CyberGuardian: An Interactive Assistant for Cybersecurity Specialists

Using Large Language Models

Ciprian Paduraru

, Catalina Camelia Patilea

and Alin Stefanescu

1,2

Department of Computer Science, University of Bucharest, Romania

Institute for Logic and Data Science, Romania

Keywords:

Large Language Models, Information Security, Cybersecurity Assistant, Security Ofﬁcers, Llama,

Fine-Tuning.

Abstract:

Cybersecurity plays an important role in protecting people and critical infrastructure. Sectors such as energy,

defense and healthcare are increasingly at risk from cyber threats. To address these challenges, dedicated

Security Operations Centers (SOCs) continuously monitor threats and respond to critical issues. Our research

focuses on the use of Large Language Models (LLMs) to optimize the tasks of SOCs and to support security

professionals. In this work, we propose a framework, which we call CyberGuardian, whose main goal is to

provide a chatbot application along with a set of tools to support SOC analysts in real-time cybersecurity tasks.

We use state-of-the-art LLM techniques and start from a Llama 2 model, then ﬁne-tune the base model using a

new dataset containing mainly cybersecurity topics. The CyberGuardian framework has a plugin architecture

that integrates processes such as Retrieval Augmented Generation (RAG), safeguard methods for interaction

between human user and chatbot, integration with tools to manage tasks such as database interactions, code

generation and execution, and plotting graphs just by specifying the task in a natural language. The work, along

with the dataset we collected and reusable code to update or customize, is made available to the cybersecurity

community as open source.

1 INTRODUCTION

In the context of our increasingly digitalized global

environment, the importance of cybersecurity to pro-

tect individuals, organizations and critical infrastruc-

ture cannot be overstated. A variety of sectors and

applications are increasingly becoming the focus of

cybercriminal activity.

In response to these real-time threats, companies

and institutions have set up specialized teams with

different expertise. A typical team that works around

the clock is called a Security Operations Center

(SOC) (Mughal, 2022), whose members are known

as SOC analysts. Their responsibilities include moni-

toring and detecting threats in real time, investigating

incidents and escalating them to various stakeholders,

and managing security tools and information. They

often work with network engineers and architects to

improve infrastructure protection against potential fu-

ture attacks. Large language models (LLMs) are in-

creasingly being used in numerous applications due

to their high natural language processing (NLP) capa-

bilities, allowing them to perform a variety of tasks.

Contributions. The goal of our research is to utilize

the latest methods and tools in the ﬁeld of large lan-

guage models (LLMs) to support these security ex-

perts and roles through a real-time chatbot applica-

tion. The goal is to streamline their work so that

they can focus on critical aspects rather than redun-

dant tasks that are often challenging. From this per-

spective, the methods developed allow users to inter-

act with the systems, protocols, databases, code gen-

eration and execution, and internal tools using nat-

ural language requests, with the chatbot serving as

the middle component. The framework developed is

named CyberGuardian.

The contributions of this work can be summarized

as follows:

• To the best of our knowledge, this is the ﬁrst open-

source work that investigates the application of

chatbots for SOC specialists to support cybersecu-

rity in real time using large language models.

• The ﬁrst public, experimentally released corpora

(datasets) with up-to-date information on aspects

of cybersecurity, including PDF documents, video

transcripts and markdown content. The collection

contains more than 3000 PDF papers and 8000

442

Paduraru, C., Patilea, C. and Stefanescu, A.

CyberGuardian: An Interactive Assistant for Cybersecurity Specialists Using Large Language Models.

DOI: 10.5220/0012811700003753

In Proceedings of the 19th International Conference on Software Technologies (ICSOFT 2024), pages 442-449

ISBN: 978-989-758-706-1; ISSN: 2184-2833

video transcripts (mainly selected conference pre-

sentations, industry practice tutorials and tools). T

• Reusable open-source code and dataset collec-

tion scripts respository \url{https://github.com/

unibuc-cs/CyberGuardian}) that composes the

aforementioned components through an extensible,

user-customizable plugin architecture.

The paper is organized as follows. The next sec-

tion describes works that we have either used as a

source of inspiration or reused by adapting them to

our context and use cases. Section 3 explains the data

collection processes implemented in the project and

the ﬁne-tuning of the LLMs based on them. Sec-

tion 4 describes the proposed plugin architecture, the

currently implemented components and the commu-

nication ﬂow. The evaluation and discussions can be

found in Section 5. Finally, the last section contains

conclusions and a plan for future work.

2 RELATED WORK

Chatbots Applications for Cybersecurity. In the pa-

per by (Al-Hawawreh et al., 2023), the authors review

the potential of ChatGPT, a chatbot-driven AI tech-

nology, in the ﬁeld of cybersecurity and demonstrate

its use in penetration testing and threat defense. In

addition, the research paper includes a case study of

ChatGPT in creating and executing false data injec-

tion attacks on vital infrastructure, including indus-

trial control systems. Furthermore, the article dis-

cusses the existing challenges and outlines possible

future directions for the integration of ChatGPT into

the cybersecurity domain. In (Franco et al., 2020) and

(Shaqiri, 2021), the authors apply classical NLP tech-

niques to support high-level cybersecurity planning

and management by identifying logs of past cyberat-

tacks, suggesting solutions, and providing insights for

decision making. The interaction is done by prompt-

ing users to extract or provide different types of solu-

tions.

In the same area, research in (Arora et al., 2023)

is developing a conversational chatbot that uses AI

and sentiment analysis of Twitter data to predict cy-

ber threats and provide tools and strategies for assess-

ing cyber threats on social media. The potential of

chatbots with deep learning as a proactive solution

for detecting persistent threats and phishing attacks

in real time is studied in (Tejonath Reddy, 2024). The

conclusion of their research is that unlike traditional

methods that struggle to keep up with cybercriminals’

evolving strategies, deep learning algorithms contin-

uously adapt to new paradigms and recognize subtle

indicators of phishing attacks. By integrating these

mechanisms into chatbots, stronger defenses can be

created against the ever-changing phishing attempts

and counterfeit prevention.

The study in (Abdelhamid et al., 2023) proposes

the use of chatbots integrated with social networks as

social collaborative agents for continuous cyberse-

curity awareness, education and training, providing

instant advice and alerts to users in various threat-

ening situations and allowing admin users to add

training materials remotely. A similar educational

goal is explored in (Fung et al., 2022), which presents

a user-friendly cybersecurity chatbot built on Google

Dialogﬂow that educates users about cyber risks,

provides a knowledge base, self-quizzes, and advice

for dealing with cybersecurity issues, effectively

raising cybersecurity awareness,

Data Security Through Chatbot Interaction. On

the other hand, an interesting topic is the security of

data when interacting with chatbots. Since our pro-

posed work and demo use case deal with sensitive

user data but also expose important system features

to users, we follow the state of the art in this area.

Chatbots are gaining popularity in various ﬁelds, but

their widespread use brings inherent security risks

and vulnerabilities. In their systematic literature re-

view, (Yang et al., 2023) the authors focus on iden-

tifying potential threats, proposing effective solutions

and outlining promising avenues for future investiga-

tion.

3 DATASETS COLLECTION,

FINE-TUNING, USE- CASES

This section presents the sources used for collecting

cybersecurity-related information for the creation of

a speciﬁc dataset and the ﬁne-tuning methods that use

them to move the Llama 2-Chat-7B (Touvron et al.,

2023) foundation model towards better aligned cyber-

security knowledge and related tasks. Finally, further

use cases that the ﬁne-tuning method could address

are discussed.

3.1 Data Collection

The corpora for the ﬁne-tuning process are collected

using human-in-the-loop as the ﬁrst layer. The au-

thors and volunteer practitioners contributed to a col-

lection of links to arXiv papers, Youtube videos (with

transcripts or at least a high-quality English transla-

tion) and markdown content from Github repositories

or websites. Above all, the selected content should

be newer than 2021 so that the ﬁne-tuned model on

CyberGuardian: An Interactive Assistant for Cybersecurity Specialists Using Large Language Models

443

Llama 2 can also incorporate newer knowledge with

that it was trained. However, the dataset also includes

content published before this date, so that we could

specialize the model on the most important cyberse-

curity techniques and concepts. In our implementa-

tion, we store the metadata about the content of D in

database chunks using MongoDB

. With this strategy,

we avoid duplication of content after automatic or hu-

man extraction of content and enable continuously

updating of the dataset. By chunking the content, old

information can also be forgotten or discarded. The

content of the dataset is also indexed on disk using

the Faiss library (Douze et al., 2024), (Johnson et al.,

2019), and loaded into RAM for efﬁciency reasons, as

far as the local machine can handle it. The process is

shown in Figure 1. While the model is ﬁne-tuned on

the dataset D , this is also indexed for RAG purposes,

as in some cases the ﬁne-tuning process may not adapt

well enough to speciﬁc content, and this would be the

backup.

D ={Subtitles(Video

), Markdown

, PDF

} (1)

3.2 Fine-Tuning

We evaluate the state-of-the-art open-source models

of Llama 2 (Touvron et al., 2023) for the selection

of the LLM foundation. After comparing different

classes of models and trade-offs, we decided to ﬁne-

tune Llama 2-Chat-7B, which specializes in chat con-

versations and has 7 billion parameters.

The complete ﬂow from the foundation model to

the ﬁne-tuned version used by our methods, Cyber-

GuardianLLM, is shown in Figure 1. We use the em-

bedding model of the sentence transformer (Reimers

and Gurevych, 2019), more precisely a variant of it

that is available as open source, all-mpnet-base-v2

Its task is to convert the text format into vectors of

ﬂoat values, as further required by the Faiss indexing

and query system (further details in Section 4.2).

For efﬁciency, D is stored in an embedded for-

mat, which we refer to as D

emb

. Batches of samples

from it are run through the model and compared to the

corresponding (ground truth) for similarity using the

cross entropy (Hui and Belkin, 2020) as a loss func-

tion. To evaluate the performance of the model at pre-

deﬁned steps, the perplexity metric (Meister and Cot-

terell, 2021) is used.

MongoDB

https://huggingface.co/sentence-transformers/all-

mpnet-base-v2

1 Sample batch o f examples B ∼ D

emb

2 # Pa ss thr ou g h the mode l the in put s

from B to ge t the pr ed ic t ed

an s we rs

3 PredAnswers = CyberGuardianLLM (B [”Input”])

4 # Com put e loss for th e o pt im iz at io n

pr o ce ss by co mp ar i ng how cl ose

the out put of the mod el is

co mpa re d to the e xam ple t e st .

5 Loss = CrossEntropy (PredAnswers, B [”Answer”])

6 U pdate weights o f CyberGuardianLLM

Listing 1: Fine-tuning process.

4 ARCHITECTURE AND

IMPLEMENTATION

The implementation of the architecture and compo-

nents uses a plugin pattern so that higher capac-

ity models or other methods of ﬁne-tuning, different

functionalities and components can be switched on

and off as required by use cases. In software engi-

neering, this is also known as separation of concerns,

which we try to utilize as a concept when developing

the framework.

The interaction of the system and its components

during a user conversation is shown in Figure 2. To

connect the interfaces of the components, track the

conversation and control the message ﬂow, we have

used the LangChain

APIs.

4.1 Chat Conversation Management

Given a conversation history and a new request from

the user, the ﬁrst step is to ask the LLM model to cre-

ate a standalone question that contains both the his-

tory and the new user’s request. In the ﬁgure, a con-

crete example is given by the element SQ. In this step,

the ability of LLMs to summarize long texts is used.

If the input text is longer than the 4096 token limit, we

only keep the last part of the conversation within this

limit. A simple strategy studied in the literature, that

was also evaluated in our case, was to create hierarchi-

cal summaries from top to bottom, all within the same

boundary (Li et al., 2023). However, in a conversa-

tional environment, it might be intuitively beneﬁcial

to store a limited queue of recent conversational mes-

sages, as our empirical tests have shown. The request

to LLM is made via a prompt template as speciﬁed in

Listing 2.

https://www.langchain.com/

ICSOFT 2024 - 19th International Conference on Software Technologies

444

4. Store metadata for

each chunck

2. Extract text

and metadata

arXiv and other PDF sources

Markdown content

Youtube transcripts

Chunk 1

Chunk 2

Chunk N

1. Obtain sources of data

3. Organize

in groups

and chunks

Mongo DB

VectorStore

Data

5. Create

embedings

Embeddings

6. Persistent

store

Llama 2 Chat 7B

CyberGuardianLLM

JSON

dataset

...........

Fine-tune with

LoRA

Figure 1: The pipeline for ﬁne-tuning the Llama 2-Chat-7B base model to a dataset containing the latest cybersecurity content.

The dataset, D, is ﬁrst exported as a series of JSON ﬁles. In addition, its metadata is stored on a MongoDB server. Finally, D

is chunked and permanently stored in a vector database with FAISS (Douze et al., 2024). The red colored blocks represent the

output of this process, while the white blocks are intermediate steps or data. The blue blocks are imported/taken over models

from external sources. Further details can be found in Section 3.

1 [ I NST ] R e p h ra s e the f o ll o wi n g c on v er s at i on an d

su b se q ue n t q ue st i on so t hat it is a s tan d - alo ne

qu est io n , in i ts o r i g in a l l an gu a ge .

2 Co n ve r sa t io n :

3 { c o n ve r sa t i on _ va r }

4 F oll ow - up qu e st i o n :

5 { q u es t io n _v a r }

6 St and - a lo ne q u es t io n :

7 [/ IN ST ]

Listing 2: The prompt template used to create an

independent question from the course of the conversation

and a new question. Inside the curly brackets are the

variables that are used to ﬁll the prompt with concrete

examples.

4.2 Retrieval Augmented Generation

(RAG)

In addition to indexing the knowledge in the base

dataset, Figure 1, which leads to the creation of a vec-

tor database VecStoreData, our method also enables

a generic representation for the private set of inter-

nal knowledge in a separate vector database called

VectorStore

int

. Indexing of internal information and

internal data is done by integrating state-of-the-art in-

dexing and retrieval methods for vector stores (Douze

et al., 2024), (Johnson et al., 2019). Various types of

common sources can be indexed immediately, but the

list can be extended on user side:

• Internal whitepapers, documentation on systems,

communication, infrastructure.

• Source code, local or private repositories, conﬁg-

uration ﬁles.

• Data sources such as SQL databases, JSON ﬁles,

pandas, csv ﬁles, etc.

The main reason for splitting the vector database

into two parts is that most questions and support re-

quests from users initially relate to internal knowl-

edge. For a user query P, it therefore makes sense

to ﬁrst search for an answer in VectorStore

int

. Only if

the similarity score determined by FAISS is not above

a certain threshold T

RAG

(empirically set to 0.85 in our

evaluation), the search follows in VectorStore

Data

. In

terms of performance, the internal knowledge store is

also signiﬁcantly smaller and faster to access than the

other. The RAG process is shown in Figure 3.

4.3 User Preference in the Chatbot

Interaction

It is important to also adapt the chatbot’s responses

to the user’s preferences. In our demo, we experi-

mentally added some options to the user registration

forms, such as

• Should the responses be concise or contain long ex-

planations?

• Does the user prefer answers from the chatbots with

emoticons?

• Does the user want the assistant to be very polite or

formal?

These options are used through prompt engineering

and by using systems prompts. Such a prompt, as

shown in Listing 3, appears before any other prompt

message from the user’s side, including, for example,

the standalone question generated (Listing 2). This

strategy prompts the LLM to follow some suggested

rules, even if it is not always forced to do so. The

available set of options for each template variable is

show in Eq. 2.

1 < < < SY S >> >

2 In yo ur r e p on s es p l ea se f o ll ow t he f ol l ow i ng

in s tr u ct i on s :

3 { r e s po n se s _ ty p e _v a r }

4 { u s e _e m ot i c on s _v a r }

5 { p o li t e ne s s_ v ar }

6 < <</ SYS > > >

Listing 3: The prompt template is used to personalize the

interaction between each user and the chatbot according to

their preferences. The variables in curly brackets are ﬁlled

with the options of the respective user.

responses type var ∈ {”Be concise in your response”,

”Provide long contextual based responses”}

useemoticons var ∈ {”Use emoticons”,

”Do not use emoticons”}

politeness var ∈ {”Be polite”, ”Be formal”} (2)

CyberGuardian: An Interactive Assistant for Cybersecurity Specialists Using Large Language Models

445

Chat history

New user question

E.g. "Between these

tools which ones

work on Windows ?"

1. Get standalone

question (SQ)

aggregating history

and new question

SQ result: "Give me a tool on

Windows to simulate a DDoS

attack on my local infrastructure."

Discussion was about

simulating a DDoS

attack .

CyberGuardianLLM

2. Given SQ, get

relevant contextual

data stored

RAG Safeguarding

3. Get final answer

SQ + retrieved context

(if any good enough)

Done

Safe

Unsafe ? Ask for rewrite

given unsafe reason

Evaluate

Embedding

(encode / decode operations)

Optional:

Tools support

Local or

distributed

platform

Figure 2: The conversational chat system implemented in the proposed method and its associated components. The ﬂow is

represented by the blue arrows. The three main steps (the green boxes) are used to aggregate the conversation ﬂow, retrieve

internally relevant stored data, and then obtain the ﬁnal response after the safeguard component approves the results. The

optional step is used by the LLM to interact with the registered tools on the deployed platform.

Internal /custom data

Embeddings

PDF, Markdown,

Youtube docs

Source code

Chunk 1

Chunk 2

Chunk N

1. Text split

into chunks

2. Create

embeedings for

each chunk

Formatted data, sql,

pandas, csv, etc

Figure 3: The pipeline for creating the RAG support for the

internal/customized data depends on the user settings and

knowledge of the platform.

User or

Chatbot system

Similarity <

yes

Select context

from local

storage

Output

content

selected

Query

Retrieval Augmented Generation (RAG)

Figure 4: The process for extracting relevant context from

the indexed vector databases for RAG. First, the system tries

to ﬁnd information in the internal knowledge base that most

closely matches the user’s needs and should be quick to

search. If nothing is found, the system tries to ﬁnd rele-

vant context in the data set used for ﬁne-tuning as a backup.

4.4 Safeguarding Interactions

Our method ﬁrst experimented with the integration of

Llama Guard (Inan et al., 2023), an LLM safeguard

model that fulﬁlls the aforementioned use case. It

provides also a taxonomy of security risks. When

prompted, the model ﬁrst outputs the status, i.e. safe

or not, and in the case of unsafe it provides details of

the element in the taxonomy of unsafe reasons.

Considering the computational requirements of

loading another 7B model, our method has also

explored and integrated packages from the NLTK

(Bauer et al., 2020) based on classical NLP tech-

niques that partially resolve various safety classiﬁca-

tions in the prompts. There is a trade-off between the

two solutions. The ﬁrst solution has the advantage of

providing more accurate results without the need to

create a local taxonomy of things to test and output

reasons. The advantage of importing or customizing

the NLTK packages is on the request side, as they are

fast and require little memory.

4.5 Tools and Interaction with the

Backend Systems

To improve the productivity and response time of

SOC specialists, our work integrates state-of-the-art

methods that address the interaction between the user,

the LLM and the system processes. The concepts are

known in the literature under the terms agents, and

tools (Yao et al., 2023), (Schick et al., 2023), (Patil

et al., 2023).

In our framework, the interaction between LLM

and tools is shown in Figure 5. At each step, the LLM

considers the problem it needs to further solve, the

set of available tools, and decides whether to invoke

one of the tools that could further interact with the

organization’s infrastructure and services, or just re-

turn the currently available response. The beneﬁt of

this method is comparable to the concept of task de-

composition in computer science, where a problem is

broken down into smaller tasks and solved piece by

piece. For LLM, and especially for small models, this

is important because it can leverage external capabili-

ties and break the problem into smaller pieces that are

easier to manage.

We use the ReACT agents (Yao et al., 2023)

and their Langchain API. The main idea behind the

method is to do prompt engineering and inform the

LLM about a short description of each of the available

tool. A prompt template similar to the one in List-

ing 2 is used, where instead of the variable conversa-

tion var, the framework ﬁlls in the description of each

tool and how it should be called. Using a small set

of 50 examples of tool calls and parameter extraction

examples, we ﬁne-tuning CyberGuardianLLM over a

few epochs.

Most of the core tools in our smart home demo

ICSOFT 2024 - 19th International Conference on Software Technologies

446

application (Section 5) are reused from Langchain

and enable interaction with the organization’s systems

through natural language queries, such as:

• Interaction with SQL or Pandas databases, e.g. ﬁl-

ter, select or aggregate data from multiple tables.

• Ofﬁce tools, e.g. sending emails or adding entries

to the calendar.

• Python code generation. Code Llama 7B (Rozi

ere

et al., 2024) is used in the demo app.

• Python code execution with PythoREPL

. This

tool can shorten the time it takes to call the code

and get results and lets the LLM do the unneces-

sary work in the background.

The Identify layer block in Figure 5 is used as

an intermediate step to help the LLM select one of

the tools by identifying keywords in the prompt and

asking the model to make a correlation between the

prompts and the tools’ tags. Our evaluation has

shown that tagging prompts and tools is more help-

ful in recognizing the correct tool than the standard

Langchain’s method of prompt engineering (default

in the ReACT implementation). Note that the tool

suite can be customized by the user. Langchain, for

example, already contains a large list of tools that can

be extended by those implemented by the user.

CyberGuardianLLM

SQL

Plots

Custom

tools

Office

Pandas

Set of

tools

Systems to interact with

Act

Result

Reason

Prompt task

Call tools

/ retrieve

results

Final

response

Identify

layer

PythonREPL

Code

Llama

Figure 5: Starting from a speciﬁc prompt or task, the ﬁgure

shows the ﬂow of interaction with tools, services, and sys-

tems provided by the organization.

5 EVALUATION

5.1 Quantitative and Qualitative

Evaluation

There are two research questions that we address in

our study:

• RQ1. How is the ﬁne-tuned model able to under-

stand the cybersecurity domain?

• RQ2. How well is the overall CyberGuardian

system able to meet user needs?

RQ1 Analysis. To understand how helpful the ﬁne-

tuned CyberGuardianLLM is from a quantitative per-

spective, we evaluate the usefulness of the responses

https://realpython.com/python-repl/

using a common method (Zheng et al., 2023) of auto-

mated evaluation using a much larger model, speciﬁ-

cally GPT-4 , as a judge.

We assume 5 topics in cybersecurity needed by

SOC specialists: a) protection of systems from secu-

rity risks and malware, b) cryptography, c) conﬁgu-

ration of security protocols such as ﬁrewalls, intru-

sion detection systems (IDS), d) network security in-

frastructure (ﬁrewalls, VPNs, web proxy, IDS/IPS),

e) investigation of data breaches and data leaks. We

denote these clusters with Topics = (t p

)

i=1,...5

. The

judge, GPT-4, is asked via a prompt to create 20 ques-

tions for each of the 5 topics, resulting in a total of 100

questions, denoted by the quantity Que. This set is ob-

tained by ﬁlling in the topic variable in the template

shown in Listing 4.

1 [ IN ST ] C on s id e r you r se l f a n in t er v ie w er f or a SO C

sp e ci a li s t p os it i on .

2 As k 2 0 r e le v an t . d if f er en t q u es t io n s o n t he to pi c : "{

to p ic _v a r }" [/ IN ST ]

Listing 4: The template prompt used to ask questions to the

judge LLM.

To compare the answers of two LLMs, LLM1 resp

and LLM2 resp, we ask the judge again via a prompt

which one he prefers, Listing 5. We ﬁll the template

variables for each question Q ∈ Que.

1 [ IN ST ] G iv en th e q u e st i on : "{ Q_ va r }" , te ll me w hi ch

of t he f o ll ow i ng t wo a ns w er s yo u p r ef er . W ri te

on ly R es p on s e1 or R e sp o ns e2 .

2 ## # R es po n se 1: { L LM 1_ r es p }.

3 ## # R es po n se 2: { LL M2 r esp }. [/ INS T ]

Listing 5: The template for classifying the answers with

judge LLM.

We measure the CyberGuardianLLM responses

for each Q ∈ Que against the 3 Llama 2 models:

Llama 2-Chat-7B, 13B, and 70B. Table 1 shows the

average preference in percent between these models.

The results are similar even when broken down by

topic, which is kind of expected since the data collec-

tion was done for all of these categories.

The BLEU metric, which is also used in the evalu-

ation of other LLMs (Touvron et al., 2023), compares

the judge’s reference response (GPT-4) with the one

generated by each LLM. The BLEU scores for our

test under the above conditions are shown in Figure 6.

The scores range from 0 to 100, with a higher score

indicating a stronger match between the generated re-

sponse and the reference. A score of 100 represents

a perfect match, while a score of 0 means that there

is no overlap between the generated response and the

reference.

RQ2 Analysis. For this analysis, we reused the work

of (Cristea et al., 2022), where different smart home

applications connect to a central hub server from dif-

ferent locations either directly or via other servers. In

CyberGuardian: An Interactive Assistant for Cybersecurity Specialists Using Large Language Models

447

Table 1: Head-to-head preference of responses using the

GPT-4 as a judge. The second column shows the percent-

age of cases in which each of the compared models was

preferred to the CyberGuardianLLM.

Model

Preferred

over

CyberGuardianLLM

Llama-Chat-7B

26%

Llama-Chat-13B

39%

Llama-70B

58%

Figure 6: The BLEU metric compared between the 4 mod-

els under evaluation.

addition, a simulator for different types of attacks, in-

cluding DDoS (de Neira et al., 2023), has been imple-

mented. The snapshots of the attacks provided var-

ious data tables with statistics on the utilization of

resources (e.g. servers, routers, local hub systems),

connection logs of users including their location, time

and resources consumed in the network. The deploy-

ment interface was handled via RestAPI and the client

was implemented with Streamlit

libraries and tools

(including visualizations). All these simulations and

screenshots can be found in the repository.

The test was attended by 23 practitioners with dif-

ferent levels of cybersecurity knowledge, but most of

them are still at the very beginning of their careers.

During our demo use case, the system triggered sig-

nals that could indicate a DDoS attack, e.g. unusu-

ally many timeouts for various operations in the IoT

hub, response code errors in class 500, etc. The hu-

man’s task was to ﬁrst recognize that there could be

a potential DDoS in the background and solve it with

the support of CyberGuardian. The resolution path

then involves: a) creating 2D/3D diagrams of the re-

sources in use at different sites (using the plotting

tool), b) ﬁltering IPs that appear to be ﬂooding the

servers through database queries, and c) asking the

chatbot to write a piece of Python code that adds the

https://streamlit.io/

identiﬁed attacking IPs to a blacklist ﬁrewall rule us-

ing the one custom tool.

The task was solved correctly by 17 people within

a single instance of the test. The rest had to restart the

test and try once or twice. We collect their feedback

after each question-response pair and the ﬁnal survey.

For each feedback, they could write it in natural lan-

guage and also give a score between 1-5. All feedback

received were collected via the Trubrics

platform.

The average score of the responses was 4.2, while

the average reported time to solve the task was ∼ 37

minutes, with a minimum of 14 and 49 maximum

minutes respectively. The natural language feedback

could later be correlated with the ratings and text in

the user chatbot interaction to learn a reward func-

tion and perform reinforcement learning from human

feedback (RLHF), as the Llama models do, but this

requires certain resources, and for now this is left as

future work given the scope. Considering the feed-

back from the users, their abilities and the potentially

difﬁcult sequential step problem they had to solve, the

results are promising in our view.

5.2 Discussion

Observations from the RQ2 Sessions. The ﬁrst im-

portant observation we made through the human eval-

uation, which we iterated a few times in different

scales and versions of CyberGuardian, is that the task

decomposition with the support of LLM reasoning

traces and tools was signiﬁcant. The impact can be

even greater for large organizations and a signiﬁcant

number of tools, which is also known in the industry

and frameworks as multi-agent workﬂows

. Another

important observation is that the models with small

classes may have problems understanding long con-

texts, with unexpected results such as repetition of the

context or inability to understand and respond appro-

priately to long contexts. Breaking it down into small

steps and prompts is recommended.

6 CONCLUSIONS AND FUTURE

WORK

This paper explores the intersection of cybersecurity

and Large Language Models (LLMs) in the context

of Security Operations Centers (SOCs). The pro-

posed framework, CyberGuardian, aims to improve

the tasks of SOCs through the use of LLM tech-

https://trubrics.com/

https://blog.langchain.dev/

langgraph-multi-agent-workﬂows/

ICSOFT 2024 - 19th International Conference on Software Technologies

448

niques. Its plugin includes features such as Retrieval

Augmented Generation (RAG), methods for securing

human-chatbot interaction and natural language in-

teraction for managing cybersecurity tasks related to

databases, ﬁrewalls, plotting graphs, code generation

and execution.

ACKNOWLEDGEMENTS

This research was supported by European Union’s

Horizon Europe research and innovation programme

under grant agreement no. 101070455, project DYN-

ABIC.

REFERENCES

Abdelhamid, S. et al. (2023). Cybersecurity awareness,

education, and workplace training using socially en-

abled intelligent chatbots. In Creative Approaches

to Technology-Enhanced Learning for the Workplace

and Higher Education, pages 3–16, Cham. Springer

Nature Switzerland.

Al-Hawawreh, M., Aljuhani, A., and Jararweh, Y. (2023).

Chatgpt for cybersecurity: practical applications,

challenges, and future directions. Cluster Computing,

26(8):3421–3436.

Arora, A., Arora, A., and McIntyre, J. (2023). Developing

chatbots for cyber security: Assessing threats through

sentiment analysis on social media. Sustainability,

15(17).

Bauer, T., Devrim, E., Glazunov, M., Jaramillo, W. L., Mo-

han, B., and Spanakis, G. (2020). # metoomaastricht:

Building a chatbot to assist survivors of sexual harass-

ment. In International Workshops of ECML PKDD

2019, pages 503–521. Springer.

Cristea, R., Feraru, M., and Paduraru, C. (2022). Building

blocks for iot testing - a benchmark of iot apps and

a functional testing framework. In SERP4IoT@ICSE,

pages 25–32. ACM.

de Neira, A. B., Kantarci, B., and Nogueira, M. (2023).

Distributed denial of service attack prediction: Chal-

lenges, open issues and opportunities. Computer Net-

works, 222:109553.

Douze, M. et al. (2024). The faiss li-

brary. arXiv preprint arXiv:2401.08281,

https://github.com/facebookresearch/faiss.

Franco, M. F. et al. (2020). Secbot: a business-driven con-

versational agent for cybersecurity planning and man-

agement. In 2020 16th International Conference on

Network and Service Management (CNSM), pages 1–

Fung, Y.-C. et al. (2022). A chatbot for promoting cyber-

security awareness. In Cyber Security, Privacy and

Networking, pages 379–387, Singapore. Springer Na-

ture Singapore.

Hui, L. and Belkin, M. (2020). Evaluation of neural archi-

tectures trained with square loss vs cross-entropy in

classiﬁcation tasks. arXiv preprint arXiv:2006.07322.

Inan, H., Upasani, et al. (2023). Llama guard: Llm-

based input-output safeguard for human-ai conversa-

tions. arXiv preprint arXiv:2312.06674.

Johnson, J., Douze, M., and J

egou, H. (2019). Billion-scale

similarity search with GPUs. IEEE Transactions on

Big Data, 7(3):535–547.

Li, M., Hovy, E., and Lau, J. H. (2023). Summarizing multi-

ple documents with conversational structure for meta-

review generation. In The 2023 Conference on Empir-

ical Methods in Natural Language Processing.

Meister, C. and Cotterell, R. (2021). Language model

evaluation beyond perplexity. In ACL-IJCNLP, pages

5328–5339.

Mughal, A. A. (2022). Building and securing the modern

security operations center (soc). International Jour-

nal of Business Intelligence and Big Data Analytics,

5(1):1–15.

Patil, S. G. et al. (2023). Gorilla: Large language model

connected with massive apis. CoRR, abs/2305.15334.

Reimers, N. and Gurevych, I. (2019). Sentence-bert: Sen-

tence embeddings using siamese bert-networks. arXiv

preprint arXiv:1908.10084.

Rozi

ere, B. et al. (2024). Code llama: Open foundation

models for code.

Schick, T. et al. (2023). Toolformer: Language models can

teach themselves to use tools. In Oh, A. et al., editors,

Advances in Neural Information Processing Systems,

volume 36, pages 68539–68551.

Shaqiri, B. (2021). Development and reﬁnement of a chat-

bot for cybersecurity support. Master’s thesis, Univer-

sity of Zurich, Zurich, Switzerland.

Tejonath Reddy, K. (2024). How deep learning chatbots

empower cybersecurity against phishing attacks. In-

ternational Center for AI and Cyber Security Re-

search and Innovations (CCRI).

Touvron, H. et al. (2023). Llama 2: Open foundation and

ﬁne-tuned chat models.

Yang, J. et al. (2023). A systematic literature review of

information security in chatbots. Applied Sciences,

13(11).

Yao, S. et al. (2023). React: Synergizing reasoning and act-

ing in language models. In The Eleventh International

Conference on Learning Representations, ICLR 2023,

Kigali, Rwanda, May 1-5, 2023.

Zheng, L. et al. (2023). Judging llm-as-a-judge with mt-

bench and chatbot arena. In Advances in Neural In-

formation Processing Systems (NeurIPS, volume 36,

pages 46595–46623.

CyberGuardian: An Interactive Assistant for Cybersecurity Specialists Using Large Language Models

449
