The IoT Breaches Your Household Again

Davide Bonaventura

1 a

, Sergio Esposito

2 b

and Giampaolo Bella

1 c

Dipartimento di Matematica e Informatica, Universit

a di Catania, Catania, Italy

Information Security Group, Royal Holloway, University of London, Egham, U.K.

Keywords:

IoT, Tp-Link, Smart Homes, Smart Devices, Smart Bulb, Smart Plug, Smart Camera, Penetration Test,

Vulnerability Assessment.

Abstract:

Despite their apparent simplicity, devices like smart light bulbs and electrical plugs are often perceived as

exempt from rigorous security measures. However, this paper challenges this misconception, uncovering

how vulnerabilities in these seemingly innocuous devices can expose users to signiﬁcant risks. This paper

extends the ﬁndings outlined in previous work, introducing a novel attack scenario. This new attack allows

malicious actors to obtain sensitive credentials, including the victim’s Tapo account email and password, as

well as the SSID and password of her local network. Furthermore, we demonstrate how these ﬁndings can

be replicated, either partially or fully, across other smart devices within the same IoT ecosystem, speciﬁcally

those manufactured by Tp-Link. Our investigation focused on the Tp-Link Tapo range, encompassing smart

bulbs (Tapo L530E, Tapo L510E V2, and Tapo L630), a smart plug (Tapo P100), and a smart camera (Tapo

C200). Utilizing similar communication protocols, or slight variants thereof, we found that the Tapo L530E,

Tapo L510E V2, and Tapo L630 are susceptible to complete exploitation of all attack scenarios, including

the newly identiﬁed one. Conversely, the Tapo P100 and Tapo C200 exhibit vulnerabilities to only a subset

of attack scenarios. In conclusion, by highlighting these vulnerabilities and their potential impact, we aim to

raise awareness and encourage proactive steps towards mitigating security risks in smart device deployment.

1 INTRODUCTION

The digital revolution in Internet of Things (IoT) de-

vices has led to “smart” devices becoming more and

more an integral part of our daily lives. From smart

home appliances to industrial sensors, IoT has un-

locked a world of convenience, efﬁciency, and in-

novation. The number of IoT devices worldwide is

forecast to almost double from 15.1 billion in 2020

to more than 29 billion IoT devices in 2030 (Vail-

shery, 2023). The interconnectedness always brings

forth signiﬁcant security challenges that cannot be ig-

nored. Due to their often neglected security, IoT de-

vices are typically preferred devices by attackers. On

average, 54% of organizations experience attempted

cyberattacks targeting IoT devices every week. This

indicates a 41% increase in the average number of

weekly attacks per organization targeting IoT devices

compared to 2022 (Check Point Research, 2023).

More and more inexpensive IoT devices are de-

https://orcid.org/0009-0004-4463-7991

https://orcid.org/0000-0001-9904-9821

https://orcid.org/0000-0002-7615-8643

signed without a security-ﬁrst mindset (Amit Ser-

per, Reuven Yakar, 2023) (Andrew Laughlin, 2020),

and their long lifecycles can expose them to evolving

threats for years. The consequences of inadequate IoT

security can be far-reaching. A compromised IoT de-

vice not only poses a risk to the privacy and safety of

users but can also serve as a gateway to launch larger-

scale attacks on critical infrastructures.

We observe that usually different devices pro-

duced by the same manufacturer, belonging to the

same product line, e.g. Tapo, share parts of the

ﬁrmware and application protocols used for commu-

nication. Following these observations, this paper

rests on the following research questions: (i) Do IoT

devices from the same vendor share similar vulnera-

bilities? (ii) What consequences does this have on the

end user’s security, privacy and safety?

1.1 Contributions

To answer the research questions we chose Tp-Link’s

IoT ecosystem as the target. Our experiments are fo-

cused on the following Tp-Link Tapo IoT devices.

Bonaventura, D., Esposito, S. and Bella, G.

The IoT Breaches Your Household Again.

DOI: 10.5220/0012767700003767

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 21st International Conference on Security and Cryptography (SECRYPT 2024), pages 475-482

ISBN: 978-989-758-709-2; ISSN: 2184-7711

475

1. Tp-Link Tapo Smart Wi-Fi Light device, Multi-

color (L530E) (TP-Link, 2023c), targeted by pre-

vious work, leading to the discovery of several

vulnerabilities (Bonaventura. et al., 2023).

2. Tp-Link Tapo Smart Wi-Fi Light Bulb, Dimmable

(L510E V2) (TP-Link, 2023b).

3. Tp-Link Tapo Smart Wi-Fi Spotlight, Multicolor

(L630) (TP-Link, 2023d).

4. Tp-Link Tapo Mini Smart Wi-Fi Socket

(P100) (TP-Link, 2023e).

5. Tp-Link Tapo Pan/Tilt Home Security Wi-Fi

Camera (C200) (TP-Link, 2023a).

We found that the tested Tapo devices, part of Tp-

Link’s IoT ecosystem, use the protocols outlined in

previous work (Bonaventura. et al., 2023), or its vari-

ants. Consequently, we had the intuition that all attack

scenarios described in previous work, or at least some

of them, could most likely be exploited across all de-

vices in the Tp-Link IoT ecosystem.

Hence, our ﬁndings regarding the tested Tp-Link

devices can be summarised as follows:

• The L510E V2 and the L630 use the same proto-

cols as the L530E, thereby making all attack sce-

narios exploitable.

• Communications between the Tapo app and the

C200 are secured via TLS encryption, limiting ex-

ploitation of the vulnerabilities.

• The conﬁguration process of the P100 occurs

over Bluetooth rather than Wi-Fi, restricting ex-

ploitability to attack scenarios that don’t target as-

sociation and conﬁguration processes.

Additionally, we introduce a new attack scenario

leveraging the ﬁrst two vulnerabilities outlined in pre-

vious work (Bonaventura. et al., 2023). In this sce-

nario, the attacker authenticates as the Tapo device

to the Tapo app. As a result, the attacker can obtain

the victim’s Wi-Fi SSID and password, as well as her

Tapo email and password.

1.2 Ethics and Responsible Disclosure

All experiments only involve resources owned by the

authors of this work, including devices, Wi-Fi net-

works, accounts, emails, and passwords. No user or

third-party data was accessed during the experiments.

Tp-Link acknowledged the issues we responsi-

bly reported through their Product Security Advisory

(PSA) (TP-Link, 2023). We actively collaborated

with them, by testing the ﬁxes and conﬁrming the at-

tack scenarios are no longer exploitable or do not give

the attacker any advantage. Tp-Link conﬁrmed that

they already released the necessary ﬁxes to address

the vulnerabilities and that the changes do not affect

the normal use and stability of the products.

1.3 Paper Summary

This document proceeds with a brief overview of rel-

evant literature in the subsequent section (§2), fol-

lowed by a concise summary of prior research (§2.1).

Subsequently, the new attack scenario is explained in

detail (§3). Then, for all devices covered by our study,

a detailed description of the applicability or non-

applicability of each attack scenario is provided(§4).

Ultimately, pertinent conclusions are derived (§5).

2 RELATED WORK

This section delves into the related work within the

ﬁeld of IoT security.

Nebbione et al. (Nebbione and Calzarossa, 2020)

delved into popular IoT protocols for data sharing

and service discovery. They underscored the secu-

rity risks posed by protocol limitations, device con-

straints, and vulnerabilities. Their conclusion empha-

sizes the need for enhancing service discovery pro-

tocols, implementing end-to-end security, and raising

user awareness about IoT security risks.

In the work by Yaacoub et al. (Yaacoub et al.,

2023), the authors underscore the importance of im-

plementing proactive security measures in IoT sys-

tems, and highlight the limitations of traditional se-

curity methods. Their solution involves periodic eth-

ical hacking simulations and penetration tests across

various IoT components. In conclusion, the paper ad-

vocates for continuous training for all employees to

make IoT systems more secure.

Unlike similar studies often focused on individ-

ual devices, Heiding et al. (Heiding et al., 2023) con-

ducted systematic penetration tests on 22 smart de-

vices across different categories commonly found in

connected homes. As a result, a total of 17 vulnera-

bilities were uncovered and published as new CVEs.

These vulnerabilities could grant attackers physical

access to homes, posing signiﬁcant risks to residents.

In the work by Akhilesh et al. (Akhilesh et al.,

2022), the authors focus on enhancing the security

of smart home-based IoT devices through automated

penetration testing. Manual testing of IoT devices

is labour-intensive and requires in-depth knowledge.

To streamline this process, authors developed an au-

tomated penetration testing framework. Five smart

home IoT devices were selected for testing, and com-

mon vulnerabilities were identiﬁed. The Tp-Link de-

SECRYPT 2024 - 21st International Conference on Security and Cryptography

476

vices were found to be the most vulnerable, while the

Google Home Mini was the most secure. The study

concludes that the framework can be used by non-

experts, contributing to improved IoT security and

safer smart homes.

Researchers are also exploring various approaches

to enhance the security levels of the IoT. For example,

Hassija et al. (Hassija et al., 2019) show how four dif-

ferent technologies, i.e., blockchain, fog computing,

edge computing, and machine learning, can be used

to increase the level of security in IoT, solving some

of the main security issues present in the four layers

in which an IoT application can be divided, which are

sensing layer, network layer, middleware layer, and

application layer. Finally, Salah and Khan (Salah and

Khan, 2017) present and survey major security issues

for the IoT environment and show how blockchain

can solve many of them.

2.1 Previous Attacks on Tapo Bulbs

Previous work on Tapo L530E smart bulbs (Bonaven-

tura. et al., 2023) delineates the communication pro-

cess between Tapo devices and the Tapo app, com-

prising three primary macro-steps: (1) Device Dis-

covery - allows the Tapo app to locate the Tapo device

within the local network, and to get the Tapo device’s

conﬁguration; (2) Tapo Symmetric Key Exchange Pro-

tocol (TSKEP) - allows the Tapo app and the Tapo de-

vice to exchange a symmetric session key; (3) Tapo

device usage - allows the user to use the Tapo device

via the Tapo app, by sending get and set messages.

Within these macro-steps, authors identify and ex-

plain four vulnerabilities:

• Vulnerability 1. Lack of authentication of the

Tapo device with the Tapo app allows an adjacent

attacker to impersonate the Tapo device with the

Tapo app during the TSKEP step.

• Vulnerability 2. Hard-coded, short shared secret

allows an adjacent attacker to obtain the secret for

authentication during the Device Discovery phase.

• Vulnerability 3. Lack of randomness during sym-

metric encryption allows an adjacent attacker to

make the AES128-CBC scheme deterministic.

• Vulnerability 4. Insufﬁcient message freshness al-

lows an adjacent attacker to replay messages both

to the Tapo device and the Tapo app.

These vulnerabilites were exploited by the authors in

ﬁve attack scenarios, which we hereby summarise:

• Attack Scenario 1, Fake Bulb Discovery Messages

Generation, that allows to discover Tapo devices

within the network and serve false conﬁgurations

to the Tapo app.

• Attack Scenario 2, Password Exﬁltration from

Tapo User Account, that allows to get the pass-

word in cleartext of the user’s Tapo account, and

its associated email account in hash form.

• Attack Scenario 3, MITM Attack with a Conﬁg-

ured Tapo L530E, that allows to perform a Man-

in-the-Middle attack and violate the conﬁdential-

ity and integrity of all messages exchanged be-

tween the Tapo app and the Tapo device. This

results in the exﬁltration of the Tapo account pass-

word in cleartext, and the associated email ac-

count in hash form.

• Attack Scenario 4, Replay Attack with the Smart

Bulb as Victim, that allows to replay previously in-

tercepted messages. If the adversary can observe

the smart bulb’s behaviour when the message ar-

rives, they can infer the message’s meaning and

reuse it at will.

• Attack Scenario 5, MITM Attack with an Un-

conﬁgured Tapo L530E, that allows to perform a

Man-in-the-Middle attack and intercept trafﬁc be-

tween the Tapo app and the Tapo device during

conﬁguration. As Tapo username and password,

together with the Wi-Fi SSID and Wi-Fi password

are sent in Base64 encoding during conﬁguration,

the adversary is able to exﬁltrate all information.

Finally, the authors conduct experiments across

three different network setups, denoted as Setup A,

Setup B, and Setup C. In Setup A, both the victim

(i.e., a phone running the Tapo app) and the adversary

are connected to the same network, while the Tapo

device is on a separate, remote network; in Setup B,

the adversary, the victim and the Tapo device are all

connected to the same local network, and the Tapo de-

vice is already conﬁgured; in Setup C, the adversary

keeps deauthenticating (Bellardo and Savage, 2003)

the Tapo device, resetting it to the unconﬁgured state,

until the user connects it to the adversary’s Wi-Fi hon-

eypot, thinking it’s their home network.

3 BREACHING THE

HOUSEHOLD AGAIN

In this section, we present a novel attack scenario,

which we call “Attack Scenario 6 - Passwords exﬁl-

tration with an unconﬁgured Tapo device”, following

the enumeration within previous work on Tapo de-

vices (Bonaventura. et al., 2023). In this new attack

scenario, the adversary is able to exﬁltrate passwords

using an unconﬁgured Tapo device.

The devices used during the attack are:

The IoT Breaches Your Household Again

477

• A Wi-Fi switch to provide local connectivity.

• A smart bulb Tapo series L530 with Hardware

Version 1.0.0 and Firmware Version 1.1.9.

• A Samsung smartphone running Android 11 and

the Tapo app Version 2.8.14.

• An Ubuntu 22.04 machine with 5.15.0-47 kernel.

3.1 Setup D

The network conﬁguration we use during the attack,

which we call Setup D, for consistency with previous

work (Bonaventura. et al., 2023), is as follows.

• The victim wants to associate an unconﬁgured

Tapo device with her Tapo account.

• The Tapo app (hence, the victim) believes to be

connected to the network X created by the Tapo

device, but is actually connected to a network Y

controlled by the attacker’s Ubuntu device.

This setup requires that the Tapo device has been

reset or has not been conﬁgured yet. The attacker

must only be connected to the network they control,

and not to the access point started by the Tapo de-

vice. The victim’s Tapo app must be connected to the

network controlled by the attacker. In this setup, the

victim opens the Tapo application and starts the de-

vice association process. The network conﬁguration

for this setup is shown in Figure 1.

Figure 1: Setup D, network with a non-conﬁgured device.

As shown in previous work (Bonaventura. et al.,

2023), the attacker can use the Wi-Fi deauthentication

attack (Bellardo and Savage, 2003) to easily get the

Setup D as well. Initially, the adversary can use the

deauthentication attack to disconnect the Tapo device

from the network to which it is connected, forcing the

victim to reset it. Subsequently, after the Tapo de-

vice enters setup mode, the attacker can perform the

same attack to deauthenticate the Tapo app from the

network started by the Tapo device, trying to get the

victim to connect to the network they control.

3.2 Attack Scenario 6

In this experiment, we exploited two of the four vul-

nerabilities, in order:

• Vulnerability 2, with the goal of creating fake de-

vice discovery response,

• Vulnerability 1, with the goal of authenticating as

the Tapo device to the Tapo app.

The context in which we conduct the experiment is

the Setup D(§3.1) previously described. The attack

diagram is shown in Figure 2.

Figure 2: Sequence chart for the attack scenario 6.

The exploitation begins when the victim starts the

association process within the Tapo app. In the be-

ginning, the app starts broadcasting device discovery

request. Hence, the attacker exploits his ability to cre-

ate fake device discovery response to respond to var-

ious device discovery request from the victim. The

attacker sets the response’s messages ﬁelds as shown

in Listing 1:

• He sets the device id and owner ﬁelds with ran-

dom hex values.

• He sets the device type and device model ﬁelds

with the name and type of the device he wants to

impersonate.

• He sets the ip and port ﬁelds to point to an

adversary-controlled server.

• He sets the factory default ﬁeld to true. This is

important because it allows the application to un-

derstand that the response is coming from a device

not yet associated with any accounts.

SECRYPT 2024 - 21st International Conference on Security and Cryptography

478

Note that, differently from the Attack Scenario 2 de-

scribed in previous work (Bonaventura. et al., 2023),

the attacker does not need the victim’s owner id.

{

” r e s u l t ” : {

” d e v i c e i d ” : ”RANDOM.HEX . VALUE” ,

” owner ” : ”RANDOM.HEX.VALUE” ,

” d e v i c e t y p e ” : ”DEVICE . TYPE” ,

” d e v i c e m o d e l ” : ”DEVICE .MODEL” ,

” I P ” : ”ATTACKER . IP ” ,

”mac ” : ”ATTACKER . PORT” ,

” f a c t o r y d e f a u l t ” : t r u e ,

” i s s u p p o r t i o t c l o u d ” : f a l s e ,

” m g t e n c r y p t s ch m ” : {

” i s s u p p o r t h t t p s ” : f a l s e ,

” e n c r y p t t y p e ” : ”AES ” ,

” h t t p p o r t ” : 80

}

} ,

” e r r o r c o d e ” : 0

}

Listing 1: JSON attack scenario 6.

After receiving the response, the Tapo app as-

sumes that it comes from a device that needs to be as-

sociated. Therefore, it starts the TSKEP protocol with

the attacking device. Because of vulnerability 1, the

TSKEP protocol does not give the Tapo app any ev-

idence about the identity of the interlocutor. For this

reason, the Tapo app assumes that the newly received

key is shared with the device to be associated, while it

is shared with the attacker instead. The attacker must

then perform the association process with the Tapo

app until the set qs info request. At that point, they

can get the password of the victim’s Tapo account and

the associated email address, as well as the SSID and

the password of the victim’s local network.

The attack can be summarised as follows:

• The attacker gets the Device Discovery shared

key and creates fake device discovery response.

Therefore, the authentication of the device discov-

ery response fails.

• The Tapo app executes the TSKEP protocol with

the attacker instead of the Tapo device. Therefore,

authentication of the Tapo device with the Tapo

app fails. This results in an integrity loss.

• The Tapo app shares the key with the attacker,

hence the distribution of the session key fails.

This results in an conﬁdentiality loss.

• The attacker can violate the conﬁdentiality of the

messages and get the password and the hash of

the email of the victim’s Tapo account as well as

the SSID and the password of the victim’s local

network. This results in a conﬁdentiality loss.

4 IMPACT ON TARGET DEVICES

Table 1 provides an overview of the different ver-

sions tested for Tapo devices and the Tapo app. We

tested versions of device ﬁrmwares that were suppos-

edly vulnerable to the discovered vulnerabilities, then

we tested the ﬁxed ﬁrmwares to check if the vulnera-

bilities were not exploitable anymore.

Table 1: Tested versions.

Vulnerable Version Fixed Version

L530E 1.1.9 1.2.4

L510E 1.0.8 1.1.0

P100 1.4.9 and 1.4.16 1.5.0

C200 1.1.18 -

L630 1.0.3 1.0.4

Tapo App 2.8.14 and 2.16.112 2.17.206

4.1 Firmware Without Fixes

Our primary focus is to assess the impact of the identi-

ﬁed vulnerabilities on each target device. A summary

of the vulnerabilities exposed by each target device

running a ﬁrmware without ﬁxes is shown in Table 2.

Throughout the section, we also analyze the applica-

bility of the attack scenarios, and we summarise the

reproducible ones on each target device in Table 3.

Table 2: Vulnerabilities exposed by target devices for

ﬁrmware without ﬁxes.

Vuln. 1 Vuln. 2 Vuln. 3 Vuln. 4

L530E    

L510E    

L630    

P100    

C200    

 if the vulnerability is present,  otherwise.

Table 3: Feasibility of the Attack Scenarios (AS) on the

target devices for ﬁrmware without ﬁxes.

AS1 AS2 AS3 AS4 AS5 AS6

L530E      

L510E      

L630      

P100     ○ ○

C200      

 if the attack scenario is feasible on the target device,

 if the attack scenario is not feasible because the

communication is encapsulated within a TLS channel,

○ if the attack scenario is not feasible because the

conﬁguration is done on the Bluetooth channel.

The IoT Breaches Your Household Again

479

4.1.1 Tp-Link Tapo Smart Wi-Fi Light Device,

Multicolor (L530E)

We test an L530E with Hardware v1.0.0 and

Firmware v1.1.9, using a Tapo app v2.8.14. The smart

bulb exposes all the vulnerabilities, and all attack sce-

narios are reproducible (Bonaventura. et al., 2023),

including our novel Attack Scenario 6 (§3).

4.1.2 Tp-Link Tapo Smart Wi-Fi Light Bulb,

Dimmable (L510E V2)

We test an L510E V2 with Hardware v2.0 and

Firmware v1.0.8, using a Tapo app v2.16.112. The

Tapo L510E, for the Device-App communications,

uses the same vulnerable protocols (§2.1) with the

same security parameters used by the L530E, i.e.,

HTTPS protocol is not supported, CBC-AES128 bit

encryption is used, and Wi-Fi is the communication

channel during conﬁguration. Therefore, this smart

bulb exposes all the listed vulnerabilities, and all at-

tack scenarios can be reproduced, including Attack

Scenario 6 introduced in this paper.

We hereby describe how we apply each attack sce-

nario to the new device, highlighting any differences

from previous work (Bonaventura. et al., 2023) as

necessary. For newly tested devices, we will refer to

the L510E’s behaviour as a baseline. In later sections,

we will only detail Attack Scenarios (AS) that deviate

from this baseline.

AS1. works with the Tapo L510E ﬁrmware tested.

The key that this device uses for the Message

Authentication Code is static and hardcoded, the

same used by the Tapo L530E. Therefore, an at-

tacker can create false device discovery messages

for both the bulb and the app.

AS2. works with the Tapo L510E ﬁrmware tested.

The Tapo L510E communicates using the TSKEP

protocol with the Tapo app. By creating fake de-

vice discovery response, the attacker can imper-

sonate the Tapo L510E, prompting the app to start

TSKEP with them. This allows the attacker to get

the Tapo password and the hash of the victim’s

Tapo email.

AS3. works with the Tapo L510E ﬁrmware tested.

TSKEP lacks identity veriﬁcation, enabling the

attacker to perform a MITM attack on the Tapo

L510E-Tapo app communication, compromising

conﬁdentiality.

AS4. works with the Tapo L510E ﬁrmware tested.

The Tapo L510E accepts all messages without

checking their timestamp. This allows attackers

to replay sniffed messages with non-expired ses-

sion keys, enabling arbitrary command execution.

AS5. works with the Tapo L510E ﬁrmware tested.

During pairing, communications between the

Tapo L510E and the Tapo app happen over Wi-Fi.

Hence, the attacker can perform a MITM attack

and hijack the association process.

AS6. works with the Tapo L510E ﬁrmware tested.

During pairing, Tapo L510E and Tapo app com-

municate via Wi-Fi. TSKEP’s identity veriﬁca-

tion vulnerability allows MITM attacks, compro-

mising the email and password of the victim’s

Tapo account, as well as the SSID and password

of her local network.

4.1.3 Tp-Link Tapo Smart Wi-Fi Spotlight,

Multicolor (L630)

We test an L630 with Hardware v1.0 and Firmware

v1.0.3, using a Tapo app v2.16.112. We conﬁrmed

this device aligns with our baseline —– mirroring the

behavior of the Tapo L510E V2. Thus, it shares all

listed vulnerabilities and allows reproduction of all

attack scenarios, including the new Attack Scenario

6 introduced in this paper.

4.1.4 Tp-Link Tapo Mini Smart Wi-Fi Socket

(P100)

We test a P100 with Hardware v1.20.0 and Firmwares

v1.4.9 and v1.4.16, using Tapo app v2.16.112. This

device employs vulnerable protocols (§2.1), lacks

HTTPS support, and uses CBC-AES128 encryption,

exposing all vulnerabilities. Unlike previous devices,

P100 uses Bluetooth for conﬁguration, limiting attack

scenarios to those involving already associated de-

vices. Hence, Attack Scenarios 1 to 4 are aligned with

our baseline, while Attack Scenarios 5 and 6 cannot

be reproduced on Tapo P100 because the adversary is

not able to perform the MITM attack during the bulb

conﬁguration process.

4.1.5 Tp-Link Tapo Pan/Tilt Home Security

Wi-Fi Camera (C200)

We test a C200 with Hardware v1.0.0 and Firmware

v1.1.18, using a Tapo app v2.16.112.

Unlike the other analysed devices, the Tapo C200

supports HTTPS, utilizing TLS for TSKEP between

the Tapo app and device even during conﬁguration.

This limits exposure to only Vulnerability 2. The use

of TLS prevents message inference or trafﬁc sniff-

ing by requiring a valid certiﬁcate from the attacker.

While TSKEP remains vulnerable to replay attacks,

TLS encapsulation ensures security. Consequently,

only Attack scenario 1 can be reproduced out of six

attack scenarios.

SECRYPT 2024 - 21st International Conference on Security and Cryptography

480

One potential attack involves downgrading the

communication channel from HTTPS to HTTP. The

attacker may attempt this by replying to the device

discovery requests from the application with the same

security parameters supported by the Tapo L530E,

i.e., HTTPS not supported, as shown in Listing 2.

However, we veriﬁed that this downgrade attack pro-

duces no results. This is because the Tapo applica-

tion does not consider valid all device discovery re-

sponse received from C200 devices that do not sup-

port HTTPS.

{

” e r r o r c o d e ” : 0 ,

” r e s u l t ” : {

” d e v i c e i d ” : ” 1 2 3 4 . . . 4 4 1 ” ,

” d e v i ce n a me ” : ” Tapo Camera E3FF ” ,

” d e v i c e t y p e ” : ”SMART . IPCAMERA” ,

” d e v i c e m o d e l ” : ” C200 ” ,

” i p ” : ” 1 9 2 . 1 6 8 . 1 . 5 5 ” ,

”mac ” : ”AA−BB−CC−DD−EE−FF ” ,

” h a r d w a r e v e r s i o n ” : ” 1 . 0 ” ,

” f i r m w a r e v e r s i o n ” : ” 1 . 1 . 1 8 B u i l d

220518 Re l .6 14 72 n ( 4 5 5 5 ) ” ,

” f a c t o r y d e f a u l t ” : f a l s e ,

” i s s u p p o r t i o t c l o u d ” : f a l s e ,

” m g t e n c r y p t s ch m ” : {

” i s s u p p o r t h t t p s ” : f a l s e ,

” e n c r y p t t y p e ” : ”AES ” ,

” h t t p p o r t ” : ” E v i l . t c p p o r t ”

}

Listing 2: Attack sub-scenario 2 UDP discovery response.

4.2 Firmware with Fixes

For each device tested, we diligently communi-

cated the discovered vulnerabilities to Tp-Link. The

responsible disclosure process enabled Tp-Link to

promptly identify and address the vulnerabilities.

They developed new versions of the Tapo app and the

Tapo devices’ ﬁrmware, implementing security up-

dates to resolve the issues. We then actively tested the

beta versions of this ﬁrmware, conﬁrming the mitiga-

tion of potential risks arising from the vulnerabilities,

and providing feedback to the manufacturer.

Although only three out of the four vulnerabilities,

i.e., Vuln. 1, Vuln. 3, and Vuln. 4, were addressed with

ﬁxes, their absence indirectly mitigates the risk asso-

ciated with the remaining vulnerability, i.e., Vuln. 2,

making it acceptable. Therefore, even if the last vul-

nerability is still exposed, it would not pose a signif-

icant security risk to the end user. A summary of the

vulnerabilities exposed by each target device running

a ﬁrmware with ﬁxes is shown in Table 4.

Regarding the attack scenarios, we tested all six of

Table 4: Vulnerabilities exposed by target devices for

ﬁrmware with ﬁxes.

Vuln. 1 Vuln. 2 Vuln. 3 Vuln. 4

L530E    

L510E    

L630    

P100    

C200 -  - -

 if the vulnerability is still present,  otherwise,

- if it was not present in the unpatched ﬁrmware.

them using the beta version of the Tapo app, speciﬁ-

cally Version 2.17.206, and the device’s ﬁrmware pro-

vided by the Tp-Link. Only one of the six attack sce-

narios can still be reproduced, i.e., Attack scenario

1, Fake Bulb Discovery Messages Generation. How-

ever, the inability for the adversary to reproduce the

other scenarios renders Attack scenario 1 virtually

negligible in terms of risk to the victim, thus offering

no advantage to the potential attacker. This observa-

tion conﬁrms that all attack scenarios are effectively

nulliﬁed, as none yields any results. A summary of

the reproducible attack scenarios on each device run-

ning a ﬁrmware with ﬁxes is shown in Table 5.

Table 5: Impact of the Attack Scenarios (AS) on the target

devices for ﬁrmware with ﬁxes.

AS1 AS2 AS3 AS4 AS5 AS6

L530E      

L510E      

L630      

P100     - -

C200  - - - - -

 if the AS is feasible without beneﬁts for the attacker,

 if the AS is not feasible anymore,

- if the AS was not feasible in the unpatched ﬁrmware.

5 CONCLUSIONS

In this paper, we attempted to exploit different Tapo

devices using vulnerabilities that affected the Tapo

L530E smart bulb, which were found in previous

work. Results show that said vulnerabilities are

present and exploitable in other devices belonging to

the Tp-Link ecosystem and not exclusive to a spe-

ciﬁc Tapo device. More generally, to answer our

ﬁrst research question, this hints at the fact that the

stack of technologies underlying IoT devices is shared

between devices of the same family, and that advi-

sories published for a single device may actually be

helpful to both attackers and defenders in identifying

the same vulnerabilities on other devices of the same

ecosystem. This is most likely not unique to the Tapo

The IoT Breaches Your Household Again

481

environment, but veriﬁcation of this claim is left to

future work.

Additionally, we expanded previous work by in-

troducing a new Attack Scenario, which we called

“Attack Scenario 6”, and a novel network conﬁgu-

ration to exploit the vulnerabilities, which we called

“Setup D”. We then tested all attack scenarios on dif-

ferent Tapo devices, ﬁnding that they are mostly re-

producible, with a few exceptions. Hence, we an-

swer our second research question by verifying that

exploitable vulnerabilities retain their potential of ob-

taining the Tapo account password of the victim user,

even when exploited on other Tapo devices. This

could allow the attacker to access the victim’s account

and control all associated devices. Additionally, the

possibility to obtain the password of the victim’s pri-

vate network should not be underestimated as well, as

network access can be the entry point for the attacker

to execute different attacks on other devices within

the network.

REFERENCES

Akhilesh, R., Bills, O., Chilamkurti, N., and Chowdhury,

M. (2022). Automated penetration testing framework

for smart-home-based iot devices. Future Internet,

14:276.

Amit Serper, Reuven Yakar (2023). ‘friendlyname’

buffer overﬂow vulnerability in wemo smart plug

v2. https://sternumiot.com/iot-blog/mini-smart-plug-

v2-vulnerability-buffer-overﬂow.

Andrew Laughlin (2020). Cheap smart plugs could

expose you to hackers, or even cause a ﬁre.

https://www.which.co.uk/news/article/cheap-smart-

plugs-could-expose-you-to-hackers-or-even-cause-

a-ﬁre-aMuck9K2OSYx.

Bellardo, J. and Savage, S. (2003). 802.11 {Denial-

of-Service} attacks: Real vulnerabilities and practi-

cal solutions. In 12th USENIX Security Symposium

(USENIX Security 03).

Bonaventura., D., Esposito., S., and Bella., G. (2023).

Smart bulbs can be hacked to hack into your house-

hold. In Proceedings of the 20th International Confer-

ence on Security and Cryptography - SECRYPT, pages

218–229. INSTICC, SciTePress.

Check Point Research (2023). The tipping point: Ex-

ploring the surge in iot cyberattacks globally.

https://blog.checkpoint.com/security/the-tipping-

point-exploring-the-surge-in-iot-cyberattacks-

plaguing-the-education-sector/.

Hassija, V., Chamola, V., Saxena, V., Jain, D., Goyal, P., and

Sikdar, B. (2019). A survey on iot security: Applica-

tion areas, security threats, and solution architectures.

IEEE Access, 7:82721–82743.

Heiding, F., S

uren, E., Oleg

ard, J., and Lagerstr

om, R.

(2023). Penetration testing of connected households.

Computers & Security, 126:103067.

Nebbione, G. and Calzarossa, M. C. (2020). Security of iot

application layer protocols: Challenges and ﬁndings.

Future Internet, 12(3).

Salah, K. and Khan, M. (2017). Iot security: Review,

blockchain solutions, and open challenges. Future

Generation Computer Systems, 82.

TP-Link (2023). Tp-link product security advisory. https:

//www.tp-link.com/us/press/security-advisory/.

TP-Link (2023a). Tp-link tapo c200 - cloud cam-

era. https://www.tp-link.com/en/home-networking/

cloud-camera/tapo-c200/.

TP-Link (2023b). Tp-link tapo l510e v2 - smart

bulb. https://www.tp-link.com/en/home-networking/

smart-bulb/tapo-l510e/v2/.

TP-Link (2023c). Tp-link tapo l530e - smart bulb.

https://www.tp-link.com/en/home-networking/smart-

bulb/tapo-l530e/.

TP-Link (2023d). Tp-link tapo l630 - smart plug.

https://www.tapo.com/en/product/smart-light-bulb/

tapo-l630/.

TP-Link (2023e). Tp-link tapo p100 - smart plug.

https://www.tp-link.com/en/home-networking/smart-

plug/tapo-p100/.

Vailshery, L. S. (2023). Number of internet of

things (iot) connected devices worldwide from

2019 to 2023, with forecasts from 2022 to

2030. https://www.statista.com/statistics/1183457/

iot-connected-devices-worldwide/.

Yaacoub, J.-P. A., Noura, H. N., Salman, O., and Chehab,

A. (2023). Ethical hacking for iot: Security issues,

challenges, solutions and recommendations. Internet

of Things and Cyber-Physical Systems, 3:280–308.

SECRYPT 2024 - 21st International Conference on Security and Cryptography

482
