A Methodology for Web Cache Deception Vulnerability Discovery

Filippo Berto

, Francesco Minetti

, Claudio A. Ardagna

and Marco Anisetti

Department of Computer Science, University of Milan, Milan, Italy

Keywords:

Web Cache Deception, Web Cache, Web Security.

Abstract:

In recent years, the use of caching techniques in web applications has increased signiﬁcantly, in line with their

expanding user base. The logic of web caches is closely tied to the application logic, and misconﬁgurations

can lead to security risks, including the unauthorized access of private information and session hijacking. In

this study, we examine Web Cache Deception as a technique for attacking web applications. We develop a

solution for discovering vulnerabilities that expands upon and encompasses prior research in the ﬁeld. We

conducted an experimental evaluation of the attack’s efﬁcacy against real-world targets, and present a new

attack vector via web-client-based email services.

1 INTRODUCTION

Content distribution is a common problem in mod-

ern web applications, as there are rapidly increasing

numbers of users who access the same resources. In

the recent years, many software products have inte-

grated web caching technologies and services to en-

hance the performance of their infrastructure. The in-

creasing popularity of these techniques has prompted

researchers to investigate the associated security as-

pects, leading to the identiﬁcation of a new type of

attack: Web Cache Deception (WCD) (Gil, 2017;

Mirheidari et al., 2022; Mirheidari et al., 2020;

Nguyen et al., 2019a)

. These attacks exploit vul-

nerabilities in caching services to exﬁltrate informa-

tion, bypassing access control features and obtaining

stored data intended for other users (Mirheidari et al.,

2022). Researchers have identiﬁed several alternative

attacks, revealing a variety of vulnerabilities in enter-

prise content distribution systems (Mirheidari et al.,

2020). Although some solutions have been developed

to automatically scan for WCD vulnerabilities, they

do not consider all the possible attack vectors. Our

contribution with this paper is threefold: i) a novel

solution for detecting WCD vulnerabilities capable of

covering a wide range of important novel cases af-

https://orcid.org/0000-0002-2720-608X

https://orcid.org/0009-0007-1272-956X

https://orcid.org/0000-0001-7426-4795

https://orcid.org/0000-0002-5438-9467

Practical Web Cache Attacks: https://portswigger.net/

research/practical-web-cache-poisoning

fecting modern applications; ii) a new attack vector

using web mail client, iii) experimentally evaluate the

effectiveness of our solution in real scenarios..

1.1 Motivation and Goals

Existing tools, including the one proposed in (Mirhei-

dari et al., 2022), do not cover a number of relevant

cases and are not automated. In most of the cases they

do not cover scenarios where there are no caching-

related HTTP headers or where there are responses

with different content for the same cached resource,

such as cases where the vulnerable application uses

the Cloudﬂare email obfuscation. In addition, they

do not cover speciﬁc cases of certain software prod-

uct versions, such as the case having advisory CVE–

2020–15151

. Also rare cases in which the web ap-

plication caches all the resources that have an HTTP

200 response code are not covered as well as cases in

which the classic payloads cannot be used but a sim-

ple unique query string must be used. Our solution

aims to cover all the above cases providing certain de-

gree of automation. In addition, we propose a novel

attack vector for WCD vulnerabilities exploiting web

mail clients automatically loading web contents. To

the best of our knowledge, this approach has never

been discussed before in literature or in public domain

resources.

https://nvd.nist.gov/vuln/detail/CVE-2020-15151

Berto, F., Minetti, F., Ardagna, C. and Anisetti, M.

A Methodology for Web Cache Deception Vulnerability Discovery.

DOI: 10.5220/0012692000003711

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 14th International Conference on Cloud Computing and Services Science (CLOSER 2024), pages 231-238

ISBN: 978-989-758-701-6; ISSN: 2184-5042

231

1.2 Paper Structure

The rest of the paper is organized as follows: Sec-

tion 2 analyses the literature related to web cache vul-

nerabilities and exploitation techniques, later focus-

ing on WCDs. Section 3 describes the background

of WCD, explaining how web caches work and how

their misconﬁguration can be exploited, and the mo-

tivation of this paper. Section 4 shows our proposed

methodology, describing how our solution works and

the new edge cases being covered. Section 5 describes

the cases covered by our solution and introduces a

novel attack vector. Section 6 contains our experi-

mental validation of the developed solutions against

real web services. Finally, in Section 7 we discuss the

results obtained and report our conclusions.

2 RELATED WORK

The security of web caches is a well known problem

without comprehensive solution yet. It is grounded on

the difﬁculties of ﬁnding the correct middle ground

between caching every content and none, it is strictly

linked to the application logic and securing it is gen-

erally a hard task. Initial works on the security of

web caches date back to the end of the last century,

when the rapid growth in popularity of Internet re-

quired systems that could handle large scale distribu-

tion of contents (Chankhunthod et al., 1996; Smith

et al., 1999).

The conﬁguration of web caching services varies

according to the requirements of the target web ap-

plication, as it manages the caching logic for its con-

tent. Correctly conﬁguring web caches is error-prone:

several considerations must be taken into account de-

pending on the application, such as the type of content

returned by the web application, the resource path,

and the HTTP code returned. Attacks against web

caches usually fall into two classes:

1. Cache poisoning, where the attacker sends a

crafted request to a vulnerable web cache, forc-

ing it to store a particular version of the server’s

response. Eventually, a user who sends a request

that matches the attacker’s caching keys will re-

ceive the cached content. This type of attack can

be used as a form of Denial of Service (DOS), pre-

venting the user from retrieving the correct con-

tent, or even as misinformation, providing the user

with outdated information (Ghaznavi et al., 2021;

Nguyen et al., 2019b; Nguyen et al., 2019a).

2. Cache deception, covered in this paper, which

occurs when web caches are incorrectly conﬁg-

ured, allowing an attacker to deceive users into

storing private content within the cache. The at-

tacker can then retrieve the data using a matching

caching key.

In both cases, the misconﬁguration of the web cache

allows the attacker to generate false positive matches

with other users’ caching keys.

WCD’s literature is still in its infancy, with only

few available related publications. Omer Gil was the

ﬁrst describing the attack, showing how misconﬁg-

ured web caches and Content Distribution Networks

(CDNs) may incorrectly store users responses’ data,

mistaking them for static ﬁles such as stylesheets

and scripts (Gil, 2017). In this scenario the attacker

can then send a key-matching request, retrieving the

cached response, possibly containing sensitive infor-

mation or session data. Mirheidari et al. introduced

a WCD search methodology focusing on markers in

HTTP responses (Mirheidari et al., 2020). Further-

more, in this article the authors have proposed inno-

vative WCD payloads, characterized by the posses-

sion of special characters that block the parsing of

the path by the origin application servers, while they

are entirely parsed by the intermediary nodes. These

payloads have broadened the spectrum of possible

WCD scenarios. These techniques have been given

the name of path confusion as they confuse the origin

application server into believing that the requested re-

source is the correct one, while letting the intermedi-

ary nodes carry out the complete parsing of the path,

letting them believe that a static resource has been

requested, and therefore that it can be saved locally.

Mirheidari et al. also implemented a WCD detec-

tion tool whose computation is based on the presence

and semantics of the HTTP caching headers. They

also conducted the largest large-scale experiment in

WCD detection. To do so they developed an automa-

tion tool that does not require a manual registration

phase on the website to be tested. The tool relies

on the fact that if a web application mistakenly saves

non-authenticated resources in the web cache, it will

probably do the same with authenticated resources.

This gave them a solution that is well suited to large-

scale experiments (Mirheidari et al., 2022). Nguyen et

al. conducted a large-scale exploration of commonly

used cache systems’ security and identiﬁed many vul-

nerabilities that can be attributed to misconﬁguration,

misinterpretation of standards, and bypassing of secu-

rity features (Nguyen et al., 2019a).

Several solutions for the security of web caches

and CDNs have been adopted in literature. In (Jabiyev

et al., 2021), Jabiyev et al. have proposed a fuzzing-

based approach to caches vulnerability discovery.

Anomaly detection techniques have been proposed to

counteract crafted requests (Yang et al., 2022; Ghaz-

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

232

p p p

HTTP/1.1

Host: www.domain.com

...

1 2

4 3

HTTP/1.1 200 OK

Content-type: text/html

...

HTTP/1.1 200 OK

Content-type: text/html

X-Cache: miss

...

Figure 1: Web caching mechanism.

navi et al., 2021; Zolfaghari et al., 2020). Others have

proposed automated techniques for identifying cache

poisoning vulnerabilities (Hildebrand, 2021) or sub-

stituted standard HTTP-based caches with ones based

on custom network protocols (Lin et al., 2022).

Different network stacks have implemented vari-

ous approaches to the security of CDNs. For instance,

networks based on the Information Centric Network-

ing (ICN) paradigm require producers to sign all con-

tent, which mitigates the risk of cache poisoning. Ad-

ditionally, automated veriﬁcation solutions have been

implemented to verify non-functional properties, such

as security and performance (Anisetti et al., 2021;

Anisetti et al., 2022). Similar solutions could be ap-

plied transparently to traditional web cache services,

reducing the risk of misconﬁguration.

3 BACKGROUND

In this section we summarize the main concepts of

web caching and web cache deception vulnerabilities.

3.1 Web Caching

Web caching refers to the process through which

HTTP responses are saved by intermediary nodes of

a multi-level web infrastructure and then served by

them if needed. This process ensures optimization of

HTTP trafﬁc, reducing latency and network usage and

improving performance. Figure 1 represents the be-

havior of a generic web caching mechanism.

In steps 1 and 2 a client requests a resource from

a server using an HTTP GET request. The request

travels from the client to the originating application

server, passing through an intermediary node that

is providing the caching service. Subsequently, the

origin application server replies with an HTTP 200

response, which will travel up to the intermediary

node. The intermediary node will now save a copy

of the response locally and forward the response to

the client. At a later time, if a client requests the same

resource, it will be returned directly by the interme-

diary node, thus eliminating useless trafﬁc between

the intermediary node and the originating application

HTTP/1.1

Host: www.vulnerable.com

Cookie: <SESSION

COOKIES>

...

HTTP/1.1 200 OK

Content-type: text/html

...

https://www.vulnerable.com/non-existent.js

HTTP/1.1 200 OK

Content-type: text/html

X-Cache: miss

...

HTTP/1.1 200 OK

Content-type: text/html

X-Cache: hit

...

GET /non-existent.js

HTTP/1.1

Host: www.vulnerable.com

...

Figure 2: Web cache deception mechanism.

server. In a real environment, the intermediary is an

edge server of a CDN or a reverse proxy at the edge of

a Demilitarized zone (DMZ). HTTP response codes

and headers may differ from the standard ones shown

in Figure 1. Resources saved in web caches are identi-

ﬁed through conﬁguration variables called cache keys

which value is generated using various parts of HTTP

requests and responses related to a given resource.

Depending on the deployment conﬁguration this duty

of continuously managing the keys handling mecha-

nism is accomplished either by the organization’s or

the CDN provider’s system administrators, as com-

plete automation often leads to false positives.

3.2 Web Cache Deception

Web cache deceptions are vulnerabilities that arise

from an incorrect conﬁguration of the web caching

mechanisms. Figure 2 shows a diagram of the WCD

attack mechanism.

In step 1 the attacker tricks the victim user into

sending a request to a crafted URL. This can be

achieved through Cross Site Scripting (XSS) (Cui

et al., 2020; Liu et al., 2019) or phishing (Barron

et al., 2021; Gupta et al., 2016) or other common at-

tack vectors. The URL consists of a ﬁrst part, indi-

cated in green in Figure 2, which points to a resource

that exists on the application server, concatenated to a

second part, the WCD payload indicated in red, which

points to a non-existent static resource on the server.

In step 2, the victim, authenticated on the vulnera-

ble site, opens the malicious link and sends an HTTP

GET request with session cookies to the origin appli-

cation server. In step 3, after the server has received

the HTTP request, it will reply with an HTTP 200 re-

sponse containing the victim user’s private informa-

tion. The response will travel up to the intermediate

node, which will save the response locally, detecting

the end of the URL path as a static ﬁle due to its mis-

conﬁguration. Finally, the content is forward it to the

client. As last step, the attacker, requests the same re-

source with the same cache keys, fetching Personally

A Methodology for Web Cache Deception Vulnerability Discovery

233

Identiﬁable Information (PII) of the victim user.

WCD vulnerabilities have the following charac-

teristics:

• require a simple HTTP GET request with session

cookies. Other web application vulnerabilities

usually have stricter requirements, e.g. Reﬂected

XSS vulnerabilities described in (Cui et al., 2020;

Shrivastava et al., 2016) where the response must

also be interpreted by the browser;

• are widespread, as many web infrastructures to-

day use one or more web caching mechanisms in-

ternally;

• have impact that varies according to the type of

content mistakenly saved in web caches;

• have a ﬁnite attack surface, given by the combina-

tion of the set of resources returned by the appli-

cation server that contain private user information

with the set of WCD payloads.

Given the above characteristics, the process of search-

ing for these vulnerabilities can be partially auto-

mated.

4 METHODOLOGY

In this section we describe our scanning methodology,

which is subdivided into 3 phases.

Registration. In the ﬁrst phase, we register a new

user on the target application. Normally this step

requires manual intervention by the researcher, in-

putting speciﬁc markers in the registration that will

later be searched by the program. Then the re-

searcher logs onto the target website and copies the

session cookies to the scanning tool using the pro-

vided browser extension.

Crawling. During the second phase, our solution

will perform an authenticated recursive crawling of

the domain using the provided cookies and a headless

browser. We found this to provide the most effective

results even with single page applications. The tool

will save all the links it ﬁnds within anchor elements

and forms, creating a representation of the application

attack surface. Algorithm 1 describes the steps of the

crawling phase.

Detection. The third and ﬁnal phase, focuses on de-

tection of WCD vulnerabilities using the collected

URLs. For each collected link and for each WCD

payload, the tool performs the following actions:

def getPageLinks(url, depth: int = 0)

if isInLinkList(url) and

isAmplitudeAllowed(url) then

save(url);

if depth < MAX DEPTH and

totalLinks < MAX LINKS then

hrefs ← getAllAnchorHref();

actions ← getAllFormAction();

foreach href ∈ hrefs do

getPageLinks(link, depth+1);

end

foreach action ∈ actions do

getPageLinks(action,

depth+1);

end

Algorithm 1: Crawling phase algorithm.

• send an HTTP GET request with session cookies

to the given link concatenated with the WCD pay-

load;

• send the same previous request, but without the

session cookies;

• ﬁnally, check if there are cookies, markers or

Cross Site Request Forgery (CSRF) tokens of the

victim user in the response to the unauthenticated

request and, if so, it will warn the user that it has

found a possible WCD.

Algorithm 2 describes the steps of the detection

phase.

def detection(payloadList)

foreach p ∈ payloadList do

authResponse ←

sendAuthRequest(p);

unauthResponse ←

sendUnauthRequest(p);

if isAuthContent(unauthResponse)

then

possible WCD found

end

Algorithm 2: Detection phase algorithm.

We note that, although not implemented in our so-

lution, the ﬁrst phase could also be fully automated

by programmatically recognizing sign up and sign in

forms and inserting the appropriate tokens and cre-

dentials. We also note that some sites require two-

factor authentication or obstruct robots and scrap-

ers with detection and prevention techniques, such as

captchas, often placed precisely in conjunction with

the sign-in and sign-up forms. It has recently been

demonstrated how it is possible to bypass these anti-

bot puzzles in an automated way with the help of neu-

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

234

ral networks (Mirheidari et al., 2022; Ma et al., 2020).

5 COVERED CASES

Our solution covers the classic cases with and with-

out HTTP headers related to caching, including path

confusion techniques. Furthermore, it covers cases in

which it receives responses where the body differs for

the same resource saved in the web cache, e.g. in web

applications that use Cloudﬂare email obfuscation.

Our solution also covers a speciﬁc case of certain

versions of the Content Management System (CMS)

OpenMage LTS, based on Magento, with advisory

CVE–2020–15151. For certain versions of this CMS,

the default installation includes a WCD-vulnerable

web cache local to the application server. Speciﬁcally,

with the default conﬁguration, all 404 responses re-

lated to a request with the path ending with a static

extension are saved in the cache. The problem is that

these 404 responses contain the CSRF token of the

victim user who requested it. As a result, an attacker

could steal the victim’s CSRF token and, if the same-

site attributes of the cookies allow it, it could perpe-

trate a CSRF attack. These versions of the CMS re-

quire a cookie called X-Magento-Vary

with a pre-

cise value (and the same for all users) to access the

web cache. Our tool detects whether the X-Magento-

Vary cookie is present in the session cookies, saves its

value and subsequently for each HTTP request made,

the cookie in question will be included in the requests

cookies. This case, like the others mentioned previ-

ously, could not have been identiﬁed using current

tools.

5.1 Novel Attack Vector: Web Mail

Client

We identiﬁed web mail clients as possible vectors for

WCD-type attacks. The hypothesis is that web mail

clients can, under certain conditions, send HTTP GET

requests with session cookies while loading email

contents. At the time of writing, we are unaware of

any previous discussion in literature or public domain

resources on the topic.

The attack is summarized in Figure 3. In step 1,

an attacker sends an email with two images in the

body to the victim’s email address. The ﬁrst image

will have the src attribute with a URL dedicated to

the WCD attack, while the second image will point

Magento’s default caching policies:

https://devdocs.magento.com/guides/v2.4/extension-dev-

guide/cache/page-caching/public-content.html

Vulnerable domain

Attacker domain

SMTP

<!DOCTYPE html>

...

</body></html>

Figure 3: Web mail client as attack vector.

to a server owned by the attacker. When the victim

user opens the malicious mail in a web mail client

that does not ﬁlter third-party content in the body of

the mail, two HTTP GET requests are sent. The ﬁrst

request will initiate the WCD attack, and second re-

quest will notify the attacker’s server that the WCD

attack has started and with what payload value it was

performed. At this point the attacker’s server will be

able to request the resource erroneously stored in the

cache and steal the victim’s private information. It

should be noted that throughout this process the in-

teraction of the victim user is almost non-existent, as

they will only have to view an email, without click-

ing any link. We have experimentally demonstrated

that in order to perpetrate the attack just described, 3

conditions must be valid:

• the site vulnerable to WCD must have session

cookies with the same-site attribute set to none

and the secure ﬂag set to true;

• the web mail client must not ﬁlter in the body of

the emails content that could generate GET re-

quests to third-party sites;

• the victim user must be using the Chrome

browser, which as of this writing has not yet im-

plemented state partitioning.

Moreover, we have demonstrated how before the

insertion of the same-site attribute of cookies in

browsers (before mid-2020) it was possible to per-

petrate the attack with any site vulnerable to WCD

and with any browser. This was demonstrated by test-

ing the attack with a mid-2020 standalone release of

the Firefox browser and a popular web mail client

that does not ﬁlter third-party content in the body of

emails. Furthermore, ﬂaws in the ﬁltering of content

in the body of emails that can generate HTTP GET

A Methodology for Web Cache Deception Vulnerability Discovery

235

requests can be exploited by an attacker to use web

mail clients that normally could not be used as an at-

tack vector. This experiment has shown how with the

advent of new types of vulnerabilities a privacy prob-

lem, such as ﬁltering third-party content in the body

of emails, can also become a security problem.

6 EXPERIMENTS

This section describes the experiments carried out to

validate the efﬁcacy of the methodology, focusing on

detection of WCD vulnerabilities, their classiﬁcation

and exploitation of the vulnerable target. Follow-

ing, additional experiments on the exploitation of web

mail clients as vectors for WCD attacks.

6.1 Detecting WCD

The developed tool has been tested on 100 domains,

chosen from organizations that explicitly allow secu-

rity testing, e.g. by providing bug bounty programs.

Furthermore, these domains have been selected in

such a way that they all have private content re-

turned directly in HTML by the application server. Of

these 100 domains, 13 were affected by WCD. Fig-

ures 4a, 4b and 4c show pie charts plots representing

respectively the consequences of the WCDs vulnera-

bility, the web caching technologies found to be mis-

conﬁgured and the HTTP response codes of the re-

sources erroneously saved in the web caches.

As shown in Figure 4a, the impact of the WCDs

found is variable and ranges from a CSRF attacks,

allowing changes to the personal information of the

victim account, to the theft of the victim account in

the worst case. Figure 4b shows how most of the web

caching software found vulnerable belonged to CDNs

(Cloudﬂare, Akamai, CloudFront) while a smaller

part to reverse proxies (Nginx, Magento). Finally,

Figure 4c shows that the HTTP response codes of re-

sources erroneously saved in the cache are mainly 200

and 404. In smaller numbers, cases with responses er-

roneously saved in the cache with HTTP 410 response

code were also detected.

A separate analysis was carried out regarding

CVE–2020–15151. First, 15 domains using the vul-

nerable version of OpenMage LTS were identiﬁed,

these domains were chosen from a different pool of

domains from those mentioned in the previous exper-

iment. In all 15 domains the default conﬁguration was

active and all were vulnerable to WCD, allowing ex-

ﬁltration of the session token. Of these 15 domains,

5 did not have the same-site session cookie attribute

set, allowing an attacker to perpetrate a CSRF attack.

CSRF (38.36%)

PII theft (23.07%)

Account takeover (23.07%)

Useless (15.4%)

(a) WCD consequences.

Cloudﬂare (38.46%)

Akamai (38.46%)

CloudFront (7.69%)

Nginx (7.69%)

Magento local cache (7.69%)

(b) Misconﬁgured technologies.

200 (38.46%)

404 (38.46%)

410 (23.07%)

CSRF (33.33%)

Useless (66.66%)

(d) OpenMage LTS WCD.

Figure 4: WCD detection experimental results.

The other domains had the session cookies’ same-site

attribute set to LAX or STRICT, thus preventing the

attack. Figure 4d contains a pie chart plot represent-

ing the consequences of the WCDs found during this

analysis.

The same domains were also tested manu-

ally in order to verify the effectiveness of the

tool. We identiﬁed false negative cases, where the

tool could not detect the vulnerability as it was

blocked by anti-bot software checking the JavaScript

navigator.webdriver property, thus identifying the

Selenium driver and halting the crawling phase. We

also noticed false positives cases in which cookies

with unimportant values, such as the domain name

or domain URLs, were returned by the application

server, misleading the tool into detecting a possible

WCD with cookie exﬁltration. The issue has been

corrected by ﬁltering the returned cookies keeping

only the ones with more than 16 characters and which

differ in the initial part from a variant of the domain

name (such as domain.com, http://domain.com,

https://domain.com).

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

236

Following the detection of WCDs vulnerabilities

in authenticated mode, the tool was run on a list of

750 domains in unauthenticated mode. In this execu-

tion mode, the tool only checked for the presence of

CSRF tokens that were erroneously stored in the web

cache. This experiment is based on the hypothesis

that if the tool detects the presence of CSRF tokens

mistakenly stored in the web cache for a particular

anonymous session, it will most likely do the same

for authenticated users. Of these 750 domains, only

3 were found to be vulnerable. This lower number

of positive cases is mainly due to the fact that the re-

search targeted a speciﬁc subset of possible WCDs

cases. In addition, the tool uses simple regular ex-

pressions to match against CSRF tokens, therefore it

is likely that some were missed. We have found that

for large-scale analysis of the unauthenticated type, it

is less computationally expensive and more effective

to use an approach based on the analysis of the HTTP

caching headers. We note that all the experiments

conducted in this study solely targeted web applica-

tions of organizations that granted explicit permission

for security testing. Additionally, the tool developed

generated minimal network overhead in comparison

to a normal browser, preventing accidental ﬂooding

of the target, and is available on our GitHub reposi-

tory under the Creative Common license

6.1.1 Global Scale Attacks

Various researchers have tackled the issue of exploit-

ing WCDs in a CDN-like environment in a globally

scalable way. The limit they encountered, from the

attacker’s point of view, was that of being able to re-

trieve the resources that were initially saved in a pre-

cise edge server in the globe, without knowing in ad-

vance in which geographical region the victim is lo-

cated. We found that the attacker can easily overcome

the issue by inducing the user in connecting to one of

their servers using attacks similar to the ones used for

WCD (e.g. XSS or phishing). When the victim user

connects to the attacker’s server, their IP is collected

and the victim is redirect to the URL of the WCD

attack. The attacker can then identify the victim lo-

cation using IP-to-Location services. Alternatively,

an attacker could simultaneously send several HTTP

requests to each CDN edge server in the victim sup-

posed region.

Source code of the proposed tool: https://github.com/

SESARLab/WCD prober

6.2 Discussion

In terms of defense against WCD vulnerabilities, the

primary solution relies on a proper conﬁguration of

web caching technologies, preventing the caches from

storing private information. This implies speciﬁc con-

siderations on the handling of HTTP requests by the

application server, even for non-existing endpoints. It

is paramount to check both the test and production

environments as the version or conﬁguration of the

application or the caching technology changes.

Considering the web mail clients as vectors for

WCD attacks, a substantial defense level can be

achieved by ﬁltering any content in the body of

the emails that could automatically generate HTTP

GET requests to third-party sites, such as images and

styling ﬁles. Current widespread behavior of allow-

ing whitelisting of entire (sub)domains could pose a

threat in the event of changes to the cache technol-

ogy conﬁguration. Finally, some vendors, such as

Cloudﬂare, have implemented software products that

mitigate WCD vulnerabilities by performing content

type checks on HTTP responses, verifying that the

content-type header matches the one declared in the

path, if any, and thus deeming it suitable for being

stored.

7 CONCLUSION

In this paper we presented a novel methodology for

detecting WCD vulnerabilities, experimentally evalu-

ate its effectiveness covering the largest possible num-

ber of WCD cases. Our detection solution demon-

strated better reliability for authenticated analyses,

compared to the unauthenticated ones. Finally, a

novel attack vector for WCDs using web mail client

has been proposed and experimentally veriﬁed. We

also have veriﬁed how some privacy-preserving tech-

niques introduced by default in web browsers in mid-

2020 have accidentally reduced part of the attack sur-

face of WCDs.

ACKNOWLEDGEMENTS

The work was partially supported by the projects

i) MUSA – Multilayered Urban Sustainability Ac-

tion – project, funded by the European Union –

NextGenerationEU, under the National Recovery

and Resilience Plan (NRRP) Mission 4 Component

2 Investment Line 1.5: Strengthening of research

structures and creation of R&D “innovation ecosys-

tems”, set up of “territorial leaders in R&D” (CUP

A Methodology for Web Cache Deception Vulnerability Discovery

237

G43C22001370007, Code ECS00000037); ii) SER-

ICS (PE00000014) under the NRRP MUR program

funded by the EU – NextGenerationEU; iii) 1H-HUB

and SOV-EDGE-HUB funded by Universit

a degli

Studi di Milano – PSR 2021/2022 – GSA – Linea 6;

and iv) program “piano sostegno alla ricerca” funded

by Universit

a degli Studi di Milano.

REFERENCES

Anisetti, M., Ardagna, C. A., Berto, F., and Damiani, E.

(2021). Security Certiﬁcation Scheme for Content-

centric Networks. In 2021 IEEE International Confer-

ence on Services Computing (SCC), pages 203–212,

Chicago, IL, USA. IEEE.

Anisetti, M., Ardagna, C. A., Berto, F., and Damiani,

E. (2022). A Security Certiﬁcation Scheme for

Information-Centric Networks. IEEE Trans. Netw.

Serv. Manage., 19(3):2397–2408.

Barron, T., So, J., and Nikiforakis, N. (2021). Click This,

Not That: Extending Web Authentication with De-

ception. In Proceedings of the 2021 ACM Asia Con-

ference on Computer and Communications Security,

ASIA CCS ’21, pages 462–474, New York, NY, USA.

Association for Computing Machinery.

Chankhunthod, A., Danzig, P. B., Neerdaels, C., Schwartz,

M. F., and Worrell, K. J. (1996). A Hierarchical Inter-

net Object Cache. In Proceedings of the 1996 annual

conference on USENIX Annual Technical Conference,

volume 164 of ATEC ’96, page 13, USA. USENIX

Association.

Cui, Y., Cui, J., and Hu, J. (2020). A Survey on XSS At-

tack Detection and Prevention in Web Applications.

In Proceedings of the 2020 12th International Confer-

ence on Machine Learning and Computing, ICMLC

’20, pages 443–449, New York, NY, USA. Associa-

tion for Computing Machinery.

Ghaznavi, M., Jalalpour, E., Salahuddin, M. A., Boutaba,

R., Migault, D., and Preda, S. (2021). Content Deliv-

ery Network Security: A Survey. IEEE Communica-

tions Surveys & Tutorials, 23(4):2166–2190. Confer-

ence Name: IEEE Communications Surveys & Tuto-

rials.

Gil, O. (2017). Web Cache Deception Attack. In Proceed-

ings of Black Hat 2017 US.

Gupta, S., Singhal, A., and Kapoor, A. (2016). A liter-

ature survey on social engineering attacks: Phishing

attack. In Proceedings of 2016 International Confer-

ence on Computing, Communication and Automation

(ICCCA), pages 537–540.

Hildebrand, M. (2021). Automated Scanning for Web Cache

Poisoning Vulnerabilities. PhD thesis, Technische

Universit

at Dortmund.

Jabiyev, B., Sprecher, S., Onarlioglu, K., and Kirda, E.

(2021). T-Reqs: HTTP Request Smuggling with Dif-

ferential Fuzzing. In Proceedings of the 2021 ACM

SIGSAC Conference on Computer and Communica-

tions Security, CCS ’21, pages 1805–1820, New York,

NY, USA. Association for Computing Machinery.

Lin, S., Xin, R., Goel, A., and Yang, X. (2022). Invi-

Cloak: An End-to-End Approach to Privacy and Per-

formance in Web Content Distribution. In Proceed-

ings of the 2022 ACM SIGSAC Conference on Com-

puter and Communications Security, CCS ’22, pages

1947–1961, New York, NY, USA. Association for

Computing Machinery.

Liu, M., Zhang, B., Chen, W., and Zhang, X. (2019).

A Survey of Exploitation and Detection Methods of

XSS Vulnerabilities. IEEE Access, 7:182004–182016.

Conference Name: IEEE Access.

Ma, Y., Zhong, G., Liu, W., Sun, J., and Huang, K. (2020).

Neural CAPTCHA networks. Applied Soft Comput-

ing, 97:106769.

Mirheidari, S. A., Arshad, S., Onarlioglu, K., Crispo, B.,

Kirda, E., and Robertson, W. (2020). Cached and

Confused: Web Cache Deception in the Wild. In

Proceedings of the 29th USENIX Security Symposium

(USENIX Security 20), pages 665–682.

Mirheidari, S. A., Golinelli, M., Onarlioglu, K., Kirda, E.,

and Crispo, B. (2022). Web Cache Deception Esca-

lates! In Proceedings of the 31st USENIX Security

Symposium (USENIX Security 22), pages 179–196.

Nguyen, H. V., Iacono, L. L., and Federrath, H. (2019a).

Mind the cache: large-scale explorative study of web

caching. In Proceedings of the 34th ACM/SIGAPP

Symposium on Applied Computing, SAC ’19, pages

2497–2506, New York, NY, USA. Association for

Computing Machinery.

Nguyen, H. V., Iacono, L. L., and Federrath, H. (2019b).

Your Cache Has Fallen: Cache-Poisoned Denial-of-

Service Attack. In Proceedings of the 2019 ACM

SIGSAC Conference on Computer and Communica-

tions Security, CCS ’19, pages 1915–1936, New York,

NY, USA. Association for Computing Machinery.

Shrivastava, A., Choudhary, S., and Kumar, A. (2016). XSS

vulnerability assessment and prevention in web appli-

cation. In 2016 2nd International Conference on Next

Generation Computing Technologies (NGCT), pages

850–853.

Smith, J., Calvert, K., Murphy, S., Orman, H., and Pe-

terson, L. (1999). Activating networks: a progress

report. Computer, 32(4):32–41. Conference Name:

Computer.

Yang, L., Moubayed, A., Shami, A., Heidari, P.,

Boukhtouta, A., Larabi, A., Brunner, R., Preda, S.,

and Migault, D. (2022). Multi-Perspective Content

Delivery Networks Security Framework Using Op-

timized Unsupervised Anomaly Detection. IEEE

Transactions on Network and Service Management,

19(1):686–705. Conference Name: IEEE Transac-

tions on Network and Service Management.

Zolfaghari, B., Srivastava, G., Roy, S., Nemati, H. R.,

Afghah, F., Koshiba, T., Razi, A., Bibak, K., Mitra,

P., and Rai, B. K. (2020). Content Delivery Networks:

State of the Art, Trends, and Future Roadmap. ACM

Comput. Surv., 53(2):34:1–34:34.

CLOSER 2024 - 14th International Conference on Cloud Computing and Services Science

238
