Robust Single Object Tracking and Following by Fusion Strategy

Alejandro Olivas

, Miguel

Angel Mu

noz-Ba

, Edison Velasco

and Fernando Torres

Group of Automation, Robotics and Computer Vision, University of Alicante, Alicante, Spain

Keywords:

Target Tracking, Autonomous Vehicles, Robot Sensing Systems, Real-Time Systems.

Abstract:

Single Object Tracking methods are yet not robust enough because they may lose the target due to occlusions or

changes in the target’s appearance, and it is difﬁcult to detect automatically when they fail. To deal with these

problems, we design a novel method to improve object tracking by fusing complementary types of trackers,

taking advantage of each other’s strengths, with an Extended Kalman Filter to combine them in a probabilistic

way. The environment perception is performed with a 3D LiDAR sensor, so we can track the object in the point

cloud and also in the front-view image constructed from the point cloud. We use our tracker-fusion method in

a mobile robot to follow pedestrians, also considering the dynamic obstacles in the environment to avoid them.

We show that our method allows the robot to follow the target accurately during long experimental sessions

where the trackers independently fail, demonstrating the robustness of our tracker-fusion strategy.

1 INTRODUCTION

In the last years, Single Object Tracking (SOT) has

been a hot research topic. The task of following an

object over time is still challenging because of the

changes in its appearance and in the environment. The

use of Machine Learning (ML) methods has increased

the accuracy and speed of the trackers, making it vi-

able to use them in real-time applications. The current

problems associated with SOT are losses of the target

due to occlusions or misunderstandings with similar

objects.

There is a trend in using mobile robots for collabo-

rative tasks with people. In this context, we propose

the use of pedestrian tracking for the design of follow-

ing behaviour. There has been a lot of research with

the aim of making a robust pedestrian follower robot

(Yoshimi et al., 2006; Koide and Miura, 2016). Be-

sides tracking the target robustly, the robot has to fol-

low the target while avoiding dynamic obstacles for

safety reasons, a fact not usually considered in the li-

terature.

For many years, researchers have dealt with SOT

in images, solving the problem with different types

of approaches. One of them is tracking-by-detection,

which uses ﬁrst a detection algorithm and then an

https://orcid.org/0000-0002-3462-0713

https://orcid.org/0000-0002-3220-2286

https://orcid.org/0000-0003-2837-2001

https://orcid.org/0000-0002-6261-9939

association method to match the target across the

frames. The shortcomings of tracking-by-detection

are the limitations of the detector, which may produce

false positives or missed detections, and failures in the

target re-identiﬁcation that produces incorrect object

associations.

The most trending approach in the last years is the

use of deep learning algorithms (Zhang et al., 2021).

Among these, the Siamese Neural Networks (SNN)

(Tao et al., 2016) highlight because of their outper-

formance in terms of speed and accuracy. These net-

works are trained in an end-to-end manner, feeding

the network with a template of the object and the cur-

rent frame and retrieving the target’s current bounding

box. Using the obtained prediction as the template for

the next frame, the target is tracked over time. The

SNNs have difﬁculty differentiating between similar

objects and recent research has focused on this pro-

blem.

There are many approaches for detecting and

tracking objects in point clouds because of the use

of LiDAR sensors to perceive the environment. The

use of geometric information may help in being aware

of the occlusions of the target, but the increase of the

search space makes the problem heavier computation-

ally. Recently, 3D SNNs have appeared to track sin-

gle objects in real time, but increasing robustness and

accuracy remains a challenge.

For tracking pedestrians, a recent work (He et al.,

2021) uses a Convolutional Neural Network (CNN)

624

Olivas, A., Muñoz-Bañón, M., Velasco, E. and Torres, F.

Robust Single Object Tracking and Following by Fusion Strategy.

DOI: 10.5220/0012178900003543

In Proceedings of the 20th International Conference on Informatics in Control, Automation and Robotics (ICINCO 2023) - Volume 1, pages 624-631

ISBN: 978-989-758-670-5; ISSN: 2184-2809

to detect the person and a SNN for tracking him. This

approach combines different deep learning meth-

ods to track the pedestrian, but we prefer to com-

bine different trackers in a probabilistic way, as they

are complementary. For this reason, we present a

tracker-fusion method that integrates a tracker based

on tracking-by-detection, another based on SNNs and

another on point cloud tracking. To do this, we use an

Extended Kalman Filter (EKF) to consider the three

trackers and coordinate them to overcome their fail-

ures. Compared with the other trackers in several ex-

periments, our method tracks the target more robustly

and precisely.

There is much research on obstacle avoidance and

this problem is not in the scope of this paper, as it is

focused on the SOT problem. We use a local planner

based on (Mu

noz-Ba

on et al., 2022).

To summarize, the contributions of our work are:

1) A tracker-fusion strategy to combine heteroge-

neous approaches to increase the robustness and

accuracy of SOT. Our method helps to automati-

cally detect when a tracker misses and corrects it.

2) The integration of our tracker-fusion method with

a local planner in an autonomous vehicle, follow-

ing the target correctly while avoiding dynamic

obstacles.

3) A comparison between the trackers and our ap-

proach, showing that our method outperforms

them.

The rest of this paper is organized as follows. Sec-

tion 2 describes the state of the art of the SOT pro-

blem. Section 3 explains the designed trackers and

our tracker-fusion method. Section 4 presents the ex-

perimental results, comparing our method to the se-

lected trackers. Finally, in Section 5, the conclusions

are exposed.

2 RELATED WORK

Our method fuses a visual tracking-by-detection

tracker, a visual tracker based on SNNs and a 3D point

cloud tracker. This section shows a brief review of

these topics in the literature.

Visual tracking-by-detection. For people tracking,

there are approaches that combine a pedestrian de-

tector with a data association and ﬁltering algo-

rithm, such as a particle ﬁlter (Breitenstein et al.,

2011). (Andriluka et al., 2008) present an approach

that combines tracking-by-detection with detection-

by-tracking, a paradigm that takes advantage of the

tracking information to improve the detections, in

a framework to track multiple people in situations

with occlusions. To re-identify the person, clothing

appearance is typically used, and many descriptors

have been proposed based on global or local features

(Satta, 2013). This type of approach has become more

robust and accurate thanks to the use of detectors

based on CNNs. The You Only Look Once (YOLO)

architecture (Redmon et al., 2016) deals with object

detection in a fast and precise way, and it has been a

hot research topic in recent years.

Siamese Neural Networks. SNNs track a single

object by similarity comparison strategy. Because

of the efﬁciency in terms of speed and accuracy, it

has drawn the attention of visual tracking researchers

(Held et al., 2016; Bertinetto et al., 2016). Many of

these approaches have the drawback of discriminating

only the foreground from non-semantic background,

having difﬁculties in distinguishing between similar

targets. SiamRPN (Li et al., 2018) employs a re-

gion proposal after the SNN to formulate the tracking

problem as a local detection task. Zhu et al. (Zhu

et al., 2018) presented DaSiamRPN, which uses a

distractor-aware module to track the target between

similar ones. (Ondra

sovi

c and Tar

abek, 2021) present

a comprehensive review of the SNNs, highlighting

the main challenges of dealing with distractors (si-

milar interference) and severe occlusions. The re-

view also discusses approaches that address these is-

sues, such as DaSiamRPN, which demonstrate better

performance in handling these challenges. However,

these problems are still not completely solved.

3D Object Tracking. Early research about object

tracking in point cloud focused on RGB-D informa-

tion, improving the tracking in images by adding

information of the depth channel (Song and Xiao,

2013). (Liu et al., 2018) present a method that uses

3D properties to separate objects that might look ad-

jacent in the images to deal with occlusions. Deep

learning methods are used to track objects in point

clouds obtained by LiDAR sensors. (Luo et al., 2018)

present a CNN to detect and track multiple objects

and forecast their motion. It uses the bird-eye-view

(BEV) of the 3D world.

Recent research has adapted SNNs for point

clouds (Giancola et al., 2019) to solve the 3D SOT

problem. (Qi et al., 2020) presented a method that

identiﬁes potential candidates in a 3D search area us-

ing the information of the target’s template. Then, the

target proposal and veriﬁcation steps are executed in-

side the net, avoiding an exhaustive 3D search which

is time-consuming. M

-Track (Zheng et al., 2022)

is based on motion-centric paradigm instead of the

appearance matching paradigm of preview research.

The use of a transformer (Hui et al., 2022) to learn a

robust cross-correlation between the template and the

Robust Single Object Tracking and Following by Fusion Strategy

625

search area point clouds achieves state-of-the-art per-

formance for many classes, although for pedestrian

tracking M

-Track shows better results. Pedestrians

have many changes in their appearance while moving,

so it makes sense that motion paradigm works better

for this class.

These types of trackers are complementary as

tracking-by-detection keeps better the target’s shape,

SNNs accurately track the object in short-term situa-

tions, and point cloud trackers take geometrical infor-

mation into account.

3 METHODOLOGY

In this research, we designed a strategy to fuse three

different trackers. Two of them are visual trackers,

one based on YOLO and the other on DaSiamRPN,

and we explain ﬁrstly the adaptations for the front-

view images of the point cloud projection. These im-

ages have four channels: depth, intensity, reﬂectivity

and infrared. Next, we explain the point cloud tracker,

which is based on M

-Track. Then, the combination

of the trackers using an EKF is explained.

3.1 YOLO Tracker

The designed YOLO tracker follows the tracking-by-

detection paradigm, where the detector is a YOLO

neural network. Firstly, the pedestrians in the image

are detected and the target is selected. We decided to

choose the person who is at the front of the robot stat-

ically for a parameterized number of seconds. Then,

the three trackers are initialized to follow the selected

pedestrian.

For the association of the detections with the tar-

get, it is needed to deﬁne the pedestrians with descrip-

tors. Firstly, the detected person is segmented using

the depth channel to remove the background. Accord-

ing to previous research (P

aez-Ubieta et al., 2022),

when determining the depth of an identiﬁed object, its

bounding box size is decreased by 40% and the depth

is estimated as the mean value of that interior box.

The bounding box of a pedestrian has many points

of the background, so to ﬁlter them we used the me-

dian value instead of the mean. Then, considering this

value, each candidate is segmented erasing the back-

ground and front obstacles.

To build the descriptor, we use histograms to de-

ﬁne the pedestrian, in a similar way to color his-

tograms, but in this case with the other three chan-

nels detected by the LiDAR, deﬁning the pedestrian

mainly by its clothes’ appearance. The depth is not

used because it is not a representative characteristic

Figure 1: The 5 parts into which the person is divided in

order to calculate the descriptor.

of the person, as it only depends on the distance to

the sensor. Usually, the clothes of the top part of the

body are different from the ones of the bottom, so we

divided the person into ﬁve parts as shown in Figure

1, although the bottom part is not considered because

it has undesired ground points. For each part, three

histograms are calculated, one for each channel, and

the descriptor is built concatenating them. There are

many possibilities to get a descriptor from a person,

but we decided to use this because it has to be fast to

build and compare to work in a real-time application

while using other trackers.

During the tracking, YOLO detects the pedestri-

ans of the image, and the ones inside a search area are

considered candidates. The search area is explained

in Section 3.4, and it is deﬁned by the position and

covariance of the target estimated by the EKF. The

candidates’ descriptors are calculated and compared

to the target’s descriptor, using the histogram correla-

tion deﬁned by (1), where H

are the histograms.

d(H

) =

∑

(K) − H

)(H

(K) − H

)

∑

(K) − H

)

∑

(K) − H

)

(1)

where,

∑

(J) (2)

and N is the total number of histogram bins.

The most similar candidate to the target is consi-

dered the target in the current frame if the correlation

is above a minimum threshold. Finally, the target’s

descriptor is updated as the mean value between the

previous and the new descriptor, because it changes

when the target or the robot moves.

Among the YOLO architectures, we decided to

use YOLOv5 (Jocher et al., 2022) to build our model.

A dataset with 2392 LiDAR images with labelled peo-

ple was created and we trained models using a differ-

ent combination of the four channels of the LiDAR

images. The best results were obtained with all the

channels. Problems that affect this tracker are high

changes in the target’s descriptor or people with simi-

lar clothes to the target, but they are mitigated by our

tracker-fusion method.

ICINCO 2023 - 20th International Conference on Informatics in Control, Automation and Robotics

626

3.2 Siamese Tracker

For tracking, a SNN receives as input the current

frame and the bounding box of the target in the pre-

vious frame and it returns directly the bounding box

in the current frame. We decided to use DaSiamRPN

(Zhu et al., 2018) because, even for the LiDAR im-

ages, it works better than other trackers without train-

ing a new model. The network is prepared for RGB

images, i.e. three channels images, so we use the

intensity, reﬂectivity and infrared channels. This

change is done without ﬁne-tuning the model, as it

shows that it can follow targets in these images.

The pedestrian can be tracked on the boundaries

of the image because the LiDAR has a view of 360º.

However, DaSiamRPN is not prepared for this. To

adapt the method, we have to add the pixels of the

other boundary to the search area when the target is

near the image limits. For doing this, the image is

shifted as shown in Figure 2 and the target can be fol-

lowed when it crosses the boundaries of the image.

As this tracker was not trained with LiDAR im-

ages, it may miss the target more frequently than in

RGB images. Furthermore, as it is designed for ge-

neral object tracking, the bounding box tends not to

focus on the whole person, which increases the error

on the position of the target. When fusing the track-

ers, these problems are overcome.

3.3 Point Cloud Tracker

We decided to use a 3D SNN for tracking the target in

the point cloud because they surpass previous meth-

ods in terms of speed and accuracy. Among these, we

decided to use M

-Track (Zheng et al., 2022) because,

as mentioned in the related work, it outperforms the

other networks in pedestrian tracking. We used the

model that was trained using the KITTI dataset, al-

though our LiDAR sensor is a different model with

more layers, speciﬁcally 128 against the 64 of the

dataset.

This network receives as input the previous and

current point cloud and the 3D bounding box of the

target in the previous frame and returns the current 3D

bounding box. The computational time of processing

the point clouds and predicting the target’s current po-

sition where larger than expected (more discussion in

Section 4) and we take advantage of the search area

in the frontal-view image, which will be explained in

Section 3.4, to speed up the tracker. Instead of feed-

ing the net with the whole point cloud captured by the

LiDAR, only the point cloud inside the search area is

sent to the net. Even if it requires a reconstruction

from an image, it does not consume much time for a

small part of the image and speeds up the tracker.

The drawbacks of this tracker are failures when

the target crosses paths with other pedestrians. The

computational cost may be a problem for real-time

applications when using it with other trackers and

we will discuss if the increase of time in the tracker-

fusion is worth the gain in robustness and precision in

Section 4.

3.4 Tracker Fusion

The diagram of our tracker-fusion strategy is shown in

Figure 3. Using the characteristics of the sensor, it is

possible to calculate the 3D coordinates of a pixel of

the image using its value in the depth channel. With

the centre pixel of the bounding box and the depth

value estimated by the method explained in Section

3.1, the coordinates of the target are estimated, which

are considered from now on as observations of a dy-

namic system. The centroid of the 3D bounding box

predicted by the point cloud tracker is also considered

an observation.

The position merging is performed with an EKF,

which uses the predict and update phases to estimate

the state and the covariance of the target. The state is

deﬁned by the position in the X and Y axis because

our local planner only needs these two coordinates.

In our case, the prediction phase works as a constant

propagation model. A new observation updates the

state of the EKF, and its covariance represents the ex-

pected error of it. We consider that, if the tracker re-

turns a bounding box that is very different or far from

the previous one, the error may be larger, as if the

tracker failed the target would be around the previous

position. Therefore, the covariance of the observation

should be higher.

For the visual trackers, the Intersection over

Union (IoU) is calculated and the covariance is in-

versely proportional to it. The IoU is deﬁned as

the percentage of the intersection area between both

bounding boxes with respect to the union of both ar-

eas. Besides, there may be a larger error in the direc-

tion between the robot and the target because of errors

in the target’s depth estimation, so the observation co-

variance is estimated higher in this direction:

R = Rot(arctan(y/x)) (3)

C =



α · (c +s · (1 − IoU)) 0

0 c + s ·(1 − IoU)



(4)

Cov = RCR

(5)

Where x and y are the estimated coordinates for

the bounding box with respect to the robot, Rot(ω)

the 2D rotation matrix of the angle ω, c is a constant,

s is a variable proportional to the state covariance and

Robust Single Object Tracking and Following by Fusion Strategy

627

Figure 2: The blue bounding box shows the target, who is cut by the boundaries of the original image (top image). The image

is shifted (bottom image) to track the target with DaSiamRPN. The front-view images are pseudo-colorized using the LiDAR

channels.

Figure 3: Scheme of our tracker-fusion method.

α is a constant greater than 1 to consider the errors

due the estimation of target’s depth.

For the point cloud tracker, we consider the size

of the 3D bounding box constant, so in this case, the

covariance is proportional to the Euclidean distance

between the previous position and the current.

A pedestrian cannot move from one position to an-

other in a short period of time. Therefore, we con-

sider a new observation as an outlier if it is far away

from the current position. We use the Mahalanobis

distance for outlier rejection because it considers the

covariance of the EKF state and of the observation.

To coordinate the three trackers, we estimate a

search area from the current state and covariance of

the EKF. Hence, the size of the search area is dynam-

ically tuned and it is proportional to the covariance,

which represents the error of the current position, and

therefore the target should be searched inside the area

deﬁned by it.

When YOLO does not detect the target in the

search area for several seconds, but it detects a per-

son there, the tracker is initialised with that pedes-

trian. This means that the target has been tracked

by the other methods and therefore it is inside the

search area. If DaSaimRPN detects the target outside

the search area, it is reset with the target detected by

YOLO. However, this is not enough to deal with the

misses of this tracker, so it is also reset if the bounding

boxes of YOLO and DaSiamRPN are very different,

i.e. the IoU between the bounding boxes is low, and

the YOLO prediction is closer to the last position es-

timated by EKF. If the point cloud tracker had failed,

which is determined by comparing the current posi-

tion of the target and the predicted position of M

Track, M

-Track is reset using the target’s current po-

sition.

The target position is sent to the local planner,

which computes the trajectory to follow the person

while avoiding the obstacles. The planner is based

on (Mu

noz-Ba

on et al., 2022), and the speed of the

robot is adjusted with the distance to the target, so

when the robot gets close to the target it slows down.

4 EXPERIMENTS

In this section, we show the results of our method. It

is compared with the three presented trackers, show-

ing the beneﬁts of fusing them. The experiments were

done in a robot equipped with the OS1-128-U LiDAR

Sensor-Ouster to perceive the environment and an on-

board computer with AMD Ryzen 7 5700G, NVIDIA

GTX 3060 (12 GB) and 32 GB of RAM.

About the metrics for comparing the methods,

we use the Euclidean distance between the predicted

and the ground truth position. The ground truth of

the bounding boxes was labelled manually in some

frames, and for the other frames, it was estimated as

the linear interpolation between the previous labelled

frame and the next. Then, the position is estimated

from the bounding boxes as explained in Section 3.4.

For the visual trackers, the IoU is also used to com-

pare the methods.

The experiments consist in eight sessions where

the robot follows different people, using the designed

tracker-fusion and the local planner. In the ﬁrst expe-

rimental session, using the DaSiamRPN tracker, the

target is lost when it moves near the robot. With the

YOLO tracker, when he crosses paths with another

person. The two pedestrians have similar clothes with

respect to the LiDAR channels and the tracker con-

fuses both after the occlusion. The point cloud tracker

also missed the target at that moment. Despite the

problems of the trackers when they are used sepa-

rately, the target is not lost when fusing them. Figure

4 shows the position error during this session.

ICINCO 2023 - 20th International Conference on Informatics in Control, Automation and Robotics

628

Figure 4: Position error during the ﬁrst experiment.

Figure 5: Box plot of the error during the second session.

The outliers are not represented for clarity, but the maxi-

mum errors were 4.45 m, 1.78 m and 1.86 m respectively.

About the IoU values for the visual trackers when

the fusion is done, YOLO tracker has better results

with a mean value of 75.7% while DaSiamRPN has

63%. This trend is common in all the sessions because

the YOLO bounding box ﬁts better to the pedestrian

than the DaSiamRPN bounding box.

In experimental session 2, M

-Track lost the target

when it crossed paths with another pedestrian, while

YOLO missed it because variations in illumination

caused a large change in the descriptor of the target.

DaSiamRPN did not lose the target in this session, al-

though our tracker-fusion method tracked the target

more accurately, which is shown in Figure 5.

Table 1 compares the different methods, showing

the time when the target is lost, if it happens, and

the average position error while tracking the target in

the 8 experimental sessions. Using the three trackers

in isolation, the target is always lost except in ses-

sion 2 with DaSiamRPN tracker and in session 6 with

YOLO. Despite being more time-consuming than the

other trackers, M

-Track does not show noteworthy

robustness and accuracy. Our tracker-fusion without

-Track outperforms the version with it, as it suc-

ceeded in more sessions.

(a)

(b)

(c)

Figure 6: (a) The trackers detect correctly the target before

the occlusion. (b) After the occlusion, the YOLO tracker

(red) detects correctly the target, but DaSiamRPN (blue)

tracks another person. (c) DaSiamRPN tracker is corrected.

In sessions 6 to 8, there were consecutive occlu-

sions that our tracker-fusion handled, and our method

was also robust to occlusions during several seconds

and could track the target when it passed from one

boundary of the image to the other. Figure 6 shows

how the target is restored after an occlusion when one

tracker misses. However, in session 5 it failed when

the target was far away, around 14 m, and the robot

rotated, which produced a high change in the position

of the target. Nevertheless, the robot should be close

to the target for our application of following, so it is

not a big issue.

We commented in Section 3.3 that the computa-

tional time of M

-Track was large for using it in a

robotic application. M

-Track consumes on average

70.5 ms when feeding the net with the whole point

cloud, while it consumes 38.3 ms when using only

the point clouds of the search area. The point cloud

reconstruction is included and is on average 3.2 ms.

In the presented results, we used the point cloud of

the search area.

About the other components, YOLO tracker con-

sumes on average 11.5 ms and DaSiamRPN 3.7 ms,

the process to get the positions from the bounding

boxes plus the update of the EKF consumes 0.4 ms

and the local planner 10.3 ms. It is needed to recon-

struct the point cloud from the image without the tar-

get because the local planner does not have to con-

sider it as an obstacle, and this process consumes 4.9

ms. Considering all these times, the method can work

at a frequency of 13.8 Hz. Therefore, our method

Robust Single Object Tracking and Following by Fusion Strategy

629

Table 1: Comparison between the trackers in the 8 sessions, duration of each one in parenthesis. T

expresses the tracking

time until the target is lost (if it happens), and Error is the average Euclidean distance between the detected position and the

ground truth.

Session 1 (250 s) Session 2 (600 s) Session 3 (138 s) Session 4 (140 s)

(s) Error (m) T

(s) Error (m)

YOLO tracker 186 0.17 66 0.08 5 0.53 77 0.28

DaSiamRPN 10 0.24 - 0.13 136 0.17 81 0.11

-Track 186 0.22 125 0.17 68 0.23 35 0.17

Ours without

-Track

- 0.11 - 0.09 - 0.18 121 0.39

Ours - 0.12 - 0.10 - 0.19 132 0.24

Session 5 (119 s) Session 6 (181 s) Session 7 (172 s) Session 8 (240 s)

(s) Error (m) T

(s) Error (m)

YOLO tracker 38.5 0.10 - 0.15 57.5 0.26 148.5 0.14

DaSiamRPN 102 0.63 43 0.10 40 0.11 170 0.15

-Track 19 0.15 43 0.25 24.5 0.24 75 0.20

Ours without

-Track

105 0.33 - 0.15 - 0.23 - 0.10

Ours 61.5 0.47 - 0.16 41 0.12 156.5 013

works in real time, as we process the measurements

faster than the frequency at which LiDAR works, 10

Hz.

Although the algorithms were executed ofﬂine

to compare the different trackers, we also used our

tracker fusion to follow the pedestrian while record-

ing the sessions. During sessions 3 and 4, we used the

3 trackers, and the onboard computer could not pro-

cess the point cloud correctly because of the compu-

tational cost, and the images were corrupted as shown

in Figure 7. For this reason, our method failed dur-

ing session 4, and the rest of the experiments were

recorded without using M

-Track.

Therefore, we conclude that M2-Track is not

worthwhile for our fusion method with our current

hardware. Besides, if it were possible to process the

whole point cloud in less time, the point cloud tracker

should miss less, as it failed many times when the

robot rotated and the point cloud changed rapidly, so

the search space was not enough to track the target.

Even though, without using M

-Track, our method is

robust enough and can work in real time. The code is

shared

and there is a video of the experiments

Figure 7: Part of an image from a corrupted point cloud. It

has no information about a region of the image.

https://github.com/AUROVA-LAB/aurova detections

https://youtu.be/n7d BEgYg2k

5 CONCLUSIONS

In this research, after showing a comparison of

pedestrian trackers in long experimental sessions, we

demonstrated that fusing them is a promising way to

improve accuracy and robustness. Our tracker-fusion

method, which uses an EKF to integrate the trackers

probabilistically, shows better performance without

-Track, only with visual trackers. Consequently,

our method can work in real-time applications cor-

rectly, as there is no need to use time-consuming point

cloud trackers.

We integrate our method in an autonomous vehi-

cle to implement following behavior. Although we fo-

cus the research on pedestrian tracking, our method is

potentially useful in all tracking applications. In ad-

dition, our method can track other dynamic objects,

such as vehicles or robots, if the YOLO model is

trained for those objects.

ACKNOWLEDGEMENTS

This work has been supported by the Ministry of

Science and Innovation of the Spanish Government

through the research project PID2021-122685OB-

I00 and through the Formaci

on del Personal Investi-

gador [Research Staff Formation (FPI)] under Grant

PRE2019-088069.

ICINCO 2023 - 20th International Conference on Informatics in Control, Automation and Robotics

630

REFERENCES

Andriluka, M., Roth, S., and Schiele, B. (2008).

People-tracking-by-detection and people-detection-

by-tracking. In 2008 IEEE Conference on computer

vision and pattern recognition, pages 1–8. IEEE.

Bertinetto, L., Valmadre, J., Henriques, J. F., Vedaldi, A.,

and Torr, P. H. (2016). Fully-convolutional siamese

networks for object tracking. In Computer Vision–

ECCV 2016 Workshops: Amsterdam, The Nether-

lands, October 8-10 and 15-16, 2016, Proceedings,

Part II 14, pages 850–865. Springer.

Breitenstein, M. D., Reichlin, F., Leibe, B., Koller-Meier,

E., and Van Gool, L. (2011). Online multiper-

son tracking-by-detection from a single, uncalibrated

camera. IEEE Transactions on Pattern Analysis and

Machine Intelligence, 33(9):1820–1833.

Giancola, S., Zarzar, J., and Ghanem, B. (2019). Leveraging

shape completion for 3d siamese tracking. In Proceed-

ings of the IEEE/CVF conference on computer vision

and pattern recognition, pages 1359–1368.

He, C., Zhang, X., Miao, Z., and Sun, T. (2021). Intelli-

gent vehicle pedestrian tracking based on yolov3 and

dasiamrpn. In 2021 40th Chinese Control Conference

(CCC), pages 4181–4186. IEEE.

Held, D., Thrun, S., and Savarese, S. (2016). Learning to

track at 100 fps with deep regression networks. In

Computer Vision–ECCV 2016: 14th European Con-

ference, Amsterdam, The Netherlands, October 11–

14, 2016, Proceedings, Part I 14, pages 749–765.

Springer.

Hui, L., Wang, L., Tang, L., Lan, K., Xie, J., and Yang,

J. (2022). 3d siamese transformer network for sin-

gle object tracking on point clouds. In Computer

Vision–ECCV 2022: 17th European Conference, Tel

Aviv, Israel, October 23–27, 2022, Proceedings, Part

II, pages 293–310. Springer.

Jocher, G., Chaurasia, A., Stoken, A., Borovec, J., Kwon,

Y., Michael, K., and et. al (2022). ultralytics/yolov5:

v7.0 - YOLOv5 SOTA Realtime Instance Segmenta-

tion.

Koide, K. and Miura, J. (2016). Identiﬁcation of a spe-

ciﬁc person using color, height, and gait features for

a person following robot. Robotics and Autonomous

Systems, 84:76–87.

Li, B., Yan, J., Wu, W., Zhu, Z., and Hu, X. (2018). High

performance visual tracking with siamese region pro-

posal network. In Proceedings of the IEEE conference

on computer vision and pattern recognition, pages

8971–8980.

Liu, Y., Jing, X.-Y., Nie, J., Gao, H., Liu, J., and Jiang,

G.-P. (2018). Context-aware three-dimensional mean-

shift with occlusion handling for robust object track-

ing in rgb-d videos. IEEE Transactions on Multime-

dia, 21(3):664–677.

Luo, W., Yang, B., and Urtasun, R. (2018). Fast and furi-

ous: Real time end-to-end 3d detection, tracking and

motion forecasting with a single convolutional net. In

Proceedings of the IEEE conference on Computer Vi-

sion and Pattern Recognition, pages 3569–3577.

noz-Ba

on, M.

A., Velasco-S

anchez, E., Candelas,

F. A., and Torres, F. (2022). Openstreetmap-based au-

tonomous navigation with lidar naive-valley-path ob-

stacle avoidance. IEEE Transactions on Intelligent

Transportation Systems, 23(12):24428–24438.

Ondra

sovi

c, M. and Tar

abek, P. (2021). Siamese visual

object tracking: A survey. IEEE Access, 9:110149–

110172.

aez-Ubieta, I., Velasco-S

anchez, E., Puente, S. T., and

Candelas, F. A. (2022). Detection and depth estima-

tion for domestic waste in outdoor environments by

sensors fusion.

Qi, H., Feng, C., Cao, Z., Zhao, F., and Xiao, Y. (2020).

P2b: Point-to-box network for 3d object tracking in

point clouds. In Proceedings of the IEEE/CVF con-

ference on computer vision and pattern recognition,

pages 6329–6338.

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You only look once: Uniﬁed, real-time object

detection. In Proceedings of the IEEE Conference on

Computer Vision and Pattern Recognition (CVPR).

Satta, R. (2013). Appearance descriptors for person re-

identiﬁcation: a comprehensive review. arXiv preprint

arXiv:1307.5748.

Song, S. and Xiao, J. (2013). Tracking revisited using

rgbd camera: Uniﬁed benchmark and baselines. In

Proceedings of the IEEE international conference on

computer vision, pages 233–240.

Tao, R., Gavves, E., and Smeulders, A. W. (2016). Siamese

instance search for tracking. In Proceedings of the

IEEE conference on computer vision and pattern

recognition, pages 1420–1429.

Yoshimi, T., Nishiyama, M., Sonoura, T., Nakamoto, H.,

Tokura, S., Sato, H., Ozaki, F., Matsuhira, N., and

Mizoguchi, H. (2006). Development of a person fol-

lowing robot with vision based target detection. In

2006 IEEE/RSJ International Conference on Intelli-

gent Robots and Systems, pages 5286–5291. IEEE.

Zhang, Y., Wang, T., Liu, K., Zhang, B., and Chen, L.

(2021). Recent advances of single-object tracking

methods: A brief survey. Neurocomputing, 455:1–11.

Zheng, C., Yan, X., Zhang, H., Wang, B., Cheng, S., Cui,

S., and Li, Z. (2022). Beyond 3d siamese tracking: A

motion-centric paradigm for 3d single object tracking

in point clouds. In Proceedings of the IEEE/CVF Con-

ference on Computer Vision and Pattern Recognition,

pages 8111–8120.

Zhu, Z., Wang, Q., Li, B., Wu, W., Yan, J., and Hu, W.

(2018). Distractor-aware siamese networks for visual

object tracking. In Proceedings of the European con-

ference on computer vision (ECCV), pages 101–117.

Robust Single Object Tracking and Following by Fusion Strategy

631
