Character Identiﬁcation in Images Extracted from Portuguese

Manuscript Historical Documents

Gustavo Cunha Lacerda and Raimundo C. S. Vasconcelos

Instituto Federal de Bras

ılia, Taguatinga - DF, Brazil

Keywords:

OCR, Text Recognition, Historical Manuscripts, Neural Networks.

Abstract:

The creation of writing has facilitated the humanity’s accumulation and sharing of knowledge, being a vital

part of what differentiates humans from other animals and has a high importance for the culture of all peoples.

Thus, the ﬁrst human records (manuscripts), historical documents of organizations and families, began to have

new perspectives with the digital age accumulation. These handwritten records remained the primary source

for the history of countries, including Brazil before the period of independence, until the Gutenberg movable

type printing press dominated the archival world. Thus, over the decades, these handwritten documents, due to

their fragility, became difﬁcult to access and manipulate. This has changed, with the possibility of digitization

and, consequently, its distribution over the internet. Therefore, this work shows a solution for transcribing

historical texts written in Portuguese, bringing accessibility, searchability, sharing and preservation to these

records, which achieved a result of 97% of letters recognized in the database used.

1 INTRODUCTION

Writing is the symbolic process that allowed human

beings to expand the information generated by the

species far beyond what was possible in time and

space for a single individual. In this way, given the

importance of the emergence of this process, which

marked the beginning of Ancient History around 4000

B.C., there was the beginning of the documentation

and recording of human actions, beginning the era of

the accumulation of knowledge, which is properly the

creation of the culture of today’s civilizations. Thus,

writing and documentation play an extremely impor-

tant role in human history, as they are fundamental

tools for the preservation and propagation of knowl-

edge throughout the generations. This production of

information has a unique importance in the construc-

tion of the human being and is much deeper than we

think, being the foundation for culture, technological

and scientiﬁc knowledge.

The process of civilization has relied heavily on

human records, which are mainly generated from

social, family, and personal organizations. These

records were traditionally written, copied, and edited

by hand until the advent of primitive printing meth-

ods. The oldest known printed texts date back to

Japan in the years 764-770, speciﬁcally Buddhist

prayers. However, it was Johannes Gutenberg’s in-

vention of the movable type printing press in Eu-

rope during the 15

century that popularized printing

worldwide. Prior to Gutenberg’s press, records were

created by scribes or literate individuals who used

their own handwriting, resulting in signiﬁcant varia-

tions in the appearance of characters. This is evident

in historical Portuguese documents, where cursive

writing leads to different letter connectors and shapes

depending on neighboring letters and the writer’s con-

sistency.

Before the invention of the Gutenberg press,

records were written by hand by scribes and literate

individual, resulting in non-standardization of char-

acters and variations in cursive writing. This is ev-

ident in historical Portuguese documents. Addition-

ally, there is a problem with storing these valuable

documents, as many are incomplete and damaged. In-

correct storage practices include using unsuitable ma-

terials, lack of backup copies, and storing in hard-to-

access locations. To preserve the integrity of these

documents and make them easily accessible to re-

searchers, proper storage is crucial.

The widespread use of computers has led to a shift

towards digital documents, with software replacing

handwriting. This trend has sparked debates about

the abolished of handwriting in some European coun-

tries. In Finland, handwriting was discontinued in

2016, as typing was deemed more relevant in today’s

Lacerda, G. and Vasconcelos, R.

Character Identiﬁcation in Images Extracted from Portuguese Manuscript Historical Documents.

DOI: 10.5220/0012353900003660

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2024) - Volume 3: VISAPP, pages

401-408

ISBN: 978-989-758-679-8; ISSN: 2184-4321

401

context. Minna Harmanen, president of Finland’s Na-

tional Board of Education, acknowledged that while

handwriting aids in motor coordination and memory

development, the personal nature of cursive handwrit-

ing can harm literacy skills.

Through the use and spread of digitization, there

is the process of collecting and storing non-original

texts digitally through manual transcription or more

modern techniques such as Optical Character Recog-

nition (OCR), which is a machine learning applica-

tion for recognizing characters in images. This tech-

nique is common in standardized typography and is

currently widely used for text recognition in digital

fonts such as signs and printed books (Edwards III,

2007).

This paper suggests an approach using image pro-

cessing and neural networks to process and recog-

nize the content of handwritten texts in Portuguese.

These texts come mainly from images collected by the

digital databases of the national libraries of Portugal,

Brazil and France, each of which has an initiative to

digitize documents physically available at their head-

quarters with the mission of cataloguing and repro-

ducing handwritten historical documentation relating

to the human history of various countries in various

languages, including the ofﬁcial language of Portugal

and several other nations such as Brazil.

2 ANALYSIS OF THE PROBLEM

Trying to recognize characters from handwritten or

printed historical documents Insertionsare full of var-

ious types of problems, as they differ greatly from

the more standardized structure of magazines, news-

papers or scientiﬁc articles (Edwards III, 2007).

According to (Yanque, 2018) these problems arise

mainly because of characteristics related to:

• Individual’s personal handwriting (Figure 1):

This problem represents a signiﬁcant challenge

challenge for OCR systems because different peo-

ple’s writing styles vary a lot. Unlike standard-

ized fonts, individual handwriting has unique id-

iosyncrasies with letter formats, sizes, spacing,

and slant angles, making it difﬁcult for OCR sys-

tems to accurately transcribe handwritten text.

• Marks of the tools used for writing (Figure 2):

This problem mainly occurs when is used a of

low-quality ink and paper, on which stains and pa-

per marks appear on manuscripts. These problems

are separate classiﬁed as faded ink (Ink fading

over time), bleed-through (Stains that go through

the paper) and ghosting (Letter stains from other

text on the page).

• Deterioration (Figure 3): This problem is caused

by time and various factors such as improper stor-

age, age the archive and various material degrada-

tion processes that lead to holes, stains, tears and

the total loss of documents.

Figure 1: Individual’s personal handwriting from two au-

thors.

Figure 2: Examples of marks due to the material used at the

time.

Figure 3: Example of a document that has been damaged.

3 RELATED WORKS

In (Str

obel et al., 2022), the authors develop a search

for TrOCR on historical documents, proposed by (Li

et al., 2021), using a neural network pre-trained with

the dataset Image-Net-1K, containing 1.2 million im-

ages. Synthetic handwritten text creation techniques

were used to augment the data and improve the train-

ing of the TrOCR architecture in the English lan-

guage. Using the ﬁne-tuning process with real data

from other datasets, it was possible to obtain a CER

of 2.55% in validation over the 15 ﬁne-tuning epochs.

The study concludes that the data shows that better

accuracies come from methods using ﬁne-tuning to

improve accuracy.

In (Silv

erio Costa et al., 2022), the computational

Lusophone language processing software Lapelinc

Framework ((Costa et al., 2022)) was used. This

software is made available through JSP and JPA. In

addition, backend uses the TensorFlow library from

Python to produce handwritten text recognition. The

program accepts training based on the letters and

words found and has proven to be of great value for

recognizing and segmenting the words in documents.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

402

In (Mart

ınek et al., 2019), ideas are presented

about how to train a neural network to recognize texts

in historical documents in the best possible way using

the state of the art. A way of generating new data is

proposed, as well as three training approaches: using

some real handwritten texts, using only manuscripts

generated by software and the third approach com-

bines the use of real and synthetic manuscripts. In this

way, using old newspapers from Germany, the results

showed that using only synthetic texts is sufﬁcient to

obtain results in OCR programs, but combining the

two types of data is the most suitable way to guaran-

tee better accuracy with little real data.

Another work by the same author, (Mart

ınek et al.,

2020), described methods for segmenting historical

document structures and an OCR method for digi-

tizing the information. In this project, Kraken, CNN

and LSTM were used to produce a model that could

be trained with data generated by software and ad-

justed using the ﬁne-tuning technique with real data.

The results proved to be superior to the state of the

art in Porta Fortium dataset of old German newspa-

pers, reaching an WER and CER of 0.118 and 0.024,

respectively.

The eScriptorium browser program is described in

(Kiessling et al., 2019). This project arose from the

absence, in the state of the art, of a web program with

a user-friendly interface and open-source to recognize

texts from historical manuscripts. The software has an

interface that allows both automatic and manual tran-

scriptions and uses the same input sector. Thus, us-

ing the trainable OCR library for historical documents

from Python, Kraken ((UNIVERSIT

E PSL, 2015)), it

was possible to obtain an CER of between 2% and

8.9% on historical Arabic manuscripts.

In (Salimzadeh, 2019), a method is proposed for

treating errors in the output of OCR algorithms, im-

proving the quality of text digitization. Using natural

language processing to correct the errors generated in

the OCR output, it was possible to correct 92% of the

errors generated in the output of the character recog-

nition algorithms. Despite having used the English

language for testing and training, the author proposed

transfer-learning so that the system would work satis-

factorily in other European languages.

The work (Neudecker et al., 2021) presents an

evaluation of the metrics used to assess OCR models

for historical documents. In this way, an experiment

was carried out to see if common methods and met-

rics for evaluating OCR agree or disagree when eval-

uating the results for different historical documents,

using two different data sets. Several common met-

rics such as CER and WER and alternatives such as

the GT-free heuristic were used, comparing the efﬁ-

ciency, use and comparability of each.

In (Aguilar and Jolivet, 2022) a system for recog-

nizing handwritten texts from medieval documents is

described. The author used a pre-trained R-CNN with

around 5.9 million adjustable parameters with a batch

size of 1 and a learning rate of 0.0001 to train the

network. It was thus possible to obtain an accuracy of

85% and, through ﬁne-tuning, this accuracy increased

to values above 90%.

In (Milioni, 2020), an analysis of the transcription

program for historical documents called Transkribus

is presented. A qualitative study was carried out based

in two research methods: a distribution questionnaire

and an experimental evaluation of the tool. The au-

thor concluded that the user interface of Transkribus

is quite simple and user-friendly for humanities schol-

ars, including all the processes and steps necessary

to achieve an automatic transcription. However, the

quality of the transcriptions produced is not yet the

highest so that libraries and archives can use this tool

systematically and for different types of historical ma-

terial.

4 TECHNOLOGIES

For this work, the Python language was chosen, which

is a high-level, general-purpose programming lan-

guage created in 1989 by Dutch mathematician Guido

van Rossum. It has a simple and intuitive syntax,

which makes it an easy language to learn and use.

The ecosystem chosen to train an OCR model is

Kraken, a system developed at the French Universit

PSL, optimized for recognizing texts from historical

documents. This system has or is easily coupled with

various tools ranging from data collection to publi-

cation of the generated model, and is widely used in

the work found in systematic mapping. This choice

is also due to the fact that Kraken is open-source and

has a native option for ﬁne-tuning through the use of

a customized database, as in the case of this work.

The tools provided and supported natively by the

ecosystem are:

• Ketos: this is the main Kraken tool, which has

commands for managing data, compiling and gen-

erating model training and tests. Using Ketos, it is

possible to create new data with the augmentation

option, in which an alphabet is formed from the

symbols found, which are then recombined into

new word sequences.

• eScriptorium: is a software that facilitates cer-

tain OCR processes, mainly the creation of

databases. It includes tools for processing, seg-

Character Identiﬁcation in Images Extracted from Portuguese Manuscript Historical Documents

403

menting and creating the masks needed for tran-

scription, which generates an ALTO ﬁle used by

Kraken for training and testing. This ﬁle contains

the coordinate information of the delimiters of the

words and letters found with the appropriate tran-

scription made by the user through a very simple

website.

• Zenodo: this is a repository of neural network re-

search and models in which Kraken stores its base

models and is ideal for ﬁnding solutions made by

other researchers and developers.

5 METHOD

The research method is shown in Figure 4 and deﬁnes

the general tasks that make up the work. The ﬁrst

step is to deﬁne the problem, which consists of clearly

and objectively deﬁning the question that will be ad-

dressed throughout the project. In addition to present-

ing the context in which the problem is inserted and

raising important deﬁnitions for the scope of the topic.

Figure 4: Steps of the research used in this work.

After, the process of analyzing the problem and

surveying the literature begins in parallel. The prob-

lem analysis stage involves gathering information, as-

sessing the context and expectations in order to ﬁnd a

possible solution. In the bibliographic survey stage, in

the case of this research, a systematic mapping tech-

nique was used to search for, agglomerate and syn-

thesize ideas, procedures and solutions from similar

works.

Subsequently, data was collected to be used in the

OCR stage, in which images are used as input for the

system that generates the prediction of the texts in the

images. In the case of historical documents, this pro-

cess is carried out by collecting the original document

and digitizing it using scanners and cameras. Once

the digitized documents have been collected, they are

agglomerated into datasets such as those used in this

research. This was done through national digitiza-

tion projects in Portugal and France. It was then tran-

scribed by the author of this research to obtain prop-

erly cataloged data for use in supervised training.

In the stage of using OCR, the key steps for ana-

lyzing historical documents presented by (Dixit and

Shirdhonkar, 2015) were used and adapted to the

needs of this research. The adapted sequence of steps

for the OCR stage is described in Figure 5 and has the

following speciﬁcations:

Figure 5: Speciﬁc OCR steps used in this work separated

by tool.

• Image and Document Capture: The ﬁrst stage of

the process is understood as the collection and se-

lection of data. In the case of historical docu-

ments, this process involves collecting the origi-

nal document and digitizing it using scanners and

cameras. Once the scanned documents have been

collected, they are agglomerated and catalogued

in datasets like those of the digital libraries used

in this research.

• Binarization and pre-processing: at this stage the

images are ﬁltered to reduce wear and noise, with

a focus on highlighting the textual components of

the documents collected. An example of a cru-

cial ﬁlter for text analysis is binarization, which

consists of a process of selecting areas of interest

in a given image using a cut-off threshold deﬁned

by the technique used. The result of binarization

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

404

is an image highlighted in binary pixels of inten-

sity 0 or 1, usually white and black respectively.

This technique is used in character recognition to

highlight text in relation to the environment and

material on which it is printed or written.

• Layout analysis: at this stage the document is sep-

arated by areas of interest for analysis. In the

case of this research, texts are extracted from the

documents and separated from images, drawings,

graphics and other non-textual elements.

• Text analysis and recognition: once the texts have

been properly ﬁltered and separated, with the best

possible highlighting, some recognition algorithm

is applied to each character of the texts found in

the document. The technique used in this research

uses machine learning to recognize handwritten

texts.

• Text description prediction: after recognizing

each character, a statistical value between 0 and

1 is assigned, which corresponds to the chance of

the character being a particular letter of the por-

tuguese alphabet, making changes if necessary to

form words correctly and maintain the original

content of the document. This stage results in the

completely digitized text of the initial manuscript.

In these more speciﬁc stages, related to optical

character recognition, two main technologies from the

Kraken ecosystem were used: eScriptorium and Ke-

tos. At ﬁrst, after choosing the documents, the steps

that make up the construction of the database are car-

ried out, in which the software web eScriptorium. It

pre-processes, analyzes and recognizes the text and

also creates transcription ﬁles for each word and let-

ter found. Figure 5 shows how the stages are divided

according to each technology.

Next, the ALTO ﬁles are compiled by Ketos into a

Arrow ﬁle type used by the program to carry out train-

ing faster than directly using the documents in XML

pairs, with coordinates and transcription, and the im-

ages. This compilation stage divides the data into

personalized parts for training, validation and testing,

which in the case of this work follow the proportions

of 0.75, 0.15 and 0.15 respectively. Finally, after com-

pilation and division, training is carried out using the

Ketos training command with a pre-trained base neu-

ral network. We also used the SGD optimizer, learn-

ing rate of 0.001 and the tool’s own data augmenta-

tion.

For the number of training epochs, a earling stop-

ping solution was chosen, which stops training when

there are a number of drops in accuracy in the val-

idation at the end of each epoch, in the case of this

research. This technique avoids overtraining (Over-

ﬁtting is a common problem in machine learning and

neural networks, in which a model overﬁts the train-

ing data. As a result, the model becomes very speciﬁc

to the training data and is often unable to generalize

well to new, unseen data, leading to poorer perfor-

mance in real-world situations.) with the data used

and works well in cases of ﬁne-tuning (Fine-tuning is

the process of adjusting a pre-trained machine learn-

ing model to a speciﬁc task or data set, taking advan-

tage of the model’s prior knowledge.)

5.1 Database and Transcripts

An extremely important part of deﬁning the effective-

ness of a neural network is the data on which it is

trained. For this research, we couldn’t ﬁnd a dataset

that had an available catalog and transcriptions of his-

torical documents handwritten in Portuguese. There-

fore, it was necessary to create a database of tran-

scriptions to test how the model would adapt to Old

Manuscript Portuguese.

The ﬁrst step was to choose the documents needed

to carry out the procedures. The criteria were ﬁles

that had good reading quality and few faults to facil-

itate and speed up the data cataloging process, since

the main objective of the research is not to create a

large complex database that can be used by other OCR

training models, although it is possible, as this would

require increasing the overall scope of the research.

Using the search engines and ﬁlters of the web-

site libraries, the few documents with a good reading

quality were chosen so that there would be no doubts

at the time of transcription, thus avoiding divergences

caused by wrong classiﬁcation.

After the selection, the documents were processed

to remove artifacts, deterioration, stains and other

problems that make it difﬁcult to extract only the text.

This part is left to non-linear binarization, which uses

methods that take into account the relationship be-

tween neighbouring pixels and the distribution of in-

tensities in the image to carry out the binarization in-

stead of a ﬁxed threshold value. This stage of the

process highlights the letters written in focus on the

page and eliminates most of the problems of histori-

cal manuscripts such as ghosting and bleed-through.

After the binarization stage, the images go

through a layout analysis and segmentation process in

order to eliminate the other non-textual components

and ensure that only the text is catalogued and used

in the transcriptions. This is done by another internal

neural network and pre-trained by the eScriptorium,

which has a very interactive abstraction in the web-

site, which requires no conﬁguration other than ﬁle

selection and segmentation initialization. The infor-

Character Identiﬁcation in Images Extracted from Portuguese Manuscript Historical Documents

405

mation found by the algorithm is saved in an ALTO

ﬁle and has the coordinates of the limiters that form

the mask of the text found by the program, the num-

ber of lines, text direction and transcription, as can be

seen in Figure 6.

Figure 6: Result of segmentation and layout analysis on a

part of a document history.

The documents are then transcribed via input by

the user, who is able to make the relationship between

the line mask and the written text. An example of how

the process of transcribing a page of a document takes

place can be seen in Figure 7. Finally, the transcrip-

tions are saved in the ALTO ﬁles in pairs with the

respective images.

Figure 7: Example of transcription input based on lines in

eScriptorium.

The process of creating the transcriptions resulted

in 20,961 characters being transcribed into four docu-

ments totaling 307 pages. Not all the characters were

transcribed, only those that there was no doubt about

in order to maintain cohesion in the database. In ad-

dition, stains and other problems made it impossi-

ble for the segmentation algorithm to recognize some

lines, which were also discarded from the generated

ﬁles. The document with the most transcribed data is

”Copia do emperio e reinos dos xarifes na Berberia

em Africa e de algumas terras de negros, comessando

da emperial cidade de Marrocos, cabessa do dito em-

perio e sua comarca.” from the National Digital Li-

brary of France, with 16,349 letters corresponding to

approximately 78% of the dataset.

6 RESULTS

Firstly, a curation process was carried out to see which

model would have the best base performance to carry

out the end-tuning (Results in Table 1). To do this,

they were selected from the newest models available

on the Zenodo platform, which Kraken recommends

and uses as a solution repository. Thus, four models

were chosen and tested on the base dataset.

Considering the accuracy results, the Generic

CREMMA and UB Mannheim German models were

chosen as the basis for ﬁne-tuning.

The model using the dataset CREMMA reached a

peak in character accuracy on the 24th epoch, with

a value of 97.38% over 34 total epochs before early

stopping stopped running (Figure 8). This ﬁne-tuning

result had a gain of 18.93% compared to the base

model tests, which is a leap that justiﬁes this type of

training. The ﬁnal generated model is 22MB and the

process took around 6 hours to complete. In addition,

the speciﬁc OCR metrics were used to measure the

quality of the generated model in which the CER and

WER values were 2.62% and 24.7%, respectively.

The results for insertion, deletion and addition er-

rors can be seen in Table 2. Finally, Table 3 shows

the relationship between the ten substitutions made

by the model in the character tests, which explains

which characters were the most difﬁcult to transcribe

correctly.

The UB Mannheim German model, on the other

hand, reached its accuracy peak in the dataset cre-

ated by this article in epoch 19, with a character accu-

racy value of 97.38% over the 29 total epochs before

stopping its execution (Figure 8). This ﬁne-tuning re-

sult represented an increase of 18.72% over the base

model tests. The model was ﬁnalized with the same

16 MB size as at the start, which is much smaller than

that of Generic CREMMA with a similar result.

In addition, the CER and WER values were 2.62%

and 24.7%, respectively. The results for insertion,

deletion and addition errors can be seen in Table 4.

Table 5 shows the ten most frequent substitutions

made by the model in the character tests, highlighting

which characters were the most challenging to tran-

scribe correctly.

Thus, the results were satisfactory compared to

the state of the art of OCR in terms of letter match-

ing. Words had a higher error rate because no treat-

ment was carried out on the output of the predic-

tions, as in related work. This absence is explained

by the fact that applying a spelling correction to the

text would require a specialized corrector for colonial

Portuguese, something that was not easily found and

that the construction was not in the initial proposal of

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

406

Table 1: Results of the curation of the OCR methods.

Modelo Base(s) de Dados Tamano Acur

acia de Letras

Generic CREMMA CREMMA Medieval; CREMMA Medieval Latin; Eutyches. 22.8 MB 78.45%

Medieval Latin and French 12th-15th c. expanded CREMMA Medieval; Oriﬂamms; Saint-Victor. 21.62 MB 71.39%

UB Mannheim German Urfehdenbuch X. 16.4 MB 78.60%

Joseph Hooker HTR Model Teanscric¸

oes de um pequeno grupo de volunt

arios. 16.2 MB 57.18%

Figure 8: Accuracy in ﬁne-tuning the Generic CREMMA and he UB Mannheim German models.

Table 2: Results of the speciﬁc OCR errors in the ﬁne-

tuning of the Generic CREMMA model.

Metric Absolute Value Percentage

Insertions 126 22,95%

Deletions 234 42,62%

Insertions 189 34,42%

Total 549 100%

Table 3: Results of the ten common errors in the predictions

of the ﬁne-tuning of the Generic CREMMA model.

No. of errors Correct character Prediction

294 ”Nothing” ”Space”

99 u v

36 ”Space” ”Nada”

24 ”Nothing” o

24 f s

6 - ”Nothing”

6 ”Nothing” s

3 g b

3 a ”Nothing”

3 a .

the research due to the non-mandatory nature of the

transcriptions and the difﬁculty.

Another test was carried out with another docu-

ment that had not been trained in the model, in which

the accuracy results dropped considerably for a com-

pletely new type of writing and author. This data re-

veals that ﬁne-tuning served to add the handwritings

of the authors used in the constructed dataset rather

than generalizing to Portuguese as a whole. The rea-

son for this divergence is that de-standardization is

colossal when it comes to cursive writing and the so-

lutions based on Kraken were not good at universaliz-

ing with the limited amount of data provided.

Similarly, the Generic CREMMA and UB

Mannheim German solutions declined in letter ac-

Table 4: Results of the speciﬁc OCR errors in the ﬁne-

tuning of the UB Mannheim German model.

Metric Absolute value Percentage

Insertions 198 35,3%

Deletions 135 24,06%

Insertions 228 40,64%

Total 561 100%

Table 5: Results of the ten common errors in the predictions

of the ﬁne-tuning of the UB Mannheim German model.

No. of errors Correct character Prediction

72 ”Space” ”Nothing”

66 ”Nothing” ”Space”

36 - ”Nothing”

18 ”Nothing” a

18 . ”Nothing”

18 a ”Nothing”

12 s ”Nothing”

12 S s

12 t s

a 9

curacy when using the dataset developed by this re-

search using the same Latin characters. There is

also great similarity in the initial accuracy and errors

of the two base models, which reinforces this idea,

but a larger amount of data and a better constructed

database are needed to corroborate this information.

7 FUTURE WORKS

To continue the work presented, it would be ideal to

segment the lines of research present, bringing more

speciﬁc improvements to each aspect of the solution:

Character Identiﬁcation in Images Extracted from Portuguese Manuscript Historical Documents

407

• Use or create some method of spell-checking the

result of the predictions to improve the quality

of the transcription of words from colonial Por-

tuguese and other eras.

• Create another optical character recognition archi-

tecture that is better at generalizing the transcrip-

tion of manuscripts with a smaller amount of data.

In this way, the solution could be more com-

plete in all respects and would gain independence,

especially in the creation of an improved database,

to help and proliferate the identiﬁcation of charac-

ters from images extracted from historical Lusophone

manuscript documents.

8 CONCLUSION

Using a small training database to perform OCR on

certain documents, using models trained in other lan-

guages with the same character, is not only possible

but also very advantageous. Although the blind use

of the model does not guarantee high accuracies, with

a small number of transcriptions, it is possible to add

the author’s handwriting and the algorithm takes care

of the rest of the translation. However, in this spe-

ciﬁc case of falling accuracy and the lack of treatment

of the output with the use of spell-checkers, fully au-

tomatic transcription is impossible. Therefore, using

Kraken with eScriptorium proved to be a better alter-

native to help digitize a handwritten historical docu-

ment.

ACKNOWLEDGMENT

We gratefully to the Conselho Nacional de Desen-

volvimento Cient

ıﬁco e Tecnol

ogico (CNPq) for the

support.

REFERENCES

Aguilar, S. T. and Jolivet, V. (2022). Handwritten text

recognition for documentary medieval manuscripts.

HAL Open Science.

Costa, B. S., Santos, J. V., Namiuti, C., and Costa, A. S.

(2022). The systematic construction of multiple types

of corpora through the lapelinc framework. In Inter-

national Conference on Computational Processing of

the Portuguese Language, pages 401–406. Springer.

Dixit, U. and Shirdhonkar, M. (2015). A survey on doc-

ument image analysis and retrieval system. Interna-

tional Journal on Cybernetics & Informatics, 4:259–

270.

Edwards III, J. A. (2007). Easily adaptable handwriting

recognition in historical manuscripts. University of

California, Berkeley.

Kiessling, B., Tissot, R., Stokes, P., and Ezra, D. S. B.

(2019). escriptorium: an open source platform for his-

torical document analysis. In 2019 International Con-

ference on Document Analysis and Recognition Work-

shops (ICDARW), volume 2, pages 19–19. IEEE.

Li, M., Lv, T., Cui, L., Lu, Y., Florencio, D., Zhang, C.,

Li, Z., and Wei, F. (2021). Trocr: Transformer-based

optical character recognition with pre-trained models.

arXiv preprint arXiv:2109.10282.

Mart

ınek, J., Lenc, L., and Kr

al, P. (2019). Training

strategies for ocr systems for historical documents.

In IFIP International Conference on Artiﬁcial Intelli-

gence Applications and Innovations, pages 362–373.

Springer.

Mart

ınek, J., Lenc, L., and Kr

al, P. (2020). Building an

efﬁcient ocr system for historical documents with lit-

tle training data. Neural Computing and Applications,

32(23):17209–17227.

Milioni, N. (2020). Automatic transcription of histori-

cal documents: Transkribus as a tool for libraries,

archives and scholars.

Neudecker, C., Baierer, K., Gerber, M., Clausner, C., An-

tonacopoulos, A., and Pletschacher, S. (2021). A sur-

vey of ocr evaluation tools and metrics. In The 6th In-

ternational Workshop on Historical Document Imag-

ing and Processing, pages 13–18.

Salimzadeh, S. (2019). Improving OCR Quality by Post-

Correction. PhD thesis, PhD thesis, Universiteit van

Amsterdam.

Silv

erio Costa, B., Viana Santos, J., and Namiuti, C. (2022).

Transcric¸

ao manual e autom

atica de textos hist

oricos

manuscritos atrav

es do software lapelinc transcrip-

tor. Col

oquio do Museu Pedag

ogico-ISSN 2175-5493,

14(1):2885–2890.

Str

obel, P. B., Clematide, S., Volk, M., and Hodel, T.

(2022). Transformer-based htr for historical docu-

ments. arXiv preprint arXiv:2203.11008.

UNIVERSIT

E PSL (2015). Kraken.

https://kraken.re/master/index.html.Online; acessed

26/12/2022.

Yanque, N. Y. A. (2018). Um estudo comparativo de meto-

dos de segmentac¸ao de documentos antigos. PhD the-

sis.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

408
