A Comprehensive Research of Data Privacy Based on Federated

Learning

Junxiang Zhang

School of Advanced Technology, Xi’an Jiaotong-Liverpool University, Suzhou, Jiangsu, 215000, China

Keywords: Federated Learning, Privacy Protection, Attack Methods, Privacy Preservation

Abstract: In recent years, Federated Learning (FL) has gained significant attention as a crucial technology for addressing

the issue of data silos. Despite possessing certain privacy-preserving capabilities, FL still carries the risk of

privacy leakage, particularly in fields such as healthcare and finance, where the demand for user privacy

protection is increasingly urgent. This review first introduces the fundamental principles and classifications

of FL, with a focus on discussing its advantages in data privacy protection. Subsequently, it reviews the

background of current data privacy challenges, encompassing various privacy attack methods that highlight

the deficiencies of FL in privacy protection. Following this, various privacy protection methods are

thoroughly discussed, analyzing the strengths of different methods in safeguarding data privacy. A

comparative analysis of specific privacy protection algorithms is then conducted, providing a detailed

examination of the advantages, disadvantages, protection strategies, and targeted subjects of each algorithm.

By systematically summarizing existing research, this paper offers a comprehensive understanding of the

application of FL in the field of data privacy, providing valuable insights for both the academic and industrial

sectors. Furthermore, it serves as a useful guide for future research and applications in this domain.

1 INTRODUCTION

Federated Learning (FL) has become highly

prominent for breaking down data silos, finding

applications across finance, healthcare, and smart

cities, thereby amplifying the importance of its

privacy considerations.

Initially proposed by Mcmahan et al. in 2016, FL

is a technology designed for efficiently training high-

quality centralized models (Konečný et al. 2016).

This technique allows models to be trained on

multiple local devices and then centrally aggregated

at a central location. Importantly, data is stored on

users' local devices rather than being uploaded to a

centralized data center, ensuring the privacy of users.

Google has made notable contributions to FL, being

the first to introduce the concept and providing open-

source · frameworks like TensorFlow Federated

(TFF) (TensorFlow, 2024).

International standardization organizations, such

as the International Organization for Standardization

(ISO), and other standardization bodies are actively

working on standardizing FL to facilitate its cross-

industry applications. For instance, the Institute of

Electrical and Electronics Engineers (IEEE) has

approved the first standard for FL architecture (IEEE

Computer Society 2021). Numerous researchers have

focused on studying privacy protection, attacks, and

security threats related to FL, proposing various

methods to ensure the security of models and data.

Examples include the Federated Meta-Learning

Algorithm (FedMA), Federated Dynamics Algorithm

(FedDyn), Multi-party Optimization with Outcomes

Network Algorithm (MOON), and knowledge

transfer personalized federated learning (KT-Pfl)

algorithm, among others (Wang et al. 2020, Acar et

al. 2021, Li et al. 2021, Zhang et al. 2021).

In China, extensive research has been conducted

on FL, and the technology has been applied in

practical settings, particularly in areas such as

agriculture and healthcare, emphasizing privacy

protection and model training (Kang et al. 2022, Xu

et al. 2021).

FL has successfully addressed the traditional

machine learning challenge where uploading all data

to a high-performance server for centralized training

could lead to issues such as data privacy breaches and

uncontrollable data flow. Essentially, FL represents a

form of distributed machine learning.

Zhang, J.

A Comprehensive Research of Data Privacy Based on Federated Learning.

DOI: 10.5220/0012832500004547

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Data Science and Engineering (ICDSE 2024), pages 531-536

ISBN: 978-989-758-690-3

531

Despite having privacy protection mechanisms,

FL remains vulnerable to various attack vectors that

may result in the leakage of user data privacy. From

the perspective of attack methods, these primarily

include poisoning attacks and Byzantine attacks.

Regarding the stages of attack initiation, they are

broadly categorized into the model training phase and

the model inference phase.

2 FEDERATED LEARNING

FL involves collaborative model training by clients

under central coordination, with the central server

(CS) aggregating locally trained models through

weighted averaging to derive a global model (GM) in

each iteration. After multiple rounds of iteration, the

final result model is achieved. This approach

effectively mitigates privacy risks associated with

traditional machine learning. Since raw data is stored

locally on client devices, only the analysis and

sharing of models take place, preventing data leakage

to the server or other locations. Additionally, the

accuracy achieved is comparable to that of traditional

machine learning.

The process involves FL algorithmic principles,

focusing on model training in a distributed

environment without necessitating raw data transfer

to a CS. The basic principles of typical FL algorithms

are outlined below:

1. Initialization: Select the architecture and

initialize parameters for the GM.

2. Device Registration: Devices register

themselves with the FL system.

3. Local Model Training: Each device utilizes

local data for model training. Training can involve

traditional gradient descent or other optimization

algorithms.

4. Model Parameter Update: After local data

training, devices transmit only the updates (gradients

or weights) of model parameters to the CS, without

transferring raw data.

5. Model Aggregation: The CS collects model

parameter updates from all devices. Using an

aggregation strategy, typically weighted averaging,

the new parameters for the GM are obtained.

6. GM Update: The CS updates the GM using the

aggregated parameters.

7. Communication and Iteration: Iterate through

the process of local model training, parameter

updates, model aggregation, and GM updates until

convergence or a predefined number of training

rounds are reached.

8. Model Evaluation: Evaluate the GM to assess

its performance in FL.

It is evident that in FL since clients are responsible

for training, they only upload the model without

transferring local data. Additionally, the trained

model uploaded to the CS can be shared among

multiple parties without significantly affecting model

accuracy.

3 CLASSIFICATION OF

FEDERATED LEARNING

According to different data situations, FL can be

divided into three types: Horizontal FL, Vertical FL,

and Federated Transfer Learning (Yang et al. 2019).

Details are presented in Table 1.

Table 1. Three Types of FL Classification

User

Overlap

Feature Overlap

in Data

Horizontal FL Multiple Few

Vertical FL Few Multiple

Federated Transfer

Learning

Few Few

Based on practical production, two scenarios for

FL can be defined: Business-to-Business (ToB) and

Consumer-to-Consumer (ToC).

In the ToB scenario, the primary entities involved

are institutions, companies, and governments.

Typically, a third-party CS is used for model

exchange and parameter control (Wang et al. 2021).

In the ToC scenario, there is often a larger number

of participants with lower computational power. This

scenario tends to weaken the characteristics of a CS

control node, placing model updates in the hands of

each participant (Wang et al. 2021).

4 FEDERATED LEARNING

PRIVACY ISSUES

While FL incorporates certain privacy protection

mechanisms, it may not provide sufficient privacy

safeguards. For instance, attacks during the process of

model update data transmission can lead to the

leakage of sensitive information. Different attack

methods may also result in data leakage from the CS.

ICDSE 2024 - International Conference on Data Science and Engineering

532

4.1 Byzantine Attacks

Byzantine attacks refer to situations in distributed

systems where a subset of nodes (called Byzantine

nodes) intentionally provides erroneous, deceptive, or

malicious information, attempting to disrupt the

normal operation of the system. In FL, attackers

control multiple Byzantine users who intentionally

provide false or harmful parameter data to the CS,

disrupting the training process of the GM. This type

of attack can impact the GM and compromise its

accuracy (Bagdasaryan et al. 2020).

4.2 Poisoning Attacks

A "Poisoning Attack" is where attackers deliberately

inject malicious, disruptive, or false data into the FL

system to influence the performance of the GM (Chen

et al. 2020). Poisoning attacks have various methods,

such as data poisoning and model poisoning.

Data poisoning involves contaminating training

sample data, such as adding erroneous data or altering

local data labels, misleading the GM during training,

and disrupting the model's learning of features (Jiang

et al. 2019).

Model poisoning disrupts the performance of the

GM by injecting malicious local model parameters

into the FL system (Bhagoji et al. 2019).

4.3 Sybil Attacks

Sybil attacks typically involve a single node in the

network having multiple identity labels and

weakening the effectiveness of network redundancy

backups through control over the system. Attack

methods include direct communication, forgery or

theft of identity, and simultaneous and non-

simultaneous attacks. In the server-client architecture

of FL, participants launching malicious attacks can

control the server, forge numerous client devices, or

control devices in a pool that have been

compromised, enabling the execution of Sybil attacks

(Wang et al. 2021).

5 PRIVACY PROTECTION IN

FEDERATED LEARNING

Privacy protection of data is a crucial aspect of FL.

Without adequate protection, there is a risk of leakage

of many privacy parameters during training. Once

leaked, both data owners and participants face

significant losses. Therefore, it is essential to

implement privacy protection measures in FL.

5.1 Defense Against Data Poisoning

Several methods exist to protect learning models from

the impact of data poisoning attacks. Examples

include anomaly detection, data filtering, and trust

evaluation. Nathalie et al. use context information

checking to detect toxic sample points. By comparing

results from different parts of training, they evaluate

and identify abnormal data models (Baracaldo et al.

2017).

5.2 Homomorphic Encryption

Homomorphic encryption is a specialized technique

for computational operations on encrypted data. It

enables operations such as addition or multiplication

on encrypted data without the need to decrypt it,

ensuring that the original data remains confidential

during transmission. Homomorphic encryption can

be utilized to protect model parameters when they are

sent from the server to the client in a FL system. This

allows clients to update in an encrypted state without

exposing model details. During model predictions,

homomorphic encryption can be used to encrypt input

data, enabling the server to make predictions in an

encrypted state without knowing the plaintext content

of the input data (Baracaldo et al. 2017).

5.3 Differential Privacy

Differential privacy provides mathematically

rigorous protection when handling individual data,

preventing re-identification attacks against individual

data. It can protect local data on each device by

introducing noise, ensuring that even locally,

contributions of individual data are not directly

exposed, thereby enhancing user privacy protection.

When aggregating local model parameters into a GM,

differential privacy can be employed to introduce

noise on model parameters, protecting the details of

individual models. This ensures that the GM's

training does not overly rely on the specific data of

any one participant. Differential privacy techniques

can be applied to gradient computation and updates,

introducing noise on gradients to protect individual

data (Dwork 2011).

5.4 Data Compression

Compression solutions involve employing various

techniques to reduce or compress the amount of data

A Comprehensive Research of Data Privacy Based on Federated Learning

533

transmitted in FL. This helps to lower communication

overhead, improve the efficiency of model updates,

and maintain the accuracy of model training. When

applying differential privacy, the size of transmitted

noisy data can be reduced by adjusting the parameters

of the noise or using more efficient differential

privacy algorithms. Sparse ternary compression

(STC) can significantly reduce the model size,

thereby lowering memory and computational costs

when deploying on embedded or edge devices. The

active participation of numerous clients also ensures

the robustness of the model (Zhou et al. 2021, Sattler

et al. 2019).

6 PRIVACY PROTECTION

ALGORITHM COMPARATIVE

ANALYSIS

6.1 Siren

Siren, a Byzantine-robust FL system with an active

alert mechanism, improves defense against attacks by

employing precision checks and distributed detection.

Each client conducts two processes: training and

alert. In the training process, a small portion of the

local dataset is retained as a test dataset. The alert

process tests the global weights, and alerts are sent to

the CS to remove malicious weights during each

communication round (Guo et al. 2021).

6.2 Edge Computing Privacy

Protection

This system utilizes blockchain for decentralization

and auditability, bolstering resistance to tampering

and single-point failure attacks. FL establishes a

collaborative training platform across multiple

devices without requiring a trusted environment or

specialized hardware. It incorporates adaptive

differential privacy to protect model parameter

privacy while reducing noise's impact on model

accuracy. This integration offers a solution with high

accuracy and robust privacy protection for edge

computing scenarios (Fang et al. 2021).

6.3 FLAME

The FLAME framework combines differential

privacy and FL, achieving the goal of simultaneously

protecting user privacy and improving model

accuracy without requiring a trusted party, using the

shuffling model in differential privacy. It balances

model accuracy and user privacy protection, avoids

some limitations of traditional models, and offers

better performance for practical applications. It also

demonstrates strong resistance against poisoning

attacks (Liu et al. 2021).

6.4 Summary

Table 2 summarizes different architectures for

protection against attacks, highlighting their methods,

advantages, disadvantages, and defense mechanisms.

Table 2. Privacy protection algorithm comparison

Architecture Protection Methods Advantages Disadvantages

Defense Against

Attacks

Siren Distributed Detection

Suitable for a large

number of malicious

clients

No Apparent

Drawbacks

Various Attacks

Edge Computing

Privacy

Protection

Adaptive Differential

Privacy Mechanism,

Gradient Checking, and

Incentive Mechanism

Suitable for scenarios

with high security and

accuracy requirements.

Low efficiency Poisoning Attacks

FLAME

Privacy amplification

benefit

Performance

improvement, avoiding

limitations

Not suitable for

large parameter

dimensions

Vulnerable to

poisoning attacks

ICDSE 2024 - International Conference on Data Science and Engineering

534

7 DISCUSSION AND ANALYSIS

By learning models in a distributed environment,

model training can be achieved without centralizing

data. Communication efficiency is crucial, especially

when learning on mobile devices and reducing

communication rounds is vital for performance

improvement. Different technologies and methods,

such as iterative model averaging, model accuracy

checks, and model alert mechanisms, can be

employed. Future research could explore the

applicability of these methods in broader and more

complex scenarios, as well as how to enhance model

robustness and privacy protection performance

further.

In the field of FL, there is a need for more

attention to comprehensive optimization methods that

address communication efficiency, security, and

model performance simultaneously.

8 CONCLUSION

In the field of FL, the technology to address the issue

of data silos has garnered significant attention.

Despite having certain privacy protection

mechanisms, FL still poses risks of privacy leakage,

especially in sectors such as healthcare and finance,

where the demand for user privacy protection is

urgent. The paper reviews the fundamental principles,

classifications, and privacy challenges of FL, with a

particular focus on privacy threats like Byzantine

attacks, poisoning attacks, and Sybil attacks.

Regarding privacy protection, researchers have

proposed various methods, including homomorphic

encryption, differential privacy, and data

compression technologies. Homomorphic encryption

enables computational operations on encrypted data,

effectively safeguarding the privacy of model

parameters and input data. Differential privacy

protects data privacy on local devices by introducing

noise and prevents overreliance on individual models

by introducing noise on model parameters. Data

compression technology enhances communication

efficiency by reducing the amount of transmitted data

while maintaining the accuracy of model training.

In the comparative analysis of privacy protection

algorithms, Siren employs an active alert mechanism,

edge computing privacy protection combines

blockchain technology, and the FLAME framework

integrates differential privacy with FL. These

methods not only enhance model accuracy but also

effectively counter various types of privacy attacks.

Overall, as a distributed machine learning

approach, FL faces challenges in the comprehensive

optimization of communication efficiency, security,

and model performance. Future research should delve

into the applicability of these methods in broader and

more complex scenarios to further enhance the

robustness and privacy protection performance of FL.

REFERENCES

A. N. Bhagoji, S. Chakraborty, P. Mittal, et al. Analyzing

federated learning through an adversarial lens. In

International Conference on Machine Learning,

(2019), pp. 634-643.

C. Dwork. Communications of the ACM, 54(1), 86-95,

(2011).

C. Fang, Y. Zheng, Y. Wang, et al. Journal of

Communications, 42(11), 28-40, (2021).

C. Zhou, Y. Sun, D. Wang, et al. Journal of Network and

Information Security, 7(5), 77-92, (2021).

D. A. E. Acar, Y. Zhao, R. M. Navarro, et al. arXiv preprint

arXiv:2111.04263, (2021).

E. Bagdasaryan, A. Veit, Y. Hua, et al. “How to backdoor

federated learning”. In International conference on

artificial intelligence and statistics, (2020), pp. 2938-

2948.

F. Sattler, S. Wiedemann, K. R. Müller, et al. IEEE

transactions on neural networks and learning systems,

31(9), 3400-3413, (2019).

H. Guo, H. Wang, T. Son, et al. “Siren: Byzantine-robust

federated learning via proactive alarming”. In

Proceedings of the ACM Symposium on Cloud

Computing, (2021), pp. 47-60.

H. Wang, M. Yurochkin, Y. Sun, et al. arXiv preprint

arXiv:2002.06440, (2020).

IEEE Computer Society. “IEEE Guide for Architectural

Framework and Application of Federated Machine

Learning.” in IEEE Std 3652.1-2020, (2021), pp.1-6.

J. Chen, J. Chu, M. Su, et al. Journal of Information

Security, 5(4), 14-29, (2020).

J. Konečný, H. B. McMahan, D. Ramage, et al. arXiv

preprint arXiv:1610.02527, (2016).

J. Wang, L. Kong, Z. Huang, et al. Big Data, 7(3), 130-149,

(2021).

J. Xu, B. S. Glicksberg, C. Su, et al. Journal of Healthcare

Informatics Research, 5, 1-19, (2021).

J. Zhang, S. Guo, X. Ma, et al. Advances in Neural

Information Processing Systems, 34, 10092-10104,

(2021).

M. Kang, J. Wang, D. Li, et al. Chinese Journal of

Intelligent Science & Technology, 4(2), (2022).

N. Baracaldo, B. Chen, H. Ludwig, et al. “Mitigating

poisoning attacks on machine learning models: A data

provenance based approach”. In Proceedings of the

10th ACM workshop on artificial intelligence and

security, (2017), pp. 103-110.

N. Baracaldo, B. Chen, H. Ludwig, et al. “Mitigating

poisoning attacks on machine learning models: A data

A Comprehensive Research of Data Privacy Based on Federated Learning

535

provenance based approach”. In Proceedings of the

10th ACM workshop on artificial intelligence and

security, (2017), pp. 103-110.

Q. Li, B. He, D. Song. “Model-contrastive federated

learning”. In Proceedings of the IEEE/CVF conference

on computer vision and pattern recognition, (2021), pp.

10713-10722.

Q. Yang, Y. Liu, T. Chen, et al. ACM Transactions on

Intelligent Systems and Technology (TIST), 10(2), 1-

19, (2019).

R. Liu, Y. Cao, H. Chen, et al. “Flame: Differentially

private federated learning in the shuffle model”. In

Proceedings of the AAAI Conference on Artificial

Intelligence, 35(10), (2021), pp. 8688-8696.

Tensorflow Federated. TensorFlow, 2024, available at

https://www.tensorflow.org/federated?hl=zh-cn

W. Jiang, H. Li, S. Liu, et al. A flexible poisoning attack

against machine learning. In ICC 2019-2019 IEEE

International Conference on Communications (ICC),

(2019), pp. 1-6.

ICDSE 2024 - International Conference on Data Science and Engineering

536
