A Systematic Mapping Study in Security Software Testing for Mobile

Devices

Felipe Faustino

1 a

, J

essyka Vilela

1 b

, Carla Silva

1 c

and Mariana Peixoto

2 d

Centro de Inform

atica, Universidade Federal de Pernambuco (UFPE), Av. Jornalista An

ıbal Fernandes, s/n,

Cidade Universit

aria, Recife-PE, Brazil

Universidade de Pernambuco (UPE), R. Cap. Pedro Rodrigues, s/n, S

ao Jos

e, Garanhuns-PE, Brazil

Keywords:

Mobile Devices, Security Testing, Systematic Mapping Study.

Abstract:

Context: Due to mobile devices’ popularity, they contain more valuable information. Problem: these devices

face many security issues and challenges since smartphones are interesting for security attacks once they

contain private and sensitive data. Objective: the aim of this paper is to investigate security testing techniques

for mobile devices. Method: a Systematic Mapping Study (SMS) was conducted to identify solutions focused

on software security testing for mobile devices. Results: 1264 primary papers were identiﬁed, and 17 relevant

papers were selected. We found mobile security testing tends to be mostly: dynamic; automated testing;

penetration testing; dynamic analysis. Conclusions: dynamic testing represents 58.82% of security testing,

followed by static testing, 29.41%, and studies that present both of them 11.76%. It’s important to highlight

that automated and semi-automated testing represent 88.23% of the studies and only 11.76% used manual

testing.

1 INTRODUCTION

Mobile devices, such as smartphones, tablets, and

wearable devices, have evolved into crucial compo-

nents for both businesses (M

endez Porras et al., 2015)

and society, playing an indispensable role in the mod-

ern world. With a wide range of applications, these

devices offer countless functionalities that cater to

the needs of consumers. They enable users to ac-

complish tasks with ease, ﬂexibility, and mobility,

rendering traditional computers obsolete in many in-

stances (Oliveira et al., 2019)(Guo et al., 2014)(Rus-

sello et al., 2013)(Shezan et al., 2017).

The widespread use of mobile devices has led

to an increase in security concerns and challenges.

Smartphones, in particular, have become attractive

targets for security attacks due to the valuable in-

formation they store, including private and sensitive

data (Wang, 2015)(Zhong and Xiao, 2014). Malicious

applications

have emerged as a signiﬁcant threat,

https://orcid.org/0000-0002-2517-5152

https://orcid.org/0000-0002-5541-5188

https://orcid.org/0000-0002-0597-3851

https://orcid.org/0000-0002-5399-4155

https://www.sciencedirect.com/topics/computer-

science/malicious-apps

aiming to steal passwords, track GPS locations, ac-

cess contacts, and exploit other applications that in-

volve ﬁnancial transactions or contain sensitive data

(Russello et al., 2013)(Avancini and Ceccato, 2013).

These security breaches pose a serious threat to the

privacy and security of a vast mobile user community

(Sun et al., 2016).

Security software testing plays a crucial role in ad-

dressing vulnerabilities that compromise information

conﬁdentiality, integrity, and privacy (Albuquerque

and Nunes, 2016)(Soares et al., 2023). Mobile ap-

plications, in particular, present unique challenges

compared to traditional web and desktop applications.

With their increasing use in critical domains, it be-

comes essential to adopt speciﬁc approaches to ensure

application quality and dependability. An effective

testing approach is required to assess the high qual-

ity and reliability of mobile applications (Zein et al.,

2016).

To meet the increasing demand for high-quality

mobile applications, developers need to allocate more

effort and attention to software development pro-

cesses. Among these processes, software testing play

a crucial role in ensuring the quality of mobile ap-

plications. However, one of the challenges related to

mobile app testing is the diversity of mobile devices,

Faustino, F., Vilela, J., Silva, C. and Peixoto, M.

A Systematic Mapping Study in Security Software Testing for Mobile Devices.

DOI: 10.5220/0012552100003705

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 9th International Conference on Internet of Things, Big Data and Security (IoTBDS 2024), pages 17-28

ISBN: 978-989-758-699-6; ISSN: 2184-4976

known as fragmentation. With multiple OS versions,

screen sizes, and resources, testing on a wide range

of devices is time-consuming and requires signiﬁcant

human and ﬁnancial resources, resulting in increased

testing costs (Souza et al., 2019).

The ﬁndings of Junior et al. (Junior et al., 2022)

from their literature review highlight the complexity

and importance of security testing. They discovered

that security testing is often overlooked compared to

other non-functional requirements. Additionally, the

use of third-party apps and frameworks can poten-

tially introduce vulnerabilities. Lastly, they observed

that apps are not adequately tested against known vul-

nerabilities.

In this context, there is a need to gain a deeper un-

derstanding of What are the techniques, approaches,

methods, tools and processes used for mobile security

testing in the literature?

Our study aims to address this gap by making

the following contributions: (1) the identiﬁcation of

techniques, approaches, methods, tools and processes

used for mobile security testing in the literature; (2)

the classiﬁcation of these techniques; 3) the criteria

and documentation used in the elaboration of those

tests; 4) the beneﬁts and gaps in using such tech-

niques, methods, tools or processes and to suggest

improvements and prevent mistakes; 5) the current

trends and future propects of mobile security testing;

and, 6) the deﬁnition of the difference between mobile

and non-mobile security testing

Hence, the objective of this study is to con-

duct a Systematic Mapping Study (SMS) about mo-

bile security testing techniques. Secondary studies

have already been used to examine different perspec-

tives of software testing, including: (Garousi and

antyl

a, 2016); automated testing of mobile appli-

cations (M

endez Porras et al., 2015), automated soft-

ware focused on the Android Platform (Musthafa

et al., 2020), and automated functional testing (Tra-

montana et al., 2019); black, grey, and white box test-

ing approaches (Hamza and Hammad, 2020); usabil-

ity attibutes (Alturki and Gay, 2019), and penetration

testing for mobile cloud computing applications (Al-

Ahmad et al., 2019). However, there is a gap regard-

ing security testing approaches for mobile devices.

By offering insights into the mobile security soft-

ware testing approaches, our research outcomes will

empower professionals to make informed decisions

while selecting the most suitable strategies for con-

ducting security testing on mobile devices present in

the testing literature. This will, in turn, contribute to

ensuring the overall security, integrity, and reliability

of mobile applications in the industry.

This paper is organized as follows: Section 2

presents the background on security software testing

and related work. Section 3 presents the research

methodology used to perform the systematic mapping

study and the context within it is inserted. The results

and the analysis related to our research questions are

presented in Section 4. Finally, we present our con-

clusions and future works in Section 5.

2 BACKGROUND AND RELATED

WORK

In this section, some important concepts related to the

ﬁeld of study on this paper are discussed. Also, the

last subsection presents related work.

2.1 An Overview of Security Software

Testing

Software testing is an integral phase in Software De-

velopment Life Cycle (SDLC) process (Dennis et al.,

2009), it involves many technical and nontechnical as-

pects (such as speciﬁcation, design, implementation,

installation, maintenance, and management issues) in

Software Engineering (Umar, 2019).

(Myers et al., 2011) deﬁne “Software testing is a

process, or a series of processes, designed to make

sure computer code does what it was designed to do

and that it does not do anything unintended”.

Regarding software testing classiﬁcation, in terms

of categories (approaches), software testing can be di-

vided into two categories: Static, related to source

code only, and Dynamic, related to actual code exe-

cutions observing its execution (Umar, 2019; Felderer

et al., 2016), and in the matter of software testing

techniques, considering code analysis, testing is of-

ten classiﬁed as a black box and white box testing

(Copeland, 2004). Tests based on the information

about how software has been designed or coded, in

which the source code is available and tests are exe-

cuted based on it, are classiﬁed as white box testing.

On the other hand, enabling mimic hackers attacks,

black box testing depends on the input/output behav-

ior of the software (Copeland, 2004; Felderer et al.,

2016).

Concerning testing types, Umar (Umar, 2019)

listed, as a result of a survey conducted by the

International Software Testing Qualiﬁcations Board

(ISTQB), six types as some of the most important

types of testing:

• Functional Testing. Test functions of the software,

• Performance Testing. Testing software respon-

siveness and stability under a particular workload,

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

• Security Testing. Protect data and maintain soft-

ware functionality,

• Usability Testing. Check ease of use of software,

• Use case Testing. Checking that path used by a

user is working as intended,

• Exploratory Testing. Validate the experience of

the user.

Felderer et al. (Felderer et al., 2016) listed con-

ﬁdentiality, integrity, availability, authentication, au-

thorization, and non-repudiation as security proper-

ties assets related to security testing. La Polla, Mar-

tinelli, and Sgandurra (La Polla et al., 2012) com-

plements that mobility, robust personalization, strong

connectivity, technology convergence, and reduced

capabilities as the ﬁve key aspects that differentiate

mobile security from conventional computer security.

Felderer et al. (Felderer et al., 2016) additionally clas-

siﬁed security testing techniques regarding how they

are executed: dynamic or static testing and manual or

automated testing. Regarding the techniques’ test ba-

sis within the secure software development life cycle,

Felderer et al. (Felderer et al., 2016) considered four

different types:

• Model-Based Security Testing. is grounded on re-

quirements and design models created during the

analysis and design phase;

• Code-Based Testing and Static Analysis. on

source and byte code created during development;

• Penetration Testing and Dynamic Analysis. on

running systems, either in a test or production

environment (penetration testing, vulnerability

scanning, dynamic taint analysis, and fuzzing);

• Security Regression Testing. performed during

maintenance.

2.2 Related Work

As related work, we search for other reviews about se-

curity software testing for mobile devices, aiming to

understand what has been done and the possible gaps

for this research. We did not ﬁnd a study with such

focus, hence, our discussion of related works is di-

vided in two parts: 1) mobile testing, and, 2) software

security testing.

Mobile testing has been studied considering sev-

eral perspectives such as mobile apps (Souza et al.,

2019)(Junior et al., 2022).

Souza et al. (Souza et al., 2019) investigate the

use of Exploratory Testing (ET) in mobile apps, aim-

ing to understand its effectiveness and application in

a wide range of apps. Two studies were conducted:

the ﬁrst analyzed how testers explore app scenarios

on Google Play, revealing unexplored bugs. The sec-

ond study applied ET to two apps developed by a soft-

ware company, identifying bugs of different levels not

found using other techniques. Results showed that ET

is a promising technique for discovering bugs in mo-

bile apps, but test professionals could learn about the

recent results from academia.

Junior et al. (Junior et al., 2022) conducted a SMS

to explore dynamic techniques and automation tools

for testing mobile apps, particularly focusing on non-

functional requirements (NFRs). They found that se-

curity is the second most addressed NFR, accounting

for 30.3% of the selected studies. An additional anal-

ysis of the primary studies revealed that the motiva-

tion behind addressing security testing was the lack

of attention to security by developers during app im-

plementation. As a result, speciﬁc techniques and

tools are needed to address this issue. The studies

also highlighted that developers often lack sufﬁcient

knowledge about security, leading to a lack of vigi-

lance in this aspect.

Web application security testing has also been

studied in literature reviews. Seng et al. (Seng et al.,

2018) present a systematic review of methodologies

and criteria for quantifying the quality of web applica-

tion security scanners, emphasizing their beneﬁts and

weaknesses. It aims to assist practitioners in under-

standing available methodologies and guiding future

development efforts. On the other hand, Aydos et al.

(Aydos et al., 2022) present a SMS on web application

security testing, addressing research questions, selec-

tion criteria, and classiﬁcation schema. It includes 80

technical articles from 2005 to 2020 and provides an

overview of web security testing tools, vulnerability

types, and more. The study beneﬁts researchers and

developers by offering insights into web application

security testing trends and secure development.

Garousi and M

antyl

a (Garousi and M

antyl

2016) conducted a tertiary study, a systematic liter-

ature review of literature reviews in software test-

ing. They identiﬁed two relevant secondary stud-

ies out of 101 selected between 1994 and 2015, in-

dicating a lack of research on mobile applications.

The selected studies focused on automated testing ap-

proaches for mobile apps, testing techniques, empiri-

cal assessments, and challenges in mobile application

testing.

The objective of Zein, Salleh, and Grundy’s study

(Zein et al., 2016) was to analyze mobile applica-

tion testing techniques, approaches, and challenges.

They conducted a Systematic Mapping Study, map-

ping and classifying 79 studies into categories such as

test automation, usability testing, context-awareness

testing, security testing, and general testing. Within

A Systematic Mapping Study in Security Software Testing for Mobile Devices

the 79 studies, eight focused on security testing, with

inter-application communication threats identiﬁed as

the main challenge. To provide an updated under-

standing of mobile security software techniques, this

work presents a systematic mapping study to identify

methodologies, approaches, and techniques used in

mobile security testing.

Regarding the perceptions of practitioners from

the mobile software testing environment on security-

related testing topics, Soares et al. (Soares et al.,

2023) present the results of a survey answered by 49

software testing practitioners, and they concluded that

there is also a lack of knowledge about the topics dis-

cussed. They also conclude the need to improve secu-

rity culture. This fact was also observed in the work

of (Santos et al., 2021)

3 RESEARCH METHODOLOGY

In order to perform this SMS, the guidelines for sys-

tematic mapping proposed by Petersen et al. (Pe-

tersen et al., 2015) were used.

3.1 Research Question(s)

The purpose of this SMS is to better understand the

state-of-the-art regarding mobile security testing and

investigate the methodologies, approaches, and tech-

niques used. With these answers, we intend to obtain

knowledge about the strong points and gaps of Mo-

bile Security Testing (MST). Therefore, new research

can take as a starting point to propose the improve-

ment of the area. Accordingly, we intend to answer

the following Research Question (RQs): What are the

techniques, approaches, methods, tools and processes

used for mobile security testing in the literature?

Based on the main RQ, speciﬁc questions were

raised according to MST aspects that we are inter-

ested in. These questions and their motivations are

described in Table 1.

3.2 Research String

First, keywords that were used to identify scientiﬁc

papers in databases were deﬁned. However, to include

as many papers as possible, and avoid losses, key-

words were deﬁned as broadly as possible. Based on

the RQs deﬁned in Table 1, two main keywords were

initially identiﬁed: Smartphone and Security Testing.

In addition, possible variations such as synonyms and

regular/plural forms of both of the keywords have

been considered, resulting in the following combina-

tion search string with the keywords:

Table 1: Research Questions.

ID Research question Motivation

RQ1 What are the techniques, ap-

proaches, methods, tools and

processes used for mobile se-

curity testing in the literature?

To get the state-of-the-art in

mobile security testing.

RQ1.1 How are the techniques, ap-

proaches, methods, tools or

processes classiﬁed by the au-

thors?

To identify the type of each

technique, method, tool or

process, such as black box,

white box, etc.

RQ1.2 How is the security mobile

testing documented by the au-

thors?

To identify the criteria and

documentation used in the

elaboration of those tests.

RQ1.3 What are the pros and cons of

these techniques, approaches,

methods, tools or processes to

mobile security testing?

To identify the beneﬁts and

gaps in using such techniques,

methods, tools or processes

and to suggest improvements

and prevent mistakes.

RQ1.4 What are the current trends of

mobile security testing?

To identify the current ap-

proaches used in mobile secu-

rity testing.

RQ1.5 What are the future prospects

of mobile security testing (if

applicable)?

To understand the path mobile

security testing is taking and

the future of the ﬁeld.

RQ1.6 What is the difference between

mobile and non-mobile secu-

rity testing?

To understand the major dif-

ference between those tests.

We did not include the term software in the search

string because it was not our goal to restrict to soft-

ware testing. Besides, there are several terms used by

the literature in this context such devices, application,

system, apps and software as well. Hence, we opted

for a wide approach.

3.3 Data Source Selection

After deﬁning the RQs and the Research String, the

approach used to perform the extraction of scientiﬁc

papers was searched based on the research string, pre-

sented in previous subsection, in four scientiﬁc pa-

pers’ databases. The following databases were se-

lected: ACM Digital Library, IEEE Xplore Digi-

tal Library, Elsevier Science Direct, Springer Link.

The searches were conducted using the “Advanced

Search” option to each of the respective databases

used. Table 2 presents the number of identiﬁed pri-

mary papers (1264), and all searches were performed

on January 13, 2022.

Table 2: Details of the Study Selection Process.

Database Primary Studies

ACM 249

IEEE 134

Science Direct 547

Springer Link 328

Total 1264

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

3.4 Selection Criteria

During a SMS, the study selection criteria play an im-

portant role setting which studies are included or ex-

cluded. In addition, the deﬁnition of inclusion crite-

ria and exclusion criteria was necessary to allow the

impersonal and standardized identiﬁcation of primary

studies by the authors. Therefore, Inclusion Criteria

(IC) and Exclusion Criteria (EC) were deﬁned as pre-

sented in Table 3.

Table 3: Inclusion and exclusion criteria.

ID Inclusion Criteria

IC1 Primary studies

IC2 Study published between January 2011 and January 2022

IC3 Full paper accepted in scientiﬁc journal or conference

IC4 Studies that report security software testing techniques

ID Exclusion criteria

EC1 Secondary studies

EC2 Short papers

EC3 Duplicated studies (only one copy of each study was in-

cluded)

EC4 Non-English written studies

EC5 Studies that do not describe techniques, approaches, methods,

tools or processes used for mobile security testing

EC6 Studies that are not available accessed using institutional cre-

dentials

A software tool was used to support the SMS

protocol deﬁnition. The tool, called Parsifal

(https://parsif.al/), is an online tool designed to sup-

port researchers to perform SMS and the results found

in the databases were imported to it. Then, the dupli-

cated studies (45) were excluded.

After deﬁning the selection criteria, the ﬁrst se-

lection step was the identiﬁcation of relevant papers

by applying the IC and EC to the primary studies

found in the databases through reading the titles and

abstracts. If there was insufﬁcient data, the complete

text from the paper was read. At the end of this step,

29 relevant studies were selected as shown in Table

2. Afterward, it was performed a quality assessment

in the selected studies (24) and those that do not sat-

isfy a minimum quality score of 50% were excluded

(subsection 3.5).

3.5 Study Quality Assessment

The quality assessment (QA) of selected studies was

achieved by a scoring technique to evaluate the cred-

ibility, completeness and relevance of the selected

studies. In order to evaluate the selected studies, 8

Quality Assessment Questions (QAQ) were deﬁned

and their relation to the RQs is presented in Table 4.

The QAQs were answered after the full read of the 24

selected studies.

Table 4: Quality Assessment Questions.

ID Quality Assessment Questions

QAQ 1 Are the techniques, approaches, methods, tools or processes

used for mobile security testing well described in the paper?

QAQ2 Is there a classiﬁcation of techniques, approaches, methods,

tools or processes by the authors?

QAQ3 Is there a description of the scope in which the research was

carried out?

QAQ4 Are the criteria and documentation well deﬁned?

QAQ5 Are the mobile security tests results validated?

QAQ6 Is there a clear statement of ﬁndings?

QAQ7 Is there a description of future work?

QAQ8 Is there a clear statement of threats to validity or studies lim-

itations?

The Rating Score of QA is the result of the sum

of the scores for each question, with the Maximum

Score (8.0) that the study could achieve after this sum

and a Cutoff Score (4.0) in which the study that scored

less than 4.0 was rejected. The possible answers for

each QAQ were: yes =1.0, partially = 0.5 or no =0.0.

The quality assessment results are presented in this

spreadsheet

After the quality assessment selection, 17 studies

were considered in this review.The studies S05, S13,

S20, S21 and S26 were excluded due to cutoff grade,

and the studies S28 and S29 were not available using

our institutional credentials.

3.6 Threats to Validity

During the development of this research, some limi-

tations may have affected the obtained results.

Selection of Relevant Studies. The set of stud-

ies was obtained through a search string presented

in subsection 3.4. All existing articles in MST were

selected based on the knowledge and experience of

the authors. In addition, there’s a potential validity

bias wherein the papers identiﬁed may not necessar-

ily represent methodologies originating from indus-

try but rather academic methodologies. To minimize

such bias, inclusion and exclusion criteria were de-

ﬁned, as well as the deﬁnition and delimitation of the

research’s scope. Yet, different authors may have dif-

ferent understandings of these criteria, so the selec-

tion results of other authors tend to vary.

Data Extraction. Data extraction was performed

based on a spreadsheet exported after the ﬁrst selec-

tion using Parsifal containing the primary studies. We

use this spreadsheet to collect the data related to the

RQs proposed by this SMS. Even though the strategy

adopted for extracting the data has helped mitigate

threats to the consistency of data extraction, there are

https://docs.google.com/spreadsheets/d/1hOaaghll8dS

jGb0JEDBvyoICjEaguGIzZTlh28zJ1 c/edit?usp=sharing

A Systematic Mapping Study in Security Software Testing for Mobile Devices

still threats of losing some crucial data through the

subjective judgment used by the authors during this

extraction.

Conclusion Bias. A general problem related to

publication bias is the tendency of researchers to al-

ways publish positive research results instead of nega-

tive ones (Kitchenham and Charters, 2007). This risk

is low because the objective of this study is to present

the state-of-the-art. Moreover, the conclusions pre-

sented may have been affected or inﬂuenced by the

different degrees of knowledge and experience of the

authors, as well as by the perspective adopted when

analyzing studies. A possible threat to validity is the

limited number of papers found, with only 24 papers

identiﬁed. To extrapolate trends or draw generaliza-

tions, a larger sample size would be necessary. There-

fore, it is essential to conduct further searches in the

future to locate more relevant works.

4 RESULTS AND ANALYSIS

This section presents the results and analysis of the

RQs introduced in Section 3. The data extraction re-

sults can be found in this spreadsheet

RQ1 - What Are the Techniques,

Approaches, Methods, Tools or Processes

Used for Mobile Security Testing in the

Literature?

From the selected studies, as shown in Figure 1, the

proposals presented in the selected studies are classi-

ﬁed considering how the authors themselves refer to

them: 5 frameworks (S11, S14, S15, S23, S27); 4

approaches (S01, S08, S19, S24); 4 tools (S03, S04,

S12, S19); 2 systems (S10, S16); 2 methods (S22,

S25); and 1 prototype (S06). S19 presents not only

an approach but also a tool to generate test cases. In

addition, Table 5 presents a brief explanation of each

selected study.

Based on the selected studies, several techniques,

approaches, methods, tools, and processes have been

identiﬁed. These contributions demonstrate the ac-

tive research and development efforts in MST, aim-

ing to enhance the security of mobile applications.

While it is acknowledged that the distinction between

”techniques”, ”approaches,” ”methods”, ”tools” and

”processes” might not always be consistently applied

across papers, its utility lies in providing a structured

https://docs.google.com/spreadsheets/d/1hOaaghll8dS

jGb0JEDBvyoICjEaguGIzZTlh28zJ1 c/edit?usp=sharing

understanding and categorizing within the context of

the research facilitating comparative analysis. From

this table, we can observe the following key points:

• Diverse Approaches. The selected studies cover

a wide range of approaches for MST, including

automated testing, token authentication, model-

based security testing, and biometric tests, among

others. This diversity indicates the need for dif-

ferent strategies to address the various security as-

pects of mobile applications.

• Tool Availability. Several tools are mentioned

in the table, such as FireDroid, Fuzzino, An-

droBugs, SandDroid, Qark, and APSET. These

tools serve different purposes, such as enforcing

security policies, generating test data, conduct-

ing security analysis, and detecting vulnerabili-

ties. Their availability suggests a growing ecosys-

tem of tools speciﬁcally designed for MST.

• Frameworks and Systems. The table includes

frameworks and systems like VAPTAi, VPDroid,

and Metasploit testing framework. These frame-

works provide a structured approach and frame-

work for identifying and mitigating vulnerabilities

in mobile applications.

• Prototype and Methods. The presence of a pro-

totype (SmartDroid) and speciﬁc methods (e.g.,

NFC vulnerabilities and biometric tests with

molds) indicates a research focus on exploring

novel approaches and techniques for identifying

and evaluating security issues in mobile devices.

Overall, the table highlights the diverse range of

techniques and tools available for MST, underscoring

the importance of employing multiple approaches to

ensure the security of mobile applications. The ﬁnd-

ings provide valuable insights for practitioners and re-

searchers in the ﬁeld of mobile security testing.

Overall, the ﬁndings highlight the ongoing efforts

in the MST domain and provide valuable insights for

professionals and researchers in selecting appropriate

techniques and tools for mobile security testing.

RQ1.1 - How Are the Techniques,

Approaches, Methods, Tools or Processes

Classiﬁed by the Authors?

In terms of code analysis classiﬁcation, we observed

that most of the studies did not explicitly classify their

contributions except study S15, classiﬁed as a white

box testing and studies S04, S19, and S25 as black

box testing.

Moreover, based on Felderer et al. (Felderer et al.,

2016) deﬁnitions of security testing, Table 6 presents

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

Table 5: Techniques, approaches, methods, tools or processes used for MST in the literature and a brief explanation.

ID Type Brief explanation

S01 Automated testing (approach) Detection and a checking module to detect the vulnerabilities existing in Android inter-application components.

S03 FireDroid (tool) An effective security solution for enforcing ﬁne-grained security policies without the need to recompile any

internal modules of the Android OS.

S04 Fuzzino (tool) A test data generator to perform fuzz testing. It enables the tester to perform black-box fuzzing based on a type

speciﬁcation for input values.

S06 SmartDroid (prototype) An automatic system for revealing UI-based trigger conditions in android applications.

S08 Token authentication (ap-

proach)

A grounded theory-based approach to identify common (unit) test cases for token authentication through analysis

of 481 JUnit tests exercising Spring Security-based authentication implementations from 53 open-source Java

projects.

S10 Automated testing (system) Based on TAINTDroid, it puts forward and implements the automated testing system, which is applied in the

Android emulator and combined with dynamic taint propagation.

S11 VAPTAi (framework) A threat model to detect and mitigate various unknown vulnerabilities in Android & iOS mobile applications

and a security testing framework for identiﬁcation of MitM attacks in mobile applications.

S12 AndroBugs, SandDroid and

Qark (tools)

Several applications from the EATL app store (app store from Bangladesh) and tested them with a few well-

known testing tools.

S14 AndroBugs (framework) AndroBugs framework was used as the automated security testing tool for security analysis of mobile money

applications on Android using reverse engineering and dynamic analysis tools.

S15 Automated testing (frame-

work)

Employs numerous heuristics and software analysis techniques to intelligently guide the generation of test cases

aiming to boost the likelihood of discovering vulnerabilities.

S16 Automated testing (system) Metasploit testing framework and deployed it on the cloud platform.

S19 Model-based security testing

(approach) and APSET (tool)

The approach generates test cases to check whether components are vulnerable to attacks, sent through intents,

that expose personal data.

S22 Security vulnerabilities - NFC

(method)

Analyze and conducted security testing on NFC-enabled mobile phones based on reader/writer operating mode

in a peer-to-peer fashion manner to ﬁnd a few vulnerabilities.

S23 VPDroid (framework) Security analysts can customize different device artifacts, such as CPU model, Android ID, and phone number,

in a virtual phone without user-level API hooking.

S24 LetterBomb (approach) Automatically generating exploits for Android apps relying on a combined path-sensitive symbolic execution-

based static analysis, and the use of software instrumentation and test oracles.

S25 Biometric tests with molds

(method)

Evaluate the security of ﬁngerprint biometric systems embedded in mobile devices.

S27 Vulvet (framework) Static analysis approaches from different domains of program analysis for detection of a wide range of vulnera-

bilities in Android apps.

Figure 1: Distribution of number of selected studies by

strategy.

how the selected studies are classiﬁed according to

how the testing technique is executed and Table 7

presents how the techniques are classiﬁed according

to their test basis within the secure software devel-

opment life cycle. As shown in Table 6 and Table

7, the predominant categories are Dynamic testing

(58.82%) and Automated testing (52.94%), related to

the way they are executed, and Penetration testing and

dynamic analysis (52.95%), related to their test basis

within the secure software development life cycle.

Table 6: Security testing techniques classiﬁcation according

to how they are executed.

Type Studies Count %

Dynamic testing S03, S04, S10, S12, S14, S15,

S16, S19, S22, S23

10 58.82

Static testing S06, S08, S24, S25, S27 5 29.41

Both S01, S11 2 11.76

Automated test-

ing

S03, S04, S06, S10, S14, S15,

S16, S19, S24

9 52.94

Semi-automated

testing

S01, S08, S12, S22, S23, S27 6 35.29

Manual testing S11, S25 2 11.76

From Table 6, we can derive the following conclu-

sions:

• Dynamic Testing Dominates. Dynamic testing

techniques, which involve the execution of soft-

ware to identify vulnerabilities, are the most

prevalent. They account for 58.82% of the studies

included in the table. This indicates the signif-

icance of evaluating mobile applications in run-

time and assessing their behavior in real-world

scenarios.

A Systematic Mapping Study in Security Software Testing for Mobile Devices

Table 7: Security testing techniques classiﬁcation acccord-

ing to their test basis within the secure software develop-

ment life cycle.

Type Studies Count %

Penetration testing

and dynamic analysis

S03, S04, S06, S10, S11,

S12, S14, S15, S16, S19,

S22, S23, S24, S25, S27

15 88.23

Code-based testing

and static analysis

S01, S08 2 11.76

Model-based secu-

rity testing

- - -

Security regression

testing

- - -

• Static Testing. Static testing techniques, which

analyze the source code or binary without exe-

cution, constitute 29.41% of the studies. These

techniques focus on identifying vulnerabilities

through code analysis and provide insights into

potential security weaknesses.

• Combined Approaches. Some studies employ

both dynamic and static testing techniques, rep-

resenting 11.76% of the studies. This approach

allows for a comprehensive evaluation of mobile

application security by leveraging the strengths of

both dynamic and static analysis.

From Table 7, the following conclusions can be

drawn:

• Penetration Testing and Dynamic Analysis. The

majority of studies (88.23%) focus on penetration

testing and dynamic analysis techniques. These

techniques involve simulating attacks and analyz-

ing the application’s response to uncover vulnera-

bilities. This indicates the importance of actively

testing the security of mobile applications during

their development and deployment.

• Code-Based Testing and Static Analysis. A

smaller proportion (11.76%) of the studies uti-

lize code-based testing and static analysis tech-

niques. These techniques involve analyzing the

source code or binary to identify security issues.

Although less prevalent, they provide valuable

insights into the security of mobile applications

from a code perspective.

• Model-Based Security Testing and Security Re-

gression Testing. These categories have no studies

identiﬁed in the table, suggesting that they may be

less explored or represented in the literature in the

context of mobile application security testing.

The tables provide an overview of the classiﬁca-

tion of security testing techniques based on execution

approach and software development life cycle. The

ﬁndings highlight the prevalence of dynamic testing

techniques and penetration testing in the evaluation

of mobile application security. However, the presence

of static analysis and code-based testing techniques

demonstrates the signiﬁcance of considering vulnera-

bilities from a code perspective as well. The absence

of studies in certain categories suggests areas for fur-

ther exploration and research in mobile application

security testing.

In summary, the results of this RQ show that we

identiﬁed a great variety of MST although the lack

of explicit classiﬁcation in terms of white box and

black box testing. We also noticed that most of the

studies were related to MST in third-party apps, and

in this scenario, tests were black box since the tester

does not have access to the source code of the appli-

cation being tested (Myers et al., 2011). Regarding

the software development life cycle, model-based se-

curity testing and security regression testing were not

mentioned. The low rate of Manual testing (11.76%)

indicated that researchers are more likely to develop

automated or semi-automated testing in their studies.

RQ1.2 - How Is the Security Mobile

Testing Documented by the Authors?

This question aims to make a classiﬁcation of the se-

lected studies in terms of criteria and documentation

used in the elaboration of the described tests. Most

studies described the test process or implementation

of the proposed tool but did not demonstrate the test

process in detail.

Table 8 provides an overview of how the selected

studies documented their security mobile testing pro-

cesses. The table highlights the types of documenta-

tion used, such as describing the test process, present-

ing case studies, identifying test cases, documenting

the development process, and providing additional in-

formation. It also indicates instances where formal

documentation was lacking or not speciﬁed.

In study S01, 20 applications were examined re-

garding the effectiveness of their approach and 24

Intents and 3 Content Providers vulnerabilities were

found among 195 weaknesses, showing the effective-

ness of their automated testing approach. Study S06

presents several case studies to demonstrate the effec-

tiveness of their prototype.

S8 identiﬁed 53 unique authentication unit test

cases, organized by ﬁve features (Token Authentica-

tion, Token Manipulation, Refresh Token, Login and

Logout) and 17 scenarios.

S10 brieﬂy describes the tests but there is no clear

documentation of them. Furthermore, the study re-

ports extra information about the system and apps

used during the experiment with a virtual machine and

Android version 2.3.3. S11 analyzed the compliance

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

Table 8: Classiﬁcation of Security Mobile Testing Docu-

mentation.

Study Type Documentation Description

S01 Automated

testing

Described the test process and identiﬁed

vulnerabilities found in the applications.

S06 Prototype Presented case studies to demonstrate the

effectiveness of the prototype.

S08 Token au-

thentication

Identiﬁed authentication unit test cases and

organized them by features and scenarios.

S10 Automated

testing

Brieﬂy described the tests without clear

documentation. Provided additional infor-

mation about the system and apps used.

S11 Compliance

analysis

Analyzed the compliance of mobile bank-

ing applications to OWASP mobile security

risks.

S12,

S16,

S24

Tools/systems Tests were performed using the mentioned

tools/systems but no further documentation

provided.

S14,

S04

Development

process

Described the development process of the

tool implementation and provided case

studies for validation.

S22 Security

testing

Presented scenarios for security testing and

vulnerability attacks.

S23,

S25

Strategy ap-

plied

Showed the strategy applied without formal

documentation.

S15,

S19

Automated

test case

generation

Presented automated test case generation

process.

S03,

S27

Not speci-

ﬁed

No mention of any type of documentation.

of mobile banking applications to the OWASP (Open

Web Application Security Project) listed mobile secu-

rity risks. In S12, S24 and S16, the tests were done

using the tools/system mentioned, but no further in-

formation on how they were performed.

All the process is described by the authors in stud-

ies S14 and S04, the authors narrated the development

process of the tool implementation and the case stud-

ies used to validate the new proposal. Using three

devices, LG Nexus 5, Sony Xperia E3 dual and Sam-

sung A5, S22 presented 2 scenarios. The ﬁrst, secu-

rity testing scenario, intended to ﬂood the browser us-

ing a single URL opened by the user and the second,

vulnerability attacks, sent a few well-crafted packets

or messages that take advantage of an existing vulner-

ability in a previously target phone.

Studies S23 and S25 showed the strategy applied

but no formal documentation. Test case automated

generation was presented in studies S15 and S19. S03

and S27 did not mention any type of documents.

The ﬁndings from this research question demon-

strate the need for further research on software test-

ing documentation beyond MST. While some studies

provided detailed documentation of their testing pro-

cesses, others lacked formal documentation or did not

specify any documentation at all. This suggests an

opportunity for future investigations to explore and

establish guidelines for documenting security mobile

testing effectively.

RQ1.3 - What Are the Pros and Cons of

These Techniques, Approaches, Methods,

Tools or Processes to Mobile Security

Testing?

The results show that the majority of the studies

(58.82%) provided either positive or negative aspects

and (17.64% ) provided both positive and negative as-

pects, as shown in Table 9. Furthermore, there was

a signiﬁcant amount of studies (41,17%) that did not

answer this RQ: S01, S08, S11, S12, S19, S23, and

S25.

Table 9: Advantages and disadvantages of selected studies.

ID Advantages Disadvantages

S03 FireDroid is able to monitor any

application and system code exe-

cuted in a device. Making it very

effective.

Not Mentioned

S04 It introduced automated security

testing based on existing func-

tional test cases using fuzzing

heuristics, ﬁnding security vul-

nerabilities more efﬁciently.

potential weaknesses in

the input validation of

input type, lengths and

value handling of the

service.

S06 SmartDroid is very effective in

revealing UI-based trigger con-

ditions automatically.

The system was not

tested by a large

amount of Android

applications.

S10 efﬁciency, avoid undetected con-

trols or Activities in human in-

teraction.

Android’s system mod-

iﬁcation.

S14 tool accessibility Not Mentioned

S15 automated test case generation,

code coverage and uncovers po-

tential security defects, highly

scalable.

Not Mentioned

S16 Accurate calculate the number

of vulnerable apps. Detect

all vulnerability levels, complete

basic functional requirements,

and simulate real network envi-

ronment.

Not Mentioned

S22 Not Mentioned NFC-enabled mobile

phones still have weak-

ness in security issues.

S24 Reduction of false positives pro-

duced by security analysis and

time a human analyst must spend

examining a vulnerability.

Not Mentioned

S27 Better result in false positive. Cannot cover all possi-

ble vulnerabilities.

FireDroid (S03). The main advantage highlighted

over other Android security approaches is the ability

to monitor any application and system code running

A Systematic Mapping Study in Security Software Testing for Mobile Devices

on a device. This makes FireDroid a powerful tool

for detecting potential security breaches.

Fuzzino (S04). Fuzzino is a test data generation

tool used to perform fuzzing tests on applications.

This approach aims to insert invalid, unexpected, or

malicious input into a program to identify potential

vulnerabilities or security holes.

SmartDroid (S06). SmartDroid is effective in

automatically revealing UI-based trigger conditions,

which is valuable for detecting security vulnerabili-

ties in Android applications. However, further testing

at scale is needed to validate its effectiveness in dif-

ferent scenarios.

TAINTDroid (S10). Combining TAINTDroid

with the Android emulator allows you to simulate var-

ious scenarios and interactions, allowing for an in-

depth analysis of mobile application security. How-

ever, the Android system modiﬁcation is mentioned

as a disadvantage.

AndroBugs (S14). The main advantage is the ac-

cessibility of the AndroBugs framework, which al-

lows security analysts to identify vulnerabilities in

mobile applications. However, potential limitations

are not explicitly mentioned.

Automated Testing Approach (S15). The main

advantage is the automated generation of test cases,

combining intelligent heuristics and software analysis

techniques. However, the automated approach may

not cover all scenarios and vulnerabilities.

Tao et al. (S16). The main advantage is the ability

to detect vulnerabilities at different vulnerability lev-

els. However, effectiveness may depend on testers’

experience.

Fahrianto et al. (S22). The study analyzes the

security of NFC devices, highlighting weaknesses in

certain modes of operation.

Garcia et al. (S24). The ability to identify vulner-

abilities and determine whether they are exploitable

is a positive advantage. The approach reduces false

positives and the time required for human analysis.

Gajrani et al. (S27). The multi-tier approach

presents better results in relation to false positives, but

it still cannot cover all possible vulnerabilities.

RQ1.4 - What Are the Current Trends of

Mobile Security Testing?

The selected studies were published between 2012

and 2021 as shown in Figure 2. The higher number

of publications occurred in 2017 and 2020 with three

studies each (2017 - S11, S12, S24 and 2020 - S04,

S08, S27) followed by 2012, 2013, 2014 and 2016

with two studies (2012 - S06, S15; 2013 - S03, S19;

2014 - S01, S10; and 2016 - S22, S25). The least

amount occurred in 2015, 2018 and 2021 with only

one study (2015 - S16; 2018 - S14; and 2021 - S23)

and in 2019 no studies were found.

Figure 2: Distribution of number of selected studies by year.

Although the apparent constancy of studies num-

ber on MST, it is hard to say that there is a trend in

the topic raised by this SMS. As presented in RQ1.1,

most of the selected studies are related to dynamic,

automated, and penetration testing and dynamic anal-

ysis. This result may indicate the beneﬁts of auto-

mated testing, once compared to manual testing, the

former is more competitive (Tao et al., 2015).

In Figure 3, we present the distribution of the re-

search about MST over the years.

Figure 3: Trend in MST Research.

RQ1.5 - What Are the Future Prospects

of Mobile Security Testing (if

Applicable)?

Most of the studies propose improvements for their

works (70.58%), indicating the gaps and the need of

complementary studies, except studies S08, S10, S12,

S23 and S24.

Table 10 summarizes the future directions and

proposed improvements in MST studies. Each study

(identiﬁed by the study code) suggests speciﬁc areas

of improvement, providing insights into the ongoing

research efforts in the ﬁeld of mobile security testing.

The results of this research question are important

to verify the need for complementary studies regard-

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

Table 10: Future Directions and Proposed Improvements in

MST Studies.

Study Future Directions/Proposed Improvements

S01 Explore automatic analysis of results and discover additional

weakness types and attack behaviors.

S03 Improve the developed tool by incorporating dynamic anal-

ysis techniques like information ﬂow and taint analysis.

S04 Enhance Fuzzino by adding more fuzzing heuristics and

cross-site scripting vulnerability detection.

S11

and

S14

Extend the approach to other mobile platforms, such as

BlackBerry, Windows, and iOS.

S15 Improve test case generation techniques and create a graph-

ical reporting environment.

S16 Extend the range of security tests by including more tools

and expanding the scope of testing.

S19 Extend the generation of partial speciﬁcations and integrate

them to test composite components.

ing MST and add new scenarios of testing, includ-

ing other platforms, improvements of what was de-

veloped, and the inclusion of automated analysis.

RQ1.6 - What Is the Difference Between

Mobile and non-mobile Security Testing?

The purpose of this research question was to under-

stand the signiﬁcant difference between mobile and

non-mobile security testing. From the selected stud-

ies, only study S01 mentioned the topic in related

work pointing out that non-mobile tests as traditional

testing techniques and applied to desktop and web ap-

plications. We infer that our research string, includ-

ing mobile in its terms, prevents us from ﬁnding more

deﬁnitions in this context.

5 CONCLUSIONS AND FUTURE

WORK

In this work, we conducted an SMS to understand the

state-of-the-art mobile security testing techniques bet-

ter and investigate the strategies used. We identiﬁed

as contributions frameworks, approaches, tools, sys-

tems, methods and prototypes, showing the range of

options for MST. We also identiﬁed that most of these

contributions did not explicitly classify their studies

related to code analysis, classifying one of them as

white box and three studies as black-box testing. In

addition, dynamic testing represents 58.82% of se-

curity testing according to how they are executed,

followed by static testing, 29.41%, and studies that

present both of them 11.76%. It’s important to high-

light that automated and semi-automated testing rep-

resent 88.23% of the studies and only 11.76% used

manual testing and we infer this as a tendency in MST.

According to the techniques’ test basis with the

secure software development lyfe cycle, penetration

testing and dynamic analysis (52.95%) and Code-

based security testing and static analysis (11.76%)

were the only types found, excluding model-based se-

curity testing and security regression testing as pre-

sented in RQ1.1, indicating a research gap and the

trends of this ﬁeld. To summarize, MST tends to be

mostly dynamic, automated testing and penetration

testing and dynamic analysis.

Among 17 identiﬁed studies, we identiﬁed a great

diversity of MST documents but also the absence of

formal documentation in most of the studies, suggest-

ing the need for additional research that elucidates

software testing documentations beyond MST. In ad-

dition, some of the studies did not provide the ad-

vantages and disadvantages of applying the developed

contribution and as future work, they suggest the in-

clusion of other platforms, improvement of what was

developed and the inclusion of automated analysis.

The results presented in this SMS can be very

useful to testers and researchers since it gathers the

current state-of-the-art regarding mobile security test-

ing techniques and indicates its prospects. As fu-

ture work, we intend to continue this systematic map-

ping study to explore how security mobile testing is

performed in the industrial context, gathering the re-

sults found with those techniques by creating a cata-

log with good MST practices.

REFERENCES

Al-Ahmad, A. S., Kahtan, H., Hujainah, F., and Jalab,

H. A. (2019). Systematic literature review on penetra-

tion testing for mobile cloud computing applications.

IEEE Access, 7:173524–173540.

Albuquerque, A. B. and Nunes, F. J. B. (2016). A pro-

posal for systematic mapping study of software secu-

rity testing, veriﬁcation and validation. International

Journal of Computer and Information Engineering,

10(6):1038–1044.

Alturki, R. and Gay, V. (2019). Usability attributes for mo-

bile applications: a systematic review. Recent trends

and advances in wireless and IoT-enabled networks,

pages 53–62.

Avancini, A. and Ceccato, M. (2013). Security testing of

the communication among android applications. In

2013 8th International Workshop on Automation of

Software Test (AST), pages 57–63.

Aydos, M., Aldan, C¸ ., Cos¸kun, E., and Soydan, A.

(2022). Security testing of web applications: A sys-

tematic mapping of the literature. Journal of King

Saud University-Computer and Information Sciences,

34(9):6775–6792.

Copeland, L. (2004). A practitioner’s guide to software test

design. Artech House.

A Systematic Mapping Study in Security Software Testing for Mobile Devices

Dennis, A., Wixom, B., and Tegarden, D. (2009). Systems

analysis and design with oop approach with uml 2.0,

4th editio.

Felderer, M., B

uchler, M., Johns, M., Brucker, A. D., Breu,

R., and Pretschner, A. (2016). Security testing: A sur-

vey. In Advances in Computers, volume 101, pages

1–51. Elsevier.

Garousi, V. and M

antyl

a, M. V. (2016). A systematic liter-

ature review of literature reviews in software testing.

Information and Software Technology, 80:195–216.

Guo, C., Xu, J., Yang, H., Zeng, Y., and Xing, S. (2014).

An automated testing approach for inter-application

security in android. In Proceedings of the 9th Interna-

tional Workshop on Automation of Software Test, AST

2014, page 8–14, New York, NY, USA. Association

for Computing Machinery.

Hamza, Z. and Hammad, M. (2020). Testing approaches

for web and mobile applications: An overview. Inter-

national Journal of Computing and Digital Systems,

9(4):657–664.

Junior, M. C., Amalﬁtano, D., Garces, L., Fasolino, A. R.,

Andrade, S. A., and Delamaro, M. (2022). Dynamic

testing techniques of non-functional requirements in

mobile apps: A systematic mapping study. ACM Com-

puting Surveys (CSUR), 54(10s):1–38.

Kitchenham, B. and Charters, S. (2007). Guidelines for per-

forming systematic literature reviews in software en-

gineering.

La Polla, M., Martinelli, F., and Sgandurra, D. (2012). A

survey on security for mobile devices. IEEE commu-

nications surveys & tutorials, 15(1):446–471.

endez Porras, A., Quesada L

opez, C. U., and Jenk-

ins Coronas, M. (2015). Automated testing of mobile

applications: A systematic map and review.

Musthafa, F. N., Mansur, S., and Wibawanto, A. (2020).

Automated software testing on mobile applications:

A review with special focus on android platform. In

2020 20th International Conference on Advances in

ICT for Emerging Regions (ICTer), pages 292–293.

IEEE.

Myers, G. J., Sandler, C., and Badgett, T. (2011). The art of

software testing. John Wiley & Sons.

Oliveira, M. d., Seabra, R. D., and Mattedi, A. P. (2019).

Usabilidade de aplicativos de seguranc¸a colaborativa

para smartphones: uma revis

ao sistem

atica. Revista

de Sistemas e Computac¸

ao-RSC, 8(2).

Petersen, K., Vakkalanka, S., and Kuzniarz, L. (2015).

Guidelines for conducting systematic mapping stud-

ies in software engineering: An update. Information

and software technology, 64:1–18.

Russello, G., Jimenez, A. B., Naderi, H., and van der Mark,

W. (2013). Firedroid: Hardening security in almost-

stock android. In Proceedings of the 29th Annual

Computer Security Applications Conference, ACSAC

’13, page 319–328, New York, NY, USA. Association

for Computing Machinery.

Santos, P., Peixoto, M., and Vilela, J. (2021). Understand-

ing the information security culture of organizations:

Results of a survey. In XVII Brazilian Symposium on

Information Systems, pages 1–8.

Seng, L. K., Ithnin, N., and Said, S. Z. M. (2018). The

approaches to quantify web application security scan-

ners quality: A review. International Journal of Ad-

vanced Computer Research, 8(38):285–312.

Shezan, F. H., Afroze, S. F., and Iqbal, A. (2017). Vulner-

ability detection in recent android apps: An empirical

study. In 2017 International Conference on Network-

ing, Systems and Security (NSysS), pages 55–63.

Soares, A., Vilela, J., Peixoto, M., Santos, D., and Silva,

C. (2023). Perceptions of practitioners on security-

related software testing in a mobile software develop-

ment company. In Proceedings of the XIX Brazilian

Symposium on Information Systems, pages 348–355.

Souza, M., Villanes, I. K., Dias-Neto, A. C., and Endo, A. T.

(2019). On the exploratory testing of mobile apps. In

Proceedings of the IV Brazilian Symposium on Sys-

tematic and Automated Software Testing, pages 42–

51.

Sun, M., Wei, T., and Lui, J. C. (2016). Taintart: A prac-

tical multi-level information-ﬂow tracking system for

android runtime. In Proceedings of the 2016 ACM

SIGSAC Conference on Computer and Communica-

tions Security, CCS ’16, page 331–342, New York,

NY, USA. Association for Computing Machinery.

Tao, D., Lin, Z., and Lu, C. (2015). Cloud platform based

automated security testing system for mobile internet.

Tsinghua Science & Technology, 20:537–544.

Tramontana, P., Amalﬁtano, D., Amatucci, N., and Fa-

solino, A. R. (2019). Automated functional testing

of mobile applications: a systematic mapping study.

Software Quality Journal, 27:149–201.

Umar, M. A. (2019). Comprehensive study of software test-

ing: Categories, levels, techniques, and types. Inter-

national Journal of Advance Research, Ideas and In-

novations in Technology, 5(6):32–40.

Wang, Y. (2015). An automated virtual security testing plat-

form for android mobile apps. In 2015 First Con-

ference on Mobile and Secure Services (MOBISEC-

SERV), pages 1–2.

Zein, S., Salleh, N., and Grundy, J. (2016). A system-

atic mapping study of mobile application testing tech-

niques. Journal of Systems and Software, 117:334–

356.

Zhong, H. and Xiao, J. (2014). Design for a cloud-based

hybrid android application security assessment frame-

work. In 2014 10th International Conference on Re-

liability, Maintainability and Safety (ICRMS), pages

539–546.

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security
