Instance Segmentation of Event Camera Streams

in Outdoor Monitoring Scenarios

Tobias Bolten

1 a

, Regina Pohle-Fröhlich

1 b

and Klaus D. Tönnies

Institute for Pattern Recognition, Hochschule Niederrhein, Krefeld, Germany

Department of Simulation and Graphics, University of Magdeburg, Germany

Keywords:

Dynamic Vision Sensor, Instance Segmentation, Outdoor Environment.

Abstract:

Event cameras are a new type of image sensor. The pixels of these sensors operate independently and asyn-

chronously from each other. The sensor output is a variable rate data stream that spatio-temporally encodes

the detection of brightness changes. This type of output and sensor operating paradigm poses processing chal-

lenges for computer vision applications, as frame-based methods are not natively applicable.

We provide the ﬁrst systematic evaluation of different state-of-the-art deep learning based instance segmenta-

tion approaches in the context of event-based outdoor surveillance. For processing, we consider transforming

the event output stream into representations of different dimensionalities, including point-, voxel-, and frame-

based variants. We introduce a new dataset variant that provides annotations at the level of instances per output

event, as well as a density-based preprocessing to generate regions of interest (RoI). The achieved instance

segmentation results show that the adaptation of existing algorithms for the event-based domain is a promising

approach.

1 INTRODUCTION

Event cameras, also known as Dynamic Vision Sen-

sors (DVS) or silicon retinas, are a new type of im-

age sensor. Unlike conventional frame-based im-

age sensors, they operate completely asynchronously

and independently per pixel. Following the biolog-

ically inspired ideas of neuromorphic engineering,

only changes in brightness per pixel are detected and

directly transmitted. The result is not a classical video

frame captured at a ﬁxed sampling frequency, but an

output stream of variable data rate depending on the

changes in the scene.

Each detected change in brightness above a de-

ﬁned threshold value results in a so-called output

event and is transmitted immediately. For each out-

put event, (a) its spatial (x, y)-position in the sensor

array, (b) a very precise timestamp t of the triggering,

and (c) the polarity p of the change (bright to dark

and vice versa) are encoded. The technical operating

paradigm of these sensors allows recordings with high

temporal resolution and low data redundancy, while

simultaneously offering a very high dynamic range.

https://orcid.org/0000-0001-5504-8472

https://orcid.org/0000-0002-4655-6851

These are very important and advantageous factors for

outdoor applications.

However, the sparse, unordered, and asyn-

chronous output of these sensors poses challenges for

processing in terms of classical computer vision ap-

proaches. In this work, we investigate the task of in-

stance segmentation on event-based data in the con-

text of outdoor surveillance recordings in order to

gain deeper insight into the usage of the monitored

areas. Additional challenges arise from unconstrained

real-world factors, small object sizes, and occlusions.

In summary, we contribute the ﬁrst systematic evalu-

ation of state-of-the-art deep learning approaches for

instance segmentation, including different event en-

codings, to assess their suitability under these condi-

tions.

The rest of this paper is structured as follows. Sec-

tion 1.1 summarizes related work. Event data rep-

resentations and instance segmentation networks are

brieﬂy described in Section 2. The datasets used and

the preprocessing are introduced in Section 3. The

results of the evaluation are discussed in Section 4.

Supplemental material is available for download

http://dnt.kr.hsnr.de/DVS-InstSeg/

452

Bolten, T., Pohle-Fröhlich, R. and Tönnies, K.

Instance Segmentation of Event Camera Streams in Outdoor Monitoring Scenarios.

DOI: 10.5220/0012369100003660

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2024) - Volume 3: VISAPP, pages

452-463

ISBN: 978-989-758-679-8; ISSN: 2184-4321

1.1 Related Work

Segmentation is an important part of computer vision

and is needed for a variety of tasks in scene under-

standing. Event-based research in this area is not as

extensive as its frame-based counterpart. This is due

to the novelty of the sensor technology itself.

Frame-Based Processing. The development of

methods for traditional 2D frame-based pro-

cessing is more advanced. Libraries such as

Detectron2 (Wu et al., 2019b) are available,

providing state-of-the-art recognition and seg-

mentation algorithms as well as pre-trained

models. Basically, two different approaches

can be distinguished here. In proposal-based

approaches, objects are ﬁrst detected using

bounding box techniques and then segmented. A

well-known example of this is Mask R-CNN (He

et al., 2017).

On the other hand, the well-known YOLO fam-

ily (Redmon et al., 2016; Jocher et al., 2023) di-

rectly predicts bounding boxes and class proba-

bilities for objects in a single pass. Along with

the use of pixel-level grouping or clustering tech-

niques to form instances, such as (Xie et al., 2020;

Xie et al., 2022; Wang et al., 2020), this provides

proposal-free methods.

3D-Based Processing. The output stream from event

cameras can also be interpreted as a three-

dimensional (x, y, t) cloud. Therefore, instead of

using (x, y, z) point clouds, 3D-based instance seg-

mentation methods are also of interest in this con-

text. Basically, 3D methods can also be distin-

guished into proposal-based and proposal-free ap-

proaches. The former decompose the segmenta-

tion problem into two sub-challenges: Detecting

objects in 3D and reﬁning the ﬁnal object masks

(Yang et al., 2019; Engelmann et al., 2020). The

latter typically omit the detection part and try to

obtain instances by clustering after semantic seg-

mentation (e.g., following the assumption that in-

stances should have similar features) (Zhao and

Tao, 2020; Jiang et al., 2020; Chen et al., 2021).

Typically, the processing here is point-based or

voxel-based.

Event-Based Processing. Event clustering can be

used to separate objects in simple scenes that typ-

ically do not include sensor ego-motion due to

the event camera operating principle (Schraml and

Belbachir, 2010; Rodríguez-Gomez et al., 2020).

For more complex and unstructured scenes, clus-

tering approaches also exist (Pi ˛atkowska et al.,

2012).

In (Barranco et al., 2015), the scene is decom-

posed based on categorized object contours to

achieve layer segmentation. In contrast, (Stof-

fregen and Kleeman, 2018) segments the scene

into structures that move at the same velocity.

Generally, event-based motion segmentation ap-

proaches can be used to distinguish objects by as-

signing events to objects with independent motion

(Vasco et al., 2017; Mitrokhin et al., 2018; Stof-

fregen et al., 2019; Mitrokhin et al., 2020; Zhou

et al., 2021). However, these approaches have in

common that no semantic class categorization is

performed for the detected objects.

Semantic segmentation ﬁlls this shortcoming.

EvNet (Sekikawa et al., 2019) is an asynchronous,

fully event-based approach for this purpose.

(Biswas et al., 2022) exploits features extracted

from the event stream and simultaneously ac-

quired grayscale images, while event-only pro-

cessing is considered as part of the ablation study.

Approaches that rely solely on the event stream

to derive a semantic segmentation are given in

(Bolten et al., 2022; Bolten et al., 2023b). Here,

the processing is done based on point cloud or

voxel grid representations, with well-known net-

work structures like PointNet++ (Qi et al., 2017)

or UNet (Ronneberger et al., 2015). However,

most semantic segmentation approaches convert

the event stream into dense frame representations,

such as (Alonso and Murillo, 2019; Sun et al.,

2022; Wang et al., 2021). Nevertheless, it is im-

possible to differentiate between spatially close or

even occluded objects of the same class that are

moving at nearly the same speed by motion or se-

mantic segmentation. This is particularly relevant

in the context of monitoring applications, such as

a group of people.

The resulting challenge of instance segmenta-

tion has been largely unaddressed for event-based

data. In the context of robotic grasping, there

are ﬁrst works towards this direction, fusing the

modality of RGB frames with events (Kachole

et al., 2023b), or deriving a panoptic segmenta-

tion by applying graph-based network processing

(Kachole et al., 2023a).

To the best of the authors’ knowledge, there is cur-

rently no prior work that adapts, applies, and evalu-

ates off-the-shelf 2D frame or 3D-based instance seg-

mentation approaches to the event-based vision do-

main. However, this represents a promising way to

achieve instance segmentation in this domain.

Instance Segmentation of Event Camera Streams in Outdoor Monitoring Scenarios

453

(x,y,t) Event-Stream

xy-plane projectionsparse "bag of events" discretized grid

Space-Time Event Cloud

Voxelization

2D Frame

(a) Event data representations

Semantic Segmentation

Spatial Clustering

(b) Baseline Method

clustering

based

proposal

based

JSNet

3D-BoNet

combination of

clustering + proposal

SoftGroup

(d) Voxel-based Method

proposal

based

proposal

free

Mask R-CNN

YOLO v8

(e) Frame-based Methods

Figure 1: Overview of performed experiments.

2 PROPOSED METHODS

In the following, we introduce different encodings

used for event stream representations in this study. In

addition, we brieﬂy outline the deep learning frame-

works used for instance segmentation.

2.1 Event Data Representations

Commonly, the event data stream from Dynamic Vi-

sion Sensors is converted into alternative representa-

tions for processing. In this work we consider the con-

struction of 3D point clouds, also called space-time

event clouds, their voxelization and conversion into

classical 2D frames for subsequent processing (see

Figure 1a).

Space-Time Event Cloud. A temporal window of

the continuous event stream directly forms an un-

ordered point cloud, where each 3D point repre-

sents an event deﬁned by its (x, y, t) coordinates.

This preserves the sparsity and high temporal res-

olution of the signal and transforms it into a geo-

metric description.

3D Voxel-Grid. The irregularity of the event clouds

can be removed by voxelization and transformed

into a regular 3D grid. The voxels encode the

distribution of events within the spatio-temporal

domain. The sparsity of the signal is lost in this

transformation. The size of the voxel bins must

be chosen application speciﬁc.

2D Frame Projection. Classic 2D frames are cre-

ated by projecting events onto the xy plane. This

results in a dense 2D grid of ﬁxed size deﬁned by

the pixel resolution of the sensor. It allows direct

processing using classical computer vision ap-

proaches. Since events are triggered by changes,

the resulting images visually resemble edge im-

ages.

There are a variety of encodings described in the

literature for this projection step. In this study, we

consider the following two variants:

Polarity. Each frame pixel is deﬁned by the po-

larity of the last event that occurred at the cor-

responding (x, y) pixel position. The polarity

is directly encoded in the single color values

red for decrease, green for increase in bright-

ness (see Figure 2a).

Merged-Three-Channel (MTC). This encoding

was proposed by Chen et al. in (Chen et al.,

2019). It incorporates three different single-

channel encodings, each addressing different

attributes of the underlying event stream, to

create an RGB false color image (see Fig-

ure 2b):

Red Channel. Leaky-Integrate-And-Fire neu-

ron model to preserve information about

temporal continuity,

Green Channel. Surface-Of-Active-Events as

a time surface containing information

about the direction and speed of object mo-

tion through its gradient, and

Blue Channel. Triggering Frequency to dis-

tinguish between noise and valid events.

These encodings are selected because they repre-

sent different levels of preserved information.

2.2 Instance Segmentation Networks

2.2.1 Point Cloud-Based Processing Methods

(Figure 1c)

JSNet (Zhao and Tao, 2020) (2020): clustering-

based processing

JSNet consists of four main components: a shared

feature encoder, two parallel branch decoders,

feature fusion modules for each decoder, and a

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

454

(a) Polarity encoding

(b) MTC encoding

Figure 2: Snippets of frame encoded events (best viewed in

color).

joint instance and semantic segmentation (JISS)

module. High-level semantic features are learned

by PointNet++ (Qi et al., 2017) and PointConv

(Wu et al., 2019a) architectures and are further

combined with low-level features for more dis-

criminative values. The JISS module transforms

the semantic features into an instance embedding

space, where instances are formed by applying a

simple mean-shift clustering.

3D-BoNet (Yang et al., 2019) (2019): proposal-

based processing

3D-BoNet is designed for a single-stage, anchor-

free instance segmentation in 3D point clouds. It

uses a PointNet++ (Qi et al., 2017) backbone to

extract local and global features, followed by two

branches: one for instance-level bounding box

prediction and another for point-level mask pre-

diction. The bounding box prediction branch is

a key component, generating unique, unoriented

rectangular bounding boxes without predeﬁned

spatial anchors or region proposals. The subse-

quent point-mask prediction branch uses these

boxes and features to generate point-level binary

masks for valid instances, distinguishing them

from the background.

2.2.2 Voxel-Based Processing Method

(Figure 1d)

SoftGroup (Vu et al., 2022) (2022): clustering and

proposal-based

SoftGroup attempts to combine the strengths

of proposal-based and grouping-based methods

while addressing their limitations. First, a bottom-

up stage uses a pointwise prediction network to

generate high-quality object proposals by group-

ing based on soft semantic scores. This stage in-

volves processing point clouds to generate seman-

tic labels and offset vectors, which are then re-

ﬁned into preliminary instance proposals using a

soft grouping module. Second, the top-down re-

ﬁnement stage reﬁnes the generated proposals by

extracting corresponding features from the back-

bone. These features are employed to predict ﬁ-

nal results, including classes, instance masks, and

mask scores.

2.2.3 Frame-Based Processing Methods

(Figure 1e)

Mask R-CNN (He et al., 2017) (2017): proposal-

based processing

Proposal-based processing is considered to be

the baseline technique for frame-based instance

segmentation (Sharma et al., 2022). Therefore,

we included Mask R-CNN in our experiments.

Mask R-CNN consists of ﬁve key components.

First, a backbone network for feature extraction,

followed by a Region Proposal Network that gen-

erates potential object proposals. The RoIAlign

layer ensures accurate spatial alignment for RoIs.

The RoI head contains two sub-networks: one for

classiﬁcation and bounding box regression, and

another for instance mask prediction. This ar-

chitecture enables object detection, classiﬁcation,

bounding box reﬁnement with detailed instance

masks predictions.

YOLO v8 (Jocher et al., 2023) (2023): proposal-

free processing

YOLO v8 is the latest version of the popular

single shot detection method and aims to improve

accuracy and efﬁciency over previous versions. A

major change is that YOLO v8 is an anchor-free

model, meaning that object centers are predicted

directly instead of the offset from a known anchor

box. This typically results in fewer predictions

and better, faster non-maximum suppression.

3 DATASETS & PREPROCESSING

Compared to the more established domain of image-

based computer vision, the range of event-based

datasets is currently limited. In the following, we de-

scribe the datasets used in our experiments and the

preprocessing steps applied.

3.1 Datasets

Annotations at the level of semantic or even instance

segmentation are only available for a few event-based

datasets. For an example in autonomous driving ap-

plications see (Alonso and Murillo, 2019; Sun et al.,

Instance Segmentation of Event Camera Streams in Outdoor Monitoring Scenarios

455

Figure 3: DVS-iOUTLAB dataset example scene (a 60 ms

time window with 95,726 events is displayed as a 3D space-

time event cloud and as a projected 2D label frame, with

ground truth classes represented by colors and instances by

bounding boxes).

2022). In the context of the monitoring scenario con-

sidered in this paper, the following datasets are rele-

vant.

DVS-iOUTLAB. Multi-Instance DVS-OUTLAB

(Bolten et al., 2021)

The DVS-OUTLAB dataset contains recordings

from a multi-DVS-based monitoring scenario

of an urban public children’s playground. The

authors provide several thousand semantically

labeled patches of event data, as well as multiple

hours of unlabeled raw material recorded during

the process of creating the dataset. We applied a

semantic segmentation based on PointNet++ (Qi

et al., 2017) and the publicly available pre-trained

weights from (Bolten et al., 2022) to these

unprocessed, complete recordings.

Based on the originally provided labels and fur-

ther semantic segmentation, we manually selected

and checked object instances. Thus, we extracted

52,293 PERSON, 3,649 DOG, 7,024 BICYCLE, and

3,134 SPORTSBALL instances. From this pool, we

randomly selected instances and artiﬁcially popu-

lated new challenging scenes that directly contain

instance annotations. We allowed spatially close

objects and prevented real occlusions based on the

convex hull of the objects. In this process, we cre-

ated 10,000 scenes, divided into 8,000 for training

and 1,000 each for test and validation. Each scene

contains a minimum of three objects and a max-

imum of 32 objects with 3-24 persons (average

8.76) and up to 2 dogs, 4 bicycles and 2 sportballs.

A sample scene of the newly created

DVS-iOUTLAB dataset is shown in Fig-

ure 3. This dataset composes challenges from

a multi-class, multi-instance scenario combined

with real sensor noise.

N-MuPeTS. Multi-Person Tracking and Segmenta-

tion (Bolten et al., 2023a)

The N-MuPeTS dataset contains ≈ 85 minutes of

time-continuous labeled event data, recorded for

multi-person tracking and segmentation applica-

tions. The authors provide annotations at the

level of instance segmentation for four recorded

individuals, as well as annotations describing the

overall scene quality (judging included artifacts

or label quality). In addition, the activity (e.g.,

WALKING, RUNNING, or CROSSING, . . .) is labeled

separately for each included individual on a 25 ms

time window basis.

Although the dataset contains only the single ob-

ject class PERSON, the processing is still challeng-

ing due to object occlusions (with infrastructure

and other people), similar body shapes, different

body poses, and different movement/interaction

patterns. Scenes with spatially close objects (such

as intersections) are particularly challenging. In

addition, there is sensor noise in the data. Fig-

ure 4a shows an example of a scene from this

dataset.

Since the dataset’s authors haven’t published a

dataset split, we propose the following: the ba-

sis for training and evaluation are all recordings

of the best quality level, except for time win-

dows in which at least one person was stand-

ing (dataset annotations KNEELING, STOOPED or

STANDING). This leads to the exclusion of ≈ 7.6

minutes of recording and is therefore negligible.

This is necessary for segmentation applications,

as standing persons are indistinguishable from

background noise in the DVS signal. The remain-

ing recordings were divided into consecutive 10

second segments. Based on these segments, the

data was divided into training, validation, and test

sets. This windowing of the data was done in

order to achieve a higher variability between the

splits compared to randomly sampled time win-

dows of a few milliseconds.

By selecting a 60/20/20 % split of these time

blocks, care was also taken to ensure that the re-

maining activity annotations of the dataset were

approximately equally represented in the respec-

tive splits. The supplement to this paper provides

a detailed overview of the resulting distribution of

annotations per split.

The newly derived DVS-iOUTLAB dataset and the

detailed split of N-MuPeTS based on the dataset ﬁles

are available for download

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

456

3.2 Preprocessing

3.2.1 Spatio-Temporal Filtering

Event cameras, like all image sensors, are subject to

noise. A major form of noise are background activ-

ity (BA) events, which occur when the event camera

triggers an output without a corresponding change in

brightness in the scene. The CeleX-IV sensor (Guo

et al., 2017) used to acquire the selected datasets has

a high level of background activity noise, as can be

seen in Figures 3, 4a. These BA events also prevent

the effective use of simple clustering approaches to

segment objects.

Spatio-temporal ﬁlters are often used in prepro-

cessing to improve the signal-to-noise ratio (SNR) of

event data. Following the analysis of different spatio-

temporal ﬁlters in (Bolten et al., 2021), we also apply

time-ﬁltering in the ﬁrst processing stage. Each event

that is not supported by another event at the same

(x, y)-position within the preceding ∆ t ms is removed.

3.2.2 Adaptive Region-of-Interest Extraction

(aRoI)

According to the function paradigm of event cameras,

scene separation into foreground and background for

moving objects and a static sensor is already done at

the sensor level. However, a straightforward selection

of events triggered by object motion is often not pos-

sible due to high noise levels. Therefore, to separate

and select dense regions of events for further process-

ing, we propose the following size-adaptive Region-

of-Interest algorithm:

1. Extended spatio-temporal ﬁltering

First, we apply a spatio-temporal ﬁltering stage

based on the Neighborhood-Filter from (Bolten

et al., 2021). This ﬁlter evaluates for each event

a minimum threshold of other supporting events

in the spatial 8-connected neighborhood. We fol-

low the parameterization given and evaluated in

(Bolten et al., 2021) for this ﬁlter. Their ﬁl-

ter achieves an almost complete removal of BA

events at the cost of events from instances. This

processing step is shown in Figures 4b → 4c.

2. Hierarchical single-linkage clustering (Müllner,

2013)

The remaining events are hierarchically clustered

into regions based on the Euclidean distance of

the events. Clustering is controlled by a prede-

ﬁned cutoff distance (d

cut

) that prevents spatially

distant clusters from merging. Resulting clusters

with a number of events less than min

#events

are

discarded in this step. An example for this step is

displayed in Figure 4d.

(a) Example scene from N-MuPeTS dataset (55,072

events)

(b) Time-ﬁltered, ∆ t=10 ms

(32,414 events)

(3,237 events)

(d) Performed clustering

(2 segments resulting)

(e) Extracted aRoIs

(765+3,820 = 4,585 events)

Figure 4: Adaptive ROI selection (given event counts refer

to complete, uncropped scene).

3. Bounding Box expansion and ﬁlter reset

In order to account for the events of objects that

may have been ﬁltered (cf. the feet of the red ac-

tor in Figure 4), the bounding box of each cluster

is expanded by bbox

offset

pixels. Within each ex-

panded bounding box, the event stream is reset to

the original time-ﬁltered event stream, reactivat-

ing the events removed by the second restrictive

ﬁltering step. Each resulting bounding box forms

a Region-of-Interest. This is shown in Figure 4e.

This processing results in Regions-of-Interest of vari-

able spatial size, where spatially separated objects are

in their own aRoI and groups of objects share a aRoI

without being sliced.

4 EXPERIMENTS

Next, we describe the methodology and results of

our comparative evaluation of the methods presented

in Section 2.2. All event representations are based

on 60 ms sliding time windows of the data. The

Instance Segmentation of Event Camera Streams in Outdoor Monitoring Scenarios

457

Table 1: Object instance statistics.

annotation

max(

dist(NN

inst

))

avg(

#Pixel

inst

)

(a) DVS-iOUTLAB

PERSON ≈ 23.09 px 332.28 px

DOG ≈ 16.49 px 360.31 px

BICYCLE ≈ 21.59 px 450.28 px

SPORTSBALL ≈ 5.39 px 116.05 px

(b) N-MuPeTS

PERSON ≈ 22.14 px 511.80 px

conﬁguration for the performed preprocessing is as

follows: spatio-temporal pre-ﬁltering with threshold

∆ t=10 ms, Region-of-Interest generation with d

cut

29.0px, min

#events

= 50 events, bbox

offset

= 10px.

4.1 Network Conﬁgurations

Network conﬁgurations and hyperparameters have

been left at their default values where possible. The

detailed conﬁgurations of the neural networks are

given in the supplemental material in the format of

the corresponding reference implementations (see the

URLs given in the bibliography entries).

4.2 Inputs and Parameters

For point- and voxel-based methods, the temporal

scaling of the input data is of particular interest, as it

has a signiﬁcant impact on the computation of spatio-

temporal distances and neighborhoods. We represent

the time information scaled in milliseconds.

Point-Based Processing. As mentioned above,

space-time event clouds form naturally from the

(x, y, t) coordinates of the events themselves.

However, while the spatial shape of the input

event cloud can vary, and therefore the generated

aRoI can be used directly as a basis, the deep

learning processing techniques require a ﬁxed

number of events as input for training.

Therefore, the event clouds are sampled to a ﬁxed

number of events by random choice. The sizes

of 1024 and 2048 events per aRoI serve as sam-

pling targets, since these powers of two are closest

to the mean event counts of the generated aRoIs

(more detailed event count statistics are given in

the supplement). For aRoIs with fewer events,

doublets are generated to achieve the desired num-

ber, following the original logic of PointNet++

processing that forms the basis of the point-based

methods under study.

The selected grouping radii and the conﬁguration

of the point abstraction layers of the networks de-

ﬁned by the provided model ﬁles are adapted from

(Bolten et al., 2022).

Voxel-Based Processing. The data shape is deﬁned

by the voxel grid size and not by the number of

events. Therefore, there is no subsampling per

aRoI performed. Instead, the time-ﬁltered aRoIs

are used directly as input.

We discretize the data per sensor pixel over a time

interval of 1 ms per voxel, as this setting has al-

ready shown good results for semantic segmenta-

tion (Bolten et al., 2023b).

Frame-Based Processing. The color frame encod-

ings are built using the full spatial sensor reso-

lution of 768 × 640 pixels (Guo et al., 2017) and

complete 60 ms window, as the frame-based pro-

cessing requires a ﬁxed input resolution.

4.3 Segmentation Baseline: Semantic

Clustering

As a basic approach for comparison, we propose to

utilize a hierarchical event clustering, extended by ap-

plying a prior semantic segmentation. This is shown

in Figure 1b.

For this semantic segmentation step, we trained

vanilla PointNets++ (Qi et al., 2017) following

(Bolten et al., 2022) using the aRoIs as input. Clus-

tering is applied separately to the events of each se-

mantic class based on the predicted labels to group

the predictions into individual instances.

The clustering cutoff distance d

cut

in this step

is individually selected per semantic class based on

the maximum Euclidean distance between nearest

neighbor pixels within the ground truth instances (see

dist(NN

inst

) in Table 1). This selection ensures that

all events of a single instance are grouped together by

this baseline approach.

4.4 Metrics

Some approaches rely on prior semantic segmenta-

tion. Therefore, we also report metrics for the quality

of the semantic segmentation. For this, we report the

F1 score, deﬁned as the harmonic mean of precision

and recall, as a weighted average using the given sup-

port per class on a per DVS event basis.

Regarding the instance segmentation quality, we

report the standard COCO metrics, including mean

average precision mAP

0.95

0.5

, which is the precision av-

eraged over the intersection over union (IoU) thresh-

old range from 0.5 to 0.95 with a step size of 0.05, as

well as the mAP

0.5

and mAP

0.75

at ﬁxed IoU values.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

458

For reproducibility, we rely on the metric implemen-

tations from (Detlefsen et al., 2022) for all reported

results. IoUs are calculated based on segmentation

masks rather than bounding boxes. For comparabil-

ity between the different methods, these masks are

formed and evaluated in 2D.

The evaluation is based on the events included in

the constructed aRoIs. Since the spatial shape can

vary between the different encoding variations (aRoI

size vs. ﬁxed and full frame resolution), only the ar-

eas covered by the aRoIs are considered for frames

and included in the metric calculation.

4.5 Application Results

The evaluation was performed on datasets that orig-

inate from the application scenario of a DVS-based

monitoring. The scenes considered therefore contain

the typical application-oriented core challenges, such

as occlusions and spatially close objects. The results

focus on these challenges.

Table 3 shows the metric results for the

DVS-iOUTLAB dataset. For the N-MuPeTS dataset,

we report in Table 4 the results on an intentionally

challenging subset of the test data. This test subset

restricts the scenes to a selection in which at least one

actor is occluded or they are spatially very close to

each other. Details on this subset selection, as well as

results on the full test set, are reported in the supple-

ment.

Segmentation Baseline. The segmentation baseline

depends on the quality of the semantic segmen-

tation performed. It achieves very good F1 scores

on both datasets. As expected, it often fails with

merge errors because instances of same classes

that are very close to each other are clustered to-

gether. This is especially true for the selected

challenging test subset of the N-MuPeTS dataset.

It can be clearly seen in the metric difference of

this approach between the two datasets.

Point-Based Processing. Segmentation tends to fail

when an aRoI is signiﬁcantly larger than average.

These regions occur when many objects are spa-

tially very close to each other, so that they are

clustered into a single input aRoI. The unsam-

pled event count in these regions deviates strongly

from the overall mean, so that the applied ran-

dom event selection changes the spatio-temporal

object densities and event neighborhoods substan-

tially. For these error-prone aRoIs, JSNet-based

processing mostly leads to interpretation as BA

event noise, while 3D-BoNet predicts better se-

mantic values, but often proposes very large and

merged object instance boundaries.

Table 2: Number of network parameters for DVS-

iOUTLAB network conﬁguration.

Network #Parameters

Baseline PointNet++ 441,893

JSNet 8,098,321

3D-BoNet 1,824,582

SoftGroup 30.836.090

Mask R-CNN 44,679,088

YOLO v8 3,264,396

A simple post-processing of the obtained results

seemed useful, since small errors in semantic seg-

mentation often propagate in the form of small

instances. We recommend to make sure that in-

stances consisting of only a few events are re-

moved and ignored before further processing.

Voxel-Based Processing. SoftGroup achieves very

good results on DVS-iOUTLAB dataset which in-

cludes spatially close but not intersecting objects.

Considering scenes containing occlusions of ob-

jects of the same semantic class (as in N-MuPeTS,

which are considered to be particularly difﬁcult),

it can be observed that instances often merge in

these cases.

Looking at the mAP

0.5

value, the best overall re-

sult is obtained for DVS-iOUTLAB, while the

value for N-MuPeTS is behind all other high-level

approaches. This indicates a need for further op-

timization of the hyperparameters used, such as

voxel size and grouping radius.

Frame-Based Processing. The IoU thresholding

performed for mAP calculation is more difﬁcult

for frame-based mask predictions. The low spa-

tial resolution of the DVS sensor (the used sensor

provides 768 × 640 px) leads to small object

sizes, as shown in Table 1. The avg(#Pixel

inst

)

value indicates the average projected object pixel

size per instance in each dataset. Even a few

mismatching pixels in the predicted masks will

signiﬁcantly lower the IoU score. Comparing the

mAP

0.95

0.5

and mAP

0.5

(improvements up to ≈40%)

shows that the segmentation works well, but is

limited by the predicted pixel mask accuracy.

When detecting and separating occluded objects

of the same semantic class, the selected Mask R-

CNN tends to predict a mask containing only one

object in these cases. YOLO v8 predicts better

partial masks at the expense of multiple false pre-

dictions.

Figure 5 shows example segmentations in the form of

false-color images for the N-MuPeTS dataset (corre-

sponding examples for DVS-iOUTLAB are given in

the supplement). These images highlight the typical

worst-case errors.

Instance Segmentation of Event Camera Streams in Outdoor Monitoring Scenarios

459

Table 3: Segmentation results on DVS-iOUTLAB test set (60 ms event time window).

Semantic Quality Instance Quality

Network Conﬁguration weighted F1-score mIoU

mAP

0.95

0.5

mAP

0.5

mAP

0.75

(a) Baseline method: PointNet++ with spatial clustering

PointNet++

2048 events

0.94 0.80 0.57 0.71 0.62

Clustering

1024 events

0.93 0.82 0.58 0.71 0.61

(b) Space-Time Event Cloud-based methods

JSNet

4 layers

in 2048 events

0.95 0.89 0.81 0.87 0.86

4 layers

in 1024 events

0.92 0.85 0.70 0.77 0.75

3D-BoNet

4 layers

in 2048 events

0.94 0.84 0.71 0.81 0.78

4 layers

in 1024 events

0.93 0.83 0.70 0.80 0.76

SoftGroup

voxel grid

(768 × 640 × 60)

0.97 0.86 0.88 0.98 0.96

(d) Frame-based methods

Mask R-CNN

polarity

in (768 × 640) px

0.92 0.78 0.62 0.96 0.72

MTC

in (768 × 640) px

0.92 0.78 0.61 0.96 0.71

YOLO v8

polarity

in (768 × 640) px

0.92 0.79 0.60 0.93 0.66

MTC

in (768 × 640) px

0.91 0.80 0.58 0.89 0.65

Table 4: Segmentation results on challenging sequences of N-MuPeTS test subset (60 ms event time window).

Semantic Quality

weighted F1-score PERSON Instance Quality

Network Conﬁguration NOISE PERSON mIoU

0.95

0.5

0.75

(a) Baseline method: PointNet++ with spatial clustering

PointNet++

2048 events

0.91 0.95 0.74 0.25 0.42 0.25

Clustering

1024 events

0.91 0.95 0.74 0.25 0.41 0.24

(b) Space-Time Event Cloud-based methods

JSNet

4 layers

in 2048 events

0.92 0.95 0.82 0.54 0.79 0.57

4 layers

in 1024 events

0.91 0.94 0.80 0.46 0.70 0.48

3D-BoNet

4 layers

in 2048 events

0.91 0.95 0.80 0.56 0.77 0.59

4 layers

in 1024 events

0.89 0.93 0.75 0.42 0.62 0.44

SoftGroup

voxel grid

(768 × 640 × 60)

0.84 0.92 0.83 0.55 0.70 0.57

(d) Frame-based methods

Mask R-CNN

polarity

in (768 × 640) px

0.80 0.89 0.72 0.41 0.80 0.41

MTC

in (768 × 640) px

0.80 0.89 0.72 0.42 0.80 0.43

YOLO v8

polarity

in (768 × 640) px

0.83 0.92 0.70 0.55 0.87 0.61

MTC

in (768 × 640) px

0.83 0.92 0.70 0.54 0.86 0.60

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

460

(a) Baseline

(merge: spatial close)

(b) JSNet

(merge: spatial expansion)

(d) SoftGroup

(merge: spatial close)

(e) Mask R-CNN

(miss at occlusions)

(f) YOLO v8

(split: object parts)

Figure 5: Typical prediction error cases on N-MuPeTS displayed as false-color aRoI-montage images (best viewed in color

and digital zoomed).

The proposed event representations and corre-

sponding off-the-shelf processing approaches can ef-

fectively be used to derive an instance segmenta-

tion. From a practical point of view, the proposal-

based point and voxel-based approaches require tem-

poral normalization in addition to temporal scaling for

training convergence. Our recommendation is to shift

the continuous event time stamps for each input aRoI

between zero and the selected sliding time window

length.

The point-based approaches are inspired and built

on PointNet++ as a backbone. By sharing the MLPs

per point, relatively small network structures are built

(see Table 2). This feature may be important when

aiming for a sensor-near implementation where hard-

ware resources are limited.

By using a submanifold sparse convolution (Gra-

ham et al., 2018), the voxel-based processing provides

good results and can offer a good trade-off in terms of

processing complexity. For applications where small

compromises in pixel accuracy of segmentation are

acceptable, classical frame-based processing seems to

be a good starting point, while offering a wide range

of well-established frameworks for processing.

5 CONCLUSION

We have performed a systematic evaluation of in-

stance segmentation approaches on data from the do-

main of event-based vision. We included multiple

state-of-the-art instance segmentation approaches that

are based on deep learning, while at the same time

considering event representations with varying de-

grees of dimensionality. Overall, very good results

can be obtained by using these off-the-shelf process-

ing approaches.

While the evaluation is scenario speciﬁc, the pro-

posed encoding and processing combinations can eas-

ily be adopted to other applications. Real-world

event-based vision projects are still uncommon. Us-

ing standard processing approaches is an appropriate

way to change this.

One aspect of further work is a detailed study

of the hyperparameters of the networks to ﬁne-tune

the possible results. Examples include non-maximum

suppression for the frame-based approaches, or

grouping radii in point or voxel-based approaches to

improve the processing of very close and occluding

objects. For future practical applications, it is im-

portant to consider environmental effects such as rain.

These exist in the real world beyond the dimensions

contained in the datasets.

ACKNOWLEDGEMENTS

We thank Laureen Klein for her preparatory work in

creating the DVS-iOUTLAB dataset. We thank Noel

Hanraths Pereira for his collaboration on the YOLO

experiments.

REFERENCES

Alonso, I. and Murillo, A. C. (2019). EV-SegNet: Seman-

tic Segmentation for Event-Based Cameras. In 2019

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition Workshops (CVPRW), pages 1624–

1633. IEEE.

Barranco, F., Teo, C. L., Fermuller, C., and Aloimonos, Y.

(2015). Contour Detection and Characterization for

Asynchronous Event Sensors. In 2015 IEEE/CVF In-

ternational Conference on Computer Vision (ICCV),

pages 486–494. IEEE.

Biswas, S. D., Kosta, A., Liyanagedera, C., Apolinario,

M., and Roy, K. (2022). HALSIE: Hybrid Approach

to Learning Segmentation by Simultaneously Exploit-

Instance Segmentation of Event Camera Streams in Outdoor Monitoring Scenarios

461

ing Image and Event Modalities. arXiv preprint

arXiv:2211.10754.

Bolten, T., Lentzen, F., Pohle-Fröhlich, R., and Tönnies, K.

(2022). Evaluation of Deep Learning based 3D-Point-

Cloud Processing Techniques for Semantic Segmen-

tation of Neuromorphic Vision Sensor Event-streams.

In Proceedings of the 17th International Joint Con-

ference on Computer Vision, Imaging and Computer

Graphics Theory and Applications - Volume 4: VIS-

APP, pages 168–179. INSTICC, SciTePress.

Bolten, T., Neumann, C., Pohle-Fröhlich, R., and Tön-

nies, K. (2023a). N-MuPeTS: Event Camera Dataset

for Multi-Person Tracking and Instance Segmentation.

In Proceedings of the 18th International Joint Con-

ference on Computer Vision, Imaging and Computer

Graphics Theory and Applications - Volume 4: VIS-

APP, pages 290–300. INSTICC, SciTePress.

Bolten, T., Pohle-Fröhlich, R., and Tönnies, K. (2021).

DVS-OUTLAB: A Neuromorphic Event-Based Long

Time Monitoring Dataset for Real-World Outdoor

Scenarios. In 2021 IEEE/CVF Conference on Com-

puter Vision and Pattern Recognition Workshops

(CVPRW), pages 1348–1357. IEEE.

Bolten, T., Pohle-Fröhlich, R., and Tönnies, K. (2023b).

Semantic Segmentation on Neuromorphic Vision Sen-

sor Event-Streams Using PointNet++ and UNet Based

Processing Approaches. In Proceedings of the 18th

International Joint Conference on Computer Vision,

Imaging and Computer Graphics Theory and Applica-

tions - Volume 4: VISAPP, pages 168–178. INSTICC,

SciTePress.

Chen, G., Cao, H., Ye, C., Zhang, Z., Liu, X., Mo, X., Qu,

Z., Conradt, J., Röhrbein, F., and Knoll, A. (2019).

Multi-Cue Event Information Fusion for Pedestrian

Detection With Neuromorphic Vision Sensors. Fron-

tiers in Neurorobotics, 13:10.

Chen, S., Fang, J., Zhang, Q., Liu, W., and Wang, X. (2021).

Hierarchical Aggregation for 3D Instance Segmenta-

tion. In 2021 IEEE/CVF International Conference on

Computer Vision (ICCV), pages 15467–15476. IEEE.

Detlefsen, N. S., Borovec, J., Schock, J., Jha, A. H., Koker,

T., Liello, L. D., Stancl, D., Quan, C., Grechkin,

M., and Falcon, W. (2022). TorchMetrics - Mea-

suring Reproducibility in PyTorch. Journal of Open

Source Software, 7(70):4101. https://github.com/

Lightning-AI/torchmetrics.

Engelmann, F., Bokeloh, M., Fathi, A., Leibe, B., and

Niessner, M. (2020). 3D-MPA: Multi-Proposal Ag-

gregation for 3D Semantic Instance Segmentation.

In 2020 IEEE/CVF Conference on Computer Vision

and Pattern Recognition (CVPR), pages 9028–9037.

IEEE.

Graham, B., Engelcke, M., and van der Maaten, L. (2018).

3D Semantic Segmentation With Submanifold Sparse

Convolutional Networks. In 2018 IEEE/CVF Con-

ference on Computer Vision and Pattern Recognition

(CVPR), pages 9224–9232. IEEE.

Guo, M., Huang, J., and Chen, S. (2017). Live Demonstra-

tion: A 768 × 640 pixels 200Meps Dynamic Vision

Sensor. In 2017 IEEE International Symposium on

Circuits and Systems (ISCAS), pages 1–1.

He, K., Gkioxari, G., Dollár, P., and Girshick, R. (2017).

Mask R-CNN. In 2017 IEEE/CVF International Con-

ference on Computer Vision (ICCV), pages 2980–

2988. IEEE. https://github.com/matterport/Mask_

RCNN.

Jiang, L., Zhao, H., Shi, S., Liu, S., Fu, C.-W., and Jia,

J. (2020). PointGroup: Dual-Set Point Grouping for

3D Instance Segmentation. In 2020 IEEE/CVF Con-

ference on Computer Vision and Pattern Recognition

(CVPR). IEEE.

Jocher, G., Chaurasia, A., and Qiu, J. (2023). YOLO by

Ultralytics. https://github.com/ultralytics/ultralytics,

v8.0.0, AGPL-3.0.

Kachole, S., Alkendi, Y., Baghaei Naeini, F., Makris,

D., and Zweiri, Y. (2023a). Asynchronous Events-

based Panoptic Segmentation using Graph Mixer Neu-

ral Network. In 2023 IEEE/CVF Conference on

Computer Vision and Pattern Recognition Workshops

(CVPRW), pages 4083–4092. IEEE.

Kachole, S., Huang, X., Baghaei Naeini, F., Muthusamy,

R., Makris, D., and Zweiri, Y. (2023b). Bimodal

SegNet: Instance Segmentation Fusing Events and

RGB Frames for Robotic Grasping. arXiv preprint

arXiv:2303.11228.

Mitrokhin, A., Fermüller, C., Parameshwara, C., and Aloi-

monos, Y. (2018). Event-Based Moving Object De-

tection and Tracking. In 2018 IEEE/RSJ International

Conference on Intelligent Robots and Systems (IROS),

pages 6895–6902.

Mitrokhin, A., Hua, Z., Fermüller, C., and Aloimonos, Y.

(2020). Learning Visual Motion Segmentation Us-

ing Event Surfaces. In 2020 IEEE/CVF Conference

on Computer Vision and Pattern Recognition (CVPR),

pages 14402–14411. IEEE.

Müllner, D. (2013). fastcluster: Fast Hierarchical, Agglom-

erative Clustering Routines for R and Python. Journal

of Statistical Software, 53(9):1–18.

Pi ˛atkowska, E., Belbachir, A. N., Schraml, S., and Gelautz,

M. (2012). Spatiotemporal Multiple Persons Track-

ing using Dynamic Vision Sensor. In 2012 IEEE/CVF

Conference on Computer Vision and Pattern Recogni-

tion Workshops (CVPRW), pages 35–40. IEEE.

Qi, C. R., Yi, L., Su, H., and Guibas, L. J. (2017). Point-

Net++: Deep Hierarchical Feature Learning on Point

Sets in a Metric Space. In Advances in Neural In-

formation Processing Systems, NIPS’17, pages 5105–

5114, Red Hook, NY, USA. Curran Associates Inc.

https://github.com/charlesq34/pointnet2.

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You Only Look Once: Uniﬁed, Real-Time

Object Detection. In 2016 IEEE/CVF Conference

on Computer Vision and Pattern Recognition (CVPR),

pages 779–788. IEEE.

Rodríguez-Gomez, J. P., Eguíluz, A. G., Martínez-de Dios,

J. R., and Ollero, A. (2020). Asynchronous Event-

Based Clustering and Tracking for Intrusion Moni-

toring in UAS. In 2020 IEEE International Con-

ference on Robotics and Automation (ICRA), pages

8518–8524.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

462

Ronneberger, O., Fischer, P., and Brox, T. (2015). U-Net:

Convolutional Networks for Biomedical Image Seg-

mentation. In Navab, N., Hornegger, J., Wells, W. M.,

and Frangi, A. F., editors, Medical Image Comput-

ing and Computer-Assisted Intervention – MICCAI

2015, pages 234–241, Cham. Springer International

Publishing.

Schraml, S. and Belbachir, A. N. (2010). A Spatio-temporal

Clustering Method Using Real-time Motion Analysis

on Event-based 3D Vision. In 2010 IEEE/CVF Con-

ference on Computer Vision and Pattern Recognition

Workshops (CVPRW), pages 57–63. IEEE.

Sekikawa, Y., Hara, K., and Saito, H. (2019). EventNet:

Asynchronous Recursive Event Processing. In 2019

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition (CVPR), pages 3882–3891. IEEE.

Sharma, R., Saqib, M., Lin, C. T., and Blumenstein, M.

(2022). A Survey on Object Instance Segmentation.

SN Computer Science, 3(6):499.

Stoffregen, T., Gallego, G., Drummond, T., Kleeman, L.,

and Scaramuzza, D. (2019). Event-Based Motion

Segmentation by Motion Compensation. In 2019

IEEE/CVF International Conference on Computer Vi-

sion (ICCV), pages 7243–7252. IEEE.

Stoffregen, T. and Kleeman, L. (2018). Simultaneous

Optical Flow and Segmentation (SOFAS) using Dy-

namic Vision Sensor. In Kodagoda, S. et al., editors,

Australasian Conference on Robotics and Automation

2017.

Sun, Z., Messikommer, N., Gehrig, D., and Scaramuzza,

D. (2022). ESS: Learning Event-based Semantic Seg-

mentation from Still Images. In Computer Vision -

ECCV 2022: 17th European Conference, Tel Aviv, Is-

rael, October 23–27, 2022, Proceedings, Part XXXIV,

pages 341–357. Springer.

Vasco, V., Glover, A., Mueggler, E., Scaramuzza, D., Na-

tale, L., and Bartolozzi, C. (2017). Independent Mo-

tion Detection with Event-driven Cameras. In 2017

18th International Conference on Advanced Robotics

(ICAR), pages 530–536.

Vu, T., Kim, K., Luu, T. M., Nguyen, T., and Yoo,

C. D. (2022). SoftGroup for 3D Instance Segmen-

tation on Point Clouds. In 2022 IEEE/CVF Con-

ference on Computer Vision and Pattern Recognition

(CVPR), pages 2708–2717. IEEE. https://github.com/

thangvubk/SoftGroup.

Wang, L., Chae, Y., Yoon, S.-H., Kim, T.-K., and Yoon,

K.-J. (2021). EvDistill: Asynchronous Events To

End-Task Learning via Bidirectional Reconstruction-

Guided Cross-Modal Knowledge Distillation. In 2021

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition (CVPR), pages 608–619. IEEE.

Wang, X., Zhang, R., Kong, T., Li, L., and Shen, C. (2020).

SOLOv2: Dynamic and Fast Instance Segmentation.

In Larochelle, H., Ranzato, M., Hadsell, R., Balcan,

M., and Lin, H., editors, Advances in Neural Informa-

tion Processing Systems, volume 33 of NeurIPS’20,

pages 17721–17732. Curran Associates, Inc.

Wu, W., Qi, Z., and Fuxin, L. (2019a). PointConv: Deep

Convolutional Networks on 3D Point Clouds. In 2019

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition (CVPR), pages 9613–9622. IEEE.

Wu, Y., Kirillov, A., Massa, F., Lo, W.-Y., and Gir-

shick, R. (2019b). Detectron2. https://github.com/

facebookresearch/detectron2.

Xie, E., Sun, P., Song, X., Wang, W., Liu, X., Liang, D.,

Shen, C., and Luo, P. (2020). PolarMask: Single Shot

Instance Segmentation With Polar Representation. In

2020 IEEE/CVF Conference on Computer Vision and

Pattern Recognition (CVPR). IEEE.

Xie, E., Wang, W., Ding, M., Zhang, R., and Luo, P.

(2022). PolarMask++: Enhanced Polar Representa-

tion for Single-Shot Instance Segmentation and Be-

yond. IEEE Transactions on Pattern Analysis and Ma-

chine Intelligence, 44(9):5385–5400.

Yang, B., Wang, J., Clark, R., Hu, Q., Wang, S., Markham,

A., and Trigoni, N. (2019). Learning Object Bound-

ing Boxes for 3D Instance Segmentation on Point

Clouds. In Wallach, H., Larochelle, H., Beygelz-

imer, A., d'Alché-Buc, F., Fox, E., and Garnett, R.,

editors, Advances in Neural Information Processing

Systems, volume 32 of NeurIPS’19, pages 6737–6746.

Curran Associates, Inc. https://github.com/Yang7879/

3D-BoNet.

Zhao, L. and Tao, W. (2020). JSNet: Joint Instance and

Semantic Segmentation of 3D Point Clouds. Pro-

ceedings of the AAAI Conference on Artiﬁcial In-

telligence, 34(07):12951–12958. https://github.com/

dlinzhao/JSNet.

Zhou, Y., Gallego, G., Lu, X., Liu, S., and Shen, S.

(2021). Event-Based Motion Segmentation With

Spatio-Temporal Graph Cuts. IEEE Transactions on

Neural Networks and Learning Systems, pages 1–13.

Instance Segmentation of Event Camera Streams in Outdoor Monitoring Scenarios

463
