Evaluating the Inﬂuence of Multi-Factor Authentication and Recovery

Settings on the Security and Accessibility of User Accounts

Andre B

uttner

and Nils Gruschka

University of Oslo, Gaustadall

een 23B, 0373 Oslo, Norway

ﬁ

Keywords:

Authentication, MFA, Security, Accessibility, Account Access Graphs.

Abstract:

Nowadays, most online services offer different authentication methods that users can set up for multi-factor

authentication but also as a recovery method. This conﬁguration must be done thoroughly to prevent an ad-

versary’s access while ensuring the legitimate user does not lose access to their account. This is particularly

important for fundamental everyday services, where either failure would have severe consequences. Neverthe-

less, little research has been done on the authentication of actual users regarding security and the risk of being

locked out of their accounts. To foster research in this direction, this paper presents a study on the account

settings of Google and Apple users. Considering the multi-factor authentication conﬁguration and recovery

options, we analyzed the account security and lock-out risks. Our results provide insights into the usage of

multi-factor authentication in practice, show signiﬁcant security differences between Google and Apple ac-

counts, and reveal that many users would miss access to their accounts when losing a single authentication

device.

1 INTRODUCTION

Online services play an ever-increasingly important

role in our digital world. We use them in many as-

pects of our private and business lives, like ﬁnance,

transport, communication, entertainment, etc. Big

tech companies—like Google and Apple—provide us

with different services, including cloud storage, de-

vice management, payment, or single sign-on (SSO)

to other online services. We highly depend on these

services for more and more everyday tasks, and their

availability and security are more crucial than ever.

Most online services require an account, and the

user must authenticate to give proof of the owner-

ship of their account. Authentication is still done

mainly through passwords, although it is commonly

known that passwords are a relatively weak method

to protect a user account (Taneski et al., 2019). This

has been conﬁrmed in many studies, highlighting the

problems with simple passwords and the reluctance

to use password managers (Hayashi and Hong, 2011;

Shen et al., 2016; Davis et al., 2022). Therefore,

multi-factor authentication (MFA) is usually offered

to increase security and make compromising an ac-

count by a malicious user signiﬁcantly harder. With

https://orcid.org/0000-0002-0138-366X

https://orcid.org/0000-0001-7360-8314

MFA, the user needs to provide, in addition to the

password, one

or more authentication factors, such

as a one-time password (OTP) from an authenticator

app or sent via SMS or a security key. Despite the

apparent advantage, many users consider MFA incon-

venient and, therefore, refrain from activating it (Das

et al., 2019). However, an increasing number of ser-

vices make MFA mandatory and enforce conﬁguring

a second authentication factor. In addition, there is a

movement towards passwordless authentication with

the use of FIDO2 passkeys (Google, 2022), but, at the

time of writing, it is not widely adopted yet.

Suppose the MFA methods are not accessible, or

users forget their password (or lose access to their

password storage). In that case, most online services

provide additional authentication factors, so-called

account recovery mechanisms. Typical examples of

these mechanisms are a link or code sent via email

or SMS. However, such account recovery can be ex-

ploited if they are less secure than the main authen-

tication, e.g., if a recovery email address is not pro-

tected sufﬁciently (Li et al., 2018). Also, a recovery

factor might be bound to the same device as the main

authentication. For example, the phone receiving the

recovery SMS might be the same as the phone used

In this case, also called two-factor authentication

(2FA). In this paper, we will generally use the term MFA.

Büttner, A. and Gruschka, N.

Evaluating the Inﬂuence of Multi-Factor Authentication and Recovery Settings on the Security and Accessibility of User Accounts.

DOI: 10.5220/0012319000003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 691-700

ISBN: 978-989-758-683-5; ISSN: 2184-4356

691

for generating the MFA OTPs, which is certainly not

an uncommon combination on a smartphone. Statis-

tics show that smartphones often get stolen, damaged,

or lost (Bitkom, 2021; Beatriz Henr

ıquez, 2022),

which can (in addition to the ﬁnancial loss) make con-

nected accounts inaccessible. Many providers warn

users if the authentication is insecurely conﬁgured

(e.g., no MFA activated or weak password). Still, they

can not derive which device the conﬁgured factors are

bound to. Furthermore, little research was done on

this issue.

To tackle this research question, we conducted

an online survey with 185 test participants to study

the authentication conﬁguration of their Google and

Apple accounts

. To analyze the participants’ re-

sponses, we extended and applied Account Access

Graphs (AAG) (Hammann et al., 2019; P

ohn et al.,

2022), a new approach to evaluate MFA and recovery

conﬁgurations. The analysis revealed insights into the

account security and accessibility “in the wild”. The

main contributions of this paper are thereby as fol-

lows:

1. An improved accessibility scoring for AAG mod-

els with higher practical signiﬁcance.

2. A security and accessibility analysis of the au-

thentication setups by actual Apple and Google

users.

The remainder of this paper is structured as fol-

lows. Section 2 presents related work on MFA and

AAGs. In Section 3, the methodology of AAGs is de-

scribed, as well as our security and accessibility scor-

ing. Afterwards, we describe our study design in Sec-

tion 4. In Section 5, we present our study results. Sec-

tion 6 discusses the limitations, our new accessibility

scoring, and the implications of our results on MFA.

The paper is ﬁnally concluded in Section 7.

2 RELATED WORK

A study from 2015 analyzed how widely MFA au-

thentication is adopted among Gmail users (Petsas

et al., 2015). Within their test set, 6.39% of all users

had an MFA method enabled, about 62% had conﬁg-

ured a phone for account recovery, and 17% had pro-

vided a recovery email address. This gives a good pic-

ture of the adoption of MFA at the time of the study,

but it might have changed signiﬁcantly throughout the

years. Their study is similar to ours regarding the col-

lected data, i.e., enabled MFA and recovery methods.

We selected Google and Apple, as they are two of the

largest online services and offer a large variety of authenti-

cation conﬁguration options.

However, they obtained the data by using the Google

Password Reminder feature with leaked email lists

while we conducted an anonymous survey with the

participants’ consent.

Much research was done on the authentication and

account recovery procedures offered by online ser-

vices. A study by Gavazzi et al. (Gavazzi et al., 2023)

investigated how popular websites support MFA and

risk-based authentication (RBA). They found that

among the 208 websites they tested, about 42% pro-

vided MFA, and about 22% applied RBA. Amft et al.,

for example, evaluated the account recovery of 1303

websites based on their documentation and tested the

actual recovery procedure on 71 of these websites. By

this, they discovered many insecure procedures, even-

tually allowing them to bypass MFA authentication

through recovery and signiﬁcant deviations between

the documentation and the actual procedure (Amft

et al., 2023). Another study analyzed usability ﬂaws

in account recovery when MFA is enabled on 78 pop-

ular websites (Gerlitz et al., 2023). Our paper, in con-

trast, focuses on which authentication and recovery

methods provided by a service are adopted by users.

Other work has been done to compare different

authentication methods based on security, privacy,

and usability properties. The conclusion is that it

is not feasible to ﬁnd authentication schemes that

perfectly satisfy all these properties (Ometov et al.,

2018). More recent research has conducted a formal

analysis of multi-factor authentication methods pro-

vided by Google, revealing some weaknesses in their

protocols (Jacomme and Kremer, 2021).

Furthermore, different studies exist that compare

the usability of MFA methods. For example, Reese

et al. have looked at the perceived usability of ﬁve

different MFA methods in terms of usability and their

efﬁciency (Reese et al., 2019). In another study, the

time used on MFA methods has been compared in two

universities, showing that this can take up a signiﬁcant

amount of working hours over a long time (Reynolds

et al., 2020).

Account Access Graphs (Hammann et al., 2019;

ohn et al., 2022) is a methodology to analyze authen-

tication systems systematically. It allows the mod-

eling of authentication and recovery methods of on-

line services and the dependencies between different

user accounts. Further, it is possible to deﬁne ded-

icated scoring schemes to evaluate various aspects

of an account, such as security and accessibility. It

was shown that this could even become a practical

tool for users to increase awareness about their ac-

count use and to support them in making it more se-

cure (P

ohn et al., 2022). Moreover, AAGs were used

in a lab study to observe patterns in account setups

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

692

Table 1: Security scores assigned to different example au-

thentication methods.

Score Category Authentication Methods

High Hardware-based Security Key, Smart Card

Medium Software-based SMS Code, OTP Apps

Low Knowledge-based Password, PIN

(Hammann et al., 2022). The methodology used in

this work mostly leans on the foundation provided in

ohn et al., 2022).

In this paper, we have enhanced the methodol-

ogy of AAGs with an improved accessibility scoring

scheme and applied it to actual user accounts. By au-

tomatically creating graphs of users, we show that an-

alyzing user accounts with AAGs can be scalable for

research on larger populations.

3 ACCOUNT ACCESS GRAPHS

In an Account Access Graph as presented in (P

ohn

et al., 2022), authentication methods and accounts are

modeled as nodes in a graph. Account nodes are il-

lustrated as rectangles, and authentication nodes as

rounded rectangles. These nodes can be connected

through intermediary nodes representing logical op-

erators, including conjunctions ’&’ and disjunctions

’|’, depicted as circles. For instance, MFA can be

modeled as a conjunction of two or more authentica-

tion methods. Recovery or alternative authentication

mechanisms are modeled as a disjunction. Graphs can

be created for the entire authentication system of an

online service or the account setup of a speciﬁc user

and can be used for qualitative and quantitative anal-

ysis.

In this paper, we use AAGs to evaluate the security

and accessibility of actual user accounts. The respec-

tive scoring schemes are described below.

3.1 Security Scoring

As suggested in (Hammann et al., 2019), there are

different possibilities to assess the security in an

AAG. We adopted a scoring scheme inspired by the

level of assurance as found in standards like NIST

(Grassi et al., 2020) or the EU electronic identiﬁca-

tion and trust services (eIDAS) (European Commis-

sion, 2023), which is a well-established method to

evaluate authentication methods. Consequently, we

chose to use an ordinal scale including low, medium

and high. An overview of how security values are as-

signed to different authentication methods is given in

Table 1.

Account

Password

SMS

Security Key

Figure 1: Example graph for showing how security scores

are calculated. The scores are indicated as L (low), M

(medium), and H (high).

The security scores of parent nodes are calculated

as follows. For the logical conjunction, the score

is calculated using the maximum score of the child

nodes. This is because all child nodes must be ac-

cessed to access this node, so the highest score deﬁnes

the security level. The score for a logical disjunction

is calculated by the minimum score of the children,

as accessing the weakest of the children is sufﬁcient

to access a node. Figure 1 shows an example for cal-

culating security scores.

Some nodes in AAGs might represent other ac-

counts, such as recovery email addresses. Ideally,

the scores for these nodes should be derived from the

respective AAGs speciﬁcally for that email account.

However, since we could not consider all possible

email accounts used, we opted for a worst-case calcu-

lation and assigned the value low to those leaf nodes.

3.2 Accessibility Scoring

Users might lose their credentials or a device required

for MFA authentication and be locked out of their

accounts. Account accessibility scores indicate how

many options users have to access their accounts.

Consequently, a low accessibility score implies a high

risk and a high score means a low risk of losing access

to an account.

The accessibility scoring, as proposed in (P

ohn

et al., 2022), provides a ﬁrst estimation of whether the

accessibility of a user account is stronger or weaker

compared to others. However, it is not precise enough

to give practical conclusions. We, therefore, propose

an improved accessibility scoring.

The basic idea behind our improved scoring re-

mains the same. All authentication methods have a

physical “representation”, e.g., passwords might be

stored on a computer or remembered in memory, and

Evaluating the Inﬂuence of Multi-Factor Authentication and Recovery Settings on the Security and Accessibility of User Accounts

693

SMS

OTPPassword

Account

Memory Tablet Phone

Figure 2: Example graph with access methods.

SMS retrieval requires a phone to which it is sent.

These elements are represented as access method in

the AAG graph and are connected to the respective

authentication node.

In contrast to the other nodes in an AAG, access

methods may have more than one parent node (as

shown in Figure 2). If multiple different access meth-

ods can access an authentication method, it means that

either one can access it. As a consequence, these ac-

cess methods have a disjunctive relation. To assess

the accessibility of a speciﬁc AAG, we use the logical

formula based on the nodes in the graph.

(Memory ∧ (Tablet ∨ Phone)) ∨ Phone (1)

(Memory ∧ Tablet) ∨ (Memory ∧ Phone) ∨ Phone (2)

(Memory ∧ Tablet) ∨ Phone (3)

As an illustrating example, the equations above

show the boolean terms describing the accessibility

of the instance in Figure 2. First, we derive the term

from the leaf nodes of the graph and replace them with

the respective access methods (1). We then transform

the term (2) to get a complete list of possible combi-

nations of access methods for accessing that account.

Finally, we reduce the term so only those access meth-

ods remain that are at least required for accessing the

account (3). This means that an account cannot be ac-

cessed if all of the device combinations in this term

are inaccessible.

We derive a numerical score based on this reduced

term for a simple comparison at a larger scale. This

is done by counting the number of occurrences n

each access method i within the reduced term and

assigning them the value s

= 1/n

. The total ac-

cessibility score is calculated using the minimum of

the conjunctive terms and the sum of the disjunctive

terms. The resulting score s

acc

gives us the lower

bound number of access methods one must lose to

lose access completely. At the same time, s

acc

− 1

can be interpreted as the upper bound number of ac-

cess methods that can be lost without any risk of being

locked out of an account. For the given example, the

accessibility score is calculated as follows:

acc

= min(1, 1) + 1 = 2

The accessibility score is 2, and losing one access

method is therefore not critical. However, losing two

methods, e.g., the phone and tablet, can make the ac-

count inaccessible to the user.

4 STUDY DESIGN

This section presents our study design. In particular,

the research questions to be answered by this study

are formulated. Furthermore, we describe the study

procedure, the AAG models created for Apple and

Google, the user account survey, and some ethical

considerations.

4.1 Research Questions

We designed a study to learn how users set up their

Google and Apple accounts and how much they de-

pend on their devices. One goal was to analyze

how users access their passwords. Nowadays, pass-

word managers are becoming increasingly popular

and are often even integrated into operating systems

or browsers. This might affect the choice of pass-

words, i.e., whether they are easy to remember or

rather created randomly and how accessible the pass-

word is. Furthermore, we wanted to check how users

adopt MFA and recovery methods compared to earlier

research (Petsas et al., 2015). In addition, we were in-

terested in the general security of the users’ accounts

by considering the primary authentication and recov-

ery methods. Finally, we wanted to assess how many

devices users depend on. From this, the following re-

search questions were derived:

• RQ1. How do the users access their passwords?

• RQ2. Which MFA and recovery methods did the

users enable?

• RQ3. How secure are the account setups?

• RQ4. How many access methods do the user ac-

counts depend on?

4.2 Methodology

For this study, we ﬁrst created the models that de-

scribe the authentication systems for Google and Ap-

ple. We then created an online survey based on the au-

thentication systems in which actual users were asked

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

694

EmailPhone

|Sign in by phone

Security keySMS / VoiceBackup codesAuthenticator appGoogle prompts

|Password

Google

Figure 3: AAG for Google.

which authentication and recovery methods they use

for their Google or Apple accounts and what means or

devices they use to access them. After that, we gen-

erated user-speciﬁc AAG models based on the survey

responses and calculated the respective security and

accessibility scores. The general survey responses, as

well as the security and accessibility scores, were ﬁ-

nally analyzed concerning the research questions.

A research tool and some scripts have been used to

facilitate the creation and analysis of the AAGs

. The

web application tool can create and visualize AAGs

and calculate security and accessibility scores. More-

over, we created Python scripts to automatically con-

vert the survey responses of the test participants into

actual AAGs. These AAGs were then imported into

the research tool and subsequently examined.

4.3 General AAG Models

The general AAG models for Google and Apple were

created in January 2023. It was ensured that the

AAGs were valid when the survey was conducted.

This is important to consider as authentication sys-

tems change over time. For instance, since Spring

2023, Google has started to support FIDO2 passkeys

as a passwordless alternative to its other authentica-

tion methods (Brand, 2023), which could not be cov-

ered in our study. The two AAG models used in this

study are described in the following paragraphs.

4.3.1 Google

To create an AAG model for Google accounts, the se-

curity settings have been examined. This is where

Our tools, survey questionnaires, anonymous partici-

pant data, and AAG ﬁles can be accessed at https://github

.com/Digital-Security-Lab/user-account-study-icissp2024

(Last accessed: 2023-12-06)

users can change their passwords or enable other

types of authentication. Note that ﬁguring out all au-

thentication methods requires experimenting because

speciﬁc options are interdependent. For Google ac-

counts, the default primary authentication method is

the password. In addition to that, it provides the

option sign-in by phone and several MFA methods.

Google users can optionally set up a recovery email

address or phone number for recovery. The respec-

tive AAG model is shown in Figure 3. In practice,

Google is applying risk based authentication (RBA)

(Wieﬂing et al., 2019), which means that it might

request different authentication factors depending on

certain features of the user’s client. This, however,

can not be modeled by the AAGs because they cur-

rently only represent static models.

4.3.2 Apple

The AAG model for Apple has been created based

on the Apple ID security settings. As with Google,

the primary authentication method here is a password.

However, users have fewer options to conﬁgure MFA

in their Apple accounts. Secondary authentication

factors can be either trusted phone numbers that are

manually added by the user or trusted devices that

are automatically conﬁgured when an Apple device is

signed in to that Apple ID account. There is also the

possibility of recovering accounts through customer

service. This can not easily be modeled or evaluated

using AAGs. Also, there is an option to set a recov-

ery contact. These two options were excluded from

the model. However, an Apple account can also be

recovered using a trusted device. This option is im-

plicitly enabled. Therefore, this has been added to the

model. Furthermore, a user can explicitly conﬁgure a

printable recovery key. If this is selected, this is the

only possible way to recover an Apple account. The

Evaluating the Inﬂuence of Multi-Factor Authentication and Recovery Settings on the Security and Accessibility of User Accounts

695

Recovery KeyDevice

SMSDevice

|Password

Apple

Figure 4: AAG for Apple.

ﬁnal AAG model for the Apple account is shown in

Figure 4.

4.4 User Account Survey

The surveys were created as two separate online

forms, each adapted to Google or Apple account set-

tings respectively. Both surveys consist of two main

parts.

First, the test participants had to make an enumer-

ated list of the devices that they actively use. They

should assign them to the categories of (1) phone, (2)

computer/laptop, (3) tablet, (4) smart watch and (5)

security key. These devices were referred to in subse-

quent questions.

For the second part, the participants were sup-

posed to log in to their Google or Apple accounts.

Afterward, they had to specify by which means they

could access their password, i.e., whether they could

remember it, whether it was stored in a password

manager, in a browser, on a device, or whether they

wrote it down on paper. They could choose multiple

options if applicable. After that, they were guided to

speciﬁc account settings and asked about them.

In the case of Google, they were asked whether

MFA methods were enabled and, if so, which ones.

In addition, they had to choose the devices by which

these methods could be accessed. For instance, if

Google prompts were selected, they had to indicate

which phones or tablets were conﬁgured for this

method. If MFA was disabled, they were asked if

sign-in by phone was enabled and for which of the

phones it was enabled. Last, they had to specify

which recovery options were enabled, including email

and phone. If a phone was selected, they had to

choose the phone from their list of devices with the

corresponding phone number.

For Apple, participants had to indicate which de-

vices were registered as trusted devices and which

used a trusted phone number. Finally, the participants

should state which recovery options were enabled in

their Apple accounts.

4.5 Ethical Considerations

In the survey, the test participants were asked about

what means they use to authenticate themselves to

their Google or Apple accounts. This could generally

be misused to exploit weak account conﬁgurations.

However, the survey was completely anonymous, and

no personal data was collected that could identify any

of the participants by any means. Also, no other sen-

sitive information, such as passwords or other secrets,

was collected. The study was conducted in compli-

ance with our university’s research ethics guidelines.

The test participants were thoroughly informed about

the procedure and fairly compensated for their time.

They could stop participating in the study at any time.

5 STUDY RESULTS

After several preliminary test runs, the survey was

conducted in mid-January 2023, with test participants

acquired using Proliﬁc (Proliﬁc, 2023). There were

94 submissions for Google (age 18-70, MV 34.89, SD

10.25) and 91 for Apple (age 19-67, MV 32.77, SD

9.7). In both cases, about half of the participants were

residents of the USA and the other half of Germany.

Below, we describe the study results concerning the

research questions.

5.1 Password Access (RQ1)

To answer RQ1, we assessed how people access their

passwords. A summary of the responses from our sur-

vey is given in Table 2. Most participants still tend to

use a password they can remember. This applies to

both Google and Apple. Yet, many also use a pass-

word manager or the password storage functionality

of a browser or device. According to our results,

less than 10% of the participants have written it down

on paper. It can be further observed that about one-

third of the Apple test participants use more than one

method to store their password, which applies to al-

most 48% of the Google participants.

5.2 Adoption of MFA and Recovery

Methods (RQ2)

In RQ2, we wanted to analyze to what extent the

users have adopted MFA and recovery methods. Ap-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

696

Table 2: Responses of test participants about their password

usage.

Password access Apple

(n = 91)

Google

(n = 94)

I can remember it 64 64

Password manager 28 37

Stored by browser/device 28 46

I wrote it down on paper 9 7

Table 3: Frequency of authentication and recovery methods

used in the participants’ Google accounts (n = 94).

Authentication method MFA Frequency

Password-only # 22

Sign-in by phone # 8

Google prompts 26

Authenticator app 15

Backup codes 8

Voice or text message 38

Security key 2

Recovery phone n/a 64

Recovery email n/a 76

ple and Google are very different in their approach

to MFA. Apple devices are implicitly conﬁgured as

MFA methods for accounts they are signed in. There-

fore, Apple users most likely have MFA enabled au-

tomatically, so we did not examine this for Apple in

more detail.

Google users have several different authentication

and recovery methods that need to be conﬁgured man-

ually. The usage of each method is shown in Table 3.

According to our results, 68% of the Google test par-

ticipants have at least one MFA method enabled. In

the previously mentioned study from 2015, only less

than 7% had MFA enabled (Petsas et al., 2015). Fur-

thermore, in 2018, a Google researcher stated that by

that time, only 10% of Gmail users had set up MFA

(Milka, 2018). Compared to that, there is a signiﬁcant

increase in our test results. One must keep in mind

that our sample size of 94 Google test participants is

relatively small. Yet, an increase was expected since

Google started to enroll MFA automatically for its

users as announced in 2021 (Risher, 2021). The most

common secondary authentication method is voice or

text message. Many of the participants also appear to

use Google prompts and authenticator apps. Backup

codes and security keys, in contrast, are used only

rarely.

Regarding recovery methods, there also seems to

be a wider adoption of a recovery email address (80%)

and a slightly increased use of the phone as a recovery

method (68%) compared to the results in (Petsas et al.,

2015).

5.3 Account Security (RQ3)

RQ3 was addressed by assessing the security scores

of the AAGs created for all test participants. In gen-

eral, it was observed that the recovery authentication

methods of Google often decrease the security of an

account, even if a user intended to use more secure

authentication methods like the security key. This

was particularly the case because most test partici-

pants used a recovery email. Nevertheless, it must

be kept in mind that the security score for email was

set to low because the accurate score could not be as-

sessed within this study. In reality, the score might be

higher depending on the email provider and account

setup. However, as mentioned before, it was shown

that recovery emails are often a weakness in an ac-

count setup (Li et al., 2018). The frequency of each

security score for Google and Apple is summarized

in Figure 5.

One can observe that there is no Google account

with a total security score high. The only way to

achieve this would be to disable all recovery meth-

ods and only enable a security key as a second au-

thentication factor. Two test participants have not

enabled recovery methods but used Google prompts

as the second authentication factor, with a score of

medium within our scoring scheme. Most Google ac-

counts have a total score of low. This is mainly be-

cause most test participants have enabled email as a

recovery method. The lesson learned is that Google

account security in practice often depends on the se-

curity of recovery email accounts.

Two Apple users are rated with the score high.

This is because they have only set up a trusted de-

vice but no trusted phone number. Most Apple ac-

counts have a score of medium. The main reason

here is likely that most Apple users use their account

in connection with at least one Apple device, which,

as mentioned before, automatically becomes a second

authentication factor.

5.4 Account Accessibility (RQ4)

We answered RQ4 by analyzing the accessibility

scores for each test participant’s Google and Apple

accounts. The scores were derived from the respec-

tive AAGs, including the access methods used by the

test participants. In Figure 6, it can be observed that

the range of accessibility scores is between 1 and 5

for Apple and between 1 and 6 for Google.

As described in Section 3.2, an accessibility score

equal to 1 indicates that an account can become inac-

cessible if one of the access methods is unavailable,

and we, therefore, analyzed these setups in more de-

Evaluating the Inﬂuence of Multi-Factor Authentication and Recovery Settings on the Security and Accessibility of User Accounts

697

Low

Medium High

100

Security score

Frequency

Apple

Low

Medium High

100

Security score

Frequency

Google

Figure 5: Histogram over security scores of the participants’ Apple and Google accounts.

tail. Within the test sample, ten of the Google ac-

counts have an accessibility score equal to 1. For Ap-

ple, this applies to seventeen accounts. After manual

analysis, it was found that in sixteen cases for Apple

and all ten cases for Google, the primary phone was

the key access method that, if lost, could cause an ac-

count lockout. This is reasonable since smartphones

play a crucial role in our lives today. The Google ac-

count of one test participant was even dependent on

the availability of both a memorized password and a

phone for Google prompts.

Beyond that, most test participants had accessibil-

ity scores of 2 or higher. This means that the major-

ity’s risk of being locked out of their account is rela-

tively low.

6 DISCUSSION

In this section, we discuss the limitations of the con-

ducted study, reﬂect on the new accessibility scoring,

and, ﬁnally, discuss what conclusions can be drawn

by our research for MFA in practice and how our

study might contribute to future improvements.

6.1 Limitations

First of all, the study was conducted with a relatively

low sample size of 91 Apple users and 94 Google

users. Hence, the study is rather an initial study, and

the results must be interpreted with that in mind. Yet,

the results give us an idea of how many possible ac-

count setups are used in practice and what potential

accessibility risks exist. Also, the results only reﬂect

a snapshot of when the study was conducted, as au-

thentication systems change with time.

Another limitation is the simpliﬁcation of the

Google model, where email accounts have been as-

signed a low security score. In practice, this will dif-

fer for each account. However, it requires a rather so-

phisticated survey covering all possible email account

setups.

Moreover, as mentioned earlier, RBA has not yet

been considered in AAGs because the models are cur-

rently static. This might inﬂuence both security and

accessibility. For that, a better understanding of RBA

is required, and future work should look into how dy-

namic AAGs may be modeled and evaluated.

6.2 Accessibility Scoring

An essential contribution of this work is the new ac-

cessibility scoring described in Section 3.2. In con-

trast to the previously proposed method (P

ohn et al.,

2022), where no transformation or reduction was con-

ducted after assessing the ﬁrst Boolean term, our ap-

proach has a more practical meaning since it shows

how many access methods a user depends on. For

the example shown in Figure 2, the score as in (P

ohn

et al., 2022) would result in an accessibility score of

1.5, while our method resulted in a score of 2.

A numerical score does not provide context about

the devices. Therefore, it could be beneﬁcial to parse

the logical formula into a human-readable description

with more context about the actual devices. For in-

stance, the ﬁnal term from the example in Figure 2

can be compiled into a description like “Access to

Account might be lost when losing both Phone and

Tablet, or losing your Phone and forgetting your pass-

word”. In practice, this could help inform online users

more effectively of the consequences of losing a par-

ticular access method and motivate them to set up an

alternative access method for authentication or recov-

ery.

6.3 MFA in Practice

Our study shows that several users depend solely on

their primary phones. For online services, it is chal-

lenging to assess the risk of their users being locked

out of their account because the services can not know

if, e.g., an authenticator app is installed on the same

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

698

1 2 3 4 5 6

Accessibility score

Frequency

Apple

1 2 3 4 5 6

Accessibility score

Frequency

Google

Figure 6: Histogram over accessibility scores of the participants’ Apple and Google accounts.

device that is used for SMS as a second authentication

factor, or that has stored a user’s password. We found

that, especially for Apple, seventeen test participants

might lose access to their accounts if they lose their

phones. For Google, this applies to ten users. Given

that, this also means that having access to the users’

phones is enough to access an account. From a user

perspective, one could argue that the term multi-factor

authentication does not always apply, even though

users have enabled multiple authentication methods in

their accounts. The likelihood of a phone being com-

promised is relatively low, as it usually requires local

authentication through a PIN or biometrics or rather

sophisticated malware. It is still a scenario that must

be considered, especially by users with high-security

requirements, e.g., due to their profession.

Also, we found that MFA and recovery are often

linked to the same device. Beyond this study, we ob-

served that, e.g., Facebook prohibits using the same

phone number for MFA and account recovery, which

is a step in the right direction. Surprisingly, other

applications, such as LinkedIn, automatically enable

both options when setting up a phone number. Web

applications should encourage users to use different

devices for different authentication methods. There-

fore, it might be helpful to have a tool for users to

keep an overview of their account and device depen-

dencies, as suggested in (P

ohn et al., 2022).

It is generally not very obvious how accessible an

account is. This depends on how people set up their

accounts and how devices and password access are

linked. AAGs can help assess this and encourage ser-

vice providers and users themselves to improve the

security and accessibility of online accounts. There-

fore, we suggest the integration of AAGs into con-

sumer tools and online services. Likewise, AAGs can

be a powerful tool in an enterprise context for an ad-

ministrator to get an overview of the account security

and accessibility of employees.

7 CONCLUSION

In this paper, we have extended the methodology of

Account Access Graphs with a new accessibility scor-

ing scheme. Moreover, we have developed and con-

ducted a study in which we analyzed several aspects

of Apple and Google user accounts, such as their

MFA adoption and their security and accessibility.

Within our security scoring scheme, Apple accounts

turned out to be more secure, likely due to the na-

ture of Apple devices being implicitly conﬁgured for

multi-factor authentication. For Google, we found

that several users still have not enabled any second

authentication factor. One of the most important ﬁnd-

ings concerning accessibility was that several Google

test participants and even more Apple test participants

entirely depended on their phones. Even though this

was not the majority, several users risk losing access

to their user accounts. All in all, our study has demon-

strated that AAGs can contribute to a deeper under-

standing of authentication methods.

We will pursue this research direction in future

work. Similar studies may be conducted for other

web services to see how secure and accessible their

users’ account setups are. Furthermore, it can be in-

vestigated how service providers can use the knowl-

edge gained to improve their authentication systems

concerning security and accessibility. Finally, dy-

namic AAG models may be developed for analyzing

accounts of online services that apply risk-based au-

thentication.

REFERENCES

Amft, S., H

oltervennhoff, S., Huaman, N., Krause, A.,

Simko, L., Acar, Y., and Fahl, S. (2023). ”We’ve Dis-

abled MFA for You”: An Evaluation of the Security

and Usability of Multi-Factor Authentication Recov-

Evaluating the Inﬂuence of Multi-Factor Authentication and Recovery Settings on the Security and Accessibility of User Accounts

699

ery Deployments. In Proceedings of the 2023 ACM

SIGSAC Conference on Computer and Communica-

tions Security, pages 3138–3152.

Beatriz Henr

ıquez (2022). Mobile Theft and Loss Report -

2020/2021 Edition. https://preyproject.com/blog/mob

ile-theft-and-loss-report-2020-2021-edition.

Bitkom (2021). Gestohlen oder verloren: Vier von zehn

Personen ist schon mal das Handy abhandengekom-

men. https://www.bitkom.org/Presse/Presseinformat

ion/Gestohlen-oder-verloren-Vier-von-zehn-Persone

n-ist-schon-mal-das-Handy-abhandengekommen.

Brand, Christiaan, K. S. (2023). The beginning of the end of

the password. https://blog.google/technology/safety-s

ecurity/the-beginning-of-the-end-of-the-password/.

Das, S., Wang, B., and Camp, L. J. (2019). MFA is a Waste

of Time! Understanding Negative Connotation To-

wards MFA Applications via User Generated Content.

arXiv preprint arXiv:1908.05902.

Davis, D. K., Chowdhury, M. M., and Rifat, N. (2022).

Password Security: What Are We Doing Wrong? In

2022 IEEE International Conference on Electro Infor-

mation Technology (eIT), pages 562–567. IEEE.

European Commission (2023). eIDAS Levels of Assurance.

https://ec.europa.eu/digital-building-blocks/wikis/di

splay/DIGITAL/eIDAS+Levels+of+Assurance.

Gavazzi, A., Williams, R., Kirda, E., Lu, L., King, A.,

Davis, A., and Leek, T. (2023). A Study of Multi-

Factor and Risk-Based Authentication Availability. In

32nd USENIX Security Symposium (USENIX Secu-

rity’23). USENIX Association, Anaheim, CA, USA.

Gerlitz, E., H

aring, M., M

adler, C. T., Smith, M., and Tiefe-

nau, C. (2023). Adventures in recovery land: Test-

ing the account recovery of popular websites when the

second factor is lost. In Nineteenth Symposium on Us-

able Privacy and Security (SOUPS 2023), pages 227–

243.

Google (2022). Passwordless login with passkeys. https:

//developers.google.com/identity/passkeys.

Grassi, P., Fenton, J., Newton, E., Perlner, R., Regenscheid,

A., Burr, W., Richer, J., Lefkovitz, N., Danker, J.,

Choong, Y.-Y., Greene, K., and Theofanos, M. (2020).

Digital Identity Guidelines: Authentication and Life-

cycle Management.

Hammann, S., Crabb, M., Radomirovic, S., Sasse, R., and

Basin, D. (2022). I’m Surprised So Much Is Con-

nected. In CHI Conference on Human Factors in

Computing Systems, pages 1–13.

Hammann, S., Radomirovi

c, S., Sasse, R., and Basin, D.

(2019). User account access graphs. In Proceedings

of the 2019 ACM SIGSAC Conference on Computer

and Communications Security, pages 1405–1422.

Hayashi, E. and Hong, J. (2011). A diary study of password

usage in daily life. In Proceedings of the SIGCHI

Conference on Human Factors in Computing Systems,

pages 2627–2630.

Jacomme, C. and Kremer, S. (2021). An extensive for-

mal analysis of multi-factor authentication protocols.

ACM Transactions on Privacy and Security (TOPS),

24(2):1–34.

Li, Y., Wang, H., and Sun, K. (2018). Email as a master key:

Analyzing account recovery in the wild. In IEEE IN-

FOCOM 2018-IEEE Conference on Computer Com-

munications, pages 1646–1654. IEEE.

Milka, G. (2018). Anatomy of Account Takeover. In

Enigma 2018 (Enigma 2018), Santa Clara, CA.

USENIX Association.

Ometov, A., Bezzateev, S., M

akitalo, N., Andreev, S.,

Mikkonen, T., and Koucheryavy, Y. (2018). Multi-

factor authentication: A survey. Cryptography, 2(1):1.

Petsas, T., Tsirantonakis, G., Athanasopoulos, E., and Ioan-

nidis, S. (2015). Two-factor authentication: is the

world ready? Quantifying 2FA adoption. In Proceed-

ings of the eighth european workshop on system secu-

rity, pages 1–7.

ohn, D., Gruschka, N., and Ziegler, L. (2022). Multi-

Account Dashboard for Authentication Dependency

Analysis. In Proceedings of the 17th International

Conference on Availability, Reliability and Security,

pages 1–13.

Proliﬁc (2023). Proliﬁc · Quickly ﬁnd research participants

you can trust. https://www.prolific.com.

Reese, K., Smith, T., Dutson, J., Armknecht, J., Cameron,

J., and Seamons, K. (2019). A usability study of ﬁve

two-factor authentication methods. In Proceedings of

the Fifteenth Symposium on Usable Privacy and Secu-

rity.

Reynolds, J., Samarin, N., Barnes, J., Judd, T., Mason, J.,

Bailey, M., and Egelman, S. (2020). Empirical mea-

surement of systemic 2fa usability. In Proceedings of

the USENIX Conference.

Risher, M. (2021). A simpler and safer future — without

passwords. https://blog.google/technology/safety-sec

urity/a-simpler-and-safer-future-without-passwords/.

Shen, C., Yu, T., Xu, H., Yang, G., and Guan, X. (2016).

User practice in password security: An empirical

study of real-life passwords in the wild. Computers

& Security, 61:130–141.

Taneski, V., Heri

cko, M., and Brumen, B. (2019). System-

atic overview of password security problems. Acta

Polytechnica Hungarica, 16(3):143–165.

Wieﬂing, S., Lo Iacono, L., and D

urmuth, M. (2019). Is

this really you? An empirical study on risk-based au-

thentication applied in the wild. In ICT Systems Se-

curity and Privacy Protection: 34th IFIP TC 11 In-

ternational Conference, SEC 2019, Lisbon, Portugal,

June 25-27, 2019, Proceedings 34, pages 134–148.

Springer.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

700
