A Systematic Mapping Study on Techniques for Generating Test Cases

from Requirements

Alessandro Rodrigues, J

essyka Vilela

and Carla Silva

Centro de Inform

atica, Universidade Federal de Pernambuco (UFPE), Av. Jornalista An

ıbal Fernandes,

s/n – Cidade Universit

aria, Recife-PE, Brazil

Keywords:

Systematic Mapping Study, Test Cases, Requirements, Generation.

Abstract:

Context: Software testing can be costly for organizations. Techniques and tools that deal with the automatic

generation of test cases provide a way to reduce the efforts employed and the time-to-market, in addition

to increasing the quality of the software. Objective: This work aims to investigate the literature regarding

techniques used to generate test cases from requirements automatically. Method: We performed a System-

atic Mapping Study (SMS) using the Snowballing technique to investigate these techniques, the information

presented in the test plan/case, the languages used to specify the requirements, and ﬁnally, the steps proposed

by the techniques. Results: techniques such as Model-based testing (MBT) and Natural Language Process-

ing (NLP) are the most used, mainly based on requirements speciﬁed through Natural Language that can be

structured or not, as well as UML (Uniﬁed Modeling Language) diagrams. We also extracted and presented a

series of languages and tools developed, and some are under development that perform this generation.

1 INTRODUCTION

Software permeates the various spheres of the world,

which creates a dependence on the proper functioning

of these utilities in our society. Bank transactions, air

travel, and automatic radiation doses are just a few

examples of critical software in which failures and

wrong software behavior can be disastrous. Thus, it

is important to have ways to ensure the correct quality

and functioning in developing a program.

Singhs and Singhs (2012) deﬁne software testing

as “a process, or a series of processes designed to

make sure computer code does what it was designed

to do and that it does not do anything unintended”

(Singh and Singh, 2012). Testing software does not

mean there is no defect in its execution, but the con-

trolled execution that test techniques provide aims to

expose as many failures as possible with the minimum

of resources invested, whether computational or hu-

man (Neto and Claudio, 2007).

Studies suggest that 50% of the time, cost, and ef-

fort of the software development process are spent on

Software Testing (Hooda and Chhillar, 2014), which

makes this task considered expensive for organiza-

https://orcid.org/0000-0002-5541-5188

https://orcid.org/0000-0002-0597-3851

tions. Using automatic test generation techniques di-

rects the organization to improve quality, reduce re-

work, saving resources and also a signiﬁcant amount

of money (Fewster and Graham, 1999). In this con-

text, automatic software testing tools are appropriate

due to improved time-to-market and accuracy.

This work investigates the current state of tech-

niques developed to generate test cases from require-

ments. We conducted a Systematic Mapping Study

(SMS) (Kitchenham and Charters, 2007) using the

snowballing technique (Wohlin, 2014) to ﬁnd relevant

studies to understand how this process has been con-

ducted. We collected results from 41 articles directly

related to the topic. We hope the results exposed here

will bring insights to the evolution of automatic test-

ing tools from requirements, such as Smartest.

This paper is organized as follows: Section 2

presents the background and related work. Section

3 presents the research methodology. The results and

the analysis related to our research questions are pre-

sented in Section 4. Threats to validity are presented

in Section 5. Finally, we present our conclusions and

future works in Section 6.

Rodrigues, A., Vilela, J. and Silva, C.

A Systematic Mapping Study on Techniques for Generating Test Cases from Requirements.

DOI: 10.5220/0012551900003705

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 9th International Conference on Internet of Things, Big Data and Security (IoTBDS 2024), pages 141-148

ISBN: 978-989-758-699-6; ISSN: 2184-4976

141

2 BACKGROUND AND RELATED

WORK

This section introduces a basis for understanding this

work. Initially, we describe test case generation,

as well as some common techniques used in the

automatic generation of test cases, such as model-

based testing (MBT) and natural language processing

(NLP). Then, we present the related work.

2.1 Test Case Generation

A test case describes a particular condition to be

tested and comprises a set of test inputs, execution

conditions, and expected results developed for a spe-

ciﬁc objective (Craig and Jaskiel, 2002). These cases

are elaborated from artifacts such as speciﬁcations,

design, and implementations (Shanthi and Kumar,

2011) and are used to verify if the system developed

corresponds to the requirements deﬁned, contributing

to project success and customer satisfaction.

The generation of test cases can be performed

manually, automatically, or semi-automatically, the

latter being preferable to save time and costs during

the test cycle (Mustafa et al., 2021). It is common

for this generation to occur based on requirements.

In this case, the tests are derived from the require-

ments without considering the internal structure of the

implementation, which may be functional and non-

functional requirements (Vaysburg et al., 2002).

To ﬁnd as many failures as possible, tests must be

conducted systematically, and test cases must be de-

signed using disciplined techniques. Some of these

techniques used to generate test cases from require-

ments automatically are:

• Model-Based Testing (MBT): In this technique,

the automatic generation of test artifacts is based

on information extracted from the software mod-

els (El-Far and Whittaker, 2002), which include in

their speciﬁcation the characteristics of the soft-

ware that will be tested.

• Natural Language Processing (NLP): it is con-

cerned with giving computers the ability to under-

stand text and spoken words in the same way as

humans by combining computational linguistics

- based on human language rules - with statisti-

cal, machine learning, and deep learning models

(IBM, 2023).

2.2 Related Work

The generation of tests cases or test plan from require-

ments speciﬁcations has been studied in some works.

Tahat et al. (Tahat et al., 2001) presented a new

test generation-based approach that accepts individual

requirements expressed in Speciﬁcation Description

Language (SDL) and textual formats automating the

creation of system models through SDL requirements.

Nebut et al.(Nebut et al., 2004) provided a method,

formal model and a prototype tool to automatically

generate speciﬁc functional and robust test cases for a

product from the requirements of a product line. This

technique, in this study, is associated with a slight for-

malism to express the product family, in a declarative

but unambiguous manner, the mutual facilities be-

tween requirements, in terms of pre/post conditions.

unior and Silva (de Santiago J

unior and da Silva,

2017) introduce a translation method called HiMoST,

which generates software test cases through Model

Checking. It starts with Harel’s Statecharts for be-

havioral modeling and translates them into a gen-

eral structure based on NuSMV language. CTL

properties are formalized using speciﬁcation patterns

and a Combinatorial Interaction Testing algorithm.

A cost-effectiveness evaluation comparing four pat-

terns/pattern scopes revealed that the Precedence

Chain pattern with Global scope performed the best.

Agile practices has also been investigated in

the context of software testing (Coutinho et al.,

2022)(Fazzolino et al., 2018). The objective of

Coutinho, Andrade e Machado (Coutinho et al., 2022)

was to understand how Requirements Engineering

(RE) and Software Testing (ST) activities are per-

formed in agile teams and their contribution to soft-

ware quality. A survey was conducted with 72 soft-

ware industry professionals experienced in RE and

ST. The ﬁndings revealed that Agile RE and Agile

ST activities still need improvement in coordinated

implementation in projects. There were both similar-

ities and differences between academic research and

industry practices. Agile practices, speciﬁc to RE and

ST, as well as other practices related to processes, ap-

proaches, and software development, were used in a

complementary manner.

Fazzolino et al. (Fazzolino et al., 2018) was to

test two enterprise systems, SISBOL and SISDOT,

from the Brazilian Army, using different approaches

and tools. The challenges in testing enterprise sys-

tems include considering user requirements, business

rules, user interaction, legacy system integration, and

database access. Test engineers face conﬂicting de-

cisions regarding test levels and the use of mock ob-

jects. The study found that using executable speciﬁca-

tions, as recommended in Behavior Driven Develop-

ment, was valid for test-ﬁrst scenarios and system re-

quirements validation. Additionally, it helped identify

new execution paths even after the source code had

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

142

been implemented, suggesting the adoption of BDD

approach in later stages of development.

The study by Mustafa et al. (Mustafa et al., 2021)

resembles ours by presenting an SRM on generation

of test cases based on requirements from 2000 to 2018

(Mustafa et al., 2021). The study was carried out to

acquire areas of knowledge about requirements-based

test case generation and identify future research. As a

result, the review showed that 53% of journal papers,

42% of conference papers and 5% of book chapters

address requirements-based tests.

Additionally, Faroq and Tahreem (Farooq and

Tahreem, 2022) conducted a systematic literature re-

view (SLR) to evaluate the approaches and techniques

that are used for automated test cases using user re-

quirements and stories and ﬁnd the best that is not just

friendly but also useful for minimizing the Software

cost and human effort . In their work, the taxonomy

was also presented based on the generation of test

cases with requirements-based techniques and tools.

As for the last two works (Mustafa et al., 2021)

(Farooq and Tahreem, 2022), although they also per-

formed a SLR on test case generation, they present

some differences when compared to ours. The study

by Mustafa et al. (Mustafa et al., 2021) also focuses

on identifying existing challenges in generating test

cases from requirements, in addition to presenting

how the transformation of requirements from natu-

ral language to the formal model occurs. However,

our research questions are more detailed, as well as

the search string we used. Also, the most recent pa-

pers they selected were published in 2018. Likewise,

Farooq and Tahreem (Farooq and Tahreem, 2022)

focused on UML based approaches published until

2021 and in discovering challenges regarding these

approaches. Our scope is a bit larger than theirs.

3 RESEARCH METHODOLOGY

The research method followed for this work is a Sys-

tematic Mapping Study (Galv

ao and Pereira, 2014).

To conduct the SMS and to answer our research ques-

tions, presented in Table 1, we chose the Snowballing

technique, which refers to the procedure in which,

starting from an initial set of papers, a list of paper

references (backward) or paper citations (forward) are

used to identify additional papers (Wohlin, 2014).

The search string used in this ﬁrst step derives

from the topic of our interest. This string was also

formed through the logical connectors AND, for ag-

gregation of keywords and OR for inclusion of the re-

spective synonyms (Kitchenham and Charters, 2007).

As a result, we get the following search string:

Table 1: Research questions.

ID Research Question Motivation

RQ1 What techniques are used to

create a test plan/case from

requirements?

Know the possible techniques

in the area.

RQ1.1 What information is present

in the test plan/case?

Learn what information is most

used in test cases.

RQ1.2 Which tool supports the gen-

eration of test plans/cases

from requirements?

Get to know the existing tools

and see the common points be-

tween them.

RQ1.3 How are requirements spec-

iﬁed?

See how the requirements are

deﬁned.

RQ1.4 Are requirements rep-

resented graphically or

textually?

Know which approaches are the

most used to represent the re-

quirements.

RQ1.5 How are test cases generated

from requirements?

Knowing how to apply the cre-

ation of test cases, having as a

starting point the requirements.

(”requirement”) AND (”software testing” OR

”test case” OR ”test plan”) AND (”aligning” OR

”derivation” OR ”integration” OR “generation”)

AND (“method” OR “approach” OR “technique”

OR “methodology” OR “tool”)

By applying our search string, in December 2022,

in the IEEE Xplore and ACM digital libraries, we se-

lected the studies S1 to S5 considering their adher-

ence to the theme, having a good number of refer-

ences and citations, as listed in Table 2, with differ-

ences in the applicability of the techniques of auto-

matic test cases generation from requirements, with

different authors and year of publication, so that we

have greater diversity.

A subsequent step was the choice of a paper,

among the ﬁve selected, to start backward and for-

ward snowballing. As the work S1 is appropriate

to the theme, besides having many referenced papers

and being one of the most cited, we decided to deﬁne

it as the initial paper.

Table 2: Details of selected papers.

Work Duplicate

authors?

Year # of ref # of ci-

tations

Work 1 S1 No 2015 37 44

Work 2 S2 No 2020 85 9

Work 3 S3 No 2011 24 8

Work 4 S4 No 2003 6 46

Work 5 S5 No 2017 33 19

Once we had selected the work, we started the

snowballing process. We applied the inclusion and

exclusion criteria, which are used to reduce the prob-

ability of bias and select studies capable of answer-

ing the research questions (Kitchenham and Charters,

2007). The criteria adopted in this work were:

• Inclusion criteria: Primary studies; Research and

papers from conferences and journals; Studies

A Systematic Mapping Study on Techniques for Generating Test Cases from Requirements

143

from 2003 onwards; Studies reporting approaches

to test plan/case creation; Studies that report ap-

proaches in creating an automated test plan;

• Exclusion criteria: Short Papers (¡ three pages);

Articles not in English or Portuguese; Secondary

studies; Duplicate studies; Redundant work by the

same author; Studies whose focus is not on creat-

ing test cases; Studies irrelevant to the research,

taking into account the research questions shown

in Table 1.

We provide all references and citations in sup-

plementary material: https://doi.org/10.5281/zenodo.

10724942.After this step, we had 316 works in total.

On the other hand, when applying the initial ﬁlter, 130

was subtracted from the total. In the supplementary

material, an interested reader may ﬁnd a ﬁgure depict-

ing the number of papers excluded by criteria versus

which paper it was derived from.

We analyzed the title and abstract in each iteration,

considering the inclusion and exclusion criteria. 112

works were excluded from this stage. Although they

are mostly related to generating test cases, they do

not adequately ﬁt the topic of this SMS. For example,

some of them dealt with later stages of test case gen-

eration. In the supplementary material, an interested

reader may ﬁnd a ﬁgure depicting the distribution of

these exclusions by source work.

Finally, as we noticed that there were still more

than 70 papers left, we also read the paper’s introduc-

tion and conclusion sections. We excluded another 32

studies according to the aforementioned inclusion and

exclusion criteria. Then, we had a total of 41 papers

since only 1 paper was excluded from the full read-

ing. We assigned the code S# for each selected paper

where S means selected and # the number of the pa-

per. The selected papers are in Table 3.

4 RESULTS AND ANALYSIS

Regarding the distribution of the selected papers by

digital libraries where they were published, IEEE (17

papers), ACM (10 papers) and Springer (9 papers) are

the most common. In the next sections, we present the

results for each research question.

4.1 RQ1: What Techniques are Used to

Create a Test Plan/Case from

Requirements?

In Table 4, the 1st column contains the technique or

approach used, and the 2nd column presents the pa-

pers that mention it as a technique used in the test

Table 3: List of selected papers.

ID Reference

S1 (Yue et al., 2015)

S2 (Liu and Nakajima, 2020)

S3 (Giannakopoulou et al., 2011b)

S4 (Nebut et al., 2003)

S5 (Ahsan et al., 2017)

S6 (Ali and Hemmati, 2014)

S7 (Ali et al., 2010)

S8 (Barros et al., 2011)

S9 (Hametner et al., 2012)

S10 (Hesari et al., 2013)

S11 (Wang et al., 2015)

S12 (Zhang et al., 2014)

S13 (Bernardino et al., 2017)

S14 (Wang et al., 2020)

S15 (Kriebel et al., 2018)

S16 (Elghondakly et al., 2015)

S17 (Gupta and Mahapatra, 2021)

S18 (Gr

opler et al., 2021)

S19 (Zhang et al., 2018)

S20 (Santos et al., 2019)

S21 (Mustafa et al., 2017)

S22 (Jorge et al., 2018)

S23 (Arruda et al., 2020)

S24 (Liu and Nakajima, 2010)

S25 (Zhang and Liu, 2013)

S26 (Legeard et al., 2004)

S27 (Bouquet et al., 2006)

S28 (Giannakopoulou et al., 2011a)

S29 (Gligoric et al., 2010)

S30 (Pickin et al., 2007)

S31 (Aniculaesei et al., 2019)

S32 (Vani et al., 2015)

S33 (Reales et al., 2012)

S34 (Mateo et al., 2009)

S35 (Lamancha et al., 2010)

S36 (Verma and Beg, 2013)

S37 (Dwarakanath and Sengupta, 2012)

S38 (Wang et al., 2015)

S39 (Malekzadeh and Ainon, 2010)

S40 (Riebisch and Hubner, 2005)

S41 (Carvalho et al., 2013)

generation plan. This data was extracted from the ex-

plicit mention by the authors. Below, we show some

quotes that conﬁrm the use of these techniques.

“[...] ‘Vibration-Method’ or simply ‘V-Method’,

for automatic generation of test cases and test oracle

from model-based formal speciﬁcations [...].” S2

“[...] automated framework for model-driven test-

ing that can be applied in MDE and SPL [...].” S39

“[...] uses text mining and symbolic execution for

test case generation.” S20

MBT is the most used technique in the papers with

a total of 10 citations. It is related to Software Product

Line. Some of them were derived from a paper S4 of

our seed set, which may explain such presence. We

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

144

Table 4: Techniques used to create a test plan/case from

requirements.

Technique/Approach #citations

MBT (Model-Based Testing) 10

NLP (Natural Language Processing) 7

UMTG (Use Case Maps-based Test Generation) 4

Symbolic Execution 3

RTCM (Requirements Traceability for Change Manage-

ment), Synthesis, RUCM (Rational Uniﬁed Process Use Case

Model)

2 each

Model Checking 2

V-method, Keyword-driven, Text-Mining, Speciﬁcation-

based Test Case Generation Process,MBTCC (Model-Based

Test Case Classiﬁcation, TCG (Test Case Generation,

SOFL (Software Functional Language), BZ-TT, Algorithms,

Reuse of test, CEG (Constraint-Driven Exploratory Test-

ing),Transformation algorithms, Metamodeling

1 each

also have that some of the aforementioned techniques

make use of another technique presented in Table 4.

These are the cases of Text Mining and RTCM that

use NLP. Algorithms are explicitly mentioned in S36,

but it is expected in others, mainly those that propose

some tool. In addition, we have works S20 S38 that

mention more than one technique.

4.1.1 RQ1.1: What Information is Present in the

Test Plan/Case?

To answer RQ 1.1 from the extraction of data stored

in the online spreadsheet, we built a word cloud with

the purpose of showing the most used ﬁelds of the re-

quirements. This information was extracted from the

ﬁgures and tables contained in the papers. We no-

ticed that ﬁelds such as “name”, “number”, “precon-

dition” are the most used in the templates and tables

presented. For the sake of space, the word cloud is

presented only in the supplementary material.

4.1.2 RQ1.2: Which Tool Supports the

Generation of Plan/Cases from

Requirements?

Table 5 shows the tools used in the selected works. Of

the 41 papers, only 8 do not refer to the tools used.

4.1.3 RQ1.3 How are Requirements Speciﬁed?

Natural language with a pattern was the most used ap-

proach to specify requirements as input for test case

generation, with 18 references. In the studies, it was

mentioned as “Restricted Natural Language”, “Struc-

tured Natural Language”, SRC, among others.

The second most used approach to specify the

requirements is the Natural language without a pat-

tern, with 11 references. In those that use these

requirements as input, these requirements appeared

Table 5: Tools used for the generation of plan/cases from

requirements (RQ 1.2).

Tools

aToucan4Test,TRUST, SysML, Litmus, TGV, BZ-TT, SOFL, Java

Pathﬁnder tool, Umlaut, TaRGeT, Fitness, UMTG plugin, NLReq2TC,

Zen tool, TestLink, WIKI, CASE tool, LTS-BT, DNF, Automatic Speci-

ﬁcation Based Test Case Generation prototype, S29, QVT, SPF, UDITA,

Pral

ınTool, T-VEC, JPL, ANSYS SCADE KCG, ANSYS SCADE Test

Environment e ANSYS SCADE Design Veriﬁer, Mutant Generation

System, Trace2TestCase, LTL2SCADE and LTL2Trap, Reform, Mod-

Gen and TCG, Style Parser, Link Grammar parser, GATE, NLTK, ADL

translator, TestSpec, Randoop, EvoSuite, T-VEC tool, CNL Parser, Au-

tomated test case generation based on state charts, Test Generation with

Veriﬁcation Technology, TestGen-Intermediate Format (IF), Test Case

Generation (TCG) and TaRGeT

as “Freestyle Natural Language”, “Predicate Expres-

sion”, and others. In third place appears “UML”, with

10 references. In this case, we identify these by ex-

pressions such as “Class Diagram”, “Sequence Dia-

gram” and “UML Diagram”. Below we show some

quotes that conﬁrm the use of these requirements.

“. . . the input to the automation process consists

of freestyle NL documents.” S27

“Our approach consists of translating ADEPT

models into Java programs that can be symbolically

executed by SPF.” S3 “Since TRUST generates test

cases from UML state machines.” S11

DSL, Domain speciﬁc data structure, Models ex-

tracted from ADEPT tool and Model-oriented nota-

tions such Z and B has only one citation each.

4.1.4 RQ1.4: Are Requirements Represented

Graphically or Textually?

From the answers of RQ1.3, it is expected that “Textu-

ally” would appear more often (70,7%) than “Graph-

ically” (29,3%). The answer was often not explicit

in the paper, so we derived it from other information

presented, such as a screenshot of a tool showing an

SRS document as being the input to generate the test

cases, thus being classiﬁed as “Textually”.

4.1.5 RQ1.5: How are Test Cases Generated

from Requirements?

RQ1.5 concerns how to achieve automatic generation

of test cases from requirements. The results of this re-

search question is presented in the supplement mate-

rial. Some of the responses extracted from the papers

are described below.

From UMTG Technique: “...ﬁve steps: 1. Test

scenario description and user stories were being pro-

cessed as inputs through a NL parser. 2. Dependen-

cies procured from the parser were being utilized in

the creation of UML activity diagram, which were

aimed to demonstrate the functionality ﬂow. 3. Ac-

A Systematic Mapping Study on Techniques for Generating Test Cases from Requirements

145

tivity graph was generated from activity diagram that

comprised of all the activities delineated as nodes. 4.

An algorithm entitled as depth ﬁrst search (DFS) is

deployed for traversing the activity graph from initial

to ﬁnal activity state, in order to discover all possi-

ble authentic paths. 5. Possible functional test cases

were then generated by utilizing the test paths (ﬁnal

outcome).” S21

From MBT Technique: “...is made up of 5 differ-

ent steps: 1. Step 1: Product Line modelling; 2. Step

2: Sequence diagram enrichment; 3. Step 3: domain-

level test scenario generation; 4. Step 4: domain level

test case generation; 5. Step 5: product level test case

generation and automation.” S37

From NLP Technique: ”The tool works on each

requirement sentence and generates one or more Test

Cases through a ﬁve step process 1) The sentence

is analyzed through a syntactic parser to identify

whether it is testable; 2) A compound or complex

testable sentence is split into

5 THREATS TO VALIDITY

(Wohlin et al., 2000) pointed out four types of threats

to validity: Construct, Conclusion, Internal, External.

In this section, we discuss the threats to validity of our

study based on these four types.

Construct: it refers to the relationship between the

theory behind the experiment and the observations.

The data came from 9 research bases, such as IEEE,

ACM and SPRINGER, providing diversity. Even so,

we understand that there are other databases of quali-

ties that could add even more value to our work.

Conclusion: it deals with how certain we can be

that the technique we use in our investigation really is

related to the actual result we observe. To mitigate the

effects of this threat, the SMS process was carefully

designed and discussed among the authors to mini-

mize the risk of exclusion from relevant studies.

Internal: it contemplates the fact that there may

be other factors that caused the result. In this sense,

SMS and the Snowballing technique aim to minimize

internal validity. Additionally, the selection process

was carried out in such a way that when there were

doubts in the application of some criterion, the study

was not eliminated and moved on to the next step.

External: it contemplates the point about whether

we can generalize the results outside the scope of our

study. This threat was mitigated with the use of selec-

tion criteria and the diversity of the selected studies.

Even so, more studies need to be conducted.

6 CONCLUSIONS AND FUTURE

WORK

Test case generation techniques can increase product

quality, reduce product costs and the time-to-market

(Fewster and Graham, 1999). This process can be

done based on requirements and may involve the use

of tools and procedures. In this sense, the present

work investigated the state of the art to identify which

techniques, tools, requirements and procedures have

been used. The objective lies in the fact of being able

to bring relevant information to the academic commu-

nity and assist in the evolution of tools for the auto-

matic test cases generation from requirements, such

as SmarTest, because it can reveal paths to follow

through the information we have in the literature.

For the selection of studies that we used to extract

the data, we used the Snowballing technique, where

we performed an iterative procedure with the refer-

ences and citations of a base set of ﬁve chosen papers.

This returned us 316 papers, which from readings and

use of inclusion and exclusion criteria, gave us a total

of 41 references to be used in extracting information.

As for the results, we noticed that there is a pref-

erence for the use of techniques and approaches in-

volving MBT and NLP. In addition, we concluded

that “Natural Language with a pattern”, “Natural Lan-

guage without a pattern” and “UML” are the most

used requirements as input, which also favored the

Textual type to be found more often. Additionally,

there are not as many template information ﬁelds and

other artifacts revealed in the works we investigated.

Finally, we can say that there is no great intersection

between the tools used, given that most of them are

tools proposed by the authors.

As future work, we intend to perform a deeper

analysis of NLP based tools, as they have a great po-

tential in a software industry that speciﬁes require-

ments using natural language.

REFERENCES

Ahsan, I., Butt, W. H., Ahmed, M. A., and Anwar, M. W.

(2017). A comprehensive investigation of natural lan-

guage processing techniques and tools to generate au-

tomated test cases. In Proc. of the Second Intl. Conf.

on Internet of things, Data and Cloud Computing,

pages 1–10.

Ali, S. and Hemmati, H. (2014). Model-based testing

of video conferencing systems: challenges, lessons

learnt, and results. In 2014 IEEE Seventh Intl.

Conf. on Software Testing, Veriﬁcation and Validation,

pages 353–362. IEEE.

Ali, S., Hemmati, H., Holt, N. E., Arisholm, E., and Briand,

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

146

L. C. (2010). Model transformations as a strategy

to automate model-based testing-a tool and industrial

case studies. Technical report, Simula Research Lab.

Aniculaesei, A., Vorwald, A., and Rausch, A. (2019). Us-

ing the SCADE toolchain to generate requirements-

based test cases for an adaptive cruise control sys-

tem. In ACM/IEEE 22nd Intl. Conf. on Model Driven

Eng. Languages and Systems Companion (MODELS-

C), pages 503–513.

Arruda, F., Barros, F., and Sampaio, A. (2020). Automa-

tion and consistency analysis of test cases written in

natural language: An industrial context. Science of

Computer Programming, 189:102377.

Barros, F. A., Neves, L., Hori,

E., and Torres, D. (2011).

The ucsCNL: A controlled natural language for use

case speciﬁcations. In SEKE, pages 250–253.

Bernardino, M., Rodrigues, E. M., Zorzo, A. F., and

Marchezan, L. (2017). Systematic mapping study on

MBT: tools and models. IET Software, 11(4):141–

155.

Bouquet, F., Dadeau, F., and Legeard, B. (2006). Auto-

mated boundary test generation from jml speciﬁca-

tions. In FM 2006: Formal Methods, volume 4085,

pages 428–443. Springer.

Carvalho, G., Falc

ao, D., Barros, F., Sampaio, A., Mota,

A., Motta, L., and Blackburn, M. (2013). Test case

generation from natural language requirements based

on SCR speciﬁcations. In Proc. of the 28th Annual

ACM Symp. on Applied Computing (SAC ’13), pages

1217–1222.

Coutinho, J., Andrade, W., and Machado, P. (2022). A sur-

vey of requirements engineering and software testing

practices in agile teams. In Proc. of the 7th Brazilian

Symp. on Systematic and Automated Software Testing,

pages 9–18.

Craig, R. D. and Jaskiel, S. P. (2002). Systematic software

testing. Artech House.

de Santiago J

unior, V. and da Silva, F. (2017). From state-

charts into model checking: A hierarchy-based trans-

lation and speciﬁcation patterns properties to generate

test cases. In Proc. of the 2nd Brazilian Symp. on Sys-

tematic and Automated Software Testing, pages 1–10.

Dwarakanath, A. and Sengupta, S. (2012). Litmus: Genera-

tion of test cases from functional requirements in nat-

ural language. In Natural Language Processing and

Inf. Systems, volume 7337, pages 58–69. Springer.

El-Far, I. K. and Whittaker, J. A. (2002). Model-based soft-

ware testing.

Elghondakly, R., Moussa, S., and Badr, N. (2015). Wa-

terfall and agile requirements-based model for auto-

mated test cases generation. In Seventh Intl. Conf.

on Intelligent Computing and Inf. Systems (ICICIS),

pages 607–612. IEEE.

Farooq, M. S. and Tahreem, T. (2022). Requirement-

based automated test case generation: Systematic lit-

erature review. VFAST Transactions on Software Eng.,

9(4):133–142.

Fazzolino, R., de Faria, H. M., Amaral, L. H. V., Canedo,

E. D., Rodrigues, G. N., and Bonif

acio, R. (2018). As-

sessing agile testing practices for enterprise systems:

A survey approach. In Proc. of the III Brazilian Symp.

on Systematic and Automated Software Testing, pages

29–38.

Fewster, M. and Graham, D. (1999). Software test automa-

tion. Addison-Wesley.

Galv

ao, T. F. and Pereira, M. G. (2014). Revis

oes sis-

tem

aticas da literatura: passos para sua elaborac¸

ao.

Epidemiologia e servic¸os de sa

ude, 23:183–184.

Giannakopoulou, D., Bushnell, D., Schumann, J., et al.

(2011a). Formal testing for separation assurance. An-

nals of Mathematics and Artiﬁcial Intelligence, 63:5–

30. Pages 1–26.

Giannakopoulou, D., Rungta, N., and Feary, M. (2011b).

Automated test case generation for an autopilot re-

quirement prototype. In 2011 IEEE Intl. Conf. on Sys-

tems, Man, and Cybernetics, pages 1825–1830. IEEE.

Gligoric, M., Gvero, T., Jagannath, V., Khurshid, S., Kun-

cak, V., and Marinov, D. (2010). Test generation

through programming in UDITA. In ACM/IEEE 32nd

Intl. Conf. on Software Eng., pages 225–234.

opler, R., Sudhi, V., Garc

ıa, E. J. C., and Bergmann, A.

(2021). NLP-based requirements formalization for au-

tomatic test case generation. In CS&P, volume 21,

pages 18–30.

Gupta, A. and Mahapatra, R. P. (2021). A circumstan-

tial methodological analysis of recent studies on nlp-

driven test automation approaches. arXiv preprint

arXiv:2104.04843.

Hametner, R., Winkler, D., and Zoitl, A. (2012). Agile

testing concepts based on keyword-driven testing for

industrial automation systems. In IECON 2012-38th

Annual Conf. on IEEE Industrial Electronics Society,

pages 3727–3732. IEEE.

Hesari, S., Behjati, R., and Yue, T. (2013). Towards a sys-

tematic requirement-based test generation framework:

Industrial challenges and needs. In 21st IEEE Intl. Re-

quirements Eng. Conf. (RE), pages 261–266. IEEE.

Hooda, I. and Chhillar, R. (2014). A review: study of test

case generation techniques. Intl. Journal of Computer

Applications, 107(16):33–37.

IBM (2023). What is natural language processing (nlp)?

topic page about natural language processing. Techni-

cal report.

Jorge, D., Machado, P., Alves, E., and Andrade, W.

(2018). Integrating requirements speciﬁcation and

model-based testing in agile development. In 26th

Intl. Requirements Eng. Conf. (RE), pages 336–346.

IEEE.

Kitchenham, B. and Charters, S. (2007). Guidelines for per-

forming systematic literature reviews in software en-

gineering. Technical Report EBSE-2007-01, School

of Computer Science and Math., Keele University.

Kriebel, S., Markthaler, M., Salman, K. S., Greifenberg,

T., Hillemacher, S., Rumpe, B., and Richenhagen, J.

(2018). Improving model-based testing in automotive

software engineering. In Proc. of the 40th Intl. Conf.

on Software Eng.: Software Eng. in Practice, pages

172–180.

Lamancha, B., Usaola, M., and Velthuis, M. (2010). An au-

tomated model-driven testing framework-for model-

A Systematic Mapping Study on Techniques for Generating Test Cases from Requirements

147

driven development and software product lines. In

ENASE, pages 112–121.

Legeard, B., Peureux, F., and Utting, M. (2004). Control-

ling test case explosion in test generation from b for-

mal models. Software Testing, Veriﬁcation and Relia-

bility, 14(2):81–103.

Liu, S. and Nakajima, S. (2010). A decompositional ap-

proach to automatic test case generation based on

formal speciﬁcations. In Fourth Intl. Conf. on Se-

cure Software Integration and Reliability Improve-

ment, pages 147–155.

Liu, S. and Nakajima, S. (2020). Automatic test case and

test oracle generation based on functional scenarios in

formal speciﬁcations for conformance testing. IEEE

Transactions on Software Eng., 48(2):691–712.

Malekzadeh, M. and Ainon, R. N. (2010). An automatic test

case generator for testing safety-critical software sys-

tems. In 2nd Intl. Conf. on Computer and Automation

Eng. (ICCAE), pages 163–167.

Mateo, P., Polo, M., and Lamancha, B. (2009). Automatic

generation of test cases in software product lines. In

Intl. Conf. on Enterprise Inf. Systems.

Mustafa, A., Wan-Kadir, W. M., and Ibrahim, I.

(2017). Comparative evaluation of the state-of-art

requirements-based test case generation approaches.

Intl. Journal on Advanced Science, Eng. and Inf. Tech-

nology, 7(4-2):1567–1573.

Mustafa, A., Wan-Kadir, W. M., Ibrahim, N., Shah, M. A.,

Younas, M., Khan, A., and Alanazi, F. (2021). Auto-

mated test case generation from requirements: A sys-

tematic literature review. Computers, Materials and

Continua, 67(2):1819–1833.

Nebut, C., Fleurey, F., Le Traon, Y., and J

equel, J. M.

(2004). A requirement-based approach to test product

families. In Software Product-Family Eng.: 5th Intl.

Workshop, PFE 2003, pages 198–210. Springer Berlin

Heidelberg.

Nebut, C., Pickin, S., Le Traon, Y., and J

equel, J. M.

(2003). Automated requirements-based generation of

test cases for product families. In 18th IEEE Intl.

Conf. on Automated Software Eng., 2003. Proceed-

ings, pages 263–266. IEEE.

Neto, A. and Claudio, D. (2007). Introduc¸

ao a teste de soft-

ware. Engenharia de Software Magazine, 1:22.

Pickin, S., Jard, C., Jeron, T., Jezequel, J.-M., and Le Traon,

Y. (2007). Test synthesis from UML models of dis-

tributed software. IEEE Transactions on Software

Eng., 33(4):252–269.

Reales, P., Polo, M., and Caivano, D. (2012). Model based

testing in software product lines. In Enterprise Inf.

Systems, volume 102, pages 270–283. Springer.

Riebisch, M. and Hubner, M. (2005). Traceability-driven

model reﬁnement for test case generation. In 12th

IEEE Intl. Conf. and Workshops on the Eng. of

Computer-Based Systems (ECBS’05), pages 113–120.

Santos, E., Costa, L., Arag

ao, B., Santos, I., and Andrade,

R. (2019). Extraction of test cases procedures from

textual use cases to reduce test effort: Test factory ex-

perience report. In Proc. of the XVIII Brazilian Symp.

on Software Quality, pages 266–275. ACM.

Shanthi, A. V. K. and Kumar, D. G. M. (2011). Auto-

mated test cases generation for object oriented soft-

ware. Indian Journal of Computer Science and Eng.,

2(4):543–546.

Singh, S. K. and Singh, A. (2012). Software testing. Van-

dana Publications.

Tahat, L. H., Vaysburg, B., Korel, B., and Bader, A. J.

(2001). Requirement-based automated black-box test

generation. In 25th Annual Intl. Computer Software

and Applications Conf. - COMPSAC 2001, pages

489–495. IEEE.

Vani, V., Mahalakshmi, G., and Antony, J. (2015). Gen-

eration of patterns for test cases. Indian Journal of

Science and Technology, 8(24):1.

Vaysburg, B., Tahat, L. H., and Korel, B. (2002). Depen-

dence analysis in reduction of requirement based test

suites. In Proc. of the 2002 ACM SIGSOFT Intl. Symp.

on Software Testing and Analysis, pages 107–111.

Verma, R. and Beg, M. (2013). Generation of test cases

from software requirements using natural language

processing. In 6th Intl. Conf. on Emerging Trends in

Eng. and Technology, pages 140–147.

Wang, C., Pastore, F., Goknil, A., Briand, L., and Iqbal,

Z. (2015). Automatic generation of system test cases

from use case speciﬁcations. In Proc. of the Intl. Symp.

on Software Testing and Analysis, pages 385–396.

Wang, C., Pastore, F., Goknil, A., and Briand, L. C.

(2020). Automatic generation of acceptance test cases

from use case speciﬁcations: an NLP-based approach.

IEEE Transactions on Software Eng., 48(2):585–616.

Wohlin, C. (2014). Guidelines for snowballing in system-

atic literature studies and a replication in software en-

gineering. In Proc. of the 18th Intl. Conf. on Evalua-

tion and Assessment in Software Eng., pages 1–10.

Wohlin, C., Runeson, P., H

ost, M., Ohlsson, M. C., Regnell,

B., and Wessl

en, A. (2000). Experimentation in soft-

ware engineering: an introduction. Kluwer Academic

Publishers, Norwell, MA, USA.

Yue, T., Ali, S., and Zhang, M. (2015). Rtcm: a natural lan-

guage based, automated, and practical test case gener-

ation framework. In Proc. of the Intl. Symp. on Soft-

ware Testing and Analysis, pages 397–408.

Zhang, H., Wang, S., Yue, T., et al. (2018). Search and

similarity based selection of use case scenarios: An

empirical study. Empirical Software Eng., 23:87–164.

Zhang, M., Yue, T., Ali, S., Zhang, H., and Wu, J. (2014).

A systematic approach to automatically derive test

cases from use cases speciﬁed in restricted natural lan-

guages. In 8th Intl. Conf. on System Analysis and

Modeling: Models and Reusability, SAM, pages 142–

157. Springer Intl. Publishing.

Zhang, W. and Liu, S. (2013). Supporting tool for automatic

speciﬁcation-based test case generation. In Struc-

tured Object-Oriented Formal Language and Method.

SOFL 2012, volume 7787, pages 12–25. Springer.

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

148
