CC-SolBMC: Condition Coverage Analysis for Smart Contracts Using

Solidity Bounded Model Checker

Sangharatna Godboley

and P. Radha Krishna

NITMiner Technologies, Department of Computer Science and Engineering,

National Institute of Technology,

Warangal, Telangana, India

Keywords:

Smart Contract, Bounded Model Checker, Condition Coverage, Solidity Compiler.

Abstract:

Advances in blockchain technologies enable society toward trust-based applications. Smart contracts are the

scripts holding the properties to perform the activities in Blockchain. Smart contracts are prepared between

the parties to hold their requirements and promises. If the deal held by a smart contract is huge and expen-

sive, then there is a high chance of attracting issues and loss of assets. This necessitates the veriﬁcation and

testing of a smart contract. In this paper, we demonstrate an approach for generating test cases to satisfy the

condition coverage of smart contracts using a solidity-bounded model checker. We show the annotation of

the original smart contract as per the condition coverage speciﬁcation and drive the bounded model checker to

prove the feasibility of the asserted properties. Finally, we collect all feasible targets and show the condition

coverage score. Also, the proposed approach generates test input values for each feasible atomic condition.

The approach presented has been tested with 70 smart contracts, resulting in 57.14% of contracts with good

condition coverage scores. Our work can be utilized to certify any smart contract to check whether the Opti-

mal or Maximal condition coverage is achieved or not.

1 INTRODUCTION

Blockchains are distributed data structures to store the

agreed sequence of transactions in a user network.

They can be employed in many applications (e.g.,

such as banking, insurance, health applications, vehi-

cle networks, shipping, logistics, and cyber-security)

that need data exchange between different users. The

actions are stored in the form of a block and the

data is distributed over individual nodes after accep-

tance by the respective user. One of the major advan-

tages of blockchain technologies are to avoid temper-

ing data (that is, immutability) by anonymous users,

which in turn increases transparency and security. In

addition, blockchain has several unique and desir-

able properties including decentralization, auditabil-

ity, anonymity, and autonomously enforcing logic via

a smart contract.

Blockchains (such as Hyperledger (Buterin et al.,

2014) and Ethereum (Dannen, 2017; etherscan,

2021)) enforce consensus, if any, by the users in-

volved, as deﬁned in the smart contract. A smart

https://orcid.org/0000-0002-6169-6334

https://orcid.org/0000-0001-8298-7571

contract is a computer program, comprising exe-

cutable codes, residing on the blockchain and exe-

cuted once speciﬁc (pre-deﬁned) conditions are met.

The transactions are programmable by smart con-

tracts. A smart contract pays attention to transactions

sent to it, executes application logic upon receipt of a

transaction, and depending on the need can generate

other transactions that can be received by participat-

ing users. Thus, a smart contract includes code and

data on which the smart contract operates. Also, a

smart contract can control other smart contracts.

Smart contract-enabled blockchains guarantee

that conditions in a smart contract are not modiﬁed

once they have been written and published. The code

for smart contracts is typically written in a high-level

programming language such as Go

for Hyperledger

and Solidity

for Ethereum. Similar to traditional

software applications, there may be deviations, errors,

and vulnerabilities in the smart contract logic code.

Thus, coding smart contract logic as per the applica-

“The Go programming language,” https://golang.org/.

“Hyperledger project,” https://www.hyperledger.org/.

“Solidity smart-contract language,”

https://solidity.readthedocs.io/.

Godboley, S. and Krishna, P.

CC-SolBMC: Condition Coverage Analysis for Smart Contracts Using Solidity Bounded Model Checker.

DOI: 10.5220/0012627200003687

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2024), pages 387-395

ISBN: 978-989-758-696-5; ISSN: 2184-4895

387

tion requirements and ensuring the correctness of that

code is very important and challenging. To the best

of our knowledge, there is very limited work in the

literature on the veriﬁcation and testing of the smart

contract logic.

Our approach enables the annotation of a smart

contract with goal constraints or targets in the form

of “asserts" that ensures the speciﬁcation of condi-

tion coverage. The solidity compiler with a bounded

model checking feature detects the targets in anno-

tated smart contracts. Later, we extract useful infor-

mation from the execution report and show the cover-

age information. The main contribution of this work

is to provide a system for the contributors of smart

contracts to test their scripts and certify the smart con-

tracts with three classes viz. Optimal, Maximal, and

Incomplete.

The rest of the paper is organized as follows. In

Section 2, we discuss the related work. Section 3

shows basic concepts. Section 4 presents the pro-

posed Condition Coverage analysis for Smart Con-

tracts using the Solidity Bounded Model Checker

(CC-SolBMC). Section 5 describes the experimental

results. Finally, We conclude the paper with future

insights in Section 6.

2 RELATED WORK

The ﬁrst blockchain platform that supports smart con-

tracts is Ethereum (Dannen, 2017; Wood et al., 2014),

in which Solidity scripting language is used for de-

veloping smart contracts. There are some works (eg.

(Sánchez-Gómez et al., 2019; Liu et al., 2020)) in the

domain of smart contract testing

Wen and Miller (Wen and Miller, 2016) described

an automated bug identiﬁcation in smart contracts,

however, our work proposed to measure the condi-

tion coverage. Praitheeshan et al (Praitheeshan et al.,

2019) presented a survey on vulnerability analysis

and formal veriﬁcation methods in Ethereum smart

contracts. They surveyed 16 kinds of vulnerabilities

in smart contracts and presented the existing security

issues, analysis tools, and detection methods along

with their limitations. They have categorized the anal-

ysis method into three categories viz. formal veriﬁca-

tion, static, and dynamic. These categories are com-

pared based on accuracy, vulnerability detection, and

performance.

Benitez et al. (Benitez et al., 2020) considered

the program for smart contracts as a chain of typed

programs (typechain) and provided veriﬁed properties

to ensure the smart contract correctness.

Andesta et al. (Andesta et al., 2020) have pro-

posed 10 classes of mutation operators and presented

a method of testing solidity smart contracts using mu-

tation testing. Their proposed method is capable of

regenerating the real bug in ten contracts out of ﬁfteen

contracts and they have also provided their mutation

operators with a universal mutator tool.

Manticore (Mossberg et al., 2019) is a Dynamic

Symbolic Executor, used for analyzing smart con-

tracts. It uses z3 a constraint solver. However, it is

unable to analyze smart contracts if there are multiple

contracts in a single ﬁle. Due to its dynamic nature, it

takes more execution time compared to others.

Solanalyser (Akca et al., 2019) uses both static

and dynamic analyses of vulnerabilities in smart con-

tracts. It can also inject faults into the existing Smart

contract for testing purposes.

sFuzz(Nguyen et al., 2020) is a combination of

AFL fuzzer and a multi-objective adaptive strategy

that is useful for the veriﬁcation of smart contracts.

This tool is prone to false positives and excludes the

view function.

ContractFuzzer (Jiang et al., 2018) uses Contract

Application Binary Interface (ABI) speciﬁcations for

generating test cases by fuzzing. However, it does not

check for Integer overﬂow/underﬂow, and in many

cases, it shows false negatives.

3 BASIC CONCEPTS

In this section we discuss, some important terminolo-

gies used in this paper.

As per IBM

“Smart contracts are scripts stored

on a blockchain that run when all the previously es-

sential requirements are full-ﬁlled. Smart contracts

are used to automate the process of an agreement so

that all contributors can be immediately certain of the

outcome, without any intermediary’s involvement or

time loss. These can be automated in a workﬂow, trig-

gering the next action when requirements are met."

In Bounded Model Checking (BMC)(Clarke et al.,

2003; Clarke et al., 2004), a Boolean formula is con-

structed which is satisﬁable if and only if the under-

lying state transition system can realize a ﬁnite se-

quence of state transitions that reach certain states of

interest.

Condition Coverage is the percentage of condi-

tions within decision expressions in a script that has

been evaluated to be both true and false by NIST

https://www.ibm.com/topics/smart-contracts

https://csrc.nist.gov/glossary/term/Condition_coverage

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

388

Source Contract

Annotator

Original Smart

Contract

Annotated Smart

Contract

SolBMC

Execution Report

Extractor

Condition

Coverage Report

Figure 1: The framework for CC-SolBMC.

4 PROPOSED APPROACH

In this section, we discuss our proposed framework

and provide a detailed explanation with a working ex-

ample.

4.1 Framework of CC-SolBMC

Fig. 1 shows a schematic representation of our pro-

posed approach CC-SolBMC. This framework mainly

contains three components namely 1. Source Con-

tract Annotator, 2. SolBMC, and 3. Extractor. The

ﬂow starts with supplying the Original Smart Con-

tract into Source Contract Annotator to produce An-

notated Smart Contract. This modiﬁed version of the

smart contract has markings for true and false branch

edges for each atomic condition. These markings are

in the form of assertions.

Next, the Annotated Smart Contract is supplied

into a smart veriﬁer SolBMC. Since SolBMC follows

the Satisﬁability Modulo Theories (SMT) technique

using Z3 constraints solver, the reachability and fea-

sibility of each marked assertion can be done. The

SolBMC generates a detailed execution report. This

execution report contains the log of each assertion vi-

olation with the counter-example (test inputs). The

Extractor component analyses the Execution Report

and identiﬁes the total number of assertion violations.

Each assertion violation represents a branch edge.

Also, the Extractor analyses the Original Smart Con-

tract to identify the total number of atomic condi-

tions present in if-else statements and in require state-

ments and counts the total number of calling mod-

iﬁers. Finally, Condition Coverage Report is gen-

erated from Extractor, which contains the condition

coverage score.

4.2 Algorithmic Description

In this section, we explain our proposed approach

with algorithmic descriptions.

Algorithm 1 shows the implementation of the

Source_Contract _Annotator. Here we supply Smart

Contract SC as an input and get Annotated Smart

Contract ASC as an output. Line 1 of Algorithm 1

shows an iteration for all the conditions (AllCondi-

tions) identiﬁed from SC. It is to be noted that, for

any conditional statement there are two branches viz.

True and False. The loop iterates for each condi-

tion identiﬁed at a speciﬁc line. For a TRUE branch

of Condition, create “assert(!(condition));". Simi-

larly, for a FALSE branch of Condition, create “as-

sert(!(!(condition)));". Line 8 of Algorithm 1 injects

the created assertions in Lines 3 and 6 of Algorithm 1

just above the location at line number where the con-

dition was identiﬁed. Finally, after iterating the loop

for all the conditions present in SC, Algorithm 1 re-

turns ASC.

Algorithm 1: Source_Contract_Annotator.

Input: SC

Output: ASC

1 while Condition ∈ AllConditions do

2 if TRUE Branch of Condition then

3 Create “assert(!(condition));"

4 end

5 if FALSE Branch of Condition then

6 Create “assert(!(!(condition)));"

7 end

8 Inject “assert(!(condition));" and

“assert(!(!(condition)));" above the line

where the Condition was identiﬁed;

9 end

10 return ASC ;

Algorithm 2 shows the logic of CC-SolBMC. We

provide a Smart Contract (SC) as an input to CC-

SolBMC and produce Condition Coverage

Score

(CC%) as an output. Line 1 of Algorithm 2 invokes

Algorithm 1 i.e. Source_Contract _Annotator by sup-

plying SC and produces Annotated Smart Contract

(ASC). At Line 2, SolBMC is called with argument

ASC and generates Execution_Report. This report

contains all the useful information for detecting the

targets with counterexamples. Finally, the Extrac-

tor is called by supplying SC and Execution_Report

to produce Condition_Coverage_Report. Using the

Condition_Coverage_Report with the values of De-

tected unique assertions and Total injected assertions,

we compute CC% Line 4.

It is to be noted that we consider atomic condition from

a decision with or without any logical operator(s).

CC-SolBMC: Condition Coverage Analysis for Smart Contracts Using Solidity Bounded Model Checker

389

Algorithm 2: CC-SolBMC.

Input: SC

Output: CC%

1 ASC ←−Source_Contract_Annotator(SC);

2 Execution_Report ←− SolBMC(ASC);

3 Condition_Coverage_Report ←−

Extractor(SC,Execution_Report);

4 CC%= (Detected unique assertions / Total

injected assertions)X100

4.3 Working Example

In this section, we consider an example smart contract

namely Token.sol from the set of 70 smart contracts.

The original smart contract for Token.sol is shown in

Listing 1. The characteristics for Token.sol wrt. size

is 37 LOCs, 4 functions, and 3 atomic conditions. In

a smart contract the predicate and conditions can be

written in if-else, if-else-if, for-loop, while-loop and

require statements. It means, for the statements with

boolean logical operators and relational operators, we

consider those statements to be analysed. So, in this

contract, we have three require conditions as shown

below:

balanceOf(msg.sender) >= value

balanceOf(from) >= value

allowance[from][msg.sender] >= value

If the ﬁrst two require conditions are true then the

“balance too low" message will be printed. Similarly,

for the third require condition “allowance too low"

message will be printed. So, it is very important to

check the other Branch of the conditions.

Next, using Source Contract Annotator compo-

nent of our proposed approach, we generate the An-

notated Smart Contract version i.e Token_mod.sol as

shown in Listing 2. In this version, we inject the tar-

gets using the “assert" syntax just above the predi-

cates or conditions identiﬁed in the contract. We pre-

pare the targets as shown below:

For I

Condition:

balanceOf(msg.sender) >= value

TRUE branch of I

Condition:

assert(!((balanceOf(msg.sender) >= value)));

FALSE branch of I

Condition:

assert(!(!(balanceOf(msg.sender) >= value)));

For II

Condition:

balanceOf(from) >= value

TRUE branch of II

Condition:

assert(!((balanceOf(from) >= value)));

FALSE branch of II

Condition:

assert(!(!(balanceOf(from) >= value)));

For III

Condition:

allowance[from][msg.sender] >= value

TRUE branch of III

Condition:

assert(!(( allowance[from][msg.sender] >= value)));

FALSE branch of III

Condition:

assert(!(!(allowance[from][msg.sender] >= value)));

Note that there is a total number of 6 targets which

represent the six branch edges for three atomic condi-

tions.

1 pragma solidity ^0.8.2;

2 contract Token {

3 mapping(address => uint) public

balances;

4 mapping(address => mapping(address =>

uint)) public allowance;

5 uint public totalSupply = 100000000000 *

10 ** 18;

6 string public name = "ELONBUCCS";

7 string public symbol = "BUC";

8 uint public decimals = 18;

9 event Transfer(address indexed from,

address indexed to, uint value);

10 event Approval(address indexed owner,

address indexed spender, uint

value);

11 constructor() {

12 balances[msg.sender] = totalSupply;

13 }

14 function balanceOf(address owner)

public view returns(uint) {

15 return balances[owner];

16 }

17 function transfer(address to, uint

value) public returns(bool) {

18 require(balanceOf(msg.sender) >=

value, ’balance too low’);

19 balances[to] += value;

20 balances[msg.sender] -= value;

21 emit Transfer(msg.sender, to,

value);

22 return true;

23 }

24 function transferFrom(address from,

address to, uint value) public

returns(bool) {

25 require(balanceOf(from) >= value,

’balance too low’);

26 require(allowance[from][msg.sender]

>= value, ’allowance too low’);

27 balances[to] += value;

28 balances[from] -= value;

29 emit Transfer(from, to, value);

30 return true;

31 }

32 function approve(address spender, uint

value) public returns (bool) {

33 allowance[msg.sender][spender] =

value;

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

390

34 emit Approval(msg.sender, spender,

value);

35 return true;

36 }

37}

Listing 1: Original Smart Contract Token.sol.

1 pragma solidity ^0.8.2;

2 contract Token {

3 mapping(address => uint) public

balances;

4 mapping(address => mapping(address =>

uint)) public allowance;

5 uint public totalSupply = 100000000000 *

10 ** 18;

6 string public name = "ELONBUCCS";

7 string public symbol = "BUC";

8 uint public decimals = 18;

9 event Transfer(address indexed from,

address indexed to, uint value);

10 event Approval(address indexed owner,

address indexed spender, uint

value);

11 constructor() {

12 balances[msg.sender] = totalSupply;

13 }

14 function balanceOf(address owner)

public view returns(uint) {

15 return balances[owner];

16 }

17 function transfer(address to, uint

value) public returns(bool) {

18 assert(!(balanceOf(msg.sender) >=

value));

19 assert(!(!(balanceOf(msg.sender) >=

value)));

20 require(balanceOf(msg.sender) >=

value, ’balance too low’);

21 balances[to] += value;

22 balances[msg.sender] -= value;

23 emit Transfer(msg.sender, to,

value);

24 return true;

25 }

26 function transferFrom(address from,

address to, uint value) public

returns(bool) {

27 assert(!(balanceOf(from) >= value));

28 assert(!(!(balanceOf(from) >= value)));

29 require(balanceOf(from) >= value,

’balance too low’);

30 assert(!(allowance[from][msg.sender] >=

value));

31 assert(!(!(allowance[from][msg.sender]

>= value)));

32 require(allowance[from][msg.sender]

>= value, ’allowance too low’);

33 balances[to] += value;

34 balances[from] -= value;

35 emit Transfer(from, to, value);

36 return true;

37 }

38 function approve(address spender, uint

value) public returns (bool) {

39 allowance[msg.sender][spender] =

value;

40 emit Approval(msg.sender, spender,

value);

41 return true;

42 }

43}

Listing 2: Annotated Smart Contract Token_mod.sol.

The annotated Smart Contract is supplied

into SolBMC which is a solidity compiler with

SMTChecker engine, that is, Bounded Model

Checker. This component generates the Execution

Report as shown in Listing 3. If a target is reachable

and is feasible the SMTChecker engine will detect it

and give the counter example for that target. Here,

the counter example shows that the constraint has the

model and the test input values for the variables in

that constraints can be generated. The warning mes-

sage “Warning: BMC: Assertion violation happens

here." highlights the detected target along with the

speciﬁc line number in the source code of the smart

contract.

1 Warning: BMC: Assertion violation happens

here.

2 --> ./Results/Token/Token_mod.sol:19:2:

3 |

4 19 | assert(!(balanceOf(msg.sender) >=

value));

5 | ^^^^^^^^^^^^^^^^^^^^^^^^^

6 Note: Counterexample:

7 = false

8 balances[owner]=38, decimals=0,

owner=28100, to=0, totalSupply=0,

value=0

9 .........................skip..

10 Warning: BMC: Assertion violation happens

here.

11 --> ./Results/Token/Token_mod.sol:20:2:

12 |

13 20 | assert(!(!(balanceOf(msg.sender)

>= value)));

14 | ^^^^^^^^^^^^^^^^^^^^^^^^^

15 Note: Counterexample:

16 =false

17 balances[owner]=20537, decimals=0,

owner=1323, to=0, totalSupply=0,

value=20538

18 .........................skip..

19 Warning: BMC: Assertion violation happens

here.

20 --> ./Results/Token/Token_mod.sol:28:2:

21 |

22 28 | assert(!(balanceOf(from) >=

value));

23 | ^^^^^^^^^^^^^^^^^^^^^^^^^

CC-SolBMC: Condition Coverage Analysis for Smart Contracts Using Solidity Bounded Model Checker

391

24 Note: Counterexample:

25 =false

26 balances[owner]=9725, decimals=0,

from=32278, owner=32278, to=0,

totalSupply=0, value=0

27 .........................skip..

28 Warning: BMC: Assertion violation happens

here.

29 --> ./Results/Token/Token_mod.sol:29:2:

30 |

31 29 | assert(!(!(balanceOf(from) >=

value)));

32 | ^^^^^^^^^^^^^^^^^^^^^^^^^

33 Note: Counterexample:

34 =false

35 balances[owner]=17887, decimals=0,

from=31597, owner=31597

36 to=0, totalSupply=0, value=17888

37 .........................skip..

38 Warning: BMC: Assertion violation happens

here.

39 --> ./Results/Token/Token_mod.sol:31:2:

40 |

41 31 |

assert(!(allowance[from][msg.sender]

>= value));

42 | ^^^^^^^^^^^^^^^^^^^^^^^^^

43 Note: Counterexample:

44 =false

45 allowance[from][msg.sender]=2331,

balances[owner]=14136, decimals=0,

from=22114, owner=22114, to=0,

totalSupply=0, value=0

46 .........................skip..

47 Warning: BMC: Assertion violation happens

here.

48 --> ./Results/Token/Token_mod.sol:32:2:

49 |

50 32 | assert(!(!(allowance [from]

[msg.sender] >= value)));

51 | ^^^^^^^^^^^^^^^^^^^^^^^^^

52 Note: Counterexample:

53 =false

54 allowance[from][msg.sender]=2747,

balances[owner]=2748, decimals=0,

from=28871, owner=28871, to=0,

totalSupply=0, value=2748

Listing 3: Execution Report with counter examples Listing

Now, the execution report generated is supplied

into the Extractor component along with the original

smart contract to get the condition coverage report as

shown in Listing 4. As we have injected 6 targets,

SolBMC has detected all of them with counterexam-

ples. We have extracted the results and found that

there were 6 targets found dynamically and uniquely.

Here, we provide both the counting of dynamic and

unique targets. It is to be noted that, dynamic means

a target can be reached multiple times through differ-

Table 1: Generated test cases for Listing 2.

Variables TC1 TC2 TC3 TC4 TC5 TC6

allowance[from][msg.sender] - - - - 2331 2747

balances[owner] 38 20537 9725 17887 14136 2748

decimals 0 0 0 0 0 0

from - - 32278 31597 22114 28871

owner 28100 1323 32278 31597 22114 28871

to 0 0 0 0 0 0

totalSupply 0 0 0 0 0 0

value 0 20538 0 17888 0 2748

ent paths or traces. Whereas, unique means a target

at least reached through a path or trace once. This

counting is important to compute the condition cover-

age because statically we know how many targets or

branch edges we have and out of them how many we

have detected. So for this contract, we have a 100%

condition coverage score, which means it is Maximal.

1 assertion inserted : 6

2 assertion violation detected (dynamic) : 6

3 assertion violation detected (unique) : 6

Listing 4: Condition Coverage Report Listing 2.

In our analysis, we have also captured the execu-

tion time of testing the smart contract. The time anal-

ysis for the working analysis is shown in Listing 5.

We can observe that SolBMC took 1.36 sec for this

example. It is to be noted that our experiment has a

1-hour timeout, so to certify any smart contract as Op-

timal or Maximal it is required to ﬁnish the execution

within 1 Hr without any out of resources.

1 ***Time Analysis Report - Start***

2 ***Total runtime in seconds 1.365783207

3 Total runtime: 0:00:00:1.3658

4 ***Time Analysis Report - End***

Listing 5: Time Analysis for Listing 2.

Finally, we extract all the counter-examples or test

inputs as shown in Table 1. The variables of the smart

contract are taken as a working example. TC1 to

TC6 represents all the 6 test cases corresponding to

the 6 targets found. The dash “-" symbol shows that

the value of the variable is missing because the vari-

able was not present in the constraint checked. These

test cases are very much useful for post-processing,

and performing a mutation testing analysis. Also,

there may be many applications that might require test

cases.

5 EXPERIMENTAL RESULTS

In this section, we discuss the setup and benchmarks

tested, and demonstration scenarios for our system.

We used an Intel® Core™ i7-9700 CPU @

3.00GHz Linux box (64-bit Ubuntu 20.04.2 LTS)

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

392

with 8 GB RAM and llvmpipe (LLVM 11.0.0, 256

bits) graphics in Oracle Virtualisation. We have used

PPAs for Ubuntu with the latest stable version of So-

lidity Compiler

. We have used the following com-

mand setting as shown in Listing 6:

solc ASC.sol --model-checker-engine bmc

--model-checker-targets assert

Listing 6: Command Line for SolBMC.

There are a total of 70 smart contracts were col-

lected and tested. 60 smart contracts were taken

from (etherscan, 2021). These contracts are real-time

smart contracts and we found them suitable to work

on. Second, we consider a set of 6 contracts from

(Azure, 2021). Other 4 contracts that we consid-

ered are: Ballot.sol (Ballot.sol, 2021), escrow.sol (es-

crow.sol, 2021), payments.sol (payments.sol, 2021),

and ptest.sol (ptest.sol, 2021).

We divide the results on 70 smart contracts with 1

Hr timeout, into three different groups:

• Group 1: In this group, we have contracts with

condition coverage lesser than 100%, and the

SolBMC ﬁnishes the execution within the 1 Hr

timeout. The rest conditions are uncovered or

dead. It means the condition coverage achieved

is Optimal.

• Group 2: In this group, we have the contracts with

100% condition coverage, and the SolBMC ﬁn-

ishes the execution within the 1 Hr timeout. It

means the condition coverage achieved is Maxi-

mal.

• Group 3: In this group we have the contracts with

0% condition coverage and the SolBMC could not

ﬁnish the execution due to resource/time restric-

tions for quarries. It means the condition coverage

achieved is Incomplete

Tables 2,3, and 4 show the detailed results for 70

smart contracts. #LOCs and #MLOCs present the size

of the contract before and after the annotations for tar-

gets respectively. Here, #LOCs show the Lines of

Code, and #MLOCs show Modiﬁed Lines of Code.

Note that the targets or goal constraints are injected

into contracts, in a way that the semantics of the con-

tract will not be affected. #TB shows the total branch

edges for the conditions in the contract. #TDBC and

#TUBC show the covered branch edges. The #TDBC

shows the branches covered dynamically after execut-

ing the conditions more than once, whereas. #TUBC

shows the unique branches covered. CC% shows the

https://docs.soliditylang.org/en/develop/installing-

solidity.html#linux-packages

Condition Coverage score calculated using Eq. 1.

CC% =

#TUBC

#T B

(1)

Table 2: Result Analysis for Optimal group.

Contracts #L #ML #B #DB #UB CC% T(sec)

AnyswapV5ERC20 357 446 88 216 42 47 18.94

Ballot 79 106 26 26 23 88 3.36

TokenVesting 177 238 60 93 58 96 5.80

MiraNft 390 481 90 167 56 62 262.06

COINNetwork 452 510 72 240 68 94 19.33

CyberFox 199 248 48 129 46 95 6.30

wLitiSale 196 245 50 97 48 96 17.75

WrappedToken 470 569 98 180 56 57 262.41

Address 504 623 118 169 53 44 1287.10

eMuppy 174 213 42 140 38 90 6.91

MJCoinToken 155 184 28 108 26 92 4.50

Galaxium 174 209 34 92 33 97 5.11

RIAS 203 248 44 130 42 95 5.45

kiaquiz 38 51 12 15 11 91 3.26

Table 3: Result Analysis for Maximal group.

Contracts #L #ML #B #DB #UB CC% T(sec)

payments 36 45 8 8 8 100 3.02

Kyuseishu 152 180 30 81 30 100 5.77

MayoOcho 308 333 24 73 24 100 4.68

PipiCoin 125 142 20 96 20 100 4.27

RBC 117 138 20 96 20 100 4.68

GOLIATH 156 179 22 61 22 100 3.91

salvador 56 63 6 6 6 100 3.04

ShibaAstronaut 37 44 6 6 6 100 3.15

StarNFTProxy 169 196 26 106 26 100 9.47

UniswapV3MigratorProxy 16 19 2 2 2 100 3.09

VamprireDoge 37 44 6 6 6 100 2.81

BasicProvenance 42 53 10 10 10 100 2.86

ClockBoxContract 192 217 24 74 24 100 4.16

DigitalLocker 128 149 20 20 20 100 2.91

ERC20 308 333 24 73 24 100 4.51

AssetTransfer 191 276 84 84 84 100 4.07

RefrigeratedTransportation 117 150 32 32 32 100 3.45

escrow 43 52 8 16 8 100 3.00

ptest 17 28 10 10 10 100 2.87

SimpleMarketplace 61 74 12 12 12 100 3.04

RoomThermostat 42 55 12 12 12 100 3.09

Token 37 44 6 6 6 100 3.47

DogeMojo 37 44 6 6 6 100 3.11

Benu 156 185 28 130 28 100 6.29

FrontRunner 265 270 4 14 4 100 3.61

BurnableERC20 167 185 24 111 24 100 6.71

Figure 2: Condition Coverage scores for Groups 1 and 2

contracts.

We compute the total execution time (seconds) to

analyse the contract. Table 2 shows the result analysis

for the Optimal group of 14 smart contracts. Here the

optimal means the executor has ﬁnished the execution

CC-SolBMC: Condition Coverage Analysis for Smart Contracts Using Solidity Bounded Model Checker

393

Figure 3: Execution time in sec for Groups 1 and 2 con-

tracts.

Table 4: Result Analysis for Incomplete group.

Contracts #L #ML #B #DB #UB CC% T(sec)

eNew 329 395 70 0 0 0 189.41

DogeRocket 475 566 90 0 0 0 118.23

ChinaCoin 330 413 82 0 0 0 127.87

BERNIE 356 443 86 0 0 0 181.43

shibabread 330 413 82 0 0 0 127.37

AIRBets 301 362 60 0 0 0 158.14

Animalia 616 727 110 0 0 0 318.80

TESTDONTBUY 349 452 102 0 0 0 118.54

SimpleECR20 154 171 22 0 0 0 2.94

EStack 330 413 82 0 0 0 125.74

goldinu 335 426 90 0 0 0 230.18

KizunaInu 475 566 90 0 0 0 114.05

LILY 321 385 68 0 0 0 182.94

Lunar 324 395 70 0 0 0 167.65

PONY 329 395 70 0 0 0 168.77

PORCUPINE 329 395 70 0 0 0 169.85

PROGEV2 356 437 80 0 0 0 142.74

Ryujin 349 452 102 0 0 0 100.71

SATURNITE 330 413 82 0 0 0 112.18

ShibaJail 469 560 90 0 0 0 108.29

ShibaKiyo 731 844 112 0 0 0 161.05

ShibaSamurai 539 616 76 0 0 0 219.00

SOTH 330 413 82 0 0 0 119.82

Thicc 271 326 60 0 0 0 2.62

TOAD 321 385 68 0 0 0 175.07

WickedCraniums 626 745 132 0 0 0 357.70

HOTDOGE 352 435 82 0 0 0 237.88

HotinuFinance 730 843 112 0 0 0 144.59

KOALA 329 395 70 0 0 0 168.48

eMastiff 321 414 92 0 0 0 105.30

Table 5: Aggregate and Average Result Analysis for 70 con-

tracts.

Groups #LOCs #MLOCs #TB #TDBC #TUBC Avg_CC% Time (sec)

Group 1 3568 4371 810 1802 600 81.71 1908.28

Group 2 3012 3498 474 1151 474 100 105.03

Group 3 11737 14195 2484 0 0 0 4657.33

#Total 18317 22064 3768 2953 1074 53.4 6670.65

within the time out given. The condition coverage is

lesser than 100%, which means the uncovered code

cannot be reached or executed for the contract, hence

the dead code. In aggregate for 14 contracts, a total

of 810 branches were checked and 600 branches were

uniquely covered in 1908.28 sec. On average Condi-

tion Coverage for Group 1 is 81.74% in an average

time of 136.30 sec.

Table 3 shows the result analysis for the Maximal

group of 26 smart contracts. Here the maximal means

the executor has ﬁnished the execution within the time

out given and achieved 100% condition coverage. It

means no part of the code is dead. This is the expec-

tation of achieving 100% for any contributor writing

a smart contract. In aggregate for 26 contracts, a total

of 474 branches were checked and 474 branches were

uniquely covered in 105.03 sec. On average Condi-

tion Coverage for Group 2 is 100% in an average time

of 4.03 sec.

Collectively, in Groups 1 and 2 we have 40 con-

tracts for which we were able to compute condition

coverage in reasonable time. Except for 5 contracts

out of 40 contracts the condition coverage is below

90%. That is, 87.5% of contracts from Groups 1 and

2 have a good condition coverage score and the level

of quality and reliability of the contract written is en-

sured. Fig. 2 shows the Condition Coverage com-

puted for the contracts from Groups 1 and 2. Fig. 3

shows the chart in logarithm format for Lines of Code

vs. Execution time in sec (increasing order). In most

cases the bigger contracts take more execution time as

shown in Fig. 3.

Table 4 shows the result analysis for the Incom-

plete group of 30 smart contracts. Here the Incom-

plete means the executor has not ﬁnished the exe-

cution due to some resource restrictions. The aver-

age LOCs for 30 contracts is 400 with 82 average

branches. So, it is showing the complexness of the

contracts for which the queries are too long and com-

plex so the solidity bounded model checker can not

process, and the process has to be killed. The so-

lidity compiler checks the resources of the machine

during the process, and if some resources are out then

the query cannot be processed. Also, BMC can only

report anything once it is ﬁnished. But for Group

3, SolBMC has run out of resources so no cover-

age information has been generated and the values

of #TDBC, #TUBC, and CC% are 0 (highlighted in

red color). Note that, for this group, none of the con-

tracts reached 3600 sec. In case any contract would

have reached timeout then we would have included

that contract in Group 3.

Table 5 shows the aggregate and average results

for all the 70 contracts in Groups 1,2, and 3. So, in ag-

gregate we processed 18.31 KLOCs of original smart

contracts and executed 22.06 KLOCs. There was a

total number of 3.76K Branch edges out of which

1.07K Branch edges were covered uniquely. Also, the

same atomic conditions can be executed several times

in the contract due to several calls, hence dynamically

2.95K Branch edges were covered. We have achieved

53.4% of the average condition coverage score for 70

contracts. These 70 contracts took 1.85 Hrs to ﬁnish

the process. Finally, we claim that for 40 contracts

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

394

(57.14%) out of 70 contracts we have good condition

coverage scores.

6 CONCLUSION

The main objective of this work is to certify the smart

contract wrt. the condition coverage analysis. It is

very important to test smart contracts by looking at

the critical business in the blockchain. If an incor-

rect contract or bug in the contract exists, then there

is a high chance of losing the expensive assets. In this

paper, we proposed a novel approach to compute con-

dition coverage for a smart contract using a solidity

compiler with a bounded model checker. We tested

70 contracts and showed that for 40 contracts i.e.,

57.14% have optimal or maximal condition coverage

scores. However, the rest 30 contracts were incom-

plete due to resource issues. We will explore other

techniques such as Fuzzing and Symbolic execution

for a more detailed analysis.

ACKNOWLEDGEMENT

This work is sponsored by IBITF, Indian Institute of

Technology (IIT) Bhilai, under the grant of PRAYAS

scheme, DST, Government of India.

REFERENCES

Akca, S., Rajan, A., and Peng, C. (2019). Solanalyser: A

framework for analysing and testing smart contracts.

In 2019 26th Asia-Paciﬁc Software Engineering Con-

ference (APSEC), pages 482–489. IEEE.

Andesta, E., Faghih, F., and Fooladgar, M. (2020). Testing

smart contracts gets smarter. In 2020 10th Interna-

tional Conference on Computer and Knowledge Engi-

neering (ICCKE), pages 405–412. IEEE.

Azure (2021). Azure. https://github.com/Azure-Samples/

blockchain/tree/master/blockchain-workbench/

application-and-smart-contract-samples.

Ballot.sol (2021). Ballot.sol. https://docs.soliditylang.org/

en/v0.4.24/solidity-by-example.html.

Benitez, S., Cogan, J., and Russo, A. (2020). Short paper:

Blockcheck the typechain. In Proceedings of the 15th

Workshop on Programming Languages and Analysis

for Security, pages 35–39.

Buterin, V. et al. (2014). A next-generation smart contract

and decentralized application platform. white paper,

3(37).

Clarke, E., Kroening, D., and Lerda, F. (2004). A tool for

checking ANSI-C programs. In TACAS, pages 168–

176. Springer.

Clarke, E., Kroening, D., and Yorav, K. (2003). Behavioral

consistency of C and Verilog programs using bounded

model checking. In 40th DAC, pages 368–371. ACM

Press.

Dannen, C. (2017). Introducing Ethereum and solidity, vol-

ume 318. Springer.

escrow.sol (2021). escrow.sol. https://www.geeksforgeeks.

org/what-is-escrow-smart-contract/.

etherscan (2021). etherscan. https://etherscan.io/.

Jiang, B., Liu, Y., and Chan, W. (2018). Contractfuzzer:

Fuzzing smart contracts for vulnerability detection.

In 2018 33rd IEEE/ACM International Conference on

Automated Software Engineering (ASE), pages 259–

269. IEEE.

Liu, Y., Li, Y., Lin, S.-W., and Yan, Q. (2020). Modcon: a

model-based testing platform for smart contracts. In

Proceedings of the 28th ACM Joint Meeting on Eu-

ropean Software Engineering Conference and Sym-

posium on the Foundations of Software Engineering,

pages 1601–1605.

Mossberg, M., Manzano, F., Hennenfent, E., Groce, A.,

Grieco, G., Feist, J., Brunson, T., and Dinaburg, A.

(2019). Manticore: A user-friendly symbolic execu-

tion framework for binaries and smart contracts. In

2019 34th IEEE/ACM International Conference on

Automated Software Engineering (ASE), pages 1186–

1189. IEEE.

Nguyen, T. D., Pham, L. H., Sun, J., Lin, Y., and Minh, Q. T.

(2020). sfuzz: An efﬁcient adaptive fuzzer for solid-

ity smart contracts. In Proceedings of the ACM/IEEE

42nd International Conference on Software Engineer-

ing, pages 778–788.

payments.sol (2021). payments.sol. https://github.

com/joaquin-alfaro/ethereum-payment-vuejs/blob/

develop/dapp/contracts/Payments.sol.

Praitheeshan, P., Pan, L., Yu, J., Liu, J., and Doss, R.

(2019). Security analysis methods on ethereum smart

contract vulnerabilities: a survey. arXiv preprint

arXiv:1908.08605.

ptest.sol (2021). ptest.sol. https://www.npmjs.com/

package/solfuzz.

Sánchez-Gómez, N., Morales-Trujillo, L., and Valderrama,

J. T. (2019). Towards an approach for applying early

testing to smart contracts. In WEBIST, pages 445–453.

Wen, Z. A. and Miller, A. (2016). Scanning live ethereum

contracts for the “unchecked-send” bug. Hacking Dis-

tributed.

Wood, G. et al. (2014). Ethereum: A secure decentralised

generalised transaction ledger. Ethereum project yel-

low paper, 151(2014):1–32.

CC-SolBMC: Condition Coverage Analysis for Smart Contracts Using Solidity Bounded Model Checker

395
