Enriching the Semantic Representation of the Source Code with Natural

Language-Based Features from Comments for Improving the

Performance of Software Defect Prediction

Anamaria Briciu

, Mihaiela Lupea

, Gabriela Czibula

and Istvan Gergely Czibula

Department of Computer Science, Babes¸-Bolyai University, Cluj-Napoca, Romania

Keywords:

Software Defect Prediction, Machine Learning, Semantic Features, BERT-Based Models, doc2vec, Source

Code, Comments.

Abstract:

The present study belongs to the new research direction that aims to improve software defect prediction by

using additional knowledge such as source code comments. The fusion of programming language features

learned from the code and natural language features extracted from the code comments is the proposed se-

mantic representation of a source code. Two types of language models are applied to learn the semantic

features: (1) the pre-trained models CodeBERT and RoBERTa for code embedding and textual embedding;

(2) doc2vec model used for both, code embedding and comments embedding. These two semantic represen-

tations, in two combinations (only code features and code features fused with comment features), are used

separately with the XGBoost classiﬁer in the experiments conducted on the Calcite dataset. The results show

that the addition of the natural language features from the comments increases the software defect prediction

performance.

1 INTRODUCTION

Software defect prediction (SDP) is an important area

in software engineering research and practice, as it

can improve the software development process by

providing automated, early detection of software de-

fects in the system. Besides its importance in mea-

suring a software project evolution, software defect

prediction assists the process management (Clark and

Zubrow, 2001), is useful in predicting software relia-

bility (Zheng, 2009) and in guiding testing and code

review (hua Chang et al., 2011). Through all these

activities, SDP contributes to a signiﬁcant decrease

of the costs required by the software products’ de-

velopment and maintenance (Hryszko and Madeyski,

2018).

The approaches from the SDP literature are cat-

egorized in two types: within-project and cross-

project software defect prediction. Within-project ap-

proaches use data from a software project both for

training and testing the defect predictor (Zhu et al.,

https://orcid.org/0000-0001-6681-7281

https://orcid.org/0000-0002-2117-2018

https://orcid.org/0000-0001-7852-681X

https://orcid.org/0000-0003-0076-584X

2020), while the cross-project SDP approaches train

the SDP model on a set of software systems and

then test its performance on different software sys-

tems (Jin, 2021).

The importance of employing semantic features

from the source code besides software metrics for

SDP has been highlighted by (Wang et al., 2016).

(Yang et al., 2015) and (Wang et al., 2016) considered

Deep Belief Neural Network (DBNN) and source

code analysis for predicting software defects. Long

Short Term Memory (LSTM) networks were pro-

posed by (Dam et al., 2018) to learn semantic features

from the abstract syntax tree (AST) of the code. A Lo-

gistic Regression (LR) and a Random Forest classiﬁer

were then trained on these semantic features for pre-

dicting software defects. (Li et al., 2017) employed

a Convolutional Neural Network (CNN) trained on

the semantic features learned from the abstract syntax

tree combined with the software metrics. A LR classi-

ﬁer applied on the automatically learned features out-

performed the DBNN approach introduced by (Wang

et al., 2016). (Zhao et al., 2019) applied Siamese par-

allel fully connected networks to generate new fea-

tures out of the software metric values, without using

the source code.

One of the main difﬁculties in SDP is the severe

132

Briciu, A., Lupea, M., Czibula, G. and Czibula, I.

Enriching the Semantic Representation of the Source Code with Natural Language-Based Features from Comments for Improving the Performance of Software Defect Prediction.

DOI: 10.5220/0012688400003687

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2024), pages 132-143

ISBN: 978-989-758-696-5; ISSN: 2184-4895

imbalance of the data, as the number of software de-

fects in the training data is signiﬁcantly outweighed

by the number of non-defects. Due to this imbalance,

the supervised classiﬁers are often biased to predict

the majority class (non-defects). (Zhao et al., 2019)

showed that even the deep learning (DL) models are

impacted by the imbalance of the defect datasets.

Most of the existing SDP approaches based on source

code are analysing its AST. Two main limitations of

DL models applied on the AST of the source code are

that AST tokens do not exploit comments and iden-

tiﬁers which are also relevant in expressing semantic

relations (Marcus et al., 2008) and the feature gener-

ation process is dependent on the programming lan-

guage. (hua Chang et al., 2011) highlighted the im-

portance of using quality data for training the defect

predictors and the importance of the features used for

characterizing the software entities.

From our perspective, a major challenge in the

SDP task lies in the selection of features, given the

numerous aspects of the source code that a represen-

tation must capture to effectively discern between de-

fects and non-defects. Therefore, we emphasize the

signiﬁcance of investigating potentially relevant fea-

tures that may improve upon existing representations.

Code comments and names in the source code may

contain relevant information regarding the domain of

the problem and may also highlight relations between

parts of the code that can not be easily discovered

by just analyzing traditional code dependencies (as-

sociations, aggregations, inheritance). Many of the

defects discovered in a software system are related

to non-technical aspects of the system such as: mis-

understandings related to the requirements or speci-

ﬁcation of functions, defects caused by problems in

interoperability between different components of the

system, mismatches between the semantic meaning

of certain variables. These semantic aspects of the

system are more likely captured by comments, vari-

able/function/class names in the system than software

metrics, AST or other data collected and used by the

majority of SDP approaches in the literature.

The present study belongs to the new research

in the ﬁeld of SDP that uses additional knowledge,

such as comments, with the aim of obtaining a bet-

ter semantic representation of the source code. To

evaluate the relevance of the new natural language

(NL) - based features in improving software defect

prediction, two SDP approaches are proposed. The

ﬁrst approach combines programming language (PL)

features extracted from the code using BERT-based

models pre-trained on code corpora with NL features

learned by RoBERTa (a pre-trained natural language

model) from textual information. In the second ap-

proach doc2vec is ﬁrst trained on the codes (of the

dataset) to extract a distributed semantic representa-

tion of a code from the PL token sequence and then

an NL-based representation of the textual information

of a source code is generated by a doc2vec model

trained on the comments. In the experiments per-

formed using both approaches, in a within-project

setting, on the Apache Calcite (Begoli et al., 2018)

dataset, we aim to investigate if the code comments

bring meaningful information besides the code itself.

Another goal of the study is the comparison of the per-

formance of an SDP predictor using the proposed fea-

tures with approaches based on traditional software

metrics-based features. To the best of our knowledge,

a study similar to ours has not been conducted in the

SDP literature. The research questions targeted in our

work are as follows:

RQ1. Does the fusion of the natural language fea-

tures (from code comments) and the program-

ming language features (from code), learned

using NL models (doc2vec, BERT-based), im-

prove the performance in the SDP task?

RQ2. To what extent does the use of the seman-

tic features automatically extracted from the

code and/or code comments enhance the pre-

dictive performance of defect classiﬁers com-

pared to the traditional software metrics-based

features?

The paper is structured as follows. In Section 2 we

review recent approaches, based on semantic features,

from the SDP literature. Section 3 contains the de-

scription of the methodology employed in the study.

The results of the experiments conducted on the Cal-

cite software are presented and discussed in Section

4 while Section 5 exposes the threats to the validity

of the present study. Conclusions and directions for

future research are presented in the last section.

2 RELATED WORK ON

SEMANTIC FEATURES USED

FOR SDP

Recent works from the SDP literature that use seman-

tic features to improve the software defect prediction

performance are presented.

(Abdu et al., 2022) conducted a comprehensive

study (based on 90 scientiﬁc articles) of the SDP ap-

proaches using contextual and semantic features ex-

tracted from the source code. The main aspects pre-

sented in this survey are (1) the source code semantic

representations (ASTs, graph-based representations,

Enriching the Semantic Representation of the Source Code with Natural Language-Based Features from Comments for Improving the

Performance of Software Defect Prediction

133

token embeddings), (2) the deep learning techniques

applied (LSTM, DBN, CNN, BERT-based) and (3)

the datasets (labeled and unlabeled) used in the se-

mantic feature-based SDP models. The domain’s crit-

ical problems and challenges are also described.

(Wang et al., 2016) proposed the ﬁrst model based

on semantic features using DBN (Deep Belief Net-

work). The features learned from token vectors ex-

tracted from ASTs have been compared with 20 tra-

ditional software metrics-based features in the experi-

ments conducted on ten open-source projects from the

PROMISE dataset (Jureczko and Madeyski, 2010). In

both within-project and cross-project SDP tasks, the

semantic features proved to be more relevant than the

other features. In the SDP model proposed by (Ud-

din et al., 2022) the contextual and semantic features

of the source code are extracted from the tokens’ se-

mantic embeddings learned through a BERT model

(Mohammed and Ali, 2021) and using the BiLSTM

method (Graves et al., 2005) that exploits the contex-

tual information. A data augmentation strategy has

been employed to generate a large set of Java source

codes, used further in ﬁne-tuning the BERT model.

The experiments conducted on the PROMISE dataset

demonstrated that the proposed model outperformed

both traditional SDP models and other DL models.

(Miholca et al., 2022) proved that the features which

capture the semantics of the source code are more

informative than the software metrics-based features

(Hosseini et al., 2019; Malhotra, 2015) in discriminat-

ing between defective and non-defective software en-

tities. Two natural language–based models, doc2vec

and LSI, have been used to extract contextual and se-

mantic features of the class entities of 16 versions of

the Calcite system. The DL-FASTAI model applied to

these semantic features achieved the best results com-

pared to other machine learning models (XGBoost,

SVM, ANN) and other software metrics-based fea-

tures.

Two types of features, internal and external, joined

together with different weights, are used by (Zhou

et al., 2022) to implement an SDP model. The internal

semantic features are learned from each source ﬁle,

using a CNN applied to the AST of the source code.

The external features represent the structural informa-

tion between all class ﬁles and are extracted from the

software network (Class Dependency Network) using

a GCN (Graph Convolutional Network). A large set

of experiments was performed on the seven projects

of the PROMISE dataset, in three settings: within-

version, cross-version and cross-project. All the per-

formance results expressed by AUC, F1 and accuracy

metrics were satisfactory, but the best results were

obtained for within-version prediction, using Syn-

thetic Minority Oversampling Technique (SMOTE)

and Random Forest (RF) as the classiﬁer.

(Huo et al., 2018) proposed CAP-CNN (Convo-

lutional Neural Network for Comments Augmented

Programs) aiming to obtain a more informative se-

mantic representation of code structure and function-

ality using also the comments. Semantic code fea-

tures extracted by a CNN are concatenated with fea-

tures extracted from code comments using another

CNN and further used in defect prediction. To deal

with cases of missing comments, the embeddings of

tokens in the comments are learned during the training

process. The experiments on the PROMISE dataset

indicated that this model outperforms state-of-the-art

methods and proved that the use of comments is ben-

eﬁcial in improving defect prediction. The semantic

representation of a source code introduced by (Yao

et al., 2023), is based on two types of features ex-

tracted from the code processed as a programming

language entity and as a natural language text, respec-

tively. The code syntax features were learned from

ASTs using a Tree-based CNN method, and the code

text features were extracted using an attention mech-

anism from the code token sequence after removing

comments and function descriptions. The proposed

program semantic feature mining method evaluated

on the PROMISE dataset proved to outperform other

DL-based SDP models in terms of F-measure.

Recently, the PM2-CNN (Pretrained Model-

Based Multi-Channel Convolutional Neural Network)

model was introduced by (Liu et al., 2023). Using

UniXcoder (uniﬁed cross-modal pre-trained model

for PL), the semantic PL features of the code and the

NL features of the code description text are extracted

simultaneously and then a multi-channel CNN pro-

cesses both types of features to obtain rich semantic

information, used further in defect prediction. The ef-

fectiveness of the model has been veriﬁed on Big-Vul,

a large C/C++ dataset in the ﬁeld of code vulnerabil-

ities. Compared to four deep learning SDP methods,

which do not use external textual information of the

codes, PM2-CNN achieved better performance results

in terms of precision, recall, and F1-score.

The present approach comes in the context of

trying to improve the software defect prediction us-

ing additional textual information, such as comments.

The novelty of our approach lies in the fusion of pro-

gramming language features (from code) and natural

language features (from code comments), learned us-

ing NL models (doc2vec or BERT-based) to obtain an

enriched semantic representation of a source code.

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

134

3 METHODOLOGY

This section presents the methodology employed in

the present study. We begin by describing the case

study used in the paper, then the theoretical model

for the SDP task is proposed. In Section 3.2 the

feature-based representations used for the source code

of application classes are introduced. In the next sec-

tion the proposed SDP classiﬁer and the experimental

methodology are described.

The open-source framework for data manage-

ment, Apache Calcite (Begoli et al., 2018), is the soft-

ware system used in our study. Apache Calcite is an

active open-source project, written in Java, with 330

contributors. The release cadence of the project on

Maven Central is averaging 4 releases per year (be-

tween the years 2014 and 2023). Even if the project is

continuously evolving, in this paper we are consider-

ing the ﬁrst 16 Calcite releases, as presented by (Her-

bold et al., 2022). During releases 1.0.0-1.15.0, a total

number of 1644 application classes were developed

and maintained. For all application classes from each

release from 1.0.0 to 1.15.0 of the Calcite software the

ground truth label (“+” or “-” ) is available, as intro-

duced by (Herbold et al., 2022). The label indicates

the defective (“+”) or non-defective (“-“) property of

an application class in that particular release. A severe

data imbalance is observed in the dataset, the defec-

tive rate decreasing from 0.166 in the ﬁrst release (178

defects and 897 non-defects) to 0.033 (45 defects and

1307 non-defects) in release 1.15.0. This dataset was

also used by (Miholca et al., 2022), (Ciubotariu et al.,

2023), (Briciu et al., 2023).

3.1 Theoretical Model

The SDP task is modeled as a binary classiﬁcation

problem, with two output classes: the positive class

(denoted by “+”) containing the software defects and

the negative class (denoted by “-”) containing non-

defects.

The dataset, an object-oriented software system,

is represented by S = {(ac

, l

), . . . , (ac

, l

)}, con-

sisting of all the software application classes and the

corresponding ground truth labels (“+” or “-”). In

the present approach we consider two types of fea-

tures: PL features learned from the code of the ap-

plication class, F

P L

= {f pl

, . . . , f pl

} and NL fea-

tures extracted from the comments attached to the ap-

plication class, F

N L

= {f nl

, . . . , f nl

}. Two sets of

features F

P L

and F

P L

∪F

N L

are extracted and used

separately to represent the application classes as high-

dimensional vectors.

The SDP classiﬁer is built from a labeled training

dataset, using a feature-based representation of the

application classes and predicts a label (“+” or “-”)

for a tested class.

3.2 Data Representations

For extracting semantic features characterizing the

application classes and thus answering research ques-

tion RQ1 we are considering embeddings obtained

separately for both: (1) the code itself and (2) the

code comments, concatenating the resulting represen-

tations to be used as input (referred in the following

as code+comments). We hypothesise that the com-

ments (represented by NL-based features), besides the

code itself (represented by PL-based features), bring

additional semantic information which would help in-

crease the performance in the SDP task.

To achieve this, the code is separated from the

comments using the pyparsing

module, and differ-

ent processing pipelines are deﬁned for each, depend-

ing on the embedding model. We note that the com-

ments considered in our work are both implementa-

tion comments (delimited in the code by /* . . . */ and

//) and documentation comments which are Java-only,

and are delimited by /**. . . */.

Two types of embedding models are considered

for the representation of the application classes, for

both the code and the comments attached. First,

we consider the semantic representations provided by

a doc2vec model trained on the considered dataset

(either on the PL or the NL content). The rel-

evance of these features in an SDP task is com-

pared to that of representations obtained using pre-

trained BERT-based models, speciﬁcally CodeBERT-

and RoBERTa-based ones. The decision to select

these models was based on prior research demonstrat-

ing their suitability for the SDP task (Miholca et al.,

2022), (Briciu et al., 2023), with the current work

aiming to expand upon previous investigations by ad-

ditionally examining the role of comments in differ-

entiating between defect and non-defect classes.

In terms of data pre-processing, in order to ob-

tain the doc2vec representations, a code tokenizer

is used to obtain the code tokens, while for the com-

ments written in natural language, we used the nltk

library

for tokenization. As far as code is concerned,

the tokenizer identiﬁed whitespace and end-of-ﬁle as

separate tokens, but these were eliminated as we con-

sidered that given the strategy employed by doc2vec

in learning, including them may hinder the model’s

ability to learn meaningful document representations.

https://pypi.org/project/pyparsing/

https://github.com/Ikuyadeu/CodeTokenizer

https://www.nltk.org/

Enriching the Semantic Representation of the Source Code with Natural Language-Based Features from Comments for Improving the

Performance of Software Defect Prediction

135

For comments, no additional pre-processing was em-

ployed.

As for the BERT-based representations, the de-

fault model tokenizer, based on a Byte-Pair-Encoding

algorithm, was used. The maximum length of a se-

quence is set to 512, which represents the upper limit

of the model, to include as much information as pos-

sible from the input ﬁles, and truncation and padding

are applied to the input code or comment instances to

account for their varying lengths.

3.2.1 doc2vec-Based Representations

The Paragraph Vector model, or doc2vec, is an un-

supervised learning algorithm that learns continuous,

distributed ﬁxed-length representations, called em-

beddings, for texts of varying lengths, such as sen-

tences, paragraphs, or documents (Le and Mikolov,

2014). These representations are obtained by extend-

ing the neural network-based framework deﬁned for

the word2vec model to include a paragraph vector. In

the Distributed Memory Model of Paragraph Vector

(PV-DM), the paragraph vector and the word vectors

are combined by either concatenation or averaging

and asked to contribute to the task of predicting the

next word in a text window. It is important to note that

the PV-DM model takes into account word order and

preserves the semantic relationships between words in

the vector space. In contrast, the Distributed Bag-of-

Words version of Paragraph Vector (PV-DBOW) only

uses the paragraph vector to predict randomly sam-

pled words from a text window within that paragraph.

Doc2vec has been successfully used in the task

of SDP (Miholca et al., 2022; Aladics et al., 2021),

either on its own or in conjunction with other repre-

sentations. In our experiments, we separately trained

doc2vec models on both the PL and NL content, re-

spectively, within the application class, using the gen-

sim

library. For the training step, we varied the

Paragraph Vector model used (PV-DM or PV-DBOW)

and the size of the resulting vector representation (50,

100, 150 or 300). The training of the doc2vec model

is done only on the training set, and the vector repre-

sentations (embeddings) for the instances in the val-

idation and test sets (as deﬁned in Section 3.3) are

obtained through inference.

3.2.2 BERT-Based Representations

In the case of BERT-based semantic representations,

we consider three pre-trained models to extract rep-

resentations for code: CodeBERT-base-MLM (Feng

https://radimrehurek.com/gensim/models/doc2vec.

html

et al., 2020), CodeBERTa

and CodeBERT-Java

(Zhou et al., 2023). The ﬁrst of these, CodeBERT-

base-MLM, is initialized from a RoBERTa-base

model and further trained on the CodeSearchNet code

corpus with a MLM (Masked Language Modeling)

objective. CodeBERTa, speciﬁcally CodeBERTa-

small-v1, is another RoBERTa-like model, but with

the architecture of DistilBERT. This model is also

trained on the full CodeSearchNet corpus. Lastly,

CodeBERT-Java builds upon the CodeBERT-base-

MLM model, being additionally trained on Java code

from the CodeParrot Github dataset on a MLM task.

The choice of the models was driven by a compari-

son between the relevance of features obtained using

CodeBERT-base-MLM, a model that has been used

in a similar setting, and a model based on a differ-

ent transformer architecture (CodeBERTa-small-v1)

and one which was additionally trained on Java code

(CodeBERT-Java).

To obtain semantic representations of natural lan-

guage comments, we employed RoBERTa-base (Liu

et al., 2019), a model that improves upon the original

BERT model by using a dynamic masked language

modeling training strategy and larger volumes of text.

The procedure for extracting the semantic rep-

resentations (embeddings) using these BERT-based

models does not depend on the type of input (i.e. code

or natural language text in the form of speciﬁcations

and comments). After completing the pre-processing

steps outlined in Section 3.2, the tokenized program-

ming language code or natural language text serves

as input for a pre-trained model. A 768-dimensional

representation corresponding to the entire input doc-

ument is derived by applying a mean pooling tech-

nique to the 512 embeddings (for the tokens in the in-

put) obtained from the last hidden state of the model.

By opting for feature extraction instead of ﬁne-tuning

with BERT models, we can directly assess and com-

pare the discriminatory power of the two types of rep-

resentations, as they will both serve as input for the

same SDP classiﬁer.

3.3 SDP Classiﬁer

The machine learning model we decided to use for

the SDP task is the eXtreme gradient boosting (XGB)

classiﬁer, as it provides good performance in a wide

range of tasks (Chen and Guestrin, 2016). The XG-

Boost classiﬁer will be trained on the semantic rep-

resentations of the application classes from the train-

ing data. In order to evaluate the practical capabil-

ities of the SDP classiﬁer, we use the application

https://huggingface.co/huggingface/

CodeBERTa-small-v1

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

136

classes (code or code+comments) from versions 0..14

for training the SDP classiﬁer, followed by testing on

version 15. In addition, the data from versions 0..14 is

divided randomly in 80% for training the model and

the remaining 20% for validation, a subset which is

used for hyper-parameter optimization.

For assessing the performance of XGB on Calcite

version 1.15.0, we are calculating several evaluation

metrics used in forecasting (Mazzarella et al., 2017)

and SDP literature (Fawcett, 2006), (Boughorbel

et al., 2017): probability of detection (POD), speci-

ﬁcity (Spec or true negative rate), false alarm ratio

(FAR), critical success index (CSI), Area under the

ROC curve (AUC), Matthews Correlation Coefﬁcient

(MCC) and F-score for the positive class (F1). The

classiﬁcation results expressed by the following

values: T P - number of true positives (the defects

correctly classiﬁed), FP - number of false positives

(the non-defects incorrectly predicted as defects), T N

- number of true negatives (the non-defects classiﬁed

correctly), FN - number of false negatives (the defects

incorrectly classiﬁed as non-defects) are computed on

the testing set. Then, the metrics values are calculated

using the formulas: POD =

T P

T P+FN

, Spec =

T N

T N+FP

FAR =

T P+FP

, CSI =

T P

T P+FN+FP

, AUC =

POD+Spec

MCC =

T P·T N−FP·FN

√

(T P+FP)·(T P+FN)·(T N+F P)·(T N+FN)

, and

F1 =

2·T P

2·T P+FP+FN

. The MCC metric ranges in [-1, 1]

while the other measures take values in [0, 1]. Lower

values for FAR indicate better predictors, while for

the other metrics higher values are better. We note

that AUC is considered in the SDP literature one of

the best metrics for evaluating the performance of the

defect classiﬁers (Fawcett, 2006).

4 RESULTS AND DISCUSSION

This section presents the results of our experiments

aimed to answer the research questions RQ1 and

RQ2.

4.1 Results

As previously discussed, our experiments consist of

training the XGB classiﬁer (described in Section 3.3)

on the Calcite versions from 1.0.0 to 1.14.0 and after-

wards evaluating its performance on release 1.15.0.

Through the proposed evaluation we aim to simulate

a real life scenario where an existing project is fur-

ther developed and all the existing historical data in

the project is used to improve the next release of the

software through the use of SDP tools.

Multiple experiments were performed using both

doc2vec and BERT-based semantic representations,

varying the representation size and PV model

(doc2vec) and the side from which the input is trun-

cated when it is longer than the maximum length

of the sequence (BERT-based representations). The

best results obtained throughout these experiments,

using the representations detailed in Section 3.2

and applied on the two possible inputs (code and

code+comments) are illustrated in Tables 1 and 2.

For each experiment conducted, the obtained classi-

ﬁcation results are presented, together with the values

for the performance metrics used for evaluation. The

best value is highlighted for each speciﬁc model and

each performance metric.

To answer the research question RQ1 we intro-

duce an evaluation measure, denoted by score. The

score is computed for each of the two represen-

tations r employed in the experiments: the repre-

sentation learned using doc2vec-based models (r =

doc2vec) and the representation learned using BERT-

based models (r = BERT). For such a representa-

tion r, considering all the performed experiments (de-

picted in Table 1 for r = doc2vec and in Table 2

for r = BERT), we deﬁne score(r) =

n(r)

. In the

previous formula, 21 is the total number of cases

(i.e., seven performance metrics for each of the three

performed experiments) and n(r) is the number of

performance metrics whose values are better for the

code+comments input than for the code input. Thus,

score(r) represents the percentage of the cases that

show an improvement of the SDP performance when

fusing the semantic features extracted from code with

those extracted from code comments, compared to the

semantic features extracted solely from the code.

Table 3 presents the values of score for both the

doc2vec and BERT-based representations. The pos-

itive values obtained for the score highlight that the

addition of the comments embedding to the code em-

bedding is beneﬁcial in SDP.

For a wider perspective, we can consider all the

performed experiments, which involved, for BERT,

experimenting with a left-side truncation besides the

default right-side one, and for doc2vec, examining

various combinations of models and representation

sizes (as detailed in Section 3.2.1). Table 4 shows the

values obtained for each evaluation metric when aver-

aged over all performed experiments together with the

95% conﬁdence interval of the mean values. As can

be observed, the inclusion of information found in NL

comments alongside the code encoding yields bene-

ﬁts, enhancing the overall performance of the models.

Among the 14 comparisons made, the conﬁguration

that incorporates both code and comments as input

wins in 11 instances, constituting 79% of the cases.

Enriching the Semantic Representation of the Source Code with Natural Language-Based Features from Comments for Improving the

Performance of Software Defect Prediction

137

Table 1: Experimental results obtained using doc2vec-based models for generating code and comments embeddings. The

classiﬁcation results calculated on Calcite 1.15.0 and the performance metrics values are presented.

Experiment Model Input Embedding TP FP TN FN POD (↑) Spec (↑) FAR (↓) CSI (↑) AUC (↑) MCC (↑) F1 (↑)

length

1 PV-DBOW code 50 35 24 1283 10 0.778 0.982 0.407 0.507 0.880 0.667 0.673

code+comments 50+50 33 30 1277 12 0.733 0.977 0.476 0.440 0.855 0.605 0.611

2 PV-DM code 150 34 41 1266 11 0.756 0.969 0.547 0.395 0.862 0.568 0.567

code+comments 150+100 34 31 1276 11 0.756 0.976 0.477 0.447 0.866 0.614 0.618

3 PV-DM code 300 32 35 1272 13 0.711 0.973 0.522 0.400 0.842 0.566 0.571

code+comments 300+100 34 30 1277 11 0.756 0.977 0.469 0.453 0.866 0.619 0.624

Table 2: Experimental results obtained using BERT-based models for learning code and comments embeddings. The classiﬁ-

cation results calculated on Calcite 1.15.0 and the performance metrics values are presented.

Experiment Model Input TP FP TN FN POD (↑) Spec (↑) FAR (↓) CSI (↑) AUC (↑) MCC (↑) F1 (↑)

1 CodeBERT-MLM code 35 26 1281 10 0.778 0.980 0.426 0.493 0.879 0.655 0.660

CodeBERT-MLM + RoBERTa code+comments 35 33 1274 10 0.778 0.975 0.485 0.449 0.876 0.618 0.619

2 CodeBERT-Java code 34 27 1280 11 0.756 0.979 0.443 0.472 0.867 0.635 0.642

CodeBERT-Java + RoBERTa code+comments 37 28 1279 8 0.822 0.979 0.431 0.507 0.900 0.671 0.673

3 CodeBERTa-small code 36 21 1286 9 0.800 0.984 0.368 0.545 0.892 0.700 0.706

CodeBERTa-small + RoBERTa code+comments 36 21 1286 9 0.800 0.984 0.368 0.545 0.892 0.700 0.706

Table 3: Values obtained for the score measure and the

doc2vec and BERT-based representations employed.

Representation score

doc2vec-based 0.62

BERT-based 0.29

Thus, overall, the values of the performance metrics

are better for PL+NL feature representation than us-

ing only PL features.

In terms of a comparison between the two types

of embeddings, the BERT-based representations yield

consistently better results than the doc2vec embed-

dings, despite the fact that in the tokenization process,

these models reduce all input sequences to a length

of 512. This result underlines the importance of the

information encoded in the pre-training step of the

BERT-based models using large source code datasets.

For doc2vec, the best results are obtained when

considering only the code as input, with a represen-

tation of size 50 obtained using the PV-DBOW archi-

tecture. Since the PV-DBOW model does not account

for word order, using only the paragraph vector to

predict words in a text window, it captures document-

level semantics more than it does local context, which

proves useful in separating defects and non-defects.

However, in our experiments, we observed that as

the size of the representation obtained with the PV-

DBOW model increases, its ability to identify de-

fects decreases (for size of 100 or 150, for instance,

a POD value of 0.622 is obtained, while for size 300,

the POD value decreases further, to 0.600). In con-

trast, the Speci f icity steadily increases with repre-

sentation size. An explanation for this could refer

to the substantial imbalance in the number of non-

defective instances relative to defective ones: the in-

creased size of representation allows for more com-

prehensive coverage of diverse document-level pat-

terns indicative of a non-defect. For PV-DM, which

also encodes word-order information, a size of 150

provides the best results in terms of the POD met-

ric (0.756), but similarly to the PV-DBOW model, in-

creasing the size of the representation aids in the iden-

tiﬁcation of non-defects, as shown by the increased

value for Speci f icity for a representation size of 300.

Concatenating the representations obtained for

code and those obtained for the comments included in

the ﬁles alongside it leads to better results if the code

representation does not manage to capture sufﬁcient

relevant information to discriminate between defects

and non-defects on its own, as highlighted by the re-

sults in Tables 1 and 2. For comments, the results in-

dicate that a representation size of 100 is best, manag-

ing to improve upon different source code representa-

tions in multiple testing conﬁgurations, especially as

far as the identiﬁcation of non-defects is concerned.

The improvement brought by adding information

encoded in the comment embeddings is less evident in

the case of BERT-based representations. This could

be attributed to the operation of truncation to 512 to-

kens of the natural language input sequence applied

by RoBERTa, similar to the truncation of the pro-

gramming language code. In terms of a compari-

son across these models, the CodeBERT-Java model

for code embeddings in conjunction with natural lan-

guage text embeddings obtained using RoBERTa-

base provides the best result for the AUC metric (0.9).

When employing doc2vec, a ﬁrst challenge lies in

determining the optimal representation size that effec-

tively captures relevant patterns from both code and

natural language comments, respectively. Addition-

ally, identifying the combination that yields the most

favorable results adds further complexity, as the num-

ber of experiments to be performed for an exhaustive

search is quite large. Secondly, the inference step in

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

138

Table 4: Average obtained over all performed experiments for the evaluation metrics for the two types of input and the two

embedding models. 95% conﬁdence intervals are used for the results.

Representation Input POD (↑) Spec (↑) FAR (↓) CSI (↑) AUC (↑) MCC (↑) F 1 (↑)

doc2vec

code 0.664±0.050 0.980±0.005 0.461±0.045 0.420±0.029 0.822±0.024 0.580±0.033 0.589±0.033

code+comments 0.706±0.022 0.979±0.002 0.459±0.027 0.440±0.019 0.843±0.011 0.602±0.018 0.610±0.018

BERT-based

code 0.715±0.063 0.983±0.002 0.407±0.023 0.479±0.035 0.849±0.031 0.637±0.034 0.646±0.032

code+comments 0.733±0.033 0.982±0.002 0.415±0.029 0.482±0.026 0.858±0.016 0.641±0.025 0.649±0.024

the doc2vec model is not inherently deterministic,

yielding similar but not identical representations for

the same input. This may pose a problem in the cur-

rent testing conﬁguration, as the content of some ﬁles

across the versions does not change, but their encod-

ing does, even if marginally.

A limitation of the proposed BERT-based repre-

sentations refers to the truncation performed in the

tokenization step of these models, which limits the

number of tokens to 512. Therefore, modiﬁcations in

the code may not be taken into consideration across

versions if the modiﬁcation is in the part of the

code that is truncated. Possible solutions to this is-

sue refer to either the use of other transformer-based

models that are better able to handle long input se-

quences (Beltagy et al., 2020) or the examination of

other types of features in conjunction with the cur-

rent doc2vec and BERT-based representations, strat-

egy which has proved winning in previous works that

address the SDP task (Miholca et al., 2022).

4.2 Discussion

While we acknowledge that limitations in the pro-

posed approach may be one reason for misclassiﬁed

instances, this section aims to analyze these instances

to illustrate other potential causes for misclassiﬁca-

tion. We further present some concrete examples

from the analysed project, that are not sufﬁcient in

isolation to conclude that the performance of our pro-

posed method would be higher, but are an indication

that any SDP approach should also consider the re-

ality of the considered software project and details

about the actual source code in order to better under-

stand the larger context of the changes made in the

project. The dataset (Herbold et al., 2022) used for

the case study provides labels for Apache Calcite up

to version 1.1.15 but the project is in a continuous de-

velopment, so we analysed the changes made to the

source code after this release.

For better understanding the misclassiﬁcations

provided by our XGB classiﬁer we analyzed both the

source code and the commit messages from Git for

the application classes that were incorrectly classi-

ﬁed. We mention that the analysis was performed

on the best performing model, namely XGB trained

on embeddings for the applications classes automat-

ically learned using CodeBERT-Java from the code

concatenated with the comments embedding gener-

ated through RoBERTa.

We investigated the application classes from Cal-

cite 1.15.0 that were classiﬁed as defective but were

labeled non-defective in the original dataset (Herbold

et al., 2022) and we noticed that multiple changes

were performed in the source code after the release

of the version 1.15.0. Commit messages were not

part of the data used for training the models, but we

analyzed them in other to get a better understanding

of the changes performed on the misclassiﬁed classes.

While some of the commits are clearly not related

to bug ﬁxes (i.e., the commit message starts with

expressions like: “Refactor:”,“Code style:”,“Update

formatting:” some commit messages clearly indicate

that the commit is related to a code change that is a

ﬁx for a defect. For example, the commit with the

ID ccbacf6 and the commit message “RelDataType

CACHE in RelDataTypeFactoryImpl can’t

be garbage collected” seems to ﬁx a mem-

ory leak issue. Our classiﬁer predicted the class

RelDataTypeFactoryImpl as being defective, even

if the class was labeled as being non-defective. Thus,

it is very likely that the classiﬁcation is correct, as

the code that is changed in this particular commit

predates version 1.15.0 and this indicates that the

class actually contained a defect but it was undetected

at the time the labels were generated.

Analysing the commit messages for the class

org.apache.calcite.rex.RexSimplify that

was predicted as non-defective by our approach

but labeled as defective in the dataset, we found

contradicting information in the commit messages.

For instance, we found the following three commit

messages: (1) Message in commit 141781b: “Avoid

simplification of x AND NOT(x) to false

for nullable x”; (2) Message in commit c8e91ea:

“RexSimplify: AND(x, y, NOT(y)) ⇒ AND(x,

null, IS NULL(y))”; and (3) Message in commit

90f49be:“RexSimplify should optimize ’(NOT

x) IS NULL’ to ’x IS NULL’ (pengzhiwei).

Previously it optimized ’(NOT x) IS NULL’

to ’x IS NOT NULL’, which is wrong.”. All

three previous commits change only the method

simplifyIs2(SqlKind kind, RexNode a) in

the class RexSimplify and the messages suggest

Enriching the Semantic Representation of the Source Code with Natural Language-Based Features from Comments for Improving the

Performance of Software Defect Prediction

139

that there is not a clear understanding on what

the speciﬁcation and requirements for this method

should be. Thus, it is unclear if the application

org.apache.calcite.rex.RexSimplify is indeed

a misclassiﬁcation (i.e., if the defective label assigned

to this class in Calcite 1.15.0 is correct).

4.3 Comparison to Related Work

To answer the research question RQ2, we are fur-

ther providing a comparison with approaches from

the literature which performed within-project SDP on

the Calcite software using software metrics or/and

semantic features for representing the application

classes.

Three related approaches from the literature will

be further considered. The ﬁrst related approach is

the one introduced by (Ciubotariu et al., 2023). The

authors adapted the support vector classiﬁer model to

an one-class classiﬁcation model (OCSVM) to per-

form outlier detection. Experiments were conducted

on Apache Calcite (Begoli et al., 2018), by training

the OCSVM model on both the “+” (defective) and

“-” (non-defective) classes. The performance of the

OCSVM models was compared with the performance

of the binary SVC model. As in our experiments, the

models were trained on all Calcite releases from 1.0.0

to 1.14.0 and tested on the 1.15.0-th release, thus al-

lowing a direct comparison between the results. We

note that we computed the values for the MCC metric

from the confusion matrices provided in (Ciubotariu

et al., 2023). The second related approach is the one

introduced by (Miholca et al., 2022). The relevance of

both semantic features extracted from the code of the

application classes using doc2vec and LSI language

models and software metrics-based features (Herbold

et al., 2022) is comparatively analyzed. The exper-

imental evaluation is conducted on the available re-

leases of the Calcite software. The testing methodol-

ogy slightly differs from ours, as a cross-validation

(CV) is performed on each Calcite release. For a

more precise comparison, we will use the result pro-

vided by (Miholca et al., 2022) after applying a 5-

fold CV on Calcite version 1.15.0. Another related

work considered in our comparison was introduced

by (Briciu et al., 2023). Experiments were conducted

on the Calcite software using the same training and

testing methodology as in the current paper (the ﬁrst

15 releases were used for training, while testing was

performed on release 1.15.0). The application classes

from the Calcite software represented as embeddings

learned from the source code using the CodeBERT-

base-MLM model were used for training an artiﬁcial

neural network (ANN) classiﬁer.

Table 5 comparatively presents the results ob-

tained in our approach and the results achieved by the

previously described approaches. The table depicts

the SDP classiﬁer (ML model) employed, the features

employed for representing the application classes and

the evaluation measures used. Most of the perfor-

mance metrics employed in our paper were employed

in the related approaches as well. We will mark in

the table with “–” the cells corresponding to perfor-

mance metrics for which the values were not reported

in the related work. We note that we are considering

for comparison our best performance (as shown in Ta-

ble 2, the fourth row) provided by the XGB classiﬁer

with embeddings for the application classes automat-

ically learned using CodeBERT-Java from the code

concatenated with the comments embedding gener-

ated through RoBERTa.

A comparative analysis of the results depicted in

Table 5 reveal the following. As a ﬁrst conclusion, our

proposed semantic representation of the application

classes, obtained from the embedding learned using

CodeBERT-Java from the code combined with com-

ments embedding generated with RoBERTa, leads to

a higher performance than the semantic representa-

tion using doc2vec+LSI proposed by (Miholca et al.,

2022) in terms of all evaluation metrics. The XG-

Boost classiﬁer has a sligthly higher speciﬁcity than

our model (0.993 vs. 0.979), but it has a very low

POD (0.166 vs. 0.822). An improvement of more

than 40% is observed in the recall of our classi-

ﬁer (POD) highlighting a better defect detection rate.

In addition, the MCC metric which is considered

in the literature a good evaluation metric for imbal-

anced datasets is also improved with more than 37%.

With respect to the BERT-based representation used

in (Briciu et al., 2023), which encodes only code in-

formation, the fusion of comments and code embed-

dings provides superior results in all metrics with the

exception of POD. This can be explained by the

ANN classiﬁer in the study employing class weights

and thus assigning higher importance to the correct

classiﬁcation of defective instances, leading to a high

POD, but low MCC, CSI, and F1 values. Our pro-

posed representation, in conjunction with an XGB

classiﬁer, leads to signiﬁcantly higher scores in terms

of the latter metrics, while still obtaining compara-

ble results with respect to POD. The statistical sig-

niﬁcance of the improvement in terms of the POD,

Spec, FAR, AUC, MCC and F1 metrics was con-

ﬁrmed using a one-tailed paired Wilcoxon signed-

rank test (Wilcoxon Signed-Rank Test, 2023).

The second conclusion of the conducted compari-

son to related work is the answer to the research ques-

tion RQ2. We observe that the fusion of PL features

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

140

Table 5: Comparison to related work.

Model Features / Model POD (↑) Spec (↑) FAR (↓) CSI (↑) AUC (↑) MCC(↑) F 1 (↑)

OCSVM

(Ciubotariu et al., 2023) Software metrics 0.644 0.523 0.956 0.043 0.584 0.060 0.083

OCSVM

−

(Ciubotariu et al., 2023) Software metrics 0.711 0.533 0.950 0.049 0.622 0.088 0.093

SVC (Ciubotariu et al., 2023) Software metrics 0.711 0.963 0.600 0.344 0.837 0.514 0.512

DL-FASTAI (Miholca et al., 2022) Software metrics 0.245 0.979 0.613 – 0.612 0.272 0.276

XGBoost (Miholca et al., 2022) Software metrics 0.166 0.993 0.443 – 0.580 0.279 0.242

DL-FASTAI (Miholca et al., 2022)

Semantic features /

doc2vec+LSI 0.390 0.961 0.726 – 0.675 0.291 0.308

ANN (Briciu et al., 2023)

Semantic features /

CodeBERT-base-MLM 0.899 0.884 0.792 0.203 0.886 0.397 0.338

Proposed XGB classiﬁer Semantic features / 0.822 0.979 0.431 0.507 0.900 0.671 0.673

CodeBERT-Java + RoBERTa

extracted from the code and the NL features from

comments improves the performance of software de-

fect predictors compared to the feature-based repre-

sentation using software metrics. The SDP classiﬁer

considering embeddings learned using CodeBERT-

Java from the code and RoBERTa from the com-

ments (the last line from the table) outperforms the

other classiﬁers (lines 1-5 from the table) that use

software metrics-based representation of the applica-

tion classes. The binary SVC classiﬁer proposed by

(Ciubotariu et al., 2023) has the closest AUC value

(0.837 vs. 0.900), but has a worse FAR (0.600 vs.

0.431) suggesting a high rate of false positive results.

5 THREATS TO VALIDITY

The threats to the validity of our study and biases

that may impact it are further discussed (Runeson and

ost, 2009). Regarding construct validity, we have

employed relevant performance metrics for evaluating

the performance of the defect classiﬁer. Best practices

in building, testing and evaluating the learning models

were used for reducing the threats to construct valid-

ity: model validation during training, a testing sce-

nario which simulates the software evolution process,

statistical analysis of the obtained results.

Threats to internal validity were minimized

by exploring several models for each of the two

distinct techniques to obtain the embeddings and

examining different sets of parameters for ﬁne-tuning

the classiﬁcation model. In what concerns the

source code embeddings we observed that, in rare

cases, the source code embeddings employed do

not capture the change made to the source code

which may have a small negative impact on the

accuracy of the proposed approach. We analyzed

the change history for classes whose labels were

changed between releases (e.g., a class that was not

defective in a release and labeled as defective in

a new release or labeled defective in a release and

labeled non-defective in the new release where the

defect was ﬁxed). In some cases (e.g. the class

org.apache.calcite.sql.type.SqlTypeUtil),

the cosine distance between the two embedddings

(the one generated using the source code before

and after the modiﬁcation) is 0 indicating that no

semantic difference between the two versions was

identiﬁed by the models used for generating text

embeddings (BERT, doc2vec). There can be many

reasons for this, and further investigations are needed,

but it’s clear that other truncation and padding mech-

anisms need to be explored when pre-processing the

inputs for the embedding model to guarantee that no

important information is lost at this step.

In terms of external validity we have used as a case

study in our work the open-source software Apache

Calcite that is representative for a well-maintained,

active, open-source project. An analysis of the change

history for every application class in the Calcite re-

leases 1.0.0 - 1.15.0 revealed some special cases that

increased the difﬁculty of the software defect classi-

ﬁcation task, where an application class changed its

label in the dataset (i.e., it was marked as defect in

one version and as non-defect in another version) but

without any change in the source code of the applica-

tion class. Such cases may be due to mislabeling in

the dataset, but most likely are caused by the nature

of the evolution of any software system. For instance,

some defects may not be discovered immediately and

will be reported in future software releases. From a

supervised classiﬁcation viewpoint, such cases intro-

duce noise during training, since an application class

with exactly the same vectorial representation appears

with two different labels in the dataset and may im-

pact the model’s performance. However, in the cur-

rent work we did not remove these occurrences from

the training dataset.

The dataset used in the experimental evaluation

(Herbold et al., 2022) only covers releases between

1.0.0 and 1.15.0 but the Apache Calcite project con-

tinuously evolved and new releases are available. As

a future work we plan to extend the dataset with labels

Enriching the Semantic Representation of the Source Code with Natural Language-Based Features from Comments for Improving the

Performance of Software Defect Prediction

141

for the releases not covered by the public dataset and

further validate the results obtained by the presented

approach. To facilitate repeatability of the experi-

ments presented in this paper, we provided in Section

3 sufﬁcient details about the models employed and the

experiments performed. Additionally, the text embed-

ding vectors for both doc2vec and BERT-based repre-

sentations are publicly available at (Briciu, A, 2024).

In what concerns the reliability and the testing

methodology we created the experimental validation

taking into account the actual evolution of the ana-

lyzed system. The model was created using the data

available in 15 versions, from 1.0.0 to 1.14.0 and then

was tested on the version 1.15.0. The performance of

the model is assessed using multiple evaluation met-

rics and the statistical signiﬁcance of the obtained re-

sults was analysed in order to increase conﬁdence in

the obtained results.

6 CONCLUSIONS AND FUTURE

WORK

The aim of the present study was to analyze the rel-

evance of the textual information of a code, such as

comments, in increasing the SDP performance. To

extract the semantic representation of a source code,

two approaches were proposed. In the ﬁrst approach,

the pre-trained models CodeBERT and RoBERTa

have been used for code embedding and textual em-

bedding of the comments. In the second method a

doc2vec model, trained on the codes, generates the

semantic representation of a programming language

code and then a doc2vec model trained on the com-

ments generates the semantic representation of the

textual information attached to the code. The con-

clusion drawn from the performed experiments, using

both feature extraction methods, is that the addition of

the NL-based features to the PL-based features has a

positive impact in defect prediction. Also, these new

types of semantic features proved to be more informa-

tive than the software metrics-based features.

However, different development methodologies

and principles may impact the amount and quality

of textual information in the source code. Even in

methodologies that favor self-explanatory code in-

stead of the use of comments (i.e., clean code prin-

ciples), semantic textual information is still present

in the code in form of variables, function names and

speciﬁcations (usually embedded in the source code

as comments). More work needs to be done in order

to asses the impact of programming methodologies on

the proposed approach, but semantic textual informa-

tion needs to be present in any code base as long as

the code is written to be understandable not only by

the computer but also by other programmers. If not

constantly maintained, code comments and speciﬁca-

tions may become obsolete, misleading, or decoupled

from the actual problem domain. Further experimen-

tation is needed to assess the impact of the quality of

comments and speciﬁcations on the performance of

the proposed approach.

The evaluation experiments will be extended to

the new versions of the Calcite system and for the

cross-project setting. A future work direction is to

identify an appropriate weighting scheme for combin-

ing PL-based and NL-based features to obtain a rele-

vant semantic representation that better discriminates

between defective and non-defective codes. The re-

ﬁnement of the binary classiﬁcation in more types of

defects, using unsupervised approaches and different

types of features is another topic of further research.

REFERENCES

Abdu, A., Zhai, Z., Algabri, R., Abdo, H., Hamad, K., and

Al-antari, M. (2022). Deep learning-based software

defect prediction via semantic key features of source

code—systematic survey. Mathematics, 10.

Aladics, T., J

asz, J., and Ferenc, R. (2021). Bug prediction

using source code embedding based on doc2vec. In

International Conference on Computational Science

and Its Applications, pages 382–397. Springer.

Begoli, E., Camacho-Rodr

ıguez, J., Hyde, J., Mior, M. J.,

and Lemire, D. (2018). Apache calcite: A founda-

tional framework for optimized query processing over

heterogeneous data sources. In Proceedings of SIG-

MOD ’18, page 221–230, New York, NY, USA. ACM.

Beltagy, I., Peters, M. E., and Cohan, A. (2020). Long-

former: The long-document transformer.

Boughorbel, S., Jarray, F., and El-Anbari, M. (2017). Opti-

mal classiﬁer for imbalanced data using matthews cor-

relation coefﬁcient metric. PloS one, 12(6).

Briciu, A., Czibula, G., and Lupea, M. (2023). A study

on the relevance of semantic features extracted us-

ing BERT-based language models for enhancing the

performance of software defect classiﬁers. Procedia

Computer Science, 225:1601–1610.

Briciu, A (2024). BERT-based and doc2vec repre-

sentations. https://github.com/anamariabriciu/

sdp-calcite-doc2vec-bert. Online; accessed 10 March

2024.

Chen, T. and Guestrin, C. (2016). XGBoost: A scalable tree

boosting system. In Proceedings of KDD ’16, pages

785–794, New York, NY, USA. ACM.

Ciubotariu, G., Czibula, G., Czibula, I. G., and Chelaru, I.-

G. (2023). Uncovering behavioural patterns of one-

and binary-class SVM-based software defect predic-

tors. In Proceedings of ICSOFT 2023, pages 249–257.

SciTePress.

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

142

Clark, B. and Zubrow, D. (2001). How good is a software:

a review on defect prediction techniques. In Software

Engineering Symposium, pages 1–35, Carneige Mel-

lon University.

Dam, H. K., Pham, T., Ng, S. W., Tran, T., Grundy, J.,

Ghose, A., Kim, T., and Kim, C. (2018). A deep tree-

based model for software defect prediction. CoRR,

abs/1802.00921:1–10.

Fawcett, T. (2006). An introduction to ROC analysis. Pat-

tern Recognition Letters, 27(8):861–874.

Feng, Z., Guo, D., Tang, D., Duan, N., Feng, X., Gong,

M., Shou, L., Qin, B., Liu, T., Jiang, D., and Zhou,

M. (2020). CodeBERT: A pre-trained model for pro-

gramming and natural languages. In EMNLP 2020,

pages 1536–1547, Online.

Graves, A., Fern

andez, S., and Schmidhuber, J. (2005).

Bidirectional LSTM networks for improved phoneme

classiﬁcation and recognition. In Proceedings of Ar-

tiﬁcial Neural Networks: Formal Models and Their

Applications - ICANN 2005, pages 799–804.

Herbold, S., Trautsch, A., Trautsch, F., and Ledel, B.

(2022). Problems with szz and features: An empirical

study of the state of practice of defect prediction data

collection. Empirical Software Engineering, 27(2).

Hosseini, S., Turhan, B., and Gunarathna, D. (2019). A sys-

tematic literature review and meta-analysis on cross

project defect prediction. IEEE Transactions on Soft-

ware Engineering, 45(2):111–147.

Hryszko, J. and Madeyski, L. (2018). Cost effectiveness

of software defect prediction in an industrial project.

Foundations of Computing and Decision Sciences,

43(1):7 – 35.

hua Chang, R., Mu, X., and Zhang, L. (2011). Software

defect prediction using non-negative matrix factoriza-

tion. Journal of Software, 6(11):2114–2120.

Huo, X., Yang, Y., Li, M., and Zhan, D.-C. (2018). Learn-

ing semantic features for software defect prediction

by code comments embedding. In ICDM 2018, pages

1049–1054.

Jin, C. (2021). Cross-project software defect prediction

based on domain adaptation learning and optimiza-

tion. Expert Systems with Applications, 171:114637.

Jureczko, M. and Madeyski, L. (2010). Towards identifying

software project clusters with regard to defect predic-

tion. In The 6th International Conference on Predic-

tive Models in Software Engineering, page 1–10.

Le, Q. V. and Mikolov, T. (2014). Distributed represen-

tations of sentences and documents. Computing Re-

search Repository (CoRR), abs/1405.4:1–9.

Li, J., He, P., Zhu, J., and Lyu, M. R. (2017). Software

defect prediction via convolutional neural network.

In 2017 IEEE International Conference on Software

Quality, Reliability and Security, pages 318–328.

Liu, J., Ai, J., Lu, M., Wang, J., and Shi, H. (2023). Se-

mantic feature learning for software defect prediction

from source code and external knowledge. Journal of

Systems and Software, 204:111753.

Liu, Y., Ott, M., Goyal, N., Du, J., Joshi, M., Chen, D.,

Levy, O., Lewis, M., Zettlemoyer, L., and Stoyanov,

V. (2019). RoBERTa: A Robustly Optimized BERT

Pretraining Approach.

Malhotra, R. (2015). A systematic review of machine learn-

ing techniques for software fault prediction. Applied

Soft Computing, 27:504 – 518.

Marcus, A., Poshyvanyk, D., and Ferenc, R. (2008). Us-

ing the conceptual cohesion of classes for fault predic-

tion in object-oriented systems. IEEE Transactions on

Software Engineering, 34(2):287–300.

Mazzarella, V., Maiello, I., Capozzi, V., Budillon, G., and

Ferretti, R. (2017). Comparison between 3d-var and

4d-var data assimilation methods for the simulation of

a heavy rainfall case in central italy. Advances in Sci-

ence and Research, 14:271–278.

Miholca, D.-L., Tomescu, V.-I., and Czibula, G. (2022). An

in-depth analysis of the software features’ impact on

the performance of deep learning-based software de-

fect predictors. IEEE Access, 10:64801–64818.

Mohammed, A. H. and Ali, A. H. (2021). Survey of

BERT (Bidirectional Encoder Representation Trans-

former) types. Journal of Physics: Conference Series,

1963(1):012173.

Runeson, P. and H

ost, M. (2009). Guidelines for conduct-

ing and reporting case study research in software en-

gineering. Empirical Softw. Engg., 14(2):131–164.

Uddin, M., Li, B., Ali, Z., Kefalas, P., Khan, I., and Zada,

I. (2022). Software defect prediction employing BiL-

STM and BERT-based semantic feature. Soft Com-

puting, 26:7877–7891.

Wang, S., Liu, T., and Tan, L. (2016). Automatically learn-

ing semantic features for defect prediction. In Pro-

ceedings of the 38th International Conference on Soft-

ware Engineering, pages 297–308. ACM.

Wilcoxon Signed-Rank Test (2023). Social science statis-

tics. http://www.socscistatistics.com/tests/.

Yang, X., Lo, D., Xia, X., Zhang, Y., and Sun, J. (2015).

Deep learning for just-in-time defect prediction. In

2015 IEEE International Conference on Software

Quality, Reliability and Security, pages 17–26.

Yao, W., Shaﬁq, M., Lin, X., and Yu, X. (2023). A Software

Defect Prediction Method Based on Program Seman-

tic Feature Mining. Electronics, 12(7).

Zhao, L., Shang, Z., Zhao, L., Zhang, T., and Tang,

Y. (2019). Software defect prediction via cost-

sensitive siamese parallel fully-connected neural net-

works. Neurocomputing, 352:64–74.

Zheng, J. (2009). Predicting software reliability with neu-

ral network ensembles. Expert Systems with Applica-

tions, 36(2):2116–2122.

Zhou, C., He, P., Zeng, C., and Ma, J. (2022). Software

defect prediction with semantic and structural infor-

mation of codes based on graph neural networks. In-

formation and Software Technology, 152:107057.

Zhou, S., Alon, U., Agarwal, S., and Neubig, G. (2023).

CodeBERTScore: Evaluating code generation with

pretrained models of code. In Proceedings of the 2023

Conf. on Empirical Methods in Natural Language

Processing, pages 13921–13937, Singapore. ACM.

Zhu, K., Zhang, N., Ying, S., and Wang, X. (2020). Within-

project and cross-project software defect prediction

based on improved transfer naive bayes algorithm.

Computers, Materials & Continua, 63(2):891–910.

Enriching the Semantic Representation of the Source Code with Natural Language-Based Features from Comments for Improving the

Performance of Software Defect Prediction

143
