Relevant Multi Domain Features Selection Based on Mutual

Information for Heart Sound Classification

Rima Touahria

, Abdenour Hacine-Gharbi

, Philippe Ravier

and Messaoud Mostefai

LMSE Laboratory, University of Bordj Bou Arréridj, Elanasser, 34030 Bordj Bou Arréridj, Algeria

PRISME Laboratory, University of Orleans, 12 rue de Blois, 45067 Orleans, France

Keywords: Heart Sound, Multidomain Features, Feature Extraction, Feature Selection, Mutual Information,

Classification.

Abstract: Many classification systems of the heart sound signals use a combination of features from different domains.

In a former reference paper, 324 multidomain features were used for classifying segmented phonocardiogram

signals. However, the large feature dimension requires high memory space, high calculus and probably

reduces the classification accuracy caused by the curse of dimensionality. In the present work, we propose to

reduce the dimensionality of features vectors by selecting the relevant features using six heuristic strategies

of feature selection based on mutual information maximisation criterion. In order to validate the selected

subset of features, a k-NN model based-classifier was used and evaluated on the PhysioNet/Computing in

Cardiology Challenge2016 dataset using the same features sets described in the reference paper. The results

demonstrate that the Joint Mutual Information (JMI) selection strategy increases the classification rate from

85. 57% to 89.28% and simultaneously reduces dimension from 324 to 46. Furthermore, this work

demonstrates that systolic segment features are the most relevant for murmur/normal classification. It also

demonstrates the capability of feature selection algorithms to emphasize specific key areas in signals, which

is helpful for aided diagnostic systems and fundamental research.

1 INTRODUCTION

The human heart provides the phonocardiogram

(PCG) signal, which can be captured by a traditional

or electronic stethoscope. PCG signal processing has

mainly two goals. The first goal is to divide the PCG

signal into heart cycles and to detect the successive

components that make up each cardiac cycle: first

heart sound (S1), systolic period (Sys), second heart

sound (S2) and diastolic period (Dias). Heart sounds

(S1, S2) are audible signals associated with the closing

of valves. The time duration of them is approximately

150 ms and 120 ms respectively with a corresponding

frequency between 20 Hz to 150 Hz. The second goal

consists to classify the heartbeats in a PCG signal into

normal and abnormal heart sounds for diagnostic of

cardiovascular diseases.

The heart sound classes can be identified by a

feature extraction step followed by a classification

step. Techniques for feature extraction may use

https://orcid.org/0000-0002-7045-4759

https://orcid.org/0000-0002-0925-6905

Discrete Wavelet Transform, mel-frequency cepstral

coefficient (MFCC). Classification may use

algorithms such as k-Nearest Neigbors (k-NN),

Artificial Neural Network (ANN), Support Vector

Machine (SVM) (Ortiz, Phoo, & Wiens, 2016),

(Jinghui, Li Ke, & Qiang Du, 2019) . In (Rubin, et al.,

2016), the authors have used the MFCC with a deep

convolutional neural network algorithm. (Tang, Chen,

Li, & Zhong, 2016) presented a method using multi-

domain features. In (Touahria, Hacine-Gharbi, &

Ravier, 2021), the authors have proposed the use of

LWE (Log Wavelet Energy) features to automatically

classify the PCG signal in a class label “normal” (N)

or “abnormal” (AN). A survey paper on heart sound

classification methods is published by (Liu, et al.,

2016). Particularly, in (Tang, Chen, Li, & Zhong,

2016), the authors proposed a classifier applied on

multi-domains features for PCG classification based

on Back Propagation Neural Network. In this work, a

set of 324 multi-domains features (domain of heart

sound intervals, energy domain, frequency spectrum,

918

Touahria, R., Hacine-Gharbi, A., Ravier, P. and Mostefai, M.

Relevant Multi Domain Features Selection Based on Mutual Information for Heart Sound Classiﬁcation.

DOI: 10.5220/0012565300003654

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 13th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2024), pages 918-923

ISBN: 978-989-758-684-2; ISSN: 2184-4313

heart rate sequence, frequency spectrum of heart rate

sequence, kurtosis, cyclostationarity, power spectral

density and power spectral density of heart rate

sequence) has been used, that lead to classification

accuracy of 83.6%. However, this high dimension of

features vectors can reduce the performance of the

classification system of PCG signals in terms of

complexity (memory space, calculus time) and

probably in accuracy. The principal aim of the present

work is to reduce this high dimension using feature

selection algorithms for a lower complex system with

possible higher classification accuracy. Two principal

features selection approaches have been used in the

states of arts. The first “wrapper” approach is applied

in low dimension and uses the classifiers to measure

the relevancy of features. Conversely, the second

'filter' approach, which is independent of classifiers, is

generally applied in high dimension and uses the

information provided by the features to explain the

classes. Hence, in our work, we use a “filter” approach

based on the criterion of mutual information

maximisation of the selected features. Several

heuristic strategies of feature selection based on

mutual information will be applied to select the

relevant local and global features (S1, Systole, S2 and

Diastole) extracted from the previous set of multi-

domains features. In order to validate the importance

of this features selection, we propose to evaluate the

performance of the classification system using k-NN

classifier using the cross-validation with 5 folds

applied on the same database used in (Tang, Chen, Li,

& Zhong, 2016).

The organization of this study is as follows.

Section 2 shows the suggested approaches for PCG

signals classification and the related work, i.e.

extracting feature vectors and choosing the relevant

features for the classification task. Section 3 describes

the proposed classification system, which adds the

feature selection step. The experiments and their

findings are presented in Section 4. Section 5

concludes the paper with some ideas for further

research.

2 RELATED WORK

Several studies on heart sound classification have

used the pattern recognition approach for the task of

cardiovascular diseases diagnosis (Barschdorff,

Bothe, & Rengshausen, 1989) (Ali, et al., 2019)

(Whitaker, Suresha, Liu, Clifford, & Anderson,

2017). This approach requires three steps: pre-

processing and segmentation, features extraction with

optional step of features selection, and classification.

Firstly, the phonocardiogram (PCG) is pre-processed

and segmented in local regions (S1, Sys, S2, Dias).

Then, the features of each PCG recording are

extracted. Finally, the features are fed into the

designed model to classify normal and abnormal heart

sound. As a result, traditional classification system

for heart sounds includes the steps listed below. The

conception of this system requires training phase for

building the model of each class and testing phase for

evaluating performance of the classification system

using training and testing databases.

In (Tang, Chen, Li, & Zhong, 2016), the authors

have proposed a system of PCG signals classification

based on Back Propagation Neural Network classifier

applied on sequences of feature vectors extracted from

several domains. In this system, the segmentation step

is based on the hidden semi-Markov model (HSMM)

method that uses the ECG information to locate the

different local regions of the heartbeat sound

(Springer, Tarassenko, & Clifford, 2016). Then, the

global and the local regions (S1, Systole, S2 and

Diastole) of the heartbeat sound have been used to

extract local and global of several multi-domains

features in (Springer, Tarassenko, & Clifford, 2016)

(Tang, Chen, Li, & Zhong, 2016). Hence, each feature

vector representing the heartbeat sound is composed

of the concatenated features vectors extracted on each

local region and the global region. However, this

concatenation increases the vectors dimension which

augments the space memory, computing time and

probably reduces the accuracy caused by the curse of

dimensionality phenomenon.

3 PROPOSED CLASSIFICATION

SYSTEM

3.1 Descriptions of the Heart Sound

Databases

The dataset described in (Tang, Chen, Li, & Zhong,

2016) is used in the present work. This includes six

databases (labeled A through F), collecting a total of

3153 phonocardiogram (PCG) recordings. These

recordings were gathered from diverse settings,

including clinical and non-clinical environments, and

involve subjects ranging from healthy individuals to

those with pathological conditions. Each PCG

recording has undergone manual labeling, indicating

whether it is categorized as normal (-1) or abnormal

(1). The database is constituted of 2500 PCG

recordings of normal class and 653 of PCG

recordings of abnormal class. In the present work, this

Relevant Multi Domain Features Selection Based on Mutual Information for Heart Sound Classiﬁcation

919

database is partitioned into five folds for cross-

validation evaluation.

3.2 Flowchart of the System

In this work, we propose to reduce the dimensionality

of the feature vectors described previously using the

feature selection approach based on the mutual

information for the task of heartbeat sounds

classification. Particularly, the k-NN classifier is used

for its simplicity (k is the number of neighbors), with

applying the same segmentation step and the same

features dataset used in (Tang, Chen, Li, & Zhong,

2016). The flowchart of the proposed classification

system of the heartbeat sounds is illustrated on Figure

The two steps of segmentation and multidomain

feature extraction are carried out by following the

procedure given in the reference paper in (Tang,

Chen, Li, & Zhong, 2016). First, PCG recordings are

segmented into primary heart sounds, including S1,

Systole, S2, and Diastole, through the application of

the Hidden Semi-Markov Model (HSMM) method

originally introduced by Springer (Springer,

Tarassenko, & Clifford, 2016). Second, features are

extracted from each segment or between segments in

multidomain which gives a set of 324 features. The

domains and the number of features per domain are

those presented in (Tang, Chen, Li, & Zhong, 2016):

22 features in domain of heart sound intervals, 10

features in energy domain, 82 features in frequency

spectrum, 2 features in heart rate sequence, 57 features

in frequency spectrum of heart rate sequence, 8

features in Kurtosis, 4 features in cyclostationarity, 82

features in power spectral density and 57 of features

in power spectral density of heart rate sequence.

Figure 1: flowchart of the proposed classification system of

the PCG heart sounds.

The feature selection step considered in this work

consists to select the relevant features using the mutual

information maximization. This step is carried out

using several feature selection strategies such as JMI

(Yang & Moody, 1999), ICAP (Jakulin, 2005), CIFE

(Kojadinovic, 2005), MRMR (Peng, 2005) and CMI

(Fleuret, 2004). These strategies are implemented

using the feast Matlab toolbox (Brown, Pocock, Zhao,

& Lujan, 2012). This step will be described in the next

section.

Performance measures of the classification system

are evaluated using the classification rate ( 𝐶𝑅),

defined as follow:

𝐶𝑅=

number o

recognised testing signals

total number o

testin

nals

(1)

3.3 Feature Selection Based on Mutual

Information

The feature selection consists to select a small subset

of N relevant features 𝒮



=𝑝





,𝑝





,…,𝑝





 that

explains the different classes of signals, from an initial

set of M features 𝐹=



𝑝



,𝑝



,…,𝑝





that produces

the maximal mutual information with the following

class variables:

𝒮



=𝑎𝑟𝑔max



⊂

𝐼



𝐶;𝑆



)

This can be performed using the forward ‘greedy’

algorithm, which selects at each iteration 𝑗 one feature

𝑝





that verifies the following equation:

𝑝





=𝑎𝑟𝑔 max





∈ 𝒮





𝐼𝐶;𝑝



, 𝒮





)

Since we have 𝐼𝐶;𝑝



, 𝒮



=𝐼𝐶; 𝒮



+

𝐼𝐶;𝑝



\ 𝒮



 (Cover & Thomas, 1991), Equation (3)

can be reduced to:

𝑝





=𝑎𝑟𝑔 max





∈ 𝒮





𝐼𝐶;𝑝



\ 𝒮





)

Two feature selection approaches are considered

in the state of arts. The first approach ‘wrappers’ uses

the accuracy of the classification system as measure of

features relevancy. This approach is applied in low

dimension cases (Kohavi & John, 1997). The second

approach ‘Filters’ is independent of the classification

system. This approach is adapted for the high

dimension cases. In our work, we use the ‘Filters’

approach because the classification system is based on

extraction of features vectors of high dimension. Next,

five strategies of feature selection will be described.

 JMI (Joint Mutual Information) (Yang &

Moody, 1999)

𝑝





=𝑎𝑟𝑔 𝑚𝑎𝑥





∈𝒮



𝐼



𝐶;𝑝





−

𝑗

−1

𝐼𝐶;𝑝



;𝑝













)

 ICAP (Interaction Capping) (Jakulin, 2005)

ICPRAM 2024 - 13th International Conference on Pattern Recognition Applications and Methods

920

𝑝





=𝑎𝑟𝑔 𝑚𝑎𝑥





∈ 𝒮



𝐼



𝐶;𝑝





−𝑚𝑎𝑥 [𝐼𝐶;𝑝



;𝑝











,0]

(6)

 CIFE (Conditional Infomax Feature Extraction)

(Kojadinovic, 2005) (Hacine-Gharbi, Ravier, &

Mohamadi, 2009)

𝑝





=𝑎𝑟𝑔 𝑚𝑎𝑥





∈ 𝒮



𝐼



𝐶;𝑝





−𝐼



𝐶;𝑝



;𝑝











(7)

 MRMR (Maximum-Relevance Minimum

Redundancy) (Peng, 2005)

𝑝





=𝑎𝑟𝑔 𝑚𝑎𝑥





∈ 𝒮



𝐼



𝐶;𝑝





−

𝑗

−1

𝐼𝑝



;𝑝













(8)

 CMI (Conditional Mutual Information)

(Fleuret, 2004)

𝑝





=𝑎𝑟𝑔 𝑚𝑎𝑥





∈ 𝒮



𝐼



𝐶;𝑝





−𝑚𝑎𝑥







∈𝒮



𝐼𝐶;𝑝



;𝑝







)

4 EXPERIMENTAL RESULTS

The aim of this paper is to select the relevant features

from a set of combined features used in (Tang, Chen,

Li, & Zhong, 2016) for the task of PCG signals

classification. This is realized using these steps:

 Apply the feature selection method based on

the MI with different strategies JMI, ICAP,

CIFE, MRMR and CMI;

 Use the k-NN classifier to validate the

relevancy of the features selected at the

iteration j;

 Estimate the optimal number of features with

the two stopping criterions considered

(Touahria, Hacine-Gharbi, & Ravier, 2023): in

the first criterion (CRT1), the optimal feature

subset is the selected feature subset that yields

a CR higher than or equal to the CR obtained

using the set of all features (324 features); in

the second criterion (CRT2), the optimal

feature subset yields to the maximal CR. Note

that the second criterion requires more time

than the first criterion.

4.1 Optimal Nearest Neighbors (K

Considering Two Stopping

Criterions) Parameterization

This experiment has the objective to search for the

optimal number of nearest neighbors (K) that gives he

best performance by varying K from 1 to 30 and by

changing the distance function (“Correlation”,

“Cosines”, “Euclidean”, “Cityblock”). Table 1 gives

the results. The best result is obtained when K is set

to 8 and the function is set to “Cityblock”. It reaches

a CR of

85. 57%.

Table 1: CR as a function of optimal number of nearest

neighbors K with four distance functions.

Euclidean Correlation Citybloc

Cosine

optimal

6 4 8 4

CR (%) 83.34 83.38 85. 57 83.00

In the next sections, the value of nearest

neighbor’s K will be set to 8 and the “

Cityblock”

function will be chosen.

4.2 Performance Study for Feature

Selection Using Different Strategies

This section focuses on the selection of the most

relevant features that explain the normal and

abnormal classes using the JMI, ICAP, CIFE, MRMR

and CMI strategies.

Table 2: CR and number of relevant features by using JMI,

ICAP, CIFE, MRMR and CMI strategies with selection

criteria CRT1 and CRT2.

CRT1

CR ≥ CR(end)

CRT2

CR==max(CR)

# of

relevant

features

(%)

# of

relevant

features

(%)

JMI 7 86.71 46 89.28

ICAP 13 86.97 22 87.95

CIFE 72 85.95 94 86.90

MRMR 13 86.11 38 86.81

CMI 6 85.63 23 89.06

The outcomes of this selection for the different

feature selection strategies in terms of CR and

relevant feature number using the two stopping

criterions CRT1and CRT2 are shown in Table 2.

From this table, we can give the following points:

 In the case of the first criterion, we notice a

strong convergence in the values of CR for all

strategies, which is around

86%. Particularly,

the JMI strategy gives the best trade-off

between accuracy of 86.71% and optimal

number of 7 features.

 In the case of the second criterion, the highest

CR of

89.28% is achieved using the JMI

strategy. However, the CMI gives the best

Relevant Multi Domain Features Selection Based on Mutual Information for Heart Sound Classiﬁcation

921

trade-off between accuracy of 89.06% and

optimal number of 23 features, which

represents a dimension reduction of 92.90%. In

addition, the ICAP gives the smallest feature

subsets with CR of 87.95%.

 The CIFE strategy selects the largest subset of

features whatever the considered criterion.

Figure 2 shows the results obtained by the five

strategies (JMI, ICAP, CIFE, MRMR and CMI)

applied on vectors of multidomain and with different

feature domains. From these curves, it can be seen

that approximately

selected features obtained by

JMI strategy are adequate for clearly explaining the

classes. Note that we observe that all strategies

identified the same first feature, which is the systolic

(“sd_energy_SysCycle”) energy as previously

demonstrated in (Touahria, Hacine-Gharbi, & Ravier,

2023).

Further, this figure shows clearly the curse

dimensionality phenomenon explained by the great

peak in the CR curves corresponding to JMI, CIFE,

MRMR. Generally, the most features selection

strategies improve the performances in terms of

complexity (space memory and computing time) and

accuracy.

Figure 2: CR (%) as a function of the number of selected

features with the five feature selection strategies.

5 CONCLUSIONS

In this study, we have proposed the use of several

feature selection strategies based on the criterion of

mutual information maximization for reducing high

dimensionality vectors composed of 324 features of

multi-domains types extracted from database of PCG

recordings used in a previous system of PCG signals

classification. The dataset of these features is used for

evaluating the performance of the proposed

classification system of PCG signals based on k-NN

classifier combined with feature selection algorithms,

using five folds cross-validation strategy.

The obtained results demonstrate that including the

feature selection step in the classification system of

PCG signals improves the performance in terms of

accuracy and complexity with high dimension

reduction of features vectors. We report a high

reduction of the dimension number (from 324 to

)

and an increased

89.28

% CR value using feature

selection procedure based on JMI strategy by

applying the second criterion. These results

demonstrate the efficiency of the feature selection

step for reducing the complexity and increasing the

accuracy of the classification system of PCG signals.

ACKNOWLEDGEMENTS

If any, should be placed before the references section

without numbering.

REFERENCES

Ali, R., Arif, M., Saleem, U., Maqsood, A., Gyu, S., &

Byung-Won, O. (2019). Heart sound classification

based on temporal alignment techniques. Sensors 19;

4819.

Barschdorff, B., Bothe, A., & Rengshausen, U. (1989).

Heart sound analysis using neural and statistical

classifiers a comparison. Comput. Cardiol. 415–418.

Brown, G., Pocock, A., Zhao, M.-J., & Lujan, M. (2012).

Conditional Likelihood Maximisation A

UnifyingFramework for information theoretic feature

selection. Journal of Machine Learning Research,

13(1), pp.27-66.

Cover, T., & Thomas, J. (1991). Elements of Information

Theory. . New York: Wiley Series In

Telecommunications.

Fleuret, F. (2004). Fast binary feature selection with

conditional mutual information. Journal of Machine

Learning Research, 5:1531–1555.

Hacine-Gharbi, A., Ravier, P., & Mohamadi, T. (2009).

Une nouvelle méthode de sélection des paramètres

pertinents: application en reconnaissance de la parole.

Proceedings of the Conference Traitement et Analyse

de l’Information:Méthodes et Applications (TAIMA),

pp.399–407.

Jakulin, A. (2005). Learning based on attribute interactions.

hD thesis, University of Ljubljana, Slovenia.

Jinghui, L., Li Ke, & Qiang Du. (2019). Classification of

Heart Sounds Based on the Wavelet Fractal and Twin

Support Vector Machine. Entropy , 21,

ICPRAM 2024 - 13th International Conference on Pattern Recognition Applications and Methods

922

472;doi:10.3390/e21050472www.mdpi.com/journal/e

ntropy.

Kohavi, J., & John, G. (1997). Wrappers for feature subset

selection. Artificial Intelligence, Vol. 97, Nos. 1/2,

pp.273–324.

Kojadinovic, I. (2005). Relevance measures for subset

variable selection in regression problems based on k-

additive mutualinformation. Computational Statistics

and Data Analysis,Vol. 49, No. 4, pp.1205–1227.

Li, F., Tang, H., Shang, S., Mathiak, K., & Cong, F. (2020).

Classification of Heart Sounds Using Convolutional

Neural Network. Appl. Sci. 10 (11)3956.

Liu, C., Springer, D., Li, Q., Moody, B., Juan, R., Chorro,

F., . . . Clifford, G. (2016). An open access database for

the evaluation of heart sound algorithms. Physiological

Mea-surement.

Ortiz, J., Phoo, C., & Wiens, J. (2016). Heart sound

classification based on temporal alignment techniques.

IEEE.

Peng, H. L. (2005). Feature selection based on mutual

information: criteria of max-dependency, max-

relevance, and min-redundancy. IEEE Transactions on

Pattern Analysis and Machine Intelligence, Vol. 27, No.

8, pp. 1226–1238.

Rubin, J., Abreu, R., Ganguli, A., Nelaturi, S., Matei, I., &

Sricharan, K. (2016). Classifying heart sound

recordings using deep convolutional neural and mel-

frequency cepstral coefficients. Computing in

Cardiology Conference (CinC), IEEE, pp. 813–816.

Springer, D., Tarassenko, L., & Clifford, G. (2016).

Logistic regression-HSMM-based heart sound

segmentation. Transactions on Biomedical

Engineering (IEEE), 822-32.

Tang, H., Chen, H., Li, T., & Zhong, M. (2016).

Classification of Normal/Abnormal Heart Sound

Recordings Based on Multi-Domain Features and Back

Propagation Neural Network. (pp. 593–596). In

Proceedings of the 2016 Computing inCardiology

Conference (CinC).

Touahria, R., Hacine-Gharbi, A., & Ravier, P. (2021).

Discrete Wavelet based Features for PCG Signal

Classification using Hidden Markov Models.

International Conference on Pattern Recognition

Applications and Methods.

Touahria, R., Hacine-Gharbi, A., & Ravier, P. (2023).

Feature selection algorithms highlight the importance

of the systolic segment for normal/murmur PCG beat

classification. Biomedical Signal Processing and

Control.

Whitaker, B., Suresha, P., Liu, C., Clifford, G., &

Anderson, D. (2017). Combining sparse coding and

time domain features for heart sound classification.

Physiol. Meas.1701 .

Yang, H., & Moody, J. (1999). Feature selection based on

joint mutual information. Intelligent Data Analysis

(AIDA) and Computational Intelligent Methods and

Application (CIMA).

Relevant Multi Domain Features Selection Based on Mutual Information for Heart Sound Classiﬁcation

923
