A Framework Addressing Challenges in Cybersecurity Testing of IoT

Ecosystems and Components

Steve Taylor

, Martin Jaatun

, Alan Mc Gibney

, Robert Seidl

, Pavlo Hrynchenko

Dmytro Prosvirin

and Rosella Mancilla

University of Southampton, Highfield Campus, SO17 1BJ, U.K.

SINTEF Digital, PO Box 4760 Torgarden, 7465 TRONDHEIM, Norway

Munster Technological University, Rossa Avenue, Bishopstown, Cork, Ireland

NOKIA Bell Labs, Werinherstr. 91, 81541 Munich, Germany

World Research Center of Vortex Energy, Rustavi Street Building 3 Apartment 47, Zaporizhzhya 69093, Ukraine

Antonov Aeronautical Scientific & Technical Company, Academika Tupoleva Str. 1, KYIV 03062, Ukraine

Engineering Ingegneria Informatica spa, Piazzale dell’Agricoltura, 24 - 00144 Rome, Italy

olegzaritskyi@gmail.com, dmytro.prosvirin@antonov-airlines.aero, RosellaOmana.Mancilla@eng.it

Keywords: IoT, Testing (Software Engineering, Penetration, Product Development), Full IoT Lifecycle Testing, Security

by Design, Component Level Testing, System Level Testing, Cyber Threat Intelligence (CTI) Sharing.

Abstract: This paper describes challenges within IoT ecosystems from the perspective of cybersecurity testing along

with a proposed approach to address them that will be investigated in a recently started Horizon Europe project

named TELEMETRY. The key observations regarding the design of the framework are summarised as

follows. There is a need to consider the full lifecycle of IoT components – at their design time, their integration

into systems, and operation of those systems. Threats and risks can propagate when components are connected

together in systems - vulnerabilities in one component can affect other components in a system. IoT devices

present limitations to current testing and management due to geographical distribution, opacity and limited

processing power. Risk assessment fulfils an important requirement because it enables assessment of what

elements are important to the system’s stakeholders, how these elements may be compromised, and how the

compromises may be controlled. Feedback from operational monitoring of IoT devices can inform firmware

updates / patches to the devices but there is a significant challenge in rolling out these patches to multiple

low-power devices geographically distributed.

1 INTRODUCTION

This paper describes challenges within IoT

ecosystems from the perspective of cybersecurity

testing along with a proposed approach to address

them, that will be taken by a recently funded Horizon

Europe project named TELEMETRY, focusing on

the key principles identiefied. The challenges and

approach are presented as a position for disucssion

and evaluation by the community.

https://orcid.org/0000-0002-9937-1762

https://orcid.org/0000-0001-7127-6694

https://orcid.org/0000-0002-0665-2005

https://orcid.org/0000-0001-8518-8433

https://orcid.org/0000-0002-6566-9560

1.1 Background

The societal and economic benefits from the rapid

advance of the digital economies are at the core of the

European Digital Agenda. This is bolstered by the

Next Generation Internet (NGI) initiative with an

emphasis on creating a more resilient, trustworthy

and sustainable Internet for our digital future. As the

Internet of Things (IoT) brings connectivity and

networked intelligence to the physical things around

us, highly distributed and complex infrastructures are

226

Taylor, S., Jaatun, M., Mc Gibney, A., Seidl, R., Hrynchenko, P., Prosvirin, D. and Mancilla, R.

A Framework Addressing Challenges in Cybersecurity Testing of IoT Ecosystems and Components.

DOI: 10.5220/0012676300003705

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 9th International Conference on Internet of Things, Big Data and Security (IoTBDS 2024), pages 226-234

ISBN: 978-989-758-699-6; ISSN: 2184-4976

emerging ultimately forming IoT ecosystems, which

can be defined as: systems of interconnected IoT

devices with hardware, software, services and

backbone network communication infrastructure to

support the required system functionality.

While these ecosystems bring many benefits and

efficiencies, their inherent complexity, heterogeneity

and dynamicity and distributed nature create

challenges for the management of security, testing,

validation, reliability and assurance at scale. The

characteristics of IoT ecosystems encapsulate some

key challenges for cybersecurity testing & assurance

of hardware, software and service components such

as: i) IoT devices are often “black boxes” to deployers

and users, meaning that their structure and inner

components are not accessible for testing; ii) IoT

devices are hard to update due to the specific nature

of their firmware and that the devices may be

manifold and geographically distributed and iii)

vulnerabilities in one component may allow threats

and risks to propagate to other components in a given

system.

To address these challenges, there is a need for

tools, techniques and holistic methodologies for

cybersecurity testing and vulnerability detection at

both component level and also in the systems the

components are integrated into (Figure 1). This will

enable continuous assessment of IoT components and

ecosystems over their whole lifecycle, supporting the

propagation of assurance for component developers,

system integrators and operators, who act on behalf

of ecosystem’s eventual users.

Figure 1: IoT Ecosystem Lifecycle & Testing Tools.

2 CONCEPT & APPROACH

Our approach is to develop a testing and risk

management framework that consists of a suite of

enabling tools and advanced methodologies that can

be used to engineer and accelerate the implementation

of testing, verification and assurance of IoT

ecosystems (as presented in Figure 2). This

framework targets the creation of a holistic decision

support system for the three major stakeholder types:

Component Developers (CDs), System Integrators

(SIs) and System Operators (SOs), enabling a shared

representation of assurance in existing and new IoT

ecosystem deployments. Continuous assessment of

the cybersecurity components & systems over their

whole lifecycle is essential to ensure the provision of

resilient digital infrastructures, systems and

processes. The framework ensures a tight coupling

exists between the design phase of components

(support security by design through targeted testing

tools), components’ integration into systems (through

systemic risk analysis), dynamic detection of

vulnerabilities and adaptation of the systems in their

operational phase (to ensure continued secure

operation).

Figure 2: Testing & Risk Management Framework.

The framework explicitly supports feedback from

operation to design. (McGraw, 2006) identifies

"Security Operations" as one of seven "touchpoints"

that constitute good practice for software security,

offering "feedback from the field" where monitoring

is used to identify security bugs and flaws in running

systems, feedback allows for these to be fixed in the

next development cycle. In a DevOps / Continuous

Integration environment, development is continuous,

and identified security bugs and design flaws can be

rectified "without undue delay". The framework

explicitly supports this feedback loop and brings

DevSecOps and DevOps closer together via its

monitoring tools and techniques that can feed into

design-time tools.

System

Integration

Component

Development

System

Operation

Component

Test ing To ol s

System Testing

Tools

Component /

System

Monitoring

Risk Management

Continuous Improvement Feedback

Components

interconnected

System

Deployed

Design Time Analysis

of Security Posture

Dynamic Analysis

of Security Posture

Static &

Dynamic Risk

Models

Vulnerability

Te sting &

Analysis Tools

Anomaly

Detectors &

Automated

Update

Runtime

Adaptation

Shared

Evidence

Metrics & Indicators

OperationDesign

Design

Adaptation

Assessment &

Certification

Methodologies

Digital Twin

Emulation

& Testing Facilities

Testing & Risk Management

Framework for IoT

Components & Ecosystems

A Framework Addressing Challenges in Cybersecurity Testing of IoT Ecosystems and Components

227

Figure 3: Risk Assessment Schema.

Risk assessment is a key element of our approach.

The schema shown in Figure 3 (derived from ISO

27000

) defines the relationships between key

elements of risk management. Assets (here software /

hardware components or systems) have

vulnerabilities, which expose them to threats. Threats

cause Consequences, which are usually adverse, and

the likelihood of a successful Threat attack on an

Asset determines the likelihood of its Consequence.

The impact (severity) of a Consequence combined

with its likelihood leads to a specific Risk. Controls

modify Risks, typically by acting to reduce the impact

of the Consequence (mitigation) or to reduce

vulnerabilities in Assets, which in turn reduces their

exposure to Threats. Risk analysis at component and

system level is a key integrating concept, which

enables transparent assessment of the effects of

vulnerabilities in components or systems.

Many of the framework’s tools and techniques are

aimed at detecting or testing for vulnerabilities in

components and systems, and their output can be

either used for benefit independently or can be used

as input to the risk assessment tooling, where the

detected vulnerabilities bootstrap the risk assessment

cycle illustrated above and lead to risks. The risk

assessment component uses an existing tool

developed by one of the project partners that provides

insight into risks to a vulnerable component, but also

propagated threats and resulting risks to other

components that are connected to it.

Advanced machine learning (ML) approaches

will be used to proactively analyse the behaviour of

components and systems with the detection of

ISO/IEC 27000:2018. Information technology —

Security techniques — Information security

management systems — Overview and vocabulary.

https://www.iso.org/standard/73906.html

abnormal/anomalous activities that can provide

insight into whether the components/systems are

working as expected. The tools aim to support two

types of monitoring, detection and testing: “black

box”, addressed via component and system level

anomaly detection tools and techniques; and “white

box”, via IoT Software Bill of Materials

, IIoT SBOM

generation

and open-source software SBOMs that

describe the sub-components that make up the

software. Both testing types can inform component-

level risk analysis.

The tools and framework approach is deliberately

designed to be extensible so that its tools and

infrastructure can integrate easily with third party

tools (e.g. vulnerability scanners such as Wazuh

) to

provide greater coverage of the space of devices /

software / hardware components and systems and to

provide a holistic risk management approach that

offers evidence-based decision support to assess and

enhance assurance across complex IoT ecosystems in

order to reduce the likelihood and impacts of

cybersecurity threats and to simplify compliance with

internal, industrial and governmental regulations and

certification standards such as the EU Cybersecurity

Certification framework (EUCC).

The approach aims to determine methodologies

for tools’ use, individually, together, and alongside

external third-party tools to support the complete

lifecycle of components & systems and for

compliance with relevant certification standards. For

this, two aspects of the operational context for IoT

ecosystems need consideration. Firstly there are

application cases, where different organisations

interact to add value (e.g. supply chains). The project

has three use cases in aerospace, telecommunications

and manufacturing, each of which represents a

complex, collaborative ecosystem (including IoT

supply chains) - they are all multi-stakeholder

systems of interacting components with different

domains of control. Secondly, there is a need to

consider the representation of an IoT device in the

context of a software supply chain, where an IoT

device / software component has upstream

dependencies and libraries. SBOMs will be used to

determine upstream dependencies (e.g. third party

libraries) used in the component for vulnerability and

risk analysis at sub-component level.

National Telecommunications and Information

Administration, Software Bill of Materials

https://ntia.gov/SBOM

https://www.iiotsbom.com/

Wazuh - The Open Source Security Platform

https://wazuh.com/

Threat Vulnerability

Consequence

Threat causes

Consequence

occurs on Asset

Control applied

to Asset

Control reduces

Vulnerability

exposes

Asset to Threat

has

Threat attacks

Asset

Risk

Likelihood and Impact

of Consequence make up Risk

Control modifies Risk

Asset Control

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

228

3 SPECIFIC CHALLENGES &

APPROACHES

This section describes key challenges identified for

the specific case of IoT ecosystems, and for each

challenge, a proposed approach is described for

addressing the challenge.

3.1 Tools & Techniques for

Semi-Automated Risk Management

of Devices, Components & Systems

There are several tools and techniques for

cybersecurity risk assessment: software tools such as

securiCAD, ThreatModeler, OWASP Threat Dragon,

Microsoft Threat Modeling Tool and CrypTier; and

manual risk analysis is supported via methodologies

such as OCTAVE, STRIDE, PASTA and Trike.

These tools and techniques are focused on the

enterprise and do not account for propagated threats

between components and stakeholders, often found in

supply chains (Boyes, 2015). Further, components

(e.g. hardware, devices, software, data) are systems in

their own right that aggregate sub-components - for

example a software component can be built of

bespoke code plus third party libraries. Components

often appear as black boxes to system integrators and

their threat and risk potential is unknown to the rest

of the higher-level system. There is thus a need to

consider both systemic and individual component-

level perspectives when assessing the risks in

scenarios where software and hardware is integrated

into a higher-level system.

Our approach is to utilise and extend a

cybersecurity-focused risk assessment toolkit named

Spyderisk that has been in development for 9+ years

and is available open source

. This follows the ISO

27005

methodology for cyber security risk

management, which in turn supports ISO 27001

certification. It has been applied to trust in

communication network situations targeting

healthcare (Surridge et al. 2019), data privacy

protection (Boniface et al 2022) and GDPR

compliance (Taylor 2021). Via a knowledge base and

reasoner, this toolkit supports modelling and

automated risk assessment of socio-technical

https://github.com/SPYDERISK

ISO/IEC 27005:2022. Information security,

cybersecurity and privacy protection. Guidance on

managing information security risks

https://www.iso.org/standard/80585.html.

ISO/IEC 27001:2022. Information security,

cybersecurity and privacy protection. Information

systems, where it automatically determines risk levels

of a system-level model and suggests controls to

lower risks. The toolkit’s knowledge base will be

extended to enable assessment at component-level,

whereby a component can be modelled as a

(sub)system in its own right, via supporting types of

assets representing, e.g., third party libraries,

operating systems, firmware; their relationships

within the component; how vulnerabilities of these

constituent parts can affect the component as a whole;

threats that may affect a component; the risks that

arise from threats; and controls that can address the

risks. Threat propagation between a component and

the higher level system in which it is integrated will

also be considered, following the system-level focus

of e.g. the IEC 62443 series of standards

. An initial

runtime risk analysis at system level will be

developed to support dynamic component-level risk

assessment. The risk assessment will be supported by

integrating vulnerabilities from advisory databases

such as Mitre CVE

driven by identification of third

party libraries in the SBOM manifest for open source

software components, and alerts from vulnerability

scanning tools such as Wazuh.

3.2 Component Level Runtime

Monitoring and Vulnerability

Detection

Numerous cybersecurity vulnerability scanners

already exist, operating at hardware, infrastructure

and application level, as either commercial products

(e.g. Nessus or Tripwire IP360) or open source

software (e.g OpenVas, Nmap or Wazuh). These are

comprehensive and powerful, but there is a need to

overcome two significant challenges. 1) many

devices and components (especially IoT) are a “black

box” to the deployers and operators of systems they

are integrated into, hence there is a need to be able to

monitor these components and detect vulnerabilities

from their inputs and outputs alone. 2) events

generated from devices often result in a deluge of data

- i.e. the devices repeatedly output similar, or only

slight deviations from, previous measurements which

can hinder the scalability of solutions and mask

detections of genuine anomalies.

security management systems Requirements.

https://www.iso.org/standard/27001.

https://www.isa.org/standards-and-publications/isa-

standards/isa-iec-62443-series-of-standards

Common Vulnerabilities and Exposures Database

https://cve.mitre.org/cve/, currently migrating to

https://www.cve.org/

A Framework Addressing Challenges in Cybersecurity Testing of IoT Ecosystems and Components

229

Our approach to address 1) is by monitoring the

output of the devices over time and creating ML

models to detect vulnerabilities or insights about the

behaviour of the device compared to normal

operation. Our approach to address 2) is via

aggregation of events via time-series analysis,

investigating different approaches for aggregation

such as: thresholds for differentiation between normal

and suspicious working conditions; silence periods

for repetitions of the same events; and how to map

multiple source events to a specific aggregated event

(e.g. one reporting that a threshold is breached) which

can be used to prioritize the order of these events.

3.3 System Level Runtime Monitoring

and Vulnerability Detection

Runtime monitoring of components to detect

anomalies and misbehaviours is needed with respect to

the expected interaction baseline in systems of devices,

software and hardware components. The analysis of

these anomalies can provide insight valuable for

assessment of components security (e.g., discovery of

vulnerabilities) and thus to inform updates to

components. The state of the art concerns Intrusion

Detection / Prevention Systems (IDS / IPS), that

monitors network traffic for suspicious activity and

alerts when such activity is discovered, or additionally

take preventative actions. IDS/IPSs are classified

based on two detection techniques. Signature-based

(Salunkhe, 2017) approaches monitor packets in the

network and compare them against a database of attack

signatures or attributes of known malicious threats.

They have a low false-positive rate, but the need for

signatures allows all unknown attacks to go

undetected. Behaviour-based (Vengatesan, 2019)

approaches identify anomalous behaviour using

machine learning techniques to recognize a normalized

baseline, to which all network activity is compared.

Behaviour-based approaches are more susceptible to

false positives and require an effective operating

algorithm to correctly analyse the arrived packets.

Some important limitations therefore persist with IDS:

detection accuracy is (relatively) poor, the rate of false

positives is still high, they have limited scalability,

current techniques often fail to detect emerging attacks

and they have very limited diagnostic facilities.

Our approach to address these challenges is to

investigate an IDS that performs anomaly detection on

IoT ecosystems. We will study the application of Fede-

rated Learning approach on behaviour-based detection

aiming at reducing the number of false positives,

increasing the detection accuracy and detection

coverage even with limited resources (IoT devices).

3.4 Misuse Detection

Devices / software / systems are designed to perform

a purpose with a specific usage in mind, and they are

deployed in socio-technical systems with human

users. These human users may either be unaware of

acceptable operating conditions or may deliberately

aim to misuse components with malicious intentions,

so there is a clear need for detection of misuse of

components in systems. Further, dynamic testing

should not only cover illicit access to components but

highlight component vulnerabilities due to the

misuse, thus supporting continuous improvement of

the components.

Our approach is to investigate the use of machine

learning to detect the misuse of software components

& systems based on baseline behavioural patterns

identified in historic usage scenarios. We will

investigate several approaches for the learning of

user-interaction models and the detection of

divergences in user behaviour from the norm, using

similar principles to social engineering for capturing

user aspects such as user functional footprint,

temporal behaviour and statistical data distribution.

These anomalies raise warnings that can identify

aspects such as impersonation of an authorised user

by an attacker, insider attacks or inadvertent misuse.

A set of algorithms such as Gaussian, Bayesian, time

series, autoencoders, deep neural networks, and other

neural networks will be used for anomaly detection.

The Misuse Detection Toolkit will also provide a

synthetic data generator capable to simulate the

misuse of software in web-based systems. For this

purpose, an analysis of the misuse case-based

interactions will be done.

3.5 Trusted Mechanisms to Facilitate

Distributed Sharing of Testing,

Verification & Cyber Threat

Intelligence (CTI)

Data exchange and sharing among independent

stakeholders, tools and services remains a real

concern. Much valuable information available for

component testing and evaluation (metrics, inputs and

results) and risk assessment remain closed and siloed

due to the complexity, interoperability, cost, privacy

& security risks, fears over data sovereignty and lack

of incentive for sharing. Thus there is a need to create

a collaborative framework that allows Component

Developers, System Integrators, System Operators

(CDs, SIs, SOs), researchers, practitioners, industry

and infrastructure providers, etc. to mutually benefit

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

230

from sharing vulnerability related information, which

will reduce redundancy and foster collaboration.

Our approach to address this is to create a

trustworthy framework for sharing security-related

information between tools and entities involved in

dynamic cybersecurity testing based on Distributed

Ledger Technology (DLT) providing functionality to

automate secure data management services, policy

enforcement and governance as well as the provision

of a secure backbone for data flows across

independent entities (Zhou, 2018). DLT underpinned

by blockchain technology increases transparency

across systems (contributing to assurances of

provenance) (Montecchi, 2019); and supports

auditability via features that allow for interrogation

each stage of the lifecycle for compliance with policy,

standards, or regulations (Lopez, 2020). Our

approach will include secure bi-directional

communication with external information sources,

e.g., Cyber Threat Intelligence (CTI) repositories.

The use of smart contracts will provide mechanisms

to automate governance, auditing and assurance

processes, to incentivise data sharing by lowering

barriers for secure data exchange and enabling data

owners to retain control & sovereignty over data. We

will investigate the types of information that are

needed for robust auditing, how they may be

efficiently stored in Distributed Ledgers and how the

information may be queried and interpreted by non-

domain-experts. This will form a reference ontology

for data sharing based current approaches e.g. Cyber

Intelligence Ontology

. We will further investigate

architectural approaches to integrate testing

methodologies and enhance existing tools with DLT-

based information sharing.

3.6 Service-Level Cybersecurity

Testing

IoT applications leverage application programming

interfaces (APIs) as a mechanism to interconnect and

exchange often outside organizational boundaries. To

ensure reliability and robustness of interactions and

activities that occur within the system requires API

analysis and security testing. Tools exist to support

testing however this is typically done at design time

and not on a continuous basis nor consider dynamic

composition of applications over time.

Our approach to address this challenge is to

develop and evaluate a security analyser for APIs

with particular emphasis on identifying potential

Cyber Intelligence Ontology https://unifiedcyber

ontology.org/index.html

vulnerabilities such as cross-site scripting (XSS),

SQL injection, cross-site request forgery (CSRF),

compromise attacks, injections, and man-in-the-

middle attacks (Badhwar, 2021). The security

analyser aims to execute a series of tests to equate and

quantify the security posture of API services running

at the edge and/or cloud layers that will inform

behaviour and reputation models of participants in

IoT ecosystems (devices & services). The models can

in turn be used to monitor performance of dynamic

IoT applications and build a digital representation of

the security posture of the application over time. This

can then be utilised to adapt the operation of a

particular component (e.g. via policy enforcement) to

ensure protection across a larger ecosystem. REST

API Penetration testing solutions such as Astra

can

be investigated and extended to include additional

security metrics (e.g. data anomalies, encryption

mechanisms).

3.7 Testing Access Control to

Components & Systems

A common problem with complex access control

systems is that they provide a mechanism for the user

to obtain permission from multiple policies, resulting

in an accumulation of effective permissions and

cumulatively constituting a certain level of risk.

Determining whether an access level poses a potential

security risk is a non-trivial task. This depends on the

sensitivity of the restricted object and the reliability

of the user, which together can give a certain level of

risk (Parkinson, 2022) and assessment of these factors

will improve decision-making when managing

systems and access to them.

To create a flexible assessment of access control

to system components indicators, which include both

quantitative and qualitative indicators, the use of a

mathematical apparatus of fuzzy logic is proposed.

This approach allows us to model complex access

control vulnerability criteria, including inaccurate,

incomplete or vague data, and the result will be an

assessment of the risk of granting more permissions

to a user or vice versa. Previous work using fuzzy

logic in discovering irregularities in access control

systems implemented as a binary classification

system will be extended to model issues of access

control via determination of ontologies of access

control concepts, their fuzzy logic representation and

risk computation.

[Astra] https://github.com/flipkart-incubator/Astra

A Framework Addressing Challenges in Cybersecurity Testing of IoT Ecosystems and Components

231

3.8 IoT Device SBOM Generation

A Software Bill of Materials (SBOM) is a

standardized list of dependencies (source

components, modules and libraries) used in a

software component, to ensure transparency and to

check the dependencies against vulnerability

databases, for example by using a service like Snyk

or a tool like OWASP's dependency-check. There are

currently (at least) three competing SBOM formats;

SPDX

from the Linux Foundation, CycloneDX

from OWASP, and SWID as defined in ISO/IEC

19770-2. NTIA has created a taxonomy for SBOM

tools

, but there is a lack of such tools for IoT

applications, hampering IoT device developers in

their ability to create SBOMs for their devices.

We will examine the different SBOM options and

select the one that is best fit-for-purpose for IoT

solutions, and develop and/or extend tools for

automatically creating an SBOM according to the

Produce-Build and Produce-Analyze paradigms to

enable IoT device developers to create and update

SBOMs for their devices quickly and easily.

3.9 IoT Device Fuzzing

Fuzzing is a technique that aims to find vulnerabilities

and bugs in a program via generating numerous test-

case inputs to the targeted program. Applying fuzzing

technique on IoT device software applications or OS

has received significant attention. However, this is

not the case when it comes to the proprietary wireless

communication stack such as 2G/3G/4G/5G

(cellular) running on IoT devices. The cellular

communication software running inside our mobile

phone is different than in IoT devices, in terms of

protocol and services perspective. In addition,

security aspects such as confidentiality, integrity and

availability are different in IoT devices (as compared

to smartphones) due to low-latency and power-

consumption requirements. Further, vulnerabilities in

these cellular proprietary software stack enables

compromise of mobile phones (Weinmann, 2012) and

even modern cars (Bazhaniuk, 2017).

We aim to fill this gap by systematically

conducting a dynamic security analysis of cellular

communication stack of IoT devices in a standardized

4G/5G network in a semi-automated manner. In

particular, we characterize IoT device specific

security properties from 3GPP standards and build a

https://spdx.dev/

https://cyclonedx.org/

database for generating test-cases and classify

problematic behaviours for automated fuzzing

frameworks.

Note that fuzz testing can be employed both at the

network level and at the software component level,

and in the Telemetry project we will also employ the

former.

3.10 Tools & Techniques for Secure

Update of Components & Systems

Secure update management is extremely challenging

in resource constrained devices (such as IoT devices)

that are geographically distributed and in different

domains of control. The secure remote distribution of

firmware updates requires secure communication

channels, primarily Transport Layer Security (TLS),

which has key agreement protocols built in. The

protocol remains too heavy for some resource-

constrained devices, and only works for TCP/IP,

which is not always the case for IoT networks (e.g.

LPWAN networks). Although lightweight key

agreement schemes have been proposed in the

literature, e.g. Noise Framework (Perrin, 2018), Julia

Key Agreement (JKA) (Lundberg, 2021), there are

still some open problems. Most schemes attempt to

reduce the number of scalar multiplications and do

not consider other constraints, such as limited

payload size. The design of a supporting Public Key

Infrastructure (PKI), particularly for highly

distributed and decentralized systems, also needs to

be addressed. Managing and evaluating access-

control and authentication requests to grant the

installation of firmware updates is an integral part of

a secure firmware update solution. Previously,

access-controls were levied on a one-to-one basis as

the number of devices were relatively low, but this

does not scale. Even though a lot of device access

control solutions have been proposed, e.g. FlowFence

(Earlence, 2016), (Bastys, 2018), ContexIoT

(Yunhan, 2017), SmartAuth (Tian, 2017), IoTGuard

(Celik, 2019), techniques do not match well with the

setting of a highly distributed and decentralized

system where multiple stakeholders have a shared

responsibility of managing an IoT device (and hence

each requiring a specific access to the device, which

can change over time).

Our approach to address this is based on a

lightweight key management solution, based on PKI,

for distributed and decentralized systems. To

SBOM Tool Classification Taxonomy https://ntia.gov/

files/ntia/publications/ntia_sbom_tooling_taxonomy-

2021mar30.pdf

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

232

authenticate the distribution of software updates, a

novel lightweight cryptographic MAC algorithm for

data authentication will be designed. Further

optimizations will be achieved on protocol level, by

exploring optimization tactics to further reduce the

energy cost of data authentication. The device access

control solution will be either based on cryptographic

tokens (in case of symmetric-key cryptography being

deployed, for example for energy-constrained

devices), or on digital signatures.

3.11 Emulation Environment for

Security Testing

Low-cost consumer edge devices have historically

failed to implement common security mechanisms

such as virtual memory, cryptographically secure

pseudo-random number generators or basic exploit

mitigations (such as ASLR or stack canaries)

(Wetzels, 2017), (Fasano, 2021). The world of

embedded systems needs the ability to conduct

dynamic analysis in addition to static, and thus

requires a way to move the software from a physical

system to a virtual one, which models the hardware

behaviour well enough - known as re-hosting. There

are several approaches: pure emulation, hardware-in-

the-loop, symbolic abstractions, or hybrid

approaches; each with each their pros and cons

(Fasano, 2021). Gustafson et al. point out the need for

an automatic process to create models of peripherals

that allow for execution of the firmware in a fully

emulated environment, as done by their proof-of-

concept tool, PRETENDER (Gustafson, 2019).

Several tools have been published, tackling the same

problem, including HALucinator (Clements, 2020)

and Fuzzware (Scharnowski, 2022), but most of the

latest tools for re-hosting are still proofs-of-concept

supporting only a subset of the architecture (typically

Cortex-M, for Fuzzware for instance).

We will build on top of those proofs-of-concept

and collaborate with the industry partners in the

project to 1) study the applicability of the tools to the

use cases in the project; 2) further develop them if

required, based on the needs from the partners; 3)

study the concept of digital twins for embedded

security, and how it can be used for security testing as

part of the development process. In particular, we will

make use of the automatically generated peripherals

models from Fuzzware to develop the digital twins.

Guidance on how to create and integrate such

virtualized environments and digital twins for

security testing will be provided.

4 CONCLUSIONS

This paper has described challenges for cybersecurity

identified in the area of IoT ecosystems. Multiple

challenges have been described, along with a

proposed solution. These solutions will be

investigated in a recently funded Horizon Europe

research project, and results of these investigations

will be reported in subsequent papers. As such the

paper represents problem statement and hypotheses

for solutions.

At a high level, key observations made during this

work are summarised as follows.

• There is a need to consider the full lifecycle of

IoT components – in their design, their

integration into systems, and operation of

those systems. Therefore, component level

testing and system level testing is needed,

especially considering that one component

may be used in different systems with different

effects.

• Threats and risks can propagate when

components are connected together in systems

- vulnerabilities in one component can affect

other components in a system.

• IoT devices provide limitations to current

testing and management due to geographical

distribution, opacity and limited processing

power.

• Monitoring and detection tools for IoT

components’ output can be used in a

cybersecurity risk assessment for the

component or the system. Risk assessment

fulfils an important requirement because it

enables assessment of what elements are

important to the system’s stakeholders, how

these elements may be compromised, and how

the compromises may be controlled.

• Feedback from operational monitoring of IoT

devices can inform firmware updates / patches

to the devices but there is a significant

challenge in rolling out these patches to

multiple low-power devices geographically

distributed.

ACKNOWLEDGEMENTS

This work is within the Horizon Europe

TELEMETRY project, supported by EC funding

under grant number 101119747.

A Framework Addressing Challenges in Cybersecurity Testing of IoT Ecosystems and Components

233

REFERENCES

Badhwar, R.: Intro to API Security - Issues and Some

Solutions! the CISO’s next Frontier Pp. 239–244 (2021).

Https://Doi.Org/10.1007/978-3-030-75354-2_ 29

Iulia Bastys, Musard Balliu, and Andrei Sabelfeld. if This

then What? Controlling Flows in Iot Apps. in

Proceedings of the 2018 ACM SIGSAC Conference on

Computer and Communications Security (CCS '18),

Page 1102-1119, 2018.

Boniface, Michael, Carmichael, Laura, Hall, Wendy,

Mcmahon, James, Pickering, J. Brian, Surridge, Mike,

Taylor, Steve, Atmaca, Ugur Ilker, Epiphaniou, Gregory,

Maple, Carsten, Murakonda, Sasi, & Weller, Suzanne.

(2022). DARE UK Priam Project D3 Report: Privacy

Risk Framework Application Guide (1.1). Zenodo.

Https://Doi.Org/10.5281/Zenodo.7107466

Boyes, H., 2015. Cybersecurity and Cyber-Resilient Supply

Chains. Technology Innovation Management Review,

5(4), P.28.

Z. Berkay Celik, Gang Tan, and Patrick Mcdaniel. Iotguard:

Dynamic Enforcement of Security and Safety Policy in

Commodity Iot. in Proceedings of the 23rd Network and

Distributed System Security Symposium (NDSS '19),

San Diego, CA.

Clements et al., A. “Halucinator: Firmware Re-Hosting

through Abstraction Layer Emulation,” Presented at the

USENIX Security Symposium (USENIX Security

20), 2020, Pp. 1201–1218. Https://Www.Usenix.Org/

Conference/Usenixsecurity20/Presentation/Clements

Bazhaniuk, Oleksandr, Jesse Michael & Mickey Shkatov.

Driving down the Rabbit Hole. Def-Con 2017.

Https://Infocondb.Org/Con/Def-Con/Def-Con-

25/Driving-down-the-Rabbit-Hole.

Earlence Fernandes, Justin Paupore, Amir Rahmati, Daniel

Simionato, Mauro Conti, and Atul Prakash. Flowfence:

Practical Data Protection for Emerging IoT Application

Frameworks. in 25th USENIX Security Symposium

(USENIX Security '16), Pages 531-548, Austin, TX.

Fasano et al., A. “Sok: Enabling Security Analyses of

Embedded Systems via Rehosting,” in Proceedings of the

2021 ACM Asia Conference on Computer and

Communications Security, New York, NY, USA, Jun.

2021, Pp. 687–701. Doi: 10.1145/3433210.3453093.

Gustafson et al., E. “Toward the Analysis of Embedded

Firmware through Automated Re-Hosting,” Presented at

the 22nd International Symposium on Research in

Attacks, Intrusions and Defenses (RAID 2019), 2019,

Pp. 135–150. https://www.Usenix.Org/Conference/ Raid

2019/Presentation/Gustafson

C. Todd Lopez, (2020). Dod Adopts 5 Principles of Artificial

Intelligence Ethics, Department of Defense (Feb. 5,

2020), Available Online: Https://Www.Defense.Gov/

Explore/News/Article/Article/2094085/Dod-Adopts-5-

Principles-of-Artificial-Intelligence-Ethics/

Frans Lundberg, Juraj Feljan. Julia: Fast and Secure Key

Agreement for Iot Devices. in Proceedings of the 14th

ACM Conference on Security and Privacy in Wireless

and Mobile Networks (WISEC '21), Pages 90-99, 2021.

G. Mcgraw, "Software Security", Addison-Wesley 2006

Montecchi, M., Plangger, K., and Etter, M. (2019). It’s Real,

Trust Me! Establishing Supply Chain Provenance using

Blockchain. Business Horizons. 10.1016/ J.Bushor.201

9.01.008.

Parkinson, S., Khana, S. Identifying High-Risk over-

Entitlement in Access Control Policies using Fuzzy

Logic. Cybersecurity 5, 6 (2022). https://Doi.Org/10.1

186/S42400-022-00112-1

Trevor Perrin. the Noise Protocol Framework, Revision 34,

2018. Https://Noiseprotocol.Org/Noise.Html

Salunkhe, U.R., Mali, S.N.: Security Enrichment in Intrusion

Detection System using Classifier Ensemble. J. Electr.

Comput. Eng. (2017). Https ://Doi.Org/10.1155/20

17/17948 49

T. Scharnowski Et Al., “Fuzzware: using Precise {MMIO}

Modeling for Effective Firmware Fuzzing,” 31st

USENIX Security Symposium (USENIX Security 22),

2022, Pp. 1239–1256. https://www.Usenix.Org/

Conference/Usenixsecurity22/Presentation/Scharnowski

Surridge M. Et Al. (2019) Modelling Compliance Threats

and Security Analysis of Cross Border Health Data

Exchange. in: Attiogbé C., Ferrarotti F., Maabout S.

(Eds) New Trends in Model and Data Engineering.

MEDI 2019. Communications in Computer and

Information Science, Vol 1085. Springer, Cham.

Taylor, S., Surridge, M., and Pickering, B., "Regulatory

Compliance Modelling using Risk Management

Techniques," 2021 IEEE World AI Iot Congress (Aiiot),

2021, Pp. 0474-0481, Doi: 10.1109/Aiiot52608.20

21.9454188.

Yuan Tian, Nan Zhang, Yueh-Hsun Lin, Xiaofeng Wang,

Blase Ur, Xianzheng Guo, and Patrick Tague. Smartauth:

User-Centered Authorization for the Internet of Things.

in 26th USENIX Security Symposium (USENIX

Security '17), Pages 361-378.

Vengatesan, K., Kumar, a., Naik, R., Verma, D.K.: Anomaly

based Novel Intrusion Detection System for Network

Traffic Reduction. in: 2nd International Conference on I-

SMAC. Iot in Social, Mobile, Analytics and Cloud

(2019)

Ralf-Philipp Weinmann. 2012. Baseband Attacks: Remote

Exploitation of Memory Corruptions in Cellular Protocol

Stacks. in Proceedings of the 6th USENIX Conference

on Offensive Technologies (WOOT'12). USENIX

Association, USA.

Jos Wetzels: the RTOS Exploit Mitigation Blues,

Hardwear.Io 2017 Https://Hardwear.Io/Document/ Rtos-

Exploit-Mitigation-Blues-Hardwear-Io.Pdf

Yunhan Jack Jia, Qi Alfred Chen, Shiqi Wang, Amir

Rahmati, Earlence Fernandes, Z. Morley Mao, and Atul

Prakash. Contexiot: towards Providing Contextual

Integrity to Appified Iot Platforms. in Proceedings of the

21st Network and Distributed System Security

Symposium (NDSS'17), San Diego, CA.

L. Zhou, L. Wang, Y. Sun, P. Lv, Beekeeper: a Blockchain-

based Iot System with Secure Storage and Homomorphic

Computation, IEEE Access (2018).

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

234
