Towards a Write once Run Anywhere Approach in

End-User IoT Development

Ekene Attoh

and Beat Signer

Web & Information Systems Engineering Lab, Vrije Universiteit Brussel, Pleinlaan 2, Brussels, Belgium

Keywords:

Cross-Platform IoT, Natural Language Processing, End-User Authoring, Semantic Interoperability.

Abstract:

With the rise of popular task automation or IoT platforms such as If This Then That (IFTTT), users can deﬁne

rules to enable interactions between smart devices in their environment and thereby improve their daily lives.

However, the rules authored via these platforms are usually tied to the platforms and sometimes even to speciﬁc

devices for which they have been deﬁned. Therefore, when a user wishes to move to a different environment

controlled by a different platform and/or devices, they need to recreate their rules for the new environment.

The rise in the number of smart devices further adds to the complexity of rule authoring since users will have

to navigate an ever-changing landscape of IoT devices. In order to address this problem, we need human-

computer interaction that works across the boundaries of speciﬁc IoT platforms and devices. A step towards

this human-computer interaction across platforms and devices is the introduction of a high-level semantic

model for end-user IoT development, enabling users to create rules at a higher level of abstraction. However,

many users who are used to the rule representation in their favourite tool might be unwilling to learn and adapt

to a new representation. We present a method for translating proprietary rules to a high-level semantic model

by using natural language processing techniques. Our translation enables users to work with their familiar rule

representation language and tool, but then apply their rules across different IoT platforms and devices.

1 INTRODUCTION

The interoperability issue between devices of dif-

ferent brands in the domain of the Internet of

Things (IoT) is omnipresent, a main reason be-

ing the unwillingness of major device manufactur-

ers to make their devices to interoperate with their

competitors’ devices (Longo et al., 2022). (Noura

et al., 2019) studied different categories interoper-

ability issues in state-of-the-art IoT solutions and

found that most IoT solutions do not support cross-

platform and cross-domain interoperability. If sup-

ported, these categories can enable IoT users to ex-

ploit different IoT services independently of the plat-

form (e.g. Apple or Samsung) or domain (e.g. health

or mobility). End-user development enables users to

develop and adapt systems in line with their back-

ground and skills (Barricelli et al., 2019) and has been

suggested to give users control over IoT solutions.

Various tools have been proposed to support end-

user IoT development (Desolda et al., 2016; Coutaz

https://orcid.org/0000-0002-8590-1005

https://orcid.org/0000-0001-9916-0837

and Crowley, 2016; Ospan et al., 2018). (Markopou-

los et al., 2017) noted that the most common program-

matic end-user control of IoT applications is through

specifying rules. Previous studies (Cabitza et al.,

2017; Ur et al., 2016) have further shown that a rule-

based approach is easily understandable and enables

end users to create their own programs. (Li et al.,

2017) identiﬁed that although the popular IFTTT

IoT task automation platform enables users to create

rules across various devices and services, not every

kind of device or service is supported.

(Corno et al., 2021) stated that most end-user de-

velopment platforms adopt a vendor-centric abstrac-

tion, thus requiring that every online service needs to

be programmed in a speciﬁc way. They argued that

this poses interoperability challenges since users need

to know any technological details to execute the in-

tended behaviours beforehand. This approach is inad-

equate in future IoT environments like smart cities, as

things will not always be known a priori but might dy-

namically appear and disappear (Corno et al., 2021).

As stated by (Attoh and Signer, 2021), tackling in-

https://ifttt.com

216

Attoh, E. and Signer, B.

Towards a Write once Run Anywhere Approach in End-User IoT Development.

DOI: 10.5220/0012675800003705

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 9th International Conference on Internet of Things, Big Data and Security (IoTBDS 2024), pages 216-225

ISBN: 978-989-758-699-6; ISSN: 2184-4976

teroperability issues ensures that users are no longer

locked-in to vendor-speciﬁc tools or platforms.

We start with an overview of related work ad-

dressing interoperability in IoT environments. Our

NLP-based solution for automatic rule translation is

presented in Section 3 and the performance of three

translation algorithms is discussed in Section 4. Users

are enabled to work with their familiar rule represen-

tation language and tool, and at the same time can

apply their rules across different IoT platforms and

devices. After an initial user evaluation of our write

once, run anywhere approach for end-user IoT devel-

opment presented in Section 5, we provide some con-

clusions and outlook for future work.

2 RELATED WORK

To address the interoperability issue across different

IoT solutions, (Li et al., 2017) presented a solution

allowing users to author rules for their IoT devices by

demonstrating interactions between smart devices us-

ing their mobile phones. The solution consists of an

Android application enabling users to create automa-

tion scripts composed by recording the actions users

perform on the mobile application of their smart de-

vices. The scripts can then be triggered to perform

the actions, using a source from another application

such as a notiﬁcation from a motion sensor applica-

tion. Note that since the solution was designed to

work on the Android operating system, the created

automations will only be usable on Android devices.

This implies that a user would lose all their automa-

tions if they were, for example, going to switch to an

iOS device.

(Corno et al., 2019) attempted to address the in-

teroperability issue by introducing the EUPont (End

User Programming Ontology) high-level semantic

model for end-user IoT development. With EUPont,

users no longer need to create rules for speciﬁc de-

vices or services, but they can deﬁne abstract rules

such that any device or service able to perform the re-

quired action can be used to execute those rules. For

instance, a speciﬁc IFTTT rule like “If my smart sen-

sor X detects that I am home and the outside tem-

perature is less than 10 degrees, then turn on my

smart heater H” would have to be recreated if a user

switches to a smart sensor “Y” or smart heater “I”. In

EUPont, the rule can be transformed to “If I am in an

indoor place and the outside temperature is less than

10 degrees, then start heating the indoor place”. Us-

ing any platform understanding the EUPont ontology,

a user’s rules can be executed on any device that can

detect their presence and also heat their environment.

Another factor contributing to the problem of in-

teroperability in IoT is an issue present in end-user

IoT development. As more technologies are sup-

ported by platforms such as IFTTT, the design space

also grows and it becomes more difﬁcult for users to

discover rules and their related functionality (Corno

et al., 2020b). This increased complexity makes in-

teroperability more difﬁcult since rules with similar

functionality can be created in different ways. The use

of recommendations in end-user development tools

has been proposed to address this issue, similar as for

the development of software artefacts (Kr

uger, 2018;

Nguyen et al., 2016). However, the opportunities for

recommendations have not yet been consistently ex-

plored to support end-user development, but rather fo-

cus on helping professional developers (Corno et al.,

2020b). Therefore, the TAPrec end-user development

platform enabling the composition of trigger-action

rules based on dynamic recommendations has been

introduced. At composition time, it suggests new

rules to be used or actions, which are based on the

rule’s ﬁnal purpose such as illuminating a place rather

than details like device brands and manufacturers, for

completing a rule.

(Mattioli and Patern

o, 2021) proposed a solution

that suggests relevant triggers, operators and actions

to a user during rule composition. The system pro-

vides both, step-by-step and full-rule recommenda-

tions and a user is either recommended components to

complete their rule or the system suggests a complete

rule. (Jeong et al., 2019) introduced a framework to

analyse the usage logs of devices in an IoT context

and make rule recommendations to users based on the

analysis of their device usage patterns.

InstructableCrowd (Huang et al., 2016) is a

crowd-sourcing system enabling users to create IF-

THEN rules based on their needs. Users can describe

their problems (e.g. often being late for a meeting) via

a smartphone user interface to crowdworkers, and the

crowdworkers create rules addressing a user’s needs

and send them back to their phone. HeyTAP (Corno

et al., 2020a) supports users in describing the desired

behaviour of their smart devices through conversa-

tions (text or voice) and getting rule recommendations

materialising their stated intentions.

The situation concept proposed by (Trullemans

et al., 2017) and implemented in the Context Mod-

elling Toolkit (CMT) is another means to tackle the

complexity of authoring rules with similar function-

ality. They proposed that the trigger side of a rule

can lead to the deﬁnition of a reusable situation rather

than just triggering an action. This situation can then

be used on the trigger side of a new rule deﬁnition,

eliminating the need for users to understand all the

Towards a Write once Run Anywhere Approach in End-User IoT Development

217

low-level details since they can also use situations in

the deﬁnition of their automations.

Although related work proposed solutions to ad-

dress IoT interoperability issues, to the best of our

knowledge they are only focusing on the creation of

new rules by users in novel ways and using new sys-

tems to bridge the interoperability gap rather than en-

abling users to retain their current tools and methods,

while still being able to beneﬁt from solutions offer-

ing cross-platform interoperability (Attoh and Signer,

2021). Based on our analysis of related work, we

identiﬁed two major problems to be addressed:

Loss of Tooling Choice: As mentioned before, var-

ious solutions have been put forward to bridge the

cross-platform gap (Li et al., 2017; Corno et al.,

2019), but they also propose the use of new tools and

languages. This means that users need to learn to use

new tools and languages for creating rules that work

across different platforms.

Rule Authoring Complexity: Related work further

shows that due to the rise in the number of smart de-

vices, the discoverability of rules and their related

functionality becomes more complex (Corno et al.,

2020b). Therefore, users do not only need to use

new tools and rule description languages to bene-

ﬁt from cross-platform interoperability solutions, but

they also have to navigate an ever-changing land-

scape of IoT devices and services while authoring

their rules. This additional complexity may not only

create an entry barrier for new users, but also increase

a user’s time needed to create their desired automa-

tion. We analysed the IFTTT user recipes (rules) from

the May 2017 dataset of Mi et al. (Mi et al., 2017) and

found that out of the total 279 828 user recipes, there

were 863 duplicate triggers (number of triggers that

were used more than once) and 502 duplicate actions

(number of actions that were used more than once).

The identiﬁcation of these triggers and actions—as

well as understanding their functionality—can be-

come more difﬁcult for lesser-known triggers and ac-

tions resulting in unmanageable complexity for most

users and in particular for non-expert users.

3 RULE TRANSLATION

We propose a Natural Language Processing (NLP)

approach for automatically translating proprietary

end-user rules to the EUPont high-level abstraction

by Corno et al. (Corno et al., 2019). This method

provides end users with a Write Once, Run Anywhere

paradigm where they can retain the authoring tool and

language description of their choice but have the ﬂex-

ibility to use their rules across different platforms, en-

abling IoT interoperability on the application layer.

A user simply has to write their rule as they would

normally do and have it translated to an equivalent

EUPont representation. For instance, let us assume

that a user has previously composed the IFTTT rule

“If AC brand X is turned off, then activate my cam-

era brand Y” for their smart home. They now ﬁnd

themselves on vacation in a smart environment which

uses an air conditioner (AC) of brand Z and a camera

of brand C. With existing solutions, the user needs to

create a new rule “If AC brand Z is turned off, then

activate my camera brand C” to have the same ex-

perience in their vacation environment as they would

enjoy at their home. We rather propose a solution

where a rule can be automatically translated to the

EUPont generalisation “If device turned off, then con-

nect to device”. Just as the JSON

format is generic

such that most (modern) language compilers and in-

terpreters are equipped with JSON parsers, the inten-

tion behind the EUPont representation is that IoT plat-

forms with the EUPont “runtime” might be able to

work with the representation. Therefore, a proprietary

rule (e.g. IFTTT rule) has to be written only once and

can be translated to the EUPont representation to be

used across different platforms. This means that an

EUPont-powered platform can make it possible for

any device which might be triggered off to be used

as the trigger of the rule. For the rule’s action, a cam-

era can be mapped to the high-level action “Connect

to device”, which can then be triggered when the rule

is executed. A user is therefore not limited to using

devices of brand X or Y in order to take advantage

of their already composed rule. Note that our rule

translation has been described in detail in a technical

report (Attoh and Signer, 2023a).

An overview of our IoT rule translation approach

is shown in Figure 1. A user creates (proprietary)

IoT rules, which can be seen as the Write Once part,

using any platform of their choice (e.g. IoT Platform A

or IoT Platform B). These platforms have access to our

translation approach described later, and the Transla-

tion Module then converts the created rules to the high-

level EUPont representation.

As stated previously, a user would need to dupli-

cate and further customise a rule authored to work on

a speciﬁc platform to use that rule on a different plat-

form, given that each platform stores its users’ data

locally. In order to address this issue, we introduce the

use of Solid Pods to store the automatically translated

high-level rules (Sambra et al., 2016). Solid aims to

provide data independence as well as simple yet pow-

erful data management mechanisms, where applica-

tions no longer store their data themselves, but request

https://www.json.org

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

218

IoT Platform A

+ EUPont runtime

Translation Module

High-Level Rules

create proprietary rules

Solid Pods

IoT Platform B

+ EUPont runtime

proprietary rules

pull rules

IoT Devices

trigger rules

create proprietary rules

proprietary rules

pull rules

trigger rules

IoT Devices

Figure 1: Architecture for translating proprietary IoT rules.

access to retrieve it from users’ Pods. The Solid in-

tegration thus enables a user to apply their high-level

rules on any IoT platform by granting individual plat-

forms access to their Pod. This, in combination with

the translation step, leads to the Run Anywhere part

of our proposed solution. A user can write their rules

using a proprietary platform and these rules are then

translated by our Translation Module and stored in the

user’s Solid Pod. A platform can then pull the user’s

translated rules from their Solid Pod and, based on the

EUPont runtime, trigger the required actions on the

corresponding IoT devices. Further, users are in con-

trol of their data, with their Solid Pods as the single

access point and source of truth for their IoT rules.

With the proposed translation solution, we aim

to minimise or eliminate a user’s need to search for

and/or understand the equivalent EUPont representa-

tion for their proprietary rules. To achieve this, we

ﬁrst propose that an expert user should be kept in the

loop during the testing phase such that initially, they

might manually select the best matching translation

in situations where the one proposed by the system

is inadequate. With this method, we intend that the

best results are learned over time and proposed to the

user. Due to the popularity of the IFTTT platform, we

have selected IFTTT rules as the ﬁrst type of input to

be addressed by our translation method. However, in

the future, we intend to apply our approach to other

IoT platforms such as Home Assistant

As mentioned earlier, the dataset of (Mi et al.,

https://www.home-assistant.io

2017) contains 279 828 user recipes, implying that

each of those recipes would need to be created for

each new platform. With our proposed solution, these

recipes can not only be written just once and then

be automatically translated to run anywhere, but a

recipe’s author can use their preferred authoring tool

and keep the ownership of their data (rules). In the

remainder of this paper, we describe the translation

approach depicted as Translation Module in Figure 1.

3.1 Dataset

(Mi et al., 2017) collected published IFTTT recipes

(rules) from November 2016 until May 2017. For

our automatic translation of rules, we decided to use

the most recent May 2017 dataset containing a total

of 279 828 recipes (rules). Not each of the recipes

necessarily contains unique triggers and actions; the

trigger “Any new photo by you” is for instance used

9680 times in the dataset. Therefore, the 279 828

rules of the dataset consist of a total of 1017 different

triggers and 616 different actions of which 154 trig-

gers and 114 actions appear only once. For our proof-

of-concept implementation and evaluation, we ran our

solution on all different triggers and actions.

3.2 Data Preparation

Before applying our translation technique, we per-

formed some data cleaning in order to remove any

present anomalies and to prepare it to be used for

Towards a Write once Run Anywhere Approach in End-User IoT Development

219

the translation steps. For the recipes (rules) present

in the dataset (Mi et al., 2017), we noticed that some

of the triggers and actions contained a forward slash

character. We thus removed that character from the

triggers and actions and further separated the triggers

and actions into two different lists which we refer to

as the IFTTT dataset. We also transformed the on-

tology proposed by (Corno et al., 2019) from XML

to JSON to extract its high-level triggers and actions.

We removed the redundant Trigger and Action suf-

ﬁxes from the triggers and actions and separated the

high-level trigger and action names into two different

lists which we refer to as the EUPont dataset.

3.3 Translation Technique

Our aim for the translation was to take a rule writ-

ten by a user in a proprietary format (e.g. IFTTT) and

return a generalisation of that rule in the high-level

EUPont format by (Corno et al., 2019) that is as ac-

curate as possible. This would enable users to main-

tain their use of the IFTTT platform without having to

learn a new rule description language. To perform this

automatic translation from proprietary rules to high-

level rules, we apply some natural language process-

ing (NLP) techniques. According to (Qurashi et al.,

2020), measuring text similarity is an important part

of NLP applications, such as information retrieval,

machine translation and text summarisation. For our

translation, we applied different document similarity

algorithms to both, the IFTTT and EUPont datasets,

using the algorithm shown in Listing 1.

f o r ea c h t r i g g e r x i n EUPont d a t a s e t :

f o r e ac h t r i g g e r y i n IFTTT d a t a s e t :

r u n d o c u m e n t s i m i l a r i t y ( x , y )

r e t u r n x , y , S i m i l a r i t y ( x , y )

o r d e r by s i m i l a r i t y d e s c e n d i n g

f o r e ac h a c t i o n a i n EUPont d a t a s e t :

f o r e ac h a c t i o n b i n IFTTT d a t a s e t :

r u n d o c u m e n t s i m i l a r i t y ( a , b )

r e t u r n a , b , S i m i l a r i t y ( a , b )

o r d e r by s i m i l a r i t y d e s c e n d i n g

Listing 1: Pseudocode of translation algorithm.

We used the algorithm with three implementa-

tions (spaCy, AlleNLP and combined similarity) of

the document similarity(x,y) function shown in List-

ing 1 and compared the results as described.

spaCy Similarity: The free spaCy

open source

Python library for advanced Natural Language Pro-

cessing can be used to build information extraction,

natural language understanding systems or even to

https://spacy.io/usage/spacy-101

pre-process text for deep learning. We use spaCy’s

similarity feature to compare how similar a given

IFTTT trigger and action are to the high-level triggers

and actions in the EUPont ontology. We then return

the IFTTT trigger or action name together with the

computed similar EUPont trigger or action names, as

well as the corresponding similarity level.

An example of a result is shown in Listing 2,

where the ﬁrst entry has the EUPont trigger “Every

Time” returned by the spaCy approach for the IFTTT

trigger name “Any event starts”. Since not all trans-

lations returned by the algorithm are relevant, we de-

ﬁned a threshold value which is used to ﬁlter out re-

sults whose similarity falls below that value. While

the threshold is customisable, based on our initial

analysis we set its value to 0.55.

[

{

” E v e r y Time ” : {

” i f t t t n a m e ” : ” Any e v e n t s t a r t s ” ,

” s i m i l a r i t y ” : 0 . 7 4 7 4772725000891 }

} ,

{

” E v e r y Day ” : {

” i f t t t n a m e ” : ” Any e v e n t s t a r t s ” ,

” s i m i l a r i t y ” : 0 . 7 0 3 4427432691928 }

} ,

. . .

]

Listing 2: spaCy IFTTT trigger translation example.

AllenNLP Similarity: AllenNLP (Gardner et al.,

2017) is an entire platform for solving NLP tasks

and comes with a Python library. We applied the

textual entailment feature of AllenNLP which, for a

pair of sentences, predicts whether the facts in the

ﬁrst sentence imply the facts in the second. We

thus determine the textual entailment between each

IFTTT trigger and action in the dataset, and the high-

level EUPont (Corno et al., 2019) triggers and actions.

The AllenNLP textual entailment algorithm returns

entailment (a measure of the similarity of both texts),

contradiction (a measure of the dissimilarity of both

texts) and neutral (a measure of the neutrality of both

texts). We return the IFTTT triggers and actions to-

gether with the computed similar EUPont triggers and

actions as well as their entailment, contradiction and

neutral values as illustrated in Listing 3.

Combined Similarity: Our initial analysis revealed

that the spaCy approach returns more reliable results

than the AllenNLP approach. In order to improve the

translation results and reduce any noise, we deﬁned a

new approach where the AllenNLP algorithm is used

to compare the similarity between the initial spaCy re-

sults and the EUPont triggers and actions. For exam-

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

220

ple, for the IFTTT trigger “Any event starts”, we see

that the ﬁrst spaCy result returned is “Every Time”

while the ﬁrst AllenNLP result returned is “Taken”.

[

{

” i f t t t n a m e ” : ” Any e v e n t s t a r t s ” ,

” e u p o n t h y p o t h e s i s ” : ” Taken ” ,

” a l l e n n l p e n t a i l m e n t ” : 9 2. 1 6 3 2 8 2 6 3 2 82 7 7 6 ,

” a l l e n n l p c o n t r a d i c t i o n ” :

3 . 0 8 1 83 5 6 2 0 10 5 2 6 6 6 ,

” a l l e n n l p n e u t r a l ” : 4 .754881 5 6 0 8 0 2 4 6

} ,

{

” i f t t t n a m e ” : ” Any e v e n t s t a r t s ” ,

” e u p o n t h y p o t h e s i s ” : ” R e c e i v e d ” ,

” a l l e n n l p e n t a i l m e n t ” : 9 1. 5 2 0 11 8 7 1 33 7 8 9 ,

” a l l e n n l p c o n t r a d i c t i o n ” :

3 . 1 7 2 38 4 2 0 24 8 0 3 1 6 ,

” a l l e n n l p n e u t r a l ” : 5 . 30750006 4 3 7 3 0 1 6

} ,

. . .

]

Listing 3: AllenNLP IFTTT trigger translation example.

While the ﬁrst result returned by the spaCy ap-

proach might be acceptable, the result returned by

the AllenNLP approach is not. However, while con-

ducting our preliminary analysis, we noted that there

were more accurate matches further down in the list

of results returned by the spaCy approach. We there-

fore ran the AllenNLP algorithm using the initial

spaCy results and the EUPont triggers in order to fur-

ther improve the translation.

In Listing 4 we can see that the ﬁrst result returned

using this combined approach is “Started Activity”.

This result is obtained by combining (averaging) its

original spaCy similarity value (61.39) with the sim-

ilarity value obtained when using the AllenNLP al-

gorithm (85.80). The entry therefore has a combined

similarity of 73.60. We are thus able to move this spe-

ciﬁc spaCy result—which had initially a low ranking

compared to the initial “Every Time” top result—to

the top. We perform this process for each result re-

turned by the spaCy approach and therefore the re-

sults with a high combined similarity are most likely

to be the most accurate since they have both, high

spaCy and high AllenNLP similarities. An example

of the result obtained using this combined approach

is highlighted in Listing 4.

While there are several NLP libraries for the

Python programming language, such as scikit-learn

https://scikit-learn.org/stable/tutorial/text analytics/

working with text data.html

and PyTorch

, we opted for the spaCy

and AllenNLP

libraries, mainly due to their user friendliness. spaCy

is also a popular choice in NLP tasks given its fast

execution time and the ease with which it lets users

build solutions. Similarly, AllenNLP enjoys popular-

ity due to its fast execution time and ease with which

it lets a user build prototypes.

[

{

” i f t t t n a m e ” : ” Any e v e n t s t a r t s ” ,

” e u p o n t h y p o t h e s i s ” : ” S t a r t e d A c t i v i t y ” ,

” s p a c y s i m i l a r i t y ” : 61 . 3 9 5 93 2 3 3 37 1 5 2 2 ,

” a l l e n n l p e n t a i l m e n t ” : 8 5. 8 0 6 7 8 7 0 1 4 00 7 5 7 ,

” a l l e n n l p c o n t r a d i c t i o n ” : 3 . 39 4 8 0 2 65 9 7 4 998 4 7 ,

” a l l e n n l p n e u t r a l ” : 10 . 7 9 8 40 8 8 3 6 12 6 3 2 8 ,

” c o m b i n e d s i m i l a r i t y ” : 73.601359 6 7 3 8 6 1 4

} ,

{

” i f t t t n a m e ” : ” Any e v e n t s t a r t s ” ,

” e u p o n t h y p o t h e s i s ” : ” P o s i t i o n R e g i s t r a t i o n ” ,

” s p a c y s i m i l a r i t y ” : 57 . 5 2 3 55 4 3 5 39 6 4 1 9 ,

” a l l e n n l p e n t a i l m e n t ” : 8 1. 5 4 6 0 5 6 2 7 0 59 9 3 7 ,

” a l l e n n l p c o n t r a d i c t i o n ” : 5 . 9 5 1 3 6 69 4 6 1 01 1 8 9 ,

” a l l e n n l p n e u t r a l ” : 12 . 5 0 2 56 8 9 6 01 8 9 8 2 ,

” c o m b i n e d s i m i l a r i t y ” : 69.534805312 2 8 1 7 8

} ,

. . .

]

Listing 4: Combined IFTTT trigger translation example.

4 RESULTS

We recorded and compared the results we obtained

when applying each of the three different approaches

described in the previous section on recipes of the

Mi et al. (Mi et al., 2017) dataset. With our trans-

lation technique, we intended that the ﬁrst result

recommended by each approach should produce the

most accurate high-level EUPont generalisation of the

IFTTT triggers and actions. However, in situations

where this is not the case, a user should at least be

able to ﬁnd an accurate high-level EUPont generalisa-

tion within the ﬁrst ﬁve returned results. We decided

to consider only the ﬁrst ﬁve results by each approach

to reduce the potential burden a user might face when

looking for the best result. In our results, we mark an

entry with “No result” if no suitable match has been

returned as part of the ﬁrst ﬁve results. For trigger

or action names that we consider to be ambiguous—

any trigger or action whose meaning could have mul-

tiple interpretations—we mark the entry and the re-

sulting translations as “Ambiguous”. For instance,

https://pytorchnlp.readthedocs.io/en/latest/

https://spacy.io

Towards a Write once Run Anywhere Approach in End-User IoT Development

221

Table 1: IFTTT trigger translation results.

No. IFTTT Name spaCy 1 spaCY 2 AllenNLP 1 AllenNLP 2 Combined 1 Combined 2

1 . . . . . . . . . . . . . . . . . . . . .

2 AC turned off Device Turned

Off

Device Turned

Off (1)

Brightness

Decreased

No result Device Turned

Off

Device Turned

Off (1)

23 Action Button

Pressed

Tap Button

Activity

Tap Button

Activity (1)

Taken No result Tap Button Activ-

ity

Tap Button Activ-

ity (1)

. . . . . . . . . . . . . . . . . . . . . . . .

Table 2: IFTTT action translation results.

No. IFTTT Name spaCy 1 spaCY 2 AllenNLP 1 AllenNLP 2 Combined 1 Combined 2

1 . . . . . . . . . . . . . . . . . . . . .

10 Add a ﬁle Share File Save File (2) Information No result Share File Save File (2)

11 Add a new site

(ambiguous)

Connect To Web

Service

Ambiguous Start

Focusing

Ambiguous Save Media

Information

Ambiguous

. . . . . . . . . . . . . . . . . . . . . . . .

the trigger “Air quality changed” is marked as “Am-

biguous” because the change in air quality could ei-

ther be positive or negative. Therefore one approach

might return “Air quality decreased” as its best re-

sult, while another approach might return “Air qual-

ity increased” as its best result. We further note that

several possible acceptable results were returned for

certain IFTTT triggers and actions by our approach.

We split our ﬁndings into two different tables,

with Table 1 showing the results for triggers and Ta-

ble 2 highlighting the results for actions. Each table

contains the following columns:

- No.: Entry Number

- IFTTT Name: IFTTT trigger or action name

- spaCy 1: EUPont trigger or action name with the

highest similarity value using the spaCy similarity

algorithm.

- spaCY 2: EUPont trigger or action name most ac-

curately representing the IFTTT trigger or action

name using the spaCy similarity algorithm (posi-

tion in the result list in brackets).

- AllenNLP 1: EUPont trigger or action name with

the highest similarity value using the AllenNLP

text entailment algorithm.

- AllenNLP 2: EUPont trigger or action name most

accurately representing the IFTTT trigger or ac-

tion name using the AllenNLP text entailment al-

gorithm (position in the result list in brackets).

- Combined 1: EUPont trigger or action name with

the highest similarity value using the combined ap-

proach.

- Combined 2: EUPont trigger or action name most

accurately representing the IFTTT trigger or action

name using the combined approach (position in the

result list in brackets).

For the presented results, we randomly selected

50 triggers and actions from the results we obtained

from running our approaches on the dataset. The re-

sults from these 50 triggers and actions were then

manually analysed (e.g. to identify and label the most

accurate EUPont triggers and actions) in order to pop-

ulate the entries in Table 1 and Table 2. Note that only

a few representative entries from these two tables are

shown but the entire tables as well as the complete but

non-annotated results of the presented approaches are

available online (Attoh and Signer, 2023b).

4.1 Analysis

We sought to determine which of the three approaches

is performing best. Thereby, we consider an approach

to be performing better than another approach based

on a combination of the following criteria:

- It has more top results than the other approach.

- It has more top 5 results than the other approach.

- It has fewer cases where a translation could not be

found in the top 5 results than the other approach.

In our analysis, entries marked as ambiguous (12 out

of the 50 randomly selected triggers) were not con-

sidered. Therefore, we found that for the remaining

38 triggers, our combined approach returned the best

EUPont match as the ﬁrst result for 16 of those trig-

gers as summarised in Table 3. For 13 of the trig-

gers, the best EUPont match was not the ﬁrst result

but could be found in the top 5 results. However,

for 9 of the IFTTT triggers, a suitable EUPont match

could not be found by our combined approach. Using

the spaCy approach, we found that the best EUPont

match was returned as the ﬁrst result for 13 triggers,

while for 9 triggers, the best EUPont match was not

the ﬁrst result but could be found in the top 5 results.

However, for 16 triggers, a suitable EUPont match

could not be found. Similarly, using the AllenNLP

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

222

Table 3: Summary of trigger translation results.

Approach First Result Top Five Result No result

spaCy 13 9 16

AllenNLP 2 12 24

Combined 16 13 9

Table 4: Summary of action translation results.

Approach First Result Top Five Result No result

spaCy 10 8 22

AllenNLP 1 11 28

Combined 8 19 13

approach we see that the best EUPont match was re-

turned as the ﬁrst result for 2 triggers. For 12 of the

triggers, the best EUPont match was not the ﬁrst result

but could be found in the top 5 results, while for 24 of

the triggers no suitable EUPont match was found.

For the actions, there were 10 entries marked as

ambiguous. Table 4 shows that when using our com-

bined approach on the 40 considered actions, for 8 of

the actions the best EUPont match was returned as the

ﬁrst result, while for 19 of the actions the best EUPont

match was not the ﬁrst result but could be found in

the top 5 results and for 13 of the actions, no suitable

EUPont match could be found. Using the spaCy ap-

proach, 10 of the actions had the best EUPont match

returned as the ﬁrst result, while for 8 of the actions

the best EUPont match was not the ﬁrst result but

could be found in the top 5 results. However, for

22 of the actions, a suitable EUPont match could not

be found. Using the AllenNLP approach, we see that

only for 1 out of the actions the best EUPont match

was returned as the ﬁrst result, while for 11 of the ac-

tions the best EUPont match was not the ﬁrst result

but could be found in the top 5 results and for 28 of

the actions, no suitable EUPont match could be found.

Based on these results, we can conclude that our

combined approach is the best-performing approach

using our test dataset for both triggers and actions.

For triggers, our combined approach returns the high-

est number of top results, top 5 results and has the

smallest number of cases where no result has been re-

turned as part of the top 5. For the actions though,

the spaCy approach returns more top results than our

combined approach. However, spaCy returns signiﬁ-

cantly fewer top 5 results and has a larger number of

cases where no result was returned as part of the top 5.

5 USER EVALUATION

(Corno et al., 2019) conducted a user study to evalu-

ate the suitability and understandability of the EUPont

approach by end users. The study was a controlled

in-lab experiment that involved 30 participants, with

only 15 of them having programming experience. It

focused on the creation of IoT applications both with

the current low-level representation of IFTTT and the

high-level representation of EUPont. The study ad-

dressed the research questions “Does the EUPont rep-

resentation help users create their IoT applications

more effectively and efﬁciently compared to the low-

level representation?” and “Which of the two rep-

resentations is preferred by users, and which are the

perceived advantages and disadvantages of the two

solutions?”. In summary, the results demonstrated

that the EUPont representation allowed end users to

reduce the errors and time needed to compose their

IoT applications, and introduced numerous beneﬁts in

terms of understandability and ease of use.

Based on the ﬁndings of the user study by (Corno

et al., 2019), we consider the EUPont representation

to be a suitable high-level representation of IoT rules

for end users. To further evaluate our approach

and gather some feedback for future work, we con-

ducted a survey targeting several respondents who

were already familiar with the use of IoT automa-

tion solutions. We aimed to investigate whether real

IoT users would ﬁnd the results returned by any of

our methods to be good high-level generalisations of

the IFTTT triggers and actions included in the dataset

described earlier in Section 3. The research question

we sought to answer with this survey was “Are the

EUPont translations returned by our methods accept-

able to end users?” We had a total of 6 respondents

(three male and three female), aged between 20 and

39 years with one of them having obtained a Bach-

elor’s degree and the others a Master’s degree. In

our survey, the respondents were presented a series of

IFTTT triggers and actions with their corresponding

translations based on the three approaches described

in Section 3. They then had to select which method

they thought returned a good high-level generalisa-

tion of the IFTTT trigger or action and also specify

to which degree they found that generalisation to be

accurate. They could further select the “N/A” op-

tion in case they found that none of the methods re-

turned a suitable generalisation. For example, given

Towards a Write once Run Anywhere Approach in End-User IoT Development

223

the IFTTT trigger “New photo upload on page”, users

were presented with the following four options:

- Method 1: “Shared Proﬁle Update”

- Method 2: “No Result”

- Method 3: “Shared Post”

- “N/A”

In a follow-up question, they were asked “To which

degree is your chosen method an accurate generali-

sation of the IFTTT trigger?” and had the choice of

“Not at all accurate”, “Low accuracy”, “Accurate”

and “Very accurate”.

For situations where multiple methods returned

the same value, the respondents were asked to pick

any of those methods if they considered the value

to be an accurate generalisation of the trigger or ac-

tion. For example, for the IFTTT trigger “If new post

from search. . . ”, method 1 and method 3 returned “If

shared post. . . ” and respondents could choose any of

those two methods if they found it a good high-level

generalisation of the IFTTT trigger. We followed the

same principle as described in Section 3.3 by consid-

ering only the ﬁrst ﬁve results of each method.

The triggers and actions selected for the survey

were those we consider to be popular in the dataset

based on the fact that they were used 1000 or more

times in the dataset described in Section 3. Triggers

and actions for which the three methods returned no

suitable or ambiguous results were not selected. The

survey thus comprised questions for 31 triggers and

33 actions. There were 19 out of the 31 triggers and

19 out of the 33 actions where more than one method

returned the same result. We will refer to these cases

as triggers with the same result and actions with the

same result respectively. For 12 triggers and 14 ac-

tions none of the three methods returned the same re-

sult. We will refer to these cases as triggers with dif-

ferent results and actions with different results.

For the 19 triggers with the same result, in

16 cases at least half of the respondents selected that

result as a good high-level description, while for the

other 3 cases they indicated that there was no suit-

able generalisation. In the case of the 19 actions with

the same result, at least half of the respondents se-

lected that result as a good high-level description in

18 cases, while for the other single case they indi-

cated that there was no suitable generalisation. For

the 12 triggers with different results, there were six

triggers where our combined method’s result was not

selected. For those six triggers, the result returned

by the spaCy method was selected by all respondents;

however, there were ﬁve cases where none of the other

two methods returned a result for those six triggers

and one case where our combined method returned a

result which was selected by two respondents. There

were 6 of the 12 triggers with different results where

the result of the combined method was selected by the

respondents. At least half of the respondents selected

the result returned by the combined method in 4 out of

those 6 cases, while for the other 2 cases, only one re-

spondent selected the result returned by the combined

method. For 5 out of the 6 triggers where the result

of our combined method was selected by the respon-

dents, the other methods did not return any suitable

result while for 1 of the triggers the spaCy method re-

turned a result which was selected by one respondent.

In the case of the 14 actions with different results,

there were 8 actions where our combined method’s

result was not selected. For those 8 actions, the re-

sult returned by the spaCy method was selected in

7 cases by at least half of the respondents and for

the last case, the result returned by the AllenNLP

method was selected once by at least half of the re-

spondents. Our combined method returned a result

for 4 of those eight actions and it was selected by less

than half of the respondents in only two cases while

AllenNLP returned a result for only one of the 8 ac-

tions which was selected by more than half of the re-

spondents. There were 5 of the 14 actions with differ-

ent results where the result returned by the combined

method was selected by the respondents. In 4 cases,

less than half of the respondents selected this result,

while for the last case half of the respondents selected

the result. In 4 of the cases, the other two methods

did not return a suitable result, while for the last case,

the spaCy method returned a result which was not se-

lected by any respondent. In summary, we can con-

clude that for 25 out of the 31 triggers and 24 out of

the 33 actions, a majority of the respondents selected

the result returned by one of our methods as a good

high-level generalisation. For the remaining cases, no

respondents selected the result returned by one of our

methods as a good high-level generalisation.

6 CONCLUSIONS

We presented a Write Once Run Anywhere paradigm

for end-user authoring in IoT settings, helping users

to maintain their preferred authoring tool as well as

their preferred description language when deﬁning

IoT rules that will work across different IoT plat-

forms. To achieve this, we employed the use of nat-

ural language processing techniques to automatically

translate proprietary rules to high-level EUPont rules

which have been positively received as shown by

(Corno et al., 2019). Therefore, we used two popu-

lar NLP algorithms in two different approaches and

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

224

proposed a third novel approach by combining these

two algorithms, and carefully analysed the results ob-

tained from all three approaches. The results of our

analysis show that all three methods return good high-

level generalisations with our novel combined method

performing better than the other two methods for the

given dataset. We acknowledge that only a small

number of users completed our survey, but from these

preliminary results, we see that real IoT users also

identiﬁed the results returned by our three approaches

as good high-level generalisations. In future work, we

will investigate how to consistently return the most

accurate high-level generalisation for a user’s rules,

by either using one or a combination of the presented

methods. We also plan to focus on improving the ac-

curacy of the results so that more often the ﬁrst result

returned is the most accurate high-level generalisation

and the number of cases where no result is returned is

minimised or even completely eliminated. Finally, we

are going to investigate how our solution can best be

integrated into existing IoT platforms as illustrated in

Figure 1 to further evaluate the proposed NLP-based

rule translation approach with end users.

REFERENCES

Attoh, E. and Signer, B. (2021). A Middleware for Implicit

Human-Computer Interaction Across IoT Platforms.

In Adjunct Proc. of UbiComp 2021.

Attoh, E. and Signer, B. (2023a). From Proprietary to High-

Level Trigger-Action Programming Rules: A Natu-

ral Language Processing Approach. Technical Report

WISE-2023-01, Vrije Universiteit Brussel.

Attoh, E. and Signer, B. (2023b). Transforming Proprietary

to High-Level Trigger-Action Programming Rules

Dataset. https://doi.org/10.5281/zenodo.10033916.

Barricelli, B. R. et al. (2019). End-User Development, End-

User Programming and End-User Software Engineer-

ing: A Systematic Mapping Study. Journal of Systems

and Software, 149.

Cabitza, F. et al. (2017). Rule-based Tools for the Conﬁgu-

ration of Ambient Intelligence Systems: A Compara-

tive User Study. MTAP, 76(4).

Corno, F., De Russis, L., and Monge Roffarello, A. (2021).

Devices, Information, and People: Abstracting the

Internet of Things for End-User Personalization. In

Proc. of IS-EUD 2021.

Corno, F., De Russis, L., and Roffarello, A. M. (2019). A

High-Level Semantic Approach to End-User Develop-

ment in the Internet of Things. International Journal

of Human-Computer Studies, 125.

Corno, F. et al. (2020a). HeyTAP: Bridging the Gaps

Between Users’ Needs and Technology in IF-THEN

Rules via Conversation. In Proc. of AVI 2020.

Corno, F. et al. (2020b). TAPrec: Supporting the Composi-

tion of Trigger-Action Rules Through Dynamic Rec-

ommendations. In Proc. of IUI 2020.

Coutaz, J. and Crowley, J. L. (2016). A First-Person Expe-

rience with End-User Development for Smart Homes.

IEEE Pervasive Computing, 15(2).

Desolda, G. et al. (2016). End-User Development for the

Internet of Things: EFESTO and the 5W Composition

Paradigm. In Proc. of RMC 2016.

Gardner, M. et al. (2017). AllenNLP: A Deep Semantic

Natural Language Processing Platform. In Proc. of

NLP-OSS.

Huang, T.-H. K., Azaria, A., and Bigham, J. P. (2016). In-

structableCrowd: Creating IF-THEN Rules via Con-

versations With the Crowd. In Proc. of CHI 2016 EA.

Jeong, H. et al. (2019). Big Data and Rule-based Recom-

mendation System in Internet of Things. Cluster Com-

puting, 22(1).

uger, J. (2018). When to Extract Features: Towards a

Recommender System. In Proc. of ICSE 2018 Com-

panion.

Li, T. J.-J. et al. (2017). Programming IoT Devices by

Demonstration Using Mobile Apps. In Proc. of IS-

EUD 2017.

Longo, C. F. et al. (2022). Towards Ontological Interop-

erability of Cognitive IoT Agents Based on Natural

Language Processing. Intelligenza Artiﬁciale, 16(1).

Markopoulos, P. et al. (2017). End-User Development for

the Internet of Things. TOCHI, 24(2).

Mattioli, A. and Patern

o, F. (2021). Recommendations for

Creating Trigger-Action Rules in a Block-based Envi-

ronment. Behaviour & Information Technology, 40.

Mi, X. et al. (2017). An Empirical Characterization of

IFTTT: Ecosystem, Usage, and Performance. In

Proc. of IMC 2017.

Nguyen, A. T. et al. (2016). API Code Recommenda-

tion Using Statistical Learning From Fine-Grained

Changes. In Proc. of FSE 2016.

Noura, M., Atiquzzaman, M., and Gaedke, M. (2019). In-

teroperability in Internet of Things: Taxonomies and

Open Challenges. Mobile Networks and Applications,

24(3).

Ospan, B. et al. (2018). Context Aware Virtual Assistant

With Case-based Conﬂict Resolution in Multi-User

Smart Home Environment. In Proc. of CoCoNet 2018.

Qurashi, A. W., Holmes, V., and Johnson, A. P. (2020).

Document Processing: Methods for Semantic Text

Similarity Analysis. In Proc. of INISTA 2020.

Sambra, A. V. et al. (2016). Solid: A Platform for Decen-

tralized Social Applications Based on Linked Data.

Technical report, MIT CSAIL & Qatar Computing

Research Institute.

Trullemans, S., Van Holsbeeke, L., and Signer, B. (2017).

The Context Modelling Toolkit: A Uniﬁed Multi-

layered Context Modelling Approach. PACMHCI,

1(EICS).

Ur, B. et al. (2016). Trigger-Action Programming in the

Wild: An Analysis of 200,000 IFTTT Recipes. In

Proc. of CHI 2016.

Towards a Write once Run Anywhere Approach in End-User IoT Development

225
