Vision Based Malware Classiﬁcation Using Deep Neural Network with

Hybrid Data Augmentation

Md. Mahbubur Rahman

1,3 a

, Md. Delwar Hossain

1 b

, Hideya Ochiai

, Youki Kadobayashi

Tanjim Sakib

and Syed Taha Yeasin Ramadan

3 c

Division of Information Science, Nara Institute of Science and Technology, Nara, Japan

Graduate School of Information Science, The University of Tokyo, Tokyo, Japan

Military Institute of Science and Technology, Dhaka, Bangladesh

Keywords:

Malware Classiﬁcation, Deep Learning, Vision Transformer, DCGAN.

Abstract:

Preventing malware attacks is crucial, as they can lead to ﬁnancial losses, privacy breaches, system downtime,

and reputational damage. Various machine learning and deep learning techniques have been proposed for

malware classiﬁcation. However, to evade detection, ﬁles from the same family are often altered by malware

developers using various approaches so that they appear to be separate ﬁles. They may even appear as previ-

ously unidentiﬁed, commonly referred to as zero-day threats. These attacks can compromise the robustness of

deep learning models trained for malware classiﬁcation. In this research, we developed six ﬁne-tuned Deep

Neural Network (DNN) classiﬁers for classifying malware represented as images. A hybrid data augmenta-

tion technique based on Deep Convolutional Generative Adversarial Network (DCGAN) and traditional image

transformation methods has been proposed to train the classiﬁers, enabling them to better handle malware vari-

ants. A subset of the publicly available Malimg dataset, comprising six-class and the whole dataset, were used

in the experiment. Additionally, both datasets were expanded using the proposed augmentation technique to

train the developed classiﬁers. Experimental results reveal that vision transformer-based classiﬁers, trained

with the proposed data augmentation technique, achieve a maximum accuracy of 99.94% for six-class classi-

ﬁcation and 99.79% for 25-class classiﬁcation.

1 INTRODUCTION

Malware is any software that is expressly designed

to harm, exploit or compromise computer systems,

networks and devices. It includes a wide variety of

dangerous applications such as viruses, worms, tro-

jans, ransomware, spyware, adware and others. Tra-

ditional malware detection systems rely on signature-

based approaches and heuristics to recognize known

malware patterns or questionable activities. These

systems compare the digital signatures or features

of ﬁles and network trafﬁc to a database of known

virus signatures. While these methods have been ef-

ﬁcient in detecting known malware, they have nu-

merous limitations. Typical signature-based detection

systems are reactive in nature, as they can only detect

https://orcid.org/0000-0001-6525-2274

https://orcid.org/0000-0002-5968-0704

https://orcid.org/0000-0003-4275-6917

and block malware for which signatures have already

been developed and submitted to the database. This

implies that new and previously unknown malware,

known as zero-day threats, can simply evade these

defenses leaving networks open to attacks. Second,

malware developers have devised methods to avoid

signature-based detection. They can obfuscate or en-

crypt their malicious code, making typical detection

systems struggle to identify the malware based on

its signature. To overcome these limitations, more

advanced and adaptive approaches, such as machine

learning and behavioral analysis are being employed

to enhance malware detection capabilities.

Recent advancements in malware detection have

seen the utilization of advanced Convolutional Neu-

ral Network (CNN) models. CNNs, originally de-

signed for image recognition tasks, have proven to

be effective in detecting patterns and features in com-

plex data, including malware. By treating malware

samples as images, CNN models may learn com-

Rahman, M., Hossain, M., Ochiai, H., Kadobayashi, Y., Sakib, T. and Ramadan, S.

Vision Based Malware Classiﬁcation Using Deep Neural Network with Hybrid Data Augmentation.

DOI: 10.5220/0012434400003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 823-830

ISBN: 978-989-758-683-5; ISSN: 2184-4356

823

plicated patterns and features that distinguish mali-

cious software from benign software. In addition to

CNN models, the usage of Vision Transformers has

gained attention in malware detection. Vision Trans-

formers use self-attentional mechanisms to identify

interdependencies and linkages between various mal-

ware sample components. This enables the models

to efﬁciently categorize and analyze different mal-

ware types based on their visual representations (Ma

et al., 2021). On the other hand, by exposing the

deep learning models to a wider variety of malware

samples, it enables higher generalization and robust-

ness. Image augmentation is commonly used in ma-

chine learning to artiﬁcially increase the diversity of a

training dataset by applying various transformations

to the existing images. Generative Adversarial Net-

work (GAN) can also produce samples using its gen-

erator and discriminator networks that closely resem-

ble the traits of novel and undiscovered malware vari-

ants, this strategy can be used to alleviate the difﬁ-

culties caused by the dynamic and evolving nature of

malware (Hu et al., 2021).

In this paper, we present a comprehensive method-

ology for malware classiﬁcation, involving both pre-

processing and augmentation of the dataset. The pa-

per introduces following contributions in the the ﬁield

of malware classiﬁcation through the following key

points-

1. The paper develops ﬁne-tuned Transfer (BiT-M-

R50x1, BiT-S-R50x1) ), Transformer (ViT-B/32

and ViT-B/16) and CNN (DenseNet121,VGG16)

models based classiﬁers for vision oriented mal-

ware classiﬁcation.

2. The paper introduces the usage of a hybrid

data augmentation technique based on DCGAN

and traditional image transformation methods for

training robustness.

3. The paper demonstrates the usage of hybrid aug-

mentation technique for dataset augmentation to

train deep learning classiﬁers for performance en-

hancement.

The paper then compares the results of models trained

on the augmented dataset with those trained on the

original dataset demonstrating the impact of proposed

augmentation technique on model performance. The

results demonstrated the effectiveness of advanced

machine learning models particularly the ViT-B/32

model with proposed augmentation technique, in ac-

curately classifying and detecting malware.

2 RELATED WORKS

CNN models have been widely used in recent years

for detecting and classifying malware. M. Yeo et

al. (Yeo et al., 2018) suggested an automated mal-

ware detection approach based on CNN and other

machine learning algorithms. Instead of relying on

port numbers and protocols, the technique utilized 35

different features retrieved from packet ﬂow. Using

Stratosphere IPS project data, the study revealed that

CNN and Random Forest (RF) obtained superior per-

formance with over 85% accuracy, precision and re-

call for all classes. Arindam Sharma et al. (Sharma

et al., 2019) offers a highly accurate and efﬁcient mal-

ware detection solution based on 1-dimensional CNN.

The system classiﬁes binary ﬁles as dangerous or be-

nign with minimum preprocessing, allowing the net-

work to uncover features during training. The use

of 1-dimensional convolutions distinguishes this ap-

proach from previous CNN-based approaches, result-

ing in better accuracy and training times when com-

pared to state-of-the-art techniques. Mahmoud Ab-

delsalam et al. (Abdelsalam et al., 2018) provides an

effective virus detection solution for cloud infrastruc-

tures based on CNN. The study employs a standard

2D CNN trained on metadata from virtual machine

processes and improves accuracy with a unique 3D

CNN that considers samples over a time interval. Ex-

periments on randomly selected malware show that

the 2D CNN model obtains an accuracy of roughly

79%, whereas the 3D CNN model greatly improves

accuracy to over 90%.

Shun Tobiyama et al. (Tobiyama et al., 2016) of-

fers a malware detection method based on process be-

havior that employs Deep Neural Networks (DNN).

The suggested method entails training a Recurrent

Neural Network (RNN) to extract features of process

activity and a CNN to classify feature images created

from the recovered features. The evaluation ﬁndings

show great accuracy, with an AUC of 0.96 obtained

in the best case scenario. Jixin Zhang et al. (Zhang

et al., 2016) offers IRMD, a malware variant detec-

tion approach based on opcode image recognition. In

this method, binary executables are broken down into

opcode sequences and then transformed into pictures.

The method detects harmful executables by using a

CNN to compare the opcode images of target binaries

with those of known malware samples. When the de-

tection set contains a large number of binaries and the

training set is limited, theoretical analysis and real-

world testing show that the visualized analysis strat-

egy improves detection accuracy by 15%.

Verma et al. (Verma et al., 2020) introduced

an innovative approach that combines ﬁrst-order and

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

824

second-order statistical texture features derived from

grey level co-occurrence matrix (GLCM) for visual-

ized malware classiﬁcation using ensemble learning.

They achieved an accuracy of 98.58%. Recently, the

use of Vision Transformers (ViTs) also has gained at-

tention in the ﬁeld of malware detection (Belal and

Sundaram, 2023).

In this paper, we introduce an efﬁcient approach

for malware detection by Big Transfers, Vision Trans-

formers, CNNs and GANs. Our methodology lever-

ages the strengths of each model and incorporates

data augmentation techniques to enhance detection

accuracy and robustness. The results obtained from

our approach are compared with existing techniques,

demonstrating its effectiveness in detecting and clas-

sifying malwares.

3 METHODOLOGY

The methodology used in this study is separated into

two parts. Here we explored how the robustness of

the deep learning models can be increased by expos-

ing diversiﬁed examples to the models in vision-based

malware classiﬁcation. The initial dataset was cre-

ated from publicly available popular data set – Mal-

img (Nataraj et al., 2011) which has 25 diversiﬁed

families of malware samples.

As we employ GAN model for new image sample

generation, for high- quality generation of new image

samples, a good number of samples are required. For

our case, we opted for classes with over 300 samples,

resulting in a total of six classes and 6560 image sam-

ples that constitute our base dataset. We augmented

this base dataset using traditional, GAN and Hybrid

augmentation techniques. In preprocessing stage, we

employ techniques such as scaling and normalization

to convert the raw dataset into a classiﬁcation-ready

state. The developed classiﬁers are trained on the pre-

processed datasets and their performance is assessed

using measures such as accuracy, loss, precision, re-

call and F1 score. In the next part of the methodology,

we experimented using the whole Malimg dataset fol-

lowing similar strategy. Figure 1 displays the overall

methodology.

3.1 Malware Detection Using Deep

Neural Network (DNN)

3.1.1 Big Transfer

BigTransfer or BiT introduced by Google stands out

as an advanced transfer learning technique designed

for image classiﬁcation. Its utilization of pre-trained

Figure 1: Overall methodology of the study.

representations enhances sample efﬁciency and sim-

pliﬁes the hyperparameter tuning process during the

training of deep neural networks for visual tasks. BiT

reevaluates the traditional approach of pre-training on

expansive supervised datasets and subsequently ﬁne-

tuning the model for a speciﬁc target task.

3.1.2 Vision Transformer

Vision Transformer (ViT) (Dosovitskiy et al., 2020) is

an advanced deep-learning model created exclusively

for image identiﬁcation tasks. It differs from typi-

cal convolutional neural networks (CNNs) in that it

makes use of the capability of transformer-based ar-

chitectures, which were originally created for natu-

ral language processing. ViT uses the self-attention

method to images, allowing it to detect both local

and global dependencies. The input image is divided

into patches in ViT, each of which is represented by a

ﬁxed-size vector. These patches are then linearly em-

bedded to get their embeddings. Positional embed-

dings are added to the patch embeddings to incorpo-

rate positional information.

3.1.3 CNN Models

The CNN model utilizes convolution and pooling lay-

ers to autonomously extract various hierarchies of

features, ranging from basic attributes such as edges

and corners to highly speciﬁc details. Typically, the

feature maps undergo ﬂattening through a ﬂatten or

global pooling operator, resulting in a 1-dimensional

feature vector. This vector is subsequently fed as in-

put through several fully-connected dense layers, cul-

minating in the prediction of the output class using a

softmax output layer. The goal of this hierarchical ar-

chitecture, implemented across multiple stages, is to

acquire spatial hierarchies of features while maintain-

ing translation invariance. This is made feasible by

means of the convolution and pooling layers, the two

primary components in the CNN architecture. In this

study, DenseNet121 and VGG16 are employed in our

experimentation as CNN models.

Vision Based Malware Classiﬁcation Using Deep Neural Network with Hybrid Data Augmentation

825

Input Layer (128,128,3)

Model

Batch Normalization

Dense (1028)

Batch Normalization

Dropout (0.2)

Dense (256)

Batch Normalization

SELU Activation

GlobalAveragePooling

Dense (64)

Batch Normalization

Dense (6)

SELU Activation

Dropout (0.2)

Figure 2: Layer architecture of deep learning models.

3.1.4 Proposed DNN Model

The proposed DNN layer architecture is shown in Fig-

ure 2. The input layer has the shape (128,128,3), in-

dicating that it accepts images with 128x128 pixels

and three color channels (RGB). Following that, the

model (Transfer, Transformer or CNN) goes through

multiple layers of operations to extract relevant fea-

tures and classify the input images.

The GlobalAveragePooling layer is the ﬁrst layer

after the input layer and it decreases the spatial dimen-

sions of the feature maps by computing the average of

each feature map, resulting in a more compact repre-

sentation of the data. Following that, a Batch Nor-

malization layer is used to normalize the activations

of the previous layer, enhancing the model’s stabil-

ity and convergence during training. The Dense layer

with 1028 units is followed by the SELU (Scaled Ex-

ponential Linear Units) activation function.

The activation functions known as Scaled Ex-

ponential Linear Units, or SELU, induce self-

normalizing features is deﬁned as:

SELU(x) = λ ·

(

x, if x > 0

α · (exp(x) − 1), if x ≤ 0

(1)

where, α and λ are two hyperparameters. In order

to maintain the mean and variance of activations at

or near 0 and 1, respectively, during training, SELU

provides self-normalization.

Following the activation of the SELU, the subse-

quent layers are designed with combination of Batch

Normalization, Dropout (0.2), SELU and Dense lay-

ers as depicted in Figure 2. The model hyper-

parameters are shown in Table 1.

Table 1: Hyperparameters used in the experiment.

Batch Epochs Optimizer Learning Loss

Size Rate

128 50 Rectiﬁed- 1.00E-3 Categorical

Adam Cross-

entropy

3.2 DCGAN Data Augmentation

The DCGAN (Deep Convolutional Generative Adver-

sarial Network) is a type of generative model that uses

deep convolutional neural networks to generate real-

istic images. The architecture of DCGAN consists of

two main components: the generator and the discrim-

inator. The generator aims to generate realistic im-

ages from random noise, while the discriminator tries

to distinguish between real and generated images by

minimizing corresponding losses.

The generator and discriminator losses are given

L gen = −

∑

i = 1

log(D(G(z

))) (2)

and

L disc = −

∑

i = 1

[log(D(x

))

+log(1 − D(G(z

)))]

(3)

where, D represents the discriminator, G repre-

sents the generator, x

represents the real images, z

represents the random noise vectors and N represents

the batch size.

3.3 Hybrid Augmentation

GAN has the capability to produce data that closely

mimics the patterns present training data it has been

exposed to. However, it generates images in an un-

supervised manner and controlling speciﬁc augmen-

tation parameters e.g., rotation angle are challenging.

The quality of images generated by GANs may not al-

ways match the quality of real images in the training

set. It may introduce artifacts and inconsistencies in

the augmented data, Training GANs can be challeng-

ing and unstable. GANs involve training a generator

and a discriminator simultaneously, and ﬁnding the

right balance can be difﬁcult. Instabilities in training

may lead to poor-quality generated images or an in-

effective augmentation process. For that we adopted

hybrid augmentaion approach for training the classi-

ﬁer. Here the data is augmented using DCGAN. Ad-

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

826

ditionally we augment the data using traditional aug-

mentation method. Finally, original training data and

augmented data from GAN and traditional augmenta-

tion are used for training.

4 RESULT ANALYSIS

In this study, we used Malimg dataset (Nataraj et al.,

2011) which comprises of malware samples classi-

ﬁed into various kinds. Here, Windows malwares are

treated as binary codes, with each 8 bits representing

a pixel value. These values map to the grayscale im-

age pixels ranging from 0 to 255. The dataset contains

a total of 9339 samples. Each malware variant has a

different number of samples, ranging from as little as

80 for Skintrim.N to as many as 2949 for Allaple.A.

Our initial dataset referred to as the base dataset

consists of six classes extracted from the Malimg

dataset and comprises 6560 samples of images de-

picting malware. We augmented the image samples

of six classes using DCGAN so that the total samples

became 7200 with more images were generated for

small classes. Table 2 depicts the distribution of the

6 malware families/classes of base dataset and their

corresponding augmentation numbers. Though the

original dataset Malimg contains 25 families, in our

initial study we have chosen 6 falmilies, those who

have 300 or more samples for DCGAN augmenta-

tion. The chosen families come from differnt worm,

trojan, rogue types of malwares. Among them Al-

laple.A and Allaple.L are varints of Win32/Allaple

family that represents a multi-threaded, polymorphic

network worm with the ability to propagate across in-

terconnected computers within a local area network

(LAN) (Microsoft, 2023). The worm’s ﬁle possesses

polymorphic encryption, causing each instance of the

worm to be distinct from one another. The rest of the

families exhibit their own distinct traits for infecting

systems through their unique methods of deception.

Figure 3 shows three distinct sets of samples: mal-

ware samples sourced from the Malimg dataset, sam-

ples generated by the DCGAN model and samples

created through image transformation techniques.

The base dataset for this work was augmented

with DCGAN, resulting in an additional 640 sam-

ples comprising the GAug dataset. Augmentaion of

the base dataset samples were also performed equally

(Table 2) using traditional augmentation technique,

the resulting dataset is referred to as TAug. The aug-

mentation procedure sought to improve the robustness

and generalization capabilities of the malware detec-

tion models by increasing the diversity and variability

of the dataset. Finally, the HAug dataset is formed

Figure 3: (a) Malware samples from Malimg dataset. (b)

DCGAN generated samples. (c) Samples generated using

image transformation.

by combining samples from the base dataset, addi-

tional samples generated through DCGAN augmen-

tation and traditional augmentation methods.

In our experiments, for each cases 20 percent data

were set aside for testing purposes and the developed

classiﬁers were trained using rest 80 percent of the

data. For classiﬁers trained with base data set, we

noticed variable performance across the examined ar-

chitectures for malware detection. Models’ perfor-

mances with respect to Precision, Recall, F1-score

and loss values are furnished in Table 3. The per-

formance values of various models after trained with

augmented dataset in malware detection with respect

to Precision, Recall, and F1 score are also furnished

in Table 3. Some training scenarios are depicted in

Figure 4 for six-class classiﬁcation.

From Table 3, it is evident that augmentation

positively affects the performance of different clas-

siﬁers in six-class classiﬁcation. For example, the

DenseNet121-based classiﬁer obtains precision val-

ues of 0.9832, 0.9885, 0.9888, and 0.9888 for the

Non-augmented, TAug, GAug, and HAug datasets,

respectively. Similarly, for the Vit-B/16-based clas-

siﬁer, recall values of 0.9984, 0.9972, 0.9986, and

0.9993 are obtained for the Non-augmented, TAug,

GAug, and HAug datasets, respectively. In general,

classiﬁers trained on GAN-augmented and Hybrid

methods produced augmented datasets achieve bet-

ter results than classiﬁers trained with non-augmented

dataset. Even they perform better than the classiﬁers

trained with datasets augmented with traditional tech-

niques. It is to be noted that ViT-based classiﬁers

exhibited a close performance when trained with a

non-augmented dataset in comparison to their perfor-

mance when trained with an augmented dataset.

Figure 5 provides a overview of the performance

measures, speciﬁcally accuracy of various machine

learning models when augmented with different tech-

niques. DCGAN, No Augmentation, Traditional

Augmentation and a Hybrid method are all studied.

Vision Based Malware Classiﬁcation Using Deep Neural Network with Hybrid Data Augmentation

827

Table 2: Augmented Dataset (DCGAN and Traditional aug-

mentation.)

Malware

Family/Class

Malware

Type

Number of

Samples

Additional

Augmented

samples

Augmented

Dataset

Allaple.A

Allaple.L

Fakerean

Instantaccess

VB.AT

Yuner.A

Worm

Rogue

Trojan

Worm

Trojan

2949

1591

381

431

408

800

140

2989

1631

521

571

548

940

Total 6560 640 7200

Figure 4: For six-class classiﬁcation: (a) and (b) are ViT-

B/32 model’s Epoch vs. Accuracy graph and confusion ma-

trix after training with dataset with hybrid augmentation.

and confusion matrix after training with dataset with hybrid

augmentation. (e) and (f) are Vit-B/32 model’s Epoch vs.

Accuracy graph and confusion matrix where no augmenta-

tion is used.

BiT-M-R50x1, BiT-S-R50x1, ViT-B/32, ViT-B/16,

DenseNet121 and VGG16 are among the models un-

der consideration. Notably, the DCGAN augmenta-

tion technique consistently produces excellent accu-

racy across all models, with BiT-M-R50x1 scoring

98.4%, BiT-S-R50x1 scoring 97.91%, ViT-B/32 scor-

ing 99.93%, ViT-B/16 scoring 99.86%, DenseNet121

scoring 98.89%, and VGG16 scoring 98.95%. On the

other hand hybrid augmentation techniques perform

best accross models. This demonstrates the efﬁcacy

of GAN based augmentation and Hybrid augmenta-

Figure 5: Comparison of accuracy for six-class classiﬁca-

tion.

tion technique in improving model performance.

Among the other models, ViT-B/32 and ViT-B/16

demonstrated exceptional performance with accuracy

values of 99.93% and 99.86%, respectively. They

both achieved near-perfect precision, recall and F1

scores, highlighting their ability to accurately classify

malware instances. Comparatively, DenseNet121 and

VGG16 achieved slightly lower accuracies ranging

from 96.58% to 99.16%. However, they still exhibited

reasonably high precision, recall and F1 scores, indi-

cating their effectiveness in malware detection. BiT

models also show improved performance after train-

ing with augmented dataset.

Models trained without augmentation perform

somewhat worse in terms of accuracy. For

example, BiT-M-R50x1 achieves 97.1%, BiT-S-

R50x1 achieves 96.8%, ViT-B/32 achieves 99.85%,

ViT-B/16 achieves 99.85%, DenseNet121 achieves

98.48% and VGG16 achieves 98.32%. Traditional

augmentation methods, designated as ”Traditional,”

produce competitive results, with BiT-M-R50x1 scor-

ing 98.06%, BiT-S-R50x1 scoring 97.71%, ViT-

B/32 scoring 99.72%, ViT-B/16 scoring 99.72%,

DenseNet121 scoring 98.4% and VGG16 scoring

98.82%. The Hybrid approach, which combines DC-

GAN and classical augmentation, achieves substantial

accuracy gains. BiT-M-R50x1 scores 98.47%, BiT-S-

R50x1 scores 98.47%, ViT-B/32 scores 99.94%, ViT-

B/16 scores 99.94%, DenseNet121 scores 98.85%

and VGG16 scores 98.97%.

To observe the proposed augmentation effect on

more number of classes, we employed hybrid aug-

mentation on the entire Malimg dataset. The same

hybrid augmentation was applied to the speciﬁed six

classes of the Malimg dataset. Speciﬁcally, these six

classes were augmented using both traditional and

DCGAN augmentation techniques, following the de-

tails outlined in Table 2. For the remaining 19 classes,

140 samples were augmented using the traditional

augmentation method. Once again, 20 percent of the

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

828

Table 3: Performance comparison of different models with and without augmentation for six-class classiﬁcation. (No Aug =

Without Augmentation, GAug = Augmentation with DCGAN, TAug=Traditional Augmentation, HAug=Hybrid Augmenta-

tion).

Model Precision Recall F1-score

GAug No TAug HAug GAug No TAug HAug GAug No TAug HAug

Aug Aug Aug

BiT- 0.9839 0.9710 0.9805 0.9847 0.9840 0.9710 0.9805 0.9846 0.9839 0.9709 0.9805 0.9846

M-R50x1

BiT- 0.9794 0.9688 0.9771 0.9847 0.9791 0.9680 0.9770 0.9846 0.9789 0.9675 0.9770 0.9846

S-R50x1

ViT-B/32 0.9993 0.9984 0.9972 0.9993 0.9993 0.9984 0.9972 0.9993 0.9993 0.9984 0.9972 0.9993

ViT-B/16 0.9986 0.9984 0.9972 0.9993 0.9986 0.9984 0.9972 0.9993 0.9986 0.9984 0.9972 0.9993

Dense- 0.9888 0.9849 0.9855 0.9885 0.9888 0.9848 0.9854 0.9885 0.9888 0.9847 0.9853 0.9885

Net121

VGG16 0.9895 0.9832 0.9895 0.9896 0.9895 0.9832 0.9895 0.9896 0.9895 0.9832 0.9895 0.9896

Figure 6: For Malimg datset: (a) and (b) are Vit-B/32 model’s Epoch vs. Accuracy graph and confusion matrix after training

with dataset enhanced by hybrid augmentation. (c) and (d) model’s Epoch vs. Accuracy graph and confusion matrix for the

same classiﬁer when trained with dataset without augmentation.

data was set aside for testing.

The top two performers, namely the ViT-B/32 and

ViT-B/16 models based classiﬁers were selected for

classiﬁcation experimentation. Both classiﬁers under-

went training using hybrid augmented data and the

non-augmented Malimg dataset with 25 classes.

The results are summarized in Table 4. To

comapre, we included some recent results from the

literature in Table 4. In this stage, we observed

that classiﬁers based on the ViT-B/32 and ViT-B/16

models with the hybrid data augmentation technique,

both achieve accuracies of 99.79%. Where as ViT-

B/16 and ViT-B/32 models based classiﬁers achieve

accuracy of 98.29% and 98.71% respectively when

Table 4: Performance comparison of different ap-

proaches to malware classiﬁcation using Malimg dataset.

(HyAug=Hybrid Augmentation, NAug=No Augmentation.

Model Precision Recall F1 score Accuracy

Belal et al. 0.9884 0.9808 0.9842 0.9932

Verma et al. 0.9804 0.9806 0.9805 0.9858

ViT-B/16(NAug) 0.9828 0.9828 0.9826 0.9829

ViT-B/32(NAug) 0.9871 0.9866 0.9866 0.9871

ViT-B/16(HyAug) 0.9978 0.9978 0.9978 0.9979

(Proposed)

ViT-B/32(HyAug) 0.9980 0.9978 0.9978 0.9979

(Proposed)

they are trained with non-augmented Malimg dataset.

Other measures like Precison, Recall and F1 score for

the best performer classiﬁer were found to be 0.9980,

Vision Based Malware Classiﬁcation Using Deep Neural Network with Hybrid Data Augmentation

829

0.9978 and 0.9978 respectively. The effectiveness of

the proposed hybrid augmentation method is evident

in the Precision, Recall and F1 scores provided in Ta-

ble 4 for Vision Transformer based classiﬁers.

The training snapshots for the ViT-B/32 model,

trained with and without hybrid augmentation are

presented in Figure 6. The classiﬁer exhibits fewer

misclassiﬁcations when trained with the hybrid aug-

mented dataset, underscoring the efﬁcacy of proposed

hybrid augmentation technique.

5 CONCLUSION AND FUTURE

WORK

In this study, we developed a set of malware classi-

ﬁers based on Transfer, Transformer and CNN mod-

els to identify different malware classes. We incorpo-

rated DC-GAN augmentation and classical augmenta-

tion methods alongside these classiﬁers. Furthermore,

we introduced a hybrid augmentation technique that

combines DCGAN and classical augmentation meth-

ods.

Initially, a dataset containing six-class malware

samples was created, and the developed classiﬁers

were trained to learn patterns from this dataset. The

performance of these classiﬁers was evaluated using

metrics such as accuracy, loss, precision, recall and F1

score. The initial dataset was then augmented using

DCGAN, traditional and the proposed method. Ex-

perimental results indicated that the ViT-B/32 model-

based classiﬁer, trained with a dataset augmented with

the proposed method, outperformed others, achieving

the highest accuracy of 99.94%.

In the second phase of experiments, we utilized

the publicly available Malimg dataset with the devel-

oped classiﬁers and the proposed augmentation tech-

nique. Here as well, classiﬁers trained with a hybrid

augmentation-enhanced dataset outperformed those

trained with a non-augmented dataset, achieving the

highest accuracy of 99.79%.

Overall, the augmentation process aimed to en-

hance the resilience and generalizability of malware

detection models by amplifying diversity and vari-

ability within the dataset. The experimental out-

comes underscore that incorporating augmented train-

ing data into the dataset contributes to the enhance-

ment of classiﬁer performance. This study utilized

only one dataset and future research could explore dif-

ferent datasets with model diversity for malware de-

tection and classiﬁcation.

ACKNOWLEDGMENT

This study was funded by the International Exchange

Program of the National Institute of Information and

Communications Technology (NICT), Japan.

REFERENCES

Abdelsalam, M., Krishnan, R., Huang, Y., and Sandhu,

R. (2018). Malware detection in cloud infrastruc-

tures using convolutional neural networks. In 2018

IEEE 11th international conference on cloud comput-

ing (CLOUD), pages 162–169. IEEE.

Belal, M. M. and Sundaram, D. M. (2023). Global-

local attention-based butterﬂy vision transformer for

visualization-based malware classiﬁcation. IEEE Ac-

cess, 11:69337–69355.

Dosovitskiy, A., Beyer, L., Kolesnikov, A., Weissenborn,

D., Zhai, X., Unterthiner, T., Dehghani, M., Minderer,

M., Heigold, G., Gelly, S., et al. (2020). An image is

worth 16x16 words: Transformers for image recogni-

tion at scale. arXiv preprint arXiv:2010.11929.

Hu, H., Peng, S., He, Z., and Huang, L. (2021). Mal-

gan: Gan-augmented dataset for malware detection.

In Proceedings of the 2021 International Conference

on Computer Science and Network Technology, pages

246–252. ACM.

Ma, X., Yang, S., and Yang, H. (2021). Malware classiﬁca-

tion based on vision transformer. Journal of Physics:

Conference Series, 1932(1):012024.

Microsoft (2023). Microsoft security intelligence. Mi-

crosoft.

Nataraj, L., Karthikeyan, S., Jacob, G., and Manjunath,

B. S. (2011). Malware images: visualization and auto-

matic classiﬁcation. In Proceedings of the 8th interna-

tional symposium on visualization for cyber security,

pages 1–7.

Sharma, A., Malacaria, P., and Khouzani, M. (2019).

Malware detection using 1-dimensional convolutional

neural networks. In 2019 IEEE European symposium

on security and privacy workshops (EuroS&PW),

pages 247–256. IEEE.

Tobiyama, S., Yamaguchi, Y., Shimada, H., Ikuse, T., and

Yagi, T. (2016). Malware detection with deep neural

network using process behavior. In 2016 IEEE 40th

annual computer software and applications confer-

ence (COMPSAC), volume 2, pages 577–582. IEEE.

Verma, V., Muttoo, S. K., and Singh, V. (2020). Multiclass

malware classiﬁcation via ﬁrst-and second-order tex-

ture statistics. Computers & Security, 97:101895.

Yeo, M., Koo, Y., Yoon, Y., Hwang, T., Ryu, J., Song,

J., and Park, C. (2018). Flow-based malware de-

tection using convolutional neural network. In 2018

International Conference on Information Networking

(ICOIN), pages 910–913. IEEE.

Zhang, J., Qin, Z., Yin, H., Ou, L., and Hu, Y. (2016). Irmd:

malware variant detection using opcode image recog-

nition. In 2016 IEEE 22nd International Conference

on Parallel and Distributed Systems (ICPADS), pages

1175–1180. IEEE.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

830
