Feather: Lightweight Container Alternatives for Deploying

Workloads in the Edge

Tom Goethals

, Maxim De Clercq

, Merlijn Sebrechts

, Filip De Turck

and Bruno Volckaert

Ghent University - imec, IDLab, Gent, Belgium

Keywords:

Edge Computing, Kubernetes, Containers, Microvm, Unikernels.

Abstract:

Recent years have seen the adoption of workload orchestration into the network edge. Cloud orchestrators

such as Kubernetes have been extended to edge computing, providing the virtual infrastructure to efﬁciently

manage containerized workloads across the edge-cloud continuum. However, cloud-based orchestrators are

resource intensive, sometimes occupying the bulk of resources of an edge device even when idle. While var-

ious Kubernetes-based solutions, such as K3s and KubeEdge, have been developed with a speciﬁc focus on

edge computing, they remain limited to container runtimes. This paper proposes a Kubernetes-compatible

solution for edge workload packaging, distribution, and execution, named Feather, which extends edge work-

loads beyond containers. Feather is based on Virtual Kubelets, superseding previous work from FLEDGE.

It is capable of operating in existing Kubernetes clusters, with minimal, optional additions to the Kubernetes

PodSpec to enable multi-runtime images and execution. Both Containerd and OSv unikernel backends are

implemented, and evaluations show that unikernel workloads can be executed highly efﬁciently, with a mem-

ory reduction of up to 20% for Java applications at the cost of up to 25% CPU power. Evaluations also show

that Feather itself is suitable for most modern edge devices, with the x86 version only requiring 58-62 MiB of

memory for the agent itself.

1 INTRODUCTION

Modern microservice architectures are shifting from

cloud-only to running in a cloud-edge continuum for

various reasons. For example, many applications ben-

eﬁt from local processing in terms of response time,

improving Quality of Experience (QoE) (Luo et al.,

2019). Additionally, processing data on or near the

edge devices where it is generated reduces network

load and can preserve privacy if implemented cor-

rectly (Sadique et al., 2020). Processing workloads

on edge devices also has the potential to better utilize

local supplies of green energy (Al-Naday et al., 2022).

Finally, an important enabler is that modern edge de-

vices have become powerful enough to run various

workloads dynamically on-demand.

In the cloud, developers commonly use orchestra-

tors such as Kubernetes

to deploy and manage appli-

https://orcid.org/0000-0002-1332-2290

https://orcid.org/0009-0009-1857-8664

https://orcid.org/0000-0002-4093-7338

https://orcid.org/0000-0003-4824-1199

https://orcid.org/0000-0003-0575-5894

Kubernetes: https://kubernetes.io/

cations on a uniform infrastructure independent of the

actual hardware. Edge computing, however, has tra-

ditionally used a different set of tools to deploy and

manage applications. This adds an additional barrier

for cloud application developers to venture into edge

computing. Therefore, bringing cloud orchestrators to

edge computing has the potential to improve the expe-

rience of transitioning from a cloud-only application

to a cloud-edge application.

Bringing cloud orchestrators to the edge is chal-

lenging, however, because of their resource overhead.

For example, Kubernetes agents have a signiﬁcant re-

source overhead, around 145MiB for the agent alone

and 300+MiB with all necessary components, poten-

tially using most of the memory on an edge device

even when idle (Goethals et al., 2020). Although re-

cent developments such as ioFog

, KubeEdge

and

FLEDGE (Goethals et al., 2020) provide alternative

orchestration options, most of them still present a

signiﬁcant overhead, and all of them are exclusively

based on containerized workloads. While contain-

ers are a highly performant, lightweight virtualization

Eclipse ioFog: https://iofog.org/

KubeEdge: https://kubeedge.io/

Goethals, T., De Clercq, M., Sebrechts, M., De Turck, F. and Volckaert, B.

Feather: Lightweight Container Alternatives for Deploying Workloads in the Edge.

DOI: 10.5220/0012536300003711

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 14th International Conference on Cloud Computing and Services Science (CLOSER 2024), pages 27-37

ISBN: 978-989-758-701-6; ISSN: 2184-5042

option, they may not always be the best solution for

any combination of workload and edge device. Other

virtualization options include micro Virtual Machines

(microVMs), which boast improved security and re-

source use compared to containers (Goethals et al.,

2022), or WebAssembly (Wasm) (Sebrechts et al.,

2022), which aims for microVM security and perfor-

mance without the necessity for a hypervisor. Exam-

ple use cases include a home automation edge gate-

way running privacy sensitive processing tasks in a

microVM, while automation rules and dashboards are

run in containers. Another use case involves ad-hoc

federation of networked resources in emergency sit-

uations, running mission critical tasks on possibly

untrusted nodes inside microVMs while support ser-

vices are run in containers.

This paper proposes a Kubernetes-compatible

solution for edge workload orchestration named

Feather. Based on the lightweight FLEDGE orches-

trator (Goethals et al., 2020), Feather extends its ca-

pabilities beyond containers to include microVMs.

As such, it allows developers to choose the right vir-

tualization option for their workloads, and allows re-

searchers to easily compare different virtualization

methods for edge computing. Additionally, Feather

uses relevant Open Container Initiative (OCI) stan-

dards, which are important for interoperability with

Kubernetes and Docker containers.

This paper also presents an end-to-end solution

for packaging, distributing and deploying workloads

in a runtime-agnostic manner, allowing developers to

use an almost identical deployment workﬂow for both

containers and microVMs that seamlessly integrates

with the Kubernetes ecosystem.

Concretely, the contributions of this paper are:

• Designing an extensible, Kubernetes-compatible

agent which allows for the deployment of non-

container workloads on edge devices

• Providing an OCI-compliant method for pack-

aging and distributing non-container workloads

through a container repository

• Illustrating the potential of multi-runtime work-

loads in a Kubernetes (edge) cluster

• Minimizing the resource overhead of edge orches-

tration, leaving the bulk of device resources for

edge computing

The rest of this paper is organized as follows: Sec-

tion 2 presents existing research related to the various

topics in this paper, from which research questions are

derived in Section 3. Section 4 introduces all the high

level architecture aspects. In Section 5, the evaluation

setup, scenarios and methodology are detailed, while

the results are presented and discussed in Section 6.

Topics for future work are listed in Section 7 and ﬁ-

nally, Section 8 draws high level conclusions from the

paper.

2 RELATED WORK

2.1 Virtualization

The properties and performance of container run-

times have been extensively examined in various stud-

ies (Wang et al., 2022; de Velp et al., 2020).

MicroVMs are a lightweight form of VM de-

signed to run individual workloads or processes.

There are several technologies that enable the cre-

ation of microVMs, among which unikernels are

a varied group with excellent security and perfor-

mance features (Kuenzer et al., 2021; Abeni, 2023).

Unikernels are a type of library operating system in

which a program, along with only the required sys-

tem libraries and system calls, is compiled into a

single kernel space executable embedded in a VM

image, thus minimizing image size and attack sur-

face. Furthermore, they can be roughly classiﬁed

into two types: POSIX-compatible (Portable Oper-

ating System Interface(Walli, 1995)) ones that fo-

cus on existing software, and those based on non-

POSIX system interfaces which sacriﬁce compatibil-

ity for smaller images and lower resource require-

ments. OSv(Kivity et al., 2014) in particular is

a POSIX-compatible unikernel platform with wide

compatibility for existing programs and programming

language runtimes. Although microVMs generally

support a wide variety of hypervisors for their ex-

ecution, QEMU(Bellard, 2005) with KVM (Kernel-

based Virtual Machine(Habib, 2008)) acceleration is

a widely supported option.

Both containers and microVMs are examples of

degrees of virtualization, where at least some degree

of isolation from the host system is established. Dif-

ferent classes of virtualization technologies, includ-

ing gVisor and Firecracker, have been compared and

benchmarked (Goethals et al., 2022), and their per-

formance examined at the kernel level (Anjali et al.,

2020).

The WebAssembly System Interface

(WASI) (M

etrey et al., 2022) is a new and

fundamentally different approach to sandboxing,

interposing itself between WebAssembly (Wasm)

programs and a host system (e.g. Linux kernel). Like

gVisor, it implements its own System Interface to

intercept program system calls, but it focuses on both

security and performance while being entirely device-

and system-agnostic. While still under development,

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

WASI covers a wide range of devices up to ESP32

microcontrollers (BytecodeAlliance, 2023), making

it suitable for the edge and IoT (Ray, 2023). WASI

can also be used to optimize container-oriented

architectures, e.g. Kubernetes controllers (Sebrechts

et al., 2022).

2.2 Orchestration

Several edge-oriented Kubernetes-based platforms

are currently available, for example KubeEdge and

Eclipse ioFog (

Cili

c et al., 2023). KubeEdge has

a memory overhead of only 70 MiB for its worker

nodes, although it is incompatible with default Kuber-

netes clusters. ioFog, another popular orchestration

platform for the edge, has a memory footprint of only

100 MiB on worker nodes, which is fairly low in com-

parison with other Kubernetes distributions. How-

ever, while these frameworks are aimed at edge com-

puting, they are limited to container workloads.

Some studies (Mavridis and Karatza, 2021) use

KubeVirt (KubeVirt, 2023) to deploy and evaluate

(micro)VM alternatives on Kubernetes clusters. How-

ever, while KubeVirt enables the deployment of virtu-

alized workloads, it also requires extensive interven-

tion in a Kubernetes cluster to work (e.g. custom re-

sources, daemonsets). Unlike KubeVirt, Feather is

aimed speciﬁcally at creating a multi-runtime agent

for edge computing, without the need to modify an

existing Kubernetes cluster in any way.

FLEDGE (Goethals et al., 2020) is a Kubernetes-

compatible edge agent based on Virtual Kubelets

and designed for minimal resource overhead, using

only around 50MiB of memory. A Virtual Kubelet is

essentially a proxy which poses as an actual kubelet

to the Kubernetes API, but allows any sort of under-

lying provider to interpret and execute the received

commands. However, despite a low-resource imple-

mentation with support for both Docker and contain-

erd, FLEDGE is limited to the use of containers.

Feather aims to extend the State of the Art by allow-

ing the OCI-compliant side-by-side orchestration of

various types of workload images (e.g. containers,

microVMs) on edge devices, without architectural or

operational changes to an existing Kubernetes cluster

or its control plane nodes.

Virtual Kubelet: an open source Kubernetes kubelet

implementation - https://github.com/virtual-kubelet/virtual-

kubelet

3 RESEARCH QUESTIONS

Considering the limitations of the state of the art, the

following research questions are stated for Feather:

1. RQ1. How can Kubernetes-compatible orchestra-

tors be extended to support pluggable backends,

including microVM workloads in the edge?

2. RQ2. How can edge microVM workloads be

seamlessly integrated into the regular cloud native

and Kubernetes ecosystem?

3. RQ3. What are the Feather overhead and perfor-

mance characteristics of microVM workloads in

the edge?

4 ARCHITECTURE

This section presents the solution architecture for both

the Kubernetes-side deployment of workloads, and

for runtime-agnostic workload packaging and distri-

bution. The code for Feather is made available on

Github

4.1 Deployments

Feather uses a Virtual Kubelet as a basis, receiv-

ing commands from Kubernetes through its interface.

Workload platforms (e.g. container, unikernel) are re-

ferred to as “backends”, which may be supported by

different runtimes (e.g. QEMU, VirtualBox), while

running workloads are “instances”.

A high-level overview of the deployment pipeline

from Kubernetes to Feather is shown in Fig. 1. On the

left side of the ﬁgure, deployments are entered into

Kubernetes through the API or dashboard. Feather

nodes are usually given a speciﬁc node label and taint

to avoid accidentally deploying heavier cloud work-

loads. While these can be disabled, deployments

should target Feather-managed devices speciﬁcally.

Next, the deployment is scheduled and sent to

Feather on an edge device, where it is picked up by

the Virtual Kubelet component. In order to separate

node and pod logic from atomic workloads (i.e. in-

dividual containers), Feather implements a Provider

which takes care of all pod-level logic, leaving the

workload-level (or instance) logic to backends (e.g.

containerd, OSv). This approach reduces the com-

plexity of additional backend implementations, and

allows mixing different runtimes in a single pod if

required, although individual backends may present

practical problems as shown in Section 4.2. The

https://github.com/idlab-discover/feather

Feather: Lightweight Container Alternatives for Deploying Workloads in the Edge

Figure 1: High-level overview of Feather components and the separation of virtualization options into backends. Full and

dashed red rectangles represent new and heavily modiﬁed components compared to FLEDGE, respectively.

Provider also interacts with a basic Resource Monitor

to report node status and determine if it has enough re-

sources to execute a deployment. For advanced mon-

itoring outside the default Kubernetes dashboard, a

Prometheus Golang exporter may be enabled in ad-

dition to default process metrics.

However, some pod-level information may be re-

quired to properly set up a workload, for example vol-

umes or pod networking information. To solve this,

the Provider extracts the relevant information from

the PodSpec (e.g. networking, volumes) on a per-

instance basis and embeds it into an extended Con-

tainer speciﬁcation indicated by Container+. For ex-

ample, if the pod is globally conﬁgured to use host

networking, the backend requires that information to

create its workloads under that condition. The ex-

tended Container speciﬁcation is then sent to the cor-

rect backend, which is responsible for pulling the cor-

rect image and managing its life-cycle.

4.2 Candidate Backends

At this point, the various backends require differ-

ent tools and kernel features, and manage instances

through different backends. This section describes the

backends currently implemented in Feather. Feather

is designed to be generic, supporting anything from

container runtimes to hypervisors and beyond. In or-

der to function as a sufﬁcient proof-of-concept of this

design, both containers and microVMs are supported,

through containerd and OSv respectively. For com-

patibility purposes, the backend design is inspired by

the OCI Runtime Spec

. This speciﬁcation describes

the conﬁguration, execution environment, and life cy-

OCI Runtime Speciﬁcation:

https://github.com/opencontainers/runtime-spec

cle of a container.

As containerd is a native container runtime

supported by Kubernetes by default, and because

FLEDGE already has a previous implementation for

it, creating a backend is self-evident. As shown in

Fig. 1, the containerd backend interacts with various

Feather tools to setup the required cgroups, names-

paces and container networking for a single container.

These in turn interact with the appropriate Linux sub-

systems, which for now is limited to cgroups v1, curb-

ing operating system options slightly. The image it-

self is started using the container runtime (contain-

erd), which may host any number of worker contain-

ers.

For microVMs, the unikernel platform OSv is

chosen for image creation, as it supports a wide array

of backends and devices, and has its own command-

line image creation and management tool Capstan.

Implementing a backend for OSv is less straightfor-

ward for several reasons. Firstly, instead of a con-

tainer runtime, the backend needs to communicate

with a hypervisor, in this case QEMU, which may

host any number of worker microVMs. Consequently,

the backend needs to extract a VM disk image from

the OCI Image Spec compliant image. The back-

end needs to determine which combination of param-

eters should be passed to the hypervisor to achieve the

same effect as they have on a container deployment.

Secondly, besides increased complexity, this can in-

troduce compatibility issues, for example for persis-

tent storage and mounts which have to be mounted

through virtio-fs drivers rather than a straightforward

shared location in the host ﬁlesystem. Due to virtio-

fs and OSv limitations, the current version of Feather

only supports read-only mounts of directories. While

Kubernetes ConﬁgMaps and Secrets may consist of a

single ﬁle, this is ﬁxed by Feather by putting them in a

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

Figure 2: Overview of the deployment sequence of a Feather workload, from an incoming deployment yaml to workload im-

age start. Full and dashed red rectangles represent new and heavily modiﬁed components compared to FLEDGE, respectively.

speciﬁc directory which is mounted into the image. A

custom C program is provided which can be inserted

into a Feather unikernel image, which scans for these

ConﬁgMaps and Secrets, and organizes them as re-

quired by the workload. Lastly, networking support

for unikernels in Feather is currently limited; while

unikernels are set up with a network interface which

is publicly reachable, and are assigned an IP address

from the same range as containers, sidecar services

are not currently possible for OSv workloads. Con-

sidering the current implementation, this section an-

swers RQ1.

4.3 Images

Packaging non-container images for backend-

agnostic storage is non-trivial. For example, OSv

images and other microVMs are packaged as raw

disk images with no additional information

. In

order to distribute these atypical “container” images

reliably and correctly, well-established container im-

age standards are used in combination with minimal

metadata.

The most straightforward solution is to store a disk

image as a layer in an OCI Image, which enables con-

ﬁguration similar to container images. In order to de-

termine the content type of an OCI Image Layer, the

OCI ImageConﬁg is extended, allowing Feather to se-

lect the correct backend for an image.

1. feather.backend: The backend that this image

was designed for.

OSv, a new operating system for the Cloud:

https://github.com/cloudius-systems/osv

2. feather.runtime (optional): The preferred run-

time to schedule this instance with. In the case of

virtual machines, this refers to the used hypervi-

sor.

Since containerd images are already OCI Images,

these ﬁelds are only required for the OSv backend.

Whenever the feather.backend ﬁeld is not present,

Feather can safely assume a container image. The

general process of pulling an image is shown in Fig.

2. A deployment yaml is sent to the edge device 1 ,

which is forwarded to the provider as a parsed De-

ployment 2 and split into separate Container+ de-

ployments forwarded to a suitable backend 3 . Due

to OCI compatibility, all image types can be pulled

from a single repository 4 , which returns an image

of the required type 5 . The backend then parses this

image and unpacks it, if required 6 . Depending on

the backend, the image is stored in either the local

containerd repository 7a , or the Capstan repository

7b. The backend sends a start command for the im-

age to the required runtime 8a & 8b, which uses the

image from the matching local repository.

Flint is developed alongside Feather to provide

multi-backend image management between online

and local repositories as a command-line tool. For

the OSv backend, it allows users to import images

from a local Capstan repository into OCI images. The

combination of optional extra Image ﬁelds and Flint

solves RQ2.

Feather: Lightweight Container Alternatives for Deploying Workloads in the Edge

5 EVALUATION SETUP

This section considers RQ3 by assessing the per-

formance of Feather and the implemented backends

through three different evaluation scenarios:

1. Baseline: Measures the resource consumption of

Feather itself, without any running workloads.

While some of the backends may have running

processes even without active workloads, they are

not yet loaded into Feather and no (container) net-

working is active.

2. Minimal: Measures the overhead of Feather per

workload container or unikernel by deploying an

idle workload to both backends. Speciﬁcally, this

scenario uses a Hello World application written

in C, which sleeps for the duration of the exper-

iment. This ensures that there is no work done,

but that it is still possible to verify if the appli-

cation has started successfully. This approach al-

lows measuring the exact overhead of deploying

a basic workload for both Feather and the back-

ends.

3. Application Benchmark: Determines the rela-

tive resource overheads and performance penal-

ties of both backends for a real-world application,

speciﬁcally a Minecraft (PaperMC) server run-

ning. Due to OSv compatibility issues, the Java

runtime is limited to v11.0, which limits PaperMC

to v1.16.4. However, for the purposes of this eval-

uation using an older version is acceptable.

Considering an edge device with 1 GiB of total mem-

ory, it is a reasonable choice to allocate a maximum

of 800 MiB for the Java application, leaving 200 MiB

for the operating system, Feather, and its backends.

Unlike the minimal application, this application can

be conﬁgured through a ConﬁgMap which contains

properties such as the world seed and default game

mode. A Minecraft game server is initialized with

a world seed, where different seeds lead to different

worlds to be generated. By keeping the seed con-

sistent between backends, a deterministic testing en-

vironment can be created. For this evaluation, the

Minecraft worlds are initialized with seed -11970185,

although others have been evaluated to rule out out-

liers. The evaluations in this scenario are performed

as follows:

a) Any previous deployment is deleted.

b) The server image is deployed on the worker node

using Kubernetes. The logs then state the startup

time of the server, and verify the conﬁguration of

the seed through the ConﬁgMap.

c) After 2 minutes, 4 clients join the server simulta-

neously. This veriﬁes the ability of the server to

handle simultaneous events, such as chunk gener-

ation, which stresses the CPU.

d) After 4 minutes, villager entities are spawned at

a rate of about 3 villagers per 10 in-game ticks.

On a fully responsive server running 20 in-game

ticks per second, this corresponds to a rate of 6

villagers per second.

For the evaluations, two physical nodes are set up

on the IDLab Virtual Wall

; a control plane node

running the Kubernetes control plane, and a worker

node running Feather and any required backends.

Both nodes are running Ubuntu 20.04.05 LTS, and

are equipped with two Intel E5520 CPUs, 12 GB of

RAM, and two Gigabit network interfaces.

Speciﬁc software versions used for the evaluations

are:

• containerd v1.6.18 to run container images

• qemu-system-x86 v4.2.1 to run unikernel images

• virtiofsd v1.6.0 for unikernel ﬁle system access

• Virtual Kubelet v1.9.0 as a basis for Feather

• Azul Zulu OpenJDK v11.0.19 for the application

benchmark

• PaperMC v1.10.2 as Minecraft server in the appli-

cation benchmark

In order to emulate an edge device with only

1 CPU and 1 GiB of RAM, Feather imposes re-

source limits on containerd and OSv using cgroups

and QEMU options respectively.

In all scenarios, Prometheus

node and process

exporters are used to gather relevant node and work-

load data. Note that while all relevant processes are

examined in order to gauge the full impact of Feather

operation, processes on the control plane node are not

included as there are no additional requirements apart

from normal Kubernetes operation. The node ex-

porter is run as a separate process outside Feather to

avoid inﬂuencing either Feather or workloads, while

the process exporter gathers workload, QEMU, and

containerd metrics. For the application benchmark,

further application metrics are gathered using the Pa-

perMC Minecraft exporter. For the Feather process

itself, the Prometheus Golang exporter is disabled and

metrics are gathered using ‘top‘ to avoid interference.

6 RESULTS

This section presents the evaluation results for all sce-

narios, presented as timeseries charts over 5 to 10

Virtual Wall — imec iLab.t documentation:

https://doc.ilabt.imec.be/ilabt/virtualwall/

https://prometheus.io/

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

minute ranges of the gathered metrics. Series are

color coded green for Feather and purple for backend

processes, with other colors reserved for scenario-

speciﬁc metrics. Importantly, all CPU percentages are

for a single core, not relative to the entire server.

6.1 Baseline

Fig. 3 shows the storage requirements of various com-

ponents and alternatives. The Feather binary used for

the experiment is a stripped, statically linked x86 64

binary. While Feather is around 13MiB larger than

FLEDGE, it is still 15MiB smaller than KubeEdge

(v1.13.0). The main size increase over FLEDGE is

caused by supporting more recent Kubernetes ver-

sions, and OSv images. As such, Feather offers high

ﬂexibility at low storage overhead. Workload back-

ends represent the bulk of storage requirements; con-

tainerd requires twice as much storage as Feather it-

self, while a default installation of QEMU requires

seven times as much. However, QEMU can be built

from source to reduce this storage overhead, exclud-

ing all features that are non-essential for the OSv

backend.

Feather

FLEDGE

KubeEdge

containerd

QEMU

100

200

300

400

Size (MiB)

Figure 3: Installed size of various components and alterna-

tives for edge workload orchestration.

Fig. 4 shows the CPU use of relevant processes

for the baseline scenario. Feather uses only around

0.3% of a single core when idle, mostly due to back-

end polling and Kubernetes status updates. As shown

in Fig. 5, Feather only uses around 58 MiB of mem-

ory after initialization. While this is signiﬁcantly

more than FLEDGE, which only requires around 46

MiB (Goethals et al., 2020), it is an acceptable in-

crease for offering multiple backends, and for newer

Kubernetes feature support due to using a higher ver-

0:00 1:00 2:00 3:00 4:00 5:00

CPU use (core %)

feather containerd

Figure 4: CPU usage of relevant processes in the baseline

scenario.

sion Virtual Kubelet. The containerd process has no

signiﬁcant CPU usage after initialization, and uses 55

MiB of memory on average.

0:00 1:00 2:00 3:00 4:00 5:00

Memory used (MiB)

feather

containerd

Figure 5: Resident memory usage of relevant processes in

the baseline scenario.

6.2 Minimal

Fig. 6 shows that Feather CPU use peaks for a few

seconds for both OSv and containerd workload cre-

ation. Although containers have a limited impact at

2.8%, creating a unikernel needs signiﬁcantly more

CPU at 6.8%. A higher setup cost is a natural con-

sequence of the superior isolation of unikernels com-

pared to containers, which requires setting up a much

more extensive virtual infrastructure. After container

creation CPU use drops back to around 0.4%. As

such, idle CPU use is no higher than in the baseline

scenario.

Both containerd and containerd-shim-runc-v2 use

an insigniﬁcant amount of processing resources, ex-

cept at container creation, when containerd spikes at

4.2% CPU. The QEMU hypervisor, however, uses

a signiﬁcant amount of processing power, idling at

Feather: Lightweight Container Alternatives for Deploying Workloads in the Edge

11.5% after a 21% spike at creation.

Memory use for this scenario is shown in Fig. 7.

Note that all processes are relatively stable in their

memory use; containerd itself seems to use around 5

MiB extra memory during container creation which

is later released, while in both cases Feather allocates

an extra 3 MiB at some point which is not directly

tied to workload creation. Comparing this to the base-

line scenario, the Feather process requires 3-4 MiB of

memory to instantiate and manage backends, putting

Feather itself at 60-62 MiB depending on the active

backend.

Comparing both backends, containerd uses 56.5

MiB of memory on average, while containerd-shim-

runc-v2 uses around 9.5 MiB, resulting in a total

memory overhead of 66 MiB on average. With

a memory consumption of 63.3 MiB on average,

QEMU performs slightly better than containerd and

containerd-shim-runc-v2 combined, although this ad-

vantage quickly disappears for multiple workloads as

containerd memory use is amortized over all contain-

ers.

Note that there are no metrics for virtiofsd in-

cluded in Fig. 6, as the minimal scenario does not

make use of any volume mounts.

0:00 1:00 2:00 3:00 4:00 5:00

CPU use (core %)

feather (ctd) feather (osv)

containerd (ctd) qemu-sys (osv)

shim-runc (ctd)

Figure 6: CPU usage of relevant processes in the minimal

scenario.

6.3 Application

Fig. 8 shows the performance of PaperMC in in-game

terms. The responsiveness of the server (expressed in

ticks per second, or TPS) drops signiﬁcantly after 2

minutes as clients join the server, leveling back out

as the server stops generating chunks. Then, it drops

steadily after 4 minutes as villagers are spawned. The

rate at which villagers are spawned also decreases in

time, which notes its relation to TPS as mentioned in

Section 5. Throughout the chunk generation phase,

0:00 1:00 2:00 3:00 4:00 5:00

Memory use (MiB)

feather (ctd) feather (osv)

containerd (ctd) qemu-sys (osv)

shim-runc (ctd)

Figure 7: Memory usage of relevant processes in the mini-

mal scenario.

OSv performance consistently changes incrementally

faster than containerd is affected, although in magni-

tude both are equally affected. This may indicate that

unikernels are signiﬁcantly more effective at chunk

generation.

0:00 2:00 4:00 6:00 8:00 10:00

Ticks per second

0.0 k

0.4 k

0.8 k

1.2 k

1.6 k

2.0 k

Number of villagers

TPS (ctd) TPS (osv)

Villagers (ctd) Villagers (osv)

Figure 8: Ticks per second and number of villagers in the

application scenario.

Additionally, TPS starts to drop slightly faster for

the OSv instance than for the containerd instance, in-

dicating that the OSv may be less efﬁcient at the type

of calculation involving villagers. Finally, the logs

show that the containerd instance starts in 38.713s,

while the OSv instance only takes 37.199s to start,

or around 4% faster. Fig. 9 shows that QEMU uses

more than the 1 CPU limit set by the deployment de-

spite producing a lower TPS. Taking into account the

higher “idle” use at 2:00 and 3:00, and the CPU re-

sults from Fig. 6, QEMU appears to have a signiﬁ-

cant, structural CPU overhead, but the application it-

self is limited to 1 CPU. Comparing Fig. 8 at con-

stant 1200 villagers, OSv on QEMU runs at a 28%

lower TPS compared to the container instance, despite

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

a 30% CPU overhead.

Fig. 9 shows that OSv on QEMU uses signif-

icantly less memory than its container counterpart

throughout the evaluation. After spawning all vil-

lagers, QEMU uses only 661 MiB of RAM, sig-

niﬁcantly less than the container Java instance at

820 MiB. Note that spawning villagers, and thus the

slightly different population of both instances, does

not seem to affect memory use signiﬁcantly. Look-

ing at JVM statistics, Fig. 11 shows that OSv garbage

collection is more efﬁcient and stable than containerd,

averaging 0,83% ± 1,11% vs 1,68% ± 2,16% CPU.

Similarly, Fig. 12 shows that the JVM on OSv al-

locates 20-40% less memory than when running in a

container, and uses the allocated memory more efﬁ-

ciently. This result is expected, as OSv claims that

it is able to expose speciﬁc hardware features to the

JVM because it is running in the same address space

as the kernel. This allows the JVM to manage mem-

ory more efﬁciently, resulting in fewer allocations and

time spent on garbage collection.

0:00 2:00 4:00 6:00 8:00 10:00

100

125

CPU use (core %)

feather (ctd) feather (osv)

containerd (ctd) qemu-sys (osv)

shim-runc (ctd) java (ctd)

Figure 9: CPU usage of relevant processes in the application

scenario.

6.4 Analysis

The evaluation is performed for a simulated edge

device with 1 CPU and 1 GiB of memory. Both

the minimal and application scenarios indicate that

QEMU has some CPU overhead independent of the

actual workload, greatly impacting its potential for

edge devices. While the overhead may be managed

by QEMU itself through cgroups, overall workload

performance would suffer as a result. However, some

types of workloads (e.g. chunk generation, or REST

services (Goethals et al., 2022)) are shown to be more

efﬁcient with OSv on QEMU despite this overhead.

Additionally, different hypervisors may produce bet-

ter results.

0:00 2:00 4:00 6:00 8:00 10:00

200

400

600

800

Memory use (MiB)

feather (ctd) feather (osv)

containerd (ctd) qemu-sys (osv)

shim-runc (ctd) java (ctd)

Figure 10: Memory usage of relevant processes in the ap-

plication scenario.

0:00 2:00 4:00 6:00 8:00 10:00

2.5

7.5

12.5

CPU use (core %)

G1 Young (ctd) G1 Young (osv)

G1 Old (ctd) G1 Old (osv)

Figure 11: CPU time spent on garbage collection by the

JVM in the application scenario.

In terms of memory, QEMU far outperforms the

containerized Java application; the OSv application

instance requires 20% less memory than the contain-

erd instance. Generally superior memory manage-

ment is also clearly visible in the increased stability

of garbage collection and memory management of the

JVM. As unikernels have a base memory overhead

of around 50 MiB compared to container instances,

the advantage of using a unikernel increases with the

memory requirements of its workload.

Finally, the evaluation does not cover ARM-based

edge devices. However, OSv is shown to perform

similarly on a Raspberry Pi 4 (Goethals et al., 2022),

although slower in absolute terms.

7 FUTURE WORK

In Kubernetes environments, data is generally stored

in PersistentVolumes, however, Feather has no sup-

Feather: Lightweight Container Alternatives for Deploying Workloads in the Edge

0:00 2:00 4:00 6:00 8:00 10:00

128

192

256

JVM Memory (MiB)

Alloc (ctd) Alloc (osv)

Used (ctd) Used (osv)

Figure 12: Used and allocated JVM memory statistics in the

application scenario.

port for PersistentVolumes at this point, which is a

limitation of using a Virtual Kubelet.

Additionally, individual ﬁles cannot be mounted,

and the virtio-fs driver provided by the OSv kernel

only supports read-only mounts. As such, the OSv

backend can not currently bind mounts for persis-

tent storage. Other options supported by OSv in-

clude NFS and ZFS, but as Kubernetes only supports

NFS ﬁlesystems as a VolumeSource, future work will

likely focus on this option to store ﬁles persistently.

Another area of improvement is container net-

working, as OSv unikernels are not currently inte-

grated into the container network. However, they do

have ﬂexible networking capabilities, and Feather al-

ready integrates other initialization programs for Ku-

bernetes features into unikernels (e.g. ConﬁgMaps,

storage, etc), making full network integration a log-

ical next step. The two most signiﬁcant steps for

future work are assigning a suitable container net-

work IP address, which is trivial with initialization

programs, and ensuring localhost availability between

workloads in the same Pod, likely through eBPF pro-

grams.

Feather can be further extended by developing

backends for other technologies, such as Wasm, Kata

Containers, Firecracker, Unikraft. Some of these are

image creation tools, while others are runtimes or may

be designed with both image creation and runtime

tools. As Feather allows deployments to distinguish

between type of workload (i.e. container, OSv) and

actual runtime (e.g. containerd, QEMU), future work

will focus on both providing additional workload im-

age formats and potential runtimes.

8 CONCLUSION

Feather provides a solution for extending the Kuber-

netes ecosystem in the edge with non-container alter-

natives such as unikernels, which can reduce resource

requirements for certain use cases.

Building on previous work from FLEDGE,

Feather leverages existing standards such as the OCI

Speciﬁcations and the Kubernetes ecosystem, ensur-

ing that the proposed solution is seamlessly interop-

erable with existing infrastructure, requiring minimal

effort by developers to leverage the capabilities of

Feather.

Two backends, containerd and OSv, are imple-

mented and evaluated in three different scenarios,

showing the relative strengths and weaknesses of

each backend for speciﬁc computational tasks. While

unikernel workloads on QEMU tend to have a sig-

niﬁcant CPU overhead compared to containers, even

when idle, their memory use is up to 20% lower in

high load scenarios.

This work opens up possibilities for further re-

search and development, including research towards

additional lightweight alternatives to containerized

workloads in the edge.

In conclusion, extending Kubernetes workloads

to cover multiple backends shows that containers are

not always the ideal choice, and other backends can

signiﬁcantly improve performance in several cases.

However, automatically determining the ideal choice

of runtime, when implemented, remains future work.

REFERENCES

Abeni, L. (2023). Real-time unikernels: A ﬁrst look. In

Lecture Notes in Computer Science, pages 121–133.

Springer Nature Switzerland.

Al-Naday, M., Goethals, T., and Volckaert, B. (2022).

Intent-based decentralized orchestration for green

energy-aware provisioning of fog-native workﬂows.

In 2022 18th International Conference on Network

and Service Management (CNSM). IEEE.

Anjali, Caraza-Harter, T., and Swift, M. M. (2020). Blend-

ing containers and virtual machines. In Proceedings of

the 16th ACM SIGPLAN/SIGOPS International Con-

ference on Virtual Execution Environments. ACM.

Bellard, F. (2005). Qemu, a fast and portable dynamic

translator. In USENIX annual technical conference,

FREENIX Track, volume 41, page 46. Califor-nia,

USA.

BytecodeAlliance (2023). Wasm micro runtime - build

iwasm.

Cili

c, I., Krivi

c, P.,

Zarko, I. P., and Ku

sek, M. (2023).

Performance evaluation of container orchestration

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

tools in edge computing environments. Sensors,

23(8):4008.

de Velp, G. E., Rivi

ere, E., and Sadre, R. (2020). Under-

standing the performance of container execution en-

vironments. In Proceedings of the 2020 6th Interna-

tional Workshop on Container Technologies and Con-

tainer Clouds. ACM.

Goethals, T., Sebrechts, M., Al-Naday, M., Volckaert, B.,

and Turck, F. D. (2022). A functional and perfor-

mance benchmark of lightweight virtualization plat-

forms for edge computing. In 2022 IEEE Interna-

tional Conference on Edge Computing and Commu-

nications (EDGE). IEEE.

Goethals, T., Turck, F. D., and Volckaert, B. (2020). Extend-

ing kubernetes clusters to low-resource edge devices

using virtual kubelets. IEEE Transactions on Cloud

Computing.

Habib, I. (2008). Virtualization with kvm. Linux Journal,

2008(166):8.

Kivity, A., Laor, D., Costa, G., Enberg, P., Har’El,

N., Marti, D., and Zolotarov, V. (2014).

{OSv—Optimizing} the operating system for

virtual machines. In 2014 usenix annual technical

conference (usenix atc 14), pages 61–72.

KubeVirt (2023). Building a virtualization api for kuber-

netes.

Kuenzer, S., B

adoiu, V.-A., Lefeuvre, H., Santhanam, S.,

Jung, A., Gain, G., Soldani, C., Lupu, C., Teodorescu,

S¸., R

aducanu, C., Banu, C., Mathy, L., Deaconescu,

R., Raiciu, C., and Huici, F. (2021). Unikraft. In

Proceedings of the Sixteenth European Conference on

Computer Systems. ACM.

Luo, J., Deng, X., Zhang, H., and Qi, H. (2019). Qoe-driven

computation ofﬂoading for edge computing. Journal

of Systems Architecture, 97:34–39.

Mavridis, I. and Karatza, H. (2021). Orchestrated sand-

boxed containers, unikernels, and virtual machines for

isolation-enhanced multitenant workloads and server-

less computing in cloud. Concurrency and Computa-

tion: Practice and Experience, 35(11).

etrey, J., Pasin, M., Felber, P., and Schiavoni, V. (2022).

WebAssembly as a common layer for the cloud-edge

continuum. In Proceedings of the 2nd Workshop on

Flexible Resource and Application Management on

the Edge. ACM.

Ray, P. P. (2023). An overview of webassembly for iot:

Background, tools, state-of-the-art, challenges, and

future directions. Future Internet, 15(8).

Sadique, K. M., Rahmani, R., and Johannesson, P. (2020).

Enhancing data privacy in the internet of things

(IoT) using edge computing. In Communications in

Computer and Information Science, pages 231–243.

Springer International Publishing.

Sebrechts, M., Ramlot, T., Borny, S., Goethals, T., Volck-

aert, B., and Turck, F. D. (2022). Adapting kubernetes

controllers to the edge: on-demand control planes us-

ing wasm and WASI. In 2022 IEEE 11th International

Conference on Cloud Networking (CloudNet). IEEE.

Walli, S. R. (1995). The posix family of standards. Stan-

dardView, 3(1):11–17.

Wang, X., Du, J., and Liu, H. (2022). Performance and

isolation analysis of RunC, gVisor and kata containers

runtimes. Cluster Computing, 25(2):1497–1513.

Feather: Lightweight Container Alternatives for Deploying Workloads in the Edge
