Vector Based Modelling of Business Processes

Virginia Niculescu

and Maria-Camelia Chis

alit¸

a-Cret¸u

, Cristina-Claudia Osman

and Adrian Sterca

Babes¸-Bolyai University, Cluj-Napoca, Romania

Keywords:

Business Process Formalization, Robotic Process Automation, Execution Optimization.

Abstract:

Robotic Process Automation (RPA) platforms target the automation of repetitive tasks belonging to business

processes, performed by human users. We are trying to increase the level of abstraction in representing com-

plex processes (made from several conceptual operations) for RPA, by using vectors that allow not only a

simple and condensed modelling, but also an efﬁcient way towards obtaining an optimal execution order for

them. Vector-based representation of the processes can serve to optimize the user-speciﬁed execution order of

the conceptual operations that constitute a process. For this, we propose an optimization strategy based on a

heuristic that helps us to rearrange the conceptual operations efﬁciently, thus reducing the total execution time

of the process.

1 INTRODUCTION

Robotic Process Automation (RPA) is generally de-

ﬁned as the application of speciﬁc methodologies

and technologies that aim to automate repetitive

tasks achieved usually by human users (Institute for

Robotic Process Automation, 2015), (Hofmann et al.,

2020). Current RPA platforms allow an increase in

work efﬁciency and accuracy by automatizing busi-

ness processes and executing them in a more ro-

bust way by avoiding possible human errors. RPA

refers to those tools that operate on the user inter-

face (UI) aiming to perform automation tasks using

an ”outside-in” approach. The information systems

are kept unchanged, compared to the traditional work-

ﬂow technology, which allows the improvement us-

ing an ”inside-out” approach (Van-der Aalst et al.,

2018). RPA frameworks (e.g., UiPath, Automation

Anywhere, Blue Prism, Microsoft Power Automate,

etc.) operate (i.e. create automated business pro-

cesses) in the following way: RPA developers identify

UI components of a software application like buttons,

text input controls, drop-down lists, and tables, and

then customize activities by writing code snippets in

a programming language to act on these UI controls

https://orcid.org/0000-0002-9981-0139

https://orcid.org/0000-0002-1414-0202

https://orcid.org/0000-0002-9706-2915

https://orcid.org/0000-0002-5911-0269

(e.g. click the selected button, writing data in the text

input, select all data from a table or a drop-down list,

etc.); this code that references the selected UI con-

trols forms the automated business process which can

be executed many times later with different input pa-

rameters.

The original contributions presented in the paper

can be summarized as follows: (i) a new vector-based

representation of processes using building blocks; (ii)

an optimization heuristic for executing business pro-

cesses represented in vector spaces.

The rest of the paper is structured as follows: Sec-

tion 2 provides related work about vector-based rep-

resentation approaches for business processes. Vec-

tor representation of the processes is introduced in

Section 3, while Section 4 describes the process ex-

ecution optimization practical aspects together with

the optimization heuristic designed to enhance exe-

cution efﬁciency. The paper concludes with the ﬁnal

remarks.

2 RELATED WORK

There are various deﬁnitions of business processes,

most of them focusing on the ﬂow of data and use of

information and resources (OMG, 2013), (Harmon,

2016). Processes can be modeled using graphical

representations like standardized or non-standardized

modelling languages. The most common modelling

Niculescu, V., Chis

ali¸t

a-Cre¸tu, M., Osman, C. and Sterca, A.

Vector Based Modelling of Business Processes.

DOI: 10.5220/0012739100003687

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2024), pages 735-742

ISBN: 978-989-758-696-5; ISSN: 2184-4895

735

languages used in process representations are Event-

driven Process Chains (EPCs) (Keller et al., 1992) and

BPMN (Business Process Model Notation) (OMG,

2013) diagrams. On the other hand, a mathemati-

cal modelling language suitable for representing pro-

cesses is Petri Nets (Petri, 1962).

The utilization of vectors for representing and an-

alyzing business processes has been extensively dis-

cussed in the literature, particularly to calculate sim-

ilarity. (Jung et al., 2009) convert business process

models into vector representations, considering both

activities and transitions. Their objective is to assess

the similarity of process models represented as vec-

tors by using the Cosine metric. Vector spaces can

also be employed to aggregate activities using the K-

means clustering algorithm (Smirnov et al., 2011). In

(Smirnov et al., 2011) there are two vector spaces,

the ﬁrst one consists of the properties associated with

the activities (heterogeneous vector space). The sec-

ond vector space refers to the dimensions that corre-

spond to the property values of a particular type of

activity (homogeneous vector space). (Dijkman et al.,

2011) deﬁne three metrics for determining the simi-

larity between business process models: node similar-

ity, structural similarity, intended behavior similarity.

The vector space document is deﬁned in (Salton et al.,

1975) as a collection of process models (documents),

together with a set of index terms for indexing the

documents and an index vector for each document.

These metrics have been implemented in the ProM

Framework (Van Dongen et al., 2005).

The data perspective of a process model is also

important. Therefore, data-aware methods for mea-

suring business process similarity are also analyzed

(Yu et al., 2013), and(Amiri and Koupaee, 2017). An

extension of Petri Nets in the context of e-commerce

- EBPN (E-commerce Business Process Net) is pro-

posed by (Yu et al., 2013). The similarity of activities

is measured by considering their access to data (Amiri

and Koupaee, 2017).

Business process variants refer to different ver-

sions or iterations of a business process that can vary

based on various criteria (Taymouri et al., 2021).

3 VECTOR REPRESENTATION

In this paper, the term concept refers to the data stored

in a database table, while entity refers to a row/record

of a database table. A concept always describes a set

of entities. In a previous work (Sterca et al., 2023)

we proposed a web automation tool that automati-

cally translates human user operations on the UI of

a target web application onto conceptual operations

in the underlying database (e.g. adding a new account

to the database, updating a contact entity). This web

automation tool takes the form of a browser plugin.

More speciﬁcally, the human user guides the automa-

tion tool (by navigating in the target business web ap-

plication) so that the plugin discovers what we call

primary blocks for process automation - which is an-

other name for a conceptual operation. After the plu-

gin discovers primary blocks, it can also execute au-

tomatically such primary blocks on the target web ap-

plication or it can form complex processes with the

discovered primary blocks and it can execute those

too.

We propose in this paper an approach for mod-

elling complex processes based on deﬁning an opera-

tion vector for each concept and considering all these

vectors together to characterize a process made from

several conceptual operations (i.e. primary blocks)

across different concepts. In the remaining of the pa-

per, but mostly in the present section, we will use the

terms building block and conceptual operation inter-

changeably.

3.1 Base Vectors for Building Blocks

The building blocks discovered by the plugin tool rep-

resent all possible conceptual operations executed by

the software robot. They are, as their name implies,

all the ingredients the robot can use when executing

automatic processes. To inform the robot regarding

the operations that should be executed, we need to

have a model of representation for the set of all these

building blocks in a way simple enough to be inter-

preted by the robot and, at the same time, ﬂexible to

possible optimizations.

For example, let’s assume that for a concept Ac-

count, the following ﬁve building blocks have been

discovered: SellectAll, Insert, Update, Delete and De-

activate.

We consider a predeﬁned order between these: Se-

lectAll, Insert, Update, Delete, and Deactivate.

Consequently, for the representation of the build-

ing blocks working with the concept Account, we pro-

pose using the following base vectors:

• e

= (1, 0, 0, 0, 0) – SelectAll

• e

= (0, 1, 0, 0, 0) – Insert

• e

= (0, 0, 1, 0, 0) – Update

• e

= (0, 0, 0, 1, 0) – Delete

• e

= (0, 0, 0, 0, 1) – Deactivate

Similar to the building blocks representation for

the Account concept, we can deﬁne base vectors for

all the concepts managed by an application. Still, the

number of building blocks – b– may vary from one

concept to another or from one application to another.

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

736

3.2 Abstract Process Representation

Considering a real application that works with the

concepts C

, . . .C

, the modelling of a correspond-

ing process could be done with one vector having the

size equal to b ∗ k, where b is the number of all possi-

ble building blocks for each concept and k is the num-

ber of concepts handled in the application.

A series of conceptual operations (i.e. building

blocks) upon a concept C can be represented as a vec-

tor :

= (n

· e

)

where n

are the number of SellectAll operations upon

C, n

are the number of Insert operations upon C, etc.

If we consider a predeﬁned order between the con-

cepts, the operations on all the concepts could be rep-

resented as:

P = ()

++ ()

....

where the operator ++ is the concatenation operator.

This modelling is possible if there is a predeﬁned

order established between all the concepts, and we

consider that for all concepts we have the same num-

ber b of possible operations applied to them. The pre-

deﬁned order does not specify implicit constraints be-

tween the concepts - it is deﬁned just to have a struc-

tured way of modelling.

A general process could be represented as one

vector of size b ∗ k, (e.g., b = 5, k = 5), obtained

through the concatenation of the vectors correspond-

ing to the operations identiﬁed for each concept.

P =

i=1

· e

++ n

· e

++ n

· e

++ n

· e

)

where

is the concatenation operator.

The type of operations that are speciﬁed in a pro-

cess could be represented using a vector O that ex-

presses only the fact that one type of operation is or is

not included. This could be deﬁned as:

O =

i=1

· e

++ x

· e

++ x

· e

++ x

· e

)

where x

could be either 0 or 1.

In addition, the number of operations n

, n

, ...

may be aggregated in a vector M, as follows:

M =

i=1

++ n

)

Therefore, the process representation is a pair of

vectors (O, M) and the process is

P = O ⊙ M,

where ⊙ is the element-wise product (Hadamard

product (Horn, 1990)) of the operations vector O and

the multiplicity vector M.

Remarks:

• If the number of possible operations differs from

one concept to another the following two options

could be applied:

– to consider b as being the maximum num-

ber of operations possible to be applied on

any concept; based on the concepts’ order the

start index for each concept could be identiﬁed

(modulo b operation).

– to deﬁne a conﬁguration that speciﬁes the num-

ber of operations on each concept together with

their signiﬁcance; this conﬁguration will al-

low computing the start index corresponding to

each concept.

• The concrete parameters of each operation are

considered to be part of the data plan and will

be speciﬁed separately by the abstract vector rep-

resentation of the process in order not to over-

load the abstract representation. For example,

for the operations Insert of the concept Account

(e2

Account

), the data plan should contain parame-

ters in the following form:

Account

AccountName : ”CompanyA”, Email : ” john@..”, ...,

AccountName : ”CompanyB”, Email : ” jane@..”, ...,

...

• The relations between the concepts emphasized

by the relations between the corresponding tables

of the database may emphasize an order between

the operations on different concepts. These re-

lations are static – they are not supposed to be

changed during the application usage. Still, since

these dependencies could be cyclic, we cannot

consider that the operations may be executed in

the order they appear in the vector representation.

The execution order should be primarily based on

the order given by the user.

• A complete representation of a process should in-

clude besides the vector P, the associated data plan

that contains all the corresponding data parame-

ters, and an execution order.

3.3 Example of a Process

Representation

To illustrate this modelling we will consider an ex-

ample with the following concepts Account, Contact,

Lead, Appointment, Opportunity, which are the 5 con-

cepts identiﬁed in Microsoft Dynamics 2016 CRM

https://www.microsoft.com/en-us/dynamics-365

Vector Based Modelling of Business Processes

737

The order between the concepts is that given by the

previous enumeration.

Since in this case, we will have 5 possible building

blocks for each concept, as a result, the vectors that

represent the processes will have a size equal to (5

concepts x 5 operations/concept).

A particular process that we consider may consist

of the following conceptual operations:

Listing 1:

1. (Insert Contact C1)

2. (Update Lead L1)

3. (Insert Account A1)

4. (Update Account A1) - using Lead L1

5. (Insert Contact C2)

6. (Update Account A2) - using Contact C2

7. (Delete Appointment X1)

8. (Insert Account A3)

9. (Delete Opportunity O1)

10. (Deactivate Opportunity O2)

11. (Delete Appointment X2)

12. (Insert Opportunity O3)

13. (Update Account A1) - using O3

14. (Update Lead L2)

15. (Delete Account A4)

We assume that the order of the operations provided

by the user is valid, i.e., update, delete, and deactivate

operations that are used for the entities available in the

database may be successfully executed. The vector-

based representation of the above process, where the

concepts are ordered as Account, Contact, Lead, Ap-

pointment, and Opportunity, is the following:

P = (0,2,3,1,0; 0,2,0,0,0; 0,0,2,0,0; 0,0,0,2,0; 0,1,0,1,1)

The corresponding O and M vectors are:

O = (0,1,1,1,0; 0,1,0,0,0; 0,0,1,0,0; 0,0,0,1,0; 0,1,0,1,1)

M = (0,2,3,1,0; 0,2,0,0,0; 0,0,2,0,0; 0,0,0,2,0; 0,1,0,1,1)

The execution order as speciﬁed by the user is

E = ( [],[3,8],[4,6,13],[15],[];

[],[1,5],[],[],[];

[],[],[2,14],[],[];

[],[],[],[7,11],[];

[],[12],[],[9],[10] )

where for each type of operation is provided a list of

indices that states the order of each concrete operation

in the process speciﬁed by the user. An empty list []

suggests that the corresponding operation is not part

of the process.

3.4 Usefulness of the Vector

Representation

Representing complex automated processes as vec-

tors has several beneﬁts. The ﬁrst one would be

that we can easily compare different processes. In

our previous work that describes the browser plugin

used for web automation, we represented complex

processes as JSON (Javascript Object Notation) ex-

pressions which included both the conceptual oper-

ations and their arguments (i.e the data plan). Using

such representation it is difﬁcult to decide if two com-

plex processes (made from tens of building blocks)

are equal (i.e. they have the same building blocks, but

maybe in a different order) or one of them is a pre-

ﬁx/sufﬁx of another or they both have a common sub-

part. By using the representation of a process as a P

vector and dissociating the data plan, these decisions

are more readily made. Such comparisons between

processes are useful in process mining.

Representing a complex process as a vector can

also be helpful when trying to optimize the execu-

tions of the conceptual operations that make a com-

plex process. The next section discusses the possible

execution optimizations and introduces an optimiza-

tion heuristic for improving the process execution ef-

ﬁciency based on the vector representation previously

discussed.

4 PROCESS EXECUTION

OPTIMISATION

Complex business processes emphasize the existence

of multiple similar operations that, most of the time,

are spread over the entire process. Optimizing the ex-

ecution of operations within a process can be achieved

based on the paths chosen by the user at the UI level.

4.1 Concrete Example

We consider the following complex process that per-

forms operations on Account and Contact concepts

available in the Microsoft Dynamics 2016 CRM ap-

plication. The access paths to operations, starting

from the root node, are:

• (BurgerMenu→Sales→Contacts→New C1→Save),

• (BurgerMenu→Sales→Accounts →New A1→Save),

• (BurgerMenu→Sales→Accounts→UpdateA1→Save),

• (BurgerMenu→Sales→Contacts→New C2→Save),

• (BurgerMenu→Sales→Accounts→New A2→Save),

• (BurgerMenu→Sales→Accounts→Update A2→Save)

BurgerMenu refers to a global menu of the appli-

cation, Sales is a submenu of the BurgerMenu and

Contacts is a submenu item of submenu Sales. In-

sert C1 is the UI form that allows a new Contact C1

to be added to the underlying database (this UI form

is triggered by the user when clicking on a New-like

button). Save is just the Save button of the application

that triggers the saving of the currently added Contact

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

738

entity. Similarly, there are other examples of navi-

gation paths in the above example: a navigation path

for adding a new Account, A1 and respectively A2,

and a navigation path for updating an existing Ac-

count. For automatic execution, each line represents

one building block. For example, when executing the

ﬁrst building block, the automation tool must click on

the BurgerMenu, then it must click on the Sales sub-

menu, then it must click on the Contacts submenu,

then it must trigger a click on the button that allows

the user to add a new Contact and after ﬁlling all the

required ﬁelds, it will ﬁnally click on the Save button.

A more efﬁcient way to execute the speciﬁed pro-

cess is to group the operations of the same type:

• (BurgerMenu→Sales→Contacts→

– New C1→Save

– New C2→Save)

• (BurgerMenu→Sales→Accounts→

– New A1→Save

– New A2→Save

– Update A1→Save

– Update A2→Save)

The optimization of the process execution reﬂects

the possibility of avoiding several BurgerMenu-based

actions that occur in a full path operation execution.

This results in a reduced number of interactions with

the UI elements that increase efﬁciency and decrease

the execution time.

4.2 Optimisation Heuristic

Based on the vector process representation speciﬁed

in section 3 we propose a strategy for obtaining an

optimized execution.

The optimization strategy is based on a heuristic

elaborated on the following observations: (i) clus-

tering the operations of identical types on the same

concept improves the efﬁciency of the execution (by

eliminating the need for full path menu navigation);

(ii) Insert operations should be executed ﬁrst (they

should not be postponed); (iii) Update, Delete and

Deactivate operations could be postponed - they are

constrained only by the previous speciﬁc Insert oper-

ations.

Following the vector modelling of the process we

will use similar vectors to compute the clusters (group

of operations that should be executed at the same

stage). In this case, we will store into the vector, not

the number of operations but their order in the execu-

tion.

Starting from the order given by the user, the fol-

lowing mathematical rules should be applied when

clusters are created:

• if two or more Insert operations on the same con-

cept appear in the user list, then the minimum po-

sition should be considered for them;

• if two or more Update, Delete or Deactivate oper-

ations on the same concept appear in the user list,

then the maximum position should be considered

for them.

For the business process provided in Subsection

3.3 we deﬁne a vector that helps us to rearrange these

primary block operations to optimize the execution on

the interface. The execution vector is similar to that

used for modelling a process (see Subsection 3.1), but

it contains the execution order of the operations, in-

stead of the number of operations of the same type

included in the process.

The application of the proposed heuristic points

out three stages. The ﬁrst stage corresponds to creat-

ing clusters of similar operations on the same concept

that use different entities.

The ﬁrst cluster consists of operations (Insert

Contact C1) and (Insert Contact C2) that had the ini-

tial execution orders 1 and 5. They are placed in

the same group, with the intent to execute based on

the min rule, deﬁned for the Insert operation, i.e.,

min(1, 5) = 1.

For operations (Update Account A1) - using Lead

L1 and (Update Account A2) - using Contact C2, a

cluster is created considering the max rule for the Up-

date operation, i.e., max(4, 6) = 6, where 4 and 6 were

in the initial order of these Update operations.

The second stage is represented by the application

of the rule that allows to group clusters for Update,

Delete, and Deactivate operations that work on the

same concept and postpone it. Therefore, the concept

Contact emphasizes clusters 13 and 15 for the Up-

date and Delete operations. The max rule is applied

to them, i.e., max(13, 15) = 15 meaning that Update

operations from cluster 13 will be postponed and ex-

ecuted together with cluster 15.

The last stage allows to normalize the cluster

identiﬁers in the execution vector, by providing new

cluster identiﬁers in ascending order with no gaps be-

tween subsequent clusters. The stage is required as

the previous phases created clusters or grouped mul-

tiple clusters to the larger identiﬁer, causing gaps in

cluster numbering.

Since the operations Update, Delete and Deacti-

vate are all commutative, we may try to cluster these

operations on each concept. To do this, for each con-

cept, we change the values corresponding to these op-

erations with the maximum value of them. The 0 val-

ues are not modiﬁed since they emphasize that there

is no such operation.

From this vector, we can obtain a better order of

Vector Based Modelling of Business Processes

739

Listing 3: Step 1 – (Insert Contact C1)

0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Step 2 – (Update Lead L1)

0 0 0 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 0 0 0 0 0 0 0

Step 3 – (Insert Account A1)

0 3 0 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 0 0 0 0 0 0 0

Step 4 – (Update Account A1) - using Lead L1

0 3 4 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 0 0 0 0 0 0 0

Step 5 – (Insert Contact C2) => min(1,5)=1

0 3 4 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 0 0 0 0 0 0 0

Step 6 – (Update Account A2) - using Contact C2 => max(4,6)=6

0 3 6 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 0 0 0 0 0 0 0

Step 7 – (Delete Appointment X1)

0 3 6 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 7 0 0 0 0 0 0

Step 8 – (Insert Account A3) => min(3,8)=3

0 3 6 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 7 0 0 0 0 0 0

Step 9 – (Delete Opportunity O1)

0 3 6 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 7 0 0 0 0 9 0

Step 10 – (Deactivate Opportunity O2)

0 3 6 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 7 0 0 0 0 9 10

Step 11 – (Delete Appointment X2) => max(7,11)=11

0 3 6 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 11 0 0 0 0 9 10

Step 12 – (Insert Opportunity O3)

0 3 6 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 11 0 0 12 0 9 10

Step 13 – (Update Account A1) - using O3 => max(6,13)=13

0 3 13 0 0 0 1 0 0 0 0 0 2 0 0 0 0 0 11 0 0 12 0 9 10

Step 14 – (Update Lead L2) => max(2,14)=14

0 3 13 0 0 0 1 0 0 0 0 0 14 0 0 0 0 0 11 0 0 12 0 9 10

Step 15 – (Delete Account A4)

0 3 13 15 0 0 1 0 0 0 0 0 14 0 0 0 0 0 11 0 0 12 0 9 10

Step 16 – Grouping Update, Delete, and Deactivate

0 3 15 15 0 0 1 0 0 0 0 0 14 0 0 0 0 0 11 0 0 12 0 10 10

Step 17 – Normalization

0 2 7 7 0 0 1 0 0 0 0 0 6 0 0 0 0 0 4 0 0 5 0 3 3

execution. For each operation of a certain type, we

obtain the number of the cluster by taking the corre-

sponding value from the vector. Since it is based on

applying a heuristic, this order is not optimal from

an efﬁciency point of view, but it increases the efﬁ-

ciency by grouping certain operations applied to the

same concept.

Therefore, the execution order of the operations

from the initial process is the following:

Listing 2:

1. (Insert Contact C1)

1. (Insert Contact C2)

2. (Insert Account A1)

2. (Insert Account A3)

3. (Delete Opportunity O1)

3. (Deactivate Opportunity O2)

4. (Delete Appointment X1)

4. (Delete Appointment X2)

5. (Insert Opportunity O3)

6. (Update Lead L1)

6. (Update Lead L2)

7. (Update Account A1) - using Lead L1

7. (Update Account A2) - using Contact C2

7. (Update Account A1) - using O3

7. (Delete Account A4)

The execution order vector speciﬁes the cluster

for each operation speciﬁed by the process vector de-

scribed in Section 3, i.e. the corresponding index in

the execution vector represents the cluster number of

the operations speciﬁed by the process vector.

P = (0,2,3,1,0; 0,2,0,0,0; 0,0,2,0,0; 0,0,0,2,0; 0,1,0,1,1)

= (0,2,7,7,0; 0,1,0,0,0; 0,0,6,0,0; 0,0,0,4,0; 0,5,0,3,3)

For example, the value on the second index in the

vector P speciﬁes two Insert operations on concept

Account which, based on the second value in vector E

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

740

will be executed in cluster 2. The order between the

operations in one cluster is given by the initial user

order.

Compared to the initial execution vector E, the op-

timized execution vector E

obtained after the heuris-

tic application will not have associated a list of indices

for every concept operation, but a single value, i.e., a

cluster identiﬁer. This indicates a simpliﬁed and im-

proved variant of the initial execution vector.

For instance, in the execution vector E for the Ac-

count concept there are the lists of operations [4, 6, 13]

and [15] that are associated with the Update and

Delete conceptual operations. This involves the ex-

ecution of operation 4 - (Update Account A1) - using

Lead L1, followed by operation 5 - (Insert Contact

C2), meaning that the user needs to switch from con-

cept Account to concept Contact.

The optimisation heuristic applied step-by-step on

the previous process example is available in Listing 3.

By grouping similar operations on the same concept

that use different entities in the same cluster, e.g., (In-

sert Contact C1) and (Insert Contact C2) in cluster

1, they are executed together, reducing the number of

interactions with the user interface components, e,g,

buttons, and the lowering the execution time.

The validation rule that ensures the fact that each

operation is included in an execution cluster and there

are no empty clusters is:

For every non-zero index of the process representation

vector, there is a non-zero index that corresponds to

an identiﬁed cluster in the process execution vector.

4.3 Numerical Evaluation

We can evaluate the time reduction obtained when

executing a complex process like the one depicted

in Listing 1 from section 3.3 using the optimization

heuristic execution described in sections 4.2, by con-

sidering what happens when our automation browser

plugin executes a single building block. Even if, the

evaluation in this section is applied to a concrete ex-

ample from Microsoft Dynamics 2016 CRM, the re-

sults should be similar to other business web applica-

tions although the actual time reduction value can be

different.

When executing the ﬁrst building block of the pro-

cess depicted in Listing 1, our automation browser

plugin must click on the BurgerMenu, then it must

click on the Sales submenu, then it must click on the

Contacts submenu, then it must trigger a click on the

button that allows the user to add a new Contact and

after ﬁlling all the required ﬁelds, it must ﬁnally click

on the Save button. After triggering each click event,

the plugin must wait a time interval so that this click

event is handled by the web application. The han-

dling of a click event can consist of a complete doc-

ument reload or one or several XHR requests accom-

panied by DOM (Document Model Object) updates

in the current document. But our automation browser

plugin has no way of knowing how much time to wait

for the completion of the handling of the click event.

So it always waits for a speciﬁc time interval, t

delay

after it triggers a UI event (e.g. a click). For Microsoft

Dynamics 2016 CRM application t

delay

= 5 seconds.

If we ignore the time duration of triggering click

events and ﬁlling text inputs and assume that it is 0,

then the time duration of executing the (Insert Contact

C1) building block is equal to 5 · t

delay

seconds. This

is because clicking on the BurgerMenu takes t

delay

seconds, then clicking on the Sales submenu takes

another t

delay

seconds, then clicking on the Contacts

submenu takes another t

delay

seconds, then clicking

the New button takes another t

delay

seconds, and ﬁ-

nally, clicking on the Save button takes t

delay

seconds.

But if the next building block executed af-

ter (Insert Contact C1) is (Insert Contact C2) as

in Listing 1 from section 5.2, then the preﬁx

(BurgerMenu→Sales→Contacts) of the second build-

ing block’s path is no longer required because we are

operating on the same concept (so we don’t have to

go through all menus starting from the top-level one).

In order to execute block (Insert Contact C2), we just

need to click on the New button which takes t

delay

sec-

onds and then click on the Save button which takes

delay

seconds. So in total, the second building block

took only 2 ·t

delay

seconds when using the heuristic.

We can compute in this way the time duration of

executing the same process in the initial order (given

by the user) depicted in Listing 1 and compare it with

the time duration of executing the process in the order

given by our heuristic - which is depicted in Listing

2. This comparison is presented in Table 1, where

each line represents the time duration of executing

the corresponding building block in both execution

orders. For example, line 2 represents the time dura-

tion when executing (Update Lead L1) from Listing

1 and, respectively, the time duration when executing

(Insert Contact C2) from Listing 2. Table 1 shows

that when using our heuristic we obtain a time reduc-

tion of 18 · t

delay

= 18 · 5 = 90 seconds (for Microsoft

Dynamics 2016 CRM t

delay

= 5 seconds).

5 CONCLUSIONS

The paper introduces a formal representation of busi-

ness processes that uses base vectors for the opera-

tions on the concepts managed by an application. A

Vector Based Modelling of Business Processes

741

Table 1: Time comparison between the user given execution

order and the heuristic given execution order.

Operation no. Listing 1 order Listing 2 order

1 5 ·t

delay

5 ·t

delay

2 5 ·t

delay

2 ·t

delay

3 5 ·t

delay

5 ·t

delay

4 2 ·t

delay

2 ·t

delay

5 5 ·t

delay

5 ·t

delay

6 5 ·t

delay

2 ·t

delay

7 5 ·t

delay

5 ·t

delay

8 5 ·t

delay

2 ·t

delay

9 5 ·t

delay

5 ·t

delay

10 2 ·t

delay

5 ·t

delay

11 5 ·t

delay

2 ·t

delay

12 5 ·t

delay

5 ·t

delay

13 5 ·t

delay

2 ·t

delay

14 5 ·t

delay

2 ·t

delay

15 5 ·t

delay

2 ·t

delay

Total 69 ·t

delay

51 ·t

delay

process is abstractly represented by a vector formed

by concatenating the vectors representing operations

on each concept. Such a process vector emphasizes

the types of operations included in the process and

their number. This is useful when comparing two pro-

cesses and when doing process mining.

The approach offers several beneﬁts and opens

new research perspectives. It provides a consistent

representation of concepts, processes, dependencies,

and operation multiplicity due to the vector-based

representation.

Application maintenance and upgrades may be

easily accommodated with our vector-based approach

when new concepts, attributes, or operations are

added to the application.

Additionally, we propose a heuristic for process

execution optimization. The heuristic is based on

grouping operational blocks that form a process into

clusters that specify an optimized execution order.

The clusters are speciﬁed using again a vector repre-

sentation that speciﬁes for each type of operation the

cluster to which it belongs. This organization of the

operations into clusters leads to a more efﬁcient exe-

cution by shortening the navigation paths through the

UI interface and thus, reducing execution time. More-

over, the identiﬁcation of clusters of non-conﬂicting

operations eases the identiﬁcation of operations eligi-

ble for parallel execution.

REFERENCES

Amiri, M. J. and Koupaee, M. (2017). Data-driven business

process similarity. IET Software, 11(6):309–318.

Dijkman, R., Dumas, M., Van Dongen, B., K

arik, R., and

Mendling, J. (2011). Similarity of business process

models: Metrics and evaluation. Information Systems,

36(2):498–516.

Harmon, P., editor (2016). Business Process Change A

Business Process Management Guide for Managers

and Process Professionals, Third Edition. Morgan

Kaufmann.

Hofmann, P., Samp, C., and Urbach, N. (2020). Robotic

process automation. Electronic Markets, 30(1):99–

106.

Horn, R. A. (1990). The hadamard product. In Proc. Symp.

Appl. Math, volume 40, pages 87–169.

Institute for Robotic Process Automation (2015). Introduc-

tion to robotic process automation. A primer.

Jung, J.-Y., Bae, J., and Liu, L. (2009). Hierarchical clus-

tering of business process models. International Jour-

nal of Innovative Computing, Information and Con-

trol, 5(12):1349–4198.

Keller, G., Scheer, A.-W., and N

uttgens, M. (1992). Se-

mantische Prozeßmodellierung auf der Grundlage”

Ereignisgesteuerter Prozeßketten (EPK)”. Inst. f

Wirtschaftsinformatik.

OMG (2013). Business Process Model and Notation

(BPMN) Speciﬁcation, Version 2.0.2.

Petri, C. A. (1962). Kommunikation mit Auto-

maten. Dissertation, Schriften des IIM 2, Rheinisch-

Westf

alisches Institut f

ur Instrumentelle Mathematik

an der Universit

at Bonn, Bonn.

Salton, G., Wong, A., and Yang, C. S. (1975). A vector

space model for automatic indexing. Communications

of the ACM, 18(11):613–620.

Smirnov, S., Reijers, H. A., and Weske, M. (2011). A se-

mantic approach for business process model abstrac-

tion. In Advanced Information Systems Engineering:

23rd Int. Conf., CAiSE 2011, London, UK, June 20-

24, 2011. Proceedings 23, pages 497–511. Springer.

Sterca, A., Niculescu, V., Chis

alit¸

a-Cret¸u, M.-C., and Os-

man, C.-C. (2023). Primary building blocks for web

automation. In Zhang, F., Wang, H., Barhamgi, M.,

Chen, L., and Zhou, R., editors, Web Information Sys-

tems Engineering – WISE 2023, pages 376–386, Sin-

gapore. Springer Nature Singapore.

Taymouri, F., La Rosa, M., Dumas, M., and Maggi, F. M.

(2021). Business process variant analysis: Sur-

vey and classiﬁcation. Knowledge-Based Systems,

211:106557.

Van-der Aalst, W. M. P., Bichler, M., and Heinzl, A. (2018).

Robotic process automation. Business and Informa-

tion Systems Engineering, 60:269–272.

Van Dongen, B. F., de Medeiros, A. K. A., Verbeek, H.,

Weijters, A., and van Der Aalst, W. M. (2005). The

prom framework: A new era in process mining tool

support. In Applications and Theory of Petri Nets

2005: 26th Int. Conf., ICATPN 2005, Miami, USA,

June 20-25, 2005. Proceedings 26, pages 444–454.

Springer.

Yu, W., Yan, C., Ding, Z., Jiang, C., and Zhou, M. (2013).

Modeling and validating e-commerce business pro-

cess based on petri nets. IEEE Transactions on Sys-

tems, Man, and Cybernetics: Systems, 44(3):327–341.

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

742
