Conditional Vector Graphics Generation for Music Cover Images

Ivan Jarsky

, Valeria Eﬁmova

, Ilya Bizyaev and Andrey Filchenkov

ITMO University, Kronverksky Pr. 49, St. Petersburg, Russia

ﬁ ﬁ

Keywords:

GAN, Image Generation, Vector Graphics.

Abstract:

Generative Adversarial Networks (GAN) have motivated a rapid growth of the domain of computer image

synthesis. As almost all the existing image synthesis algorithms consider an image as a pixel matrix, the

high-resolution image synthesis is complicated. A good alternative can be vector images. However, they

belong to the highly sophisticated parametric space, which is a restriction for solving the task of synthesizing

vector graphics by GANs. In this paper, we consider a speciﬁc application domain that softens this restriction

dramatically allowing the usage of vector image synthesis. Music cover images should meet the requirements

of Internet streaming services and printing standards, which imply high resolution of graphic materials without

any additional requirements on the content of such images. Existing music cover image generation services

do not analyze tracks themselves; however, some services mostly consider only genre tags. To generate music

covers as vector images that reﬂect the music and consist of simple geometric objects, we suggest a GAN-

based algorithm called CoverGAN. The assessment of resulting images is based on their correspondence to the

music compared with AttnGAN and DALL-E text-to-image generation according to title or lyrics. Moreover,

the signiﬁcance of the patterns found by CoverGAN has been evaluated in terms of the correspondence of the

generated cover images to the musical tracks. Listeners evaluate the music covers generated by the proposed

algorithm as quite satisfactory and corresponding to the tracks. Music cover images generation code and demo

are available at https://github.com/IzhanVarsky/CoverGAN.

1 INTRODUCTION

Drawing images manually is a time-consuming pro-

cess, therefore, image synthesis is a trending re-

search direction due to its high demand in many

ﬁelds. Various Generative Adversarial Networks

(GANs) (Goodfellow et al., 2014), Variational Au-

toencoders (VAEs) (Kingma and Welling, 2019), Au-

toregressive Models (Oord et al., 2016), and other

models (Bond-Taylor et al., 2021) have been proposed

to address this challenge. They all work with bitmap

generation representing an image as a matrix of pix-

els. This results in limitations of the image quality

when its resolution is meant to be high. Moreover,

new networks capable of synthesizing high-resolution

bitmap images are very time- and power-consuming.

An alternative to raster images is vector graph-

ics that may help avoid fuzzy lines and artifacts typ-

ical of GANs (Hertzmann, 2020) and achieve sufﬁ-

cient image resolution. However, vector image gen-

eration from scratch has not been sufﬁciently stud-

https://orcid.org/0000-0003-1107-3363

https://orcid.org/0000-0002-5309-2207

https://orcid.org/0000-0002-1133-8432

Figure 1: Music cover images generated in vector format

with the proposed CoverGAN.

ied. Recently, the vector images are generated con-

taining only points or thin curves (Frans et al., 2021;

Li et al., 2020), however artists usually draw vector

images with color-ﬁlled shapes.

Jarsky, I., Eﬁmova, V., Bizyaev, I. and Filchenkov, A.

Conditional Vector Graphics Generation for Music Cover Images.

DOI: 10.5220/0012456100003660

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2024) - Volume 2: VISAPP, pages

233-243

ISBN: 978-989-758-679-8; ISSN: 2184-4321

233

Being motivated by the potential of vector graph-

ics synthesis and lack of relevant work, we formu-

late our research question as: is it possible to syn-

thesize visually appealing vector graphic images with

machine learning methods?

The main challenge here is that vector images are

highly different from raster images. Raster images are

represented as a two-dimensional rectangular matrix

or grid of square pixels, while a common vector image

is an XML (xml, 2024) ﬁle containing descriptions of

geometric lines, which can be completed or not. The

most useful tag of the XML ﬁle is the <path> tag; it

deﬁnes a set of rules for drawing straight segments,

ezier curves of the 2nd and 3rd order, and circular

arcs. This tag mainly consists of control points speci-

fying the type and shape of the rendered ﬁgure.

A promising application area is music cover im-

ages, which have retained their importance as a key

component of music marketing despite the digital mu-

sic distribution. Listeners usually navigate music col-

lections by small cover images before actual listening

to tracks. The attractiveness of cover image does not

determine music quality but draws the attention of on-

line music consumers to discographies (Cook, 2013),

and remains one of the most important issues of pop-

ular culture, especially on physical media (Medel,

2014). Noteworthy, streaming services require high-

resolution cover images (a common recommendation

is 3000 × 3000 pixels). Independent musicians order

cover image production from artists, designers, and

photographers, or make attempts to create them on

their own, which, however, requires special skills mu-

sicians usually lack.

Despite the recent advancements in text-to-image

generation (Xu et al., 2018; Zhang et al., 2017),

few audiovisual models have been developed. Ex-

isting models are mostly aimed at correlating sound

information with certain real scenes (Qian et al.,

2020), actions (Gao et al., 2020), or actors (Oh et al.,

2019). Currently, various simpliﬁed editors and tem-

plate constructors exist, but there are only four pub-

licly available Internet services offering musicians

computer-generated images as cover images for their

musical compositions: Rocklou Album Cover Gener-

ator (Gavelin, 2023), Automated Art (aa, 2023), GAN

Album Art (Seyp, 2023), and ArtBreeder (art, 2023).

We propose a GAN, which can generate vector

graphics using only image supervision. Therefore, we

suggest an approach to cover generation in vector for-

mat for musical compositions and call it CoverGAN.

The samples of generated cover images can be seen in

Fig. 1.

The structure of the paper is as follows. In Sec-

tion 2, we brieﬂy describe the results achieved. In

Section 3, we present a novel method for the cover

generation task. Experimental evaluation is presented

in Section 5. Limitations of the approach presented

are discussed in Section 6. Section 7 concludes the

paper and outlines future research.

2 RELATED WORK

The construction of an audiovisual generative model

using musical composition includes the extraction of

its sound characteristics and conditional image gen-

eration. Cover generating services have also already

been created for musical compositions.

2.1 Music Information Retrieval

Music information retrieval (MIR) from audio data is

a well-studied interdisciplinary ﬁeld of research (Choi

et al., 2017; Schedl et al., 2014; Moffat et al., 2015)

based on signal processing, psychoacoustics and mu-

sicology. Currently, various information can be ob-

tained automatically from audio data. Librosa li-

brary (lib, 2024) can extract mel-frequency cepstral

coefﬁcients (MFCC) (Davis and Mermelstein, 1980),

which measure the timbre of a music piece and are

often used as a feature for speech recognition. They

are also widely used for classiﬁcation based on acous-

tic events in the habitat. Essentia library (Bogdanov

et al., 2013; ess, 2024) offers methods for extracting

tonality, chords, harmonies, melody, main pitch, beats

per minute, rhythm, etc.

2.2 Conditional Image Generation

Conditional image generation is the process of con-

structing images corresponding to speciﬁed criteria

based on certain input data (most often categori-

cal). The Conditional Generative Adversarial Net-

work (cGAN) (Mirza and Osindero, 2014) is one of

the most popular model architecture applied. Unlike

a common unconditional GAN, in this model the con-

dition is passed to the input of both the generator and

the discriminator. It becomes possible to generate an

image based on a text condition.

Successful modiﬁcation of the cGAN model is At-

tnGAN (Xu et al., 2018). This model considers the

mechanism of attention (Vaswani et al., 2017) as a

learning factor, which allows selecting words to gen-

erate image fragments. Due to modiﬁcations, this net-

work shows signiﬁcantly better results than traditional

GAN systems. ObjGAN (Li et al., 2019) also uses

the attention. However, its basic principle of image

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

234

Figure 2: Automated cover generation services examples:

left-top: Rocklou Cover Generator, right-top: GAN Album

Art, left-bottom: The Automated Art, right-bottom: Art-

Breeder.

generation is to recognize and create individual ob-

jects from a given text description. MirrorGAN pa-

per (Qiao et al., 2019) uses the idea of learning by re-

description and consists of three modules: the seman-

tic text embedding module, global-local collaborative

attentive module for cascaded image generation, and

semantic text regeneration and alignment module.

Not only cGANs can generate images by condi-

tion. A well-known model is Variational Autoencoder

(VAE) (Kingma and Welling, 2019). A striking rep-

resentative of this approach is the NVAE model (Vah-

dat and Kautz, 2020), which uses depth-wise sepa-

rable convolutions, residual parameterization of Nor-

mal distributions, and spectral regularization that sta-

bilizes training.

A well-known project from OpenAI (ope, 2024)

is the DALL-E model (Ramesh et al., 2021), which

is a decoder-only transformer (Vaswani et al., 2017)

built on GPT-3 (Brown et al., 2020) architecture and

capable of generating realistic images based on pro-

vided text condition. At the same time, OpenAI has

released a Contrastive Language–Image Pre-training

(CLIP) model (Radford et al., 2021) that learns the

relationship between the whole sentence and the im-

age it describes, and can act as a classiﬁer.

2.3 Vector Images Generation

The generation of vector images, in contrast to the

generation of raster images, is still poorly studied.

However, several papers on this topic have been re-

cently published.

The well-known SVG-VAE (Lopes et al., 2019)

and DeepSVG (Carlier et al., 2020) models are ca-

pable of generating vector images. However, they

require vector supervision and need collecting large

datasets of vector images, which is complicated.

DiffVG (Li et al., 2020) has become a great

achievement in creating vector images. This work

proposed a differentiable rasterizer for vector graph-

ics, which bridges the raster and vector domains

through backpropagation and enables gradient-based

optimization. This method supports polynomial and

rational curves, stroking, transparency, occlusion, and

gradient ﬁlls.

In the paper (Reddy et al., 2020) the problem of

differentiable image compositing was considered by

proposing the DiffComp model. The authors pre-

sented a differentiable function, which composes pro-

vided discrete elements into a pattern image. Us-

ing this operator, vector graphics becomes connected

with image-based losses, and it becomes possible to

optimize provided elements in accordance with losses

on the composited image.

Another successful work is Im2Vec (Reddy et al.,

2021), which discusses synthesizing vector graphics

without vector supervision. Inspired by ideas of SVG-

VAE (Lopes et al., 2019) and DeepSVG (Carlier et al.,

2020), authors proposed an end-to-end VAE that en-

codes a raster image to a latent code and then decodes

it into a set of ordered closed vector paths. After that,

these paths are rasterized and composited together us-

ing the DiffVG and DiffComp solutions mentioned

above. An important element is the proposed path de-

coder, which is capable of decoding the latent code

into closed B

ezier curves. It becomes possible due to

sampling the path control points uniformly on the unit

circle, which is then deformed and transformed into

ﬁnal points in the absolute coordinate system of the

drawing canvas. In this paper multi-resolution raster

loss solves the problem when at the early stages the

gradients have a small area of inﬂuence using ras-

terisation at multiple resolutions. The authors claim

that Im2Vec shows better results than SVG-VAE and

DeepSVG.

ClipDRAW (Frans et al., 2021) paper is devoted to

generating vector images based on the input text. This

model combines CLIP language-image encoder and

DiffVG rasterizer. Initially, a set of random B

ezier

curves is generated, after that, they gradually trans-

form into understandable silhouettes. Also, the model

allows creating more or less realistic pictures depend-

ing on a given number of strokes.

Conditional Vector Graphics Generation for Music Cover Images

235

2.4 Approaches to the Automatic

Creation of a Cover for a Musical

Composition

For the best of our knowledge, four services have

been proposed to generate covers for musical com-

positions. The examples of the generated covers for

each of them are presented in Fig. 2.

The Rocklou Album Cover Generator (Gavelin,

2023) service allows generating covers with resolu-

tion of 900 × 900 pixels specifying the name of the

artist and the title of the track, and selecting the genre

of the audio track. To generate the album covers, it

picks one of 160 fonts and one of 1500 template im-

ages. However, the covers are only for inspiration,

they are not allowed to be used commercially.

The Automated Art (aa, 2023) service allows se-

lecting from pre-generated covers using GAN, but

they contain a lot of fuzzy lines and artifacts. Two

types of licensing are provided: One Time Use and

Extended. Both of them limit the cover resolution to

a maximum of 480000 pixels in total, permit to use

the purchased media in one project only and contain

many other prohibitions in use.

The GAN Album Art (Seyp, 2023) website dis-

plays a randomly selected low-resolution image from

pre-generated covers, with an internal division by

genre, but without any input data and without speci-

fying a license. In addition, the generated covers con-

tain a lot of characters from different and seemingly

non-existent languages, which are impossible to read

and understand.

The ArtBreeder (art, 2023) service allows creat-

ing up to 5 high-resolution images per month for free

based on user-deﬁned color preferences and random

noise. All generated images are considered the public

domain. However, the resulting covers contain fuzzy

ﬁgures, artifacts, as well as fragments of signatures

and human bodies.

In addition to the Internet services listed above,

the use of GAN for generating covers of musical com-

positions is found in the paper (Hepburn et al., 2017).

The authors report successful generation of images

with a resolution of 64 × 64 pixels for the speciﬁed

genre labels and with genre-speciﬁc visual features.

It can be noted that all of these works have signiﬁ-

cant drawbacks, such as the use of generation meth-

ods with a poor diversity of results, low resolution of

output images, and the presence of a large number of

artifacts. Moreover, they do not analyze a music track

itself. As seen from all literature reviewed, all the

approaches did not solve the task to generate music

cover images of acceptable quality and corresponding

to music track. Therefore, we have challenged our-

selves to develop such a model.

3 METHOD

The creative nature of the problem has moti-

vated us to use unsupervised learning, and we ap-

ply the Conditional Generative Adversarial Network

(cGAN) (Mirza and Osindero, 2014). In this work,

music cover images are generated based on several

sound features, which is a hallmark of this research.

Both generator and discriminator inputs are condi-

tioned. The condition can be an embedding of the en-

tire music track or its fragment (Duarte et al., 2019),

as well as some additional data, for instance, a track

emotion indicated by a musician. It is required to train

the mapping both from an audio embedding and a ran-

dom vector to an output vector to ﬁnd a correlation

of the cover image content with the features obtained

from audio data.

3.1 Input Features

We have used several common algorithms for calcu-

lating the following music features (Bogdanov et al.,

2013): MFCC (Davis and Mermelstein, 1980), spec-

tral contrast (Jiang et al., 2002), spectral peaks (pea,

2024), loudness (Skovenborg et al., 2004), danceabil-

ity (Streich and Herrera, 2005), beats per minute and

onset rate, mean beats volume, Chromagram (Ko-

rzeniowski and Widmer, 2016), music key and its

scale. These parameters can strongly inﬂuence musi-

cal perception (Col, 2024; Freeman, 2020; Lindborg

and Friberg, 2015; Tsiounta et al., 2013). For exam-

ple, covers for songs with a rough voice, high vol-

ume, non-standard alarming fast rhythm or tonality

with abundant musical chromaticisms, usually con-

tain dark shades and sharp lines. At the same time,

for the quiet, calm, and harmonious tracks the light

and soft colors are prevailing on the covers.

The track is resampled to a frequency of 44100Hz.

After that music features are calculated for 10-second

track fragments with 5-second overlapping and then

normalized.

Emotions in musical compositions are one-hot en-

coded as a vector with the length equal to the total

number of emotions. The positions corresponding to

the selected emotions are encoded with ones, and the

rest are encoded with zeros.

3.2 CoverGAN

The noise vector, encoded track emotion selected by

a musician and audio features are passed as an input

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

236

Figure 3: Fully-connected generator architecture.

to the generator that creates a description of an image

consisting of vector primitives. We have tested two ar-

chitectures of the generator. The ﬁrst one is presented

in Fig. 3. It consists of 5 fully-connected layers with

LeakyReLU with slope 0.2 for 4 layers and sigmoid

activation function for the last one. As the result, out-

put range is (0;1), which allows direct setting of color

channels values. The coordinates of the points are set

relative to the size of the canvas. However, the actual

canvas size available to the generator for each of the

dimensions is twice as large as the visible one; this

gives the generator the ability to place parts of shapes

outside the visible area. The thickness of the outlines

is predicted relative to the speciﬁed maximum. To

prevent internal covariate shift and speed up learning,

batch normalization with a momentum of 0.1 is ap-

plied.

The second tested architecture of the generator,

consisted of a three-layer recurrent neural network

with long short-term memory (LSTM) and several

fully-connected layers corresponding to the optimized

shape parameters: point coordinates, outline thick-

ness, transparency, ﬁll color, and outline color. Al-

though this model has not yet brought an acceptable

result, work on its reﬁnement and improvement con-

tinues.

For correct error backpropagation during model

training, the rasterization of vector cover images must

be differentiable, which is achieved by using the dif-

fvg library (Li et al., 2020) as the renderer. However,

diffvg library cannot optimize the topology, such as

adding and removing shapes, changing their order and

type; therefore, the number of shapes is ﬁxed to 3 cu-

bic B

ezier curves of 4 segments. Each B

ezier curve

consists of 13 points: one initial and 3 points by seg-

ment. We also create a square to represent the can-

vas color. For the ﬁrst model the number of curves

is ﬁxed and equal to 3; for the second architecture,

it corresponds to the number of embeddings of track

fragments received by the generator.

The discriminator is presented in Fig. 4. The

model consists of 3 convolutional and 2 fully-

connected layers. Tensors of real and generated cov-

Figure 4: Discriminator architecture.

ers with 3 color channels (RGB) are provided as the

input to the ﬁrst convolutional layer. Real and gen-

erated covers are Gaussian blurred to prevent the in-

ﬂuence of real covers noise on the discriminator de-

cision. Then, the ﬁrst layer outputs 24 channels, the

subsequent ones – 48 each. The ﬁrst fully-connected

layer takes as input the result of convolution, the

mood vector and embedding of a large fragment of the

musical composition. The number of features of the

next layer is 64 times less. The output of the network

is one number – the assessment of the realism of the

cover, which takes into account the compliance with

audio data. LeakyReLU is the activation function on

all layers, except the last one. Its slope for convolu-

tional layers is 0.1, for fully-connected layers – 0.2.

On the last layer, in accordance with the recommen-

dation of the Wasserstein GAN (WGAN) (Arjovsky

et al., 2017), the activation function is not applied.

Layer normalization and normalization by elimina-

tion with a probability of 0.2 are used.

The ﬁrst loss function of the discriminator is the

Wasserstein loss with the gradient penalty (Gulrajani

et al., 2017). Additional stimulation of the discrimi-

nator training in the correspondence of covers to the

characteristics of musical compositions is provided

by the secondary loss function. It is set as the dif-

ference of the average scores on the rearranged cyclic

shift and on the corresponding covers from the train-

ing set batches, as follows (see Eq. 1):

= D(˜r, a, e) − D(r, a, e), (1)

where a is a batch of audio embeddings, e is a batch

of emotion embeddings, r is a batch of real cover im-

ages, ˜r is a random cyclic shift of the real covers r.

The cyclic shift is important, because we do not want

at least one cover in a batch to remain in its original

place as it might with random shufﬂing.

We considered the possibility of shape parameters

selection in a separate (nested) GAN. Then, the ex-

ternal GAN would operate with vectors of the latent

space of the internal one. However, despite the ap-

plication of the pre-training on a Variational Autoen-

coder (VAE) to stabilize the training of the internal

Conditional Vector Graphics Generation for Music Cover Images

237

Figure 5: Captioning network architecture.

GAN, this approach led to no results. Currently, the

nested GAN is not used.

After captioning (see Subsec. 3.3), the resulting

description of the cover is saved in a common vector

graphics format (SVG) (Cohn et al., 2000) or raster-

ized. The generated image of the cover does not vio-

late the rights of the authors of the covers used while

training (Gillotte, 2019). After generation, it can be

licensed to the performer of the track.

3.3 Captioning

To format generated images as complete covers, we

add captions with authorship information, which op-

timal placement, color and style are determined by

an additional neural network presented in Fig. 5. It

consists of 6 fully-connected layers with 3 × 3 and

5 × 5 convolutional kernels and two 2-layered sub

networks, all with LeakyReLU activation with slope

0.01.

Images with four channels are fed to the network

input, namely, three color channels (RGB) and the

boundaries of the ﬁgures in these images, determined

by the Canny edge detector (Canny, 1986). The net-

work outputs text bounding boxes and text colors for

captions. The optimal font size is selected accounting

the predicted bounding rectangles. The font family is

currently selected randomly from Google Fonts.

The training dataset is described in details in sec-

tion 4, it consists of original covers with text captions

removed using a graphic editor. For training the cap-

tioning network, each image was labelled with text

bounding boxes and colors. The labelling was par-

tially automated by comparing the edited covers with

the original ones.

4 DATASET

The advantages provided by vector graphics in the

ﬁeld of scalability come at the cost of disadvantages:

not every bitmap image can be rationally represented

as a set of vector primitives. Thus, if the cover, for

example, is a detailed photo, an attempt to vectorize

and enlarge such a cover leads to a noticeable change

in style. In this regard, it is reasonable to make a

training dataset from covers that can be reproduced

by a generator that draws vector primitives (basic ge-

ometric shapes and curves with strokes and ﬁlls). In

addition, to better match the covers to musical com-

positions, it is preferable to collect a dataset from sin-

gles or mini-albums, where the album cover obviously

refers to one of the tracks.

These limitations determine the need to collect a

new dataset. In accordance with the listed require-

ments, a set of 1500 musical compositions of various

genres was collected. With the help of the Adobe Pho-

toshop graphic editor (pho, 2024), the captions were

removed from the covers. On the crowdsourcing plat-

form Yandex Toloka (tol, 2024) the tracks were la-

beled with emotions and included in the dataset. The

label contains 2-3 emotions of a musical composi-

tion from the following list: comfortable, happy, in-

spirational, joy, lonely, funny, nostalgic, passionate,

quiet, relaxed, romantic, sadness, soulful, sweet, se-

rious, anger, wary, surprise, fear. We can not release

the dataset with music cover images due to copyright;

however, its part containing 1500 objects in the fol-

lowing format: track author – track title, 2-3 emotions

from the list, is publicly available

Furthermore, to obtain additional information

about tracks (genres, release date, artist attributes,

and others) was prepared a program that extracts

available metadata directly from audio ﬁles and sup-

plements them with information from public infor-

mation databases (Wikidata (wik, 2024) and Mu-

sicBrainz (mus, 2024)). Track metadata is not cur-

rently used by the algorithm, but it is possible to do in

the future.

After all, the collected dataset contains a number

of covers that is not large enough to train deep learn-

ing models. Thus, to enlarge the resulting dataset,

augmentation was applied; operations such as hor-

izontal ﬂip and 90 degrees clockwise and counter-

clockwise rotation were applied to the covers.

5 RESULTS

Unlike the existing solutions, which generates covers

that do not take into account musical compositions,

the suggested model allows using extracted sound

https://www.kaggle.com/datasets/

viacheslavshalamov/music-emotions

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

238

features in a generative algorithm. The created cov-

ers contain titles with information about authorship

and track name and are available in a common vec-

tor graphics format without additional licensing re-

strictions on components. This allows us to speak

about their compliance with generally accepted re-

quirements for the design of musical compositions re-

leases.

5.1 Training

Training of neural networks was performed on the ca-

pacities of the Google Colaboratory (goo, 2024) ser-

vice using the CUDA computing architecture. To

achieve stable training of the model, various hyper-

parameters were tried, including different network ar-

chitectures, the number of layers in models, learning

rate, optimization algorithms, gradient penalty coef-

ﬁcient and the number of steps to update discrimina-

tor. The ﬁnal version uses the generator consisting

of fully-connected layers, a learning rate coefﬁcient

of 0.0005 with a batch size of 64, a ﬁve-time repe-

tition of the discriminator training and a canvas size

of 128 × 128 pixels. The training took 7200 epochs

based on a manual assessment of the quality of the

generated images.

The Adam optimization algorithm (Kingma and

Ba, 2015) was chosen for CoverGAN training. Its

gradients decay rate control coefﬁcient β

was set to

0.9 and for the second moments of gradients β

0.999.

To train the captioning network, batch normaliza-

tion with a following hyperparameters is used: a mo-

mentum of 0.1 and normalization by elimination with

a probability of 0.2. The Adam algorithm with gradi-

ents decay rate control coefﬁcient β

= 0.5 and for the

second moments of gradients β

= 0.999 is chosen as

the optimization algorithm.

During the training of the captioning network,

256 × 256 pixel images and a batch size of 64 are

used to select the design of signatures. The aver-

age quadratic error is used as a loss function. For

validation, the Generalized Intersection over Union

(GIoU) (Rezatoﬁghi et al., 2019) metric is calculated

and averaged for the entire dataset. In order to maxi-

mize it, training lasts 138 epochs. The value of GIoU

metric of 0.65 has been achieved for the arrangement

of rectangles; the average error value for colors on the

entire training set reaches about 0.00014 at the end of

training.

Table 1: Comparison of the covers generated by the

proposed CoverGAN with DALL-E for titles denoted

as DALL-E

, DALL-E for lyrics denoted as DALL-E

AttnGAN

for lyrics, and AttnGAN for lyrics ﬁne-tuned on

covers denoted as AttnGAN

+ covers. ’All score’ column

indicates the normalized score given by all assessors. ’Mu-

sicians’ column indicates the normalized assessment score

given by assessors identiﬁed themselves as musicians.

Method All score Musicians

DALL-E

0.34 ± 0.03 0.31 ± 0.05

DALL-E

0.3 ± 0.03 0.26 ± 0.05

AttnGAN

0.44 ± 0.04 0.23 ± 0.06

AttnGAN

+ covers 0.36 ± 0.03 0.19 ± 0.04

CoverGAN (Ours) 0.68 ± 0.05 0.71 ± 0.05

5.2 Comparison with Text-to-Image

Generation

To assess the effectiveness of the proposed algorithm,

we tested it on musical compositions not included in

the training set. As a result, for different musical com-

positions, the algorithm created signiﬁcantly different

covers (Figure 1).

Due to the lack of alternative algorithms that rely

on musical features for cover creation, we used im-

ages generated by the AttnGAN (Xu et al., 2018) and

DALL-E (rud, 2024) based on lyrics for the following

quality comparison. AttnGAN takes as input text of

arbitrary length, when more modern approaches, such

as DALL-E, focus on short texts (up to 200 symbols)

that are much shorter than a song lyrics. Thus, we

also assess the quality of DALL-E-generated-images

by query: ’Cover for the track <title> <lyrics>’.

Furthermore, we ﬁne-tuned AttnGAN model initially

trained on COCO dataset on our dataset of vector cov-

ers.

We conducted a survey asking participants to lis-

ten to 15 popular musical compositions and rate the

covers generated by the proposed algorithm and At-

tnGAN on a scale of 1 to 5 (1 stands for completely in-

appropriate, 5 stands for the perfect ﬁt). 110 assessors

aged 16 to 40 years took part in an anonymous survey,

24 of them identiﬁed themselves as musicians. Nor-

malized survey results are presented in Tab. 1. The

examples of the generated images are shown in Fig. 6.

As it can be seen from the ﬁgure, DALL-E gener-

ates unknown symbols and undetermined shapes, At-

tnGAN generates patterns, whereas shapes generated

by our CoverGAN are very simple.

The text-to-image generation models are very sen-

sitive to the input text string, which often does not

describe the entire track, and sometimes even contra-

dicts the general mood of the song. Therefore, the

Conditional Vector Graphics Generation for Music Cover Images

239

Figure 6: Generated music cover images using different models; each row corresponds to real music track.

resulting images do not often correspond to music.

Although the AttnGAN

+ covers model gener-

ates images with a monotonous background, the ob-

jects depicted have incomprehensible outlines and ar-

tifacts. Moreover, the generated images can have grid

pattern. These are probably the reasons that assessors

rated this model worse than the previous one, as it can

be seen from the table.

The CoverGAN score means that the generated

cover images are quite satisfactory, however, further

work in this direction is reasonable.

5.3 Different Genres

To assess the signiﬁcance of the patterns found by the

GAN model comparing sound and the generated cov-

ers, another survey was conducted using the crowd-

sourcing project Yandex Toloka. Its participants were

asked to listen to 10 musical compositions from vari-

ous genre categories and choose the most suitable of

the two generated covers for each. One of the cov-

ers was created by the generator directly based on

the speciﬁed track, the other – based on a track from

another category with the replacement of the caption

text.

According to the results based on the assessments

collected from 110 listeners, the probability of the re-

spondents, who have chosen the cover created by the

generator for the track, was 0.76 ± 0.03. This score

conﬁrms the presence of signiﬁcant differences be-

tween the proposed covers for listeners and indicates

a moderate tendency of survey participants to agree

with the conclusions of the generator. At the same

time, there is a need for further improvement of the

generative algorithm, including to increase the diver-

sity of generated images.

Figure 7: The results of running the algorithm on several

versions of the same musical composition with different

volume levels (from left to right volume level: 100%, 75%,

50%, 25%).

Figure 8: The dependence of the cover on the speciﬁed

emotion of the track (from left to right: comfortable, pas-

sionate, relaxed, wary).

5.4 Qualitative Analysis

To check the generalization ability of the CoverGAN,

we analyzed the results of running the algorithm on

musical compositions, which are not included in the

training set. It was revealed that the algorithm creates

signiﬁcantly different covers for different tracks (see

Fig. 1). By changing the noise vector, we achieve the

generation of alternative images to provide the user

with a choice.

For individual sound features, it can be traced

how the generated cover image changes with a grad-

ual change in the feature (for example, for the same

musical composition at different volume levels as in

Fig. 7).

Moreover, user-speciﬁed emotions have a signiﬁ-

cant impact on the generated covers. Figure 8 shows

the change of the cover when the speciﬁed emotion

changes.

Finally, on the test dataset, it was found that the

covers of similar tracks also have some similarities.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

240

Figure 9: Covers generated for lullabies and rock music.

Therefore, for several lullabies, the algorithm sug-

gested covers of light tones, while the covers gen-

erated for heavy metal genre turned out to be dark

(Fig. 9). Such connections are not universal, although

their presence is consistent with the conclusions of the

work (Hepburn et al., 2017). In the future, such corre-

spondences can be used to detect and analyze patterns

found by a trained generative network.

6 LIMITATIONS

The major limitation is the simplicity of generated

paths. They usually do not have any regular shape

such as a circle or a square. Moreover, it is difﬁcult for

CoverGAN to generate objects with visual semantics

(i.e., person images, natural scenes). The generated

images are abstract and cannot cover all scenarios in

art design.

The generated covers are diverse and often quite

well suited to musical compositions. Nevertheless, it

is not always easy to interpret the connections taken

into account by the generator for choosing the shape

parameters. Sometimes, the covers of two completely

different tracks may turn out to be visually similar. It

is assumed that in order to obtain more stable and ex-

plicable patterns in the generation of covers, it is nec-

essary to enlarge the dataset, as well as signiﬁcantly

complicate the generator architecture used. The basis

of such a model can be an implemented recurrent gen-

erator, modiﬁed to transform a sequence of musical

fragments embeddings into a sequence of ﬁgures, for

example, using the transformer architecture (Vaswani

et al., 2017). However, such developments require

preliminary theoretical research in the ﬁeld of vector

image generation.

For the additional network engaged in the creat-

ing of captions, the main difﬁculty in practice is to

ensure that the color is sufﬁciently contrasting with

the background. In real covers, artists often use ad-

ditional visual effects (shadows, contrasting strokes,

glow, background ﬁll) to achieve matching of slightly

contrasting colors; a similar approach may be imple-

mented for this solution in the future. Another difﬁ-

cult task is to wrap text inside the bounding box es-

timating the best number of lines. Currently, this is

not provided and the text may not ﬁt the canvas com-

pletely. In the future, it is supposed to use the func-

tionality of the HarfBuzz (har, 2024) text generation

library or the Pango (pan, 2024) rendering library.

7 CONCLUSION

There exist music services offering musicians

computer-generated images as cover images for their

musical compositions; however, they do not consider

the music track itself. In this work, we have devel-

oped the CoverGAN model to generate vector im-

ages conditioned by a music track and its emotion.

We have compared the model suggested to AttnGAN

and DALL-E models for text-to-image generation.

The reported results prove that the proposed algo-

rithm is competitive in the task of music cover syn-

thesis. This is also good evidence that vector graph-

ics synthesis is a promising research direction. The

approach applied is limited only with the parametric

space where the image is located. In the future, it is

planned to generate B

ezier curves with an arbitrary

number of segments based on an approach similar to

Im2Vec (Reddy et al., 2021), as well as potentially

some concrete shapes (natural scene, human silhou-

ette).

ACKNOWLEDGEMENTS

The research was supported by the ITMO University,

project 623097 ”Development of libraries containing

perspective machine learning methods”

REFERENCES

(2023). Artbreeder. https://www.artbreeder.com/compose/

albums. Accessed: 2023-01-15.

(2023). Automated art. https://automated-art.co.uk/. Ac-

cessed: 2023-01-15.

(2024). Adobe photoshop. https://www.adobe.com/

products/photoshop.html. Accessed: 2024-01-07.

(2024). Color-music-association. https://prezi.com/

4asqw6p wbpl/color-music-association/. Accessed:

2024-01-07.

(2024). Essentia. https://essentia.upf.edu/algorithms

reference.html. Accessed: 2024-01-07.

Conditional Vector Graphics Generation for Music Cover Images

241

(2024). Google colaboratory. https://colab.research.google.

com. Accessed: 2024-01-07.

(2024). Harfbuzz. https://harfbuzz.github.io/. Accessed:

2024-01-07.

(2024). Librosa. https://librosa.org/doc/latest/feature.html.

Accessed: 2024-01-07.

(2024). Musicbrainz. https://musicbrainz.org. Accessed:

2024-01-07.

(2024). Openai. https://openai.com/. Accessed: 2024-01-

07.

(2024). Pango. https://pango.gnome.org/. Accessed: 2024-

01-07.

(2024). Ru dall-e. https://rudalle.ru/. Accessed: 2024-01-

07.

(2024). Spectral peaks. https://ccrma.stanford.edu/

∼

jos/parshl/Peak Detection Steps 3.html. Accessed:

2024-01-07.

(2024). Wikidata. https://www.wikidata.org. Accessed:

2024-01-07.

(2024). Xml documentation. https://www.w3.org/TR/xml/.

Accessed: 2024-01-07.

(2024). Yandex toloka. https://toloka.ai/. Accessed: 2024-

01-07.

Arjovsky, M., Chintala, S., and Bottou, L. (2017). Wasser-

stein generative adversarial networks. In Interna-

tional conference on machine learning, pages 214–

223. PMLR.

Bogdanov, D., Wack, N., G

omez, E., Gulati, S., Herrera, P.,

Mayor, O., Roma, G., Salamon, J., Zapata, J. R., and

Serra, X. (2013). Essentia: An audio analysis library

for music information retrieval. In ISMIR.

Bond-Taylor, S., Leach, A., Long, Y., and Willcocks, C. G.

(2021). Deep generative modelling: A compara-

tive review of vaes, gans, normalizing ﬂows, energy-

based and autoregressive models. arXiv preprint

arXiv:2103.04922.

Brown, T. B., Mann, B., Ryder, N., Subbiah, M., Kaplan, J.,

Dhariwal, P., Neelakantan, A., Shyam, P., Sastry, G.,

Askell, A., Agarwal, S., Herbert-Voss, A., Krueger,

G., Henighan, T., Child, R., Ramesh, A., Ziegler,

D. M., Wu, J., Winter, C., Hesse, C., Chen, M., Sigler,

E., Litwin, M., Gray, S., Chess, B., Clark, J., Berner,

C., McCandlish, S., Radford, A., Sutskever, I., and

Amodei, D. (2020). Language models are few-shot

learners. CoRR, abs/2005.14165.

Canny, J. (1986). A computational approach to edge de-

tection. IEEE Transactions on pattern analysis and

machine intelligence, (6):679–698.

Carlier, A., Danelljan, M., Alahi, A., and Timofte,

R. (2020). Deepsvg: A hierarchical generative

network for vector graphics animation. CoRR,

abs/2007.11301.

Choi, K., Fazekas, G., Cho, K., and Sandler, M. B. (2017).

A tutorial on deep learning for music information re-

trieval. CoRR, abs/1709.04396.

Cohn, R., Dodds, D., Donoho, A. W., Duce, D. A., Evans,

J., Ferraiolo, J., Furman, S., Graffagnino, P., Graham,

R., Henderson, L., Hester, A., Hopgood, B., Jolif, C.,

Lawrence, K. R., Lilley, C., Mansﬁeld, P., McCluskey,

K., Nguyen, T., Sandal, T., Santangeli, P., Sheikh,

H. S., Stevahn, R. E., and Zhou, S. (2000). Scalable

vector graphics svg 1.0 speciﬁcation.

Cook, K. (2013). Music industry market research-the effect

of cover artwork on the music industry.

Davis, S. and Mermelstein, P. (1980). Comparison of para-

metric representations for monosyllabic word recog-

nition in continuously spoken sentences. IEEE trans-

actions on acoustics, speech, and signal processing,

28(4):357–366.

Duarte, A., Roldan, F., Tubau, M., Escur, J., Pascual, S.,

Salvador, A., Mohedano, E., McGuinness, K., Torres,

J., and Giro-i Nieto, X. (2019). Wav2pix: Speech-

conditioned face generation using generative adver-

sarial networks. In ICASSP, pages 8633–8637.

Frans, K., Soros, L. B., and Witkowski, O. (2021). Clip-

draw: Exploring text-to-drawing synthesis through

language-image encoders. CoRR, abs/2106.14843.

Freeman, S. (2020). Musical variables and color association

in classical music. Journal of Student Research, 9(1).

Gao, R., Oh, T.-H., Grauman, K., and Torresani, L. (2020).

Listen to look: Action recognition by previewing au-

dio. In Proceedings of the IEEE/CVF Conference

on Computer Vision and Pattern Recognition, pages

10457–10467.

Gavelin, D. (2023). Rocklou album cover generator. https:

//www.rocklou.com/albumcovergenerator. Accessed:

2023-01-15.

generated artworks. UC Davis L. Rev., 53:2655.

Goodfellow, I., Pouget-Abadie, J., Mirza, M., Xu, B.,

Warde-Farley, D., Ozair, S., Courville, A., and Ben-

gio, Y. (2014). Generative adversarial nets. Advances

in neural information processing systems, 27.

Gulrajani, I., Ahmed, F., Arjovsky, M., Dumoulin, V., and

Courville, A. (2017). Improved training of wasser-

stein gans. arXiv preprint arXiv:1704.00028.

Hepburn, A., McConville, R., and Santos-Rodrıguez, R.

(2017). Album cover generation from genre tags.

In 10th International Workshop on Machine Learning

and Music.

Hertzmann, A. (2020). Visual indeterminacy in gan art.

Leonardo, 53(4):424–428.

Jiang, D.-N., Lu, L., Zhang, H., Tao, J., and Cai, L. (2002).

Music type classiﬁcation by spectral contrast feature.

Proceedings. IEEE International Conference on Mul-

timedia and Expo, 1:113–116 vol.1.

Kingma, D. P. and Ba, J. (2015). Adam: A method for

stochastic optimization. CoRR, abs/1412.6980.

Kingma, D. P. and Welling, M. (2019). An introduc-

tion to variational autoencoders. arXiv preprint

arXiv:1906.02691.

Korzeniowski, F. and Widmer, G. (2016). Feature learning

for chord recognition: The deep chroma extractor. In

ISMIR.

Li, T.-M., Luk

c, M., Micha

el, G., and Ragan-Kelley, J.

(2020). Differentiable vector graphics rasterization

for editing and learning. ACM Trans. Graph. (Proc.

SIGGRAPH Asia), 39(6):193:1–193:15.

VISAPP 2024 - 19th International Conference on Computer Vision Theory and Applications

242

Li, W., Zhang, P., Zhang, L., Huang, Q., He, X., Lyu, S., and

Gao, J. (2019). Object-driven text-to-image synthesis

via adversarial training. 2019 IEEE/CVF Conference

on Computer Vision and Pattern Recognition (CVPR),

pages 12166–12174.

Lindborg, P. and Friberg, A. K. (2015). Colour association

with music is mediated by emotion: Evidence from

an experiment using a cie lab interface and interviews.

PloS one, 10(12):e0144013.

Lopes, R. G., Ha, D., Eck, D., and Shlens, J. (2019). A

learned representation for scalable vector graphics.

CoRR, abs/1904.02632.

Medel, I. L. (2014). The death and resurrection of the album

cover. index.comunicaci

on, 4(1):37–57.

Mirza, M. and Osindero, S. (2014). Conditional generative

adversarial nets. arXiv preprint arXiv:1411.1784.

Moffat, D., Ronan, D., and Reiss, J. D. (2015). An evalua-

tion of audio feature extraction toolboxes.

Oh, T.-H., Dekel, T., Kim, C., Mosseri, I., Freeman,

W. T., Rubinstein, M., and Matusik, W. (2019).

Speech2face: Learning the face behind a voice. In

Proceedings of the IEEE/CVF Conference on Com-

puter Vision and Pattern Recognition, pages 7539–

7548.

Oord, A. v. d., Kalchbrenner, N., Vinyals, O., Espeholt,

L., Graves, A., and Kavukcuoglu, K. (2016). Condi-

tional image generation with pixelcnn decoders. arXiv

preprint arXiv:1606.05328.

Qian, R., Di Hu, H. D., Wu, M., Xu, N., and Lin, W. (2020).

Multiple sound sources localization from coarse to

ﬁne. arXiv preprint arXiv:2007.06355.

Qiao, T., Zhang, J., Xu, D., and Tao, D. (2019). Mirror-

gan: Learning text-to-image generation by redescrip-

tion. CoRR, abs/1903.05854.

Radford, A., Kim, J. W., Hallacy, C., Ramesh, A., Goh, G.,

Agarwal, S., Sastry, G., Askell, A., Mishkin, P., Clark,

J., Krueger, G., and Sutskever, I. (2021). Learning

transferable visual models from natural language su-

pervision. CoRR, abs/2103.00020.

Ramesh, A., Pavlov, M., Goh, G., Gray, S., Voss, C., Rad-

ford, A., Chen, M., and Sutskever, I. (2021). Zero-shot

text-to-image generation. CoRR, abs/2102.12092.

Reddy, P., Gharbi, M., Lukac, M., and Mitra, N. J. (2021).

Im2vec: Synthesizing vector graphics without vector

supervision. arXiv preprint arXiv:2102.02798.

Reddy, P., Guerrero, P., Fisher, M., Li, W., and Mitra, N. J.

(2020). Discovering pattern structure using differen-

tiable compositing. ACM Transactions on Graphics

(TOG), 39(6):1–15.

Rezatoﬁghi, S. H., Tsoi, N., Gwak, J., Sadeghian, A., Reid,

I. D., and Savarese, S. (2019). Generalized intersec-

tion over union: A metric and a loss for bounding box

regression. 2019 IEEE/CVF Conference on Computer

Vision and Pattern Recognition (CVPR), pages 658–

666.

Schedl, M., G

omez Guti

errez, E., and Urbano, J. (2014).

Music information retrieval: Recent developments

and applications. Foundations and Trends in Infor-

mation Retrieval. 2014 Sept 12; 8 (2-3): 127-261.

Seyp, V. (2023). Gan album art. https://ganalbum.art/. Ac-

cessed: 2023-01-15.

Skovenborg, E., Quesnel, R., and Nielsen, S. H. (2004).

Loudness assessment of music and speech. Journal

of The Audio Engineering Society.

Streich, S. and Herrera, P. (2005). Detrended ﬂuctuation

analysis of music signals danceability estimation and

further semantic characterization. In In Proceedings

of the AES 118th Convention.

Tsiounta, M., Staniland, M., and Patera, M. (2013). Why is

classical music yellow: A colour and sound associa-

tion study. In AIC 2013-12th Congress of the Interna-

tional Colour Association.

Vahdat, A. and Kautz, J. (2020). Nvae: A deep hierarchical

variational autoencoder. ArXiv, abs/2007.03898.

Vaswani, A., Shazeer, N., Parmar, N., Uszkoreit, J., Jones,

L., Gomez, A. N., Kaiser, Ł., and Polosukhin, I.

(2017). Attention is all you need. In Advances in

neural information processing systems, pages 5998–

6008.

Xu, T., Zhang, P., Huang, Q., Zhang, H., Gan, Z., Huang,

X., and He, X. (2018). Attngan: Fine-grained text

to image generation with attentional generative ad-

versarial networks. In Proceedings of the IEEE con-

ference on computer vision and pattern recognition,

pages 1316–1324.

Zhang, H., Xu, T., Li, H., Zhang, S., Wang, X., Huang, X.,

and Metaxas, D. N. (2017). Stackgan: Text to photo-

realistic image synthesis with stacked generative ad-

versarial networks. In Proceedings of the IEEE inter-

national conference on computer vision, pages 5907–

5915.

Conditional Vector Graphics Generation for Music Cover Images

243
