Exploring the Test Driven Development of an Information

Retrieval System

Daniel Staegemann

, Sujith Sudhakaran, Christian Daase

and Klaus Turowski

Magdeburg Research and Competence Cluster VLBA, Otto-von-Guericke University Magdeburg, Magdeburg, Germany

Keywords: Software Engineering, Information Retrieval, Test Driven Development, TDD, Testing, Quality Assurance.

Abstract: Today’s society is heavily driven by data intensive systems, whose application promises immense benefits.

However, this only applies when they are utilized correctly. Yet these types of applications are highly

susceptible to errors. Consequently, it is necessary to test them comprehensively and rigorously. One method

that has an especially high focus on test coverage is the test driven development (TDD) approach. While it

generally has a rather long history, its application in the context of data intensive systems is still somewhat

novel. Though, rather recently, a microservice-based test driven development concept has been proposed for

the big data domain. The publication at hand explores its feasibility regarding the application in an actual

project. For this purpose, a prototypical, microservice based information retrieval system is implemented in a

test driven way with particular consideration for scalability.

1 INTRODUCTION

Test driven development (TDD) is a popular

approach for developing software. However, despite

the associated potential advantages and some

corresponding works (Daase et al. 2023; Staegemann

et al. 2022b; Staegemann et al. 2022a), it is still rather

underexplored in the context of big data (BD) and the

related applications. Here, in our study we apply TDD

to implement an information retrieval system. While

the presented prototypical implementation is rather

small in a BD context, it still showcases a typical BD

use case (Volk et al. 2020) and the presented

architectural approach allows for further scaling. For

this purpose, we write unit tests starting from

tokenization to similarity computation.

However, it has to be noted that the primary focus

of the publication at hand is to further explore the use

of the TDD approach itself. Therefore, the

information retrieval system is just a vehicle to

achieve this. Thereby, it is in our interest to further

increase the complexity, which we did my adding an

explainability component to the posed task.

Oftentimes, machine learning models are black

box models which compute the results without

https://orcid.org/0000-0001-9957-1003

https://orcid.org/0000-0003-4662-7055

https://orcid.org/0000-0002-4388-8914

explaining how the results were computed. These

black box models are difficult to interpret making it

very hard to understand the reason behind the

outcome. In order to make it more interpretable, the

features of the model can be exploited to provide

basic explanations to at least somewhat open the

black box. This helps to verify the outcome if the

model works correctly and helps in gaining more trust

from the user.

In our proposed system, we try to improve the

trust and fairness of the retrieval system by providing

valid explanations on how results are retrieved. We

try to transfer the system into a white box system by

providing necessary explanation and analyse how the

system performance can be improved using such

explanations. We follow test driven development

during each phase of the development cycle, and we

develop the system as microservice architecture so

that the components are loosely coupled and largely

scalable.

The publication is structured as follows.

Succeeding this introduction, the test driven

development approach is described. Afterwards, the

general design of the prototypical application is

outlined. This is followed by a section dedicated to

104

Staegemann, D., Sudhakaran, S., Daase, C. and Turowski, K.

Exploring the Test Driven Development of an Information Retrieval System.

DOI: 10.5220/0012147700003552

In Proceedings of the 20th International Conference on Smart Business Technologies (ICSBT 2023), pages 104-113

ISBN: 978-989-758-667-5; ISSN: 2184-772X

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

the actual implementation. Then, the findings are

discussed. Finally, a conclusion of the work is given.

2 TEST DRIVEN DEVELOPMENT

When consulting the scientific literature (Staegemann

et al. 2021), the application of TDD is highlighted as

a promising way to improve the quality of an

implementation as long as the associated increase in

development time and effort is considered an

acceptable trade-off.

In general, the approach aims at improving the

quality of the product under consideration by mainly

influencing two aspects. It aims to increase test

coverage, which helps to find and subsequently fix

problems that occurred during the implementation of

the artifact under consideration. Further, TDD also

influences the design process itself by leading to a

more manageable and pre-planned structure that

helps to avoid errors and incompatibilities (Crispin

2006; Shull et al. 2010). The main application area is

software development, but process modelling (Slaats

et al. 2018), the special case of BD application

implementation (Staegemann et al. 2020), and

ontology development (Davies et al. 2019; Keet and

Ławrynowicz 2016) can also be found in the literature.

In "traditional" software development, a function

or change to be realized is implemented and then

tested. In contrast, the test-driven approach reverses

the order of implementation and testing. That is, after

the desired change is designed, it is broken down into

its smallest meaningful parts (Fucci et al. 2017). For

these, one or more tests are written to ensure that the

required functionality is provided. Then the tests are

run, and are expected to fail because the actual

functionality is not yet implemented (Beck 2015).

Only then is the production code written to provide

the new functionality. Factors such as the elegance of

the code are not yet considered; instead, the simplest

solution is sought. Once the code is created, it must

pass the previously written tests (Crispin 2006). If it

is successful, the code is revised to improve aspects

such as readability or compliance with standards and

best practices (Beck 2015). In this process, its

functionality is constantly validated against the tests.

However, this approach not only affects test

coverage, but also the design of the software, since

small work packages are generated instead of large

tasks. In addition, this focus on incremental changes

(Williams et al. 2003), where testing and

implementation are interwoven, provides more timely

feedback to the developer by creating short test cycles

(Janzen and Saiedian 2005). Although most tests are

written specifically for these small units, other tests

such as integration, system, or acceptance tests can

also be used in TDD (Sangwan and Laplante 2006).

In addition, to fully exploit the potential of TDD

without tying up the developers' attention by forcing

them to manually execute the tests, TDD is often used

in conjunction with test automation in a continuous

integration (CI) context (Karlesky et al. 2007; Shahin

et al. 2017). Here, to ensure the latest code addition

or change does not negatively impact existing parts of

the implementation, a CI server automatically starts

and re-executes all applicable tests when a new code

commit is registered by the versioning system.

Figure 1: The implemented microservices.

Exploring the Test Driven Development of an Information Retrieval System

105

3 THE DESIGN

As suggested in (Staegemann et al. 2020), we chose

to design the application as a microservice

architecture, which is more modular and scalable

compared to a monolithic implementation (Ataei and

Staegemann 2023). Figure 1 shows all the services

that are part of our information retrieval system.

We have developed multiple services which use

their own database. For the login service, we had to

choose between relational and non-relational

databases. Since the login data of the user is

structured, we decided to implement it in the postgres

relational database. For convenience reasons, we

decided to use an on-premise database to run the

postgres database locally. We used the java

programming language and the Spring Boot

framework for development of the login microservice.

Besides that, we used the python programming

language and the flask framework for the

development of other services such as the Data

Exploration Service, the Feature Extraction Service,

and the Information Retrieval Service. In this

prototypical implementation, these services use the

computer’s internal file system for processing and

storage of documents. However, in a real-world

scenario, this would of course also be handled

through distinct databases. The information retrieval

components are developed in python as there are

plenty of libraries available as open source to use

them for various functionalities.

Benjelloun at al. (2020) did a comparative study

of different techniques used for processing data in

data heavy applications. These data processing

methods adhere to the same cycle such as the data

collection, data preparation, data input, data

processing, data output/interpretation, and data

storage. The different methods of processing data are

batch processing, stream processing, and real time

processing. The proposed system doesn’t require data

to be processed frequently in real time. Therefore, we

designed a pipeline that can process data in batches

and schedule the data to be extracted as chunks. The

data that we processed consisted of 13499 books in

varying sizes and the size of the dataset was almost

seven GB.

Although this is already a somewhat big size, it is

still a rather low scale in the context of BD. Yet, for a

prototypical scenario it should be sufficient. However,

the goal is, naturally, to showcase the suitability in a

BD scenario. Therefore, to process it, we employed a

pipeline, which we term as Combi-Pipeline, for

feature extraction. The term Combi-Pipeline refers to

the pipeline that we designed which has the

combination of data from google drive and the local

file system and merged them to feature vectors. As

shown in Figure 2, we used this Combi-Pipeline to

extract the features such as named entity recognition

and term frequency-inverse document

frequency (tf-idf) vectors. The features were

extracted by dividing the data into 14 chunks having

1000 books in each chunk except the last chunk which

has 499 books. This shall show the general possibility

to distribute the processing across multiple different

(types of) workers.

For the design and development of front-end web

pages, there are multiple frameworks such as

AngularJS, React, Marko js etc. available. The

JavaScript framework AngularJS was developed to

enhance HTML’s syntax. By using this framework,

developers may create rich internet applications more

Figure 2: The feature extraction pipeline.

ICSBT 2023 - 20th International Conference on Smart Business Technologies

106

quickly and easily. Further, AngularJS allows the

development of application as single page

applications and provides techniques for boosting

HTML, whereas many JavaScript frameworks

concentrate on enhancing the capabilities of

JavaScript itself. AngularJS enables developers to

avoid the complicated workarounds that are typically

required when attempting to construct responsive

web apps with HTML front ends by introducing

features like data-binding. Therefore, we chose

Angular JS for developing the front-end of our system.

4 THE IMPLEMENTATION

The entire retrieval system architecture is shown in

Figure 3. There are two back-end blocks and a front-

end block in our retrieval system. As mentioned

earlier, the front-end web application is developed in

Angular JS, a framework based on typescript and the

back end units are developed using python and java.

We have used Springboot (a java-based framework)

for the implementation of the login service. The user

data is persisted in the postgres database as shown.

We have used flask (a python-based framework)

for the implementation of the data exploration service,

the feature extraction service, and the information

retrieval service. As described in the previous section,

in this prototypical implementation, these services

use the local file system as the database storage. The

user communicates with the front-end web

application, which, in turn, queries from the login

service for authentication. Once the authentication is

successful, the python service for retrieval is invoked.

The services for feature exploration and

extraction were already invoked and loaded into the

file system so as to reduce the response time for each

query. The architecture is designed based on diverse

languages such as java script, java, and python for the

purpose of highlighting the possibility of mixing

different programming languages when using a

microservice architecture (Shakir et al. 2021). Further,

it also allowed to explore the test driven methodology

with different frameworks that are used by the

languages.

4.1 Login Service

We developed the service starting with writing the

tests for the functionalities involved with the service.

The login service has three major methods used

for login purposes. The getUser() method is used for

logging an existing user into the application. The user

triggers a post request with username and password

in the request payload. The addUser() method is used

for registering a new user to the application. This is a

post http request, which gets parameters such as

username, email, password, and designation. The

designation is an enum variable and it can be

“student”, “researcher” or “others”. This is tracked so

that we can perform analytic on who is searching for

what books in the future. The updataUser() method is

designed for updating the existing user information.

The user shall update their username, email,

designation and password by triggering a PUT http

request. Further, there is also a getUsers() method to

fetch all the users from the database. This is not used

currently but it can be used in the future to report

certain metrics based on the users in the system. As

we store information about the designation of users,

we shall use this to derive certain analytics such as

users tagged as "Researchers" search for a particular

book genre and users tagged as "Students" search for

particular books.

Figure 3: The architecture of the retrieval system prototype.

Exploring the Test Driven Development of an Information Retrieval System

107

The following unit test cases were derived from

our use cases of adding user, updating user, getting

user and deleting user:

 Successful addition of user into database

on correct values

 Error message on passing incorrect

username and password

 Encryption of password while inserting

into database

 Decryption of password while

authenticating users from database

 Test to check if the user is updated

correctly for the PUT http request

4.2 Data Exploration Service

The data is extracted from dataset “The book Corpus”

(Zhu et al. 2015) since there are many researches

being performed in the field of NLP using the book

corpus dataset. Bandy et al. (2021) discuss certain

limitations involved with the book corpus dataset but

also highlight how it is used in popular systems such

as Open-AIs GPT models, further emphasizing its

significance.

We have also extracted metadata of the dataset

from a GitHub account that also had the actual dataset

(soskek 2019). Note that the actual book dataset and

metadata json listed in the GitHub are fetched from

different scraped sources and so they have different

book counts and orders. While the book dataset

comprised 17869 titles, the metadata set had only

15000 entries.

Hence, we had to find the intersecting books in

the two datasets to merge the two datsets to construct

the master dataset. This is done in the

create_meta_data() method. The pick

_book_document_from_file_system method is

created because we require to choose only the books

that are available in the metadata dataset to perform

all subsequent tasks such as pre-processing and

feature extraction. To do so, we decided to go with a

simple approach. We created a new column called

“exists” in the meta data. This column determines if

the book title in the metadata exists in the books in

file system. The “exists” value is true if the book

exists in our file system or false if it does not exist in

the file system. All the book names in the file system

are scanned and the column “exists” is populated if

the book is present in the file system.

Further, as the name suggests, the save_into_csv

method saves the updated meta_data.csv into the file

system. In the service’s other methods, we modify the

existing meta data file and save the updated version

into the file system. Thereby, this service acts as a

helper method to accomplish the task of saving the

metadata into the local disk.

The data exploration service is developed in the

python programming language using the flask

framework to facilitate the microservice architecture.

We have written the tests using the unittest library in

python and we used the mock class from the same

library for mocking method calls. Before starting with

the functionalities on the data extraction and

exploration, we began with the test cases that are

listed below:

 Test if the specific directory in the local disk

is being scanned for the books and meta data

is created

 Tests asserting the size of metadata records,

number of columns, books retrieved are

verified

 Since we are excluding books which have a

number of words greater than 200000 from

the dataset (to have a more homogeneous

set), there is a test that explicitly checks if

the dataset includes any book over 200000

words

 As we have two different datasets extracted

from different sources one containing meta

data in json format and the other containing

the books as compressed files, we had to

write a test to match the metadata with the

book dataset within the directory. So, only

the books that are present in the local

directory are used for processing while the

books that only have meta data and don’t

have an actual book associated in the local

directory are ignored

All these tests were written keeping in mind that

the core functionality of the data extraction should not

be hindered, and any possibility of functional errors

must be eliminated.

4.3 Feature Extraction Service

The data that is extracted from the previous step is

passed to the feature extraction step where we derive

the features from the books and the meta data

available. The feature extraction service is developed

with the python programming language using the

flask framework. In this step, we extract the features

by converting books to tf-idf vectors and combined it

with a set of handcrafted features to yield better

results for the retrieval system. The feature extraction

pipeline can be divided into three parts with their own

functionalities. These are further described in the

following.

ICSBT 2023 - 20th International Conference on Smart Business Technologies

108

4.3.1 Extraction of Hand-Crafted Features

Such as Named Entities and NRC

Emotions

We decided on a few handcrafted features such as

Named Entities and NRC emotions for our retrieval

system.

Named Entity Recognition (NER) is an important

feature (Mansouri et al. 2008) in the text retrieval

domain as it can detect the person, place, quantity,

time etc., which is useful for retrieval systems. We

used a popular library called spaCy (spaCy 2023) for

detecting the named entities in the books. SpaCy

provides pre-trained model with set of named entities

and it recognises the tokens and predicts the named

entity for the token.

Moreover, sentiment analysis is an important

aspect of information retrieval. In our work, we have

used the NRCLex library (Bailey 2019) to detect the

emotions from the book. This library uses the

lexicons from the NRC Word-Emotion Association

Lexicon (Mohammad and Turney 2011). This library

scans the dataset for specific words and classifies the

words based on the emotions. The output of this is the

word count of emotions such as anticipation, joy, fear,

or sadness.

4.3.2 Extraction of the tf-idf Vectors from

the Books

In all the NLP tasks, the natural language should be

converted to tokens for identifying the features. In our

tokenization process, we scan through the dataset and

convert all the books as corresponding tokens. The

nltk library (NLTK Project 2023) in python is used

for creating tokens out of the books. Thus, we

tokenize the entire document corpus using the library.

In our approach we used tf-idf to convert the

books to vectors using the python based library

sklearn (scikit-learn 2023). In order to perform tf-idf

vectorization using sklearn, we passed the optional

parameter max_features to the method

TfidfVectorizer in the library.

Further, we have filtered the stop words occurring

in the documents. We have set a maximum features

limit of 300000 so as to include only the first 300000

features with the highest weightage. Therefore, after

the tokenization step, the tokens are moved to the stop

word removal where we remove stop words from the

tokens. Then we perform stemming where words with

the same stem are grouped into one word and finally,

we perform the tf-idf vectorization on the remaining

words. After the vectorization we collect the features

in a pandas dataframe data structure and store it into

a csv file in the file system.

4.3.3 Principal Component Analysis and

Feature Combination

After the steps described above, it is necessary to

group all features that we constructed into a single file

so that it becomes easy for processing. It is important

to perform principal component analysis (PCA) on

the tf-idf features so to reduce the error caused by a

high dimensionality. We also merged all the meta

data with the PCA features and performed label

encoding to our feature set.

In (Korenius et al. 2007), the authors explain how

the search space can be reduced for text retrieval

systems using PCA. They also establish the relation

between cosine measure and the euclidean distance in

association with PCA. Performing PCA on the entire

dataset was challenging as we could not fit the entire

feature space in the main memory for processing.

Additionally, when considering that this is only a

prototypical implementation geared towards BD

applications, this issue would be even bigger on larger

scale. In response, we tried out multiple approaches

to perform PCA. The first approach is to split the data

into chunks and perform PCA. The chunk size was set

to 1000 books and after computing PCA for all the

books, we combined the PCA vectors. As we are

performing TDD, we started by writing the test for

this approach. However, when running it, we

identified that the results are not identical and so we

cannot proceed chunking books for PCA as it yields

incorrect results.

Another approach is discussed in (Bai et al. 2014).

Here, the authors propose an incremental learning for

a robust visual tracking systems which performs the

PCA in an incremental way without the results being

impacted. We used the method IncrementalPCA in

the sklearn library (scikit-learn 2023) to perform PCA

for the books dataset so that we arrive at the correct

values for PCA.

The reason why we highlight the first (failed)

attempt is to emphasize that the test driven approach

helped in arriving at the correct method and yielding

correct results when performing PCA. This was one

such instance where TDD helped to detect the flaws

in the methods chosen for the development of our

retrieval system. After performing PCA, we have

reduced the multi-dimensional feature space into a

three-dimensional space and thus reduced 300000

terms (features) to three features.

After effectively performing the PCA on the tf-idf

features and reducing the dimensions, our PCA

features were ready to be integrated with the other

features. To do so, we merged the PCA features with

NER features, NRC emotions, and the meta data to

construct the final feature set. This feature set consists

Exploring the Test Driven Development of an Information Retrieval System

109

Figure 4: Operational sequence of the information retrieval service.

of 37 features. These features had to be further taken

for encoding as the text features should be converted

to numbers.

The retrieval system that we developed works on

similarity metric (cosine similarity) to find the

similarity between the data points (books). In order to

compute similarity, it was necessary to convert all the

text to numbers. We have features such as authors,

category1 (genre 1), category2 (genre 2) and

category3 (genre 3), which are text-based features.

The number of unique authors in the dataset found is

8283. The category1 feature consist of two unique

categories which are fiction or non-fiction. The

category2 feature consist of 63 unique categories

whereas the category3 feature consist of 889 unique

categories. Thus, these features are converted to

numbers using label encoders in the sklearn library

(scikit-learn 2023).

4.4 Information Retrieval Service

The Information retrieval service is the user facing

service where the user interacts with the system and

searches for the required books. As the name suggests,

this service retrieves the books matching to the query

book provided by the user. Its operational sequence is

depicted in Figure 4.

In (Ristanti et al. 2019), the authors describe how

the cosine similarity measure was used to detect

similarity in documents and evaluate the performance

after applying K-fold validations. As explained in the

paper, we have also used the cosine similarity

measure, mainly because it is not affected by length

of the document and thus yields a better result for

identifying the document similarity.

This functionality was written in python and we

used the sklearn library (scikit-learn 2023) to detect

the cosine similarity. When the user queries for a

book, the information retrieval service computes the

cosine similarity between the query vector and all the

feature vectors in the database and computes the

result, which is the cosine similarity of the query with

all the other books in the document corpus.

After finding the similarity score for all the

documents with the query vector, it is important to

retrieve the top similar books and return them to the

user. To retrieve only the top n books, where n is set

to 10 from the list of all the books in the corpus, we

created the get_top_n_neighbour method. It identifies

only the top 10 retrieved books, which are similar to

the query books and acts as a utility method, which

can be used by other services.

Before writing the code, we started with the test

scenarios, which ensured that the functionality of the

service was complete. In the test, we are passing a test

dataframe whose similarity values are already known,

and assertions are performed to test if the retrieved

similarity rankings are correct. This test was useful

because we figured out from the test that the

cosine_similarity() method from the sklearn library

(scikit-learn 2023) returns similarity scores in

ascending order. Consequently, we modified our code

so that it returns the similarity in descending order,

which means that the books with highest similarity

score should be fetched first.

4.5 Explanation Service

The explanation service is a user facing service,

meaning it consists of a front-end user interface,

which would be exposed to the user on click of a

button that explains why the query book matches with

the selected book. Explainability in NLP systems has

been explored in various researches to open the black

box layer and provide the interpretability to the users.

In (Zini and Awad 2023), a survey on the

explainability of deep models is presented and the

authors decompose the explainability methods into

three categories such as word embeddings, inner

working of NLP models, and model’s decision. Out

of these aspects, we provide explanation that focusses

only on the inner working of the model. Further, in

(Danilevsky et al. 2020), the authors present a survey

on explanations in NLP systems, discussing the types

of explanations. The paper also talks about the self-

explanations generated by the models and post-hoc

explanations provided by generating explanations as

post processing techniques after prediction. In our

prototype, we focussed on two major kinds

of explanation which are generated as post-hoc

ICSBT 2023 - 20th International Conference on Smart Business Technologies

110

Figure 5: Local explanation template.

explanations. While they might not exhaustively

explain the exact position of a retrieved item in the

ranking, they at least help the user to get somewhat of

an idea on the reasoning behind the assessment,

allowing them to evaluate the reasonability and

suitability for their purpose.

4.5.1 Global Explanation

The global explanation explains the retrieval system

on the whole by giving an explanation to the user to

understand the factors behind retrieving the results by

the system.

It helps the user in understanding the assessment

on a high level. This explanation is written in the

frontend side of the application where the features on

which the retrieval system works are displayed to the

user. We used the AngularJS framework, which is

based on typescript to design and develop the front-

end of the application. We explain that the major

features considered while retrieving are content of

books, meta data information such as author, genre,

named entities, and emotions of the contents.

4.5.2 Local Explanation

The local explanation is a backend service written in

the python flask framework. When the user clicks on

the corresponding button in the web page, it invokes

the local explanation functionality. It checks the

similarity and constructs the explanation in a specific

syntax and returns the explanation as a json response.

As shown in Figure 5, we constructed the

explanation telling the user about the primary and

secondary genre of the book. We also provide

explanation about the author of the book and the most

occurring named entities in the book.

5 DISCUSSION

Even though the created prototype in its current scale

is not necessarily a BD application, it still serves as a

demonstration of the utility of TDD for the

implementation of data intensive systems. This is

because it is implemented test driven and shows the

processing of heterogeneous data from different

sources in a distributed manner, which are then fused

for further utilization. Hence, for a real-world

application, it could be scaled up, still using the same

principles that were applied here.

While the prototype delivers satisfying results as

determined during manual system testing, showing

that the followed approach was generally suitable, the

use of TDD also explicitly benefitted the

development in several ways. For once, it helped to

detect and avoid errors during the code writing and

helped to install confidence in the created code.

Further, it helped to shape the design not only by

breaking the functionality down, but also by showing

that a considered problem solving approach did not

deliver the desired results and an alternative had to be

found (cf. section 4.3.3). On top of that, it also

allowed to save some time in one instance by helping

to figure out the specificities of a utilized function

without the need to consult the documentation (cf.

section 4.4).

Thereby, the application of TDD based on

microservices showed its worth for the

implementation of data intensive systems by

benefiting the development process. Hence, it

generally seems reasonable to apply it also on large

scale projects, at least if they are heavily relying on a

high quality, and also to further explore the approach

in the future.

6 CONCLUSION

While TDD is generally not a new approach, it is still

somewhat underexplored in the context of data

intensive systems. Yet, with their growing influence

on today’s society, assuring their quality becomes

increasingly important. To bridge this gap, in the

publication at hand, the test driven implementation of

an information retrieval system was demonstrated

and discussed. This is done on the basis of

Exploring the Test Driven Development of an Information Retrieval System

111

microservices, making use of the architecture’s

property that varying programming languages and

frameworks can be mixed to use the most favourable

combination. Further, while the implemented

application is only a prototype, it already comprises

elements of distributed processing, which would

allow for further upscaling. However, already on this

size, indications for its feasibility and usefulness

could be determined.

To gain further insights on the applicability of the

approach as well as its strengths, weaknesses,

challenges, and opportunities, in the future, additional

data intensive applications of varying scales should

be implemented in a test driven manner. Moreover,

the knowledge and opinions of experienced

practitioners should be gathered through expert

interviews, to be able to also incorporate the industry

perspective on the proposed approach and its

application in a real-world scenario.

REFERENCES

Ataei, P., and Staegemann, D. (2023). “Application of

microservices patterns to big data systems,” Journal of

Big Data (10:1) (doi: 10.1186/s40537-023-00733-4).

Bai, S., Liu, R., Su, Z., Zhang, C., and Jin, W. (2014).

“Incremental robust local dictionary learning for visual

tracking,” in 2014 IEEE International Conference on

Multimedia and Expo (ICME), Chengdu, China.

14.07.2014 - 18.07.2014, IEEE, pp. 1-6 (doi:

10.1109/ICME.2014.6890262).

Bailey, M. M. (2019). “NRCLex 4.0,” available at

https://pypi.org/project/NRCLex/, accessed on May 3

2023.

Bandy, J., and Vincent, N. (2021). “Addressing

"Documentation Debt" in Machine Learning Research:

A Retrospective Datasheet for BookCorpus,”

Beck, K. (2015). Test-Driven Development: By Example,

Boston: Addison-Wesley.

Benjelloun, S., Aissi, M. E. M. E., Loukili, Y., Lakhrissi,

Y., Ali, S. E. B., Chougrad, H., and Boushaki, A. E.

(2020). “Big Data Processing: Batch-based processing

and stream-based processing,” in 2020 Fourth

International Conference On Intelligent Computing in

Data Sciences (ICDS), Fez, Morocco. 21.10.2020 -

23.10.2020, IEEE, pp. 1-6 (doi:

10.1109/ICDS50568.2020.9268684).

Crispin, L. (2006). “Driving Software Quality: How Test-

Driven Development Impacts Software Quality,” IEEE

Software (23:6), pp. 70-71 (doi:

10.1109/MS.2006.157).

Daase, C., Staegemann, D., Volk, M., and Turowski, K.

(2023). “Creation of a Framework and a Corresponding

Tool Enabling the Test-Driven Development of

Microservices,” Journal of Software, pp. 55-69 (doi:

10.17706/jsw.18.2.55-69).

Danilevsky, M., Qian, K., Aharonov, R., Katsis, Y., Kawas,

B., and Sen, P. (2020). “A Survey of the State of

Explainable AI for Natural Language Processing,” (doi:

10.48550/arXiv.2010.00711).

Davies, K., Keet, C. M., and Lawrynowicz, A. (2019).

“More Effective Ontology Authoring with Test-Driven

Development and the TDDonto2 Tool,” International

Journal on Artificial Intelligence Tools (28:7) (doi:

10.1142/S0218213019500234).

Fucci, D., Erdogmus, H., Turhan, B., Oivo, M., and Juristo,

N. (2017). “A Dissection of the Test-Driven

Development Process: Does It Really Matter to Test-

First or to Test-Last?” IEEE Transactions on Software

Engineering (43:7), pp. 597-614 (doi:

10.1109/tse.2016.2616877).

Janzen, D., and Saiedian, H. (2005). “Test-driven

development concepts, taxonomy, and future

direction,” Computer (38:9), pp. 43-50 (doi:

10.1109/MC.2005.314).

Karlesky, M., Williams, G., Bereza, W., and Fletcher, M.

(2007). “Mocking the Embedded World: Test-Driven

Development, Continuous Integration, and Design

Patterns,” in Embedded Systems Conference, San Jose,

California, USA. 01.04.2007 - 05.04.2007, UBM

Electronics.

Keet, C. M., and Ławrynowicz, A. (2016). “Test-Driven

Development of Ontologies,” in The Semantic Web.

Latest Advances and New Domains, H. Sack, E.

Blomqvist, M. d'Aquin, C. Ghidini, S. P. Ponzetto and

C. Lange (eds.), Cham: Springer International

Publishing, pp. 642-657 (doi: 10.1007/978-3-319-

34129-3_39).

Korenius, T., Laurikkala, J., and Juhola, M. (2007). “On

principal component analysis, cosine and Euclidean

measures in information retrieval,” Information

Sciences (177:22), pp. 4893-4905 (doi: 10.1016/

j.ins.2007.05.027).

Mansouri, A., Affendey, L. S., and Mamat, A. (2008).

“Named entity recognition approaches,” International

Journal of Computer Science and Network Security

(8:2), pp. 339-344.

Mohammad, S. M., and Turney, P. (2011). “NRC Word-

Emotion Association Lexicon,” available at

http://saifmohammad.com/WebPages/NRC-Emotion-

Lexicon.htm, accessed on May 3 2023.

NLTK Project. (2023). “Natural Language Toolkit,”

available at https://www.nltk.org/, accessed on May 3

2023.

Ristanti, P. Y., Wibawa, A. P., and Pujianto, U. (2019).

“Cosine Similarity for Title and Abstract of Economic

Journal Classification,” in 2019 5th International

Conference on Science in Information Technology

(ICSITech), Yogyakarta, Indonesia. 23.10.2019 -

24.10.2019, IEEE, pp. 123-127 (doi: 10.1109/

ICSITech46713.2019.8987547).

Sangwan, R. S., and Laplante, P. A. (2006). “Test-Driven

Development in Large Projects,” IT Professional (8:5),

pp. 25-29 (doi: 10.1109/MITP.2006.122).

ICSBT 2023 - 20th International Conference on Smart Business Technologies

112

scikit-learn. (2023). “scikit-learn Machine Learning in

Python,” available at https://scikit-learn.org/stable/,

accessed on May 3 2023.

Shahin, M., Ali Babar, M., and Zhu, L. (2017). “Continuous

Integration, Delivery and Deployment: A Systematic

Review on Approaches, Tools, Challenges and

Practices,” IEEE Access (5), pp. 3909-3943 (doi:

10.1109/ACCESS.2017.2685629).

Shakir, A., Staegemann, D., Volk, M., Jamous, N., and

Turowski, K. (2021). “Towards a Concept for Building

a Big Data Architecture with Microservices,” in

Proceedings of the 24th International Conference on

Business Information Systems, Hannover,

Germany/virtual. 14.06.2021 - 17.06.2021, pp. 83-94

(doi: 10.52825/bis.v1i.67).

Shull, F., Melnik, G., Turhan, B., Layman, L., Diep, M.,

and Erdogmus, H. (2010). “What Do We Know about

Test-Driven Development?” IEEE Software (27:6), pp.

16-19 (doi: 10.1109/MS.2010.152).

Slaats, T., Debois, S., and Hildebrandt, T. (2018). “Open to

Change: A Theory for Iterative Test-Driven

Modelling,” in Business Process Management, M.

Weske, M. Montali, I. Weber and J. Vom Brocke (eds.),

Cham: Springer International Publishing, pp. 31-47

(doi: 10.1007/978-3-319-98648-7_3).

soskek. (2019). “bookcorpus,” available at

https://github.com/soskek/bookcorpus, accessed on

May 3 2023.

spaCy. (2023). “Industrial-Strength Natural Language

Processing,” available at https://spacy.io/, accessed on

May 3 2023.

Staegemann, D., Volk, M., Byahatti, P., Italiya, N.,

Shantharam, S., Chandrashekar, A., and Turowski, K.

(2022a). “Implementing Test Driven Development in

the Big Data Domain: A Movie Recommendation

System as an Exemplary Case,” in Proceedings of the

7th International Conference on Internet of Things, Big

Data and Security, Online Streaming, --- Select a

Country ---. 22.04.2022 - 24.04.2022, SCITEPRESS -

Science and Technology Publications, pp. 239-248

(doi: 10.5220/0011085600003194).

Staegemann, D., Volk, M., Jamous, N., and Turowski, K.

(2020). “Exploring the Applicability of Test Driven

Development in the Big Data Domain,” in Proceedings

of the 31st Australasian Conference on Information

Systems (ACIS), Wellington, New Zealand.

01.12.2020 - 04.12.2020.

Staegemann, D., Volk, M., Lautenschläger, E., Pohl, M.,

Abdallah, M., and Turowski, K. (2021). “Applying Test

Driven Development in the Big Data Domain – Lessons

From the Literature,” in Proceedings of the 2021

International Conference on Information Technology

(ICIT), Amman, Jordan. 14.07.2021 - 15.07.2021,

IEEE, pp. 511-516 (doi: 10.1109/ICIT52682.

2021.9491728).

Staegemann, D., Volk, M., Perera, M., and Turowski, K.

(2022b). “Exploring the Test Driven Development of a

Fraud Detection Application using the Google Cloud

Platform,” in Proceedings of the 14th International

Joint Conference on Knowledge Discovery,

Knowledge Engineering and Knowledge Management,

Valletta, Malta. 24.10.2022 - 26.10.2022,

SCITEPRESS - Science and Technology Publications,

pp. 83-94 (doi: 10.5220/0011559000003335).

Volk, M., Staegemann, D., Trifonova, I., Bosse, S., and

Turowski, K. (2020). “Identifying Similarities of Big

Data Projects–A Use Case Driven Approach,” IEEE

Access (8), pp. 186599-186619 (doi: 10.1109/

ACCESS.2020.3028127).

Williams, L., Maximilien, E. M., and Vouk, M. (2003).

“Test-driven development as a defect-reduction

practice,” in Proceedings of the 14th ISSRE, Denver,

Colorado, USA. 17.11.2003 - 20.11.2003, IEEE, pp.

34-45 (doi: 10.1109/ISSRE.2003.1251029).

Zhu, Y., Kiros, R., Zemel, R., Salakhutdinov, R., Urtasun,

R., Torralba, A., and Fidler, S. (2015). “Aligning Books

and Movies: Towards Story-Like Visual Explanations

by Watching Movies and Reading Books,” in 2015

IEEE International Conference on Computer Vision

(ICCV), Santiago, Chile. 07.12.2015 - 13.12.2015,

IEEE, pp. 19-27 (doi: 10.1109/ICCV.2015.11).

Zini, J. E., and Awad, M. (2023). “On the Explainability of

Natural Language Processing Deep Models,” ACM

Computing Surveys (55:5), pp. 1-31 (doi:

10.1145/3529755).

Exploring the Test Driven Development of an Information Retrieval System

113
