Towards a SQL Injection Vulnerability Detector Based on Session Types

Ant

onio Silvestre

, Ib

eria Medeiros

and Andreia Mordido

LASIGE, Departamento de Inform

atica, Faculdade de Ci

encias, Universidade de Lisboa, Portugal

Keywords:

SQL Injection Vulnerabilities, Session Types, Type Checking, Static Analysis, Software Security.

Abstract:

Vulnerabilities in web applications pose a risk for organisations. Among them, SQL injections (SQLi) give

the attacker access to private data by submitting malicious SQL queries to the database via invalidated entry

points. Although there are various techniques for detecting SQLi, static analysis is widely used as it inspects

the application code without executing it. However, static analysis tools are not always precise. In this work,

we explore an avenue that links the detection of SQLi to type checking, thus providing stronger guarantees of

their existence. We propose a novel approach which consists of interpreting the behaviour of a web application

as if it was a communication protocol and uses session types to specify this behaviour. We leverage FreeST,

a functional programming language for session types, to implement FREESQLI, a seminal detector of SQLi

in PHP web applications. The tool translates the PHP code into FreeST code and capitalizes on FreeST’s type

checker to verify protocol adherence and detect inconsistencies associated with the presence of SQLi.

1 INTRODUCTION

Despite efforts to prevent vulnerabilities in web appli-

cations, the number of detected vulnerabilities has in-

creased yearly and continues to be a security threat for

organizations. SQL injections (SQLi) are among the

top three vulnerabilities listed in the OWASP Top 10

Web Application Security Risks

. SQLi attacks oc-

cur when a system fails to sanitize or validate user in-

puts correctly, which allows malicious SQL queries to

be submitted to the database. According to CVEDe-

tails

, the number of reported SQLi has increased

from 740 in 2021 to 1790 in 2022 and is still ris-

ing. This data highlights the importance (and growing

prevalence) of this vulnerability on web applications,

despite being a well-researched topic.

Over the years, some programming languages

have developed mechanisms to prevent these attacks,

but they are still susceptible to human error (Halfond

et al., 2006). For this reason, there has been an ef-

fort to develop tools to automatically detect vulnera-

bilities by inspecting the application code and assist-

ing developers in identifying exploitable code frag-

ments. Yet, these tools can produce many false posi-

https://orcid.org/0000-0003-4227-2752

https://orcid.org/0000-0003-4478-8680

https://orcid.org/0000-0002-1547-0692

https://owasp.org/Top10/

https://www.cvedetails.com/

tives, leading to developers spending time correcting

nonexistent vulnerabilities.

PHP is the most widely used language on

the server-side of web applications, accounting for

roughly 76.5%

. It is a dynamically typed lan-

guage since variable data types are determined in run-

time, and the programmer does not need to specify

them (Achour et al., 2023). As PHP does not require

type speciﬁcations, it can pose security risks to ap-

plications if the intended types do not match. The

absence of strict type enforcement makes data vali-

dation from external sources (e.g., user inputs) more

difﬁcult. For instance, if a numeric ﬁeld is not cor-

rectly validated, an attacker can inject a handcrafted

string containing suspicious characters, leading to se-

curity ﬂaws within the application.

Unlike PHP, strongly typed languages require the

programmer to specify types that govern the program

speciﬁcation explicitly and throw an exception or an

error at compile time (i.e., before execution) whenever

the program does not meet the speciﬁed type. Fol-

lowing the numeric ﬁeld example, in these languages,

a type mismatch is identiﬁed when the ﬁeld receives

a string. Although type systems alone can not elim-

inate the need for content validation, (e.g., user in-

puts), they tend to lead to fewer fault errors than dy-

namic languages.

https://w3techs.com/technologies/overview/

programming language

Silvestre, A., Medeiros, I. and Mordido, A.

Towards a SQL Injection Vulnerability Detector Based on Session Types.

DOI: 10.5220/0012732500003687

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2024), pages 711-718

ISBN: 978-989-758-696-5; ISSN: 2184-4895

711

In this work, we resort to more expressive types

– the so-called session types – which extend the tra-

ditional notion of data types and enable the speciﬁ-

cation of communication protocols between different

parties by specifying types of data exchange and their

directions (Vasconcelos, 2012; Thiemann and Vas-

concelos, 2016). Session type systems provide ad-

ditional guarantees of protocol adherence, which is

paramount for our approach to the detection of SQLi:

using session types we can, for instance, specify mes-

sages exchanged between the web application and the

database and detect if the latter is receiving unsani-

tised queries from the former, which indicates the

presence of a vulnerability for SQLi.

In this paper, we propose an approach to de-

tect SQLi vulnerabilities in PHP web applications

through a novel static analysis technique based on

session types to deﬁne the nature of interactions

between servers, clients, and databases. The ap-

proach leverages a strongly typed language called

FreeST (Almeida et al., 2019), which has a robust

type system based on session types. More speciﬁ-

cally, the approach converts PHP code into FreeST

code, which must include the translation of the pro-

gram and the inference of the expected type. Trans-

lation includes an analysis of the application’s be-

haviour (over its interaction with the database and the

user) and the speciﬁcation of a communication proto-

col (read, session type) that speciﬁes this behaviour.

Once the code has been translated, the FreeST com-

piler identiﬁes inconsistencies between the expected

types and the respective values. These inconsistencies

allow us to identify vulnerabilities for SQLi, which

will then be appropriately collected and reported to

the developer. So far we have implemented a proof of

concept of our approach in the FREESQLI prototype.

The main contributions of this paper are: (1) A

novel static analysis approach that uses session types

to detect vulnerabilities for SQL injections; (2) The

FREESQLI tool that identiﬁes SQLi vulnerabilities in

PHP code, using the FreeST language.

2 BACKGROUND

Our work lives at the intersection of vulnerability de-

tection for SQLi and programming languages. So, in

this section we introduce some background related to

SQLi and detection mechanisms, but also related to

programming languages, session types and the lan-

guage that underpins our work – FreeST.

SQL Injections. An SQLi is a security vulnerabil-

ity that occurs when an attacker injects SQL com-

mands and meta-characters into the application’s un-

sanitised entry points, such as user forms, cookies and

server variables (Halfond et al., 2006). These meta-

characters when inserted in an existing SQL query,

they can change its structure so that it is interpreted as

a different SQL query, allowing the attacker to bypass

authentication, access the database, view, change, or

delete sensitive data, or even take control of adminis-

trative functions. One example of a vulnerable PHP

code to SQLi can be seen in Listing 1.

1 $u = $_GET [ ’ username ’];

2 $p = $_GET [ ’ password ’];

3 $qry = " S E L E CT * FROM us e r s WHERE un a m e = ’ $u’ A ND

pas s w d = ’$p ’";

4 $r = m y sql i _ que r y ( $conn , $qry );

Listing 1: Example of PHP code vulnerable to SQLi.

This example veriﬁes if a user belongs to the

database after he provides their credentials on the

and 2). Both entry points are injectable and do not

go through sanitisation. An attacker can access all

users’ information by simply providing the string

’ OR 1=1;-- on the username ﬁeld. This input al-

ters the ﬁnal query to:

SELECT * FROM users WHERE uname=’’ OR 1=1;-- ’

AND passwd=’’

The use of -- meta-characters serves as a com-

ment delimiter, which prevents the remaining content

from being treated as part of the query. Consequently,

the interpreted query would be:

SELECT * FROM users WHERE uname=’’ OR 1=1;

The tautology ’’ OR 1=1 in the WHERE clause

makes the query always true, which is logically equiv-

alent to the query SELECT * FROM users;. Next,

this query is sent to the database through the sensitive

sink mysqli_query to be executed. In this context,

a sensitive sink is a function that when executed with

abnormal data (like injected SQL code) can return un-

expected values.

According to Halfond et al. (Halfond et al., 2006),

different types of SQLi have distinct goals and char-

acteristics. However, they occur essentially because

of unsanitised input ﬁelds, which made languages

adopt mechanisms to prevent them. PHP was en-

dowed with input sanitisation functions and prepared

statements to mitigate the lack of validation on entry

points (Achour et al., 2023). Nonetheless, since these

mechanisms are applied by the developer, they are

prone to human error. For this reason, there has also

been an effort to develop tools to detect or prevent this

kind of vulnerability (Gould et al., 2004; Halfond and

Orso, 2005; Medeiros et al., 2016b; Medeiros et al.,

2016a).

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

712

Static Analysis Tools. Although programming lan-

guages provide defensive mechanisms to prevent vul-

nerabilities, such as the sanitization functions (e.g.,

mysqli_real_escape_string in PHP), they can not

guarantee that the software produced is secure since

human errors remain inevitable. Supplementary tools

are, therefore, essential for validating the code pro-

duced and supporting developers throughout the de-

velopment process.

Static analysis is a strategy that involves analysing

the application source, intermediate or binary code

without executing it to detect errors and vulnerabil-

ities. There is a wide variety of static analysis tools,

but usually, they follow a similar approach. They start

by taking the code and building a model that repre-

sents it. This model is created based on different ap-

proaches, often inspired by compiler strategies. Once

the model is complete, they analyse it based on the

knowledge and rules they have of what they are pro-

grammed to and generate a report containing the re-

sults (Chess and West, 2007). However, as these tools

depend on programmed knowledge, they may pro-

duce false positives (FP) by detecting nonexistent vul-

nerabilities and occasionally missing actual vulnera-

bilities, resulting in false negatives (FN). In security,

we know that FP and FN always have a negative effect

on the programmer’s conﬁdence. It is thus crucial to

minimise both and maximise true positives when de-

veloping a static analyser.

Types and Type Systems. Modern software engi-

neering recognises a wide range of formal methods

to ensure the desired and correct behaviour of a sys-

tem. Of all formal methods, type systems are best

established and prevalent (Pierce, 2002). Type sys-

tems, often associated with programming languages,

try to prevent errors from occurring during the exe-

cution of a program by detecting inconsistencies be-

tween types and values at compile time. When de-

signed, they should be easily veriﬁable and transpar-

ent, which means they must be able to verify if a pro-

gram is typed correctly, and their behaviour should be

predictable. Type systems enable the establishment

of the relationship between the program and the types

used to annotate them (Cardelli, 1996).

Programming languages can be categorised based

on their type systems. PHP is a weakly and dynam-

ically typed language. This means that while each

variable has a speciﬁc type, the programmer does not

need to declare their type because it is inferred at run-

time. Due to this dynamic nature and the lack of strict

type enforcement, PHP becomes more susceptible to

potential vulnerabilities, like attackers injecting mali-

cious code in a string to be used in a numeric ﬁeld.

As previously stated, types function as annota-

tions within computer programs. While different pro-

gramming languages have unique types, certain types,

such as integers, strings, booleans, and others, are

commonly used across multiple languages. Some lan-

guages can feature more complex types like arrays,

objects, or session types, which are especially perti-

nent to this work.

Session Types and FreeST. Session types enable

the speciﬁcation of heterogenously typed channels,

deﬁning communication protocols between two par-

ties (Vasconcelos, 2012). Session types can be seen as

sequences of input and output operations deﬁning the

messages being exchanged: !T represents the sending

of a value of type T, whereas ?T represents the recep-

tion of a value of type T . Session types can also of-

fer some ﬂexibility in the form of internal or external

choices: +{ℓ : T

ℓ

}

ℓ∈L

represents the internal choice of

a label ℓ, followed by the execution according to T

ℓ

whereas &{ℓ : T

ℓ

}

ℓ∈L

offers a set of choices labelled

with ℓ ∈ L and with continuation T

ℓ

. This structure

of sequential operations makes them ideal for mod-

elling protocols in distributed scenarios (Dardha et al.,

2012).

FreeST is an experimental concurrent program-

ming language

that uses a core of linear functional

programming and enables the creation of channels for

inter-thread communication. The most notable fea-

ture of FreeST is its robust type system founded on

context-free session types that regulate communica-

tion on channels (Almeida et al., 2019). Context-

free session types (Thiemann and Vasconcelos, 2016)

enable the speciﬁcation of communication protocols

whose traces are deﬁned by context-free languages,

while regular session types only enable the speciﬁca-

tion of tail recursive protocols. The detail “context-

free” vs “regular” is not important in our setting, so

we will use FreeST for its implementation of session

types (although we could choose any other language

that implements session types

Table 1 presents the different session types and

primitives within the FreeST language. These types

allow the deﬁnition of communication protocols be-

tween threads, with each type being linked to a spe-

ciﬁc primitive. FreeST features several communica-

tion primitives: send and receive are used for trans-

mitting and receiving values, select is used to make

choices within the channel, and match is used to align

with the selected option. The close primitive is used

for channel termination, while the wait primitive is

https://freest-lang.github.io/

https://rss.rd.ciencias.ulisboa.pt/tools/sepi/

https://docs.rs/session types/latest/session types/

Towards a SQL Injection Vulnerability Detector Based on Session Types

713

Table 1: FreeST session type constructor and primitives.

Session Type

Constructor

Behaviour

FreeST

Primitive

send value of type T

send

receive value of type T

receive

+{l: T, ..} select a choice select

&{l: T, ..}

offer a set of choices

match

T ; U do T, then U -

Close close the channel close

Wait

wait for channel to be closed

wait

Skip neutral element of ; -

used to wait for channel termination. The Skip type

is the neutral element of the sequential composition ;.

For example, consider a scenario where a server

thread is responsible for receiving two integers,

checking if their sum exceeds ten and providing the

result. The communication between the client and

server threads can be read as: send the ﬁrst number,

send the second number, and receive a boolean value.

This sequence can be translated into a FreeST proto-

col using the type constructors presented in Table 1,

as shown below:

type protocol = !Int; !Int; ?Bool; Close

Type Checking. Type checking is one of the most

(involuntarily) used static analysis techniques by de-

velopers. It involves checking and validating the types

of values in a programming language and ensuring, at

compile time, that the variables or expressions used in

operations are compatible with their expected types.

Although most programmers are familiar with type-

checking, they may not pay much attention to it since

the rules are already deﬁned by the programming lan-

guage and enforced by the compiler, transparently to

the user. Regardless, type checking, like any other

static analysis method, is not foolproof and can pro-

duce FP and FN. Programmers often overlook these

imperfections, yet they can signiﬁcantly impact vul-

nerability detection (Chess and West, 2007).

3 FREESQLI PROTOTYPE

We aim to develop a static analysis tool to detect SQLi

in PHP code using session types offered by FreeST.

To enable and guarantee the use and practicality of

our tool, session types, FreeST and its compiler are

used in a way that is completely transparent to the

user, so that FreeST goes unnoticed.

We call our tool FREESQLI, and its approach op-

erates in two distinct phases: the translation and the

vulnerability detection, represented in Figure 1. The

translation phase translates the PHP code into FreeST

PHP

Source

Code

Intermediate Language

Code Translator

PHP-IL

Mapping

FreeST Code

Translator

IL-FreeST

Lines Mapping

FreeST Compiler

SQL Injection

Vulnerability

knowledge

FreeST Syntatic

Rules

Vulnerability Detector

Vulnerabilies

Reported

Type

Checking

Rules

FreeSQLi

Translation Phase

Vulnerability Detection Phase

Intermediate

Language (IL)

FreeSTCode

FreeST

Compiler Errors

Figure 1: Architecture of the proposed solution.

code, passing through an intermediate language (IL).

The conversion of PHP into IL enables us to remove

irrelevant syntax from the PHP and simplify the trans-

lation to FreeST. The IL code is then transformed into

FreeST code, including the program deﬁnition and the

protocol speciﬁcation (i.e. the type that should govern

the program). This translation registers the mapping

of the IL lines into FreeST lines to facilitate the gen-

eration of a comprehensive report in the next phase.

Once we have the FreeST code, we are able to

compile it and proceed to the vulnerability detection

phase. The FreeST compiler checks for protocol com-

pliance and identiﬁes type mismatches, generating a

list of errors in case of any inconsistencies. These er-

rors, the source code, and the corresponding mapping

are then used to pinpoint the vulnerabilities in PHP

code and develop a comprehensive report.

We now give a more detailed explanation of

each phase, illustrated by a running example of how

FREESQLI detects SQLi vulnerabilities.

Running Example. Consider the PHP code frag-

ment in Listing 2, which consists of an SQL query

where we limit the number of returned results to 20

and establish an offset, speciﬁed by the user. The code

aims to divide a result set into pages, but it overlooks

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

714

the proper sanitation of the $offset variable. This

oversight creates an opportunity for an attacker to in-

ject malicious code, and since the query relies on this

variable, the code becomes vulnerable to SQLi.

1 $offs e t = $_GET[ ’ offset ’];

2 $q = " S E L ECT id , n a m e F ROM pro d u cts O R D E R B Y

name L I M I T 2 0 O F FSET $offset ;";

3 $r = m y sql i _ que r y ( $conn , $q);

Listing 2: Example of a PHP code vulnerable to SQLi.

Translation Phase. In this phase, we focus on con-

verting the PHP source code into FreeST code. In

PHP (as in other languages), some functions behave

similarly. For example, the entry point functions, like

$_GET and $_POST, invoke different HTTP request

methods, but both consist of receiving user inputs.

With this in mind and to simplify the translation pro-

cess, we start this phase by converting source code

into an IL. The IL allows us to remove unnecessary

PHP code (e.g., comments) without oversimplifying

the program, which could prevent us from detecting

certain vulnerabilities.

The Intermediate Language Code Translator,

shown in Figure 1, converts the PHP code into IL

through a lexer. This translation assigns tokens to in-

dividual PHP functions based on their behaviour, us-

ing the IL-PHP mapping. Since we are translating

to FreeST, we focus on the behaviour of the func-

tions, and the IL already establishes the connection to

the communication protocols (later speciﬁed through

session types). Always taking the application’s point

of view, PHP entry points functions will be trans-

lated into the receive token, PHP functions that con-

sist of sending data (queries) to the database (e.g.,

mysql_query) will be represented in IL by the send

token. We also need tokens that allow us to repre-

sent sanitisation functions (sanit_f), type checking

(typechk) and other functions that do not fall into

the previous categories (e.g., replace_str). Table 2

presents an excerpt of the mapping between these to-

kens and the anticipated behaviour corresponding to

each function. (Note that we are still working with a

small fragment of the PHP language and that we will

extend the translation to other primitives soon.)

Variable names are not altered by the translation

and do not have a speciﬁc token since it could lead

us to lose information. SQL queries are represented

as the token query and its variables since we assume

their safeness depends on the variables they use.

Coming back to our running example, the $_GET

and mysqli_query functions are represented as the

receive and send tokens, respectively, meaning that

the protocol will receive data provided by $_GET

and it will send data (to the database) through

mysqli_query function. Therefore, line 1 of the code

would be translated to $offset receive, while line

3 would become $r send $conn $q. The query on

line 2 would also become $q query $offset. The

complete IL conversion is shown in Listing 3.

1 $offs e t recei v e

2 $q q u e r y $offset

3 $r se n d $conn $q

Listing 3: Conversion of PHP code of Listing 2 to IL.

Once we obtain the IL code, the translation into

FreeST occurs through the FreeST Code Translator,

involving two essential steps: (1) speciﬁcation of the

(translated) FreeST program, and (2) inference of the

expected protocol, by means of a session type.

The ﬁrst step leverages the IL tokens, and the

translator parses the lines of IL code into FreeST us-

ing predeﬁned templates based on the FreeST syntac-

tic rules. In the second step, the translator identi-

ﬁes and speciﬁes protocol deﬁnitions. Here, we use

session types to describe the protocol of the server’s

communication with the user and the database. When

a server receives data from the user via entry points,

he receives unsafe data since it comes from an un-

trusted source. On the other hand, when the server

queries a database, it should send safe data to avoid

possible attacks. For this purpose, we endow the

FreeST language with two new types: Safe and

Unsafe, similar to tainted and untainted variables

used in the literature (Shankar et al., 2001; Dahse and

Holz, 2014). These new types represent whether a

variable can be tampered with. For example, user-

input variables fall under the unsafe category, whereas

data supplied to a sensitive sink should fall under

the safe category. The sanitisation functions (e.g.,

mysqli_real_escape_string) modify the variable

type from Unsafe to Safe. We chose the terms Safe

and Unsafe over tainted and untainted for clarity and

their potential use in FreeST features beyond identi-

fying vulnerabilities. Considering this, we can ob-

serve in Table 3 the correlation between the IL to-

kens that involve communication and their expected

behaviour as a FreeST session type. These correla-

tions allow us to deﬁne the correct communication

protocol based on the IL’s tokens. For example, the

IL receive token represents user input, categorised

as Unsafe due to its untrusted source. This means

that the FreeST session type corresponds to ?Unsafe

(i.e. “receive unsafe”), which means we will use the

primitive receive when translating to FreeST code,

as indicated in Table 1.

In our running example, each IL instruction of

Listing 3 is transformed following a template, result-

ing in the FreeST code of Listing 4.

Towards a SQL Injection Vulnerability Detector Based on Session Types

715

Table 2: PHP-IL Mapping: IL tokens and respective PHP functions.

IL token Description Example of PHP primitives/functions

receive entry point $ GET, $ POST, $ COOKIE, $ REQUEST

send sensitive sink

mysql query, mysql unbuffered query, mysql db query,

mysqli query, mysqli real query

sanit f sanitization function mysql escape string, mysql real escape string

replace str replace string function str replace, str ireplace, substr replace, preg replace, strtr,

typechk type checking function is array, is bool, is callable, is ﬂoat, is int, is null, is string

query SQL query -

Table 3: Correlation between IL and FreeST session types.

FreeST FreeST

IL token Description of expected behaviour session type primitive

receive Receive unsafe input from a user ?Unsafe receive

send Make a safe query to the database !Safe send

1 let ( offset , p rotoc o l ) = re c e ive p r otoco l in

2 let q = q u e r y offse t in

3 let p rotoc o l = send q p r otoco l i n

Listing 4: Code in Listing 3 translated to a FreeST program.

1 type Pr o t ocol = ? U n safe ; ! Safe ; C l o s e

3 serve r : Pr o t ocol - > ()

4 serve r prot o c ol =

5 let ( offset , pr o t ocol ) = r e ceive p rotoc o l in

6 let q = q u ery off s e t i n

7 let pro t o col = send q p rotoc o l in

8 close p rotoc o l

Listing 5: The resulting FreeST code of Listing 2.

It is important to note that in FreeST, the receive

primitive returns a tuple with the received result and

the continuation type (e.g., (offset, protocol) in

Listing 4, line 1), while the send primitive only re-

turns the continuation type. In the second step, we

specify a communication protocol (i.e., a type). The

type is deﬁned based on speciﬁc communication to-

kens like send and receive. For instance, a receive

token appears in line 1, followed by a send token

in line 3. In this particular case, the communication

involves receiving an Unsafe type, sending a Safe

type, and closing the channel. Consequently, the type

for this program would be:

type Protocol = ?Unsafe; !Safe; Close

Once the protocol is deﬁned and the lines are con-

verted based on templates, we add other necessary

FreeST syntax to allow the program compilation. As

the translated instructions are not in the same line as

in the IL, we need to annotate the program with the

type. So, to correctly report the vulnerable part of the

code, we store a mapping between the IL and FreeST

lines for future reference (IL-FreeST Lines Mapping

in Figure 1). The ﬁnal FreeST code for our running

example is depicted in Listing 5.

Vulnerability Detection Phase. In this phase, we

detect SQLi vulnerabilities by relying on the FreeST

compiler to verify if the generated FreeST code fol-

lows the inferred protocol. Using its type checking

rules, the FreeST compiler evaluates if the protocol

is being followed by the (translated) FreeST program

and generates a list of errors in case of type mis-

matches. These errors may occur when, for exam-

ple, the server sends Unsafe data (to the database) us-

ing the primitive send while the protocol requires the

server to do it with Safe values. Such discrepancies

suggest the existence of SQLi vulnerabilities, indicat-

ing the presence of one or more unsanitised variables.

As part of our protocol adherence veriﬁcation, we

have modiﬁed the compiler to include types Safe and

Unsafe and have developed a FreeST module that

speciﬁes the functions needed to properly infer the

type of queries based on the types of their arguments.

This module speciﬁes, for instance, that a query with

one argument with type Unsafe, has type Unsafe:

query : Unsafe -> Unsafe

However, if all arguments in a query are Safe, the

query has type Safe. In the case were the query has

two arguments, we have:

query : Safe -> Safe -> Safe

In short, if some variable in a query statement has

type Unsafe, the query has type Unsafe. Sanitisation

functions transform Unsafe values into Safe values:

sanitise : Unsafe -> Safe

Once the FreeST errors are collected and the map-

ping between IL and FreeST lines is identiﬁed, a re-

port with all SQLi detected is generated. The report

includes queries vulnerable to injections alongside the

unsanitised variables used within these queries. Also,

it speciﬁes the exact line where these vulnerabilities

occur for clear identiﬁcation and resolution.

Coming back to our running example, we need

to compile the resulting FreeST code in Listing 5.

Following the program execution, we notice that the

offset variable is assigned type Unsafe; as q is de-

ﬁned from a query with an argument of type Unsafe,

it also has type Unsafe. And so, in line 7 of the pro-

gram, we send a value of type Unsafe, when we were

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

716

expecting to send a value of type Safe (as indicated

in the type in line 1). As a result, the compiler detects

this error and generates the following message: Could

not match expected type Safe with actual type Unsafe

for expression q, providing details in which lines this

error appears. This message indicates that we tried to

send an Unsafe query to the database when it should

be Safe. Because the query uses the offset variable,

which is an entry point that was not sanitised, we are

in the presence of an SQLi. Based on this compila-

tion error, the vulnerability detector detects this vul-

nerability and generates a report to the user with the

necessary information to correct it:

-----------------------------------------

SQL injections detected: 1

Queries: "SELECT id , name FROM products

ORDER BY name LIMIT 20 OFFSET $offset;"

Vulnerable variables: $offset

-----------------------------------------

4 USAGE EXAMPLE

Listing 6 contains a code example that conventional

static analysis tools may wrongly identify it as vul-

nerable to SQLi. The input received from the user un-

dergoes the substr function, which extracts the ﬁrst

four characters. This substring is not dangerous be-

cause it contains less than ﬁve characters (Medeiros

et al., 2016a) and does not compromise the query,

making this example a false positive (FP) for certain

tools (e.g., (Dahse and Holz, 2014)).

1 $u = $_POST[ ’ user ’ ];

2 $u1 = subs t r ($ u , 0 , 4) ;

3 $q = " S E L ECT * from u s e r s WHERE user = ’".$u1 ." ’";

4 $r = m y sql i _ que r y ( $con , $q );

Listing 6: PHP example without a SQLi vulnerability.

1 type Pr o t ocol = ? U n safe ; ! Safe ; C l o s e

3 serve r : Pr o t ocol - > ()

4 serve r prot o c ol =

5 let (u , p r o tocol ) = rece i v e pr o t ocol in

6 let u1 = s a n itise u1 i n

7 let q = q u ery u1 in

8 let pro t o col = send q p rotoc o l in

9 close p rotoc o l

Listing 7: The resulting FreeST code of Listing 6.

Our approach does not classify this code as an FP

because the substr function is considered a saniti-

sation function if it extracts less than ﬁve characters.

The translated FreeST code for this example is in List-

ing 7. The compiler does not detect any inconsistency

because the sanitise function converts the Unsafe

variable u in a Safe variable u1.

5 RELATED WORK

SQL injections are well-researched and documented

threats, and over the years, various techniques and

tools have been developed to prevent or detect

them (Gould et al., 2004; Halfond and Orso, 2005;

Medeiros et al., 2016b; Medeiros et al., 2016a). These

auxiliary tools aim to help developers reduce the num-

ber of vulnerabilities or accelerate the code review

process. However, their adoption in real-world ap-

plications can vary since developers tend to prioritize

tools that seamlessly integrate into their systems and

offer minimal false-positive rates (Oyetoyan et al.,

2018). In this section, we provide an overview of sev-

eral such techniques and tools.

JDBC-Checker (Gould et al., 2004) is a static code

checker that statically veriﬁes the accuracy of types in

dynamically created SQL queries. It was one of the

earliest static analysis tools, and even if its primary

purpose is not to prevent general SQLi attacks, it can

aid in blocking attacks that exploit type discrepancies

within dynamically generated query strings. It can

help address one of the main issues leading to SQLi

vulnerabilities: the lack of proper validation of input

types. Yet, it is worth noting that JDBC-Checker is

ineffective against more general SQLi, which involve

syntactically and type-correct queries.

Another tool that appeared at an early stage was

AMNESIA (Halfond and Orso, 2005). It uses a model

that combines static analysis with runtime monitoring

to enhance security against SQLi attacks. The process

involves a static phase that constructs models of legiti-

mate query types for each database access point using

static analysis. Subsequently, in the dynamic phase,

queries undergo interception pre-database execution

and veriﬁcation against the built models. Queries con-

ﬂicting with these models are ﬂagged as SQLi and

prevented from execution. The effectiveness of this

tool is tied to the accuracy of the built query models

and can inﬂuence both FP and FN.

More recently, some tools have focused on detect-

ing various vulnerabilities, not only SQLi, by leverag-

ing some machine learning techniques. One of these

tools is WAP (Medeiros et al., 2016b). The tool uses

taint analysis to detect vulnerabilities and machine

learning to ensure that identiﬁed vulnerabilities are

genuine and not FP. The tool breaks down the code

into smaller parts using a Lexer and organises it into

Towards a SQL Injection Vulnerability Detector Based on Session Types

717

an abstract syntax tree (AST). During the taint anal-

ysis process, WAP looks for vulnerable entry points

and veriﬁes if they compromise any sensitive sink,

considering possible entry point sanitisation through-

out the code. The tool corrects the code automatically.

Unlike WAP, DEKANT (Medeiros et al., 2016a)

differs in how it detects vulnerabilities in PHP code.

Instead of using an AST, it employs taint analysis and

machine learning, breaking the code into tokens and

converting them into an intermediate language (simi-

lar to our approach). DEKANT learns to spot vulner-

abilities by observing Hidden Markov Model (HMM)

sequence models, enabling it to autonomously detect

ﬂaws without relying on explicit detection methods.

The main drawback of employing machine learn-

ing on DEKANT and WAP is their reliance on the

quality of their training datasets. If a poor set is used,

it can lead to large numbers of FP and FN. As a re-

sult, they cannot offer guarantees regarding their pre-

diction or detection abilities, something we want to

reach with our approach.

6 CONCLUSION

In this paper, we propose a novel approach that anal-

yses PHP code’s behaviour to identify vulnerabilities

for SQLi. Looking at the program from the appli-

cation’s point of view, we use session types to iden-

tify communication protocols between the applica-

tion, the user, and the database. Our approach uses

the FreeST programming language in the backend

and capitalises on its compiler and expressive types

to identify type mismatches and infer the existence of

vulnerabilities for SQL injections. Also, we present

FREESQLI, a proof of concept of our approach.

In the near future, we will extend the fragment of

PHP that we are considering to include the if prim-

itive and we will prove results of correctness of our

translations. In addition, we will adapt our FreeST

implementation so that Safe is considered a subtype

of Unsafe, which will enable us to identify second-

order SQLi. We will also evaluate the performance of

our tool. To do this, we will use NIST SARD

, which

offers small synthetic applications. The test suite will

include different scenarios, such as instances where

traditional static analyzers produce false positives and

negatives and patches for vulnerable cases.

https://samate.nist.gov/SARD/

ACKNOWLEDGMENTS

This work was supported by FCT through the project

SafeSessions PTDC/CCI-COM/6453/2020 (http:

//doi.org/10.54499/PTDC/CCI-COM/6453/2020)

and LASIGE Research Unit UIDB/00408/2020

(https://doi.org/10.54499/UIDB/00408/2020) and

UIDP/00408/2020 (https://doi.org/10.54499/UIDP/

00408/2020)

REFERENCES

Achour, M. et al. (2023). PHP Manual. https://www.php.

net/manual/en/.

Almeida, B., Mordido, A., and Vasconcelos, V. T. (2019).

FreeST: Context-free session types in a functional lan-

guage. arXiv preprint arXiv:1904.01284.

Cardelli, L. (1996). Type systems. ACM Computing Surveys

(CSUR), 28(1):263–264.

Chess, B. and West, J. (2007). Secure programming with

static analysis. Pearson Education.

Dahse, J. and Holz, T. (2014). Simulation of Built-in PHP

Features for Precise Static Code Analysis. In NDSS,

volume 14, pages 23–26.

Dardha, O., Giachino, E., and Sangiorgi, D. (2012). Session

types revisited. In PPDP, pages 139–150.

Gould, C., Su, Z., and Devanbu, P. (2004). JDBC checker:

a static analysis tool for SQL/JDBC applications. In

Proceedings. 26th ICSE, pages 697–698.

Halfond, W. G. J. and Orso, A. (2005). AMNESIA: Anal-

ysis and Monitoring for NEutralizing SQL-Injection

Attacks. In IEEE/ACM ASE, page 174–183.

Halfond, W. G. J., Viegas, J., and Orso, A. (2006). A Clas-

siﬁcation of SQL-Injection Attacks and Countermea-

sures. In IEEE ISSSE.

Medeiros, I., Neves, N., and Correia, M. (2016a).

DEKANT: A Static Analysis Tool That Learns to De-

tect Web Application Vulnerabilities. In Proceedings

of the 25th ISSTA, page 1–11.

Medeiros, I., Neves, N., and Correia, M. (2016b). Detect-

ing and removing web application vulnerabilities with

static analysis and data mining. IEEE TR.

Oyetoyan, T. D., Milosheska, B., Grini, M., and

Soares Cruzes, D. (2018). Myths and facts about static

application security testing tools: an action research at

Telenor digital. In XP 2018, pages 86–103.

Pierce, B. C. (2002). Types and programming languages.

MIT press.

Shankar, U., Talwar, K., Foster, J. S., and Wagner, D.

(2001). Detecting format string vulnerabilities with

type qualiﬁers. In 10th USENIX Security Symposium.

Thiemann, P. and Vasconcelos, V. T. (2016). Context-free

session types. In ICFP, pages 462–475. ACM.

Vasconcelos, V. T. (2012). Fundamentals of session types.

Information and Computation, 217:52–70.

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

718
