Overcoming the Complexity of Quality Assurance for Big Data

Systems: An Examination of Testing Methods

Christian Daase

, Daniel Staegemann

and Klaus Turowski

Institute of Technical and Business Information Systems, Otto-von-Guericke University, Magdeburg, Germany

Keywords: Big Data Analytics, Software Testing, Quality Assurance, Systematic Literature Review.

Abstract: As the complexity and diversity of big data systems reaches a new level, testing the solutions developed is

becoming increasingly difficult. In this study, a systematic literature review is conducted on the role of testing

and related quality assurance techniques in current big data systems in terms of applied strategies and design

guidelines. After briefly introducing the necessary knowledge about big data in general, the methodology is

explained in a detailed and reproducible manner, including the reasoned division of the main question into

two concise research questions. The results show that methods such as individual experiments, standardized

benchmarking, case studies and preparatory surveys are among the preferred approaches, but also have some

drawbacks that need to be considered. In conclusion, testing alone may not guarantee a perfectly operating

system, but can serve to minimize malfunctions to a limited number of special cases by revealing its principal

weaknesses.

1 INTRODUCTION

The technological advancements of our increasingly

digitized world do not only influence our daily lives,

but also pose new challenges to those who contribute

to this rapid development. In contrast to former times,

when data were usually gathered in small quantities

within an experimental context, today’s data

acquisition is characterized by high volumes,

velocities, and varieties (Dremel et al. 2020). Reasons

for this development are new possibilities to analyze

documents, images, geospatial and three-dimensional

data (Lonetti and Marchetti 2018; Saheb and Izadi

2019), both structured and unstructured (Abidin et al.

2016). These can be collected first-hand with modern

technologies such as sensors and camera systems

(Hamilton and Sodeman 2020), by taking advantage

of data people voluntarily share via social media sites

(Abidin et al. 2016), or through their buying behavior

in e-commerce systems (Mithas et al. 2013).

Regarding the characteristics, these masses of data

are generally referred to as big data, or big data

analytics (BDA) if the processing is meant. The

arguments found in the literature for calling BDA a

https://orcid.org/0000-0003-4662-7055

https://orcid.org/0000-0001-9957-1003

https://orcid.org/0000-0002-4388-8914

“game changer” (Wamba et al. 2017), “driving force

for innovation” (Chen et al. 2018), or “next big thing

for innovation” (Côrte-Real et al. 2017) are manifold

and to a certain degree interconnected. Along with the

goal of allowing for predictive analytics (Hamilton

and Sodeman 2020), companies try to use BDA to

uncover hidden patterns or interrelationships to

support their decision making (Abidin et al. 2016) and

the optimization of their organizational activities

(Staegemann et al. 2020). However, the actual value

of BDA systems may depend on the industry in which

they operate. In a study by Müller et al. (2018), the

authors found that although the productivity of a

company can increase by an average of 4 percent, this

only holds true for IT-intensive or highly competitive

industries. BDA may also be employed to answer

research questions in the fields of medicine and

healthcare (Hamilton and Sodeman 2020; Mithas et

al. 2013; Saheb and Izadi 2019), crime data analysis

(Jain and Bhatnagar 2016), human resources

management (Hamilton and Sodeman 2020) and

supply chain or delivery route optimization (Côrte-

Real et al. 2019). However, to benefit from BDA, it

must be considered which requirements the

358

Daase, C., Staegemann, D. and Turowski, K.

Overcoming the Complexity of Quality Assurance for Big Data Systems: An Examination of Testing Methods.

DOI: 10.5220/0012742100003705

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 9th International Conference on Internet of Things, Big Data and Security (IoTBDS 2024), pages 358-369

ISBN: 978-989-758-699-6; ISSN: 2184-4976

respective scenario places upon the system. Operating

environments can vary in terms of data sources and

structures, velocity of data acquisition, and speed of

their obsolescence due to changing external

influences (Staegemann et al. 2020). Software

engineers must therefore consider necessary

adjustments in the development and life cycle of their

solutions. As usual in software engineering, a

developed solution only delivers its maximum value

if it works as intended. Since BDA is no exception to

this statement, its utilization can also lead to severe

failures and malicious effects if the system was not

sufficiently tested (Abidin et al. 2016). While

debugging is generally a huge unknown in terms of

development time, as it adds about 100 to 200 percent

of the amount of productive coding time to the total

development time (Martin 2007), BDA additionally

poses new challenges depending on the specific

requirements, from processing capacities to adapted

visualization techniques, and privacy issues due to

legal restrictions (Jain and Bhatnagar 2016). The

significance of these issues becomes even more

apparent when considering that more than half of the

BDA initiatives developed fail to achieve their

strategic goal (Côrte-Real et al. 2019), either because

of the underestimated complexity and diversity of the

technologies involved (Lonetti and Marchetti 2018;

Ordonez and Bellatreche 2020) or the

unpredictability of the outcomes (Mithas et al. 2013).

A major shortcoming in the testing of BDA solutions

is that realistic, high-volume data sets are difficult to

simulate with the same velocity as they would occur

in a real-world scenario (Lonetti and Marchetti 2018).

To bridge the research gap on how BDA solutions

can be tested to avoid the mentioned pitfalls, this

paper conducts a systematic literature review (SLR),

in which theoretical contributions as well as practical

developments are examined. The focus can be

consolidated into the following central question:

What is the role of testing in current BDA

developments in terms of quality assurance (QA) of

the results and sophistication of test strategies?

Necessary background knowledge on big data and

software testing is given in the subsequent section.

The research questions are formalized in section 3.1,

in which the central question is divided into two

questions. Furthermore, a detailed research

justification is given. The results of the SLR are

presented and discussed in the fourth section with

separate subsections for the quantitative and

qualitative results. Finally, in the fifth section a

conclusion on the role of testing in BDA systems and

a short outlook on possible future research are given.

2 BACKGROUND

In this section, necessary prior knowledge on the two

areas of big data and software testing in general is

outlined.

2.1 Big Data

In general, big data is a rapidly evolving topic whose

definition changes frequently, and so do the

requirements regarding the areas of application.

While a few years ago mainly the plain volume of

data was of importance for practitioners and

academics (Staegemann et al. 2020), today’s

perception of big data is much broader in scope.

Although its characteristics nowadays seem to be

inconsistent, recurring terms can be observed in

current literature, referred to as the five Vs, meaning

volume, velocity, variety, veracity and value (Jain and

Bhatnagar 2016; Wamba et al. 2017). Most of the

found literature adopts a subset of these terms in order

to describe the meaning of big data. While the volume

is undeniably an integral component for the

understanding of big data, it could be found that for

example the veracity is sometimes neglected (Lonetti

and Marchetti 2018). Other publications refrain from

considering the value as an autonomous characteristic

of big data (Abidin et al. 2016; Ordonez and

Bellatreche 2020). With these considerations taken

into account, the publication at hand incorporates the

definition of big data with only the first four Vs (i.e.,

without value) in the following investigation.

In a broader sense, BDA can be considered as a

“socio-technical phenomenon” (Dremel et al. 2020)

not only consisting of the technological aspects, but

also the intentions of the analysis themselves and the

expectations and efforts towards further data-driven

developments. Therefore, it is no surprise that

researchers try to connect other recent topics of

interest with the BDA domain, for example advanced

technologies of artificial intelligence (Saheb and

Izadi 2019), cloud computing (Daase et al. 2023;

Ordonez and Bellatreche 2020) or the internet of

things (Lonetti and Marchetti 2018). The synthesis of

the understanding for the already high complexity of

these domains with the assumption that BDA is only

supported by an organization if its value can be

clearly demonstrated (Mithas et al. 2013) reveals the

necessity of finding ways to ease the testing and with

it the presentation of the value of the BDA solution.

Overcoming the Complexity of Quality Assurance for Big Data Systems: An Examination of Testing Methods

359

2.2 Software Testing

The fundamental role of testing in a software

development cycle and its impact on the quality of the

outcome of a project are well known among software

engineers, but the majority of developers either

refrain from writing an adequate amount of tests or

overestimate their efforts in terms of reliability and

code coverage (Palomba et al. 2016). Furthermore,

apart from human error in testing, also the

technological aspects pose problems regarding the

test quality. There is a trend towards automating the

process of generating and processing test data sets

(Palomba et al. 2016), leading to new paradigms of

how a development cycle might be designed, notably

test-driven development (TDD). The expectation is

that the permanent execution of tests that are usually

written before the actual program code, can

significantly reduce the effort for debugging, since

each newly occurring error must have just been added

(Bissi et al. 2016; Martin 2007). A study conducted

by Bissi et al. (2016) found that this focus on testing

through TDD improved the internal software quality

in about 76 percent and the external software quality

in about 88 percent of the publications examined.

However, about 44 percent reported a decrease in

productivity.

3 RESEARCH JUSTIFICATION

Both topics individually show an increasing interest

in the literature, as a quick screening in the scientific

database Scopus, which claims to be the largest

abstract and citation database (Kitchenham and

Charters 2007), indicates. A search carried out in

February 2024 for the term “big data” in article titles

yielded only 6 publications in 2010 with a steadily

growing number rising to 6602 articles found for

2021 and a slight decrease afterwards. A search for

testing, this time restricted to the subject of computer

science, also resulted in 1819 articles for 2010 and a

peak of 2706 for 2023. Since it could be argued that

this is due to an increasing number of scientific

publications in general, a more reliable indicator of

the growing interest in both topics in combination

could be the percentage of articles on big data

solutions that take testing into account. Therefore,

two other queries in Scopus were used for searching

the abstracts of all publications:

(A): “big data analytic*” OR “big data solution*”

OR “big data system*”

(B): (A) in brackets and in addition AND test*

As further explained in the review protocol in section

3.2, this query also corresponds to the search phrase

of the later review part carried out in Scopus. The

asterisks were added to include the plural forms and

slight variations. Figure 1 and Figure 2 depict the

relationship between articles about BDA and articles

with an additional mention of testing. How and to

what extent testing is ultimately handled by these

articles is the subject of the following main sections.

On the left-hand side, the absolute numbers of

publications on BDA and similar (i.e., query A) and

with the additional requirement of mentioning test

strategies (i.e., query B) are juxtaposed. In 2020, the

events of the COVID-19 pandemic led to the

cancellation or postponement of several conferences

(Agarwal and Sunitha 2020), which is one reason for

the sudden decrease in newly published articles. In

Figure 2, the percentage share of B in A is graphically

displayed, indicating that testing is an emerging issue

within BDA, with a quota of more than 12 percent in

2023 at the time of this study. A search for "big data"

AND test* AND "literature review" in the titles of all

articles yielded no results, suggesting that no

thorough systematic literature review on the role of

testing in BDA has been conducted as of today.

However, due to the rapid developments in

information science, searches in digital libraries are

difficult to replicate after a short period of time

(Kitchenham and Charters 2007).

Figure 1: Publications on BDA with (A) and without (B)

testing considered.

200

400

600

800

1000

1200

1400

1600

2010

2011

2012

2013

2014

2015

2016

2017

2018

2019

2020

2021

2022

2023

A B

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

360

Figure 2: Percentage of B in A.

3.1 Research Questions

The specification of the RQs clarifies the perspective

with which the publications were evaluated and the

context in which the results are synthesized

(Kitchenham and Charters 2007). In addition, this

contributes to concluding the purpose of the literature

review in concise sentences (Okoli 2015). Moreover,

the RQs as a whole determine the composition of the

query that is sent to the database to be searched.

Kitchenham and Charters (2007) suggest that in

essence the query should be composed of three

elements: firstly, the population, which in this case

refers to the application areas of big data, secondly,

the intervention, which is testing among different

variations of this term and thirdly, outcomes. The

search term used in this paper does not contain a

segment for outcomes because the role of testing

itself is to be explored. Possible influences on

productivity, reliability or software quality are not

analyzed in isolation, rather the occurrence of such

terms themselves is investigated. In order to keep the

RQs summarized in Table 1 short and concise, all

questions refer to the examined publications found

with query B from the previous section.

Table 1: Research questions focused during the literature

review.

ID Question

RQ1 Which quality assurance methods are primarily

used before and during the development time

and as how reliable can their respective results

be classified?

RQ2 How should tests be designed according to

guidelines and what issues could arise?

3.2 Review Protocol

In order to provide a sufficient publication basis for

this literature review, Scopus is chosen. In contrast to

a full-text database, Scopus offers only abstracts and

bibliographic data of the articles presented, but in

return combines results from different actual full-text

databases such as IEEE Xplore, ACM Digital Library

and ScienceDirect (Staegemann et al. 2020).

The search query used is identical to the one used

in section 3 for the derivation of the research interest

between the topics of big data systems and testing.

Since this query is the result of multiple test searches

in order to provide an appropriate foundation of

relevant publications, this paragraph serves the

purpose to formalize the search phrase in accordance

with the guidelines of Kitchenham and Charters

(2007). As stated in the previous subsection, the

search query consists of the population (i.e., different

terms related to BDA) and the intervention (i.e.,

testing and related terms). The elements of each

segment are combined with an OR while the segments

themselves are combined with the AND operator.

Table 2 lists the different terms used for this query. In

the literature, system, solution, or analytics in general

have been proved to be frequent synonyms for this

topic. Moreover, with the asterisks phrases like

analytical or systematic are included. Test* on the

other hand includes terms such as testing, tested or

test-driven. The query is searched for in the abstracts

and titles of the articles. The keywords are not

considered because Scopus does not distinguish

between author keywords and indexed keywords in

the fields to be searched. Test searches have shown

that these automatically added indexed keywords do

not always correspond exactly to the topic of the

paper. Furthermore, it is assumed that important

keywords are also present in the abstract.

Table 2: Composition of the search query.

Population Intervention

Big data analytic* Test*

data s

stem*

data solution*

After defining the query, the search must be refined

by applying certain inclusion and exclusion criteria as

an integral part of any systematic review process

(Kitchenham and Charters 2007). Furthermore, these

criteria are necessary to increase the density of

relevant articles in the final publication base and to

reduce the large number of articles to a practically

manageable collection (Okoli 2015). Since the

application of some criteria requires different levels

0,00%

2,00%

4,00%

6,00%

8,00%

10,00%

12,00%

14,00%

2010

2011

2012

2013

2014

2015

2016

2017

2018

2019

2020

2021

2022

2023

Overcoming the Complexity of Quality Assurance for Big Data Systems: An Examination of Testing Methods

361

of insight, Table 3 lists the SLR stages used in this

paper.

Table 3: SLR stages and related RQs.

Stage ID Description

0 Before the SLR

1 Readin

title an

abstract

2 Reading introduction an

conclusion

3 Reading the full text in-depth

For the definition of the inclusion and exclusion

criteria, the recommendations of Okoli (2015) are

considered. Table 4 shows the criteria and the

corresponding SLR stages in which they are applied.

For example, the publication language, year, and

source type are already considered using the built-in

mechanics of Scopus. Contrary to section 3, where a

marginal number of articles before 2012 could be

found in Scopus for BDA related terms alone, the

addition of the intervention segment caused that no

articles could be found for this period. The lack of

publications for the time before the early 2010s is

consistent with the findings of other researchers that

the general term big data did not become a buzzword

before the year 2012 (Che et al. 2013; Ghandour

2015; Hong et al. 2020). The selection process in

section 4 starts with the number of publications found

after adapting the criteria indicated with (0), which

can be automatically applied through the built-in

mechanisms the database.

Table 4: Inclusion/exclusion criteria and corresponding

SLR stages.

Inclusion Exclusion

(0) Written in English (1) Duplicates/proceedings

introduction

(0) Published between

2012 an

2023

(1) Only review/no own

contribution

(0) Source type is

ournal or conference

roceedin

(1) Testing in non-BDA

context/of no concrete solution

(0) Finalized

ublication

(2) No conclusion on influence

of testin

(1) Big data related

main sub

ect

(3) No explanation of testing

strate

ies

(2) Thoughtful

considerations for

testing

(3) No careful test execution

(projects only)

4 RESULTS AND DISCUSSION

The search carried out in Scopus led to the search

process illustrated in Figure 3. With an initial number

of 870 articles, the publication base decreased

significantly, as different topics used the term test in

other contexts than a technical big data solution. In

the health sector in particular, research focused on

patient and drug testing drove up the number of

articles that apparently use and evaluate BDA.

Furthermore, about 10 percent of the articles found

were introductions to proceedings or workshops,

duplicates or had abstracts indicating that the article

does not contain a sufficient contribution to the topic

covered in this study.

Figure 3: Conducted search workflow.

In the following, the research questions established in

section 3.1 are answered as far as the material

fulfilling the corresponding review stages allows.

4.1 Quantitative Results

The found articles can be divided into seven

categories. Benchmarking refers to techniques that

compare a solution’s performance against some

predefined metric. Experiments are individual testing

procedures in which a BDA solution’s outcome is

compared against an expected result. Case studies are

comprehensive sets of activities in a realistic

environment. Surveys mean that a BDA solution is

instantiated and afterwards stakeholders are

questioned about their experience regarding the

results. Discussions, in turn, are partially opinion

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

362

papers in which the topic of testing in BDA is

considered from different angles. Guidelines mean

sets of recommendations from experienced BDA

developers based on profound prior knowledge.

Finally, papers on challenges comprise lists of

potential issues that need to be addressed when

developing, deploying, and testing BDA systems.

Table 5 summarizes the findings.

Table 5: Categorization of the found publications.

Categor

Publications

Benchmarking (Chen et al. 2018; Demirbaga et al.

2022; Ghazal et al. 2013; Hart et

al. 2023; Skracic and Bodrusic

2017; Xia et al. 2019; X. Zhang et

al. 2023; Zhen

et al. 2017

)

Experiment (Covioli et al. 2023; Draughon et

al. 2023; Fahrudin et al. 2022;

Gulzar et al. 2018; Peng et al.

2020; Peng Zhang et al. 2018)

Case study (Barba-González et al. 2019;

Caputo et al. 2023; Eugeni et al.

2022; Prom-on et al. 2014; Sariyer

et al. 2022)

Survey (Côrte-Real et al. 2017; Shahbaz et

al. 2019; C. Zhang et al. 2019)

Discussion

(

Pen

chen

Zhan

et al. 2017

)

Guidelines (Shapira and Chen 2016;

Staegemann et al. 2019; Tao and

Gao 2016

)

Challenges (Alexandrov et al. 2013; Gulzar et

al. 2019; Janković et al. 2018;

Rabl et al. 2015)

4.2 Qualitative Results

The RQs on the primarily applied quality assurance

methods and on how tests should be designed derive

their answers from different subsets of the

publications listed in Table 5. In the following, the

methods of software testing (e.g., experiments,

benchmarking, and case studies) and the more

subjective conduct of surveys are explained based on

the findings of this literature review. After that, the

guidelines and extracted challenges are consulted to

give an answer to the question how to organize test

scenarios, and which issues could arise.

4.2.1 Surveys

The quality factors of big data applications are well

known and partly similar to traditional software

systems, including performance, reliability,

correctness, security and the more application-

specific scalability (Pengcheng Zhang et al. 2017).

However, chronologically QA does not begin with

the testing of a final system, but with pre-analyses on

the issues of which purpose the developed solution

should fulfill and how the acceptance by the intended

user can be ensured. Although surveys in terms of

asking participants for their opinion might lack

objectivity (Bertrand and Mullainathan 2001),

especially when determining the correctness of

functional aspects, the subjective acceptance factors

can still be investigated. Precautionary as well as

during runtime, surveys can help in accumulating

knowledge on user experience and satisfaction and

are therefore considered as an adequate method of

QA in the context of this paper. Shahbaz et al. (2019),

for example, found that security and trust on

information are important concerns of users by

surveying 400 BDA end users in Pakistani hospitals,

resulting in 224 valid responses. The authors

concluded that the absence of sufficient trust leads to

a higher resistance against a proposed BDA system

which in turn negatively affects the overall

usefulness. The survey of C. Zhang et al. (2019), also

conducted in healthcare, observed similar issues that

have to be considered before an actual

implementation. Moreover, this research team

suggests that the usefulness of a BDA system can

depend on the knowledge of a user in the application

field, meaning that knowing what and how data is

stored and utilized within electronic health records

(EHR) can have a significant influence. While the

issue of storing data is linked to the software

architecture and can therefore be viewed in

connection with typical technical quality factors of

BDA systems (Tao and Gao 2016), the knowledge

about the EHRs is solely dependent on the training of

the user. Although C. Zhang et al. (2019) pointed out

that the lack of domain specific knowledge might

have serious downturns on a systems performance,

Shahbaz et al. (2020) found that the usefulness (i.e.,

the scope of the system) is more important than the

perceived ease of use. Therefore, the potential for

improvement of a BDA system can be higher in

ensuring a better training for the employees than in

the attempt of optimizing the user experience with the

possible risk of removing parts of the functionality.

Another dimension of suitability can be referred to as

technology-task fit (TTF) (Shahbaz et al. 2019) which

can be used as a term describing to what extend the

features of the system match the intended task of a

user. Organizations that heavily rely on economic

success need to consider the aforementioned issues as

well, as the study by Côrte-Real et al. (2017) shows.

By surveying 500 European firms with 175 valid

responses, the researchers found that organizational

agility in particular is vital in competitive markets.

Overcoming the Complexity of Quality Assurance for Big Data Systems: An Examination of Testing Methods

363

Beyond that, external knowledge was found to be

more important than internal knowledge, which is

why the call for an increase of the TTF has to be

regarded in terms of adjustments on data sources and

the corresponding analysis processes to make a BDA

system more advantageous in a business context.

Apart from these findings, the first part of an answer

to RQ1 has to take the reliability of surveys into

account. Although the complexity and the effort can

be significantly lower than with other QA methods,

results of surveys tend to be viewed as less reliable

because the data mainly consists of the participants

subjective opinions (Bertrand and Mullainathan

2001). Nonetheless, the easily obtained data can serve

as a sufficient basis for important insights before an

actual development or during runtime to identify

necessary adjustments.

4.2.2 Experiments, Benchmarks, Case

Studies

One technique for QA of big data applications is

testing during development time (Pengcheng Zhang

et al. 2017). The order of the remarks is based on the

complexity and scope of the proposed methods,

starting with individual experiments, through

benchmarks to case studies. However, these methods

might overlap regarding goals and work steps.

Examining the literature reveals that studies

conducting experiments and benchmarks often

primarily concentrate on the performance of a system

(e.g., transactions per minute, processing time)

(Caputo et al. 2023; Draughon et al. 2023; Ghazal et

al. 2013; Peng et al. 2020; Skracic and Bodrusic 2017;

Xia et al. 2019; Peng Zhang et al. 2018). Zheng et al.

(2017) criticize this focus, noting that also the

reliability of a system has to be considered more

intensive. Along with concerns about security, Peng

et al. (2020) also recognize risks to overall

performance if insufficient attention is paid to these

two issues. In order to evaluate whether a tradeoff

between security and performance is inevitable, the

research team around Peng in this study conducted an

experiment comparing two algorithms of access

control in a BDA environment. The authors found

that their newly developed algorithm enables a

reliable security while affecting the performance less

than the older solution. It can be concluded that these

two dimensions of quality are not exclusive and can

have a negligible tradeoff if carefully considered.

Another issue for the reliability of tests in BDA can

be associated with abstractions of data and

workloads. A major difference between big data

systems and traditional software resides in the

considerably higher hardware requirements (Shapira

and Chen 2016; Staegemann et al. 2019). Data

scientists usually test their solutions with small

samples of data on local workstations and hope that

they will work equally well later when implemented

in an expensive production cloud (Gulzar et al. 2018).

While a cloud based testing environment might be

thinkable depending on the resources of the

respective organization, modern BDA systems also

strive to take advantage of other current architectural

ideas like edge computing and similar technologies

(Xia et al. 2019). Those aspirations can even exceed

the possibilities of a well-equipped company as such

networks of devices can be of highly variable extend.

Thus, certain risks when transferring a sufficiently

locally tested solution into a real-world scenario can

remain. Further studies detect dangers of abstraction

due to a shortage of realistic test datasets and a

resulting insufficient coverage of system behavior

regarding the intended use case (Alexandrov et al.

2013; Rabl et al. 2015). In an attempt to address this

issue, Gulzar et al. (2019) developed BigTest, a

systematic input generation tool, and BigSift, an

automated debugging toolkit (Gulzar et al. 2018),

with a note in 2018 that the evolution of debugging in

BDA is still in its early days. In the same year, Peng

Zhang et al. (2018) followed a different approach in

the application area of high-frequency trading by

suggesting that transaction speed has already reached

peak because of the current hardware capabilities.

Therefore, the authors believe that more complex data

analysis models are a key concept of further

advancing traders performance. However, the study is

limited to an approach to improve the performance of

such complex models by adopting a parallel

processing architecture which was then evaluated

against competing approaches.

The incorporation of benchmarks into the testing

strategy can constitute an advanced addition to single

experiments with synthetic datasets. Alongside the

usual functional performance measurements,

benchmarks can enable more precise predictions

regarding the price performance of a big data system

as well, responding to the rising pressure to evaluate

this quality factor (Ghazal et al. 2013). Beyond that,

the scope of benchmarks can also include the

verification of the correctness and the opportunity to

compare different BDA systems (Chen et al. 2018).

However, benchmarks must be standardized to gain

meaningful comparisons of multiple solutions. In the

late 1980s, this requirement led to the formation of

benchmark consortia such as the Transaction

Processing Performance Council (TPC) and the

Standard Performance Corporation (SPEC) (Ghazal

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

364

et al. 2013). While at that time the need for

benchmarks for data warehouses was a crucial aspect,

current software trends draw attention to benchmarks

in the area of big data. Ghazal et al. (2013) responded

to the call for more standardization by developing

BigBench which was accepted by the TPC as a

benchmark since its finalization. Apart from the

notable interest in benchmarks in the literature,

indications can be found that this technique may

require a considerably higher effort than single

experiments. Chen et al. (2018) present six phases of

testing BDA systems by benchmarking, including a

requirement analysis, preparing the test environment,

preparing test datasets and workloads, loading the

data, executing the tests and analyzing the results.

While these phases may overlap with those of an

experiment, they are not optional in the case of

benchmarks and may exceed the requirements of

small experiments, since they cover all system

properties at once. The issue of generating realistic

test data intensifies as the scenario has to be designed

in a way that the special characteristics of big data

(i.e., the Vs) are considered (Chen et al. 2018; Covioli

et al. 2023; Pengcheng Zhang et al. 2017). Xia et al.

(2019), for example, complement their benchmarking

efforts with an evaluation in a real testbed. Thus, the

problem of insufficient realistic test datasets can

partly be tackled. Despite the popularity of

experiments and benchmarks both can show a

decisive pitfall when not adequately standardized.

Organizations may tend to use self-defined and thus

biased scenarios to make performance claims, a

practice that Ghazal et al. (2013) refer to as

benchmarketing. Unintentionally, such unrealistic

claims can also occur when the benchmark is

designed without sufficient consideration of real-life

requirements (Shapira and Chen 2016). The

reliability of both explained methods is therefore

highly dependent on their degree of standardization.

The most time-consuming approach to testing a

BDA system found in the literature are case studies in

the real world, which is why only two publications of

satisfactory depth were identified. Prom-on et al.

(2014) conducted two different case studies, one to

categorize social media posts into positive and

negative opinions, and one for the prediction of traffic

problems in Bangkok. Since the reliability heavily

relies on the quality of the applied testing

methodology, the time required already increases

during the planning phase. Furthermore, in this case

it is not possible to automate the test routine because

only a properly functioning system could determine

the correctness of the categorization, which in turn

would be the system under test itself. The other

publication utilizing case studies, written by Barba-

González et al. (2019), introduces a framework to

enhance analytical processes with semantic

annotations. Their case studies were also conducted

in the traffic sector and on a classification task, but in

a comparative context. The reliability of the results is

therefore less of a concern since the relative

comparison is more comprehensible in terms of

evaluating one solution over another than verifying

the absolute results of a single system. The findings

of the authors mirror the ones of Shahbaz et al. (2019)

who found that more precise knowledge of the

semantics of a system is beneficial for increasing the

TTF and therefore the value of the software solution.

The previously explained findings from the

literature are summarized in Table 6 listing the

advantages and disadvantages of the QA techniques

of conducting surveys, experiments, benchmarks and

case studies. The table does not claim completeness

as many more aspects of QA may have to be

considered in any respective scenario.

Table 6: QA techniques and reliability in BDA.

Metho

Advanta

es Disadvanta

Survey

• Easy to

perform

• Provides prior

knowledge for

acceptance and

use

experience

• Questionable

reliability and

objectivity of

data

Experiment

• Fast

implementation

on local

workstations

• Uncertainty

when

transferred to

real world

scenario due to

lack of realistic

test datasets

Benchmark

• Comparison of

different

solutions

• Standardized

suitable for

against

competitors

• Possible

laborious

adjustments

• Risk of

benchmarketing

Case study

• Realistic

conditions

• Time-

consuming

evaluation

4.2.3 Test Design and Possible Issues

As mentioned, Pengcheng Zhang et al. (2017)

identified testing as an integral part of QA, but their

study does not contain sufficient guidelines on how to

design appropriate test scenarios. The most detailed

and matured publication found on this subject is the

Com

lexit

/ Reliabilit

Overcoming the Complexity of Quality Assurance for Big Data Systems: An Examination of Testing Methods

365

industry experience paper by Shapira and Chen

(2016). Besides conditions that have to be taken into

account while testing, especially in terms of

benchmarking, the paper also examines attributes of

well-performed tests and reasons for their thoughtful

execution. Among others, the authors demand the

regard for realistic hardware and workload choices as

well as the consideration of the systems properties

such as the size of data and the number of nodes and

tasks. A certain knowledge of the application domain

is therefore a beneficial requirement for the testers or

users, as other researchers have also noted (Shahbaz

et al. 2019; C. Zhang et al. 2019). Especially

emphasized by Shapira and Chen (2016) are the

components of a proper documentation of the testing

process. All necessary information to guarantee the

reproducibility of the tests must be carefully

recorded, including the configuration, hardware and

workloads. The authors also make clear that the

results must be unambiguous and that in tests that

investigate the influence of a single parameter, it is

essential to ensure that exclusively this parameter has

been changed. Furthermore, according to the paper,

outcomes are only reasonable if a model of the

expected system behavior exists. Due to the

explorative nature of BDA applications, this could be

a difficulty since the desired output is not always

known in a defined form (Staegemann et al. 2019). A

possible solution for this test oracle problem can be

metamorphic testing (MT). Tao and Gao (2016)

explain, that a set of expected properties, known as

metamorphic relation, specifies how the output would

change following a particular change of the input.

Another approach mentioned by the authors,

assuming a sufficient number of known combinations

of valid inputs and outputs, can be a trained classifier.

Thus, the testing could be automated and newly

produced outputs can be checked for their

correctness. In all cases, the reusability and

reproducibility of the tests should be considered, as

this is generally viewed as an advantage (Shapira and

Chen 2016; Staegemann et al. 2019). A possible

dilemma for this demand are privacy issues if

problematic system behavior occurs outside of

internal tests and the users inputs, consisting of

private data, would be mandatory for reproducibility

(Alexandrov et al. 2013; Rabl et al. 2015; X. Zhang

et al. 2023). Based on this, a further attribute of

comprehensive testing is the coverage of every

involved system component and status. Not only a

shortage of realistic test data can lead to

complications, but also the unpredictable behavior of

external users. Although a randomly based input

strategy could give a chance of covering neglected

scenarios, it is unlikely to reveal every weak point,

which is why a systematic testing strategy is generally

more sensible (Gulzar et al. 2019). Nonetheless, the

challenge of varying data origins and structures

remains as it is a permanent requirement for BDA

applications to integrate new sources (Janković et al.

2018). Hence, the security of the system might be

endangered if those new sources are not under direct

control of the user (Staegemann et al. 2019).

Summarizing the findings to answer RQ2, the

design of a BDA test strategy might orientate on the

following key concept. First, realistic datasets should

be used whenever possible, otherwise a data model

should first be created to generate synthetic datasets

and workloads. Second, any procedure and

configuration should be strictly documented to enable

the reusability and reproducibility of the performed

tests. Third, appropriate strategies which cover

ideally every scenario and special case should be

evaluated beforehand, especially if exact outcomes

are unknown. Fourth, the security of the BDA system

should always be considered for the case of

integrating new data sources, structures and other

risky adjustments.

5 CONCLUSION

This work presents a comprehensive literature review

in the abstract and citation database Scopus to

examine the role and adopted strategies of testing in

current BDA approaches in the context of QA.

Although Scopus provides the essential information

to get hands on publications from different full-test

databases like IEEE Xplore, ACM Digital Library

and ScienceDirect (Staegemann et al. 2020) it does

not cover the full range of every relevant database

such as, for example, Springer Link. One

improvement for this work might be the integration

of the full-text databases themselves as

considerations of the main topic could be hidden

inside the text body and neglected in the title or

abstract of an article. Moreover, a few terms that were

found to occur frequently (e.g. big data application,

validation, evaluation) could be a sensible addition

for the search string.

Nonetheless, the main approaches on how to

ensure the quality of a BDA project could be

identified and thoroughly investigated. The most

popular strategies here are standardized benchmarks,

as provided by the TPC, because of their

comparability, surveys in advance and at runtime

because of their simplicity and case studies because

of their elaborate results. However, every approach

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

366

suffers possible downsides such as the lack of realism

when benchmarking with synthetic data, the

uncertainty of reliability of participants answers in

surveys, and the necessary effort for real-world case

studies. Aside discussions on those techniques, this

work covers quality factors on how they should be

applied according to various scholars. In this regard,

the reproducibility and realism of test data turned out

to be decisive attributes of well-conducted testing

routines. Concluding it can be stated that despite all

efforts and especially because of the existing lack of

realistic test data, BDA applications will remain

complex systems with a wide range of issues and long

patch histories at runtime (Huang et al. 2015). In

response to the initial question about the role of

testing in current BDA developments, the systematic

literature research carried out here supports the

answer that testing is currently not meant to provide

a perfectly running system, but rather to limit

malfunctions to special cases that cannot be detected

even by extensive testing or preliminary analysis.

REFERENCES

Abidin, A., Lal, D., Garg, N., & Deep, V. (2016).

Comparative analysis on techniques for big data testing.

In 2016 International Conference on Information

Technology (InCITe) - The Next Generation IT Summit

on the Theme - Internet of Things: Connect your Worlds.

IEEE.

Agarwal, V., & Sunitha, B. (2020). COVID – 19: Current

pandemic and its societal impact. In International

Journal of Advanced Science and Technology, 29, 432–

439.

Alexandrov, A., Brücke, C., & Markl, V. (2013). Issues in

big data testing and benchmarking. In Proceedings of

the Sixth International Workshop on Testing Database

Systems - DBTest '13. ACM Press.

Barba-González, C., García-Nieto, J., Roldán-García, M. d.

M., Navas-Delgado, I., Nebro, A. J., & Aldana-Montes,

J. F. (2019). BIGOWL: Knowledge centered Big Data

analytics. In Expert Systems with Applications, 115,

543–556.

Bertrand, M., & Mullainathan, S. (2001). Do People Mean

What They Say? Implications for Subjective Survey

Data. In American Economic Review, 91(2), 67–72.

Bissi, W., Serra Seca Neto, A. G., & Emer, M. C. F. P.

(2016). The effects of test driven development on

internal quality, external quality and productivity: A

systematic review. In Information and Software

Technology, 74, 45–54.

Caputo, F., Keller, B., Möhring, M., Carrubbo, L., &

Schmidt, R. (2023). Advancing beyond technicism

when managing big data in companies’ decision-

making. In Journal of Knowledge Management, 27(10),

2797–2809.

Che, D., Safran, M., & Peng, Z. (2013). From Big Data to

Big Data Mining: Challenges, Issues, and Opportunities.

In Lecture Notes in Computer Science. Database

Systems for Advanced Applications. Springer Berlin

Heidelberg.

Chen, M., Chen, W., & Cai, L. (2018). Testing of Big Data

Analytics Systems by Benchmark. In 2018 IEEE

International Conference on Software Testing,

Verification and Validation Workshops (ICSTW). IEEE.

Côrte-Real, N., Oliveira, T., & Ruivo, P. (2017). Assessing

business value of Big Data Analytics in European firms.

In Journal of Business Research, 70, 379–390.

Côrte-Real, N., Ruivo, P., Oliveira, T., & Popovič, A.

(2019). Unlocking the drivers of big data analytics

value in firms. In Journal of Business Research, 97,

160–173.

Covioli, T., Dolci, T., Azzalini, F., Piantella, D., Barbierato,

E., & Gribaudo, M. (2023). Workflow Characterization

of a Big Data System Model for Healthcare Through

Multiformalism. In Lecture Notes in Computer Science.

Computer Performance Engineering and Stochastic

Modelling. Springer Nature Switzerland.

Daase, C., Volk, M., Staegemann, D., & Turowski, K.

(2023). The Future of Commerce: Linking Modern

Retailing Characteristics with Cloud Computing

Capabilities. In Proceedings of the 25th International

Conference on Enterprise Information Systems.

SCITEPRESS - Science and Technology Publications.

Demirbaga, U., Wen, Z., Noor, A., Mitra, K., Alwasel, K.,

Garg, S., Zomaya, A. Y., & Ranjan, R. (2022).

AutoDiagn: An Automated Real-Time Diagnosis

Framework for Big Data Systems. In IEEE

Transactions on Computers, 71(5), 1035–1048.

Draughon, G., Lynch, J., & Salvino, L. (2023). Integrated

Vision-Body Sensing System for Tracking People in

Intelligent Environments. In Lecture Notes in Civil

Engineering. European Workshop on Structural Health

Monitoring. Springer International Publishing.

Dremel, C., Herterich, M. M., Wulf, J., & vom Brocke, J.

(2020). Actualizing big data analytics affordances: A

revelatory case study. In Information & Management,

57(1), 103121.

Eugeni, M., Quercia, T., Bernabei, M., Boschetto, A.,

Costantino, F., Lampani, L., Spaccamela, A. M.,

Lombardo, A., Mecella, M., Querzoni, L., Usinger, R.,

Aliprandi, M., Stancu, A., Ivagnes, M. M., Morabito,

G., Simoni, A., Brandão, A., & Gaudenzi, P. (2022). An

industry 4.0 approach to large scale production of

satellite constellations. The case study of composite

sandwich panel manufacturing. In Acta Astronautica,

192, 276–290.

Fahrudin, T. M., Riyantoko, P. A., & Hindrayani, K. M.

(2022). Implementation of Big Data Analytics for

Machine Learning Model Using Hadoop and Spark

Environment on Resizing Iris Dataset. In 2022

International Conference on Informatics, Multimedia,

Cyber and Information System (ICIMCIS). IEEE.

Ghandour, A. (2015). Big Data Driven E-Commerce

Architecture. In International Journal of Economics,

Commerce & Management (IJECM), 3.

Overcoming the Complexity of Quality Assurance for Big Data Systems: An Examination of Testing Methods

367

Ghazal, A., Rabl, T., Hu, M., Raab, F., Poess, M., Crolotte,

A., & Jacobsen, H.‑A. (2013). BigBench. In

Proceedings of the 2013 international conference on

Management of data - SIGMOD '13. ACM Press.

Gulzar, M. A., Mardani, S., Musuvathi, M., & Kim, M.

(2019). White-box testing of big data analytics with

complex user-defined functions. In Proceedings of the

2019 27th ACM Joint Meeting on European Software

Engineering Conference and Symposium on the

Foundations of Software Engineering - ESEC/FSE

2019. ACM Press.

Gulzar, M. A., Wang, S., & Kim, M. (2018). BigSift:

automated debugging of big data analytics in data-

intensive scalable computing. In Proceedings of the

2018 26th ACM Joint Meeting on European Software

Engineering Conference and Symposium on the

Foundations of Software Engineering - ESEC/FSE

2018. ACM Press.

Hamilton, R. H., & Sodeman, W. A. (2020). The questions

we ask: Opportunities and challenges for using big data

analytics to strategically manage human capital

resources. In Business Horizons, 63(1), 85–95.

Hart, M., Dave, R., & Richardson, E. (2023). Next-

Generation Intrusion Detection and Prevention System

Performance in Distributed Big Data Network Security

Architectures. In International Journal of Advanced

Computer Science and Applications, 14(9).

Hong, Y., Li, Z [Zheng], & Wang, J. (2020). Business

Value of Telecom Operators’ Big Data. In Journal of

Physics: Conference Series, 1437.

Huang, J., Zhang, X [Xuechen], & Schwan, K. (2015).

Understanding issue correlations. In Proceedings of the

Sixth ACM Symposium on Cloud Computing - SoCC '15.

ACM Press.

Jain, A., & Bhatnagar, V. (2016). Crime Data Analysis

Using Pig with Hadoop. In Procedia Computer Science,

78, 571–578.

Janković, S., Mladenović, S., Mladenović, D., Vesković, S.,

& Glavić, D. (2018). Schema on read modeling

approach as a basis of big data analytics integration in

EIS. In Enterprise Information Systems, 12(8-9), 1180–

1201.

Kitchenham, B., & Charters, S. (2007). Guidelines for

performing Systematic Literature Reviews in Software

Engineering: Technical report, Version 2.3 EBSE

Technical Report.

Lonetti, F., & Marchetti, E. (2018). Emerging Software

Testing Technologies. In Advances in Computers.

Elsevier.

Martin, R. C. (2007). Professionalism and Test-Driven

Development. In IEEE Software, 24(3), 32–36.

Mithas, S., Lee, M. R., Earley, S., Murugesan, S., &

Djavanshir, R. (2013). Leveraging Big Data and

Business Analytics [Guest editors' introduction]. In IT

Professional, 15(6), 18–20.

Müller, O., Fay, M., & vom Brocke, J. (2018). The Effect

of Big Data and Analytics on Firm Performance: An

Econometric Analysis Considering Industry

Characteristics. In Journal of Management Information

Systems, 35(2), 488–509.

Okoli, C. (2015). A Guide to Conducting a Standalone

Systematic Literature Review. In Communications of

the Association for Information Systems, 37.

Ordonez, C., & Bellatreche, L. (2020). Guest Editorial—

DaWaK 2018 Special Issue—Trends in Big Data

Analytics. In Data & Knowledge Engineering, 126.

Palomba, F., Di Nucci, D., Panichella, A., Oliveto, R., &

Lucia, A. de (2016). On the diffusion of test smells in

automatically generated test code. In Proceedings of the

9th International Workshop on Search-Based Software

Testing - SBST '16. ACM Press.

Peng, J., Zhou, H., Meng, Q., & Yang, J. (2020). Big data

security access control algorithm based on memory

index acceleration in WSNs. In EURASIP Journal on

Wireless Communications and Networking, 2020(1).

Prom-on, S., Ranong, S. N., Jenviriyakul, P., Wongkaew,

T., Saetiew, N., & Achalakul, T. (2014). DOM: A big

data analytics framework for mining Thai public

opinions. In 2014 International Conference on

Computer, Control, Informatics and Its Applications

(IC3INA). IEEE.

Rabl, T., Danisch, M., Frank, M., Schindler, S., & Jacobsen,

H.‑A. (2015). Just can't get enough. In Proceedings of

the 2015 ACM SIGMOD International Conference on

Management of Data - SIGMOD '15. ACM Press.

Saheb, T., & Izadi, L. (2019). Paradigm of IoT big data

analytics in the healthcare industry: A review of

scientific literature and mapping of research trends. In

Telematics and Informatics, 41, 70–85.

Sariyer, G., Ataman, M. G., Mangla, S. K., Kazancoglu, Y.,

& Dora, M. (2022). Big data analytics and the effects of

government restrictions and prohibitions in the

COVID-19 pandemic on emergency department

sustainable operations. In Annals of Operations

Research, 1–31.

Shahbaz, M., Gao, C., Zhai, L., Shahzad, F., & Arshad, M.

R. (2020). Moderating Effects of Gender and

Resistance to Change on the Adoption of Big Data

Analytics in Healthcare. In Complexity, 2020, 1–13.

Shahbaz, M., Gao, C., Zhai, L., Shahzad, F., & Hu, Y

[Yanling] (2019). Investigating the adoption of big data

analytics in healthcare: the moderating role of

resistance to change. In Journal of Big Data, 6(1).

Shapira, G., & Chen, Y. (2016). Common Pitfalls of

Benchmarking Big Data Systems. In IEEE

Transactions on Services Computing, 9(1), 152–160.

Skracic, K., & Bodrusic, I. (2017). A Big Data solution for

troubleshooting mobile network performance problems.

2017 40th International Convention on Information

and Communication Technology, Electronics and

Microelectronics (MIPRO). IEEE.

Staegemann, D., Volk, M., Daase, C., & Turowski, K.

(2020). Discussing Relations Between Dynamic

Business Environments and Big Data Analytics. In

Complex Systems Informatics and Modeling

Quarterly(23), 58–82.

Staegemann, D., Volk, M., Nahhas, A., Abdallah, M., &

Turowski, K. (2019). Exploring the Specificities and

Challenges of Testing Big Data Systems. In 2019 15th

IoTBDS 2024 - 9th International Conference on Internet of Things, Big Data and Security

368

International Conference on Signal-Image Technology

& Internet-Based Systems (SITIS). IEEE.

Tao, C., & Gao, J. (2016). Quality Assurance for Big Data

Application – Issuses, Challenges, and Needs. In

International Conferences on Software Engineering

and Knowledge Engineering. In Proceedings of the

28th International Conference on Software

Engineering and Knowledge Engineering. KSI

Research Inc. and Knowledge Systems Institute

Graduate School. https://doi.org/10.18293/SEKE2016-

166

Wamba, S. F., Gunasekaran, A., Akter, S., Ren, S. J., Dubey,

R., & Childe, S. J. (2017). Big data analytics and firm

performance: Effects of dynamic capabilities. In

Journal of Business Research, 70, 356–365.

Xia, Q., Bai, L., Liang, W., Xu, Z., Yao, L., & Wang, L.

(2019). QoS-Aware Proactive Data Replication for Big

Data Analytics in Edge Clouds. In Proceedings of the

48th International Conference on Parallel Processing:

Workshops. ACM.

Zhang, C., Ma, R., Sun, S., Li, Y., Wang, Y., & Yan, Z.

(2019). Optimizing the Electronic Health Records

Through Big Data Analytics: A Knowledge-Based

View. In IEEE Access, 7, 136223–136231.

Zhang, P [Peng], Gao, Y., & Shi, X. (2018). QuantCloud:

A Software with Automated Parallel Python for

Quantitative Finance Applications. In 2018 IEEE

International Conference on Software Quality,

Reliability and Security (QRS). IEEE.

Zhang, P [Pengcheng], Zhou, X., Li, W., & Gao, J. (2017).

A Survey on Quality Assurance Techniques for Big

Data Applications. In 2017 IEEE Third International

Conference on Big Data Computing Service and

Applications (BigDataService). IEEE.

Zhang, X [Xiang], Lu, B., Zhang, L [Lyuzheng], Pan, Z.,

Liao, M., Shen, H., Zhang, L [Li], Liu, L., Li, Z

[Zuxiang], Hu, Y [YiPao], & Gao, Z. (2023). An

enhanced grey wolf optimizer boosted machine

learning prediction model for patient-flow prediction.

In Computers in Biology and Medicine, 163, 107166.

Zheng, Y., Xu, L., Wang, W., Zhou, W., & Ding, Y. (2017).

A Reliability Benchmark for Big Data Systems on

JointCloud. In 2017 IEEE 37th International

Conference on Distributed Computing Systems

Workshops (ICDCSW). IEEE.

Overcoming the Complexity of Quality Assurance for Big Data Systems: An Examination of Testing Methods

369
