Feasibility of Privacy Preserving Minutiae-Based Fingerprint Matching

Julia Mader and Thomas Lor

unser

AIT Austrian Institute of Technology, Vienna, Austria

{ﬁrstname.lastname}@ait.ac.at

Keywords:

Multiparty Computation (MPC), Minutiae-Based Fingerprint Matching.

Abstract:

While biometric data, such as ﬁngerprints, are increasingly used for identiﬁcation and authentication, their

inability to be revoked once compromised raises privacy concerns. To mitigate these concerns, in this ongo-

ing research, we explore the use of Multiparty Computation (MPC), which allows secure computations on

encrypted data, as an option for privacy-preserving ﬁngerprint matching. Despite MPC’s known drawback of

slowing down computation, recent advancements make it a viable option for real-world applications. Our re-

search focuses on implementing and optimizing a minutiae-based ﬁngerprint matching algorithm with MPC,

addressing the challenge of maintaining privacy while ensuring reasonable computation times. We present

our implementation using SourceAFIS optimized for MPC and evaluate its performance to assess if current

protocols are ready for deployment in time critical scenarios. Preliminary results show promise, emphasizing

our ongoing research to achieve a fully-ﬂedged MPC implementation with high accuracy.

1 INTRODUCTION

Biometric data such as ﬁngerprints, retina or facial

characteristics are increasingly used as a promising

replacement for conventional identiﬁcation and au-

thentication such as passwords or other identiﬁcation

tokens. However, while they are unique, permanent

and difﬁcult to forge, they cannot be revoked once

leaked. Where passwords can be changed if compro-

mised, biometric data cannot be altered. Furthermore,

there are privacy concerns about the inevitable data

collection, storage and potential misuse of personal

and unique physical characteristics (Simoens et al.,

2009). These disadvantages clearly demonstrate the

importance of including protections against deliberate

and accidental disclosure or misuse of biometric data.

For this very reason, ﬁngerprints are typically only

scanned, stored and processed locally and on dedi-

cated hardware, i.e., secure elements. However, this

approach also limits application to local authentica-

tion and prevents from more advanced use cases.

An alternative approach to special hardware for

privacy-preserving ﬁngerprint matching is using mul-

tiparty computation (MPC), which allows for secure

computations to be performed on encrypted data with-

out the need for decryption, thus mitigating the secu-

rity risks associated with exposing sensitive informa-

tion during processing. To do so, MPC ensures in-

https://orcid.org/0000-0002-1829-4882

put privacy by allowing a set of parties to collectively

compute a function over their private inputs without

disclosing those inputs to any other party involved in

the computation.

However, it should be noted that MPC comes with

the drawback of signiﬁcantly slowing down compu-

tation and therefore the matching process. While this

is not a problem for matchers based on feature vector

comparisons, as the matching process of computing

the Euclidean distance can be also performed quickly

in the encrypted domain, it poses a signiﬁcant chal-

lenge for the more complex minutiae-based match-

ers. However, in recent years, there have been sig-

niﬁcant advancements in MPC protocol design and

implementation, making it ready for real-world ap-

plication. A different application was presented in

(Lor

unser et al., 2022). In particular, in this work we

show, that the realization of a fully ﬂedged privacy

preserving minutiae-based matcher with practical ef-

ﬁciency is actually feasible.

1.1 Motivation and Use Cases

Our work is motivated by a novel use case identi-

ﬁed together with the UN to improve border safety

at airports which cannot rely on local matching but

require remote matching capabilities (Strobl and Na-

tali, 2022). For this solution we envision ﬁngerprints

being matched against No-Fly Lists at airport secu-

Mader, J. and Lorünser, T.

Feasibility of Privacy Preserving Minutiae-Based Fingerprint Matching.

DOI: 10.5220/0012472300003648

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 10th International Conference on Information Systems Security and Privacy (ICISSP 2024), pages 899-906

ISBN: 978-989-758-683-5; ISSN: 2184-4356

899

rity checks. The idea is that in addition to verifying

the traveler’s passport data, their ﬁngerprints are also

compared to national and international No-Fly Lists.

If a match is found, the traveler is not allowed to pro-

ceed their travels.

MPC is ideally suited for this scenarios, because

it supports both objectives. Firstly, enables the conﬁ-

dential pooling of No-Fly Lists among these organi-

zations that may not be willing to share them openly.

Secondly, it ensures the privacy of regular travelers

by keeping their biometrical data conﬁdential. Only

in the event of a match will the relevant data be dis-

closed to start further investigations, but never will

ﬁngerprints of regular travellers be disclosed.

More concretely, the data ﬂow works as follows.

First the individual No-Fly Lists of different organi-

zations are secret shared (encrypted) and distributed

among servers, e.g., three servers in this case. This

corresponds to the pooling of input data in a way such

that the individual servers dos not learn the data they

are holding, but only see encrypted data. Now, if a

ﬁngerprint is scanned, a so called template is gener-

ated and also encrypted (secret shared) and sent to the

severs. Once the servers received the encrypted parts,

they are able to obliviously compute the result of the

matching function in a joint MPC protocol and only

reveal the result, a predicate in this case. If no match

was found in the database, the individual at the se-

curity check preserves his privacy, because the server

does not learn anything about his identity. In case of

a match an alarm is triggered and further handling of

the suspect can be triggered.

However, this is also a highly time-critical appli-

cation and because MPC substantially slows down

computation it is interesting to ask, if it is possible

to obliviously compute matching results in reasonable

time. The waiting time for travelers should not be

extended due to the additional check. The objective

of our research is to implement and optimize a fully

featured ﬁngerprint matching algorithm with MPC to

assess whether current protocols are ready for deploy-

ment in the given use case.

1.2 Research Goals and Methodology

Our research focuses on achieving an optimized im-

plementation of multiparty computation of a pre-

viously existing minutiae-based ﬁngerprint match-

ing algorithm with state-of-the-art matching accuracy.

Additionally, as a baseline for comparison we also

implemented and evaluated a popular feature vector

matcher (Jain et al., 1999) with MPC, as proposed

in (Eerikson, 2020). However, it was already clear

at the beginning, that the matching accuracy of the

FingerCode will not be good enough, which was con-

ﬁrmed in tests on plaintext data. However, in our gen-

eral comparison of matchers we found that the open

source minutiae-based matcher SourceAFIS (Va

zan,

2004) could compete with commercial matchers in

terms of accuracy and showed outstanding perfor-

mance, shown in Figure 2. Therefore, we selected

SourceAFIS (Va

zan, 2004) for the implementation in

MPC. The goal was to optimize it for the implemen-

tation with MPC and evaluate the results in terms of

speed and accuracy.

The MPC implementation is developed using an

open-source package called MPyC: Python Package

for Secure Multiparty Computation (Schoenmakers,

2018). This package offers a range of cryptographic

functionalities necessary for secure computation. Ad-

ditionally, the work comprises an estimation of the ex-

ecution time utilizing the MPC framework MP-SPDZ

(Keller, 2020). Benchmarks of the frameworks can be

found in (Lor

unser and Wohner, 2020).

The algorithms are evaluated using ﬁngerprint

databases from the FVC2000: Fingerprint Veriﬁca-

tion Competition (Maio et al., 2002). Most note-

able characteristics used for the evaluation are the Fail

Rate, False-Match-Rate (FMR), False-Non-Match-

Rate (FNMR) and Equal-Error-rate (EER), where

FMR and FNMR are the same. These rates provide

valuable insights into the accuracy of the ﬁngerprint

matching algorithms.

For the purpose of this research, the implementa-

tion will be considered successful if it can complete

the matching process within a time frame of less than

10 seconds.

1.3 Related Work

The best known performance of encrypted ﬁnger-

print matching was achieved by feature vector-based

matchers, thanks to their straightforward structure and

encryption friendly nature. In fact, in this approach

it is enough to compute the Euclidean distance be-

tween two vectors of reasonable length. (Barni et al.,

2010) as well as (Eerikson, 2020) have used this ap-

proach for their research. We actually based our Fin-

gerCode implementation on the latter utilizing their

code for the feature extraction and only implement-

ing their comparison from scratch. However, as al-

ready stated, matching accuracy of this techniques is

very poor.

amas¸ et al., 2021) recently presented their re-

search on privacy preserving password and iris au-

thentication with mpc and secret sharing using feature

vector comparison for the iris authentication. While

this method of comparing feature vectors works well

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

900

for iris as well as facial recognition (Adnan et al.,

2020), most ﬁngerprint matchers are still minutiae-

based matchers, because they perform better than

feature-based ﬁngerprint matchers.

There have also been some implementations of

privacy-preserving minutiae based matchers. (Blan-

ton and Gasti, 2011) encrypted FingerCode and an iris

code as well as a minutiae-based ﬁngerprint matcher

using garbled circuits and homomorphic encryption.

While they did not include a review of their match-

ers accuracy, we can draw certain conclusions from

the structure of the matcher. Since the comparison

of two minutiae is not rotation or translation invariant

and calculated by computing their Euclidean distance,

the accuracy of the matcher cannot surpass that of a

feature vector-based one. (Shahandashti et al., 2012)

also encrypt a minutiae-based ﬁngerprint matcher us-

ing homomorphic encryption, once again using a very

simplistic ﬁngerprint matcher.

1.4 Contribution and Outline

To the best of our knowledge, we are the ﬁrst to study

the possibility for a fully ﬂedged MPC implementa-

tion of a minutae-based matcher with high accuracy

comparable to commercial plaintext matchers. The

effort is ongoing research and we present our ap-

proach as well as preliminary results. The remain-

der of the paper is organized as follows. In Section 2

we present the minutia matcher SourceAFIS and our

ideas to optimize the algorithm for the implementa-

tion with MPC. In Section 3 we discuss preliminary

evaluation of the privacy preserving implementation.

In Section 4 we summarize our ﬁndings and present

our future work.

2 PRIVACY PRESERVING

MINUTIA MATCHING

2.1 Overview

The primary focus of this work is the implementation

of a privacy preserving minutiae-based ﬁngerprint

matcher, speciﬁcally a MPC version of SourceAFIS

(Va

zan, 2004) using the MPyC framework (Schoen-

makers, 2018). The used algorithm was not imple-

mented from scratch but partly taken from Robert

Vazan’s SourceAFIS implementation in Java. Espe-

cially the feature extraction could be used as is, since

it is intended to run locally on the scanner side and

not in the encrypted back-end. However, the core part

for the matching functionality had to be completely

refactored and rewritten to achieve reasonable run-

times with MPC, albeit we did not deviate from the

high level concept of the matcher regarding the com-

putation of matching scores.

The goal of our research is to generate an un-

derstanding of the complications involved in imple-

menting these complex algorithms using MPC and

to provide optimizations as well as estimates for best

achievable runtimes with current technology.

2.2 Feature Vector Matcher

Matchers based on feature vector comparisons work

as follows: from the raw biometric information, e.g.,

a ﬁngerprint scan, a feature vector is extracted which

can then be compared to other feature vectors by cal-

culating their standard deviation.

In that case, features represent key characteristics

of biometric information and similarity is given by

feature values being close to each other. A match-

ing score is then simply given by the distance be-

tween two vectors, e.g., in the l

-norm. This makes

these matchers very easy to implement and fast, even

in the encrypted domain. These matchers also work

exceptionally well on iris or face recognition, how-

ever, when it comes to ﬁngerprint matching there ac-

curacy is very low and far below any useful threshold

as shown in our evaluation results in Figure 2. Com-

pared to minutiae-based matchers they suffer from ex-

tremely high error rates in all possible working con-

ditions and are not used in practice. Nevertheless, to

have a baseline for benchmarking the minutiae based

matcher, we also implemented and evaluated a feature

vector matcher.

For this, we used FingerCode (Jain et al., 1999),

a ﬁlterbank-based matcher, that uses a set of ﬁlters to

analyse the texture information of the ﬁngerprint im-

age. In the paper Jain et al. summarized the three

main steps as (i) determination of the reference frame

of the ﬁngerprint image, (ii) ﬁltering the image in

eight different directions using a bank of Gabor ﬁl-

ters and (iii) computing the standard deviation of grey

values around the reference point. The results are then

stored in a feature vector, the so-called FingerCode,

which can be easily compared to the FingerCode of

other ﬁngerprints by computing the Euclidean dis-

tance. This concludes a computationally cheap way

to represent and match ﬁngerprints.

2.3 Minutiae Matcher (SourceAFIS)

SourceAFIS is a commercially used and open-source

minutiae-based ﬁngerprint matcher by Robert Va

zan

(Va

zan, 2004). The algorithm can be divided into two

Feasibility of Privacy Preserving Minutiae-Based Fingerprint Matching

901

parts: feature extraction and ﬁngerprint matching.

During the feature extraction, SourceAFIS reads

in an image of a scanned ﬁngerprint and extracts their

minutiae to store them in the so-called template. The

minutiae are saved with their type, namely ending or

bifurcation, their respective position as x and y co-

ordinates and their direction as a 32-bit direction an-

gle of the minutiae. As these features are not rota-

tion and translation invariant, the template not only

stores minutiae, but also computes and stores edges,

which are connections between two minutiae. For

each minutia the algorithm calculates a ﬁxed number

of edges, which are described by their length and two

angles relative to the reference minutia and the neigh-

boring minutia respectively. These parameters do not

change when the edge is moved or rotated, making

the algorithm rotation and translation invariant.

During the second part – the ﬁngerprint match-

ing – the algorithm evaluates whether two ﬁngerprint

templates, which are called probe and candidate, be-

long to the same ﬁnger. To do this, the algorithm ﬁrst

generates an special edge hash table for the probe in a

pre-processing step to speed-up later search for simi-

lar candidate edges.

The candidate’s part of the algorithm comprises

three phases: (i) enumerate, (ii) crawl and (iii) score.

In detail, during (i) the algorithm’s goal is to ﬁnd

root pairs available in both ﬁngerprints. For this, it

iterates through the minutiae of the candidate and cal-

culates an edge to every other minutiae of the candi-

date and their respective value of the edge hash. This

hashvalue is then compared to the probe’s hash table.

If there is an edge with the same hashvalue, the corre-

sponding probe edge is further compared in detail to

the calculated candidate edge. Are the edges similar

enough a root minutia was found and a root pair con-

sisting of the probe’s edge and the candidate’ edge is

created.

Starting from the ﬁrst root pair, in (ii) the algo-

rithm then tries to build a spanning tree through all

minutiae. For this the algorithm compares the sur-

rounding edges of a root pair in probe and candidate.

If one edge is similar enough, the ending minutiae

gets added to the tree on both ﬁngerprints and its sur-

rounding edges will once again be compared to each

other. This procedure is repeated until all minutiae

are checked. An example how a spanning tree of

matching ﬁngerprints could look like is shown in Fig-

ure 1. In contrast to the previous step, where edges

were compared to each other, this comparison takes

the edge surroundings and placement into account, as

edges can look very similar but be at different loca-

tions on the ﬁngerprint.

After generating a spanning tree the algorithm

Figure 1: Spanning Tree of Matching Fingerprint Pair with

minutiae marked in red, root pair blue, pairing tree green

and graph of supporting edges yellow (Va

zan, 2004).

computes a match probability score in (iii). In or-

der to achieve this, the algorithm counts matched fea-

tures, scores how close they match, and sums the the

scores up. The result is a representation of the match-

ing probability, i.e., an indication if the resulting tree

is a match or just a coincidence.

The generation of the tree and the scoring are re-

peated for every root pair to ensure the the best possi-

ble representation of the ﬁngerprint. The best tree and

probability score is returned as the similarity, which

can then be compared to a threshold to declare the

ﬁngerprints matching or not.

2.4 Privacy Preserving SourceAFIS

As the feature extraction can be computed locally and

without MPC, it can be incorporated unchanged from

the original code to generate the ﬁngerprint templates

consisting of the ﬁngerprint’s minutiae and edges

needed for the matching process. These templates can

subsequently be fed into the MPC implementation for

further ﬁngerprint matching.

Regarding the encryption with MPC, the decision

was made that all minutiae-describing details, includ-

ing the coordinates, orientation, edge lengths and an-

gles, have to be encrypted at all times. However, we

choose that the minutiae and edge id can be handled

unencrypted, because they do not contain sensitive in-

formation. By encrypting the minutiae information

while handling minutiae and edge id unencrypted, a

good balance between privacy and computational ef-

ﬁciency is achieved. This approach ensures that the

most critical and private ﬁngerprint data is protected

while allowing some freedom for an efﬁcient MPC

implementation.

Moreover, it is stated in the SourceAFIS docu-

mentation (Va

zan, 2004) that the minutiae numbers

are permuted pseudorandomly during the feature ex-

traction. Although the ordering is consistent, which

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

902

ensures that running the algorithm with same image

twice results in the same ﬁngerprint template, thus

guaranteeing no cryptographic security, the permuta-

tion adds an extra layer of protection, making it chal-

lenging for potential attackers to ﬁnd sensitive data

from the minutiae and edge numbering alone. Any-

way, we also plan to add an additional random per-

mutation step also for the candidate templates stored

in the database, to prevent from any linkage of tem-

plates between different runs.

2.5 Optimizing SourceAFIS for MPC

A naive MPC implementation would just translate

the existing algorithm into the secure domain, how-

ever, the existing implementation makes heavy use

of MPC-unfriendly operators and data structures as

well as programming patterns, which would render

the approach infeasible. In particular, the algorithm

extensively re-computes values, which are computa-

tionally expensive with MPyC per se, and applies the

mentioned hash tables which would require oblivi-

ous indexing in Python dictionaries. In essence, we

needed a different approach for the implementation

with MPC and speciﬁc optimizations for the MPyC

software framework and its protocols. In the follow-

ing we describe our preliminary results on the pre-

sented main steps of SourceAFIS, which correspond-

ing functions are called (i) enumerate, (ii) crawl and

(iii) score and can be implemented with MPyC inde-

pendently of each other.

(I) Enumeration Step

The ﬁrst thing we changed from the original imple-

mentation is the redundancy at certain parts of the al-

gorithm. Speciﬁcally, edges were computed during

both feature extraction and enumeration, and again

in the crawl phase, leading to unnecessary repeti-

tion. While acceptable in environments with neg-

ligible execution times, this became inefﬁcient with

MPC due to its substantial computational costs. Con-

sequently, within our implementation, the strategy in-

volves reusing results and leveraging pre-computed

values.

The original implementation stores the hash as

key-value pairs, where the key is the calculated hash

value and the value includes the associated edge. Im-

plementing this hash in MPyC poses challenges as the

key has to remain secret while indexing the list. While

the MPyC module seclist would allow secret indexing

through encrypted scalar multiplication, the indexing

cannot be performed since the keys do not exist seam-

lessly, making it impossible to incorporate this hash

list with MPyC.

These considerations taken into account, we de-

cided to utilize the edges generated in the feature ex-

traction to create a look-up table that indicates which

edges match. This look-up table can then be used for

both the localization of the roots and the formation of

the tree.

Speciﬁcally for the enumerate function, this meant

that the re-computation of edges, the calculation of

the hash value, the search of edges with the same

hash value and the comparison of edges, when ﬁnding

matching edges in the probe’s hash, can be replaced

by the 1:1 comparison of all edges, resulting in the

output of a match array. To compare these edges the

algorithm checks whether the difference between the

lengths and angles of the probe and candidate edge

fall within an acceptable error tolerance.

The match array can then be decrypted and is sub-

sequently available in unencrypted form for further

processing and as a lookup table for the ﬁngerprint

template’s roots. This is permissible because the val-

ues in the array only represent the edge numbers,

which are permuted, thus making the association of

information challenging for a potential attacker.

Extensive testing revealed that while the imple-

mentation is correct, its independent use remains im-

practical due to substantial execution time challenges.

For instance, comparing 164 edges takes 104s, av-

eraging 640ms per edge. Extrapolating to an aver-

age 1 : 1 ﬁngerprint comparison with around 16, 000

edge comparisons, the execution time for the ﬁrst part

alone would be 3 hours. Consequently, the algorithm

underwent further modiﬁcations to shorten the execu-

tion time.

Reﬂecting on the MPC implementation of the Fin-

gerCode algorithm, it can be observed that the most

efﬁcient time optimization lies in the combination of

operations, thereby eliminating the need to re-share

the values several times. Thus, instead of utilizing

MPyC functions for performing operations in each

step of the edge comparison, the compared lengths

and angles are stored in lists, allowing for simultane-

ous operations over the whole list. At this point, AND

and OR operations are replaced by element-wise vec-

tor multiplication and addition respectively.

These code modiﬁcations yield signiﬁcant im-

provements, as the execution time of length compari-

son was reduced from 18s to 0.62s. This corresponds

to a resulting time of 3.4% of the original time. The

angle comparisons are implemented similarly, leading

to the complete function needing 4.4s for 164 edge

comparisons, which is an execution time of 26.7ms

per edge comparison. This extrapolates to 7 minutes

for 16000 edge comparisons, resulting in 4.2% of the

original execution time.

Feasibility of Privacy Preserving Minutiae-Based Fingerprint Matching

903

(II) Crawl Step

Continuing the encryption approach of the enumerate

function, the aim of the implementation is to utilize

the resulting array of root pairs from the enumerate

function, which represents matching edges, to con-

struct the best possible spanning tree. Considering the

previous decision to use edge and minutia numbers

unencrypted, along with the utilization of the root ar-

ray, this enables an unencrypted computation of the

crawl function.

Since the function can be computed without en-

cryption, the new implementation closely resembles

the original implementation. The primary difference

lies in the collection and comparison of the surround-

ing edges. Instead of re-matching the collected probe

and candidate edges to each other, which would re-

quire encryption and increase the execution time, the

new implementation utilizes the root array as a look

up table to determine if the edges match and subse-

quently can be added to the spanning tree.

(III) Scoring Step

As previously mentioned, the scoring function com-

putes the match probability score of the probe and

candidate ﬁngerprint image. Similar to the crawl

function, the look-up table can be employed here as

well. Furthermore, certain operations that do not in-

volve sensitive data can be computed without encryp-

tion. Consequently, only a few comparison operations

need to be encrypted. As this part of the implementa-

tion has not been completed yet, no performance re-

sults can be presented. For all additional evaluations,

the unencrypted program was utilized.

3 PRELIMINARY EVALUATION

3.1 Setup

The software development and evaluation were con-

ducted using rather standard hardware, namely a Dell

Latitude 7490 notebook with an Intel i5-8350U CPU

running on 1.70GHz with 4 cores and 16GB of RAM.

The Python version 3.8.10 was used for the develop-

ment.

The ﬁngerprint databases used for the evalu-

ation of the ﬁngerprint matcher were created for

the FVC2000: Fingerprint Veriﬁcation Competition

(Maio et al., 2002) and can be accessed online. There

are four databases consisting of 80 ﬁngerprint im-

ages, each database collected by different means. The

databases 1 and 2 were collected by one optical and

one capacitive sensor; both were small-size and low-

cost sensors, no attention was paid to correct ﬁnger

centering and the sensor platens were not systemati-

cally cleaned. Database 3 was collected by a higher

quality optical sensor with the sensor platens getting

cleaned between images and database 4 consists of

synthetically generated ﬁngerprint images. The avail-

able databases include 80 images, consisting of 10 ﬁn-

gers with eight images each.

3.2 FingerCode Implementation

The algorithm for the feature vector extraction can be

executed locally, thus encryption with MPC is only

needed for the ﬁngerprint matching. As for all feature

vector based matchers the ﬁngerprint matching con-

sists of computing the euclidean distance between two

feature vectors representing the biometrics. To com-

pute the values in their encrypted form via Multiparty

Computation, we were able to use various MPyC

functions. The package provides heavily optimized

operations for matrices and vectors, ensuring efﬁcient

execution of these operations within the MPyC frame-

work. Our tests showed that by using the vector sub-

traction the average execution time for the subtraction

can be lowered by 75%, while using the Schur prod-

uct reduces the execution time for the multiplication

to an eighth.

This results in an execution time for an 1 : 1 ﬁnger-

print comparison with 3 parties of 45ms. Compared

to the time needed for the not encrypted FingerCode

match of 1µs this amounts to a slowdown by 45000

times by using MPyC.

While the execution time of 45ms would work

nicely for our envisioned scenario, the downside of

feature vector based matchers is their accuracy. For

the implemented matcher the feature extraction fails

for 60-94% of the ﬁngerprint images depending on

the used ﬁngerprint database. The main reasons are

(i) that the core is too far on the edge of the image,

such that the tessellated sectors around it are already

outside of the picture, hence the image cannot be ﬁl-

tered and the FingerCode not created and (ii) that the

quality of the ﬁngerprint images is too bad and the

core cannot be correctly identiﬁed.

This can be prevented by scanning ﬁngerprints

with greater precision and ensuring that the cores are

centered in the scan. However, even when taking

those ﬁngerprint images not into account, the EER of

the FingerCode matcher lies between 18% and 30%.

This accuracy of the algorithm is extremely poor and

does not fulﬁll any quality criteria in practical appli-

cations.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

904

3.3 SourceAFIS Benchmarks

By combining the locally executed feature extraction

implemented in Java with the three steps of ﬁngerprint

matching implemented and executed using MPyC, a

complete ﬁngerprint matching algorithm is obtained

based on the open-source project SourceAFIS (Va

zan,

2004). Each database contains 80 ﬁngerprint images

that are matched against each other, resulting in a total

of 6400 matching attempts per database.

With a FAIL rate of 2.5% and an EER of 7.9%

on average, the matcher achieved very good results

for an open-source project, especially compared to the

results of the FingerCode matcher, as shown in Figure

2. The FNMR could be lowered by decreasing the

threshold. However, the potential for improvement is

already severely limited, as the EER is at a threshold

of 2 or 4, depending on the database.

Figure 2: Comparison of Error Rates of minutiae-based

matcher SourceAFIS and feature vector-based matcher Fin-

gerCode to measure accuracy.

While there are no apparent weaknesses in the

functionality of the MPyC implementation, its pri-

mary disadvantage lies in the execution time. In the

original implementation, the matching process, ex-

cluding the feature extraction, requires approximately

45ms to execute one 1 : 1 matching. However, in the

case of the MPyC implementation, this process takes

approximately 7 minutes, with crawl and scoring tak-

ing 0.2s and the edge comparison the rest. Despite

achieving a signiﬁcant improvement compared to the

initial MPyC implementation with an execution time

of around 3 hours, the resulting time still exceeds

the requirements for the intended use-case. Thus, al-

though the execution time has been reduced, further

optimizations may be necessary to meet the desired

performance targets.

3.4 Estimation for MP-SPDZ

Realizing that the current implementation of

SourceAFIS with MPyC does not meet the re-

quirements for the intended application, the author

investigates alternative frameworks to potentially

improve execution time. In this pursuit of execution

time optimization for the ﬁngerprint matcher, the

MP-SPDZ framework is selected. MP-SPDZ (Keller,

2020) is a Multiparty Computation framework that

may offer performance enhancements over the

MPyC framework, which was utilized in the initial

implementation.

To be able to provide a meaningful comparison of

the two frameworks, a key component of the matcher

is implemented in MP-SPDZ. This operation is repre-

sentative of the computational complexity and perfor-

mance characteristics of the full matcher.

Through the extensive evaluation of the ﬁnger-

print matcher it was determined that the most time-

consuming part is the enumerate function trying to

ﬁnd all matching root pairs of two ﬁngerprint images.

For the MPC implementation the enumerate func-

tion was implemented as the comparison of all probe

edges to all candidate edges, generating a root array

that highlights the matching pairs. Generally, the full

comparison of two edges consists of six separate com-

parisons of the lower and upper bounds of the length

and the two angles, respectively. Considering that

the ﬁngerprint templates of the used databases con-

sist of 10 to 100 minutiae depending on their quality,

the algorithm comprises 50, 000 to 5, 000, 000 com-

parisons.

The MP-SPDZ framework includes various proto-

cols and settings. For comparison purposes, only dif-

ferent secret sharing schemes were chosen, all with

a semi-honest setting. The protocol rep-ﬁeld is on

the basis of replicated secret sharing, while atlas and

shamir are based on Shamir’s secret sharing. The re-

sults can be found in Table 1.

Table 1: Execution time depending on the number of edge

comparisons in MP-SPDZ.

comparisons rep-ﬁeld atlas shamir

10,000 0.06s 0.56s 0.31s

100,000 0.51s 5.21s 2.69s

1,000,000 6.5s 61.76s 38.65s

Comparing the tested protocols, the most efﬁcient

execution time is achieved utilizing replicated secret

sharing. When factoring in the time required for

the remainder of the matching algorithm, along with

some computational overhead, the execution time for

a 1:1 ﬁngerprint comparison remains under 7 seconds.

This represents a signiﬁcant improvement, being ap-

Feasibility of Privacy Preserving Minutiae-Based Fingerprint Matching

905

proximately 1/60th of the time required for the MPyC

implementation. Based on this estimation, it is rec-

ommended to utilize MP-SPDZ for future implemen-

tations and optimizations.

4 CONCLUSIONS

In our work we present the preliminary evaluation

of two privacy preserving ﬁngerprint matchers. The

ﬁrst is FingerCode, a matcher based on feature vector

comparison. As expected the matcher was simple to

implement with MPC and achieved a fast execution

time of 45ms per 1:1 ﬁngerprint comparison. How-

ever, the matcher showed poor accuracy results and is

thus not applicable for real-world deployment.

While researchers are actively exploring machine

learning-based FingerCode extraction and more ac-

curate results can be expected in the future, the ma-

jority of matchers currently favor minutiae-based ap-

proaches due to their superior accuracy. This is why

we focused mainly on the encryption of minutiae-

based ﬁngerprint matchers in our research.

The second matcher we implemented was

SourceAFIS, a minutiae-based ﬁngerprint matcher

with very good matching accuracy. Our prelimi-

nary evaluation estimated that we are not only able

to implement a working minutiae-based ﬁngerprint

matcher with MPC but also improve the execution

time from 3 hours to 7 seconds.

In the future we plan optimizations regarding par-

allelization and exploitation of techniques to speedup

the MPC implementation. We are also working on a

full implementation in MP-SPDZ to fully leverage the

potential of our optimizations. Finally, we are study-

ing the leakage of our trade-off in detail as well as

additional measures to further reduce it, e.g., by edge

and vertex permutations.

ACKNOWLEDGEMENTS

The work was partially funded by the Austrian Se-

curity Research Programme KIRAS of the Federal

Ministry of Finance via grant agreement no. 905287

(”PASSENGER”) and from the European Union’s

Horizon Europe Programme via grant agreement no.

101073821 (”SUNRISE”). Views and opinions ex-

pressed are however those of the author(s) only and

do not necessarily reﬂect those of the European Union

or the European Research Executive Agency. Neither

the European Union nor the granting authority can be

held responsible for them.

REFERENCES

Adnan, S., Ali, F., and Abdulmunem, A. A. (2020). Fa-

cial feature extraction for face recognition. In Jour-

nal of Physics: Conference Series, volume 1664, page

012050. IOP Publishing.

Barni, M., Bianchi, T., Catalano, D., et al. (2010). Privacy-

preserving ﬁngercode authentication. In Proceedings

of the 12th ACM workshop on Multimedia and secu-

rity, pages 231–240.

Blanton, M. and Gasti, P. (2011). Secure and efﬁcient proto-

cols for iris and ﬁngerprint identiﬁcation. In Computer

Security–ESORICS 2011: 16th European Symposium

on Research in Computer Security, Leuven, Belgium,

September 12-14, 2011. Proceedings 16, pages 190–

209. Springer.

Eerikson, H. (2020). Privacy preserving ﬁngerprint identi-

ﬁcation. Bachelor’s Thesis.

amas¸, D.-E., Marton, K., and Suciu, A. (2021). Assess-

ment of two privacy preserving authentication meth-

ods using secure multiparty computation based on se-

cret sharing. Symmetry, 13(5):894.

Jain, A., Prabhakar, S., Hong, L., and Pankanti, S. (1999).

Fingercode: a ﬁlterbank for ﬁngerprint representation

and matching. In Proceedings. 1999 IEEE Computer

Society Conference on Computer Vision and Pattern

Recognition, volume 2, pages 187–193.

Keller, M. (2020). Mp-spdz: A versatile framework for

multi-party computation. In Proceedings of the 2020

ACM SIGSAC conference on computer and communi-

cations security, pages 1575–1590.

Lor

unser, T. and Wohner, F. (2020). Performance compar-

ison of two generic mpc-frameworks with symmetric

ciphers. In ICETE (2), pages 587–594.

Lor

unser, T., Wohner, F., and Krenn, S. (2022). A veriﬁable

multiparty computation solver for the linear assign-

ment problem: And applications to air trafﬁc manage-

ment. In Proceedings of the 2022 on Cloud Comput-

ing Security Workshop, CCSW’22, page 41–51, New

York, NY, USA. Association for Computing Machin-

ery.

Maio, D., Maltoni, D., Cappelli, R., et al. (2002). Fvc2000:

Fingerprint veriﬁcation competition. IEEE transac-

tions on pattern analysis and machine intelligence,

24(3):402–412.

Schoenmakers, B. (2018). Mpyc secure multiparty compu-

tation in python. Last accessed 01-07-2023.

Shahandashti, S. F., Safavi-Naini, R., and Ogunbona, P.

(2012). Private ﬁngerprint matching. In Australasian

Conference on Information Security and Privacy,

pages 426–433. Springer.

Simoens, K., Tuyls, P., and Preneel, B. (2009). Privacy

weaknesses in biometric sketches. In 2009 30th IEEE

Symposium on Security and Privacy, pages 188–203.

Strobl, B. and Natali, M. (2022). Enhancing biometric data

security by design. ERCIM NEWS, 131:25–26.

zan, R. (2004). Sourceaﬁs ﬁngerprint matcher. Last ac-

cessed 09-11-2023.

ICISSP 2024 - 10th International Conference on Information Systems Security and Privacy

906
