APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event

Processing Systems

Majid Lotﬁan Delouee

1 a

, Victoria Degeler

2 b

, Peter Amthor

3 c

and Boris Koldehofe

3 d

Bernoulli Institute, University of Groningen, Groningen, Netherlands

Informatics Institute, University of Amsterdam, Amsterdam, Netherlands

Department of Computer Science and Automation, Technische Universit

at Ilmenau, Ilmenau, Germany

ﬁ

Keywords:

Distributed Complex Event Processing, Stream Processing, Privacy, Pattern, Adaptation.

Abstract:

Although privacy-preserving mechanisms endeavor to safeguard sensitive information at the attribute level,

detected event patterns can still disclose privacy-sensitive knowledge in distributed complex event processing

systems (DCEP). Events might not be inherently sensitive, but their aggregation into a pattern could still breach

privacy. In this paper, we study in the context of APP-CEP the problem of integrating pattern-level privacy in

event-based systems by selective assignment of obfuscation techniques to conceal private information. Com-

pared to state-of-the-art techniques, we seek to enforce privacy independent of the actual events in streams.

To support this, we acquire queries and privacy requirements using CEP-like patterns. The protection of pri-

vacy is accomplished through generating pattern dependency graphs, leading to dynamically appointing those

techniques that have no consequences on detecting other sensitive patterns, as well as non-sensitive patterns

required to provide acceptable Quality of Service. Besides, we model the knowledge that might be possessed

by potential adversaries to violate privacy and its impacts on the obfuscation procedure. We assessed the

performance of APP-CEP in a real-world scenario involving an online retailer’s transactions. Our evaluation

results demonstrate that APP-CEP successfully provides a privacy-utility trade-off. Modeling the background

knowledge also effectively prevents adversaries from realizing the modiﬁcations in the input streams.

1 INTRODUCTION

Interpreting the individual’s data to generate insight-

ful information has attracted interest in various ap-

plication ﬁelds such as e-commerce, public health-

care, and the Internet of Things (IoT). Such appli-

cations typically involve distributed, timely process-

ing of data for preventive or predictive use, with con-

straints ranging from mere least-latency up to real-

time requirements (Lotﬁan Delouee et al., 2022).

One of the state-of-the-art paradigms for analyzing

data in a distributed manner in real-time is Dis-

tributed Complex Event Processing (DCEP): Streams

of simple events (e.g., IoT raw data) are analyzed

and transformed into complex events representing

situations of interest (e.g., queries over sensor data

streams). This transformation is performed using a

https://orcid.org/0000-0003-1326-7540

https://orcid.org/0000-0001-7054-3770

https://orcid.org/0000-0001-7711-4450

https://orcid.org/0000-0002-1588-2056

set of processing logic called CEP rules (Lotﬁan De-

louee et al., 2023a). For example, a trafﬁc moni-

toring system can infer a road congestion via sim-

ple events: Average Vehicles Speed < 20 km/h and

Vehicles Density > Normal Density.

A key challenge in the analysis of such informa-

tion is privacy. It leads to a conﬂict of goals: On

the one hand, users of a DCEP system should be

provided an optimal Quality of Service (QoS). As

an example from the e-commerce domain, product

managers should be able to detect and reason about

varying sales. On the other hand, disclosing speciﬁc

events (e.g., purchase details) might violate the pri-

vacy of data owners (e.g., customers of a webshop)

(Lotﬁan Delouee et al., 2023b). Similar examples

can be found for medical data of hospital patients

or health insurance clients (Palanisamy et al., 2018).

They share an honest-but-curious type of adversary,

represented by users as well as nodes of a distributed

CEP middleware.

Hence, DCEP requires Privacy Preserving Mech-

anisms (PPM) to protect the privacy of data owners.

486

Lotﬁan Delouee, M., Degeler, V., Amthor, P. and Koldehofe, B.

APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event Processing Systems.

DOI: 10.5220/0012358700003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 486-497

ISBN: 978-989-758-683-5; ISSN: 2184-4356

Despite most PPMs (e.g., access control) operating on

the level of single events (i.e., by protecting event at-

tributes), privacy requirements are often represented

by a combination of events through complex event

patterns. A pattern is the CEP representation of a

complex event with a set of one or more operations

over simple events (e.g., ﬁltering special events) to

detect a situation. For instance, a sequence pattern

equals the occurrence of speciﬁc events in a prede-

ﬁned order over single or joint streams, such as a pur-

chase of a pregnancy test followed by children’s toys.

Those privacy-sensitive patterns that data owners

want to conceal are called private patterns. Con-

versely, public patterns are non-privacy-sensitive pat-

terns that must be detected accurately and timely to

deliver the promised services, e.g., query results. Re-

garding the accuracy of complex event detection, fail-

ing to detect a complex event that occurred in the real

world (i.e., False Negative, FN) and false detection of

events that did not actually happen (i.e., False Posi-

tive, FP) are the main QoS metrics by which the per-

formance of a DCEP system can be evaluated.

In this work, we demonstrate that a feasible trade-

off between concealing private patterns and detecting

public patterns cannot be comprehensively provided

by a single, statically applied PPM. To this end, our

approach is based on a dynamic assignment of differ-

ent obfuscation techniques (OT) to optimize the fol-

lowing constraints.

First, complex event patterns share causal depen-

dencies. This forbids a na

ıve solution based on just

one OT, e.g., event reordering, which fails in case the

reordered event stream cannot allow for any meaning-

ful public pattern detection. Second, an adversary’s

background knowledge must be taken into account

when choosing an OT. For example, for any event

dropped in the result of one query, but not of an-

other, an adversary could possibly infer parts of the

original stream based on the combined knowledge of

both. Third, DCEP systems are by nature dynamic:

Public and private patterns can be dynamic due to

changes in active queries or the data owners’ privacy

requirements. Input stream sources might vary spon-

taneously. Finally, an adversary’s background knowl-

edge monotonically increases over time.

In this paper, we present APP-CEP as a solution

to these challenges. Our contributions are as follows:

1. A PPM that obtains privacy requirements and sit-

uations of interest in the form of event patterns as

input and speciﬁes the most efﬁcient OT to con-

ceal each private pattern when delivering the re-

sults to the queries.

2. OT selection in our proposed PPM based on a

graph structure, used to model pattern dependen-

cies and extract the input stream’s features to pre-

dict the switching time between OTs to avoid pri-

vacy violations and meet scalability requirements.

3. A structure for data owners to dynamically model

the adversary’s potential background knowledge

based on an event dependency set and possible

statistical event-related information gathered from

the available event streams’ history.

4. Performance evaluation based on a real-world

dataset to show the ability of APP-CEP to boost

the performance of the DCEP systems in real-

world scenarios.

The remainder of this paper is structured as fol-

lows. We further detail the problem, particularly

for an online shop scenario, and motivate the need

for pattern-level privacy in DCEP systems in Sec-

tion 2. We introduce an overview of the APP-CEP

system model in Section 3. We formalize the prob-

lem statement in Section 4. Section 5 presents the de-

tailed overview of APP-CEP. The evaluation results

of APP-CEP are exhibited in Section 6. The related

work is presented in Section 7. Finally, Section 8 con-

cludes our paper and points to our future work.

2 CASE STUDY: WEBSHOP

In a recent project by the National Statistical Insti-

tute of Norway (Gundersen, 2022), several grocery

chains have been ordered to share all their receipt data

with this statistics agency. To protect privacy, this in-

stitute claims that by performing pseudonymization,

the account number, which can identify a person, will

be changed to another unique number (i.e., attribute-

level access control). However, pattern-level corre-

lation plus background knowledge would enable the

adversaries to realize customers’ identities, violating

their privacy.

In this section, we introduce a scenario based on

the transaction set of an online retailer that demon-

strates the application of APP-CEP in real-world sit-

uations similar to the mentioned Norwegian example

(see Figure 1). In such a scenario, a state-of-the-art

PPM fails to provide an acceptable level of privacy

protection since they mainly protect at the level of

events (e.g., by controlling the access using event at-

tributes obfuscation). We consider all transactions of

a retailer selling all-occasion gifts as the input stream

and attempt to detect predeﬁned public and private

patterns. Any user (e.g., webshop’s manager) can is-

sue a query to detect situations of interest (e.g., top-

selling products in a particular period) that are active

for a speciﬁc time. On the other hand, data owners are

APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event Processing Systems

487

Transac�on Set

Webshop

Manager

Customers

…

Figure 1: Webshop Scenario. The system aims to pro-

tect customers’ privacy while answering webshop manager

queries.

customers of the webshop, and each of their purchases

triggers an event in this scenario (i.e., using their cus-

tomer ID) and is labeled with a timestamp. Lining

up the purchase records according to their timestamp

generates a transaction set event stream, which is an-

alyzed to detect valuable real-time correlations.

By employing APP-CEP, a customer can specify

the privacy requirements, e.g., concealing a Christ-

mas party. In this scenario, we assume the sensitive

information can be represented by CEP patterns (e.g.,

sequence, conjunction, negation, etc.). For instance,

a Christmas party can be represented by CONJ (In-

vitation Card, Christmas Ribbon, Christmas Deco-

rations). To conceal such sensitive information, the

chosen obfuscation technique (e.g., drop event for In-

vitation Cards) might inﬂuence the results of non-

sensitive queries (e.g., top-selling products). More-

over, various parameters (e.g., pattern dependencies,

event distribution in the input stream, etc.) should be

considered carefully. Hence, the goal of APP-CEP is

to answer user queries intelligently in such a way that

the privacy of customers is not violated.

3 SYSTEM MODEL

This section presents the components of APP-CEP,

the model of event sources, and obfuscation models.

3.1 APP-CEP Model

We consider a typical DCEP system with multiple

producers (e.g., IoT sensors) that advertise the simple

event streams they can provide. Each of these streams

is related to one or more Data Owners (DO), meaning

the provided data belongs to this data owner(s) from a

privacy protection point of view. For example, the lo-

cation event stream of a car belongs to its driver. Cor-

respondingly, consumers (e.g., applications, services,

etc.) submit their situations of interest as continuous

queries to the system. Hence, the set Q = {q

, ..., q

}

denotes the set of running queries that must be re-

sponded to by processing the events of current input

streams. In addition, a set of brokers (e.g., CEP en-

gines) perform event processing tasks (e.g., drop, re-

order, union, tamper, etc.) by hosting corresponding

operators and delivering the resulting stream(s) to the

next step.

A query q

determines the logic to detect complex

events by applying standard CEP operators over sim-

ple events’ attributes (e.g., pattern matching). To this

end, each detection logic needs to be hosted by a spe-

ciﬁc operator to be executed. Moreover, each data

owner is able to describe its privacy requirements and

deliver them to the system. Such requirements should

be accompanied by a normalized weight that shows

their importance. Hence, the set

PR(DO

) = {(pr

, w

), ..., (pr

, w

)}

shows the privacy requirements speciﬁed by data

owner DO

along with their corresponding weights.

As another query feature, the importance of queries

might vary due to their priorities. That is why detect-

ing such query patterns is of more signiﬁcance to the

system instead of concealing privacy requirements,

e.g., life-related queries in a healthcare scenario.

3.2 Event Source Model

Producers, also called event sources, are the ori-

gin of the events that generate simple event streams.

As an example, if we implement our mechanism in

an IoT scenario, the sensors that measure a speciﬁc

phenomenon (e.g., location of a target) act as event

sources. Regarding the number of targets that can be

covered, we categorized the event sources into two

groups: DO-Speciﬁc and Multi-DO. For the former,

the event source can only be used for queries related

to the corresponding data owner. In other words, the

generated stream will not reveal privacy-sensitive in-

formation about other targets (i.e., data owner). For

instance, a cellphone’s GPS signal can only be used

for tracking a speciﬁc target. For the latter, informa-

tion about multiple targets can be acquired by analyz-

ing such event source streams. For instance, a sta-

tionary security camera delivers data related to vari-

ous targets. These event sources should be used cau-

tiously in any privacy-aware data analysis approaches.

In addition, the event sources here are intercon-

nected to the system over a wireless network and must

be registered in the system due to privacy concerns.

Besides, each data owner can act as a CEP consumer

by submitting queries. CEP operators can also be

hosted in nodes with sufﬁcient computing capabili-

ties, e.g., on the cloud or fog node in an IoT scenario.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

488

3.3 Obfuscation Model

An obfuscation technique is a real-time modiﬁcation

in the order, occurrences, or values of event attributes

that results in concealing sensitive information (i.e.,

private patterns). Such a modiﬁcation can be applied

to event streams, executed prior to the CEP middle-

ware. More importantly, the obfuscation technique

should be placed on the earliest available, trustworthy

resources to the producers, preventing inconsistencies

in the delivered streams. Among common obfusca-

tion techniques, we consider a PPM is able to hire the

following techniques:

• Suppression. Removing the occurrence of events

by dropping them from the event stream, e.g., re-

moving the event HomePage Visit

to conceal

page navigation behavior of customer c

• Reordering. Changing the order of two events

by swapping their timestamps, e.g., changing the

occurrence time of an event Buy

with the event

Buy

to conceal the order of purchases for a spe-

ciﬁc customer c

• Injection. Introducing fake events and inserting

them in unique places in the stream, e.g., inject-

ing the event Buy

multiple times to conceal a

speciﬁc interest to item i. It shows the person c

interested in both items, i.e., i and j.

• Tampering. Changing attributes of an event

to a wrong value or noise injection in event

timestamps, e.g., changing the value of item

type i in Add To Basket

to j which produces

Add To Basket

in order to conceal unhealthily

shopping habit of a diabetic customer from an in-

surance company.

• Generalization. Anonymizing the event’s at-

tributes by changing to a general value, e.g., gen-

eralizing an event Buy

apple

to Buy

f ruit

to conceal

a customer’s shopping interests.

• Hybrid. A combination of thereof, e.g., sup-

pression of event Buy

medicine

and injecting event

Buy

drink

to conceal a customer’s decease.

4 PROBLEM STATEMENT

Consider as inputs of a stream processing system sets

of public and private patterns. Basically, a PPM re-

quires checking the actual events in the input stream

to compare and assign OTs on the ﬂy (i.e., by limiting

the stream dimension using windowing) (Palanisamy,

2020). Therefore, adaptive decisions for maintaining

the privacy-QoS trade-off should be performed at run-

time by exchanging between the best possible PPMs.

Such run-time changes are also referred to as tran-

sitions (Alt et al., 2019). Performing transitions be-

tween PPMs requires careful treatment regarding the

required time and resources. Moreover, transitions

can impose gaps during which PPM cannot meet the

privacy requirements (i.e., periods with no applied ob-

fuscation). Also, it will lead to an oscillation between

obfuscation techniques that will worsen by scaling up

the pattern sets since it will drastically increase the

number of switches. Consequently, ﬁnding a solution

to predict transition points is necessary to minimize

the overhead and prevent oscillation.

Moreover, the adversary’s background knowledge

level is determined in such systems in the initial stage.

However, an Omnipresent adversary can increase its

knowledge by issuing more and more queries and try-

ing to correlate the generated results. This indicates

another weakness of current approaches that do not

consider this dynamicity. In addition, it again ap-

proves the idea of adaptive assignment of OT models

to private patterns since new knowledge obtained by

adversaries should be taken into account in the assign-

ment procedure. So, a comprehensive PPM should

also provide enough means for dynamic modeling of

the adversary’s background knowledge.

Therefore, the main problem this paper solves is

obtaining data owners’ privacy requirements in run-

time in the form of patterns and trying to conceal

them in a way that leads to maximizing the Quality

of Service (QoS) (i.e., utility) while considering po-

tential adversary’s knowledge. Here, the comparison

metric is calculated based on the number of truly de-

tected matches of public patterns (i.e., T P

PUB

) and

False Positives (FP) in detecting public patterns (i.e.,

PUB

). In addition, regarding private patterns, the

number of truly obfuscated matches of private pat-

terns (i.e., T O

PRIV

) and wrongly created new pri-

vate patterns after applying obfuscation models (i.e.,

PRIV

) are being involved. Finally, the last consid-

ered metric is the number of matches for private pat-

terns that can be derived using the adversary’s back-

ground knowledge.

Each of these event types (e.g., TP) has its own

group weight (e.g., W

T P

). The rationale behind these

coefﬁcients is in some applications, the importance

of true detection of a phenomenon is not equal to the

wrong extra detection or vice versa. The same can

be deﬁned as concealing a private pattern over gen-

erating not true new private patterns. For example,

in a healthcare scenario, vital situations of patients

(i.e., public patterns) must be detected regardless of

the individual’s privacy protection (i.e., private pat-

APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event Processing Systems

489

terns). Besides, the signiﬁcance of private patterns

within their set is not equal (i.e., pattern priority). To

consider this fact, we deﬁne a unique weight for each

pattern (e.g., w

). The same also applies to public

patterns (e.g., w

t p

According to the mentioned event groups, a

Privacy-Utility Trade-off (PUT) function is formu-

lated as an optimization problem to make the perfor-

mance of each OT model comparable. We extend the

objective function formulation in (Palanisamy, 2020)

i) to deal with the dynamicity of matched private and

public patterns, ii) and quantify the adversary’s back-

ground knowledge.

More formally, the resulting formula is:

Max

(



T P

∑

t p∈T P

PUB

t p



−



∑

f p∈FP

PUB

f p





∑

to∈T O

PRIV



−



∑

f r∈FR

PRIV

f r



−



Adv

∑

p∈PRIV



)

This objective function generally can be used in

any application context. In other words, the last part

is calculated by estimating the number of already ob-

fuscated private pattern matches, which can be re-

vealed based on the adversary’s background knowl-

edge. However, if such a piece of knowledge is not

available enough, the last part of this objective func-

tion can be skipped to make a fair comparison.

5 THE APP-CEP DESIGN

In Figure 2, we illustrate the main functionalities of

APP-CEP. Parts of our system are built on existing

concepts for converting the privacy requirements and

situations of interest in natural language to a CEP-

like pattern representation (Stach and Steimle, 2019).

Therefore, we assume that data owners and users are

able to feed the system with public and private pat-

terns. The main goal of APP-CEP is to gather re-

lated information about 1 patterns’ dependencies,

2 event dependency set, as well as 3 input stream

features to opt for 4 obfuscation techniques which

satisfy PUT, even without knowledge about the actual

events in the input streams and adapt the selection

based on the obfuscation results in execution time.

This section will further elaborate on the functionality

of these four components of APP-CEP.

Here, there are two dynamic databases, namely

stream database and OT database, which assist

APP-CEP in the obfuscation procedure by providing

up-to-date information. In the former, all previous

OT Deployment

Adaptation

Database

Pattern

Dependency

Graph Generator

Private Patterns

Public Patterns

User

Stream Feature

Extractor

Event

Dependency

Extractor

Stream

Database

Obfuscation

Technique

Assigner

DCEP

Middleware

Consumer

Results

Input stream

Producer

Figure 2: The APP-CEP Proposed System Design. The

solid lines indicate the data/event ﬂow, while the dashed in-

dicates the control ﬂow.

events are collected (e.g., the transaction history of

the webshop) for further analysis, such as extracting

event dependencies and stream features. In the lat-

ter, all available models of applying obfuscation tech-

niques (e.g., dropping the ﬁrst event is a private pat-

tern) are gathered to support performance analysis of

deployed obfuscation technique and make adaptation

decisions. Moreover, we presume a data owner has

sufﬁcient skills to support APP-CEP by dynamically

providing event dependencies to facilitate the obfus-

cation procedure in the execution time. For example,

a webshop customer can provide information about

his preferred pick-up point for purchases that will be

delivered in the working days since such information

should be considered while obfuscating the patterns

in location tracking applications.

In preliminary approaches on multiple pattern-

type privacy protection (Palanisamy, 2020) , a PPM is

only able to calculate a utility value by inspecting the

actual events in the input streams. Therefore, assign-

ing the best obfuscation technique for each private

pattern is achievable by comparing the utility values.

However, a signiﬁcant disadvantage of such strategies

is the complexity of designing a low-overhead adapta-

tion procedure to maintain the privacy protection per-

formance at an acceptable level concerning the sys-

tem’s dynamics, e.g., changing data owners’ privacy

requirements . To appropriately respond to dynamics,

a greedy idea would be to switch between obfusca-

tion techniques whenever a model with a higher util-

ity value is provided by the corresponding component

(i.e., Obfuscation Technique Assigner). The main pit-

falls with this approach are, ﬁrstly, time and resource

overhead for transitions and, secondly, oscillation be-

tween obfuscation techniques that downgrade the ob-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

490

Figure 3: The global pattern dependency graph represents

the impacts of obfuscating each private pattern on related

public/private patterns.

fuscation performance.

To overcome the mentioned challenges, one could

realize that relying only on the actual events that ap-

pear in the input streams causes transition overheads

and oscillation issues. In other words, if a PPM is

able to predict the obfuscation techniques’ transition

time, the data/operator migration can be performed

ahead of time in order to minimize inefﬁciency in both

time and resource utilization. Such prediction can be

achieved by realizing the correlation between patterns

as well as events. Moreover, extracting input stream

features will enable a PPM to prevent unnecessary

obfuscation transitions, leading to performance efﬁ-

ciency. For example, the number of pattern matches

can roughly be estimated by extracting the event dis-

tribution in each event stream. This will prevent os-

cillation in obfuscation assignment, which might be

produced by transition from dropping to reordering

and quickly returning to dropping.

Nevertheless, generating more up-to-date insights

about patterns and also events helps APP-CEP to

wisely adapt the system to maximize the overall per-

formance of the obfuscation procedure.

5.1 Pattern Dependency Graph

Predicting the obfuscation transition time is possible

by determining the potential dependencies between

private and public patterns. To be more precise, con-

sider the following public and private patterns.

PUBLIC = { {pu

| Buy

→ Return

′

{pu

| Buy

∗

→ Buy

∗

→ Buy

∗

{pu

| Buy

|| Buy

} }

PRIVAT E = { {pr

| Buy

|| Buy

{pr

| Buy

|| Buy

{pr

| Buy

→ Buy

} }

These sample pattern sets indicate the following event

correlations:

PlP-CEP









Reorder (e

)











Suppression (e

)











Suppression (e

)









Tamper (e

)

Figure 4: The alternative pattern dependency sub-graphs

represent the obfuscation impacts based on enforcing a spe-

ciﬁc obfuscation technique.

• pu

. A causal relationship between buying and re-

turning two types of Christmas decorations (CD)

with the same customer ID, which shows the cus-

tomers’ interests.

• pu

. Multiple purchases of the same product (i.e.,

birthday candle (BC)) by different customers,

which helps recommendation systems.

• pu

. The concurrent ordering of alcoholic drinks

(AD) and fruit juice (FJ) with the same customer

ID, which detects customers’ drinking interests.

• pr

. Simultaneous purchasing of invitation cards

(IC), Christmas ribbons (CR), and Christmas dec-

orations, which reveals a Christmas party.

• pr

. The concurrent purchase of invitation cards

and birthday candles, which reveals a birthday

party.

• pr

. A causal ordering dependency of alcoholic

drinks and diabetic medicine (DM) reveals a bad

lifestyle for a diabetic person.

The respective pattern dependency graph for the

mentioned patterns is depicted in Figure 3. Here, the

submitted privacy requirements belonging to an indi-

vidual customer (i.e., p

) have been used to deﬁne

private patterns. Besides, queries represented as pub-

lic patterns are generally deﬁned, not for a speciﬁc

customer ID. Signs (→) and (||) indicate the causal

dependency in a sequence pattern and parallel occur-

rence of events in a conjunction pattern, respectively.

To construct a pattern dependency graph, we as-

sume that nodes of the graph are patterns, and for

each private pattern, outgoing edges are one-way ar-

rows from this private pattern to all dependent pub-

lic/private patterns. A pattern is called the neighbor

of private pattern pr if an edge exists going from pr to

this speciﬁc node. For instance, if we plan to obfus-

cate private pattern pr

, suppression of event Buy

APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event Processing Systems

491

helps to obfuscate private pattern pr

(positive im-

pact). However, suppression of the event Buy

will

result in false negatives in the detection of public pat-

tern pu

(negative impact).

The graph representation of pattern dependencies

supports deriving insights that can be helpful in OT

model selection. For example, the outgoing edges of

each node indicate the detection of how many patterns

will be inﬂuenced. In a particular case, disconnected

nodes (i.e., nodes with no neighbor) do not have any

relationship with other nodes. Hence, the obfuscation

selection is much easier and even static in such cases

until their connectivity changes in the updated pattern

dependency graph. Any available obfuscation tech-

nique can be chosen in such situations since they all

support the PUT goal.

On the other side, if a private pattern has one

or more outgoing edges in the global dependency

graph, an alternative solution would be to break down

the global dependency graph into obfuscation-speciﬁc

sub-graphs (e.g., suppression(e

) graph, which drops

the ﬁrst event of all matches). This way, APP-CEP

can ﬁnd a sub-graph in which this speciﬁc node has

no neighbors. Figure 4 shows the generated graphs

of four different obfuscation techniques as examples

of sub-graphs. Here, nodes pr

and pr

are discon-

nected nodes in the Suppression(e

), and pr

has no

neighbors in the Suppression(e

). Therefore, these

OT models are potential candidates for correspond-

ing private patterns. Note that Reorder(e

, e

) is not

among available OT models for pr

and pr

because

the conjunction operator is used in the deﬁnition of

those patterns between the ﬁrst and second events,

and such obfuscation technique is not able to conceal

these patterns. Similarly, Tamper(e

) is not applicable

for patterns of length 2, e.g., pr

and pr

5.2 Event Dependencies

Modeling the adversaries’ background knowledge is

a complicated task that has yet to be well-studied in

this ﬁeld. Some research works have been conducted

to statistically predict special privacy attacks to model

the adversary (Palanisamy, 2020). For example, an

adversary might infer several event types’ true mean

inter-arrival time from stream history. Then, he can

realize enforced pattern obfuscation by computing

statistical metrics like the suppression probability of

this event type and try reconstructing the original in-

put stream. However, the potential data owners’ infor-

mation is not exploited to complement the ﬁnal adver-

sary model.

To this end, APP-CEP supports the runtime ex-

pression of event dependencies. This facilitates mod-

eling the possible information that an adversary might

use to derive insights related to data owners. For in-

stance, the regular shopping habits of a customer, e.g.,

buying two products always together, give a hint to the

system not to drop one while publishing the other. In

more detail, four types of event dependencies can be

introduced to be considered in the obfuscation assign-

ment phase.

5.2.1 Causal Dependency (→)

In this category, a relationship between two events

can be speciﬁed in two ways: ﬁrstly, one event is the

reason for occurrences of the other (i.e., cause and

effect), and secondly, one event always happens be-

fore the other. For example, in our use-case scenario,

a causal dependency can be derived from history as:

CD (Submit Order

, Payment Success f ul

)

which means the event of submitting an order is the

cause, and the successful payment event is the ef-

fect. Also, a customer c

might express that he always

checks the available balance before adding a product

p to the shopping basket. Therefore, the customer c

can provide a causal dependency to the system as:

CD (Check Balance

, Add To Basket

)

In these cases, APP-CEP considers the depen-

dency, e.g., does not suppress the cause event and

keeps the effect event or reorders these two events.

5.2.2 Parallel Occurrence ( || )

Special events (two or more) happen always, or at

least with a high probability, simultaneously or in a

short period. This means an intelligent obfuscation

assignment should consider them as a single com-

bined event, e.g., reorder all events instead of one. As

an example in the proposed webshop scenario, a cus-

tomer c

might express that he always buys products

p and q together. This leads to a parallel occurrence

of the corresponding two events, represented as:

PO (Add To Basket

, Add To Basket

5.2.3 Infeasible Events (↛)

Another type of event relationship also shows the

impossible occurrences of one or several events or

patterns. For instance, when a customer c

is nav-

igated to the bank payment page as a result of the

Submit Order event with id i, it is not possible

to observe two events of Payment Success f ul and

Payment Re jected afterward for this special order

submission in the stream, that can be expressed by:

IE [CD (Submit Order

, Payment Success f ul

CD (Submit Order

, Payment Re jected

)]

Such dependencies usually cannot be expressed

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

492

by a data owner, but require help from domain experts

in the application scenario.

5.2.4 Periodic Events (

Apart from dependencies between events, this type of

information shows insights can be derived as a result

of statistical calculation over a speciﬁc event type for

a unique data owner. We assume that the adversary

has the required computing resources and access to

the data history to correlate the statistical dependen-

cies for a particular data owner. For example, a cus-

tomer c

might have a shopping habit of buying a spe-

cial product p each day. Hence, such a habit can be

expressed by:

PE (Buy

, day )

Therefore, applying any obfuscation technique re-

lated to dropping or altering such events (e.g., sup-

pression, tampering, generalization, etc.) will lead to

violating the privacy of data owner by revealing the

stream modiﬁcation on the adversary side, whereas

obfuscation techniques like reordering still might be

applicable in such situations.

5.3 Stream Features

Even if we know the privacy requirements of data

owners and the dependencies between patterns and

events, the input streams also bring up another dy-

namicity that should be considered. In more detail,

the number of matches for a pattern determines an-

other vital dimension. For example, a Christmas party

is more likely to be revealed during Christmas. There-

fore, obfuscating a private pattern that increases the

reveal of any Christmas party at another time of the

year (e.g., in July) would be acceptable because the

detection probability of such a party is very low in

other periods.

Hence, extracting input stream features helps a

PPM to assign the OT model more efﬁciently. To

do so, APP-CEP investigates the stream database and

analyzes the input streams online to adapt the fea-

tures. As mentioned earlier, one signiﬁcant feature

of streams is the average number of matches for each

pattern. For instance, the number of matches for a

Christmas party pattern is calculated weekly, which

helps dynamically assign weight to this private pat-

tern in the PUT function.

Apart from patterns, event-related stream features

bring up the beneﬁts, causing a more brilliant OT

model selection. For instance, the event distribution

helps estimate a more accurate weight for each sup-

pression model of a private pattern (He et al., 2011).

If the event e on a private pattern pr has a higher

frequency in history, suppression of e tends to create

Algorithm 1: Obfuscation Technique Assignment.

1: Initialization:

P U , P R ← ∅;

D ← Event Dependencies;

O ← Obfuscation Techniques;

2: upon (Submit(Q

)) do

3: P U ← P U ∪ CEP-Pattern(Q

); ▷ Query

4: OT Assigner (P U, PR , D);

5: upon (Submit(Pr

)) do

6: P R ← P R ∪ CEP-Pattern(Pr

); ▷ Priv Req

7: OT Assigner (P U, PR , D);

8: upon (Submit(d

)) do

9: D ← D ∪ d

; ▷ Event Dependency

10: OT Assigner (P U, PR , D);

11: function OT ASSIGNER(P U, P R , D)

12: G ← Pattern Dependency Graphs;

13: F ← Input Stream Features;

14: for pr ∈ P R do

15: O

← O;

16: for ot ∈ O do

17: if ot violates D|F then

18: O

← O

− ot ;

19: OT

← ∅;

20: for ot ∈ O

21: if OutDeg

= 0 then

22: OT

← OT

∪ ot;

23: if O T

̸= ∅ then

24: α

← O T

;

25: else

26: α

← Random(O

);

27: α ← {(pr

, α

), ..., (pr

, α

)}; ▷ Solution

more FN in detecting neighbors of pr which contain e.

Such an idea can also be extended to subsets of each

private pattern instead of a single event by checking

its distribution for other types of obfuscation (e.g., a

two-event subset for reordering).

5.4 Obfuscation Technique Assignment

In connection with the OT database, the obfuscation

technique assigner module, which is the core com-

ponent of APP-CEP, acts as the system’s brain. It

aggregates the information collected from the other

three modules (i.e., 1 pattern dependency graph gen-

erator, 2 event dependency extractor, and 3 stream

feature extractor) to decide which OT model should

be chosen regardless of the current input streams for

each private pattern.

In Algorithm 1, the sets of public and private pat-

terns are initialized, and the event dependencies de-

rived from streams’ history alongside the available

APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event Processing Systems

493

obfuscation operators are delivered as inputs (line

1). Upon receiving new public or private patterns,

APP-CEP updates the obfuscation technique assign-

ment (lines 2-7). Here, we also accept the event de-

pendencies the data owner enters at runtime (lines 8-

10). The OT Assigner function generates pattern de-

pendency graphs for each OT model and updates them

on runtime based on changes in both public and pri-

vate sets. Also, it extracts input stream features based

on history and updates those features using the current

streams (lines 12-13).

According to the event dependency set and stream

features, for each private pattern pr, APP-CEP per-

forms the following tasks: ﬁrst, it removes those

OT models whose obfuscation can be realized by an

adversary (lines 16-18). For example, if the result

of reordering violates a causal dependency, such an

OT model will be removed from the list of available

OTs. In the remaining OT model space (i.e., O

APP-CEP looks for a member whose dependency

graph has a node with an out-degree equal to zero for

pr, so-called zero-out-degree (ZOD) node (lines 20-

22). One of the OT models containing such a node

will be assigned to the pr. A random OT model will

be assigned to a pr if no ZOD node has been found for

this private pattern (lines 23-26). Finally, the assigned

OT model for each private pattern is determined and

will be updated upon any change in patterns or event

dependencies.

Although APP-CEP is a restrictive approach since

the idea of selecting a ZOD node does not achieve the

maximum QoS, ﬁnding these nodes guarantees both

obfuscating each private pattern and trying to detect

as many public patterns as possible. In addition, cal-

culating the exact PUT value requires considering the

exact number of pattern matches in each input stream,

whose disadvantages have been discussed earlier. In

case of ﬁnding no ZOD node, we believe assigning

the best OT model is outside the scope of our paper.

Therefore, we randomly assign the OT model in such

a worst-case scenario.

6 EVALUATION

The evaluation investigates the following questions:

1. Can graph-based pattern-level privacy provide a

trade-off between privacy concerns and the sys-

tem’s promised QoS?

2. What limitations are involved in applying pattern-

level privacy in real-world scenarios?

We created a single Virtual Machine (VM) in Or-

acle VM Virtual Box Manager, in which we installed

100

3*3 6*3 9*3 12*3 15*3

TOTAL REVEALED PRIVATE

PATTERN MATCHES (%)

# OF PUBLIC PATTERNS * # OF PRIVATE PATTERNS

APP-CEP Graph-based Window-based

Figure 5: Percentage of total revealed private pattern

matches Vs. The increasing number of public patterns.

Ubuntu version 20 OS. We allocated 6 CPU cores

with 100 percent execution capacity and 24 GB of

main memory to the VM. Furthermore, for event de-

tection, we build on FlinkCEP (Flink, 2017), a library

implemented on top of Apache Flink. We evaluated

our ideas by analyzing a publicly available real-world

dataset (Chen et al., 2012), transactions of an online

retailer selling all-occasion gifts. A part of this dataset

is selected for this evaluation, including 12000 cus-

tomer purchase records. We selected the 50 most fre-

quent patterns (length 3) from which public and pri-

vate pattern sets were randomly formed. We also per-

formed another statistical analysis to extract the most

parallel purchased items and periodically purchased

items as dependencies considered for the adversary’s

background knowledge. We executed the event detec-

tion process ten times for each combination of public

and private patterns and stated the average results.

Since modeling the adversary’s background

knowledge and graph-based OT assignment have not

been addressed before, we selected two baseline ap-

proaches to analyze the performance of APP-CEP.

The ﬁrst technique, called Window-based, simulates

the performance of the state-of-the-art mechanisms

(Palanisamy, 2020; Palanisamy et al., 2018), which

relies on splitting the input stream into multiple ﬁ-

nite windows of events. This approach tries to se-

lect an obfuscation technique for each private pat-

tern match precisely based on a utility value calcu-

lated according to the expected number of matches

for all patterns after applying that speciﬁc obfusca-

tion technique. The second approach, called Graph-

based, performs the obfuscation technique selection

similar to APP-CEP but without considering the ad-

versary’s background knowledge (i.e., event depen-

dencies). It only checks the pattern dependency graph

or OT-speciﬁc sub-graphs, if needed, and makes a de-

cision accordingly.

Figure 5 indicates the total percentage of re-

vealed private pattern matches (i.e., the summation of

matches for data owners’ privacy requirements added

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

494

0.5

0.6

0.7

0.8

0.9

1.1

3*3 6*3 9*3 12*3 15*3

F1-SCORE IN DETECTING PUBLIC

PATTERN MATCHES

# OF PUBLIC PATTERNS * # OF PRIVATE PATTERNS

APP-CEP Graph-based Window-based

Figure 6: F1-score in detecting public pattern matches Vs.

The increasing number of public patterns.

to the number of matches revealed by the adversary’s

background knowledge, totally divided by the actual

matches) while the number of public patterns is in-

creasing. Error bars also indicate the standard devia-

tion of ten rounds of simulations for each approach. It

can be seen that modeling and considering the adver-

sary’s background knowledge helps APP-CEP to sig-

niﬁcantly reveal less (i.e., conceal more) private pat-

terns than other approaches. By adding more queries

to the system, Graph-based and Window-based tech-

niques ﬂuctuate, but APP-CEP’s results stay around

ten percent. The random assignment of obfuscation

techniques when APP-CEP cannot ﬁnd a ZOD node

in the global dependency graph or in obfuscation-

speciﬁc sub-graphs shows its impacts in the last three

bars. That is why complementing our algorithm with

an intelligent solution for such situations would be

challenging but necessary for our future work to solve

the potential scalability issue.

Similar to FN and FP, F1-score is a well-

known performance measure in machine learning ap-

proaches. It combines the other two measures, pre-

cision and recall, which are mainly employed to

distinguish between classiﬁers (Li et al., 2020) in

terms of accuracy. Therefore, the F1-score can be

used in stream processing to compare mechanisms

in terms of accuracy. From the public pattern de-

tection’s accuracy point of view, by increasing the

number of involved queries, all three approaches ﬂuc-

tuate but gradually degrade; thereby, there is not a

speciﬁc front-runner, illustrated in Figure 6. How-

ever, APP-CEP’s detection accuracy is mostly equal

to or better than the Window-based approach when

increasing the number of involved queries (i.e., public

patterns), which conﬁrms a slight improvement over

the literature, even in this challenging comparison.

The effects of increasing the knowledge of the ad-

versary are depicted in Figure 7. It can be seen that

APP-CEP reveals signiﬁcantly fewer matches than

the other two approaches. By involving more de-

pendencies in query processing, the percentage of

100

20 40 60 80 100

REVEALED PRIVATE PATTERNS

MATCHES BY ADVERSARY (%)

# OF INVOLVED DEPENDENCIES

APP-CEP Graph-based Window-based

Figure 7: Percentage of revealed private pattern matches

by adversary Vs. The increasing adversary’s background

knowledge (number of dependencies).

200

400

600

800

1000

3*3 6*3 9*3 12*3 15*3

PRIVACY-UTILITY TRADE-OFF

# OF PUBLIC PATTERNS * # OF PRIVATE PATTERNS

APP-CEP Graph-based Window-based

Figure 8: Privacy-Utility Trade-off Vs. The increasing

number of public patterns.

expected revealed private pattern matches unexpect-

edly rises slightly but is still negligible compared to

Graph-based and Window-based approaches. Here,

the Graph-based approach reveals little more private

pattern matches than the Window-based, but gen-

erally, both approaches show similar performance.

Adding more dependencies corresponds to a more

knowledgeable adversary that even impacts the per-

formance of APP-CEP. Protecting against such an ad-

versary is almost impossible without sacriﬁcing util-

ity in the system. However, the proposed approach

shows such a trade-off can be achievable even inde-

pendently of the actual events in the stream. More-

over, note that it becomes hard to compensate for the

revealed matches without modeling the adversary’s

additional background knowledge.

Last, Figure 8 accumulates the previous results to

compare the privacy-utility trade-off of the three ap-

proaches. As discussed in Section 4, the main goal

of this paper is to provide a method to maximize the

trade-off value (cf. PUT equation).

The computation of such a value requires the

system designer to opt for an optimized value for

weights. We decided to set equal weights for re-

vealed private pattern matches and expected revealed

matches by the adversary. This weight is the ratio of

the average of actual public matches to the average

of actual private matches for each pattern set com-

APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event Processing Systems

495

bination. For instance, the weight for the scenario in

which we have 3 public patterns and 3 private patterns

was calculated as 1.0301. Also, we set the weight for

the detected public pattern matches equal to 1.

Here, the results indicate that APP-CEP is capa-

ble of achieving the expected PUT even by scaling up

the system’s involved queries. Although the Window-

based approach had a good start, the bars fall once

more public pattern matches are going to be detected,

as the amount of revealed private matches by the ad-

versary signiﬁcantly impacts the PUT value. The

Graph-based approach seemingly had a better perfor-

mance than the Window-base. However, its results

also had a downward ending for the same reason.

Ultimately, the evaluation results prove the

expected improvements provided by graph-based

pattern-level privacy protection, solving the litera-

ture’s PUT gap. APP-CEP performs better in almost

all aspects discussed in this section than approaches

presented in previous studies due to considering both

pattern dependencies and modeling the adversary’s

background knowledge.

7 RELATED WORK

Although sharing data between stakeholders increases

the utility of IoT applications, ensuring efﬁcient

preservation of privacy is still challenging (Tran et al.,

2023). Similarly, providing privacy in DCEP systems

requires establishing a trade-off concerning QoS since

protecting an individual’s privacy should not sacriﬁce

the application’s functionality, which lays on more

data to maximize the quality (Plagemann et al., 2022;

Schilling et al., 2013). Therefore, PPMs are required

to be lightweight and do not prevent any application

from detecting query patterns adequately. Moreover,

although data owners have been recently becoming

more aware of how their data will be analyzed and

being able to control it (Tokas et al., 2023; Leicht and

Heisel, 2023; Barber and Furnell, 2022), providing

sufﬁcient means for them to express their privacy con-

cerns is still poorly studied.

The initial idea of preserving the individual’s pri-

vacy by employing patterns was introduced more than

a decade ago (He et al., 2011). It was theoretically

proved that by employing a probabilistic model, the

choice of event suppression can be estimated to max-

imize the utility alongside a window-based approach,

which makes the obfuscation decision according to

the actual events. Similar methods computed the

event distribution using advanced pattern match car-

dinality estimation techniques (Wang et al., 2013).

Other obfuscation operators (e.g., Reordering) have

been discovered in the literature as an alternative to

suppression operator (Palanisamy et al., 2018). The

main drawback of the mentioned studies is they failed

to obfuscate various pattern types since they focused

only on sequence type. In addition, they were highly

dependent on the input streams to apply obfuscation

techniques, i.e., they failed to obfuscate various kinds

of private patterns well in an environment with dy-

namic input event streams. Moreover, they have not

supported simultaneous obfuscation techniques cus-

tomized for each private pattern.

Recently, the idea of multi-operator multi-pattern

privacy protection has been introduced (Palanisamy,

2020). Although this ILP-based approach maximizes

the QoS while preserving privacy, it is limited to three

pattern types and three obfuscation operators. Be-

sides, it suffers from oscillation between OT mod-

els since they change the deployment as soon as they

detect a change in the input stream. This instability

in the deployed OT models degrades performance by

imposing unnecessary transition overhead. Besides,

the adversary’s background knowledge, which might

be used to realize the obfuscation, needed to be con-

sidered thoroughly.

8 CONCLUSION

In this work, we proposed APP-CEP, which repre-

sents how to enable dynamic integration of pattern-

level privacy in event-based systems to protect privacy

while providing an acceptable level of QoS. In ad-

dition, by producing pattern dependency graphs, our

mechanism is able to assign obfuscation techniques to

conceal sensitive patterns selectively and make an ob-

fuscation plan ahead of time. Our evaluation results

demonstrated that APP-CEP outperforms two base-

line techniques, namely Window-based and Graph-

based approaches, in the total percentage of revealed

private pattern matches and performed slightly bet-

ter in the number of detection errors of public pattern

matches. Moreover, by involving more background

knowledge, APP-CEP achieves a signiﬁcant perfor-

mance in the expected revealed private matches by the

adversary. Furthermore, the PUT results prove that

APP-CEP successfully provides a solution to the gap

mentioned in this study and envisions a new era in this

ﬁeld for adaptively assigning obfuscation techniques

regardless of actual events in the streams effectively.

In our future work, we will consider designing

an intelligent algorithm to select the best obfuscation

technique in case the dependency sub-graphs do not

offer a ZOD node. That can be achievable by in-

troducing a comparison metric by which both posi-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

496

tive and negative effects of obfuscations can be com-

puted and labeled in the sub-graphs. Besides, Enhanc-

ing the suitability for real-world applications requires

thoughtful consideration of the stakeholders and their

respective interests when selecting input representa-

tions. Moreover, we plan to extend our evaluation to

different use cases to ﬁgure out other aspects of this

problem as well as APP-CEP limitations in fulﬁlling

various applications’ requirements.

ACKNOWLEDGEMENTS

This work has been supported by the Research Coun-

cil of Norway as part of the project Parrot (311197).

REFERENCES

Alt, B., Weckesser, M., Becker, C., Hollick, M., Kar, S.,

Klein, A., Klose, R., Kluge, R., Koeppl, H., Kold-

ehofe, B., et al. (2019). Transitions: A protocol-

independent view of the future internet. In Proceed-

ings of the IEEE, 107(4):835–846.

Barber, F. and Furnell, S. (2022). Benchmarking con-

sumer data and privacy knowledge in connected and

autonomous vehicles. In Proceedings of the 8th Inter-

national Conference on Information Systems Security

and Privacy (ICISSP’22), pages 426–434.

Chen, D., Sain, S. L., and Guo, K. (2012). Data mining for

the online retail industry: A case study of rfm model-

based customer segmentation using data mining. Jour-

nal of Database Marketing & Customer Strategy Man-

agement, 19:197–208.

Flink (2017). Flink-cep. https://nightlies.apache.org/ﬂink/

ﬂink-docs-master/docs/libs/cep/, Accessed on Oct

9th, 2023.

Gundersen, M. (2022). Statistics norway demands to

know exactly what norwegians buy in the grocery

store. https://nrkbeta.no/2022/05/28/ssb-krever-a-fa-

vite-noyaktig-hva-nordmenn-kjoper-i-matbutikken/,

Accessed on Oct 9th, 2023.

He, Y., Barman, S., Wang, D., and Naughton, J. F. (2011).

On the complexity of privacy-preserving complex

event processing. In Proceedings of the 13th ACM

SIGMOD-SIGACT-SIGART symposium on Principles

of database systems, pages 165–174.

Leicht, J. and Heisel, M. (2023). P2bac: Privacy policy

based access control using p-lpl. In Proceedings of the

9th International Conference on Information Systems

Security and Privacy (ICISSP’23), pages 686–697.

Li, L., Zhong, B., Hutmacher Jr, C., Liang, Y., Horrey, W. J.,

and Xu, X. (2020). Detection of driver manual distrac-

tion via image-based hand and ear recognition. Acci-

dent Analysis & Prevention, 137:p. 105432.

Lotﬁan Delouee, M., Koldehofe, B., and Degeler, V. (2022).

Towards adaptive quality-aware complex event pro-

cessing in the internet of things. In Proceedings of

the 18th International Conference on Mobility, Sens-

ing and Networking (MSN’22), pages 571–575. IEEE.

Lotﬁan Delouee, M., Koldehofe, B., and Degeler, V.

(2023a). Aqua-cep: Adaptive quality-aware complex

event processing in the internet of things. In Pro-

ceedings of the 17th ACM International Conference

on Distributed and Event-Based Systems (DEBS’23),

page 13–24. ACM.

Lotﬁan Delouee, M., Koldehofe, B., and Degeler, V.

(2023b). Poster: Towards pattern-level privacy pro-

tection in distributed complex event processing. In

Proceedings of the 17th ACM International Confer-

ence on Distributed and Event-Based Systems, page

185–186. ACM.

Palanisamy, S. M. (2020). Towards multiple pattern

type privacy protection in complex event processing

through event obfuscation strategies. In Data Privacy

Management, Cryptocurrencies and Blockchain Tech-

nology: ESORICS 2020 International Workshops,

DPM 2020 and CBT 2020, Guildford, UK, Septem-

ber 17–18, 2020, Revised Selected Papers 15, pages

178–194. Springer.

Palanisamy, S. M., D

urr, F., Tariq, M. A., and Rothermel,

K. (2018). Preserving privacy and quality of service

in complex event processing through event reordering.

In Proceedings of the 12th ACM International Confer-

ence on Distributed and Event-based Systems, pages

40–51.

Plagemann, T., Goebel, V., Hollick, M., and Koldehofe, B.

(2022). Towards privacy engineering for real-time an-

alytics in the human-centered internet of things. arXiv

preprint arXiv:2210.16352.

Schilling, B., Koldehofe, B., Rothermel, K., and Ra-

machandran, U. (2013). Access policy consolidation

for event processing systems. In 2013 Conference on

Networked Systems, pages 92–101. IEEE.

Stach, C. and Steimle, F. (2019). Recommender-based

privacy requirements elicitation-epicurean: an ap-

proach to simplify privacy settings in iot applica-

tions with respect to the gdpr. In Proceedings of the

34th ACM/SIGAPP Symposium on Applied Comput-

ing, pages 1500–1507.

Tokas, S., Erdogan, G., and Stølen, K. (2023). Privacy-

aware iot: State-of-the-art and challenges. In Proceed-

ings of the 9th International Conference on Informa-

tion Systems Security and Privacy (ICISSP’23), pages

450–461.

Tran, T., Nguyen, P., and Erdogan, G. (2023). A system-

atic review of secure iot data sharing. In Proceed-

ings of the 9th International Conference on Informa-

tion Systems Security and Privacy (ICISSP’23), pages

95–105.

Wang, D., He, Y., Rundensteiner, E., and Naughton, J. F.

(2013). Utility-maximizing event stream suppression.

In Proceedings of the 2013 ACM SIGMOD Interna-

tional Conference on Management of Data, pages

589–600.

APP-CEP: Adaptive Pattern-Level Privacy Protection in Complex Event Processing Systems

497
