IndraFlow: Seamless Data Transfer and Transformation Between

Internet of Things, Robot Systems and Cloud-Native Environments

Attila Csaba Marosi

1 a

and Kriszti

an P

ora

1,2 b

Laboratory of Parallel and Distributed Systems, Institute for Computer Science and Control (SZTAKI),

Hungarian Research Network (HUN-REN), Hungary

John von Neumann Faculty of Informatics,

Obuda University, Hungary

Keywords:

Data Analytics, IoT, IIoT, Big Data, Data Streaming, ROS, Data Bridge.

Abstract:

In this paper we present our solution which aims to be a generic streaming data bridge. It utilizes a mod-

ular architecture with current support for MQTT, ROS1, ROS2, Kafka and relational database management

systems (RDBMS), such as MySQL or PosgreSQL as data sources or destinations. Our solution also sup-

ports custom transformations of messages and using multiple sources and destinations within a single bridge

instance. We compare our solution to existing generic streaming solutions (such as the GUI-based Apache

NiFi) and custom-made bridge codes (such as a ROS to MQTT bridge). Next, we present two use cases for

our solution from different projects. In the ﬁrst use case ROS messages are received from drones, transformed

and sent to a cloud-based Kafka cluster. The second use case is representing an industrial IoT use case where

MQTT messages are received, transformed and sent to a PostgreSQL server for persistent storage. Finally, we

evaluate the performance and reliability of our solution using the second use case.

1 INTRODUCTION

The rise of the Internet of Things (IoT) has led to an

era where enormous amount of data is generated by

countless devices. This presents a challenge in ef-

fectively using this data, as it requires robust infras-

tructure and connectivity. Similarly, for robots using

the Robot Operating System (ROS) (Quigley et al.,

2009), there’s a growing need for a strong connection

between them and cloud environments.

Message consumption patterns and messaging

systems in distributed systems have evolved to meet

the need for efﬁcient communication and data pro-

cessing, also supporting the challenges of IoT sys-

tems. Publish-subscribe (Eugster et al., 2003) and

message queuing are two important patterns that have

emerged. Publish-subscribe allows for decoupling of

producers and consumers, enabling scalability and a

loosely-coupled architecture. Message queuing en-

sures reliable and asynchronous communication, with

features like load balancing and message persistence.

Initially, generic messaging systems like email and

instant messaging allowed basic communication but

https://orcid.org/0000-0001-9105-6816

https://orcid.org/0009-0008-2229-9521

lacked complex integration capabilities. Message-

oriented middleware (MOM) (Curry, 2004) intro-

duced reliable messaging and clustering provided

fault tolerance and scalability. Enterprise service

bus (ESB) enhanced messaging systems with cen-

tralized infrastructure for managing message routing

and transformation. For messaging systems beside

custom-tailored solutions (Institut f

ur Kraftfahrzeuge,

2023) (Lourenco et al., 2021) (Chaari et al., 2019),

generic distributed message systems like Apache

Kafka (Kreps et al., 2011), Apache Flink (Carbone

et al., 2015) or Apache Pulsar (Pulsar, 2023) have

gained popularity, handling high-throughput, fault-

tolerant messaging for modern architectures and with

data processing capabilities (Akidau et al., 2015).

This research focuses on the need for a reliable

data bridge that connects robot systems, IoT devices

and cloud environments, allowing for smooth and

real-time data transmission and analysis across the

different connected systems. The main contributions

of the paper are as follows. We present our so-

lution, IndraFlow, a generic streaming data bridge

with support for MQTT (Light, 2017), ROS1, ROS2,

Kafka (Wang et al., 2021) and RDBMS (e.g., MySQL

or PosgreSQL) as data sources or destinations. Our

solution also supports custom transformations of mes-

Marosi, A. and Póra, K.

IndraFlow: Seamless Data Transfer and Transformation Between Internet of Things, Robot Systems and Cloud-Native Environments.

DOI: 10.5220/0012622600003705

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 9th International Conference on Internet of Things, Big Data and Security (IoTBDS 2024), pages 191-198

ISBN: 978-989-758-699-6; ISSN: 2184-4976

191

sages and using multiple sources and destinations

within a single bridge instance. We compare our solu-

tion to existing streaming solutions such as the GUI-

based Apache NiFi, and to use case speciﬁc custom-

made bridge codes. Additionally, we present two use

cases: (a) we receive ROS messages from drones,

transform them and sending them to a cloud-based

Kafka cluster; and (b) in an industrial IoT scenario we

receive MQTT messages, transform and send them to

a PostgreSQL server for permanent storage. Finally,

we evaluate our solution through the second use case.

The structure of the paper is as follows. In Sec-

tion 2 we are discussing related works. In Section 3

we are introducing IndraFlow and present its architec-

ture and the design decisions we chose. Additionally,

we present two use cases where IndraFlow is used. In

Section 4 we present performance and reliability eval-

uations using the second use case. Finally, Section 5

discusses future work and concludes the paper.

2 RELATED WORKS

We discuss related works in three categories using a

top-down approach. First, we discuss high-level con-

cepts of data streaming. Second, we discuss generic

data ﬂow solutions with focus on their Robot and

IoT capabilities. We include in this category com-

plete data streaming platforms that provide capabili-

ties both for data sources and sinks and have computa-

tion capabilities either built-in or support via a plug-

in mechanism. Third, we look at custom bridge so-

lutions serving single use-cases. These solutions are

typically developed serving a single use case. Ad-

ditionally, we note here, that we relate the presented

related works concepts to our solution in Section 3.

First, the Lambda (Marz, 2011) and

Kappa (Kreps, 2014) architectures are two popular

high-level approaches for building data processing

systems. The Lambda architecture was designed for

handling massive amounts of data in a fault-tolerant

manner using a batch, a speed and a serving layer. On

the other-hand the Kappa architecture simpliﬁes the

system by eliminating the batch layer, relying solely

on the speed layer for processing both real-time and

historical data. The Kappa architecture focuses on

stream processing and streamlining the processing

pipeline, while the Lambda architecture has both a

batch and a streaming pipeline.

Next, Differential Dataﬂow (McSherry et al.,

2013; Murray et al., 2013), developed by Microsoft, is

a computational framework that enhances traditional

data ﬂow systems by enabling incremental and timely

processing of data. It introduces the concept of dif-

ferences, allowing for efﬁcient handling of updates

to large-scale datasets. By processing incremental

updates instead of recomputing the entire dataset, it

achieves signiﬁcant performance improvements. It

offers a declarative programming model for express-

ing complex data processing tasks in a concise and in-

tuitive manner. Also, it includes fault-tolerance mech-

anisms to ensure data consistency and reliability.

A prominent example of the second related works

category, Apache NiFi is an open-source data integra-

tion tool designed to automate the ﬂow of data be-

tween systems. NiFi provides a user-friendly inter-

face for designing data ﬂows, allowing users to eas-

ily collect, process, and distribute data across vari-

ous environments. It supports a wide range of data

sources and destinations, however it does not sup-

port ROS directly. In case of running multiple data

ﬂows (e.g., different use cases) on a single cluster,

all nodes instantiate all components. This means that

the CPU and memory footprint has always a factor

that is determined by only the complexity of the data

ﬂow and cannot be reduced by scaling the cluster.

Apache NiFi MiNiFi (MiNiFi, 2023) is a sub-project

of Apache NiFi and provides a complementary, low-

footprint data collection approach. It functions as an

agent near or adjacent to data sources such as sensors,

edge devices or other systems. It has a low footprint,

but can support only a subset of NiFi processors.

Logstash is an open-source data processing

pipeline tool that allows users to collect, transform,

and store data from various sources. It is part of the

Elastic Stack (Elastic, 2023), along others such as the

data collectors called as ’Beats’ and Elastic Agent

used for data ingestion. Logstash does not support

MQTT and ROS as input or output. MQTT support is

available via Filebeat, but only as a data source.

Integration frameworks (Ibsen and Anstey,

2018) (MuleSoft, 2023) (Google, 2023) enable the

connection of different systems for data consumption

and production. These support multiple data formats

like such as XML, JSON, CSV and AVRO, and allow

the transformation of messages between different

systems and protocols. They typically provide a

developer environment, where custom components

can be developed (e.g., via Java code or XML

descriptors) and deployed. These solutions can be

considered as low-level, but highly conﬁgurable.

Fluvio (Fluvio, 2023) is an open-source stream-

ing platform with built-in computation capabilities.

Its composed of dedicated components for processing

and stream handling. It supports horizontal scaling

and is backed by a distributed key-store via an uni-

versal interface that currently works with Etcd (Etcd,

2023) and native Kubernetes (Brewer, 2015) key-

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

192

value stores. Fluvio follows the uniﬁed cluster ap-

proach, where all components for streaming and state-

ful computation are integrated. On the other hand,

Arroyo (Arroyo, 2023) is a distributed stream pro-

cessing engine developed for the execution of stateful

computations on different data streams. Its core is a

distributed data ﬂow engine. Its goal is to achieve efﬁ-

cient processing of both bounded and unbounded data

sources. In contrast to traditional batch processors,

Arroyo operates on data streams of varying sizes, en-

abling the immediate generation of results as soon

as they are available and pipelines are deﬁned using

SQL. Also, it provides a web based user interface for

creating pipelines, monitoring and conﬁguration.

Finally, in the third category we discuss custom

solutions for bridging different systems. For exam-

ple (Institut f

ur Kraftfahrzeuge, 2023) provides a bi-

directional bridge between ROS1/ROS2 and MQTT.

It is written in C++ and uses a YAML-based con-

ﬁguration ﬁle for deﬁning topic mappings between

source and destination systems. A similar solution

is (GROOVE X, 2016). In (Lourenco et al., 2021),

authors present a solution that enables the communi-

cation between Apache Kafka and ROS2 using their

custom bridge code. The authors report the number

of messages they produced and the number of mes-

sages stored in Kafka, however they do not report the

rate of messages produced. The presented solution

allows bi-directional data ﬂow, but does not support

any security features of Kafka (authentication, autho-

rization and encryption). In (Chaari et al., 2019), au-

thors present an architecture that allows computation

ofﬂoading to cloud based environments for robotics

environments. Here ROS is used for communication

framework between different robots, Apache Kafka

is used as an intermediary buffer and as a translation

layer between the cloud and robot environment, and

Apache Storm is used for computation. The presented

solution allows bi-directional data ﬂow. The solution

is ROS1 based and relies on Rosbridge (Crick et al.,

2017) that allows sending to and collecting data from

ROS in JSON format using Websockets. The authors

evaluated their solution using message rates up to 25

messages/second (25Hz).

3 IndraFlow DESIGN

We can see that on the higher-level of the spectrum

of the related works we can ﬁnd generic solutions

such as Apache NiFi, Apache Camel, Fluvio, etc.

These are highly customizable, but also require a

steep learning curve and typically lack support for

ROS based use cases. On the lower part of the spec-

trum we can see custom solutions such as (Lourenco

et al., 2021) that are tailored for a speciﬁc use case or

provide bridging capabilities between two solutions

(e.g., bridging between ROS and MQTT) with no or

limited transformation capabilities.

The aim of IndraFlow is to provide a middle

ground. The ﬁrst goal of IndraFlow is to offer a

generic, but still highly customizable solutions with

support for cloud, IIoT and Robot based use cases.

The second goal is to provide light-weight transfor-

mation capabilities for changing the structure or for-

mat of the messages between source and destination

systems. Additionally, we aim to provide an a mod-

ularized structure, rather than an integrated all-in-one

solution such as Fluvio. Furthermore, we use a de-

scriptive conﬁguration (i.e., YAML-based) such as in

(Institut f

ur Kraftfahrzeuge, 2023) and a simpliﬁed

setup, thus a single instance focuses on data transfer

between a single source and destination.

Figure 1 presents the IndraFlow architecture. On

the left side of the architecture we observe the data

source modules. Currently ROS, ROS2, MQTT and

Kafka sources are supported out of the box. How-

ever, data sources are connected via modules that

rely on a well-deﬁned interface. Thus, adding new

sources is a straight-forward process. Similarly, on

the right side of Figure 1, the available data destina-

tions are shown. Currently IndraFlow has modules

for Kafka, RDBMS (relational databases supported

via SQLAlchemy) and MQTT data destinations. The

list of outputs is also extensible with new destination

modules that implement a well-deﬁned interface.

The Intermediary Storage and Processing (ISP, see

in Figure 1) is a special module as it can act both as

a data source and destination. Its role is to decouple

other data sources and other data destinations. Next,

in IndraFlow the basic data ﬂow is represented by a

span. A span is similar to an input → ﬁlter → out-

put pipeline in Logstash. However, IndraFlow allows

custom transformations and supports ROS and MQTT

based data sources and destinations. Figure 2 depicts

a single span denoted by N as follows (see Figure 1):

N = ⟨S, T (t

, ..., t

), D⟩ (1)

Here S represents a data source, T (t

, ..., t

) de-

notes the transformation functions used in the span,

and D is the destination for the data. Both source S

and destination D can be any of the supported plu-

gins or the ISP. Any number of transformations are

allowed, however, currently a span is executed within

a single process, thus, increasing the number of trans-

formations will increase the latency of messages.

Next, lets consider D as a set of points. This set

of points represent the available data sources and des-

IndraFlow: Seamless Data Transfer and Transformation Between Internet of Things, Robot Systems and Cloud-Native Environments

193

Figure 1: General architecture of IndraFlow.

tinations within an environment or use case. A span

is an edge between data source v

∈ D and desti-

nation v

∈ D with the weight w

= T (t

1,1

, ..., t

1,n

Using the notation from equation 1:

= ⟨v

, w

, v

⟩ (2)

Furthermore, a pipeline P is can be constructed us-

ing arbitrary number of spans (edges) (see Figure 1):

P = (e

, e

..., e

) (3)

A pipeline denotes and end-to-end data ﬂow, how-

ever it does not need to be continuous. Spans within

a pipeline behave independently, they can be created,

started and stopped as needed. They might form a

path (a continuous data ﬂow) within a directed graph

(e.g., e

→ e

). In this case the destination of

is the data source of e

. Additionally, each edge

(span) in a pipeline has an additional weight p that

denotes the multi-span conﬁguration (see section 3),

where multiple parallel instances of the same span are

started to load balance the transfer of messages.

IndraFlow runs on top of a container orchestrator

such as Kubernetes or Docker Compose. Currently,

each span is implemented as a separate container, and

pipelines are scaled and orchestrated via standard-

ized tools such as Docker Compose and Helm (Helm,

2023). Currently, the ISP is a containerized Apache

Kafka cluster. These tools allow to deploy, manage

and scale IndraFlow on a component by component

basis. For example in case of Apache NiFi when run-

ning multiple data ﬂows (e.g., different use cases) on

a single cluster, all nodes instantiate all components.

This means that the CPU and memory footprint has

always a factor that is determined by only the com-

plexity of the data ﬂow and cannot be reduced by scal-

ing the cluster. The best-practice for NiFi is to sepa-

rate each data ﬂow to its dedicated cluster (Cloudera,

2023). However, this would increase the administra-

tive burden or require further automation.

Figure 2: Structure of a single IndraFlow Span.

In the following sections we introduce two real-

world use cases where IndraFlow is actively be-

ing used. The ﬁrst use case involves bi-directional

data ﬂow between drones and autonomous vehi-

cles, and cloud-based environments. Within the Na-

tional Laboratory for Autonomous Systems (abbre-

viated as ARNL in Hungarian) and the TKP2021-

NVA-01 project (”Research on Hydrogen-Powered,

Cooperative Autonomous Remote Sensing Devices

and Related Data Processing Framework”) in Hun-

gary IndraFlow is used for data bridging between

ROS1/ROS2 based drones and autonomous vehi-

cles (N

emeth and G

asp

ar, 2021) and a cloud-based

data platform (Marosi et al., 2022). This involves

multiple data ﬂows between (i) bi-directional ROS

and Apache Kafka, and (ii) ROS and TimescaleDB/

PostgreSQL. Originally the ﬂow of data was ROS →

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

194

MQTT (via custom bridge code) → Apache Kafka

(via Apache NiFi) → TimescaleDB (via Apache

NiFi). With the help of IndraFlow this is simpliﬁed

to (a) ROS → TimescaleDB/ PostgreSQL or (b) ROS

→ Kafka → TimescaleDB/ PostgreSQL, depending

on the message rate (see section 4 for details).

The second use case is based on Industrial IoT

(IIoT) data collection and enrichment in a robotic as-

sembly scenario (Beregi et al., 2019) (Beregi et al.,

2021). This scenario involves a service-oriented man-

ufacturing execution system, in which the collabo-

rative robotic arm near real time-data provision pro-

vides the foundation necessary for a better under-

standing of the entire process. In this use case, the

robots used provide data on their physical operations

at up to 125Hz via an MQTT interface. This data is

subsequently stored in TimescaleDB (TimescaleDB,

2023), a time-series database based on PostgreSQL.

Here similar Apache NiFi based data ﬂows were used

as in the previous use case, and they are being phased

out in favor of IndraFlow based ones.

This use case is actively utilized within ARNL

in Hungary, and is detailed in (Marosi et al., 2022).

However, for the evaluation, we opted to use a pub-

licly available dataset to support the reproducibility

of our research. Therefore, we selected an environ-

mental dataset from Kaggle (Stafford, 2020).

Furthermore, in contrast to the original use case

where TimescaleDB is actively used, we chose to

use the standard PostgreSQL for the evaluation. This

decision was made to eliminate an external variable

(TimescaleDB) from the assessment.

4 EVALUATION AND

DISCUSSION OF RESULTS

In order to evaluate the scalability and reliability

of our solution, numerous performance benchmarks

simulating the previously described IIoT use case

were performed. As detailed previously, the ex-

periments were based on a public dataset of sensor

telemetry data (Stafford, 2020). For the sake of sys-

tematic and reproducible experimentation, we devel-

oped an automated benchmarking framework capable

of starting and terminating components, logging uti-

lization, gathering results, and generating reports.

The experiments presented were performed on

HUN-REN Cloud (H

eder et al., 2022), a federated,

community cloud based on OpenStack. We utilized

the resources of a single m2.2xlarge ﬂavoured virtual

machine instance, featuring a 16-Core virtual CPU

(Intel Xeon Gold 6230R) and 32 GB of memory. All

components were deployed using Docker.

Three containers were launched in order to act

as parts of a sensor network, and provide a stable

stream of time-series data. Under the hood, the sen-

sor containers were reading rows from the dataset and

transforming them to JSON objects before forward-

ing them to the message broker. In order to enable the

evaluation of the scalability of IndraFlow, a delay pa-

rameter was implemented, which determines the rate

at which the sensors send out messages. The sen-

sors were generating data throughout a ﬁve minute

benchmark period in all presented cases. The ﬁrst

step in the message ﬂow was an open source MQTT

message broker, Mosquitto (Light, 2017). The main

aim of this use case is to provide long-term storage

for the messages received by the broker, namely to

store them in a PostgreSQL (Stonebraker and Rowe,

1986) database, which serves as the ﬁnal destination

for the ﬂow of data. IndraFlow interconnects the

source and destination systems and handles the de-

livery of messages and the transformation of time-

series data into records of a relational database. The

executed benchmarks were scaled twofold: the deliv-

ery rates, throughput, and latency of IndraFlow were

measured with message frequencies from 120Hz to

up to 845Hz, and with pipelines consisting of 1 to

up to 16 Spans. While in the 1-Span case all mes-

sages were handled by the single Span, in Multi-Span

conﬁgurations the messages are balanced among the

Spans using a shared subscription model.

We present reliability measurements in Table 1.

The ﬁrst row of the table describes the destination of

the messages. We performed experiments with the

PostgreSQL database at increasing frequency values,

and repeated with a Dummy destination at the highest

frequency. The two rows below describe the param-

eters of the sensor network. The frequency of mes-

sages, denoted by f , is calculated as follows:

f =

δ + θ

× N (4)

Where δ stands for the message delay, and N is

the number of sensors transmitting messages. θ rep-

resents the overhead of publishing messages, which

is increasingly signiﬁcant as the delay is lowered: at a

delay of 0.025 seconds, the sensors are able to publish

messages without a noticeable overhead, and achieve

a frequency of 120 Hz. In theory, halving the delay

would mean twice the frequency, however, as it can

be observed, due to the effect of the overhead, with

a delay of 0.0125 seconds messages are published at

a frequency of 235 Hz instead of the expected 240

Hz. The message delay is set up before running the

benchmark, and then forwarded to the sensor contain-

ers at runtime. The rows below show the achieved

results of 1- to 16-Span conﬁgurations of IndraFlow.

IndraFlow: Seamless Data Transfer and Transformation Between Internet of Things, Robot Systems and Cloud-Native Environments

195

Table 1: Measurements of scalability and reliability focusing on the delivery rate and latency achieved by different pipeline

conﬁgurations under increasing message frequency. The 845Hz conﬁguration was also tested with a Dummy destination

model in order to verify the database adapter as a source of bottleneck.

Destination PostgreSQL Dummy

Message

Frequency [Hz] 120 235 450 845 845

Delay [s] 0.025 0.0125 0.00625 0.003125 0.003125

1-Span

Delivery Rate 100% 30.4% 11.7% 7.3% 100%

Latency [ms] 11 21800 14318 14886 12

2-Span

Delivery Rate 100% 100% 48.9% 19.7% 100%

Latency [ms] 8 9 14973 18508 15

4-Span

Delivery Rate 100% 100% 100% 39.8% 100%

Latency [ms] 8 9 13 17392 12

8-Span

Delivery Rate 100% 100% 100% 100% 100%

Latency [ms] 8 9 13 28 9

16-Span

Delivery Rate 100% 100% 100% 100% 100%

Latency [ms] 8 9 13 19 9

(a) Latency of messages at 850Hz.

(b) CPU Utilization of a single Span at 120Hz.

Figure 3: Latency and CPU utilization measurements with different conﬁgurations.

The delivery rate represents the percentage of mes-

sages successfully stored. The latency, measured in

milliseconds, shows the amount of time between the

sensors publishing a message, and it being stored

by the PostgreSQL database. The presented values

were taken as the median of three 5-minute bench-

mark executions. In case of the latency, the median

value for all messages sent is ﬁrst selected for each

run. As it can be seen, an IndraFlow pipeline consist-

ing of just a single Span handles a 120 Hz message

ﬂow without errors, however becomes highly unre-

liable beyond this point, storing smaller and smaller

fractions of total messages sent as the frequency in-

creases. It can also be observed that the message loss

is accompanied by latency values that are several or-

ders of magnitude larger. The measurements show

that scaling the pipelines, namely increasing the num-

ber of Spans improves the reliability of the solution,

enabling low-latency, lossless message delivery even

for data streams with signiﬁcantly higher frequency.

IndraFlow is able to achieve lossless message deliv-

ery at the last measurement point, 845 messages per

second, while utilizing 8 or 16 Spans.

We found that the main problem occurring in

high-frequency benchmarks is that due to a bottle-

neck in the destination model, the employed Spans

are simply too busy with storing data, and cannot

keep up with the velocity of messages. In the cur-

rent iteration of IndraFlow, messages are handled one-

by-one, meaning that the database adapters in the

RDBMS model were forced to perform many costly

single insertions, which becomes a limiting factor at

higher frequencies. In order to verify this, additional

benchmarks were executed with a Dummy destination

model, which simply drops messages after the Span

forwards them for storage. The results in the last col-

umn of the table demonstrate that without the bottle-

neck of the database adapters, even a single Span is

able to receive all messages at a frequency of 845Hz.

Figure 3a shows the latency of messages measured

over the duration of a benchmark conducted with 845

messages sent per second. While it was shown pre-

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

196

viously that both 8- and 16-Span conﬁgurations man-

aged to deliver all the messages from source to des-

tination at this frequency, it can be observed on the

ﬁgure that the 16-Span pipeline achieved this with

signiﬁcantly lower latency. The fastest message took

5 milliseconds in both cases, while to slowest took

526 milliseconds using 8 Spans, and 138 millisec-

onds using 16. The mean latency for 8- and 16-Span

pipelines were 45.66 and 19.18 milliseconds respect-

fully. Based on the histogram on the right side of the

plot, we can conclude that while major spikes in la-

tency occur (especially in the 8-Span case), most of

the messages are delivered with a latency of less then

100 milliseconds. These results nicely demonstrate

why scaling even beyond conﬁgurations achieving a

100% delivery rate might be beneﬁcial in use-cases

with time-critical systems.

Lastly, tendencies in the CPU utilization of In-

draFlow were also examined. Measurements of the

CPU utilization percentage of a single Span in dif-

ferent conﬁgurations are presented on Figure 3b. As

indicated by the results, scaling the data pipelines to

multiple Spans can be a major factor in not only reli-

ability and performance, but also in the efﬁcient uti-

lization of computational resources. As doubling the

number of utilized Spans nearly halves the CPU uti-

lization per Span, scaled IndraFlow pipelines can be

considered as beneﬁcial options in use cases where

the available processing power in individual devices

might be limited (e.g., Edge and Fog computing).

5 CONCLUSIONS AND FUTURE

WORK

In this paper, we presented our generic data bridge,

IndraFlow. It features a modular architecture, sup-

porting currently different protocols and systems such

as MQTT, ROS1, ROS2, Kafka and various RDBMS.

Furthermore, it supports custom message transforma-

tions and multiple sources and destinations within a

single bridge instance. Our evaluation has shown that

the scalability of our solution enables it to provide re-

liable and and low latency transmission at high mes-

sage frequencies. Additionally, it was demonstrated

that increasing the number of Spans is beneﬁcial both

in terms latency and the resource utilization of single

Spans, making IndraFlow a promising option in time-

and resource-critical systems.

For future we would like to focus on enhancing

the orchestration of spans, particularly for use cases

requiring multiple spans and more intricate work-

ﬂows (graphs), and enabling components of spans

(source, transform, destination) to run on Function-

as-a-Service (FaaS) platforms such as AWS Lambda

or OpenFaaS (OpenFaaS, 2023).

ACKNOWLEDGEMENTS

The research was partially supported by the Min-

istry of Innovation and Technology NRDI Ofﬁce

within the framework of the Autonomous Systems

National Laboratory Program. Project no. TKP2021-

NVA-01 has been implemented with the support pro-

vided by the Ministry of Innovation and Technol-

ogy of Hungary from the National Research, De-

velopment and Innovation Fund, ﬁnanced under the

TKP2021-NVA funding scheme, as well as under

OTKA Grant Agreement No. K 132838. On be-

half of projects ”ARNL: GPU-enabled Cloud-based

Big Data/AI Research Platform” and ”Research on

Hydrogen-Powered, Cooperative Autonomous Re-

mote Sensing Devices and Related Data Processing

Framework” we thank for the usage of HUN-REN

Cloud (H

eder et al., 2022) (https://science-cloud.hu/)

that signiﬁcantly helped us achieving the results pub-

lished in this paper.

REFERENCES

Akidau, T., Bradshaw, R., Chambers, C., Chernyak, S.,

Fern

andez-Moctezuma, R. J., Lax, R., McVeety, S.,

Mills, D., Perry, F., Schmidt, E., and Whittle, S.

(2015). The dataﬂow model: A practical approach

to balancing correctness, latency, and cost in massive-

scale, unbounded, out-of-order data processing. Pro-

ceedings of the VLDB Endowment, 8(12):1792–1803.

Arroyo (2023). Arroyo: Cloud-native stream processing.

https://www.arroyo.dev/. Accessed: 2023-12-01.

Beregi, R., Pedone, G., H

ay, B., and V

ancza, J. (2021).

Manufacturing execution system integration through

the standardization of a common service model for

cyber-physical production systems. Applied Sciences,

11(16).

Beregi, R., Pedone, G., and Mezg

ar, I. (2019). A novel

ﬂuid architecture for cyber-physical production sys-

tems. International Journal of Computer Integrated

Manufacturing, 32(4-5):340–351.

Brewer, E. A. (2015). Kubernetes and the path to cloud

native. In Proceedings of the Sixth ACM Symposium

on Cloud Computing, SoCC ’15, page 167, New York,

NY, USA. Association for Computing Machinery.

Carbone, P., Katsifodimos, A., Ewen, S., Markl, V., Haridi,

S., and Tzoumas, K. (2015). Apache ﬂink: Stream and

batch processing in a single engine. The Bulletin of the

Technical Committee on Data Engineering, 38(4).

Chaari, R., Cheikhrouhou, O., Koubaa, A., Youssef, H., and

Hmam, H. (2019). Towards a Distributed Computa-

tion Ofﬂoading Architecture for Cloud Robotics. In

IndraFlow: Seamless Data Transfer and Transformation Between Internet of Things, Robot Systems and Cloud-Native Environments

197

2019 15th International Wireless Communications &

Mobile Computing Conference (IWCMC), pages 434–

441, Tangier, Morocco. IEEE.

Cloudera (2023). Cloudera dataﬂow for the public cloud

(cdf-pc) datasheet. https://www.cloudera.com/conte

nt/dam/www/marketing/resources/datasheets/cloude

ra-dataflow-datasheet.pdf. Accessed: 2023-12-26.

Crick, C., Jay, G., Osentoski, S., Pitzer, B., and Jenkins,

O. C. (2017). Rosbridge: Ros for non-ros users. In

Robotics Research: The 15th International Sympo-

sium ISRR, pages 493–504. Springer.

Curry, E. (2004). Message-oriented middleware. Middle-

ware for communications, pages 1–28.

Elastic (2023). Elastic stack: Elasticsearch, kibana, beats

& logstash. https://www.elastic.co/elastic- stack/.

Accessed: 2023-12-27.

Etcd (2023). Etcd: A distributed, reliable key-value store

for the most critical data of a distributed system. https:

//etcd.io/. Accessed: 2023-12-26.

Eugster, P. T., Felber, P. A., Guerraoui, R., and Kermarrec,

A.-M. (2003). The many faces of publish/subscribe.

ACM computing surveys (CSUR), 35(2):114–131.

Fluvio (2023). Fluvio: The programable data streaming

platform. https://www.ﬂuvio.io/. Accessed: 2023-

12-01.

Google (2023). Google Cloud: Apigee API Management.

https://cloud.google.com/apigee. Accessed: 2023-12-

31.

GROOVE X, I. (2016). mqtt bridge: functionality to bridge

between ROS and MQTT in bidirectional. https://gi

thub.com/groove-x/mqtt bridge. Accessed: 2023-12-

31.

eder, M., Rig

o, E., Medgyesi, D., Lovas, R., Tenczer,

S., Farkas, A., Em

odi, M. B., Kadlecsik, J., and

Kacsuk, P. (2022). The past, present and future of the

elkh cloud. INFORM

ACI

OS T

ARSADALOM:

ARSADALOMTUDOM

ANYI FOLY

OIRAT,

22(2):128–137.

Helm (2023). Helm: The package manager for kubernetes.

https://helm.sh/. Accessed: 2023-12-31.

Ibsen, C. and Anstey, J. (2018). Camel in action. Simon

and Schuster.

Institut f

ur Kraftfahrzeuge, RWTH Aachen, i. (2023).

MQTT client: ROS / ROS 2 C++ Node for bi-

directionally bridging messages between ROS and

MQTT. https://github.com/ika-rwth-aachen/mqtt

client. Accessed: 2023-12-31.

Kreps, J. (2014). Questioning the lambda architecture. http

s://www.oreilly.com/radar/questioning-the-lambda-a

rchitecture/. Accessed: 2023-12-31.

Kreps, J., Narkhede, N., Rao, J., et al. (2011). Kafka: A dis-

tributed messaging system for log processing. In Pro-

ceedings of the NetDB, volume 11, pages 1–7. Athens,

Greece.

Light, R. A. (2017). Mosquitto: server and client implemen-

tation of the mqtt protocol. Journal of Open Source

Software, 2(13):265.

Lourenco, L. L., Oliveira, G., Mea Plentz, P. D., and Ron-

ing, J. (2021). Achieving reliable communication be-

tween kafka and ROS through bridge codes. In 2021

20th International Conference on Advanced Robotics

(ICAR), pages 324–329, Ljubljana, Slovenia. IEEE.

Marosi, A. C., Em

odi, M., Farkas, A., Lovas, R., Beregi,

R., Pedone, G., N

emeth, B., and G

asp

ar, P. (2022).

Toward reference architectures: A cloud-agnostic data

analytics platform empowering autonomous systems.

IEEE Access, 10:60658–60673.

Marz, N. (2011). How to beat the cap theorem. http://nathan

marz.com/blog/how-to-beat-the-cap-theorem.html.

Accessed: 2023-12-31.

McSherry, F., Murray, D., Isaacs, R., and Isard, M. (2013).

Differential dataﬂow. In Proceedings of CIDR 2013.

Proceedings of cidr 2013 edition.

MiNiFi, A. N. (2023). Apache niﬁ miniﬁ:a subproject of

apache niﬁ to collect data from the point of origin.

https://niﬁ.apache.org/minifi/. Accessed: 2023-12-

01.

MuleSoft (2023). MuleSoft Anypoint Platform: Enterprise

Hybrid Integration Platform. https://www.mulesoft.c

om/platform/enterprise-integration. Accessed: 2023-

12-31.

Murray, D. G., McSherry, F., Isaacs, R., Isard, M., Barham,

P., and Abadi, M. (2013). Naiad: A timely dataﬂow

system. In Proceedings of the Twenty-Fourth ACM

Symposium on Operating Systems Principles, pages

439–455, Farminton Pennsylvania. ACM.

emeth, B. and G

asp

ar, P. (2021). The design of perfor-

mance guaranteed autonomous vehicle control for op-

timal motion in unsignalized intersections. Applied

Sciences, 11(8).

OpenFaaS (2023). OpenFaaS: Serverless Functions, Made

Simple. https://www.openfaas.com/. Accessed: 2023-

12-31.

Pulsar (2023). Apache Pulsar: Cloud-Native, Distributed

Messaging and Streaming. https://pulsar.apache.org/.

Accessed: 2023-12-31.

Quigley, M., Conley, K., Gerkey, B., Faust, J., Foote, T.,

Leibs, J., Wheeler, R., Ng, A. Y., et al. (2009). Ros: an

open-source robot operating system. In ICRA work-

shop on open source software, volume 3, page 5.

Kobe, Japan.

Stafford, G. (2020). Environmental sensor telemetry data.

https://www.kaggle.com/datasets/garystafford/envir

onmental-sensor-data-132k. Accessed: 2023-12-01.

Stonebraker, M. and Rowe, L. A. (1986). The design of

postgres. ACM Sigmod Record, 15(2):340–355.

TimescaleDB (2023). TimescaleDB: Time-series data sim-

pliﬁed. https://www.timescale.com. Accessed: 2023-

12-31.

Wang, G., Chen, L., Dikshit, A., Gustafson, J., Chen, B.,

Sax, M. J., Roesler, J., Blee-Goldman, S., Cadonna,

B., Mehta, A., Madan, V., and Rao, J. (2021). Con-

sistency and completeness: Rethinking distributed

stream processing in apache kafka. In Proceedings

of the 2021 International Conference on Management

of Data, SIGMOD ’21, page 2602–2613, New York,

NY, USA. Association for Computing Machinery.

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

198
