Explainable Intrusion Detection for Internet of Medical Things

Shafique Ahmed Memon

, Uffe Kock Wiil

and Mutiullah Shaikh

IMCS, University of Sindh, Jamshoro, Pakistan

SDU Health Informatics and Technology, University of Southern, Denmark

Keywords: Intrusion Detection (ID), Explainable AI (XAI), Internet of Things (IoT), Internet of Medical Things (IoMT),

Message Queuing Telemetry Transport (MQTT), Particle Swarm Optimization (PSO).

Abstract: IoMT sensors are used for continuous real-time remote monitoring of patients’ health indicators. IoMT

integrate several devices to capture sensitive medical data from devices such as implants and wearables that

results in cost-effective and improved health. In IoT settings, the Message Queuing Telemetry Transport

(MQTT) protocol is frequently used for machine-to-machine data transfer. However, secure transmission of

sensitive health data is critical because these devices are resource constrained and are more vulnerable to

MQTT based threats including brute force attack. This warrants a robust, effective, and reliable threat

mitigation mechanism, while maintaining a fine balance between accuracy and interpretability. Based on a

comprehensive overview of previous work and available datasets, we propose an explainable intrusion

detection mechanism to detect MQTT-based attacks. The MQTT-IOT-IDS2020 dataset is used as a

benchmark. Particle swarm optimization (PSO) is used for the selection of optimal features from the dataset.

The performance of ten machine learning (ML) methods is evaluated and compared. The results demonstrate

excellent classification accuracies between 97% and 99%. We applied LIME explanations to increase human

interpretability for the best performing model.

1 INTRODUCTION

The Internet of Medical Things (IoMT) is a

subcategory of the Internet of Things (IoT) that

focuses on the application of connected devices in the

healthcare domain. These devices enable continuous

monitoring and real-time data transmission, leading

to improved patient outcomes, reduced healthcare

costs, and increased overall efficiency. The IoMT

eco-system is vast, encompassing wearable devices,

remote patient monitoring systems, and smart

hospital infrastructure. IoMT devices are highly

sensitive and critical as they transmit sensitive data

which is used for diagnosis and treatment of patients.

(Alsabah et al., 2021), (Asghar et al., 2022). The

sensitive health data is vulnerable to unauthorized

access and data breaches. Among several

communication and messaging protocols that ensure

machine-to-machine data transfer among devices,

MQTT (Message Queuing Telemetry Transport) is

commonly used and widely adopted in IoT network

environments because of its capability to support

https://orcid.org/0000-0001-6898-4083

resource constrained devices. (Yao et al., 2019),

(Khan et al., 2021), (Hindy et al., 2021).

The legacy threats detection approaches have

proved ineffective amidst the above scenario. The

network traffic generated by such a huge number of

devices makes the security of IoT/IoMT structure a

critical factor to reckon with. The security

complications necessitate and underlie the

significance of a reliable and trustworthy security

mechanism for IoT (Fraile et al., 2018), (Ruzafa-

Alcazar et al., 2021).

There is growing interest in using machine

learning (ML) and deep learning (DL) driven

intrusion detection and security approaches to ensure

trustworthy, resilient, and reliable cyber threat

detection mechanisms. Several techniques have been

used in previous studies including. Based on the

overview presented in Section 2, we identified

relevant areas that needs to be explored further:

 Few studies use feature selection to optimize

model performance. Non-representative and

Memon, S., Wiil, U. and Shaikh, M.

Explainable Intrusion Detection for Internet of Medical Things.

DOI: 10.5220/0012210300003598

In Proceedings of the 15th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2023) - Volume 3: KMIS, pages 40-51

ISBN: 978-989-758-671-2; ISSN: 2184-3228

irrelevant features lead to increased complexity,

model convergence, and misclassification.

 Few studies focus on explainability aspects of

their models to increase human interpretability.

Lack of model explainability leads to lack of trust

in the results.

This paper presents a novel approach towards

explainable intrusion detection (XID) for IoMT. We

propose an intelligent framework that combines

Particle Swarm Optimization (PSO) and several ML

techniques to detect impending threats to IoMT and

health data. To the best of our knowledge, the

proposed approach with LIME-based explanations

using the MQTT-IOT-IDS2020 dataset has not been

used in previous studies. The contributions of this

study are:

 The use of PSO to select the optimal set of

features to increase model performance.

 Evaluation and comparison of ten different ML

classifiers to develop an effective model with

excellent performance.

 The use of LIME on the best performing model

to increase model insights and improve human

interpretability.

The rest of the paper is structured as follows:

Section 2 discusses the background and related work.

Section 3 describes the proposed approach for XID in

IoMT. Section 4 includes the evaluation of model

performance, results, and discussion. Section 5

concludes the paper and describe future work.

2 BACKGROUND AND RELATED

WORK

This section mainly focuses on describing major

security concerns and challenges of IoMT as well as

the reviewing state-of-the-art research related to the

use of artificial intelligence (AI) for intrusion

detection and threat mitigation strategies and

techniques. This section also highlights the

limitations of previous work.

2.1 IoT/IoMT Security Challenges

IoT devices are resource-constrained which make IoT

based infrastructure are vulnerable to several threats

including: DoS, DDoS, Mirai botnet, Spying, Scan,

Fuzzers, Backdoor, Packet Flooding, Vulnerability

Attack, Blackhole Attack, Sybil Attack, Sinkhole

Attack, Clone Attack and hello, flood attack, man-in-

the-middle (MitM), CPI Eavesdrop-ping, and system

identification attack. As such, the IoMT nodes are

super critical, being resource-constrained are

vulnerable and can be comprised. The intruders can

take advantage of these weaknesses by targeting them

and can cause severe damages in terms of

compromised data availability and data integrity (Jan

et al., 2019), (Vargas et al., 2021), (Bagaa et al.,

2020).

2.2 Intrusion Detection Systems

An intrusion detection system (IDS) is a threat or

cyber-attack detection mechanism (originating from

1999) as an approach that seeks to address the

security challenges by inspecting the data packets

(Elrawy et al., 2018). According to Man et al. (2021),

intrusion detection is of two kinds, mis-use-based and

anomaly-based. The misuse-based methods detect the

threat based on some already known or defined

patterns in the network traffic. An anomaly is an

unusual or abnormal activity in the network traffic

making it suspicious. Hence, anomaly-based

intrusion detection is used to segregate such patterns

in the traffic for maintaining the da-ta privacy and

detect malicious traffic patterns (Imrana et al., 2021),

(Belavagi & Muniyal, 2016).

The enormous number of IoMT devices generates

a large volume of data that requires further intelligent

data analysis and processing methods such DL. Latif

et al., 2020, stated that notwithstanding the fact the

IoMT is improving the efficiency, they are less se-

cure and remain always prone to varied types of

attacks.

Keeping in mind the limitations and specificity of

IoMT devices, traditional intrusion detection

mechanism become unsuitable and need to be

improved (Jan et al., 2019). Man et al. (2021) pointed

out that that ML approaches have the capability to

efficiently classify the anomalous trends in the

network traffic thereby detecting the threat. ML

methods learn to detect such activity in the network

that can be classified as anomaly or a threat. The

capability of ML classification methods to efficiently

classify the anomaly-based threats has inspired many

researchers to use these methods extensively.

2.3 Artificial Intelligence for Cyber

Security

In this section, we provide a comprehensive overview

of previously used AI techniques for cyber security

including ML, DL, PSO, and feature selection.

ML algorithms can analyze and identify malicious

patterns from huge data and network traffic to

Explainable Intrusion Detection for Internet of Medical Things

automate the threat detection and response

mechanism. ML can be trained on large datasets for a

wide range of security activities including: (i)

identifying and classifying different types of

malwares, (ii) intrusion detection, (iii) anomalies, (iv)

network traffic analysis (Xin et al., 2018). Similarly,

various DL algorithms have been proposed, including

Restricted Boltzmann Machine (RBM),

Convolutional Neural Network (CNN), Autoencoder,

and Recurrent Neural Networks (RNN) (Xin et al.,

2018), (Kirsch, 2018). Recent work has focused on

various AI algorithms, including:

 Decision Tree (DT) has been used for intrusion

detection, vulnerability assessment, and network

traffic analysis (Farnaaz and Jabbar, 2016).

 Random Forest (RF) has been used for malware

detection, network intrusion detection, and

classification of security events (Yang and

Sinaga, 2019).

 Support Vector Machine (SVM) has been used

for intrusion detection, malware detection, and

identification of network attacks (Thaseen and

Kumar, 2017).

 Clustering algorithms, such as k-means and

hierarchical clustering, have been used for

anomaly detection, network traffic analysis, and

malware classification (Yang and Sinaga, 2019),

(Kaluarachchi et al., 2021).

 DL algorithms such as convolutional neural

networks (CNNs), recurrent neural networks

(RNNs), autoencoders, have been used for

malware detection, intrusion detection, and

phishing detection (Peng et al., 2018), (Ahmad et

al., 2018), (Farnaaz and Jabbar, 2016).

 Federated Learning (FL), which is a

decentralized approach to training ML models,

has recently received attention in relation to ID

(Popoola et al., 2021).

 PSO has been used in various cyber security

applications such as ID, malware detection,

phishing detection, feature selection, and

parameter optimization (Chaddad et al., 2023),

(Adnan et al., 2021).

Feature selection is a critical step in developing

ML models, as non-representative and irrelevant

features can introduce noise into the dataset and lead

to overfitting issues. To avoid these problems,

datasets are often reduced to a relevant subset of

features. Appropriate feature selection leads to

optimized models that enhance overall performance

and accuracy while substantially reducing training

time. Unimportant features can also be

computationally burdensome and costly. As a result,

feature selection is a crucial technique for creating a

viable subset of features in machine learning models.

Commonly used feature selection approaches include

wrapper, filter, and intrinsic/hybrid methods

(Mukherjee and Sharma, 2012), (Gad et al., 2021),

(Jiang et al., 2020), (Awotunde et al., 2021), (Panda

et al., 2021), (Kumar et al., 2021).

Table 1 provides an overview of previous related

studies that have used feature selection as well as the

datasets used in these studies (see Section 2.4 for an

overview of datasets).

Table 1: Overview of studies using feature selection.

Study Feature selection technique Dataset

Kumar et al.,

2021)

Hybrid Feature Reduced

Approach using Correlation

coefficient, random forest,

mean decrease accuracy and

gain ratio.

NSL-

KDD,

BoT-IoT

and

DS2OS

Tsang and

Kwong, 2005

Used four unsupervised

technique for feature extraction.

KDD-

Cup99

Wu et al.,

2020

Feature-weighted support

vector machines (WSVM)

NSL-

KDD

Kasongo and

Sun, 2019

Filter based feature selection

algorithm.

NSL-

KDD)

(Mukherjee

and Sharma,

2012

Proposed Feature Vitality Based

Reduction Method (FVBRM)

NSL-

KDD

dataset.

Chen and

Hao, 2019

PCA–LDA --

Panda et al.,

2021

K-Medoid sampling and scatter

search-

ased feature

UNSW-

NB15

Ding et al.,

2020

Stack Sparse Autoencoder

(sSAE)

NSL-

KDD,

UNSW_

NB15

Alqahtani et

al., 2020

Fisher-score-based feature

selection method along with a

genetic-based extreme gradient

oosting (GXGBoost) model.

N-BaIoT

Derhab et al.,

2020

Feature space reduction and

feature transformation

technique.

Bot-IoT

Awotunde et

al., 2021

Hybrid rule-based feature

selection

NSL-

KDD and

UNSW-

NB15

KMIS 2023 - 15th International Conference on Knowledge Management and Information Systems

2.4 Publicly Available Datasets

A comprehensive review of previous work has

revealed several publicly available datasets that has

been used in previous studies:

 DARPA1998, KDD99, and NSL-KDD:

DARPA1998 dataset is one of the most used

datasets in IDS that contains four malware traffic

types i.e., DoS, Probe, U2R, and R2L as well as

normal traffic data (Wang et al., 2017). The

KDD99 dataset was created from DARPA1998

dataset and contains 41 traffic characteristics.

The KDD99 was improved and enhanced and

named NSL-KDD; it contains 125,973 records.

Conversely, these versions have become

obsolete. The reason for their being outdated is

that these versions no longer represent latest

threat traffic. Moreover, these datasets cannot be

used for IoT as they have non IoT representative

network traffic. (Wang et al., 2017).

 WSN-DS: This dataset was created for detection

of threat in wireless sensor networks (WSN).

This dataset contains four types of DoS attacks

i.e., Blackhole, Grayhole, Flooding, and

Scheduling having 23 features (Siddiqi and Pak,

2021).

 ISCX: This ID dataset was developed in 2012

having five types of attack traffic i.e., BruteForce

SSH, DDoS, HttpDoS, and Infiltrating along

with normal traffic [73]. For the development of

this dataset, a real time simulator was used to

generate simulated attack traffic. The attack

types are close to real world. This dataset

contains 82 features, five classes, and 73566

samples. However, this dataset does not

incorporate any new security events against IoT

sensors (Moustafa, 2021), (Wang et al., 2017).

 CICIDS2017: The CICIDS (Canadian Institute

for Cyber security Intrusion Detection System)

was created based on diverse normal and hack

scenarios. Concept of data profiling was

employed. The CICIDS dataset contain 79

features, 11 attack classes (including Benign,

BoT, DDoS, DoS/DDoS, PortScan, SSH, etc.),

and 786,633 samples (Wang et al., 2017).

 UNSW-NB15: The UNSW-NB15 dataset was

created at the University of New South Wales

(UNSW) Canberra to evaluate IDS. It consists of

162724 samples with a total of 10 classes,

including 9 attack classes and one normal class,

and has 42 features. However, the dataset does

not include security features related to IoT or

operating systems (Moustafa, 2021), (Wang et

al., 2017).

 Bot-IoT: The Bot-IoT dataset was created at the

UNSW with the primary goal of evaluating

intrusion detection and network forensics

systems. This dataset comprises 14 features,

including several IoT system features, and has 7

different attack classes with a total of 74680

attack samples. However, the dataset does not

include hacking vectors against IoT systems

(Moustafa, 2021), (Siddiqi and Pak, 2021).

 TON_IoT: This dataset is a database from the

UNSW that addresses the limitations of existing

datasets by incorporating four heterogeneous

data sources - Telemetry datasets of IoT and IoT

sensors, operating systems, and network traffic.

It contains the latest attack information related to

operating systems and IoT/IoMT devices. It

contains instances of normal and attack data.

This dataset can be used to develop machine

learning models. However, the dataset suffers

from an imbalance class issue as the number of

normal records exceeds the number of abnormal

records (Siddiqi and Pak, 2021), (Priya et al.,

2020).

 Kyoto: The Kyoto dataset was created using

honeypots at Kyoto University. The Kyoto

dataset contains traffic generated from honeypots

and not from real world environment having 24

statistical features. Out of these 24 features, 14

features are adopted from KDDCup 99. In

addition to this, 10 features were derived from

honeypot’s network traffic system (Siddiqi &

Pak, 2021). The drawback of this dataset is also

non representative of IoT systems (Moustafa,

2021).

 IoT-23: This dataset is considered as one of the

latest datasets containing information related to

IoT traffic and network monitoring. This dataset

was developed as a part of Stratosphere project

and contains 20 types of attacks including Mirai

and Torri for IoT devices and 3 types of benign

IoT devices traffic (Tsang and Kwong, 2005).

 N-BaIoT: This dataset was developed through a

simulated IoT environment to detect botnet

whereby IoT devices were connected through

WiFi, access points to switch, and router data

was gathered using Wireshark (Siddiqi and Pak,

2021).

 MQTT-IoT-IDS2020: Message Queuing

Telemetry Transport (MQTT) is one of the IoT

standard protocols used for machine-to-machine

communication. MQTT-IoT-IDS2020 dataset is

Explainable Intrusion Detection for Internet of Medical Things

simulated representation of an MQTT-based

network. This dataset consists of five different

scenarios, which include: (1) normal operation,

(2) aggressive scan, (3) UDP scan, (4) Sparta

SSH brute-force, and (5) MQTT brute-force

attack (Hindy et al., 2020).

Table 3 (Appendix) provides an overview of the

encountered publicly available datasets.

2.5 Overview of Related Work

There are several studies using either ML, DL, or a

hybrid approach for ID. Table 4 (Appendix) provides

an overview of multiple studies. The overview

focuses on the used AI technique(s), the used

dataset(s) and the obtained accuracy of each study.

2.6 Summary

The above review of related work reveals different

state-of-the-art techniques based on ML, DL, and

evolutionary computing used for intrusion detection

demonstrating good results in classifying threat types.

The review also identified areas that need further

studies, such as the use of feature selection techniques

to improve model performance and the use of

explainable AI techniques for increased trust in model

predictions.

3 MATERIALS AND METHODS

This section contains a description of the dataset and

the steps involved in developing the proposed model.

Figure 1 provides an overview of the steps.

The developed model aims to achieve a binary

classification of ATTACK and NO ATTACK. In

doing so we have used the MQTT-IOT-IDS2020

dataset as benchmark. The dataset contains several

features. Therefore, we have used the PSO algorithm

to achieve an optimal feature subset. The feature

subset was used as input for machine learning

classifiers. The performance of ten ML methods was

evaluated and compared. Finally, the best performing

classifier was explained using LIME to increase

human interpretability.

3.1 Dataset

The MQTT-IOT-IDS2020 generated by Hindy et al.

(2020) is publicly available. This dataset contains

both normal and malicious MQTT traffic. The

MQTT-IOT2020 datasets contains normal, uni-flow

Figure 1: Overview of machine learning pipeline.

and bi-flow. In this study, we have used bi-flow brute

force scenario category dataset which has a total of

16696 instances (2152 normal and 14544 attack) and

contains total 32 features inclusion the binary attack

class “is attack” feature having 0 for no attack and 1

representing the attack (Hindy et al., 2020). The

features of the dataset are:

3.2 Machine Learning Pipeline

Step 1: Data Preprocessing. Firstly, IP address

features, i.e., the ip_src and ip_dst, were handled

through encoding. Secondly, to interpret and easily

compare that data Min-max normalization was used

as preprocessing technique. (Sadaf and Sultana,

2020). The objective was to scale the numeric

features to some specific minimum and maximum

normalized range, i.e., between 0 and 1. The min-max

normalization is mathematically presented as:

X_normalized = (X - X_min)/(X_max - X_min).

Some of the features in the dataset were also treated

using label encoding and one-hot encoding technique

(Gad et al., 2021).

Step 2: Feature Selection. Feature selection is of

vital importance in ML processes. Feature selection

can help avoid dimensionality and over fitting issues

and improves model accuracy and performance.

Feature selection also enhance model explainability

KMIS 2023 - 15th International Conference on Knowledge Management and Information Systems

and interpretability. It is also noticeable that most ML

based IDS suffer from explainability and

interpretability. Explainability of AI models is

essential as it unfolds insights of black box models

(Ruzafa-Alcazar et al., 2021), (Kasongo, 2021),

(Fatani et al., 2022), (Jabbar et al., 2017). Therefore,

it has been recommended that AI models be

explainable and interpretable (Duque and Omar,

2015), (Saranya et al., 2020), (Priya et al., 2020).

Keeping this in mind, PSO based feature selection

was performed and as a result, out of the original 32

features, the following 22 features we selected using:

{'prt_src', 'prt_dst', 'proto', 'fwd_num_pkts',

'bwd_num_pkts', 'bwd_mean_iat', 'fwd_std_iat',

'bwd_min_iat', 'fwd_max_iat', 'bwd_max_iat',

'fwd_mean_pkt_len', 'bwd_mean_pkt_len',

'fwd_std_pkt_len', 'fwd_min_pkt_len',

'bwd_min_pkt_len', 'bwd_max_pkt_len',

'fwd_num_bytes', 'bwd_num_bytes',

'fwd_num_rst_flags', 'bwd_num_rst_flags',

'bwd_num_urg_flags'}.

Step 3. Dataset Splitting for Training and Testing.

The selected optimal subset of features was used as

the final dataset. The final dataset was further split

into two subsets, i.e., 80% for training and 20% for

testing and validating purposes.

Step 4. ML Algorithms for Classification. Ten

different ML techniques were used in the study: LR,

NB, KNN, SVM, MLP, DT, ET, RF, XGB, and SGD.

Each technique has its pros and cons. LR is a simple,

easy, and powerful algorithm, Naive Bayes (NB) is a

probabilistic algorithm that is also simple and fast.

KNN is a non-parametric and lazy algorithm that is

likely to be computationally expensive for large

datasets. SVM is a powerful method to handle linear

and non-linear data. SVM finds hyper plane for

classifications tasks. MLP is a type of ANNs and

consists of multiple layers. DT is also a supervised,

simple, and interpretable technique. RF is an

ensemble method which works by constructing

several trees for data. ET is also an ensemble method

and is an extension of RF. XGB is an optimized

implementation of gradient boosting. SGD is an

optimization technique.

4 RESULTS

In this section, the evaluation and comparison of the

above-mentioned ML models are presented. The

performance of the models is evaluated using typical

performance metrics, i.e., accuracy, precision, recall,

and F1_Score based on confusion matrix indicators

such as True Positive (TP), True Negative (TN), False

Positive (FP), and False Negative (FN). These metrics

suggest that all models have achieved very good

results, i.e., between 97% to 99%. Table 2 provides

an overview of the metrics for the ten ML techniques.

The proposed techniques achieved excellent

accuracies. Hindy et al. (2020) also achieved

excellent classification accuracy on the same dataset,

however no feature reduction technique or any

justification of selected features has been presented in

the paper. Another study by Vigoya et al. (2021)

validated two IoT datasets and obtained best mean

accuracy of 99% for the tree-based models. Khan et

al. (2021) also achieved more than 99% accuracy with

a DNN-based model. However, we did not find

studies using PSO based feature selection with

classification techniques using MQTT-IOT-

IDS2020. Also, none of these studies provide

explainability methods to facilitate human

interpretability.

Table 2: Model performance.

Model Accurac

Score Precision Recall

LR 0.97 0.98 1.0 0.98

NB 0.97 0.98 1.0 0.98

KNN 0.97 0.98 0.98 0.93

SVM 0.97 0.98 1.0 0.98

MLP 0.97 0.98 0.97 0.89

DT 0.99 0.99 0.99 0.98

ET 0.99 0.99 0.99 0.99

RF 0.99 0.99 0.99 0.99

XGB 0.99 0.99 0.99 0.98

SGD 0.97 0.98 1.0 0.98

4.1 LIME for Human Interpretability

According to Ribeiro and Guestrin (2016), model

evaluation solely based on accuracy does not suffice

as the real time data may differ significantly. Due to

their complex and black box nature, ML based

solutions (including IDS) suffer from lack of trust and

reliability (Yao et al., 2019), which has resulted in the

recent focus on explainable AI (XAI) as it offers

interpretation and understandability to the machine

learning model predictions (Ribeiro and Guestrin,

2016), (Adadi and Berrada, 2018). In this paper,

LIME has been used to provide XID (Chen and Lee,

2020), (Houda et al., 2022).

LIME stands for Local Interpretable Model-

agnostic Explanations. LIME enhances the

interpretability of machine learning models. LIME

Explainable Intrusion Detection for Internet of Medical Things

interprets the pre-diction of any classifier or repressor

thereby making the model more trustworthy.

LIME provides local interpretability that is based

on inspecting features of a specific instance. Figure 2

provides an example of the human interpretable

output of a classification of a particular instance (in

this case an attack instance).

Figure 2: LIME explanations.

The visualization in Figure 2 consists of three

parts. The left part (Prediction probabilities) reflects

100% confidence interval for detection of attack. The

middle part shows the feature importance score on the

selected sample. For instance, for proto with 14%

feature importance, bwd_min_pt_len 6% and so on.

This part shows the top ten features and their

respective values. The features highlighted in orange

(right part) show contributions toward class 1

(ATTACK), whereas features highlighted in blue

contribute toward class 0 (NO ATTACK). Figure 3

visualize the LIME generated feature importance.

Figure 3: LIME generated feature importance.

The bar graph in Figure 3 reflects local feature

explanations for attack class with features and their

respective values generated by LIME showing

contribution to classifications, such as ('proto <=

6.00', 0.144), ('bwd_min_pkt_len <= 52.00', 0.056),

('bwd_min_iat <= 0.00', 0.048), ('fwd_min_pkt_len

<= 52.00', 0.045), ('bwd_mean_pkt_len <= 54.00',

0.033), ('fwd_min_iat <= 0.00', 0.019),

('bwd_max_pkt_len <= 60.00', .0113),

('fwd_std_pkt_len <= 12.00', -0.011),

('fwd_mean_iat <= 3.00', 0.008), and

('fwd_mean_pkt_len <= 59.00', 0.007), respectively.

5 DISCUSSION

There is growing interest in using ML and DL driven

ID and security approaches. However, the issue of

trustworthiness of ML and DL models has raised

focus on the interpretability of these approaches.

This study demonstrates that PSO can be used to

optimize the selection of relevant features for IDS.

Using PSO, the features were reduced from 32 to 22.

PSO helped identify an optimal subset of relevant and

informative features, which lead to significantly

improved model accuracy and increased model

interpretability. Furthermore, given the overhead and

complexity of ID techniques, the reduced feature size

also leads to efficient utilization of resources given

the context of resource constrained devices.

LIME explanations demonstrate how each

selected feature contributes to classification both at

the class level (ATTACK or NO ATTACK) and at

the instance level. See Figures 3 and 2, respectively.

The study showcases that the chosen hybrid

approach using PSO for feature selection, ML models

for classification, and LIME based explanations for

model interpretability is a viable solution for accurate

XID.

The study also emphasizes the need to reconsider

the complex traffic patterns and the key security

concerns and challenges that data driven healthcare

faces.

The key lessons learnt include that evolutionary

computing techniques can be employed for an

efficient and optimal feature selection. This improves

model performance and interpretability and enables

more informed decision making. The study has

highlighted the significance of explainability,

interpretability, and gaining insights into the logic or

reason behind specific predictions, which help

increase the trust of domain experts and stakeholders

in the decision support. The development of trust can

further result in acceptance and adoption of ML based

ID models for resource constrained devices.

6 CONCLUSION

The paper provided a comprehensive overview of

state-of-the-art ML, DL, and hybrid techniques with

promising results. We also discussed datasets that are

KMIS 2023 - 15th International Conference on Knowledge Management and Information Systems

frequently used in ID research. Based on this, the

present study proposed a novel explainable intrusion

detection (XID) approach based on PSO based feature

selection and ten different ML classifiers trained and

tested on a new dataset in the domain of IoMT. LIME

has been applied to support human model prediction

interpretability using the classifier with the best

performance (ExtraTreeClasssifier). The approach

used typical performance metrics to test the validity

of the proposed XID methodology. Our proposed

hybrid methodology using PSO and ML has resulted

in an excellent attack classification accuracy between

97-99%.

LIME can be applied to wide range of models for

explainability. However, LIME can be

computationally expensive when applied to large

datasets. Hence as part of our future work, we plan to

test and use other explainable and interpretable AI

techniques such as SHAP to provide insights into how

the developed models work. We also plan to conduct

a systematic literature review to investigate and

compare various techniques for AI explainability to

provide insights into the strengths and weaknesses of

each technique in relation to XID.

Furthermore, we plan to use evolutionary

computing techniques such as Genetic Algorithm,

Ant Colony Optimization, Grey Wolf Optimization to

evaluate the performance of these as compared to the

ten developed ML models.

Finally, we plan perform a qualitative

reinforcement study (i.e., a Delphi study) involving

domain experts and other relevant stakeholders to

increase our understanding of how to best provide

future XID decision support.

REFERENCES

Aboelwafa, M. M. N., Seddik, K. G., Eldefrawy, M. H.,

Gadallah, Y., & Gidlund, M. (2020). A Machine-

Learning-Based Technique for False Data Injection

Attacks Detection in Industrial IoT. IEEE Internet of

Things Journal, 7(9). https://doi.org/10.1109/

JIOT.2020.2991693

Adadi, A., & Berrada, M. (2018). Peeking Inside the Black-

Box: A Survey on Explainable Artificial Intelligence

(XAI). IEEE Access, 6. https://doi.org/10.1109/

ACCESS.2018.2870052

Adnan, A., Muhammed, A., Ghani, A. A. A., Abdullah, A.,

& Hakim, F. (2021). An intrusion detection system for

the internet of things based on machine learning:

Review and challenges. Symmetry, 13(6).

https://doi.org/10.3390/sym13061011

Ahmad, I., Basheri, M., Iqbal, M. J., & Rahim, A. (2018).

Performance Comparison of Support Vector Machine,

Random Forest, and Extreme Learning Machine for

Intrusion Detection. IEEE Access, 6. https://doi.

org/10.1109/ACCESS.2018.2841987

Al-Haija, Q. A., & Zein-Sabatto, S. (2020). An efficient

deep-learning-based detection and classification

system for cyber-attacks in iot communication

networks. Electronics, 9(12). https://doi.org/10.3390/

ELECTRONICS9122152

Almomani, I., Al-Kasasbeh, B., & Al-Akhras, M. (2016).

WSN-DS: A Dataset for Intrusion Detection Systems in

Wireless Sensor Networks. Journal of Sensors.

https://doi.org/10.1155/2016/4731953

Alqahtani, M., Mathkour, H., & Ben Ismail, M. M. (2020).

IoT Botnet Attack Detection Based on Optimized

Extreme Gradient Boosting and Feature Selection.

Sensors, 20(21). https://doi.org/10.3390/S20216336

Alsabah, M., Naser, M. A., Mahmmod, B. M.,

Abdulhussain, S. H., Eissa, M. R., Al-Baidhani, A.,

Noordin, N. K., Sait, S. M., Al-Utaibi, K. A., &

Hashim, F. (2021). 6G Wireless Communications

Networks: A Comprehensive Survey. IEEE Access, 9.

https://doi.org/10.1109/ACCESS.2021.3124812

Anand, A., Rani, S., Anand, D., Aljahdali, H. M., & Kerr,

D. (2021). An efficient CNN-based deep learning

model to detect malware attacks (CNN-DMA) in 5G-

IoT healthcare applications. Sensors, 21(19).

https://doi.org/10.3390/s21196346

Asghar, M. Z., Memon, S. A., & Hämäläinen, J. (2022).

Evolution of Wireless Communication to 6G: Potential

Applications and Research Directions. Sustainability,

14(10). https://doi.org/10.3390/su14106356

Awotunde, J. B., Chakraborty, C., & Adeniyi, A. E. (2021).

Intrusion Detection in Industrial Internet of Things

Network-Based on Deep Learning Model with Rule-

Based Feature Selection. Wireless Comm and Mobile

Comp. https://doi.org/10.1155/2021/ 7154587

Bagaa, M., Taleb, T., Bernabe, J. B., & Skarmeta, A.

(2020). A Machine Learning Security Framework for

Iot Systems. IEEE Access, 8. https://doi.org/10.1109/

ACCESS.2020.2996214

Belavagi, M. C., & Muniyal, B. (2016). Performance

Evaluation of Supervised Machine Learning

Algorithms for Intrusion Detection. Procedia

Computer Science, 89. https://doi.org/10.1016/

j.procs.2016.06.016

Chaddad, A., Peng, J., Xu, J., & Bouridane, A. (2023).

Survey of Explainable AI Techniques in Healthcare.

Sensors, 23(2). https://doi.org/10.3390/s23020634

Chen, H. Y., & Lee, C. H. (2020). Vibration Signals

Analysis by Explainable Artificial Intelligence

(XAI) Approach: Application on Bearing Faults

Diagnosis. IEEE Access, 8. https://doi.org/10.1109/

ACCESS.2020.3006491

Chen, X., & Hao, X. (2019). Feature reduction method for

cognition and classification of IoT devices based on

artificial intelligence. IEEE Access, 7. https://doi.org/

10.1109/ACCESS.2019.2929311

CIC-IDS (2017). https://www.unb.ca/cic/datasets/nsl.html

Derhab, A., Aldweesh, A., Emam, A. Z., & Khan, F. A.

(2020). Intrusion Detection System for Internet of

Things Based on Temporal Convolution Neural

Explainable Intrusion Detection for Internet of Medical Things

Network and Efficient Feature Engineering. Wireless

Comm and Mobile Comp. https://doi.org/10.1155/

2020/6689134

Ding, P., Li, J., Wen, M., Wang, L., & Li, H. (2020).

Efficient BiSRU combined with feature dimensionality

reduction for abnormal traffic detection. IEEE Access,

8. https://doi.org/10.1109/ACCESS.2020.3022355

Duque, S., & Omar, M. N. Bin. (2015). Using Data Mining

Algorithms for Developing a Model for Intrusion

Detection System (IDS). Procedia Computer Science,

61. https://doi.org/10.1016/j.procs.2015.09.145

Elrawy, M. F., Awad, A. I., & Hamed, H. F. A. (2018).

Intrusion detection systems for IoT-based smart

environments: a survey. Journal of Cloud Computing,

7(1). https://doi.org/10.1186/s13677-018-0123-6

Farnaaz, N., & Jabbar, M. A. (2016). Random Forest

Modeling for Network Intrusion Detection System.

Procedia Computer Science, 89. https://doi.org/

10.1016/j.procs.2016.06.047

Fatani, A., Dahou, A., Al-qaness, M. A. A., Lu, S., & Abd

Elaziz, M. A. (2022). Advanced Feature Extraction and

Selection Approach Using Deep Learning and Aquila

Optimizer for IoT Intrusion Detection System. Sensors,

22(1). https://doi.org/10.3390/S22010140

Fraile, F., Tagawa, T., Poler, R., & Ortiz, A. (2018).

Trustworthy Industrial IoT Gateways for

Interoperability Platforms and Ecosystems. IEEE

Internet of Things Journal, 5(6). https://doi.org/

10.1109/JIOT.2018.2832041

Gad, A. R., Nashat, A. A., & Barkat, T. M. (2021). Intrusion

Detection System Using Machine Learning for

Vehicular Ad Hoc Networks Based on ToN-IoT

Dataset. IEEE Access, 9. https://doi.org/10.1109/

ACCESS.2021.3120626

Gao, X., Hu, C., Shan, C., Liu, B., Niu, Z., & Xie, H.

(2020). Malware classification for the cloud via semi-

supervised transfer learning. Journal of Information

Security and Applications, 55. https://doi.org/10.1016/

j.jisa.2020.102661

Ghanem, W. A. H. M., Jantan, A., Ghaleb, S. A. A., &

Nasser, A. B. (2020). An Efficient Intrusion Detection

Model Based on Hybridization of Artificial Bee Colony

and Dragonfly Algorithms for Training Multilayer

Perceptrons. IEEE Access, 8. https://doi.org/10.1109/

ACCESS.2020.3009533

Ghubaish, A., Salman, T., Zolanvari, M., Unal, D., Al-Ali,

A., & Jain, R. (2021). Recent Advances in the Internet-

of-Medical-Things (IoMT) Systems Security. IEEE

Internet of Things Journal, 8(11). https://doi.org/

10.1109/JIOT.2020.3045653

Hindy, H., Bayne, E., Bures, M., Atkinson, R., Tachtatzis,

C., & Bellekens, X. (2021). Machine Learning Based

IoT Intrusion Detection System: An MQTT Case Study

(MQTT-IoT-IDS2020 Dataset). Lecture Notes in

Networks and Systems, 180. https://doi.org/10.1007/

978-3-030-64758-2_6

Houda, Z. A. El, Brik, B., & Khoukhi, L. (2022). “Why

Should I Trust Your IDS?”: An Explainable Deep

Learning Framework for Intrusion Detection Systems

in Internet of Things Networks. IEEE Open Journal of

the Communications Society, 3. https://doi.org/

10.1109/OJCOMS.2022.3188750

Huma, Z. E., Latif, S., Ahmad, J., Idrees, Z., Ibrar, A., Zou,

Z., Alqahtani, F., & Baothman, F. (2021). A Hybrid

Deep Random Neural Network for Cyberattack

Detection in the Industrial Internet of Things. IEEE

Access, 9. https://doi.org/10.1109/ACCESS.

2021.3071766

IoT-23 (2020). https://www.kaggle.com/datasets/ engraq

eel/iot23preprocesseddata

Imrana, Y., Xiang, Y., Ali, L., & Abdul-Rauf, Z. (2021). A

bidirectional LSTM deep learning approach for

intrusion detection. Expert Systems with Applications,

185. https://doi.org/10.1016/j.eswa.2021.115524

ISCXIDS (2012). https://www.unb.ca/cic/datasets/nsl.html

Jabbar, M. A., Aluvalu, R., & Reddy, S. S. (2017).

RFAODE: A Novel Ensemble Intrusion Detection

System. Procedia Computer Science, 115, 226–234.

https://doi.org/10.1016/j.procs.2017.09.129

Jan, S. U., Ahmed, S., Shakhov, V., & Koo, I. (2019).

Toward a Lightweight Intrusion Detection System for

the Internet of Things. IEEE Access, 7. https://doi.org/

10.1109/ACCESS.2019.2907965

Jiang, H., He, Z., Ye, G., & Zhang, H. (2020). Network

Intrusion Detection Based on PSO-Xgboost Model.

IEEE Access, 8. https://doi.org/10.1109/

ACCESS.2020.2982418

Kaluarachchi, T., Reis, A., & Nanayakkara, S. (2021). A

review of recent deep learning approaches in human-

centered machine learning. Sensors, 21(7).

https://doi.org/10.3390/s21072514

Kasongo, S. M. (2021). An advanced intrusion detection

system for IIoT Based on GA and tree based algorithms.

IEEE Access, 9. https://doi.org/10.1109/

ACCESS.2021.3104113

Kasongo, S. M., & Sun, Y. (2019). A deep learning method

with filter based feature engineering for wireless

intrusion detection system. IEEE Access, 7.

https://doi.org/10.1109/ACCESS.2019.2905633

Khan, M. A. M. A., Khan, M. A. M. A., Jan, S. U., Ahmad,

J., Jamal, S. S., Shah, A. A., Pitropakis, N., &

Buchanan, W. J. (2021). A deep learning-based

intrusion detection system for mqtt enabled iot.

Sensors, 21(21). https://doi.org/10.3390/s21217016

Kirsch, J. H. and D. (2018). Machine Learning For

Dummies®, IBM Limited Edition Published. In

Journal of the American Society for Information

Science, 35, 5. https://doi.org/10.1002/asi.4630350509

Kumar, P., Gupta, G. P., & Tripathi, R. (2021). Toward

Design of an Intelligent Cyber Attack Detection System

using Hybrid Feature Reduced Approach for IoT

Networks. Arab Journal for Science and Eng, 46(4).

https://doi.org/10.1007/S13369-020-05181-3

Kyoto (2006), https://www.impactcybertrust.org/

dataset_view?idDataset=918

Latif, S., Huma, Z. e, Jamal, S. S., Ahmed, F., Ahmad, J.,

Zahid, A., Dashtipour, K., Umar Aftab, M., Ahmad, M.,

& Abbasi, Q. H. (2021). Intrusion Detection

Framework for the Internet of Things using a Dense

KMIS 2023 - 15th International Conference on Knowledge Management and Information Systems

Random Neural Network. IEEE Trans on Industrial

Informatics. https://doi.org/10.1109/tii.2021.3130248

Man, D., Zeng, F., Yang, W., Yu, M., Lv, J., & Wang, Y.

(2021). Intelligent Intrusion Detection Based on

Federated Learning for Edge-Assisted Internet of

Things. Security and Communication Networks, 2021.

https://doi.org/10.1155/2021/9361348

Mendonca, R. V., Teodoro, A. A. M., Rosa, R. L., Saadi,

M., Melgarejo, D. C., Nardelli, P. H. J., & Rodriguez,

D. Z. (2021). Intrusion Detection System Based on Fast

Hierarchical Deep Convolutional Neural Network.

IEEE Access, 9. https://doi.org/10.1109/

ACCESS.2021.3074664

Moustafa, N. (2021). A new distributed architecture for

evaluating AI-based security systems at the edge:

Network TON_IoT datasets. Sustainable Cities and

Society, 72. https://doi.org/10.1016/j.scs.2021.102994

MQTT-IOT (2020). https://ieee-dataport.org/open-access/

mqtt-iot-ids2020-mqtt-internet-things-intrusion-detecti

on-dataset

Mukherjee, S., & Sharma, N. (2012). Intrusion Detection

using Naive Bayes Classifier with Feature Reduction.

Procedia Technology, 4. https://doi.org/10.1016/

j.protcy.2012.05.017

Naseer, S., Saleem, Y., Khalid, S., Bashir, M. K., Han, J.,

Iqbal, M. M., & Han, K. (2018). Enhanced network

anomaly detection based on deep neural

networks. IEEE Access, 6. https://doi.org/10.1109/

ACCESS.2018.2863036

N-BaIoT (2018). https://www.kaggle.com/datasets/

mkashifn/nbaiot-dataset

Panda, M., Mousa, A. A. A., & Hassanien, A. E. (2021).

Developing an Efficient Feature Engineering and

Machine Learning Model for Detecting IoT-Botnet

Cyber Attacks. IEEE Access, 9. https://doi.org/10.1109/

ACCESS.2021.3092054

Peng, K., Leung, V. C. M., Zheng, L., Wang, S., Huang, C.,

& Lin, T. (2018). Intrusion detection system based on

decision tree over big data in fog environment. Wireless

Comm and Mobile Comp. https://doi.org/10.1155/

2018/4680867

Popoola, S. I., Adebisi, B., Ande, R., Hammoudeh, M.,

Anoh, K., & Atayero, A. A. (2021). Smote-drnn: A

deep learning algorithm for botnet detection in the

internet-of-things networks. Sensors, 21(9).

https://doi.org/10.3390/s21092985

Priya, V., Thaseen, I. S., Gadekallu, T. R., Aboudaif, M. K.,

& Nasr, E. A. (2020). Robust attack detection approach

for iiot using ensemble classifier. Comp, Mat and Cont,

66(3). https://doi.org/10.32604/cmc.2021.013852

Qureshi, A. U. H., Larijani, H., Mtetwa, N., Javed, A., &

Ahmad, J. (2019). RNN-ABC: A new swarm

optimization based technique for anomaly detection.

Computers, 8(3). https://doi.org/10.3390/computers

8030059

Ribeiro, M. T., & Guestrin, C. (2016). “ Why Should I Trust

You ?” Explaining the Predictions of Any Classifier.

Ruzafa-Alcazar, P., Fernandez-Saura, P., Marmol-Campos,

E., Gonzalez-Vidal, A., Hernandez Ramos, J. L.,

Bernal, J., & Skarmeta, A. F. (2021). Intrusion

Detection based on Privacy-preserving Federated

Learning for the Industrial IoT. IEEE Trans on

Industrial Informatics, 1–10. https://doi.org/10.1109/

TII.2021.3126728

Sadaf, K., & Sultana, J. (2020). Intrusion detection based

on autoencoder and isolation forest in fog computing.

IEEE Access, 8. https://doi.org/10.1109/ ACCESS.

2020.3022855

Saranya, T., Sridevi, S., Deisy, C., Chung, T. D., & Khan,

M. K. A. A. (2020). Performance Analysis of Machine

Learning Algorithms in Intrusion Detection System: A

Review. Procedia Computer Science, 171. https://doi.

org/10.1016/j.procs.2020.04.133

Siddiqi, M. A., & Pak, W. (2021). An Agile Approach to

Identify Single and Hybrid Normalization for

Enhancing Machine Learning-Based Network Intrusion

Detection. IEEE Access, 9. https://doi.org/10.1109/

ACCESS.2021.3118361

Sumaiya Thaseen, I., & Aswani Kumar, C. (2017).

Intrusion detection model using fusion of chi-square

feature selection and multi class SVM. Journal of King

Saud University - Computer and Information Sciences,

29(4). https://doi.org/10.1016/j.jksuci.2015.12.004

Tavallaee, M., Bagheri, E., Lu, W. & Ghorbani A. A., A

detailed analysis of the KDD CUP 99 data set, 2009

IEEE Symp on Comp Intel for Security and Defense

Applications. doi: 10.1109/CISDA.2009.5356528.

Tian, Q., Li, J., & Liu, H. (2019). A Method for

Guaranteeing Wireless Communication Based on a

Combination of Deep and Shallow Learning. IEEE

Access, 7. https://doi.org/10.1109/ACCESS. 2019.

2905754

TS, P., & Shrinivasacharya, P. (2021). Evaluating neural

networks using Bi-Directional LSTM for network IDS

in cyber security. Global Transition Proc, 2(2).

https://doi.org/10.1016/ j.gltp.2021.08.017

Tsang, C. H., & Kwong, S. (2005). Multi-agent intrusion

detection system in industrial network using ant colony

clustering approach and unsupervised feature

extraction. Proceedings of the IEEE Inter Conf on Ind

Tech. https://doi.org/10.1109/ICIT.2005.1600609

UNSW (2015). https://research.unsw.edu.au/projects/

unsw-nb15-dataset

UNSW (2019). https://research.unsw.edu.au/projects/bot-

iot-dataset

UNSW (2021). https://research.unsw.edu.au/projects/

toniot-datasets

Vargas, H., Lozano-Garzon, C., Montoya, G. A., &

Donoso, Y. (2021). Detection of security attacks in

industrial iot networks: A blockchain and machine

learning approach. Electronics, 10(21). https://doi.

org/10.3390/electronics10212662

Vigoya, L., Fernandez, D., Carneiro, V., & Nóvoa, F. J.

(2021). IoT dataset validation using machine learning

techniques for traffic anomaly detection. Electronics,

10(22). https://doi.org/10.3390/electronics10222857

Wang, W., Sheng, Y., Wang, J., Zeng, X., Ye, X., Huang,

Y., & Zhu, M. (2017). HAST-IDS: Learning

Hierarchical Spatial-Temporal Features Using Deep

Neural Networks to Improve Intrusion Detection. IEEE

Explainable Intrusion Detection for Internet of Medical Things

Access, 6. https://doi.org/10.1109/ACCESS.2017.

2780250

Wu, Y., Lee, W. W., Xu, Z., & Ni, M. (2020). Large-scale

and robust intrusion detection model combining

improved deep belief network with feature-weighted

svm. IEEE Access, 8. https://doi.org/10.1109/

ACCESS.2020.2994947

Xin, Y., Kong, L., Liu, Z., Chen, Y., Li, Y., Zhu, H., Gao,

M., Hou, H., & Wang, C. (2018). Machine Learning

and Deep Learning Methods for Cybersecurity. IEEE

Access, 6. https://doi.org/10.1109/ACCESS.2018.

2836950

Yang, M. S., & Sinaga, K. P. (2019). A feature-reduction

multi-view k-means clustering algorithm. IEEE Access,

7. https://doi.org/10.1109/ACCESS.2019.2934179

Yao, H., Gao, P., Zhang, P., Wang, J., Jiang, C., & Lu, L.

(2019). Hybrid intrusion detection system for edge-

based IIoT relying on machine-learning-aided

detection. IEEE Network, 33(5). https://doi.org/

10.1109/MNET.001.1800479

Yoo, J., Min, B., Kim, S., Shin, D., & Shin, D. (2021).

Study on Network Intrusion Detection Method Using

Discrete Pre-Processing Method and Convolution

Neural Network. IEEE Access, 9. https://doi.org/

10.1109/ACCESS.2021.3120839

Yu, Y., Long, J., & Cai, Z. (2017). Network Intrusion

Detection through Stacking Dilated Convolutional

Autoencoders. Security and Communication Networks.

https://doi.org/10.1155/2017/4184196

Zavrak, S., & Iskefiyeli, M. (2020). Anomaly-Based

Intrusion Detection from Network Flow Features Using

Variational Autoencoder. IEEE Access, 8.

https://doi.org/10.1109/ACCESS.2020.3001350.

APPENDIX

Table 3: Overview of publicly available datasets.

Dataset Threat type Features Records Limitations

NSL-KDD

(Tavallaee et al., 2009)

Four malware traffic types i.e., DoS,

Probe, U2R, and R2L

41 125,973 Non IoT

WSN-DS

(Almomani et al., 2016)

DoS attacks (Blackhole, Grayhole,

Flooding, and Scheduling)

23 NA WSN

ISCX (ISCXIDS, 2012) BruteForce SSH, DDoS, HttpDoS 82 73566 Non IoT

CICIDS2017

(CIC-IDS, 2017)

Benign, BoT,DDoS, DoS/DDoS,

PortScan, SSH

79 786,633 NA

UNSW-NB15 (UNSW,

2015)

9 attack classes 42 162724 Non IoT

Bot-IoT (UNSW, 2019) 7 attack classes 14 74680 Non IoT

TON_IoT (UNSW, 2021)

DoS, DDoS, R2L, U2R, probe attacks

NA NA IoT/Imbalance

Kyoto (Kyoto, 2006)

10 Honeypots generated features and 14

adopted from KDDcup99.

24 NA Non IoT

IoT-23 (IoT-23, 2020)

20 types of attacks including Mirai and

Torri etc. 3 types of benign IoT devices

traffic

23 NA IoT traffic

N-BaIoT (N-BaIoT, 2018)

Public botnet IoT dataset.

115

7062606

IoT

MQTT-IoT-IDS2020

(MQTT-IOT, 2020)

Contain simulated five MQTT-based

network attack scenarios including the

Brute Force attack.

32 16696 IoT

KMIS 2023 - 15th International Conference on Knowledge Management and Information Systems

Table 4: Overview of recent intrusion detection studies.

Study AI technique(s) Type Dataset(s) Accuracy

Yao et al., 2019 Light GBM DL NSL-KDD and CSE-CIC-IDS

2018

Khan et al., 2021 DNN DL MQTT-IoT-IDS2020 NA

Imrana et al., 2021 Bidirectional Long-Short-Term-

Memory (BiDLSTM)

DL NSL-KDD 94.26%

Belavagi and Muniyal 2016) LR, Gaussian NB, SVM, RF ML NSL-KDD NA

Mukherjee and Sharma, 2012 Naive Bayes ML NSL-KDD NA

Gad et al., 2021 XGBoost ML Ton_IoT NA

Jiang et al., 2020 PSO, XGBoost ML NSL-KDD NA

Ghanem et al., 2020 Hybridization of ABC and Dragonfly

algorithm (DA) for training ANN

Hybrid KDD CUP 1999, NSL-KDD,

UNSW- NB15, and ISCX2012

Awotunde et al., 2021 DFFNN DL NSL-KDD and UNSW-NB15 NA

TS & Shrinivasacharya, 2021 Bi-directional LSTM DL KDDCUP-99 and UNSW-

NB15

99%

Sadaf and Sultana, 2020 Autoencoder and IF DL NLS-KDD 95.40%

Yoo et al., 2021 CNN DL NSL-KDD and CSE-CIC-IDS

2018

Qureshi et al., 2019 RNN-ABC Hybrid NLS-KDD 91.65%

Huma et al., 2021 DRaNN and MLP DL DS2OS and UNSW-NB15 98%

Anand et al., 2021 CNN DL Malimg 99%

Adnan et al., 2021 Neural Network (NN) DL KDD99, NSLand Kyoto NA

Naseer et al., 2018 Autoencoder and CNN DL NSLKDD NA

Latif et al., 2021 DnRaNN DL ToN_IoT 99.14%

Popoola et al., 2021 SMOTE-DRNN DL Bot-IoT NA

Aboelwafa et al., 2020 Autoencoder DL NA NA

Ruzafa-Alcazar et al., 2021 FL FL ToN IoT NA

Kasongo, 2021 GA-RF Hybrid UNSW-NB15 87.61%

Fatani et al., 2022 CNN, SI Hybrid CIC2017, NSL-KDD, BoT-

IoT, and KDD99

Jabbar et al., 2017 RF and AODE. Average One-

Dependence Estimator (AODE) based

ML Kyoto 90.51%

Duque and Omar, 2015 K-means clustering ML NSL-KDD NA

Saranya et al., 2020 Linear Discriminant Analysis (LDA),

Classification and Regression Trees

compared along with the latest research.

(CART) and Random Forest.

ML KDD-CUP NA

Priya et al., 2020 Multi class SVM ML NSL-KDD NA

Tian et al., 2019 Auto encoder and SVM ML/DL NA NA

Mendonca et al., 2021 Tree-CNN ML/DL CICIDS2017 98%

Ribeiro and Guestrin, 2016 Lime explanation technique XAI NA NA

Adadi and Berrada, 2018 DNN with Lime and Shap XAI NSL-KDD, UNSW-NB15 NA

Chen and Lee, 2020 Random Forest with Lime

interpretations

XAI NA 100%

Explainable Intrusion Detection for Internet of Medical Things
