Using Trace Clustering to Group Learning Scenarios: An Adaptation of

FSS-Encoding to Moodle Logs Use Case

Noura Joudieh

1 a

, Marwa Trabelsi

1 b

, Ronan Champagnat

1 c

, Mourad Rabah

1 d

and Nikleia Eteokleous

2 e

L3i Laboratory, La Rochelle University, La Rochelle, France

Frederick University, Cyprus

Keywords:

Learning Process, Trace Clustering, Process Mining, Learning Scenarios, Learning Paths, Quality of

Education.

Abstract:

Learners adopt various learning patterns and behaviors while learning, rendering their experience a valuable

asset for recommending learning paths for other learners. Process Mining is useful in this case to discover

models that reveal learners’ taken learning paths in an educational platform. Nonetheless, due to the hetero-

geneity of behavior and the volume of data, trace clustering is crucial to reveal various groups of learners and

discover relevant process models rather than ‘spaghetti’ ones. In this paper, we address the limits of and im-

prove on a feature-based trace clustering approach known as FSS-encoding, ideal for unstructured processes to

extract diverse learning patterns adopted by students, to be later employed in a learning path recommendation.

Our enhancements include a reﬁned pattern selection, preserving the uniqueness of less frequent events and

increasing the overall effectiveness of the trace clustering process. Our method was applied to Moodle logs

acquired from 2018 to 2022, comprising 471 students in the Computer Science and Engineering Department

of Frederick University in Cyprus. The results show three clusters with a 25% improvement in silhouette coef-

ﬁcient. Their consequent discovered process models depict the various learning scenarios adopted, including

activities like studying, solving exercises, undergoing assessments, applying, and others.

1 INTRODUCTION

Learning is no longer conﬁned to classrooms or con-

ventional teacher-student scenarios, thanks to ad-

vancements in technology that improved the educa-

tional sector. On the other hand, e-learning is becom-

ing more prevalent, as learning material and resources

are accessible to everyone, at any time, and anywhere.

However, this accessibility comes at a cost: learners

may become overwhelmed when attempting to meet a

learning goal, which could ultimately result in a drop

in motivation and learning efﬁciency. In this direc-

tion, Recommender Systems (RS) (Aggarwal, 2016)

in e-learning aim to personalize the learning experi-

ence by intelligently ﬁltering online content based on

individual learner preferences, actions, and needs, de-

https://orcid.org/0000-0003-3142-2962

https://orcid.org/0009-0001-2040-063X

https://orcid.org/0000-0001-5256-5706

https://orcid.org/0000-0001-8136-5949

https://orcid.org/0000-0003-4364-9558

viating from one-size-ﬁts-all models. On the other

hand, users in information systems leave their traces

recorded by logging system in the form of event logs.

Process Mining (PM), a discipline that combines data

mining, machine learning and process modeling uses

these event logs to discover process models that reveal

the behavior followed by users in a system (Van der

Aalst, 2016). In educational platforms and systems,

the former has paved the way for a rich line of re-

search to discover the behaviors of students while per-

forming different learning activities like attending a

course, or taking a quiz (Cenka and Anggun, 2022).

In a previous work (Joudieh et al., 2023), we have

proposed a framework to recommend a personalized

adaptive learning path for a learner seeking a learn-

ing objective, while employing past learning experi-

ence extracted via Process Mining. The framework

constitutes 3 main modules: Recommender Module,

Data Module and Process Mining Module. The PM

module is the focal point of this article. The for-

mer is in charge of using event logs from the Moodle

learning management system to discover a model that

Joudieh, N., Trabelsi, M., Champagnat, R., Rabah, M. and Eteokleous, N.

Using Trace Clustering to Group Learning Scenarios: An Adaptation of FSS-Encoding to Moodle Logs Use Case.

DOI: 10.5220/0012636400003693

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 16th International Conference on Computer Supported Education (CSEDU 2024) - Volume 2, pages 247-254

ISBN: 978-989-758-697-2; ISSN: 2184-5026

247

shows the learning paths taken by students while tak-

ing courses. It enables the generation of insights into

students’ learning journeys, forming the foundation

for personalized and effective learning path recom-

mendations. However, a huge amount of logs might

generate incomprehensible “spaghetti” models, thus

the need of trace clustering (Song et al., 2008) as a

primary step to capture the different learning patterns

and discover more understandable models.

Driven by this objective, we adopt a recent trace

clustering approach (Trabelsi et al., 2021) based on

encoding the traces in terms of the frequent subse-

quent patterns within, called FSS Encoding. Origi-

nally applied to digital library users, this method was

able to discover three different proﬁles of users. In

this paper, we address the limitations of this method

and propose an improved version that enhances the

clustering results and discovered models. The im-

proved approach is applied on collected Moodle Logs

of 471 students taking courses in the Department of

Computer Science and Engineering in Frederick Uni-

versity in Cyprus for the period of 2018-2022.

The paper provides an overview of trace cluster-

ing approaches in Section 2, followed by an in-depth

discussion of FSS encoding, its limitations, and pro-

posed improvements in Section 3. The enhanced FSS

approach is demonstrated using Moodle logs, with

data collection and treatment detailed in Section 4 and

results presented in Section 5. The paper concludes in

Section 6 with discussions on future perspectives.

2 RELATED WORKS

Process Mining is a ﬁeld of science bridging the gap

between data-oriented analysis and process-oriented

analysis, which aims to extract knowledge from event

logs. The application of process mining techniques

extends across various domains, including hospitals,

banks and municipalities (Van der Aalst, 2016; Lu

et al., 2019; Trabelsi et al., 2021).

Process mining techniques utilize event logs as in-

put to generate, enhance, or validate process models.

An event log comprises a set of execution traces, each

representing a speciﬁc process instance. For example,

the workﬂow of a student on an e-learning platform.

Starting with the action of viewing a course (Course

viewed), the student may navigate to explore speciﬁc

elements within the course (Course module viewed).

These elements could include lectures, videos, assign-

ments, or quizzes. Upon selecting a quiz element, the

student proceeds to submit his/her answers (Quiz sub-

mitted). Each of these activities constitutes a unique

trace within the main process.

Table 1: Sample of students event logs.

CaseId Timestamp Activity label

1 2018-01-12T10:34:25 Course viewed

2 2018-01-12T10:36:25 Course viewed

1 2018-01-12T10:34:26 Course module viewed

1 2016-01-12T10:34:28 Submission viewed

3 2018-01-12T10:36:26 Course viewed

3 2018-01-12T10:36:27 Submission form viewed

For instance, in the Moodle platform, every stu-

dent can be considered as a case following a learning

process. The series of events associated with a spe-

ciﬁc case is referred to as a trace. Each row in Table 1

represents an executed event, including details such

as the event identiﬁer (CaseId), the activity label, the

timestamp (day, hour, minute, and second), and ad-

ditional attributes relevant to the event. Formally, an

event log L = {t

, ..., t

} is a set of k traces where

each trace t

(1 ≤ i ≤ k) is a set of n

consecutive events

=< e

, e

, ...e

> made by the same CaseId.

Many process discovery methods have been pro-

posed in the literature in order to automatically gen-

erate process models. Process discovery algorithms

aim to discover process models based on event logs.

The discovered process models are intended to rep-

resent the whole event logs. Several models can be

used for this purpose such as Petri nets or Fuzzy mod-

els (Van der Aalst, 2016).

Nevertheless, numerous process mining studies

have demonstrated that creating a single process

model for an entire log is not ideal, particularly for

very large datasets containing unstructured processes.

An unstructured process is one that is driven by a user

rather than a software. It results in many possible

paths, but only few are relevant. Process mining tech-

niques often result in complex and/or overﬁtted mod-

els, such as the widely recognized spaghetti model

or ﬂower model (Van der Aalst, 2016). To overcome

these issues, existing works proposed trace clustering

methods prior to modeling (Diamantini et al., 2016).

The literature offers numerous approaches to trace

clustering, which can be categorized into three types

of clustering techniques based on how the traces are

presented before clustering (Song et al., 2008; Zand-

karimi et al., 2020). Additionally, there is a hybrid-

based clustering category that integrates various tech-

niques from the aforementioned methods (De Kon-

inck and De Weerdt, 2019).

The ﬁrst category, referred to as trace-based clus-

tering, groups traces based on syntax similarity, as

explained in (Bose and Van der Aalst, 2009) and

(Chatain et al., 2017). This approach draws in-

spiration to the Levenshtein distance metric, which

measures the dissimilarity between two strings. In

this context, a trace can be transformed into another

CSEDU 2024 - 16th International Conference on Computer Supported Education

248

through edit operations like substitution, addition, or

removal of events. The edit distance between two

traces is then calculated as the minimum number of

these edit operations required to convert one trace into

the other. A lower edit distance indicates a higher

level of similarity between the traces. Following this,

distance-based clustering algorithms are applied to

group the traces into distinct clusters. In the ﬁeld

of education, both (Laksitowening et al., 2023) and

(Zhang et al., 2022) focus on students’ logs to capture

various characteristics and learning patterns. They

both employ hierarchical clustering as a clustering al-

gorithm to group students’ traces.

The second category is the model-based cluster-

ing. It assumes that accurate models are discovered

from homogeneous sub-logs (Cadez et al., 2003; Fer-

reira et al., 2007). The process model is considered

as input for the clustering in order to structure traces.

These traces are used back to mine process models.

The obtained clusters strongly depend on the quality

metrics used for evaluating the accuracy of discovered

process models (De Weerdt et al., 2013).

The third category, called feature-based cluster-

ing, involves the conversion of each trace into a vector

of features based on predeﬁned characteristics. The

similarity between two traces is then determined by

the similarity between their corresponding vectors.

Existing methods within this category often rely on

metrics such as the frequency of events or the fre-

quency of direct succession relations between events

to transform traces into vectors (Song et al., 2008).

For instance, (Song et al., 2008) analyzed traces from

healthcare information systems, converting them into

features such as the count of individual event occur-

rences or the count of pairs of events in immediate

succession. (Bose and van der Aalst, 2009) employed

a similar technique on longer sub-parts of traces, eval-

uating the occurrence of more complex motifs like re-

peats, deﬁned as n-grams observed at different points

in the trace. Subsequently, distance-based clustering

algorithms are applied to group the traces into distinct

clusters (Zandkarimi et al., 2020).

Our work in this article aligns with the feature-

based approach, as we enhance a feature-based

method called FSS encoding (Trabelsi et al., 2021).

The foundational FSS encoding method originated

in the context of digital libraries. Its primary con-

cept involves extracting features from traces through

the identiﬁcation of frequent sub-sequences and their

corresponding encoding. The encoding of frequent

sub-sequences considers multiple parameters to ef-

fectively distinguish traces of digital libraries users.

A clustering algorithm was then applied on the con-

verted traces to ﬁnally assign each trace to the appro-

priate cluster. In the case of digital libraries, FSS en-

coding results showed the effectiveness of the method

to cluster users and to model their journeys. These re-

sults were validated on a real-world data provided by

the national library of France

3 [F]REQUENT

[S]UB-[S]EQUENCES

ENCODING OF LEARNERS

INTERACTIONS

As mentioned in Section 1, we extended the FSS

encoding method (henceforth baseline) proposed by

(Trabelsi et al., 2021). The improvement preserves

more information about the traces and the uniqueness

of each trace, and allows better patterns to be discov-

ered from the traces.

3.1 Baseline

In this section, we brieﬂy describe the baseline, the

FSS encoding proposed in (Trabelsi et al., 2021). The

fundamental strategy of this method operates under

the assumption that a trace containing a frequent sub-

sequence (FSS) is the most signiﬁcant trace (Lu et al.,

2019). This strategy involves grouping traces based

on frequent sub-sequences. An FSS, denoted as

< e

, ..., e

>, comprises a ﬁnite set of events of

length n (n > 1), where the events are executed in or-

der at least two times.

Traces are converted using a speciﬁc FSS encod-

ing. In this encoding, each identiﬁed FSS in a trace is

replaced by its corresponding encoding. Events that

don’t belong to any FSS are deemed irrelevant, and

only their positions contribute to the clustering. Thus,

such events in the traces are replaced by 1.

The baseline itself aims to effectively distinguish

traces within different clusters by considering factors

such as the [1-length] and [2-frequency] of the FSS,

the [3-frequency of events] within the FSS, and the

[4-frequency of direct succession relations between

events] in the FSS. This encoding strategy enhances

the vector representation of traces, emphasizing the

signiﬁcance of longer FSSs, higher frequencies, and

the occurrence of speciﬁc events and relations within

the sequences.

All the extracted FSS are encoded in each trace as

follows:

Biblioth

eque Nationale de France: https://www.bnf.fr/

Using Trace Clustering to Group Learning Scenarios: An Adaptation of FSS-Encoding to Moodle Logs Use Case

249

Encoding(FSS) =

FSS

∑

n−1

i=1

i+1

i,i+1

(1)

Where, f

FSS

is the frequency of the extracted FSS,

n is its length (number of events), f

is the frequency

of the event e

in the event logs and f

i,i+1

is the fre-

quency of the direct relation between all consecutive

events of the FSS in the event logs. The resulting

encoding value falls between 0 and 1, where a value

closer to 0 signiﬁes the signiﬁcance of the FSS within

the entire event logs.

This encoding method allows the distinction be-

tween traces that share the same FSS but not in the

same position. Furthermore, by replacing all events

not part of an FSS with 1, the information about the

position of the FSS was retained, the gaps between

different FSS, as well as the size of the trace. Follow-

ing the FSS encoding, all the traces in the event logs

are converted into sparse vectors. These vectors are

then clustered based on the similarity between them.

3.2 Our Approach

While the baseline approach replaces all events not

part of a Frequent Sub-sequence with 1, it leads to

a loss of information regarding the uniqueness of in-

dividual activities that do not participate in a pat-

tern. These activities might carry signiﬁcance even

though they occur less frequently. The baseline’s

simpliﬁcation may overlook the diversity and im-

portance of such singular activities, potentially im-

pacting the comprehensiveness of the analysis. For

instance, two traces, t

= < e

, e

> and

= < e

, e

>, are converted into vectors

FSS

, 1, 1] and [1, E

FSS

], respectively, where E

FSS

represents the encoding of < e

, e

>. Addition-

ally, the events e

, e

and e

are not considered in the

clustering.

On the other hand, our proposed FSS encoding

method takes into account the frequency and rela-

tionships of both the FSS and individual events, of-

fering a more nuanced representation that preserves

the distinctive characteristics of each activity. For ex-

ample in Moodle, a learner is more likely to view a

course several times before taking a quiz once. Thus,

it is important to preserve the position and identity

of these less frequent activities as they might hold

signiﬁcant information to understand the undertaken

learning process. Driven by this, using our approach

traces t

and t

in the previous example, are con-

verted respectively into vectors [E

FSS

, f (e

), f (e

)]

and [ f (e

), E

FSS

]. f (a) represents the frequency of

occurrence of activity a in all the traces, thus preserv-

ing its identity in means of its frequency that eventu-

ally reﬂects its signiﬁcance.

Algorithm 1 depicts our proposed approach. As

outlined, the initial step involves the transformation

of the original event logs R (refer to Table 1) into a set

of traces L . This set organizes the sequence of events

chronologically based on the unique identiﬁer CaseId.

For example, based on the Table 1, the corresponding

trace of CaseId 1 is < Course viewed, Course module

viewed, Submission viewed >.

Algorithm 1: Improved FSS Encoding algorithm.

Data: Original log ﬁle R, Minimum pattern

support percentage minSup, Minimum

pattern Length minLen, Number of Clusters

n clusters

Result: Log Files F corresponding to resulting

clusters

begin

Convert R to a set of traces L;

From L, extract frequent sub-sequences FSS

with length >= minLen and minimum

support >= minSup;

From FSS, remove x ∈ FSS if x does not exist

as is in L;

For x ∈ FSS, compute Encoding(x) ;

Sort FSS in descending order of pattern

lengths ;

For each trace in L, replace any existing FSS

by their encoding;

Remove traces from L where no FSS is found;

For remaining traces in L, replace remaining

activities with their frequency ;

Scale the values in the traces using MinMax

Scaler, to have a range of [0, 1] ;

Add padding of −1 for the traces to have same

lengths ;

Cluster the traces in L into n clusters;

Generate Log Files F for resulting clusters;

Return F;

end

Subsequently, we employ the PreﬁxSpan algo-

rithm (Pel et al., 2001) to extract sequential patterns

FSSs from the modiﬁed event logs L. This algo-

rithm efﬁciently identiﬁes recurring patterns within

the traces, aiding in the discovery of signiﬁcant se-

quences of activities over time.

In the baseline, the frequent subsequences selec-

tion criteria using PreﬁxSpan is the top-k patterns,

that extracts the top k frequent patterns extracted by

PreﬁxSpan leading to a loss of control over the rele-

vance of patterns based on their support. This could

result in situations where all top-k patterns have sup-

port percentages above 90%, or conversely, some pat-

terns have support percentages below 50%. Also, us-

ing top-k patterns can be computationally expensive

because it requires generating and checking many po-

tential patterns. In our approach, we reﬁne the pat-

tern selection criteria by incorporating two thresholds,

CSEDU 2024 - 16th International Conference on Computer Supported Education

250

(i) a minimum support percentage (minSup) and (ii)

a pattern length (minLen). In this reﬁnement, the

dataset is scanned once to determine the support of

candidate patterns and then ﬁlters out those below the

speciﬁed threshold. The support of a pattern X is the

ratio of traces in which X appears to the total number

of traces, and the length of a pattern is the number of

activities it includes. Also, as PreﬁxSpan can extract

patterns that do not exist as they are in the traces, the

extracted patterns are ﬁltered from such cases.

Following, the encoding of each FSS is calculated

using equation 1 and the FSSs are sorted in descend-

ing order of their length (the longer the pattern, the

more important it is). This deﬁnes the priority of

replacement in the next step. For each trace, where

found, the FSS is replaced by its encoding. If 2 FSSs

are found in the same trace, the longer FSS is ﬁrst re-

placed and then the rest of the trace is searched for

other FSSs. After the replacement, traces with no

found FSSs are removed as they count as unrepresen-

tative ones. For remaining traces, individual activities

that did not belong to a pattern are replaced by their

frequency as previously explained. Finally, the en-

coded values are scaled to a range of [0,1] and cluster-

ing is performed on the resulting traces converted to

numerical vectors. Finally, the log ﬁles correspond-

ing to each cluster are generated and returned as an

output. These ﬁles are later used to discover a process

model describing the general behavior of learners in

each cluster.

In a nutshell, our method enhances trace encoding

in two key ways. First, it reﬁnes the selection crite-

ria for patterns by replacing the top-k approach with a

combination of minimum support percentage and pat-

tern length. Second, in the conversion of traces, in-

dividual activities within traces possessing FSSs are

substituted with their respective frequencies instead

of a uniform value of 1. This alteration preserves the

identity and positional signiﬁcance of less frequent

events. These enhancements have a direct impact on

the representation of traces, consequently elevating

the quality of trace clustering. As a result, this im-

provement facilitates a more detailed understanding

and analysis of learning scenarios within each cluster.

4 DATA TREATMENT

As the context of this work lies within the previously

proposed framework, as mentioned in Section 1, the

data we are dealing with is Moodle Logs. This section

is dedicated to elaborate on the data collection and

treatment steps of the former.

4.1 Data Collection and Preprocessing

Moodle, a well-known learning management system

that is extensively used in universities and educational

institutions, contains a logging system that captures

any user’s activity in the system at any point in time.

In the current study, Moodle event logs of 471 stu-

dents enrolled in courses at Frederick University’s

Department of Computer Science and Engineering in

Cyprus from 2018 to 2022 were collected.

The collected event logs were cleaned to keep only

actions made by students on Moodle while studying,

such as taking courses, tests, and assignments, as the

initial logs included the actions taken by all users in

the system (students, instructors, assisting instructors,

manager, etc.). Additionally, a unique identiﬁer for

each student was created to be used in the trace clus-

tering later on.

The structure of a single log ﬁle is illustrated by Ta-

ble 2. The “Regnum” is the registration number, used

as a unique identiﬁer to track the path of a student

throughout different courses and different years, i.e.

it is used as “CaseId”. The “Timestamp” records the

exact time of each event taken by the students, used

to order the events. While the “Event Name” is used

as the activity and the “Event Context” gives infor-

mation about the concerned learning resource (ﬁle,

assignment, folder, etc.) affected by the event. Fi-

nally, the “Description” explains the event in a more

detailed manner.

Table 2: The structure of a single event log.

Regnum Timestamp Event Context Event Name Description

The initial number of event names was 65, includ-

ing events related to course actions, quiz taking, as-

signments submissions, chats and discussions, pro-

ﬁle viewing, and others. Only 14 events are kept,

as shown in Table 3. These events were chosen as

they particularly show actions like completion of an

assignment or a learning resource, assessment, taking

feedback, studying, and exploring. The log is ﬁltered

given the chosen events to ﬁnally end with 471 stu-

dents with a total of 3942 traces for the period of 2018

until 2022.

Table 3: The chosen event names from Moodle logs.

Event Name

“A submission has been submitted” “Quiz attempt submitted”

“Course activity completion updated” “Course module viewed”

“Zip archive of folder downloaded” “Content page viewed”

“Clicked join meeting button” “Course summary viewed”

“Course module instance list viewed” “Sessions viewed”

“Lesson started” “Lesson resumed”

“Feedback viewed” “Course viewed”

Using Trace Clustering to Group Learning Scenarios: An Adaptation of FSS-Encoding to Moodle Logs Use Case

251

Table 4: The generated semantic activity.

Semantic Activity

Study P Study A Revise Expand

Exercise P Exercise A View Interact

Assess P Assess A Feedback Apply

Table 5: The structure of the trace ﬁle.

CaseId Trace

1 course1 <View, Exercise P, Assess A >

1 course2 <View, View, Study P, Study A >

2 course1 <Interact >

4.2 Enrichment /Transformation

As the collected logs express the interaction between

students and Moodle of different courses, a transfor-

mation step followed to create a new activity that

gives more information on the pedagogical action

done by the student. We refer to this activity as

‘Semantic Activity’. It is rule-based created using

the ‘Event Context’, ‘Event Name’ and ‘Description’

from the original logs. The details of this transfor-

mation step are outside the scope of this paper. This

activity can have one of the 12 values presented in

Table 4. We differentiate between two types of ac-

tions: passive and active (denoted by P and A re-

spectively). When a student downloads a lecture ma-

terial to study it, it is considered a ’passive’ action as

there is no guarantee of completion. When a student

submits an assignment, we presume they completed

exercises, referred to as ’active’ actions.

4.3 Traces Preparation

This part explains the initial step of Algorithm 1.

To perform clustering, the traces should be extracted

from the event logs. As each event log corresponds to

activities done in one course, we deﬁne a trace as an

ordered sequence of events taken by a student in one

course. Thus, the trace ﬁle used to perform clustering

looks as illustrated in Table 5, where the CaseId is the

unique value of a student behaving in one course and

the trace t

(1 ≤ i ≤ k) is an ordered sequence of n

‘Semantic Activity’ events t

=< se

, se

, ..., se

made by the same CaseId.

5 IMPLEMENTATION AND

RESULTS

In what follows, we illustrate the improvement im-

plied by our approach at the level of the extracted pat-

Table 6: Comparison among extracted patterns.

Baseline Our Approach

Parameters K = 100 (MinSup = 80%, MinLen = 2)

# of Extracted Patterns 100 1412

# of Patterns Existing in Traces 32 248

Among Patterns that exist as they are in the Traces

[Min - Max] Pattern Length [1 - 6] [2 - 9]

[Min - Max] Pattern Support % [86% - 100%] [80% - 95%]

On Trace Level

[Min - Max] Original Trace Length [2 - 5599] [2 - 5599]

[Min - Max] Encoded Trace Length [1 - 2484] [1 - 1618]

# of Traces with no FSS 49 45

terns and their encoding, the level of clusters and the

discovered models.

5.1 Patterns Extraction and Encoding

Table 6 compares the baseline and our approach in

pattern extraction and trace encoding. Our reﬁned

selection criteria yield better control over minimum

support and pattern length, resulting in more and

longer patterns with high support. The encoded traces

in our approach are shorter, emphasizing longer and

more signiﬁcant patterns, outperforming the baseline

in both extraction and encoding levels, as reﬂected in

subsequent trace clustering results.

5.2 Trace Clustering

In the ﬁnal section of Algorithm 1, FSS-encoded

traces are clustered using Hierarchical Agglomera-

tive Clustering (HAC) with ward linkage, known for

merging similar clusters in a bottom-up approach.

Our approach is demonstrated as efﬁcient through a

comparison with baseline and ‘Activity Proﬁle’ (Song

et al., 2008), where the latter transforms traces into

binary vectors (0 and 1) using one-hot encoding. The

vector length equals the number of unique activities,

providing a binary representation of activity presence

in each trace. As for the clustering, the optimal num-

ber of clusters, determined through dendrogram anal-

ysis, is found to be 3 for all approaches as shown in

Figure 1. Evaluation metrics, including Silhouette co-

efﬁcient (-1 to 1, higher is better) and Davies Bouldin

index (lower is better), reveal the quality of resulting

clusters, as presented in Table 7.

Despite the initial impression that the Silhouette

is better without FSS, detailed analysis in Table 7 re-

veals potential misinterpretations of numeric values.

The Activity Proﬁle yields clusters with almost all

elements in one, rendering its results meaningless.

In contrast, the baseline divides traces into different

clusters, but they lack clear separation, as reﬂected in

their Silhouette, while our approach combines well-

divided traces with acceptable Silhouettes for each

cluster.

CSEDU 2024 - 16th International Conference on Computer Supported Education

252

(a) On activity proﬁle encoded traces. (b) On baseline encoded traces. (c) On improved FSS encoded traces.

Figure 1: The dendrogram of HAC using ward linkage.

Figure 2: Fuzzy models of the resulting clusters.

Table 7: Cluster and Silhouette Analysis with 3 Clusters.

Activity Proﬁle Baseline Our Approach

Final # of Traces 3942 3893 3897

Silhouette Coefﬁcient 0.546 0.117 0.360

Davies Bouldin Index 0.720 2.43 1.15

Detailed Silhouette Analysis

Cluster 0 # of Traces 710 1000 1496

Silhouette 0.156 -0.065 0.260

Cluster 1

# of Traces 3 1482 1961

Silhouette 0.520 0.038 0.470

Cluster 2

# of Traces 3229 1411 440

Silhouette 0.632 0.408 0.250

5.3 Process Models

The resulting clusters are used with the Fuzzy Miner

algorithm in ProM tool to discover process models,

chosen for its capacity to generate simpliﬁed models

with a focus on signiﬁcant nodes and well-correlated

edges (Van der Aalst, 2016). With Fuzzy Miner, less

signiﬁcant but highly correlated nodes are aggregated,

i.e. hidden in clusters within the simpliﬁed model.

Figure 2 displays the models of clusters 0, 1, and

2, simpliﬁed using node signiﬁcance, leading to the

aggregation of some nodes into clusters. Analyzing

the learning scenarios through model readings, Clus-

ter 1, representing the majority of learners, primarily

engages in routine activities such as viewing, study-

ing, and solving exercises. In contrast, Cluster 0, the

second-largest cluster, encompasses learners who en-

gage in routine tasks but also actively ‘Apply’ knowl-

edge, often through project submissions. Lastly, Clus-

ter 2, with the smallest learner count, consists of in-

dividuals who show a preference for quizzes and tests

as part of their learning paths.

Using Trace Clustering to Group Learning Scenarios: An Adaptation of FSS-Encoding to Moodle Logs Use Case

253

6 CONCLUSION

This study revolves around a previous work pre-

senting a framework aimed at providing personal-

ized adaptive learning paths, taking into account a

learner’s objective and leveraging the learning expe-

rience of previous learners. Employing Process Min-

ing, we extract past learning experiences through the

discovery of learning scenarios. However, dealing

with the unstructured and voluminous Moodle data,

that holds speciﬁc learning characteristics, poses a

challenge, making trace clustering crucial. Thus,

our approach enhances a feature-based Frequent-

Subsequence (FSS) trace clustering method by re-

ﬁning pattern selection, particularly preserving the

uniqueness of less frequent events. Applied to Moo-

dle logs, our method demonstrates signiﬁcant im-

provements, generating more and longer patterns, in-

ﬂuencing encoding results, and leading to better clus-

ters reﬂected by the silhouette coefﬁcient. The iden-

tiﬁed clusters reveal three distinct learning scenar-

ios: one characterized by a focus on studying and

solving exercises, another by the application of ac-

quired knowledge through projects, and a third by a

preference for undergoing more assessments. These

scenarios provide valuable insights for tailoring per-

sonalized recommendations. Future work involves

integrating these ﬁndings into the recommendation

framework, leveraging past learning experiences for

more effective guidance. It’s noteworthy that exten-

sive testing of clustering algorithms and linkage crite-

ria preceded the selection of the best-performing ap-

proach presented in this work.

REFERENCES

Aggarwal, C. C. (2016). Recommender Systems. Springer

Int. Publishing, Cham.

Bose, R. J. C. and Van der Aalst, W. M. (2009). Context

aware trace clustering: Towards improving process

mining results. In Proceedings of the Int. Conf. on

Data Mining, pages 401–412. SIAM.

Bose, R. J. C. and van der Aalst, W. M. (2009). Trace clus-

tering based on conserved patterns: Towards achiev-

ing better process models. In Int. Conf. on Business

Process Management, pages 170–181. Springer.

Cadez, I., Heckerman, D., Meek, C., Smyth, P., and White,

S. (2003). Model-based clustering and visualization

of navigation patterns on a web site. Data mining and

knowledge discovery, 7(4):399–424.

Cenka, N. and Anggun, B. (2022). Analysing student be-

haviour in a learning management system using a pro-

cess mining approach. Knowledge Management & E-

Learning: An Int. Journal, 14(1):62–80.

Chatain, T., Carmona, J., and Van Dongen, B. (2017).

Alignment-based trace clustering. In Int. Conf. on

Conceptual Modeling, pages 295–308. Springer.

De Koninck, P. and De Weerdt, J. (2019). Scalable mixed-

paradigm trace clustering using super-instances. In

2019 Int. Conf. on Process Mining, pages 17–24.

IEEE.

De Weerdt, J., Vanden Broucke, S., Vanthienen, J., and Bae-

sens, B. (2013). Active trace clustering for improved

process discovery. IEEE Transactions on Knowledge

and Data Engineering, 25(12):2708–2720.

Diamantini, C., Genga, L., and Potena, D. (2016). Behav-

ioral process mining for unstructured processes. Jour-

nal of Intelligent Information Systems, 47(1):5–32.

Ferreira, D., Zacarias, M., Malheiros, M., and Ferreira, P.

(2007). Approaching process mining with sequence

clustering: Experiments and ﬁndings. In Int. Conf.

on business process management, pages 360–374.

Springer.

Joudieh, N., Eteokleous, N., Champagnat, R., Rabah, M.,

and Nowakowski, S. (2023). Employing a process

mining approach to recommend personalized adap-

tive learning paths in blended-learning environments.

In 12th Int. Conf. in Open and Distance Learning,

Athens, Greece.

Laksitowening, K. A., Prasetya, M. D., Suwawi, D. D. J.,

Herdiani, A., et al. (2023). Capturing students’ dy-

namic learning pattern based on activity logs using hi-

erarchical clustering. Jurnal RESTI (Rekayasa Sistem

dan Teknologi Informasi), 7(1):34–40.

Lu, X., Tabatabaei, S. A., Hoogendoorn, M., and Reijers,

H. A. (2019). Trace clustering on very large event

data in healthcare using frequent sequence patterns.

In Int. Conf. on Business Process Management, pages

198–215. Springer.

Pel, J., Han, J., Mortazavi-Asl, B., Pinto, H., Chen, Q.,

Dayal, U., and Hsu, M. (2001). Preﬁxspan: Min-

ing sequential patterns by preﬁx-projected growth. In

Proc. 17th IEEE Int. Conf. on Data Engineering. Hei-

delberg, Germany, pages 215–224.

Song, M., Gunther, C. W., and Van der Aalst, W. M.

(2008). Trace clustering in process mining. In Int.

Conf. on Business Process Management, pages 109–

120. Springer.

Trabelsi, M., Suire, C., Morcos, J., and Champagnat, R.

(2021). A new methodology to bring out typical users

interactions in digital libraries. In 2021 ACM/IEEE

Joint Conf. on Digital Libraries (JCDL), pages 11–20.

Van der Aalst, W. (2016). Process mining: data science in

action. Springer.

Zandkarimi, F., Rehse, J.-R., Soudmand, P., and Hoehle, H.

(2020). A generic framework for trace clustering in

process mining. In 2020 2nd Int. Conf. on Process

Mining, pages 177–184. IEEE.

Zhang, T., Taub, M., and Chen, Z. (2022). A multi-level

trace clustering analysis scheme for measuring stu-

dents’ self-regulated learning behavior in a mastery-

based online learning environment. In LAK22: 12th

Int. Learning Analytics and Knowledge Conf., pages

197–207.

CSEDU 2024 - 16th International Conference on Computer Supported Education

254
