UPSS: A Global, Least-Privileged Storage System with Stronger Security

and Better Performance

Arastoo Bozorgi

, Mahya Soleimani Jadidi and Jonathan Anderson

Department of Electrical and Computer Engineering, Memorial University, St. John’s, NL, Canada

Keywords:

Cryptographic Filesystem, Distributed Filesystem, Private Sharing, Redaction, Private Version Control.

Abstract:

Strong conﬁdentiality, integrity, user control, reliability and performance are critical requirements in privacy-

sensitive applications. Such applications would beneﬁt from a data storage and sharing infrastructure that

provides these properties even in decentralized topologies with untrusted storage backends, but users today are

forced to choose between systemic security properties and system reliability or performance. As an alternative

to this status quo we present UPSS: the user-centric private sharing system, a cryptographic storage system

that can be used as a conventional ﬁlesystem or as the foundation for security-sensitive applications such as

redaction with integrity and private revision control. We demonstrate that both the security and performance

properties of UPSS exceed that of existing cryptographic ﬁlesystems and that its performance is comparable

to mature conventional ﬁlesystems — in some cases even superior. Whether used directly via its Rust API or

as a conventional ﬁlesystem, UPSS provides strong security and practical performance on untrusted storage.

1 INTRODUCTION

Across a broad spectrum of domains, there is an acute

need for private storage with ﬂexible, granular shar-

ing. Environments as diverse as social networking,

electronic health records and surveillance data man-

agement require both strong cryptographic protection

and ﬁne-grained sharing across security boundaries

without granting overly-broad access. Existing sys-

tems provide coarse security guarantees or strong per-

formance properties, but rarely both. Fine-grained,

ﬂexible, high-performance sharing of default-private

data is still a challenging problem.

What is needed is a mechanism for least-

privileged storage that facilitates simple discretionary

sharing of arbitrary subsets of data, providing strong

conﬁdentiality and integrity properties on commodity

cloud services from untrusted providers. In the previ-

ous years, some cryptographic ﬁlesystems have been

developed that store user data on untrusted storage

providers. However, they cannot provide strong se-

curity properties nor ﬂexible data sharing. For exam-

ple, EncFS (Team, 2018) and CryFS (Messmer et al.,

2017) are cryptographic ﬁlesystems that leave meta-

data unprotected, or in the latter one, everything is

https://orcid.org/0000-0002-7059-9501

https://orcid.org/0000-0002-7352-6463

encrypted with one key. TahoeFS (Wilcox-O’Hearn

and Warner, 2008) is another cryptographic ﬁlesystem

with strong security properties, but its design does not

allow ﬂexible and ﬁne-grained data sharing.

In this paper, we have built UPSS: the user-centric

private sharing system, which is a “global ﬁrst” cryp-

tographic ﬁlesystem with no assumptions of trustwor-

thiness for storage infrastructure or even on common

deﬁnitions of user identities. Relying on key con-

cepts from capability systems (Dennis and Van Horn,

1966), distributed systems, log-structured ﬁlesystems

and revision control, we have developed a new ap-

proach to ﬁlesystems that offers novel features while

being usable in ways that are compatible with existing

applications.

UPSS makes several key contributions to the ﬁeld

of privacy-preserving ﬁlesystems. First, unlike cryp-

tographic ﬁlesystems that entangle user and group

identiﬁcations and device speciﬁcation with access

controls, UPSS stores all data as encrypted blocks

on untrusted block stores including local, network,

or cloud block stores, without any mapping between

the blocks or blocks to block owners. Granular ac-

cess controls are then deﬁned by higher level applica-

tions according to application semantics. Traditional

access control modalities such as Unix permissions

can be implemented by systems using UPSS, as in the

case of our FUSE-based interface, but they are not

660

Bozorgi, A., Jadidi, M. and Anderson, J.

UPSS: A Global, Least-Privileged Storage System with Stronger Security and Better Performance.

DOI: 10.5220/0012306600003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 660-671

ISBN: 978-989-758-683-5; ISSN: 2184-4356

encoded in the shared cryptographic ﬁlesystem itself.

This decoupling allows the ﬁlesystem to be global-

ﬁrst and local-second.

Second, all UPSS blocks can be accessed by cryp-

tographic capabilities (Dennis and Van Horn, 1966)

called block pointers consist of block names and their

decryption keys that reduces the burden of key man-

agement and simpliﬁes naming; a block pointer is

enough to fetch, decrypt and read a block, with no

central key management required. Block pointers en-

able ﬂexible data sharing at the block level among

mutually-distrustful users. They also enable per-

block encryption rather than per-ﬁle or per-ﬁlesystem

encryption, which provides a stronger security model.

Third, UPSS enables aggressive and safe caching

by deﬁning a multi-layer caching block store consists

of other block stores that guarantee data consistency

between all block stores. The caching block store pri-

oritizes applying the operations on faster block stores

on the cache hierarchy and processes the operations

on slower block stores in the background. Therefore,

the caching block store becomes available immedi-

ately despite the number of layers in the hierarchy or

the slowness of higher-level block stores. This pro-

vides performance that exceeds cryptographic ﬁlesys-

tems by factors of 1.5–40×.

UPSS’ system model and design is described in

Section 2. Performance is evaluated in Section 4

via three case studies comparing UPSS to existing

ﬁlesystems: local ﬁlesystems (Section 4.2), network

ﬁlesystems (Section 4.3) and global ﬁlesystems (Sec-

tion 4.4). The related works are discussed in Section 5

and we conclude our paper in Section 6.

2 UPSS SYSTEM MODEL AND

DESIGN

UPSS is a cloud-ﬁrst private storage and sharing sys-

tem. Rather than a local cryptographic ﬁlesystem

that projects POSIX assumptions (e.g., ﬁle owner-

ship, user identiﬁcation and trusted devices) into the

cloud, UPSS starts with the assumptions of untrusted

storage and user-directed sharing via cryptographic

capabilities (Dennis and Van Horn, 1966). UPSS can

be exposed via FUSE (fus, 2019) as a conventional

POSIX ﬁlesystem, allowing performance comparison

to existing local ﬁlesystems, network ﬁlesystems and

global ﬁlesystems, but its most exciting capabilities

are exposed directly through a Rust API.

In this section, we review key elements of the

UPSS design, which was seeded in (Bozorgi et al.,

2019; Bozorgi, 2020) as prototype ideas, and de-

scribe new design elements that enable practical per-

Encrypted Block Store

Immutable DAG

Mutable FS

Access

Unix VFS

(future)

UPSS library API

User application

FUSE VFS

POSIX system calls

CLI/GUI/TUI

MutableDirectory

currentVersion

MutableFile

currentVersion

Cloud

File-backedIn-memory

Mirror

UPSS-CLI

CLI

Networked

Cacheing

Figure 1: The layered structure of UPSS.

formance that had previously been envisioned as fu-

ture work. These elements are visible across four lay-

ers shown in Figure 1: untrusted storage (Section 2.1),

an immutable copy-on-write DAG of blocks (Sec-

tion 2.2), mutable ﬁlesystem objects (Section 2.3) and

two user-visible ﬁlesystem interfaces (Section 2.4).

2.1 Untrusted Storage

Like all ﬁlesystems, UPSS ultimately stores data in

ﬁxed-size blocks on persistent media. Block sizes are

all multiples of common physical sector sizes and are

set by the backing store rather than the client. UPSS

uses a default block size of 4 kiB that can be over-

ridden on a per-store basis. Unlike other ﬁlesystems,

all UPSS blocks are encrypted in transit and at rest:

plaintext blocks is only held in memory and never

stored to persistent media. Rather than using per-

ﬁle or per-ﬁlesystem encryption keys, each block is

encrypted with a key k

derived from its plaintext

and named by a cryptographic hash n

of its cipher-

text. The 2-tuple (n

, k

) constructs a block pointer

as given in eq. (1).

= h(B)

= h (E

{B})

(1)

In this equation, B represents the plaintext contents

of a block, which contains user content and random

padding to ﬁll out the ﬁxed-size block, h is a cryp-

tographic hash function and E is a symmetric-key

encryption algorithm. A block pointer is a crypto-

graphic capability (Dennis and Van Horn, 1966) to

fetch, decrypt and read a block’s contents, though not

to modify it, as blocks are immutable. Changing a

single byte in the block would change a block’s en-

cryption key k

, which would change the encrypted

version of the block, which would change its name

UPSS: A Global, Least-Privileged Storage System with Stronger Security and Better Performance

661

. As a matter of practical implementation, se-

rialized block pointers also contain metadata about

their hashing and encryption algorithms (typically

SHA3 (Dworkin, 2015) and AES-128 (Dworkin et al.,

2001)).

Deriving a symmetric encryption key from a

block’s contents is an example of convergent encryp-

tion (Douceur et al., 2002; Li et al., 2013; Agarwala

et al., 2017). Convergent encryption is a symmetric-

key encryption technique in which identical cipher-

texts are produced from identical plaintexts. This

technique affords two beneﬁts: a reduced burden of

key management and the possibility of block (rather

than ﬁle) level data deduplication (Satyanarayanan

et al., 1990; Douceur et al., 2002). Deduplication

is an important feature for global-scale information

sharing systems in which many users may share the

same content with others. By deduplication, only two

extra 4 KiB meta blocks are required to ingest a 1 GB

ﬁle to UPSS for the second time with the same con-

tent. However, convergent encrypion and deduplica-

tion bring with themselves some risks that are dis-

cussed in Section 3.

2.1.1 Block Stores

A narrow API including read, write, block_size

and is_persistent methods is implemented by

several types of block stores shown in Figure 1:

in-memory (non-persistent), ﬁle-backed, networked,

cloud via Amazon S3 (Amazon Web Services, Inc.,

2020) or Azure blob storage (Microsoft, Inc., 2023),

caching and mirror. The caching and mirror block

stores consist of multiple stores, that accomplish

different tasks. The former enables caching (Sec-

tion 2.1.2) and the latter handles replication (Sec-

tion 2.1.3), both at the block level.

When an encrypted block is stored in a block

store, the block store responds with a block name

derived using that store’s preferred cryptographic

hash algorithm. A block’s name can be used to re-

trieve the block in the future without any further au-

thorization — it is a cryptographic capability (Den-

nis and Van Horn, 1966). This approach allows block

stores to be oblivious to user identities and content

ownership. Instead, it is a content-addressed store.

The operator of a block store cannot view plaintext

content or even directly view metadata such as ﬁle

sizes or directory-ﬁle relationships. Inference of these

relationships is discussed in Section 3, which also de-

scribes the stronger privacy and security properties

that UPSS provides relative to other cryptographic

and conventional ﬁlesystems.

Cacheing

block store

Journal

Cacheing

block store

Journal

near near

far farget 8b3…

store 4dc…

Figure 2: A caching hierarchy of untrusted block stores.

2.1.2 Caching

The caching block store consists of two other near and

far stores and a journaling mechanism. A near store

can be an in-memory block store that processes the

operations faster than a far store that can be a ﬁle-

backed, networked, cloud, mirror, or another caching

block store. Note that both near and far stores can be

any block stores. By having the caching block store,

UPSS enables building a cache hierarchy as shown in

Figure 2. For storing an encrypted block, the caching

block store stores the block to the near store and jour-

nals it to an on-disk ﬁle. The journaled blocks will

be processed in the background to be stored to the far

store. For reading, the caching block store tries to

read the block from the near store and if it does not

exist (e.g., the near store is an in-memory store which

has been cleared), the block is read from the far store.

The conﬁdentiality and immutability of blocks in a

block store enable aggressive yet safe caching, even

with remote storage on untrusted systems. This makes

UPSS achieve better performance results as discussed

in Section 4.

A challenging problem with caching data in any

information system is handling inconsistencies; a

block’s content can be updated in a cache while not

in other locations. However, UPSS avoids any cache

inconsistencies and reduces this problem to a version

control problem by the immutable nature and crypto-

graphic naming of the stored blocks. A block may be

present within or absent from a store, but it cannot be

inconsistent between two stores: even the smallest in-

consistency in content would cause the blocks to have

different cryptographic names.

2.1.3 Data Availability via Replication

The mirror block store handles data replication across

multiple block stores. For storing an encrypted block,

the mirror block store replicates the block to all block

stores in parallel and returns the block name upon suc-

cessful replication. For reading, the mirror block store

queries the block by its name from all block stores

in parallel and returns the block from a block store

that responds faster and ignores other block store re-

sponses.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

662

Version

blocks

bp bp bp

…

bp bp

Version

∅

blocks

bp bp bp …bp bp

Figure 3: Two sequential Version objects that reference

two common blocks and one diverging block.

2.2 Immutable DAGs

UPSS uses directed acyclic graphs (DAGs) of im-

mutable blocks to represent ﬁles and directories. Re-

lationships among blocks are speciﬁed by Version

objects that describe arbitrary-length collection of im-

mutable blocks, each accessible by their block point-

ers. As shown in Figure 3, multiple Version objects

can reference underlying immutable blocks, facilitat-

ing the copy-on-write modiﬁcation of ﬁles and direc-

tories described in Section 2.3. Version objects are

themselves stored in UPSS blocks, allowing them to

be named according to their cryptographic hashes.

For ﬁles smaller than 100 kiB, a Version ﬁts in a

single UPSS block. A Version may contain a block

pointer to a previous Version, and thus a Version

can be used as a Merkle tree (Merkle, 1979) (more

precisely, a Merkle DAG) that represents an arbitrary

number of versions of an arbitrary quantity of im-

mutable content.

This use of Merkle DAGs reduces the problem of

data consistency to that of version control: it is pos-

sible for two ﬁles to contain different blocks, but not

two variations of the “same” block. It is left to the

user of these immutable DAGs to provide mutable

ﬁlesystem objects using copy-on-write (CoW) seman-

tics and to ensure that new blocks are appropriately

pushed to backend block stores.

2.3 Mutable Filesystem Objects

Conventional mutable ﬁlesystem objects (ﬁles and di-

rectories) are provided by UPSS by mapping arrays

of bytes into mutable Blob objects. These objects

maintain copy-on-write (CoW) references to underly-

ing blocks and versions. Non-traditional objects such

as structured binary key-value data structures are also

possible using multiple blobs and versions.

A Blob manages an array of bytes via copy-on-

write block references, starting from an empty se-

quence of blocks and permitting operations such as

truncation, appending and random-access reading and

writing. A Blob accumulates edits against an im-

mutable Version in an “edit session” (Asklund et al.,

1999) until a ﬁle or directory is persisted into a new

immutable Version. This allows UPSS to accumu-

late write operations and batch them into aggregate

CoW operations.

Files and directories are both backed by Blob ob-

jects, and both can be explicitly persisted to backing

storage via API calls persist() and name(), which

persists an object and returns its block pointer. A

ﬁle version can be named by a block pointer to its

Version object which represents the ﬁle’s content

and, optionally, history. A directory is represented as

a sequence of directory entries, each of which maps

a unique, user-meaningful name to a ﬁlesystem ob-

ject (ﬁle or directory). A directory can be persisted

by serializing its entries into a Version that is named

by a block pointer. Thus, directories are also Merkle

DAGs that reference the lower-level Merkle DAGs of

other ﬁle and directory objects.

Cryptographic hashes are computed and blocks

encrypted when ﬁles and directories are persisted,

making persisting one of the most expensive opera-

tions in UPSS. Tracking chains of Version objects in

addition to content makes both the time and storage

requirements for persistence superlinear. It is, there-

fore, only done when requested via the API or, in the

case of UPSS-FUSE, every 5 s. Based on our mea-

surement results, the total space b

required in a block

store to store b bytes of content follows Equation (2).

= (1.09 + 0.001613 ) b (2)

2.3.1 Mutation and Versioning

Naming all ﬁlesystem objects by block pointers to

Version structures introduce new challenges to han-

dling modiﬁcations. Whenever a ﬁle or directory is

modiﬁed in a directory hierarchy, a new block pointer

is generated that should be updated in the object’s

parent entries , and this update should be applied

up to the root directory. In order to handle updates

efﬁciently, every ﬁle and directory object keeps an

Updater object, which is a reference to its parent in-

memory object. Upon modiﬁcation and persisting,

an object notiﬁes its Updater about its new block

pointer and the parent object is modiﬁed to reﬂect the

child’s new version. Similar requirements for updat-

ing of parents exist in other CoW ﬁlesystems such as

ZFS (Bonwick et al., 2003), but the case of a global

CoW ﬁlesystem such as UPSS is more challenging

than that of local ﬁlesystems. In a local CoW ﬁlesys-

tem, it is possible for the ﬁlesystem implementation to

be aware of all concurrent uses of a parent directory,

UPSS: A Global, Least-Privileged Storage System with Stronger Security and Better Performance

663

including by multiple users. In a global ﬁlesystem,

however, not all uses of a parent directory are visible

to a local host. UPSS therefore, treats every update

to a ﬁlesystem subtree as a potential versioning oper-

ation, allowing new directory snapshots to be created

and shared as described in section 2.3.2; versions can

be integrated at the level of ﬁlesystem interfaces as

described in section 2.4.

2.3.2 Snapshot and Sharing

As a copy-on-write ﬁlesystem, UPSS provides cheap

snapshots of previous versions. UPSS creates snap-

shots whenever requested via sync(2), fsync(2) or

the UNIX sync(1) command, or in case of FUSE

(ﬁlesystem in user space) wrapper, by querying

a directory’s cryptographic name with POSIX ex-

tended attributes, or in case of UPSS API, by calling

persist() or name() methods. Also, extended at-

tributes can be queried to retrieve the cryptographic

hash or serialized block pointer of any UPSS ﬁle

or directory. Exposing serialized block pointers to

users facilitates sharing of ﬁle and directory snapshots

from user to user, including sharing from UPSS FUSE

wrapper snapshots to users employing the UPSS CLI.

Also, this allows users to check integrity guaran-

tees over ﬁle and directory Merkle DAGs, facilitating

blockchain-like applications.

As a user-empowering sharing system, these

snapshots can be quickly shared with other users for

read-only access: user a need only share the block

pointer to a ﬁle or directory with user b, and user b

will be able to retrieve the content from a block store

and decrypt it. Since block pointers correspond to

immutable blocks, user b cannot modify the shared

block. Upon modiﬁcation, a new block is generated

with a new block pointer and user a still has access to

the unmodiﬁed shared block.

2.4 File Access Interfaces

Users can access an UPSS ﬁlesystem via a variety of

interfaces, including a Rust API which can be com-

piled to WebAssembly, a command-line interface and

a FUSE (Filesystems in Userspace) interface. Unlike

many ﬁlesystems, any UPSS directory can be treated

as the root directory of a ﬁlesystem. Within a direc-

tory hierarchy, a user may persist any subdirectory to

retrieve a block pointer to an immutable version of

it. That version may then be used as the basis for fur-

ther ﬁlesystem operations including mounting, mutat-

ing and further sharing. When new versions of ﬁles

and directories are generated, parent directories are

updated until a new root directory version is created.

Storing the block pointer of that new root directory is

15898

15972

353307

177870

3202

3166

278554

24568

5242

5233.4

52105.4

5877

2700

2524.4

49921.6

468.6

1e+01

1e+03

1e+05

MakeDir MakeFile Read Write

Systems

Ops/s ± s.d.

api-local api-remote upss-fuse-local upss-fuse-remote

Figure 4: UPSS performance when accessed via its API

and via UPSS-FUSE connected to a local or remote block

store. The average number of operations per 60 seconds is

reported for ﬁve runs; error bars show standard deviation.

the responsibility of an UPSS client (API, CLI, FUSE

or future native VFS implementation). The UPSS CLI

and FUSE clients both store this information in a lo-

cal passphrase-protected ﬁle as per PKCS #5 Version

2.0 (Kaliski, 2000) for interoperability.

Direct API invocation provides clear performance

beneﬁts when compared to FUSE-based wrapping.

As shown in Figure 4, directly invoking the UPSS

API yields higher performance than using a FUSE

wrapper with the same storage backend. For two of

the four microbenchmarks described in Section 4.1,

the cost of the FUSE wrapper exceeds that of the cost

of communicating with a remote blockstore via direct

UPSS API.

3 SECURITY MODEL

The judicious use of full-ﬁlesystem, per-block con-

vergent encryption allows UPSS to employ untrusted

storage backends that can scale to the largest of

workloads without revealing user data or metadata.

Its user-agnostic approach allows it to be employed

within applications and in a range of uses from a lo-

cal ﬁlesystem to a global sharing system.

Other cryptographic ﬁlesystems take a variety of

approaches to encryption. EncFS (Team, 2018) and

NCryptFS (Wright et al., 2003) employ encryption for

ﬁle content but not the ﬁlesystem itself, e.g., directory

structure. CryFS (Messmer et al., 2017) protects the

ﬁlesystem with a single encryption key. This implies

strong ﬁlesystem boundaries and precludes safe sub-

set sharing: the unit of possible sharing in the system

is a ﬁlesystem, not a ﬁle. It also increases the value of

one speciﬁc encryption key, making it a more attrac-

tive target for attackers. UPSS, in contrast, encrypts

data using per-block keys derived from block content,

removing the need for separate storage of keys and re-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

664

ducing the value of any single encryption key. Since

keys are not re-used, they are not secret from autho-

rized users.

Commonly cloud-based storage allows providers

to examine users’ plaintext; backend block store

providers in UPSS can only see a sea of encrypted

blocks, as encryption is performed on the client side.

This approach ensures that metadata such as ﬁle sizes

and directory structures are not revealed explicitly to

storage providers. Providers might perform trafﬁc

analysis to infer relationships among various blocks,

but only at signiﬁcant computational cost. This threat

could be addressed by the use of oblivious transfer

techniques such as ORAM, but other large-scale dis-

tributed systems that support such techniques have

disabled them due to cost (uta, 2020b).

Convergent encryption, ﬁrst used in Farsite (Adya

et al., 2002), can also introduce risks that are not

present in traditional cryptosystems. Convergent en-

cryption is a deterministic encryption model, but the

traditional objective of indistinguishability under cho-

sen plaintext attack (IND-CPA) forbids determinism

in encryption; it can therefore reveal whether a given

plaintext has previously been encrypted and stored in

the content addressable storage if an attacker encrypts

a plaintext, presents it to a block store and uses timing

or other response information to determine whether

that block has previously been stored. Worse still,

ıve systems could allow an attacker to guess varia-

tions on a known format (user=1000, user=1001, etc.)

to test whether any such variations have previously

been stored.

UPSS addresses these concerns by appending ran-

dom padding to plaintext blocks to bring them to the

ﬁxed block size. Small blocks of user data, those

that most need protection from guessing attacks, are

padded with high-entropy random bits. Full blocks

of user data, such as content from shared media ﬁles,

do not require padding, allowing such ﬁles to enjoy

deduplication. Conﬁrmation of a large existing block

is still possible, but not via guessing attacks due to

the block sizes involved, and no user can be associ-

ated with the content. By default, any block of plain-

text data that is smaller than the ﬁxed block size will

have random padding appended. A typical AWS cre-

dential ﬁle with a known access key will have 72 B

of data that could be known to the attacker, 40 B of

Base64-encoded secret key that the attacker would

like to guess and, in a 4 kiB block, 3,984 B of random

padding.

UPSS does not explicitly represent users or user

identities. This allows applications or clients to bring

their own user model to the ﬁlesystem and avoid

the limitations of system-local users, as in systems

that project local ﬁlesystems to a multi-system con-

text, e.g., multi-user EncFS (Leibenger et al., 2016)).

Multiple users on separate systems can share a back-

end block store without interference, but the common

block store permits efﬁcient sharing among systems

and users.

4 PERFORMANCE EVALUATION

In this section, we demonstrate the practicality of

UPSS as a local ﬁlesystem (Section 4.2), a network

ﬁlesystem (Section 4.3) and a global ﬁlesystem (Sec-

tion 4.4). Although UPSS achieves its best perfor-

mance when accessed via API rather than FUSE, em-

ploying the FUSE interface allows us to directly com-

pare its performance with the performance of extant

systems. These performance comparisons are com-

pleted using a suite of microbenchmarks and one

FileBench-inspired macrobenchmark.

4.1 Benchmark Description

We have compared the performance of UPSS with

other systems using both custom microbenchmarks

and a Filebench-inspired benchmark. All bench-

marks were executed on a 4-core, 8-thread 3.6 GHz

Intel Core-i7-4790 processor with 24 GiB of RAM

and 1 TB of ATA 7200 RPM magnetic disk, run-

ning Ubuntu Linux 4.15.0-72-generic. Remote block

stores, where employed, used machines with different

conﬁgurations as described in Section 4.3.

For microbenchmarking, we evaluated the cost of

creating ﬁles and directories and reading and writing

from/into on-disk local and remote block stores. For

evaluating ﬁle and directory creation, we generated

a user-deﬁned number of ﬁles and directories, added

them to an ephemeral root directory and persisted the

results into ﬁle-backed block stores. To evaluate read

and write operations, we generated 1000 ﬁles ﬁlled

with random data of size 4 KiB, the natural block size

of our underlying storage, select a ﬁle randomly and

performed sequential read and write operations on it.

We also implemented a macrobenchmark that

simulates more complex behaviour. In this bench-

mark, we selected a ﬁle randomly from a set of ﬁles

and performed 10 consecutive read and write op-

erations with different I/O sizes: 4 KiB, 256 KiB,

512 KiB and 1 MiB. The building blocks of this

benchmark were inspired by the Filebench frame-

work (ﬁl, 2016), but Filebench itself could not pro-

duce the ﬁne-grained timing information used to

produce the ﬁgures shown in Sections 4.2.2, 4.3

and 4.4.1.

UPSS: A Global, Least-Privileged Storage System with Stronger Security and Better Performance

665

4.2 UPSS as a Local Filesystem

Direct usage of the UPSS API requires program mod-

iﬁcation — and, today, the use of a speciﬁc program-

ming language. In order to expose the beneﬁts of

UPSS to a wider range of software, we have imple-

mented a ﬁlesystem in userspace (FUSE) (fus, 2019)

wrapper that exposes UPSS objects to other applica-

tions via a hook into the Unix VFS layer. The chal-

lenge here is picturing UPSS’s global view of en-

crypted blocks to a local view of ﬁles and directories

that can be accessed via FUSE inode numbers. To

tackle this, UPSS-FUSE uses a mapping from FUSE

inode numbers to in-memory UPSS objects to service

VFS requests. This allows conventional applications

to access an UPSS directory mounted as a Unix direc-

tory with POSIX semantics, though there is one un-

supportable feature: hard links. Hard links are deﬁned

within the context of a single ﬁlesystem, but UPSS

is designed to allow any directory to be shared as a

root directory of a ﬁlesystem. Owing to this design

choice, it is impossible to provide typical hard link se-

mantics and, e.g., update all parents of a modiﬁed ﬁle

so that they can perform their own copy-on-write up-

dates (see Section 2.3). Therefore, we do not provide

support for hard links — a common design choice in

network ﬁle systems such as NFS.

The UPSS-FUSE wrapper exposes an ephemeral

plaintext view of an UPSS’s directory underneath a

Unix mount point, allowing conventional ﬁle and di-

rectory access, while keeping all data and metadata

encrypted at rest in a local or remote block store (see

Section 2.1). Unlike existing cryptographic ﬁlesys-

tems such as NCryptFS (Wright et al., 2003) and

EncFS (Leibenger et al., 2016; Team, 2018), no plain-

text directory structure is left behind in the mount

point after the ﬁlesystem has been unmounted.

4.2.1 Consistency

In order to provide data consistency, UPSS-FUSE re-

quests that UPSS persist a “dirty” — i.e., modiﬁed

— root directory every ﬁve seconds, or after a tun-

able number of dirty objects require persisting. As de-

scribed in Section 2.3, persisting a Directory object

causes its versioned children to be recursively per-

sisted (if dirty), after which the cryptographic block

pointer for the new root directory version can be

stored in the UPSS-FUSE metadata ﬁle. This root

block pointer is the only metadata that UPSS-FUSE

needs to mount the ﬁlesystem again. The block

pointer size is 80 bytes as the defualt hashing and en-

cryption algorithm in UPSS are SHA3-512 and AES-

128 respectively. As in other copy-on-write ﬁlesys-

tems, the cost of persisting an entire ﬁlesystem de-

4000

4500

5000

5500

6000

6500

5000 10000 15000 20000

Sync interval (dirty objects)

Ops/s ± s.d.

Operation

MakeDir

Write

Figure 5: Performance of 4 kiB operations vs sync fre-

quency (in number of dirty objects) over ﬁve runs.

pends on the amount of “dirty” content in the ﬁlesys-

tem. The trade-off between the demand for frequent

data synchronization and the requirement for more

frequent — though smaller — persistence operations

is illustrated in Figure 5.

4.2.2 Performance Comparisons

To illustrate the performance of UPSS when used

as a conventional local ﬁlesystem, we compared

UPSS-FUSE with the cryptographic ﬁlesystems

CryFS (Messmer et al., 2017) and EncFS (Leibenger

et al., 2016; Team, 2018), also based on FUSE, as

well as the mature, heavily-optimized ZFS (Bonwick

et al., 2003). ZFS is not a cryptographic ﬁlesystem

designed for ﬁne-grained conﬁdentiality, but it does

share some design elements with UPSS: it is a log-

structured ﬁlesystem with copy-on-write updates that

uses cryptographic hashes to name blocks. In con-

trast to UPSS-FUSE, ZFS has been extensively opti-

mized over the past two decades to become a high-

performance, widely-deployed ﬁlesystem.

We mounted each of these four ﬁlesystems on

different paths in the Linux host referenced in Sec-

tion 4.1 and ran four microbenchmarks to test their

speed in creating empty directories (MakeDir), creat-

ing empty ﬁles (MakeFile), reading randomly select

ﬁles sequentially including 4 KiB of data (ReadFile)

and writing random data to ﬁles (WriteFile).

Each of these four operations was run 100k and

the behaviour of the ﬁlesystems were reported in

Figure 6. In these plots, the x-axis represents the

time needed to complete all 100k operations. UPSS

outperforms EncFS and CryFS for all operations,

with performance especially exceeding these exist-

ing systems in the critical read and write bench-

marks. As might be expected, ZFS signiﬁcantly out-

performs UPSS in all benchmarks, with read perfor-

mance 3× and write performance 10.9× faster than

UPSS-FUSE. In UPSS-FUSE, creating ﬁles and di-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

666

2000

4000

6000

0.0 2.5 5.0 7.5 10.0

MakeDir x 100k

2000

4000

0 4 8 12

MakeFile x 100k

2000

3000

4000

5000

6000

7000

0.0 0.2 0.4 0.6

Read x 100k

1000

2000

3000

4000

5000

0.0 2.5 5.0 7.5

Write x 100k

Time(s)

Ops/s

(a) UPSS-FUSE.

2000

4000

6000

0.0 0.5 1.0 1.5 2.0

MakeDir x 100k

3000

6000

9000

0.0 0.5 1.0 1.5 2.0

MakeFile x 100k

15000

17500

20000

22500

0.00 0.05 0.10 0.15 0.20 0.25

Read x 100k

8000

10000

12000

0.0 0.2 0.4 0.6 0.8

Write x 100k

Time(s)

Ops/s

(b) ZFS.

3000

6000

9000

0 5 10 15

MakeDir x 100k

1000

2000

3000

4000

5000

0 5 10 15

MakeFile x 100k

10000

15000

20000

0 1 2 3 4

Read x 100k

3000

4000

5000

6000

0 5 10 15

Write x 100k

Time(s)

Ops/s

2000

4000

6000

0 50 100 150

MakeDir x 100k

2000

4000

6000

0 100 200 300 400 500

MakeFile x 100k

10000

15000

20000

25000

0 2 4 6

Read x 100k

4000

6000

8000

0 10 20

Write x 100k

Time(s)

Ops/s

(d) CryFS.

Figure 6: Performance comparison of UPSS-FUSE with

CryFS, EncFS and ZFS. Benchmarks were run for 100 kops.

rectories have the same cost, as they are both backed

by empty collections of blocks. We also note that

UPSS-FUSE performs 1.47 − 41.6× more operations

per second in various benchmarks than CryFS and

EncFS while also providing stronger security prop-

erties (see Section 5). This is due to our design

choice that the requests are served from the mapped

in-memory objects that are persisted periodically, if

dirty. Therefore, expensive persist operations can be

done quickly: with little accumulation of dirty state,

less synchronous persistence work is required.

These plots show the bursty nature of real ﬁlesys-

tems, and in the case of CryFS, they reveal perfor-

mance that scales poorly as the number of requested

operations increases. Much of the bursty nature of

these plots derives from how each ﬁlesystem synchro-

nizes data to disk. For example, by default, ZFS syn-

chronizes data every 5 s or when 64 MiB of data has

accumulated to sync, whichever comes ﬁrst. Simi-

larly, to provide a fair comparison, UPSS-FUSE is

conﬁgured to synchronize after 5 s or 15,000 writes

(close to 64 MiB of data when using 4 KiB blocks).

These periodic synchronizations cause performance

to drop, even on dedicated computers with quiescent

networks and limited process trees.

4.2.3 Macro-Benchmark

We ran the macrobenchmark described in Section 4.1

on UPSS-FUSE, CryFS, EncFs and ZFS, to evalu-

ate UPSS-FUSE in a simulation in which consecu-

tive read and write operations with different I/O sizes

are performed on different ﬁles. The results are re-

ported in Figure 7. As in our microbenchmarks,

71657.6

726312.8

19813.6

24135.2

104396.8

1263104

335564.8

69836.8

103321.6

1388646.4

409088

73625.6

98508.8

1284505.6

367820.8

74752

1000

100000

4 256 512 1024

I/O size (KiB)

KiB/s ± s.d.

CryFS EncFS UPSS-FUSE ZFS

Figure 7: Performance of CryFS, EncFS, UPSS-FUSE and

ZFS for the macrobenchmark. The numbers are the average

of KiB of I/O per second for ﬁve runs, each 60 seconds

along with their standard deviations.

ZFS outperforms the other ﬁlesystems for different

I/O sizes. UPSS-FUSE achieved better results than

CryFS and EncFS for the 4 KiB case. However, as the

I/O size increases, CryFS outperforms UPSS-FUSE.

The larger the I/O operation, the more ﬁxed-sized

blocks are generated by UPSS-FUSE, each of which

needs to be encrypted with a different key and per-

sisted. In CryFS, however, all the ﬁxed-size blocks

related to a ﬁle are encrypted with the same sym-

metric key. This causes better performance for larger

ﬁles, but at the same time makes CryFS inapplica-

ble to the partial sharing and redaction use cases that

can be supported by UPSS. UPSS has been designed

for small block sizes (typically 4 kiB), as decades of

research has shown that ﬁlesystems mostly contain

small ﬁles (Rosenblum and Ousterhout, 1992; Baker

et al., 1991; Lazowska et al., 1986).

4.3 UPSS as a Network Filesystem

Although UPSS can be used as a local ﬁlesystem, it is

primarily designed as a system for sharing data across

networks with untrusted storage providers. UPSS’

use of encrypted block stores, in which conﬁden-

tiality and integrity of these blocks’ content are as-

sured by clients and not servers, allows us to build

a block store in which a centralized server exploits

high-quality network links to transfer large numbers

of encrypted blocks — the data plane — regardless

of what block pointers are shared between users —

the control plane. This design is amenable to multi-

layer caching, as described in Section 2.1. Thus,

we have compared the performance of UPSS-FUSE

when connected to a remote block store to that of

UPSS: A Global, Least-Privileged Storage System with Stronger Security and Better Performance

667

20000

40000

60000

0 5 10 15

MakeDir x 100k

10000

20000

30000

40000

50000

0 5 10 15

MakeFile x 100k

20000

40000

0 1 2 3

Read x 100k

429

572

715

858

0 50 100 150

Write x 100k

Time(s)

Ops/s

(a) UPSS-FUSE-network.

1600

1800

2000

2200

0 10 20 30 40

MakeDir x 100k

625

1250

1875

0 10 20 30 40

MakeFile x 100k

2000

4000

6000

0 5 10 15

Read x 100k

400

600

800

1000

0 25 50 75 100 125

Write x 100k

Time(s)

Ops/s

(b) NFS.

750

875

1000

1125

0 25 50 75 100

MakeDir x 100k

250

500

750

0 50 100

MakeFile x 100k

400

800

1200

0 20 40 60 80

Read x 100k

600

800

1000

0 25 50 75

Write x 100k

Time(s)

Ops/s

Figure 8: Performance comparison of UPSS-FUSE-

network, NFS and SSHFS. Benchmarks were run for

100 kops.

SSHFS (Team, 2020) and the venerable NFS (Shepler

et al., 2003).

4.3.1 Performance Comparison

As in Section 4.2.2, we evaluated the performance of

UPSS by mounting an UPSS-FUSE ﬁlesystem in a

Unix mount point and comparing it to other ﬁlesys-

tems using four microbenchmarks. In this section,

however, we connected our UPSS-FUSE ﬁlesystem

to a remote block store and compared our perfor-

mance results against two other remote ﬁlesystems:

the FUSE-based SSHFS (Team, 2020) and the ven-

erable NFS (Shepler et al., 2003). Similar to Sec-

tion 4.2.2, one comparison ﬁlesystem is primarily de-

signed for security and the other has higher perfor-

mance after a long history of performance optimiza-

tion.

The remote block store server was run on a 4-

core, 2.2 GHz Xeon E5-2407 processor with 16 GiB

of RAM and 1 TB of magnetic disk, running FreeBSD

12.1-RELEASE. The client machine, that runs UPSS-

FUSE, is a 4-core, 3.5 GHz Xeon E3-1240 v5 pro-

cessor with 32 GiB of RAM and 1 TB of magnetic

disk, running Ubuntu Linux 16.04. The client and

server were connected via a dedicated gigabit switch.

Figure 8 shows the behaviour of the benchmarked

ﬁlesystems when executing 100k MakeDir, Make-

File, Read and Write operations.

UPSS outperforms SSHFS and even NFS for

MakeDir, MakeFile and Read operations and for

Write, it achieves comparable results. For the

Read benchmark, UPSS-FUSE has a slow start as

encrypted blocks are read from the remote block

store and are loaded into memory. After ﬁles are

loaded into memory, other read operations are served

from the in-memory objects. This causes UPSS-

FUSE to be about 5× faster than NFS in the Read

benchmark, validating UPSS-FUSE’s approach to en-

crypted block storage and the safe and aggressive

caching it enables.

4.4 UPSS as a Global Filesystem

In addition to local and network ﬁlesystem, UPSS-

FUSE can also be connected to untrusted cloud stor-

age providers. To do so, we have implemented an

UPSS block store backed in the Amazon S3 service

(Amazon Web Services, Inc., 2020) and compared its

performance with S3FS (Gaul et al., 2020), Perkeep

(Lindner and Norris, 2018) and UtahFS (uta, 2020a;

uta, 2020b).

4.4.1 Performance Comparison

We mounted UPSS-FUSE backed with the Amazon

block store (with and without local caching), S3FS,

Perkeep and UtahFS in different Unix mount points

and compared them using our four microbenchmarks.

S3FS allows Linux and macOS to mount an Amazon

S3 bucket via FUSE without any security properties.

Perkeep, formerly called Camlistore, is a FUSE-based

cryptographic ﬁlesystem that can be backed by mem-

ory, local or cloud storage. UtahFS which is in its

initial stage of development, stores encrypted data on

untrusted cloud storage. We mounted UtahFS without

Path ORAM that hides the access patterns, as it de-

grades the performance (uta, 2020b). Having the Path

ORAM enabled, the Write benchmark runs 18.59×

slower. We conﬁgured Perkeep and UtahFS to use an

Amazon S3 account for our evaluation.

We ran the benchmarks discussed in Section 4.2.2

with 5k MakeDir, MakeFile, Read and Write op-

erations and the behaviours of UPSS-FUSE-network,

S3FS, Perkeep and UtahFS during time are reported

in Figure 9. In all of these cases, Amazon S3’s re-

sponse time is the bottleneck. To have a fair compar-

ison, we ran the benchmarks for UPSS-FUSE with

and without caching. With caching enabled, we write

the encrypted blocks in a caching block store and

journal the blocks to an on-disk ﬁle, then we write

to Amazon S3 bucket by processing the journal us-

ing a background thread. This makes a large differ-

ence in the number of operations that can be done

by UPSS-FUSE as a global ﬁlesystem in comparison

with S3FS, Perkeep and UtahFS (Figure 9a). In Fig-

ure 9b, we disabled caching and persisted the con-

tent just before the benchmark script is ﬁnished so

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

668

20000

40000

60000

0.00 0.05 0.10 0.15

MakeDir x 5k

100

0.00 0.05 0.10 0.15 0.20

MakeFile x 5k

100

0.00 0.05 0.10 0.15 0.20

Read x 5k

200

400

0 50 100 150

Write x 5k

Time(s)

Ops/s

(a) UPSS-FUSE-global.

20000

40000

60000

0 5 10 15

MakeDir x 5k

20000

40000

0 5 10 15

MakeFile x 5k

20000

40000

60000

0.000 0.025 0.050 0.075 0.100

Read x 5k

200

400

0 50 100 150

Write x 5k

Time(s)

Ops/s

(b) UPSS-FUSE-global(full-

sync).

1.50

1.67

1.83

2.00

2.17

0 1000 2000 3000

MakeDir x 5k

0.33

0.67

1.00

1.33

1.67

0 1000 2000 3000 4000

MakeFile x 5k

0.00

3.33

6.67

10.00

13.33

16.67

0 50 100 150

Read x 5k

1.67

2.00

2.33

2.67

0 500 1000 1500 2000

Write x 5k

Time(s)

Ops/s

2.00

2.50

3.00

3.50

4.00

0 1000 2000 3000 4000

MakeDir x 5k

0.00

0.33

0.67

1.00

1.33

0 1000 2000 3000

MakeFile x 5k

2.00

4.00

6.00

8.00

0 200 400 600 800

Read x 5k

1.00

1.50

2.00

2.50

3.00

3.50

0 500 1000 1500

Write x 5k

Time(s)

Ops/s

(d) S3FS.

0.06

0.09

0.11

0.14

0 250 500 750 1000 1250

MakeDir x 5k

0.00

0.03

0.06

0.09

0.11

0.14

0 250 500 750 1000 1250

MakeFile x 5k

1000.00

1333.33

1666.67

0 1 2 3

Read x 5k

1.33

1.67

2.00

2.33

2.67

0 1000 2000

Write x 5k

Time(s)

Ops/s

(e) UtahFS.

Figure 9: Performance comparison of UPSS-FUSE-global,

S3FS, Perkeep and UtahFS. Owing to long read and write

delays for comparison ﬁlesystems, benchmarks were run for

5 kops rather than 100 kops.

that the content is ready to be read from the Ama-

zon block store. Even without caching and having the

content persisted to the Amazon block store, UPSS-

FUSE outperforms the other three ﬁlesystems by fac-

tors of 10–8,000. These results show that the crypto-

graphic foundation of UPSS provides, not just strong

security properties, but a foundation for aggressive

caching that would be unsafe in a system that does

not use cryptographic naming.

5 RELATED WORK

The CFS (Dabek et al., 2001), Coda (Satyanarayanan

et al., 1990), Ivy (Muthitacharoen et al., 2002),

and FARSITE (Adya et al., 2002) ﬁlesystems pro-

vide availability for user data stored on dedicated

servers in a distributed environment along with other

features such as disconnected operations, content-

addressable storage and log-structured systems. Sim-

ilar to UPSS-FUSE, FARSITE, which is a decentral-

ized network ﬁlesystem, uses convergent encryption

(Douceur et al., 2002; Li et al., 2013; Agarwala et al.,

2017) to protect user data. As CFS, Coda and Ivy

are non-cryptographic ﬁlesystems, they cannot rely

on untrusted storage servers. On the other hand, the

access control lists in FARSITE, which is a crypto-

graphic ﬁleystem, is not completely decoupled from

user data; therefore, higher level applications cannot

deﬁne their own policies, as it is possible in UPSS.

Several ﬁlesystems have been designed for un-

trusted cloud settings, such as NCryptFS (Wright

et al., 2003), EncFS (Team, 2018; Leibenger et al.,

2016), OutFS (Khashan, 2020) and CryFS (Messmer

et al., 2017). NCryptFS and EncFS are cryptographic

ﬁlesystems, which protect content by encrypting ﬁles,

but leave ﬁlesystem metadata such as the directory

structure unprotected. CryFS and OutFS solve this

problem by splitting all ﬁlesystem data into ﬁxed-size

blocks and encrypting each block individually. PLU-

TUS (Kallahalla et al., 2003), VDisk (Wires and Fee-

ley, 2007) and TVFS (Catuogno et al., 2014) also ap-

ply per block encryption. CryFs uses one key for all

encryptions, but OutFS generates separate keys per

ﬁle.

Ori (Mashtizadeh et al., 2013), IPFS (Benet, 2014)

and Perkeep (Lindner and Norris, 2018) (formerly

known as Camlistore) connect multiple devices with

a ﬁlesystem that users can access anywhere. Both Ori

and IPFS reduce the data inconsistency problem to a

version control problem by storing new versions of

ﬁles upon modiﬁcation. Similar to UPSS-FUSE, Per-

keep can be backed by a memory store, a local store or

a cloud account. However, none of Ori, IPFS or Per-

keep provide a mechanism for sharing redacted ﬁle

and directory hierarchies. Moreover, Perkeep leaves

the directory structure unprotected on the backing ser-

vice.

MetaSync (Han et al., 2015) and DepSky (Bessani

et al., 2013) are synchronization services that

store conﬁdential data on untrusted cloud storage

providers. However, these two systems cannot be

used as a platform for novel applications that UPSS

can support and they just synchronize multiple cloud

services.

Tahoe (Wilcox-O’Hearn and Warner, 2008) and

UtahFS (uta, 2020a) are cryptographic ﬁlesystems

with the goal of storing user data on untrusted storage

servers. As in UPSS, Tahoe and UtahFS store con-

tent encrypted in Merkle DAGs and provide access

control by cryptographic capabilities. Unlike UPSS,

however, Tahoe’s replica-oriented design lends itself

more readily to storage of shared immutable data than

to the use cases of a general-purpose ﬁlesystem.

UPSS: A Global, Least-Privileged Storage System with Stronger Security and Better Performance

669

6 CONCLUSION

UPSS: the user-centric private sharing system pro-

vides data availability, strong conﬁdentiality and in-

tegrity properties while relying only on untrusted

backend storage (local or remote). Data is encrypted

at rest, named cryptographically and store within a

content-addressable sea of blocks, so no ﬁle or direc-

tory structure can be discerned directly from the con-

tents of an encrypted block store. Cryptographic ca-

pabilities are used to authorize access to arbitrarily-

sized DAGs of ﬁles and directories without cen-

tralized access control. Convergent encryption en-

ables data de-duplication for large ﬁles among even

mutually-distrustful users while avoiding the com-

mon pitfalls of the technique for small, low-entropy

ﬁles.

UPSS wraps copy-on-write operations with a con-

ventional ﬁlesystem API, accessible directly as a li-

brary or proxied via a FUSE interface. Although

UPSS-FUSE’s performance is lower than that of di-

rect API usage, it exceeds that of comparable cryp-

tographic ﬁlesystems and is within an order of mag-

nitude of that of the mature copy-on-write ﬁlesys-

tem ZFS. When using remote storage, UPSS’s per-

formance exceeds that of UtahFS, Google’s Perkeep

and even, for some benchmarks, unencrypted NFS.

UPSS demonstrates that it is possible to achieve

both strong security properties and high performance,

backed by untrusted local, remote or global stor-

age. UPSS’s performance is comparable to — or, in

some cases, superior to — mature, heavily-optimized

ﬁlesystems. Adoption of UPSS will lay the founda-

tion for future transformations in privacy and integrity

for applications as diverse as social networking and

medical data storage, providing better opportunities

for users — not system administrators — to take con-

trol of their data.

REFERENCES

(2016). Filebench - A model based ﬁlesystem workload

generator. https://github.com/ﬁlebench/ﬁlebench.

(2019). FUSE (Filesystem in Userspace). https://github.

com/libfuse/libfuse/releases/tag/fuse-3.9.0.

(2020a). UtahFS. https://github.com/cloudﬂare/utahfs/

releases/tag/v1.0.

(2020b). UtahFS: Encrypted File Storage. https://blog.

cloudﬂare.com/utahfs.

Adya, A., Bolosky, W. J., Castro, M., Cermak, G., Chaiken,

R., Douceur, J. R., Howell, J., Lorch, J. R., Theimer,

M., and Wattenhofer, R. P. (2002). FARSITE: Fed-

erated, available, and reliable storage for an incom-

pletely trusted environment. ACM SIGOPS Operating

Systems Review, 36(SI):1–14.

Agarwala, A., Singh, P., and Atrey, P. K. (2017). DICE:

A dual integrity convergent encryption protocol for

client side secure data deduplication. In 2017 IEEE

International Conference on Systems, Man, and Cy-

bernetics (SMC), pages 2176–2181. IEEE.

Amazon Web Services, Inc. ((Accessed on February

28, 2020)). Amazon Simple Storage Service.

”https://aws.amazon.com/s3”.

Asklund, U., Bendix, L., Christensen, H. B., and Magnus-

son, B. (1999). The uniﬁed extensional versioning

model. In System Conﬁguration Management, pages

100–122, Berlin, Heidelberg. Springer Berlin Heidel-

berg.

Baker, M. G., Hartman, J. H., Kupfer, M. D., Shirriff, K. W.,

and Ousterhout, J. K. (1991). Measurements of a dis-

tributed ﬁle system. In Proceedings of the thirteenth

ACM Symposium on Operating Systems Principles,

pages 198–212.

Benet, J. (2014). IPFS: content addressed, versioned, P2P

ﬁle system. arXiv preprint arXiv:1407.3561.

Bessani, A., Correia, M., Quaresma, B., Andr

e, F., and

Sousa, P. (2013). DepSky: dependable and secure

storage in a cloud-of-clouds. ACM Transactions on

Storage (TOS), 9(4):1–33.

Bonwick, J., Ahrens, M., Henson, V., Maybee, M., and

Shellenbaum, M. (2003). The Zettabyte ﬁle system.

In Proc. of the 2nd Usenix Conference on File and

Storage Technologies, volume 215.

Bozorgi, A. (2020). From online social network analysis

to a user-centric private sharing system. PhD thesis,

Memorial University of Newfoundland.

Bozorgi, A., Jadidi, M. S., and Anderson, J. (2019). Chal-

lenges in Designing a Distributed Cryptographic File

System. In Cambridge International Workshop on Se-

curity Protocols, pages 177–192. Springer.

Catuogno, L., L

ohr, H., Winandy, M., and Sadeghi, A.-R.

(2014). A trusted versioning ﬁle system for passive

mobile storage devices. Journal of Network and Com-

puter Applications, 38:65–75.

Dabek, F., Kaashoek, M. F., Karger, D., Morris, R., and

Stoica, I. (2001). Wide-area cooperative storage with

CFS. In ACM SIGOPS Operating Systems Review,

volume 35, pages 202–215. ACM.

Dennis, J. B. and Van Horn, E. C. (1966). Programming

semantics for multiprogrammed computations. Com-

munications of the ACM, 9(3):143–155.

Douceur, J. R., Adya, A., Bolosky, W. J., Simon, P., and

Theimer, M. (2002). Reclaiming space from dupli-

cate ﬁles in a serverless distributed ﬁle system. In Pro-

ceedings of the 22nd International Conference on Dis-

tributed Computing Systems, pages 617–624. IEEE.

Dworkin, M. (2015). SHA-3 Standard: Permutation-Based

Hash and Extendable-Output Functions. Federal Inf.

Process. Stds. (NIST FIPS), National Institute of Stan-

dards and Technology.

Dworkin, M. J., Barker, E. B., Nechvatal, J. R., Foti, J.,

Bassham, L. E., Roback, E., and Jr., J. F. D. (2001).

Advanced Encryption Standard (AES). Federal Inf.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

670

Process. Stds. (NIST FIPS), National Institute of Stan-

dards and Technology.

Gaul, A., Nakatani, T., and rrizun (2020). S3FS: FUSE-

based ﬁle system backed by Amazon S3). https:

//github.com/s3fs-fuse/s3fs-fuse/releases.

Han, S., Shen, H., Kim, T., Krishnamurthy, A., Anderson,

T., and Wetherall, D. (2015). MetaSync: File synchro-

nization across multiple untrusted storage services. In

2015 USENIX Annual Technical Conference (USENIX

ATC 15), pages 83–95.

Kaliski, B. (2000). PKCS #5: Password-Based Cryptogra-

phy Speciﬁcation Version 2.0. RFC 2898.

Kallahalla, M., Riedel, E., Swaminathan, R., Wang, Q., and

Fu, K. (2003). Plutus: Scalable secure ﬁle sharing on

untrusted storage. In 2nd USENIX Conference on File

and Storage Technologies (FAST 03).

Khashan, O. A. (2020). Secure outsourcing and sharing

of cloud data using a user-side encrypted ﬁle system.

IEEE Access, 8:210855–210867.

Lazowska, E. D., Zahorjan, J., Cheriton, D. R., and

Zwaenepoel, W. (1986). File access performance of

diskless workstations. ACM Transactions on Com-

puter Systems (TOCS), 4(3):238–268.

Leibenger, D., Fortmann, J., and Sorge, C. (2016). EncFS

goes multi-user: Adding access control to an en-

crypted ﬁle system. In 2016 IEEE Conference on

Communications and Network Security (CNS), pages

525–533. IEEE.

Li, J., Chen, X., Li, M., Li, J., Lee, P. P., and Lou, W. (2013).

Secure deduplication with efﬁcient and reliable con-

vergent key management. IEEE Transactions on Par-

allel and Distributed Systems, 25(6):1615–1625.

Lindner, P. and Norris, W. (2018). Perkeep (n

ee Camli-

store): your personal storage system for life. https:

//github.com/perkeep/perkeep/releases.

Mashtizadeh, A. J., Bittau, A., Huang, Y. F., and Mazieres,

D. (2013). Replication, history, and grafting in the Ori

ﬁle system. In Proceedings of the Twenty-Fourth ACM

Symposium on Operating Systems Principles, pages

151–166. ACM.

Merkle, R. (1979). Secrecy, authentication, and public key

systems. PhD thesis.

Messmer, S., Rill, J., Achenbach, D., and M

u ller Quade,

J. (2017). A novel cryptographic framework for

cloud ﬁle systems and CryFS, a provably-secure con-

struction. In IFIP Annual Conference on Data and

Applications Security and Privacy, pages 409–429.

Springer.

Microsoft, Inc. ((Accessed on January, 2023)). Azure

Blob Storage. ”https://azure.microsoft.com/en-

us/products/storage/blobs/ ”.

Muthitacharoen, A., Morris, R., Gil, T. M., and Chen, B.

(2002). Ivy: A read/write peer-to-peer ﬁle system.

ACM SIGOPS Operating Systems Review, 36(SI):31–

44.

Rosenblum, M. and Ousterhout, J. K. (1992). The design

and implementation of a log-structured ﬁle system.

ACM Transactions on Computer Systems (TOCS),

10(1):26–52.

Satyanarayanan, M., Kistler, J. J., Kumar, P., Okasaki,

M. E., Siegel, E. H., and Steere, D. C. (1990). Coda: A

highly available ﬁle system for a distributed worksta-

tion environment. IEEE Transactions on Computers,

39(4):447–459.

Shepler, S., Callaghan, B., Robinson, D., Thurlow, R.,

Beame, C., Eisler, M., and Noveck, D. (2003).

RFC3530: Network File System (NFS) Version 4 Pro-

tocol.

Team, E. (2018). EncFS: an Encrypted Filesystem for

FUSE. https://github.com/vgough/encfs/releases/tag/

v1.9.5.

Team, S. (2020). SSHFS (a network ﬁlesystem client to

connect to ssh servers). https://github.com/libfuse/

sshfs/releases.

Wilcox-O’Hearn, Z. and Warner, B. (2008). Tahoe: the

least-authority ﬁlesystem. In Proceedings of the 4th

ACM International Workshop on Storage Security and

Survivability, pages 21–26.

Wires, J. and Feeley, M. J. (2007). Secure ﬁle system

versioning at the block level. In proceedings of the

2nd ACM SIGOPS/EuroSys European Conference on

Computer Systems 2007, pages 203–215.

Wright, C. P., Martino, M. C., and Zadok, E. (2003).

NCryptfs: A Secure and Convenient Cryptographic

File System. In USENIX Annual Technical Confer-

ence, General Track, pages 197–210.

UPSS: A Global, Least-Privileged Storage System with Stronger Security and Better Performance

671
