A Revisited Branch and Bound Method for the Weighted Safe Set

Problem

Alberto Boggio Tomasaz

and Roberto Cordone

Department of Computer Science, University of Milan, Italy

Keywords:

Weighted Safe Set Problem, Branch and Bound.

Abstract:

The Weighted Safe Set Problem requires to partition an undirected graph into two families of connected com-

ponents, respectively denoted as safe and unsafe, in such a way that each safe component dominates the unsafe

adjacent components with respect to a weight function. We introduce some improvements to an existing exact

approach that produce a signiﬁcant reduction in the effort required to ﬁnd the optimum or in the gap between

the optimum and the best solution obtained within a given time limit. The ﬁrst improvement consists of a

relaxation that is weaker than the original one, but allows to adopt a more effective branching strategy and

stronger variable ﬁxing procedures. The second one is the integration of a dedicated heuristic in the exact ap-

proach. The experimental results show a strong average reduction of the computational time and the number

of branching nodes. This also mitigates the anticipated termination of the algorithm due to the exhaustion of

the memory on the largest benchmark instances.

1 INTRODUCTION

The Weighted Safe Set Problem (WSSP) is the prob-

lem of ﬁnding a safe set of minimum weight on a

connected undirected graph G = (V,E) with weights

w : V → R

deﬁned over the vertices. To deﬁne a

safe set it is necessary to introduce some concepts.

The weight w(C) of a subset of vertices C ⊆ V is the

sum of the weights of all vertices in it. Two sub-

sets C

⊆ V are considered adjacent (and we write

 C

) if there is at least one edge (u,v) in the graph

such that u ∈ C

and v ∈ C

. Given a set S ⊆ V of ver-

tices and its complementary set U = V \ S, C

(S) is

the collection of all maximal connected components

induced by S in graph G and C

(U) the correspond-

ing collection induced by U. If the weight of each

component of C

(S) is not smaller than that of each

adjacent component of C

(U), we denote S as a safe

set, the components in C

(S) as safe components and

those in C

(U) as unsafe components. Given a safe

component S

and an adjacent unsafe component U

we will refer to the condition that w(S

) ≥ w(U

) as

safety constraint.

The WSSP was ﬁrst introduced in its unweighted

version (the weight of every vertex is 1) by Fujita et al.

https://orcid.org/0000-0003-3334-6238

https://orcid.org/0000-0002-5439-1743

(2014), while Bapat et al. (2016) deﬁned the general

weighted version. The real-world applications pro-

posed in these articles concern the choice of buildings

or areas to be converted into temporary shelters in or-

der to host people from the adjacent dangerous areas,

and the identiﬁcation of a critical community which

can control the totality of a social network.

The problem is NP-hard for both unweighted and

weighted versions (Fujita et al., 2016; Bapat et al.,

2016). Its parameterised complexity has been studied

Agueda et al. (2018) and Belmonte et al. (2020).

Exact algorithms for speciﬁc instances have been pro-

posed by Fujita et al. (2016),

Agueda et al. (2018)

and Cordone and Franchi (2023). Approximation al-

gorithms have been proposed by Bapat et al. (2018)

and Ehard and Rautenbach (2020). Heuristic ap-

proaches have been presented by Macambira et al.

(2019) and Boggio Tomasaz et al. (2023b). Finally,

exact (non-polynomial) approaches have been pre-

sented by Macambira et al. (2019), Hosteins (2020),

Malaguti and Pedrotti (2023) and Boggio Tomasaz

et al. (2023a). The last one solves instances up to 60

vertices in a time limit of one hour.

In this article we revisit the combinatorial branch

and bound algorithm presented in Boggio Tomasaz

et al. (2023a), introducing a relaxation that is theo-

retically weaker, but most of the time equivalent, and

allows more efﬁcient branching rules and reduction

Boggio Tomasaz, A. and Cordone, R.

A Revisited Branch and Bound Method for the Weighted Safe Set Problem.

DOI: 10.5220/0012359400003639

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 13th International Conference on Operations Research and Enterprise Systems (ICORES 2024), pages 113-122

ISBN: 978-989-758-681-1; ISSN: 2184-4372

113

procedures leading to a simpler and faster algorithm.

We also discuss the contribution provided by a good

heuristic initialisation.

2 THE REVISITED ALGORITHM

Boggio Tomasaz et al. (2023a) present a combinato-

rial branch and bound algorithm for the WSSP with

the following main features. The algorithm builds a

binary branching tree. It progressively assigns the

vertices either to the safe set S or the unsafe one,

U, thus extending the current safe and unsafe com-

ponents or creating new ones. The branching tree

is explored with the best-bound strategy, that is, al-

ways visiting the open node with the minimum lower

bound. In fact, in any branching node, the algorithm

computes a lower bound through a sequence of relax-

ations that combine manipulations of the graph and of

an Integer Linear Programming formulation. More-

over, it applies logical reduction procedures to move

free (i.e. unassigned) vertices into S or U. The com-

putation of the lower bound requires that at most one

of the connected components of the current safe set

S have free adjacent vertices. The other safe compo-

nents must be completely surrounded by unsafe ver-

tices. This is a basic drawback of the approach for two

reasons. First, it limits the branching rule, since not

all vertices can be selected and assigned to S and U in

the two children nodes. Second, it hampers the logi-

cal reduction procedures, since they cannot be applied

when the result creates several safe components with

adjacent free vertices, violating the requirement. On

sufﬁciently sparse instances (with a threshold exper-

imentally identiﬁed between 0.1 and 0.2), these lim-

itations are so strong that it actually proves more ef-

fective to resort to a trivial lower bound (the weight

of the current safe set, or of the maximum weight of

a current unsafe component) in order to preserve the

remaining parts of the algorithm.

In each branching node, the algorithm also gener-

ates a heuristic solution compatible with the branch-

ing constraints. While these solutions are computed

very quickly, their quality is bad. This is another

drawback of the approach. On small instances, in

fact, the branching process is still fast enough to ﬁnd

a provably optimal solution in short time. On large

instances, on the contrary, the time limit sometimes

expires when the best known solution is still far from

the optimum. Moreover, a bad upper bound implies

an increase in the number of open nodes during the

visit of the branching tree, possibly leading to exhaust

the available memory.

In this paper we revise the branch and bound al-

gorithm in order to alleviate its two main drawbacks.

To address the ﬁrst issue, we introduce an additional

graph manipulation that in principle yields a further

relaxed problem, and therefore a weaker lower bound.

The empirical results, however, show that the down-

side is most of the time null or negligible, while the

possibility to select the branching vertex more freely

and to apply all reduction procedures gives a bene-

ﬁcial contribution. Overall, this allows to simplify

the algorithm, avoiding the distinction between sparse

and dense instances, and to exploit the strengths of all

components of the algorithm at the same time. To

address the second issue, we apply a reﬁned heuris-

tic before the branch and bound algorithm to obtain a

starting upper bound.

In the following section, we present the relaxation

proposed by Boggio Tomasaz et al. (2023a) and the

additional manipulation here introduced, discussing

its potential effects and the reasons that often make

them irrelevant. Section 2.2 describes the branching

rule and logical reduction procedures, focusing on the

more general applicability guaranteed by the new re-

laxation. Section 2.3 deals with the heuristic used to

initialise the search.

2.1 A Weaker but More Versatile

Relaxation

Any subproblem in the branching tree is characterised

by a partition (S,U,F) of the vertex set V into the

set S of ﬁxed safe vertices, the set U of ﬁxed unsafe

vertices and the set F = V \ (S ∪U) of free vertices,

not already ﬁxed. We also deﬁne the subset of free

vertices adjacent to both S and U :

:= {v ∈ F | ∃s ∈ S : (s,v) ∈ E ∧∃u ∈ U : (u, v) ∈ E}

In this work we present and prove the following

new proposition, that allows to manipulate graph G in

order to obtain a relaxation of the given WSSP.

Proposition 1. Adding to graph G = (V,E) an edge

(u,v) with u,v ∈ S provides a relaxation of subprob-

lem (S,U, F).

Proof. We show that in the modiﬁed graph all feasible

solutions keep their value and remain feasible. Con-

sider two ﬁxed safe vertices u,v ∈ S and a solution

for subproblem (S,U, F). Two cases are possible:

1. u and v are in the same safe component in

in such a situation adding edge (u, v) does not

change the components and the value of

2. u and v are in different safe components in

by adding (u,v), the two safe components merge,

while all unsafe components and the value of the

objective remain unchanged.

ICORES 2024 - 13th International Conference on Operations Research and Enterprise Systems

114

Applying this proposition to all pairs of safe vertices

merges them into a single safe component. The fol-

lowing propositions, introduced and proved in Bog-

gio Tomasaz et al. (2023a), will be combined with the

previous one to further relax the problem.

Proposition 2. Removing from graph G = (V,E) an

edge (u,v) with u ∈ U and v ∈ F or both u,v ∈ F

provides a relaxation of subproblem (S,U,F).

Proposition 3. Replacing in graph G = (V,E) an

edge (u,v) with an edge (s,v) provides a relaxation

of subproblem (S,U,F) if s ∈ S, u ∈ F

, v ∈ F \ F

and (s, u) ∈ E.

Notice that Proposition 3 has been slightly

rephrased in an equivalent form in order to adapt it

to the new context.

The three propositions above allow to manipulate

the graph as follows:

• connect all vertices in S to one another;

• remove all edges (u,v) with u,v ∈ F

;

• remove all edges (u,v) with u ∈ U and v ∈ F \ F

;

• for each vertex v ∈ F

, remove all but one of the

edges (u,v) such that u ∈ U;

• replace every edge (u, v) with u ∈ F

and v ∈ F \

with an edge (s, v) with s ∈ S (if such an edge

already exists, just remove (u,v)).

The resulting manipulated graph, which we call G

(V,E

), consists of: i) a clique S of ﬁxed safe vertices;

ii) a collection of unsafe components C

(U) with the

original internal edges; iii) an independent set F

vertices, which are linked to S by at least one edge,

to U by exactly one edge, to F by no edge; iv) the

remaining set of free vertices F \ F

with the original

internal edges, disconnected from F

and U, but pos-

sibly connected with S. As a consequence, the unique

safe component can be enlarged including vertices in

F, whereas each unsafe component U

∈ C

(U) can

be enlarged including only the vertices in F

that are

directly adjacent to U

. These vertices form set:

:= {v ∈ F

| ∃s ∈ S : (s,v) ∈ E

∧ ∃u ∈ U

: (u, v) ∈ E

}

Given the current subproblem (S ,U,F) and the

manipulated graph G

, we can introduce the follow-

ing Integer Linear Programming formulation. Let

= 1 when vertex v belongs to the solution, and

= 0 otherwise. The auxiliary variable σ represents

the weight of the free vertices assigned to the unique

safe component, while τ

represents the weight of the

free vertices assigned to the unsafe component U

min w(S)+ σ (1a)

subject to:

w(S) + σ ≥ w(U

) + τ

∈ C

(U) (1b)

σ =

∑

v∈F

· x

(1c)

∑

v∈F

· (1 − x

) U

∈ C

(U) (1d)

σ,τ

≥ 0 U

∈ C

(U) (1e)

∈ {0, 1} v ∈ F (1f)

where objective (1a) is the weight of the safe set and

constraints (1b) are the safety conditions between the

unique safe component and the currently known un-

safe ones. Constraints (1c) and (1d) deﬁne the aux-

iliary variables and constraints (1e) and (1f) the do-

mains of all variables. Since the safety constraints

(1b) neglect the components that the free vertices

could still form, Formulation (1) is a relaxation of the

subproblem (S,U, F).

Now, we replace constraints (1c), (1d) and (1f)

with:

≤ w(F

) ∀U

∈ C

(U) (2)

σ +

∑

∈C

(U )

≥ w(F

) (3)

The former derives from majorising (1 − x

)

with 1 in (1d), the latter from summing con-

straints (1c) and (1d). This yields a relaxation of For-

mulation (1):

min w(S) + σ (4a)

subject to:

w(S) + σ ≥ w(U

) + τ

∈ C

(U) (4b)

σ +

∑

∈C

(U )

≥ w(F

) (4c)

σ ≥ 0 (4d)

0 ≤ τ

≤ w(F

) U

∈ C

(U) (4e)

which we solve with a simple readaptation of the al-

gorithm proposed in Boggio Tomasaz et al. (2023a).

With respect to the original relaxation, the new

approach provides a weaker bound, due to the fact

that forcing all safe vertices in the same safe com-

ponent generates new feasible solutions, that could

improve the value of the optimum. However, the

empirical results show that the branching nodes in

which the number of safe components is larger than

one are very rare, and that all benchmark instances

have a connected optimal solution. This can be ex-

plained in view of the properties of random graphs,

which asymptotically tend to become connected as

their number of vertices increases, as discussed in

Cordone and Franchi (2023).

A Revisited Branch and Bound Method for the Weighted Safe Set Problem

115

2.2 Reduction Procedures and

Branching Rule

Given a subproblem (S,U, F), suitable reduction pro-

cedures allow to assign some of the free vertices to

the safe or the unsafe set without affecting the value

of the optimum. The following propositions, proved

in Boggio Tomasaz et al. (2023a), guarantee the cor-

rectness of these procedures.

Proposition 4. Given a subproblem (S,U, F), if a

component F

∈ C

(F) is not adjacent to S and has

weight w(F

) smaller than that of an adjacent unsafe

component, all its vertices can be assigned to U.

This proposition also allows to test the existence

of feasible solutions. In fact, after its application, sub-

problem (S,U, F) is feasible if and only if S∪F is fea-

sible. The best solution thus generated yields the up-

per bound in the original branch and bound approach.

The following proposition extends the test with an

implicit branching operation. We remind that the sign

 represents the adjacency relation between subsets

of vertices.

Proposition 5. Given a subproblem (S,U,F), let C

be a component of C

(S ∪ F) and f a vertex of C ∩ F.

w(C)− w

∑

∈C

(U ):

{ f }

w(U

) + w

(5)

then vertex f can be assigned to S.

Finally, another implicit branching operation ﬁxes

vertices into the safe or the unsafe set, based on a

comparison with the currently best known value.

Proposition 6. Let (S,U, F) be a subproblem, f ∈ F

a free vertex and

S the best known feasible solution.

w(S) + w

≥ w(

then vertex f can be be assigned to U. If

∑

∈C

(U ):

{ f }

w(U

) + w

≥ w(

then vertex f can be be assigned to S.

Notice that moving free vertices into S can create

new safe components. This was forbidden in the orig-

inal algorithm, thus curtailing its performance. On the

contrary, the new relaxation is compatible with all the

operations listed above. Since they reduce the size of

the problem and this can eventually increase the lower

bound, adopting the weaker relaxation is not necessar-

ily disadvantageous.

Similarly, the branching mechanism of the origi-

nal approach is simpliﬁed and extended by the new

relaxation. The basic idea of the branching rule is to

select the free vertex of maximum weight (and maxi-

mum degree as a tie breaker), since moving it into ei-

ther S or U is very likely to increase the lower bound

by the maximum amount. However, such a choice in

general creates new safe components, which was pre-

viously forbidden. The branching rule was therefore

restricted to select the free vertex of maximum weight

adjacent to S or (in case none exists) the free vertex of

maximum weight adjacent to U. In sparse instances,

this restriction was particularly limiting. By contrast,

the new relaxation allows to apply the more effective

basic selection rule.

2.3 Heuristic Procedure

Proposition 4 allows to compute feasible solutions

during the exploration of the branching tree. How-

ever, the quality of these solutions can be very poor,

especially at the beginning, when the number of free

vertices is high. To overcome this issue, we can feed

the algorithm with an initial upper bound generated

by a heuristic procedure in order to amplify the effect

of the pruning.

The state-of-the-art heuristics for the WSSP are

the ones presented by Boggio Tomasaz et al. (2023b).

The most promising one is the Simple Delayed Ter-

mination (SDT). This can be explained as a sort of

Large Neighbourhood Search which ﬁrst builds a fea-

sible solution and then alternatively enlarges it with

redundant vertices and reduces it to a minimal feasi-

ble subset.

The algorithm starts with an unfeasible empty set

S =

0 and iteratively extends it with vertices in V \ S.

The choice of the vertex to insert is randomised ex-

ploiting a Restricted Candidate List (RCL) mecha-

nism that favours the vertices with many adjacent ver-

tices in V \ S. Once a feasible solution is found, in-

stead of stopping, the algorithm further enlarges S

delaying its termination for a certain number of it-

erations, proportional to the size of the instance. In

this phase, the insertion deterministically selects the

vertex of minimum weight (and maximum degree to

break ties) adjacent to S. Moreover, a destructive pro-

cedure is applied to every feasible solution S found, in

order to compute a minimal feasible solution S

⊆ S.

Starting from S

= S, the destructive heuristic consid-

ers each vertex and tries to erase it. If the resulting

set is unfeasible, the vertex is reinserted in S

; other-

wise, it remains discarded. The vertices are processed

in non-increasing order of weight (and increasing or-

der of degree as a tie breaker). The computational

complexity of the SDT heuristic is O(|V |

(|V | + |E|))

(Boggio Tomasaz et al., 2023b).

ICORES 2024 - 13th International Conference on Operations Research and Enterprise Systems

116

Since the initial phase is randomised, the heuristic

is restarted several times and returns the best feasible

solution found among all the attempts.

3 COMPUTATIONAL RESULTS

In this section we report the results obtained by the

computational experiments conducted on the revisited

branch and bound algorithm, that in the following we

will denote as RevBB. All the experiments are con-

ducted on a Linux server, with processor Intel Xeon

E5-2620 2.1 GHz and 16 GB of RAM, that is the same

machine used in Boggio Tomasaz et al. (2023a). The

algorithm is coded in C99 and compiled with GNU

GCC 8.3.0, and runs in a single thread.

The instances are the ones presented in the litera-

ture by Macambira et al. (2019) and the ones added

by Hosteins (2020) and extended in Boggio Tomasaz

et al. (2023a). They can be found at this link: https:

//homes.di.unimi.it/cordone/research/wssp.html. The

graphs are randomly generated in accordance with the

Erd

os-Renyi model. In the former set the number

of vertices progressively rises from 10 to 30 and the

number of edges is |E| = δ·|V |·(|V |−1)/2, where the

density parameter assumes values δ ∈ {0.3,0.5,0.7}.

There are weighted instances with random weights

extracted from a uniform distribution in {1,...,100}

and unweighted instances with weights uniformly set

to 1. This benchmark consists of 21 · 3 · 2 = 126 in-

stances. In the latter set, the number of vertices is

|V | ∈ {20, 25,30,35,40,50,60} and the density pa-

rameter assumes values δ ∈ {0.1,0.2,0.3,0.4}. For

each combination of |V | and δ there are 5 weighted

instances with random uniform integer weights be-

tween 1 and 10 and 5 unweighted instances, that is

7 · 4 · 5 · 2 = 280 instances overall.

3.1 Effect of the Revised Relaxation

In this section we compare the computational results

of the revisited algorithm with those reported in Bog-

gio Tomasaz et al. (2023a) for the original branch and

bound within the time limit of one hour. Tables 1

and 2 provide in the ﬁrst two columns the density δ

and the size |V | of the instances. The following four

columns show the gap (formatted as a percentage), the

number of solved instances in each group, the com-

putational time in seconds (CPU) and the number of

branching nodes (BN). Each value is averaged over

the 5 instances with the density and size indicated

in the corresponding row. The gap is computed as

(UB − LB)/LB, where UB and LB are the best upper

and lower bounds found by the algorithm. The last

four columns contain the same information for algo-

rithm RevBB. The computational times and the num-

bers of branching nodes marked with ∗ point out that

the exhaustion of memory anticipated the termination

on some instances. The symbol OM indicates that all

5 instances of a group went “out of memory”.

In the weighted case (see Table 1), the revisited al-

gorithm leaves only 2 unsolved instances out of 140,

instead of 5. One of the newly solved instances was

previously terminated because it exceeded the avail-

able memory. The two remaining unsolved instances

strictly improve both the upper and the lower bound:

the residual gap is about one third of its original value.

The computational time and the number of branch-

ing nodes is roughly halved, except for the instances

in which the memory is no longer exhausted and the

computation can proceed for a longer time.

Considering the unweighted instances (see Ta-

ble 2), the unsolved ones decrease from 21 to 16 out

of 140. The ones with an out-of-memory termination

decrease from 11 to 10. On average, the gaps of the

16 unsolved instances are more than 2 times smaller,

with the exception of the instances with δ = 0.2, for

which there is a moderate increase. In this speciﬁc

case, the weaker lower bound is not completely coun-

terbalanced by its advantages, leading to an over-

consumption of memory. The comparison between

the computational times and the number of branch-

ing nodes still shows an improvement, in particular

for the denser instances, but less pronounced than in

the weighted case. The instances with |V | = 60 and

δ ∈ {0.1, 0.2} are difﬁcult to compare from this point

of view because of the anticipated termination.

3.2 Effect of the Initial Heuristic

In this section we present the results obtained by

exploiting the SDT heuristic presented in Bog-

gio Tomasaz et al. (2023b) as an initial incumbent

for the RevBB algorithm. Tables 3 and 4 share the

same structure of Tables 1 and 2, but show the re-

sults obtained by RevBB and SDT+RevBB. Since the

RevBB algorithm solves to optimality the instances

with |V | ≤ 35 in few seconds, we do not consider

those instances in the comparison. The time limit for

SDT+RevBB is one hour, to obtain a fair comparison

with the original branch and bound. The computa-

tional time for the SDT heuristic is set to 0.1 seconds

for |V | = 40, 1 second for |V | = 50 and 10 seconds

for |V | = 60. The aim is to keep into account the

longer time required by each iteration as the size of

the instance grows, but also to slightly increase the

number of iterations, that is in the range of a few

thousands. The heuristic runs with the same parame-

A Revisited Branch and Bound Method for the Weighted Safe Set Problem

117

Table 1: Comparison between the algorithm in Boggio Tomasaz et al. (2023a) and RevBB over all weighted instances of the

benchmark.

Boggio Tomasaz et al. (2023a) RevBB

δ |V | gap solved CPU BN gap solved CPU BN

0.1 20 - 5 0.001 485 - 5 0.003 466

25 - 5 0.009 2453 - 5 0.007 1830

30 - 5 0.046 8773 - 5 0.037 6394

35 - 5 0.147 23993 - 5 0.109 16155

40 - 5 4.306 518719 - 5 2.788 299276

50 - 5 237.366 19445646 - 5 111.651 8102922

60 4.52% 4 2274.268* 133230523* - 5 1199.706 62877972

0.2 20 - 5 0.009 1570 - 5 0.004 724

25 - 5 0.138 19199 - 5 0.042 6154

30 - 5 0.803 84500 - 5 0.113 12504

35 - 5 6.127 495403 - 5 1.225 105793

40 - 5 21.879 1417253 - 5 3.997 277123

50 - 5 1072.342 49478072 - 5 307.728 14711729

60 6.94% 1 3043.631 97237260 1.82% 3 2290.738 74773767

0.3 20 - 5 0.013 1947 - 5 0.004 609

25 - 5 0.114 12616 - 5 0.040 4637

30 - 5 0.481 39254 - 5 0.218 18706

35 - 5 3.133 204212 - 5 1.084 74413

40 - 5 10.821 576087 - 5 4.898 266300

50 - 5 90.217 3195695 - 5 47.728 1665147

60 - 5 1362.553 32921438 - 5 743.674 17805962

0.4 20 - 5 0.016 2119 - 5 0.008 1152

25 - 5 0.088 8404 - 5 0.046 4509

30 - 5 0.465 32787 - 5 0.220 15963

35 - 5 2.151 119618 - 5 1.210 66598

40 - 5 4.239 181951 - 5 2.059 89991

50 - 5 50.748 1405504 - 5 27.720 773785

60 - 5 461.939 8411394 - 5 271.408 5005143

ter tuning suggested by the experiments described in

Boggio Tomasaz et al. (2023b).

With respect to the weighted problem (see Ta-

ble 3), the number of unsolved instances remains 2

out of 60, but one instance improves both the lower

and the upper bound. The improvements on the com-

putational time and the number of branching nodes

are less marked and uniform than in Table 1. In

general, they decrease, but the denser instances with

|V | = 40 and |V | = 60 show a moderate increase.

As for the unweighted problem (see Table 4), the

number of unsolved instances decreases from 16 to

15. The average gaps sharply decrease on the sparse

instances, where both the lower and the upper bounds

improve. For δ ∈ {0.1,0.2}, the computational times

and the branching nodes signiﬁcantly decrease. For

δ = 0.3, however, they decrease slightly, whereas for

δ = 0.4 they undergo a moderate increase, as in the

weighted case. In short, the heuristic initialisation

gives a useful contribution mainly on the sparser in-

stances, that are the harder ones for the exact algo-

rithm.

3.3 Comparison with the State of the

Art

Currently, the best performing exact algorithm for the

WSSP is the combinatorial branch and bound by Bog-

gio Tomasaz et al. (2023a), except for the sparsest

instances (δ = 0.3) introduced by Macambira et al.

(2019), on which the branch and cut by Malaguti and

Pedrotti (2023) requires lower computational times.

The machine used by the latter algorithm is an In-

tel i7-4790 processor running at 3.60 GHz and en-

dowed with 32 GB RAM. It is roughly comparable,

but probably faster than the one used by the branch

and bound. Table 5 reports the running times required

by the two algorithms to solve to optimality each in-

stance of this benchmark, rounded to the ﬁrst deci-

mal digit, as in Malaguti and Pedrotti (2023). The

values for |V | = 10 are missing in the original refer-

ence. Label MP denotes the branch and cut algorithm,

ICORES 2024 - 13th International Conference on Operations Research and Enterprise Systems

118

Table 2: Comparison between the algorithm in Boggio Tomasaz et al. (2023a) and RevBB over all unweighted instances of

the benchmark.

Boggio Tomasaz et al. (2023a) RevBB

δ |V | gap solved CPU BN gap solved CPU BN

0.1 20 - 5 0.020 6034 - 5 0.022 5964

25 - 5 0.042 10326 - 5 0.048 11280

30 - 5 0.189 32846 - 5 0.199 34788

35 - 5 3.943 551247 - 5 3.262 410217

40 - 5 107.544 12642269 - 5 44.817 4778665

50 57.91% 0 1716.793* OM 1.25% 4 2165.374 152910911

60 142.42% 0 1258.089* OM 68.40% 0 2193.231* OM

0.2 20 - 5 0.034 6582 - 5 0.014 2751

25 - 5 0.434 57475 - 5 0.139 18431

30 - 5 1.801 189567 - 5 0.614 67147

35 - 5 20.079 1759531 - 5 11.266 1040831

40 - 5 55.688 3775550 - 5 47.749 3390965

50 - 5 2500.817 124134933 - 5 1974.602 100802247

60 23.67% 0 3252.847* 122036862* 33.90% 0 2024.438* OM

0.3 20 - 5 0.016 2378 - 5 0.010 1604

25 - 5 0.193 22433 - 5 0.114 13614

30 - 5 1.069 90049 - 5 0.622 54952

35 - 5 6.962 488122 - 5 4.799 348552

40 - 5 29.723 1612367 - 5 14.626 837818

50 - 5 873.641 34062285 - 5 480.459 18963773

60 9.60% 0 3600.000 89662194 4.29% 0 3600.000 94802520

0.4 20 - 5 0.020 2655 - 5 0.013 1823

25 - 5 0.166 16999 - 5 0.110 12119

30 - 5 0.820 60469 - 5 0.388 30495

35 - 5 5.449 331489 - 5 2.933 180731

40 - 5 17.279 788391 - 5 5.800 270571

50 - 5 214.247 6238868 - 5 56.295 1689201

60 0.69% 4 2734.279 53504023 - 5 710.371 13912611

Table 3: Comparison between the RevBB algorithm without and with an initial heuristic solution over all the weighted

instances of the benchmark.

RevBB SDT+RevBB

δ |V |

gap solved CPU BN gap solved CPU BN

40 - 5 2.788 299276 - 5 2.549 258594

0.1 50 - 5 111.651 8102922 - 5 99.890 7073450

60 - 5 1199.706 62877972 - 5 874.839 43777463

40 - 5 3.997 277123 - 5 3.421 222507

0.2 50 - 5 307.728 14711729 - 5 249.368 11734634

60 1.82% 3 2290.738 74773767 1.07% 3 2160.774 68785511

40 - 5 4.898 266300 - 5 4.524 235375

0.3 50 - 5 47.728 1665147 - 5 45.325 1541978

60 - 5 743.674 17805962 - 5 694.451 16086338

40 - 5 2.059 89991 - 5 2.272 94113

0.4 50 - 5 27.720 773785 - 5 24.890 676289

60 - 5 271.408 5005143 - 5 320.006 5558855

SDT+RevBB the revised branch and bound initialised

with a very short run of the SDT heuristic (0.001 sec-

onds). Many of the reported times are too short to

allow a meaningful comparison (0.0 stands for val-

ues < 0.05). However, on the denser instances the

combinatorial approach conﬁrms to be order of mag-

A Revisited Branch and Bound Method for the Weighted Safe Set Problem

119

Table 4: Comparison between the RevBB algorithm without and with an initial heuristic solution over all the unweighted

instances of the benchmark.

RevBB SDT+RevBB

δ |V | gap solved CPU BN gap solved CPU BN

40 - 5 44.817 4778665 - 5 25.922 2718502

0.1 50 1.25% 4 2165.374 152910911 - 5 1342.176 100049161

60 68.40% 0 2193.231 OM 14.40% 0 3032.005 186290447*

40 - 5 47.749 3390965 - 5 24.351 1804663

0.2 50 - 5 1974.602 100802247 - 5 1234.439 65906293

60 33.90% 0 2024.438 OM 10.40% 0 3600.000 129482857

40 - 5 14.626 837818 - 5 13.193 786002

0.3 50 - 5 480.459 18963773 - 5 442.337 18425442

60 4.29% 0 3600.000 94802520 4.29% 0 3600.000 94782363

40 - 5 5.800 270571 - 5 5.236 249147

0.4 50 - 5 56.295 1689201 - 5 59.519 1827820

60 - 5 710.371 13912611 - 5 900.183 17445371

Table 5: Comparison between the branch and cut of Malaguti and Pedrotti (2023) and the RevBB algorithm initialised by the

SDT heuristic on the benchmark by Macambira et al. (2019).

Weighted Unweighted

δ = 0.3 δ = 0.5 δ = 0.7 δ = 0.3 δ = 0.5 δ = 0.7

|V | MP SDT+ MP SDT+ MP SDT+ MP SDT+ MP SDT+ MP SDT+

RevBB RevBB RevBB RevBB RevBB RevBB

10 0.0 0.0 0.0 0.0 0.0 0.0

11 0.0 0.0 0.1 0.0 1.4 0.0 0.0 0.0 0.2 0.0 19.6 0.0

12 0.0 0.0 0.1 0.0 7.3 0.0 0.0 0.0 0.1 0.0 4.3 0.0

13 0.0 0.0 0.0 0.0 1.6 0.0 0.0 0.0 0.0 0.0 27.5 0.0

14 0.0 0.0 0.1 0.0 2.7 0.0 0.0 0.0 0.2 0.0 38.8 0.0

15 0.0 0.0 0.1 0.0 2.6 0.0 0.0 0.0 0.3 0.0 10.1 0.0

16 0.0 0.0 0.2 0.0 7.2 0.0 0.0 0.0 0.8 0.0 33.1 0.0

17 0.0 0.0 0.1 0.0 4.3 0.0 0.0 0.0 1.5 0.0 455.9 0.0

18 0.0 0.0 0.5 0.0 2.8 0.0 0.0 0.0 2.6 0.0 80.7 0.0

19 0.0 0.0 0.4 0.0 5.8 0.0 0.0 0.0 0.5 0.0 24.9 0.0

20 0.0 0.0 0.2 0.0 25.4 0.0 0.0 0.0 0.8 0.0 93.3 0.0

21 0.0 0.0 0.5 0.0 9.6 0.0 0.0 0.0 0.7 0.0 140.0 0.0

22 0.0 0.0 0.1 0.0 1.9 0.0 0.0 0.0 1.0 0.0 52.1 0.0

0.1 0.0 0.7 0.0 12.0 0.0 0.0 0.0 3.7 0.0 418.1 0.0

24 0.0 0.0 1.6 0.0 7.2 0.0 0.0 0.0 0.2 0.1 311.0 0.0

25 0.1 0.0 1.2 0.0 13.3 0.0 0.1 0.1 0.5 0.1 80.7 0.1

26 0.1 0.1 1.4 0.1 58.4 0.0 0.1 0.1 6.5 0.1 878.8 0.0

27 0.1 0.1 1.6 0.1 26.6 0.1 0.0 0.1 3.6 0.1 2 416.3 0.1

28 0.0 0.0 0.4 0.1 14.7 0.0 0.1 0.2 3.6 0.2 111.2 0.0

29 0.0 0.2 0.8 0.3 65.9 0.2 0.1 0.2 11.1 0.2 2 418.2 0.5

30 0.2 0.2 0.1 0.3 46.8 0.3 0.1 0.5 11.1 0.4 439.1 0.0

nitude faster than the branch and cut. On the sparser

instances, the two approaches are now equivalent for

the weighted instances, while the branch and cut ap-

proach is still faster on the unweighted ones.

Table 6 reports the results for the benchmark in-

troduced by Hosteins (2020). For the branch and cut

algorithm, it provides the average execution time in

seconds, the average residual gap and the number of

solved instances after one hour of computation. Since

the combinatorial branch and bound solves all in-

stances within one hour, we report only the average

computational time. The SDT heuristic for the initial-

isation phase runs for 0.001 seconds on the instances

up to 35 vertices, 0.1 seconds for |V | = 40, 1 second

for |V | = 50 and 10 seconds for |V | = 60. The ra-

tionale is that the smaller instances could be solved

ICORES 2024 - 13th International Conference on Operations Research and Enterprise Systems

120

Table 6: Comparison between the branch and cut of Malaguti and Pedrotti (2023) and the RevBB algorithm initialised by the

SDT heuristic on the benchmark by Hosteins (2020).

Weighted Unweighted

MP SDT+RevBB MP SDT+RevBB

|V | δ CPU gap solved CPU CPU gap solved CPU

20 0.1 0.8 - 5 0.0 1.3 - 5 0.0

25 0.1 4.9 - 5 0.0 5.2 - 5 0.0

30 0.1 20.1 - 5 0.0 32.4 - 5 0.1

35 0.1 55.0 - 5 0.1 469.4 - 5 1.8

40 0.1 1 244.2 2.2% 4 2.5 2 976.1 19.0% 1 25.9

50 0.1 3 600.0 22.7% 0 99.9 3 600.0 37.6% 0 1 342.2

20 0.2 0.3 - 5 0.0 0.6 - 5 0.0

25 0.2 1.9 - 5 0.0 4.9 - 5 0.1

30 0.2 10.6 - 5 0.1 45.2 - 5 0.4

35 0.2 195.3 - 5 1.2 2 825.1 7.7% 2 7.1

40 0.2 1 207.8 - 5 3.4 3 116.9 29.2% 0 24.4

50 0.2 3 600.0 33.1% 0 249.4 3 600.0 45.8% 0 1 234.4

20 0.3 0.2 - 5 0.0 0.2 - 5 0.0

25 0.3 2.3 - 5 0.0 12.5 - 5 0.1

30 0.3 22.5 - 5 0.2 174.3 - 5 0.4

35 0.3 326.6 - 5 1.0 3 141.5 10.5% 1 4.2

40 0.3 2 400.3 2.1% 3 4.5 3 368.4 30.3% 0 13.2

50 0.3 3 600.0 24.1% 0 45.3 3 600.0 43.2% 0 442.3

20 0.4 0.5 - 5 0.0 1.1 - 5 0.0

25 0.4 5.1 - 5 0.0 40.8 - 5 0.1

30 0.4 34.2 - 5 0.2 256.6 - 5 0.4

35 0.4 404.6 - 5 1.2 3 486.8 9.8% 1 2.9

40 0.4 1 367.2 - 5 2.3 3 600.0 26.6% 0 5.2

50 0.4 3 600.0 17.8% 0 24.9 3 600.0 39.6% 0 59.5

very quickly even without an initialisation, whereas

the time for the larger ones is tuned so as to slightly

increase the number of iterations of the SDT heuris-

tic as the size of the instance grows. On this bench-

mark the original algorithm was already faster than

the branch and cut for all classes of instances. As dis-

cussed in the previous section, the revised algorithm

further reduces the time in most cases. Even when

the time increases, however, the comparison with the

branch and cut remains favourable to the combinato-

rial approach.

4 CONCLUSIONS

In this article we presented a revised branch and

bound algorithm for the Weighted Safe Set Problem.

Its main strength lies in a theoretically weaker, but

more versatile, relaxation, which allows to exploit a

more efﬁcient branching rule and reductions. The

new algorithm outperforms the previous one on the

vast majority of instances in the literature, solving to

optimality instances with up to 60 vertices. The use

of an existing heuristic to initialise the search is rather

useful on the largest instances (60 vertices), but hardly

necessary on the smaller ones (up to 35 vertices). On

denser instances, however, the additional effort asso-

ciated to the initialisation is not always justiﬁed. A

ﬁner tuning of this aspect, therefore, seems a promis-

ing development.

REFERENCES

Agueda, R., Cohen, N., Fujita, S., Legay, S., Manoussakis,

Y., Matsui, Y., Montero, L., Naserasr, R., Ono, H.,

Otachi, Y., Sakuma, T., Tuza, Z., and Xu, R. (2018).

Safe sets in graphs: Graph classes and structural pa-

rameters. Journal of Combinatorial Optimization,

36(4):1221–1242.

Bapat, R., Fujita, S., Legay, S., Manoussakis, Y., Matsui, Y.,

Sakuma, T., and Tuza, Z. (2016). Network majority on

tree topological network. Electronic Notes in Discrete

Mathematics, 54:79–84.

Bapat, R. B., Fujita, S., Legay, S., Manoussakis, Y., Matsui,

Y., Sakuma, T., and Tuza, Z. (2018). Safe sets, net-

work majority on weighted trees. Networks, 71(1):81–

92.

Belmonte, R., Hanaka, T., Katsikarelis, I., Lampis, M.,

Ono, H., and Otachi, Y. (2020). Parameterized com-

A Revisited Branch and Bound Method for the Weighted Safe Set Problem

121

plexity of safe set. Journal of Graph Algorithms and

Applications, 24(3):215—-245.

Boggio Tomasaz, A., Cordone, R., and Hosteins, P. (2023a).

A combinatorial branch and bound for the safe set

problem. Networks, 81(4):445–464.

Boggio Tomasaz, A., Cordone, R., and Hosteins, P.

(2023b). Constructive–destructive heuristics for the

safe set problem. Computers & Operations Research,

159:106311.

Cordone, R. and Franchi, D. (2023). The safe set problem

on particular graph classes. In Proceedings of the 19th

Cologne-Twente Workshop on Graphs and Combina-

torial Optimization (CTW), Garmisch-Partenkirchen,

Germany.

Ehard, S. and Rautenbach, D. (2020). Approximating con-

nected safe sets in weighted trees. Discrete Applied

Mathematics, 281:216–223.

Fujita, S., MacGillivray, G., and Sakuma, T. (2014). Bor-

deaux graph workshop: Safe set problem on graphs.

https://bgw.labri.fr/2014/bgw2014-booklet.pdf.

Fujita, S., MacGillivray, G., and Sakuma, T. (2016). Safe

set problem on graphs. Discrete Applied Mathematics,

215:106–111.

Hosteins, P. (2020). A compact mixed integer linear for-

mulation for safe set problems. Optimization Letters,

14(8):2127–2148.

Macambira, A. F. U., Simonetti, L., Barbalho, H., Silva, P.

H. G., and Maculan, N. (2019). A new formulation

for the safe set problem on graphs. Computers and

Operations Research, 111:346–356.

Malaguti, E. and Pedrotti, V. (2023). Models and algorithms

for the weighted safe set problem. Discrete Applied

Mathematics, 329:23–34.

ICORES 2024 - 13th International Conference on Operations Research and Enterprise Systems

122
