Research on Optimization of Machine Learning Algorithm Based on

Feature Selection

Lei Yang, Yungui Chen and Longqing Zhang

Guangdong University of Science and Technology, Dongguan, China

Keywords: Feature Selection, Machine Learning, Prediction.

Abstract: Feature selection, as a method of machine learning algorithm optimization, aims to improve the

performance and efficiency of the algorithm by selecting important features. This research selects 3 A-share

stocks of China's Shanghai Stock Exchange as the research object and proposes a prediction model based on

feature selection decision tree optimization algorithm, which is used to predict the closing price of the stock.

Our research results show that the optimized Models can improve the performance of predictions.

INTRODUCTION

In machine learning, feature selection is a commonly

used data preprocessing technique, which can reduce

the data dimension, reduce the influence of noise

and redundant data, and improve the generalization

ability and interpretability of the model at the same

time (Zhou H F-Alsahaf A). Research on machine

learning algorithm optimization based on feature

selection is an important research direction, which

aims to improve the performance and accuracy of

machine learning algorithms, so as to better solve

practical problems (Sharma, 2022).

Feature selection refers to the selection of the

most useful features in machine learning algorithms,

thereby reducing the complexity of the model and

improving the generalization ability of the model.

There are many methods of feature selection,

including filtering, wrapping, and embedding. The

filtering method refers to evaluating the importance

of features by calculating the correlation between

features and labels, and then sorting according to the

importance index to select features with higher

rankings 0 (Christo,2022). The advantage of the

filtering method is fast calculation, but the

disadvantage is that it is easily affected by noisy

data. The wrapping method refers to searching the

feature space through a search algorithm to find the

optimal feature subset. The advantage of the

wrapping method is that it can find the optimal

feature subset, but the disadvantage is that it is

computationally intensive and time-consuming

(Chen, 2021). The embedding method refers to

limiting the complexity of the model through

methods such as regularization during the training

process of the machine learning algorithm, thereby

realizing feature selection. The advantage of the

embedding method is that it can optimize the

accuracy and generalization ability of the model at

the same time, but the disadvantage is that it is

computationally intensive and time-consuming 0

(Yun, 2021).

This research uses the filtering method for

feature selection, uses spearman correlation to

analyze the characteristics of the data, and extracts

more relevant data to become another data set

separately, using the same machine learning

algorithm, that is, decision tree algorithms to learn

and predict on two datasets.

DATASET AND METHOD

The data used in this research comes from the data

of China’s Shanghai Stock Exchange Index in the

first half of 2022. The historical transaction data of

three China’s Shanghai Stock Exchange A-shares

were selected as the research objects, namely Gd

Power Development Co., Ltd., Hundsun

Technologies Inc. and Ningbo Joyson Electronic

Corp. The stock codes are 600795, 600570 and

600699 respectively.

This research analyzes and processes the data of

the opening date, opening price, highest price,

lowest price, closing price, and trading volume of

these three stocks, and uses the machine learning

algorithm of decision tree to predict the stock price

100

Yang, L., Chen, Y. and Zhang, L.

Research on Optimization of Machine Learning Algorithm Based on Feature Selection.

DOI: 10.5220/0012275300003807

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 2nd International Seminar on Artiﬁcial Intelligence, Networking and Information Technology (ANIT 2023), pages 100-103

ISBN: 978-989-758-677-4

trend. The original data set of each stock has 117

samples, each sample contains 8 features, the first

102 samples are used as the training set, and the

remaining 15 samples are used as the test set.

We set the maximum depth of the decision tree

to 100 layers, use the inductive binary tree, set the

minimum number of samples on the leaf nodes to 3,

and no longer split when the number of subsets is

less than 3, the regression prediction model is used

in the prediction, and the prediction Visualize the

analysis results after outputting the results(

Luo

M,2021). Meanwhile, we also performed

performance analysis of our predictive model using

different evaluation metrics.

Divide the input space into M regions R

, R

, ...

and generate the decision tree:

() ( )

xcIxR

= ∈



(1)

The tree can be created as shown in Algorithm 1.

Algorithm 1: Tree creation.

INPUT: Training set T ;

Feature set F

OUTPUT: A tree

Procedure : Function TC(T, F)

0: Initialize a node;

1: if The tests in T all have the same sort W then

2: Stamp node as a W-type leaf node; return

3: end if

4: if F = Ø OR The test in T has the same value on F then

5: Stamp node as a leaf node;

6: The type is singled out in T; return

7: end if

8: Select the ideal parcel feature a,

from F;

9: for Each value a

in a,

10: Create a branch for node;

11: Let T

indicate a subset of tests in T that have a value of a

on a,

;

12: if T

is vacant then

13: Stamp branch nodes as leaf nodes;

14: The type is singled out in T; return

15: else

16: TC(T

, F\{a,

}) as a branch node;

17: end if

18: end for

To optimize predictive models for machine

learning, we apply feature selection to the original

dataset. Feature selection algorithms include

filtering, wrapping, and embedded three types.

Filtering feature selection algorithms are

independent of any specific machine learning model

and select features by performing statistical tests or

mathematical transformations on them 0. Wrapped

feature selection algorithms treat feature selection as

a search problem, taking a subset of features as

input, and evaluating the performance of each subset

using a given machine learning algorithm 0. The

embedded feature selection algorithm embeds

feature selection into the training process of machine

learning algorithms and selects the best features by

optimizing the loss function of the model.

For the selection of feature evaluation indicators,

feature evaluation indicators are mainly used to

evaluate the importance and contribution of features.

Commonly used indicators include information gain,

chi-square test, mutual information, and correlation

coefficient 0.

In order to better predict the stock price, we use

Spearman correlation to analyze the characteristics

of the data, conduct correlation analysis on the 8

features in the data set, and finally select the

strongest 3 features plus the opening date, A total of

4 features were used to construct a new data set, and

the same decision tree algorithm and parameters

were used to perform machine learning on the new

data set again. Our research results show that the

optimized model can improve prediction

performance.

EXPERIMENT AND ANALYSIS

A decision tree algorithm is an algorithm used in

machine learning that uses a tree model to build a

decision process from input to output. It is a type of

classification and regression tree (CART) algorithm

and can be used for classification and regression

tasks 0. The advantage of the decision tree algorithm

is that it can represent the decision process in a

readable form, and it is also fast to train. As shown

in Figure 1, it is the decision tree model of the stock

price prediction of the stock Gd Power, which is

visualized with the Pythagorean tree. The decision

tree models for the other 2 stocks are similar.

Figure 1: The decision tree model with Gd Power.

Research on Optimization of Machine Learning Algorithm Based on Feature Selection

101

In this research, the historical transaction data of

3 stocks are divided into training sets and test sets.

There are 351 pieces of data in total. The total

amount of data for a single stock is 117. In order to

better compare the effect of feature selection on the

prediction model, the training set and test set adopt a

fixed sampling mode. There are 102 samples in the

training set and 15 samples in the test set. The

prediction results are shown in Table 1.

Table 1: The predicted results and real values of the 3 stocks.

Power

real

Power

pred

Power

devi

Hundsun

real

Hundsun

pred

Hundsun

devin

Joyson

real

Joyson

pred

Joyson

devi

1 3.8 3.78 0.47% 42.9 42.52 0.90% 13.45 13.31 1.04%

2 3.73 3.73 0.00% 42.02 41.67 0.84% 13.7 13.77 0.51%

3 3.8 3.78 0.47% 42.18 42.52 0.79% 13.94 13.77 1.22%

4 3.72 3.76 0.99% 43.86 44.07 0.49% 13.57 13.59 0.18%

5 3.69 3.66 0.88% 41.76 41.67 0.23% 13.48 13.59 0.85%

6 3.78 3.78 0.05% 42.78 42.52 0.62% 13.63 13.59 0.26%

7 3.77 3.76 0.35% 42.79 42.56 0.54% 13.96 14.05 0.66%

8 3.96 3.92 1.01% 45.2 44.88 0.70% 13.66 13.59 0.48%

9 3.89 3.92 0.77% 43.17 43.25 0.17% 13.63 13.59 0.26%

10 3.78 3.76 0.62% 45.01 44.88 0.28% 14.65 14.43 1.48%

11 3.74 3.73 0.27% 45.25 45.17 0.18% 15.56 15.41 0.96%

12 3.72 3.73 0.27% 45.69 45.77 0.18% 16.24 16.19 0.29%

13 3.77 3.78 0.32% 45.7 45.17 1.17% 16.28 16.19 0.54%

14 3.92 3.92 0.00% 44.27 44.88 1.39% 15.98 16.19 1.33%

15 3.91 3.92 0.26% 43.54 43.25 0.68% 15.71 15.84 0.83%

It can be seen from the above table that most of

the deviations between the predicted values of the 3

stocks and the real values are less than 1%. The

curves of the predicted values and the real values of

the 3 stocks are shown in Figure 2.

Figure 2: The curves of the predicted value and the real

value of the 3 stocks.

In order to optimize our prediction model, for the

original data set, we use Spearman correlation to

analyze the characteristics of the data and perform

correlation analysis on the 8 features in the data set.

The correlation analysis of the three stocks is shown

in Table 2.

Table 2: The correlation analysis of the 3 stocks’ features.

SN Gd Power Hundsun Joyson

1 0.989 close high 0.994 close high 0.995 close low

2 0.986 close low 0.99 close low 0.994 close high

3 0.971 close open 0.983 close open 0.987 close open

4 0.818 amount close -0.785 close date -0.747 close date

5 0.727 close volume -0.342 close volume 0.437 amount close

6 0.554 close date 0.029 amount close 0.018 close volume

As can be seen from Table 2, the three features

of the three stocks, the opening price, the highest

price of the day, and the lowest price of the day,

have the strongest correlation with the closing price.

Therefore, we choose these three features, plus the

opening time, to form a the new data set uses the

same decision tree algorithm and parameters to

perform machine learning on the new data set again,

and the prediction results are shown in Table 3.

Table 3: The predicted results and real values of the new

dataset.

Power

real

Power

pred

Power

devi

Hundsun

real

Hundsun

pred

Hundsun

devi

Joyson

real

Joyson

pred

Joyson

devi

1 3.8 3.79 0.18% 42.9 42.43 1.10% 13.45 13.46 0.04%

2 3.73 3.73 0.13% 42.02 41.89 0.31% 13.7 13.82 0.88%

3 3.8 3.79 0.18% 42.18 42.43 0.58% 13.94 13.82 0.86%

4 3.72 3.73 0.13% 43.86 44.07 0.49% 13.57 13.60 0.22%

5 3.69 3.69 0.00% 41.76 41.89 0.31% 13.48 13.56 0.56%

6 3.78 3.79 0.35% 42.78 42.79 0.01% 13.63 13.56 0.55%

7 3.77 3.78 0.13% 42.79 42.79 0.01% 13.96 14.05 0.64%

8 3.96 3.94 0.51% 45.2 45.07 0.28% 13.66 13.67 0.04%

9 3.89 3.90 0.26% 43.17 43.36 0.43% 13.63 13.60 0.22%

10 3.78 3.78 0.13% 45.01 45.07 0.14% 14.65 14.43 1.48%

11 3.74 3.73 0.27% 45.25 45.17 0.18% 15.56 15.46 0.64%

12 3.72 3.73 0.27% 45.69 45.54 0.34% 16.24 16.11 0.80%

13 3.77 3.77 0.13% 45.7 45.17 1.17% 16.28 16.28 0.03%

14 3.92 3.94 0.51% 44.27 44.60 0.75% 15.98 16.11 0.81%

15 3.91 3.90 0.26% 43.54 43.36 0.42% 15.71 15.84 0.83%

MSA (Mean Squared Absolute Error), RMSE

(Root Mean Squared Error), MAE (Mean Absolute

Error), and R2 (R Squared) are commonly used

regression error indicators or scoring indicators. The

value of R2 is between 0 and 1, the closer to 1, the

better the fitting effect of the model. The

performance of the predictive scoring indicators of

the two machine learning models on the two datasets

is shown in Table 4.

ANIT 2023 - The International Seminar on Artiﬁcial Intelligence, Networking and Information Technology

102

Table 4: The performance of the decision tree model.

Stock

MSE

before

MSE

after

RMSE

befor

RMSE

after

MAE

before

MAE

after

before

after

impr

Avg

devi

befor

Avg

devi

after

Avg

devi

impr

Gd Power 0.011 0.006 0.021 0.01 0.017 0.009 0.93 0.983 5.70% 0.45% 0.23% 48.97%

Hundsun 0.097 0.058 0.311 0.242 0.267 0.191 0.945 0.966 2.22% 0.61% 0.44% 28.74%

Joyson 0.015 0.011 0.122 0.103 0.106 0.084 0.987 0.991 0.41% 0.73% 0.57% 21.12%

As shown in Table 4, the performance of the

prediction model after the feature selection process

has been improved in both R2 and average deviation,

especially the average deviation index, which has

increased by more than 20%. Our experimental

results show that after feature selection processing,

the performance of machine learning model

prediction can indeed be improved.

CONCLUSION

Based on the feature selection algorithm, this

research improves the prediction model of the

decision tree algorithm and uses this model to

predict the closing price of the stock. The research

shows that the performance of the prediction model

has been improved. The optimization research of

machine learning algorithms based on feature

selection can also help Solve other types of practical

problems, such as text classification, image

recognition, bioinformatics, financial risk control,

etc. For stock price prediction, there are many

optimization methods based on feature selection,

which we will further study in future topics research.

ACKNOWLEDGMENTS

This research was funded by the following

programs: Research Capability Enhancement Project

of Guangdong University of Science and

Technology: Application Research of Artificial

Intelligence Technology Based on Kunpeng

Computing Platform; Natural Science Project of

Guangdong University of Science and

Technology(GKY-2022KYZDK-12, GKY-2022K

YZDK-9); Innovation and School Strengthening

Project of Guangdong University of Science and

Technology(GKY-2022CQTD-2, GKY-2022CQTD-

4, CQ2020062); 2022 Guangdong Province

Undergraduate University Quality Engineering

Construction Project - Exploration of Integrated

Teaching Reform of "Curriculum Chain, Practice

Chain, and Competition Chain"; Education Research

and Reform Project of Online Open Course Alliance

of Universities in Guangdong–Hong Kong–Macao

Greater Bay Area(WGKM2023166); Quality

Engineering Project of Guangdong University of

Science and Technology(GKZLGC2022018,

GKZLGC2022271).

REFERENCES

Zhou H F, Zhang J W, Zhou Y Q, et al. A feature selection

algorithm of decision tree based on feature weight[J].

Expert Systems with Applications, 2021, 164: 113842.

Qian H, Wang B, Yuan M, et al. Financial distress

prediction using a corrected feature selection measure

and gradient boosted decision tree[J]. Expert Systems

with Applications, 2022, 190: 116202.

Alsahaf A, Petkov N, Shenoy V, et al. A framework for

feature selection through boosting[J]. Expert Systems

with Applications, 2022, 187: 115895.

Sharma A, Mishra P K. Performance analysis of machine

learning based optimized feature selection approaches

for breast cancer diagnosis[J]. International Journal of

Information Technology, 2022: 1-12.

Christo V R E, Nehemiah H K, Brighty J, et al. Feature

selection and instance selection from clinical datasets

using co-operative co-evolution and classification

using random forest[J]. IETE Journal of Research,

2022, 68(4): 2508-2521.

Chen W, Jiang M, Zhang W G, et al. A novel graph

convolutional feature based convolutional neural

network for stock trend prediction[J]. Information

Sciences, 2021, 556: 67-94.

Yun K K, Yoon S W, Won D. Prediction of stock price

direction using a hybrid GA-XGBoost algorithm with a

three-stage feature engineering process[J]. Expert

Systems with Applications, 2021, 186: 115716.

Luo M, Wang Y, Xie Y, et al. Combination of feature

selection and catboost for prediction: The first

application to the estimation of aboveground

biomass[J]. Forests, 2021, 12(2): 216.

Bhandari H N, Rimal B, Pokhrel N R, et al. Predicting

stock market index using LSTM[J]. Machine Learning

with Applications, 2022, 9: 100320.

Kumbure M M, Lohrmann C, Luukka P, et al. Machine

learning techniques and data for stock market

forecasting: A literature review[J]. Expert Systems with

Applications, 2022, 197: 116659.

Buchaiah S, Shakya P. Bearing fault diagnosis and

prognosis using data fusion based feature extraction

and feature selection[J]. Measurement, 2022, 188:

110506.

Qiu Y, Song Z, Chen Z. Short-term stock trends prediction

based on sentiment analysis and machine learning[J].

Soft Computing, 2022, 26(5): 2209-2224.

Kurani A, Doshi P, Vakharia A, et al. A comprehensive

comparative study of artificial neural network (ANN)

and support vector machines (SVM) on stock

forecasting[J]. Annals of Data Science, 2023, 10(1):

183-208.

Research on Optimization of Machine Learning Algorithm Based on Feature Selection

103
