Uncovering Bad Practices in Junior Developer Projects Using Static

Analysis and Formal Concept Analysis

Simona Motogna

, Diana Cristea

, Diana-Florina S¸otropa

and Arthur-Jozsef Molnar

Faculty of Mathematics and Computer Science, Babes¸ -Bolyai University, Cluj-Napoca, Romania

Keywords:

Static Code Analysis, Formal Concept Analysis, Bad Practices, SonarQube.

Abstract:

Static code analysis tools have been widely used as a resource for early error detection in software develop-

ment. This paper explores the use of SonarQube together with Formal Concept Analysis, used for detecting

data clusters, in enhancing source code quality among junior developers by facilitating the early detection

of various quality issues and revealing dependencies among detected issues. We analyze the distribution of

bad-practice issues in junior developers’ projects and show where the main problems occur, as well as the

associations of bad practice issues with other types of issues. We conclude the analysis with a comparison be-

tween Python and Java projects with respect to the mentioned aspects. While focusing the analysis on issues

related to bad practices in both Java and Python projects, the paper aims to to uncover challenges faced by

junior developers in Java and Python projects, promoting awareness of code quality.

1 INTRODUCTION

As the complexity and size of software systems con-

stantly increase, their quality must be an essential ob-

jective through entire life cycle. Quality of the pro-

duced source code should be a primary concern to all

developers, junior and senior all together. Observing

and assessing coding guidelines and best practices in

junior developers’ projects can be a tedious and time

consuming task.

This study shows how static analysis tools can be

successfully used to assess quality aspects in junior

developers’ projects. The main features of such tools

allow early automatic detection of several types of

quality issues, allowing in depth analysis of bad prac-

tices patterns. Code review tools based on static anal-

ysis have been widely adopted by industry, such as

SonarQube which is used in this study, and proved to

be a useful resource to improve quality (McConnell,

2004; Avgeriou and o., 2021).

Data generated by these tools can be further sub-

ject to analysis to detect programmers behavior, com-

mon mistakes or programming concepts misunder-

standing. We have chosen to use Formal Concept

https://orcid.org/0000-0002-8208-6949

https://orcid.org/0000-0003-1440-3786

https://orcid.org/0000-0003-4403-9946

https://orcid.org/0000-0002-4113-2953

Analysis (FCA) for data analysis given previous ap-

plications of this method to similar educational prob-

lems (Duquenne, 2007; Priss, 2013; Priss, 2020;

Cristea et al., 2021).

Both Java and Python are programming languages

intensively used in software development in indus-

try. Python became more and more popular in the

last years due to its versatility, efﬁciency and strong

support for AI/ML application development, so it is

desirable to also have speciﬁc quality gates.

The goal of our study is to investigate the results

of static analysis related to bad practices. For this pur-

pose, we designed and carried a case study on student

projects, developed in Java and Python, and the ﬁnd-

ings can be used to detect dependencies between the

issues detected by static analysis tools, respectively to

observe common mistakes in programming behavior.

The methodology that we apply in our study com-

bines quantitative observations with the strengths of

FCA in order to produce a more precise understand-

ing of the dependencies at code level.

2 THEORETICAL BACKGROUND

Static Analysis Tools. The existing static analysis

tools have undergone a signiﬁcant transformation by

using the abstract syntax tree (AST) to perform source

code analysis and compute several metrics. This has a

752

Motogna, S., Cristea, D., ¸Sotropa, D. and Molnar, A.

Uncovering Bad Practices in Junior Developer Projects Using Static Analysis and Formal Concept Analysis.

DOI: 10.5220/0012739500003687

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2024), pages 752-759

ISBN: 978-989-758-696-5; ISSN: 2184-4895

Table 1: SonarQube rules tagged as bad practice for Java in our extended quality proﬁle, as described in (SonarSource, 2024)

(note that Java rule id’s are preﬁxed with java: (e.g., java:S1215)).

Rule Id Description Type Severity

S1215 Execution of the Garbage Collector should be triggered only by the JVM Code Smell Critical

S2077 Formatting SQL queries is security-sensitive Security Hotspot Major

S5976 Similar tests should be grouped in a single Parameterized test Code Smell Major

S2925 ”Thread.sleep” should not be used in tests Code Smell Major

S1607 JUnit4 @Ignored and JUnit5 @Disabled should be used to disable tests and should provide a

rationale

Code Smell Major

S1181 Throwable and Error should not be caught Code Smell Major

S1161 ”@Override” should be used on overriding and implementing methods Code Smell Major

S1214 Constants should not be deﬁned in interfaces Code Smell Critical

S1123 Deprecated elements should have both the annotation and the Javadoc tag Code Smell Major

S106 Standard outputs should not be used directly to log anything Code Smell Major

S4838 An iteration on a Collection should be performed on the type handled by the Collection Code Smell Minor

S3066 ”enum” ﬁelds should not be publicly mutable Code Smell Minor

S1319 Declarations should use Java collection interfaces such as ”List” rather than speciﬁc imple-

mentation classes such as ”LinkedList”

Code Smell Minor

S1301 ”switch” statements should have at least 3 ”case” clauses Code Smell Minor

S1199 Nested code blocks should not be used Code Smell Minor

S1132 Strings literals should be placed on the left side when checking for equality Code Smell Minor

Table 2: SonarQube rules tagged as bad practice for Python in our extended quality proﬁle, as described in (SonarSource,

2024) (note that Python rule id’s are preﬁxed with python: (e.g., python:S5754)).

Rule Id Description Type Severity

S5754 ”SystemExit” should be re-raised Code Smell Critical

S5712 Some special methods should return ”NotImplemented” instead of raising ”NotImplemented-

Error”

Code Smell Critical

S2077 Formatting SQL queries is security-sensitive Security Hotspot Major

S5806 Builtins should not be shadowed by local variables Code Smell Major

S5706 Special method ” exit ” should not re-raise the provided exception Code Smell Major

S1607 A reason should be provided when skipping a test Code Smell Major

direct impact on the entire development time and also

on the time to ﬁx issues in code (Boehm and Papaccio,

1988; Boehm and Basili, 2001).

SonarQube is one of the most popular and widely

used static analysis tools, providing continuous in-

spection in order to deliver clean code. One of the

reasons for its extensive use is the support offered for

more than 30 programming languages, and integra-

tion with different IDEs. As a functioning principle,

once the code is transformed into an AST, analysis

rules are applied to the tree structure. These rules en-

compass a set of predeﬁned patterns, best practices,

and coding standards that are used to identify poten-

tial issues classiﬁed in: code smells, bugs, vulnerabil-

ities or security hotspots.

SonarQube also assigns a severity level to each

issue: Info, Minor, Major, Critical, and Blocker.

Blocker and Critical detrimentally inﬂuence the sys-

tem. Blocker issues should be handled with higher

priority and considered to have a greater impact. Ma-

jor issues can considerably affect a developer’s pro-

ductivity, while Minor and Info are considered as hav-

ing a reduced impact.

In this study we focus on rules tagged as ”bad

practice”, which, according to SonarQube documen-

tation (SonarSource, 2024), means that they incorpo-

rate a bad design decision. This category is important,

especially for junior developers, since it establishes

some guidelines for making the code easier to under-

stand, update, and maintain over time.

Table 1 comprises the rules tagged with ”bad prac-

tice” deﬁned for Java language, while Table 2 those

for Python, together with their category and severity

level.

Formal Concept Analysis. provides a theoretical

model for clustering data based on lattice theory

(Ganter and Wille, 1999) . The fundamental struc-

tures of FCA are the formal context, i.e. a dataset

containing objects, attributes and a relation between

them, and formal concepts, i.e. maximal clusters of

objects having certain attributes. The concept lattice

provides a visual representation of all concepts of a

context. In the triadic case, FCA additionally contains

conditions as a third dimension (Lehmann and Wille,

1995). The triadic context does not always have a vi-

sual lattice representation. However, when projecting

on one of the dimensions the data can be visualized as

a dyadic lattice. The projection can then be changed

Uncovering Bad Practices in Junior Developer Projects Using Static Analysis and Formal Concept Analysis

753

in order to continue the data exploration ((Rudolph

et al., 2015b)).

Answer Set Programming for FCA. It is known that

FCA has some scalability issues regarding comput-

ing concepts in larger contexts ((Khaund et al., 2023),

(Slezak, 2012)). Most tools cannot compute the con-

cepts of a very large dataset or generate the corre-

sponding lattice. In order to deal with this scalability

issue, we use Answer Set Programming (ASP) (Geb-

ser et al., 2012), which is a declarative approach to

solve NP-hard problems in a time efﬁcient manner.

For this purpose we use the ASP encoding for FCA

(Rudolph et al., 2015a) and the Potsdam answer set

solving collection, Potassco (Potassco, 2024).

3 PROGRAMMING PRACTICES

ASSESSMENT

Our main objective is to analyze bad practice issues

from the perspective of junior developers in the con-

text of Python and Java software projects. We further

divide the main objective in the following research

questions:

RQ1. Which is the distribution of bad practice issues

in the source code?

RQ2. Are bad practice issues associated with other

issues?

RQ3. Is there any similarity between Python and Java

in terms of issues tagged with bad practice?

In RQ1 we focus on the bad practice issues in

terms of occurrence and severity, and we assess which

issues labeled as bad practice are more frequent and

how often they occur. Then in RQ2 we aim to identify

and understand the dependencies with other issues de-

tected by SonarQube, while in RQ3 we compare bad

practice issues from Java and Python projects.

3.1 Data Collection and Processing

Our case study covers three iterations, namely fall

semester of 2020, 2021 and 2022, of the Formal

Languages and Compiler Design mandatory course,

taken by last year undergratuate students of the Com-

puter Science program at the Babes¸-Bolyai Univer-

sity. We assimilate them as being junior developers,

since they have accumulated knowledge in different

programming languages and IDEs, and have spent at

least six weeks at internships in software companies.

As part of laboratory activities, students had to im-

plement two programming assignments (medium size

projects, developed over two to four weeks), using a

language of their choice. Requirements were exactly

the same for all students implementing the same as-

signment. Since most students used either Python or

Java, we focus our case study on the assignments sub-

mitted in these languages.

We conﬁgured SonarQube 9.9.0 to employ an ex-

tended quality proﬁle by activating all static analysis

rules for both Java and Python, with the exception of

rules that enforce coding standards (e.g., location of

curly braces in Java), the use of annotations or those

related to tests (e.g., test method discoverability in

Python). This resulted in a Sonar proﬁle having 588

rules for Java and 205 rules for Python.

The static analysis resulted in 25,665 issues, of

which 2,990 are tagged as bad-practice by Sonar-

Qube. The vast majority of them (2,883 issues) were

found in Java code, with only 107 issues targeting

Python. All issues were categorized as code smells

and thus belong to the maintainability domain. With

regards to severity, there were 22 critical issues, 2,131

major issues and 837 minor issues.

3.2 FCA Applied

When interested in an overview of correlations among

issues in the whole dataset, the visual representation

is not essential, hence using the approach described in

section 2 we compute the concepts using ASP.

For an in depth analysis we have an approach that

supports data exploration and is focused on particular

correlations among issues. In this case, both a visual

lattice representation and a triadic FCA approach can

be useful. Therefore, we use FCA Tools Bundle (Kis

et al., 2016), which, to the best of our knowledge,

is the only tool that includes the triadic navigation

paradigm described in section 2 and also uses ASP for

efﬁciently computing the concepts. For this approach,

we generate a triadic context, where dimensions are

represented by objects, i.e. a collection of projects

with the same requirements denoted 2020-L1, 2021-

L1, 2022-L1, 2020-L3, 2021-L3, 2022-L3, attributes,

i.e. classes from individual projects denoted p1-c1,

p1-c2, etc., p2-c1, p2-c2, etc. (where p1, p2, etc. are

the projects of each collection), and conditions, i.e.

issues. While the analysis is on the whole dataset,

each dyadic projection shows a subset of the data. In

Figure 1 we can see the lattice obtained by projecting

on the collection of projects 2020-L1.

For a better readability of the lattice we use the

sparse representation where each label is represented

only once and we use a functionality of FCA Tools

Bundle that allows hiding a type of labels. In Fig-

ure 1 we hide the object labels represented by classes

of individual projects, since the names of the classes

are not relevant to the analysis. When reading the

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

754

Figure 1: Fragment of dyadic lattice with classes of individual projects as objects and issues as attributes, obtained by pro-

jecting on the collection of projects 2020-L1.

Table 3: SonarQube rules generating bad-practice issues in Java projects.

Rule Id Severity Total number of occurrences

No. of classes in which the issues occurred/

Total no. of classes with issues

S106 major 2044 307 / 6606

S1132 minor 613 150 / 6606

S1319 minor 212 98 / 6606

S1199 minor 9 3 / 6606

S1301 minor 3 3 / 6606

S1161 major 2 1 / 6606

Table 4: SonarQube rules generating bad-practice issues in Python projects.

Rule Id Severity Total number of occurrences

No. of classes in which the issues occurred/

Total no. of classes with issues

S5806 major 85 77 / 1023

S5754 critical 22 18 / 1023

elements of a concept in the sparse lattice represen-

tation one must follow the lattice lines up and down

as described in the following. The concept marked

with red in the zoomed in Figure 1 has one dimen-

sion represented by the projection, {2020-L1}, the

next dimension contains all the objects from the lat-

tice reachable when going downward, {p1-c1, p2-c1,

p3-c1, etc.}, and the third dimension contains all the

attributes reachable when going upward in the lattice,

{confusing, pitfall, bad-practice}.

3.3 Results

We analyze the source code in relation with Sonar

rules that generate bad-practice issues and, based on

our results, we provide answers to the formulated re-

search questions.

RQ1: Which is the distribution of bad practice is-

sues in the source code? We aggregated all the

results of running SonarQube on individual source

code, and then summarize the ﬁndings: bad-practice

occurs in 122 out of the 126 Java projects, with a total

of 2,883 occurrences, as shown in Table 3. In case

of Python, bad-practice occurs in 75 out of the 228

Python projects, with a total of 107 occurrences, as

shown in Table 4.

Bad Practice Issues in Java: As the Table 3 shows,

there is an overwhelming appearance of rule S106 in

the dataset. Rule S106 refers to ”Standard outputs

should not be used directly to log anything”, and ac-

cording to SonarQube documentation, it is generated

by the fact that the program writes directly to the stan-

dard output, instead of abstracting away the output be-

hind a method. Using standard output does not com-

ply to logging requirements, such as to easily retrieve

Uncovering Bad Practices in Junior Developer Projects Using Static Analysis and Formal Concept Analysis

755

the logs, to record the data or to log securely in case

of sensitive data.

Two rules with minor severity that are worth men-

tioning are: i) S1132 that addresses equality method

calls, recommending to replace foo.equals(”bar”)

with ”bar”.equals(foo), in an attempt to prevent rais-

ing null pointer exceptions; and ii) S1319 that signals

cases when a collection implementation class from

java.util.* is used in different typing context of a pub-

lic method, and mostly related to performance.

Starting with version 8.6, introduced in September

2020, SonarQube also provides information about the

clean code attributes, as deﬁned by (Martin, 2008).

Regarding the distribution of concerns for the identi-

ﬁed bad practice issues in Java, all of the mentioned

issues have an impact on maintainability, while as

clean code attributes affected, they include: adaptabil-

ity (S106), intentionality (S1132), respectively con-

sistency (S1319).

Remark 1: Regarding Distribution of Bad Practices

Issues in Java, junior developers seem to produce

clean code, with the exception of one aspect related

to handling of output operations. This has a relative

small impact to maintainability. Only three out of 16

rules are not respected on a meaningful basis, two of

them being minor, and only one major. One important

remark concerning the diffuseness of rule java:S106

is that it appears in the top 10 most violated rules in

(Baldassarre et al., 2020), in a study that considers a

similar context, being the only rule in the bad practice

category.

Bad Practice Issues in Python: The results of our

analysis are summarized in Table 4. In terms of

severity, the rule python:S5754, namely ”SystemExit”

should be re-raised, has a meaningful appearance in

the experiments. Another rule that appears quite of-

ten, of major severity, is python:S5806, which gen-

erates an issue when a local variable name matches

the builtin name, thus builtin name becoming locally

inaccessible. This might be error-prone.

Discussing the clean code attributes in relation to

these bad practice issues in Python, they are all related

to intentionality, deﬁned as code being ”clear, logical,

complete, and efﬁcient”. They affect maintainability,

at a high level.

Remark 2: Regarding Distribution of Bad Practices

Issues in Python, junior developers exhibit problems

when dealing with output operations. Two out of eight

rules are broken, but the severity of these rules are of

concern, being critical and major.

RQ2: Are Bad Practice Issues Associated with other

issues? In order to answer this research question, we

explore the lattices and the concepts created through

FCA as explained in section 3.2. The tool we used,

allowed us to detect the association of tag ”bad prac-

tice” with other tags, namely other types of issues.

Another aspect that we were interested in was that the

associations are relevant in terms of appearance, so

we introduced a threshold of 3%.

Associations of Bad Practice Issues in Java: some

remarks can be drawn from the results in Table 5.

Firstly, the occurrences are below 5%, which consid-

ering the target group of junior developers is a good

sign. The next aspect that we notice is that bad prac-

tice issues are mostly associated with issues tagged as

”cwe” and ”owasp” which correspond to security vul-

nerabilities. This was inferred from a similar situation

as the one presented in Figure 1, involving 307 classes

with attributes {bad-practice, cwe, owasp-a3}.

Also, ”cert”, linked to community developed stan-

dard CERT, is quite related to bad practice issue.

Other associations that have a mentionable occur-

rence refer to: brain-overload (signaling high com-

plexity), pitfall (notifying possible future errors) and

error-handling (several code smell and bug issues re-

lated to handling errors in code).

Remark 3: Regarding association of bad practices

issues in Java, although they have a lower occurrence

ratio, some concerns are raised regarding frequent as-

sociation between bad practice and security issues.

Even if bad practice issues are mostly code smells

(see Table 1) their association with security vulner-

abilities, high complexity and standard coding prac-

tices highlights their importance.

Associations of Bad Practice Issues in Python: Ta-

ble 6 summarizes the lattice exploration for Python

projects, in which we also applied a 3% threshold

for meaningful results. The bad practice issues and

associations with other issues are, in our opinion, in

some cases quite high, between 5 to 9.19%. Regard-

ing the different types of associated issues we notice:

”pitfall” (high possibility to generate future error),

”confusing” (denoting code comprehension difﬁculty,

and in consequence higher maintainability costs) and

”brain-overload” (high complexity indicator). We al-

locate a lower importance to the ”convention” tag, as

it refers to coding conventions.

Remark 4: Regarding association of bad practices

issues in Python, the projects corresponding to ju-

nior developers exhibit a signiﬁcant link to issues re-

lated to high maintainability costs: pitfall, confusing,

brain-overload. 4.50% of the projects expose associ-

ation of bad practice tags with all three other types of

issues.

RQ3: Is there any similarity between Python and

Java in terms of issues tagged with bad practice?

Our dataset consists of two sets of projects with the

same requirements. Based on the fact that the stu-

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

756

Table 5: Frequent issues associated with bad-practice in Java projects (Number, respective percentage of classes in which the

issues occurred / Total no. of classes with issues).

No. Percentage of classes Tag(s)

308 / 6606 4.66% bad-practice

307 / 6606 4.65% bad-practice, cert, owasp-a3

225 / 6606 3.41% bad-practice, cert, owasp-a3, cwe

216 / 6606 3.27% bad-practice, brain-overload

215 / 6606 3.25% bad-practice, cert, owasp-a3, brain-overload

209 / 6606 3.16% bad-practice, pitfall

208 / 6606 3.15% bad-practice, pitfall, cert, owasp-a3

207 / 6606 3.13% bad-practice, error-handling, cert,owasp-a3

Table 6: Frequent issues associated with bad-practice in Python projects (Number, respective percentage of classes in which

the issues occurred / Total no. of classes with issues).

No. Percentage Tag(s)

94 / 1023 9.19% bad-practice

78 / 1023 7.62% bad-practice, pitfall

77 / 1023 7.53% bad-practice, confusing,pitfall

58 / 1023 5.67% bad-practice, brain-overload

47 / 1023 4.59% bad-practice, brain-overload,pitfall

46 / 1023 4.50% bad-practice, brain-overload,confusing,pitfall

33 / 1023 3.26% bad-practice, convention

dents had to implement the same requirements, thus

using the same algorithms, it allows us to explore if

the type of issues that they introduce using Java and

Python are related in any way.

Our ﬁrst observations is that the imbalance be-

tween the number of Java and Python rules in our

extended Sonar quality proﬁle (588 and 205, respec-

tively) is maintained after ﬁltering for rules covering

bad practices. As shown in Tables 1 and 2, our ex-

tended ruleset includes 16 rules for Java and 6 rules

for Python covering bad practices. The only common

rule is S2077, which refers to formatting SQL queries

and which did not generate any issues in our dataset.

While some of the rules are platform-speciﬁc (e.g.,

java:S1181, java:1319), platform-agnostic rules such

as java:S1215 or java:S1199 do not have a Python

equivalent, even when considering rules that are not

tagged as bad-practice.

Tables 3 and 4 illustrate the prevalence of issues

generated by the considered rules. We observe that

only a small number of the considered rules generate

issues; furthermore, most issues are generated by a

small number of rules, which is in line with the ﬁnd-

ings in previous research. (Walkinshaw and Minku,

2018) found that most defects were indeed reported

in a limited number of ﬁles, while the case study

carried out in (Molnar and Motogna, 2020b) showed

that in the case of open-source software analyzed us-

ing SonarQube, around 80% of reported issues were

grouped under a third of all tags.

In our case, we ﬁnd the rules generating the ma-

jority of issues across Java and Python projects are

not comparable. We ﬁnd this to be the result of plat-

form differences combined with the different level of

support these languages have in SonarQube itself.

Remark 5: Regarding the similarity of bad-practice

issues between the studied languages, we believe

that the sound takeaway from a teaching perspec-

tive is to combine the detected issues and adapt ex-

isting teaching techniques in order to mitigate de-

tected bad practices. While python:S5806 highlights

an already well-known bad practice, we can assimi-

late python:S5754 with java:S1181 and highlight the

platform-dependent correct way of handling special

cases of exceptions and program halting.

3.4 Discussion

Understanding and adhering to clean code principles

and best practices, particularly among junior develop-

ers, are essential for producing high-quality software

with improved maintainability and reduced technical

debt. Thus, we consider that investigating bad prac-

tices issues in junior developers code can have a sig-

niﬁcant impact on the way they will evolve and learn.

The ﬁndings of the case study reveals that bad

practices vary dependending on the language (in this

case Java, respectively Python), with a reasonable fre-

quency but they can be associated with other issues in

code. As remarks 3 and 4 has pointed out, we suggest

that classes or modules that expose several code is-

sues at the same time should be candidates for a code

review performed by an experienced developer.

We consider our study to be an experiential report

with impact in education. We encourage the adoption

of static analysis tools, such as SonarQube in soft-

Uncovering Bad Practices in Junior Developer Projects Using Static Analysis and Formal Concept Analysis

757

ware engineering discipline, such that students can be

aware of the importance of the quality of the code they

produce.

The practitioners community can also beneﬁt from

our ﬁndings, both in adopting SonarQube or similar

tools to inspect and manage code quality from early

stages in the development, but also to pay more at-

tention to code fragments that expose several quality

issues simultaneously.

From a research perspective, we show the

strengths of FCA in investigating software quality is-

sues, based on its capabilities to observe relations and

dependencies among attributes and offering several

perspectives (dyadic and triadic) about the data.

4 RELATED WORK

Technical Debt (TD) has raised the interest of the

research community for over 10 years with a large

number of signiﬁcant contributions to the domain as

a systematic literature review records (Murillo et al.,

2023). As SonarQube is one of the most used tools in

industry to detect and manage technical debt, there are

studies that focus on investigating the technical debt

as handled by this tool (Molnar and Motogna, 2020a;

Molnar and Motogna, 2020a; Lenarduzzi et al., 2020;

Baldassarre et al., 2020; Lenarduzzi et al., 2020b),

Similar approaches in which the scope of the re-

search study is to investigate how junior developers

deal with technical debt are (Lenarduzzi et al., 2020a),

(Baldassarre et al., 2020) and (Pl

osch and Neum

uller,

2020). In (Lenarduzzi et al., 2020a), the purpose was

to investigate how junior developers (also last year un-

dergraduate students as in our case) deal with TD pri-

oritization during refactoring, concluding that they fo-

cus homogeneously when dealing with different types

of TD and that they appreciate SonarQube as a tool to

handle the code quality. Junior developers were also

involved in the study (Baldassarre et al., 2020) fo-

cusing on diffuseness and remediation time of Sonar-

Qube issues in relation with their type. The ﬁrst

study (Lenarduzzi et al., 2020a) also considers same

project requirements given to different students as in

our study, while in the second study the junior devel-

opers were asked to address quality issues to a set of

selected open source Java projects. Finally, (Pl

osch

and Neum

uller, 2020) shows that ﬁxing SonarQube

issues signiﬁcantly depends on the experience level

of students.

Regarding comparison dealing with coding prac-

tices and quality issues between Java and Python,

(Tan et al., 2021) perform an empirical study of 44

Python projects from Apache Software Foundation

ecosystem, and compare the remediation effort with

a previous study on Java projects, showing similari-

ties between ﬁxing rates in both languages.

Techniques like FCA, which involve represent-

ing, manipulating, and categorizing data, can be em-

ployed in software engineering to offer solution to

different speciﬁc problems such as software reuse

(Godin et al., 1995), reverse engineering and code

inspection (Dekel, 2002), or concept and fault loca-

tion (Poshyvanyk and Marcus, 2007), or program-

ming style (Cristea et al., 2021). This study shows

another approach in which FCA can be used in inves-

tigating quality issues in data from SonarQube.

5 THREATS TO VALIDITY

We addressed potential threats to our study’s valid-

ity by observing existing best practices for empiri-

cal (Paul Ralph (ed.), 2021) and case study research

(Runeson and H

ost, 2008). In order to facilitate repli-

cating or extending our work, we created a data pack-

age that includes the SonarQube rule conﬁguration

employed together with the anonymized list of issues

resulting from the analysis (Molnar, 2024).

Internal threats were addressed by carrying out

a manual examination of the source code included in

our study. Our reliance on SonarQube as a static anal-

ysis tool can be construed as an internal threat.

We aimed to limit external threats by including

three course iterations in our study in order to improve

data triangulation (Runeson and H

ost, 2008) and help

identify recurring issues or trends. We included both

the complete rule set employed as well as all detected

issues in our open data package (not just those tagged

bad-practice).

Construct threats were mitigated by using

SonarQube, the most widely used static analysis tool

in both academia and the industry (Avgeriou and o.,

2021). We took into consideration existing results ar-

guing for the limited fault-prediction power of indi-

vidual SonarQube rules (Lenarduzzi et al., 2020), and

used detected issues as guidelines that will direct fu-

ture teaching efforts.

6 CONCLUSIONS

Static code analysis is known to provide an important

insight into the quality of software projects. In this pa-

per, we propose an approach that uses FCA as a data

mining technique on the output of SonarQube in or-

der to analyze behavior of junior developers. The cur-

rent analysis focuses on issues related to bad-practice

ENASE 2024 - 19th International Conference on Evaluation of Novel Approaches to Software Engineering

758

in Python and Java projects, since this type of issues

directly impacts the maintainability and reliability of

the source code.

The study shows that junior developers have dif-

ﬁculties handling output operations both in Java and

Python. Moreover, the results showed that bad prac-

tice issues in Java are often associated to security is-

sues, while bad practice issues in Python are often

associated to issues related to high maintainability

costs.

As future work, we plan to further explore FCA-

based data mining and static analysis tools in software

projects in order to analyze the error-prone behavior

of junior developers and to ﬁnd ways in which it can

be improved regarding other categories of issues as

well, such as ”brain-overload”.

REFERENCES

Avgeriou, P. and o. (2021). An Overview and Compari-

son of Technical Debt Measurement Tools. IEEE Soft-

ware, PP.

Baldassarre, M. T., Lenarduzzi, V., Romano, S., and Saari-

maki, N. (2020). On the diffuseness of technical debt

items and accuracy of remediation time when using

SonarQube. IST, 128:106377.

Boehm, B. and Basili, V. R. (2001). Software defect reduc-

tion top 10 list. Computer, 34(1):135–137.

Boehm, B. and Papaccio, P. N. (1988). Understanding and

controlling software costs. IEEE Transactions on Soft-

ware Engineering, 14(10):1462–1477.

Cristea, D., S¸otropa, D., Molnar, A.-J., and Motogna, S.

(2021). On the use of FCA models in static analysis

tools to detect common errors in programming. In

Proc. of ICCS, pages 3–18.

Dekel, U. (2002). Applications of Concept Lattices to Code

Inspection and Review.

Duquenne, V. (2007). What can lattices do for teaching

math. and education? volume 331.

Ganter, B. and Wille, R. (1999). Formal Concept Analysis -

Mathematical Foundations. Springer.

Gebser, M., Kaminski, R., Kaufmann, B., and Schaub, T.

(2012). Answer Set Solving in Practice. SLAIML.

Godin, R., Mineau, G., Missaoui, R., St-Germain, M., and

Faraj, N. (1995). Applying Concept Formation Meth-

ods to Software Reuse. IJSEKE, 5:119–142.

Khaund, A., Sharma, A. M., Tiwari, A., Garg, S., and

Kailasam, S. (2023). RD-FCA: A resilient distributed

framework for formal concept analysis. J. Parallel

Distributed Comput., 179:104710.

Kis, L. L., Sacarea, C., and Troanca, D. (2016). FCA Tools

Bundle - A Tool that Enables Dyadic and Triadic Con-

ceptual Navigation. In Proc. of FCA4AI. CEUR.

Lehmann, F. and Wille, R. (1995). A triadic approach to

formal concept analysis. In Proc. of ICCS. Springer.

Lenarduzzi, V., Lomio, F., Huttunen, H., and Taibi, D.

(2020). Are SonarQube Rules Inducing Bugs? In

Proc. of SANER, pages 501–511.

Lenarduzzi, V., Mandi

c, V., Katin, A., and Taibi, D.

(2020a). How long do Junior Developers take to Re-

move Technical Debt Items? In Proc. of ESEM.

Lenarduzzi, V., Saarimaki, N., and Taibi, D. (2020b). Some

SonarQube issues have a signiﬁcant but small effect

on faults and changes. A large-scale empirical study.

Journal of Systems and Software, 170:110750.

Martin, R. C. (2008). Clean Code: A Handbook of Agile

Software Craftsmanship. Prentice Hall PTR, USA.

McConnell, S. (2004). Code Complete, Second Edition. Mi-

crosoft Press, USA.

Molnar, A. and Motogna, S. (2020a). Longitudinal evalua-

tion of open-source software maintainability. In Proc.

of ENASE, pages 120–131. INSTICC, SciTePress.

Molnar, A.-J. (2024). Open Data Package. https://doi.org/

10.6084/m9.ﬁgshare.25270243.v1.

Molnar, A.-J. and Motogna, S. (2020b). Long-Term Evalu-

ation of Technical Debt in Open-Source Software. In

ESEM 2020. ACM.

Murillo, M. I., Lopez, G., Spanola, R., Guzman, J., Rios,

N., and Pacheco, A. (2023). Identiﬁcation and Man-

agement of Technical Debt: A Systematic Mapping

Study Update. JSERD, 11(1):8:1 – 8:20.

Paul Ralph (ed.) (2021). ACM Sigsoft Empirical Standards

for Software Engineering Research, version 0.2.0.

osch, R. and Neum

uller, C. (2020). Does Static Analysis

Help Software Engineering Students? In ICEIT.

Poshyvanyk, D. and Marcus, A. (2007). Combining For-

mal Concept Analysis with Information Retrieval for

Concept Location in Source Code. In Proc. of ICPC.

Potassco (02024). Potassco, the Potsdam Answer Set Solv-

ing Collection.

Priss, U. (2013). Using FCA to analyse how students learn

to program. In Proc. of ICFCA, volume 7880 of

LNCS, pages 216–227. Springer.

Priss, U. (2020). A preliminary semiotic-conceptual analy-

sis of a learning management system. Procedia Com-

puter Science, 176:3702–3709.

Rudolph, S., Sacarea, C., and Troanca, D. (2015a). Mem-

bership Constraints in Formal Concept Analysis. In

Proc. of IJCAI, pages 3186–3192. AAAI Press.

Rudolph, S., Sacarea, C., and Troanca, D. (2015b). Towards

a Navigation Paradigm for Triadic Concepts. In Proc.

of ICFCA, volume 9113 of LNCS. Springer.

Runeson, P. and H

ost, M. (2008). Guidelines for conduct-

ing and reporting case study research in software en-

gineering. ESE, 14:131–164.

Slezak, D. (2012). Rough Sets and FCA - Scalability Chal-

lenges. In Proc. of ICFCA, volume 7278 of LNCS.

SonarSource (2024). Sonar source static code analysis.

Tan, J., Feitosa, D., Avgeriou, P., and Lungu, M. (2021).

Evolution of technical debt remediation in Python: A

case study on the Apache Software Ecosystem. Jour-

nal of Software: Evolution and Process, 33(4).

Walkinshaw, N. and Minku, L. (2018). Are 20% of ﬁles

responsible for 80% of defects? In Proc. of ESEM.

Uncovering Bad Practices in Junior Developer Projects Using Static Analysis and Formal Concept Analysis

759
