Constructive Assertions with Abstract Models

Yoonsik Cheon

Department of Computer Science, The University of Texas at El Paso, El Paso, Texas, U.S.A.

Keywords: Abstraction Function, Assertion, Assertion Library, Assertion State, Constructive Assertion, Dart,

Object Constraint Language.

Abstract: An assertion is a statement that specifies a condition that must be true at a particular point during program

execution. It serves as a tool to ensure the program functions as intended, reducing the risk of introducing

subtle errors. Usually expressed algebraically, an assertion utilizes Boolean expressions to specify permissible

relationships among program variables. In complex scenarios, calculating the expected value of a program

variable often proves more effective than specifying the constraints it must adhere to. In this paper, we present

an approach to formulating assertions using abstract models in a constructive manner, which complements

the traditional algebraic style. Constructive assertions empower programmers to articulate comprehensive

assertions, including pre and postconditions, in a succinct, comprehensible, reusable, and maintainable

manner.

1 INTRODUCTION

An assertion, as defined by Matuszek (1976), is a

statement establishing a condition expected to be true

at a specific point during program execution. It is

essentially a Boolean expression inserted directly into

the code. If the condition evaluates as true, the

program proceeds without disruption; if false, the

assertion fails, triggering an exception or displaying

an error message. Assertions can validate code

assumptions, verify code logic, and aid in identifying

potential errors promptly. Their adoption, often in the

form of assert statements, has been widespread in

programming languages, with empirical studies

showing that code containing assertions has fewer

defects (Casalnuovo et al., 2015; Counsell et al.,

2017; Kochhar & Lo, 2017).

While traditional assertions express conditions

algebraically, involving relationships among program

variables and state components, writing such

assertions can become complex, especially dealing

with multiple variables or various object parts.

This paper introduces a complementary approach

called constructive assertions. In this approach,

expected values for program variables are computed

to produce more straightforward and understandable

assertions. It leverages an abstraction of program

states with an abstraction function (Hoare, 72;

Sitaraman, Weide, & Ogden, 1997), providing an

immutable model, to write assertions constructively

and representation-independently. The paper also

introduces an assertion library offering immutable

collection classes specifically designed for writing

assertions. Although demonstrated using Dart

(Bracha, 2016) and Flutter (Flutter, 2023) for mobile

applications, the concept of constructive assertions is

applicable to other languages and platforms.

The integration of traditional algebraic and new

constructive assertions broadens the range of

assertion techniques. Algebraic assertions define

constraints on program variables and states, whereas

constructive assertions provide a more streamlined

approach to express expected outcomes. Therefore,

this paper empowers programmers to select the most

appropriate technique depending on the assertion's

unique context and complexity. This enhances the

thoroughness and effectiveness of assertions,

ultimately fostering improved code quality and more

efficient debugging practices.

While existing literature extensively explores

various applications of assertions, including

debugging and testing tools utilizing pre and

postconditions (Rosenblum, 1995; Chalin, 2014;

Cheon, 2021; Cheon, 2022), as well as test oracles

(Cheon & Leavens, 2005; Watson et al., 2020), a

noticeable gap exists in publications studying distinct

styles of writing assertions, particularly the

comparative analysis of algebraic and constructive

Cheon, Y.

Constructive Assertions with Abstract Models.

DOI: 10.5220/0012418800003645

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 12th International Conference on Model-Based Software and Systems Engineering (MODELSWARD 2024), pages 211-218

ISBN: 978-989-758-682-8; ISSN: 2184-4348

211

methodologies. This specific aspect has received

limited research attention. The use of an abstraction

function to define an abstract assertion state can be

considered a way to implement a model variable in a

specification language (Cheon et al., 2005). The

assertion library, designed to support constructive

assertions, draws inspiration from the collections

library of the Object Constraint Language (OCL)

(Warmer & Kleppe, 2003).

This paper is organized as follows. Section 2

introduces assertions, covering algebraic and

constructive writing styles. Section 3 presents an

assertion library consisting of immutable collection

classes. Section 4 demonstrates constructive

assertions via examples, including app written in

Flutter. Section 5 explores open issues and future

research directions. Section 6 concludes the paper.

2 CONSTRUCTIVE ASSERTIONS

2.1 Assertions

In programming, assertions are straightforward

statements that declare conditions expected to be true

at specific points during program execution

(Matuszek, 1976; Rosenblum, 1996). These Boolean

expressions, embedded within the code, facilitate

smooth program flow when conditions are met. If

false, assertions trigger errors, highlighting

unexpected situations. Operating as lightweight

mechanisms, assertions enable programmers to

validate code assumptions and logic, aiding in testing,

debugging, and enhancing software quality.

To illustrate, consider a Dart function calculating

the maximum value from a list of integers. The

function assumes a non-empty input list, a critical

point addressed by an assertion at the code's outset. If

the function encounters an empty list, this assertion

signals an error to inform the invalid input. Further

assertions, strategically placed post-computation,

verify that the returned value represents the maximum

within the input list. Any failure triggers an assertion

exception, signaling potential implementation errors.

int max(List<int> list) {

assert(list.length > 0, 'Invalid argument');

var result;

… // calculate the result.

assert(list.contains(result), 'Wrong result');

assert(list.every((n) => n <= result, 'Wrong result');

return result;

}

By using assertions during development and

testing, one can effectively verify both the

preconditions (input assumptions) and postconditions

(expected output) of the code, thereby enhancing its

reliability. Note that assertions are typically disabled

in production environments and automatically

removed from the Dart/Flutter production code.

2.2 Assertion Styles

Traditionally, assertions are formed by examining

program states to assert facts that these states must

meet. This algebraic approach constrains program

states by specifying permissible relationships among

program variables and state components. For

instance, in the earlier max() function, the first assert

statement ensures the list's length is greater than 0,

indicating a non-empty list. Similarly, other assert

statements verify that the result is an element of the

list and is greater than or equal to every other element

in the list.

An alternative approach involves calculating the

expected value of a state component and asserting the

equivalence between the actual and expected values,

termed the constructive style. For example, instead of

explicitly listing properties of a maximum value in a

list, we can find the maximum value using the

reduce() method and assert that the result is equal to

this calculated value:

assert(result == list.reduce((r,e) => math.max(r,e));

This constructive style focuses on calculated

expected results and their equivalence with actual

values. Both algebraic and constructive styles have

merits, depending on specific code requirements.

In this paper, we informally use the term

constructive assertions. These assertions take a

Boolean expression, denoted as P(x), where x

represents program variables or state components.

P(x) outlines constraints on a program's state or

establishes permissible relationships among its

components. When P(x) is structured as x == E(y), we

classify it as a constructive assertion, where E(y)

calculates or constructs the anticipated value or state

for the specific variable or component x. The essence

lies in computing a solution rather than enumerating

solution properties.

For example, asserting the sorted order of a list,

denoted as l, conventionally involves scrutinizing the

sorted property of the list:

for (var i = 0; l < l.length - 1; i++) {

assert(l[i] <= l[i + 1]);

}

MODELSWARD 2024 - 12th International Conference on Model-Based Software and Systems Engineering

212

Contrastingly, a constructive approach creates a

sorted version of the list and asserts the equivalence

between the sorted and original lists:

assert(listEquals(l, List<int>.from(l)..sort()));

Although the assertion involves Dart-specific

constructs and syntax, its essence is summarized as l

== l.clone()..sort(). The listEquals() function from

the Flutter SDK compares two lists element-wise; the

List class's == operator evaluating object identity. To

create a fresh list and prevent inadvertent alterations

to the original, we use the List.from() method. Dart's

cascade notation (..), exemplified as e..m(), allows

executing a series of operations on the same object

without introducing temporary variables. Thus, the

expression List<int>.from(l)..sort() efficiently clones

and sorts the list, yielding its sorted version.

This constructive approach is particularly

effective for asserting state changes and specifying

the behavior of mutation operations. For example,

asserting the insertion of a value n into a sorted list l

while maintaining its sorted order is succinctly

expressed using constructive assertions:

var expected = List<int>.from(l)..append(n)..sort();

// … code to insert n to l.

assert(listEquals(l, expected));

The local variable expected is an assertion-only

variable introduced to store the expected value of l

calculated in the initial state. This calculated value is

then compared to the actual value of l in the final

state. As done previously, before the calculation, the

list is cloned to prevent unintended modifications to

the original list.

Now, let's formulate the same assertion using the

conventional style of stating properties. The skeletal

code is shown below:

var preL = List<int>.from(l); // initial value of l

// … code to insert n into l.

assert(…);

In the final state, we need to formulate the

properties that l is a version of preL with n

appropriately inserted. This entails articulating the

following properties (see Section 3):

• The list l maintains its sorted order. This

implies that for each index i from 0 to l.length

- 2, the element at index i is less than or equal

to the element at index i + 1.

• The value n is present within the list l after the

insertion operation.

• There are no other changes in l. That is, all

elements are retained and no new elements

other than n have been introduced. This

principle, referred to as the frame axiom

(Borgida et al., 1993), makes the assertion

comprehensive and conclusive.

The complexity of stating certain properties, such

as the last one above, can be notably intricate,

especially when verifying not only the existence of an

element within a list but also the exact count of its

occurrences when duplicates are allowed.

Modern object-oriented programming languages,

such as Dart (Bracha, 2016), offer a spectrum of

language constructs and functionalities that

streamline the composition of assertions through a

constructive approach. These include lambda

expressions, higher-order functions, cascade

notation, operator overriding, and collections.

Complementing these capabilities, we can enhance

the efficacy of constructive assertions by introducing

a dedicated assertion library.

3 ASSERTION LIBRARY

Constructive assertions are highly valuable for

validating modifications in object state or side effects,

enabling programmers to formulate complete

postconditions. For example, let us consider the code

snippet to insert an element e into a list l at a position

i. Below, we present its pre and postconditions

without utilizing constructive assertions:

// precondition

assert(i >= 0 && i <= l.length);

var preL = List<int>.from(l); // initial value of l

l[i] = e;

// postcondition

for (var j = 0; j < i – 1; j++) {

assert(l[j] == preL[j];

}

assert(l[i] == e);

for (var j = i; j < preL.length; j++) {

assert(l[j+1] == preL[j]);

}

Surprisingly, for this simple one-line operation,

the postcondition assertions are long and somewhat

complicated, meticulously detailing the effects on

each location within the list, including the newly

added one. We can enhance the clarity of the

postcondition by employing the constructive

approach and incorporating more appropriate

terminology, such as “insert,” as illustrated below:

assert(listEquals(l, preL..insert(i,e));

Constructive Assertions with Abstract Models

213

Assuming familiarity with the insert() operation,

the resultant assertion offers a notably simpler and

more elegant expression compared to the original

version. It states that the final state of l is equivalent

to the result state of “inserting” the element at the

position i within its initial state. It is worth noting that

the insert() operation used in the assertion carries a

side effect. However, this side effect is confined to a

duplicate copy (preL) that is created to write

assertions, rendering it inconsequential for actual

operations of the code. In a way, this duplicated copy

represents an assertion state that remains

imperceptible to the operational code.

Two immediate improvements can enhance the

clarity of the above assertion further. Firstly, using

the overridable == operator available in Dart instead

of the listEquals() function improves readability.

Secondly, a more significant refinement involves

avoiding the manual cloning of objects in the initial

state, such as preL in the example, and utilizing

mutation operations like insertion. The reason is that

it poses the risk of inadvertent mutations on the

program state and thus potential reliability issues, as

assertions should remain free from side effects. To

address these concerns and enhance the effectiveness

of constructive assertions, we propose introducing an

assertion library.

The assertion library aims to offer a high-level

vocabulary tailored for manipulating program states,

with a specific emphasis on creating anticipated

values without unintentionally impacting the actual

program state. This is accomplished through the

provision of immutable collection classes designed

for abstracting concrete program states into assertion

states. The underlying idea involves mapping a

program state to an abstract state and formulating

assertions in terms of this abstract state. Thus,

assertions indirectly impose constraints on the code

without explicitly referring to concrete program

states. To illustrate this concept, the preceding

assertion can be elegantly rewritten using the library:

var expected = OCLSequence<int>(l).insertAt(e, i);

l[i] = e;

assert(expected == l);

The program state l is abstracted into an

immutable sequence, and the insertAt() operation is

an immutable insertion operation as it creates a new

sequence incorporating the original data and the

newly inserted element. Importantly, this operation

leaves the initial sequence untouched. The thoughtful

override of the == operator facilitates the comparison

of sequences, allowing the conversion of a concrete

collection, such as a list, into a sequence when

necessary. This approach ensures the clarity of the

assertion without compromising the integrity of the

program state.

The assertion library operates similarly to

mathematical toolkits commonly found in formal

specification languages like VDM-SL and Z (Jones,

1986; Spivey, 1989). Realizing the assertion library

can be achieved through various avenues. In this

paper, we utilize the Dart implementation of OCL

collection classes (Cheon, Lozano, & Prabhu, 2023).

The implementation provides various collections,

including sets, ordered sets, bags, and sequences,

meticulously designed for immutability, with

operations conforming to the OCL standard (Object

Management Group, 2023). It also incorporates

streamlined Dart language-specific adaptations, such

as translating iteration operations into higher-order

functions, enabling conversion between Dart and

OCL collections, and introducing other Dart-inspired

operations.

4 EXAMPLES

In this section, we apply constructive assertions to a

small Flutter app for text-based notetaking adapted

from Zammetti (2019). The app comprises two main

screens: a note list display and a note editor (see

Figure 1). Our focus is on the app's model and state

management, crucial in the reactive programming of

Flutter, where the user interface (UI) functions as a

mapping from the state to widgets. Widgets are

regenerated and adapted automatically in response to

state modifications.

Figure 1: Sample screens: list screen and note editor.

Figure shows the architecture of the app,

consisting of three widget classes and several non-

widget classes. The main widget class hosts two

widgets—one for note display and the other for

MODELSWARD 2024 - 12th International Conference on Model-Based Software and Systems Engineering

214

editing. This class dynamically selects and updates its

view, driven by the screen index (screenIndex) stored

within the model class.

The app's state, managed by the NotesModel

class, comprises an ordered collection of notes, with

an optional note for buffered editing. All notes persist

in a local database, and the NotesModel class ensures

synchronized updates between this database and in-

memory notes. The state also includes a screen index

(screenIndex), indicating the active screen widget—

NotesList or NoteEntry. Changing this index triggers

seamless UI updates facilitated by the state

management framework in use.

Figure 2: Class diagram.

Now, let's examine a portion of the NotesModel

class implementation to explore its assertions. Below,

we show the skeletal code that instantiates the

previously discussed associations and attributes. This

model class is defined as a subclass of a state

management framework class, facilitating automatic

UI reconstruction in response to state changes. The

specific choice of the state management framework

does not impact our discussion in this paper.

class NotesModel extends Model {

final List<Note> _notes = [];

Note? noteEdited;

int screenIndex = 0;

…

get __notes => OCLSequence<Note>(_notes);

get __notesDB async => OCLSequence<Note>(

await DBWorker.db.getAll());

}

The code features two getter methods (__notes

and __notesDB) serving as abstraction functions to

access abstract views of notes within the (in-memory)

model and those stored in the database. These getters

transform Dart lists into immutable sequences

(OCLSequence). They are assertion-only methods

designed solely for writing assertions; we may

introduce an annotation like @assert to indicate this.

We are now ready to examine several key

operations of the NotesModel class and formulate

their assertions. Writing assertions is a common

practice for verifying code assumptions and logic.

Our aim is to construct complete pre and

postconditions for these operations to evaluate the

effectiveness of constructive assertions.

The loadNotes() method populates notes to be

displayed by the notes list screen by fetching them

from a local database (see below). This method

should be invoked upon app launch and when the list

screen widget is created.

Future<void> loadNotes() async {

…

assert(__notes == await __notesDB);

}

Its constructive postcondition is expressed as

__notes == await __noteDB. The abstraction

functions simplify its formulation, resulting in a clear

assertion. They return OCL sequences, and the

overridden == operator evaluates the equality of these

sequences. The use of abstraction functions improves

the reusability and maintainability of assertions. If the

implementation changes, only the abstraction

functions need redefining, eliminating the need to

rewrite assertions. This assertion also shows the

advantage of abstraction, as the database is perceived

as a sequence of notes, independent of specific

storage intricacies.

The createNote() method, shown below, serves as

a callback function to be invoked when the user taps

the floating action button on the notes list screen (see

Figure ). This action facilitates the creation of a new

note, which will later either be discarded or added to

the list of notes using the saveNote() method to be

introduced later in this section.

void createNote() {

…

assert(noteEdited == Note.empty());

assert(screenIndex == screenIndexNote);

}

The method creates an empty note and assigns it

to the editing buffer noteEdited field, anticipating its

later presentation by the note editor widget. It also

modifies the screenIndex field to prompt a UI update,

transitioning to the note editor screen. The overridden

== operator in the Note class enables proper

comparison, and the side effect of creating a new

empty note in the first assertion occurs within the

assertion state, remaining unobservable to the code.

The deleteNote() method removes a note from the

list and the database (see below), triggered by a user

tap on the delete slide action (see Figure ). This

method alters the list of notes, presenting an

interesting case for assertions. The first two assertions

confirm the presence of the note in the list and a non-

null id, indicating its existence in the database.

Considering the side effects, pre-state calculations

anticipate final values for both the notes list and the

{ordered} *

0..1

<<widget>>

Notes

Note

<<widget>>

NotesList

<<widget>>

NotesEntry

DBWorker

<<model>>

NotesModel

+screenIndex: int

Constructive Assertions with Abstract Models

215

database, stored in notesExp. The excluding()

operation is an immutable removal operation defined

in OCL collection classes. Post-state assertions then

validate the equivalence between these final values

and the expected sequences of notes. As expected,

abstraction functions are used to retrieve the actual

final values. The last assertion confirms that the

method prompts an update of the notes list screen to

reflect the note's removal.

void deleteNote(Note note) async {

assert(__notes.includes(note));

assert(note.id != null);

var notesExp = __notes.excluding(note);

…

assert(__notes == notesExp);

assert(await __notesDB == notesExp);

assert(screenIndex == screenIndexList);

}

The user can edit a note by tapping on it displayed

in the notes list screen, triggering the editNote()

method to transition to the editing screen (see below).

The precondition requires the tapped note to exist in

the list of notes. The postcondition ensures that the

noteEdited field contains an equivalent note to the

argument, emphasizing that it's not the same instance.

This field serves as an editing buffer, signifying that

changes are temporary until explicitly saved. The last

assertion confirms that the method triggers a UI

update to transition to the editing screen.

void editNote(Note note) {

assert(__notes.includes(note));

…

assert(noteEdited == note

&& !identical(noteEdited, note));

assert(screenIndex == screenIndexNote);

}

The saveNote() method (see below), invoked

when the user taps the save button on the note editing

screen (see Figure ), handles updates to both the notes

list and the database, addressing the complexities of

editing new and existing notes.

Future<void> saveNote() async {

assert(noteEdited != null);

assert(noteEdited!.id == null

|| _notes.any((e) => e.id == noteEdited!.id));

var preNote = noteEdited!.clone();

var preNotes = __notes;

…

if (preNote.id != null) {

var index = preNotes.indexWhere(

(e) => e.id == preNote.id);

assert(__notes ==

preNotes.setAt(index, preNote));

assert(await __notesDB) == __notes;

} else {

var lastNote = __notes.last;

assert(lastNote.id != null);

assert(preNotes.collect((e) =>

e.id).excludes(lastNote.id));

assert(__notes ==

preNotes.append(preNote..id = lastNote.id));

assert(await __notesDB ==__notes);

}

assert(screenIndex == screenIndexList);

}

The first assertion ensures that the method is

invoked when there is an active editing buffer. The

second confirms that the edited note is either new or

an existing one based on its ID. The subsequent pair

of local variables, preNote and preNotes, store pre-

state values for later reference in the post-state,

necessitating cloning due to potential modifications

by the code. For an existing note, the postcondition

locates the index of the edited note, replaces it in the

pre-state list, and ensures that the change is reflected

in the database. In the case of a new note, the post

condition asserts the uniqueness of the ID field, and

using a constructive approach, appends the edited

note to the list with an ID selected by the code.

5 DISCUSSIONS

Creating assertions covering complete pre and

postconditions is uncommon, except in certain cases,

such as aiming for formal code verification. However,

when such needs arise, using constructive assertions

with an assertion library enables programmers to

express them in a concise, understandable, reusable,

and maintainable manner. To substantiate this claim,

we measured the size complexities of assertions by

comparing constructive assertions to conventional

algebraic assertions across 24 methods in the Notes

and NotesModel model classes. For the comparison,

we wrote equivalent assertions in conventional

algebraic style. The results are summarized in Table

I, where only assertions involving abstraction

functions for non-primitive values were counted as

constructive; that is, assertions in the form of x = E,

with E being a primitive expression, were not

considered constructive.

The first row compares the total source lines of

code (SLOC) for both code and assertions, revealing

a 13% reduction in SLOC for the constructive style

(257 vs. 295). The second row compares only

assertions, including supporting code, showing a

notable difference. Constructive style includes 49

MODELSWARD 2024 - 12th International Conference on Model-Based Software and Systems Engineering

216

assert statements within 75 SLOC, while algebraic

style incorporates 59 assertions within 115 SLOC.

This translates to 35% less code for the constructive

style. If we specifically examine only those assertions

written constructively and their corresponding

algebraic assertions (the last row), it becomes evident

that constructive style requires fewer assertions (36%

less) and significantly fewer SLOC (67% less). These

findings underscore the efficiency of constructive

assertions, providing a concise and understandable

approach for expressing complete pre and

postconditions.

Table 1: Size complexities of assertions.

Con.

. C/A 1

–

C/A

Total SLOC 257 295 0.87 0.13

No. all assert stmts

SLOC

115

0.83

0.65

0.17

0.35

No. con./alg. assert

SLOC

0.64

0.33

0.36

0.67

We observed in our assertions that most accessor

methods, such as the getNoteId() method listed

below, exhibit an interesting assertion pattern where

postconditions, whether algebraic or constructive,

often parallel the code logic for calculating the return

value. Constructive assertions, structurally similar

but referencing specification-only variables (e.g.,

__notes), highlight their advantage. In contrast to

algebraic-style assertions, constructive assertions

retain reusability despite changes in the underlying

representation. When the representation changes,

only the abstraction functions require redefinition,

simplifying maintenance and preserving assertion

integrity. This shows the robustness and adaptability

of constructive assertions, contributing to more

reusable and maintainable code.

Note? getNoteId(int id) {

var result = notes.any((e) => e.id == id) ?

notes.firstWhere((e) => e.id == id) : null;

…

assert(result == (__notes.exists((e) => e.id == id) ?

__notes.any((e) => e.id == id) : null));

return result;

}

In the previous section, we briefly touched upon

how we assert that a method initiates a UI update by

indicating the expected screenIndex value. However,

in our actual implementation code, we employed two

assert statements: one in the pre-state to clear a flag

and another in the post-state to verify if the flag is set

to a specific value (refer to the skeletal code below).

To facilitate this, we introduced an assertion-only

method __uiNotified(), which serves the dual purpose

of clearing the flag and checking it for a specific

value.

assert(__uiNotified()); // clear the flag.

…

assert(__uiNotified(screenIndexNote); // check.

While effective, this technique has inherent

challenges, especially when used to verify if a

specific method was invoked during execution, such

as state management framework methods. It can be

error-prone and may require additional handling for

nested cases. Investigating built-in mechanisms to

assert the occurrence of method calls could simplify

and streamline the formulation of such assertions

(Cheon & Perumandla, 2007).

An assertion typically focuses on a single program

state, representing either the initial state for a

precondition or the final state for a postcondition.

However, in scenarios where a postcondition requires

referencing the initial value of a changing program

variable, the introduction of a specification-only local

variable becomes essential. Despite its utility, there

are drawbacks. For objects, careful handling is crucial

to ensure accurate cloning, particularly when the

object's state might be altered by the code. While

OCL collection classes offer automatic cloning for

collections, manual intervention is needed for non-

collection types. Caution is also warranted if the

object undergoes mutation within assertions, as the

order of assertions could impact correctness. The use

of specification-only local variables may introduce

namespace clutter and the risk of accidental

references in the code, which could be addressed

through a well-defined naming convention or

annotation. Overcoming these challenges presents a

promising avenue for future research and refinement.

In addition to assertion-only variables, assertion-

only code—comprising code sections, functions,

methods, and classes—can coexist within the asserted

codebase. Unlike assertion-only variables, integrating

assertion-only code within regular code does not pose

issues, aside from its presence in the production code.

It is advisable, however, to confine the use of

assertion-only code to assertion-specific contexts.

Clear indication of its purpose can be achieved

through a well-defined naming convention or

annotations. While most instances of assertion-only

code are private within classes or libraries, certain

scenarios may require public visibility. For instance,

when introducing a method to clone a Note object for

assertion purposes, the method needs to be public if

the Note class and NotesModel class are in separate

libraries. Abstraction functions serve as another

example, enabling client assertions to manipulate

Constructive Assertions with Abstract Models

217

values abstractly. Exploring the potential

establishment of a specialized interface, such as an

assertion interface, could be an intriguing avenue for

future research, allowing client code to formulate

assertions about objects with hidden states and

enhancing the assertion framework's capabilities and

flexibility.

6 CONCLUSIONS

This paper has introduced and explored the concept

of constructive assertions as a valuable technique for

enhancing code reliability and verification. By

leveraging abstraction functions and assertion-only

variables, we have demonstrated how constructive

assertions offer a concise and comprehensible

approach to specifying program behavior. The

assertion library of immutable collection classes

further underscores the potential of this approach.

While challenges such as proper cloning and

namespace pollution warrant consideration, the future

holds promise for refining and expanding the utility

of constructive assertions. As software development

continues to evolve, the judicious application of this

technique stands to contribute to more reusable,

maintainable, and reliable software systems.

REFERENCES

Borgida, A., Mylopoulos, J., & Reiter, R. (1993). '. . . and

nothing else changes': the frame problem in procedure

specifications. 15

International Conference on

Software Engineering (ICSE), IEEE, 303-314.

Bracha, G. (2016). The Dart Programming Language.

Addison-Wesley.

Casalnuovo, C., Devanbu, P., Oliveira, A., Filkov, V., &

Ray, B. (2015). Assert use in GitHub projects.

IEEE/ACM 37

International Conference on Software

Engineering (ICSE), Florence, Italy, 755-766.

Chalin, P. (2014). Ensuring that your Dart will hit the mark:

An introduction to Dart contracts. International

Conference on Information Reuse and Integration,

Redwood City, CA, August 13-15, IEEE, 369-377.

Cheon, Y. (2021). Toward more effective use of assertions

for mobile app development. International Conference

on Progress in Informatics and Computing, Shanghai,

China, December 17-19, IEEE, 319-323.

Cheon, Y. (2022). Design assertions: executable assertions

for design constraints. 14

International Symposium on

Software Engineering Processes and Applications

(SEPA), July 4-7, Malaga, Spain. Published as ICCSA

2022 Workshops, Lecture Notes in Computer Science,

13381, 617-631, Springer.

Cheon, Y. & Leavens, G. T. (2002). A simple and practical

approach to unit testing: The JML and JUnit way. In

European Conference on Object-Oriented

Programming (ECOOP), Malaga, Spain, June. Lecture

Notes in Computer Science, 2374, 231–255, Springer.

Cheon, Y., Leavens, G. T., Sitaraman, M., & Edwards, S.

(2005). Model variables: cleanly supporting abstraction

in design by contract. Software: Practice and

Experience, 35(6), 583-599, Wiley.

Cheon, Y., Lozano, R., & Prabhu, R. S. (2023). A library-

based approach for writing design assertions.

IEEE/ACIS 21

International Conference on Software

Engineering Research, Management, and Applications

(SERA), Orlando, FL, USA, 22-27.

Cheon, Y. & A. Perumandla (2007). Specifying and

checking method call sequences of Java programs.

Software Quality Journal, 15(7), 7-25, Springer.

Counsell, S., Hall, T., Shippey, T., Bowes, T., Tahir, A., &

MacDonell, S. (2017). Assert use and defectiveness in

industrial code. IEEE International Symposium on

Software Reliability Engineering Workshops

(ISSREW), Toulouse, France, 20-23.

Flutter. (2023). Retrieved from https://flutter.dev.

Hoare, C. A. R. (1972). October. Proof of correctness of

data representations, Acta Informatica, 1(1), 271–281.

Jones, C. B. (1986). Systematic Software Development

Using VDM. Prentice Hall.

Kochhar, P.S. & Lo, D. (2017). Revisiting assert use in

GitHub projects. 21

International Conference on

Evaluation and Assessment in Software Engineering

(EASE), June, 298-307.

Leavens, G.T., Cheon, Y., Clifton, C., Ruby, C., & Cok, D.

(2005). How the design of JML accommodates both

runtime assertion checking and formal verification.

Science of Computer Programming, 55(1-3), 185-208.

Matuszek, D. (1976). The case for assert statement. ACM

SIGPLAN Notices, 36-37, August.

Object Management Group. (2023). Object Constraint

Language, version 2.4. Retrieved November 13, 2023,

from https://www.omg.org/spec/OCL/.

Rosenblum, D. S. (1995). A practical approach to

programming with assertions. IEEE Transactions on

Software Engineering, 21(1), 19-31, January.

Spivey, J. (1989). The Z Notation: A Reference Manual.

Prentice Hall.

Sitaraman, M., Weide, B. W., & Ogden, W. F. (1997). On

the practical need for abstraction relations to verify

abstract data type representations, IEEE Transactions

on Software Engineering, 23(3), 157-170, March.

Warmer, J. & Kleppe, A. (2003). The Object Constraint

Language: Getting Your Models Ready for MDA (2

ed.). Addison-Wesley.

Watson, C., Tufano, M., Moran, K., Bavota, G., &

Poshyvanyk, D. (2020). On learning meaningful assert

statements for unit test cases. IEEE/ACM 42

International Conference on Software Engineering

(ICSE), Seoul, Korea, 1398-1409.

Zammetti, F. (2019). Practical Flutter: Improve Your

Mobile Development with Google’s Latest Open-

Source SDK. Apress.

MODELSWARD 2024 - 12th International Conference on Model-Based Software and Systems Engineering

218
