Cross-Lingual Low-Resources Speech Emotion Recognition with Domain

Adaptive Transfer Learning

Imen Baklouti

, Olfa Ben Ahmed

and Christine Fernandez-Maloigne

XLIM Research Institute, UMR CNRS 7252, University of Poitiers, France

Keywords:

Domain Adaptation, Transfer Learning, Cross-Lingual Speech Emotion Recognition.

Abstract:

Speech Emotion Recognition (SER) plays an important role in several human-computer interaction-based

applications. During the last decade, SER systems in a single language have achieved great progress through

Deep Learning (DL) approaches. However, SER is still a challenge in real-world applications, especially

with low-resource languages. Indeed, SER suffers from the limited availability of labeled training data in the

speech corpora to train an efﬁcient prediction model from scratch. Yet, due to the domain shift between source

and target data distributions traditional transfer learning methods often fail to transfer emotional knowledge

from one language (source) to (target) to another. In this paper, we propose a simple yet effective approach

for Cross-Lingual speech emotion recognition using supervised domain adaptation. The proposed method

is based on 2D Mel-Spectrogram images as features for model training from source data. Then, a transfer

learning method with domain adaptation is proposed in order to reduce the domain shift between source and

target data in the latent space during model ﬁne-tuning. We conduct experiments through different tasks on

three different SER datasets. The proposed method has been evaluated on different transfer learning tasks

namely for low-resource scenarios using the IEMOCAP, RAVDESS and EmoDB datasets. Obtained results

demonstrate that the proposed method achieved competitive classiﬁcation performance in comparison with the

classical transfer learning method and with recent state-of-the-art SER-based domain adaptation works.

1 INTRODUCTION

The ability to understand and interpret human emo-

tions is a fundamental aspect of effective communica-

tion and social interaction. In recent years, the ﬁeld of

affective computing has gained signiﬁcant attention

as researchers and technologists seek to develop intel-

ligent systems capable of perceiving, analyzing, and

responding to human emotions. Among the various

modalities explored in affective computing, speech

has garnered signiﬁcant attention due to its rich emo-

tional content, and accessibility. Our voice carries a

wealth of information, including vocal pitch, inten-

sity, rhythm, and spectral properties, all of which are

inﬂuenced by our emotional states.

Speech Emotion Recognition (SER) presents an im-

portant ﬁeld in affective computing that involves the

automatic detection and analysis of emotions con-

veyed through speech signals. SER systems are used

in several daily applications such as marketing, gam-

https://orcid.org/0000-0001-5413-8660

https://orcid.org/0000-0002-6942-2493

https://orcid.org/0000-0003-4818-9327

ing, psychology, healthcare, and cognitive sciences.

(El Ayadi et al., 2011; Lugovi

c et al., 2016). However,

several challenges exist in the ﬁeld of SER because of

the subjective and context-dependent nature of emo-

tion in addition to the individual differences and lin-

guistic variations (Lech et al., 2020). While signif-

icant progress has been made in SER, the majority

of existing systems focus on single-language settings,

limiting their applicability in multilingual and multi-

cultural contexts (Agarla et al., 2022; Cai et al., 2021;

Sharma, 2022; Zhang et al., 2021b). Indeed, emotions

are very important and can have an impact on what we

say and what we do and drive us to take decisions and

make choices. However, through different languages

and cultures, emotions are expressed differently that’s

why it’s important to take into account these differ-

ences (Barth, 2020). Hence, developing an efﬁcient

and generalizable SER system remains challenging.

Indeed, different languages exhibit unique phonetic

and acoustic characteristics posing a challenge to de-

veloping language-independent deep learning models

for SER. Additionally, the availability of labeled emo-

tion datasets for training across multiple languages

118

Baklouti, I., Ben Ahmed, O. and Fernandez-Maloigne, C.

Cross-Lingual Low-Resources Speech Emotion Recognition with Domain Adaptive Transfer Learning.

DOI: 10.5220/0012788100003756

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 13th International Conference on Data Science, Technology and Applications (DATA 2024), pages 118-128

ISBN: 978-989-758-707-8; ISSN: 2184-285X

presents a signiﬁcant obstacle. Yet, insufﬁcient data

for less-resourced languages hinders the development

of accurate multilingual SER systems.

In this paper, we propose a new domain adaptation-

based transfer learning method for multi-lingual

SER. The proposed method is based on 2D Mel-

Spectrogram data extracted from voice signals. A

source model is learned in the ﬁrst step and adapted

in the second step to reduce the domain shift between

the source and the target datasets. The goal is to lever-

age the knowledge learned from the source task to im-

prove the performance of the model on a related but

with a different (language) target SER task. Notably,

our proposed method goes beyond conventional ap-

proaches by incorporating the extraction of domain-

invariant features directly into the loss function in a

supervised manner. This supervised adaptation mech-

anism guides the neural network to acquire features

that are less inﬂuenced by domain-speciﬁc variations

while maintaining the critical emotional information

necessary for precise SER. The proposed method has

been evaluated on different tasks using three differ-

ent data-sets in different languages namely Interac-

tive Emotional Dyadic Motion Capture (IEMOCAP),

Berlin Database of Emotional Speech (EmoDB), and

Ryerson Audio-Visual Database of Emotional Speech

and Song (RAVDESS).

The rest of the paper is organized as follows. First,

section 2 exposes some literature review on deep

learning and domain adaptation for SER. Second, sec-

tion 3 presents the proposed SER method. Then in

section 4, experiments and results are presented. Fi-

nally, section 5 concludes the work and gives some

perspectives.

2 RELATED WORK

SER has witnessed signiﬁcant advancements in re-

cent years, fueled by the growing applications of af-

fective computing in human-computer interaction and

artiﬁcial intelligence. In this section, we will start

by reviewing the use of deep learning in SER in the

last years, and then we will present and discuss some

recent and relevant works on domain adaptation for

SER.

2.1 Deep Learning for SER

Deep Learning (DL) has been widely used for SER

(Khalil et al., 2019) by extracting high-level fea-

tures from raw speech data. Several works in SER

have used Convolutional Neural Networks (CNN) to

capture local acoustic patterns and learn discrimina-

tive features for spectrograms for emotion recognition

(Huang et al., 2014; Badshah et al., 2019). Recur-

rent Neural Networks (RNNs) have also been investi-

gated to capture both temporal and spectral informa-

tion (Zhao et al., 2018; Ma et al., 2019). However,

DL models trained on one language may not gener-

alize well to other languages due to the differences

between languages (Hu et al., 2020). Ensuring cross-

lingual generalization and transferability of models

are challenges in multilingual SER. In this context,

cross-lingual Transfer Learning (TL), where models

are pre-trained on large-scale speech datasets, is used

for SER in small data. Indeed, pre-trained models can

leverage the learned representations from general au-

dio tasks and transfer them to SER, enhancing per-

formance, especially in low-resource settings. For in-

stance the authors in (Padi et al., 2021), proposed the

TL of a pre-trained ResNet model with spectrogram

data augmentation. the authors in (Liu et al., 2021),

proposed to transform interval time parts of speech

signals into a spectrogram and a discrete waveform

fed separately to the FaceNet model for training. The

network was pre-trained on the Chinese Academy of

Sciences’ Institute of Automation (CASIA) dataset

and ﬁne-tuned on the IEMOCAP dataset. The authors

in (Gerczuk et al., 2021) presented a combination of

residual adapters and ResNet model to be transferred

from visual recognition to multi-corpus EmoSet. The

authors in (Goel and Beigi, 2020), proposed a Multi-

Task Learning framework with arousal, naturalness,

and gender tasks for TL across SER datasets for ﬁve

languages in single and cross corpus data. The au-

thors in (Latif et al., 2018) proposed the Deep Be-

lief Networks (DBN) model for TL evaluated on ﬁve

corpora in different three languages SER. The au-

thors in (Deng et al., 2013) proposed a sparse Au-

toEncoder (AE) technique evaluated on six databases

for feature TL for SER. More recently, authors in

(Scheidwasser-Clow et al., 2022), proposed a bench-

mark with nine datasets in six languages called SER

adaptation benchmark for evaluating the extracted

handcrafted features and leverages Deep Neural Net-

works (DNN).

TL has gained a lot of attention for multi-language

deep-learning-based SER systems. However, it still

suffers from some limitations. In fact, TL assumes

that the source and the target domains are similar

which is not the case in real-work speech emotion

recognition tasks. This domain shift can degrade the

performance of the model. Yet, pre-trained models

may not generalize well to new emotional expressions

or speakers not represented in the training data. More-

over, the limited availability of labeled data hampers

the ability to effectively ﬁne-tune the models, leading

Cross-Lingual Low-Resources Speech Emotion Recognition with Domain Adaptive Transfer Learning

119

to overﬁtting and poor generalization.

2.2 Domain Adaptation for SER

In order to reduce the gap between source and tar-

get domains, Domain Adaptation (DA) methods have

been recently proposed for cross-lingual SER. Most

of the existing works focus on adversarial training

for DA. For instance, The authors in (Latif et al.,

2019) proposed an unsupervised DA cross-lingual

SER using a Generative Adversarial Network (GAN)

model. The authors in (Abdelwahab and Busso, 2018)

proposed a novel Domain Adversarial Neural Net-

work that exploits target unlabeled data to predict

emotional descriptors for dominance, valence, and

arousal. Authors proposed in (Gideon et al., 2019)

an Adversarial Discriminative Domain Generaliza-

tion and Multiclass MADDoG methods for cross-

corpus SER evaluated on MSP-Improv, IEMOCAP

and PRIORI datasets. More recently, authors in (Latif

et al., 2022) proposed Adversarial Dual Discriminator

(ADDi) and self-supervised (sADDi) methods to min-

imize the distance between source and target datasets.

However, the presence of two discriminators in the

ADDi architecture leads to training instability and an

increase in both computational complexity and over-

ﬁtting risk. A DA method based on the constant-Q

Transform (CQT) for time-frequency has been pro-

posed for SER in (Singh et al., 2021). The authors

mentioned that they had no gain improvement over

EmoDB because time-frequency needs monitoring in

SER.

Another group of works maximizes the domain

confusion to learn a common feature space by min-

imizing some measures of domain shift namely the

Maximum Mean Discrepancy (MMD) distance (Yang

et al., 2020; Liu et al., 2020; Zhang et al., 2021a;

Kexin and Yunxiang, 2023; Ye et al., 2023). In-

deed, the MMD has been used for DA in the com-

puter vision ﬁeld and proved its effectiveness in fea-

ture alignments compared to L1 and L2 distances, es-

pecially in high-dimensional spaces, which is often

the case with complex data like images or spectro-

grams (Rezaeianjouybari and Shang, 2020). How-

ever, achieving DA for speech emotion presents a

heightened level of complexity. This complexity

arises from the necessity to simultaneously preserve

emotional information while mitigating domain shift.

For example, the authors in (Yang et al., 2020) pro-

posed DA based on MMD layers with dynamic trans-

fer coefﬁcients using VGG19 and AlexNet models.

The method has been evaluated on an ofﬁce envi-

ronment dataset leading to questions regarding its

applicability in the real-world SER scenarios. Au-

thors in (Liu et al., 2020) proposed DA using the

MMD technique with CNN model based on LeNet

and AlexNet models, to validate transfers between the

eNTERFACE and CASIA datasets. More recently,

the authors in (Zhang et al., 2021a) proposed an unsu-

pervised novel Joint Distribution Adaptation Regres-

sion (JDAR) method for DA-based regression. The

authors in (ZHAO et al., 2023) extracted 3D-mel-

spectrograms using CNN then a Long Short-Term

Memory (LSTM) model was trained on these fea-

tures for SER. The authors in (Kexin and Yunxiang,

2023) combined Linear Discriminant Analysis, MMD

and graph embedding to constrain the differences be-

tween target and source data while the authors in

(Ye et al., 2023) proposed a novel dual-level emo-

tion alignment module based on unsupervised DA.

The authors proposed in this paper (Fu et al., 2023)

to evaluate gender impact in SER, subdomain adapta-

tion based on LMMD and multi-task learning models.

However, integrating multiple tasks or subdomains

into a single model often increases the model’s com-

plexity. In (Agarla et al., 2024) authors in proposed

for Cross lingual SER a Semi-Supervised Learning

method based on a transformer to classify unlabeled

utterances. Some limitations are mentioned by au-

thors. First pseudo-labeling can deteriorate perfor-

mance if the model makes incorrect, unlabeled pre-

dictions. Second hard-pseudo labels can cause over-

ﬁtting and the proposed method assumes that the tar-

get and source sets have the same number of emo-

tions. The authors in proposed in this paper (Huijuan

et al., 2023) a local domain adaptation using the lo-

cal MMD method, to measure the distance between

the source and target data. The authors proposed as

future work, a multi-source DA using LMMD to be

more suitable across SER.

Within the MMD-based domain adaptation ap-

proaches, there has been a notable omission in pre-

serving emotional information while aligning the fea-

ture distributions. Moreover, most existing domain

adaptation methods are designed for unsupervised or

semi-supervised SER tasks due to the lack of anno-

tated data in the target domain (low-resource domain).

However, both unsupervised and semi-supervised DA

methods lack direct supervision from labeled target

domain data. This limits their ability to explicitly

guide the adaptation process towards the target do-

main’s speciﬁc characteristics. Without explicit su-

pervision, the models may struggle to capture ﬁne-

grained details or subtle differences in emotional ex-

pressions across languages. In addition, most of the

works cited above evaluate DA methods for cross-

corpus SER using similar language corpora and few

works show the effectiveness of their methods for

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

120

different languages in cross-corpus SER (Ahn et al.,

2021). Yet, few works have tackled the problem

of DA from source to low-resource target domain.

Hence, in this work, we propose a supervised DA-

based transfer learning approach for SER for low-

resource target domains. Combining classiﬁcation

loss, which encourages the model to correctly clas-

sify data, with MMD, which emphasizes the align-

ment of data distributions, can result in a more power-

ful discriminative model. This means the model can

both classify well and adapt effectively to different

domains.

3 PROPOSED APPROACH

Figure 1 illustrates the proposed framework of DA-

based transfer learning for SER which is composed of

two steps. The ﬁrst one consists of learning the source

model from source data, while the second one imple-

ments the domain adaptation-based transfer learning

approach for ﬁnal prediction from the target data.

3.1 Step 1: Learning the Source Model:

A Mel-Spectrogram-Based Transfer

In order to get a source model for later transfer learn-

ing to the target data, we perform low-level feature-

based transfer learning using an image-based pre-

trained network. First, 2D Mel-Spectrograms are ex-

tracted from signals using the Librosa library (McFee

et al., 2015). Indeed, a spectrogram is a visual repre-

sentation of the spectrum of frequencies of the speech

signal as it varies with time. Hence, we use spec-

trogram data to represent speech signals as images.

Each point in the spectrogram represents the energy,

or magnitude, of a speciﬁc frequency component at

a particular time. Indeed, the process of ﬁne-tuning

the CNN using the spectrogram data involves taking

advantage of the pre-trained CNN’s ability to detect

low-level image features. By initializing the CNN

with these learned features and then adapting it to

the spectrogram domain through ﬁne-tuning, the net-

work gains the capability to recognize low-level fea-

tures and spatial details such as edges, and textures in

spectrogram images that are informative for speech

analysis. This process ultimately helps in transfer-

ring the knowledge of low-level image features to the

speech domain, enhancing the network’s performance

on SER the task.

3.2 Step 2: Domain Adaption Based

Transfer Learning

In this section, we describe our proposed method for

transfer learning with domain adaptation in the case

of cross-lingual SER. Hence, we propose a hybrid

loss function for source model ﬁne-tuning. Based

on the Maximum Mean Discrepancy (MMD) method,

the DA is proposed to minimize the discrepancies

between source and target datasets for cross-lingual

SER. The ﬁnal strategy of model training is to mini-

mize both, the CNN classiﬁcation loss and the MMD

loss. Hence, the model is optimized to classify sam-

ples with the classiﬁcation loss when minimizing the

domain distribution difference during transfer learn-

ing using the MMD loss.

For a source data D

= [(x

),...,(x

)]

where input features X

= [x

,..., x

] with out-

put labels Y

= [y

,..., y

] and target data D

[(x

),..., (x

)] where input features X

,..., x

] with output labels Y

= [y

,..., y

], satisfy

the marginal distributions P(D

) and Q(D

). MMD is

often chosen for feature alignment in domain adapta-

tion due to its ability to capture differences in distri-

butions in a high-dimensional space compared to L1

and L2 distances (Attabi and Dumouchel, 2013). The

total loss function is presented in Eq 1 :

Loss

Total

= C

) + λMMD

) (1)

Where C

is a loss function Cross entropy computed

from labeled source set, MMD

presents the MMD

loss function (the distance between the target data D

and the source data D

), y

is the source labels data

and λ is the weight of MMD

to transfer source

knowledge to domain target.

The estimation of the MMD method is presented

as follow (see Eq 2), where the kernel function k

(Gretton et al., 2006) is a gaussian function also P

and Q are two marginal different distributions sam-

ple sets (P(D

) ̸= Q(D

)). Such explicit alignment in

the Reproducing Kernel Hilbert Space (RKHS) could

support the structure learning for precise conditional

alignment.

MMD

[P,Q] =

∑

i=1

∑

j=1





−

∑

i=1

∑

j=1





∑

i=1

∑

j=1





(2)

Two output batches from the source D

and target D

datasets are calculated in the ﬁrst Fully Connected

(FC) layer. Eq 2 calculates the MMD

as a loss

function for the output, to the optimize the train-

ing process. The objective here is that the distance

Cross-Lingual Low-Resources Speech Emotion Recognition with Domain Adaptive Transfer Learning

121

Figure 1: Domain adaptation based transfer learning proposed method for cross lingual SER.

between the source and target data (MMD loss) for

cross-lingual SER will be narrowed and the total loss

function will be decreased.

By jointly optimizing the cross-entropy loss and

the MMD loss, we encourage the model to learn a fea-

ture representation that minimizes the distribution dis-

crepancy between the source and the target domains

while maintaining good classiﬁcation performance on

the source domain. The weighting factor λ determines

the trade-off between the two loss terms.

4 EXPERIMENTS AND RESULTS

4.1 SER Datasets

In this work, we use three different SER datasets

for the evaluation of the proposed method. Ta-

ble 1 provides the characteristics of these corpus

namely IEMOCAP (English, Audio) (Busso et al.,

2008), EmoDB (German, Audio) (Burkhardt et al.,

2005) and RAVDESS (North American, Audio-

Visual) dataset. (Livingstone and Russo, 2018). A

total of 535, 9952 and 1248 audio ﬁles with seven

emotions have been used for EmoDB, IEMOCAP and

RAVDESS datasets, respectively.

Table 1: Characteristics of Emotional Speech Databases.

Database data Emotions

IEMOCAP (English) 9952 1:Angry, 2:Happy,

3:Excited, 4:Sad,

5:Frust, 6:Fear, 7:Neutral

EmoDB (German) 535 1:Angry, 2:Bored,

3:Disgust, 4:Fear,

5:Happy, 6:Sad, 7:Neutral

RAVDESS (North American) 1248 1:Neutral, 2:Calm,

3:Happy, 4:Sad,

5:Angry, 6:Fear, 7:Disgust

4.2 Training Setting and Model

Parameters

The model is ﬁne-tuned for 400 epochs, with a learn-

ing rate of 10

−4

and a batch size equal to 16 for all ex-

periments. Categorical cross entropy loss and Adam

optimizer are used for model optimization. In this

way, the model has been adapted to the new prop-

erties of the source data. Source and target datasets

are randomly divided into training (80%) and testing

(20%) sets. Two evaluation metrics are used:

• Unweighted Accuracy: Accuracy = (t

)/p +

n where t

and t

are predictions of scores true

positive and true negative, respectively. n + p =

+ t

+ f

where f

is a prediction of score

false negative and f

is a prediction of a false pos-

itive score.

• Unweighted Average Recall (UAR): UAR = 0.5 ∗

/p +t

/n) .

4.3 Classiﬁcation Results

In this section, we present and discuss the obtained

classiﬁcation results namely on the source model and

the target model with DA.

4.3.1 Classiﬁcation Results for the Source Model

Learning (Only Source Domain)

In order to select the best model for source data pre-

diction, we computed the prediction of the test set

for the three source datasets. By employing transfer

learning for feature extraction, we have generated Log

Mel-Spectrogram from the input audio set. We per-

formed several experiments with different parameters

and conﬁgurations for ﬁne-tuning the VGG model on

the source data. Table 2 presents the best obtained

classiﬁcation accuracy for the source model. We re-

port classiﬁcation accuracies of 82.24%, 78.5% and

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

122

83.17% for the RAVDESS, IEMOCAP and EmoDB

datasets, respectively.

Table 2: Classiﬁcation results for the source model.

work Model Dataset Accuracy %

(Senthilkumar et al., 2022) Spec VGG16 RAVDESS 77

(Aggarwal et al., 2022) Spec VGG16 RAVDESS 81.94

Ours TL RAVDESS 82.24

(Senthilkumar et al., 2022) Spec VGG16 IEMOCAP 63

Ours TL IEMOCAP 78.5

(Senthilkumar et al., 2022) SpecVGG16 EmoDB 75

Ours TL EmoDB 83.17

We also compare the obtained results with re-

cent works on SER in Table 2. In (Aggarwal et al.,

2022), the authors proposed a two-way approach for

SER. The ﬁrst one is based on Principal Component

Analysis for feature extraction and a DNN for train-

ing. In the second method, Mel-spectrogram images

are extracted from audio ﬁles and given as input to

a pre-trained VGG-16 model. Senthilkumar et .al

(Senthilkumar et al., 2022) proposed Bi-directional

LSTM architecture. They also have some disad-

vantages such as increased computational complex-

ity, overﬁtting risk and increased memory require-

ments. Indeed, Table 2 shows that our proposed trans-

fer learning strategy has better accuracy results com-

pared to (Senthilkumar et al., 2022) and (Aggarwal

et al., 2022). For instance, for RAVDESS from Table

2, we can observe that our transfer learning method

leads to an average increase of at least 0.3% for the

accuracy, 15.5% for the IEMOCAP and 8.17% for the

EmoDB dataset compared to the results obtained in

recent works.

In order to evaluate the model performance per

class, we present confusion matrices on the test data

of the source domain (Figure 2). The goal here is

to see how well the model is performing for each

class, including any imbalances or weakly repre-

sented classes. The test data were randomly sampled.

Figures 2(a),2(b),2(c) show that the proposed transfer

learning gives high accuracy with low misclassiﬁca-

tions for all datasets. Table 3 presents further classiﬁ-

cation results per category.

We can see in the case of RAVDESS, IEMOCAP

and EmoDB datasets that precision of fear, recall of

fear and precision of disgusted, sad and neutral recall

emotions achieve 1, respectively.

4.3.2 Classiﬁcation Results on Target Data (New

Domain)

In order to evaluate the proposed method, we perform

4 transfer learning tasks (Source → Target) with DA

using different datasets:

Table 3: Classiﬁcation results on source model.

Neutral Calm Happy Sad Anger Fear Disgust

RAVDESS

Precision 0.84 0.86 0.86 0.71 0.64 1 0.81

Recall 0.84 0.92 0.60 0.92 0.58 0.89 0.87

F1-score 0.84 0.89 0.71 0.80 0.61 0.94 0.84

Anger Happy Excited Sad Frust Fear Neutral

IEMOCAP

Precision 0.79 0.86 0.71 0.57 0.64 0.87 0.80

Recall 0.85 0.83 0.50 0.73 0.58 1 0.75

F1-score 0.82 0.84 0.59 0.64 0.61 0.93 0.77

Anger Bored Disgust Fear Happy Sad Neutral

EmoDB

Precision 0.76 0.83 1 0.94 0.54 1 0.89

Recall 0.92 0.91 0.46 0.94 0.64 0.79 1

F1-score 0.83 0.87 0.63 0.94 0.58 0.88 0.94

• Task 1: IEMOCAP (9952) → EmoDB (535)

(English→German)

• Task 2: EmoDB (535) → IEMOCAP (9952)

(German→ English)

• Task 3: RAVDESS (1248) → EmoDB (535) (En-

glish:North American → German)

• Task 4: EmoDB (535) → RAVDESS (1248)

(German → English:North American)

We used the output of the ﬁrst FC layer in VGG 16

model to calculate the MMD loss between source

and target domains (Yang et al., 2020). The model

has been trained for 50 epochs. Table 4 presents the

classiﬁcation results using the proposed DA-based

transfer learning approach on the 4 transfer tasks.

In order to ensure a fair comparison with the works

cited in Table 4, we compute the average and the

standard deviation values of both accuracy and UAR

metrics for task 1 and task 2. All values are calculated

with a margin of error or uncertainty associated with

the true value is expected to fall within this range

centered around the given value. We repeat each

experiment ten times and computed the standard

deviation and mean. We compare the performance

of the DA-based TL method with sADDi (Latif

et al., 2022), GAN (Latif et al., 2019), AE (Deng

et al., 2013) and CNN-LSTM (Parry et al., 2019)

methods. Our proposed method compared to these

existing techniques, achieves better results. More-

over, the DA-based TL technique has demonstrated

improvements in UAR for tasks 1 and 2 in UAR

by 1.1% and 4.1%, respectively, compared to the

sADDi method (Latif et al., 2022), 4.9% and 8.5%

compared to the GAN method (Latif et al., 2019) and

7% and 9.5% (including 9.5% in term of accuracy for

task 1) compared to the CNN-LSTM method (Parry

et al., 2019), respectively. For tasks 3 and 4, we have

only one state of the art work that have performed

cross-corpus in SER (Singh et al., 2021) and there

Cross-Lingual Low-Resources Speech Emotion Recognition with Domain Adaptive Transfer Learning

123

(a) Confusion Matrix of RAVDESS (b) Confusion Matrix of IEMOCAP (c) Confusion Matrix of EmoDB

Figure 2: Confusion Matrices of the source model on RAVDESS, IEMOCAP and EmoDB datasets.

are not be speciﬁc studies directly comparing these

two datasets in a cross-lingual context. However,

both datasets are widely used for emotion recognition

tasks in speech processing. We can see in table 4

when we used our proposed DA-based TL method

for tasks 3 and 4, that we achieved better results than

CQT (Singh et al., 2021) and MFSC (Singh et al.,

2021) methods. Accuracy and UAR metric values are

further boosted by using a DA-based TL method. We

achieved a 57% accuracy rate against CQT 48% and

MFSC 45% (Singh et al., 2021) in task 3 and a 50%

accuracy rate against 44% and 41% (Singh et al.,

2021) in task 4, respectively. Indeed for UAR values,

we obtained 58% against CQT 48% and MFSC

42% (Singh et al., 2021) in task 3 and 50% against

CQT 44% and MFSC 41% (Singh et al., 2021)

in task 4, respectively. In summary, the proposed

method proves that the network is able to produce

better-generalized features for cross-language SER

by increasing the ﬁnal UAR and accuracy of the four

tasks.

Table 4: Comparative results of DA-based TL cross-lingual

results by UAR (%) and Accuracy (%) metrics for the 4

tasks.

Work Models Task 1 Task 2

UAR/Accuracy UAR/Accuracy

(Parry et al., 2019) CNN-LSTM 42.1±1.8/41.99 38.9±2.1/NA

(Latif et al., 2018) DBN 42.5±2.1/NA 39.5±2.4/NA

(Deng et al., 2013) AE 43.2±2.3/NA 40.1±1.8/NA

(Latif et al., 2019) GAN 44.3±1.7/NA 40.3±1.7/NA

(Latif et al., 2022) ADDi 46.1±1.6/NA 41.2±1.8/NA

(Latif et al., 2022) sADDi 48.3±1.5/NA 44.8±1.6/NA

Ours DA based TL 50.1±0.8/ 50.74±0.3 50±0.5/ 50.02±0.4

Work Models Task 3 Task 4

UAR/Accuracy UAR/Accuracy

(Singh et al., 2021) MFSC 42/45 44/41

(Singh et al., 2021) CQT 48/48 46/44

Ours DA based TL 58/ 57 50/ 50

Table 5 presents the classiﬁcation results of TL

compared to DA-based TL methods for task 1 and

task 3 cross-lingual SER. It shows that the classiﬁ-

cation accuracy of seven emotions in terms of Pre-

cision, Recall and F1-score are improved with DA-

based TL compared to classiﬁcation report values of

the TL. In the case of the proposed DA-based TL

method, RAVDESS→EmoDB (task 3) achieves high

F-score, Precision and Recall values (> 70%) over

Happy emotion while in the case of TL method F-

score, Precision and Recall are the categories with

the lowest values (< 30%). As shown in Table

5, IEMOCAP→EmoDB (task 1) with TL method

over Boredom emotion achieves a classiﬁcation per-

formance (< 35%) lower than IEMOCAP→EmoDB

with DA-based TL (> 50%) method.

Table 5: Classiﬁcation results of IEMOCAP → EmoDB

(task 1) and RAVDESS→EmoDB (task 3) cross-lingual

SER using DA based TL method.

Angry Bored Disgust Fear Happy Sad Neutral

Task 1

Classiﬁcation results of DA based TL method

Precision 0.32 0.55 0.32 0.33 0.58 0.60 0.45

Recall 0.47 0.55 0.29 0.39 0.61 0.39 0.49

F1-Score 0.38 0.55 0.31 0.36 0.59 0.47 0.47

Classiﬁcation results of transfer learning method

Precision 0.35 0.34 0.47 0.29 0.58 0.46 0.47

Recall 0.39 0.29 0.45 0.44 0.56 0.44 0.38

F1-score 0.37 0.31 0.46 0.35 0.57 0.45 0.42

Task 3

Classiﬁcation results of DA based TL method

Precision 0.45 0.72 0.61 0.50 0.70 0.53 0.61

Recall 0.69 0.82 0.41 0.32 0.73 0.65 0.74

F1-score 0.55 0.77 0.49 0.39 0.71 0.58 0.67

Classiﬁcation results of transfer learning method

Precision 0.74 1 0.5 0.37 0.27 0.28 0.27

Recall 0.57 0.42 0.5 0.44 0.27 0.83 0.42

F1-score 0.64 0.59 0.5 0.40 0.27 0.42 0.52

4.3.3 Effect of DA on Transfer Learning

Classiﬁcation Results: In this section, we present

results for the most representative tasks namely task 1

and task 3 that illustrate an adaptation from English

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

124

data to a smaller German (low resource) one. Ta-

ble 6, presents a comparative study of accuracy and

UAR results metrics for IEMOCAP→EmoDB (task

1) and RAVDESS→EmoDB (task 3) cross-corpus us-

ing DA-based TL and TL methods.

Table 6: Classiﬁcation results on the target domain.

Method Task Accuracy (%) UAR (%)

Transfer Learning Task 1 45.8 44.73

DA-based TL (ours) Task 1 50.74 50.1

Transfer Learning Task 3 50.47 50.65

DA-based TL (ours) Task 3 53.47 58.01

As shown in Table 6 the results of the ex-

perimental groups using the DA based TL tech-

nique are better than those obtained by the TL

method from scratch. Indeed, with task DA

based TL for IEMOCAP→EmoDB (task 1), the

recognition accuracy and UAR are 5.24% and 6%

higher than those obtained by TL method for

IEMOCAP→EmoDB (task 1) model, respectively.

For RAVDESS→EmoDB (task 3) accuracy and

UAR obtained by DA based TL, are 3% and 8.6%

higher than those obtained by the TL method for

RAVDESS→EmoDB (task 3), respectively.

(a) IEMOCAP→EmoDB (b) IEMOCAP→EmoDB

Figure 3: Confusion Matrices for RAVDESS→EmoDB

and IEMOCAP→EmoDB tasks using TL and DA based

TL methods with 1:Angry, 2:Boredom, 3:Disgust, 4:Fear,

5:Happy, 6:Sad, 7:Neutral emotions.

We plot confusion matrices on the test data of the

target domain (Figure 3) with the same goal as for the

evaluation of the source model. Indeed, some emo-

(a) IEMOCAP→EmoDB

(Task 1)

(b) IEMOCAP→EmoDB

(Task 1)

(Task3)

(d) RAVDESS→EmoDB

(Task 3)

Figure 4: Visualization of features for the tasks 1 and 3

using transfer learning (Fig.(a,c)) and proposed approach

(Fig.(b,d)).

tions might naturally occur less frequently in real-

world scenarios, making them weakly represented

in the data. Hence, in our experiments, the test

data are randomly sampled to contain some under-

represented emotions that may illustrate real-world

and low-resource scenarios. We can see from the con-

fusion matrix Figures of IEMOCAP→EmoDB 3(b)

and RAVDESS→EmoDB 3(d) cross-lingual, that the

distribution of features resulted in a high classiﬁca-

tion effect using the proposed approach DA based

TL compared to the confusion matrix Figures of

IEMOCAP→EmoDB 3(a) and RAVDESS→EmoDB

3(c) cross-lingual with TL technique. This is because

the good detection emotion abilities of DA-based TL

over TL techniques. Comparing Figures 3(b) and

3(d), we observe a general increase in accuracy for

different classes of emotions for the DA based TL

method, usually at the expense of the ”disgust” class.

Further-more, we note that ”Happy, Sad and Neutral”

classes, appears to have the largest gain in accuracy.

Features Visualization: In order to validate the

effectiveness of the proposed domain adaptation

method for speech emotion recognition, we plot

the t-SNE (Van der Maaten and Hinton, 2008) for

Cross-Lingual Low-Resources Speech Emotion Recognition with Domain Adaptive Transfer Learning

125

features extracted from the obtained model by simple

transfer learning and features generated by the

proposed method. Hence, we used the layer FC-4 to

extract the features and to plot labels. The points are

colored according to the emotion category.

From Figure 4 we can see that our proposed ap-

proach (ﬁgures 4(b) and 4(d)) is able to more ef-

fectively separate emotional features from different

classes and the clusters are better structured than

the basic transfer learning method (ﬁgures 4(a) and

4(c)) from the tasks IEMOCAP→EmoDB (task 1)

and RAVDESS→EmoDB (task 3). As can be ob-

served in ﬁgures 4(b) and 4(d), that the inter-class

variance is increased and the emotional classes are

highly correlated, while the obtained emotional clus-

ters are more compact. The proposed adaptive trans-

fer learning method helps in learning discriminative

multi-language features and hence improves the clas-

siﬁcation performance of emotions from speech.

5 CONCLUSION

In this paper, we propose a domain adaptive-based

transfer learning approach for cross-lingual Speech

Emotion Recognition problem. The proposed method

jointly align domain invariant features and improve

feature quality for better classiﬁcation in a supervised

manner. The proposed method has been evaluated

on different transfer learning tasks namely for low-

resource scenarios using IEMOCAP, RAVDESS and

EmoDB datasets. Obtained results revealed that our

proposed approach outperforms existing SER meth-

ods in terms of both UAR and Accuracy metrics. The

promising results obtained from this study open av-

enues for future research in the realm of cross-lingual

low-resource speech emotion recognition due to the

the modest improvement.

ACKNOWLEDGEMENTS

Support for this research was provided by a grant

from La R

egion Nouvelle Aquitaine (CPER FEDER

P-2019-2022), in partnership with the European

Union (FEDER/ ERDF, European Regional Develop-

ment Fund).

REFERENCES

Abdelwahab, M. and Busso, C. (2018). Domain adversarial

for acoustic emotion recognition. IEEE/ACM Trans-

actions on Audio, Speech, and Language Processing,

26(12):2423–2435.

Agarla, M., Bianco, S., Celona, L., Napoletano, P., Petro-

vsky, A., Piccoli, F., Schettini, R., and Shanin, I.

(2022). Semi-supervised cross-lingual speech emo-

tion recognition. arXiv preprint arXiv:2207.06767.

Agarla, M., Bianco, S., Celona, L., Napoletano, P., Petro-

vsky, A., Piccoli, F., Schettini, R., and Shanin, I.

(2024). Semi-supervised cross-lingual speech emo-

tion recognition. Expert Systems with Applications,

237:121368.

Aggarwal, A., Srivastava, A., Agarwal, A., Chahal, N.,

Singh, D., Alnuaim, A. A., Alhadlaq, A., and Lee,

H.-N. (2022). Two-way feature extraction for speech

emotion recognition using deep learning. Sensors,

22(6):2378.

Ahn, Y., Lee, S. J., and Shin, J. W. (2021). Cross-corpus

speech emotion recognition based on few-shot learn-

ing and domain adaptation. IEEE Signal Processing

Letters, 28:1190–1194.

Attabi, Y. and Dumouchel, P. (2013). Anchor models for

emotion recognition from speech. IEEE Transactions

on Affective Computing, 4(3):280–290.

Badshah, A. M., Rahim, N., Ullah, N., Ahmad, J., Muham-

mad, K., Lee, M. Y., Kwon, S., and Baik, S. W.

(2019). Deep features-based speech emotion recog-

nition for smart affective services. Multimedia Tools

and Applications, 78:5571–5589.

Barth, I. (2020). When we talk about emotions and plurilin-

gualism.

Burkhardt, F., Paeschke, A., Rolfes, M., Sendlmeier, W. F.,

Weiss, B., et al. (2005). A database of german emo-

tional speech. In Interspeech, volume 5, pages 1517–

1520.

Busso, C., Bulut, M., Lee, C.-C., Kazemzadeh, A., Mower,

E., Kim, S., Chang, J. N., Lee, S., and Narayanan,

S. S. (2008). Iemocap: Interactive emotional dyadic

motion capture database. Language resources and

evaluation, 42:335–359.

Cai, X., Wu, Z., Zhong, K., Su, B., Dai, D., and Meng,

H. (2021). Unsupervised cross-lingual speech emo-

tion recognition using domain adversarial neural net-

work. In 2021 12th International Symposium on Chi-

nese Spoken Language Processing (ISCSLP), pages

1–5. IEEE.

Deng, J., Zhang, Z., Marchi, E., and Schuller, B. (2013).

Sparse autoencoder-based feature transfer learning for

speech emotion recognition. In 2013 humaine associ-

ation conference on affective computing and intelli-

gent interaction, pages 511–516. IEEE.

El Ayadi, M., Kamel, M. S., and Karray, F. (2011). Sur-

vey on speech emotion recognition: Features, classi-

ﬁcation schemes, and databases. Pattern recognition,

44(3):572–587.

Fu, H., Zhuang, Z., Wang, Y., Huang, C., and Duan, W.

(2023). Cross-corpus speech emotion recognition

based on multi-task learning and subdomain adapta-

tion. Entropy, 25(1):124.

Gerczuk, M., Amiriparian, S., Ottl, S., and Schuller, B. W.

(2021). Emonet: A transfer learning framework

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

126

for multi-corpus speech emotion recognition. IEEE

Transactions on Affective Computing.

Gideon, J., McInnis, M. G., and Provost, E. M. (2019).

Improving cross-corpus speech emotion recognition

with adversarial discriminative domain generalization

(addog). IEEE Transactions on Affective Computing,

12(4):1055–1068.

Goel, S. and Beigi, H. (2020). Cross lingual cross cor-

pus speech emotion recognition. arXiv preprint

arXiv:2003.07996.

Gretton, A., Borgwardt, K., Rasch, M., Sch

olkopf, B., and

Smola, A. (2006). A kernel method for the two-

sample-problem. Advances in neural information pro-

cessing systems, 19.

Hu, J., Ruder, S., Siddhant, A., Neubig, G., Firat, O.,

and Johnson, M. (2020). Xtreme: A massively mul-

tilingual multi-task benchmark for evaluating cross-

lingual generalisation. In International Conference on

Machine Learning, pages 4411–4421. PMLR.

Huang, Z., Dong, M., Mao, Q., and Zhan, Y. (2014). Speech

emotion recognition using cnn. In Proceedings of the

22nd ACM international conference on Multimedia,

pages 801–804.

Huijuan, Z., Ning, Y., and Ruchuan, W. (2023). Improved

cross-corpus speech emotion recognition using deep

local domain adaptation. Chinese Journal of Electron-

ics, 32(3):1–7.

Kexin, Z. and Yunxiang, L. (2023). Speech emotion recog-

nition based on transfer emotion-discriminative fea-

tures subspace learning. IEEE Access.

Khalil, R. A., Jones, E., Babar, M. I., Jan, T., Zafar, M. H.,

and Alhussain, T. (2019). Speech emotion recogni-

tion using deep learning techniques: A review. IEEE

Access, 7:117327–117345.

Latif, S., Qadir, J., and Bilal, M. (2019). Unsupervised ad-

versarial domain adaptation for cross-lingual speech

emotion recognition. In 2019 8th international con-

ference on affective computing and intelligent inter-

action (ACII), pages 732–737. IEEE.

Latif, S., Rana, R., Khalifa, S., Jurdak, R., and Schuller,

B. W. (2022). Self supervised adversarial do-

main adaptation for cross-corpus and cross-language

speech emotion recognition. IEEE Transactions on

Affective Computing.

Latif, S., Rana, R., Younis, S., Qadir, J., and Epps, J. (2018).

Transfer learning for improving speech emotion clas-

siﬁcation accuracy. arXiv preprint arXiv:1801.06353.

Lech, M., Stolar, M., Best, C., and Bolia, R. (2020). Real-

time speech emotion recognition using a pre-trained

image classiﬁcation network: Effects of bandwidth re-

duction and companding. Frontiers in Computer Sci-

ence, 2:14.

Liu, J., Zheng, W., Zong, Y., Lu, C., and Tang, C. (2020).

Cross-corpus speech emotion recognition based on

deep domain-adaptive convolutional neural network.

IEICE TRANSACTIONS on Information and Systems,

103(2):459–463.

Liu, S., Zhang, M., Fang, M., Zhao, J., Hou, K., and

Hung, C.-C. (2021). Speech emotion recognition

based on transfer learning from the facenet frame-

work. The Journal of the Acoustical Society of Amer-

ica, 149(2):1338–1345.

Livingstone, S. R. and Russo, F. A. (2018). The ryerson

audio-visual database of emotional speech and song

(ravdess): A dynamic, multimodal set of facial and

vocal expressions in north american english. PloS one,

13(5):e0196391.

Lugovi

c, S., Dunder, I., and Horvat, M. (2016). Techniques

and applications of emotion recognition in speech.

In 2016 39th international convention on information

and communication technology, electronics and mi-

croelectronics (mipro), pages 1278–1283. IEEE.

Ma, A., Filippi, A. M., Wang, Z., and Yin, Z. (2019).

Hyperspectral image classiﬁcation using similarity

measurements-based deep recurrent neural networks.

Remote Sensing, 11(2):194.

McFee, B., Raffel, C., Liang, D., Ellis, D. P., McVicar, M.,

Battenberg, E., and Nieto, O. (2015). librosa: Audio

and music signal analysis in python. In Proceedings

of the 14th python in science conference, volume 8,

pages 18–25.

Padi, S., Sadjadi, S. O., Sriram, R. D., and Manocha, D.

(2021). Improved speech emotion recognition using

transfer learning and spectrogram augmentation. In

Proceedings of the 2021 international conference on

multimodal interaction, pages 645–652.

Parry, J., Palaz, D., Clarke, G., Lecomte, P., Mead, R.,

Berger, M., and Hofer, G. (2019). Analysis of deep

learning architectures for cross-corpus speech emo-

tion recognition. In Interspeech, pages 1656–1660.

Rezaeianjouybari, B. and Shang, Y. (2020). Deep learn-

ing for prognostics and health management: State of

the art, challenges, and opportunities. Measurement,

163:107929.

Scheidwasser-Clow, N., Kegler, M., Beckmann, P., and Cer-

nak, M. (2022). Serab: A multi-lingual benchmark for

speech emotion recognition. In ICASSP 2022-2022

IEEE International Conference on Acoustics, Speech

and Signal Processing (ICASSP), pages 7697–7701.

IEEE.

Senthilkumar, N., Karpakam, S., Devi, M. G., Balakumare-

san, R., and Dhilipkumar, P. (2022). Speech emotion

recognition based on bi-directional lstm architecture

and deep belief networks. Materials Today: Proceed-

ings, 57:2180–2184.

Sharma, M. (2022). Multi-lingual multi-task speech emo-

tion recognition using wav2vec 2.0. In ICASSP 2022-

2022 IEEE International Conference on Acoustics,

Speech and Signal Processing (ICASSP), pages 6907–

6911. IEEE.

Singh, P., Saha, G., and Sahidullah, M. (2021). Non-

linear frequency warping using constant-q transforma-

tion for speech emotion recognition. In 2021 Interna-

tional Conference on Computer Communication and

Informatics (ICCCI), pages 1–6. IEEE.

Van der Maaten, L. and Hinton, G. (2008). Visualizing data

using t-sne. Journal of machine learning research,

9(11).

Cross-Lingual Low-Resources Speech Emotion Recognition with Domain Adaptive Transfer Learning

127

Yang, Z., Liu, G., Xie, X., and Cai, Q. (2020). Efﬁcient

dynamic domain adaptation on deep cnn. Multimedia

Tools and Applications, 79(45):33853–33873.

Ye, J., Wei, Y., Wen, X.-C., Ma, C., Huang, Z., Liu, K., and

Shan, H. (2023). Emo-dna: Emotion decoupling and

alignment learning for cross-corpus speech emotion

recognition. arXiv preprint arXiv:2308.02190.

Zhang, J., Jiang, L., Zong, Y., Zheng, W., and Zhao, L.

(2021a). Cross-corpus speech emotion recognition us-

ing joint distribution adaptive regression. In ICASSP

2021-2021 IEEE International Conference on Acous-

tics, Speech and Signal Processing (ICASSP), pages

3790–3794. IEEE.

Zhang, S., Liu, R., Tao, X., and Zhao, X. (2021b). Deep

cross-corpus speech emotion recognition: Recent ad-

vances and perspectives. Frontiers in Neurorobotics,

15.

ZHAO, H., YE, N., and WANG, R. (2023). Improved cross-

corpus speech emotion recognition using deep local

domain adaptation. Chinese Journal of Electronics,

32(3):1–7.

Zhao, Z., Zhao, Y., Bao, Z., Wang, H., Zhang, Z., and Li,

C. (2018). Deep spectrum feature representations for

speech emotion recognition. In Proceedings of the

Joint Workshop of the 4th Workshop on Affective So-

cial Multimedia Computing and ﬁrst Multi-Modal Af-

fective Computing of Large-Scale Multimedia Data,

pages 27–33.

DATA 2024 - 13th International Conference on Data Science, Technology and Applications

128
