Beyond Variational Models and Self-Similarity in Super-Resolution:

Unfolding Models and Multi-Head Attention

Ivan Pereira-S

anchez

1,2 a

, Eloi Sans

1 b

, Julia Navarro

1,2 c

and Joan Duran

1,2 d

Departament de Ci

encies Matem

atiques i Inform

atica, Universitat de les Illes Balears (UIB), Spain

Institute of Applied Computing and Community Code (IAC3), Spain

Keywords:

Unfolding, Multi-Head Attention, Image Super-Resolution, Variational Methods, Nonlocal Regularization,

Self-Similarity.

Abstract:

Classical variational methods for solving image processing problems are more interpretable and ﬂexible than

pure deep learning approaches, but their performance is limited by the use of rigid priors. Deep unfolding

networks combine the strengths of both by unfolding the steps of the optimization algorithm used to estimate

the minimizer of an energy functional into a deep learning framework. In this paper, we propose an unfolding

approach to extend a variational model exploiting self-similarity of natural images in the data ﬁdelity term for

single-image super-resolution. The proximal, downsampling and upsampling operators are written in terms

of a neural network speciﬁcally designed for each purpose. Moreover, we include a new multi-head attention

module to replace the nonlocal term in the original formulation. A comprehensive evaluation covering a wide

range of sampling factors and noise realizations proves the beneﬁts of the proposed unfolding techniques. The

model shows to better preserve image geometry while being robust to noise.

1 INTRODUCTION

The goal of image super resolution is to recover a

high-resolution image from a low-resolution obser-

vation of it. This ﬁeld has signiﬁcant importance

due to its numerous practical applications, includ-

ing satellite imaging, biometric information identiﬁ-

cation, medical imaging, remote sensing, microscopy

image processing, surveillance, multimedia industry,

video enhancement or astrological studies, among

others (Lepcha et al., 2023).

In the literature, a wide variety of methods have

been proposed to address image super-resolution.

One may roughly divide them into interpolation,

model-based, and learning-based methods.

Interpolation methods are commonly used for

quickly generating zoomed images, providing a good

compromise between efﬁciency and quality. These

methods typically estimate pixel intensity using ﬁxed

kernels, such as local variance coefﬁcients (Keys,

1981), or adaptive structural kernels (Li and Orchard,

2001; Zhang and Wu, 2006). While these methods

https://orcid.org/0000-0002-9400-5720

https://orcid.org/0009-0000-7702-2425

https://orcid.org/0000-0003-3667-7008

https://orcid.org/0000-0003-0043-1663

are efﬁcient, they can introduce artifacts. For applica-

tions demanding greater precision, more sophisticated

techniques are required.

Model-based methods assume that the low-

resolution observed image is derived from the sought

high-resolution one after applying a sequence of op-

erators, usually blur ﬁltering and downsampling. Re-

versing such a process is an ill-posed inverse prob-

lem, thus prior knowledge on the structure of nat-

ural images must be assumed to regularize it. The

most popular model-based methods are variational

models, which deﬁne an energy functional that in-

duces a high energy when the priors are not ful-

ﬁlled. The total variation (TV) semi-norm (Rudin

et al., 1992) and nonlocal regularization terms, which

exploit image self-similarities (Duran et al., 2014;

Wang et al., 2019; Gilboa and Osher, 2009), have

been mainly used as regularization terms in the varia-

tional framework. Several variational methods have

been proposed in the literature to deal with image

super-resolution (Yue et al., 2016). In this setting,

the total variation (TV) semi-norm (Babacan et al.,

2008) and nonlocal regularization exploiting image

self-similarities (Dong et al., 2011; Dong et al., 2013;

Zhang et al., 2012) have been mainly used as priors.

Recently, (Pereira-S

anchez et al., 2022) proposed to

190

Pereira-Sánchez, I., Sans, E., Navarro, J. and Duran, J.

Beyond Variational Models and Self-Similarity in Super-Resolution: Unfolding Models and Multi-Head Attention.

DOI: 10.5220/0012395400003660

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2024) - Volume 3: VISAPP, pages

190-198

ISBN: 978-989-758-679-8; ISSN: 2184-4321

leverage the self-similarity in the ﬁdelity term rather

than in the regularization term.

In the last decade, a growing number of deep

learning-based super-resolution methods have been

suggested in the literature and showed promising re-

sults. These approaches can be categorized depend-

ing on their architectures. In this setting, we can

ﬁnd residual connections (Tai et al., 2017; Lim et al.,

2017), generative adversarial networks (Bell-Kligler

et al., 2019), or attention modules (Dai et al., 2019).

In fact, attention modules are based on the assumption

that images are self-similar and are the key of vision

transformers, which have become remarkably popular

(Wang et al., 2022; Lu et al., 2022).

The use of observation models makes variational

methods robust to distortions, but their performance is

limited by rigid hand-crafted priors. On the contrary,

data-driven learning approaches can easily learn natu-

ral priors, but are less ﬂexible and interpretable. Deep

unfolding networks (Monga et al., 2021) combine the

strengths of both. The general idea consists in un-

folding the steps of the optimization algorithm used

to estimate the minimizer of an energy functional into

a deep learning framework. Since these networks do

not model the complete problem but particular oper-

ations, architectures are shallower than pure learning

approaches. Besides, the unfolding process avoids the

need of deﬁning an explicit prior in the model-based

formulation. This results in efﬁcient and highly inter-

pretable methods whose network architectures can be

trained on acceptable-sized datasets.

In this paper, we propose to extend the variational

model in (Pereira-S

anchez et al., 2022) with algo-

rithm unfolding techniques. This model leverages the

self-similarity of natural images in the ﬁdelity term.

We use the proximal gradient algorithm to compute

the minimizer of the proposed energy functional and

replace all proximal, downsampling and upsampling

operators with a neural network speciﬁcally tailored

to model each function. In addition, we introduce a

new multi-head attention module to take the place of

the nonlocal term in the original formulation. Exten-

sive experiments under different sampling factors and

noise realizations of the proposed approach demon-

strate the effectiveness of the presented method.

The rest of the paper is organized as follows. Sec-

tion 2 presents the proposed model. Section 3 cov-

ers implementation details. Experimental results in

comparison with other methods are included in Sec-

tion 4, while Section 5 analyses the different compo-

nents of our model. Finally, Section 6 provides the

conclusions and outlines the future work. The source

code of the proposed method is publicly available at

https://github.com/TAMI-UIB/UNLDSR.

2 PROPOSED MODEL

The most common observation model in image super-

resolution relates the observed data f with the under-

lying image u via

f = DBu + η, (1)

where D is a decimation operator and B is a low-pass

ﬁlter. Then, DB is a linear operator modelling the

degradation of u and η is the realization of i.i.d. zero-

mean noise. Since solving (1) is an ill-posed inverse

problem, the choice of a good prior is required.

2.1 Variational Formulation

Let us denote the low resolution image as f ∈ R

C×N

where N is the number of pixels and C is the num-

ber of spectral bands, and the restored image as u ∈

C×M

:= X , with M > N.

Classical variational models for image restoration

include the ﬁdelity term

∥DBu − f ∥

∑

k=1

∑

i=1

((DBu)

k,i

− f

k,i

)

(2)

In order to take advantage of image self-similarity, the

work in (Pereira-S

anchez et al., 2022) extends the pre-

vious energy to a nonlocal framework, replacing the

previous term by a nonlocal data term. We propose

to enhance the performance of this nonlocal ﬁdelity

term by incorporating learning-based modules in the

variational framework. In particular, we consider the

super-resolution variational model

min

u∈X

R(u) +

∥(DBu − f )

∥

, (3)

where R : X → [−∞, +∞] is a strictly convex, coer-

cive and lower-semicontinuous functional that plays

the role of the regularitzation term, λ > 0 is a trade-

off parameter, and (DBu − f )

∈ R

C×N×N

is deﬁned

∥(DBu − f )

∥

∑

k=1

∑

i, j=1

i, j



(DBu)

k,i

− f

k, j



The weights {ω

i, j

} are originally computed on the

observed data f , taking into account both the spatial

closeness and the spectral similarity in f .

Since the proposed energy (3) is also strictly con-

vex, coercive and lower-semicontinuous, the exis-

tence and uniqueness of minimizer is guaranteed. In

contrast to (Pereira-S

anchez et al., 2022), the prior R

does not have a speciﬁc form in our formulation, since

it will be folded into the learning-based scheme. This

will permit to learn the regularization on u from train-

ing data.

Beyond Variational Models and Self-Similarity in Super-Resolution: Unfolding Models and Multi-Head Attention

191

𝐷𝑜𝑤𝑛

𝑀𝐻𝐴

τ · 𝑈𝑝

𝑃𝑟𝑜𝑥𝑁𝑒𝑡

𝑢

!" #

𝑓

x(−1)

Figure 1: Illustration of one stage of the proposed model,

which unfolds Equation (5). Down

represents the down-

sampling DB, and Up

is its transposed counterpart (DB)

MHA

denotes the multi-attention module that substitutes

the nonlocal operator in the data term, and ProxNet

is the

architecture that replaces the proximity operator.

2.2 Proximal Gradient

We use the proximal gradient algorithm (Combettes

and Wajs, 2005; Chambolle and Pock, 2016) to min-

imize (3). Given a Hilbert space Z, when consider-

ing a proper, lower semi-continuous convex function

R : Z → [−∞, +∞], the associated proximal operator

is deﬁned as

prox

τR

(x) = argmin

y∈Z

R(y) +

2τ

∥y − x∥

, (4)

which can be seen as a generalization of the projection

operators.

The iterative scheme given by the proximal gradi-

ent algorithm becomes

=prox

τR



− τ∇F

)



=prox

τR



− τ(DB)

(DBu − f

)



(5)

where (DB)

is the transposed operator of DB and

∑

j∈X

i, j

2.3 Algorithm Unfolding

We propose to unfold (5) and replace the operators

involved the iterative scheme with learning-based net-

works. In particular, we replace prox

τR

by ProxNet

DB with Down

, (DB)

with Up

and the nonlocal

operator by a multi-head attention module MHA

With these replacements we allow the operators to

learn the intrinsic properties and geometry of natural

images. In addition, by rewriting the proximity opera-

tor with a neural network, we avoid the need of speci-

fying the prior on u, which will be implicitly modelled

by the network.

In the following we accurately describe these net-

works. Also, in the rest of the paper we refer to each

step k in the iterative scheme as a stage. Figure 1 il-

lustrates one stage of the proposed approach. In the

ﬁrst stage, u

is initialized with bicubic interpolation.

2.3.1 From Proximal Operator to Residual

Network

The proximal operator deﬁned in (4) can be reduced

ˆy = prox

τR

(x) ⇐⇒ x ∈ ˆy + τ∂R( ˆy)

⇐⇒ ˆy ∈ (Id + τ∂R)

−1

(x),

where ∂R is the sub-differential operator. Therefore,

we can view the proximal operator as the inverse of

a perturbation of the identity. Given this perspective,

residual networks are good candidates for replacing

the proximal operator in the unfolding context. They

consist of a convolutional neural network followed by

a skip connection, also known as a residual connec-

tion, making it an approach to identity.

Then, we replace the prox

τR

function by a resid-

ual network ProxNet

. We maintain the same archi-

tecture in all stages but without sharing the weights.

This architecture is depicted in Figure 2.

2.3.2 Upsampling and Downsampling Operators

The classic downsampling operator DB is modelled

with a convolution by a Gaussian kernel of σ

blur

stan-

dard deviation, followed by a decimation operator.

We propose to learn this operator by modelling it with

two 2-dimensional convolutions. The ﬁrst convolu-

tion substitutes the Gaussian convolution and their

parameters are determined by the standard deviation

blur

. While the decimation operator is replaced by

another convolution which stride equals the sampling

factor.

On the other hand, the upsampling operator

(DB)

is classically modelled by a zero-padding op-

erator followed by a Gaussian convolution of the same

standard deviation. We replace this upsampling by a

concatenation of transposed 2-dimensional convolu-

tions, which serve the purpose of zero padding, fol-

lowed by a 2-dimensional convolution that replaces

the Gaussian convolution. To determine the concate-

nation of transposed convolutions, we consider the

prime decomposition of sampling factors, sorted in

ascending order as s = p

· . . . · p

. This decompo-

sition determines the steps of the concatenation. For

a prime number p, we denote T C

as the transposed

convolution with a stride equal to p. Using this nota-

tion, we can describe the concatenation as the follow-

ing composition:

z }| {

T C

◦ ·· · ◦ T C

| {z }

◦·· · ◦ T C

◦ ·· · ◦ T C

{z }

This formula is designed to simplify the upsampling

operation by decomposing it into the smallest feasible

steps.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

192

𝑢

Conv2d

𝐷𝑜𝑤𝑛(𝑢)

Conv2d

stride =s

𝑢

Conv2d

𝑈𝑝(𝑢)

TConv2d

stride =2

TConv2d

stride =2

𝑢

Conv2d

ReLU

Conv2d

ReLU

Conv2d

ReLU

Conv2d

ReLU

Conv2d

𝑃𝑟𝑜𝑥𝑁𝑒𝑡(𝑢)

Figure 2: Diagrams of the downsampling and upsampling

architectures for a sampling factor of 4, and ProxNet net-

work. We keep the same architectures at each stage, but

weights are not shared.

These replacements lead to the new downsam-

pling and upsampling operators, Down

and Up

, re-

spectively, which appear in Figure 1. Importantly, the

involved parameters in both upsampling and down-

sampling are not shared per stage. An example illus-

trating the proposed downsampling and upsampling

processes for a sampling factor of 4 is shown in Fig-

ure 2.

2.3.3 From Self-Similarity to Multi-Head

Attention

In the variational model, the weights {ω

i, j

} are com-

puted on the observed data f , taking into account the

similarities in f . This similarity is computed by con-

sidering a whole patch around each pixel and using

the Euclidean distance across channels. For compu-

tational purposes, nonlocal interactions are limited to

pixels at a certain distance. In practice, the weights

are deﬁned as

i, j

exp

−



f (P

) − f (P

)



sim

if ∥i − j∥

∞

≤ ν and zero otherwise. In this setting,

ν ∈ Z

determines the size of the window to search

for similar pixels, P

denotes a patch centered at pixel

i, and Γ

is a normalitzation factor. The ﬁltering pa-

rameters h

spt

> 0 measure how fast the weights decay

with increasing dissmilarity between patches.

In (Wang et al., 2018), this expression is simpli-

ﬁed by considering ω

i, j

exp( f (i)

f ( j)), and by

computing the similarity using the dot product while

employing the spectral representation of the image x

at pixel i. The primary motivation for this simpliﬁ-

cation is that the dot product is computationally more

efﬁcient, and the difference between the distance and

the dot product does not yield signiﬁcant differences

in practice. Furthermore, they propose a simple ex-

tension of these weights by incorporating a convolu-

𝑓

𝐻𝐴

!"#

𝑎𝑢𝑥

𝐻𝐴

(𝑓)

𝐻𝐴

"#$

(𝑓)

𝐻𝐴

(!,"#$)

(𝑓)

MLP

concat

𝑀𝐻𝐴(𝑓 )

𝑓

Conv2d

𝐻𝐴

!"#

(𝑓)

Unfold

Reshape

Conv2d

Unfold

Reshape

Conv2d

Unfold

Reshape

Softmax

𝑎𝑢𝑥

Figure 3: Illustration of the multi-head attention and self-

attention networks. The same architecture is used at each

stage without sharing weights.

tion operation, such that,

i, j

exp((θ ∗ f )(i)

(φ ∗ f )( j)))

=softmax



(θ ∗ f )(i)

(φ ∗ f )( j)



Finally, they compute the nonlocal ﬁlter, denoted as

∑

i, j

, by reshaping the data and perform-

ing matrix multiplication between the last two dimen-

sions, which can be efﬁciently executed on a GPU.

This module, followed by a residual connection, is re-

ferred to as self-attention. This architecture has been

widely used and forms the basis of the well-known

transformer block, which concatenates the previous

architecture and follows it with a multi-layer percep-

tron (MLP).

In our approach, we propose to write the varia-

tional nonlocal module as a multi-head attention one.

Instead of working with the spectral representation

of individual pixels, we propose to compute the dis-

tance between pixels using the spectral representation

of patches, to obtain more robust weights. Moreover,

we concatenate three self-attention layers, employing

three different auxiliary images for weight computa-

tion: f , DBu, and the concatenation of both. The ar-

chitecture is detailed in Figure 3.

Beyond Variational Models and Self-Similarity in Super-Resolution: Unfolding Models and Multi-Head Attention

193

Reference VCLD UCLD

BIC VNLD UNLD (ours)

Figure 4: Close-ups of the results for single-image super-resolution on temple, with s = 2, σ

blur

= 0.75 and σ

noise

= 0. While

the variational methods give oversmooth results, both unfolded models better preserve the geometry and textures of the image.

3 IMPLEMENTATION DETAILS

3.1 Convolution Parameters

The convolution that replaces the Gaussian operators

in the downsampling and upsampling operators is de-

termined by the blur standard deviation, denoted as

blur

. The kernel size is calculated as [4σ

blur

]+1, and

the padding is set to the integer division of the kernel

size by 2. The padding consists of replicating the last

pixel at the boundary. This convolution operates in-

dependently on channel information, and the weights

are initialized with a Gaussian kernel.

For the transposed convolutions of the upsampling

operator, when given a prime factor p, the stride is

set equal to p, the kernel size is set to the smallest

odd number strictly greater than p, and consequently,

the padding is established as the integer division of

the kernel size by 2. In the case of the convolution

that replaces the decimation operator, the stride is set

equal to p, the kernel size is chosen as the smallest

odd number greater than the sampling factor, and the

padding is determined in the same way than the pre-

vious convolutions.

For all the convolutions in ProxNet we employ a

kernel size of 3 and a padding of 1. The number

of features added in the ﬁrst convolution before the

residual block is 16. These convolutions do not have

bias terms, except for the last convolution, which in-

cludes a bias.

Finally, the involved convolutions in the attention

module MHA have a kernel size equal to one and

therefore no padding is needed, any of these convo-

lution have bias. The window size deﬁned for the

neighbors in the multi-head attention is set to 5 for

all self-attentions. However, the patch size is equal to

3 for the self-attentions that use f and DBu, and it is

set to 1 for the one that uses the concatenation of both.

3.2 Training

We trained our complete system in an end-to-end

manner using the mean square error as loss function

for 400 epochs. The learning rate was initially set to

0.001 and was updated by a factor of 0.75 whenever

the loss for the training data did not decrease by more

than 0.0001 during the last 10 epochs. Regarding the

number of stages, a detailed study of its inﬂuence is

conducted in Section 5. For most experiments we

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

194

Reference VCLD UCLD

BIC VNLD UNLD (ours)

Figure 5: Close-ups of the results for single-image super-resolution on squirrel, with s = 4, σ

blur

= 1.4 and σ

noise

= 10. While

the variational methods face difﬁculties in reconstructing the textures of the images, the unfolded results yield better results.

Additionally, UNLD proves to be more effective in removing noise when compared to UCLD.

Figure 6: Set of images used for validation. From left to

right and from top to botom: stairs, lock, statue, squirrel,

temple, penguin.

have chosen to set it at 5 because it strikes a good bal-

ance between performance and computational cost.

3.3 Dataset

We have selected 19 images from the DIV2K dataset

and cropped each of these images to a size of

512x512. These crops have been divided into 13 for

training, with the remaining 6 for validation, consid-

ering these crops as the reference images. Figure 6

displays the validation data. The low-resolution im-

ages are generated by applying a Gaussian kernel,

followed by bicubic interpolation for downsampling,

and then adding Gaussian noise with a standard devi-

ation in the range of [0, 255].

4 RESULTS

In this section, we assess the performance of the pro-

posed unfolded nonlocal model (UNLD) and compare

it with other methods. In particular, we compare with

the unfolding of the variational model that uses the

classic data ﬁdelity term from Equation (2) (UCLD).

This comparison will prove the inﬂuence of the multi-

head attention module. Also, we include two varia-

tional models, the conventional classic data (VCLD),

and the one with the nonlocal data term (VNLD) from

(Pereira-S

anchez et al., 2022). Both of these vari-

ational methods use total variation as regularization.

Additionally, we include the bicubic (BIC) interpola-

tion method in our evaluation.

The comparison is conducted by using sampling

factors of 2 and 4, with standard blur deviations of

0.75 and 1.4, respectively. In both cases, the mod-

els have been evaluated for different realizations of

noise, with standard deviations of 0, 5, 10, and 25.

The parameters of the variational methods have been

optimized using the image penguin from the valida-

tion set.

Beyond Variational Models and Self-Similarity in Super-Resolution: Unfolding Models and Multi-Head Attention

195

Table 1: Results for a sampling factor of 2, a blur level of 0.75, and various noise levels: 0, 5, 10, and 25. The comparison is

based on PSNR and SSIM metrics, with the averages computed across the entire validation data. Bold numbers indicate the

best metrics for the mean, and the italic numbers represent the second-best metrics. Notably, the proposed UNLD achieves

the best metrics across all noise levels.

BIC VCLD VNLD UCLD UNLD

Noise PSNR SSIM PSNR SSIM PSNR SSIM PSNR SSIM PSNR SSIM

0 26,33 0,784 28,29 0,811 29,40 0,871 29,31 0,870 29,57 0,876

5 25,69 0,716 27,61 0,781 27,95 0,805 28,39 0,822 28,49 0,826

10 24,33 0,595 26,58 0,738 26,63 0,739 27,01 0,758 27,30 0,775

25 20,18 0,342 24,02 0,597 24,48 0,624 24,79 0,648 24,86 0,654

Table 2: Results for a sampling factor of 4, a blur level of 1.4, and various noise levels: 0, 5, 10, and 25. The comparison is

based on PSNR and SSIM metrics, with the averages computed across the entire validation data. Bold numbers indicate the

best metrics for the mean, and italic numbers represent the second-best metrics. Notably, the unfolded nonlocal data achieves

the best metrics across all noise levels.

BIC VCLD VNLD UCLD UNLD

Noise PSNR SSIM PSNR SSIM PSNR SSIM PSNR SSIM PSNR SSIM

0 24,37 0,640 24,22 0,647 24,24 0,658 24,77 0,670 24,81 0,672

5 23,96 0,598 23,88 0,609 23,89 0,616 24,34 0,630 24,37 0,633

10 22,98 0,517 23,33 0,569 23,37 0,575 23,77 0,590 23,88 0,601

25 19,53 0,318 22,04 0,498 22,11 0,503 22,35 0,515 22,38 0,518

The quantitative results can be found in Tables 1

and 2 for sampling factors of 2 and 4, respectively.

Our method achieves the best metrics for both sam-

pling factors and for all noise realizations. Moreover,

the second-best metrics are achieved by the other un-

folding method. This corroborates the fact that un-

folding methods are capable of learning the intrin-

sic and natural geometry of the images better than

variational methods. Furthermore, the superiority of

UNLD over UCLD demonstrates the importance of

the multi-head attention module.

Moreover, the qualitative results are showcased in

Figures 4 and 5. The visual comparison aligns with

the quantitative results. In both examples, variational

methods VNLD and VCLD provide oversmooth solu-

tions while their unfolded versions UNLD and UCLD

better preserve the image geometry and textures.

However, in Figure 5 the proposed UNLD shows to

be superior to UCLD in removing noise. When as-

sessing the performance of both models, it becomes

evident that the nonlocal model consistently outper-

forms its counterpart when subjected to varying de-

grees of noise.

5 ABLATION STUDY

In this section, we evaluate the inﬂuence of differ-

ent components of our system. First, we explore

the efﬁcacy and robustness of various residual net-

works architectures within our context. Four propos-

als of residual networks were considered to replace

the proximal network ProxNet. These proposals can

be divided into two different approaches. The ﬁrst

approach incorporates the argument in the proximal

network provided by Equation (5), i.e., u − τ∇F

Within this approach, we tested two similar architec-

tures: one with batch normalization, denoted as Net

and the other without batch normalization, denoted as

Net

. The second approach introduces a concatena-

tion of u and ∇F

instead. Within this approach, we

tested two similar architectures: one without adding

features to u and ∇F

, denoted as Net

, and the other

adding features, denoted as Net

. Table 3 demon-

strates that the second option delivers the best perfor-

mance, indeed, this architecture is the one used in our

model, as shown in Figure 2.

Next, we study the behaviour of the model un-

der different samplings of the data. We evaluated the

model with samplings 2, 3, 4 and 8 and blur 0.75,

1, 1.4, 1.8, respectively, all of them with absence of

noise. The results of both unfolding models is shown

in Table 4. As expected, the greater the sampling

the lower metrics, but in every scenario the nonlocal

model UNLD outperforms the classic model UCLD.

This behaviour conﬁrms the adaptability of the model

to different data types.

Also, we have tested the performance of UNLD in

a scenario with high noise level. Figure 7 illustrates

that the model can reconstruct an image even with a

noise level of 50 in the case of sampling 2 and blur

0.75.

Finally, we checked the inﬂuence of the selected

number of stages in the iterative process. We trained

UCLD and UNLD models with 3, 5, and 7 stages.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

196

Reference BIC UNLD

Figure 7: Example showcasing the robustness to high noise level of UNLD. The images were generated from an input image

with a sampling factor of 2, a blur level of 0.75, and a noise level of 50.

Figure 8: Evolution of PSNR as a function of the number

of stages and noise values. Each PSNR value corresponds

to the average value over the validation set.

Table 3: Results for sampling factor 2, blur level 0.75 and

3 stages, and different architectures for the ProxNet. The

comparison is conducted in terms of average PSNR. The

bold numbers indicate the best metrics. Notably, the Net

outperforms all other architectures.

ProxNet Net1 Net2 Net3 Net4

PSNR 25,676 29,160 29,041 28,827

Results are reported in Figure 8 in terms of average

PSNR. While from 3 to 5 there is a signiﬁcant in-

crease in performance, from 5 to 7 the performance is

just slightly better. This behaviour is consistent across

all noise levels. Therefore, we selected 5 stages as a

good compromise between performance and compu-

tational cost.

Table 4: Average PSNR values of UCLD and UNLD with

sampling factors of 2, 3, 4, and 8, and with blur levels of

0.75, 1, 1.4, and 1.8, respectively.

Sampling 2 3 4 8

UCLD 29,31 25,97 24,77 22,06

UNLD 29,57 26,08 24,81 22,12

6 CONCLUSIONS

In this work, we proposed an unfolding algorithm to

extend a variational model that includes a nonlocal

data ﬁdelity term. After the minimization of the en-

ergy through the proximal gradient algorithm, we re-

placed all proximal, downsampling and upsampling

operators with neural networks. While we wrote the

nonlocal module in terms of a learning-based multi-

head attention.

Experimental results demonstrated that learning-

based methods can enhance the performance of vari-

ational models by leveraging prior knowledge from a

dataset, rather than solely relying on traditional reg-

ularization terms. Additionally, we have shown that

the beneﬁts of self-similarity persist in the unfolded

network when using multi-head attention, making the

model more robust to noise.

As future work we plan to continue exploring such

models with novel architectures that further improve

performance. Furthermore, we aim to experiment

with different energy terms from the wide array of

models available in the literature.

ACKNOWLEDGEMENTS

This work is part of the MaLiSat project TED2021-

132644B-I00, funded by MCIN/AEI/10.13039/

501100011033/ and by the European Union

NextGenerationEU/PRTR, and also of the Mo-

LaLIP project PID2021-125711OB-I00, ﬁnanced

by MCIN/AEI/10.13039/501100011033/FEDER,

EU. Also, we are grateful for the funding provided

by the Conselleria de Fons Europeus, Universitat i

Cultura (GOIB). The authors gratefully acknowledge

the computer resources at Artemisa, funded by the EU

Beyond Variational Models and Self-Similarity in Super-Resolution: Unfolding Models and Multi-Head Attention

197

ERDF and Comunitat Valenciana and the tech-

nical support provided by IFIC (CSIC-UV).

REFERENCES

Babacan, S. D., Molina, R., and Katsaggelos, A. K. (2008).

Total variation super resolution using a variational ap-

proach. In 2008 15th IEEE International Conference

on Image Processing, pages 641–644. IEEE.

Bell-Kligler, S., Shocher, A., and Irani, M. (2019). Blind

super-resolution kernel estimation using an internal-

gan. Advances in Neural Information Processing Sys-

tems, 32.

Chambolle, A. and Pock, T. (2016). An introduction to

continuous optimization for imaging. Acta Numerica,

25:161–319.

Combettes, P. L. and Wajs, V. R. (2005). Signal recovery

by proximal forward-backward splitting. Multiscale

modeling & simulation, 4(4):1168–1200.

Dai, T., Cai, J., Zhang, Y., Xia, S.-T., and Zhang, L.

(2019). Second-order attention network for single im-

age super-resolution. In Proceedings of the IEEE/CVF

conference on computer vision and pattern recogni-

tion, pages 11065–11074.

Dong, W., Zhang, L., Shi, G., and Li, X. (2013). Non-

locally centralized sparse representation for image

restoration. IEEE Transactions on Image Processing,

22(4):1620–1630.

Dong, W., Zhang, L., Shi, G., and Wu, X. (2011). Im-

age deblurring and super-resolution by adaptive sparse

domain selection and adaptive regularization. IEEE

Transactions on Image Processing, 20(7):1838–1857.

Duran, J., Buades, A., Coll, B., and Sbert, C. (2014). A

nonlocal variational model for pansharpening image

fusion. SIAM Journal on Imaging Sciences, 7(2):761–

796.

Gilboa, G. and Osher, S. (2009). Nonlocal operators with

applications to image processing. Multiscale Model-

ing & Simulation, 7(3):1005–1028.

Keys, R. (1981). Cubic convolution interpolation for digital

image processing. IEEE Transactions on Acoustics,

Speech, and Signal Processing, 29(6):1153–1160.

Lepcha, D. C., Goyal, B., Dogra, A., and Goyal, V. (2023).

Image super-resolution: A comprehensive review, re-

cent trends, challenges and applications. Information

Fusion, 91:230–260.

Li, X. and Orchard, M. (2001). New edge-directed inter-

polation. IEEE Transactions on Image Processing,

10(10):1521–1527.

Lim, B., Son, S., Kim, H., Nah, S., and Mu Lee, K. (2017).

Enhanced deep residual networks for single image

super-resolution. In Proceedings of the IEEE con-

ference on computer vision and pattern recognition

workshops, pages 136–144.

Lu, Z., Li, J., Liu, H., Huang, C., Zhang, L., and Zeng,

T. (2022). Transformer for single image super-

resolution. In Proceedings of the IEEE/CVF con-

ference on computer vision and pattern recognition,

pages 457–466.

Monga, V., Li, Y., and Eldar, Y. C. (2021). Algorithm un-

rolling: Interpretable, efﬁcient deep learning for sig-

nal and image processing. IEEE Signal Processing

Magazine, 38(2):18–44.

Pereira-S

anchez, I., Navarro, J., and Duran, J. (2022). What

if image self-similarity can be better exploited in data

ﬁdelity terms? In 2022 IEEE International Confer-

ence on Image Processing (ICIP), pages 3697–3701.

IEEE.

Rudin, L., Osher, S., and Fatemi, E. (1992). Nonlinear total

variation based noise removal algorithms. Physica D:

nonlinear phenomena, 60(1-4):259–268.

Tai, Y., Yang, J., and Liu, X. (2017). Image super-resolution

via deep recursive residual network. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 3147–3155.

Wang, W., Li, F., and Ng, M. (2019). Structural similarity-

based nonlocal variational models for image restora-

tion. IEEE Transactions on Image Processing,

28(9):4260–4272.

Wang, X., Girshick, R., Gupta, A., and He, K. (2018). Non-

local neural networks. In Proceedings of the IEEE

Conference on Computer Vision and Pattern Recogni-

tion (CVPR).

Wang, Z., Chen, Y., Shao, W., Li, H., and Zhang, L. (2022).

Swinfuse: A residual swin transformer fusion network

for infrared and visible images. IEEE Transactions on

Instrumentation and Measurement, 71:1–12.

Yue, L., Shen, H., Li, J., Yuan, Q., Zhang, H., and Zhang,

L. (2016). Image super-resolution: The techniques,

applications, and future. Signal processing, 128:389–

408.

Zhang, K., Gao, X., Tao, D., and Li, X. (2012). Single im-

age super-resolution with non-local means and steer-

ing kernel regression. IEEE Transactions on Image

Processing, 21(11):4544–4556.

Zhang, L. and Wu, X. (2006). An edge-guided image

interpolation algorithm via directional ﬁltering and

data fusion. IEEE Transactions on Image Processing,

15(8):2226–2238.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

198
