Clinical Evaluation of Collaborative Artificial Intelligence Systems:

Lessons from the Case of Robot-Assisted Surgery

Alexandre Coste

, Frédéric Barbot

and Thierry Chevalier

3,4,5 c

EuroMov Digital Health in Motion, Univ. Montpellier, IMT Mines Ales, Montpellier, France

INSERM CIC 1429, Raymond Poincaré Hospital APHP, France

CHU Nîmes, Department of Biostatistics, Epidemiology, Public Health and Innovation in Methodology,

30029 Nîmes, France

Univ. Montpellier, INSERM, UMR 1302, Institute Desbrest of Epidemiology and Public Health, Montpellier, France

Tech4Health-FCRIN, France

Keywords: Clinical Evaluation, Robotic Surgery, Human-Machine Collaboration, Artificial Intelligence, Medical

Devices.

Abstract: Collaborative AI systems, which combine both forms of intelligence (i.e., human and machine), are attracting

increasing interest from the scientific and medical communities, with various applications in radiology

(clinical decision support systems) and surgery (robot-assisted surgery). However, despite their promise, these

systems face significant challenges in integrating into clinical practice due to a lack of transparency, trust, and

clinical validation. Drawing on the case of robotic surgery, the aim of this work was to analyse the scientific

evidence for ten surgical robots currently on the market (i.e., CE-marked or FDA-cleared/approved) that meet

the definition of a collaborative AI system. We found a low number of peer-reviewed publications and a lack

of transparency from authors and manufacturers, particularly regarding the functioning of their devices, which

are often considered as ‘black boxes’. Furthermore, the term ‘artificial intelligence’ is under-utilised in

scientific publications, regulatory submissions, and commercial materials. Based on these findings, we

propose three recommendations to promote the integration of these medical devices: 1) promote the

transparency, explainability, and comprehensibility of AI devices by encouraging manufacturers to provide

more detailed information about their systems and their functioning, including the interrelationship with the

user; 2) promote randomised controlled multicentre trials to provide stronger evidence on the performance

and safety of these devices; 3) encourage the publication of scientific results in peer-reviewed journals to

expose them to scientific scrutiny and improve transparency. These recommendations have been carefully

formulated to cover a wide range of AI/ML-enabled medical devices, beyond the case of surgical robots

reviewed here.

1 INTRODUCTION

Artificial intelligence (AI) is expanding rapidly,

particularly in the healthcare sector. Technological

advances, particularly in computer science, have led

to increasingly powerful AI systems, but

paradoxically only a limited number of these systems

have been integrated into clinical practice, a

phenomenon known as the ‘AI chasm’ (e.g.,

Aristidou et al. 2022, Reyna et al. 2022). Key limiting

https://orcid.org/0000-0002-4497-6473

https://orcid.org/0000-0002-4648-9134

https://orcid.org/0000-0002-5110-6273

factors include a lack of transparency, trust,

interpretability, adaptability and scientific evidence.

In particular, many concerns have been raised in

recent years about the fact that certain AI systems

have been tested and validated using retrospective, in

silico data, which does not reflect real-world clinical

practice. Moreover, few studies have taken into

account the specificities of so-called ‘collaborative’

AI systems. These systems, which are based on the

close collaboration between two forms of

intelligence, human and artificial, (Vasey et al. 2022),

852

Coste, A., Barbot, F. and Chevalier, T.

Clinical Evaluation of Collaborative Artiﬁcial Intelligence Systems: Lessons from the Case of Robot-Assisted Surgery.

DOI: 10.5220/0012598500003657

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 17th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2024) - Volume 1, pages 852-857

ISBN: 978-989-758-688-0; ISSN: 2184-4305

present significant methodological challenges due to

their inherent complexity. This complexity arises

primarily from the ongoing interplay between human-

related factors, such as the learning curve, the level of

expertise or the physical and mental fitness of the

operators, and AI-model factors, including

algorithmic specificities, the evolutionary nature for

continuous learning models, and the quality of the

learning data that shapes the model and its

performance.

The surgical field is undoubtedly one of the most

representative areas for collaborative AI systems

(Mayor et al. 2022), where the integration of human

expertise with AI capabilities shows remarkable

potential for advancing surgical practices. In

particular, the proposed benefits include: i) enhancing

the surgeon's perceptual abilities through three-

dimensional imaging; ii) improving the precision of

surgical gestures, particularly in minimally invasive

procedures, by filtering out tremors and reducing

differences associated with laterality preferences.

While autonomous surgery was the main

motivation for the pioneers (e.g., the PROBOT for

prostate resection), it is the robots that assist the

surgeon (i.e., teleoperated or co-manipulated), not

intended to replace him, that have become

widespread over the last twenty years. There are now

hundreds of surgical robots (on the market or under

development), covering various medical indications,

from general surgery, to gynaecology, orthopaedics

and even cardiac surgery. The Da Vinci surgical

system, developed by Intuitive Surgical, currently

dominates the market with more than 6,000 units sold

worldwide and more than 7 million procedures

carried out with the robot (figures given by the

manufacturer on its website

https://www.intuitive.com/). However, little is known

about the clinical evaluation of these medical devices

required for both European (Medical Device

Regulation, MDR) and American (FDA) compliance.

In this context, the objective of the present research is

to provide an overview of commercially available

collaborative AI systems in robotic surgery and to

review the associated scientific evidence.

2 METHODS

Following a similar methodology to Wu et al. (2021),

Benjamens et al. (2020), and van Leeuwen et al.

(2021), we identified ten robotic surgical systems

currently available in the market (i.e., compliant with

European regulations or FDA approved/cleared, see

Figure 1).

2.1 Search Strategy and Selection

Criteria

The surgical robots selection process was carried out

in two phases. First, we used the following

resources/databases:

i) FDA's database:"AI/ML-Enabled Medical

Devices," listing FDA approved AI/ML-

based medical devices.

ii) The recent review by Muehlematter,

Daniore & Vokinger (2021) listing 462 AI-

based devices approved in Europe and the

U.S. from 2015 to 2020.

iii) The new European Medical Devices

Database (Eudamed).

iv) The list of communications for Class IIa, IIb,

and III medical devices and implantable

medical devices from the ANSM (French

National Agency for Medicines and Health

Products Safety), covering devices in the

market from 2010 to 01/12/2021 (n =

83129).

v) PubMed

and Google Scholar

databases.

To ensure relevant results, precise keywords were

identified using the bilingual version of the INSERM

(French National Institute of Health and Medical

Research) MeSH (Medical Subject Headings)

lexicon. Keywords included terms related to robotic

surgery, artificial intelligence and machine learning.

A search of these keywords against those in the

above databases identified approximately one

hundred potential devices. A detailed analysis

involving cross-referencing with various sources,

including manufacturers' websites and commercial

documentation, led to the selection of devices that

met the following criteria:

vi) Surgical robots commercially available in

the European or American markets (i.e., EU-

MDR or FDA compliant).

vii) Collaborative surgical robots involving

human-machine interaction (i.e., co-

manipulated or teleoperated).

viii) Surgical robots incorporating AI, machine

learning, or deep learning processes.

2.2 Analysis of Scientific Evidence and

Clinical Evaluation Methodology

The level of scientific evidence and clinical

evaluation methodology for the ten selected devices

were examined using two methods. Firstly, a

systematic search of PubMed, Google Scholar and

Clinical Evaluation of Collaborative Artiﬁcial Intelligence Systems: Lessons from the Case of Robot-Assisted Surgery

853

Figure 1: Overview of the ten collaborative surgical robots integrating AI/ML processes marketed in the U.S. and/or Europe.

IEEE Xplore was performed using the trade name

and/or the manufacturer name of each robot. This

allowed us to extract peer-reviewed articles from

1988 to April 2023. The ClinicalTrials.gov registry

and the medRxiv biomedical research preprint

platform were also consulted to avoid potential

publication bias and to obtain a comprehensive view

of ongoing research.

Secondly, the FDA and European Commission

(Eudamed) databases were consulted to access

detailed information on devices, including preclinical

and clinical data submitted by manufacturers to

regulatory authorities for the conformity assessment.

3 RESULTS

Figure 1 presents the ten collaborative surgical robots

selected for the analysis, categorized according to

their trade name, their manufacturer, their type

(teleoperated or co-manipulated), the associated

scientific publications, and the type of validation

studies.

3.1 Collaborative Surgical Robots: A

Highly Heterogeneous Landscape

Among the ten collaborative surgical robots, four are

teleoperated (Da Vinci Xi

, Versius

, Senhance

, R-

One+

), and six are co-manipulated (Epione

Mako

, Rosa Knee System

, Maestro

, Pulse

System

, 7D Surgical System

). All teleoperated

robots belong to the same risk class, i.e., Class IIb for

EU-MDR compliance (4/4) and Class II for FDA

compliance when obtained (2/4: Da Vinci Xi

and

Senhance

). In contrast, the risk class for co-

manipulated devices is more heterogeneous, ranging

from Class I to Class IIb for EU-MDR compliance

and from Class I to II for FDA compliance. This

diversity is partly explained by the variety of

technologies used and the range of covered

indications, including orthopaedic, cardiac, spinal,

and general laparoscopic surgery. Notably, the

Maestro

robot stands out by being classified in the

lowest risk class (Class I), contrary to the general

trend where active devices are typically classified at

least in Class IIa according to the MDR. Also, it is

important to note that all the analysed surgical robots

have obtained U.S. compliance through the 510(k)

procedure, a simplified procedure highly coveted by

Vinci

Intuitive

Surgical

Teleoperated

> 22000 publications

including

[1]

and

[2]

using AI processes

Ver sius

CMR

Surgical

Teleoperated

[3],

[4],

[5],

[6]

Senha nce

Asensus Surgical

Teleoperated

[7], [8], [9]

R-One+™

Robocath

Teleoperated

studies

referenced

ClinicalTrials.gov

Epione

Quantum Surgical

Co-manipulated

[10],

[11],

[12]

studies

referenced on

ClinicalTrials.gov

Mak o

Stryker

Co-manipulated

[13],

[14],

[15]

Rosa

Knee

Sys tem

Zimmer Biomet

Co-manipulated

[16], [17], [18]

Mae s tr o

Moon Surgical

Co-manipulated

clinical

investigation

referenced on the

Eudamed

portal

Pulse

Sys tem

NuVasive

Co-manipulated

[19]

Sur gical

Sys tem

Surgical

Inc.

Co-manipulated

publications

including

[20] and [21]

Otherorgans/

Multiplesites

Insilico/

cadaveric

model

Invivo

0 0

Prospectivestudytovalidateasystem

basedonAIprocesses

Multicentricstudy

Othertypeofstudy

0-4

ValidationstageaccordingtotheIDEAL

recommandations

Usabilitystudy

Retrospectivestudy

[1] Cheng, Q., & Dong, Y. (2022). Da Vinci Robot-Assisted Video Image Processing under Artificial Intelligence Vision Processing Technology. Computational and Mathematical Methods in Medicine.

[2] Azad, R. I., Mukhopadhyay, S., & Asadnia, M. (2021). Using explainable deep learning in da Vinci Xi robot for tumor detection. International Journal on Smart

Sensing and Intelligent Systems, 14(1), 1-16.

[3] Kelkar, D. S., Kurlekar, U., Stevens, L., Wagholikar, G. D., & Slack, M. (2023). An early prospective clinical study to evaluate the safety and performance of the versius surgical system in robot-assisted cholecystectomy. Annals of Surgery, 277(1), 9.

[4] Kayser, M., Krebs, T. F., Alkatout, I.,

Kayser, T., Reischig, K., Baastrup, J., ... & Bergholz, R. (2022). Evaluation of the Versius robotic surgical system for procedures in small cavities. Children, 9(2), 199.

[5] Haig, F., Medeiros, A. C. B., Chitty, K., & Slack, M. (2020). Usability assessment of Versius, a new robot-ass isted surgical device for use in minimal access

surgery. BMJ Surgery, Interventions, & Health Technologies, 2(1).

[6] Morton, J., Hardwick, R. H., Tilney, H. S., Gudgeon, A. M., Jah, A., Stevens, L., ... & Slack, M. (2021). Preclinical evaluation of the versius surgical system, a new robot-assisted surgical device for use in minimal access general and colorectal procedures. Surgical

endoscopy, 35,

2169-2177.

[7] Sasaki, T., Tomohisa, F., Nishimura, M., Arifuku, H., Ono, T., Noda, A., & Otsubo, T. (2023). Initial 30 cholecystectomy procedures performed with the Senhance digital laparoscopy system. Asian Journal of Endoscopic Surgery, 16(2), 225-232.

[8] Sasaki, M., Hirano, Y., Yonezawa, H., Shimamura, S., Kataoka, A., Fujii, T., ...

& Koyama, I. (2022). Short-term results of robot-assisted colorectal cancer surgery using Senhance Digital Laparoscopy System. Asian Journal of Endoscopic Surgery, 15(3), 613-618.

[9] Holzer, J., Beyer, P., Schilcher, F., Poth, C., Stephan, D., von Schnakenburg, C., ... & Staib, L. (2022). First Pediatri c Pyeloplasty Using the Senhance® Robotic System—A Case Report. Children,

9(3), 302.

[10] de Baère, T., Roux, C., Noel, G., Delpla, A., Deschamps, F., Varin, E., & Tselikas, L. (2022). Robotic assistance for percutaneous needle insertion in the kidney: preclinical proof on a swine animal model. European Radiology Experimental, 6(1), 13.

[11] de Baère, T., Roux, C., Deschamps, F., Tselikas, L.,

& Guiu, B. (2022). Evaluation of a New CT-Guided Robotic System for Percutaneous Needle Insertion for Thermal Ablation of Liver Tumors: A Prospective Pilot Study. Cardiovascular and Interventional Radiology, 45(11),

1701-1709.

[12] Gunderman, A. L., Musa, M., Gunderman, B. O., Banovac, F., Cleary, K., Yang, X., & Chen, Y. (2023). Autonomous

Respiratory Motion Compensated Robot for CT-Guided Abdominal Radiofrequency Ablations. IEEE Transactions on Medical Robotics and Bionics.

[13] Sires, J. D., Craik, J. D., & Wilson, C. J. (2021). Accuracy of bone resection in MAKO total knee robotic-assisted surgery. The journal of knee surgery, 34(07), 745-748.

[14] Young, S. W., Zeng, N.,

Tay, M. L., Fulker, D., Esposito, C., Carter, M., ... & Walker, M. (2022). A prospective randomised controlled trial of mechanical axis with soft tissue release balancing vs functional alignment with bony resection balancing in total knee replacement—a

study using Stryker Mako robotic arm-assi sted technology. Trials, 23(1), 1-10.

[15] Ando, W., Takao, M.,

Hamada, H., Uemura, K., & Sugano, N. (2021). Comparison of the accuracy of the cup position and orientation in total hip arthroplasty for osteoarthritis secondary to developmental dysplasia of the hip between the Mako robotic arm-assisted system and

computed tomography-based navigation. International orthopaedics, 45, 1719-1725.

[16] Vanlommel, L., Neven, E., Anderson, M. B.,

Bruckers, L., & Truijen, J. (2021). The initial learning curve for the ROSA® Knee System can be achieved in 6-11 cases for operative time and has similar 90-day complication rates with improved implant alignment compared to

manual instrumentation in total knee arthroplasty. Journal of Experimental Orthopaedics, 8, 1-12.

[17] Parratte, S., Price, A.

J., Jeys, L. M., Jackson, W. F., & Clarke, H. D. (2019). Accuracy of a new robotically assisted technique for total knee arthroplasty: a cadaveric study. The Journal of arthroplasty, 34(11), 2799-2803.

[18] Anderson, M. B. ROSA

Knee System 2022 Clinical Evidence Summary.

[19] Beisemann, N., Gierse, J., Mandelka, E., Hassel, F., Grützner, P. A., Franke, J., & Vetter, S. Y. (2022). Comparison of three imaging and navigation systems regarding accuracy of pedicle screw placement in a sawbone model. Scientific Reports, 12(1), 12344.

[20] Guha, D., Jakubovic, R., Gupta, S.,

Fehlings, M. G., Mainprize, T. G., Yee, A., & Yang, V. X. (2019). Intraoperative error propagation in 3-dimensional spinal navigation from nonsegmental registration: a prospective cadaveric and clinical study. Global Spine Journal, 9(5), 512-520.

[21] Peh, S., Chatterjea, A., Pfarr, J., Schäfer, J. P., Weuster, M., Klüter, T., ... &

Lippross, S. (2020). Accuracy of augmented reality surgical navigation for minimally invasive pedicle screw insertion in the thoracic and lumbar spine with a new tracking device. The Spine Journal, 20(4),

629-637.

Device Trade

Name

Manufacturer Type of robot

Associated

scientific

publications

Illustration

ClinMed 2024 - Special Session on European Regulations for Medical Devices: What Are the Lessons Learned after 1 Year of

Implementation?

854

manufacturers. Indeed, the manufacturers must only

demonstrate that their device is as safe and effective,

i.e., substantially equivalent, to a legally marketed

device.

3.2 A Significant Lack of Transparency

Surprisingly, 70% of robot manufacturers do not

explicitly mention the use of artificial intelligence or

machine learning processes. Some manufacturers,

such as Asensus Surgical

, use instead terms like

‘augmented intelligence’ without explicit mention of

AI in regulatory documents. Nuvasive

is one of the

few manufacturers explicitly using the term ‘artificial

intelligence’ on its website, but the term does not

appear in any compliance submission documents. AI

or not AI: it seems that talking about artificial

intelligence can be beneficial in certain cases, less so

in others, particularly with regulatory authorities.

3.3 Lack of Scientific Evidence

A detailed examination of publications associated

with the devices reveals varied levels of scientific

evidence. While some devices have limited or no

peer-reviewed articles, others, like the Da Vinci

have extensive literature due to their longer market

presence. Importantly, the number of studies

specifically dedicated to evaluating AI algorithm

performance and safety is extremely limited, even for

the well-established robot like Da Vinci

. Moreover,

most of these studies focus on preclinical stages or

involve a very small number of patients. Only 20% of

the analysed studies (6 out of 30) are multicentric,

emphasizing the need for more comprehensive

research.

4 DISCUSSION

The aim of this work was to delineate the contours

and inherent challenges in the clinical validation of

collaborative AI systems, particularly those involving

close collaboration between human and artificial

intelligence, with a particular focus on robotic

surgery. As mentioned above, these systems present

new methodological challenges in clinical evaluation

due to the inherent variability of individual factors

and those related to the AI system itself. The

introduction of an AI component adds a new

dimension and complexity to the existing challenges

of validating technological innovation in surgery.

Previously, it was known that different levels of

expertise could lead to different levels of

performance, creating a performance bias in favour of

established technologies (Rudicel & Esdaile, 1985).

Now, the performance of collaborative AI systems

can vary between different user profiles.

Furthermore, the capabilities of continuously learning

systems can evolve over time, either positively or

negatively.

4.1 Current Regulatory Framework

and Issues

The current regulatory framework, both in Europe

with the MDR and in the U.S., does not adequately

address the specificities of AI systems, especially

collaborative AI systems. Formulated at a time when

devices had limited interactivity and infrequent

updates, the existing framework struggles to

accommodate the evolving and interactive nature of

new technologies, particularly those incorporating AI

(Gilbert et al., 2023). However, this is changing, with

the imminent arrival of the first regulation on

artificial intelligence (i.e., ‘EU AI Act’) and the

FDA's draft guidance ‘Marketing Submission

Recommendations for a Predetermined Change

Control Plan for Artificial Intelligence/Machine

Learning (AI/ML) - Enabled Device Software

Functions / Draft Guidance for Industry and Food and

Drug Administration Staff’. The latter specifically

aims to address the evolving nature of these new

devices, which are capable of real-time or near real-

time learning. These regulatory advances are

welcome, particularly in light of the observations

made in this work.

4.2 Promoting Transparency,

Explainability, and Intelligibility of

Devices

A key finding of this study is that leading surgical

robots on the market currently lack sufficient detailed

information about the technologies used, despite

recommendations from the World Health

Organization in its core ethical principle number 3

(i.e., ensure transparency, explainability, and

intelligibility) and the ISO/IEC TR 24028:2020.

While recognising the highly competitive nature of

the robotic surgery market, characterised by a

constant drive for innovation and the protection of

intellectual property, it remains crucial to ensure a

minimum level of transparency, particularly in the

context of AI. Transparency goes beyond regulatory

compliance and is a key factor in building trust among

both practitioners and patients. The development of

Eudamed represents a real opportunity for greater

Clinical Evaluation of Collaborative Artiﬁcial Intelligence Systems: Lessons from the Case of Robot-Assisted Surgery

855

transparency on the part of manufacturers, as

envisaged by the European Commission in the

creation of this unique database, which will provide

public access to certain information on marketed

medical devices. in Europe (device identification,

reported incidents, ongoing clinical investiga-

tions, ...). However, it is regrettable that the Eudamed

database is not yet fully operational and is not as

comprehensive as the FDA databases. It is also

regrettable that the Summary of Safety and Clinical

Performance (SSCP), required by the Art. 32 of the

MDR, is limited to implantable devices and class III

devices. As we have observed, most surgical robots

fall into the IIa and IIb categories and are therefore

not directly subject to this obligation.

4.3 Promoting Randomized Controlled

Multicentre Studies and Scientific

Publications

Another important point is the lack of robust evidence

from rigorous clinical trials. Indeed, most of the

reported trials were monocentric and observational,

which can lead to significant methodological biases.

In particular, monocentric studies may produce

results that are not generalisable to geographically

diverse patient populations with different economic,

educational, social, behavioural, ethnic and cultural

characteristics (Kaushal et al, 2020). In addition,

randomised controlled trials (RCTs) are considered

the gold standard in clinical trials as they provide the

highest level of scientific evidence. In this regard,

authors/manufacturers can use various published

guidelines such as SPIRIT-AI (Rivera et al., 2020),

DECIDE-AI (Vasey et al., 2022), STARD-AI

(Sounderajah et al., 2021), TRIPOD-AI and

PROBAST-AI (Collins et al., 2021) to better develop

their research protocols and write their scientific

papers.

4.4 Limitations and Future

Perspectives

Naturally, this research has some limitations. Firstly,

it focuses exclusively on surgical robots, which limits

its representativeness in terms of the diversity of AI

solutions available on the market. However, these

surgical robots illustrate well the concept of

collaborative AI systems, and the recommendations

formulated herein are intended to be transversal and

applicable to a wider range of medical devices,

including autonomous or non-surgical devices.

Secondly, it is important to note that our analysis

exclusively concentrated on robots that are already on

the market (i.e., having obtained EU or US

conformity), specifically in the context of their

clinical validation This approach excludes the pre-

approval phases, including the development of the

idea into a product. Consequently, there might exist

additional barriers not identified within this study.

For a more comprehensive insight, future research

could expand its purview by examining a wider range

of medical devices, including aspects associated with

the development of medical devices. Furthermore, it

would be interesting to consider an extension of the

IDEAL protocol (i.e., IDEAL-AI, see McCulloch et

al. 2009) to include specificities related to the

validation of surgical technology innovations based

on AI/ML processes, such as the collaborative

surgical robots studied here.

5 CONCLUSIONS

In this work, we have identified several barriers to the

implementation of collaborative AI systems in

clinical practice, in particular the lack of transparency

and scientific publications. We have therefore formu-

lated a set of recommendations aimed at promoting the

integration of AI systems into clinical practice,

namely: i) promoting transparency, explainability and

intelligibility of AI devices, ii) promoting the conduct

of randomised controlled multicentre trials, and iii)

encouraging the publication of study results in peer-

reviewed journals. These recommendations have been

formulated to be as transversal as possible and

applicable to a wide range of AI/ML-enabled medical

devices, not just surgical robots.

ACKNOWLEDGEMENTS

AC thanks the Tech4Health network

(https://www.reseau-tech4health.fr) for its financial

support.

REFERENCES

Aristidou, A., Jena, R., & Topol, E. J. (2022). Bridging the

chasm between AI and clinical implementation. The

Lancet, 399(10325), 620.

Benjamens, S., Dhunnoo, P., & Meskó, B. (2020). The state

of artificial intelligence-based FDA-approved medical

devices and algorithms: an online database. NPJ digital

medicine, 3(1), 118.

Collins, G. S., Dhiman, P., Navarro, C. L. A., Ma, J., Hooft,

L., Reitsma, J. B., ... & Moons, K. G. (2021). Protocol

ClinMed 2024 - Special Session on European Regulations for Medical Devices: What Are the Lessons Learned after 1 Year of

Implementation?

856

for development of a reporting guideline (TRIPOD-AI)

and risk of bias tool (PROBAST-AI) for diagnostic and

prognostic prediction model studies based on artificial

intelligence. BMJ open, 11(7), e048008.

Gilbert, S., Fenech, M., Hirsch, M., Upadhyay, S.,

Biasiucci, A., & Starlinger, J. (2021). Algorithm change

protocols in the regulation of adaptive machine

learning–based medical devices. Journal of Medical

Internet Research, 23(10), e30545

Kaushal, A., Altman, R., & Langlotz, C. (2020).

Geographic distribution of US cohorts used to train

deep learning algorithms. Jama, 324(12), 1212-1213.

Mayor, N., Coppola, A. S., & Challacombe, B. (2022). Past,

present and future of surgical robotics. Trends in

Urology & Men's Health, 13(1), 7-10.

McCulloch, P., Altman, D. G., Campbell, W. B., Flum, D.

R., Glasziou, P., Marshall, J. C., & Nicholl, J. (2009).

No surgical innovation without evaluation: the IDEAL

recommendations. The Lancet,

374(9695), 1105-1112.Muehlematter, U. J., Daniore, P., &

Vokinger, K. N. (2021). Approval of artificial

intelligence and machine learning-based medical

devices in the USA and Europe (2015–20): a

comparative analysis. The Lancet Digital Health, 3(3),

e195-e203.

Reyna, M. A., Nsoesie, E. O., & Clifford, G. D. (2022).

Rethinking algorithm performance metrics for artificial

intelligence in diagnostic medicine. JAMA, 328(4),

329-330.

Rivera, S. C., Liu, X., Chan, A. W., Denniston, A. K.,

Calvert, M. J., Ashrafian, H., ... & Yau, C. (2020).

Guidelines for clinical trial protocols for interventions

involving artificial intelligence: the SPIRIT-AI

extension. The Lancet Digital Health, 2(10), e549-

e560.

Rudicel, S., & Esdaile, J. (1985). The randomized clinical

trial in orthopaedics: obligation or option? JBJS, 67(8),

1284-1293.

Sounderajah, V., Ashrafian, H., Golub, R. M., Shetty, S.,

De Fauw, J., Hooft, L., ... & Liu, X. (2021). Developing

a reporting guideline for artificial intelligence-centred

diagnostic test accuracy studies: the STARD-AI

protocol. BMJ open, 11(6), e047709.

Vasey, B., Nagendran, M., Campbell, B., Clifton, D. A.,

Collins, G. S., Denaxas, S., ... & McCulloch, P. (2022).

Reporting guideline for the early-stage clinical

evaluation of decision support systems driven by

artificial intelligence: DECIDE-AI. Nature medicine,

28(5), 924-933.

van Leeuwen, K. G., Schalekamp, S., Rutten, M. J., van

Ginneken, B., & de Rooij, M. (2021). Artificial

intelligence in radiology: 100 commercially available

products and their scientific evidence. European

radiology, 31, 3797-3804.

Wu, E., Wu, K., Daneshjou, R., Ouyang, D., Ho, D. E., &

Zou, J. (2021). How medical AI devices are evaluated:

limitations and recommendations from an analysis of

FDA approvals. Nature Medicine, 27(4), 582-584.

Clinical Evaluation of Collaborative Artiﬁcial Intelligence Systems: Lessons from the Case of Robot-Assisted Surgery

857
