JThermodynamicsCloud: Case Study in an Ontology-Driven NoSQL

Database Cloud Based Application in Chemical Domain

Edward Blurock

Blurock Consulting AB, Lund, Sweden

Keywords: Model Driven Development, MDD, MDA, Ontology-Driven, NoSQL, Cloud-Based Application, Chemistry,

Thermodynamics, Database Management.

Abstract: JThermodynamicsCloud is software service for the combustion research domain to perform thermdynamic

calculations and manage the data needed to make those calculations. The JThermodynamicsCloud service can

be said to be a model driven application, where the ontology is a platform independent model of the data and

operational structures. All the ontology concepts outlined here, from the ontology definition to the utilization

of this definition in the application, have been implemented. The ontology, as used by the service, has three

distinct purposes: documentation, data structure definition and operational definitions. One goal of the

ontology is to place as much of the design and domain specific structures in the ontology rather than in the

application code. The calculation itself is highly dependent on the varied types of molecular data found in the

database The complete service is a system with three interacting components, a user interface using Angular,

a (RESTful) backend written in JAVA (with the JENA API interpreting the ontology) and the Google

Firestore noSQL document database and Firebase storage.

1 INTRODUCTION

JThermodynamicsCloud is software service for the

chemical, or more specifically, the combustion

research domain. The primary purpose is to perform

the calculation and manage the data needed to make

the calculation. The complete service is a system with

three interacting components, a GUI interface, a

RESTful backend and a noSQL document-based

database. The service uses these three components to

make calculations for thermodynamic quantities

based on molecular species structure. The calculation

itself is highly dependent on the varied types of

molecular data found in the database.

JThermodynamicsCloud service can be said to be

a model driven application where the model is

defined in the ontology. JThermodynamicsCloud is

comprised of three different platforms with three

different data formats. The user interface uses

Angular (Angular, n.d.), the (RESTful) backend is

written in JAVA and the Google Firestore (Cloud

Firestore | Store and Sync App Data at Global Scale,

n.d.) noSQL document database has a map-based data

format. These different data formats are united

https://orcid.org/0000-0001-9487-3141

through the platform independent ontology

definitions. All definitions and methodologies within

all three systems of the service have a corresponding

ontology classes. This means that communication

between systems has an ontology reference. In

particular the data structures. This is particularly

important because the data structures in each of the

systems are in a free format, namely, property name

and untyped value pairs. The ontology provides the

underlying structure by defining the property name

and the information that field contains. The ontology

definitions are translated to the exact data structures

within each of the respective systems. In all systems,

the data structure is a JSON like data structure.

1.1 Background and Context

The use of ontologies in software engineering is, of

course, not new (Bhatia & Beniwal, 2016; Espinoza-

Arias et al., 2021). This application can be seen as an

application of ontologies in a Model Driven

Development (Bučko et al., 2019; Silva Parreiras et

al., 2010) or Model Driven Engineering (Gaševic et

al., 2009) context, where the ontology guides the

288

Blurock, E.

JThermodynamicsCloud: Case Study in an Ontology-Driven NoSQL Database Cloud Based Application in Chemical Domain.

DOI: 10.5220/0012254700003598

In Proceedings of the 15th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2023) - Volume 2: KEOD, pages 288-295

ISBN: 978-989-758-671-2; ISSN: 2184-3228

development of the software, particularly the data

structures and the operational definitions using the

data structures. In a sense, all the modeling languages

such as the Unified

Modelling Language (UML), Meta Object Facility

(MOF), XML Metadata Interchange

(XMI), and the Common Warehouse Metamodel

(CWM), are taken over by the use of ontology of the

application. The modelling descriptions needed for

the JThermodynamicsCloud application are handled

solely by the ontology.

The ontology data model is currently not used to

actually generate software code, though this has been

experimented with in the CHEMCONNECT(E.

Blurock, 2021; E. S. Blurock, 2019) application

(which is at the base of JThermodynamicsCloud). But

the ontology definitions do specify, within a Model

Driven Architecture (Bučko et al., 2019), the top two

levels of abstraction, namely the Computer

Independent Model (CIM) and Platform Independent

Model (PIM). A common ontology class defines data

and operational classes that are common to the three

platforms within the system, namely the interface, the

background and the database. The ontology is

interpreted under runtime by the background service,

written in JAVA, and uses the JENA API(Apache,

n.d.). SPARQL queries are made, and the answers are

converted to appropriate data structures.

Another advantage that was exploited with using

ontologies in the data modelling approach is working

toward developing a ‘normalized system’(De Bruyn

et al., 2018; Suchánek et al., 2021). The five

necessary conditions can be seen directly in the

ontology definition. ‘Separation of Concerns’ can be

seen in the data structure class and operational

definition classes. ‘Separation of Actions’ can be seen

not only in the operational classes’ definition, but also

the concept of transactions (see section Ontology

Transaction Definition), which break down a task into

individual and traceable subtasks. ‘Action Version’

and ‘Data Version’ transparency can be seen in

modularity and how data is passed between

operational units in the software.

2 MOTIVATIONS AND USE OF

ONTOLOGIES

The following outlines how the ontology was used

and implemented. All the concepts, definitions and

code have been implemented in the current version of

JThermodynamicsCloud. The Results:

EXPERIENCE section outlines the experiences and

advantages of the use of ontologies as outlined in this

paper.

Within this section, ontology class names and

identifiers have the form:

namespace:nameofclass

The namespace denotes which ontology the class is

defined. For example, all with the namespace

dataset are from the JThermodynamicCloud

ontology. The JThermodynamicCloud ontology with

all the definitions shown in this section can be found

in github:

https://github.com/blurock/Angular/releases

2.1 General Goals of Ontology

The ontology as used by JThermodynamicsCloud has

three distinct purposes, documentation, data structure

definition and operational definitions. These are

briefly outlined in the following sections.

2.1.1 Documentation

Through annotations and the hierarchy of ontology

classes a level of documentation is provided that is

not inherently present within the software

implementation definitions. Through the class

hierarchy a context is given to each object and

through the annotations there is human and machine

readable documentation.

2.1.2 Data Structure Definition

Every data object in JThermodynamicsCloud has a

respective ontology definition. This gives a common

reference for how each data structure is translated in

the different software components of the system.

Since the definition is machine readable, this allows

a certain amount of automation, for example in the

user interface, to take place. For the software

engineer, this common reference provides the

template for accessing data from the data structures

which is not otherwise present because the data

structures themselves are inherently non-typed and

free format.

2.1.3 Operational Definitions

In addition to data structures within the system, there

are also sets of algorithms using these data structures.

Certain classes of algorithms have corresponding

ontology definitions. For example, all RESTful

services have a corresponding ontology definition. In

addition, within the background system, certain

classes of working algorithms (programmed using the

enumeration class in JAVA) have ontology

JThermodynamicsCloud: Case Study in an Ontology-Driven NoSQL Database Cloud Based Application in Chemical Domain

289

definitions. These are often associated with pull-

down list choices within the interface or specific

related manipulations dependent on classes of data

types. This is an example of the backend interpreting

the ontology and delivering the appropriate data

structure to the interface.

2.2 Uses of the Ontology

The following subsections provide a summary of how

ontologies are implemented and utilized in multiple

capacities in JThermodynamicCloud. In later

sections, some of these applications are elaborated

with more details.

2.2.1 JSON Data Object Definitions

The JSON (like) representation, meaning property-

value pairs is used throughout

JThermodynamicsCloud. However, JSON is a an

untyped and free-format language, meaning that the

only information about the fields in the JSON object

are the property labels. Use of ontologies provides

context and documentation of the fields within the

JSON objects. There is a one-to-one correspondence

between the data object definition and the ontology

class. The ontology is what defines the type of the

data object for each property label within the free-

format context. This is further outlined in JSON data

object definitions.

2.2.2 RESTful Service Definition

The functionality of JThermodynamicsCloud are

accessed through the RESTful services. The RESTful

service ontology is used to provide context, through a

hierarchy of definitions, and, within each class

definition, the input and output objects expected from

the restful service. In addition, annotations to each

class give further documentation. These are defined

in a subclass of

dataset:DatabaseServicesBase

which is a subclass of the prov:SoftwareAgent (of

the PROV ontology). This is further outlined in

RESTful Service Definition.

2.2.3 Transaction Description

Transactions represent class of RESTful services

which modify the database (as opposed to services

which perform only queries on the ontology and the

database). The corresponding ontology class specifies

the input, output and prerquisites of the transaction.

See the Section Ontology Transaction Definition.

2.2.4 Database Structure Hierarchy

The noSQL document database of

JThermodynamicsCloud is a hierarchy of collections

and documents. All catalog objects are 'documents'

(in the sense of the noSQL database) located at the

end root nodes of the hierarchy. The hierarchy

position of the collection of catalog objects

types gives a context to the objects. The database

definition ontology is used to define this

hierarchial structure. Within this definition is

which catalog object type is being defined and

how the nodes leading to the catalog object are to

be named. These are defined in a subclass of

dataset:CollectionDocumentHierarchy which is a

subclass of the skos:Concept (of the SKOS

ontology). This is further outlined in Database

Hierarchy Specification in the Ontology.

2.2.5 Classification Components

Some single string valued components (in the sense

of the DCAT ontology) represent classifications

(enumerations) with specific values. The ontology

definition of the component points to the top of a

hierarchy (for a tree classification) or the top of a set

of subclasses (for a list). In the annotations of these

subclasses are labels and comments that can be used

for the user interface (and documentation). The

subclasses can be components, if the selection should

be, for example, types or records or catalog object (in

the sense of the DCAT ontology), if the selection

should have more information.

2.2.6 Implementation Operations by Type

Often within the implementation there are set of

similar operations, with the same input, but

different functionalities based on type. In JAVA this

is an enumeration with abstract methods. In the

ontology, these are defined in a subclass of

dataset:DataObjectManipulation which is a

subclass of the

prov:SoftwareAgent (of the PROV

ontology (Timothy Lebo, Satya Sahoo, Deborah

McGuinness, 2013)).

2.2.7 Units

An important aspect of scientific numerical data is

units. JThermodynamicsCloud uses the QUDT

ontology (QUDT, 2018) to enable the transformation

of one unit to another. In general, the original units,

i.e. that of the source data, are stored in the database.

In the calculation and presentation, the user can

choose the preferred units. The QUDT ontology

KEOD 2023 - 15th International Conference on Knowledge Engineering and Ontology Development

290

includes all the transformation parameters needed.

This is further outlined in Parameters and Units:

QUDT ontology.

2.3 JSON Data Object Definitions

The representation of data objects in

JThermodynamicCloud has a JSON like structure,

i.e. property label with a corresponding value. This

design decision allows the same data representation

to be used even though the syntactical form within

each of the different system components can differ.

The JAVA objects in the background services are

based on

com.google.gson.Gson, the data objects in

the Angular Material are based on typescript JSON

objects, the RESTful service representation of data in

the body are JSON objects and in the database the

JSON objects translate directly to the mapping

structure used in the Google Firebase Firestore

representation. This common format design makes

the transitions, between user interface, backend

computation/manipulation and database access

seamless. The ontology definition also gives the

software engineer managing and programming the

system a common reference.

The JSON format is non-typed and free-format

and thus the only documentation of the objects

themselves are the keywords of the fields. In

JThermodynamicsCloud, the ontology definitions

provide machine and human interpretable

documentation and context to the JSON data objects.

There is a one-to-one correspondence between each

JSON object type and the ontology class. The JSON

objects are modelled in the ontology after the DCAT

ontology. The keywords of the JSON objects are

defined in the

dcterm:identifier field in the

annotations. The annotations also give human

interpretable labels (

rdfs:label) and comments

(

rdfs:comment) about the objects. The position of the

ontology hierarchy of the object gives added context

to the objects. From a programming perspective, the

ontology object definition is an invaluable tool for

keeping track of the objects structure. Since the JSON

object is inherently free format it can be difficult to

keep track of which fields are available or which

fields must be filled in. This task, which is often

accomplished with the programming environment,

cannot be applied to JSON objects. Using the

ontology as a reference facilitates this task. The

additional documentation within the ontology is also

helps the programming process.

Due to the machine readability of the ontology, a

certain degree of automation can be utilized. This is

particularly useful when a generalized algorithm can

read the ontology and base its manipulation on the

ontology definition. This means that updates to

include more data can be made only updating the

ontology and not modifying the program. One

common example of this are pull-down lists in the

user interface. More choices can be added within the

ontology without touching the program.

2.4 RESTful Service Definition

The input and output of RESTful services are also, to

a certain extend, free-format, similar to the free

format of JSON objects. The purpose of the ontology,

with regard to RESTful services, is to provide

machine readable and standard documentation of

each of the services provided by

JThermodynamicsCloud. A POST to a RESTful

service, as used by JThermodynamicsCloud, sends

JSON data to the server and with this information

performs a task and sends a response, also a JSON

object, back to the client. JSON objects are, in

general, free-format, so they can be of any property-

value pair, where the value can be a simple data object

like a string or a nested object like another JSON

object. There is nothing in the RESTful service

definition that specifies the form of the JSON object.

So the user must 'know' the form of the valid data that

the server expects and also the form of the response.

In the JThermodynamicsCloud ontology definition,

the exact form of the JSON data needed to perform

the task and the expected JSON response is specified.

Thus the ontology provides documentation for the

user of the service. However, since the ontology is

machine-readable, its role of just documentation can

be expanded. For example, the ontology could

provide a level of input checking to see that the JSON

object in the POST has all the necessary information.

Also the machine readable ontology could be used to

set up the user interface.

2.5 Ontology Transaction Definition

Transactions are one of the more important features

promoting the traceability of data as it is created and

transformed within the database. A single transaction

event performs a single task. Transactions also

promote modularization of tasks (one important aspect

of ‘normalized system’). A transaction task could be

dependent on other prerequisite transaction tasks. In

other words, the prerequisite transactions set up the

necessary data for the current task. Thus, inherent in

the definition of a transaction is the list of prerequisite

transactions that are needed. The transaction event can

be thought of as a node in the tree of manipulations that

JThermodynamicsCloud: Case Study in an Ontology-Driven NoSQL Database Cloud Based Application in Chemical Domain

291

data undergoes. The transaction also is a tool to isolate

single tasks making the organization of data

manipulation more transparent.

The ontology's role in this design is to give the

specification to the input to the transaction, this

includes the list of transactions that are needed to

perform the current transaction. Due the structure of

the database and the organization of transactions,

often just knowing the type of transaction needed is

enough to isolate the particular prerequisite

transaction needed (an aid to automation). If the exact

prerequisite transaction cannot be isolated, the

choices for the user are fewer.

2.5.1 Transactions and Traceability

The purpose of transactions is to keep track of every

change in the database. Whenever the database is to

be modified, a RESTful transaction is performed. The

purpose of a transaction is to have a trace of the

evolution of a database catalog object. To perform a

transaction, the prerequisites to the transaction have

had to be performed. These prerequisites are

themselves transactions. In this way the user can trace

the evolution of the database catalog object by tracing

through the transactions that were used to create the

current database object. To perform a transaction,

first the prerequisites of the transaction must be

collected. The transaction ontology (see Transaction

Specification in Ontology) definition contains the list

of prerequisite transaction classes. The prerequisite

for the process is a database transaction object of this

class. When a transaction process is initiated, the set

of database transaction catalog objects are

retrieved. Each of these transaction objects (created

previously by another transaction) has the

FirebaseID's (the address within the database) of the

needed prerequisites. The FirestoreID's are used to

retrieve from the database the actual prerequisite

catalog objects. These catalog objects are then passed

to the transaction process.

In order to perform the transaction, in addition to

the list of prerequisite transaction catalog objects,

some additional information may be needed to guide

the process. These are specified through a

dataset:ActivityInformationRecord (a subclass

of dcat:CatalogRecord of the DCAT ontology)

record object. The properties of this record object

supplements the prerequisite data. In the ontology

definition of the transaction, the specific class of

dataset:ActivityInformationRecord gives a

specification of the specific data needed. In the data

sent to the RESTful service this information is under

the

dataset:activityinfo property.

The final output of a transaction process is an

array of catalog objects of the same class. These are

passed back through the RESTful process response.

Each catalog object has the FirestoreID of the

transaction that created it. The FirestoreID of each of

the output catalog objects are listed in the database

transaction object of the process.

2.5.2 Transaction Specification in Ontology

The ontology provides the complete specification of

each transaction, i.e. the form of the expected input

and output information. Each transaction is described

with an ontology class which is in the subclass

hierarchy under

dataset:TransactionEvent, a

subclass of Dublin Core class dcmitype:Event. The

specification in the form of an ontology class has

several properties:

dcat:catalog: This is the class of the catalog

object that the transaction creates.

dcterms:source: This is the class of the

dataset:ActivityInformationRecord JSON

input information object that is needed to derive

the output catalog objects. The ontology class

specifies the supplementary data needed to

perform transaction.

dcterms:type: This is the class of transaction

that is produced. This class is a subclass of

dataset:ChemConnectTransactionEvent

(which ultimately is a subclass of

dataset:SimpleCatalogObject which is a

subclass of dcat:Catalog). The database

transaction catalog object is not the same class as

the transaction class specification. Different

transaction class specifications can produce a

database transaction object of the same class.

dcterms:requires: These are the classes of the

transaction specifications, i.e. subclass of

dataset:TransactionEvent, that are required

before this transaction can be performed. Through

these transaction specifications the database

transaction object class that was produced by the

transaction is specified. This class information is

used to retrieve the specific database transaction.

2.6 Database Hierarchy Specification

in the Ontology

The Google Firestore (Cloud Firestore | Store and

Sync App Data at Global Scale, n.d.) noSQL database

has a document oriented data-model (Cloud Firestore

Data Model, n.d.). The structure is an alternating

hierarchy of collections and documents. Within a

collection, which is specified by a string label, is a set

KEOD 2023 - 15th International Conference on Knowledge Engineering and Ontology Development

292

of documents. A document is a map of property-value

pairs. The value specified by the document can either

be an object, such a string or numerical value, or it

can be a label to a further subcollection. Thus the final

document (one with no further subcollections under

it) is a set of property-object value pairs at the end of

a hierarchy. Access to this document is through a

alternating set of collection labels and subcollection

labels within a document.

Within the JThermodynamicsCloud implementa-

tion, the catalog objects, a mapping similar to a JSON

object, are found at the end nodes of hierarchy of

collection and documents nodes. The nodes of the

branch leading to the catalog object are designated by

string labels. The string labels are either a collection

label or a document property label pointing to a

subcollection. Thus each of the documents in the

hierarchy leading to this final catalog object only

have a set of unique single labels, each pointing to a

different subcollection. In the document form of

noSQL databases, the design model is to group all

'documents' into a single collection. In

JThermodynamicCloud, all collections of documents,

the catalog objects, are at the end of a branch

designated with string labels for each node. The

address, meaning the set of labels of the nodes in the

branch leading to the catalog object, are specified in

the FirestoreID class.

In JThermodynamicsCloud the position of

each catalog with a collection-document

hierarchy object is specified under the

dataset:CollectionDocumentHierarchy. The

ontology classes and subclasses under this class

specify the classes of collection-document nodes

leading to the final catalog objects at the end of the

branch. Each class in this hierarchy specifies how the

node should be labeled. A given catalog object class

has a unique position in the hierarchy defined by the

ontology. The label specification of the nodes leading

to the catalog object can be a constant or can be

derived from the current catalog being stored. The

end class in this specification ontology hierarchy

specifies which class of catalog object is to be stored

in the database. In each of the ontology class

specifications, the

rdfs:isDefinedBy annotation

specifies how the label is to be created. The set of

methods to create these labels are defined in the

ontology under the

dataset:GenerateStringLabel

class (this is an example of an implementation of

operations by type). Each of the methods in the

ontology has a corresponding code within a JAVA

Enumeration class (using the ontology class name as

reference). If the (final) node is to store a catalog

object, then the class of the catalog object is specified

skos:member. Thus when a class object is to be

stored, the skos:member fields are searched for the

class name. The catalog object address (to be

specified in the FirestoreID catalog address) is

generated by the branch of classes leading to this

node.

For example, suppose we are to store a specific

instance of a collection set of the class

dataset:ChemConnectDatasetCollectionIDsSet.

Following the ontology class hierarchy under

dataset:CollectionDocumentHierarchy, we find

there are four classes in the hierarchy leading to the

class specifying the instance class as the

skos:member. This means that this class is the

document specified by four labels. All four classes

together specify the labels of the branches leading to

the specific instance (and specified in the FirestoreID

address).

2.7 Parameters and Units: QUDT

Ontology

One of the most important aspects of managing

scientific data is the handling of units. Although there

is a standardized system of units, the SI, International

System of Units, units(SI Brochure, n.d.), it is not

absolutely said that researchers are using them. For

example, in the combustion thermodynamics domain

(the domain of this tool), though the trend is toward

SI units, it is not said that the available data needed

by the application is in SI units. In addition, even if

SI units are used, there is still some conversion that is

necessary. For example, depending on the range of

values of the parameter, the simple unit could be used

or if it has a larger range, with the prefix, for example,

kilo-, or if with a smaller range, for example, milli-.

There are two philosophies of handling units in a

database. The first is to convert them to a 'standard',

relative to the database. Each parameter would have

it's expected unit. With this philosophy, the units are

implicit and do not need to be stored with the value.

The disadvantage is that it is left to the user on input

to convert the units. This can lead to errors and this

'hidden' step makes it more difficult to trace the value

to and check the value with the original source value.

The other philosophy, is to store not only the value,

but the unit used for the value. In

JThermodynamicsCloud the second philosophy is

used for basically two reasons. The most important

reason is that keeping the unit with the parameter

means that the value stored can be exactly that of the

original source. This promotes traceability and error-

checking.

JThermodynamicsCloud: Case Study in an Ontology-Driven NoSQL Database Cloud Based Application in Chemical Domain

293

To convert between different units requires a

knowledge base of units. For a application within a

small domain, this knowledge base could be 'hard-

coded' into the application. However, a more general

approach is provided by the QUDT ontology(QUDT,

2018). In the QUDT ontology each 'kind' of unit is an

instance of

qudt:QuantityKind, for example

qudt:MolarEnergy. In the annotations of

the instance of qudt:QuantityKind, the available

units of this kind are given by qudt:applicableUnit.

For example, on applicable unit of

qudt:MolarEnergy is qudt:CAL-PER-MOL, i.e.

calories/mol of substance. In the applicable unit, the

conversions to the SI units are given. To convert

calories/mol to the SI unit joule, one multiplies the

calories by 4.184.

The ontology definition for a parameter data

object in JThermodynamicCloud stores both the

value and the specification, meaning the units for the

value. In addition, uncertainty values are taken into

account. A parameter is represented by the

dataset:ParameterValue class with three fields:

dataset: ValueAsString: This is a string

representation of the value. If the value is

numeric, there is no requirement for its

representation, it would just be able to be

converted by a string to numeric algorithm.

dataset:ValueUncertainty: This, if used, is

the uncertainty of the value, of course in the same

units as the value. If there is no uncertainty, then

this value is zero.

dataset:ParameterSpecification: This is

a record, meaning several components, giving the

specification of the value.

The specification of the value is defined by

dataset:ParameterSpecification. This

specification is used not only within the parameter

definition, but also to specify what type of data is

expected in other data structures. The specification is

made of the following:

dataset:ParameterLabel: This is a string

keyword or label given to this parameter value. In

a matrix, this would be the column name.

dataset:ParameterTypeSpecification:

This is the

qudt:QuantityKind, of the QUDT

ontology, specifying the type of unit, for example,

qudt:MolarEnergy in the above example.

dataset:ValueUnits: This is the QUDT label

for the specific unir of the

qudt:QuantityKind.

For example, for qudt:MolarEnergy, a specific

instance could be

qudt:CAL-PER-MOL.

dataset:DataPointUncertainty: This is a

classification parameter and specifies the type of

uncertainty is given.

3 RESULTS: EXPERIENCE

All the above concepts using have been implemented

in JThermodynamicsCloud. During the simultaneous

development of the ontology and the application,

distinct advantages of the approach were realized.

First and foremost, one of the greatest advantages

of using the ontology is having the documentation of

the data classes centralized and, furthermore,

categorized (meaning the class structure of the

ontology definitions). This is not only convenient, but

almost essential considering that the data structures

are JSON-like and free format. Furthermore,

JThermodynamicsCloud is made of three distinct

subsystems, the GUI interface in Angular, the

backend in JAVA and the database in Google

Firestore and without the centralized data structure

definition offered by the ontology, developmental

programming and the (programmed) communication

between these subsystems would have been more

difficult and error-prone.

The use of the ontology in the definition of the

RESTful services, both for the services and for the

transactions, provides a clear documentation of what

inputs and what outputs are to be expected for the

RESTful services in a machine and human readable

format. Without this, the only specification is within

the backend code itself.

In terms of automation, the specification of the

database hierarchy is extremely efficient and

convenient. Where catalog objects are stored in the

hierarchy of the noSQL document based database is

handled completely by the ontology specification. If

a new catalog data object is to be created, this only

need be specified in the ontology. This is done by

placing the class name of the new catalog object in

the ontology hierarchy and, if necessary, define the

labeling of the branches leading to the class in the

hierarchy. This also means that the structure of the

database can be changed purely by changing the

ontology specification. No (JAVA) programming is

involved in the backend.

The use of the QUDT ontology for units increases

flexibility and efficiency in unit manipulation. Once

again all the domain knowledge of units in the

ontology and any changes in units is done through the

ontology without modification of the code. In terms

of database management and the results in the

calculations of the system, the added flexibility of

unit conversion when needed eliminates the

restriction that the units of the parameters stored in

the database have to be ‘standardized’. Elimination of

this restriction reduces, or at least facilitates the

detection of, errors in the database. This is

KEOD 2023 - 15th International Conference on Knowledge Engineering and Ontology Development

294

particularly important for the combustion community

where there two standards for units of energy. Which

is preferred is more a personal preference of the

researcher involved.

4 CONCLUSIONS

This paper has described the use of ontologies

in the model driven development of

JThermodynamicsCloud. The ontology serves is

platform independent description of the data

structures and the operational structures that are used

in the three distinct platforms of the system, namely

the interface (written in Angular), the backend

(written in JAVA and accessed through RESTful

services) and the database (the noSQL database of

Google Firestore). Though the ontology was not used

to generate code for the application, the ontology is

queried extensively (using the SPARQL queries of

the JENA API of the JAVA backend) to perform its

tasks.

On github further information about

JThermodynamicsCloud can be found:

https://github.com/blurock/Angular/releases

This link includes more detailed documentation (both

from the ontology point of view, but also from a

combustion application point of view), a link to the

current ontology and a link to the working version of

JThermodynamicsCloud on the Google Cloud

platform.

REFERENCES

Angular. (n.d.). Retrieved September 5, 2023, from

https://angular.io/

Apache. (n.d.). Apache Jena—SPARQL Tutorial. Retrieved

April 30, 2019, from https://jena.apache.org/tutorials/

sparql.html

Bhatia, M. P. S., & Beniwal, A. K. and R. (2016). Ontologies

for Software Engineering: Past, Present and Future.

Indian Journal of Science and Technology, 9(9), 1–16.

https://doi.org/10.17485/ijst/2016/v9i9/71384

Blurock, E. (2021). Use of Ontologies in Chemical Kinetic

Database CHEMCONNECT. 240–247. https://www.

scitepress.org/PublicationsDetail.aspx?ID=ai7xFiBEN8

E=&t=1

Blurock, E. S. (2019, June 29). CHEMCONNECT: An

Onotology-Based Repository of Experimental Devices

and Observations. 8th International Conference on

Advanced Information Technologies and Applications

(ICAITA 2019), Copenhagen, Denmark. https://icaita

2019.org/index.html#home

Bučko, B., Zábovská, K., & Zábovský, M. (2019). Ontology

as a Modeling Tool within Model Driven Architecture

Abstraction. 2019 42nd International Convention on

Information and Communication Technology,

Electronics and Microelectronics (MIPRO), 1525–1530.

https://doi.org/10.23919/MIPRO.2019.8756968

Cloud Firestore | Store and sync app data at global scale.

(n.d.). Firebase. Retrieved September 5, 2023, from

https://firebase.google.com/products/firestore

Cloud Firestore Data model. (n.d.). Firebase. Retrieved

September 5, 2023, from https://firebase.google.com/

docs/firestore/data-model

De Bruyn, P., Mannaert, H., Verelst, J., & Huysmans, P.

(2018). Enabling Normalized Systems in Practice –

Exploring a Modeling Approach. Business &

Information Systems Engineering, 60(1), 55–67.

https://doi.org/10.1007/s12599-017-0510-4

Dublin Core. (2012, June 12). Dublin Core Metadata

Initiative. Dublin Core Metadata Initiative.

http://dublincore.org/

Espinoza-Arias, P., Garijo, D., & Corcho, O. (2021).

Crossing the chasm between ontology engineering and

application development: A survey. Journal of Web

Semantics, 70, 100655. https://doi.org/10.1016/

j.websem.2021.100655

Gaševic, D., Djuric, D., & Devedžic, V. (2009). Model

Driven Engineering. In V. Deved¿ic, D. Djuric, & D.

Ga¿evic (Eds.), Model Driven Engineering and Ontology

Development (pp. 125–155). Springer. https://doi.org/

10.1007/978-3-642-00282-3_4

Maali, F., & Erickson, J. (2014, January 16). Data Catalog

Vocabulary (DCAT). https://www.w3.org/TR/vocab-

dcat/

QUDT. (2018, December 16). Quantities, Units, Dimensions

and Data Types Ontologies. Quantities,Units,

Dimensions and Data Types Ontologies. http://qudt.org/

SI Brochure. (n.d.). BIPM. Retrieved September 5, 2023,

from https://www.bipm.org/en/publications/si-brochure

Silva Parreiras, F., Walter, T., Wende, C., & Thomas, E.

(2010). Bridging software languages and ontology

technologies: Tutorial summary. Proceedings of the

ACM International Conference Companion on Object

Oriented Programming Systems Languages and

Applications Companion, 311–315. https://doi.org/10.11

45/1869542.1869626

Suchánek, M., Mannaert, H., Uhnák, P., & Pergl, R. (2021).

Towards Evolvable Ontology-Driven Development with

Normalized Systems. In R. Ali, H. Kaindl, & L. A.

Maciaszek (Eds.), Evaluation of Novel Approaches to

Software Engineering (pp. 208–231). Springer

International Publishing. https://doi.org/10.1007/978-3-

030-70006-5_9

Timothy Lebo, Satya Sahoo, Deborah McGuinness. (2013).

PROV-O: The PROV Ontology. https://www.w3.org/TR/

prov-o/

JThermodynamicsCloud: Case Study in an Ontology-Driven NoSQL Database Cloud Based Application in Chemical Domain

295
