Using Ensemble Models for Malicious Web Links Detection

Claudia-Ioana Coste

Faculty of Mathematics and Computer Science, Babes

-Bolyai University,

Mihail Kogalniceanu Street, no. 1, Cluj-Napoca, Romania

Keywords:

Malicious Web Links Detection, Machine Learning Algorithms, Ensemble Models, Particle Swarm

Optimization, Nature-Inspired Algorithms, Web-Malware.

Abstract:

Web technology advances faster than humans can adapt to it and develop the proper online skills. Most users

are not experienced enough to have a good online knowledge on how to protect their data. Thus, many people

can become vulnerable to threats. The most common online attacks are through malicious web links, which

can deceive users into clicking them and running malicious code. The present approach proposed to advance

the ﬁeld of malicious web links detection through ensemble models by developing a nature-inspired ensemble.

Our methodology is tested against two datasets, and we conduct an additional calibration step for all the mod-

els. For the ﬁrst database, we managed to improve the detection accuracy from other solutions, by achieving

97.05%. In the case of the second dataset, our empirical strategy is not accurate enough, reaching just 91.12%

accuracy. The proposed ensemble is heterogeneous, having a weight voting mechanism, where weights are

generated with the Particle Swarm Optimization algorithm. To build the ensemble we compared 12 individual

machine learning models, including Logistic Regression, Support Vector Machine, Adaptive Boosting, Ran-

dom Forest, Decision Tree, K-Nearest Neighbor, Perceptron, Nearest Centroid, Passive Aggressive Classiﬁer,

Stochastic Gradient Descent, KMeans, and different variants for Naive Bayes.

1 INTRODUCTION

With the latest development of web applications,

there were signiﬁcant improvements in web security,

but as well in producing new web malware. These

threats have become more and more sophisticated af-

fecting many people with poor online abilities. An

important category of attacks are malicious links

which can be spread through social media posts, pri-

vate messages, SMSs, and emails. The main security

issues associated with suspicious links are perform-

ing redirections or downloading programs without the

user’s consent (i.e. drive-by-downloads), executing

malicious code that can use browser’s resources and

leaking personal information. Finally, malicious links

can contribute to the disinformation phenomenon by

pointing to fake news and low-quality online content

such as clickbait articles.

In 2022, it was stated by (IT, 2023), that some

of the most common top level domains are included

in malicious links. For instance, 54% of them be-

long to .com domain and 8.4% have the .net domain.

From the domains included under .com, some of the

https://orcid.org/0000-0001-8076-9423

most common ones are Adobe, Google, Myportfo-

lio, Backblazeb2, Weebly. Moreover, the shortened

URLs are a constant threat since they may hide mali-

cious links. In 2021, the most common malware link

found in emails was a Trojan with the aim of steal-

ing browser’s information (e.g., stored credentials, lo-

gin information etc.) (IT, 2023). Developing a solu-

tion for malicious links involves a complex pipeline

where the classiﬁcation should be robust, sensitive,

and fast enough to not inﬂuence users’ online experi-

ence (Saxe et al., 2018).

To our consideration, malicious web links detec-

tion can be seen as a binary classiﬁcation problem,

where the input is a text representing an URL and

the output should be a class malicious or benign.

The present solution proposes a URL preprocessing,

where features are extracted from the URL to form the

feature vector using the term frequency-inverse docu-

ment frequency (TF-IDF) method. Thus, we can split

our problem deﬁnition into two stages: feature extrac-

tion and classiﬁcation. The feature extraction phase

can be described as f : WebLinks −→ R

, f(web link)

= (x

, x

, ..., x

), where d is the number of features

and x

, for each d ∈ N is a feature. Next, the classiﬁ-

cation is taking as input the feature vector computed

Coste, C.

Using Ensemble Models for Malicious Web Links Detection.

DOI: 10.5220/0012381800003636

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 16th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2024) - Volume 3, pages 657-664

ISBN: 978-989-758-680-4; ISSN: 2184-433X

657

with TF-IDF formula and it returns a class benign or

malicious, encoded as 0 or 1. f : R

−→ R, f(X) =

class.

Current solution proposes a nature-inspired en-

semble that could advance the research in malicious

web links detection. To our considerations, this

type of ensemble was not yet applied to malicious

web links detection. The ensemble is heterogeneous,

and it is formed with some of the best performing

machine learning (ML) algorithms and as a meta-

classiﬁer to adjust the weights, a Particle Swarm Op-

timization (PSO) algorithm is used. For the ML

models depicted to form the ensemble, we tested a

total of 12 methods, such as: Naive Bayes (NB)

variants (e.g., Bernoulli NB, Multinomial NB, Com-

plement NB), Perceptron, Passive Aggressive Clas-

siﬁer (PAC), Stochastic Gradient Descent Classiﬁer

(SGD), Nearest Centroid (NC), Logistic Regression

(LR), Adaptive Boosting (ADA), Decision Tree (DT),

Random Forest (RF), KMeans, K-Nearest Neighbor

(KNN), and Support Vector Machine (SVM) with dif-

ferent kernel values (e.g., polynomial, linear, radial

basis function and sigmoid). The approach is tested

against two datasets: D1 (GTKlondike, 2019) and D2

(Siddhartha, 2021). The best result for D1, an accu-

racy of 97.05%, is achieved with an ensemble formed

out of seven ML algorithms, improving the solution

provided in (Pakhare et al., 2021). On the second

dataset, D2, an ensemble with 3 classiﬁers achieved

just 91.12% accuracy, being not as efﬁcient as the ap-

proach in (Alsaedi et al., 2022). Still, we proposed a

novel detection model using TF-IDF for dataset D2.

The present approach is structured in four sec-

tions. In the next section, an overview of the current

state of the art is detailed in the domain of malicious

web links detection using ensemble models. The 3

section tackles the empirical methodology used for

the experiments. The 4 part discusses the results of

our experiments together with relevant comparisons.

The last section draws conclusions and presents future

directions for research.

2 PREVIOUS WORK

There has been work done considering ensemble

models when detecting malicious web links. Some

works take into consideration features extracted from

the link and others from the web content of the web

page. In both cases, ensembles are a better alternative

to single models considering accuracy. Additionally,

nature inspired algorithms are used for malicious web

links detection, especially Genetic Algorithm (GA)

and Particle Swarm Optimization (PSO).

2.1 Ensemble Models

Work done by (Pakhare et al., 2021) considers run-

ning individual models and ensemble models. The en-

semble is formed with three ML models, and the ﬁnal

output is decided by an equally deﬁned voting mech-

anism. The best ML individual model is LR, achiev-

ing 94.31% accuracy. The best ensemble was the one

containing KNN, DT and sigmoid SVM with an ac-

curacy of 94.93%. The preprocessing is done with the

TF IDF method. Similarly, (Subasi et al., 2021) com-

pares multiple types of homogeneous ensembles (e.g.,

AdaBoost, Random Subspace, Multi Boost, Bagging)

with multiple ML algorithms. All models are tested

using a private dataset containing 5000 URLs. Ran-

dom Subspace used in conjunction with KNN outper-

forms the rest with 89.24% accuracy rate.

Another stacked ensemble type was proposed by

(Alsaedi et al., 2022) with three RF models and a

MLP as meta-classiﬁer. Each RF model is specif-

ically tuned for a particular feature category. All

extracted features fall into three categories: lexical,

WHOIS features and Google Cyber Threat Intelli-

gence (CTI) characteristics. The RF model was cho-

sen based on multiple experiments where its perfor-

mance was compared with other ML models, includ-

ing some deep learning methods. The proposed so-

lution reaches 96.8% accuracy. The dataset used

is found in (Siddhartha, 2021). For experiments,

20,000 links were randomly sampled for each class.

This same dataset is used in (Shetty et al., 2023)

and in (Zhang and Yan, 2023). In (Shetty et al.,

2023) there is a comparison between tree-models

in a multi-classiﬁcation problem with four classes:

benign, phishing, defacement, and malware. The

weighted average across all classes is 97% for preci-

sion, recall and F1 score. Considering malicious web

links detection as a multi-classiﬁcation and a binary

problem, (Zhang and Yan, 2023) is delivering a com-

plex neural network (NN) model. The methodology

involves extracting features from the URL at a word-

piece level. For classiﬁcation, it used a multi-head

attention mechanism connected to a Convolutional

Neural Network (CNN) with N-gram. Word piece

representation of URL features is compared with char

and char & word representation. (Zhang and Yan,

2023) is using two datasets to prove their approach

and the Multi-ﬁlter CNN model was compared with

other deep learning methods proposed by literature.

2.2 Nature-Inspired Solutions

Exploring ensemble methods and GA, (Sajedi, 2019),

proposed a solution with REP trees and a meta-

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

658

classiﬁer developed with GA. This approach is com-

pared with other homogeneous ensemble types (e.g.,

AdaBoost, Bagging, Decorate, Rotation Forest) and

multiple classiﬁers. The features are manually engi-

neered and extracted from the HTML and JavaScript

ﬁles. Their proposed approach has an accuracy of

95.38% on a small dataset containing a total of 4,400

web pages.

The PSO algorithm is used to optimize classiﬁca-

tion process for phishing websites detection. For in-

stance, in (Gupta and Singhal, 2017), PSO is used to

better train an ANN model. Their proposed model

outperforms the Back Propagation Neural Network

(BPNN). The dataset is retrieved from (PhishTank,

2023), having 31 attributes and 11,055 records. Simi-

larly, to improve detection of phishing links, (Ali and

Malebary, 2020) is using PSO for feature weighting

and the classiﬁcation is done by multiple ML models

(e.g., BPNN, SVM, KNN, DT, RF, NB). For feature

selection, PSO-optimization is compared with GA,

information gain, wrapper, and chi-square test. The

best performance is reached by RF with PSO fea-

ture selection, with 96.83% accuracy. The dataset has

11,055 phishing and non-phishing websites. Another

solution proposed by (Lee et al., 2020) is using PSO

for malicious web links detection. More speciﬁcally,

PSO is run for feature selection to improve the ac-

curacy of NB and SVM classiﬁers. This approach

reaches 99% accuracy for both estimators. Moreover,

the PSO algorithm is used as well in an ensemble

but to build an intrusion detection system. (Aburom-

man and Reaz, 2016) is proposing a KNN-SVM-PSO

ensemble. PSO is used in comparison with meta-

optimized PSO and with weighted majority voting.

3 METHODOLOGY

The methodology followed when driving experiments

for our approach can be split into the next steps:

1. Preprocessing;

2. Balancing the datasets;

3. Run individual methods;

4. Run PSO ensemble models.

3.1 Preprocessing

The ﬁrst step of our methodology involves prepro-

cessing the database with TF-IDF vectorizer from

Python Sklearn library (Pedregosa et al., 2011). For

the experiments we used two databases, one from

(GTKlondike, 2019) (D1) and the other one from

(Siddhartha, 2021) (D2). Both datasets were pre-

viously used in other malicious web links detec-

tion solutions. The dataset (GTKlondike, 2019) was

used in (Pakhare et al., 2021) and the dataset (Sid-

dhartha, 2021) was used for binary classiﬁcation in

(Alsaedi et al., 2022) and for multi-label classiﬁca-

tion in (Zhang and Yan, 2023) and (Shetty et al.,

2023). There are not many details on how the data

within the ﬁrst dataset was collected, but there are a

total of 420,464 samples (344,821 benign and 75,643

malicious). The second dataset is freely available

on Kaggle and it was formed by aggregating multi-

ple datasets such as ISCX-URL-2016 (Mamun et al.,

2016), (malwaredomainlist, 2010), (Marchal et al.,

2014), (PhishTank, 2023), and (Joerg, 2017). D2 pro-

vides 651,191 URLs (428,102 benign, 32,520 mal-

wares, 94,111 phishing and 96,455 defacement). We

preprocessed it for binary classiﬁcation, the malware,

phishing, and defacement classes were merged. Even-

tually, in D2 there were 428,102 legitimate samples

and 223,086 malicious ones.

The TF-IDF preprocessing was done following

the methodology from (Pakhare et al., 2021), using

a TFIDF vectorizer.

3.2 Balancing the Datasets

Because in this domain of malicious web links de-

tection is quite common to deal with dataset imbal-

ancement problems, we chose to equal the number of

malicious and benign links. Thus, as in the methodol-

ogy followed by (Pakhare et al., 2021), from the ﬁrst

dataset D1 (GTKlondike, 2019) we used in experi-

ments 75,643 legitimate links and 75,643 malicious

ones. From the second dataset D2 (Siddhartha, 2021)

we chose to randomly depict just 20,000 records from

each class, as in (Alsaedi et al., 2022).

3.3 Run Individual Methods

There were experiments driven with multiple ML

algorithms, such as NB variants (e.g., Bernoulli

NB, Multinomial NB, Complement NB), Percep-

tron, PAC, SGD classiﬁer, NC, LR, ADA, DT, RF,

KMeans, KNN, and SVMs with different kernel val-

ues (e.g., polynomial, linear, radial basis function and

sigmoid). There are a total of 12 different ML mod-

els. We explicitly chose these algorithms such that

they would be suitable to work with sparse data since

the result of the TFIDF tokenization is a sparse ma-

trix. All models used in the experiments were imple-

mented in the Python Sklearn framework (Pedregosa

et al., 2011). Moreover, the algorithms were run

taking into consideration a parameters’ calibration

Using Ensemble Models for Malicious Web Links Detection

659

step, which was implemented with GridSearchCV

and RandomizedSearchCV (Pedregosa et al., 2011).

The values for the parameters were chosen accord-

ing to the documentation and our binary classiﬁcation

problem. For training 75% of the dataset was used,

while the rest of 25% was used for testing. Grid-

SearchCV and RandomizedSearchCV are both using

5-fold cross-validation to ﬁnd the best classiﬁer.

3.4 Run PSO Ensemble Models

Figure 1: The PSO-ensemble model.

The proposed ensembles are heterogeneous, and we

opted for a Voting Classiﬁer implemented in (Pe-

dregosa et al., 2011) with two voting strategies (i.e.,

’hard’ or ’soft’) and a set of weights to adjust the con-

tribution of each single classiﬁer compounding the

ensemble. A graphical representation of the ensem-

ble is presented in Figure 1. The ﬁnal decision is a

weighted average of each output given by the classi-

ﬁers. The ML algorithms that are going to form the

ensemble were depicted from TOP 3, TOP 5, or TOP

7 individual algorithms. This algorithm selection was

proposed because, to our considerations, an uneven

number of models forming the ensemble would be

more efﬁcient. Moreover, in (Pakhare et al., 2021)

and (Alsaedi et al., 2022), the solutions proposed by

them are using ensembles constructed with three clas-

siﬁers.

The weights are generated based on the PSO al-

gorithm. The PSO algorithm was ﬁrst proposed in

(Kennedy and Eberhart, 1995) and it was inspired by

how birds cooperate in a ﬂock when searching for

food. Each possible solution is represented by a bird,

which is described by a position and a velocity. Each

candidate stores its best position and the best global

position obtained by the ﬂock. At each iteration, birds

are updating their positions and velocities according

to their previous records using the inertia coefﬁcient

(w) and based on the ﬂock’s previous positions by

considering a cognitive factor (c1) and a social pa-

rameter (c2).

In the ensemble’s case, we used 75% of data for

training and 25% for testing. The training set is fur-

ther split into 75% exclusively for training and 25%

Table 1: Details on how the PSO ensemble was calibrated.

Parameters Values

Type (Ens.) {TOP 3, TOP 5, TOP 7}

Strategy - weight

voting (Ens.)

{weight voting hard,

weight voting soft}

no iterations

(PSO)

10, 100, 300, 500

no particles

(PSO)

10, 30, 50, 80, 100

c1, c2, w (PSO) randomly uniformly dis-

tributed [0.5, 0.99]

c1, c2, w strategy

(PSO)

{exp decay, nonlin mod,

lin variation}

for validation. Based on the validation set, the PSO

algorithm tries to optimize the ensemble accuracy by

adjusting the weights. Then after the weights are gen-

erated based on the validation, the testing is done. The

calibration process of the PSO ensemble is based on

multiple experiments. The parameters used to con-

ﬁgure our nature-inspired approach are: c1 (cogni-

tive parameter), c2 (social facto) and w (inertia coef-

ﬁcient), number of iterations, number of particles and

ensemble’s voting strategy (e.g., soft or hard). The

calibration was done in two steps to better manage

the computer’s resources and time. The ﬁrst stage in-

volves the calibration of the adjusting strategies for

the PSO options parameters (i.e., c1, c2, w), their ini-

tial values and the ensemble’s strategy. During this

stage the number of PSO iterations are established

at 200 and the number of particles at 20 for the ﬁrst

dataset and to 100 and 10 respectively, for the sec-

ond one. The initial values for the PSO options are

randomly generated from the 0.5 and 0.99 interval, as

in (Aburomman and Reaz, 2016). The results of the

ﬁrst phase are sorted according to the testing accu-

racy and an average value is computed for the c1, c2,

and w parameters. These mean values are going to be

the initial values for the w, c1, c2 parameters for the

second phase of calibration experiments. During the

second stage, the number of iterations is calibrated to-

gether with the number of particles. Table 1 has more

details on the parameter calibration done for the PSO-

ensemble solution.

PSO was chosen to adjust the weights of the

ensemble model based on the work developed by

(Sajedi, 2019), where a Genetic Algorithm is a meta-

classiﬁer for the ensemble. We chose PSO as a meta-

classiﬁer because of its previous usages for feature

optimization as in (Gupta and Singhal, 2017) and (Lee

et al., 2020). Because of its good results on feature

selection, we propose to experiment with it for the

weighting of the classiﬁers within an ensemble.

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

660

4 EXPERIMENTS

The next section presents details about the experi-

ments run on both single models and on ensemble

models. All experiments are developed with Python

version 3.9, using models already implemented in

Python scikit-learn library (Pedregosa et al., 2011)

version 1.0.2. The PSO implementation was from the

pyswarms library version 1.3.0 (Lester, 2017). The

empirical analysis was run on a 64-core machine with

64 GBs of RAM.

4.1 Individual Models Results

The current subsection tackles the performance of the

single algorithms on dataset D1 (Pakhare et al., 2021)

and on dataset D2 (Siddhartha, 2021). The results for

the individual algorithms run on D1 are graphically

presented in Figure 2a. It can be observed that the best

seven models are in order: SGD, PAC, Linear SVC or

SVC, Bernoulli, Complement and Multinomial NB,

LR. Thus, the ensembles for D1 are formed with:

• TOP 3 ensemble: SGD + PAC + linear SVC;

• TOP 5 ensemble: SGD + PAC + linear SVC +

Bernoulli NB + Complement NB;

• TOP 7 ensemble: SGD + PAC + linear SVC +

Bernoulli NB + Complement NB + Multinomial

NB + LR.

Comparing the results achieved by Linear SVC

and SVC, we chose to continue with Linear SVC

model because there are small differences between

their metrics and because it is more efﬁcient con-

sidering time. Moreover, the best estimator for the

SVC model is using a linear kernel. In addition, in

Figure 2a, it could be observed that KMeans is un-

derperforming, reaching just 48.09% accuracy. This

may be due to the reason that having sparse TF-IDF

data and splitting it into just two clusters is not ac-

curate enough. Maybe working with other features,

especially less features, and in a multiclass prob-

lem, KMeans would perform better for malicious web

links detection.

The results for the single models run on D2 dataset

(Siddhartha, 2021) are presented in Figure 2b. There

is a resemblance between the results for D1 and D2,

the top seven models are almost the same. In both

cases, SGD has the best performance. While in the D1

case, SGD has a test accuracy of 96.73%, in D2 case

it achieves just 91.07% accuracy. Moreover, it can be

observed that the RF classiﬁer manages to reach ﬁfth

place on the D2 dataset, while for D1, RF misses the

top seven algorithms. In addition, there is not much of

a difference between the ranking obtained by NB vari-

ants and LR model by comparing the results for the

two datasets. A similarity between the results for both

datasets is the linear SVC and SVC reach almost the

same accuracy, placing them on the third and fourth

rank. For the same reasons as in the case of dataset

D1, we decided to further use Linear SVC instead of

SVC. For D2, KMeans is the worst performing algo-

rithm as it is in the D1’s case. The similarity between

the input data for D1 and D2 could be responsible for

such similar results. The top algorithms compound-

ing the ensembles are:

• Top 3 ensemble: SGD + PAC + Linear SVC;

• Top 5 ensemble: SGD + PAC + Linear SVC + RF

+ Bernoulli NB;

• Top 7 ensemble: SGD + PAC + Linear SVC + RF

+ Bernoulli NB + Multinomial NB + LR.

4.2 PSO Ensemble Results

Current subsection details the performance of the en-

semble models on both datasets. The experiments

were run on the data quantiﬁcations presented in Ta-

ble 2.

Table 2: The datasets for the experiments run on the ensem-

ble models.

Dataset D1 D2

Training 85,098 22,500

Validation 28,366 7,500

Testing 37,822 10,000

Total 151,286 40,000

Table 3: The parameters for PSO-ensemble conﬁguration.

Parameters D1 D2

Type (Ens.) TOP 7 TOP 3

Strategy - weight

voting (Ens.)

soft soft

no iterations (PSO) 100 100

no particles (PSO) 30 10

w (PSO) 0.815 0.747

c1 (PSO) 0.739 0.7904

c2 (PSO) 0.829 0.671

w strategy (PSO) exp decay exp decay

c1 strategy (PSO) lin variation exp decay

c2 strategy (PSO) nonlin mod nonlin mod

For both datasets, the calibration phase of the en-

semble’s parameters was done over two phases. In

the ﬁrst stage, the strategy parameters were calibrated

(i.e., w strategy, c1 strategy, c2 strategy, ensemble’s

Using Ensemble Models for Malicious Web Links Detection

661

(a) D1. (b) D2.

Figure 2: The accuracy and weighted average of F1 score for D1 and D2 for individual algorithms (metrics computed on the

testing set as an average of 10 different data splits).

strategy, its ML algorithms) and the initialization val-

ues for w, c1, and c2. Little differences have been

found in the experiments considering the ﬁrst calibra-

tion stage. Still, we depicted the values for the best

performance and continued with the second phase of

calibration. The chosen values for the parameters

are detailed in Table 3 for both datasets. It can be

observed that the calibration is rather similar, with

some exceptions such as the type of the ensemble,

the number of particles, the initialization values for

c2, the social parameter, and its updating policy. The

lin variation strategy is tuning the parameter linearly

decreasing or increasing it, while exp decay is up-

dating the parameter exponentially. The nonlin mod

strategy means that the parameter is updated consid-

ering a nonlinear modulation index. The initialization

values for w, c1, and c2 were computed as an aver-

age of the best ten ensemble conﬁgurations. From the

experiments run, there were little differences, at most

1%, between the performance obtained for different

values for the parameters.

All in all, the ﬁnal experiment involves running

the obtained conﬁguration on ﬁve different data splits

to get the proper results, which are going to be com-

pared with other similar approaches. The obtained ac-

curacy for D1 is detailed in Table 4 together with the

generated weights. It can be observed that the best

performing algorithm from the individual models has

the highest weight in the ensemble. This is true, as

well, for the least performing ML method, LR. The

rest of the intelligent mechanisms are weighted ac-

cording to the validation set, trying to adjust the en-

semble to be robust and ﬂexible.

Considering the ﬁrst stage of experiments for the

D2 ensemble, there were no signiﬁcant differences

between the parameters. Still, the methodology tries

to maximize the performance of our algorithm and

continues with the values that obtain the best accu-

racy scores. The tuned values for the PSO-ensemble

are presented in 3. The last experiment on D2 runs

the ﬁne-tuned conﬁguration on ﬁve data splits. The

D2 ensemble reaches an accuracy of 91.112% as it is

displayed in Table 4. Moreover, in the same table,

there are detailed the obtained weights from running

PSO. As was observed in the case for D1 dataset, the

best performing individual algorithm has the largest

weight. In this case, the SGD algorithm has the

largest weight, and it is followed by the Linear SVC,

which is the third performing algorithm. PAC has the

lowest weight, even though it is in second place con-

sidering its efﬁciency as a solo algorithm. This may

be because the PSO-ensemble is trained to be robust

and more ﬂexible, such that on the testing set (unseen

data) it would still perform well enough. Taking into

consideration the time used for training and testing

an ensemble as seen in Table 4, running an ensem-

ble is considerably more expensive than using a sin-

gle model. SGD has a training time of approximately

2,416 ms on D1 and 612 ms on D2. The same thing is

observable for the testing time which is smaller com-

pared to the testing time of the ensembles. SGD has 2

ms for testing on D1 and 0.58 ms for D2. In this case,

using ensembles is a trade-off between accuracy and

running time because accuracy is improved compared

with the single models.

4.3 Comparisons and Discussion

For this approach, we chose to follow the data pre-

processing methodology from (Pakhare et al., 2021).

In this way, the comparison provided is very accu-

rate and relevant. Moreover, the dataset was freely

available, and the methodology was proposing TF-

IDF lexical features. Lexical features are not time

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

662

Table 4: The generated weights and the ﬁnal metrics (i.e. accuracy, F1 score - weighted average, training and testing time) for

the PSO ensembles.

Weights obtained for the PSO ensemble (weight, classi-

ﬁer)

Acc. F1

score

Training

time (ms)

Testing

time (ms)

D1 {(1.61, SGD), (1.05, ComplementNB), (1.01,

BernoulliNB), (0.73, PAC), (0.57, MultinomialNB),

(0.29, LinearSVC), (0.26, LR)}

97.0546 97.0545 3,291,308 58

D2 {(0.58, SGD), (0.38, LinearSVC), (0.26, PAC)} 91.112 91.107 107,317 4

dependent; they are not directly dependable if the on-

line content of a web link changes over time. Thus,

their methodology enables the experiments to be eas-

ily reproducible. In (Pakhare et al., 2021), the authors

propose LR, as the best individual algorithm with an

accuracy of 94.31% and the majority voting ensemble

KNN-DT-SVM with 94.93% accuracy. The graphical

representation from Figure 3 presents the accuracies

previously obtained in literature and our obtained per-

formances. It can be observed that with SGD (96.66%

accuracy) as a single algorithm, we managed to sur-

pass the best accuracy reached for the KNN-DT-SVM

ensemble in (Pakhare et al., 2021). Moreover, our Top

7 ensemble (97.05% accuracy) tested against dataset

D1 manages to further improve the accuracy. It is

clear and logical for an ensemble model to improve

accuracy of single models. As well, it can be ob-

served that, the ensemble presented in (Pakhare et al.,

2021) improved the classiﬁcation with 0.62% com-

pared with the single model, while in our case, we

improved performance with just 0.39%.

The model proposed in (Alsaedi et al., 2022)

reaches 96.8% accuracy. The algorithm is an ensem-

ble as well, formed out of three RFs, and a MLP,

that works as a meta-classiﬁer. We proposed to keep

the TF-IDF methodology developed on D1 and ap-

ply it on D2, such that we were able to intra-compare

our methods. Moreover, their used features such

as Google CTI-based characteristics and WHOIS in-

formation are time-dependent features, which may

change over time. The process of feature retrieval

is time-consuming, and it may not even be accurate.

Even though the comparison between our proposed

models and the ensemble proposed by (Alsaedi et al.,

2022) may not be error-less or precise, there is still

a contribution to their research by applying a new

methodology and a new ensemble model. Moreover,

there are differences because (Alsaedi et al., 2022)

split the dataset into training 70% and 30% for test-

ing and they added a feature selection step.

Even though the current results on D2 are satis-

factory, they do not manage to improve the results ob-

tained in (Alsaedi et al., 2022). With SGD as a single

algorithm, an accuracy of 90.95% is obtained as it can

be seen in 3. With the TOP 3 ensemble, an improve-

ment is made with respect to the individual model,

the ensemble achieving 91.122%. Even though our

TF-IDF and PSO-ensemble approach is inaccurate in

this case, we must conclude that maybe the charac-

teristics extracted by (Alsaedi et al., 2022) (lexical,

WHOIS information and Google CTI-based features)

are more relevant than TF-IDF features. This could

support the fact that maybe time-dependent features

could add valuable information to the input data and

reduce the complexity of the ML model. To conclude

that our model is worse than theirs, there needs to be

more experiments using the same feature categories

as input. Still, we managed to propose a novel ap-

proach using a PSO-weights ensemble and TF-IDF

features on the D2 dataset. An improvement we could

add to our proposed methodology could be adding a

feature selection step. In addition, the TOP 3 ensem-

ble used for D2 may overﬁt and to prevent that we

could rerun the ensemble experiments on the TOP 5

and TOP 7 ensemble as well.

Figure 3: Comparisons between our approaches and models

presented in (Pakhare et al., 2021) and (Alsaedi et al., 2022).

5 CONCLUSIONS

Because of the continuous improvements made in the

web security ﬁeld, attackers come with new ways of

deceiving the detection mechanisms. Consumers are

Using Ensemble Models for Malicious Web Links Detection

663

affected as well; they are easily lured into clicking

malicious links. The current approach proposed a

novel PSO ensemble to improve and advance research

done in the maliciousness detection problem of web

links. Our ensemble is heterogeneous, combining

multiple ML algorithms that proved to be efﬁcient in-

dividually. The combining mechanism uses weights,

which are generated with the PSO algorithm on a vali-

dation set. The experiments follow a calibration stage,

and they are tested on two different datasets. The re-

sults achieved on the ﬁrst dataset (97.05% accuracy)

improve the previous solution. In contrast, for the

second dataset, our approach is not so accurate com-

pared to the solution found in literature. There are

still things to improve, but, to our considerations, we

manage to propose an innovative empirical approach

on malicious web links detection.

Considering future work, we propose to develop

a real-time reporting framework that aims to collect

data associated with a link, including time-dependent

features that can improve detection algorithms and re-

duce their complexity. Time-dependent features in-

clude network information if the web link was in-

cluded in blacklists or whitelists. The framework is

supposed to get a snapshot with the current link data.

Moreover, we propose to test this PSO-ensemble

against larger datasets to further prove its efﬁciency

and robustness.

REFERENCES

Aburomman, A. A. and Reaz, M. B. I. (2016). A novel

svm-knn-pso ensemble method for intrusion detection

system. Applied Soft Computing, 38:360–372.

Ali, W. and Malebary, S. (2020). Particle swarm

optimization-based feature weighting for improving

intelligent phishing website detection. IEEE Access,

8:116766–116780.

Alsaedi, M., Ghaleb, F. A., Saeed, F., Ahmad, J., and Alasli,

M. (2022). Cyber threat intelligence-based malicious

url detection model using ensemble learning. Sensors,

22(9):3373.

GTKlondike (2019). Machine-learning-for-security-

analysts. Dataset website.

Gupta, S. and Singhal, A. (2017). Phishing url detection by

using artiﬁcial neural network with pso. In 2017 2nd

International Conference on Telecommunication and

Networks (TEL-NET), pages 1–6. IEEE.

IT, A. (2023).

Joerg, S. (2017). Using-machine-learning-to-detect-

malicious-urls. faizan dataset website.

Kennedy, J. and Eberhart, R. (1995). Particle swarm opti-

mization. In Proceedings of ICNN’95-international

conference on neural networks, volume 4, pages

1942–1948. IEEE.

Lee, O. V., Heryanto, A., Ab Razak, M. F., Raffei, A. F. M.,

Phon, D. N. E., Kasim, S., and Sutikno, T. (2020).

A malicious urls detection system using optimization

and machine learning classiﬁers. Indonesian Jour-

nal of Electrical Engineering and Computer Science,

17(3):1210–1214.

Lester, J. V. (2017). Welcome to pyswarms’s documenta-

tion!

malwaredomainlist (2010). Malware domain list. malware-

domainlist.

Mamun, M. S. I., Rathore, M. A., Lashkari, A. H.,

Stakhanova, N., and Ghorbani, A. A. (2016). Detect-

ing malicious urls using lexical analysis. In Network

and System Security: 10th International Conference,

NSS 2016, Taipei, Taiwan, September 28-30, 2016,

Proceedings 10, pages 467–482. Springer.

Marchal, S., Franc¸ois, J., State, R., and Engel, T. (2014).

Phishstorm: Detecting phishing with streaming ana-

lytics. IEEE Transactions on Network and Service

Management, 11(4):458–471.

Pakhare, P. S., Krishnan, S., and Charniya, N. N. (2021).

Malicious url detection using machine learning and

ensemble modeling. In Computer Networks, Big Data

and IoT, pages 839–850. Springer, Singapore.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer,

P., Weiss, R., Dubourg, V., Vanderplas, J., Passos,

A., Cournapeau, D., Brucher, M., Perrot, M., and

Duchesnay, E. (2011). Scikit-learn: Machine learning

in Python. Journal of Machine Learning Research,

12:2825–2830.

PhishTank (2023). PhishTank - Out of the Net, into the Tank

- Developer Information. PhishTank website.

Sajedi, H. (2019). An ensemble algorithm for discovery of

malicious web pages. International Journal of Infor-

mation and Computer Security, 11(3):203–213.

Saxe, J., Harang, R., Wild, C., and Sanders, H. (2018). A

deep learning approach to fast, format-agnostic detec-

tion of malicious web content. In 2018 IEEE Security

and Privacy Workshops (SPW), pages 8–14, San Fran-

cisco, CA, USA. IEEE, IEEE.

Shetty, U., Patil, A., and Mohana, M. (2023). Malicious

url detection and classiﬁcation analysis using machine

learning models. In 2023 International Conference

on Intelligent Data Communication Technologies and

Internet of Things (IDCIoT), pages 470–476. IEEE.

Siddhartha, M. (2021). Malicious urls dataset. Kaggle -

Malicious URLs dataset.

Subasi, A., Balfaqih, M., Balfagih, Z., and Alfawwaz, K.

(2021). A comparative evaluation of ensemble classi-

ﬁers for malicious webpage detection. Procedia Com-

puter Science, 194:272–279.

Zhang, L. and Yan, Q. (2023). Detect malicious websites by

building a neural network to capture global and local

features of websites. Research Square.

ICAART 2024 - 16th International Conference on Agents and Artiﬁcial Intelligence

664
