Quality Measurement of Functional Requirements

David

Senk

and Petr Kroha

Faculty of Information Technology, Czech Technical University in Prague, Th

akurova 9, Prague, Czech Republic

Keywords:

Textual Functional Requirements Speciﬁcation, Text Processing, Text Mining, Domain Model, Ambiguity,

Incompleteness, Inconsistency, Quality Measurement.

Abstract:

In this contribution, we propose a metric to measure the quality of textual functional requirements speciﬁ-

cations. Since the main problem of such requirements speciﬁcations is their ambiguity, incompleteness, and

inconsistency, we developed textual patterns to reveal shortcomings in these properties. As a component of

our analysis, we use not only the text of the requirements but also the UML model that we construct during the

text analysis. Combining the results of part-of-speech tagging of the text and the modeled properties, we are

able to identify a number of irregularities concerning the properties named above. Then, the text needs human

intervention to correct or remove the suspicious formulations. As a measure of the requirements speciﬁcation

quality, we denote the number of necessary human interventions. We implemented a tool called TEMOS that

can test ambiguity, incompleteness, and inconsistency, and we use its results to evaluate the quality of textual

requirements. In this paper, we summarize our project results.

1 INTRODUCTION

The idea of requirements speciﬁcation is not new.

The famous Italian painter Raffael (1483–1520)

produced his paintings to the orders of wealthy

customers. They wanted to know in advance what

they would pay for. Rafael described the picture in

words, for example, “In the oil painting on canvas

with dimensions according to the His Highness’s

wishes, there will be His Highness like a knight

in armor on a white horse with a sword and spear

ﬁghting a dragon” and added a sketch (drawing) of

the painting. The customer could opt, for example,

for a black horse and a helmet with a plume. Then

they wrote a contract, and the image had to match its

content. After ﬁve hundred years, we follow (more

or less) the same practice in software engineering

projects. The description of the software product to

be constructed is called requirements speciﬁcation.

There are two viewpoints on the quality of a soft-

ware product. It has to satisfy the requirements spec-

iﬁcation, and it has to state and imply the needs of all

stakeholders. The problem is that the requirements

speciﬁcation usually does not reﬂect the needs of the

stakeholders completely. Many stakeholders cannot

articulate the requirements or do not even know what

https://orcid.org/0000-0002-7522-3722

https://orcid.org/0000-0002-1658-3736

they want. The second reason is that the analysts,

who should help them, often do not deeply understand

the semantics of the application domain (e.g., molecu-

lar biology). So, mistakes are practically guaranteed.

For these reasons, it is worth investing effort into for-

mulations of textual requirements before the analysis

starts. Another point of view is the software product

maintenance that is the most costly part of the whole

project. It is very difﬁcult to include all corrections,

enhancements, and upgrades of the requirements into

existing textual requirements speciﬁcation.

Textual formulated requirements speciﬁcations

are necessary as a base of communication between

the customer, the user, the domain expert, and the an-

alyst. It has one main advantage – it is understandable

for all of them. In the event of a lawsuit between the

company and the customer, the judge has a facilitated

role because he understands the assignment and can

assess whether the product meets the assignment.

Unfortunately, any text suffers from ambiguity,

incompleteness, and inconsistency – in our project

TEMOS, we focused on checking them. In Section 3,

we deﬁne a quality measure that can be used not only

in the ﬁrst phase of the software development but also

during the maintenance for checking the new versions

of updated requirements speciﬁcations.

Mainly, the inspection is used to check the quality

of requirements. Experienced people remove some

736

aenkÃ¡Å

Z, D. and Kroha, P.

Quality Measurement of Functional Requirements.

DOI: 10.5220/0012148700003538

In Proceedings of the 18th International Conference on Software Technologies (ICSOFT 2023), pages 736-743

ISBN: 978-989-758-665-1; ISSN: 2184-2833

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

of the problems in requirements, but some of the

shortcomings remain. Some deﬁciencies are cleared

and corrected or removed gradually during the

program development in the following development

steps. Some of them are discovered during testing,

and some others are revealed after release by the

customer. Mistakes made but not corrected during

the ﬁrst phase of the cycle migrate then to other

phases. This fact results in a costly process because

all corrections cause costs that increase multiplicative

with the later discovery and correction of the bugs.

It is known that manual approaches that rely on

human intelligence and the application of inspection

checklists do not scale to large speciﬁcations (Dalpiaz

et al., 2018). Therefore, we try to detect errors in the

requirements speciﬁcation during the requirements

deﬁnition process. We provide defect density, i.e., we

count the number of detected places in formulations

that may have the meanings of a defect. A human

intervention makes the decision. In this contribution,

we deﬁned the quality metrics we developed and used

in the requirements’ quality improvement process. To

support it, we summarized our methods for check-

ing ambiguity, incompleteness, and inconsistency of

textual functional requirements speciﬁcations imple-

mented in our tool TEMOS.

2 RELATED WORK

Quality in software development on all levels is

a topic discussed for many years, and it has been

included into ISO standards, e.g., ISO/IEC/IEEE

29148:2011. Quality of requirements is a speciﬁc part

of it. It is a well-established concept that is described

in many papers, e.g., (Davis et al., 1993), (Fabbrini

et al., 2001), (Nordin et al., 2017). In (Loucopoulos

and Karakostas, 1995), the requirements engineering

is described as an iterative co-operating process of im-

provements in the understanding gained. The survey

is given in (Kocerka et al., 2018). In (Davis et al.,

1993), the authors list 24 qualities of requirements.

Most of them are qualitative; they can only be judged

and not measured. Because of that, we selected only

three of them – ambiguity, incompleteness, and incon-

sistency.

We used a mapping between requirements speci-

ﬁcation and a UML class model for plain English in

our paper (

Senk

r and Kroha, 2018). In (Bugayenko,

2021), the author uses a similar concept for “con-

trolled” English.

In (Femmer et al., 2017), the authors classify 166

rules for requirements and estimate that 53 % of them

can be checked automatically with good heuristics.

They investigate the problem what cannot be checked

automatically in requirements. We do not exclude hu-

man intervention because we think that the semantics

may be very complex and that the mistakes caused

by automated checking may be very expensive. In

(Medeiros et al., 2016), requirements of agile projects

are investigated.

In (Nordin et al., 2017), a study of practice is

given, and it is stressed that the quality problems of

requirements are an important topic. The quality eval-

uation is done manually during review sessions in

(Saito et al., 2013). A survey of methods is given

in (Kummler et al., 2018). The inspection is also de-

scribed in (Takoshima and Aoyama, 2015).

It is known that most defects indicated in deliv-

ered software products are based on deﬁcient require-

ments understanding (G

enova et al., 2013). A com-

plexity measure for textual requirements is described

in (Antinyan et al., 2016). The measure indicates the

amount of actions (and actors) and their relations in

requirements. We do not investigate correctness like

in (Feng et al., 2021). A semantic representation of

functional requirements is investigated using methods

of information retrieval in (Sonbol et al., 2020).

In (Wilson et al., 1997), the quality of textual re-

quirements is measured using weak phrases, the size

of text, text structure, hierarchical levels, and read-

ability statistics. A similar approach is given in (Berry

et al., 2006).

In (B

aumer and Geierhos, 2018), the authors

developed methods of detecting quality violations in

a requirements speciﬁcation called linguistic triggers.

Besides the problem of incompleteness, there is

also presented an approach of ambiguity detection.

First, the detection via predicate argument analysis

in which a semantic role labeler assigns semantic

roles such as agent, theme, and beneﬁciary to the

recognized predicate. Presented illustrating example

is the verb “send” that is a three-place predicate

because it requires the agent (sender), the theme

(sent) and the beneﬁciary argument (sent-to). If

the beneﬁciary is not speciﬁed here, it is unknown

whether one or more recipients are possible. The

second step is compensation. Using the similarity

search component known from the information

retrieval (IR) domain, they try to ﬁnd the potentially

missing part sent-to based on software descriptions

gathered from one software-to-download portal.

Patterns belong to the standard technology of text

mining, e.g., (Bhatia et al., 2013). In (Eckhardt et al.,

2016), sentence patterns have been used but for per-

formance requirements, not for functional require-

ments like in our tool, and their sentence patterns

are completely different from our sentence patterns.

Quality Measurement of Functional Requirements

737

Using NLP for requirements engineering is analyzed,

e.g., in (Dalpiaz et al., 2018), (Zhao et al., 2021), (Fer-

rari et al., 2021). Building models from requirements

is used for example in (Robeer et al., 2016). Differ-

ently to our approach, they do not use it to analyze

requirements.

Ambiguity is deﬁned in (Davis et al., 1993) as

the percentage of requirements that have been inter-

preted in a unique manner by all its human review-

ers. There are many papers about automated construc-

tion of glossaries, e.g., (Arora et al., 2017), (Gemkow

et al., 2018), (Ezzini et al., 2021). In (Kose and Ay-

demir, 2021), a method is proposed to automatically

extract a glossary from a set of models. We derived a

glossary from the text of requirements. Ambiguity of

words is investigated in (Gleich et al., 2010), (Arora

et al., 2017), and (Kose and Aydemir, 2021). We ad-

ditionally investigate the ambiguity of sentences (Sec-

tion 3.1).

In (Dalpiaz et al., 2018), the authors explore po-

tential ambiguity and incompleteness based on the

terminology used in different viewpoints. They com-

bine possibilities of NLP technology with information

visualization. Their approach is completely different

from our approach.

Two incompleteness metrics of input documents

of the requirements speciﬁcations are described in

(Ferrari et al., 2014). The second one – the back-

wards functional completeness that the paper focuses

on – refers to the completeness of a functional re-

quirements speciﬁcation with respect to the input doc-

uments. Contrary to this approach, we do not mea-

sure the incompleteness using metrics and quantiﬁed

results, even though it is a good idea.

In (Li, 2015), a meta-model approach is used to

detect the missing information in a conceptual model.

It is also an approach of the class forward functional

completeness but at the level of a conceptual model.

3 OUR APPROACH TO QUALITY

OF REQUIREMENTS

We developed our tool TEMOS to test whether there

are some problems of ambiguity, incompleteness, and

inconsistency in the requirements under considera-

tion. Then we found that we can use it to measure

the quality of the requirements as a “side effect”.

Our approach is based on a concept that is well-

known in traditional publishing houses. During the

editing process of manuscripts, all editor’s corrections

can be qualiﬁed, collected and evaluated to the quality

of the manuscript. We used the same method.

Each positive test (i.e., a test revealing a potential

problem) is evaluated, and the value becomes part

of the quantitative description using metrics. The

best quality (zero problems) is achieved when our

algorithms do not ﬁnd any suspicious formulations in

the sense of ambiguity, incompleteness, and inconsis-

tency. While checking, our system TEMOS always

generates warning messages when it reveals some

suspicious irregularities. We have deﬁned the quality

metrics of functional requirements as the value

computed from the numbers of the generated warning

messages. For clarity, it is structured according to the

topics (ambiguity, incompleteness, inconsistency).

In some topics, we can compute the relative quality,

which is the number of the generated warning

messages related to the number of sentences in the re-

quirements. The proposed quality measure formula is

Q-Req = w

· AW + w

· AS + w

· ISen

+ w

· ISc + w

·CGS + w

· DSR

where variables w

are weights that can be individu-

ally set. It uses the following components. Ambi-

guity: AW – the number of ambiguous words found,

AS – the number of ambiguous sentences found. In-

completeness: ISen – the number of incomplete sen-

tences found, ISc – the number of incomplete scenar-

ios found. Inconsistency: CGS – the number of con-

tradictions in groups of sentences, DSR – the number

of necessary enrichments in the sense of the default

consistency rules.

As we already mentioned in Section 1, our qual-

ity measurement can be (and should be) used during

the maintenance to master all the inserted corrections,

enhancements, and upgrades of the requirements into

existing textual requirements speciﬁcation.

Below, in separate sections, we present topics con-

nected to each problem area mentioned in Section 1 –

ambiguity, incompleteness, and inconsistency. Due to

the scope of this paper, it is not our goal to recall here

all details, so we only brieﬂy mention the problems

we solved in our previous work and we refer to our

previous papers.

3.1 Problem of Ambiguity

We investigate the problem of ambiguity in our paper

(

Senk

r and Kroha, 2019a). In our metric, we include

the following.

The number of ambiguous words (AW ). Ambigu-

ity arises whenever a word or an expression can be in-

terpreted in more that one way; the reason is that nat-

ural languages use: homonyms, i.e., words which are

spelled alike but have different meanings, synonyms,

i.e., different words that have the same meaning.

The number of ambiguous sentences (AS). Re-

garding the sentences, we can focus on:

ICSOFT 2023 - 18th International Conference on Software Technologies

738

• syntactic methods – to check a different meaning

that depends on the position in the parsing tree

of a sentence (example: “The button next to the

warning box with the red border. . . ” – Does the

button have the red border? Or does the warning

box have the red border?),

• semantic methods – the semantic meaning in-

cludes coreferences and a model created dur-

ing requirements processing or a model imported

from an external ontology source; for example,

the model of sentences “Our delivery contains

product XYZ-123 in container X-50. Its weight is

50 kg.” can contain classes delivery, product,

and container and all these classes can have the

attribute weight.

3.2 Problem of Incompleteness

We investigate the problem of incompleteness in our

papers (

Senk

r and Kroha, 2019b) and (

Senk

r and

Kroha, 2020). In our metric, we include the follow-

ing.

The number of incomplete sentences (ISen). On

the level of a sentence, we can check the usual usage

of words – in the sense that we expect usual text frag-

ments – for example, we deﬁne a common noun and

preposition collocation set – if the kind of usage in the

textual requirements (e.g., a list) does not correspond

to the kind of usage in the vocabulary (e.g., a list of)

then a warning is counted; acronyms deﬁnition – all

acronyms should be deﬁned (in an attached vocabu-

lary); semantic model (as mentioned in the previous

section) – here, we can check described actions, i.e.,

verbs in sentences of queries are investigated in the

sense whether the action that they describe, can be

performed in the existing model (e.g., sorting without

a key).

The number of incomplete scenarios (ISc). For

recognized enumerations (e.g., of attribute values),

we can check if the recognized scenarios cover all

known values of the speciﬁc enumeration. We can

also check the generated class model extracted from

the requirements – warnings can be counted when we

notice “empty” classes without attributes or classes

without relation to any other class.

3.3 Problem of Inconsistency

We investigate the problem of incompleteness in our

papers (

Senk

r and Kroha, 2021), (

Senk

r and Kroha,

2021a), and (

Senk

r and Kroha, 2021b). In our met-

ric, we include the following.

The number of contradictions in groups of sen-

tences (CGS). The linguistic sources of the inconsis-

tency include using antonyms, a negation, or a com-

bination of synonyms together with changed roles of

subject and object, passive voice, and negation, e.g.,

“the user can edit a document” contra “the user can-

not correct a document in this mode” (here, we sup-

pose that the verbs “to edit” and “to correct” have

the same meaning) contra “a document cannot be cor-

rected by the user”. Using numerically different data,

e.g., “you will start the function by double click”

contra “you will start the function by one click”. Us-

ing factive contradiction in the sense of attributes of

the subject. Using lexical contradiction, e.g., “to ob-

tain results stay joined and wait” contra “to obtain re-

sults restart the application” contra “to obtain results

restart the system”. Using world knowledge to indi-

cate the contradiction, e.g., “there is public access to

your private data”.

Additionally, some words may change, inﬂuence,

or limit the sense of the sentence, e.g., but, except,

however, instead of, when, so that, that.

The number of necessary enrichments in the sense

of the default consistency rules (DSR). In our pa-

per (

Senk

r and Kroha, 2021b), we deﬁne the de-

fault consistency rules as the omitted part of the tex-

tual requirements that we can try to extend by pro-

cessing sentences from external sources. For that

purpose, we can cluster existing triplets (subject—

predicate—object) from the requirements, and each

clustered triplet compare with sentences matching the

same triplet (or at least a part of the triplet) from ex-

ternal sources.

4 DATA AND EXPERIMENTS

To evaluate our proposed methods, we have prepared

a data set

. We have collected textual requirements

from four different sources: (1) a set of requirements

from the PUblic REquirements Documents (PURE)

data set

(preﬁxed with uppercase P in the evaluation

table), (2) a set of requirements collected by (Hayes

et al., 2019) (preﬁxed with uppercase H in the eval-

uation table), (3) a set of requirements provided by

(Dalpiaz et al., 2019) (preﬁxed with lowercase g in the

evaluation table), (4) a custom collection of require-

ments found in the Internet (preﬁxed with uppercase

C in the evaluation table).

In Table 1, for each input requirements text (case)

from the aforementioned data set, we record (a legend

of the table):

• ARI – automated readability index – value ob-

https://zenodo.org/record/7897601

https://zenodo.org/record/7118517

Quality Measurement of Functional Requirements

739

Figure 1: Correlation comparison of IPA and ARI. Figure 2: Correlation comparison of EN and Q-Req.

tained using the Free Text Complexity Analyzer

online tool

• the number of all recognized issues (warnings)

in the sense of the proposed quality measure for-

mula Q-Req deﬁned in Section 3, where we use

all weights w

equivalent and equal to 1,

• EN – the number of recognized entities in the re-

quirements text,

• IEN – the number of issues per one recognized

entity in the requirements text,

• RN – the number of recognized relations in the

requirements text,

• IRN – the number of issues per one recognized

relation in the requirements text,

• AN – the number of recognized attributes in the

requirements text,

• IAN – the number of issues per one recognized

attribute in the requirements text,

• IPW – the number of issues per word in the re-

quirements text,

• IPS – the number of issues per sentence in the re-

quirements text,

• IPA – the number of issues per average number of

words in a sentence in the requirements text.

In Figure 1, we compare the correlation of IPA (the

number of issues per average number of words in

a sentence in the requirements text) and ARI (auto-

mated readability index). According to the used data

set, it cannot be claimed that the requirements texts

with the most generated warnings are the most com-

plex texts according to ARI at the same time.

In Figure 2, we compare the correlation of EN

(the number of recognized entities in the requirements

https://www.lumoslearning.com/llwp/

free-text-complexity-analysis.html

text) and Q-Req (the number of generated warnings).

In this case, as might be intuitively expected, the in-

creasing size of the generated model in the sense of

recognized entities is reﬂected in the number of gen-

erated warnings due to the need for a more complex

speciﬁcation.

5 CONCLUSIONS

In this contribution, we described a method to check

the quality of textual functional requirements. We

used the linguistic patterns we originally developed to

build a UML class model from textual requirements.

Our implemented system TEMOS analyses the am-

biguity, incompleteness, and inconsistency of textual

functional requirements and indicates a set S of recog-

nized suspicious irregularities. This set is used to gen-

erate warning messages that inform the analyst about

the problems found.

To measure the quality of requirements, we have

deﬁned a simple formula that uses the number of el-

ements in the set S – see Section 3. We compute the

formula and declare this result to be the value of our

quality metric. In the evaluation (Section 4), we com-

pare the result value of this metric with the readability

index ARI, recognized parts of the generated model

from the requirements, and number of words and sen-

tences of the requirements.

We assume the analysts remove some of the prob-

lem sources according to the generated warnings.

Then they iterate in quality checking as long as there

are no more problems found or the problems can be

explained by the imperfection of our system TEMOS.

As we declare above, our methods do not guarantee

that they reveal all problems concerning ambiguity,

incompleteness, and inconsistency. The semantics of

natural languages is enormously complex, and it is

based not only on the written text but also on educa-

ICSOFT 2023 - 18th International Conference on Software Technologies

740

Table 1: The evaluation of the recognized issues (warnings) using Q-Req.

Case ARI Q-Req EN IEN RN IRN AN IAN IPW IPS IPA

g02-federalspending 8.4 27 81 0.33 51 0.53 0 0.00 0.01 0.28 1.27

g03-loudoun 14.2 43 34 1.26 23 1.87 1 43.00 0.03 0.75 1.55

g04-recycling 10.1 25 29 0.86 17 1.47 0 0.00 0.02 0.49 1.01

g05-openspending 12.6 14 38 0.37 26 0.54 0 0.00 0.01 0.26 0.46

g08-frictionless 11.8 48 38 1.26 29 1.66 1 48.00 0.03 0.73 1.90

g10-scrumalliance 9.9 60 62 0.97 45 1.33 1 60.00 0.02 0.61 2.29

g11-nsf 9.0 25 36 0.69 21 1.19 0 0.00 0.01 0.34 1.21

g12-camperplus 10.5 36 21 1.71 15 2.40 0 0.00 0.03 0.68 1.34

g13-planningpoker 10.4 39 41 0.95 34 1.15 1 39.00 0.03 0.74 1.42

g14-datahub 11.0 26 35 0.74 33 0.79 2 13.00 0.01 0.39 0.95

g16-mis 12.1 33 63 0.52 62 0.53 1 33.00 0.02 0.49 1.46

g17-cask 11.4 17 42 0.40 45 0.38 2 8.50 0.01 0.27 0.67

g18-neurohub 9.4 56 72 0.78 62 0.90 0 0.00 0.03 0.55 2.57

g19-alfred 7.2 42 55 0.76 42 1.00 2 21.00 0.02 0.30 2.37

g21-badcamp 12.1 32 39 0.82 26 1.23 0 0.00 0.02 0.46 1.19

g22-rdadmp 12.4 30 51 0.59 48 0.63 0 0.00 0.01 0.36 1.11

g23-archivesspace 7.6 14 14 1.00 9 1.56 0 0.00 0.02 0.25 0.90

g24-unibath 13.8 17 31 0.55 21 0.81 1 17.00 0.01 0.33 0.60

g25-duraspace 9.5 31 65 0.48 67 0.46 4 7.75 0.02 0.31 1.46

g26-racdam 9.9 33 33 1.00 23 1.43 0 0.00 0.02 0.33 1.54

g27-culrepo 13.8 77 94 0.82 64 1.20 1 77.00 0.02 0.64 2.65

g28-zooniverse 9.2 15 29 0.52 17 0.88 0 0.00 0.01 0.25 0.85

P01. Blit 5.0 12 30 0.40 34 0.35 1 12.00 0.02 0.25 1.10

P02. CS179G. . . 8.0 22 95 0.23 83 0.27 6 3.67 0.02 0.33 1.21

P03. eProcurement 11.4 62 72 0.86 78 0.79 0 0.00 0.04 0.69 3.06

P04. Grid 3D 4.9 2 18 0.11 13 0.15 0 0.00 0.01 0.18 0.12

P05. Home 1.3 6.4 25 60 0.42 74 0.34 2 12.50 0.02 0.29 1.94

P06. Integrated. . . 8.3 124 115 1.08 149 0.83 1 124.00 0.06 1.57 4.46

P07. Inventory 3.5 116 180 0.64 317 0.37 8 14.50 0.02 0.23 13.79

P08. KeePass. . . 4.2 12 44 0.27 32 0.38 0 0.00 0.03 0.33 0.94

P09. Mashbot 8.8 14 24 0.58 28 0.50 0 0.00 0.02 0.54 0.66

P10. MultiMahjong 9.3 62 61 1.02 66 0.94 1 62.00 0.04 0.70 3.21

P11. Nenios 6.6 70 44 1.59 59 1.19 2 35.00 0.07 0.85 6.08

P12. Pontis 5.0. . . 11.5 71 168 0.42 267 0.27 3 23.67 0.02 0.32 3.83

P13. Public Health. . . 17.4 140 181 0.77 244 0.57 0 0.00 0.05 1.27 10.68

P14. Publications. . . 9.1 96 99 0.97 196 0.49 3 32.00 0.04 1.57 3.43

P15. Puget Sound. . . 7.0 36 104 0.35 123 0.29 1 36.00 0.02 0.39 1.90

P16. Tactical. . . 7.5 61 223 0.27 204 0.30 1 61.00 0.01 0.21 3.10

P17. Tarrant. . . 13.1 79 30 2.63 33 2.39 4 19.75 0.04 0.59 6.00

P18. X-38 Fault. . . 12.5 88 211 0.42 233 0.38 4 22.00 0.02 0.25 5.95

H01. CCHIT 12.7 65 173 0.38 205 0.32 4 16.25 0.03 0.58 3.10

H02. CM1 10.2 1 21 0.05 13 0.08 0 0.00 0.00 0.03 0.06

H03. InfusionPump 10.4 24 186 0.13 185 0.13 2 12.00 0.01 0.10 1.61

H04. Waterloo 9.0 175 355 0.49 1070 0.16 3 58.33 0.01 0.26 9.85

C01. Amazing. . . 5.4 78 110 0.71 251 0.31 0 0.00 0.02 0.84 2.28

C02. EU Rent 4.1 26 75 0.35 97 0.27 6 4.33 0.05 0.60 2.33

C03. FDP Expand. . . 9.9 6 39 0.15 29 0.21 1 6.00 0.01 0.15 0.49

C04. Library System 6.1 57 74 0.77 109 0.52 1 57.00 0.03 0.45 4.01

C05. Nodes Portal. . . 7.8 16 97 0.16 259 0.06 1 16.00 0.01 0.10 1.09

C06. Online Nat. . . 6.1 135 93 1.45 137 0.99 3 45.00 0.04 0.51 12.42

C07. Restaurant. . . 7.9 17 32 0.53 65 0.26 0 0.00 0.02 0.37 0.87

Quality Measurement of Functional Requirements

741

tion and experience, i.e., each human being has (or

can have) a different model of the world in its head.

ACKNOWLEDGEMENTS

This research was supported by the grant

of Czech Technical University in Prague

No. SGS23/206/OHK3/3T/18.

REFERENCES

Antinyan, V., Staron, M., Sandberg, A., and Hansson, J.

(2016). A Complexity Measure for Textual Require-

ments. In 2016 Joint Conference of the International

Workshop on Software Measurement and the Inter-

national Conference on Software Process and Prod-

uct Measurement (IWSM-MENSURA), pages 148–

158, Los Alamitos, CA, USA. IEEE Computer Soci-

ety.

Arora, C., Sabetzadeh, M., Briand, L., and Zimmer, F.

(2017). Automated Extraction and Clustering of Re-

quirements Glossary Terms. IEEE Transactions on

Software Engineering, 43(10):918–945.

aumer, F. S. and Geierhos, M. (2018). Flexible Ambiguity

Resolution and Incompleteness Detection in Require-

ments Descriptions via an Indicator-Based Conﬁgura-

tion of Text Analysis Pipelines. In Proceedings of the

51st Hawaii International Conference on System Sci-

ences, pages 5746–5755.

Berry, D., Bucchiarone, A., Gnesi, S., Lami, G., and G., T.

(2006). A New Quality Model for Natural Language

Requirements Speciﬁctions. In Proceedings of the

12th International Working Conference on require-

ments Engineering: Foundation of Software Quality

(REFSQ-06).

Bhatia, J., Sharma, R., Biswas, K., and Ghaisas, S. (2013).

Using Grammatical Knowledge Patterns for Structur-

ing Requirements Speciﬁcations. In IEEE Third Inter-

national Workshop on Requirements Patterns (RePa).

Bugayenko, Y. (2021). Combining Object-Oriented

Paradigm and Controlled Natural Language for Re-

quirements Speciﬁcation. In Proceedings of the 1st

ACM SIGPLAN International Workshop on Beyond

Code: No Code, BCNC 2021, page 11–17, New York,

NY, USA. Association for Computing Machinery.

Dalpiaz, F., Ferrari, A., Franch, X., and Palomares, C.

(2018). Natural Language Processing for Require-

ments Engineering: The Best Is Yet to Come. In Pro-

ceedings of the Workshop NLPRE´18, pages 70–77.

IEEE.

Dalpiaz, F., van der Schalk, I., Brinkkemper, S., Aydemir,

F. B., and Lucassen, G. (2019). Detecting terminolog-

ical ambiguity in user stories: Tool and experimenta-

tion. Information and Software Technology, 110:3–16.

Davis, A., Overmyer, S., Jordan, K., Caruso, J., Dandashi,

F., Dinh, A., Kincaid, G., Ledeboer, G., Reynolds, P.,

Sitaram, P., Ta, A., and Theofanos, M. (1993). Identi-

fying and Measuring Quality in a Software Require-

ments Speciﬁcation. In Proceedings First Interna-

tional Software Metrics Symposium, pages 141–152,

Los Alamitos, CA, USA. IEEE Computer Society.

Eckhardt, J., Vogelsang, A., Femmer, H., and Mager, P.

(2016). Challenging Incompleteness of Performance

Requirements by Sentence Patterns. In 2016 IEEE

24th International Requirements Engineering Confer-

ence (RE), pages 46–55, Beijing, China. IEEE.

Ezzini, S., Abualhaija, S., Arora, C., Sabetzadeh, M., and

Briand, L. C. (2021). Using Domain-Speciﬁc Cor-

pora for Improved Handling of Ambiguity in Require-

ments. In 2021 IEEE/ACM 43rd International Con-

ference on Software Engineering (ICSE), pages 1485–

1497, Los Alamitos, CA, USA. IEEE Computer Soci-

ety.

Fabbrini, F., Fusani, M., Gnesi, S., and Lami, G. (2001). An

Automatic Quality Evaluation for Natural Language

Requirements. In Proceedings of the Seventh Interna-

tional Workshop on Requirements Engineering: Foun-

dation for Software Quality (REFSQ), volume 1.

Femmer, H., Unterkalmsteiner, M., and Gorschek, T.

(2017). Which Requirements Artifact Quality De-

fects are Automatically Detectable – A Case Study.

In 2017 IEEE 25th International Requirements Engi-

neering Conference Workshops, pages 400–406. IEEE

Computer Society.

Feng, S., Chen, X., Li, Q., and Zhao, Y. (2021). RE2B: En-

hancing Correctness of Both Requirements and De-

sign Models. In 2021 International Symposium on

Theoretical Aspects of Software Engineering (TASE),

pages 191–198, Los Alamitos, CA, USA. IEEE Com-

puter Society.

Ferrari, A., dell’Orletta, F., Spagnolo, G. O., and Gnesi, S.

(2014). Measuring and Improving the Completeness

of Natural Language Requirements. In Proceedings

of Requirements Engineering: Foundation for Soft-

ware Quality - REFSQ 2014. LNCS 8396, pages 23–

38, Cham. Springer.

Ferrari, A., Zhao, L., and Alhoshan, W. (2021). NLP for

Requirements Engineering: Tasks, Techniques, Tools,

and Technologies. In 2021 IEEE/ACM 43rd Interna-

tional Conference on Software Engineering: Compan-

ion Proceedings (ICSE-Companion), pages 322–323,

Los Alamitos, CA, USA. IEEE Computer Society.

Gemkow, T., Conzelmann, M., Hartig, K., and Vogelsang,

A. (2018). Automatic Glossary Term Extraction from

Large-Scale Requirements Speciﬁcations. In IEEE

26th International Requirements Engineering Confer-

ence, pages 412–417.

Gleich, B., Creighton, O., and Kof, L. (2010). Measuring

and Improving the Completeness of Natural Language

Requirements. In Proceedings of Requirements Engi-

neering: Foundation for Software Quality - REFSQ

2010, LNCS 6182, pages 233–247, Cham. Springer.

enova, G., Fuentes, J. M., Llorens, J., Hurtado, O., and

Moreno, V. (2013). A Framework to Measure and Im-

prove the Quality of Textual Requirements. Require-

ments Engineering, 18(1):25–41.

ICSOFT 2023 - 18th International Conference on Software Technologies

742

Hayes, J. H., Payne, J., and Leppelmeier, M. (2019). To-

ward Improved Artiﬁcial Intelligence in Requirements

Engineering: Metadata for Tracing Datasets. In 2019

IEEE 27th International Requirements Engineering

Conference Workshops (REW), pages 256–262.

Kocerka, J., Krzeslak, M., and Galuszka, A. (2018).

Analysing Quality of Textual Requirements using

Natural Language Processing: A Literature Review.

In Conference: 2018 23rd International Conference

on Methods and Models in Automation and Robotics

(MMAR).

Kose, S. and Aydemir, F. (2021). Automated Glossary

Extraction from Collaborative Requirements Models.

In 2021 IEEE 29th International Requirements Engi-

neering Conference Workshops (REW), pages 11–15,

Los Alamitos, CA, USA. IEEE Computer Society.

Kummler, P., Vernisse, L., and Fromm, H. (2018). How

Good are My Requirements? A New Perspective on

the Quality Measurement of Textual Requirements.

In 2018 11th International Conference on the Qual-

ity of Information and Communications Technology

(QUATIC), pages 156–159, Los Alamitos, CA, USA.

IEEE Computer Society.

Li, A. (2015). Analysis of Requirements Incompleteness

Using Metamodel Speciﬁcation. Master’s thesis, Uni-

versity of Tampere.

Loucopoulos, P. and Karakostas, V. (1995). System Require-

ments Engineering. McGraw-Hill.

Medeiros, J., Goulao, M., Vasconcelos, A., and Silva, C.

(2016). Towards a Model about Quality of Software

Requirements Speciﬁcation in Agile Projects. In 2016

10th International Conference on the Quality of Infor-

mation and Communications Technology (QUATIC),

pages 236–241, Los Alamitos, CA, USA. IEEE Com-

puter Society.

Nordin, A., Zaidi, A., and Mazlan, A. (2017). Measuring

Software Requirements Speciﬁcation Quality. Jour-

nal of Telecommunication, Electronic and Computer

Engineering, 9(3-5):123–128.

Robeer, M., Lucassen, G., van der Werf, J. M. E. M.,

Dalpiaz, F., and Brinkkemper, S. (2016). Automated

Extraction of Conceptual Models from User Stories

via NLP. In 2016 IEEE 24th International Require-

ments Engineering Conference (RE), pages 196–205.

Saito, S., Takeuchi, M., Hiraoka, M., Kitani, T., and

Aoyama, M. (2013). Requirements Clinic: Third

Party Inspection Methodology and Practice for Im-

proving the Quality of Software Requirements Spec-

iﬁcations. In 2013 IEEE 21st International Require-

ments Engineering Conference (RE), pages 290–295,

Los Alamitos, CA, USA. IEEE Computer Society.

Senk

r, D. and Kroha, P. (2018). Patterns in Textual Re-

quirements Speciﬁcation. In Proceedings of the 13th

International Conference on Software Technologies,

pages 197–204, Porto, Portugal. SCITEPRESS – Sci-

ence and Technology Publications.

Senk

r, D. and Kroha, P. (2019a). Patterns of Ambiguity

in Textual Requirements Speciﬁcation. In Rocha,

A.,

Adeli, H., Reis, L. P., and Costanzo, S., editors, New

Knowledge in Information Systems and Technologies,

volume 1, pages 886–895, Cham. Springer Interna-

tional Publishing.

Senk

r, D. and Kroha, P. (2019b). Problem of Incom-

pleteness in Textual Requirements Speciﬁcation. In

Proceedings of the 14th International Conference on

Software Technologies, volume 1, pages 323–330,

Porto, Portugal. INSTICC, SCITEPRESS – Science

and Technology Publications.

Senk

r, D. and Kroha, P. (2020). Patterns for Checking

Incompleteness of Scenarios in Textual Requirements

Speciﬁcation. In Proceedings of the 15th Interna-

tional Conference on Evaluation of Novel Approaches

to Software Engineering, volume 1, pages 289–296,

Porto, Portugal. INSTICC, SCITEPRESS – Science

and Technology Publications.

Senk

r, D. and Kroha, P. (2021a). Problem of Inconsis-

tency and Default Consistency Rules. In Fujita, H.

and P

erez-Meana, H., editors, New Trends in Intelli-

gent Software Methodologies, Tools and Techniques

– Proceedings of the 20th International Conference

on New Trends in Intelligent Software Methodologies,

Tools and Techniques (SoMeT 2021), volume 337 of

Frontiers in Artiﬁcial Intelligence and Applications,

pages 674–687. IOS Press.

Senk

r, D. and Kroha, P. (2021b). Problem of Semantic En-

richment of Sentences Used in Textual Requirements

Speciﬁcation. In Polyvyanyy, A. and Rinderle-Ma,

S., editors, Advanced Information Systems Engineer-

ing Workshops, pages 69–80, Cham. Springer Interna-

tional Publishing.

Senk

r, D. and Kroha, P. (2021). Problem of Inconsistency

in Textual Requirements Speciﬁcation. In Ali, R.,

Kaindl, H., and Maciaszek, L. A., editors, Proceed-

ings of the 16th International Conference on Evalua-

tion of Novel Approaches to Software Engineering –

ENASE, pages 213–220. INSTICC, SciTePress.

Sonbol, R., Rebdawi, G., and Ghneim, N. (2020). Towards

a Semantic Representation for Functional Software

Requirements. In 2020 IEEE Seventh International

Workshop on Artiﬁcial Intelligence for Requirements

Engineering (AIRE), pages 1–8, Los Alamitos, CA,

USA. IEEE Computer Society.

Takoshima, A. and Aoyama, M. (2015). Assessing the

Quality of Software Requirements Speciﬁcations for

Automotive Software Systems. In 2015 Asia-Paciﬁc

Software Engineering Conference (APSEC), pages

393–400, Los Alamitos, CA, USA. IEEE Computer

Society.

Wilson, W., Rosenberg, L., and Hyatt, L. (1997). Auto-

mated Analysis of Requirement Speciﬁcations. In Au-

tomated Software Engineering, pages 161–171.

Zhao, L., Alhoshan, W., Ferrari, A., Letsholo, K. J., Ajagbe,

M. A., Chioasca, E.-V., and Batista-Navarro, R. T.

(2021). Natural Language Processing for Require-

ments Engineering: A Systematic Mapping Study.

ACM Comput. Surv., 54(3).

Quality Measurement of Functional Requirements

743
