API usage examples in the form of

call sequences from client code. However, it lacks

diversity-awareness of the extracted methods, which

ultimately leads to the production of a substantial

amount of, often irrelevant, API examples. To mit-

igate that, the UP-Miner (Wang et al., 2013) system

was developed, which aims at mining succinct and

high-coverage usage patterns of API methods from

source code, using the BIDE algorithm. From a ma-

chine learning point of view, another notable imple-

mentation is PAM (Fowkes and Sutton, 2016), which

extracts API calls via probabilistic machine learning.

Interestingly, PAM introduces an automated evalua-

tion framework, based on libraries that were provided

with handwritten API example code by developers.

Apart from thesystems that focus on API call

sequences, there are also approaches recommend-

ing reusable snippets, such as APIMiner (Montandon

et al., 2013), which identiﬁes and analyzes API calls

using code slicing. Moving a step further in that direc-

tion, certain approaches cluster the retrieved snippets,

according to the targeted API calls. Two such sys-

tems are eXoaDocs (Kim et al., 2010) and CLAMS

(Katirtzis et al., 2018); the former applies snippet

clustering using semantic features to spot duplicate

code, via the DECKARD algorithm (Jiang et al.,

2007), while the latter also incorporates a summariza-

tion algorithm for succinct and readable snippet pre-

sentation. Finally, MUSE (Moreno et al., 2015) also

includes ranking of the resulting clusters by introduc-

ing the ease of reuse metric. The metric is deﬁned as

the percentage of the object types that belong to the

library under analysis and is based on the assumption

that custom object types may require importing other

third-party libraries and thus hinder reuse.

Though certainly functional, most aforementioned

methods suffer from the same limitations. First of all,

the usage examples they provide are limited to a hand-

ful of API methods, while disregarding the need for a

potential library change. Several of those also mainly

focus on generating API call sequences, rather than

practical code snippets, and, last but not least, none of

these systems receive queries in natural language.

Generic snippet mining techniques have been de-

veloped to alleviate some of those limitations. In-

dicative examples are the Eclipse IDE plug-ins Snip-

Match (Wightman et al., 2012) and Blueprint (Brandt

et al., 2010), from which the ﬁrst leverages code pat-

terns and local indexes to improve snippet search and

suggestions, while the second accepts queries in nat-

ural language while at the same time is connected

to the Google search engine for accurate snippet re-

trieval and ranking. Another search engine-based rec-

ommender, developed as a Visual Studio extension,

is Bing Code Search (Wei et al., 2015), which also

allows for natural language questions while also im-

plementing a multi-parameter ranking system as well

as active code snippet adaptation to the developer’s

needs. Finally, CodeCatch (Diamantopoulos et al.,

2018), is another snippet mining system, which apart

from the advantages of the aforementioned plug-ins,

also provides the added assets of different options

for snippet selection, as well as the incorporation of

reusability scoring of the mined snippets, extracted

from a set of the most popular GitHub projects.

Lately, there are also several approaches using

deep learning, either in the API usage mining domain

or in the more generic snippet mining. Regarding API

usage mining, systems like SWIM (Raghothaman

et al., 2016) and T2API (Nguyen et al., 2016), trans-

late questions given in natural language to API calls

and then generate the appropriate code, containing

said calls. In a similar fashion, DeepAPI (Gu et al.,

2016) implements RNNs to transform queries into

API sequences. On the other hand, RNNs are also

utilized for code snippet reusability by the DeepCS

implementation (Gu et al., 2018), where two networks

are used to encode natural language and code respec-

tively and the produced embeddings are then com-

pared using the cosine similarity metric. CodeTrans-

former (Papathomas et al., 2022) follows a similar

methodology, where the RNNs are replaced by Trans-

Towards Readability-Aware Recommendations of Source Code Snippets

689

formers and the similarity metric of choice is the Tri-

angle’s Area Similarity-Sector’s Area Similarity. The

last two systems have the added beneﬁt of incorpo-

rating semantics, partly due to the fact that the net-

works are trained on the well-curated and semantics-

oriented CodeSearchNet dataset (Husain et al., 2019).

Although the aforementioned solutions usually re-

trieve relevant results to programming queries, they

neglect to assess the readability of the provided rec-

ommendations. In this work, we present a readability-

aware recommender that supports code reuse through

readable code snippet selection. Our system features

clustering based on API calls like API usage mining

approaches, however it also allows queries in natu-

ral language and produces ready-to-use snippets in-

stead of sequences. Moreover, using our readabil-

ity model based on static analysis metrics, the sys-

tem ranks these snippets using both a functional and a

readability score, thus supporting developers to make

the optimal decision based on their requirements.

3 METHODOLOGY

The architecture of our recommender is shown in Fig-

ure 1. As already mentioned, we use as input the

CodeSearchNet dataset (Husain et al., 2019) in order

to create an index of code snippets. We use the Java

version of the dataset as a proof of concept, although

our methodology could also be easily extended to

other languages. Upon preprocessing the data (Data

Preprocessor), we are able to build an index (Index

Builder) for ﬁnding similar snippets. Moreover, we

build a Readability Model using static analysis met-

rics. When a new query is given by the developer,

it is initially parsed by the Query Parser (to prepro-

cess it) and sent to the index in order to retrieve rele-

vant snippets. The snippets are then sent to the Clus-

terer, which groups them according to their API calls.

Finally, the Presenter is responsible for ranking the

groups with respect to their functional similarity and

their readability and present them to the developer.

3.1 Building Models for Snippets

3.1.1 Data Preprocessing

Before proceeding to the indexes built by our ap-

proach, we ﬁrst preprocess the data. Concerning the

docstrings, which are used for ﬁnding relevant meth-

ods, we create a text preprocessing pipeline that in-

cludes (1) the removal of the docstring located af-

ter the ﬁrst dot symbol, effectively retaining the ac-

tual description of each snippet, (2) the removal of

non-ascii and special characters, while replacing them

with empty characters, (3) the removal of empty char-

acters, (4) the conversion of every character to low-

ercase, (5) the removal of common stopwords of the

English language, which appear frequently in text and

may skew results, and (6) the lemmatization of every

token, so that each word is converted to its base form.

For the code, as already mentioned, we extract the

API calls of the snippets to group them, so we simply

use the preprocessing pipeline by Papathomas et al.

(2022), which covers our purposes. The pipeline in-

cludes steps for (1) the removal of non-ascii charac-

ters, (2) the removal of all the tokens of the code list

that contain space, double quotes, or create a com-

ment, (3) the removal of empty characters, and (4)

the conversion of every character to lowercase. There

are also two more steps, which do not affect our case,

which are the encoding of programming symbols to

unique tokens (e.g. < becomes ‘lessoperator’, + be-

comes ‘addoperator’, etc.

) and the removal of any to-

kens after ﬁrst 100 for each method (used to enhance

the uniformity of the dataset).

3.1.2 Index Building

Following the data preprocessing, a means of retriev-

ing relevant data is needed. To achieve that we built a

similarity scheme based on a vector space model and

a metric to calculate the similarity of the two vectors.

Firstly, for the vectorization of the snippets, two

vocabularies are created, corresponding to the de-

scription and code tokens, respectively. The two vo-

cabularies consist of the 10,000 most common words

of each set and are used in conjunction with a tf-idf

vectorizer in order to create the vector representations

of the respective docstring or code. The vectorizer

calculates the weight of each token t within a snip-

pet/document D according to the following formula:

t f id f (t,d,D) = t f (t,d) · id f (t,D)

where t f (t,d) is the term frequency of term t in doc-

ument d and refers to the appearances of a token

in the snippet, while id f (t,D) is the inverse docu-

ment frequency of term t in the set of all documents

D, referring to how common a speciﬁc token is in

all the snippets. In speciﬁc, id f (t,D) is equal to

1 + log((1 + |D|)/(1 + d

)), where |d

|is the number

of documents containing the term t, i.e. the number

of snippets containing the token. By doing so, tokens

that appear frequently in the snippets descriptions or

code are given small weights and less common and

usually more case-speciﬁc, hence useful, terms are as-

signed larger weights.

The full list of transformations is available at (Papath-

omas et al., 2022).

ICSOFT 2023 - 18th International Conference on Software Technologies

690

Snippet Data

Data

Preprocessor

Index

Builder

Readability

Model Builder

Models

Docstring

Index

Code

Index

Readability

Model

Query

Parser

Clusterer

Presenter

Figure 1: Methodology of our Readability-Aware Recommender of Source Code Snippets.

Finally, we use the cosine similarity metric to

compare the resulting vectors. For two document vec-

tors (i.e. query, docstring) d

and d

, it is deﬁned us-

ing the following equation:

cos

similarity(d

) =

· d

| · |d

∑

· w

∑

· w

where w

and w

are the tf-idf scores of term t

documents d

and d

respectively, and N is the total

number of terms.

Any new input query in our system is vectorized

through the aforementioned process, using the doc-

string vocabulary, and its similarity to every docstring

of the dataset is computed.

To compute the similarities between snippets, we

create documents by extracting the API calls of each

snippet and subsequently, apply the tf-idf vectorizer

of the code vocabulary to extract the vector represen-

tation for each document. Then, the cosine similar-

ity metric is again computed. The similarity between

API calls is preferred to the comparison of whole code

snippets, as there are a lot of tokens that are shared

between two snippets, thus skewing the results.

3.1.3 Readability Assessment

Regarding the readability assessment of each source

code snippet, we created a machine learning model

to provide a readability assessor based on static anal-

ysis metrics. A Random Forest regressor was cho-

sen as the estimator, due to its versatility and ease of

use. In order to train the model, we used the static

analysis metrics and readability metrics computed

by Karanikiotis et al. (2023) on the CodeSearchNet

dataset. In speciﬁc, we used all metrics from the four

static analysis categories relevant to snippets (com-

plexity, coupling, documentation, and size), while we

also used the readability score derived by the tool of

Scalabrino et al. (2018)

as ground truth.

https://dibt.unimol.it/report/readability/

Through an exhaustive grid search, the parame-

ters of the model that yielded the best R

score were

the following: n estimators = 100 (number of trees

in forest), max f eatures = 0.8 (fragment of features

were considered at each split), max depth = 9 (max-

imum depth of each tree, max samples = 100 (sub-

sample size used to build each tree). By the end of the

training process, our model had achieved an 83.5%

accuracy on a snippets readability estimation, based

on the code’s quality characteristics, a performance

which was considered adequate for the model to be

integrated in our recommendation system. The distri-

bution of readability for all snippets of the dataset is

shown in the histogram of Figure 2.

Figure 2: Histogram of the Readability of all Snippets.

3.2 Retrieving Useful Snippets

3.2.1 Query Parsing

The Query Parser receives as input the query of the

user in natural language, it tokenizes and preprocesses

it in the same way as described in subsection 3.1.1 and

creates a tf-idf vector of the query, based on the cre-

ated docstring vocabulary, as described in subsection

3.1.2. We consider a snippet as relevant if the simi-

larity of its docstring to the developer’s query is more

than a similarity threshold, which we set to 0.75 as it

Towards Readability-Aware Recommendations of Source Code Snippets

691

was enough for retrieving an adequate number of re-

sults for different queries. For each result, we retrieve

the docstring, the code of snippet, as well the met-

rics used as input to the Readability Model in order to

compute its readability.

3.2.2 Snippet Clustering

The most relevant snippets that were extracted in the

previous step are forwarded to the Clusterer, which

is responsible for grouping the snippets according to

their API calls. To do so, we ﬁrst extract the API calls

of each snippet using the javalang tool

. The tool is

used to traverse the abstract syntax tree of each snip-

pet and retrieve two types of instructions, call instan-

tiations (e.g. new BufferedReader) and method calls

(e.g. reader.readLine()). Upon extracting the types

of these instructions, we then employ the similarity

scheme deﬁned in subsection 3.1.2 (based on tf-idf)

to build a distance matrix, which is in turn used for

the grouping of the snippets.

The clustering algorithm of choice is Agglomer-

ative clustering, which is a common type of hierar-

chical clustering used to group objects based on their

similarity. The algorithm, however, has a limitation,

as it requires as input the number of clusters. To auto-

matically determine the most suitable number of clus-

ters for a given query, we use the silhouette metric.

Silhouette was selected as it encompasses both the

similarity of the snippets within the cluster (cohesion)

and their difference with the snippets of other clusters

(separation). The clustering algorithm is executed for

2 to snip num−1 clusters, where sip num is the num-

ber of the retrieved snippets associated with the user’s

query. For each execution, we compute the total sil-

houette value (average over the silhouette values of

all snippets) and, ﬁnally, we select the the number of

clusters resulting in the highest total silhouette. The

value of silhouette for each document/snippet (d) is

calculated by the following equation:

silhouette(d) =

b(d) − a(d)

max(a(d), b(d))

where a(d) is the average distance of document d

from all other documents in the same cluster, while

b(d) is computed by measuring the average distance

of d from the documents of each of the other clus-

ters and keeping the lowest one of these values (each

corresponding to a cluster).

Note that the reasoning behind the clustering is

that snippets with similar API calls reﬂect similar

methods and, therefore, more than one results of the

same solution are redundant. Hence, the clustering

https://github.com/c2nes/javalang

discards any duplicates, thus allowing the developer

to differentiate among different implementations.

An example silhouette analysis for query ”How to

convert a string to integer?” is shown in Figure 3. It

depicts the silhouette score for 2 to 22 clusters, where

it is clear that the optimal number of clusters is 14.

Figure 3: Example silhouette analysis for clustering the

snippets of query ”How to convert a string to integer?”, de-

picting the silhouette scores for 2 to 22 clusters.

3.2.3 Results Ranking

After the clustering, the produced groups of snippets

are forwarded to the Presenter, which is tasked with

ranking and presenting the results. More speciﬁcally,

we assume that each group/cluster consists of snip-

pets describing the same method, thus it can be ac-

tually represented by the code snippet that has the

highest similarity (or functional score) to the given

query. Thus, the clusters are ranked according to their

snippet’s functional score, whereas, in cases of iden-

tical scores between snippets, higher priority is given

to the snippet with the highest readability. Finally, if

the readability between two snippets is also equal, the

larger cluster is presented in higher order.

The results of the clustering and ranking are pre-

sented to the user along with all the necessary infor-

mation, such as the original query, the optimal num-

ber of clusters, the functional and readability score of

a snippet and the number of snippets in each cluster,

and of course, the description, code and API calls of

the retrieved snippets. To further illustrate the ranking

process, we depict the two most relevant snippets for

the example query ”How to convert a string to inte-

ger?” in Figure 4. In this case, both results scored a

perfect 1.0/1.0 similarity score with the query, while

their readability scores were 86.08% and 85.89% for

the ﬁrst and second result, respectively.

ICSOFT 2023 - 18th International Conference on Software Technologies

692

public static Integer parse(ﬁnal String s) {

try {

return Integer.parseInt(s);

} catch (ﬁnal NumberFormatException e) {

return null;

}

private int idToInt(String value) {

try {

return Integer.valueOf(value);

} catch (NumberFormatException e) {

throw new ConﬁgurationException(”invalid

type ID: ” + value);

}

Figure 4: Top two relevant snippets for the query ”How to

convert a string to integer?”.

4 EVALUATION

4.1 Evaluation Framework

Our methodology is not compared with similar ap-

proaches, since it focuses on providing different im-

plementations and readability scores, and not on pro-

viding the maximum number of relevant results. We

assess our methodology on a dataset of 10 common

programming queries shown in Table 1.

Table 1: Queries of the Evaluation Dataset.

ID Query

Q1 How to sort an array?

Q2 How to read a csv ﬁle?

Q3 How to split a string?

Q4 How to sort list in descending order?

Q5 How to convert a string to integer?

Q6 How to get current date?

Q7 How to list all ﬁles in directory?

Q8 How to load an image?

Q9 How to move a ﬁle from directory?

Q10 How to convert date to string?

As already mentioned, the results for the queries

shown in Table 1 are extracted from the CodeSearch-

Net dataset (Husain et al., 2019) using the vector

space model for docstrings deﬁned in Section 3. The

results are then clustered, and ﬁnally the snippet

groups are manually annotated to determine whether

they are relevant to the given query. This annotation

step was kept simple, as we marked as relevant any

snippet that covers the functionality of the query, re-

gardless of its quality and of any APIs used.

We use different metrics to assess the results of

our methodology. First of all, we employ the recipro-

cal rank, which is computed as the inverse of the rank

of the ﬁrst relevant result (e.g. if the ﬁrst relevant re-

sult is in the second position, then the reciprocal rank

is 1/2 = 0.5). This metric is the best ﬁt if we assume

that the developer most often selects the ﬁrst relevant

result to his/her query. However, given that in our

case we assume that there may be more than one rel-

evant implementations, which use different API calls,

we also employ the average precision metric. The av-

erage precision for a query further takes into account

the order of all relevant results, and is computed as:

Avg Precision =

∑

k=1

P(k) · rel(k)

number o f relevant results

(1)

where P(k) is the precision at k (fragment of relevant

results at k-th position) and rel(k) is equal to 1 if the

result at the k-th position is relevant or 0 otherwise.

4.2 Evaluation Results

Table 2 presents certain statistics about our results.

As discussed in Section 3, for each query we ﬁrst re-

trieve any relevant snippets and then we cluster them

to produce groups (third column of Table 2). We also

report the number of relevant results (groups) based

on the annotations (fourth column of Table 2), which

are quite encouraging. In speciﬁc, most queries have

at least 15 results, which are (arguably) adequate in

a code search/reuse scenario. Furthermore, for 9 out

of 10 queries, there are at least 3 different relevant

recommendations (groups), indicating that developers

could beneﬁt from using our system.

Table 2: Statistics of the Results.

Query #Retrieved #Grouped #Relevant

ID Snippets Results Results

Q1 18 14 4

Q2 27 11 2

Q3 23 11 6

Q4 15 7 4

Q5 24 14 6

Q6 12 9 4

Q7 27 18 6

Q8 14 7 3

Q9 16 10 9

Q10 33 23 6

Given the results for the reciprocal rank (Figure 5,

it is also clear that our methodology is effective for

Towards Readability-Aware Recommendations of Source Code Snippets

693

retrieving useful snippets. In speciﬁc, for all queries

except Q2 and Q4, a relevant result is produced in the

ﬁrst position, while even for Q2 and Q4 one can ﬁnd

a relevant snippet at least in the third position. The

Mean Reciprocal Rank (MRR) is also quite high, with

value 0.883, depicted with a dashed line in Figure 5.

Figure 5: Reciprocal rank per query.

The results for average precision (Figure 6) are

also quite encouraging. Our methodology achieves

average precision close to 1 for half the queries of the

dataset, with Mean Average Precision (MAP) equal

to 0.826 (depicted using a dashed line). Only the re-

sults of the second query have low average precision

(0.367), which is due to the fact that several snip-

pets are incomplete (e.g. the code calls functions not

present in the snippet and there are no API calls) and

there are also snippets about writing csv ﬁles. An in-

teresting note is that for Q10 there are several results

about converting date to string but there are also re-

sults about converting string to date. The order of the

terms is actually not captured by our model, which is

a limitation that we plan to confront in future work.

Figure 6: Average precision per query.

Finally, to assess whether our methodology re-

trieves snippets with high readability in the top po-

sitions, we compute the average readability of the re-

sults of each query at different levels. For each query,

Figure 7 depicts the readability of the ﬁrst result, the

average readability of the top 3, top 5, and all re-

sults. The ﬁrst result usually has quite high read-

ability score, indicating that the developer can easily

comprehend it as well as integrate it into his/her own

source code. Moreover, the readability averages at top

3 and top 5 results exhibit high values (more than 0.6)

indicating that on average our methodology retrieves

highly readable snippets in the top positions.

5 CONCLUSION

Although ﬁnding reusable snippets is widely re-

searched, most approaches focus only on the func-

tional aspect. We proposed a methodology that re-

trieves snippets and assesses both their functionality

and their readability. This way, developers can ﬁnd a

snippet that covers the purpose of their query and ex-

hibits high readability, so that they can easily integrate

it and, when needed, maintain it. Moreover, since we

group snippets according to their API calls, we ensure

that the developer reviews only the top (most read-

able) snippet from each possible implementation.

Concerning future work, we plan to compare our

system with other systems as well as to evaluate more

effective retrieval algorithms (e.g. based on code em-

beddings) to further enhance its results. Moreover, we

could conduct a developer study to assess whether our

methodology is perceived as useful by developers.

ACKNOWLEDGEMENTS

Parts of this work have been supported by the Horizon

Europe project ECO-READY (Grant Agreement No

101084201), funded by the European Union.

REFERENCES

Brandt, J., Dontcheva, M., Weskamp, M., and Klemmer,

S. R. (2010). Example-centric Programming: Inte-

grating Web Search into the Development Environ-

ment. In Proceedings of the SIGCHI Conference

on Human Factors in Computing Systems, CHI ’10,

pages 513–522, New York, NY, USA. ACM.

Diamantopoulos, T., Karagiannopoulos, G., and Symeoni-

dis, A. L. (2018). CodeCatch: Extracting Source Code

Snippets from Online Sources. In Proceedings of the

6th International Workshop on Realizing Artiﬁcial In-

telligence Synergies in Software Engineering, RAISE

’18, pages 21–27, New York, NY, USA. ACM.

Fowkes, J. and Sutton, C. (2016). Parameter-free Proba-

bilistic API Mining across GitHub. In Proceedings

ICSOFT 2023 - 18th International Conference on Software Technologies

694

Figure 7: Readability of our methodology at the top result, the top 3 results, the top 5 results, and all the results of each query.

of the 2016 24th ACM SIGSOFT International Sym-

posium on Foundations of Software Engineering, FSE

2016, pages 254–265, New York, NY, USA. ACM.

Gu, X., Zhang, H., and Kim, S. (2018). Deep Code Search.

In Proceedings of the 40th International Conference

on Software Engineering, ICSE ’18, page 933–944,

New York, NY, USA. ACM.

Gu, X., Zhang, H., Zhang, D., and Kim, S. (2016). Deep

API Learning. In Proceedings of the 2016 24th ACM

SIGSOFT International Symposium on Foundations

of Software Engineering, FSE 2016, pages 631–642,

New York, NY, USA. ACM.

Husain, H., Wu, H.-H., Gazit, T., Allamanis, M., and

Brockschmidt, M. (2019). CodeSearchNet Challenge:

Evaluating the State of Semantic Code Search.

Jiang, L., Misherghi, G., Su, Z., and Glondu, S. (2007).

Deckard: Scalable and accurate tree-based detection

of code clones. In Proceedings of the 29th Inter-

national Conference on Software Engineering, ICSE

’07, page 96–105, USA. IEEE Computer Society.

Karanikiotis, T., Diamantopoulos, T., and Symeonidis, A.

(2023). Source code snippets and quality analytics

dataset. https://doi.org/10.5281/zenodo.7893288.

Katirtzis, N., Diamantopoulos, T., and Sutton, C. (2018).

Summarizing Software API Usage Examples Using

Clustering Techniques. In 21th International Confer-

ence on Fundamental Approaches to Software Engi-

neering, FASE 2018, pages 189–206, Boston, MA,

USA. Springer International Publishing.

Kim, J., Lee, S., Hwang, S.-w., and Kim, S. (2010). To-

wards an Intelligent Code Search Engine. In Proceed-

ings of the 24th AAAI Conference on Artiﬁcial Intel-

ligence, AAAI ’10, pages 1358–1363, Palo Alto, CA,

USA. AAAI Press.

Montandon, J. E., Borges, H., Felix, D., and Valente, M. T.

(2013). Documenting APIs with Examples: Lessons

Learned with the APIMiner Platform. In Proceed-

ings of the 20th Working Conference on Reverse En-

gineering, WCRE 2013, pages 401–408, Piscataway,

NJ, USA. IEEE Computer Society.

Moreno, L., Bavota, G., Di Penta, M., Oliveto, R., and Mar-

cus, A. (2015). How Can I Use This Method? In

Proceedings of the 37th International Conference on

Software Engineering - Volume 1, ICSE ’15, pages

880–890, Piscataway, NJ, USA. IEEE Press.

Nguyen, T., Rigby, P. C., Nguyen, A. T., Karanﬁl, M., and

Nguyen, T. N. (2016). T2API: Synthesizing API Code

Usage Templates from English Texts with Statistical

Translation. In Proceedings of the 2016 24th ACM

SIGSOFT International Symposium on Foundations of

Software Engineering, FSE 2016, pages 1013–1017,

New York, NY, USA. ACM.

Papathomas, E., Diamantopoulos, T., and Symeonidis, A.

(2022). Semantic code search in software reposito-

ries using neural machine translation. In 25th Inter-

national Conference on Fundamental Approaches to

Software Engineering, pages 225–244, Munich, Ger-

many.

Raghothaman, M., Wei, Y., and Hamadi, Y. (2016). SWIM:

Synthesizing What I Mean: Code Search and Id-

iomatic Snippet Synthesis. In Proceedings of the 38th

International Conference on Software Engineering,

pages 357–367, New York, NY, USA. ACM.

Scalabrino, S., Linares-V

asquez, M., Oliveto, R., and

Poshyvanyk, D. (2018). A Comprehensive Model for

Code Readability. J. Softw. Evol. Process, 30(6).

Wang, J., Dang, Y., Zhang, H., Chen, K., Xie, T., and

Zhang, D. (2013). Mining Succinct and High-

Coverage API Usage Patterns from Source Code. In

Proceedings of the 10th Working Conference on Min-

ing Software Repositories, MSR ’13, pages 319–328,

Piscataway, NJ, USA. IEEE Press.

Wei, Y., Chandrasekaran, N., Gulwani, S., and Hamadi, Y.

(2015). Building Bing Developer Assistant. Technical

Report MSR-TR-2015-36, Microsoft Research.

Wightman, D., Ye, Z., Brandt, J., and Vertegaal, R. (2012).

SnipMatch: Using Source Code Context to Enhance

Snippet Retrieval and Parameterization. In Proceed-

ings of the 25th Annual ACM Symposium on User

Interface Software and Technology, UIST ’12, pages

219–228, New York, NY, USA. ACM.

Xie, T. and Pei, J. (2006). MAPO: Mining API Usages

from Open Source Repositories. In Proceedings of

the 2006 International Workshop on Mining Software

Repositories, MSR ’06, pages 54–57, New York, NY,

USA. ACM.

Towards Readability-Aware Recommendations of Source Code Snippets

695
