A Comparative Study on the Impact of Categorical Encoding on Black

Box Model Interpretability

Hajar Hakkoum

and Ali Idri

1,2

SPM, ENSIAS, Mohammed V University, Rabat, Morocco

Faculty of Medical Sciences, Mohammed VI Polytechnic University, Ben Guerir, Morocco

Keywords:

Interpretability, Black Box, Machine Learning, Data Mining, Categorical Encoding, XAI.

Abstract:

This study explores the challenge of opaque machine learning models in medicine, focusing on Support Vector

Machines (SVMs) and comparing their performance and interpretability with Multilayer Perceptrons (MLPs).

Using two medical datasets (breast cancer and lymphography) and three encoding methods (ordinal, one-

hot, and dummy), we assessed model accuracy and interpretability through a decision tree surrogate and

SHAP Kernel explainer. Our ﬁndings highlight a preference for ordinal encoding for accuracy, while one-

hot encoding excels in interpretability. Surprisingly, dummy encoding effectively balanced the accuracy-

interpretability trade-off.

1 INTRODUCTION

Machine learning (ML) models, particularly black

box models like Support Vector Machines (SVMs),

are increasingly utilized in medical ﬁelds to pro-

vide critical insights and serve as adjuncts to human

decision-making (London, 2019) (Idri et al., 2018)

(Benhar et al., 2020) (Hosni et al., 2019) (Zerouaoui

et al., 2020). Despite their superior performance

over more transparent models (Heinrichs and Eick-

hoff, 2020), such as Decision Trees (DTs), their adop-

tion is hindered by a lack of interpretability, a crucial

factor in healthcare where understanding model ra-

tionale is as important as the predictions themselves.

This has, therefore, made research into interpretabil-

ity appealing to the research community (Hakkoum

et al., 2022).

Interpretability techniques are distinguished by

two criteria (Molnar, 2022): 1) whether they explain

the behaviour of the black box model globally or lo-

cally (single instance), and 2) whether they are ag-

nostic or speciﬁc to one type of black box model. Our

systematic literature review (SLR) (Hakkoum et al.,

2022) on 179 papers investigating interpretability in

medicine discovered that 95 (53%) and 72 (40%) pa-

pers focused solely on global or local interpretability,

respectively, while 10 papers (6%) proposed and/or

evaluated both global and local interpretability tech-

niques. Moreover, most of the data types that the se-

lected studies worked on were numeric (46%, 111 pa-

pers) and categorical (24%, 59 papers). The categori-

cal features employed were often encoded using ordi-

nal or label categorical encoding (CE), both of which

map the numerical values onto an integer in order to

represent each category. Label CE can disregard any

order a feature might have, such as the degree of ma-

lignancy in a cancer prognosis dataset. This can have

a negative impact on the relevance of the feature and,

therefore, on the performance of the model. It is for

this reason that ordinal CE is often used.

The gap in interpretability, coupled with the sig-

niﬁcant inﬂuence of data preprocessing methods like

CE on model performance, underscores the need for

more focused research in this area. Building on our

previous work that investigated Multilayer Percep-

trons (MLPs) (Hakkoum. et al., 2023), this study ex-

tends the exploration to SVMs, aiming to compare the

interpretability and performance of these models in

medical applications, particularly considering the im-

pact of different CE techniques.

This study, therefore, compares two well-known

interpretability techniques: global surrogates us-

ing DT and Shapley Additive exPlanations (SHAP)

(Lundberg and Lee, 2017) when used with an SVM

trained on two categorical medical datasets: breast

cancer (BC) and lymphography (Lymph) (Dua and

Graff, 2017). Moreover, it compares the results to

our previous analysis on MLP (Hakkoum. et al.,

2023). Following the application of three different

CEs, namely ordinal, categorical and dummy, the ML

384

Hakkoum, H. and Idri, A.

A Comparative Study on the Impact of Categorical Encoding on Black Box Model Interpretability.

DOI: 10.5220/0012766300003756

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 13th International Conference on Data Science, Technology and Applications (DATA 2024), pages 384-391

ISBN: 978-989-758-707-8; ISSN: 2184-285X

models were optimised using the particle swarm op-

timisation algorithm (PSO) to ensure maximum ac-

curacy. The accuracy of the models was ﬁrst com-

pared using the Wilcoxon test and the Borda count

voting system, after which the CEs were compared

using the SkottKnott (SK) statistical test. Moreover,

the SK test was repeated on the basis of the ﬁdelity

of the interpretability techniques in different settings

in order to discover the best CE in each situation. Fi-

nally, the effects of the CEs on accuracy and ﬁdelity

were compared in order to examine the effect on the

trade-off of accuracy versus interpretability. In this re-

spect, the research questions (RQs) listed below will

be addressed:

• RQ1: What is the impact of the CEs on accuracy?

• RQ2: Which CE is best for global interpretabil-

ity?

• RQ3: What is the best CE considering local inter-

pretability?

• RQ4: Which CE best reduces the trade-off be-

tween accuracy and interpretability?

This paper’s key contributions are: 1) A quan-

titative evaluation of interpretability techniques. 2)

The identiﬁcation of the effect of CE, along with the

best encoding scheme(s) in terms of accuracy and in-

terpretability, and 3) The determination of whether

a speciﬁc CE alleviates the accuracy-interpretability

trade-off.

The remainder of this paper is organised as fol-

lows: Section 2 describes related work while Section

3 describes the datasets, along with the metrics and

statistical tests used to identify the best performing

models. The experimental design used in this empir-

ical evaluation is presented in Section 4. Section 5

presents and discusses the ﬁndings, while Section 6

reports conclusions, limitation, and future directions.

2 RELATED WORK

While prior research has extensively explored the ac-

curacy of ML models, the impact of CEs on in-

terpretability remains less examined. Elshawi et

al.’s analysis of various interpretability techniques

(Elshawi et al., 2021), including global surrogates

and SHAP, within a cardio-respiratory ﬁtness dataset

highlights the need for more nuanced handling of cat-

egorical data. The data, as they presented it, contains

categorical features such as gender, race, and reason

for test (pains in chest, shortness of breath...). Unfor-

tunately, no further information regarding how cate-

gorical data were handled was provided. In general,

we believe that ordinal CE is, in most cases, used to

maintain the order that the attribute might have. In

fact, in some of the datasets in the UCI repository

(Dua and Graff, 2017), the categorical variable is al-

ready encoded with ordinal CE.

Similarly, Crone et al. and Potdar et al. have un-

derscored the signiﬁcant inﬂuence of CEs like ordi-

nal, one-hot, and dummy on model accuracy, with

disparities up to 14% observed across different encod-

ing schemes (Crone et al., 2006; Potdar et al., 2017).

These ﬁndings underscore the intricate balance be-

tween accuracy and interpretability in ML models,

particularly in SVMs and MLPs, prompting a deeper

investigation into the role of CEs within this context.

Figure 1: Experimental Design.

A Comparative Study on the Impact of Categorical Encoding on Black Box Model Interpretability

385

Table 1: Performance results.

Data Encoding MLP SVM Borda Winner

Acc F1 AUC Spearman Acc F1 AUC Spearman

BC Ordinal 0.6 0.476 0.398 0.167 0.6 0.153 0.455 -0.067 MLP

One-hot 0.618 0.399 0.404 0.120 0.654 0.095 0.425 0.003 MLP and SVM

Dummy 0.618 0.432 0.440 0.145 0.654 0.095 0.367 0.003 MLP and SVM

Lymph Ordinal 0.758 0.695 0.808 0.497 0.896 0.857 0.555 0.778 SVM

One-hot 0.827 0.782 0.580 0.641 0.827 0.782 0.656 0.641 SVM

Dummy 0.793 0.625 0.699 0.583 0.827 0.782 0.575 0.641 SVM

3 DATASETS AND METRICS

This study utilizes two only online categorical

datasets on the UCI repository: BC and Lymph (Dua

and Graff, 2017). The datasets have different numbers

of attributes (9 and 18 respectively) and a very low

number of instances (286 and 148 respectively). The

BC dataset describes a prognosis task of BC. There-

fore the binary classiﬁcation refers to the recurrence

or no recurrence of BC. Meanwhile, four classes of

the lymph dataset are available with different numbers

of instances: normal ﬁnd: 2, metastases: 81, malign

lymph: 61, and ﬁbrosis: 4. The ﬁrst and last classes

have very few instances: two in normal ﬁnd and four

in ﬁbrosis. Therefore, the multi-classiﬁcation in the

lymph dataset was converted to a binary one by re-

moving the classes normal ﬁnd and ﬁbrosis. There-

fore, for both datasets, we keep our classiﬁcation task

binary.

Moreover, performance is assessed similarly to

our previous study (Hakkoum. et al., 2023) using

standard metrics such as accuracy, F1-score, Spear-

man, and Area under the ROC (Receiver operating

characteristic) curve (AUC).

Interpretability is examined through the ﬁdelity

metric (which compares the black-box model’s pre-

dictions to the interpretability technique’s predictions

using the usual classiﬁcation metrics), the depth and

number of leaves in global surrogate models as well

as the Mean squared error (MSE) between SHAP and

the black box certainties for the test sets.

Cross-validation is used to ensure the robustness

of our ﬁndings, while the Borda count voting system

(de Borda, 1781) help identify the most effective CE

in optimizing both performance and interpretability.

Moreover, the statistical tests Wilcoxon (for pair com-

parisons) and SK (for multiple comparisons) were

conducted to determine the signiﬁcance of the differ-

ence between methods based on the aforementioned

metrics.

Wilcoxon was mainly used to check whether the

pair of models compared (MLP and SVM) was sta-

tistically different for one or multiple datasets. The

Table 2: Appearances of SK ranks according to model per-

formance.

Encoding 1st 2nd 3rd

Ordinal 8 4 4

One-hot 7 4 5

Dummy 4 10 2

Wilcoxon test returns a p-value that can be used to

interpret the results of the test. It can be considered

as the probability of observing the performance of the

two models given the base assumption/hypothesis that

they were drawn from a population with the same dis-

tribution. In this study, the threshold is ﬁxed at 5%.

Therefore, the assumption of the methods belonging

to the same distribution was rejected if the p-value

was less than 5%.

4 EXPERIMENT

Our experiment, as depicted in Figure 1, comprises

four primary stages: 1) Model construction and

evaluation including our previous results on MLP

(Hakkoum. et al., 2023); 2) We then delve into the

effects of CEs on model accuracy, examining how

different encoding strategies inﬂuence model perfor-

mance; 3) The third stage focuses on interpretability,

exploring how CEs impact both global and local inter-

pretability techniques, evaluated via the ﬁdelity met-

ric; 4) Lastly, we address the trade-off between ac-

curacy and interpretability, analyzing how CEs affect

this balance in SVM and MLPs.

5 RESULTS

This section presents and discusses the ﬁndings of

empirical evaluations carried out in this study in order

to answer the RQs. The experiments were performed

on a Lenovo Legion laptop with hexa-core Intel Core

i7-9750H processor with 16GB of RAM.

Initial data preparation involved cleaning and ad-

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

386

Table 3: Results of DT global surrogate.

Dataset Encoding MLP global surrogate SVM global surrogate Borda Winner

Spear. ﬁ-

delity

Depth Leaves Spear. ﬁ-

delity

Depth Leaves

BC Ordinal 0.285 15 67 0.348 14 83 SVM

One-hot 0.524 12 77 0.344 15 75 MLP

Dummy 0.671 18 72 0.375 16 65 SVM

Lymph Ordinal 0.368 6 16 0.454 8 25 MLP

One-hot 0.716 6 17 0.715 6 17 MLP

Dummy 0.629 7 19 0.607 7 17 MLP and SVM

dressing class imbalances in the Lymph dataset by

removing exceptionally small classes and applying

SMOTE to balance the training-validation sets, result-

ing in 159 no-recurrence and 63 recurrence cases for

the BC dataset, and 63 metastases and 50 malignant

cases for the Lymph dataset. The model hyperparam-

eters were optimised using PSO on the basis of ac-

curacy with a 10-fold cross validation using only the

training-validation set.

5.1 RQ1: What Is the Impact of the

CEs on Accuracy?

The concern of this empirical evaluation is the impact

of the CE on interpretability. Nevertheless, it starts

by investigating the impact of the CE on accuracy in

order to study the similarities of the effect of differ-

ent CEs on accuracy and interpretability, which can

explain changes in the trade-off.

Table 1 shows the performances of SVM along

with MLP from our previous study (Hakkoum. et al.,

2023). The Wilcoxon test was performed on the ac-

curacy of both models with the three CEs for: 1) each

dataset, and 2) both datasets. In order to further assess

the differences between the models (MLP vs. SVM)

the Borda count voting system was carried out to dis-

cover whether one model was outperforming the other

according to all the metrics.

For each dataset as well as regardless of the

dataset, the Wilcoxon test provided a p value higher

than 5% which validates the hypothesis of same dis-

tribution. Table 1 also shows the Borda winner where

SVM always outperformed MLP on Lymph while

MLP outperformed only once on BC with ordinal CE.

Although the Wilcoxon test showed that the models

are not signiﬁcantly different, it is possible to con-

sider that, according to the Borda count voting sys-

tem, SVM slightly outperforms MLP.

Investigating the inﬂuence of CEs on model ac-

curacy, the SK test was used to evaluate and rank

the performance of ordinal, one-hot, and dummy CEs

ﬁrst for each dataset, then across both datasets. The

evaluation considered four metrics: Accuracy, F1-

score, AUC, and Spearman correlation. The num-

ber of appearances of each CE in a SK rank (cluster)

was computed by considering the ranks of the CEs

for each metric in Table 1, and these are presented in

Table 2.

The appearances of each CE in a SK rank was

computed by considering each performance metric at

a time in different settings (each dataset/model, both

datasets/models). The ordinal CE generally outper-

formed the others, since it came ﬁrst 8 times, second

4 times and last 4 times, followed by one-hot then

dummy. Despite these differences, an aggregated SK

analysis across both models and both datasets deemed

all three CEs similarly effective.

5.2 RQ2: Which CE Is Best for Global

Interpretability?

Exploring global interpretability, we assessed the per-

formance of DT surrogates constructed with various

CEs. Despite ordinal encoding’s superior accuracy in

RQ1, this phase evaluated global surrogate efﬁcacy

via Spearman ﬁdelity, tree depth, and leaf count as

shown in Table 3.

Based on Table 3, it appears that there is a higher

performance for the Lymph dataset when compared

to the BC dataset, which was also noticed in the

case of model performance (RQ1). When compar-

ing SVM to the MLP, it is also noted that, according

to the Borda count voting system, MLP slightly out-

performed SVM by 3 wins to 2 with 1 draw. Nev-

ertheless, according to the Wilcoxon test, this differ-

ence was not signiﬁcant, since it led to very high p-

values (28%, 100%, and 46% on BC, Lymph, and

both datasets, respectively).

The SK clustering statistical test was used to help

rank the three CEs on the basis of global surrogate

metrics. The number of appearances of each CE in

each SK rank was computed according to Spearman

ﬁdelity, depth, and number of leaves, and is sum-

marised in Table 4. The one hot CE generally outper-

formed the others, since it came ﬁrst 6 times, second 4

times and last twice, followed by dummy and ordinal.

A Comparative Study on the Impact of Categorical Encoding on Black Box Model Interpretability

387

Despite these differences, an aggregated SK analysis

across both models and both datasets deemed all three

CEs similarly effective.

Table 4: Appearances of SK ranks according to global sur-

rogates.

Encoding 1st 2nd 3rd

Ordinal 4 3 5

One-hot 6 4 2

Dummy 4 5 3

5.3 RQ3: What Is the Best CE

Considering Local Interpretability?

This phase investigated local interpretability using

SHAP Spearman ﬁdelity to discern the most effec-

tive CE in enhancing model interpretability as shown

in Table 5. The results indicated that MLP classi-

ﬁers, particularly with the Lymph dataset, showcased

commendable performances. However, the Wilcoxon

test’s high p-values, both dataset-speciﬁc and overall,

suggested negligible differences in SHAP ﬁdelity be-

tween SVM and MLP models.

Further examination through SK rankings and the

frequency of appearances in these rankings as per

SHAP ﬁdelity underscored one-hot encoding’s supe-

riority, consistently securing top positions as shown in

Table 6. Despite these differences, an aggregated SK

analysis across both models and both datasets deemed

all three CEs similarly effective considering local ﬁ-

delity.

The inﬂuence of CEs on both interpretability and

model accuracy was also analysed, exploring if these

aspects are affected similarly by CEs. According to

the SK test on Spearman ﬁdelity, CEs belong to same

cluster, with a nuanced preference for one hot encod-

ing.

The SK clustering of the CEs for global and lo-

cal ﬁdelities is illustrated in Figure 2. All CEs of

global scope appeared to rank better than the local

ones. The one hot and dummy CEs of the global sur-

rogates came ﬁrst, followed by ordinal. Meanwhile,

the one hot CE from the local scope was placed in

the third cluster, followed by ordinal and dummy in

the last cluster. Nonetheless, regardless of the inter-

pretability scope (global or local), the CEs were as-

signed to the same cluster, with an insigniﬁcant pref-

erence for the one hot CE.

5.4 RQ4: Which CE Best Reduces the

Trade-Off Between Accuracy and

Interpretability?

For further comparison, the errors of model and

global surrogate were computed along with the MSE

of SHAP probabilities against model probabilities.

The errors are presented in Table 7 for both models

with both datasets, along with the Borda count vot-

ing system results, while Figure XXX illustrates the

differences between the CEs with the average number

of errors for both datasets. The analysis revealed that

while all CEs produced acceptable interpretability er-

rors (below 0.21), local interpretability errors were

notably lower than global ones, with ordinal CE lead-

ing in local interpretability and dummy CE excelling

globally, particularly for SVMs.

The Borda count voting system’s results further

reﬁned these insights, showing dummy CE’s superi-

ority in balancing the trade-off, as evidenced by its

consistent high rankings. Conversely, despite one-

hot CE’s high interpretability ﬁdelity, it did not se-

cure top ranks in balancing the trade-off according to

Borda count, suggesting that dummy CE might offer

the best compromise between maintaining model ac-

curacy and ensuring interpretability.

6 CONCLUSIONS AND

PERSPECTIVES

Two interpretability techniques (global surrogate and

SHAP) were empirically evaluated in this study. The

primary goal was to identify the inﬂuence of CE on

interpretability techniques using two opaque models

(SVM and MLP) trained on two medical categorical

datasets.

In most cases, the quantitative evaluations re-

vealed that SVM outperformed MLP and that ordinal

CE is preferred for better model performance. The

one hot CE appeared to provide better interpretabil-

ity results when using the global surrogate and SHAP.

However, according to SK clustering, global surro-

gate performed slightly better than SHAP when using

the Spearman ﬁdelities of both datasets. Finally, the

three CEs helped the black box models gain a degree

of transparency by reducing the trade-off with the sur-

prising outperformance of the dummy CE when com-

paring accuracy errors.

Ongoing work concerns studying the effect of

continuous attribute encoding on the accuracy and in-

terpretability of ML black box models. In fact, it

might be interesting to analyse the effect of many DP

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

388

Table 5: SHAP ﬁdelity and Wilcoxon tests.

Dataset Encoding MLP Spear. ﬁdelity SVM Spear. ﬁdelity Wilcoxon (p value)

BC Ordinal -0.330 -0.341

0.785

0.141

One-hot -0.146 0.103

Dummy 0.049 -0.200

Lymph Ordinal 0.697 -0.134

0.108

One-hot 0.384 0.298

Dummy 0.067 -0.196

Figure 2: SK clustering for CEs considering global/local scopes.

Table 6: Appearances of SK ranks according to SHAP ﬁ-

delity.

Encoding 1st 2nd 3rd

Ordinal 1 1 2

One-hot 2 2 0

Dummy 1 1 2

methods.

This study’s validity is inﬂuenced by the use of

only two datasets, potentially limiting the generaliz-

ability of the ﬁndings. The performance of the models

on these datasets may not fully capture the challenges

of applying CEs and interpretability techniques to

more complex or diverse medical data. Reproducibil-

ity efforts must consider the variability inherent in

ML models, especially with different hyperparameter

conﬁgurations.

ACKNOWLEDGEMENTS

This work was conducted under the research project

“Machine Learning based Breast Cancer Diagnosis

and Treatment”, 2020-2023. The authors would like

to thank the Moroccan Ministry of Higher Education

and Scientiﬁc Research, Digital Development Agency

(ADD), CNRST, and UM6P for their support.

REFERENCES

Benhar, H., Idri, A., and Fern

andez-Alem

an, J. (2020). Data

preprocessing for heart disease classiﬁcation: A sys-

tematic literature review. Computer Methods and Pro-

grams in Biomedicine, 195:105635.

Crone, S. F., Lessmann, S., and Stahlbock, R. (2006). The

impact of preprocessing on data mining: An evalua-

A Comparative Study on the Impact of Categorical Encoding on Black Box Model Interpretability

389

Table 7: Model and global/local errors.

Dataset Encoding MLP Borda

Ranks

SVM Borda Ranks

Accuracy er-

ror

Global error SHAP MSE Accuracy error Global error SHAP MSE

BC Ordinal 0.4 0.128 0.041 1 0.4 0.237 0.030 2

One-hot 0.382 0.164 0.090 3 0.346 0.237 0.063 3

Dummy 0.382 0.164 0.076 2 0.346 0.219 0.060 1

Lymph Ordinal 0.242 0.173 0.029 3 0.104 0.173 0.039 1

One-hot 0.173 0.138 0.107 2 0.173 0.138 0.065 3

Dummy 0.207 0.035 0.046 1 0.173 0.069 0.061 2

Figure 3: Model vs. global and local interpretability techniques trade-off based on error.

tion of classiﬁer sensitivity in direct marketing. Euro-

pean Journal of Operational Research, 173(3):781–

800.

de Borda, J.-C. (1781). M

emoire sur les

elections au scrutin.

Histoire de l’Acad

emie Royale des Sciences.

Dua, D. and Graff, C. (2017). UCI machine learning repos-

itory.

Elshawi, R., Al-Mallah, M., and Sakr, S. (2021). On

the interpretability of machine learning-based model

for predicting hypertension. BMC Med Inform Decis

Mak, 19(146).

Hakkoum, H., Abnane, I., and Idri, A. (2022). Interpretabil-

ity in the medical ﬁeld: A systematic mapping and re-

view study. Applied Soft Computing, 117:108391.

Hakkoum., H., Idri., A., Abnane., I., and Luis Fernades-

Aleman., J. (2023). Does categorical encoding af-

fect the interpretability of a multilayer perceptron for

breast cancer classiﬁcation? In Proceedings of the

12th International Conference on Data Science, Tech-

nology and Applications - DATA, pages 351–358. IN-

STICC, SciTePress.

Heinrichs, B. and Eickhoff, S. B. (2020). Your evi-

dence? machine learning algorithms for medical

diagnosis and prediction. Human Brain Mapping,

41(6):1435–1444.

Hosni, M., Abnane, I., Idri, A., Carrillo de Gea, J. M., and

Fern

andez Alem

an, J. L. (2019). Reviewing ensem-

ble classiﬁcation methods in breast cancer. Computer

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

390

Methods and Programs in Biomedicine, 177:89–112.

Idri, A., Chlioui, I., and Ouassif, B. E. (2018). A systematic

map of data analytics in breast cancer. In Proceedings

of the Australasian Computer Science Week Multicon-

ference, ACSW ’18, New York, NY, USA. Associa-

tion for Computing Machinery.

London, A. J. (2019). Artiﬁcial intelligence and black-

box medical decisions: Accuracy versus explainabil-

ity. Hastings Center Report, 49(1):15–21.

Lundberg, S. M. and Lee, S.-I. (2017). A uniﬁed ap-

proach to interpreting model predictions. NIPS’17,

page 4768–4777, Red Hook, NY, USA. Curran Asso-

ciates Inc.

Molnar, C. (2022). Interpretable Machine Learning. 2 edi-

tion.

Potdar, K., Pardawala, T., and Pai, C. (2017). A comparative

study of categorical variable encoding techniques for

neural network classiﬁers. International Journal of

Computer Applications, 175:7–9.

Zerouaoui, H., Idri, A., and El Asnaoui, K. (2020). Ma-

chine learning and image processing for breast can-

cer: A systematic map. In Rocha,

A., Adeli, H., Reis,

L. P., Costanzo, S., Orovic, I., and Moreira, F., edi-

tors, Trends and Innovations in Information Systems

and Technologies, pages 44–53, Cham. Springer In-

ternational Publishing.

A Comparative Study on the Impact of Categorical Encoding on Black Box Model Interpretability

391
