Optimizing Privacy-Utility Trade-Off in Healthcare Processes:

Simulation, Anonymization, and Evaluation (Using Process Mining) of

Event Logs

Omar Samy Kamal

, Syeda Amna Sohail

and Faiza Allah Bukhsh

University of Twente, 7500 AE, Enschede, The Netherlands

Keywords:

Simulation, Synthetic Data, Anonymization, K-Anonymity, Event Logs, Process Mining, Privacy-Utility

Trade-Off.

Abstract:

In healthcare, big data analytics involve balancing patients’ privacy and data utility. Optimizing healthcare

data utility often includes limited access to sensitive data by trusted onsite entities. This potentially hinders

broader-scale data utilization by third-party data analysts. As a solution, this research simulates a health-

care process-based event log, inspired by a local hospital’s radiology department. The simulated event log is

anonymized using k-anonymity. The anonymized and un-anonymized event logs are evaluated, through pro-

cess discovery techniques, using the process mining tool, ProM 6.11, for Privacy-utility trade-off assessment.

Results indicate successful privacy preservation with a distinct loss in utility in the anonymized healthcare

process model, which was not visible otherwise. Therefore, to ensure the efﬁcacy of healthcare process anal-

ysis on anonymized sensitive event logs, the utilization of process mining techniques is beneﬁcial for process

utility and privacy protection evaluation.

1 INTRODUCTION

In healthcare, big data analytics involve balancing be-

tween the privacy of patients’ personally identiﬁable

information (PII) and optimal data utility. Optimal

data utility entails the maximum usefulness of health-

care datasets (Mivule, 2013). Whereas, privacy in-

volves patients’ direct or indirect control over their

PII in addition to their explicit informed consent. To

avoid potential privacy threats, healthcare providers

limit the access of their healthcare data to onsite data

analysts only. This hampers the large-scale usefulness

of the healthcare datasets. Recognizing the sensitiv-

ity of using real data belonging to individuals and its

privacy concerns, the utilization of synthetic data be-

comes imperative and hence contributes immensely to

the scientiﬁc community at large.

This research work ensures the preservation of the

privacy rights of data subjects and compliance with

data privacy regulations as per GDPR (2018). Sim-

ulation and synthetic data generation are considered

essential in accurately mimicking a real-world system

https://orcid.org/0009-0004-8836-2520

https://orcid.org/0000-0001-8078-0411

https://orcid.org/0000-0001-5978-2754

with private patients’ data. The generated synthetic

model allows the generation of the most suitable event

logs. Event logs are the datasets that depict an end-to-

end process of all the activities/treatments of all the

patients involved. The extracted event logs can then

serve as a valuable tool to assist healthcare providers

in making informed decisions that enhance the quality

of healthcare processes. The discrete event simulation

technique was chosen to generate this model mainly

because this technique guarantees the accurate repre-

sentation of healthcare processes and events (being

carried out in the model). The simulated healthcare

event logs are later anonymized to ensure privacy. Af-

terward, the data utility of both, the anonymized and

unanonymized event logs, is evaluated using ProM for

process mining. ProM (ProM) is a one-stop shop for

the evaluation of end-to-end processes using process

mining.

The research objective of this paper is to report

a healthcare event log simulation, its anonymization,

and evaluation using Process Mining (PM). The eval-

uation will include the assessment of the privacy-

utility-tradeoff of healthcare process workﬂow. For

the latter, the un-anonymized event log will be com-

pared against the anonymized event log using the in-

ductive visual miner plugin in ProM. This compar-

Kamal, O., Sohail, S. and Bukhsh, F.

Optimizing Privacy-Utility Trade-Off in Healthcare Processes: Simulation, Anonymization, and Evaluation (Using Process Mining) of Event Logs.

DOI: 10.5220/0012766800003758

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 14th International Conference on Simulation and Modeling Methodologies, Technologies and Applications (SIMULTECH 2024), pages 289-296

ISBN: 978-989-758-708-5; ISSN: 2184-2841

289

ison will reveal whether privacy is preserved while

maintaining optimal data utility? If not, the underly-

ing reasons will be provided on why the utility might

have been affected. This research objective yields the

research question “How was the utility of event logs

affected by the anonymization process when compar-

ing un-anonymized event logs with anonymized event

logs using ProM?”

The structure of the paper is as mentioned ahead:

The section 2 will explore the relevant literature.

The section 3 will depict the employed overarch-

ing methodology and employed tools in this research

work. The section 4 will exhibit the artifact design

that includes simulation modeling, data set genera-

tion, even log simulation, and its anonymization using

K-anonymity. The section 5 assesses the effective-

ness of the design through evaluation and discovers

their contribution to fulﬁlling the research objectives

by answering the research question. The paper will

discuss limitations encountered during the study and

propose suggestions for future work in section 6.

2 RELATED WORK

The simulation model is a reasonable approximation

to a real system. The aim of the simulation model-

ing process or a system is to predict what impact the

modiﬁcations may have on the system (Maria, 1997).

Simulation is used to validate, modify, and experi-

ment in ways that are usually expensive and unre-

alistic using a real system. This simulated model

can then be used to analyze the model’s behavior to

make judgments/assumptions about the actual pro-

cesses and system. Additionally, simulation is a crit-

ical tool for evaluating the performance of a process

within a deﬁned period while under numerous conﬁg-

urations. Simulation is also generally used to lower

the chances of not meeting the required standards, op-

timize the utilization of resources to avoid shortage or

wastage, prevent unexpected inefﬁciencies, and en-

sure maximum system efﬁciency by optimizing the

performance of a system before applying any changes

to the existing system or the new system being built

(Maria, 1997). The simulation technique used in this

paper is discrete event simulation, due to its focus on

healthcare operations which correlates to the radiol-

ogy department model being simulated in this paper.

Discrete Event Simulation is a modeling tech-

nique that is focused more on how individual events in

a system behave, rather than at a collective level. This

technique models the systems which involve discrete

events, examples of such events include a queuing,

manufacturing process, or patients’ care pathways.

Discrete event simulation gives freedom in testing dif-

ferent scenarios and later evaluates the effect of these

different factors on the system’s performance.

Process Mining (PM) is a collection of tech-

niques that enables the discovery, analysis, and en-

hancement of business processes using event logs,

which provide valuable insights (Van Dongen et al.,

2005). PM is utilized by organizations to identify re-

lationships, visualize workﬂows, and uncover hidden

dynamics within a process (Leemans and Fahland,

2014), (Leemans, 2017) & (Schrijver, n.d.). PM ex-

poses inefﬁciencies and bottlenecks in the process

being analyzed. Moreover, these analysis methods

help organizations identify limitations within their

processes, leading to informed decisions that reduce

costs, increase efﬁciency, and maximize overall per-

formance.

Event logs are end-to-end process-based datasets

that are typically extracted from an organization’s in-

formation systems. In process mining, event logs rep-

resent a sequential record of events that occur within a

business process (Nogueira, 2021). Each event in the

log represents an action, interaction, or incident. The

events are timestamped with their start and stop dates

of execution and may contain other associated data.

Examples of data that event logs capture include the

agents involved in a process, resources utilized, and

outcomes of a process (Van Dongen et al., 2005).

Noise Addition/Anonymization Large data col-

lected by organizations such as the Population and

Housing Census in the EU usually release statisti-

cal databases (Eurostat, n.d.). However, before this

is done, sensitive information such as personal iden-

tifying information (PII) is removed. Although PII

is removed, researchers agree that if these databases

are combined with extra data, malicious actors could

succeed in identifying an individual. Data Privacy

& Conﬁdentiality are the measures taken to protect

individuals from any unauthorized sharing of infor-

mation. Data Security ensures that this private data

is only accessible to authorized parties. Data de-

identiﬁcation involves a process where PII is ﬁrst

removed from a dataset. Moreover, the Data de-

identiﬁcation process which is also interchangeably

named as data anonymization can remove or modify

PII attributes in such a way that it makes the retrieval

of an individual identity difﬁcult upon the data re-

lease to the public. Furthermore, Data Utility versus

privacy also referred to as Privacy-Utility Trade-Off

(PUT) is the balance between how useful a dataset is

to the user and the crucial need to safeguard privacy.

Usually, before datasets are published to the public,

publishers follow procedures to remove PII and ap-

ply noise-adding techniques to distort the data. How-

SIMULTECH 2024 - 14th International Conference on Simulation and Modeling Methodologies, Technologies and Applications

290

ever, these measures may result in the original data

to suffer from losing its statistical properties. Con-

sequently, achieving PUT is always a desired goal

for researchers (Sramka et al., 2010), (Rastogi et al.,

n.d.), and (Sankar et al., 2010). Unfortunately, re-

searchers in data privacy agreed that achieving data

privacy without reducing data utility is a challenging

task (Mivule, 2013).

3 METHODOLOGY AND TOOLS

For a systematic methodological approach, the paper

is based on the CRISP-DM (Cross-Industry Standard

Process for Data Mining) methodology (Hotz, 2018).

The CRISP-DM is a framework, used in data mining

projects, made up of six phases. The six main phases

of the CRISP-DM methodology are: Business Un-

derstanding, Data Understanding, Data Preparation,

Modeling, Evaluation, Deployment see (Hotz, 2018)

for details. Some of the publicly available tools used

in this research work include:

AnyLogic (AnyLogic, n.d.) is a simulation soft-

ware tool that is used to create models to gain insights

into the workﬂows of several systems, enabling opti-

mization. The AnyLogic software offers an easy-to-

use user interface, that allows the modeling of health-

care processes as well. The software tool offers differ-

ent simulation techniques such as Discrete-Event sim-

ulation, Agent-Based Modeling, and System dynam-

ics, which help discover complexities found within

real-world systems.

ARX (ARX, n.d.), also known as Anonymiza-

tion Toolbox, is a software tool used for incorporat-

ing privacy-preserving techniques. This tool helps

tackle concerns regarding data privacy by implement-

ing techniques that aim to protect sensitive infor-

mation while still preserving data utility (Kadampur,

2010). By utilizing this tool datasets are anonymized

before being shared with third parties, which results in

compliance with privacy regulations. Anonymization

techniques that the tool offers include k-anonymity, t-

closeness, differential privacy, and l-diversity (ARX,

n.d.).

ProM (ProM, n.d.), is a tool that allows analysis

and reﬁnement of a business process by using event

logs (Nogueira, 2021), (Leemans and Fahland, 2014),

and (Leemans, 2017). The tool assists organizations

in gaining valuable insights from their data. Pro-

cess mining techniques ProM supports include pro-

cess discovery, conformance checking, and perfor-

mance analysis. ProM can effectively present pro-

cess models, showcase bottlenecks, and detect unex-

pected behavior. Additionally, ProM includes a li-

brary that has an extensive collection of plugins, en-

hancing the capability and functionality of the soft-

ware, making it an invaluable tool for process mining

research projects.

4 DESIGN

4.1 AnyLogic: Radiology Department

AnyLogic is used for the simulated Radiology De-

partment Model, modiﬁed from a pre-existing exam-

ple model named “Emergency Department” in Any-

Logic (AnyLogic, n.d.).This simulation model recre-

ates the workﬂow and process of radiology services

offered to patients. The model is made up of entities

that fall under different resource categories. These

entities provide utility and execute actions within the

model. The three resource categories are: moving,

static, and portable. The moving resources are en-

tities within the model that can move freely. Ex-

amples include Nurses, Physician Assistants (PA’s),

and Technicians. Static resources refer to the entities

that remain in ﬁxed positions, they are represented

by a location or a physical piece of medical equip-

ment. Examples are Waiting Rooms, Triage Rooms,

EC Rooms, and the X-RAY device. The last resource

type, portable, are entities within the model that can

be moved around, however, movement is not possible

on its own. Thus, only personnel within the hospital

are allowed to carry these resources. So, the resources

are carried and moved by speciﬁc hospital staff, who

then use them for a particular task. The MRI and Ul-

trasound devices are examples of portable resources.

The radiology department model is made of var-

ious agents (Entities & Resources)namely: 2 Triage

Room, 2 ECG Rooms, 1 Waiting Room, 1 Medi-

cal Device Storage Room, 1 X-Ray Room, 5 PA’s, 5

Nurses, 3 Technicians, 2 MRI Devices, 2 Ultrasound

Devices, and 1 X-Ray Device. The simulation model

can be viewed in 3D, 2D, and Logic 1 views. The

3D format displays a three-dimensional environment

of the model, along with other 3D icons for resources.

The 2D format displays a two-dimensional view, and

the logic format shows the ﬂowchart with blocks for

building the model.

The healthcare process starts with patients’ arrival

as agents in the simulation model. After that, the pa-

tients register at the front desk, waiting at the queue

to get registered. After registration, the Patients wait

to be allocated to a nurse to get checked on in a wait-

ing room. Afterwards, the nurse escorts the patient

into a triage room where the severity of the patient’s

condition is examined. Later the patient returns to the

Optimizing Privacy-Utility Trade-Off in Healthcare Processes: Simulation, Anonymization, and Evaluation (Using Process Mining) of

Event Logs

291

Figure 1: 3D, 2D, and Logic models of Radiology Department (Left to Right).

waiting room, and the nurse then decides whether the

patient should be treated ﬁrst. The patient then returns

to the waiting room and when it’s time for treatment

a Physician Assistant (PA) and technician are called

up to treat the patient. Then the patient is assigned

a medical treatment process based on three different

outputs namely: Ultra Sound , MRI , and X-Ray. Af-

ter the process is completed, the patient is discharged

and leaves the department.

4.2 Synthetic Data Generation

A synthetic dataset is generated and imported into

the built simulation model. The website ”Fake Name

Generator” (Generator, 2006) is a platform for gen-

erating bulk fake data and allows the customization

of many different attributes. The data is generated

for around 500 patients with the following attributes:

Given name, Surname, Gender, Birthday (m/d/yyyy),

Telephone number, and Blood type. Afterwards,

the data set is imported into the built-in AnyLogic

database. This database mapped the attributes of the

patients entering the radiology department. Lastly,

the simulation model was run to generate required

event logs.

4.3 Event Logs

Model execution recorded different event logs, cap-

turing the behavior of diverse agents and resources

within the radiology department, into the log folder

inside the AnyLogic database. Since the focus is

on testing the PUT using ProM, the emphasis is on

evaluating event logs that offer information on pa-

tient IDs, timestamps of activities, resource pools,

and processes patients undergo for valuable insight.

The event logs providing these insights are the “agent

parameter log” (APL) and “ﬂowchart process states

log” (FPSL). The APL stores parameter values of in-

dividual agents in the simulation model, and the FPSL

records the timestamps individual agents spent in dif-

ferent states of the ﬂowchart blocks.

4.4 Anonymization Using ARX

After exporting the unanonymized event log from

AnyLogic, it is imported into ARX for anonymiza-

tion see 2. Before anonymization using ARX, at-

tributes are labeled either under: Identifying, quasi-

identifying, sensitive, or insensitive. The identify-

ing attributes include given name, surname, and tele-

phone number. Quasi-identifying attributes include

blood type, date of birth, and gender. Sensitive at-

tributes does not have any speciﬁc columns associ-

ated. Insensitive attributes include agent, agent type,

block type, block, activity type, start date, and stop

date.

The columns listed in the identifying attributes

include personally identiﬁable information (PII). PII

can directly identify a speciﬁc individual, thus. needs

to be removed from the dataset to preserve the pri-

vacy of the patient. However, quasi-identifying at-

tributes can indirectly be linked to individuals. The

more quasi-identiﬁer attributes are present in a dataset

the easier it becomes for the risk of re-identiﬁcation

to increase. Thus, it is essential to safeguard these

attributes during the anonymization process appropri-

ately. Sensitive attributes are attributes that patients

do not necessarily like being associated with, these

may include symptoms, diagnosis, and health condi-

tions. It is important to note that the dataset being

anonymized does not include any columns of the sen-

sitive attribute type. Finally, the last attribute type,

insensitive, which includes most of the columns in

ﬁgure 2, does not pose any privacy risks. Moreover,

the inclusion or exclusion of these columns within the

dataset does not affect the anonymization process.

4.5 Transforming Quasi-Identiﬁers

Once all columns are classiﬁed according to their at-

tribute type, the anonymization process begins with

a focus on transforming quasi-identifying attributes.

Since quasi-identiﬁers when combined, can poten-

tially lead to patient identiﬁcation. For attribute trans-

formation, a method known as generalization is used.

This method aids in reducing the possibility of re-

identiﬁcation by broadening the data and making it

SIMULTECH 2024 - 14th International Conference on Simulation and Modeling Methodologies, Technologies and Applications

292

Figure 2: Final version of imported event log.

less precise to a speciﬁc individual (Marques and

Bernardino, 2020). The ﬁrst quasi-identifying at-

tribute, blood type, is transformed using the general-

ization method known as masking by adding an aster-

isk for each level, making it more privacy-preserving.

As shown in ﬁgure 3, there are three different lev-

els, level-0 is the raw data from the data set, level-1

is the masking of either the plus or minus sign, and

level-2 is a fully suppressed data. The second quasi-

identifying attribute being transformed is the date of

birth. The ﬁrst level, level 0, shows the raw data from

the dataset. The second level, level 1, generalizes the

date more by only using the birth year. The last level,

level 2, shows the patient’s decade intervals. Finally,

the third quasi-identifying attribute , gender, has only

two levels one being the raw data and the other in-

cludes a universal bracket with both genders.

4.6 Anonymization Using K-Anonymity

Following the transformation of quasi-identiﬁers us-

ing generalization, a privacy model in ARX also

known as an anonymization technique is applied. In

ARX various anonymization techniques are available,

however, for this paper, the k-anonymity technique is

used. K-anonymity ensures that each group of quasi-

identiﬁers within a dataset is identical to at least k-

1 other patients (Prasser et al., 2016). This means

that the groups of attributes that could identify a pa-

tient are combined with other groups making it difﬁ-

cult for anyone to separate patients in and follow each

other and re-identify them. This technique provides a

higher level of privacy protection within a dataset and

helps maintain conﬁdentiality for sensitive informa-

tion. An example of K-anonymity is shown in ﬁgure

4.7 Anonymized Event Log Attributes

Finally, after the use of the k-anonymity, ARX gen-

erates an anonymized dataset. ARX generates this

anonymized dataset by taking into consideration spe-

ciﬁc weight settings chosen for each quasi-identifying

attribute to prioritize their importance. These weight

settings ensure that information loss is minimized

while preserving privacy. A subset of the dataset con-

taining the anonymized attributes is shown in ﬁgure

5 EVALUATION

5.1 Utility and Re-Identiﬁcation Risk

Analysis Using ARX

ARX includes a feature that allows the analysis of the

datasets’ utility post-anonymization, this enables the

evaluation of the success of the anonymization pro-

cess. The insights provided concern the granular-

ity and precision (generalization intensity) percent-

ages of quasi-identiﬁers, which help assess the level

of detail and accuracy preserved in the anonymized

event log. ARX also offers a risk analysis feature that

evaluates the potential re-identiﬁcation risk associated

with the event log before and after anonymization.

As shown in table 1, the re-identiﬁcation risk for the

unanonymized log was 24.347% but after anonymiza-

tion, this number decreased to 0.232%. This indicates

the successful anonymization of the dataset.

5.2 Utility Analysis Using ProM

To import the anonymized and anonymized ﬁles into

ProM, ﬁrst, they had to be converted from CSV

format into the eXtensible Event Stream (XES) ﬁle

format, which is the format compatible with ProM.

To successfully achieve this conversion, the “Con-

vert CSV to XES” plugin by F. Mannhardt was used

(Mannhardt et al., n.d.). This process involved map-

ping the columns of the event log to the case of the

relevant ﬁeld, event, start time, and completion time

(Nogueira, 2021). The column “agent” is mapped

to “case column”, “block” to “event column”, “start

time” to “start date”, and “completion time” to “stop

date”. Following the completion of this conversion,

the event log is then suitable for analysis.

For measuring the utility difference between the

unanonymized and anonymized event logs in ProM,

a comparison was made using the process discov-

Optimizing Privacy-Utility Trade-Off in Healthcare Processes: Simulation, Anonymization, and Evaluation (Using Process Mining) of

Event Logs

293

Figure 3: Levels of generalization transformations for blood type, dob, and gender attributes (left to right).

Table 1: Re-identiﬁcation risk of un-anonymized log vs anonymized log.

Unanonymized Log Anonymized Log

Re-identiﬁcation Risk (%) 24.347% 0.232%

Figure 4: Example of a k-anonymity dataset (k=4).

Figure 5: Snapshot of a subset of the anonymized event log.

ery technique namely, “inductive visual miner plu-

gin” (Leemans and Fahland, 2014)(Leemans, 2017).

This plugin extracts behavioral patterns and process

ﬂow from the events to then provide a visual anima-

tion of the process model (Schrijver, n.d.). This ani-

mated process model then enables understanding the

relationship between events and gaining insights into

the whole process.

Figure 6 displays both the unanonymized and

anonymized event logs of the two different paths be-

ing compared using the IVM plugin in ProM 6.11.

The paths in the unanonymized and anonymized logs

exhibit distinct differences, indicating a potential im-

pact on utility. In the left ﬁgure, there are fewer oc-

currences of paths, displaying only true paths without

redundancy. However, the right ﬁgure shows a signiﬁ-

cantly higher number of path occurrences. This result

suggests that the utility of the observed anonymized

event log is distinctively affected by anonymization.

Additionally, the observed differences in the paths

demonstrate a potential trade-off between privacy and

utility for the event logs, particularly in terms of pri-

vacy preservation for patients and the level of data

granularity.

Figure 6: Process model of un-anonymized (left) and

anonymized (right) event logs.

5.3 Discussion

The k-anonymity technique is crucial for preserving

privacy, it also presents challenges that impact the

data utility. Three reasons that might lead to this util-

ity loss are information loss, indirect effects, and ran-

domness.

The ﬁrst reason for information loss is due to the

SIMULTECH 2024 - 14th International Conference on Simulation and Modeling Methodologies, Technologies and Applications

294

reduction in information. Since attributes are either

generalized or suppressed to achieve anonymity and

avoid re-identiﬁcation, the level of detail within the

data decreases. This loss of precise detail in the event

logs makes it harder when conduct a detailed analysis

of the process model. Furthermore, the rich insights

that could be previously extracted from the original

data now become restricted, leading to a lack of in-

depth information. The second critical reason for ex-

periencing this utility loss is that k-anonymity may

have indirect effects that result in additional changes

to the data. Although the focus may be on preserving

privacy for certain columns, the column related to ac-

tivities in the event log may be accidentally modiﬁed

during anonymization. This would then lead to con-

sequences for the data such as reduced reliability. The

third and ﬁnal factor is the introduction of randomness

to the process model due to anonymization. Since

the k-anonymity technique groups different patients

into equivalence classes, this can affect the ordering

of events or activities and may introduce deviations to

the process model. Therefore, randomness spreads in

the event log, resulting in a less accurate and consis-

tent representation compared to the error-less process

model of the unanonymized event log. Furthermore,

one notable thing that was observed is that process

mining was able to reveal hidden insights from the

simulation model that were not apparent at ﬁrst. Dur-

ing the examination of the unanonymized event log,

differences in the process ﬂow were noticed, which

were not conﬁgured in the model settings. This evi-

dence proves the signiﬁcance of process mining in un-

covering valuable insights that would usually remain

unnoticed. In a nutshell, with process mining, health-

care organizations can gain a deeper understanding

of their processes, identify bottlenecks, and make in-

formed decisions resulting in the optimization of their

workﬂow performance, and can extend the evaluation

of privacy-utility trade-off as well.

5.4 Limitations Concerning Process

Mining

The limitations included the limited available litera-

ture and plugins on process mining applications for

privacy-utility trade-off evaluation. Another sub-area

limitation was the non-working condition of noise-

adding plugins within the ProM toolkit. The noise-

adding plugins would have allowed anonymization

using ProM itself and would have prevented the addi-

tion of another tool usage outside the domain of ProM

and process Mining. Another limitation is the usage

of compliance-checking plugins within ProM and the

calculation of precision, ﬁtness, and generalization.

We intentionally avoided the aforementioned quality

assurance parameters to keep the focus on the health-

care process workﬂow comparisons of both the event

logs and not an event log and its comparison to the

discovered process model.

6 CONCLUSION & FUTURE

WORK

6.1 Conclusion

Initially, this research work included the simulation

of a model that reﬂected well the real-life hospi-

tal settings of a local radiology department with a

wide range of customizable parameters using Any-

Logic. The model allowed us to simulate a syn-

thetic dataset, comprising 500 patients with varied at-

tributes, respective agents, and resources, to be im-

ported into the simulation model for event log cre-

ation. The simulation run created several event logs.

However, the most suitable event logs were selected

that could provide the most useful insight concerning

healthcare process workﬂow using ProM for process

mining (PM). The event logs are then anonymized

using K-anonymity with the ARX tool. ARX also

performed the re-identiﬁcation risk and utility assess-

ments of anonymized event logs to assess privacy and

utility preservation respectively. ARX showed 24%

more privacy and 40% less utility in the anonymized

event logs. The decrease in utility resulted because

of the shufﬂing in patients’ physical attributes, which

was required to apply the k-anonymity. We wanted

to dig deeper to evaluate the privacy-utility-tradeoff

for the events-based process workﬂows (namely pa-

tients’ clinical pathways), their relationship to one an-

other, and the whole process. To identify the latter,

the event logs are evaluated using ProM 6.11. Pro-

cess Mining (PM) offered valuable insights into pro-

cess workﬂows. The utility difference between the

unanonymized and anonymized event logs is evalu-

ated using the process discovery technique namely

the inductive visual miner plugin in ProM 6.11. This

plugin extracts the process workﬂow from the events

(i.e., treatments) and provides a visual animation of

the process model. The animated process models en-

abled an understanding of the relationship between

events and gaining insights into the whole process by

replaying the log. Additionally, the PM highlighted

privacy preservation in the anonymized event log but

a distinct utility loss in the process model and hence

potentially reduced the utility of the anonymized

event log. Therefore, ensuring the efﬁcacy of process

analysis on anonymized sensitive event logs is imper-

Optimizing Privacy-Utility Trade-Off in Healthcare Processes: Simulation, Anonymization, and Evaluation (Using Process Mining) of

Event Logs

295

ative for progress in both process utility analysis and

privacy protection through the utilization of process

mining.

6.2 Future Work

The future work can include reﬁning the simulation

model by adding patients’ symptoms to the selected

output block for the three imaging processes to avoid

patients being randomly assigned using probabilities.

Additionally, other synthetic data attributes (such as

symptoms, BSN, occupation, etc) inclusion will im-

prove the quality of the dataset and enrich its in-

formation. Furthermore, other anonymization tech-

niques such as l-diversity and t-closeness, can be built

upon k-anonymity after the inclusion of sensitive at-

tributes as they are a prerequisite for the use of other

anonymization techniques. Lastly, the use of newly

available plugins for process discovery and perfor-

mance analysis would be beneﬁcial in evaluating the

utility of event logs.

REFERENCES

Hotz, N. (2018). What is CRISP DM? Data Science Process

Alliance. https://www.datascience-pm.com/crisp-dm-

2/.

Maria, A. (1997). Introduction to modeling and

simulation. Proceedings of the 29th Confer-

ence on Winter Simulation - WSC ’97, 7–13.

https://doi.org/10.1145/268437.268440

Van Dongen, B. F., De Medeiros, A. K. A., Verbeek, H. M.

W., Weijters, A. J. M. M., & Van Der Aalst, W. M. P.

(2005). The ProM Framework: A New Era in Process

Mining Tool Support. In G. Ciardo & P. Darondeau

(Eds.), Applications and Theory of Petri Nets 2005

(Vol. 3536, pp. 444–454). Springer Berlin Heidelberg.

https://doi.org/10.1007/11494744 25

Population and housing censuses—Population and demog-

raphy—Eurostat. (n.d.). Retrieved December 8, 2023,

from https://ec.europa.eu/eurostat/web/population-

demography/population-housing-censuses

Mivule, K. (n.d.). Utilizing Noise Addition for Data Pri-

vacy, an Overview.

Prasser, F., Kohlmayer, F., & Kuhn, K. (2016).

The Importance of Context: Risk-based De-

identiﬁcation of Biomedical Data. Methods

of Information in Medicine, 55(04), 347–355.

https://doi.org/10.3414/ME16-01-0012

Mannhardt, F., Tax, N., Schunselaar, D., & Verbeek, E.

(n.d.). Den Dolech 2, 5612 AZ Eindhoven P.O.

Box 513, 5600 MB Eindhoven The Netherlands

www.tue.nl.

Nogueira, F. (2021). Hands-on Process Mining:

Event Visualisation with ProM. Laredoute.Io.

https://laredoute.io/blog/hands-on-process-mining-

event-visualisation-with-prom/

Leemans, S. J. J., & Fahland, D. (2014). Process and Devi-

ation Exploration with Inductive visual Miner.

Leemans, S. (2017). Inductive visual Miner manual.

https://www.semanticscholar.org/paper/Inductive-

visual-Miner-manual-Leemans-Prom/

c09fd03d82bea9d2df50682ed4c220df21648005

Schrijver, G. (n.d.). Using process mining to compare dif-

ferent variants of the same reimbursement process: A

case study.

Radiologie. (n.d.). Medisch Spectrum

Twente. Retrieved July 21, 2023, from

https://www.mst.nl/p/specialismen/radiologie/

Sramka, M., Safavi-Naini, R., Denzinger, J., & Askari, M.

(2010). A practice-oriented framework for measuring

privacy and utility in data sanitization systems. Pro-

ceedings of the 2010 EDBT/ICDT Workshops, 1–10.

https://doi.org/10.1145/1754239.1754270

Rastogi, V., Suciu, D., & Hong, S. (n.d.). The Boundary

Between Privacy and Utility in Data Publishing.

Sankar, L., Rajagopalan, S. R., & Poor, H. V. (2010).

Utility and privacy of data sources: Can Shannon

help conceal and reveal information? 2010 Informa-

tion Theory and Applications Workshop (ITA), 1–7.

https://doi.org/10.1109/ITA.2010.5454092

AnyLogic: Simulation Modeling Software Tools & Solu-

tions for Business. (n.d.). Retrieved July 21, 2023,

from https://www.anylogic.com/

Kadampur, M. A. (2010). A Noise Addition Scheme in De-

cision Tree for Privacy Preserving Data Mining. 2(1).

ARX - Data Anonymization Tool — A comprehen-

sive software for privacy-preserving microdata pub-

lishing. (n.d.). Retrieved July 21, 2023, from

https://arx.deidentiﬁer.org/

ProM Tools – The Process Mining Framework. (n.d.). Re-

trieved July 21, 2023, from https://promtools.org/

Order Free Random Names—Fake Name Genera-

tor. (n.d.). Retrieved July 21, 2023, from

https://www.fakenamegenerator.com/order.php

Marques, J., & Bernardino, J. (2020). Analy-

sis of Data Anonymization Techniques: Pro-

ceedings of the 12th International Joint Confer-

ence on Knowledge Discovery, Knowledge En-

gineering and Knowledge Management, 235–241.

https://doi.org/10.5220/0010142302350241

SIMULTECH 2024 - 14th International Conference on Simulation and Modeling Methodologies, Technologies and Applications

296
