Testing on Dynamically Adaptive Systems: Challenges and Trends

Isabely do Nascimento Costa

1 a

, Ismayle S. Santos

2 b

and Rossana M. C. Andrade

1 c

Federal University of Cear

a (UFC), Fortaleza, Brazil

Cear

a State University (UECE), Fortaleza, Brazil

Keywords:

Adaptive Systems, Software Testing, Systematic Review.

Abstract:

Dynamically Adaptive Systems (DAS) are systems capable of modifying themselves automatically according

to the surrounding environment. Traditional testing approaches are ineffective for these systems due to their

dynamic aspects, making fault detection complex. Although various testing approaches have been proposed

for DASs, there is no up-to-date overview of the approaches, challenges, and trends. This research therefore

presents the results of a systematic literature review to identify the challenges, approaches and trends in testing

dynamically adaptable systems. For this objective, 25 articles between 2020 and 2023 were analyzed to answer

our research questions. As a result, approaches and their characteristics were identiﬁed, such as what type of

system they can be applied to, what activity is included in the testing process, and at what level of testing. We

also highlighted challenges that are still being faced and trends in testing dynamically adaptive systems. For

a more in-depth analysis of the results related to the challenges, grounded theory procedures were applied to

organize them and encourage future research that seeks to overcome and mitigate them.

1 INTRODUCTION

Modern information systems are becoming increas-

ingly complex due to the growing use of mobile de-

vices and, consequently, the need for them to work

uninterruptedly in any environment. The software in-

dustry has had to adapt to these demands by using

highly distributed systems to meet this need. These

systems must integrate all available, highly special-

ized, and heterogeneous devices and data ﬂows op-

erating in a constantly changing environment with

ﬂuctuating network availability and resources. De-

veloping, conﬁguring, and maintaining these systems

is challenging, error-prone, and costly. One solution

to this problem is self-adaptation, and a dynamically

adaptive system (DAS) is capable of automatically

modifying itself in response to changes in its oper-

ating environment (Krupitzer et al., 2015).

However, these dynamic adaptations of systems,

while they are already in operation, can lead to unsafe

changes at runtime and can then lead to new risks of

bugs, unexpected interactions, performance degrada-

tion, and unwanted modes of operation (Lahami and

Krichen, 2021). In the context of DASs, traditional

https://orcid.org/0009-0008-5879-7469

https://orcid.org/0000-0001-5580-643X

https://orcid.org/0000-0002-0186-2994

testing approaches are ineffective due to the inher-

ent characteristics of these systems, and therefore, de-

tecting faults effectively is not a trivial task (Siqueira

et al., 2016).

Based on this challenge, various approaches have

already been proposed to solve the most diverse chal-

lenges listed in the literature, as we can ﬁnd in the

following works (de Sousa Santos et al., 2017), (Mat-

alonga et al., 2022), (Priya and Rajalakshmi, 2022)

and (Lahami and Krichen, 2021). However, there was

a lack of studies presenting an up-to-date overview of

the challenges of testing DASs and their approaches.

To contribute to future research related to testing in

DASs that seeks to solve these challenges, this re-

search proposes a systematic literature review with

the application of Grounded theory procedures. To

this end, two research questions were deﬁned, and 25

articles from the last three years (2020, 2021, 2022,

and early 2023) were analyzed.

The rest of this paper is organized into ﬁve sec-

tions: Section 2 describes the methodology adopted

in this research; Section 3 presents the results ob-

tained by the systematic review; Section 4 analyzes

the results obtained and presents the threats to valid-

ity; Section 5 presents the related work; and ﬁnally,

Section 6 summarizes the results and indicates future

work.

Costa, I., Santos, I. and Andrade, R.

Testing on Dynamically Adaptive Systems: Challenges and Trends.

DOI: 10.5220/0012555900003690

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 26th International Conference on Enterprise Information Systems (ICEIS 2024) - Volume 2, pages 129-140

ISBN: 978-989-758-692-7; ISSN: 2184-4992

129

2 METHODOLOGY

2.1 Background

This paper aims to present the challenges of test-

ing adaptive systems and identify current testing ap-

proaches and possible ways of testing DAS through

a systematic literature review. To this purpose, the

guideline of (Kitchenham et al., 2016) for Systematic

Literature Review (SLR) was followed. In addition,

procedures from Grounded Theory (GT) (Strauss and

Corbin, 1990) were applied to part of the data ob-

tained from the synthesis stage of the SLR.

2.2 Research Questions

The research questions were initially deﬁned based on

the objective of this study and are as follows:

• RQ1) What Are the Characteristics of Cur-

rent Approaches to Testing DAS? This research

question aims to present testing approaches for

DASs by categorizing the type of test the approach

performs, the level of testing and type of activity

the approach is inserted in, the type and domain

of the system under test the approach is applied

to, and when the approach is applied.

• RQ2) What Are the Current Challenges Re-

lated to Testing DAS? This research question

presents the challenges of testing DASs by catego-

rizing them using Grounded Theory procedures.

2.2.1 Extraction Questions

The following extraction questions were deﬁned to

obtain the information to answer the research ques-

tions. The correlation with the research questions can

be visualized through the IDs, where questions RQ1.1

to RQ1.3 support the search for the answer to question

RQ1, and RQ2.1 supports the search for the answer to

question RQ2.

• RQ1.1) What are the approaches to testing adap-

tive systems?

• RQ1.2) What are the System Under Test (SUT)

types of the approach?

• RQ1.3) Are the testing approaches applied at run-

time or design time?

• RQ2.1) What are the challenges of DAS testing?

2.3 Search Strategy

The strategy used to search for articles was an auto-

mated search. A search string deﬁned by (Siqueira

et al., 2021) was used. After all, it was the most up-

to-date systematic review (with papers up to 2019),

which had the characteristic of having a comprehen-

sive string because it used more generic keywords.

The guidelines of (Kitchenham et al., 2016) were fol-

lowed to validate the search strategy, starting with

identifying relevant electronic resources. Then, some

articles found by the string in the IEEE database were

analyzed, and based on the inclusion and exclusion

criteria, it was conﬁrmed that the string was provid-

ing satisfactory results. Finally, an automated search

was performed.

The motivation for a new systematic review rather

than an update of the review by (Siqueira et al., 2021)

was based on the 3PDF checklist (Mendes et al.,

2020) for deﬁning when to update a systematic re-

view. (Mendes et al., 2020) deﬁne an update of a sys-

tematic review only when the same methodology as

the previous review is followed. Neither is it possible

to compare the results of reviews that followed differ-

ent protocols. From this deﬁnition, differences were

noted compared to this review and the (Siqueira et al.,

2021), such as different databases, this work did not

use snowballing, how the systems were categorized,

different inclusion and exclusion criteria, the previous

review did not use a checklist to assess the quality of

the studies or grounded theory procedures to analyze

the results.

2.3.1 Databases

The databases selected for this work were IEEE

ACM

, Scopus

and ScienceDirect

. These databases

were chosen because of their widespread use by the

academic community. In addition, four databases

were chosen to cover a greater diversity of work.

2.3.2 Search String

The following search string was used:

(”Testing”) AND (”adaptive systems” OR

”adaptive system” OR ”context a ware” OR

”context-aware” OR ”context awareness” OR

”context-awareness” OR ”adaptive software” OR

”autonomic”)

2.3.3 Inclusion and Exclusion Criteria

The following inclusion and exclusion criteria were

used to select the articles:

https://ieeexplore.ieee.org/Xplore/home.jsp

https://dl.acm.org/

https://www.scopus.com/

https://www.sciencedirect.com/

ICEIS 2024 - 26th International Conference on Enterprise Information Systems

130

Inclusion Criteria: The article deals with testing

DASs and is a primary work.

Exclusion Criteria: Article in a language different

from English, an article published before 2020, and

an article dealing with network testing

2.4 Study Selection

In the conduction stage, 312 articles were found us-

ing the search string. A ﬁlter for possible duplicates

was carried out using the Parsifal

tool, which found

109 duplicates between the databases. The title and

abstract of the articles were then read using the inclu-

sion and exclusion criteria, giving a total of 25 articles

for analysis. The 25 articles are listed in Table 1.

2.5 Quality Assessment

To assess the quality of the 25 articles selected for the

study, they were analyzed according to a checklist for

assessing the quality of studies. This checklist

was

adapted to identify better information relevant to this

research, such as the description of the approach and

how it is presented, based on the checklist and evalu-

ation scale suggested by (Kitchenham et al., 2010).

Following the evaluation scale suggested by

(Kitchenham et al., 2010), ten articles answered “yes”

to all the questions, and 15 articles answered most

questions (but not all) with “yes”. The lowest percent-

age of questions answered with “yes” was 81.25%,

and the closer to 100%, the better the quality of the

work. This percentage was calculated by the number

of questions in the checklist divided by the number

of questions answered with “yes”. Thus, the articles

selected have an acceptable degree of quality.

2.6 Data Extraction

Three researchers were involved in this review, so

the selection activity was distributed between the two

of them, and the review and synthesis of the results

were shared between all those involved. In addition,

alignment meetings were held to ensure that the au-

thors agreed when extracting the information, and the

agreement index was calculated from the Kappa test

(Cohen, 1960) using the Jamovi tool (Jamovi, 2022)

to check whether the reviewers agreed. We obtained

a coefﬁcient of 0.8, which, within the scale of inter-

pretation indicated by (Kitchenham et al., 2010), ﬁts

”Substantial” and is considered a good coefﬁcient of

https://parsif.al/

The completed checklist can be found at

https://github.com/isabelycosta/Testing-DAS-Challenges-

and-Trends

agreement between authors. The extraction stage was

then carried out using the questions mentioned in the

2.2.1 section.

2.7 Data Synthesis and Aggregation

Strategy

The data collected was synthesized in two forms:

RQ1.1, RQ1.2, and RQ1.3, which were summa-

rized and analyzed to answer research question RQ1.

Meanwhile, the data collected by question RQ2 was

analyzed and synthesized using Grounded Theory

processes described in Section 2.7.1.

2.7.1 Grounded Theory

For the data collected in the extraction stage related to

research question RQ2, Grounded Theory procedures

were applied to consolidate the results obtained and

systematize the analysis of this qualitative data. The

procedures carried out were:

Open Coding: This stage involved deﬁning the codes

and code identiﬁers, shown in Table 4, and associat-

ing them with the translated citations. The citations

would be excerpts from the article collected in the

phase described in 2.7. The codes were drawn up

from the citations themselves.

Axial Coding: After open coding, the categories and

sub-categories were deﬁned at this stage based on the

previously deﬁned codes. In addition, the categories

and sub-categories were related using propositions of

causes and effects, intervening conditions, and action

strategies. The propositions used were: is associated

with, is the cause of, and is part of the.

Selective Coding: Finally, in this stage, the central

category was deﬁned, and the relationships between

categories and sub-categories were reviewed. A net-

work view was created to improve data visualization.

2.8 Reporting

Finally, in the ﬁnal stage of presenting the results, the

research and extraction questions were used as a refer-

ence for organizing the sections. At the same time, the

discussion section was structured following the SLR

objective mentioned in Section 2.1.

3 RESULTS

After applying the process described in Section 2, 25

articles were selected to answer the research ques-

tions. These articles are listed in Table 1. In ad-

dition, each paper is accompanied by its reference

Testing on Dynamically Adaptive Systems: Challenges and Trends

131

and the type of system dealt with in the paper’s test-

ing approach (i.e., Android, Web, Embedded Soft-

ware, Internet of Things (IoT), Cyber-Physical Sys-

tems (CPS), and Undeﬁned. A discussion of system

types is provided in subsection 3.2.2.

Table 1: Selected papers.

Ref Title SUT

(Michaels

et al., 2022)

Data Driven Testing

for Context Aware

Apps

Android

(Dadeau

et al., 2022)

Online Testing of

Dynamic Recon-

ﬁgurations w.r.t.

Adaptation Policies

Undeﬁned

(Fanitabasi

et al., 2020)

A self-integration

testbed for decentral-

ized socio-technical

systems

IoT

(dos Santos

et al., 2021)

Runtime testing of

context-aware vari-

ability in adaptive

systems

Android

(Piparia

et al., 2021)

Combinatorial Test-

ing of Context

Aware Android

Applications

Android

(DeVries

et al., 2021)

Analysis and Mon-

itoring of Cyber-

Physical Systems

via Environmental

Domain Knowledge

& Modeling

CPS

(Chen et al.,

2021b)

Context-Aware

Regression Test

Selection

Web

(Mandrioli

and Maggio,

2022)

Testing Self-

Adaptive Software

With Probabilis-

tic Guarantees on

Performance Met-

rics: Extended and

Comparative Results

Undeﬁned

(Shaﬁei and

Rafsanjani,

2020)

A Test Case Design

Method for Context

Aware Android Ap-

plications

Android

(Mirza et al.,

2021)

ContextDrive: To-

wards a Functional

Scenario-Based

Testing Framework

for Context-Aware

Applications

Undeﬁned

(Yigitbas,

2020)

Model-Driven Engi-

neering and Usability

Evaluation of Self-

Adaptive User Inter-

faces

Undeﬁned

(Mandrioli

and Maggio,

2020)

Testing Self-

Adaptive Software

with Probabilis-

tic Guarantees on

Performance Metrics

Undeﬁned

(de Almeida

et al., 2020a)

Context-Aware An-

droid Applications

Testing

Android

(de Almeida

et al.,

2020b)

ENVIAR: ENVIron-

ment DAta Simula-

toR

Android

(Chen et al.,

2021a)

Simulated or Phys-

ical? An Empirical

Study on Input

Validation for

Context-Aware Sys-

tems in Different

Environments

CPS

(Doreste and

Travassos,

2023)

CATS: A Testing

Technique to Support

the Speciﬁcation

of Test Cases for

Context-Aware

Software Systems

Undeﬁned

(Usman

et al., 2020)

TEGDroid: Test case

generation approach

for android apps con-

sidering context and

GUI events

Android

(Doreste and

Travassos,

2020)

Towards supporting

the speciﬁcation

of context-aware

software system test

cases

Undeﬁned

(Yi et al.,

2022)

Improving the Ex-

ploration Strategy of

an Automated An-

droid GUI Testing

Tool based on the Q-

Learning Algorithm

by Selecting Poten-

tial Actions

Android

(Dadeau

et al., 2020)

Testing adaptation

policies for software

components

CPS

ICEIS 2024 - 26th International Conference on Enterprise Information Systems

132

Table 1: Selected papers (cont.).

(Dadeau

et al., 2021)

Automated Gen-

eration of Initial

Conﬁgurations for

Testing Component

Systems

Undeﬁned

(Maurio

et al., 2021)

Agile services and

analysis framework

for autonomous and

autonomic critical

infrastructure

CPS

(Silva, 2020) Adaptation oriented

test data generation

for Adaptive Systems

Undeﬁned

(Chen et al.,

2022)

Simulation Might

Change Your Results:

A Comparison of

Context-Aware Sys-

tem Input Validation

in Simulated and

Physical Environ-

ments

CPS

(Wang et al.,

2023)

Design and imple-

mentation of a testing

platform for ship con-

trol: A case study on

the optimal switching

controller for ship

motion

Embedded

3.1 Overview

A ﬁlter of articles found by year of publication was

carried out to analyze the number of papers related

to testing approaches in DASs in the last four years.

The highest number of publications was 2020 (10 arti-

cles), followed by 2021 (8 articles), 2022 (5 articles),

and the lowest number 2023 (2 articles). The low

number of articles in 2023 is expected because the

database search was carried out until the beginning of

2023, on March 16, 2023.

The selected papers were also categorized by

database, nine publications were identiﬁed in Sco-

pus[(Usman et al., 2020), (Doreste and Travassos,

2020),(Dadeau et al., 2020), (Dadeau et al., 2021),

(Yi et al., 2022), (Chen et al., 2022), (Dadeau

et al., 2022), (Michaels et al., 2022), (Maurio et al.,

2021)], 7 in IEEE Xplorer[(Piparia et al., 2021),

(DeVries et al., 2021), (Chen et al., 2021b), (Man-

drioli and Maggio, 2022), (Shaﬁei and Rafsanjani,

2020), (Mirza et al., 2021), (Silva, 2020)], 6 in ACM

[(Yigitbas, 2020), (Mandrioli and Maggio, 2020),

(de Almeida et al., 2020a), (Chen et al., 2021a),

(Doreste and Travassos, 2023), (de Almeida et al.,

2020b)], and 3 in ScienceDirect[(Fanitabasi et al.,

2020), (dos Santos et al., 2021), (Wang et al., 2023)].

3.2 RQ1) What Are the Characteristics

of Current Approaches to Testing

DAS?

In this Section, the results obtained from the extrac-

tion questions RQ1.1, RQ1.2 and RQ1.3 that con-

tribute to answering the research question RQ1 are

presented.

3.2.1 Characteristics of the Approaches

The types and levels of testing from Pierre and

Richard (Pierre Bourque, 2014) and the deﬁnitions of

testing activities from Garousi et al. (Garousi et al.,

2020) were used to categorize the approaches. Thus,

the approaches are listed in Table 2 by type of test

(e.g., Performance test), by the level of the test (e.g.,

Unit), and ﬁnally by type of activity (e.g., Test-case

design(criteria-based)). It is important to note that

the testing activity indicated in the table is related to

the ﬁnal product of the approach, which means that

even though the approach helps with other activities,

only the ﬁnal product was considered, considering

this is the objective of the approach. In addition, the

acronyms “I” and “S” were used to indicate Integra-

tion and System levels in the testing level column, re-

spectively. These deﬁnitions are presented below:

Type of test (Pierre Bourque, 2014):

Acceptance testing determines whether a system

satisﬁes its acceptance criteria, usually by checking

desired system behaviors against the customer’s

requirements;

Regression testing is the selective retesting of a

system or component to verify that modiﬁcations

have not caused unintended effects and that the

system or component still complies with its speciﬁed

requirements;

Performance testing veriﬁes that the software meets

the speciﬁed performance requirements and assesses

performance characteristics—for instance, capacity

and response time.

Security testing is focused on the veriﬁcation that

the software is protected from external attacks. In

particular, security testing veriﬁes the conﬁdentiality,

integrity, and availability of the systems and its data;

Interface testing aims at verifying whether the

components interface correctly to provide the correct

exchange of data and control information.

Testing level (Pierre Bourque, 2014):

Integration testing is the process of verifying the

interactions among software components;

Testing on Dynamically Adaptive Systems: Challenges and Trends

133

System testing is concerned with testing the behavior

of an entire system

Testing activity (Garousi et al., 2020):

Test-case design (criteria-based):Designing test

suites (set of test cases) or test requirements to sat-

isfy coverage criteria;

Test execution: Running test cases on the software

under test (SUT) and recording the results.

Table 2: Categorization of approaches by type, level and

testing activity.

Ref Testing type Testing

level

Testing

activity

(Fanitabasi

et al.,

2020)

Performance I Test

execution

(dos San-

tos et al.,

2021)

Acceptance S Test

execution

(Piparia

et al.,

2021)

Acceptance S Test

execution

(DeVries

et al.,

2021)

Acceptance S Test

execution

(Chen

et al.,

2021b)

Regression S Test

execution

(Mandrioli

and Mag-

gio, 2022)

Performance S Test

execution

(Shaﬁei

and Raf-

sanjani,

2020)

Acceptance S Test-case

design

(criteria-

based)

(Mirza

et al.,

2021)

Acceptance S Test

execution

(Yigitbas,

2020)

Interface S Test

execution

(Mandrioli

and Mag-

gio, 2020)

Performance S Test

execution

(de Almeida

et al.,

2020a)

Acceptance S Test

execution

(Chen

et al.,

2021a)

Acceptance S Test

execution

(Doreste

and

Travassos,

2023)

Acceptance S Test-case

design

(criteria-

based)

(Usman

et al.,

2020)

Acceptance S Test

execution

(Doreste

and

Travassos,

2020)

Acceptance S Test-case

design

(criteria-

based)

(Dadeau

et al.,

2020)

Acceptance S Test

execution

(Dadeau

et al.,

2021)

Acceptance S Test

execution

(Yi et al.,

2022)

Acceptance S Test

execution

(Chen

et al.,

2022)

Acceptance S Test

execution

(Dadeau

et al.,

2022)

Acceptance S Test

execution

(Michaels

et al.,

2022)

Acceptance S Test

execution

(Wang

et al.,

2023)

Acceptance S Test

execution

(Silva,

2020)

Acceptance S Test

execution

(de Almeida

et al.,

2020b)

Acceptance S Test

execution

(Maurio

et al.,

2021)

Security S Test

execution

Based on the categorization of Table 2 and fol-

lowing Pierre and Richard (Pierre Bourque, 2014)

deﬁnition, the percentage of functional and non-

functional testing approaches was analyzed. As a

result, we obtained 20 functional approaches (dos

Santos et al., 2021) (Piparia et al., 2021) (DeVries

et al., 2021) (Chen et al., 2021b) (Shaﬁei and Raf-

sanjani, 2020) (Mirza et al., 2021) (de Almeida et al.,

2020a) (Chen et al., 2021a) (Doreste and Travassos,

2023) (Usman et al., 2020) (Doreste and Travassos,

2020) (Dadeau et al., 2020) (Dadeau et al., 2021)

(Yi et al., 2022) (Chen et al., 2022) (Dadeau et al.,

2022) (Michaels et al., 2022) (Wang et al., 2023)

(Silva, 2020) (de Almeida et al., 2020b), includ-

ing Acceptance Testing and Regression Testing, and

ﬁve (Fanitabasi et al., 2020) (Mandrioli and Maggio,

2022) (Yigitbas, 2020) (Mandrioli and Maggio, 2020)

ICEIS 2024 - 26th International Conference on Enterprise Information Systems

134

(Maurio et al., 2021) non-functional approaches, di-

vided into Security Testing, Interface Testing, and

Performance Testing. The results are shown in Fig-

ure 1.

Figure 1: Percentage of functional and non-functional ap-

proaches.

3.2.2 Types of SUT Covered by the Approaches

Obtained from RQ1.2, this subsection presents the

number of articles for each type of system addressed

in the test approaches.

As shown in Table 1, it was unclear in most pa-

pers (9 papers) what type of SUT the approach is

aimed. However, the main types identiﬁed were An-

droid (8 papers), Cyber-physical systems (CPS) (5 pa-

pers), and Web, IoT, and Embedded with one paper

each. Figure 2 shows the percentage of target system

types per publication.

Figure 2: Percentage of target system types per publication.

3.2.3 Characteristics of the Execution

Approaches

From RQ1.3, we obtained the characteristics related

to when the testing approaches are applied, whether

at runtime or design-time.

In most of the publications analyzed (10 articles),

it was not possible to identify whether the approach

presented by the author was applied at runtime or

design-time since the distinction between the two

types of execution is the environment in which the

approach will be executed. The articles do not ex-

plicitly state the focus. Then there are eight runtime

approaches, 5 in design-time and two that can be exe-

cuted at runtime and design-time. Table 3 relates the

runtime of the approach presented in the article to the

publication reference.

Table 3: Type of execution per article.

Types of

execution

Papers

Undeﬁned (Mirza et al., 2021), (Chen et al.,

2021a), (Doreste and Travassos,

2023), (Doreste and Travassos,

2020), (Dadeau et al., 2021), (Yi

et al., 2022), (Chen et al., 2022),

(Dadeau et al., 2022), (Wang et al.,

2023), (Silva, 2020)

Runtime (dos Santos et al., 2021), (Yigitbas,

2020), (de Almeida et al., 2020a),

(Usman et al., 2020), (Dadeau et al.,

2020), (Michaels et al., 2022),

(de Almeida et al., 2020b), (Maurio

et al., 2021)

Design-

time

(Fanitabasi et al., 2020), (Piparia

et al., 2021), (DeVries et al., 2021),

(Chen et al., 2021b), (Shaﬁei and

Rafsanjani, 2020)

Both (Mandrioli and Maggio, 2022),

(Mandrioli and Maggio, 2020)

3.2.4 Other Results

By analyzing the articles using RQ1, it was also pos-

sible to obtain data related to approaches that used op-

timization mechanisms in their structure. This result

is essential for understanding some of the challenges

addressed in Section 3.3.

Most articles do not use optimization in their

testing approaches (20 papers). Only ﬁve arti-

cles use optimization mechanisms to solve chal-

lenges related to DAS testing within the deﬁnition

of Search-Based Software Engineering (SBSE) (Si-

mons, 2013). The following paragraphs describe the

Testing on Dynamically Adaptive Systems: Challenges and Trends

135

mechanisms applied in these ﬁve articles (Fanitabasi

et al., 2020),(Mandrioli and Maggio, 2022), (Dadeau

et al., 2021), (Silva, 2020), (Maurio et al., 2021).

The optimization mechanism used in article

(Fanitabasi et al., 2020) was the I-EPOS system

(Pournaras et al., 2018), which performs a fully de-

centralized, self-organizing, and privacy-preserving

combinatorial optimization. I-EPOS optimizes an ob-

jective for the entire system, measured by a global

cost function. (Mandrioli and Maggio, 2022) test

problem was ﬁnding the limits for an adaptive sys-

tem’s performance parameter. To solve this prob-

lem, they deﬁned the following optimization prob-

lem: maximize the performance that can always be

guaranteed under the constraint that it cannot ex-

ceed what is experienced in the tests carried out.

In addition, the authors used classic statistical tools

such as Monte Carlo Simulations (Robert and Casella,

2005) and Extreme Value Theory (Haan and Ferreira,

2010). (Dadeau et al., 2021), in turn, present a ded-

icated combinatorial algorithm that is used to enu-

merate all possible non-symmetric solutions of the

CSP (Constraint Satisfaction Problem) deﬁned by the

component model in order to produce initial conﬁg-

urations. This algorithm integrates symmetry elim-

ination patterns that reduce the combinations to be

considered. Finally, (Maurio et al., 2021) use a

genetic algorithm-based constraint programming ap-

proach for their scheduler/allocator to produce an ini-

tial conﬁguration containing the start times and loca-

tions for all microservices. It is also worth mention-

ing that (Silva, 2020) claims to use an optimization

mechanism in his testing approach, but from the arti-

cle’s analysis, it was impossible to identify what this

mechanism might be and how it was used to support

the testing activity.

3.3 RQ2) What Are the Current

Challenges Related to Testing DAS?

In this Section, the results obtained from the extrac-

tion question RQ2.1 that contribute to answering the

research question RQ2 are presented.

3.3.1 Testing Challenges in DASs

Among the 25 papers analyzed, 18 articles (Fanitabasi

et al., 2020), (dos Santos et al., 2021), (Piparia et al.,

2021), (DeVries et al., 2021), (Mandrioli and Mag-

gio, 2022), (Mirza et al., 2021), (Yigitbas, 2020),

(Mandrioli and Maggio, 2020), (de Almeida et al.,

2020a), (Chen et al., 2021a), (Usman et al., 2020),

(Doreste and Travassos, 2020), (Dadeau et al., 2020),

(Yi et al., 2022), (Silva, 2020), (Dadeau et al., 2022),

(de Almeida et al., 2020b), (Maurio et al., 2021) men-

tioned challenges of testing DASs and only in 7 ar-

ticles (Chen et al., 2021b), (Shaﬁei and Rafsanjani,

2020), (Doreste and Travassos, 2023), (Dadeau et al.,

2021), (Chen et al., 2022), (Michaels et al., 2022),

(Wang et al., 2023) no mention of challenges was

identiﬁed.

Following the Grounded Theory procedures de-

scribed in Section 2, there was initially open cod-

ing where quotes related to the challenges of testing

DASs were identiﬁed, and codes associated with these

quotes were deﬁned. The codes in Table 4 were de-

ﬁned according to the reading of the selected quotes.

IDs were deﬁned for each code for better organization

and maintenance of the codes.

Table 4: Codes.

ID Codes

COD01 The adaptation layer that reacts explic-

itly to uncertainty

COD02 Difﬁculty in detecting incorrect conﬁg-

urations at runtime

COD03 How to identify an application’s context

events

COD04 Complexity of the testing activity

COD05 High cost of test maintenance

COD06 Inconsistent and inaccurate context data

COD07 Dependence on dynamic context moni-

toring at runtime for validation and ver-

iﬁcation

COD08 Different execution scenarios that can

be difﬁcult to reproduce manually

COD09 Fragmented ecosystem

COD10 Explosion of scenario combinations

COD11 Lack of runtime approaches

COD12 Context heterogeneity

COD13 Uncertainties in change that affect va-

lidity

COD14 Limited validation and veriﬁcation tech-

niques

COD15 Limited methodologies that do not con-

sider context

COD16 Limited methodologies that do not con-

sider adaptation

COD17 Continuous change and adaptation

COD18 Need for an adaptation modeling lan-

guage

COD19 Need for a context modeling language

COD20 Limited testing platforms

COD21 Large number of GUI and context

events

COD22 Costly time to test many combinations

COD23 Costly to test many combinations

ICEIS 2024 - 26th International Conference on Enterprise Information Systems

136

Table 5 refers to a part of the open coding stage

containing the association of the articles, with the ex-

tracted citation and the code related to the citation.

In the axial coding stage, the categories were

deﬁned based on the previously deﬁned codes:

The adaptation layer that explicitly reacts to uncer-

tainty (COD01), Complexity of the testing activity

(COD04), and Limitation of validation and veriﬁca-

tion techniques (COD14)

Table 5: Part of the open coding table.

Ref. Quote Code ID

(dos San-

tos et al.,

2021)

“Among the main chal-

lenges, the detection of

incorrect conﬁgurations

at runtime in the pres-

ence of context changes

can be highlighted. ”

COD02

Finally, in the selective coding stage, the cen-

tral category was ”Testing challenges in adaptive sys-

tems”. Figure 3 shows the ﬁnal result of the GT, with

the central category, sub-categories, and their rela-

tionships presented by a network view.

4 DISCUSSION

This section discusses the results presented in Section

3, which are organized according to the SLR’s objec-

tive of presenting challenges and trends. The “Chal-

lenges” subsection presents the challenges in testing

DASs that are cited in the papers. The “Trends” sub-

section presents data indicating research opportunities

in testing DASs.

4.1 Challenges

In order to identify the current challenges, the data

collected in Section 3.3 was analyzed to see how

many times the codes in Table 4 were cited in the

25 articles in this research. The most cited challenge

among the articles was Continuous change and adap-

tation (cited eight times), followed by Complexity of

the testing activity and Explosion of scenario com-

binations, both cited seven times. Other challenges

involve Uncertainties in change that affect validity

(cited six times), and ﬁnally, Limited methodologies

that do not consider context (cited four times).

Category 1 (The adaptation layer that reacts ex-

plicitly to uncertainty) and 3 (Limited validation and

More information is available at

https://github.com/isabelycosta/Testing-DAS-Challenges-

and-Trends

veriﬁcation techniques) have the most subcategories,

eight respectively. It can be seen that the signiﬁcant

challenges in testing DASs are the adaptation layer

related to:

• High cost of test maintenance

• Different execution scenarios that can be difﬁcult

to reproduce manually

• Context heterogeneity

• Uncertainties in change that affect validity

• Continuous change and adaptation

• Large number of GUI and context events

• Costly time to test many combinations

• Costly to test many combinations

Furthermore, the limitation of techniques to help

validate and verify these systems, which are associ-

ated with:

• Difﬁculty in detecting incorrect conﬁgurations at

runtime

• Dependence on dynamic context monitoring at

runtime for validation and veriﬁcation

• Lack of runtime approaches

• Limited methodologies that do not consider con-

text

• Limited methodologies that do not consider adap-

tation

• Need for an adaptation modeling language

• Need for a context modeling language

• Limited testing platforms

In addition, Category 2 (Complexity of the testing

activity) is also signiﬁcant, with four subcategories,

as it can also be seen that several factors make testing

these systems complex (How to identify an applica-

tion’s context events, Inconsistent and inaccurate con-

text data, and Explosion of scenario combinations).

4.2 Trends

Based on the subsection 3.2.1 results, there are few

approaches to non-functional testing; only ﬁve arti-

cles deal with this type of testing. In addition, only

the non-functional Performance, Interface, and Secu-

rity tests are covered. Furthermore, most of the ap-

proaches focus more on the activity of executing tests

on DASs and system-level testing. In this way, ap-

proaches to non-functional testing that focus on other

activities and levels of testing are an opportunity for

study.

Testing on Dynamically Adaptive Systems: Challenges and Trends

137

is associated with

Limited validation and

verification techniques

Testing challenges in

adaptive systems

The adaptation layer that reacts

explicitly to uncertainty

Uncertainties in change that

affect validity

is the cause of

Continuous change and

adaptation

is the cause of

Explosion of scenario

combinations

is associated with a

is the cause of

Context heterogeneity

is the cause of

Complexity of the testing activity

How to identify an application's

context events

is associated with

Different execution scenarios

that can be difficult to

reproduce manually

Fragmented ecosystem

Large number of GUI and

context events

Inconsistent and inaccurate

context data

is associated with

is the cause of

Costly time to test many

combinations

is associated with a

is the cause of

is part of the

High cost of test maintenance

Costly to test many

combinations

is the cause of

Lack of runtime approaches

Limited methodologies that do

not consider context

Limited testing platforms

is the cause of

Limited methodologies that do

not consider adaptation

Difficulty in detecting incorrect

configurations at runtime

Dependence on dynamic context

monitoring at runtime for

validation and verification

Need for an adaptation modeling

language

is associated with a

Need for a context modeling

language

is associated with a

Figure 3: Network view of categories and sub-categories.

Based on the results presented in Subsection 3.2.2,

there has been a lack of approaches focused on Em-

bedded, Web, and IoT systems in recent years. There-

fore, presenting new approaches for DAS aimed at

these systems could be an interesting topic for further

research.

In Subsection 3.2.3, it can be seen that most of the

studies that indicate the type of execution of the test-

ing approach are aimed at runtime testing, and only

two studies present approaches that can be both run-

time and design-time. Proposing testing approaches

for ﬂexible DASs that can be executed at runtime and

design-time could also be an opportunity for further

research.

Work-related to optimization approaches is

scarce. As presented in Section 3.2.4, only ﬁve

articles in 4 years address optimization mechanisms

within testing approaches in DASs. It is noteworthy

that the use of optimization mechanisms in testing

approaches for DAS may be promising due to the

beneﬁts already observed from using Search-Based

Software Testing in other domains (McMinn, 2011).

4.3 Threats to Validity

The main threat related to the process of this sys-

tematic review is selection bias. To mitigate this,

a strict research protocol was followed, with string

testing and discussions about the results between the

researchers at all stages of the review. In addition,

relevant Software Engineering databases were used,

which are the most frequently used in work in this

area. A second threat identiﬁed concerns the data ex-

traction process due to inaccuracy in extraction and

bias in data synthesis. The research protocol was

strictly followed to mitigate this threat, and the re-

searchers frequently reviewed the data collected.

5 RELATED WORKS

There are already papers in the literature that ad-

dress testing challenges and approaches in dynami-

cally adaptive systems. However, we have identiﬁed

a gap concerning an up-to-date overview of the chal-

lenges and characterization of testing approaches in

DAS. The following is a summary of the main related

works found in the literature so that it is possible to

see the differences to our work, whose main contribu-

tion is to provide an up-to-date overview (2020-2023)

of testing in DASs, seeking to identify its character-

istics, associated challenges and trends in the area of

testing in DASs.

(de Sousa Santos et al., 2017) present a quasi-

systematic review of the literature on test case design

techniques for CASS (Context Aware Software Sys-

tems) about quality characteristics evaluated, cover-

age criteria used, type of test and testing techniques.

The quick review by (Matalonga et al., 2022) presents

how researchers deal with context variation when test-

ing CASS (Context-Aware Software Systems) devel-

oped in non-academic environments. (Priya and Ra-

jalakshmi, 2022) provides an overview of the vari-

ous CAA (Context Aware Applications) testing tech-

niques available in the literature, research challenges

in testing such applications, and what can help re-

searchers in this ﬁeld. Finally, (Lahami and Krichen,

2021) present a review of the literature focused on

studies related to runtime testing in DAS, as well as

approaches, frameworks, and test isolation techniques

for these systems.

ICEIS 2024 - 26th International Conference on Enterprise Information Systems

138

6 CONCLUSION

Through the systematic review presented in this ar-

ticle, we can get an overview of the context of test-

ing DASs over the last three years and envision chal-

lenges and opportunities. We were also able to iden-

tify a need for approaches focused on Embedded,

Web, and IoT systems and that only two approaches

are ﬂexible in terms of the type of execution, being

possible to execute them at runtime and design-time.

In addition, there is a lack of approaches aimed at

non-functional testing that support various testing lev-

els and activities. Furthermore, of the 25 articles se-

lected, only ﬁve applied optimization mechanisms in

their testing approaches.

Finally, we realized several challenges related to

testing DASs, mainly linked to the adaptation layer,

the limited number of testing techniques, and the

complexity of testing these systems. Our results can

help future research on testing dynamically adap-

tive systems and encourage scientiﬁc production that

seeks to mitigate the challenges identiﬁed.

ACKNOWLEDGMENTS

The authors would like to thank CNPQ, which

provided the Industrial Technological Development

Scholarship of Isabely do Nascimento Costa DTI-B

384087 / 2023-0) and the Productivity Scholar-

ship in Technological Development and Innovative

Extension of Rossana M. C. Andrade 1D (N

306362

/ 2021-0). Furthermore, to Funcap/Iplanfor for their

ﬁnancial support in executing the ”Big Data Fort-

aleza” project.

REFERENCES

Chen, J., Qin, Y., Wang, H., and Xu, C. (2021a). Simulated

or physical? an empirical study on input validation for

context-aware systems in different environments. In-

ternetware ’20, page 146–155, New York, NY, USA.

Association for Computing Machinery.

Chen, J.-C., Qin, Y., Wang, H.-Y., and Xu, C. (2022).

Simulation might change your results: a comparison

of context-aware system input validation in simulated

and physical environments. Journal of Computer Sci-

ence and Technology, 37(1):83–105.

Chen, Y., Chaudhari, N., and Chen, M.-H. (2021b).

Context-aware regression test selection. In 2021

28th Asia-Paciﬁc Software Engineering Conference

(APSEC), pages 431–440. IEEE.

Cohen, J. (1960). A coefﬁcient of agreement for nominal

scales. Educational and psychological measurement,

20(1):37–46.

Dadeau, F., Gros, J.-P., and Kouchnarenko, O. (2020). Test-

ing adaptation policies for software components. Soft-

ware Quality Journal, 28:1347–1378.

Dadeau, F., Gros, J.-P., and Kouchnarenko, O. (2021). Au-

tomated generation of initial conﬁgurations for testing

component systems. In Formal Aspects of Component

Software: 17th International Conference, FACS 2021,

Virtual Event, October 28–29, 2021, Proceedings 17,

pages 134–152. Springer.

Dadeau, F., Gros, J.-P., and Kouchnarenko, O. (2022). On-

line testing of dynamic reconﬁgurations wrt adapta-

tion policies. Automatic Control and Computer Sci-

ences, 56(7):606–622.

de Almeida, D. R., Machado, P. D., and Andrade, W. L.

(2020a). Context-aware android applications testing.

In Proceedings of the XXXIV Brazilian Symposium on

Software Engineering, pages 283–292.

de Almeida, D. R., Machado, P. D. L., and Andrade, W. L.

(2020b). Enviar: Environment data simulator. SBES

’20, New York, NY, USA. Association for Computing

Machinery.

de Sousa Santos, I., de Castro Andrade, R. M., Rocha,

L. S., Matalonga, S., de Oliveira, K. M., and Travas-

sos, G. H. (2017). Test case design for context-aware

applications: Are we there yet? Information and Soft-

ware Technology, 88:1–16.

DeVries, B., Fredericks, E. M., and Cheng, B. H. (2021).

Analysis and monitoring of cyber-physical systems

via environmental domain knowledge & modeling.

In 2021 International Symposium on Software En-

gineering for Adaptive and Self-Managing Systems

(SEAMS), pages 11–17. IEEE.

Doreste, A. C. d. S. and Travassos, G. H. (2020). Towards

supporting the speciﬁcation of context-aware software

system test cases. In CIbSE, pages 356–363.

Doreste, A. C. D. S. and Travassos, G. H. (2023). Cats:

A testing technique to support the speciﬁcation of test

cases for context-aware software systems. SBQS ’22,

New York, NY, USA. Association for Computing Ma-

chinery.

dos Santos, E. B., Andrade, R. M., and de Sousa Santos, I.

(2021). Runtime testing of context-aware variability

in adaptive systems. Information and Software Tech-

nology, 131:106482.

Fanitabasi, F., Gaere, E., and Pournaras, E. (2020). A self-

integration testbed for decentralized socio-technical

systems. Future Generation Computer Systems,

113:541–555.

Garousi, V., Felderer, M., Kuhrmann, M., Herkilo

glu, K.,

and Eldh, S. (2020). Exploring the industry’s chal-

lenges in software testing: An empirical study. Jour-

nal of Software: Evolution and Process, 32(8):e2251.

Haan, L. and Ferreira, A. (2010). Extreme value theory: an

introduction. Springer.

Jamovi (2022). The jamovi project.

Kitchenham, B., Sjøberg, D. I., Brereton, O. P., Budgen, D.,

Dyb

a, T., H

ost, M., Pfahl, D., and Runeson, P. (2010).

Can we evaluate the quality of software engineering

experiments? In Proceedings of the 2010 ACM-IEEE

Testing on Dynamically Adaptive Systems: Challenges and Trends

139

International Symposium on Empirical Software En-

gineering and Measurement, pages 1–8.

Kitchenham, B. A., Budgen, D., and Brereton, P. (2016).

Evidence-based software engineering and systematic

reviews. CRC press.

Krupitzer, C., Roth, F. M., VanSyckel, S., Schiele, G.,

and Becker, C. (2015). A survey on engineering ap-

proaches for self-adaptive systems. Pervasive and Mo-

bile Computing, 17:184–206.

Lahami, M. and Krichen, M. (2021). A survey on runtime

testing of dynamically adaptable and distributed sys-

tems. Software Quality Journal, 29(2):555–593.

Mandrioli, C. and Maggio, M. (2020). Testing self-adaptive

software with probabilistic guarantees on performance

metrics. In Proceedings of the 28th ACM Joint Meet-

ing on European Software Engineering Conference

and Symposium on the Foundations of Software En-

gineering, pages 1002–1014.

Mandrioli, C. and Maggio, M. (2022). Testing self-adaptive

software with probabilistic guarantees on performance

metrics: Extended and comparative results. IEEE

Transactions on Software Engineering, 48(9):3554–

3572.

Matalonga, S., Amalﬁtano, D., Doreste, A., Fasolino, A. R.,

and Travassos, G. H. (2022). Alternatives for testing

of context-aware software systems in non-academic

settings: results from a rapid review. Information and

Software Technology, 149:106937.

Maurio, J., Wood, P., Zanlongo, S., Silbermann, J.,

Sookoor, T., Lorenzo, A., Sleight, R., Rogers, J.,

Muller, D., Armiger, N., et al. (2021). Agile ser-

vices and analysis framework for autonomous and au-

tonomic critical infrastructure. Innovations in Systems

and Software Engineering, pages 1–12.

McMinn, P. (2011). Search-based software testing: Past,

present and future. In 2011 IEEE Fourth International

Conference on Software Testing, Veriﬁcation and Val-

idation Workshops, pages 153–163. IEEE.

Mendes, E., Wohlin, C., Felizardo, K., and Kalinowski, M.

(2020). When to update systematic literature reviews

in software engineering. Journal of Systems and Soft-

ware, 167:110607.

Michaels, R., Piparia, S., Adamo, D., and Bryce, R. (2022).

Data driven testing for context aware apps. page 206

– 211.

Mirza, A. M., Khan, M. N. A., Wagan, R. A., Laghari,

M. B., Ashraf, M., Akram, M., and Bilal, M.

(2021). Contextdrive: Towards a functional scenario-

based testing framework for context-aware applica-

tions. IEEE Access, 9:80478–80490.

Pierre Bourque, R. E. F. (2014). Guide to the Software En-

gineering Body of Knowledge (SWEBOK(r)): Version

3.0. IEEE Computer Society Press, 3rd edition.

Piparia, S., Adamo, D., Bryce, R., Do, H., and Bryant,

B. (2021). Combinatorial testing of context aware

android applications. In 2021 16th Conference on

Computer Science and Intelligence Systems (FedC-

SIS), pages 17–26. IEEE.

Pournaras, E., Pilgerstorfer, P., and Asikis, T. (2018). De-

centralized collective learning for self-managed shar-

ing economies. ACM Transactions on Autonomous

and Adaptive Systems (TAAS), 13(2):1–33.

Priya, S. S. and Rajalakshmi, B. (2022). Testing context

aware application and its research challenges. In 2022

International Conference on Smart Technologies and

Systems for Next Generation Computing (ICSTSN),

pages 1–7. IEEE.

Robert, C. P. and Casella, G. (2005). Monte Carlo statistical

methods. Springer.

Shaﬁei, Z. and Rafsanjani, A. J. (2020). A test case de-

sign method for context aware android applications. In

2020 25th International Computer Conference, Com-

puter Society of Iran (CSICC), pages 1–8. IEEE.

Silva, D. N. A. d. (2020). Adaptation oriented test data

generation for adaptive systems. In 2020 15th Iberian

Conference on Information Systems and Technologies

(CISTI), pages 1–7.

Simons, C. L. (2013). Whither (away) software engineers in

sbse? In 2013 1st International Workshop on Combin-

ing Modelling and Search-Based Software Engineer-

ing (CMSBSE), pages 49–50. IEEE.

Siqueira, B. R., Ferrari, F. C., Serikawa, M. A., Menotti,

R., and de Camargo, V. V. (2016). Characterisation of

challenges for testing of adaptive systems. In Proceed-

ings of the 1st Brazilian Symposium on Systematic and

Automated Software Testing, pages 1–10.

Siqueira, B. R., Ferrari, F. C., Souza, K. E., Camargo,

V. V., and de Lemos, R. (2021). Testing of adap-

tive and context-aware systems: approaches and chal-

lenges. Software Testing, Veriﬁcation and Reliability,

31(7):e1772.

Strauss, A. and Corbin, J. (1990). Basics of qualitative re-

search. Sage publications.

Usman, A., Ibrahim, N., and Salihu, I. A. (2020). Tegdroid:

Test case generation approach for android apps con-

sidering context and gui events. International Journal

on Advanced Science, Engineering and Information

Technology, 10(1):16.

Wang, L., Li, S., Liu, J., Hu, Y., and Wu, Q. (2023). Design

and implementation of a testing platform for ship con-

trol: A case study on the optimal switching controller

for ship motion. Advances in Engineering Software,

178:103427.

Yi, G. K., Baharom, S. B., and Din, J. (2022). Improv-

ing the exploration strategy of an automated android

gui testing tool based on the q-learning algorithm by

selecting potential actions. Journal of Computer Sci-

ence, 18(2):90 – 102.

Yigitbas, E. (2020). Model-driven engineering and usabil-

ity evaluation of self-adaptive user interfaces. ACM

SIGWEB Newsletter, (Autumn):1–4.

ICEIS 2024 - 26th International Conference on Enterprise Information Systems

140
