Efﬁcient Secure Computation of Edit Distance on Genomic Data

Andrea Migliore

, Stelvio Cimato

and Gabriella Trucco

Department of Computer Science, Universit

a degli Studi di Milano, Milan, Italy

Keywords:

Secure Multi-Party Computation, Garbled Circuit, Edit Distance.

Abstract:

Genetic data are the most sensitive information for a person, containing many speciﬁc features that uniquely

determine an individual and also make it possible to trace relationships with other people or evaluate the pre-

disposition to particular diseases. For this reason, any processing of genetic data should be carefully performed

and any threat to their privacy properly considered. A very important computation in medical and public health

domains involves the evaluation of the edit distance between human genomes, that can eventually lead to a

better diagnosis of several diseases. To maintain the privacy of the genetic data, it is possible to apply secure

computation protocols and then, in this context, the improvement of the computational performance of such

techniques is a key factor for real-world application scenarios.

In this paper we focus on the application of the garbling circuit technique for the computation of the edit dis-

tance, showing its efﬁciency. We apply the technique considering four different algorithms and compare their

performances to the best previous results found in literature. We show that the Ukkonen algorithm with gener-

alized cut-off is the one that performed better among the considered algorithms, reporting some experimental

results obtained considering datasets composed of both randomly generated and real genomic strings.

1 INTRODUCTION

Bionformatics is a rapidly advancing ﬁeld, where the

application of information technology to the treat-

ment of biological data is helping in better analyzing

and understanding the various types of data resulting

from different biological processes. Last years have

registered a huge advance in speed and cost reduc-

tion, allowing the completion of the Human Genome

Project and the possibility to sequence a full genome

for a small amount of money.

However the intersection of genomics and secu-

rity arises stimulating ethical and social issues that

need to be addressed, since genetic information can

be considered the most sensitive data for a person and

consequently, it must be protected from any kind of

malicious attack or disclosure. Since genomes are

usually represented as strings, the computation of the

similarity between genomes can be easily mapped to

the application of efﬁcient methods for string com-

parison. In particular, the computation of different

metrics such as edit distance or Needleman-Wunsch

distance can help in the diagnosis of several genetic

https://orcid.org/0009-0008-1494-9547

https://orcid.org/0000-0003-1737-6218

https://orcid.org/0000-0002-5904-0969

diseases.

A natural way to protect genetic data is to ensure

that computations are performed on encrypted strings,

so that sensitive information remain protected even

in case of misbehaviour from one of the collaborat-

ing parties. Secure Multi-Party Computation (SMPC)

(Yao, 1982) is a branch of cryptography whose goal

is to enable a group of independent data owners, who

do not trust each other or any common third party, to

jointly compute a function that depends on all of their

private inputs. SMPC can be deﬁned as the problem

of n players who want to compute an agreed func-

tion of their inputs in a secure way. Formally, we as-

sume x

, . . . , x

inputs, where player i knows x

, and

we want to compute f (x

, . . . , x

) = (y

, . . . , y

) such

that player i is guaranteed to learn y

and nothing more

than that.

There are a number of efﬁcient implementation of

these protocols based on ad-hoc techniques developed

to solve speciﬁc problems or on the generic transfor-

mation of the computed function, such as in the case

of garbled circuits protocol (Yao, 1986) (Micali et al.,

1987). Secure multi-party computation can be used to

solve a wide variety of real-life problems where sen-

sitive data may be compromised.

In this paper, we focus on the application of secure

multi-party computation to bioinformatics and more

878

Migliore, A., Cimato, S. and Trucco, G.

Efﬁcient Secure Computation of Edit Distance on Genomic Data.

DOI: 10.5220/0012459400003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 878-883

ISBN: 978-989-758-683-5; ISSN: 2184-4356

speciﬁcally to the computation of the edit distance,

generically used to compute the distance between two

strings. The human genome is composed by two com-

plementary strands, with 3 billion DNA bases each.

Each unit consists of Adenine (A), Cytosine (C), Gua-

nine (G), or Thymine (T), the nitrogenous bases that

constitute nucleotides.

Edit distance is an important metric to quantify

how dissimilar two DNA strings are, by counting the

minimum number of operations required to transform

one string into the other. It is one of the most used

and well established metrics among genetic similar-

ity indicators because it is very useful for the diagno-

sis and treatment of many genetically based diseases

such as cancer, Alzheimer’s, schizophrenia and others

(Koboldt et al., 2012) (Taylor et al., 2001) (Waddell

et al., 2015) (Evans and Relling, 2004).

In this work, we propose some secure implemen-

tations of the most efﬁcient edit distance algorithms,

achieving better performances over existing proto-

cols found in literature, without sacriﬁcing security

and accuracy. Moreover, a secure implementation of

the Ukkonen’s algorithm with the generalized cut-off

technique using all possible state-of-the-art optimiza-

tions for garbled circuits is proposed. Also, the pro-

posed algorithms are applied on both random, high-

entropy, and real genomics, low-entropy strings and

are provably secure with respect to the standard def-

inition of security for SMPC protocols. Finally, the

methodology, the experiment setup details, and the

source codes used for this study are described and

provided, deﬁning a clear baseline for future works

and enabling anyone to reproduce the experiments in-

dependently.

The paper is organized as follows: ﬁrst we intro-

duce the basic notions about edit distance and secure

multi-party computation.

Next, we describe the optimized techniques for the

computation of the edit distance, and their implemen-

tation in SMPC. Finally we report the basic results

and draw some conclusions.

2 BACKGROUND

We now provide some basic deﬁnitions and quick

overview of the algorithms used for the computation

of edit distance.

2.1 Edit Distance

Given two strings s

and s

on an alphabet Σ, the edit

distance d(s

, s

) is the minimum number of edit op-

erations (insertion, deletion and substitution) required

to transform s

into s

and measures the similarity be-

tween the two sequences. An edit operation is the

basic step in transforming a word into another word.

There are different types of edit distance that allow

different combinations of editing operations. In com-

putational biology, one of the most frequently used

type of edit distance is the Levenshtein edit distance

(Levenshtein et al., 1966).

In more details, a word over the ﬁnite alphabet

Σ is a sequence a

, ..., a

of symbols, where a

∈ Σ

for i = 1, 2, ..., n. The empty word is denoted by the

symbol ε. An edit operation is a pair (a, b) with

a, b ∈ Σ ∪{ε} and ab ̸= ε and it is a basic step in trans-

forming a word into another word. There are three

types of operations: insertion, deletion and substitu-

tion. The edit operation is called insertion if a = ε,

deletion if b = ε, and substitution if a ̸= ε ̸= b.

Each of these operations has a cost associated with it.

Usually, the cost c(a → b) for a ̸= b is 1, whereas for

a = b it is 0. This results in a cost equal to 1 in the

case of insertion, deletion or replacement and a cost

equal to 0 when the two letters are the same.

An edit sequence S is a sequence of edit operations

S = ((a

, b

), ..., (a

, b

)), n ≥ 1. The ﬁnal cost of

an edit sequence S is deﬁned as C(S) =

∑

i=1

c(a

, b

)

(Aziz et al., 2017).

In 2014 it has been proved (Backurs and Indyk,

2014) that the Levenshtein distance of two strings of

length n cannot be computed in time O(n

2−µ

) for any

µ greater than zero unless the strong exponential time

hypothesis (SETH) is violated. This issue introduces

strong limitations on the research for exact optimiza-

tion of edit distance because, despite O(n

) is a poly-

nomial time, it is not acceptable for speciﬁc applica-

tions or for very long strings.

2.2 Algorithms for Computing the Edit

Distance

Over the years, several exact algorithms, which seek

the optimal answer to the problem without consid-

ering margins of error or speciﬁc conditions, have

been proposed. The most famous exact algorithm is

the Wagner-Fischer algorithm (Wagner and Fischer,

1974), based on dynamic programming that has a time

complexity of O(nm), where n and m are the string

lengths to compare.

2.3 Wagner-Fischer Algorithm

The Wagner-Fischer algorithm is based on dynamic

programming and starts from the observation that

it is possible to create a matrix with a number of

rows and columns corresponding to the length of the

Efﬁcient Secure Computation of Edit Distance on Genomic Data

879

two strings to be processed. The ﬁnal edit distance

D(n, m), where n and m represent the lengths of the

two strings respectively, is obtained by resolving all

the edit distances of the substrings that constitute

the ﬁnal strings. In other words, the computation

proceeds with each D(i, j) where i and j are values

smaller than n and m. The key idea is to solve all

the sub-problems relying on the values obtained from

the previous computation. Basically, we have to com-

pute D(i, j) for each 0 < i < n and 0 < j < m. Each

cell represents the edit distance of two substrings and,

consequently, one of these sub-problems.

Since exact algorithms require at least O(nm) op-

erations to compute the Levenshtein distance, over the

years scientiﬁc research has been heavily involved in

the search for better alternatives through approximate

algorithms that are generally faster (Hyyr

o, 2003).

2.4 Ukkonen Algorithm

Typically, approximation algorithms search for ap-

proximate matches of a pattern from a string using

also a predetermined maximum error threshold that

indicates the maximum edit distance allowed for an

approximate match.

The most important algorithm in this category is

the Ukkonen’s algorithm (Ukkonen, 1985), that op-

timizes the computation of edit distance by trying to

restrict the number of cells that must be ﬁlled in the

dynamic programming table. Given m and n the two

string lenghts, and i, j the coordinates of any cell in

the matrix, from the diagonal and adjacency proper-

ties, Ukkonen observed that if D(i, j) ≤ k and m ≤ n,

then it is sufﬁcient to ﬁll only the cells in the di-

agonals: −⌊

(k−n+m)

⌋, −⌊

(k−n+m)

⌋ + 1, . . . , ⌊

(k+n−m)

⌋

of the dynamic programming matrix. He concluded

that the d(i, j) values form a non-decreasing sequence

along any given diagonal, i.e. d(i, j)−1 ≤ d(i−1, j −

1) ≤ d(i, j) consequently, it’s necessary to calculate

only the values that do not exceed the chosen thresh-

old k. Once D(i, j) > k, the cells D(i+h, j +h) where

h ≥ 0 are irrelevant for computation purposes. This

technique is called cut-off because, intuitively, it cuts

out unnecessary values.

If we are not interested in an edit distance greater

than some maximum threshold k, then it is necessary

to calculate only the diagonal band of width 2k +1 of

the matrix because the other cells are irrelevant for the

computation.

2.5 Generalized Ukkonen

An advantageous optimization of the Ukkonen’s algo-

rithm with a generalization of the cut-off technique,

ε A C G T

ε 0 1

G 1 1 2

A 1 2 3

C 1 2 3

T 2 2

Figure 1: Generalized Ukkonen.

described and used in the ﬁnal experiment, leverages

an implicit upper bound of the Levenshtein distance

and can be used without a pre-speciﬁed threshold pa-

rameter k (Ukkonen, 1985) (Seiji, 2019). This opti-

mization is rarely, if ever, used in literature although

it turns an approximation algorithm into an exact one.

Suppose we have two strings S and T whose

lengths are n and m respectively, with m ≥ n. We can

guarantee that the Levenshtein distance cannot exceed

LevenshteinDist(S, T ) ≤ m.

If we deﬁne the two strings as S = S

. . . S

n−1

and

T = T

. . . T

m−1

, since m ≥ n, we can rewrite S =

. . . S

n−1

and T = T

. . . T

n−1

n+1

. . . T

Now we can convert T into S by replacing the se-

quence T

. . . T

with S

. . . S

and deleting T

n+1

. . . T

The cost of performing this operation is at most m be-

cause it needs n substitution and (m − n) deletions.

Hence, the upper bound is proved.

This upper bound is quite useful because it allows

fewer cells to be computed without specifying a pre-

cise threshold. Let X

be the Manhattan distance from

a cell to the upper right corner. Then, as a rule, we

can say that as long as the expression

(n − X

) + (m − X

) ≥ m with X

≥ 0

is valid, we can safely ignore the corresponding ma-

trix cells. An example is given in Figure 1.

Assuming two strings have the same lenghts n =

m, this optimization reduces by approximately (

1)(

+ 2) the number of cells to be computed, result-

ing in a substantial computational gain.

2.6 Secure Multi-Party Computation

Secure Multi-Party Computation (SMPC) is a ﬁeld of

cryptography having the goal of enabling a group of

independent data owners who do not trust each other

or any common third party to jointly compute a func-

tion that depends on all of their private inputs. SMPC,

introduced by Andrew Yao in the early 1980s (Yao,

1982), can be deﬁned as the problem of n players

who want to compute an agreed function of their in-

puts in a secure way. Formally, we assume x

, . . . , x

inputs, where player i knows x

, and we want to com-

pute f (x

, . . . , x

) = (y

, . . . , y

) such that player i is

guaranteed to learn y

and nothing more than that.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

880

Adversaries involved in the computation can be

categorized into two types: semi-honest and mali-

cious, according to how willing they are to devi-

ate from the protocol. In (Yao, 1982), Yao intro-

duced the idea of secure computation, in which n par-

ties (or players) want to jointly compute a function

f (x

, x

, . . . , x

) where x

is the i

party’s private in-

put. In the next years he also introduced the Garbled

Circuits Protocol that is the basis for many of the most

efﬁcient SMPC implementations still today.

At the beginning, secure computation was only

a theoretical interest but in the 2000s, algorithmic

improvements and computing costs reached a point

where it became realistic to think about building prac-

tical systems using general-purpose multi-party com-

putation.

The ﬁrst project that implemented this type of

system was Fairplay (Malkhi et al., 2004). For the

ﬁrst time, with Fairplay, it was possible to express a

privacy-preserving program in a high level language

and compile it to executables that could be run by

the parties involved in the computation. However, its

scalability and performance limited its use to toy pro-

grams.

The speed of the SMPC protocol signiﬁcantly

increased over time and today is several orders of

magnitude higher due to a combination of crypto-

graphic, protocol, network and hardware improve-

ments. These improvements made possible the adop-

tion of SMPC implementations in important con-

texts and applications (Evans and M. Rosulek, 2020).

Thanks to the increasingly efﬁcient protocols for

SMPC that have been proposed in recent years,

SMPC can now be considered as a practical solution

to several real-life problems.

2.6.1 Yao’s Garbled Circuits Protocol

Yao’s Garbled Circuits protocol (GC) is one the most

widely known SMPC technique (Yao, 1986) (Micali

et al., 1987). Furthermore, Yao’s GC runs in con-

stant rounds and avoids the costly latency associated

with approaches where the number of communica-

tion rounds scales with the circuit depth. The starting

point for this and all other protocols is the same: we

want to evaluate a given function F(x, y) where party

holds x ∈ X and P

holds y ∈ Y .

First of all we have to convert the function we

need into a boolean circuit. Then we have to evalu-

ate each gate securely. To do this, Alice picks two

random keys for each wire (inputs and outputs). One

key corresponds to 0, the other to 1. There are a total

of 6 keys for a 2-input gate. Alice encrypts each row

of the truth table by encrypting the output key with

the corresponding pair of input keys, then she ran-

domly permutes (“garbles”) the encrypted truth table

and sends it to Bob. In this way Bob doesn’t know

which row of garbled table corresponds to which row

of original table. Then Alice sends to Bob the corre-

sponding key to her input bit. Since keys are random,

Bob won’t know what this bit is. The last step consists

in running the oblivious transfer protocol between the

two keys and Bob’s 1-bit input in order to provide Bob

with the correct key.

3 SECURE COMPUTATION OF

THE EDIT DISTANCE

Edit distance, weighted edit distance and Needleman-

Wunsch algorithms are often used and widely adopted

in the bioinformatics research ﬁeld. However, se-

curely computing these metrics is a highly challeng-

ing research task. Many research works focused on

secure and efﬁcient implementations of edit distance

algorithms and the analysis of their benchmarks (Zhu

and Huang, 2020) (Zhu and Huang, 2017) (Kaghaz-

garan, 2017) (Aziz et al., 2017) (Wang et al., 2015)

(Huang et al., 2011). However, almost none of these

works precisely deﬁne and provide all the details used

for the experiment setup, such as machine type, cho-

sen framework, implementation and benchmarking

settings, source codes, used input data, custom op-

timizations, etc.

In this work we implement novel secure imple-

mentations of existing edit distance algorithms, par-

ticularly the Ukkonen’s generalized algorithm which

has never been implemented before in literature, us-

ing the current state-of-the-art garbled circuits in the

context of semi-honest model. We will also analyze

their performances, and deﬁne a clear baseline for fu-

ture works.

3.1 Experimental Setup

In order to provide meaningful and reproducible re-

sults, we decided to use Google Cloud Platform. For

this work, the N1, a Compute Engine’s ﬁrst gen-

eration general-purpose machine type, was chosen;

speciﬁcally the n1-standard-1 instance, provided

with 1 vCPU and 3.75 GB of memory and Ubuntu

21.04.

To develop all secure implementations we chose

the EMP-toolkit framework (Wang et al., 2016), be-

cause it integrates all existing applicable optimiza-

tions for garbled circuits including efﬁcient OT exten-

sion (Kolesnikov and Kumaresan, 2013) (Ishai et al.,

2003), FreeXOR technique (Kolesnikov and Schnei-

der, 2008) and Half-Gates garbling (Zahur et al.,

Efﬁcient Secure Computation of Edit Distance on Genomic Data

881

Table 1: Algorithms performance on different string lengths. Computation inputs are two n-nucleotides genomes. Times are

in seconds.

String Lengths

Randomly Generated Genomic (iDash)

Algorithm 200 1000 2000 3000 4000 3456 3465 3475

Wagner-Fischer 0.2 8.1 34.9 - - - - -

Wagner-Fischer (opt.) 0.2 7.8 34.0 82.6 146.7 109.2 108.6 108.6

Ukkonen (thr.) 0.1 5.0 21.9 52.7 93.7 71.0 70.4 70.9

Ukkonen (gen.) 0.1 4.8 20.9 50.6 90.2 67.4 67.7 68.6

2015). EMP-toolkit also provides a 127-bit compu-

tational security (κ). For the purpose of this work

a semi-honest model and two-party computation was

chosen. All algorithms were developed in C/C++.

3.2 Benchmark Settings

In computer science there is no common consensus

regarding benchmark measurement. Many variables

can distort the effective result of a process execu-

tion, mainly due to I/O operations, task switches, time

spent on other processes, interrupt handling, etc. run-

ning in the same time span. Generally, two methods

are taken into account to measure how much time has

passed: Wall time and CPU time.

In this work we decided to mainly adopt the CPU

time, using the clock

gettime function with the

CLOCK PROCESS CPUTIME ID option, available in the

GNU C Library. However some comparisons have

been carried out using also the wall time. To obtain

a signiﬁcant value, each test has been executed 10

times, and the arithmetic mean among all the results

has been calculated.

3.3 Experimental Results

For the experimental results, we considered strings of

approximately 3000-4000 characters, as done in most

of the related works on the secure computation of

the exact edit distance of genomic strings (Zhu and

Huang, 2020) (Zhu and Huang, 2017) (Kaghazgaran,

2017) (Aziz et al., 2017) (Huang et al., 2011). These

lengths are already useful for many types of applica-

tions and comparisons on DNA and RNA strings. Of

course, the provided code can manage longer strings,

comparable to the human DNA lenghts (human chro-

mosomes range in size from about 50 million to 300

million base pairs).

In particular, the proposed algorithms were eval-

uated using two datasets of DNA data. The ﬁrst

dataset consists of randomly generated strings of var-

ious lenghts containing {A,C, G, T } elements. The

considered lengths were 200, 1000, 2000, 3000, and

4000 elements. The second dataset consists of real

DNA strings from a genome database released by

“iDASH Security and Privacy Workshop 2016” (Tang

et al., 2016). The database includes 50 strings of ap-

proximately 3400 − 3500 characters each.

Table 1 reports the performance of the four

privacy-preserving algorithms that have been imple-

mented: the Wagner-Fischer algorithm, using the

entire dynamic programming matrix; the Wagner-

Fischer algorithm, optimized to use the minimum

needed columns; the Ukkonen’s algorithm, consider-

ing a threshold of about 60% of the longest string;

the Ukkonen’s algorithm, using the generalized cut-

off technique. The source code is available publicly

at GitHub (Migliore, 2021) for interested readers.

The symbol “-” means that the algorithm was ter-

minated by Linux Out of Memory Killer process

before it ended.

In Table 2 we compared the results obtained in

this work with the best prior results found in liter-

ature (Zhu and Huang, 2020) (without considering

particular and speciﬁc customization to the garbling

scheme with the EMP-Toolkit), revealing a signiﬁcant

increase in performance with a 36% speedup.

Table 2: Performance comparison. Computation inputs are

two 4000-nucleotide genomes.

CPU time (s) Wall time (s)

Best Prior N/A 286

This Work 9

2 1

4 CONCLUSIONS

The computation of the edit distance between human

genomes has become a very important task in medical

domain. In this paper we have proposed some novel

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

882

techniques to securely compute the edit distance on

human genomes and proposed an efﬁcient implemen-

tation reporting some experimental results on both ar-

tiﬁcial and public datasets.

Our techniques show improved efﬁciency over

state of the art, reducing the overall time needed and

providing a 36% speedup over best prior result found

in literature.

Some more optimizations, on both the computa-

tion of the distance and the usage of secure computa-

tion frameworks can be pursued.

ACKNOWLEDGEMENTS

This work was partially supported by project SERICS

(PE00000014) under the MUR National Recovery

and Resilience Plan funded by the European Union

- NextGenerationEU.

REFERENCES

Aziz, M. M. A., Alhadidi, D., and Mohammed, N. (2017).

Secure approximation of edit distance on genomic

data. BMC medical genomics, 10(2):55–67.

Backurs, A. and Indyk, P. (2014). Edit distance cannot be

computed in strongly subquadratic time (unless seth is

false).

Evans, David Kolesnikov, V. and M. Rosulek, M. (2020).

A Pragmatic Introduction to Secure Multi-Party Com-

putation. NOW Publishers.

Evans, W. E. and Relling, M. V. (2004). Moving towards

individualized medicine with pharmacogenomics. Na-

ture, 429(6990):464–468.

Huang, Y., Evans, D., Katz, J., and Malka, L. (2011). Faster

secure {Two-Party} computation using garbled cir-

cuits. In 20th USENIX Security Symposium (USENIX

Security 11).

Hyyr

o, H. (2003). Practical methods for approximate string

matching.

Ishai, Y., Kilian, J., Nissim, K., and Petrank, E. (2003). Ex-

tending oblivious transfers efﬁciently. In International

Cryptology Conference (CRYPTO).

Kaghazgaran, P. (2017). Privacy-preserving edit distance

on genomic data. arXiv preprint arXiv:1711.06234.

Koboldt, D. C., Fulton, R., McLellan, M., Schmidt, H.,

Kalicki-Veizer, J., McMichael, J., Fulton, L., Dooling,

D., Ding, L., Mardis, E., et al. (2012). Comprehensive

molecular portraits of human breast tumours. Nature,

490(7418):61–70.

Kolesnikov, V. and Kumaresan, R. (2013). Improved ot ex-

tension for transferring short secrets. In Advances in

Cryptology (CRYPTO).

Kolesnikov, V. and Schneider, T. (2008). Improved gar-

bled circuit: Free xor gates and applications. In Pro-

ceedings of the 35th International Colloquium on Au-

tomata, Languages and Programming, Part II, ICALP

’08, page 486–498, Berlin, Heidelberg. Springer-

Verlag.

Levenshtein, V. I. et al. (1966). Binary codes capable of cor-

recting deletions, insertions, and reversals. In Soviet

physics doklady, volume 10, pages 707–710. Soviet

Union.

Malkhi, D., Nisan, N., Pinkas, B., and Sella, Y. (2004). Fair-

play—a secure two-party computation system. In Pro-

ceedings of the 13th Conference on USENIX Security

Symposium - Volume 13, SSYM’04, page 20, USA.

USENIX Association.

Micali, S., Goldreich, O., and Wigderson, A. (1987). How

to play any mental game. In Proceedings of the Nine-

teenth ACM Symp. on Theory of Computing, STOC,

pages 218–229. ACM.

Migliore, A. (2021). Smpc-ed. https://github.com/Andre

aMigliore/smpc-ed.

Seiji, F. (2019). Can we optimize the wagner-ﬁscher algo-

rithm? https://ceptord.net/wagner-fischer/index.html.

Tang, H., Wang, X., Kuo, T.-T., Ohno-Machado, L., Jiang,

X., Harmanci, A. O., and Kim, M. (2016). Idash pri-

vacy & security workshop. http://www.humangenom

eprivacy.org/2016/index.html.

Taylor, J. G., Choi, E.-H., Foster, C. B., and Chanock, S. J.

(2001). Using genetic variation to study human dis-

ease. Trends in molecular medicine, 7(11):507–512.

Ukkonen, E. (1985). Algorithms for approximate string

matching. Information and Control, 64(1):100–118.

Waddell, N., Pajic, M., Patch, A.-M., Chang, D. K., Kas-

sahn, K. S., Bailey, P., Johns, A. L., Miller, D., Nones,

K., Quek, K., et al. (2015). Whole genomes redeﬁne

the mutational landscape of pancreatic cancer. Nature,

518(7540):495–501.

Wagner, R. A. and Fischer, M. J. (1974). The string-

to-string correction problem. Journal of the ACM

(JACM), 21(1):168–173.

Wang, X., Malozemoff, A. J., and Katz, J. (2016). Emp

toolkit. https://github.com/emp-toolkit.

Wang, X. S., Huang, Y., Zhao, Y., Tang, H., Wang, X.,

and Bu, D. (2015). Efﬁcient genome-wide, privacy-

preserving similar patient query based on private edit

distance. In Proceedings of the 22nd ACM SIGSAC

Conference on Computer and Communications Secu-

rity, pages 492–503.

Yao, A. C. (1982). Protocols for secure computations. In

23rd annual symposium on foundations of computer

science (sfcs 1982), pages 160–164. IEEE.

Yao, A. C. (1986). How to generate and exchange secrets. In

27th Annual Symposium on Foundations of Computer

Science (sfcs 1986), pages 162–167. IEEE.

Zahur, S., Rosulek, M., and Evans, D. (2015). Two halves

make a whole - reducing data transfer in garbled cir-

cuits using half gates. In EUROCRYPT, pages 220–

250.

Zhu, R. and Huang, Y. (2017). Efﬁcient privacy-preserving

general edit distance and beyond. Cryptology ePrint

Archive.

Zhu, R. and Huang, Y. (2020). Efﬁcient and precise secure

generalized edit distance and beyond. IEEE Transac-

tions on Dependable and Secure Computing.

Efﬁcient Secure Computation of Edit Distance on Genomic Data

883
