Explainability and Interpretability for Media Forensic Methods:

Illustrated on the Example of the Steganalysis Tool Stegdetect

Christian Kraetzer and Mario Hildebrandt

Dept. of Computer Science, Otto-von-Guericke University Magdeburg, Germany

Keywords:

Media Forensics, Explainability and Interpretability, Machine Learning, Artiﬁcial Intelligence, Quality

Assurance and Proﬁciency Testing in Forensics.

Abstract:

For the explainability and interpretability of the outcomes of all forensic investigations, including those in

media forensics, the quality assurance and proﬁciency testing work performed needs to ensure not only the

necessary technical competencies of the individual practitioners involved in an examination. It also needs to

enable the investigators to have sufﬁcient understanding of machine learning (ML) or ‘artiﬁcial intelligence’

(AI) systems used and are able to ascertain and demonstrate the validity and integrity of evidence in the context

of criminal investigations.

In this paper, it is illustrated on the example of applying the multi-class steganalysis tool Stegdetect to ﬁnd

steganographic messages hidden in digital images, why the explainability and interpretability of the outcomes

of media forensic investigations are a challenge to researchers and forensic practitioners.

1 INTRODUCTION

Forensic procedures in many domains, but especially

in media forensics, see an increase in machine learn-

ing (ML) or ‘artiﬁcial intelligence’ (AI) based analy-

sis and investigation tools. Such methods have to un-

dergo rigorous quality assurance evaluations and pro-

ﬁciency testing like all other methods to be used in

trustworthy forensic processes. The requirements for

such evaluations are very illustratively summarised

for example in the corresponding European Network

of Forensic Science Institutes (ENFSI) Best Prac-

tice Manuals (BPM), see e.g., (European Network of

Forensic Science Institutes (ENFSI), 2021) for the

guidelines on digital image authentication. In con-

trast to validation methodologies for well established

human based analysis methods, which, to a large ex-

tent, rely on internationally acknowledged proﬁciency

tests, the evaluation of ML or AI based methods has

not jet reached the same degree of maturity. This is

the reason why the (UNICRI and INTERPOL, 2023)

state that using such systems “for high-stakes deci-

sions such as those taken in criminal justice and law

enforcement contexts is controversial.” In quality as-

surance of such methods, besides their accuracy, ro-

bustness and efﬁciency, also factors focusing on hu-

man control and oversight have to be addressed. Part

of this complex is the question how good an human

expert (here, a forensic practitioner) can interpret the

method and its output for the ‘customer’ in a forensic

process (the beneﬁciary of the forensic report, usu-

ally a police ofﬁcer, prosecutor, judge or jury). In

this context, it has to be differentiated between ex-

plainability and interpretability of machine learning

(ML) / ‘artiﬁcial intelligence’ (AI) methods. (UNI-

CRI and INTERPOL, 2023) deﬁnes the explainabil-

ity of such methods as follows: “Explainability (in a

narrow sense) refers to the ability of developers and

users of an AI system to understand its functioning,

meaning how the system makes decisions or gener-

ates outputs. It focuses on the inner workings of the AI

system, its internal logic or underlying processes.” In

this paper this is addressed by process modelling and

validation work, including opening up the black box

of an ML-based analysis tool, replacing the core part

of the tool (the used classiﬁcation algorithm) by an

interchangeable module and then benchmarking the

detection performance changes occurring when dif-

ferent, well established, classiﬁcation algorithms are

used (with corresponding trained models) instead of

the original one while still using the same feature

space.

Interpretability, as the second of these two aspects,

is deﬁned in (UNICRI and INTERPOL, 2023) as:

“the ability to provide reasoning for a speciﬁc out-

come the system has produced – in other words, to

Kraetzer, C. and Hildebrandt, M.

Explainability and Interpretability for Media Forensic Methods: Illustrated on the Example of the Steganalysis Tool Stegdetect.

DOI: 10.5220/0012423800003660

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2024) - Volume 4: VISAPP, pages

585-592

ISBN: 978-989-758-679-8; ISSN: 2184-4321

585

understand why a certain result has been generated.”

Not all AI methods are in their workings and deci-

sions entirely explainable. (UNICRI and INTERPOL,

2023) points out that with the recently developed re-

search ﬁeld of ‘Explainable AI’ an entire scientiﬁc

domain has formed, focusing on work that intends

to ensure the interpretability of non-explainable mod-

els. In this paper, the issue of interpretability is ad-

dressed by creating reproducible data sets with ﬁxed

parameters, including different JPEG-compression al-

gorithms - although this does not ensure interpretabil-

ity for real world use cases, this intermediate step is

necessary in order to assess the output of the ML clas-

siﬁcation models.

The ML-based forensic analysis tool considered

in this paper is the steganalysis tool Stegdetect.

It implements steganalysis (as practice of detect-

ing steganographic

communication) for multiple

different steganographic tools for JPEG images.

In short, Stegdetect tries to detect the presence

of steganographically hidden information in those

images and if corresponding traces are found it

performs an embedding method attributation and

reports a decision conﬁdence. Stegdetect was in-

troduced in 2002 in the seminal work of Provos

and Honeyman (Provos and Honeyman, 2002). It

is described in more detail in Section 2.2 of this paper.

The contributions in this paper are:

• Turning Stegdetect from a black-box detection en-

gine into a gray-box setup, to make its workings

more explainable and allow for a validation of the

feature space and original classiﬁcation algorithm

used in this tool

• The replacement of the original classiﬁcation al-

gorithm in Stegdetect and a benchmarking of a set

of alternative methods

• Empirical experiments addressing the explainabil-

ity and interpretability of Stegdetect decisions

The empirical evaluations are performed us-

ing the ALASKA2 image steganography reference

database (Kaggle, 2020). On one hand, it allows

for easy performance of obtained steganalysis perfor-

mances with other publications (since ALASKA2 is

widely established in this ﬁeld). On the other hand,

the image characteristics (especially the resolution

of 512x512) of the 75000 images in the ALASKA2

Steganography is considered to be the art and science

of hidden communication. In contrast to cryptography,

where only the content of a communication is hidden but

the communication itself is visible, in steganography also

the existence of the communication channel is hidden, by

embedding/hiding the message into innocent looking cover

objects, e.g., digital images.

set are assumedly very close to images that might

have been used by Provos and Honeyman in 2002.

Thereby, a certain degree of comparability to the re-

sults in that publication could be assumed.

The paper is structured as follows: In Section 2

some details on the state of the art are summarised.

These include a brief introduction to explainability

and interpretability in ML/AI for law enforcement

and forensics as well as a brief summary on multi-

class steganalysis with Stegdetect, which is the basis

for the empirical evaluations performed within this

paper. In Section 3 the experimental setup is intro-

duced, while Section 4 discusses the evaluation re-

sults. The Section 5 closes the paper with a summary

and conclusions.

2 BACKGROUND

In Section 2.1 a perspective on the issues of explain-

ability and interpretability in ML/AI for law enforce-

ment and forensics is presented. This perspective is

strongly based on the United Nations Interregional

Crime and Justice Research Institute (UNICRI) and

International Criminal Police Organization (INTER-

POL) joined efford on a ‘Toolkit for Responsible AI

Innovation in Law Enforcement’ (‘AI Toolkit’). In

Section 2.2 the ML-based tool Stegdetect, which acts

as the illustration example for explainability and inter-

pretability issues in this paper, is introduced in some

detail.

2.1 Explainability and Interpretability

in ML/AI for Law Enforcement and

Forensics

Due to the huge amount of beneﬁts that machine

learning (ML) or ‘artiﬁcial intelligence’ (AI) based

methods can offer in law enforcement and forensics

there is a strong pull from policy makers to see them

integrated into an increasing number of procedures

and forensic processes. A good example for this

pull is the following quote from the 60 page docu-

ment (Vaughan et al., 2020) issued by the National

Police Chiefs’ Council (NPCC) of the United King-

dom of Great Britain and Northern Ireland (GB) in

2020: “The insights DF [=digital forensics] science

can bring to an investigation are unique in forensic

science disciplines; society’s pervasive use of tech-

nology gives new power to DF science, allowing

phones, computers and even smart speakers, watches

or doorbells to act as ‘digital witnesses’ to what hap-

pens in daily life. We can get rapid insights from DF

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

586

analysis which in the past could have taken months

of physical surveillance. It also gives unprecedented

access to someone’s innermost thoughts from the con-

tent of conversations, or search histories. If policing

is to use this ability, it is vital it does so responsi-

bly and sensitive to the ethical issues that arise. As

well as new investigative opportunities, advances in

technology offer opportunities to expand DF services.

Rapid growth in cloud services will allow us to sim-

plify and rationalise DF data storage. These same

cloud services allow investigations access to more

processing power, to harness the power of automation

and explore the potential of new and evolving tech-

nologies such as machine learning.”

Until now, forensic practitioners are very hesitant to

rely to much on ML/AI in trustworthy forensic pro-

cesses. The reasons lie on one hand in issues of accu-

racy and proﬁciency and on the other hand in concerns

regarding explainability and interpretability.

The accuracy of such methods is discussed in

(UNICRI and INTERPOL, 2023) as: “Accuracy

corresponds to the degree to which an AI system

can make correct predictions, recommendations or

decisions. It is important that agencies verify that

any system they are developing and/or intend to use is

highly accurate, as using inaccurate AI systems can

result in various types of harm.” [...] The accuracy of

an AI system is dependent on the way the system was

developed, and in particular the data that was used

to train it. In fact, training the system with sufﬁcient

and good quality data is paramount to building a

good AI model. [...] In most cases, it is preferable

that the training data relates to the same or a similar

context as the one where the AI system will be used.”

The deﬁnitions for explainability and inter-

pretability have already been discussed in Section 1

above. As response to the issue of explainability re-

quirements, (UNICRI and INTERPOL, 2023) points

toward the research ﬁeld of ‘explainable AI’, which

“[...] aims to ensure that even when humans cannot

understand ‘how’ an AI system has reached an out-

put, they can at least understand ‘why’ it has pro-

duced that speciﬁc output. This ﬁeld distinguishes

explainability in a narrow sense, as different from

interpretability. [...] In the context of criminal in-

vestigations, the explainability of AI systems used to

obtain or analyze evidence is particularly important.

In fact, in some jurisdictions, criminal evidence ob-

tained with the support of AI systems has been chal-

lenged in courts on the basis of a lack of understand-

ing of the way the systems function. While the re-

quirements for evidence admissibility are different in

each jurisdiction, a sufﬁcient degree of explainability

needs to be ensured for any AI system used to obtain

and examine criminal evidence. This helps guaran-

teeing, alongside the necessary technical competen-

cies, that law enforcement ofﬁcers involved in investi-

gations and forensic examinations have sufﬁcient un-

derstanding of the AI systems used to be able to as-

certain and demonstrate the validity and integrity of

criminal evidence in the context of criminal proceed-

ings.”

2.2 Multi-Class Steganalysis with

Stegdetect

In their seminal paper, (Provos and Honeyman, 2002)

criticise the current state-of-the-art in steganalysis ap-

proaches at the point of time of their publication in

2002 as being practically irrelevant, due to faulty ba-

sic assumptions (modelling as a two-class problem

and statistical over-ﬁtting to the training sets). In con-

trast to these publications Provos and Honeyman con-

struct a multi-class pattern recognition based image

steganalysis detector called Stegdetect: Each input

image for Stegdetect is considered to be member of

one of four classes, either it is an unmodiﬁed cover or

it is the result of the application of one out of three dif-

ferent steganographic tools (JSteg, JPHide and Out-

Guess 0.13b) which have been amongst the state-of-

the-art at this point of time. Stegdetect is then ap-

plied blindly (without knowledge about the true class)

to two million images downloaded from eBay auc-

tions and one million images obtained from USENET

archives. As a result, Stegdetect classiﬁes over 1% of

all images seem to have been steganographically al-

tered (mostly by JPHide) and therefore contain hidden

messages. Based on these ﬁndings, the authors de-

scribe in (Provos and Honeyman, 2002) also a second

tool called Stegbreak for plausibility considerations,

i.e., for verifying the existence of messages hidden by

JPHide in the images identiﬁed by Stegdetect. Their

veriﬁcation approach is based on the assumption that

at least some of the passwords used as embedding

key for the steganographic embedding are weak pass-

words. Based on this assumption, they implement for

Stegbreak a dictionary attack using JPHide’s retrieval

function and large (about 1,800,000 words) multi-

language dictionaries. This attack is applied to all im-

ages that have been ﬂagged as stego objects by the sta-

tistical analyses in Stegdetect. To verify the correct-

ness of their tools, Provos and Honeyman insert tracer

images into every Stegbreak job. As expected the dic-

tionary attack ﬁnds the correct passwords for these

tracer images. However, they do not ﬁnd any single

genuine hidden message. Even though the result of

this large scale investigation is negative, the method-

Explainability and Interpretability for Media Forensic Methods: Illustrated on the Example of the Steganalysis Tool Stegdetect

587

ology and concepts for addressing the interpretability

behind the work in (Provos and Honeyman, 2002) are

remarkable

and are widely considered to be amongst

the ﬁrst (modern) works on forensic steganalysis.

This forensic steganalysis process, as an conceptual

model, is considered in (Fridrich, 2009) to consist

of the following six steps: 1. selection of investiga-

tion targets, 2. reliable 2-class detection that distin-

guishes stego images from cover images, 3. identi-

ﬁcation of the embedding method, 4. identiﬁcation

of the steganographic software, 5. searching for the

stego key and extracting the embedded data, and 6.

decoding/deciphering the extracted data and obtain-

ing the secret message (cryptanalysis). In this process

model, this paper addresses the steps 2 and 3.

3 EXPERIMENTAL SETUP

Stegdetect was seeing functional updates and bug-

ﬁxes for some years. The ﬁnal version released in

2004 by the original authors is Stegdetect 0.6. This

last version added detection support for the steganog-

raphy algorithm F5 to the capabilities and is used as

basis for the experiments conducted here.

Three sets of evaluations are performed within this

paper with the following test goals:

• First (test goal T1), baseline tests are performed

with an unmodiﬁed Stegdetect (using its original

pre-trained models) on steganography algorithms

supposedly supported by Stegdetect and with

image data that should be similar to the material

considered in (Provos and Honeyman, 2002).

• Second (test goal T2), Stegdetect is used only as a

feature extractor allowing for re-training of detec-

tor models using different classiﬁers and thereby

for an estimation of the actual performance

of the Stegdetect feature space. In those tests

steganography algorithms supposedly supported

by Stegdetect are used as well as algorithms for

which Stegdetect was not used before.

• Third (test goal T3), a sequence of smaller tests

is used to determine what the re-trained classi-

ﬁers (and as a consequence the Stegdetect feature

space) are really representing, either image ste-

ganalysis (as originally assumed) or a JPEG en-

coder artefact classiﬁcation. I.e., it is evaluated

whether the Stegdetects feature space actually de-

Unfortunately, no similar effort regarding the explain-

ability of Stegdetect as a tool that might be used in forensics

was performed in (Provos and Honeyman, 2002).

tects the slight variations within the image caused

by steganographic embedding or rather the arte-

facts caused by different JPEG compression algo-

rithms used to create the training and testing im-

ages.

3.1 T1: Evaluation of Stegdetect for

Detecting Image Steganography

As one of the few existing multi-class image steganal-

ysis tools existing, Stegdetect is used for the empir-

ical evaluations in this paper. The work performed

is done using the latest ofﬁcial version released by

Niels Provos as Stegdetect 0.6 ((Provos and Honey-

man, 2002), (Provos, 2004)).

Since this version of Stegdetect (and the pre-

trained detection models contained therein) was pub-

lished in 2002, it was decided for our paper to utilise

the cover data of the ALASKA2 dataset (Kaggle,

2020) well established in the image steganography

and steganalysis community, since it consists of dig-

ital images similarly sized to those widely used in

the early 2000s. By using ALASKA2 data (in-

stead of much newer image steganography reference

databases like StegoAppDB) it can be assumed that

Stegdetects pre-trained models should work for the

supported steganography algorithms at those image

sizes.

In the evaluation setup for those baseline tests for

T1, all 75000 cover images from the ALASKA2 set

are used for embedding of a single stego message.

Afterwards, Stegdetect is run on the stego images as

well as on the cover images in order to determine the

detection performance.

For the exemplary stego algorithms, we use F5

(Feng, 2012) JPHide (Church, 2017), both of which

are supposedly supported by Stegdetect.

3.2 T2: Using the Stegdetect Feature

Spaces in Conjunction with Various

Classiﬁers

Motivated from the differences in detection perfor-

mances reported in (Provos and Honeyman, 2002)

and the results for our own baseline tests (T1), the sec-

ond objective in this paper is to perform an evaluation

of the feature space of Stegdetect. Besides the actual

classiﬁcation in a black-box mode, the tool allows in

a gray-box (debug) setup also the exporting the fea-

ture vectors that are extracted. It separates them into

the following four feature sub-spaces: 1. Differen-

tial of Squares Error features, 2. Gradient features, 3.

Roughness features, 4. Spline interpolation features.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

588

In the experiments within this paper, this gray-

box setup is used to enable a feature-level fusion by

concatenating the four feature vectors for those sub-

spaces in order to form a combined feature vector.

Turning Stegdetect from a black-box into a gray-box

feature extractor allows for re-training detector mod-

els using different classiﬁers from the Weka data min-

ing suite (Frank et al., 2016) and thereby for a better

estimation of the usability of the Stegdetect feature

space. In addition to the stego algorithms natively

supported by Stegdetect (F5 and JPHide), for those

tests also Jsteg (Champine, 2011), Steghide (Hetzl,

2003) and the LSB stego tool Stegano (Bonhomme,

2023) with an additional JPEG compression are uti-

lized in the training and test procedures.

3.3 T3: Steganalysis vs. JPEG Encoder

Artefact Classiﬁcation

The third experimental setup is designed to inves-

tigate the initial assumption of correlation instead

of causality towards the detection results using the

Stegdetect feature space. In order to perform the ex-

periments, the feature extraction mode of Stegdetect

is used exactly like in T2, again with using the Weka

data mining suite to perform the evaluation.

For the evaluation a subset of 9370 randomly

drawn genuine samples from the ALASKA2 dataset

(Kaggle, 2020) are used and ﬁrst converted into the

PNG format. Afterwards, the pixel domain Least Sig-

niﬁcant Bit (LSB) replacement tool Stegano (Bon-

homme, 2023) is used to embed a stego message

into those images. After this preparation phase,

the images are converted using ImageMagick’s con-

vert tool (with command line options -quality 100

-sampling-factor 4:4:4) and the Python Image

Library (PIL). We chose the latter, because it is also

used as the JPEG encoder within the Python imple-

mentation of F5 that is used in the test performed here.

With that setup it is obvious that the stego message

embedded by Stegano is destroyed by the JPEG com-

pression performed. The artefacts caused in the image

by the LSB replacement are overwritten by the mod-

iﬁcations and corresponding artefacts cased by the

new last step in the image editing history, the JPEG

compression.

The evaluation setup for T3 consists of multiple

experiments:

1. Single compression with the PIL algorithm for

genuine and stego images

2. Single compression with the ImageMagic algo-

rithm for genuine and stego images

3. Double compression of stego images with PIL in

the ﬁrst place and ImageMagick in the second

place, single compression of the genuine images

with PIL

4. Double compression of stego images with Im-

ageMagick in the ﬁrst place and PIL in the second

place, single compression of the genuine images

with ImageMagick

5. Double compression of stego images with PIL in

the ﬁrst place and ImageMagick in the second

place, single compression of the genuine images

with ImageMagick

6. Double compression of stego images with Im-

ageMagick in the ﬁrst place and PIL in the second

place, single compression of the genuine images

with PIL

Each of the experiments is designed in order to deter-

mine whether Stegdetects feature space actually de-

tects the slight variations within the image caused

by steganographic embedding or rather the artefacts

caused by different JPEG compression algorithms.

In order to exclude classiﬁcation-algorithm-

dependent inﬂuences, the experiments are run as a

two fold stratiﬁed cross validation with the following

ﬁve classiﬁcation algorithms from the Weka data min-

ing suite: Bagging, J48 (C4.5 decision tree), Logistic

Model Tree (LMT), RandomForest and SMO.

4 EVALUATION RESULTS

In this Chapter, the results for the experiments de-

scribed in Chapter 3 are summarised.

4.1 Evaluation Results for T1

The evaluation results using the integrated detection

models of Stegdetect are shown in Table 1. The true

negative rate classifying the unmodiﬁed cover images

is with 90.05% rather low, which in return means

a false alarm rate of almost 10 percent. Moreover

the detection rate for JPHide is quite rather low at

31.96%. For F5, Stegdetect offers two different op-

eration modes. Even using the slower (and more pre-

cise) detection mechanism, a mere 8.19% of the stego

samples for the Python implementation of F5 are cor-

rectly detected. Those results signiﬁcantly deviate

from those reported in the work of Provos and Honey-

man (Provos and Honeyman, 2002). This drop in the

detection performances between 2002 and now indi-

cates that the pre-trained models in Stegdetect did not

age well and lost performance on newer images. This

assumption is evaluated in the tests performed for T2.

Explainability and Interpretability for Media Forensic Methods: Illustrated on the Example of the Steganalysis Tool Stegdetect

589

Table 1: Detection performance of Stegdetect (original, pre-

trained models) based on 75000 samples each for the classes

genuine (=cover), JPHide and F5.

True Negative

(on covers)

True Positive

JPHide

True Positive

90.05% 31.96% 8.19%

4.2 Evaluation Results for T2

The evaluation results for the two-fold stratiﬁed cross-

validation using the concatenated feature sub-spaces

of Stegdetect together with a training of new detec-

tor models using four arbitrarily selected classiﬁca-

tion schemes of the Weka data mining software are

summarised in Table 2. Overall pretty convincing de-

tection rates are achieved for F5, Jsteg and the JPEG-

converted LSB samples from Stegano. The latter is

quite surprising, as the LSB embedding (which was

done on PNG versions of the cover image ﬁles) should

be heavily corrupted or completely destroyed by the

JPEG conversion and compression using ImageMag-

ick’s convert utility even at a quality factor of 100%.

On the other hand, for Steghide and JPHide no us-

able results are achieved. While this might be reason-

able for Steghide, since Stegdetect is not designed for

that algorithm, at least detecting JPHide should yield

a better performance.

Those results for Stegano particularly raise the

question what is distinguished between using those

feature spaces - is it actually the embedding of a

steganographic message within a JPEG compressed

image or is it rather the utilised JPEG compression

library in conjunction with the compression param-

eters. The sole purpose of the T3 experiments is to

answer that question.

4.3 Evaluation Results for T3

After achieving questionable results for some of the

steganography algorithms in T2 (especially for the

LSB replacement performed by Stegano) while using

newly trained models on the existing Stegdetect fea-

ture space, additional experiments with double com-

pression of the images using two different JPEG en-

coders (ImageMagick and PIL) are performed.

The evaluation results for the six experiments

for cover data and Stegano output described in Sec-

tion 3.3 for T3 are summarised in Table 3.

Most of those results indicate that the feature

space is more sensitive to the JPEG compression algo-

rithm rather than the embedded steganographic mes-

sages. As a result, if genuine (=cover) data and stego

data is compressed with the same algorithm, the clas-

siﬁcation performance is low. There is one exception,

though. When using a double compression with Im-

ageMagick in the ﬁrst compression and PIL in the sec-

ond compression, the classiﬁcation accuracy remains

high - at > 99.75% - when training with PIL com-

pressed genuine images. Since the LSB replacement

performed by Stegano is mostly destroyed during the

JPEG compression, this result is quite surprising, es-

pecially since all other experiments indicate a total

loss of discriminatory power when both sets of im-

ages are compressed with the same JPEG encoder in

the last step. This phenomenon can not be explained

with the current evaluations and would require further

investigations.

Generalising the results obtained, it can be stated

that the high classiﬁcation accuracies obtained here

(and of course in T2) for Stegano are not due to suc-

cessfully performed steganalysis but rather due to the

fact that the machine learning approach has success-

fully trained the strongest characteristic present which

is in this case the inﬂuences imposed to the images by

the JPEG encoder used.

5 SUMMARY & CONCLUSIONS

The results presented here for image steganalysis

show machine learning driven solutions are suffering

from ageing effects of the trained models: In the ex-

periments performed for T1 the performance obtained

in 2023 is much lower than the original performance

reported in 2002 even though the conditions of the

tests are closely reconstructed.

Secondly, detectors that come as a black-box (here

Stegdetect) should be turned into (more) transpar-

ent (i.e., gray- or white-box) mechanisms, which was

here achieved by using the raw feature vectors that

could be output from Stegdetect for debug reasons.

Based on those feature vectors, a wide range of classi-

ﬁcation algorithms from a well established data min-

ing suite (here Weka (Frank et al., 2016)) are trained

and the results are analysed and compared. This work

could easily be extended by applying model inter-

pretation or feature selection strategies also offered

within Weka.

Third, Machine learning tends to train/learn the

most signiﬁcant difference in the feature space pro-

jections of the classes present in the training data. It

is shown, that, in case of the Stegdetect feature space,

this tends to be the artefacts caused by the JPEG

encoder used. In case of steganography tools that

are embedding in the JPEG transform domain (e.g.,

Jsteg which directly modiﬁes the DCT coefﬁcients)

these tools are basically implementing an own, non-

standard JPEG encoder. Therefore, in their case the

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

590

Table 2: Detection performance using the re-trained Stegdetect (with Weka classiﬁers) in using the concatenated Stegdetect

feature space. Results based on 75000 samples for genuine and stego images in a 2-fold stratiﬁed cross-validation.

F5 Jsteg Steghide JPHide Stegano +

ImageMagick

convert

Weka Classiﬁer TN TP TN TP TN TP TN TP TN TP

Bagging 97.9% 96.9% 97.1% 98.1% 67.2% 35.6% 50.2% 52.7% 99.6% 99.8%

J48 95.9% 96.3% 96.9% 96.9% 84.0% 24.7% 56.3% 55.1% 99.5% 99.6%

RandomForest 98.7% 97.8% 97.9% 98.3% 66.9% 25.0% 40.3% 39.5% 99.8% 99.9%

SMO 96.2% 96.5% 95.5% 96.3% 96.4% 10.8% 55.0% 54.9% 99.6% 99.9%

Table 3: T3: Results of the 2-fold stratiﬁed cross-validation using the Weka data mining suite with 9370 genuine and 9370

stego samples; In these tests only the steganography tool Stegano performing LSB replacement in pixel domain was used to

create the stego ﬁles.

Training PIL com-

pressed Genuine

Training ImageMag-

ick compressed Gen-

uine

Last Compression First

Compres-

sion

Weka Classiﬁer Genuine Stego Genuine Stego

Python Image Library (PIL) none Bagging 28.06% 27.75% -

J48 100.00% 0.00%

LMT 80.90% 18.15%

RandomForest 25.86% 23.23%

SMO 46.82% 45.94%

Image-

Magick

Bagging 38.64% 40.22% 99.79% 99.68%

J48 100.00% 0.00% 99.65% 99.74%

LMT 80.79% 18.32% 99.88% 99.80%

RandomForest 26.89% 24.53% 99.83% 99.94%

SMO 47.85% 48.10% 99.88% 99.78%

ImageMagick none Bagging 28.26% 28.80% -

J48 100.00% 0.00%

LMT 47.56% 48.88%

RandomForest 26.52% 22.37%

SMO 45.12% 48.29%

PIL Bagging 99.90% 99.80% 67.04% 98.04%

J48 99.82% 99.75% 98.09% 97.62%

LMT 99.93% 99.94% 99.46% 98.92%

RandomForest 99.99% 99.96% 99.36% 98.16%

SMO 99.94% 99.94% 99.56% 98.47%

attribution of the stego tool as an attribution of the en-

coder will give reliable results.

Generalising those results, it can be said that ma-

chine learning (ML) / ‘artiﬁcial intelligence’ (AI)

methods learn to distinguish the most apparent differ-

ences between the different classes presented in train-

ing. This is not necessarily the one that has been in-

tended in the learning setup but could also be an un-

foreseen effect, as demonstrated above in the discus-

sions on T3.

For that reason, ML-/AI-based forensic methods

need to undergo vigorous quality assurance and

proﬁciency testing before they can be included into

trustworthy forensic processes and afterwards a

cyclic re-evaluation of the models trained and the

feature spaces used needs to be performed during

the operational life of such a ML-/AI-based forensic

method. Especially in media forensics, models

trained are assumed to age pretty badly since the

assumed source characteristics are signiﬁcantly

changing over times. This can be well illustrated with

digital images, where the technical developments

since the late 1990s saw a steady but signiﬁcant

increase in image sizes and resolutions as well

Explainability and Interpretability for Media Forensic Methods: Illustrated on the Example of the Steganalysis Tool Stegdetect

591

as leap-breaks with new image formats (e.g., the

High Efﬁciency Image File Format (HEIF) or High

dynamic range (HDR) image formats).

Considering the explainability and interpretabil-

ity of the outcomes of such forensic investigations, as

requested, amongst others, in (UNICRI and INTER-

POL, 2023), the quality assurance and proﬁciency

testing work performed needs to ensure not only the

necessary technical competencies of the individual

practitioners involved in an examination. It also needs

to enable the investigators to have sufﬁcient under-

standing of the ML/AI systems used and to be able to

ascertain and demonstrate the validity and integrity of

evidence in the context of criminal proceedings.

ACKNOWLEDGEMENTS

This work received funding from the European

Union’s Horizon 2020 research and innovation pro-

gram under grant agreement No 101021687 (project

“UNCOVER”).

The authors wish to thank Jana Dittmann for her

comments on the evaluation procedure.

Author Contributions. Initial idea & methodol-

ogy: Christian Kraetzer (CK); Conceptualization:

CK, Mario Hildebrandt (MH); Discussion on Ex-

plainability and Interpretability in ML/AI for Law En-

forcement and Forensics: CK, Empirical evaluations -

design: CK, MH; Empirical evaluations - realisation:

MH; Writing – original draft: CK; Writing – review

& editing: MH.

All authors have read and agreed to the published

version of the manuscript.

REFERENCES

Bonhomme, C. (2023). Stegano.

https://github.com/cedricbonhomme/Stegano -

last accessed: October 26st, 2023.

Champine, L. (2011). Jsteg - jpeg steganography.

https://github.com/lukechampine/jsteg - last accessed:

October 26st, 2023.

Church, D. (2017). jphide & seek steganography tools.

https://github.com/h3xx/jphs - last accessed: October

26st, 2023.

European Network of Forensic Science Institutes (ENFSI)

(2021). Best Practice Manual for Digital Image Au-

thentication. Technical Report BPM-DI-03-2021, Eu-

ropean Network of Forensic Science Institutes (EN-

FSI), Wiesbaden, Germany.

Feng, J. (2012). f5-steganography, a python implement

of f5 steganography. https://github.com/jackfengji/f5-

steganography - last accessed: October 26st, 2023.

Frank, E., Hall, M. A., and Witten, I. H. (2016). The WEKA

Workbench. Online Appendix for Data Mining: Prac-

tical Machine Learning Tools and Techniques. Mor-

gan Kaufmann, Burlington, MA, 4th edition.

Fridrich, J. (2009). Steganography in Digital Media: Prin-

ciples, Algorithms, and Applications. Cambridge Uni-

versity Press, New York, NY, USA, 1st edition.

Hetzl, S. (2003). Steghide. https://steghide.sourceforge.net/

- last accessed: October 26st, 2023.

Kaggle (2020). Alaska2 image steganalysis set.

https://www.kaggle.com/competitions/alaska2-

image-steganalysis/data - last accessed: August 21st,

2023.

Provos, N. (2004). Stegdetect.

https://www.provos.org/p/outguess-and-stegdetect-

downloads/ - last accessed: October 24th, 2023.

Provos, N. and Honeyman, P. (2002). Detecting stegano-

graphic content on the internet. In NDSS. The Internet

Society.

UNICRI and INTERPOL (2023). Toolkit for Responsi-

ble AI Innovation in Law Enforcement: Principles for

Responsible AI Innovation. Guidelines, United Na-

tions Interregional Crime and Justice Research Insti-

tute (UNICRI) and International Criminal Police Or-

ganization (INTERPOL), Brussels.

Vaughan, J., Baker, N., and Underhill, M. (2020). Digi-

tal Forensic Science Strategy. Policy, National Police

Chiefs’ Council (NPCC), London, UK.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

592
