A Resnet and U-Net Hybrid Discriminator Based on GANs for Facial

Images Inpainting

Yue Zhu

Data Science and Big Data Technology, Shanghai University of Engineering Science, Shanghai, China

Keywords: Reconstructing Image, Inpainting, GANs, Hybrid Discriminator.

Abstract: Image inpainting technique is an application of computer vision technology, whose main task is to complete

reconstructing image with missing or damaged areas by using the information of the existing part, which

becomes a crucial part in computer vision (CV). This research presents a method for optimizing discriminators

in Generative Adversarial Networks (GANs) inpainting application. By introducing a hybrid discriminator

comprised by Residual Network-50 (Resnet50) and U-Net network, it has better perception of reconstructed

facial image textures and regional contours, thereby reducing the common blurring problem of reconstructed

images. Through random blurring images pre-training for the proposed discriminator, only the fine-tuned

process is required in practical applications, resulting in faster training time. Through comparative

experiments, this research can achieve smaller training losses, while the subjective image effect after

reconstruction is also significantly improved, specifically in areas such as the nose and eyes, where the edge

resource is more pronounced. The discriminator optimization design proposed in this research, combined with

pre- training methods, can be applied to GANs image inpainting application, significantly improving the

reconstruction effect of complex texture areas in damaged images, especially facial areas.

1 INTRODUCTION

Image inpainting is an image processing technique

which involves the selection of suitable pixels to fill

the defect area by extracting and screening the features

of the known area. At present, the development of

inpainting algorithms have become a research hotspot

of Computer Vision (CV) field, which can be widely

applied in multimedia, medical, entertainment and

film industry (Shah et al 2022). The basic idea of

image inpainting techniques is inferring the damaged

content from the content of undamaged areas in the

same image. The traditional techniques use many

kinds of graphic filters to reconstruct areas which can

generally perform well for repairing small and regular

damaged areas, but it is not effective for complex

graphic textures (such as faces), large or irregular

damaged areas. They can’t extract higher-level

semantic features and often lack enough context and

semantic information.

After Deep learning techniques was introduced in

2014, researchers found it could be a good solution to

the above problems, therefore it is now a widely used

research technique in image inpainting (Shah et al

2022). In 2016, Pathak et al. introduced the concept of

Context Encoders (CE) based on Goodfellow's

research on Generative Adversarial Networks (GANs)

(Pathak et al 2016 & Goodfellow et al 2014). CE can

extract semantic features and the global structure. It has

a good effect on reconstruction. After that, many

improved versions of CE have emerged. For example,

Lizuka et al. simultaneously used global and local

discriminators to improve the coherence between

reconstructed pixels and surrounding pixels (Iizuka et

al 2017). Convolution Neural Networks (CNN), as the

core algorithm of deep learning, bring a bright

perspective to image processing related application

such as millions of image classifications. The

convolutional algorithm has better generalization for

different tasks due to their better interpretability in

image processing (Donahue et al 2014). If context

related information is added in image generation, the

effect of image generation will exceed that of

autoencoder (Doersch et al 2015). Yeh et al. introduced

two new loss functions with no need for masking

during training. However, this method still cannot

reconstruct irregular damaged areas (Yeh et al 2017).

The main purpose of this research is to introduce

pre-trained context discriminator to improve the

inpainting performance of facial images based on

192

Zhu, Y.

A ResNet and U-Net Hybrid Discriminator Based on GANs for Facial Images Inpainting.

DOI: 10.5220/0012819400003885

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Data Analysis and Machine Learning (DAML 2023), pages 192-196

ISBN: 978-989-758-705-4

GANs image reconstruction algorithms. Specifically,

first, a CNN structured convolutional network is used

to mine image features, generate image feature

vectors, and then use deconvolution to generate

predicted image pixel information. Secondly, in

adversarial generation networks, discriminator is

crucial for the pixel-wised authenticity and

comprehensibility of generated images, as it can infer

the overall semantic information of the image. The

discriminator adopts a hybrid network structure of

Residual Network-50 (Resnet50) and U-net, and pre-

trains through random blurring images. By

introducing adversarial loss functions, it mitigates the

common blurring problems in facial images for

GANs; Thirdly, the predictive performance of

different models is analyzed and compared. In this

research, a ResNet and U-net hybrid discriminator is

introduced to highlight the generation of context and

segment structural information for facial regions such

as nose, eyes etc., enhancing facial local texture

coherence in the reconstructed image. The proposed

model has significant improvements in terms of

accuracy. The experiments show that this research can

effectively decrease the blur phenomenon in

reconstructed facial images.

2 METHODOLOGY

2.1 Dataset Description and

Preprocessing

The dataset used in this study is CelebFaces Attribute

(CelebA-HQ) images, containing 30,000 high-quality

celebrity photos resized to 256 x 256 pixels (Dataset).

This dataset has been often used in tasks like face

recognition, facial attribute analysis and face

generation. Data transformations and augmentations

are applied in the experiments, including converting

images into Tensor format, random cropping,

normalizing etc. These operations can improve the

generalization ability of the model and reduce the

overfitting in training process.

2.2 Proposed Approach

Using GANs to generate images, if only pixel wise

loss (L1 or L2) is used to train parameters, it is easy to

cause image blur in the generated image. This may be

due to this prediction method simply comparing pixel

wise errors without considering the contextual

information of the image, so the predictor tends to

minimize the pixel-wise L2 loss, but also generates

blurry images. Generally, the discriminator in GANs

trained together with the generator, which just

recognizes original and artifact image parts, hasn’t

pre-knowledge for blurred images and facial

segmentation features, so loss function has no related

parts. ResNet enhances face context perception

ability, while U-Net can enhance its semantic

consistency based on facial feature segmentation. By

using resnet50 and U-Net as hybrid discriminator,

corresponding reconstruction error parts are also

considered for loss function. The blurriness of

reconstructed can be reduced. The process is shown in

the Figure 1.

Figure 1: The pipeline of the model (Picture credit:

Original).

2.2.1 ResNet

Unlike traditional neural networks, the outputs of

each layer in ResNet are residuals of any previous

layer output. ResNet is a neural network structure that

solves the problem of gradient explosion and gradient

vanishing in the training of deep neural networks by

applying residual connectivity, thus allowing the

network to be deeper and easier to train. The internal

feature is the introduction of residual block which

contains two or three convolutional layers, where the

first convolutional layer is used to extract the features,

the second convolutional layer is used to fuse the

features, and finally the inputs and outputs are added

by using the residual connection to get the output of

the residual block. This residual join helps to keep

more information in the training process, thus

increasing the accuracy of the network. Each stage

contains multiple residual blocks, and each residual

block contains multiple convolutional layers and

residual connections inside. The input of the whole

network passes through a convolutional layer and

pooling layer and enters the first stage, and then

passes through multiple stages sequentially, and

finally the output is obtained through a fully

connected layer and a global average pooling layer.

ResNet's framework process consists of the input

passing through a convolutional layer and a pooling

layer to get the input for the first stage; The first stage

contains multiple residual blocks, each containing

A ResNet and U-Net Hybrid Discriminator Based on GANs for Facial Images Inpainting

193

two or three convolutional layers and residual

connections; Stages two through four are similar to

stage one and contain multiple residual blocks;

Finally, the output is obtained through a global

average pooling layer and a fully connected layer.

The internal idea of ResNet is to solve the problem of

gradient vanishing and gradient explosion during the

training of deep neural networks through residual

connectivity, thus allowing the network to be deeper

and easier to train. In each residual block, the residual

connection adds the inputs and outputs to get the

output of the residual block, and this residual

connection allows the network to retain more

information in the training process, thus increasing

the accuracy of the network.

Residual refers to that the inputs can skip

computations of intermediate layers and go directly to

the output. The approach of skipping layers is also

called shortcut connection. This design helps neural

networks to avoid problems such as vanishing

gradient or exploding gradient which tends to appear

with the increasing number of layers. ResNet enables

training robustness and reliability while improving

speed and accuracy. Considering computation

complexity, ResNet50 is used. ResNet50, as its name

suggests, is a 50-layer deep Residual Network which

consists of six layers: input layer, convolution layer,

residual block, pooling layer, fully-connected layer

and output layer. The convolution layer executes

convolution calculations on the input image to extract

features. Then, the convolutional results are fed into

the residual blocks. This allows more effective

extraction of high-dimensional image features. The

pooling layer down samples the feature maps. Finally,

in the fully connected layer, the feature maps are

connected and classified (He et al 2016).

2.2.2 U-Net

U-Net is a type of CNN that is specifically designed for

image segmentation tasks. The structural

characteristics of U-Net is its ability to connect the

feature maps of traditional encoder-decoder structures

with corresponding low-level feature maps. This

connection allows U-Net to retain more information

during the feature extraction process, which makes it

highly effective at handling incomplete or blurry

boundaries in images. The U-Net network includes a

symmetric encoder and decoder structure, with the

segmentation accuracy improved by connecting the

encoder and decoder feature maps. The encoder is

made up of multiple convolutional and max-pool

layers, which progressively reduce the size and channel

of feature maps while extracting high-level features.

On the other hand, the decoder comprises multiple

convolutional and up-sampling layers, which gradually

restore the size and channel of feature maps. Overall,

U-Net is a effective tool for image segmentation tasks,

especially when dealing with complex or challenging

images. Its ability to retain more information during

feature extraction and connect encoder and decoder

feature maps makes it a highly efficient and effective

solution for a wide range of image segmentation

applications. Additionally, by connecting low-level

feature of the encoder directly with the corresponding

feature maps of the decoder, U-Net can retain even

more information (Shen et al 2018 & Ronneberger et

al 2015).

2.2.3 Loss Function

Generator joint loss is a loss function that is obtained

by weighting and summing the pixel-wise

reconstruction loss and adversarial loss. Adversarial

loss is comprised of adversarial context loss and

semantic loss. The generator related loss functions are

defined as show:









  





(1)









  





(2)





   



   



(3)

where G and D respectively represent generator and

discriminator network processing. 



and 





represent pixel-wise loss and adversarial loss. They

are both L2 loss functions. Img and Mask_Img

respectively represents original image and masked or

damaged image, Ones represents all 1 vector. The

linear combination 



 of the 2 losses makes

joint generator loss to train only generator

parameters. α and β are weights that are obtained

during training to obtain the optimal value.

Discriminator joint loss is a loss function that is

obtained by weighting and summing the both the real

and fake image discrimination loss. The discriminator

related loss functions are defined as show:









  





(4)









  











(5)





   



   



(6)

DAML 2023 - International Conference on Data Analysis and Machine Learning

194

where 



represents loss of judging real image as

fake, and 



 represents loss of judging fake

image as real. They are both discriminator loss and

take L2 loss functions. Zeros represents all 0 vector.

The linear combination 



of the 2 losses

makes joint discriminator loss to train only

discriminator parameters. γ and ε are weights that are

obtained during training to obtain the optimal value.

2.3 Implementation Details

This experiment uses Python version 3.9 and imports

Python libraries such as NumPy, pandas, torch and

scikit-learn. The entire process is trained on CPU and

Adam optimizer is used for optimization. The Adam

optimizer can adaptively adjust the learning rate and

handle sparse gradients, thus improving the speed and

effectiveness of the model. The hybrid discriminator

pre-training uses 10000 images from the CelebA-HQ

training set. In order to make the discriminator more

general in recognition, the images are resized to

128x128 using blurring processing, and then select a

square area with upper left corner coordinates (80,80)

and random integer 64~80 width/height. A two-

dimensional blurring Gaussian filter with a mean of 0

and a variance of random 5~15 numbers is applied into

the area. After processing, the Resnet50 and U-Net

networks are pre-trained. The target is binary

classification to accurately recognize original and

blurred images. The pre-trained discriminator model

is trained for 5 epochs and other model is trained for

15 epochs with a batch size of 16. The learning rate of

the Adam optimizer is 0.0008. The number of CPU

threads is 4.

3 RESULTS AND DISCUSSION

Here are some experiments results. Table 1 shows the

pre-training data for hybrid discriminator. Table II

shows the loss comparison between CNN

discriminator model and this research. Furtherly

comparing reconstructed images quality of CelebA-

HQ dataset by using the discriminator structure in

(Pathak et al 2016) and the pre-trained hybrid

discriminator structure proposed in this paper, fig. 2

shows research in this paper has better quality.

Table 1: Pre-Training Data for Hybrid Discriminator.

Epochs

Test loss for pre-train

discriminator

0.013

0.008

0.007

Table 2: Loss Comparison in Last 3 Epochs Between

(Pathak et al 2016) and Research.

Epoc

Loss data in (Pathak et al

2016)

research

gen_adv_l

oss

gen_pixel_

loss

disc_l

oss

gen_adv_l

oss

gen_pixel_

loss

disc_l

oss

0.999

0.196

0.0013

0.322(-

68%)

0.149(-

24%)

0.241

0.999

0.194

0.0013

0.321(-

68%)

0.147(-

24%)

0.246

0.999

0.191

0.0012

0.328(-

68%)

0.136(-

28%)

0.238

According to Table 1, the hybrid discriminator is

highly effective in distinguishing between the original

and blurred images, with a minimal loss value of 0.008.

Additionally, Table II shows that the research in this

paper resulted in a 68% decrease in gen_adv_loss, a

24% decrease in gen_pixel_loss, and a significant

reduction in error. As shown in Figure 2, the

introduction of the discriminator through context and

segmentation mechanisms not only reduces the loss but

also significantly improves the subjective recognition

effect of some reconstructed images, particularly in

areas such as the nose and eyes, where the edge contour

is more pronounced. These results indicate that the

hybrid discriminator is a powerful tool for image

Figure 2: Reconstruction images comparison between Pathak et al’s study (2016) and research, the left 6 images is from

Pathak et al’s study (2016), the right 6 images from this paper research (Picture credit: Original).

A ResNet and U-Net Hybrid Discriminator Based on GANs for Facial Images Inpainting

195

reconstruction tasks. For the reconstruction of 64x64

regions on 128x128 resolution images, the entire

GANs training typically requires 20 epochs and takes

approximately 45 minutes on a single Nvidia

RTX3090 GPU. However, by parallelizing multiple

GPUs, the training time can be significantly reduced.

4 CONCLUSION

Intuitively, for better repairing defective areas of an

image, it is essential to understand the content of the

surrounding images, and use the correlation of the

image area content to infer the defective content.

Previous research from Pathak et al’s study (2016)

found that the repaired images areas generally are

blurry, especially contours around the eyes and nose.

During the training process, I also found that even after

multiple rounds of training, even if the image contour

is blurry, the discriminator's error remains basically

unchanged. That is, the discriminator is no longer

sensitive to this kind of blurring, so I decided to use

relevant pre-blurred image as training set and also

combine context with segmentation analysis to

enhance the discriminator's sensitivity to blurry

contour.

This research proposes a hybrid neural network

discriminator network structure of resnet50 and U-net

for image inpainting, which has good perception

ability for facial textures and segmentation structures.

When combined with GANs, it can significantly

reduce the blurring in reconstructed images.

Specifically, firstly, a 2D Gaussian filter is used to

randomly blur the images to generate a pre-trained

blurred image set. Secondly, through the pre-training

by using the blurred image set, the hybrid discriminator

can discriminate the original image from the blurred

image. Thirdly, build GANs networks for image

generation training, and compare the reconstructed loss

values and the quality of reconstructed images between

this study and other papers. The experimental results

indicate a significant decrease in the loss, while the

subjective recognition effect of some reconstructed

images is also significantly improved, particularly in

areas such as the nose and eyes, where the edge source

is more pronounced.

In the future, further work about optimizing the

discriminator network structure, pre-training method

and loss models design will be continued to recognize

different size texture and thus achieving better general

image reconstruction results.

REFERENCES

R. Shah, A. Gautam and S. K. Singh, “Overview of Image

Inpainting Techniques: A Survey,” 2022 IEEE Region

10 Symposium (TENSYMP), 2022, pp. 1-6.

D. Pathak, P. Krahenbuhl, J. Donahue, T. Darrell, and A.A.

Efros. “Context encoders: Feature learning by

inpainting,” Proceedings of the IEEE Conference on

Computer Vision and Pattern Recognition, 2016, pp.

2536–2544.

I. Goodfellow, J. Pouget-Abadie, M. Mirza, B. Xu, D.

Warde-Farley, S. Ozair, A. Courville, and Y. Bengio.

“Generative adversarial nets,” Proceedings of

Advances in neural information processing systems

(NIPS), vol. 27, 2014, pp. 2672–2680.

S. Iizuka, E. Simo-Serra, and H. Ishikawa. “Globally and

locally consistent image completion,” ACM

Transactions on Graphics, vol. 36, 2017, pp. 1–14.

J. Donahue, Y. Jia, O. Vinyals, J. Hoffman, N. Zhang, E.

Tzeng, and T. Darrell. “Decaf: A deep convolutional

activation feature for generic visual recognition,”

Proceedings of the 31st International Conference on

Machine Learning (ICML), 2014, pp. 647-655.

C. Doersch, A. Gupta, and A.A. Efros. “Unsupervised visual

representation learning by context prediction,”

Proceedings of the IEEE International Conference on

Computer Vision (ICCV), 2015, pp. 1422-1430.

R. A. Yeh, C. Chen, T. Yian Lim, A. G. Schwing, M.

Hasegawa-Johnson, and M. N. Do. “Semantic image

inpainting with deep generative models,” Proceedings

of the IEEE Conference on Computer Vision and

Pattern Recognition, 2017, pp. 5485–5493.

Dataset

https://www.kaggle.com/datasets/badasstechie/celeba

hq-resized-256x256

K. He, X. Zhang, S. Ren and J. Sun. “Deep Residual

Learning for Image Recognition,” IEEE Conference on

Computer Vision and Pattern Recognition (CVPR),

2016, pp. 770-778.

Z. Y. Shen, W.S. Lai, T.F. Xu, J. Kautz, Y. Ming-Hsuan,

“Deep Semantic Face Deblurring,” Proceedings of the

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR), 2018, pp. 8260-8269.

O. Ronneberger, P. Fischer, T. Brox, “U-net: convolutional

networks for biomedical image segmentation,”

Proceedings of Springer International conference on

medical image computing and computer-assisted

intervention, 2015, pp 234–241.

DAML 2023 - International Conference on Data Analysis and Machine Learning

196
