Fuzzing Matter(s): A White Paper for Fuzzing the Matter Protocol

Marcello Maugeri

Department of Maths and Computer Science, University of Catania, Catania, Italy

Keywords:

Fuzzing, IoT, Security Testing.

Abstract:

IoT and smart home devices have transformed daily life, consequently raising more and more concerns about

security vulnerabilities. Robust security testing methods are essential to fortify devices against potential

threats. While dynamic analysis techniques, such as fuzzing, help identify vulnerabilities, some challenges

arise due to diverse architectures, communication channels and protocols. Testing directly on devices over-

comes difﬁculties in ﬁrmware emulation, but lack of protocol standardisation still poses hurdles. The recently

released Matter protocol aims to unify smart home ecosystems, thus also simplifying security testing. In par-

ticular, Matter inherits the concept of Cluster from Zigbee in its Data Model. The Data Model clearly deﬁnes

attributes, commands, status codes and events that could be leveraged to design automated security testing

techniques such as fuzzing. This paper proposes the design of a fuzzing framework for Matter-enabled smart

home devices. The framework employs stateful fuzzing to cover the inherent state-fullness of IoT devices.

Such a framework would bestow beneﬁts upon manufacturers, researchers, and end-users.

1 INTRODUCTION

The increasing growth of smart home devices has

led to problems with competing standards and pro-

tocols. The World Economic Forum estimates that

more than 130 million households owned at least a

smart speaker – the most common smart home de-

vice – in 2022 (World Economic Forum, 2022). As

smart home technology rapidly expands, a signiﬁcant

challenge arises for consumers who own devices from

multiple vendors. Integrating new devices into their

existing smart home ecosystem becomes a tedious

task. Typically, each vendor requires users to down-

load their speciﬁc app or, in the case of voice assis-

tants such as Amazon Alexa, install the corresponding

skill to enable communication with the new device.

This process not only demands considerable time and

effort but also results in a fragmented user experience.

Moreover, an additional concern emerges regard-

ing device usability during service disruptions. In

fact, as depicted in Figure 1, many smart home de-

vices rely on cloud services to fully function. As

a consequence, when the cloud service experiences

downtime or connectivity issues, the device’s func-

tionality may be severely affected or temporarily dis-

abled, causing inconvenience and limiting the de-

vice’s reliability.

https://orcid.org/0000-0002-6585-5494

Cloud Service

User

ControllersSmart Home

Figure 1: Typical usage of a smart home device.

As a solution for such issues, Matter establishes

a new smart home standard that allows devices to

be operated relying on the local network, improving

user convenience and eliminating the need for multi-

ple vendor-speciﬁc applications. To this extent, Mat-

ter (Connectivity Standards Alliance, 2023b) enables

devices to work ofﬂine without requiring continuous

access to the cloud, thus increasing the devices’ secu-

rity, especially for sensitive hardware like smart locks

and security cameras. In addition, this functionality

allows local testing, indirectly empowering end-users

and researchers.

Within the realm of security testing techniques,

446

Maugeri, M.

Fuzzing Matter(s): A White Paper for Fuzzing the Matter Protocol.

DOI: 10.5220/0012469200003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 446-451

ISBN: 978-989-758-683-5; ISSN: 2184-4356

fuzzing has gained prominence for its automated and

effective approach to identifying vulnerabilities. The

concept is straightforward—repeatedly execute a tar-

get system with inputs designed to provoke unex-

pected behaviours.

Despite its efﬁcacy, fuzzing encounters challenges

in the context of embedded systems (Eisele et al.,

2022), such as smart home devices, due to their

diverse architectures, communication channels, and

protocols. While testing directly on devices can over-

come issues related to ﬁrmware emulation, the lack of

protocol standardisation remains a hurdle.

However, since Matter is expected to become the

de-facto standard among smart home and IoT de-

vices, this paper relies on the necessity of develop-

ing a fuzzer speciﬁcally tailored to Matter protocol.

While adapting a pre-existing fuzzer to Matter might

appear straightforward, the intricacies inherent in the

protocol necessitate a specialised solution. Devel-

oping an effective framework involves utilising Mat-

ter’s speciﬁcs, including events and attributes for in-

ferring the state model, and leveraging the command

list knowledge for precise input generation. Hence,

this paper proposes a white paper of a possible solu-

tion.

The paper is structured as follows: Section 2 gives

a brief introduction to the state-of-the-art of embed-

ded fuzzing, followed by a brief description of the

Matter protocol. Section 3 outlines the research goals,

anticipates challenges, and provides an overview of

the proposed fuzzing framework’s design. Finally,

Section 4 concludes the paper.

2 BACKGROUND

2.1 Embedded Fuzzing

In the pursuit of robust ﬁrmware security testing,

several vulnerability-ﬁnding systems employ static

analysis (Costin et al., 2014). While static analysis

can uncover potential vulnerabilities, it often reports

false positives (Costin et al., 2016) since the target

ﬁrmware is not actually executed during the analysis.

To address this limitation and achieve more accurate

results, dynamic analysis is preferred.

Dynamic analysis methods, such as fuzzing, typ-

ically involve the emulation of the target ﬁrmware in

a controlled and efﬁcient environment, allowing se-

curity testers and the fuzzer itself to observe the be-

haviour and interactions with various inputs. Rel-

evant emulation-based works include Firmfuzz (Sri-

vastava et al., 2019), FirmAE (Kim et al., 2020) and

Icicle (Chesser et al., 2023). Unfortunately, emulat-

ing ﬁrmware from different architectures and deal-

ing with obfuscated code still pose signiﬁcant chal-

lenges (Wright et al., 2021), hindering the efﬁcacy of

dynamic analysis. As a consequence, researchers and

security experts often resort to testing directly on ac-

tual devices to overcome the challenges of accurately

emulating ﬁrmware.

However, testing directly on devices effectively

introduces its own set of challenges due to the lack

of relevant feedback. GDBFuzz (Eisele et al., 2023)

addresses the issue effectively by monitoring the tar-

get device through the debug interface. However, it is

worth noting that not all devices have a debug inter-

face available on their shield, causing this solution to

be challenging to apply.

Then, it is preferred to use the network commu-

nication channel as an entry point. Another major

issue is the limited resources of IoT devices, which

may not be able to handle large-scale testing of nu-

merous inputs in a short amount of time. This con-

straint calls for smart and efﬁcient testing methodolo-

gies – for example by leveraging machine learning al-

gorithms (Eceiza et al., 2021; Aichernig et al., 2021)

– to maximise the effectiveness of the testing process.

Another signiﬁcant challenge is the diversity of

network communication channels used by IoT de-

vices. The devices may employ different protocols

and mechanisms for communication, leading to com-

plex communication pathways. For example, a user

might use a companion app on a smartphone to send

commands to the cloud through the use of Wi-Fi. The

cloud then relays the command to a smart hub on the

local network, and the smart hub communicates with

the actual device using a protocol such as Zigbee.

This intricate network of communication necessitates

careful consideration and testing of all communica-

tion paths to ensure comprehensive security coverage.

Additionally, the lack of standardisation in the ap-

plication protocols used to communicate with IoT de-

vices poses a signiﬁcant hurdle. In some cases, de-

vices may use standard protocols such as HTTP, but

with custom payloads or unconventional implementa-

tions. Alternatively, MQTT may be used to leverage a

publish-subscribe pattern for communication. These

variations demand the development of tailored testing

tools and methodologies for each unique target under

test. As a consequence, most of the relevant works,

such as IoTFuzzer (Chen et al., 2018), DIANE (Re-

dini et al., 2021) leverage companion apps provided

by the device’s respective vendor to communicate di-

rectly with the device without inferring the underlying

protocol and cipher.

Nevertheless, these tools are tailored to the respec-

tive companion app, hence they are not easily reusable

Fuzzing Matter(s): A White Paper for Fuzzing the Matter Protocol

447

without requiring additional effort. In addition, most

apps are obfuscated, nullifying this method. As a con-

sequence, some tools such as Snipuzz (Feng et al.,

2021) and FIoTFuzzer (Xu et al., 2022) work di-

rectly by mutating previously acquired messages to

send to the target device. Both works employ guided

mutation based on feedback inferred from the re-

sponse provided by the target device. However, cer-

tain devices may not generate a detailed response

and instead prioritise providing a simplistic error

code. Also, the message acquisition phase is time-

consuming and could not cover all possible function-

alities.

To make a more comprehensive solution, Ma et

al. (Ma et al., 2023) recently developed HubFuzzer,

which leverages a device pretending to be a smart hub,

to receive allowed commands from the target device

directly. Unfortunately, HubFuzzer is not currently

open-sourced, and it is designed to work with devices

based on Zigbee and Z-Wave protocols only. In ad-

dition, Ma et al. discuss the possible re-using of this

approach with the Matter protocol. Still, this paper

foresees that it will require extensive additional work

to provide an effective solution, due to the Matter’s

speciﬁcation complexity.

2.2 Matter Protocol

The Matter protocol deﬁnes a seven-layer stack as

depicted in Figure 2. At the topmost layer, the Ap-

plication Layer orchestrates the high-level business

logic, managing tasks such as turning on or off a smart

home device. Situated beneath the ﬁrst layer, the Data

Model Layer serves as a fundamental component, elu-

cidating data and verb elements pivotal for the proto-

col’s delineation. Notably, this layer introduces the

concept of a Cluster: a speciﬁcation that intricately

deﬁnes attributes, commands, behaviours, and depen-

dencies for a set of functionalities.

In particular, a Command is a data ﬁeld set that

triggers a behaviour in the receiver. The receiver,

upon receiving a command, can respond with a suc-

cess or error status code. Alternatively, it may remain

silent (no response), or reply with a speciﬁc response

command if the initial command is not a request.

Note that the status code could be cluster-speciﬁc or a

global status code deﬁned from the underlying Inter-

action Model.

Another integral element within a Cluster is an At-

tribute. Attributes encompass queryable or settable

states, conﬁgurations, or capabilities of the device.

For instance, a smart bulb may feature the On/Off

attribute to indicate its operational status. A more

intricate example is the AcceptedCommandList, de-

tailing the supported commands. Similar functional-

ities are achieved through AttributeList for attributes

or EventList for events.

Speciﬁcally, Events serve as records of past state

transitions. While attributes convey current states,

events function as a historical journal, equipped with

a monotonically increasing counter, timestamp, and

priority. This design enables the capture of state tran-

sitions and facilitates data modelling that extends be-

yond the capabilities of attributes.

Moving further down, the Interaction Model layer

sets the stage for communication between devices of

the same Fabric acting as a client or a server. A Fabric

is a set of nodes that interact by accessing data model

elements. For completeness, a Node is a unique ad-

dressable entity, usually a physical device, but can

also be a logical instance of it. In addition, a node

is composed of one or more endpoints adhering to a

speciﬁc device type, and the Cluster is an instance of

an endpoint.

Subsequently, the Action Framing layer is respon-

sible for encoding the message into a prescribed bi-

nary format for network transmission. Consequently,

security measures are accomplished in the Security

layer. In this layer the action frame is processed, un-

dergoing encryption and the addition of a message

authentication code using the AES-CCM mode as de-

ﬁned in NIST 800-38C (Dworkin, 2007).

Finally, the Message Layer takes charge of con-

structing the payload format post-encryption. This

layer adds required and optional header ﬁelds, speci-

fying message properties and logical routing informa-

tion. The ﬁnalised payload is then ready for transmis-

sion via the underlying transport protocol, either TCP

or the Matter’s Message Reliability Protocol (MRP)

through UDP, for effective IP management of the data.

As the data reaches the peer device, it ascends the pro-

tocol stack, with each layer reversing the operations

performed by the sender.

3 FUZZING MATTER(S)

3.1 Research Goals

Matter offers a comprehensive deﬁnition of smart

home device functionalities through its Cluster speci-

ﬁcation. Additionally, the Matter Application Cluster

Library (MACL), curated by the Connectivity Stan-

dards Alliance, serves as a dynamic repository for

cluster functionalities, regularly updated with new

features. Essentially, the MACL comprises multiple

sets of clusters for general use. The primary research

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

448

Application Layer

Data Model

Interaction Model

Action Framing

Security

Message Framing +

Routing

IP Framing +

Transport Management

Matter

TCP UDP

IPV6

Ethernet Wi-Fi

Thread

802.15.4

Transport

Network

Link

Application

Figure 2: Stack of the Matter Protocol.

goal is to develop a fuzzer capable of effectively cov-

ering all functionalities outlined in the MACL.

Moreover, smart home devices inherently possess

statefulness. In Matter, this state can be extracted

from queryable attributes and events within a Clus-

ter, laying the foundation for the design of a state-

ful fuzzer (Daniele et al., 2023). This dual-pronged

research approach aims to enhance security testing

by addressing the unique characteristics of Matter’s

Cluster functionalities and the inherent statefulness of

smart home devices.

3.2 Expected Challenges

The project expects the following challenges:

1. Benchmark – Acquiring a relevant set of real

case studies with multiple natures to build a

benchmark for the design and evaluation of the

fuzzer.

2. Information Gathering from Static Analysis of

the Firmware – Although static analysis cannot

be always applicable, existing techniques could

be tailored to obtain Matter-relevant information

from the ﬁrmware.

3. Information Gathering from Firmware Emu-

lation – Although ﬁrmware emulation is not al-

ways possible, an alternative approach could be

tailored to perform fuzzing in an emulated envi-

ronment, improving test speed and validating the

obtained results with the real device.

4. Handling Multiple Link Layers – Matter pri-

marily operates with Wi-Fi and Thread protocols,

but it also supports other protocols such as Zigbee.

Therefore, the fuzzer must be compatible with all

link layer protocols speciﬁed in Matter.

5. Stateful Fuzzing – IoT devices often have stateful

behaviour, where their actions and responses de-

pend on previous inputs. Fuzzing stateful proto-

cols can be more complicated than stateless ones.

The proposed solution will likely need to design

stateful fuzzing strategies to adequately cover all

possible device states and interactions related to

the Matter protocol.

6. Handling Vendor-Speciﬁc Implementations –

Different manufacturers may implement the Mat-

ter protocol differently, introducing variations in

the behaviour of devices. For example, a manu-

facturer could deﬁne its own Cluster speciﬁcation.

The fuzzer should account for vendor-speciﬁc im-

plementations and adapt the fuzzing techniques

accordingly.

7. Validating True Positives – Fuzzing often pro-

duces numerous inputs and potential vulnerabili-

ties. The proposal requires effective methods to

validate and reproduce the obtained ﬁndings ac-

curately.

3.3 Proposed Framework

The proposed fuzzing framework consists of four

components, illustrated in Figure 3.

Initially, the Input Generator creates input fol-

lowing the Cluster speciﬁcation, utilising information

such as accepted commands, queryable/settable at-

tributes, and accessible events. It is important to note

that, at the current design stage, speciﬁc input genera-

tion algorithms have not been chosen as any grammar-

Fuzzing Matter(s): A White Paper for Fuzzing the Matter Protocol

449

Node / Device

Cluster

Fuzzer

Connection Handler

Input

Generator

State

Monitor

Status Code

Attributes

Events

Response

Handler

Bug Oracle

Request

Command

Sender

Response

Attributes

Commands

Events

AttributeList

EventList

AcceptedCommandList

Figure 3: Proposed Framework.

based approach adapted to the problem should ﬁt.

However, the modular design of the framework facil-

itates easy replacement with minimal effort.

Once the input is generated, the Connection Han-

dler engages with the target node (or device), man-

aging the transmission of input generated by the In-

put Generator and receiving any corresponding re-

sponses. Given Matter’s use of Thread, Wi-Fi, and

Ethernet as networking technologies, the fuzzer must

support communication with any Matter-compliant

device, accommodating various link layer protocols.

Responses can carry diverse information. If the

request involves a command, the response should in-

clude a success or error status code, signalling poten-

tial bugs to the Bug Oracle. A bug might manifest as

an unexpected success code inappropriately granted

or an unforeseen error code in a properly formed com-

mand.

Additionally, a response may include the queried

attribute or event, updating the State Monitor on any

state transitions. The fuzzer should account for the

stateful nature of smart home devices, considering

variables such as device states (e.g., on or off). Un-

derstanding the current state proves valuable during

input generation, as the same input may trigger dif-

ferent behaviours based on the device’s state.

4 CONCLUSIONS

In conclusion, this paper has explored the neces-

sity and design of a fuzzing framework tailored for

Matter-enabled smart home devices. By leverag-

ing the inherent structure provided by Matter’s Clus-

ter speciﬁcation (Connectivity Standards Alliance,

2023a) and the MACL, the proposed framework aims

to comprehensively cover all aspects of device func-

tionality. The modular nature of the framework allows

for ﬂexibility, enabling potential advancement and ex-

tensions.

Furthermore, considering the stateful nature of

smart home devices, the framework incorporates a

State Monitor to capture state transitions during test-

ing. Also, the Connection Handler component facil-

itates interaction with Matter-compliant devices, en-

suring compatibility across different link layers.

The fuzzer aims to be open-sourced and promote

collaboration and knowledge sharing within the smart

home and fuzzing community, providing valuable

testing methods to companies, researchers, and end-

users alike. As such, the advances of this project will

be published on the web page https://fuzzingmatter.gi

thub.io/ which anyone is welcome to join.

REFERENCES

Aichernig, B. K., Mu

skardin, E., and Pferscher, A. (2021).

Learning-based fuzzing of iot message brokers. In

2021 14th IEEE Conference on Software Testing, Ver-

iﬁcation and Validation (ICST), pages 47–58.

Chen, J., Diao, W., Zhao, Q., Zuo, C., Lin, Z., Wang,

X., Lau, W., Sun, M., Yang, R., and Zhang, K.

(2018). Iotfuzzer: Discovering memory corruptions

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

450

in iot through app-based fuzzing. In Network and Dis-

tributed System Security Symposium.

Chesser, M., Nepal, S., and Ranasinghe, D. C. (2023). Ici-

cle: A re-designed emulator for grey-box ﬁrmware

fuzzing. In Proceedings of the 32nd ACM SIG-

SOFT International Symposium on Software Testing

and Analysis, ISSTA 2023, page 76–88, New York,

NY, USA. Association for Computing Machinery.

Connectivity Standards Alliance (2023a). Matter Applica-

tion Cluster Speciﬁcation 1.2.

Connectivity Standards Alliance (2023b). Matter Core

Speciﬁcation 1.2.

Costin, A., Zaddach, J., Francillon, A., and Balzarotti, D.

(2014). A Large-Scale analysis of the security of em-

bedded ﬁrmwares. In 23rd USENIX Security Sym-

posium (USENIX Security 14), pages 95–110, San

Diego, CA. USENIX Association.

Costin, A., Zarras, A., and Francillon, A. (2016). Auto-

mated dynamic ﬁrmware analysis at scale: A case

study on embedded web interfaces. In Proceedings

of the 11th ACM on Asia Conference on Computer

and Communications Security, ASIA CCS ’16, page

437–448, New York, NY, USA. Association for Com-

puting Machinery.

Daniele, C., Andarzian, S. B., and Poll, E. (2023). Fuzzers

for stateful systems: Survey and research directions.

arXiv preprint arXiv:2301.02490.

Dworkin, M. (2007). Recommendation for block cipher

modes of operation: The ccm mode for authentication

and conﬁdentiality. Technical report, National Insti-

tute of Standards and Technology.

Eceiza, M., Flores, J. L., and Iturbe, M. (2021). Fuzzing

the internet of things: A review on the techniques and

challenges for efﬁcient vulnerability discovery in em-

bedded systems. IEEE Internet of Things Journal,

8(13):10390–10411.

Eisele, M., Ebert, D., Huth, C., and Zeller, A. (2023).

Fuzzing embedded systems using debug interfaces. In

Proceedings of the 32nd ACM SIGSOFT International

Symposium on Software Testing and Analysis, ISSTA

2023, page 1031–1042, New York, NY, USA. Associ-

ation for Computing Machinery.

Eisele, M., Maugeri, M., Shriwas, R., Huth, C., and Bella,

G. (2022). Embedded fuzzing: a review of challenges,

tools, and solutions. Cybersecurity, 5(1):18.

Feng, X., Sun, R., Zhu, X., Xue, M., Wen, S., Liu, D.,

Nepal, S., and Xiang, Y. (2021). Snipuzz: Black-box

fuzzing of iot ﬁrmware via message snippet inference.

In Proceedings of the 2021 ACM SIGSAC Conference

on Computer and Communications Security, CCS ’21,

page 337–350, New York, NY, USA. Association for

Computing Machinery.

Kim, M., Kim, D., Kim, E., Kim, S., Jang, Y., and Kim,

Y. (2020). Firmae: Towards large-scale emulation of

iot ﬁrmware for dynamic analysis. In Annual Com-

puter Security Applications Conference, ACSAC ’20,

page 733–745, New York, NY, USA. Association for

Computing Machinery.

Ma, X., Zeng, Q., Chi, H., and Luo, L. (2023). No more

companion apps hacking but one dongle: Hub-based

blackbox fuzzing of iot ﬁrmware. In Proceedings

of the 21st Annual International Conference on Mo-

bile Systems, Applications and Services, MobiSys ’23,

page 205–218, New York, NY, USA. Association for

Computing Machinery.

Redini, N., Continella, A., Das, D., De Pasquale, G., Spahn,

N., Machiry, A., Bianchi, A., Kruegel, C., and Vigna,

G. (2021). Diane: Identifying fuzzing triggers in apps

to generate under-constrained inputs for iot devices. In

2021 IEEE Symposium on Security and Privacy (SP),

pages 484–500.

Srivastava, P., Peng, H., Li, J., Okhravi, H., Shrobe, H., and

Payer, M. (2019). Firmfuzz: Automated iot ﬁrmware

introspection and analysis. In Proceedings of the 2nd

International ACM Workshop on Security and Privacy

for the Internet-of-Things, IoT S&P’19, page 15–21,

New York, NY, USA. Association for Computing Ma-

chinery.

World Economic Forum (2022). The market for smart home

devices is expected to boom over the next 5 years.

Wright, C., Moeglein, W. A., Bagchi, S., Kulkarni, M., and

Clements, A. A. (2021). Challenges in ﬁrmware re-

hosting, emulation, and analysis. ACM Comput. Surv.,

54(1).

Xu, Z., Huang, W., Fan, W., and Cheng, Y. (2022). Fiot-

fuzzer: Response-based black-box fuzzing for iot de-

vices. In 2022 IEEE/ACIS 22nd International Con-

ference on Computer and Information Science (ICIS),

pages 239–244.

Fuzzing Matter(s): A White Paper for Fuzzing the Matter Protocol

451
