Machine Learning-Based Qualitative Analysis of Human Gait Through

Video Features

Nicoletta Balletti

1,2 a

, Roberto Zinni

, Marco Russodivito

1 b

, Gennaro Laudato

1 c

Simone Scalabrino

1,4 d

and Rocco Oliveto

1,4 e

STAKE Lab, University of Molise, Pesche (IS), Italy

Defense Veterans Center, Ministry of Defense, Rome, Italy

Word Power SRL, Italy

Datasound srl, Pesche (IS), Italy

Keywords:

Gait Analysis, Motion Tracking, DGI, Machine Learning.

Abstract:

Strokes constitute a major cause of both mortality and disability, carrying signiﬁcant economic implications

for healthcare systems. Evaluating the quality of gait in post-stroke patients during rehabilitation is essential

for providing effective care. The Dynamic Gait Index (DGI) is a valuable metric for evaluating gait quality.

However, the assessment of such an index typically requires invasive tests or specialized sensors. In this paper,

we introduce a machine learning-based approach for estimating DGI exclusively from video recordings. Our

research encompasses a comprehensive set of experiments, including data preprocessing, feature selection,

and the application of various machine learning algorithms. To ensure the robustness of our ﬁndings, we

employ the Leave 1 Subject Out (L1SO) cross-validation method. Our results underscore the challenge of

accurately estimating DGI using solely video data. We achieved an R-squared (R

) value of only 0.19 and a

mean absolute error (MAE) of 2.2. Notably, we observed that our approach yielded notably poorer results for a

speciﬁc subset of three patients. Upon excluding this subset, the R

increased to 0.30, and the MAE improved

to 1.9. This observation suggests that incorporating patient-speciﬁc features into the model may hold the key

to enhancing its overall accuracy.

1 INTRODUCTION

Strokes provide a signiﬁcant contribution to both mor-

tality and disability. From a clinical perspective, a

stroke occurs when there is a temporary interrup-

tion in the blood supply to a part of the brain.

the US, the economic burden associated with strokes

amounted to approximately $57B between 2018 and

2019.

Most of such costs are directed toward

addressing the long-term disabilities resulting from

strokes, which affect over half of stroke survivors

aged 65 and older.

Gait abnormalities are frequently

encountered in patients who have suffered a stroke.

https://orcid.org/0000-0002-6617-7074

https://orcid.org/0009-0004-8860-1739

https://orcid.org/0000-0002-5241-1608

https://orcid.org/0000-0003-1764-9685

https://orcid.org/0000-0002-7995-8582

https://www.cdc.gov/stroke/facts.htm

These individuals must undergo extended rehabil-

itation before they can regain the ability to walk. Prior

research has introduced various techniques to sup-

port the rehabilitation of post-stroke patients by as-

sessing the quality of their gait. For instance, Swank

et al. (2020) employed video gait analysis to establish

the effectiveness of Robotic Exoskeletons (EKSO) in

post-stroke rehabilitation therapy. Liu et al. (2021)

used the Microsoft Kinect camera to monitor the rota-

tion and movement of the Center of Mass in multiple

planes for gait analysis.

Recently, Balletti et al. (2023) introduced GIU-

LYO, an approach designed to automatically pre-

dict the number of independent co-excited muscle

groups by analyzing patients’ video recordings of

their gait. Indeed, speciﬁc muscle groups can be iden-

tiﬁed through Surface Electromyography (S-EMG)

by analyzing the number of channels displaying EMG

activity (Routson et al., 2014). GIULYO provides this

information without the need for installing sensors on

450

Balletti, N., Zinni, R., Russodivito, M., Laudato, G., Scalabrino, S. and Oliveto, R.

Machine Learning-Based Qualitative Analysis of Human Gait Through Video Features.

DOI: 10.5220/0012375900003657

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 17th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2024) - Volume 2, pages 450-457

ISBN: 978-989-758-688-0; ISSN: 2184-4305

the human body, and it was validated using the ARRA

post-stroke database (Routson et al., 2014). Although

GIULYO’s predictions support the evaluation of reha-

bilitation sessions, they are limited to distinguishing

only three classes (2, 3, or 4 co-excited muscles).

Ideally, healthcare practitioners would beneﬁt

from a more granular measurement of gait quality.

The literature presents a metric known as the Dy-

namic Gait Index (DGI) (Shumway-Cook and Wool-

lacott, 1995), which aims to achieve this goal. DGI

assesses gait quality by providing an index ranging

from 0 to 24, with a lower index indicating lower gait

quality and a higher risk of falls (Herdman, 2000).

Currently, DGI can only be measured through inva-

sive tests, requiring patients to perform speciﬁc ex-

ercises or wear specialized sensors (Herdman, 2000;

Shumway-Cook and Woollacott, 1995).

This work aims to automatically estimate a re-

habilitation session’s DGI using a video recording,

providing a ﬁne-grained assessment of gait quality.

To accomplish this, we introduce a machine learn-

ing (ML)-based approach that, based on features ex-

tracted from the gait video, predicts the DGI value.

Similar to GIULYO, our approach is device-agnostic

and does not rely on speciﬁc motion tracking instru-

ments.

To validate our approach, we conducted exten-

sive experiments involving various data preprocess-

ing techniques, feature selection strategies, and ML

algorithms to develop the best DGI prediction model.

We employed a Leave 1 Subject Out (L1SO) cross-

validation approach, ensuring that no subject’s data

used for testing was included in the training set.

Our results reveal the considerable challenge of ac-

curately measuring DGI exclusively from video data.

The most successful combination of preprocessing

techniques, feature selection, and ML algorithms

achieved an R

value of only 0.19 for the regression

problem, with a mean absolute error of 3.1. How-

ever, we observed that the model’s errors are most

pronounced in patients with slower walking speeds.

By excluding such patients from the dataset upfront,

we achieved more favorable results (R

= 0.24) with a

mean absolute error of 2.7. This ﬁgure falls below the

minimum detectable change for DGI (Romero et al.,

2011), which is 2.9.

2 BACKGROUND AND RELATED

WORK

We ﬁrst introduce the Dynamic Gait Index (DGI).

Then, we review related studies concerning DGI es-

timation and the assessment of gait quality.

2.1 Dynamic Gait Index

The Dynamic Gait Index (DGI) is a clinical assess-

ment tool originally proposed by Shumway-Cook and

Woollacott in 1995 (Shumway-Cook and Woollacott,

1995). It is widely employed by healthcare profes-

sionals, particularly physical therapists and rehabili-

tation specialists, to evaluate an individual’s dynamic

balance and walking ability. DGI is often utilized to

assess those at risk of falling, such as the elderly pop-

ulation, post-stroke patients, individuals with vestibu-

lar disorders or brain injuries, and those experiencing

balance issues resulting from non-vestibular causes

(Jonsdottir and Cattaneo, 2007; Wrisley et al., 2003).

DGI comprises a sequence of eight distinct walk-

ing tasks or conditions designed to evaluate various

facets of gait and dynamic balance. These tasks are

typically administered in a controlled setting, with

the individual being assessed receiving a performance

score for each task.

The equipment necessary for the assessment in-

cludes a box, two cones, stairs, and a 6-meter-long,

40-centimeter-wide walkway. The speciﬁc activities

involved in the DGI assessment are as follows (Herd-

man, 2000; Shumway-Cook and Woollacott, 1995):

1. Gait Level Surface. Walk a distance of approxi-

mately twenty feet (or six meters) at your normal

pace.

2. Change in Gait Speed. Begin walking at your

usual speed, then, on the assessor’s cue, walk as

fast as possible. On the cue to slow down, walk as

slowly as you can.

3. Gait with Horizontal Head Turns. Walk at your

usual pace. When instructed to “look right”, con-

tinue walking straight but turn your head to the

right. Keep your gaze to the right until instructed

to “look left”, at which point you should turn your

head left. When told to “look straight”, return

your gaze to the center.

4. Gait with Vertical Head Turns. Tip your head

up and maintain your upward gaze until instructed

to “look down”. When prompted to look down,

continue walking straight while lowering your

head. Upon receiving the cue to “look straight”,

return your head to a neutral position while con-

tinuing to walk.

5. Gait and Pivot Turn. Begin walking at your

usual pace. Upon the cue to “turn and stop”,

swiftly pivot to face the opposite direction and

come to a stop.

6. Step Over Obstacle. Walk at your normal speed.

When you encounter a shoebox, step over it di-

Machine Learning-Based Qualitative Analysis of Human Gait Through Video Features

451

rectly, rather than circumventing it, and continue

walking.

7. Step Around Obstacles. Begin walking at your

normal pace. When you reach the ﬁrst cone, ap-

proximately two meters away, circumnavigate it

on the right side. As you approach the second

cone, located approximately six meters beyond

the ﬁrst, navigate around it on the left side.

8. Steps. Ascend the stairs as you would at home,

using the railing if necessary. Upon reaching the

top, pivot and descend the stairs.

Each task is assessed by a specialist on a scale

ranging from a minimum score of 0, indicating se-

vere impairment, to a maximum of 3, signifying nor-

mal function. Consequently, the overall DGI score

can range from 0 to 24 (Shumway-Cook and Woolla-

cott, 1995).

The DGI score serves as an indicator of a patient’s

propensity for falls. An index exceeding 22 character-

izes individuals as safe ambulators, whereas an index

below 20 denotes an increased risk of falls (Herdman,

2000; Whitney et al., 2000).

2.2 Related Work

We direct our focus towards gait analysis in individ-

uals who have undergone a stroke, with a brief refer-

ence to works concerning DGI reliability.

Nadeau et al. (2013) conducted a comprehensive

study that delved into the gait analysis process, shed-

ding light on key gait parameters and deviations ob-

served in stroke survivors. Their investigation re-

volved around the effects of gait speed and ground

response forces (GRFs). Notable ﬁndings included

reduced walking speed, an unsteady gait pattern, and

diminished peak moments and powers on the affected

side as common traits in post-stroke hemiparetic gait.

Remarkably, even when two hemiparetic individuals

exhibited similar walking speeds, their gait patterns

could exhibit signiﬁcant disparities. This underscores

the critical role of GRFs in assessing gait abnormali-

ties among stroke patients, among other gait charac-

teristics.

Ferrarin et al. (2015) conducted an observational

study aimed at evaluating how gait analysis inﬂu-

ences therapeutic decision-making, be it surgical or

non-surgical, for adult patients with chronic walk-

ing difﬁculties resulting from a stroke. Their re-

search unveiled substantial differences in recommen-

dations based solely on clinical examination and vi-

sual gait observation compared to those supplemented

with gait analysis data. This study underscored the

profound impact of gait analysis on treatment plan-

ning for chronic post-stroke patients with locomotor

dysfunction, endorsing both surgical and non-surgical

decision-making processes.

Li et al. (2019) employed dynamic time warp-

ing (DTW), sample entropy, and empirical mode

decomposition-based stability index to extract fea-

tures associated with symmetry, regularity, and sta-

bility in post-stroke hemiparetic gaits. Their study

encompassed 15 stroke survivors and 15 healthy con-

trol subjects, with ﬁndings strongly supporting the ef-

ﬁcacy of the identiﬁed features in distinguishing post-

stroke hemiparetic patients from their healthy coun-

terparts.

Eichler et al. (2022) proposed an approach to au-

tomate the BBS fall risk assessment test. Subjects

are required to execute the BBS tasks while a com-

puter vision system captures poses and motion. Sub-

sequently, a multi-level machine learning model pre-

dicts the overall score. Results conﬁrm the feasibil-

ity of predicting gait assessment indexes through non-

invasive video features.

Liuzzi et al. (2023) introduced machine learning

techniques for predicting mDGI, suggesting an in-

sightful comparison with its MDC (Minimally De-

tectable Change). Given that this research targets the

unmodiﬁed DGI, Romero et al. (2011) is used as a

reference, as it established an MDC

95%

of 2.9 points

for DGI.

Balletti et al. (2023) presented GIULYO, an ap-

proach designed to automatically predict the number

of co-excited muscles by visually analyzing patients’

gait. GIULYO offers an estimation of the number of

co-excited muscles during walking, categorizing gait

into three classes (2, 3, or 4 co-excited muscles). As

the authors note, the predictions furnished by this ap-

proach have the potential to support the evaluation of

rehabilitation sessions.

While the latter work lays a solid foundation for

assisting practitioners in the automatic evaluation of

patients’ gait, it remains a coarse-grained approach.

In this study, we strive to bridge this gap by the auto-

matic prediction of the DGI, a more reﬁned measure

of gait quality.

3 ESTIMATING THE QUALITY

OF WALKING

Our primary design objective is to develop a system

capable of assessing the quality of a patient’s gait

without the need for specialized staff in the least inva-

sive manner. To achieve this, we employ a computer

vision markerless device with the capability to detect

the positions of subject joints and bone rotations in

real-time. Consequently, the input to our approach is

HEALTHINF 2024 - 17th International Conference on Health Informatics

452

Table 1: The features used to estimate the quality of walking

in our ML-based approach.

Aspect Aggregations

Stride

Walking speed Mean, SD

Number of strides Mean, SD

Paretic step ratio over all steps Mean, SD

Paretic propulsion Mean, SD

Paretic stride length Mean, SD

Non-paretic stride length Mean, SD

Paretic step length Mean, SD

Non-paretic step length Mean, SD

Norm. foot height for paretic side Mean, SD

Norm. foot height for non-paretic side Mean, SD

Walking Cycle

Left single support percentage //

Right single support percentage //

Left step length Mean

Right step length Mean

Left stride length Mean

Right stride length Mean

Legs+Feet

Paretic leg sagittal-plane angle Sum, Min, Max, Mean, SD

Non-paretic leg sagittal-plane angle Sum, Min, Max, Mean, SD

Paretic leg frontal-plane angle Sum, Min, Max, Mean, SD

Non-paretic leg frontal-plane angle Sum, Min, Max, Mean, SD

Paretic leg length Sum, Min, Max, Mean, SD

Non-paretic leg length Sum, Min, Max, Mean, SD

Normalized paretic leg length Sum, Min, Max, Mean, SD

Normalized non-paretic leg length Sum, Min, Max, Mean, SD

Paretic leg vertical-length Sum, Min, Max, Mean, SD

Non-paretic leg vertical-length Sum, Min, Max, Mean, SD

Normalized paretic leg vertical-length Sum, Min, Max, Mean, SD

Normalized non-paretic leg vertical-length Sum, Min, Max, Mean, SD

Normalized paretic foot height Sum, Min, Max, Mean, SD

Normalized non-paretic foot height Sum, Min, Max, Mean, SD

Non-paretic leg angle Sum, Min, Max, Mean, SD

Paretic foot height Sum, Min, Max, Mean, SD

Non-paretic foot height Sum, Min, Max, Mean, SD

Demogr.

Age //

Gender //

Affected side //

Trial condition //

a video recording of the patient’s gait, while the out-

put is a numerical estimation of the DGI.

Irrespective of the selected acquisition device, our

system comprises two key modules: a recorder mod-

ule responsible for translating gait data into a stan-

dardized format, and a calculator module designed to

extract features related to the acquired video. Once

acquired the gait data, we perfom a video analysis

procedure aiming to obtain a feature vector that rep-

resents a single gait session for a given patient.

The features extracted capture four distinct as-

pects of the gait: stride-related, walking cycle-

related, leg and feet-related, and demographics. In

the following we provide a detailed description of

each of these features, which are also succinctly sum-

marized in Table 1.

Stride-Related Aspects. These aspects focuses

on stride measurements and timing data. They of-

fer insight into the impact of pathology on the sub-

ject’s stride, which can be instrumental in assessing

overall gait quality. For patients with a paretic side

and a non-paretic side, we consider the following as-

pects: (i) walking speed, (ii) number of strides, where

a stride represents a complete gait cycle consisting of

two steps, starting with one foot making contact with

the ground and ending when the same foot repeats this

contact, (iii) paretic step ratio calculated as the aver-

age of (paretic step length) / (stride length) over all

strides in the trial, (iv) paretic propulsion, (v) paretic

and non-paretic stride length, (vi) paretic and non-

paretic step length, and (vii) normalized foot height

for both paretic and non-paretic sides. Mean and stan-

dard deviation are computed for these aspects to ex-

tract relevant features.

Walking Cycle-Related Aspects. This aspects

comprise metrics derived from the walking cycle,

which can help in assessing disparities between the

paretic and non-paretic sides, contributing to the esti-

mation of DGI. These aspects include: (i) single sup-

port percentages, representing the (total time in which

the subject is supported by a single leg on the chosen

side) / (total trial time) for both sides, and (ii) step and

stride length averages across the entire trial.

Legs and Feet-Related Aspects. The third set

of aspects encompasses measurements related to the

legs and feet, both paretic and non-paretic, providing

insights into how this gait differs from a normal one

in terms of movement. Speciﬁc aspects include: (i)

sagittal plane leg angle, measured from pelvic Cen-

ter Of Mass (COM) to foot COM, (ii) frontal plane

leg angle, measured from pelvic COM to foot COM,

(iii) leg length, deﬁned as the distance between pelvis

COM and foot COM, (iv) normalized leg length, ex-

pressed as (leg length) / (height of pelvis COM from

the ﬂoor), (v) vertical-only leg length, representing

the difference between the vertical components of

pelvis COM and foot COM, (vi) normalized vertical

length, deﬁned as (vertical-only length) / (height of

pelvis COM), and (vii) normalized foot height, calcu-

lated as (foot COM height) / (pelvis COM height). For

each of these seven aspects, measured for both sides,

we compute the sum, maximum, minimum, mean,

and standard deviation.

Demographic and Clinical Aspects. To enhance

the effectiveness of the evaluation system, we include

demographic information known to the patient. This

data, collected alongside gait analysis, consists of the

patient’s age, gender, the affected side expressed as

1/2 for left/right, and the trial condition, represented

by an integer from 0 to 4, addressing one of the ﬁve

trial conditions described in Section 4.

The above features are then used to estimate the

DGI. Given the numerical nature of DGI, estimating it

naturally falls under the category of regression prob-

lems. Thus, we employ machine learning techniques

to train a regression model capable of estimating DGI.

Further details regarding the algorithms used are pre-

sented in our description of the experimental design

(Section 4).

Machine Learning-Based Qualitative Analysis of Human Gait Through Video Features

453

4 EMPIRICAL STUDY DESIGN

The goal of our empirical study is to understand to

what extent our approach can be used to automati-

cally assess DGI. Our study is guided by the follow-

ing research question: Can DGI be estimated through

machine learning approaches trained only on video

recordings of human gait?

The answer to this research question is crucial in

determining whether video data alone is sufﬁcient for

DGI estimation.

4.1 Context Selection

For our study, we utilized the ARRA Post-Stroke

Database (Kautz, 2018; Routson et al., 2014). This

database originates from a study focused on eluci-

dating the cause-and-effect relationship between neu-

ral output and the level of walking functionality in

post-stroke patients. It encompasses a wide range of

data, including kinematics, kinetics (captured using

split belt treadmill force plates), and electromyogra-

phy (EMG) data collected from 27 post-stroke indi-

viduals (who were at least 6 months post-stroke) and

17 healthy control participants.

The dataset entails multiple gait trials performed

by each subject under ﬁve distinct conditions:

• Self-Selected (SS) walking pace: The participant’s

usual walking speed.

• Fastest Comfortable (FC): The participant’s max-

imum comfortable walking speed.

• High Step (HS): Participants were instructed to

take the highest possible steps while maintaining

their self-selected pace.

• Quick step (QS): Subjects walked at their self-

selected speed, taking the quickest possible steps.

• Long step (LS): While retaining their self-selected

speed, participants were instructed to take the

longest possible steps.

Data collection involved several measurement

techniques and equipment, including a 12-camera

motion capture system from PhaseSpace, Inc., which

employed active infrared markers placed on anatom-

ical landmarks to measure body movements. Ground

reaction forces and moments in three dimensions

were measured using a split-belt treadmill from FIT,

Bertec, Inc. Electromyography (EMG) data was ac-

quired using the MA400, a 16-channel EMG system

from Motion Lab Systems.

Each participant’s gait data consisted of multiple

trials, ensuring data diversity and representativeness.

The dataset includes raw measurements required to

derive the features utilized in our approach. Addi-

tionally, it contains EMG modules, a feature indi-

cating the number of independent co-excited muscle

groups measured during the trial, which we do not

use due to its requirement for invasive sensors. Simi-

larly, clinical assessments, such as the 6 Minutes Walk

Test (6MWT), the Berg Balance Scale (BBS), and the

Fugl-Meyer (FM) Score, were not used, as they ne-

cessitate specialized medical staff and would render

the estimation of DGI redundant.

Furthermore, the dataset provides the previously

assessed Dynamic Gait Index (DGI) for each partic-

ipant. DGI scores in the patient population ranged

from 8 to 22, though, as explained earlier, the theoret-

ical DGI range is 0 to 24.

4.2 Experimental Procedure

The dataset was pre-processed to create a single row

for each trial instance. This involved collecting de-

mographic data (gender, age, affected side, trial con-

dition, and treadmill speed, which serves as a proxy

for walking speed) directly from the dataset. Sub-

sequently, stride measurements, timing information,

and stride-related metrics were included for both the

paretic and non-paretic sides. For each bone type,

the mean and standard deviation were calculated from

the angles measured across the acquisition frames to

quantify these metrics.

The resulting dataset, derived from the ARRA

Post-Stroke Database (Kautz, 2018; Routson et al.,

2014), comprises 322 instances and 130 features.

We employed several machine learning algo-

rithms to train a regression model for DGI estima-

tion, including RandomForestRegressor (Liu et al.,

2012), MLPRegressorg, LogisticRegression, Lin-

earSVR (Boser et al., 1992), SVR (Gunn et al., 1998),

KNeighborsRegressor (Kramer, 2011), SGDRegres-

sor (Ketkar and Ketkar, 2017), DecisionTreeRegres-

sor (Loh, 2011), BaggingRegressor (Breiman, 1996),

GradientBoostingRegressor (Friedman, 2001), Ad-

aBoostRegressor (Freund and Schapire, 1997), Pas-

siveAggressiveRegressor (Crammer et al., 2006), Ex-

traTreesRegressor (Geurts et al., 2006).

In terms of pre-processing, we utilized two tech-

niques: automatic feature selection to exclude un-

necessary features and make the problem more

manageable for the machine learning algorithm,

and correlation-based feature selection to eliminate

highly correlated features that might not signiﬁcantly

contribute to the estimation. We tested various com-

binations of these pre-processing techniques to opti-

mize performance.

For automatic feature selection, we employed

HEALTHINF 2024 - 17th International Conference on Health Informatics

454

a wrapper approach based on different regression

techniques, including LogisticRegression, Random-

ForestRegressor (Liu et al., 2012), AdaBoostRe-

gressor (Freund and Schapire, 1997), SGDRegres-

sor (Ketkar and Ketkar, 2017), PassiveAggressiveRe-

gressor (Crammer et al., 2006), ExtraTreesRegressor

(Geurts et al., 2006), DecisionTreeRegressor (Loh,

2011), GradientBoostingRegressor (Friedman, 2001).

Instead, in correlation-based feature selection, fea-

tures with a correlation coefﬁcient exceeding 0.90

were discarded. We considered and combined all pos-

sible pre-processing options for the two steps (au-

tomatic feature selection and correlation-based fea-

ture selection) with the machine learning techniques

chosen for testing. This resulted in testing 208 con-

ﬁgurations (8 for automatic feature selection × 2

for correlation-based feature selection × 13 machine

learning techniques). To prevent overﬁtting and en-

sure that the model did not learn from data already ob-

served for the speciﬁc patient on which it was tested,

we employed a Leave-1-Person Out (L1PO) cross-

validation. This approach partitioned the data into

folds, with one fold assigned to each patient. Sub-

sequently, we used these folds one by one as the test

set, while the union of the remaining folds served as

the training set. This method ensured that an individ-

ual patient’s data contributed to the training dataset

n-1 times and to the test dataset once.

To answer our research question, we initiated our

analysis by evaluating the goodness of ﬁt for our mod-

els. To accomplish this, we employed the R

metric,

which falls within the range of 0 to 1. A higher R

value indicates a better ﬁt of the model to the data.

Furthermore, we utilized two error metrics for as-

sessing accuracy, namely MAE (Mean Absolute Er-

ror) and MSE (Mean Squared Error). MSE penalizes

larger errors, offering a more precise estimate of the

cost of errors, while MAE provides a realistic assess-

ment of the error range in our approach for DGI as-

sessment. Lower values in both metrics correspond

to better performance. Lastly, we employed the ex-

plained variance metric, which indicates the extent to

which the variance in the response variable can be ac-

counted for by the features in our model. A higher

explained variance value reﬂects a greater ability to

explain data variation and implies a higher level of

predictive quality.

5 EMPIRICAL STUDY RESULTS

We report the results achieved by the top four conﬁg-

urations in terms of the goodness of ﬁt (R

) in Table 2.

Subsequently, we detail their respective performance

Figure 1: MAE and MSE values for the ﬁrst conﬁguration.

Table 2: The four best machine learning conﬁgurations.

Conf. Algo. Auto. Sel. Corr. Sel.

#1 tree gbc False

#2 tree tree False

#3 log gbc False

#4 tree adaboost False

outcomes in Table 3.

The DecisionTreeRegressor model exhibited the

highest R

and explained variance values. Notably,

the top four conﬁgurations employed various auto-

matic selection algorithms, while correlation-based

selection was not utilized in any of these cases.

However, it is evident that the results are some-

what underwhelming in terms of R

. The best model

achieved only a R

of 0.19, signifying that even the

most effective model cannot adequately ﬁt the data.

This model produced a Mean Absolute Error (MAE)

of 3.11, indicating that the model’s estimates are ex-

pected to deviate by an average of 3 DGI points in

either direction.

Upon analyzing the selected features in the top

four models, we observed that all walking cycle fea-

tures and a subset of demographic features were con-

sistently included. Additionally, all stride-related fea-

tures were retained. In contrast, most features related

to legs and feet were discarded during the feature se-

lection process. To validate this observation and fur-

ther explore feature importance, we tested the best

conﬁguration with each of the four feature categories

isolated. A model based on walking cycle features

achieved the highest R

(0.19), followed by demo-

graphic features (0.11), stride-related features (0.03),

and legs-and-feet features (0.0). While raw measure-

ments from legs and feet features failed to guide ma-

Table 3: Regression results achieved by the best four ma-

chine learning conﬁgurations accoding to R

Conf. R

MSE MAE Explained Variance

#1 0.19 16.04 3.11 0.96

#2 0.15 21.90 3.73 1.00

#3 0.15 17.84 3.33 0.92

#4 0.12 21.47 3.92 0.96

Machine Learning-Based Qualitative Analysis of Human Gait Through Video Features

455

chine learning in establishing a correlation between

gait and DGI, domain-speciﬁc and calculated aggre-

gations, such as walking-related features, provided a

better description of this relationship.

5.1 Discussion

We observed that the overall results of the best model

we trained are slightly underwhelming: we achieve

an R

of 0.19 and a mean absolute error of 3.11. In

practice, this error might be low enough for some DGI

values (e.g., very high or very low), while it might be

detrimental for in-between values. We compared the

MAE we achieved with the variations observed when

different human experts measure DGI through the

standard state-of-the-art procedure. Such a variation

is also called Minimum Detectable Change (MDC).

Romero et al. (2011) computed the MDC

95%

for DGI

and reported that it is 2.9 (i.e., in 95% of the cases, the

error in the estimation of DGI is ±2.9). The MAE of

our approach is above such a value. Thus, on average,

the approach makes larger errors than the minimum

detectable change.

We report in Figure 1 the MAE and MSE regis-

tered during the training of the best conﬁguration for

different patients. It can be noticed that the model

is particularly inaccurate on three subjects. We tried

to identify features common to those patients so that

we can characterize them. To do this, we used ag-

glomerative clustering (Murtagh and Legendre, 2014)

on the dataset, considering all the features selected

to train the ﬁrst conﬁguration. Speciﬁcally, we con-

ﬁgured the algorithm to identify ﬁve clusters using

the Euclidean linkage metric with ward linkage cri-

terion, which minimizes the variance of the clusters

being merged. We found that the smallest cluster

containing outlier patients is composed of 9 subjects.

To understand which features are most responsible

for this cluster aggregation, we used the silhouette

score(Shahapure and Nicholas, 2020), a metric that

provides a measure of how similar a data entry is to its

own cluster compared to other clusters. Speciﬁcally,

we ﬁrst calculated the average silouette score for the

outliers cluster. Then, for each feature, we created

a copy of the dataset replacing the selected feature

with its mean. In this way, we nullify the feature vari-

ance and its clustering power. For each dataset copy

we computed the cluster average silouette score again

and compared each score with the original one. The

worse the new score, the more important the feature

is for clustering.

Through this procedure, we discovered that the

most characterizing feature for this cluster is Right

single support percentage. Besides, we found that this

cluster has a single-support-percentage difference,

deﬁned as the absolute value of the difference be-

tween left and right single support percentages, higher

than the other data points (11.56 percentage points

versus 5.3 percentage points on average for all the

other instances). This analysis led us to conclude that

this cluster contains trials with more impaired gaits

which are assigned with better-ranged DGI values.

In particular, we compared single-support-percentage

differences with the original DGI value assigned to

the trials and noticed higher ratios for cluster data

(0.22) than for the remaining part of the dataset

(0.08), which suggests how the outliers cluster is char-

acterized by a less inverse-proportionality between

gait impairment and DGI values. Then, we performed

an experiment in which we excluded the cluster that

contains the outlier patients to understand what theo-

retical improvements could be achieved. Overall, we

obtained better results (R

= 0.24, explained variance

= 1.0). The error also signiﬁcantly decreased (MSE =

13.18, MAE = 2.70). It is also worth noting that this

new experiment allowed the model to achieve a MAE

score below the MDC

95%

value.

6 CONCLUSION

We developed a machine learning-based approach

for automatically estimating the Dynamic Gait In-

dex (DGI) for post-stroke patients during rehabili-

tation sessions using video recordings. The results

of our study showed that our approach performed

poorly, particularly on patients who walked very

slowly. When we removed these subjects from the

analysis, the overall R

improved to 0.24, and the

MAE reduced to 2.7, which falls below the minimum

detectable change. In summary, our study demon-

strates the feasibility of using video data for DGI es-

timation in post-stroke patients during rehabilitation.

While challenges in achieving high precision persist,

further research should focus on ﬁnding features that

allow for more accurate DGI measurement, especially

for patients who walk at slower speeds.

ACKNOWLEDGMENT

The authors have been supported by the project

“EDAM: A Diagnosis Recommender System based on

Explainable Artiﬁcial Intelligence and the Combina-

tion of Motion Analysis and Others Clinical Biomark-

ers“ funded by the Italian Ministry of Defense.

HEALTHINF 2024 - 17th International Conference on Health Informatics

456

REFERENCES

Balletti, N., Laudato, G., and Oliveto, R. (2023). A gait

analysis tool based on machine learning to support

the rehabilitation strategy of post-stroke patients. In

HEALTHINF, pages 400–407.

Boser, B. E., Guyon, I. M., and Vapnik, V. N. (1992). A

training algorithm for optimal margin classiﬁers. In

WCLT, pages 144–152.

Breiman, L. (1996). Bagging predictors. Machine learning,

24:123–140.

Crammer, K., Dekel, O., Keshet, J., Shalev-Shwartz, S.,

and Singer, Y. (2006). Online passive aggressive al-

gorithms.

Eichler, N., Raz, S., Toledano-Shubi, A., Livne, D.,

Shimshoni, I., and Hel-Or, H. (2022). Automatic and

efﬁcient fall risk assessment based on machine learn-

ing. Sensors, 22(4):1557.

Ferrarin, M., Rabuffetti, M., Bacchini, M., Casiraghi, A.,

Castagna, A., Pizzi, A., Montesano, A., and Palsy, C.

(2015). Does gait analysis change clinical decision-

making in poststroke patients? results from a prag-

matic prospective observational study. Eur J Phys Re-

habil Med, 51(2):171–184.

Freund, Y. and Schapire, R. E. (1997). A decision-theoretic

generalization of on-line learning and an application

to boosting. Journal of computer and system sciences,

55(1):119–139.

Friedman, J. H. (2001). Greedy function approximation: a

gradient boosting machine. Annals of statistics, pages

1189–1232.

Geurts, P., Ernst, D., and Wehenkel, L. (2006). Extremely

randomized trees. Machine learning, 63:3–42.

Gunn, S. R. et al. (1998). Support vector machines for

classiﬁcation and regression. ISIS technical report,

14(1):5–16.

Herdman, S. (2000). Physical therapy diagnosis for vestibu-

lar disorders. Vestibular Rehabilitation. 2nd ed.

Philadelphia, PA: FA Davis Company.

Jonsdottir, J. and Cattaneo, D. (2007). Reliability and valid-

ity of the dynamic gait index in persons with chronic

stroke. Archives of physical medicine and rehabilita-

tion, 88(11):1410–1415.

Kautz, S. A. (2018). Medical University of South Carolina

Stroke Data (ARRA).

Ketkar, N. and Ketkar, N. (2017). Stochastic gradient de-

scent. Deep learning with Python: A hands-on intro-

duction, pages 113–132.

Kramer, O. (2011). Unsupervised k-nearest neighbor re-

gression. arXiv preprint arXiv:1107.3600.

Li, M., Tian, S., Sun, L., and Chen, X. (2019). Gait analysis

for post-stroke hemiparetic patient by multi-features

fusion method. Sensors, 19(7):1737.

Liu, Y., Liu, B., Zhou, Z., Cai, S., and Xie, L. (2021). A

novel center of mass (com) perception approach for

lower-limbs stroke rehabilitation. In ICSR, pages 606–

615. Springer.

Liu, Y., Wang, Y., and Zhang, J. (2012). New machine

learning algorithm: Random forest. In ICICA, pages

246–252. Springer.

Liuzzi, P., Carpinella, I., Anastasi, D., Gervasoni, E.,

Lencioni, T., Bertoni, R., Carrozza, M. C., Cattaneo,

D., Ferrarin, M., and Mannini, A. (2023). Machine

learning based estimation of dynamic balance and gait

adaptability in persons with neurological diseases us-

ing inertial sensors. Scientiﬁc Reports, 13(1):8640.

Loh, W.-Y. (2011). Classiﬁcation and regression trees. Wi-

ley interdisciplinary reviews: data mining and knowl-

edge discovery, 1(1):14–23.

Murtagh, F. and Legendre, P. (2014). Ward’s hierarchical

agglomerative clustering method: which algorithms

implement ward’s criterion? Journal of classiﬁcation,

31:274–295.

Nadeau, S., Betschart, M., and Bethoux, F. (2013). Gait

analysis for poststroke rehabilitation: the relevance

of biomechanical analysis and the impact of gait

speed. Physical Medicine and Rehabilitation Clinics,

24(2):265–276.

Romero, S., Bishop, M. D., Velozo, C. A., and Light, K.

(2011). Minimum detectable change of the berg bal-

ance scale and dynamic gait index in older persons at

risk for falling. Journal of geriatric physical therapy,

34(3):131–137.

Routson, R. L., Kautz, S. A., and Neptune, R. R. (2014).

Modular organization across changing task demands

in healthy and poststroke gait. Physiological reports,

2(6):e12055.

Shahapure, K. R. and Nicholas, C. (2020). Cluster quality

analysis using silhouette score. In DSAA, pages 747–

748. IEEE.

Shumway-Cook, A. and Woollacott, M. H. (1995). Theory

and practical applications. Motor control, pages 89–

90.

Swank, C., Sikka, S., Driver, S., Bennett, M., and Callender,

L. (2020). Feasibility of integrating robotic exoskele-

ton gait training in inpatient rehabilitation. Disability

and rehabilitation. Assistive technology, 15(4):409—

-417.

Whitney, S., Hudak, M., and Marchetti, G. (2000). The

dynamic gait index relates to self-reported fall history

in individuals with vestibular dysfunction. Journal of

Vestibular Research, 10(2):99–105.

Wrisley, D. M., Walker, M. L., Echternach, J. L., and

Strasnick, B. (2003). Reliability of the dynamic gait

index in people with vestibular disorders. Archives

of physical medicine and rehabilitation, 84(10):1528–

1533.

Machine Learning-Based Qualitative Analysis of Human Gait Through Video Features

457
