An Evaluation of the Impact of End-to-End Query Optimization

Strategies on Energy Consumption

Eros Cede

, Ana Aguilera

, Denisse Mu

nante

, Jorge Correia

, Leonel Guerrero

Carlos Sivira

and Yudith Cardinale

1,4

Departamento Computaci

on y Tecnolog

ıa de la Informaci

on, Universidad Sim

on Bol

ıvar, Caracas, Venezuela

Escuela de Ingenier

ıa Inform

atica, Facultad de Ingenier

ıa, Universidad de Valpara

ıso, Chile

ENSIIE & SAMOVAR,

Evry, France

Centro de Estudios en Ciancia de Datos e IA (ESenCIA), Universidad Internacional de Valencia, Spain

ycardinale@universidadviu.com

Keywords:

Energy Consumption, Relational Databases, Empirical Evaluation, Query Optimization.

Abstract:

Query optimization strategies is an important aspect in database systems that have been mainly studied only

from the perspective of reducing the execution time, neglecting the analysis of their impact on energy con-

sumption. We perform an empirical evaluation for understanding the impact of end-to-end query optimization

strategies on the power consumption of database systems, from both client and server perspectives. We per-

form tests over a PostgreSQL database for two optimization strategies (i.e., indexation and data compression)

using the TPC-H benchmark, conﬁgured with 22 queries on a 1GB dataset. To measure the energy consump-

tion of both client and server, we propose Juliet, a C++ agent for monitoring and estimating Linux processes

energy consumption in Joules (J). Experimental results show that indexation is more effective than data com-

pression to reduce the energy consumed by the execution of the majority of the 22 queries tested.

1 INTRODUCTION

Database Management Systems (DBMS), specif-

ically Relational Database Management Systems

(RDBMS), are software components that could re-

quire a lot of hardware resources for a database with

a lot of information, and this possibly could lead to a

lot of power consumption at several modules on the

servers, as well as on the client side.

Currently, there exist studies approaching the

energy-efﬁciency of RDBMS based on prediction

models (Guo et al., 2022), by proposing guidelines

to reduce energy waste in terms of improving query

planning, processing, and execution (Stavros, 2009;

You et al., 2020), or by measuring the energy con-

sumption with tools and benchmarks (Guo et al.,

2022). In particular, query optimization strategies

is an important aspect in database systems that have

been studied only from the perspective of perfor-

mance improvements in their operations, rather than

on the energy costs of their operations. Neverthe-

less, the goal of the query optimization would move

to choosing the best trade-offs between different met-

rics in order to meet the multi-criteria quality of ser-

vice that consumers have requested. It is important

to look into the potential trade-offs between various

metrics and resources, as well as the intricate rela-

tionships between these metrics and how they affect

query processing as a whole (Guo et al., 2022).

To better understand the impact of end-to-end

query optimization strategies on the power consump-

tion of RDBMS, from both client and server perspec-

tives, we perform an empirical evaluation by consid-

ering two optimization strategies (i.e., indexation and

data compression) and their combination. We use

TPC-H benchmark

, conﬁgured with 22 queries on a

1GB dataset, to do tests over a PostgreSQL RDBMS.

To monitor the power consumption of both client and

server, we propose Juliet, a C++ agent aimed to mon-

itor and estimate the energy consumption of Linux

processes. Experimental results show that indexation

is more effective than data compression to reduce the

energy consumed by the execution of the majority of

the 22 queries of the TPC-H benchmarking. The com-

https://www.tpc.org/tpch/default5.asp

Cedeño, E., Aguilera, A., Muñante, D., Correia, J., Guerrero, L., Sivira, C. and Cardinale, Y.

An Evaluation of the Impact of End-to-End Query Optimization Strategies on Energy Consumption.

DOI: 10.5220/0012708000003687

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2024), pages 657-665

ISBN: 978-989-758-696-5; ISSN: 2184-4895

657

Table 1: Related work. Where: LSSVM = Least Square Support Vector Machine, PM = Predictive Model.

Work Measure Method DBMS Benchmark

Optimization stra-

tegy/Operations

Side

(Yang et al.,

2023)

Energy LSSVM, sensors,

Oracle 11g TPC-H - Client (C)

(Karyakin and

Salem, 2017)

Background and

active power

SIMM riser and

linear power model

Shore-MT, MonetDB TPC-C, TPC-H - Server (S)

(Mahajan et al.,

2019)

Performance,

power, energy

Self-built power

measurement tool

MySQL, MongoDB,

Cassandra

YCSB Twitter

data

Index, ordered writes,

aggregations, row

caching, compaction

Client

(Koc¸ak et al.,

2018)

Average power UPM EM100 En-

ergy Meter

IBM DB2 TPC-H Compression, material-

ized query tables, index

Client

(Lella et al.,

2023)

Energy, Mean

Energy

PSUTIL, python

package

MySQL, PostgreSQL,

MongoDB, Couchbase

Netﬂix Userbase,

SMS Spam coll.

SELECT, INSERT,

DELETE, UPDATE

Client

(Xu et al., 2015) Energy RLS, Wattsup

power, and PM

PostgreSQL TPC-H, SDSS - Server

(Rodr

ıguez et al.,

2013)

Energy, power,

time

Wattsup power PostgreSQL TPC-DS - Server

(Roukh et al.,

2016)

Time, power (W) Watts Up Pro PostgreSQL TPC-H, SSB - Server

(Guo et al.,

2017)

Time, energy (J),

power (W)

WT3000, power

analyzer, and PM

Oracle 11g TPC-C, TPC-H Buffer Cache, Shared

Pool

Server

(Liu et al., 2013) Time, power PM1000, power

analyzer, and PM

PostgreSQL 9.1.8 TPC-H - Server

(Procaccianti

et al., 2016)

Time, energy Watts Up Pro PLAIN SQL, Propel,

and TinyQueries

- CREATE, READ, UP-

DATE, DELETE

Client

Our proposal Time, energy Juliet Postgres TPC-H Index, compression C & S

bination of indexation and data compression does not

outperforms the indexation.

2 RELATED WORK

To better understand the different components of

DBMS that impact on the energy consumption, it is

necessary to consider several aspects of the database

system in the evaluation process. In particular, we

consider that the hardware components (e.g., CPU,

memory, disk), the optimization strategies, and the

evaluated execution side (client or server) are key

aspects that might be taken into account during the

evaluation process. In this section, we describe re-

cent studies focused on at least one of these aspects,

whether based on prediction models for energy con-

sumption estimations (Yang et al., 2023; Karyakin

and Salem, 2017), based on empirical evaluation of

optimization strategies and operations using measure

tools or benchmarks (Mahajan et al., 2019; Koc¸ak

et al., 2018; Lella et al., 2023), or based on energy-

efﬁcient query optimizers (Xu et al., 2015; Rodr

ıguez

et al., 2013; Roukh et al., 2016; Guo et al., 2017; Liu

et al., 2013; Procaccianti et al., 2016). Additionally,

we look at the measures considered, the method used

for evaluation, the DBMS evaluated, and the bench-

mark used on each study reviewed.

Table 1 summarizes the works reviewed in this

section. Estimation models have been successfully

used to predict energy consumption with measures

such as power and energy workloads and memory us-

age. Most of the reviewed works are in the context of

query optimizers, however, despite their critical sig-

niﬁcance in decision support systems, there is no ev-

idence that power predictions are used as the primary

goal when optimising large join queries (Rodr

ıguez

et al., 2013). Our work is more related to those using

query optimization strategies, such as indexes or com-

pression. But, these works do not perform an empiri-

cal evaluation of the end-to-end server-client applica-

tion to evaluate the impact of energy consumption of

database query optimizations. Furthermore, many of

them concentrate the energy consumption analysis on

the server side and neglect the analysis on the client

side; while the studies that perform the analysis from

the client perspective do not carry out a ﬁne analysis

to distinguish the measurements by module.

3 STUDY DESIGN

From the the literature review, we realize that only

few studies perform empirical assessment to measure

the impact of energy consumption in applying differ-

ent database query optimization strategies (Mahajan

et al., 2019; Koc¸ak et al., 2018); however, they do not

consider the analysis of the end-to-end execution of

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

658

client-server applications. We are interested in evalu-

ating that aspect. Thus, the goal of this study is to in-

crease developers awareness about energy consump-

tion for relational databases, from which they can

deduce database optimization strategies guidelines in

the context of the development of client-server appli-

cations. From this goal, the following research ques-

tions are derived:

RQ1. Does the implementation of database optimiza-

tion strategies affect the energy consumption of client-

server applications?

RQ2. Does the addition of database optimization

strategies affect the energy consumption of client-

server applications?

To answer these RQ, we implemented two rela-

tional database optimization strategies (i.e., index-

ation and data compression) on TPC-H and devel-

oped client-server Java applications able to inten-

sively access data coming from the TPC-H bench-

mark. Figure 1 depicts the architectural design of

the experiments. For the server side, we use Post-

greSQL 16 database system that is open source and is

a commonly used for developers and supports indexa-

tion and compression as optimization strategies. The

TPC-H benchmark, implemented in the server, con-

sists of a suite of business oriented ad-hoc queries and

concurrent data modiﬁcations. The queries and the

data populating the database have been chosen to have

broad industry-wide relevance

. This benchmark con-

tains 22 queries in total with a dataset with different

sizes, from which we select the 1GB dataset. For

the implementation of the benchmark in PostgreSQL,

we use an implementation that offers a Python script

to create the query ﬁles and the databases and loads

the information of the databases based on the TPC-

H benchmark

. The Java client application is im-

plemented and conﬁgured to execute each of the 22

queries of the TPC-H benchmark.

Our experiments are setup using four different

conﬁgurations at the server: i) without strategies

Java

Application

22 SQL

queries

implemented

of TPC-H

CLIENT

CONFIGURATION

i) PostgreSQL database

system without strategies

1GB of dataset from TPC-H

SERVER CONFIGURATIONS

ii) PostgreSQL database

system with compression

iii) PostgreSQL database

system with indexes

iv) PostgreSQL database

system with compression

and indexes

Figure 1: Architectural design of the experiments.

https://www.tpc.org/tpch/default5.asp

https://github.com/Data-Science-Platform/tpch-pgsql.

(called base); ii) with compression and without in-

dexation (called compression); iii) with indexation

and without compression (called index); and iv) both

compression and indexation enabled (called index-

compression).

We create the indexes manually following the

method provided by Martins et al., who indicate ”cre-

ate indexes for the columns designated as foreign keys

and to the columns in join operations or the columns

used under the conditions of WHERE clauses” (Mar-

tins et al., 2021). Regarding the compression, we use

the functionality pg squeeze of the PostgreSQL ex-

tension

to compress databases once they are loaded.

Table 2 shows the storage usage for each conﬁg-

uration. As expected, the conﬁgurations with com-

pression takes up less storage than other conﬁgura-

tions and indexes without compression takes the high-

est storage.

We identify as a hypothesis that the database op-

timization strategies inﬂuence the energy consumed

by client-server applications. In order to evaluate the

extent of this inﬂuence, we collect the energy con-

sumption in Joules (J) through Juliet (see Section 4),

at the client and the server. The PostgreSQL applica-

tion is analyzed during the execution of the query for

each query in each iteration and its estimated energy

consumption is returned in Joules.

On each test, server and client are executed in the

same dedicated computer. The server is an instance of

the PostgreSQL service and the client is the Java pro-

gram used to run all the queries, which is the unique

user connected to the server. The experiments were

conducted in a 8th generation Intel Core i7 proces-

sor, 12 cores, and 4 threads per core, a frequency of

3.75GHz, 16GB of RAM and 500GB of HDD, and

Linux Mint 21.1 GNU/Linux Operating System, Java

11, and PostgreSQL 16.

Algorithm 1 presents the scenario of experiments

execution, which requires as inputs: i) the list of op-

timization strategies (base, index, compression, and

index-compression); ii) the number of iteration for

managing the ﬂuctuations values of metrics – i.e., 30

in our experiments; and iii) the list of queries to be ex-

ecuted (i.e., the 22 queries of the TPC-H benchmark).

Per each optimization strategy in the list of

strategies (lstOpt), we ﬁrst delete the database if it is

already created and we then create the database in the

Table 2: Storage usage for each optimization.

No compression Compression

No index 1741 MB 1476 MB

Index 2512 MB 2246 MB

https://github.com/cybertec-postgresql/pg squeeze

An Evaluation of the Impact of End-to-End Query Optimization Strategies on Energy Consumption

659

Require: lstOpt; // base, index, compression, index-compression

numIterations = 30; // number of iterations

lstQueries; // list of queries (22 queries en total)

Ensure: collect metrics for the analysis of energy consumption of a

client-server application

1: for optimization in lstOpt do

2: delete the database if it already exists

3: create the database according to the conﬁguration of

optimization

4: for query in lstQueries do

5: for i in numIterations do

6: restart the service of database server

7: start monitoring tools

8: execute query in the database server with the conﬁg.

9: collect metrics (execution time from client, energy

consumption from client and server)

10: stop monitoring tools

11: end for

12: end for

13: end for

Algorithm 1: Scenario of execution of the experiments.

PostgreSQL server taking into consideration the

conﬁguration provided by the chosen optimization

strategy (line 1 and line 2, in Algorithm 1). For in-

stance, if the strategy is base, we create the database

without any strategy, whilst if the strategy is in-

dex we create the database and we then add the in-

dexes, similar to the strategies compression and index-

compression. Once the database is created (line 3),

per each query in the list of queries (lstQueries),

we run 30 executions (line 4 and line 5) in order to

manage the energy ﬂuctuations that the energy moni-

toring tools experience. Per each iteration, we restart

the service of the database server in order to have the

same conditions for each execution (line 6), we then

start the monitoring tools (line 7) and execute the cho-

sen query in the database that was conﬁgured with

the optimization strategy (line 8). Finally, per each

iteration, we collect metrics related to execution time

from the client side and energy consumption from the

both client and server sides (line 9). This process is

repeated for all iterations, queries, and optimization

strategies.

4 JULIET: MONITOR OF

ENERGY CONSUMPTION

Juliet is a software tool for monitoring the energy con-

sumption of processes executing in a Linux-based op-

erating system. It takes advantage of the RAPL in-

terface provided by Intel processors, which reports

an estimate in microjoules of the accumulated energy

consumption in real time of the processor in various

power domains (e.g., CPU or RAM). Juliet accesses

process and CPU usage statistics located in /proc/

and performs periodic readings at regular and con-

ﬁgurable intervals to monitor the percentage of to-

tal CPU usage of the system and the percentage of

CPU usage allocated to a target process. Based on

these percentages and the total energy consumption

reported by the RAPL interface, the percentage of the

energy corresponding to the target processes is esti-

mated. Juliet is written in C++ Version 11, comprised

of four main classes: RaplLinux class that manages

the interaction with the Linux RAPL interface; CPU

class for access and compute the CPU statistics, as

well as associated functions; System class that man-

ages the processes, the system load among other func-

tionalities; and Monitor class that handles the mon-

itoring and recording of results. Juliet also searches

for all processes that match a given name and ana-

lyzes the energy consumption of all of them.

5 RESULTS

To answer the research questions (RQ), we ﬁrst an-

alyzed the time of execution of the queries for the

different conﬁgurations with the purpose of assuring

that the database optimization strategies have been

well-applied on the TPC-H benchmarking. For all

of the queries and strategies the expected reduction

of the execution time was obtained, however for the

space reasons, we do not present these results in

this paper. We next perform a statistical analysis

to know in which extent the database optimization

strategies (negatively or positively) impact the energy

consumed by the execution of the 22 queries of the

TPC-H benchmarking in the client-server application.

Results of this analysis are introduced in Table 3 and

Table 4. To get these values, we are guided by a set of

steps described as follows:

Step 1: we ﬁrst analyze the distribution of the en-

ergy consumption measurements (in Joules) collected

from the experiment. The analysis is made for the

client and server sides. To do that, we calculate the

average values of the energy consumption collected

from the 30 iterations executed per each query and

per each strategy (see columns 3 and 7 of Table 3 and

Table 4). We then calculate the relative standard de-

viation of the energy consumption of the previous 30

iterations (see columns 4 and 8). These relative stan-

dard deviations show that the ﬂuctuation of values are

small (i.e., less than 1) so the average values can be

used as representative values for the 30 iterations.

Step 2: we next analyze if there is any signiﬁcant

difference of the energy consumption measurements

between the execution of the 22 queries by apply-

ing a database optimization strategy, i.e., index, com-

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

660

Table 3: The distribution of the energy consumed by the queries Q01 to Q11. Where: B = Base, Index = Index, C =

Compression, IC = Index and Compression, AEC = average of energy consumption (EC in Joule unit), RSEC = relative

standard deviation of EC, DEC = difference of EC vs Base, W= Wilcoxon values vs Base.

Client Server

AEC RSEC %DEC W, p-value AEC RDEC %DEC W, p-value

Q01

B 25.28 0.12 – – 320.26 0.03 – –

I 22.34 0.10 11.63 200, = 0.0001 139.65 0.07 56.39 0, < 2.2e-16

C 24.04 0.07 – 344, = 0.1194 318.36 0.01 – 454, = 0.959

IC 22.74 0.08 10.04 213, = 0.0003 135.74 0.05 57.61 0, < 2.2e-16

Q02

B 19.71 0.22 – – 1.84 0.45 – –

I 16.45 0.11 16.48 242, = 0.0018 7.62 0.10 -313.5 900, < 2.2e-16

C 18.39 0.12 – 423, = 0.6973 8.38 0.11 -355 900, < 2.2e-16

IC 18.17 0.1 – 437, = 0.8545 7.49 0.11 -306.5 900, < 2.2e-16

Q03

B 22.09 0.14 – – 60.22 0.07 – –

I 19.50 0.09 11.74 232, = 0.001 57.52 0.04 4.48 251, = 0.0029

C 19.80 0.11 10.4 269, = 0.007 53.62 0.04 10.96 18, = 2.7e-14

IC 18.57 0.08 15.95 132, = 6.2e-07 54.48 0.05 9.52 70, = 4.8e-10

Q04

B 18.95 0.09 – – 6.15 0.24 – –

I 16.62 0.10 12.31 109, = 1.1e-05 3 0.19 51.23 2, = 1.6e-14

C 16.34 0.10 13.76 96, = 2.6e-06 4.25 0.29 30.91 125, = 5.01e-05

IC 16.44 0.08 13.23 76, = 2.3e-07 2.76 0.22 55.06 2, = 1.6e-14

Q05

B 18.78 0.13 - - 21.43 0.06 – –

I 18.32 0.11 – 387, = 0.3581 26.50 0.07 -23.68 892, = 1.13e-15

C 18.12 0.12 – 387, = 0.3581 18.18 0.1 15.13 53, = 3.57e-11

IC 19.14 0.11 486, = 0.6022 25.04 0.08 -16.84 860, = 3.63e-12

Q06

B 19.58 0.09 – – 35.49 0.05 – –

I 18.94 0.11 – 342, = 0.1124 34.72 0.06 – 347, = 0.1304

C 18.30 0.08 6.51 268, = 0.0066 33.62 0.06 5.28 222, = 0.0006

IC 18.66 0.11 4.72 308, = 0.0358 36.14 0.06 – 533, = 0.2244

Q07

B 18.24 0.14 – – 28.87 0.07 – –

I 18.47 0.10 – 494, = 0.5229 33.82 0.07 -17.12 854, = 1.08e-11

C 18.64 0.10 – 538, = 0.1973 30.58 0.07 -5.88 646, = 0.0034

IC 17.91 0.14 – 412, = 0.5819 33.22 0.08 -15.02 844, = 5.8e-11

Q08

B 18.32 0.12 – – 30.89 0.05 – –

I 17.78 0.09 – 381, = 0.3136 39.43 0.04 -27.66 900, < 2.2e-16

C 18.58 0.11 – 478, = 0.6865 29.42 0.05 4.73 245, = 0.0021

IC 18.81 0.11 – 498, = 0.4853 38.19 0.04 -23.63 900, < 2.2e-16

Q09

B 18.98 0.13 – – 60.02 0.03 – –

I 16.26 0.11 14.35 169, = 1.52e-05 9.23 0.10 84.62 0, < 2.2e-16

C 19.40 0.09 – 506, = 0.4147 56.66 0.03 5.6 72, = 6.3e-10

IC 16.61 0.12 12.46 215, = 0.00038 4.29 0.18 92.85 0, < 2.2e-16

Q10

B 19.45 0.08 – – 57.76 0.03 – –

I 18.95 0.12 – 409, = 0.552 23.28 0.06 59.69 0, < 2.2e-16

C 19.48 0.1 – 457, = 0.924 56.05 0.03 2.95 205, = 0.0002

IC 18.50 0.1 4.86 309, = 0.03713 52.86 0.03 8.48 20, = 4.59e-14

Q11

B 17.47 0.06 – – 4.55 0.16 – –

I 15.38 0.10 11.99 131, = 5.63e-07 1.98 0.31 56.51 1, < 2.2e-16

C 16.74 0.09 – 321, = 0.0853 4.82 0.14 – 509, = 0.2673

IC 14.79 0.11 15.36 74, = 8.32e-10 1.36 0.4 70.19 0, < 2.2e-16

pression, index-compression strategies, versus by not

using any optimization strategy, i.e., base strategy.

To do that, we use the Wilcoxon statistical test (see

columns 6 and 10). As we observe, not for all the

cases a signiﬁcant difference is reported. For instance,

for query 1 (Q01), a signiﬁcant difference of the en-

ergy consumed by the client and server was found for

the index strategy versus the base (see row 4), how-

ever for the same query, the difference of energy con-

sumption between the compression strategy and the

base for the client is not signiﬁcant (see row 5).

Step 3: only for the cases in which a signiﬁcance

difference was obtained in the previous step, we

calculate the percentage in which extent the en-

ergy consumption measurements were increased

or decreased (see columns 5 and 9). To do that,

we consider that the average values of the energy

consumed by the base represent the 100% and we

calculate which is the percentage that represent

the average values of energy consumed by the

An Evaluation of the Impact of End-to-End Query Optimization Strategies on Energy Consumption

661

Table 4: The distribution of the energy consumed by the queries Q12 to Q22. Where: B = Base, Index = Index, C =

Compression, IC = Index and Compression, AEC = average of energy consumption (EC in Joule unit), RSEC = relative

standard deviation of EC, DEC = difference of EC vs Base, W= Wilcoxon values vs Base.

Client Server

AEC RSEC %DEC W, p-value AEC RSEC %DEC W, p-value

Q12

B 19.22 0.1 – – 56.08 0.03 – –

I 18.07 0.12 6.0 309, =0.0371 17.63 0.08 68.56 0, <2.2e-16

C 19.44 0.1 – 481, =0.6543 53.33 0.04 4.9 149, =2.9e-06

IC 15.18 0.15 21.04 88, =5.2e-09 11.74 0.1 79.06 0, <2.2e-16

Q13

B 19.12 0.09 – – 49.71 0.04 – –

I 19.02 0.12 – 435, =0.8315 48.05 0.04 3.33 248, =0.0025

C 18.75 0.1 – 395, =0.4232 48.63 0.04 – 328, =0.0723

IC 17.94 0.11 6.17 284, =0.0136 48.38 0.05 2.67 306, =0.0332

Q14

B 18.99 0.12 - - 35.42 0.06 – –

I 17.14 0.12 9.75 255, =0.0035 7.30 0.27 79.37 0, <2.2e-16

C 18.44 0.09 – 379, =0.2996 32.34 0.07 8.71 149, =2.9e-06

IC 16.74 0.09 11.89 198, =0.00012 7.32 0.22 79.33 0, <2.2e-16

Q15

B 26.16 0.21 – – 98.10 0.16 – –

I 18.6 0.11 28.91 127, =3.8e-07 46.70 0.07 52.4 0, <2.2e-16

C 19.80 0.10 24.31 185, =5.1e-05 73.51 0.03 25.07 46, =1.1e-11

IC 18.19 0.10 30.48 103, =3.1e-08 47.26 0.06 51.83 0, <2.2e-16

Q16

B 25.01 0.06 – – 24.76 0.06 – –

I 16.7 0.09 33.24 0, <2.2e-16 17.14 0.12 30.78 0, <2.2e-16

C 17.02 0.1 31.94 0, <2.2e-16 18.5 0.08 25.28 1, <2.2e-16

IC 15.38 0.09 38.53 0, <2.2e-16 17.9 0.05 27.71 0, <2.2e-16

Q17

B 43.78 0.08 – – 393.82 0.03 – –

I 22.74 0.09 48.06 0, <2.2e-16 241.73 0.01 38.62 0, <2.2e-16

C 23.76 0.08 45.73 0, <2.2e-16 265.73 0.02 32.53 0, <2.2e-16

IC 23.39 0.10 46.56 0, <2.2e-16 238.51 0.02 39.44 0, <2.2e-16

Q18

B 38.64 0.21 – – 334.93 0.09 – –

I 23.57 0.08 39.0 75, =9.5e-10 263.12 0.02 21.44 0, <2.2e-16

C 23.13 0.08 40.14 61, =1.3e-10 277.66 0.01 17.1 95, =1.2e-08

IC 22.89 0.08 40.77 56, =5.8e-11 275.38 0.01 17.78 49, =1.8e-11

Q19

B 19.45 0.10 – – 54.97 0.03 – –

I 15.84 0.08 18.54 43, =6.3e-12 0.68 0.41 98.76 0, <2.2e-16

C 19.64 0.11 – 476, =0.7082 53.76 0.04 2.20 265, =0.0058

IC 15.80 0.09 18.74 41, =4.4e-12 0.6 0.43 98.91 0, <2.2e-16

Q20

B 20.02 0.10 – – 65.6 0.07 – –

I 20.55 0.10 – 519, =0.3136 60.43 0.03 7.88 99, =1.94e-08

C 20.82 0.07 -4.04 583, =0.0496 63.94 0.07 – 340, =0.1058

IC 20.67 0.11 – 522, =0.2928 61.46 0.04 6.3 172, =1.9e-05

Q21

B 20.00 0.11 – – 61.87 0.03 – –

I 20.01 0.11 – 447, =0.9707 61.91 0.03 – 443, =0.924

C 19.86 0.10 – 433, =0.8087 60.32 0.02 2.51 259, =0.004

IC 20.77 0.09 – 527, =0.2601 61.67 0.04 – 407, =0.532

Q22

B 119.39 0.06 – – 4427.2 0.07 – –

I 16.22 0.07 86.41 0, <2.2e-16 1.41 0.19 99.97 0, <2.2e-16

C 118.93 0.06 – 389, =0.7938 4387.18 0.07 – 376, =0.6402

IC 16.26 0.05 86.38 0, < 2.2e-16 1.2 0.19 99.97 0, < 2.2e-16

other strategies. As observed, the majority of these

percentages show that a decreasing of the energy

consumed by the execution of the queries is produced

when a strategy is applied. However, for ﬁve queries

(see Q02, Q05, Q07, Q08 and Q20), an increasing of

the energy consumption is reported when a strategy

is applied. Analysing these queries we did not ﬁnd

any particularity that can justify this effect, so more

studies are needed in order to explain this phenomena.

RQ1: Does the Implementation of Database Op-

timization Strategies Affect the Energy Consump-

tion of Client-Server Applications?

From Table 3 and Table 4, we observe that the

strategies index and compression are able to have an

impact of the execution of the queries. These impacts

are more evident for the server side than for the client

side for the majority of the cases.

The Index Strategy: we observe that for the majority

of queries the index strategy is able to impact the en-

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

662

ergy consumption of the execution of queries: for four

queries (Q02, Q05, Q07 and Q08) the energy con-

sumption is increased, for two queries no signiﬁcance

difference was determined (Q06 and Q21), and for the

other 16 queries the energy consumption is decreased

by applying the index strategy. Regarding the latest

16 queries, the index strategy can reduce: i) for the

client, at least 6% equivalent to 1.15 J (Q12) and up

to 86.41% equivalent to 103.17 J (Q22); ii) for the

server, at least 3.33% equivalent to 1.66 J (Q13) and

up to 99.97% equivalent to 4425.79 J (Q22).

The Compression Strategy: we observe that for the

majority of queries the compression strategy is able

to impact the energy consumption of the execution of

queries: for three queries (Q02, Q07 and Q20) the

energy consumption is increased, for four queries no

signiﬁcance difference was determined (Q01, Q11,

Q13, and Q22), and for the other 15 queries the en-

ergy consumption is decreased by applying the com-

pression strategy. Regarding the latest 15 queries,

the compression strategy can reduce: i) for the client,

at least 6.51% equivalent to 1.28 J (Q06) and up to

45.73 % equivalent to 20.02 J (Q17); ii) for the server,

at least 2.2% equivalent to 1.21 J (Q19) and up to

32.53% equivalent to 128.09 J (Q17).

From previous results, we note that the positive

impact is more important by applying the index

strategy than applying the compression strategy for

the majority of the queries.

In response to RQ1. Seeing the results, the reduction

of the energy consumption for the index strategy was

between [1.15, 103.17] J for the client side, whilst for

the compression was [1.28, 20.02] J. For the server

side, the index strategy was able to reduce between

[1.66, 4425.79] J, whilst the compression reduced

between [1.21, 128.08] J. Therefore, we can conclude

that the index strategy is more effective than the com-

pression strategy in reducing the energy consumed by

the execution of SQL queries for relational databases

such as the PostgreSQL database system. The reason

for this may be due to the mechanism PostgreSQL

uses for compression that avoids data repetitions to

save space and adds references to the original data

having to use them later to recover the original data.

RQ2: Does the Addition of Database Optimiza-

tion Strategies Affect the Energy Consumption of

Client-Server Applications?

The interaction of database optimization strategies

is evaluated by applying both strategies (i.e., index

and compression) at the same time. The statistical

evaluation for this interaction is also reported in Ta-

ble 3 and Table 4.

The Index-Compression Strategy: we observe that

for the majority of queries the index-compression

strategy is able to impact the energy consumption

of the execution of queries: for four queries (Q02,

Q05, Q07 and Q08) the energy consumption is in-

creased and we observe that these queries are the

same reported for the index strategy, so it could in-

dicate that the index strategy inﬂuence more the in-

teraction index-compression than the strategy com-

pression. Moreover, for one query no signiﬁcance

difference was determined (Q21), the Q21 also re-

ported a not signiﬁcance value for index, however

Q06 that was also reported for the index becomes hav-

ing a signiﬁcant difference for the interaction index-

compression for the client. For the other 17 queries

the energy consumption is decreased by applying the

index-compression strategy. Regarding the last 17

queries, the index-compression strategy can reduce:

i) for the client, at least 4.72% equivalent to 0.92 J

(Q06) and up to 86.38 % equivalent to 103.13 J (Q22);

ii) for the server, at least 2.67% equivalent to 1.33 J

(Q13) and up to 99.97% equivalent to 4426 J (Q22).

From these experiments, we observe that the

results of index-compression are inﬂuenced for

both strategies. However as the index strategy is

more effective than the compression in reducing

energy consumption as was reported in RQ1, we

note that there is a tendency that the strategy index-

compression is more inﬂuenced by the index strategy.

In response to RQ2. Seeing the results, the reduction

of the energy consumption for the index-compression

strategy was between [0.92, 86.38] J for the client

side, whilst for the server side was between [1.33,

4426] J. These values are very similar to the val-

ues obtained for the index strategy. Therefore, we

can conclude that the interaction index-compression

is more inﬂuenced by the the index strategy than the

compression strategy. The reason could be that the

fact of the index strategy outperforms the compression

strategy in reducing the energy consumption for the

majority of the cases as was reported in RQ1. More-

over, the reduction of energy consumption is not so

different by applying just the strategy index, hence

we can recommend that use only the strategy index,

and not the combination of the strategies index and

compression, to reduce the energy consumption of

relational databases. It can save effort in applying

database optimization strategies for reducing energy

consumption of relational databases such as the Post-

greSQL database system.

An Evaluation of the Impact of End-to-End Query Optimization Strategies on Energy Consumption

663

6 THREATS TO VALIDITY

Internal Validity. For collecting energy consumption

measurements, we used Juliet, a tool created for our

experiment. It could introduce bias, so the building of

Juliet, which was inspired by similar tools, was inde-

pendent of the experiment in order to avoid any bias.

Construct Validity. For the design of the experiment,

we use the same computer for running the client and

server, it limits our experiment to a monolithic sce-

nario. This threat is partially reduced by Juliet being

able to collect the energy consumed by isolated pro-

cesses, i.e., the processes for the client and server. We

plan to run experiments in a real distributed scenario.

On the other hand, the ﬂuctuation of energy measure-

ments can affect the results and conclusions of the ex-

periment. To reduce this threat, we run 30 times per

each database strategy optimization and query, then

we calculate the average values of them. Moreover,

the database server can be altered by the execution of

previous queries affecting the results and conclusions

of the experiment. To reduce this threat, we restart the

server in order to collect energy by considering equal

conditions. A similar decision is taken for the con-

dition of the database itself each time that a strategy

should be implemented, i.e., the database is deleted

and recreated with the selected strategy to avoid any

alterations in results and conclusions.

External Validity. As our experiment was performed

on a speciﬁc benchmarking limited to 22 speciﬁc

queries, our results cannot be generalized. This threat

is partially reduced by using the TPC-H benchmark-

ing that is well known in this kind of experiment.

7 CONCLUSION

To better understand the impact of end-to-end query

optimization strategies (i.e., indexation, data com-

pression, and their combination) on the power con-

sumption of RDBMS, from both client and server per-

spectives, we execute tests, using TPC-H benchmark,

conﬁgured with 22 queries on a 1GB dataset on Post-

greSQL RDBMS. To do so, we propose a monitoring

tool, called Juliet, able to monitor and estimate the

energy and power consumption of processes execut-

ing in Linux-based systems. From the experimental

results, we conclude that indexation is more effective

than data compression to reduce the energy consumed

by the execution of the majority of the 22 queries.

However, more experiments are needed to accurately

evaluate the impact on energy consumption and ob-

tain stronger conclusions.

We are working on improving the scenario of the

experiments to reﬂect more real-world deployments

(e.g., run client and server in different machines), on

classifying the queries according their complexity, re-

sponses time and size, and on considering consump-

tion on other resources, such as CPU, I/O usage, and

memory. We also plan to apply the same empirical

evaluation over other RDBMS and NoSQL datasets.

ACKNOWLEDGEMENTS

This work was partially supported by the

”GreenSE4IoT: Towards Energy-efﬁcient Software

for Distributed Systems” project whose code is STIC-

AMSUD 22-STIC-04, and was partially carried out

at the Energy4Climate Interdisciplinary Center (E4C)

of IP Paris and

Ecole des Ponts ParisTech, which is in

part supported by 3rd Programme d’Investissements

d’Avenir [ANR-18-EUR-0006-02].

REFERENCES

Guo, B., Yu, J., Yang, D., Leng, H., and Liao, B. (2022).

Energy-efﬁcient database systems: A systematic sur-

vey. ACM Computing Surveys, 55(6):1–53.

Guo, Y., Li, J., Li, X., Li, J., and Li, X. (2017). A

green framework for dbms based on energy-aware

query optimization and energy-efﬁcient query pro-

cessing. Journal of Network and Computer Applica-

tions, 84:118–130.

Karyakin, A. and Salem, K. (2017). An analysis of memory

power consumption in database systems. In Workshop

on Data Management on New Hardware, pages 1–9.

Koc¸ak, S. A., Alptekin, G. I., Miranskyy, A. V., Bener,

A., and Cialini, E. (2018). An empirical evaluation

of database software features on energy consumption.

In Internat. Conf. on Information and Communication

Technology for Sustainability, volume 52, pages 1–19.

Lella, H. S., Manasa, K., Chattaraj, R., and Chimalakonda,

S. (2023). DBJoules: An Energy Measurement Tool

for Database Management Systems. arXiv preprint

arXiv:2311.08961.

Liu, X., Wang, J., Wang, H., and Gao, H. (2013). Gener-

ating power-efﬁcient query execution plan. In Inter-

national Conf. on Advances in Computer Science and

Engineering, pages 286–290.

Mahajan, D., Blakeney, C., and Zong, Z. (2019). Improv-

ing the energy efﬁciency of relational and NoSQL

databases via query optimizations. Sustainable Com-

puting: Informatics and Systems, 22:120–133.

Martins, P., Tom

e, P., Wanzeller, C., S

a, F., and Abbasi,

M. (2021). Comparing oracle and postgresql, perfor-

mance and optimization. In Trends and App. in Infor-

mation Systems and Technologies, pages 481–490.

Procaccianti, G., Lago, P., and Diesveld, W. (2016). En-

ergy Efﬁciency of ORM Approaches: an Empirical

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

664

Evaluation. In International Symposium on Empirical

Software Engineering and Measurement, pages 1–10.

Rodr

ıguez, M., Jabba, D., Zurek, E. E., Salazar, A., Wight-

mam, P., Barros, A., and Nieto, W. (2013). Analyzing

power and energy consumption of large join queries in

database systems. In Symposium on Industrial Elec-

tronics & Applications, pages 22–25.

Roukh, A., Bellatreche, L., and Ordonez, C. (2016). En-

erquery: Energy-aware query processing. In Interna-

tional Conf. on Information and Knowledge Manage-

ment, pages 2465–2468.

Stavros, H. (2009). Energy efﬁciency: The new holy grail of

data management systems research. In Biennial Conf.

on Innovative Data Systems Research, pages 1–8.

Xu, Z., Tu, Y.-C., and Wang, X. (2015). Online Energy Esti-

mation of Relational Operations in Database Systems.

IEEE transactions on computers, 64(11):3223–3236.

Yang, D., Yu, J., He, Z., Li, P., and Du, X. (2023). Apply-

ing self-powered sensor and support vector machine in

load energy consumption modeling and prediction of

relational database. Scientiﬁc Reports, 13(19097):1–

16.

You, X., Lv, X., Zhao, Z., Han, J., and Ren, X. (2020). A

survey and taxonomy on energy-aware data manage-

ment strategies in cloud environment. IEEE Access,

8:94279–94293.

An Evaluation of the Impact of End-to-End Query Optimization Strategies on Energy Consumption

665
