A Recommender System to Detect Distributed Denial of Service Attacks

with Network and Transport Layer Features

gan

Ozg

, Ays¸e Tosun

and Mehmet Tahir Sandıkkaya

Department of Computer Engineering, Istanbul Technical University, Istanbul, Turkey

Keywords:

Distributed Denial of Service Attacks, Network Trafﬁc, Attack Detection, LSTM, Gaussian Naive Bayes.

Abstract:

Detecting Distributed Denial of Service (DDoS) attacks are crucial for ensuring the security of applications

and computer networks. The ability to mitigate potential attacks before they happen could signiﬁcantly re-

duce security costs. This study aims to address two research questions concerning the early detection of

DDoS attacks. First, we explore the feasibility of detecting DDoS attacks in advance using machine learning

approaches. Second, we focus on whether DDoS attacks could be successfully detected using a Long Short-

Term Memory (LSTM) based approach. We have developed rule-based, Gaussian Naive Bayes (GNB), and

LSTM models that were trained and assessed on two datasets, namely UNSW-NB15 and CIC-DDoS2019.

The results of the experiments show that 82–99% of DDoS attacks can be successfully detected 300 seconds

prior to their arrival using both GNB and LSTM models. The LSTM model, on the other hand, is signiﬁcantly

better at distinguishing attacks from benign packets. Additionally, incident response teams could utilize a

two-level alert mechanism that ranks the attack detection results, and take actions such as blocking the trafﬁc

before the attack occurs if our proposed system generates a high risk alert.

1 INTRODUCTION

In information security, accessibility is ensuring sys-

tem and data availability is a key aspect. Denial of

Service (DoS) attacks poses a threat to accessibility

and aim to disrupt a targeted system by overwhelm-

ing it with excessive requests or resource consump-

tion. The ultimate goal is causing prolonged ser-

vice disruption and potential ﬁnancial losses (Mas-

dari and Jalali, 2016). Subsequently, Distributed De-

nial of Service (DDoS) attacks leverage compromised

devices, i.e., bots, distribute malicious trafﬁc across

multiple sources, and thereby, raise mitigation chal-

lenges (Vishwakarma and Jain, 2020). Analyzing

DDoS attacks reveals that the frequency of incoming

packets can be used to identify sub-categories (Mas-

dari and Jalali, 2016). Packet sizes and headers also

indicate the subcategories of these attacks.

Mitigation methods developed on a rule-based

logic, namely Intrusion Detection Systems (IDS) (Liu

and Lang, 2019), can be integrated into network se-

curity systems for early detection for effective inci-

https://orcid.org/0009-0002-5094-4168

https://orcid.org/0000-0003-1859-7872

https://orcid.org/0000-0002-9756-603X

dent response (Chan et al., 2004). This underscores

the importance of early identiﬁcation to address po-

tential threats. While rule-based approaches have tra-

ditionally been the primary choice for attack detec-

tion, they lack the capability for attack forecasting.

To address the dynamic nature of network data, adap-

tive methods that learn from historical data are es-

sential. Deep learning (DL) approaches provide ﬂex-

ibility and effectiveness in handling evolving attack

scenarios (LeCun et al., 2015). Studies utilizing DL

models for DDoS attack detection report impressive

accuracy scores ranging from 95% to 99% (Stiawan

et al., 2021; Ramzy Shaaban et al., 2019; Cil et al.,

2021).

Notably, time-based network data has led to stud-

ies employing the LSTM model for DDoS attack

classiﬁcation, achieving accuracy and F1-score rates

above 95% and 90% respectively (Gaur and Kumar,

2022; Li and Lu, 2019; Zou et al., 2022). These

promising results are often reported on one dataset

representing a limited number of attacks, making it

unrealistic to expect similar performance in real sys-

tems. Furthermore, a signiﬁcant drawback in studies

using DL or other machine learning (ML) methods

is their focus on detecting attack-containing network

packets only after they have entered the network. This

390

Özgün, K., Tosun, A. and Sandıkkaya, M.

A Recommender System to Detect Distributed Denial of Service Attacks with Network and Transport Layer Features.

DOI: 10.5220/0012350100003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 390-397

ISBN: 978-989-758-683-5; ISSN: 2184-4356

limitation hinders early detection based on the behav-

ior of network trafﬁc, a crucial aspect for real-world

applicability and reaching more beneﬁts than post-

attack classiﬁcation.

This paper aims to propose a DL-based recom-

mender system for early detection of incoming DDoS

attacks. This system can be integrated as a valuable

component into Security Information and Event Man-

agement (SIEM) systems (Catillo et al., 2022) to warn

the incident response team before an attack occurs.

Our research questions are listed below:

• RQ1: To what extent can we detect DDoS attacks

(k seconds) prior to their arrival by employing DL

techniques and network trafﬁc data?

• RQ2: How successful is an LSTM model in de-

tecting DDoS attack datasets compared to other

rule-based and ML-based approaches?

To address these questions, we propose a recom-

mender system utilizing LSTM, GNB, and rule-based

models for detecting DDoS attacks k seconds in ad-

vance. This system generates early alerts for likely

attacks, facilitating practical integration into network

incident response teams and allowing the ranking of

alerts based on their criticality.

2 RELATED WORK

In this section, we review relevant literature on SIEM

systems and DDoS detection models. Catillo et al.

(Catillo et al., 2022) developed a big data-operated

SIEM system employing a semi-supervised deep Au-

toencoder model for anomaly detection in BG/L and

Hadoop log records, and report recall of 96–99% and

precision of 93–98%. Cinque et al. (Cinque et al.,

2018) propose a rule-based SIEM system for air traf-

ﬁc data augmented with Latent Dirichlet Allocation,

and report 90% precision and 93% recall in detecting

anomalies.

Various works have addressed DDoS attack clas-

siﬁcation using ML methods (Wu et al., 2022; Hal-

laday et al., 2022; Ramzy Shaaban et al., 2019; Cil

et al., 2021) . We summarize studies utilizing the

same datasets and algorithms with our research in Ta-

ble 1. Each study uses different approaches for DDoS

classiﬁcation, either comparing the results of differ-

ent DL methods or developing a better DL model

by using different methods together. Boonchai et al.

(Boonchai et al., 2022) compare the performance of

DNN, Autoencoder, Logistic Regression, and Na

ıve

Bayes models for DDoS classiﬁcation, while the Au-

toencoder model outperforms all with 85% accuracy.

Gaur and Kumar (Gaur and Kumar, 2022) explore bi-

nary and multi-classiﬁcation approaches with LSTM

layers, reporting accuracy values exceeding 99% and

98% respectively. In their study, the features in CIC-

DDoS2019 dataset are grouped to increase the per-

formance of the models. Zou et al. (Zou et al., 2022)

propose FAMF-LSTM, a feature-attended multi-ﬂow

LSTM model, and outperform RNN and LSTM mod-

els with over 97% accuracy and 96% recall in two

datasets. Li and Lu (Li and Lu, 2019) performed bi-

nary DDoS classiﬁcation using an LSTM model and

Bayesian approach, achieving 98% accuracy and 97%

recall in their experiments.

3 METHODOLOGY

The methodological phase of the study is designed

based on recommender system guidelines (Rezaimehr

and Dadkhah, 2021) with speciﬁc details for DDoS

detection.

3.1 Data Collection

Like in all data science studies, the development

of recommender systems initiates with data collec-

tion and storing this acquired data. Datasets uti-

lized in recommender systems are categorized as ex-

plicit or implicit, contingent upon the data collec-

tion method (Rezaimehr and Dadkhah, 2021). In

our study’s context, we employed two synthetically

generated, and explicitly collected datasets that have

been widely used in DDoS attack detection. The ﬁrst

of these datasets is a derived cyber-attack dataset re-

leased under the name UNSW-NB15 (Moustafa and

Slay, 2015). The second dataset is CIC-DDoS2019

(Sharafaldin et al., 2019) which is speciﬁcally built

out of known DDoS attack types.

UNSW-NB15. UNSW-NB15 dataset was created

by the Cyber Range Lab at the University of New

South Wales (UNSW) (Moustafa and Slay, 2015).

The tool, IXIA PerfectStorm was used to automat-

ically generate normal trafﬁc data and synthetic at-

tacks for modern networks. The raw network data

in the established simulation environment has been

recorded via the tcpdump tool, and is approximately

100GB. UNSW-NB15 includes nine different attack

types apart from normal trafﬁc data: Fuzzers, Anal-

ysis, Backdoors, DoS/DDoS, Exploits, Generic, Re-

connaissance, Shellcode and Worms.

Argus and Bro-IDS tools were utilized to de-

rive 49 different features from this dataset. The ﬁ-

nal dataset containing 49 columns and a total of

2,540,044 rows is shared as a CSV ﬁle in (Moustafa

and Slay, 2015). In our study, we only need data

A Recommender System to Detect Distributed Denial of Service Attacks with Network and Transport Layer Features

391

Table 1: Related works on DDoS attack detection.

Author Model Dataset Performance

Proposed Method LSTM UNSW-NB15

CIC-DDoS2019

0.83–0.82

0.99–0.99

(Zou et al., 2022) FAMF-LSTM BoT-IoT

UNSW-NB15

0.99–1.00

0.97–0.96

(Boonchai et al., 2022) DNN Autoencoder CIC-DDoS2019 0.81–0.81

0.85–0.85

(Gaur and Kumar, 2022) LSTM (Binary)

LSTM (Multiclass)

CIC-DDoS2019 0.99–0.98

0.98–0.98

(Li and Lu, 2019) LSTM-BA ISCX2012 0.98–0.97

Metrics given as (Accuracy - Recall)

related to DoS attacks and benign network pack-

ets. Other attack categories were dropped from the

dataset.

CIC-DDoS2019. CIC-DDoS2019 dataset, which was

created at the Canadian Institute for Cybersecurity

(CIC), University of New Brunswick (UNB), was

generated speciﬁcally for research on DDoS attacks

(Sharafaldin et al., 2019). While creating the simu-

lation environment, the network data was generated

by 25 different users using HTTP, HTTPS, FTP, SSH

and email protocols on devices running different op-

erating systems. Since the researchers aim to sim-

ulate subtypes of DDoS attacks, data belonging to

13 different DDoS attack types known as NTP, DNS,

LDAP, MSSQL, NetBIOS, SNMP, SSDP, UDP, UDP-

Lag, WebDDoS, SYN, TFTP and SYN are available

in the dataset. The raw data contains 87 features and

70,619,331 rows of data.

3.2 Pre-Processing Data

In this study, we conducted several pre-processing

steps to enhance the efﬁciency of our LSTM model

for DDoS attack detection. First, categorical features

in both datasets were converted into binary features

using the one-hot encoding method. Subsequently,

we normalized all numerical features to mitigate the

risk of overﬁtting. To identify the most effective fea-

tures for attack detection and reduce training costs,

we trained an LSTM model with four layers, includ-

ing dropout and dense layers. The top 10 features se-

lected for both datasets are available in our GitHub

repository (Ozgun, 2023).

Given that DDoS attacks typically target speciﬁc

entities from multiple sources acting as bots, we im-

plemented additional pre-processing steps to predict

attacks occurring k seconds later. This involved dis-

tinguishing prior packets from the same source and

targeting the same destination address. To achieve

this, we applied a grouping strategy, grouping pack-

src_ip_1

dst_port_1

UNSW-NB15 Src_ip - Dst_port

2 3 ... 20 21 22

src_ip_2

dst_port_2

src_ip_3

dst_port_3

src_ip_20

dst_port_20

src_ip_21

dst_port_21

src_ip_22

dst_port_22

... ... 221 222 223Time

src_ip_1

dst_port_1

src_ip_2

dst_port_2

src_ip_3

dst_port_3

label_1 label_2 label_3

Figure 1: UNSW-NB15 (Source IP - Destination Port) Rule

Based Data Preparation.

ets based on network addresses, utilizing a sliding

window approach to prevent overlooking attacks from

new sources.

During model training, we divided the input data

into mini-batches containing 50, 100, 150, and 200

packets. A sliding window was applied during the

mini-batch creation phase to preserve the time-series

structure of the data within each mini-batch. These

mini-batch groups were employed to detect DDoS at-

tacks in time series data after 300, 600, 1200, 1800,

2400, and 3000 packets. With an average of 100 ms

between each packet, our models could detect attacks

roughly 30, 60, 120, 180, 240, and 300 seconds in

advance.

The grouping of packets based on network ad-

dresses was crucial for the success of our approach.

For the UNSW-NB15 dataset, source IP–destination

port and destination IP–destination port were used

for grouping, while for the CIC-DDoS2019 dataset,

source IP–destination IP was employed. This innova-

tive approach allowed us to create a three-dimensional

array that ﬁts the LSTM model framework, enabling

the model to consider reconnaissance attacks and pro-

viding a more comprehensive analysis of DDoS sce-

narios.

For Rule-Based Model. In the rule-based model,

classiﬁcation decisions are based solely on the source

and destination addresses of the packets. The mini-

batches and sliding windows are visually depicted in

Figure 1, where different colors represent distinct el-

ements. It is crucial to highlight that classiﬁcation oc-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

392

src_ip_1

src_ip_2

label1

. . .

221

src_ip_19

src_ip_20

src_ip_1

Input

Data

Output

Data

feature_1 feature_2 feature_9 feature_10

1 2 ... 9 10

Input

Features

UNSW-NB15 Src IP Dst Port

feature_1 feature_2 feature_9 feature_10

1 2 ... 9 10

Input

Features

dst_port_1

feature_1 feature_2 feature_9 feature_10 feature_1 feature_2 feature_9 feature_10 feature_1 feature_2 feature_9 feature_10 label1

11 12 ... 19 20 181 182 ... 189 190 191 192 ... 199 200...

Row_1 Row_2 Row_19 Row_20

Preprocessed Data Row 1

Processed Data Row 1

dst_port_1

dst_port_2

dst_port_19

dst_port_20

dst_port_1

src_ip_1

Figure 2: UNSW-NB15 (Source IP - Destination Port)

Gaussian Naive Bayes Data Preparation.

src_ip_1

dst_port_1

UNSW-NB15 Src_ip - Dst_port

2 3 ... 20 21 22

src_ip_2

dst_port_2

src_ip_3

dst_port_3

src_ip_20

dst_port_20

src_ip_21

dst_port_21

src_ip_22

dst_port_22

... ... 221 222 223Time

feature_1

feature_2

feature_9

feature_10

feature_1

feature_2

feature_9

feature_10

feature_1

feature_2

feature_9

feature_10

feature_1

feature_2

feature_9

feature_10

feature_1

feature_2

feature_9

feature_10

feature_1

feature_2

feature_9

feature_10

src_ip_1

dst_port_1

feature_1

feature_10

src_ip_2

dst_port_2

feature_1

feature_10

src_ip_3

dst_port_3

feature_1

feature_10

label_1 label_2 label_3

Figure 3: UNSW-NB15 (Source IP - Destination Port)

LSTM Data Preparation.

curs for a given packet when it shares the same source

IP and destination port as the ﬁrst packet within its

corresponding window. For instance, packets at the

ﬁrst and 221

seconds must have identical IP ad-

dresses and ports to undergo classiﬁcation.

For GNB Model. In addition to grouping based

on source and destination addresses, the GNB model

was trained using the top 10 selected features. How-

ever, the GNB model inherently cannot process three-

dimensional data. Consequently, the data within each

group had to be concatenated to create a row vector.

Figure 2 visually represents the structure of data from

the UNSW-NB15 dataset in a mini-batch of 20 pack-

ets, illustrating the concatenation of different packets

to form a row vector of 1 ×200. The output is derived

from the packet at the 221

second.

For LSTM Model. The LSTM model is capable of

handling arrays larger than two dimensions, so the

GNB model’s operation of concatenating the data was

not performed. Instead, the three-dimensional data

was directly fed as the input to the LSTM model, af-

ter the grouping process as we did in the other models.

Figure 3 illustrates this process for UNSW-NB15.

3.3 Recommender Engine

Once essential data-related procedures are executed,

the next phase is building a recommendation engine.

In our study’s context, we assessed three different

classiﬁcation-based methods to build our engine for

DDoS attack detection. This section provides details

on the models’ designs and training/test procedures.

Rule-Based Model. We employed a rule-based

model, a common method in attack detection, to as-

sess its effectiveness in comparison to LSTM and

GNB models. Rule-based models, popular among

network security experts, assess packets based on

source and destination addresses, ﬂagging an attack if

packet numbers surpass a set threshold. While experts

can often set effective limits through observation, this

approach is prone to human error, especially when

done by non-experts, and can be easily deceived. In

our rule-based model, determining the threshold for

labeling a packet as an attack is crucial. A threshold

of one ﬂags all subsequent packets as attacks, lead-

ing to numerous false positives. Conversely, a very

high threshold, like 200, may result in missing attacks

and generating high false negatives. We opted for two

thresholds, three and ﬁve, indicating attack criticality.

If there are more than three but less than 6 packets

with the same source and destination addresses within

our mini-batch data, subsequent packets are labeled

as potentially containing a DDoS attack (Level 1). If

there are more than ﬁve such packets, we label it as a

Level 2 attack. Fewer than three packets are marked

as benign.

GNB Model. GNB model is used as the base ML

model in our study. Unlike the rule-based model,

since features other than the source IP/port and des-

tination IP/port information are used as input, a more

efﬁcient attack detection would be made by process-

ing the data of the reconnaissance process, especially

before the attack starts. GNB model has been reported

to produce effective attack detection in datasets con-

taining known attack types and network movements

(Belavagi and Muniyal, 2016). For this reason, we

utilize this model as a simple and robust alternative to

the LSTM model. Within the scope of our study, we

implemented the GNB model in the Python sklearn

library. We have divided the datasets as 70% train

and 30% test. We kept the same grouping used in the

rule-based model to perform detection on the same

data instances over three models.

LSTM Model. We developed a LSTM-based model,

known for its efﬁcacy in handling time-series data

(Siami-Namini et al., 2019). Unlike GNB, LSTM

does not impose speciﬁc data distributions, and un-

like rule-based models, it accommodates information

from multiple features in multi-dimensional forms.

LSTM, with its various memory types, processes his-

torical data and adapts to changing data in deep learn-

ing approaches (Van Houdt et al., 2020), making it

suitable for detecting attacks k seconds in advance

by observing prior packets over time. Our proposed

LSTM model comprises four layers: LSTM layer

A Recommender System to Detect Distributed Denial of Service Attacks with Network and Transport Layer Features

393

LSTM with 32 Units LSTM with 16 UnitsDropout (0.3) Dense with SigmoidInput Data Output Label

Figure 4: LSTM Model Structure.

with 32 units, enabling the model to learn from in-

put data and maintain memory of previous inputs.

Dropout layer to prevent overﬁtting by randomly de-

activating neurons during training, enhancing model

robustness (Sanjar et al., 2020). Additional LSTM

layer with 16 units, capturing complex temporal pat-

terns in the data. Dense layer with a sigmoid acti-

vation function for binary classiﬁcation, determining

the presence of an attack in the received packet. This

architecture is designed to effectively handle time-

series data, capture temporal dependencies, prevent

overﬁtting, and make binary classiﬁcations related to

DDoS attacks. Fig. 4 shows the general structure of

our model. The training and test splits as well as

grouping of data are the same as those described in

the GNB models.

3.4 Ranking

The system introduces a two-level alert mechanism

for incident response teams instead of providing bi-

nary results for detecting attacks k seconds in ad-

vance. Level 1 packets signify a likelihood of con-

taining attacks, while Level 2 packets are considered

high-risk, indicating a very probable attack. Benign

packets are classiﬁed as safe, indicating no attacks.

The ranking is based on posterior probabilities gen-

erated by the models during classiﬁcation. In GNB

and LSTM models, a Level 1 alert is triggered when

the posterior probability falls between 51% and 75%,

while a Level 2 alert is generated for probabilities ex-

ceeding 75%. The rule-based model, not producing

probabilities, relies on the count of packages in mini-

batches from the same source and going to the same

destination. In this context, more than three packages

prompt a Level 1 alert, while more than ﬁve packets

trigger a Level 2 alarm.

4 RESULTS

In total, 144 different experiments were performed

with combinations of two different datasets, three dif-

ferent models, two different data grouping approaches

and 24 different experimental conﬁgurations due to

mini-batch sizes and detection windows (k seconds).

In order to discuss the results more effectively, a sam-

ple is reported in this section: Three models, two

datasets, two different groupings with two mini-batch

sizes (100 and 200 packets) and three detection win-

dows (60 and 300 seconds).

RQ1. In order to answer our ﬁrst RQ, we have an-

alyzed LSTM and GNB models’ performance pre-

sented in Table 2. Please note that we have ana-

lyzed the ﬁndings on Level 1 scores only because

this level indicates that any packet with more than

50% probability is labelled as attack. Experiments

show that network trafﬁc data can be used to effec-

tively detect 80-99% DDoS attacks (recall rates) 30

to 300 seconds in advance. The precision rates also

show that the models produce very low false positives

while detecting the attacks. When we examine Table

2 in detail, it is seen that both GNB and LSTM mod-

els distinguish attacks from benign packets in CIC-

DDoS2019 dataset successfully, although this is an

attack-intensive dataset. F1-scores of 96%–99% with

GNB and 97%–99% with LSTM are reported for de-

tecting attacks. The rates are similar for detecting

benign packets, although LSTM is slightly better in

detecting benign packets in terms of recall and F1-

score. For UNSW-NB15 dataset, which is a dataset

with 10% attack data, we observe that the LSTM

model outperforms GNB in detecting attacks: An ac-

curacy rate of 81–83%, and an F1-score of 78–81%

are achieved for detecting the packets that contain an

attack. Furthermore, we have assessed the impact of

mini-batch size and k seconds on the performance of

the LSTM model for both datasets.

We have seen that increasing the mini-batch size

slightly improves the performance, whereas increas-

ing k value does not necessarily affect the ﬁndings.

For instance, in UNSW-NB15, using mini-batch size

of 20 packets and detecting attacks 60 seconds in ad-

vance gives us an F1-score of 82%, whereas mini-

batch size of 100 packets and detecting 60 seconds in

advance gives an F1-score of 85% in case of Level 1

attacks. However, mini-batch size of 200 and k value

of 60 or k value of 300 both give F1-scores of 85%

and recall 77–79% for benign and attack packets, re-

spectively. Thus, we report higher mini-batch values

and three packet counts in Table 2. We recommend

choosing the k value as 300 seconds in order to give

the network security teams the necessary time for in-

tervention, as it has been seen as the most appropri-

ate conﬁguration for both the accuracy of the recom-

mender made and for sending notiﬁcations in advance

of the required time.

RQ2. We compare the models’ performance with

each other to answer this RQ. Overall, LSTM out-

performs other models in distinguishing attacks from

other packets on both datasets with varying attack

rates. The rule-based model manages to achieve 59–

99% F1-Score for attacks but poorly performs for be-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

394

nign packets in terms of F1-score on both datasets.

The F1-score of attacks drops from 99% to 59% when

we observe UNSWNB-15 dataset, as this model tends

to classify majority of the packets as attack. This

shows us the problem with the rule-based models due

to false positive rates. When we look at the results of

GNB model in Table 2, we observe an opposite sce-

nario on UNSWNB-15 dataset: 70% F1-score is re-

ported for benign packets, whereas the F1-score rates

are very low (1%) for detecting the attacks. This

indicates that GNB model is not able to detect at-

tack packets in the context of our experimental de-

sign. When we look at the results on CIC-DDoS2019

dataset, the model reaches F1-scores above 96% for

detecting attacks, and around 81% for detecting be-

nign packets. Additionally, when we examine the

precision and recall values, we can say that GNB is

much more successful than the rule-based model, es-

pecially on CIC-DDoS2019 dataset. Upon scrutiniz-

ing the outcomes of the LSTM model, it becomes ev-

ident that it consistently outperforms other models in

distinguishing both classes in the datasets. We ob-

serve an F1-score of over 78% and 97% for detect-

ing attacks in two datasets, UNSW-NB15 and CIC-

DDoS2019 respectively.

When we assess our ﬁndings with respect to their

consistency (Avazpour et al., 2014), we can inter-

pret that the results of the experiments conducted on

UNSW-NB15 dataset, which is closer to real-life net-

work trafﬁc, are more realistic, and LSTM shows its

effectiveness on this dataset. We need further exper-

iments to prove LSTM model’s stability on real-life

data, but our ofﬂine analysis gives useful insights on

its potential.

5 DISCUSSION

Level-Based Analysis. Our recommender system of-

fers a two-level alert mechanism, prioritizing likely

attacks for efﬁcient incident response. Table 2 illus-

trates model performance for both alert levels. Since

each packet has a single label (benign/attack) in both

datasets, evaluating the performance involves catego-

rizing packets into Level 1 or Level 2 attacks based

on algorithmic posterior probabilities. A Level 1 at-

tack is identiﬁed if the probability exceeds 50%, and

a Level 2 attack is declared if the probability is above

75%. LSTM’s Level 2 alert performance exhibits

lower recall but higher precision compared to Level 1,

indicating conservative but mostly accurate detection.

In a real-life scenario, prioritizing Level 2 alerts can

aid incident response teams in preemptive actions like

trafﬁc blocking before an attack unfolds. The conser-

vative nature of Level 2 alerts, with lower false pos-

itives, aligns with expert decisions. Although delay-

ing action on Level 1 alerts may miss some incoming

attacks within the next 300 seconds, conﬁguring the

recommender system to generate forecasts and moni-

tor alert level changes can address this concern. Nei-

ther rule-based nor GNB can provide such a ranking

system in our study. Rule-based lacks probabilities,

and GNB produces probabilities close to zero or one

for selected datasets.

Training Conﬁgurations. The experimental phase

of the study starts by trying different split rates for

training, testing and validation. In addition to the

presented results, two other split rates are evaluated

for the LSTM model. One of them is split as 60%,

20%, 20% respectively for train, validation and test-

ing. The other one is similarly split into 60, 30, 10.

We observe that using a validation set improves de-

tecting benign packets in CIC-DDoS2019, as the be-

nign packets represent a minority class in this dataset,

and tuning the parameters using a validation set gen-

erates a more successful model. However, since we

cannot build the GNB model using a train-validation-

test split, the results of these different training con-

ﬁgurations were excluded from the experiments. We

continued with 70% train and 30% test data while re-

porting this study.

Grouping Strategy. While performing data process-

ing operations in the analysis part of the study, two

different grouping strategies were applied on each

dataset. These strategies simply consider grouping

the packets coming from the same source IP or go-

ing to the same destination IP. For the UNSW-NB15

dataset, we also added the destination port next to the

IP information during grouping because we have ob-

served that adding this information increases the per-

formance of attack detection. Overall, a grouping

strategy is necessary to build time-series based mod-

els and to detect incoming attacks in advance. How-

ever, we cannot clearly say which information in the

grouping matters the most. Both source IP and desti-

nation IP based groupings report similar performance

in detecting attacks 300 seconds in advance. The deci-

sion of which information to use in a grouping should

be made according to the trafﬁc data structure.

6 CONCLUSION

We have designed and implemented a recommender

system that can be used as part of SIEM systems, with

a speciﬁc focus on detecting DDoS attacks k seconds

in advance. We have trained LSTM, GNB, and rule-

based models to answer our two RQs.

A Recommender System to Detect Distributed Denial of Service Attacks with Network and Transport Layer Features

395

Table 2: Performance of rule-based, GNB and LSTM models.

Dataset Group By

Alert Level Conﬁg

Accuracy Recall

Precision

F1 Score

Rule-based model

UNSW-NB15 dstip-dport Level 1 100 / 60 0.56 0.15 / 0.97 0.85 / 0.53 0.25 / 0.69

UNSW-NB15 dstip-dport Level 2 100 / 60 0.58 0.19 / 0.95 0.81 / 0.54 0.31 / 0.64

UNSW-NB15 srcip-dport Level 1 100 / 60 0.50 0.28 / 0.72 0.50 / 0.50 0.36 / 0.59

UNSW-NB15 srcip-dport Level 2 100 / 60 0.50 0.29 / 0.71 0.50 / 0.50 0.24 / 0.60

UNSW-NB15 dstip-dport Level 1 200 / 300 0.53 0.09 / 0.99 0.95 / 0.51 0.16 / 0.67

UNSW-NB15 dstip-dport Level 2 200 / 300 0.55 0.14 / 0.99 0.95 / 0.52 0.24 / 0.68

UNSW-NB15 srcip-dport Level 1 200 / 300 0.49 0.19 / 0.80 0.51 / 0.49 0.28 / 0.61

UNSW-NB15 srcip-dport Level 2 200 / 300 0.49 0.19 / 0.80 0.51 / 0.49 0.28 / 0.61

CIC-DDoS2019 dstip Level 1 100 / 60 0.95 0.08 / 0.99 0.98 / 0.95 0.08 / 0.98

CIC-DDoS2019 dstip Level 2 100 / 60 0.96 0.08 / 0.99 0.95 / 0.96 0.14 / 0.98

CIC-DDoS2019 srcip Level 1 100 / 60 0.91 0.03 / 0.99 0.99 / 0.91 0.06 / 0.96

CIC-DDoS2019 srcip Level 2 100 / 60 0.92 0.05 / 0.99 0.96 / 0.92 0.10 / 0.96

CIC-DDoS2019 dstip Level 1 200 / 300 0.96 0.02 / 0.99 0.93 / 0.96 0.03 / 0.99

CIC-DDoS2019 dstip Level 2 200 / 300 0.96 0.03 / 0.99 0.93 / 0.96 0.06 / 0.98

CIC-DDoS2019 srcip Level 1 200 / 300 0.93 0.01 / 0.99 0.99 / 0.93 0.02 / 0.99

CIC-DDoS2019 srcip Level 2 200 / 300 0.93 0.02 / 0.99 0.99 / 0.93 0.03 / 0.96

Gaussian Na

ıve Bayes model

UNSW-NB15 dstip-dport Level 1 100 / 60 0.54 0.99 / 0.01 0.54 / 0.97 0.70 / 0.01

UNSW-NB15 dstip-dport Level 2 100 / 60 0.54 0.99 / 0.01 0.54 / 0.97 0.70 / 0.01

UNSW-NB15 dstip-dport Level 1 200 / 300 0.56 0.99 / 0.01 0.56 / 0.94 0.72 / 0.01

UNSW-NB15 dstip-dport Level 2 200 / 300 0.56 0.99 / 0.01 0.56 / 0.94 0.72 / 0.01

UNSW-NB15 srcip-dport Level 1 100 / 60 0.54 0.99 / 0.01 0.54 / 0.97 0.70 / 0.01

UNSW-NB15 srcip-dport Level 2 100 / 60 0.54 0.99 / 0.01 0.54 / 0.97 0.70 / 0.01

UNSW-NB15 srcip-dport Level 1 200 / 300 0.56 0.99 / 0.01 0.56 / 0.95 0.72 / 0.01

UNSW-NB15 srcip-dport Level 2 200 / 300 0.56 0.99 / 0.01 0.56 / 0.95 0.72 / 0.01

CIC-DDoS2019 dstip Level 1 100 / 60 0.98 0.80 / 0.99 0.99 / 0.97 0.89 / 0.99

CIC-DDoS2019 dstip Level 2 100 / 60 0.98 0.80 / 0.99 0.99 / 0.97 0.89 / 0.99

CIC-DDoS2019 dstip Level 1 200 / 300 0.98 0.77 / 0.99 0.99 / 0.97 0.87 / 0.99

CIC-DDoS2019 dstip Level 2 200 / 300 0.98 0.77 / 0.99 0.99 / 0.97 0.87 / 0.99

CIC-DDoS2019 srcip Level 1 100 / 60 0.94 0.71 / 0.99 0.99 / 0.93 0.83 / 0.96

CIC-DDoS2019 srcip Level 2 100 / 60 0.94 0.71 / 0.99 0.99 / 0.93 0.83 / 0.96

CIC-DDoS2019 srcip Level 1 200 / 300 0.94 0.68 / 0.99 0.99 / 0.93 0.81 / 0.96

CIC-DDoS2019 srcip Level 2 200 / 300 0.94 0.68 / 0.99 0.99 / 0.93 0.81 / 0.96

LSTM model

UNSW-NB15 dstip-dport Level 1 100 / 60 0.82 0.84 / 0.80 0.83 / 0.81 0.84 / 0.81

UNSW-NB15 dstip-dport Level 2 100 / 60 0.82 0.92 / 0.71 0.79 / 0.88 0.85 / 0.78

UNSW-NB15 dstip-dport Level 1 200 / 300 0.82 0.79 / 0.85 0.87 / 0.76 0.83 / 0.80

UNSW-NB15 dstip-dport Level 2 200 / 300 0.83 0.89 / 0.75 0.82 / 0.85 0.85 / 0.79

UNSW-NB15 srcip-dport Level 1 100 / 60 0.82 0.84 / 0.80 0.83 / 0.81 0.84 / 0.81

UNSW-NB15 srcip-dport Level 2 100 / 60 0.81 0.91 / 0.70 0.78 / 0.87 0.84 / 0.78

UNSW-NB15 srcip-dport Level 1 200 / 300 0.83 0.83 / 0.82 0.85 / 0.79 0.84 / 0.81

UNSW-NB15 srcip-dport Level 2 200 / 300 0.83 0.90 / 0.74 0.81 / 0.85 0.85 / 0.79

CIC-DDoS2019 dstip Level 1 100 / 60 0.99 0.92 / 0.99 0.99 / 0.99 0.96 / 0.99

CIC-DDoS2019 dstip Level 2 100 / 60 0.99 0.93 / 0.99 0.99 / 0.99 0.96 / 0.99

CIC-DDoS2019 dstip Level 1 200 / 300 0.96 0.61 / 0.99 0.99 / 0.96 0.76 / 0.99

CIC-DDoS2019 dstip Level 2 200 / 300 0.97 0.70 / 0.99 0.99 / 0.97 0.82 / 0.99

CIC-DDoS2019 srcip Level 1 100 / 60 0.98 0.90 / 0.99 0.99 / 0.97 0.95 / 0.99

CIC-DDoS2019 srcip Level 2 100 / 60 0.98 0.91 / 0.99 0.99 / 0.97 0.95 / 0.99

CIC-DDoS2019 srcip Level 1 200 / 300 0.96 0.77 / 0.99 0.99 / 0.95 0.87 / 0.97

CIC-DDoS2019 srcip Level 2 200 / 300 0.96 0.79 / 0.99 0.99 / 0.95 0.88 / 0.98

dstip-dport: Destination IP - Destination Port. srcip-dport: Source IP - Destination Port.

Packet count used / detection for next k seconds

Metrics given as (normal / attack)

As a result of our experiments, we have success-

fully managed to propose a system that runs with an

LSTM-based model and is capable of detecting 82%

of DDoS attacks 300 seconds in advance. We chose

to use two different datasets from the literature and in-

tentionally picked these with different characteristics

in terms of attack trafﬁc density. However they both

are synthetically generated, and in turn, we could not

fully observe how the performance of our proposed

model would be in real life. As a future work of this

study, running similar models on network data col-

lected from real environments will be pursued. Ad-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

396

ditionally, using this as an SIEM system component

designed for detecting DDoS attacks in a real-life sys-

tem, and evaluating its performance together with the

experts could be future research directions. This way,

we could evaluate how such systems reduce network

security costs and beneﬁt to incident response teams.

REFERENCES

Avazpour, I., Pitakrat, T., Grunske, L., and Grundy, J.

(2014). Dimensions and Metrics for Evaluating Rec-

ommendation Systems. In Robillard, M. P., Maalej,

W., Walker, R. J., and Zimmermann, T., editors, Rec-

ommendation Systems in Software Engineering, pages

245–273. Springer Berlin Heidelberg, Berlin, Heidel-

berg.

Belavagi, M. C. and Muniyal, B. (2016). Performance Eval-

uation of Supervised Machine Learning Algorithms

for Intrusion Detection. Procedia Computer Science,

89:117–123.

Boonchai, J., Kitchat, K., and Nonsiri, S. (2022). The

Classiﬁcation of DDoS Attacks Using Deep Learn-

ing Techniques. In 2022 7th International Conference

on Business and Industrial Research (ICBIR), pages

544–550.

Catillo, M., Pecchia, A., and Villano, U. (2022). AutoLog:

Anomaly detection by deep autoencoding of system

logs. Expert Systems with Applications, 191:116263.

Chan, A., Ng, W., Yeung, D., and Tsang, C. (2004).

Reﬁnement of rule-based intrusion detection system

for denial of service attacks by support vector ma-

chine. In Proceedings of 2004 International Con-

ference on Machine Learning and Cybernetics (IEEE

Cat. No.04EX826), pages 4252–4256.

Cil, A. E., Yildiz, K., and Buldu, A. (2021). Detection

of ddos attacks with feed forward based deep neural

network model. Expert Systems with Applications,

169:114520.

Cinque, M., Cotroneo, D., and Pecchia, A. (2018). Chal-

lenges and Directions in Security Information and

Event Management (SIEM). In 2018 IEEE Interna-

tional Symposium on Software Reliability Engineering

Workshops (ISSREW), pages 95–99.

Gaur, V. and Kumar, R. (2022). DDoSLSTM: Detection of

Distributed Denial of Service Attacks on IoT Devices

using LSTM Model. In 2022 International Confer-

ence on Communication, Computing and Internet of

Things (IC3IoT), pages 01–07.

Halladay, J., Cullen, D., Briner, N., Warren, J., Fye, K., Bas-

net, R., Bergen, J., and Doleck, T. (2022). Detection

and Characterization of DDoS Attacks Using Time-

Based Features. IEEE Access, pages 49794–49807.

LeCun, Y., Bengio, Y., and Hinton, G. (2015). Deep learn-

ing. Nature, pages 436–444.

Li, Y. and Lu, Y. (2019). LSTM-BA: DDoS Detection Ap-

proach Combining LSTM and Bayes. In 2019 Seventh

International Conference on Advanced Cloud and Big

Data (CBD), pages 180–185.

Liu, H. and Lang, B. (2019). Machine learning and deep

learning methods for intrusion detection systems: A

survey. Applied Sciences, 9(20).

Masdari, M. and Jalali, M. (2016). A survey and taxon-

omy of DoS attacks in cloud computing. Security and

Communication Networks, pages 3724–3751.

Moustafa, N. and Slay, J. (2015). UNSW-NB15: a compre-

hensive data set for network intrusion detection sys-

tems (UNSW-NB15 network data set). In 2015 Mil-

itary Communications and Information Systems Con-

ference (MilCIS), pages 1–6.

Ozgun, K. (2023). A Recommender System to Detect

Distributed Denial of Service Attacks with Network

and Transport Layer Features. https://github.com/

kaganozgun/dos-prediction-with-lstm.

Ramzy Shaaban, A., Abdelwaness, E., and Hussein, M.

(2019). TCP and HTTP Flood DDOS Attack Analy-

sis and Detection for space ground Network. In 2019

IEEE International Conference on Vehicular Elec-

tronics and Safety (ICVES), pages 1–6.

Rezaimehr, F. and Dadkhah, C. (2021). A survey of attack

detection approaches in collaborative ﬁltering recom-

mender systems. Artif Intell Rev, pages 2011–2066.

Sanjar, K., Rehman, A., Paul, A., and JeongHong, K.

(2020). Weight Dropout for Preventing Neural Net-

works from Overﬁtting. In 2020 8th International

Conference on Orange Technology (ICOT), pages 1–

Sharafaldin, I., Lashkari, A. H., Hakak, S., and Ghorbani,

A. A. (2019). Developing Realistic Distributed Denial

of Service (DDoS) Attack Dataset and Taxonomy. In

IEEE 53rd International Carnahan Conference on Se-

curity Technology, pages 1–6.

Siami-Namini, S., Tavakoli, N., and Namin, A. S. (2019).

The Performance of LSTM and BiLSTM in Forecast-

ing Time Series. In 2019 IEEE International Confer-

ence on Big Data (Big Data), pages 3285–3292.

Stiawan, D., Suryani, M. E., Susanto, Idris, M. Y., Al-

dalaien, M. N., Alsharif, N., and Budiarto, R. (2021).

Ping Flood Attack Pattern Recognition Using a K-

Means Algorithm in an Internet of Things (IoT) Net-

work. IEEE Access, pages 116475–116484.

Van Houdt, G., Mosquera, C., and N

apoles, G. (2020). A

review on the long short-term memory model. Artiﬁ-

cial Intelligence Review, 53(8):5929–5955.

Vishwakarma, R. and Jain, A. K. (2020). A survey of DDoS

attacking techniques and defence mechanisms in the

IoT network. Telecommunication Systems, 73(1):3–

25.

Wu, Z., Zhang, H., Wang, P., and Sun, Z. (2022). RTIDS:

A Robust Transformer-Based Approach for Intrusion

Detection System. IEEE Access, pages 64375–64387.

Zou, L., Wei, Y., Ma, L., and Leng, S. (2022). Feature-

Attended Multi-Flow LSTM for Anomaly Detection

in Internet of Things. In IEEE INFOCOM 2022

- IEEE Conference on Computer Communications

Workshops (INFOCOM WKSHPS), pages 1–6.

A Recommender System to Detect Distributed Denial of Service Attacks with Network and Transport Layer Features

397
