The Advancements of Pruning Techniques in Deep Neural Networks

Xinrui Li

Software Engineering, Beijing-Dublin International College, Beijing, China

Keywords: Neural Network, Structured Pruning, Unstructured Pruning.

Abstract: Neural network pruning is widely used to compress large, over-parameterized Deep Neural Network (DNN)

models. Previous studies have shown that pruning optimizes DNN models in the following aspects: saving

resource consumption and storage space costs, improving model deployment range, improving inference

speed, and achieving real-time service. This article summarizes the development and main progress of pruning

technology up to now and discusses the two types of pruning, basic principles, advantages and disadvantages,

and the performance in different application scenarios. The research prospect of combining automation

technology with pruning technology is also prospected. Pruning can be divided into two categories including

unstructured pruning and structural pruning. Unstructured pruning provides the flexibility to adjust parameters

to task requirements while achieving a greater proportion of compression, while structural pruning improves

model performance, stability, and interpretability by removing the entire module. Their respective

characteristics make them suitable for models with different structural complexity and different task

requirements. Although pruning is relatively well developed compared to other model compression

techniques, there are still some challenges. The current pruning technology is still dependent on manual

recognition of pruning parameters, and the technology of automatic recognition of pruning objects has not yet

been developed. This paper summarizes the research status of pruning technology in the field of DNN and

discusses current technological developments, applications, limitations, and challenges in development. The

review concludes by highlighting some potential for future research in this area, including exploring

automated pruning and the ability to enhance and transfer learning between fields.

1 INTRODUCTION

In contrast to traditional Artificial Neural Networks

(ANN), Deep Neural Networks (DNN) can

automatically learn features from large amounts of

data, enabling numerous Artificial Intelligence (AI)

technologies e.g. image and speech recognition

(Afouras et al, 2022) , natural language processing,

object detection and autonomous driving (Basiri et al,

2021, Qutub et al, Jinhan et al) . The wide range of

applications of DNNs has led to their vigorous

development in academia and industry. Despite rapid

development, the enormous scale and computational

requirements of these DNN models present

significant challenges for actual deployment,

especially in facilities with limited hardware

resources, such as smart sensors, and wearables

(Denil et al, 2013) . As these challenges become more

relevant, the field of model compression has emerged

as a key area of research to mitigate these limitations.

Generally speaking, model compression technology

could help improve calculation speed and model

storage friendliness by reducing model parameters

and scale, and maintaining or surpassing previous

model performance.

In recent years, more and more research has been

done on model compression methods, and great

progress has been made from theoretical research to

platform implementation. The earliest model

compressions can be traced back to 1989 when Cun

et al. proposed for the first time in OBD (Optimal

Brain Damage) to achieve the effect of compression

size by eliminating unimportant parameters in the

network (Cun et al, 1989) . At present, most cropping

schemes are based on Cun's OBD method. The paper

"Deep Compression" published by Han et al. in 2015

triggered a wave of research on pruning, which

reviewed the application of cutting, weight sharing,

quantization, coding and other technologies (Han et

al, 2015) . At present, DNN model compression is

mainly divided into three directions. First, optimize

the model design and build a compact and efficient

model, for example, SqueezeNet and MobileNet

Li, X.

The Advancements of Pruning Techniques in Deep Neural Networks.

DOI: 10.5220/0012837000004547

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Data Science and Engineering (ICDSE 2024), pages 177-181

ISBN: 978-989-758-690-3

177

(Iandola et al, 2017, Howard et al) . The second is to

cut the model by cutting the redundant parameters

and trying to maintain the performance. Among them,

the method of evaluating weights and the pruning

method have received wide attention. The third is

kernel sparsity, which makes the model sparser by

inducing weight updates and applying compact

storage methods such as CSC coding (Barra et al,

2020, Gu et al, 2015) . Although sparsity operates

faster on hardware platforms, it is affected by

bandwidth. In addition, there is also much research on

neural architecture search (Fedorov et al, 2019) ,

policy refinement (Wu et al, 2022) , and other

methods, which have played a good role in model

compression.

In the field of deep neural networks, the

mainstream model compression techniques can be

roughly divided into the following four categories:

pruning, knowledge distillation, quantization, and

low-rank decomposition. Among them, pruning is

widely used to reduce the most common model

compression problem - over-parameterization, which

mainly occurs during the model training phase.

Because some parameters assist the training of the

model and are not often used after the training, it is

necessary to trim these redundant parameters. Thus,

the pruning algorithm is proposed and its core idea is

to reduce the number of parameters and computations

in the network model while ensuring the performance

of the model is not affected as much as possible.

The excellent performance of pruning technology

is reflected in that it cannot only improve model

sparsity and inference speed, but also reduce

overfitting risk and resource demand, and is

environmentally friendly. In addition, in different

tasks and scenarios, the research of pruning

technology can also provide more possibilities for

customization and optimization. Therefore, the in-

depth exploration of pruning is expected to drive

continuous innovation and development in the field

of model compression.

The rest of this paper is organized as follows. In

the method section, this paper will mainly list the

application of the pruning method in various fields, as

well as the core changes and innovations of the

pruning method in recent years. In the discussion

section, possible challenges and future directions for

the pruning method will be further discussed. Finally.

this review will predict the future potential

development of model compression techniques in the

conclusion part.

2 METHOD

The broad definition of pruning includes three

aspects, regulation, pruning and growth. The

development of these techniques provides a

comprehensive optimization scheme for the

efficiency and performance of deep learning models

in practical applications. The basic idea and principle

of pruning is to streamline the model structure by

removing unnecessary neurons and connections,

promoting model storage friendliness, memory

efficiency, and computational efficiency. The steps of

pruning algorithm include model training, pruning,

fine-tuning and model retraining.

Pruning algorithms can be broadly divided into

two branches according to the target level to be cut:

unstructured pruning and structured pruning shown in

Figure 1. The main difference between them lies in

the pruning target and the structure after pruning.

Unstructured pruning refers to pruning individual

weight and would result in sparse weight matrix due

to the direct weight-pruning. This results in the need

for dedicated hardware or libraries to achieve

compression and acceleration. Structured pruning·

refers to prune in the level of filter or channel or layer,

which preserves the original convolutional structure

and can directly run on a mature deep learning

framework without requiring the support of a specific

algorithm library or hardware platform.

Figure 1. The schematic illustration of pruning (Chen et al,

2021) .

2.1 Unstructured Pruning

In unstructured pruning, unimportant elements in the

model weight matrix are zeroed to create a sparse

matrix, which is then stored in a sparse way to reduce

the storage capacity of the model to achieve

compression. But this element-removing would

ignore the internal structure and lead to irregular

sparse structure after pruning (Anwar et al, 2017,

Fang et al) . Among unstructured pruning models, the

most representative one is Han's Deep Compression

paper which uses unstructured loss, weight reunion

class, and Huffman coding to achieve the ultimate

compression effect of the model (Han et al, 2015) .

ICDSE 2024 - International Conference on Data Science and Engineering

178

Because unstructured pruning can lead to random

and sparse structures, it will destroy the model

structure greatly and may affect the model

performance, so the application scope is relatively

narrow.

2.1.1 Graphic Processing

In Pietron et al. ‘s model, unstructured pruning

improved the efficiency of graphics processing units

(Pietro & Żurek, 2022) . Previous studies on

unstructured pruning focused only on the memory

footprint of compressed models, which resulted in a

relatively low reduction in the computational effort.

More recent studies have looked more at how to

balance the compression model and reduce the

computational effort. Xu et al. proposed a method to

explore the entire pruning structure space effectively

and found a balanced pruning scheme between model

size and pruning workload (Xu, 2021) .

2.2 Structured Pruning

Current structured pruning models mainly focus on

how to automatically identify redundant parameters

and prune them, or how to prune them away more

quickly. Ning et al.’s AutoCompress model

efficiently incorporates the combination of structured

pruning schemes into an automated process (Ning et

al, 2020) . Mitsuno et al. proposed a sparse

regularization algorithm to improve the ability of

automatically identify unnecessary weights (Mitsuno

et al, 2020) . To prune parameters more quickly, Li et

al. proposed a single-pass automated pruning

framework that enables faster convergence and fewer

hyperparameters (Li et al) .

Structured pruning is not only used to prune

computationally heavy DNN models in various fields

but also to help restore robustness to attacked models.

For instance, Guan et al. developed a model called

ShapPruning to recognize and cut off infected

neurons to enhance robustness (Guan et al, 2022) .

2.2.1 Graphic Processing

Zhang et al. have developed structural pruning

methods that can offset the limitations of irregular

network structures and accelerate at high resolution

(Zhang et al, 2022) . The MPDCompress algorithm

proposed by Supic et al. can improve the model

inference speed on various hardware platforms and

achieve more than 4 times the operational efficiency

(Supic et al, 2018).

2.2.2 Medical

Current DNN models have shown better recognition

accuracy than human experts in some fields, such as

tumor recognition (Qiu et al, 2022) , so how to

compress and simplify the models and put them into

use with the increase in scale and computational

complexity has become an urgent task.

More research has focused on how to solve this

problem in recent years. Li et al. combined hardware-

friendly, structured model compression with moving

target encoder optimization to achieve DNN model

inference on mobile devices (Li et al, 2021) . Li et al.

also overcame the difficulty of limited medical

instrument resources and successfully compressed

the original model by 36 times using structural weight

pruning (Li et al, 2019) . Hedegaard et al. proposed

the concept of Continuous Inference Networks

(CINs) and used fusible adaptation networks and

structured pruning to achieve exceptional prediction

accuracy over finetuning plus pruning (Hedegaard) .

3 DISCUSSION

Under limited resources, pruning improves the

efficiency of DNN but affects the interpretability.

Structural pruning improves explainability by

removing entire modules, while non-structural

pruning makes the model structure difficult to

interpret. Although structural pruning is superior in

interpretability, the choice of method should take into

account the task and application scenario. Structural

pruning is better suited for tasks that emphasize

overall model performance, inference speed, and

model stability, especially in resource-constrained

environments. Its hardware optimization advantages

make it suitable for embedded devices and edge

computing platforms, such as in the graphics

processing field and the medical field (Zhang et al,

2022, Supic et al, 2018, Li et al, 2021, Li, 2019,

Hedegaard). Unstructured pruning also has unique

advantages in some tasks. Its flexibility and

adjustability enable the model to meet the

requirements of different application scenarios, such

as image classification requirements for graphics

processing (Pietro & Żurek,2022, Xu et al, 2021). In

summary, the selection of pruning strategies needs to

balance model interpretation, performance, hardware

optimization, task requirements, and interpretability

to ensure the best results in practical applications.

The biggest limitation of pruning methods is that

there is no universal standard for building parameters

that applies to all models and tasks. Each model still

The Advancements of Pruning Techniques in Deep Neural Networks

179

has a strong artificial dependency, relying on the

manual selection of pruning parameters, and the cost

of model compression increases greatly as the model

gets larger.

Recent studies mainly focus on automatic pruning

methods and solving the impact of unstructured

pruning on interpretability, such as using sparse

regularization algorithm to automatically identify

pruning parameters and reduce the dependence on

manual parameter selection (Mitsuno et al, 2020) .

The automated pruning field has uncultivated

potential. Most of the existing pruning methods are

only for specific models and tasks, which require

strong domain knowledge. Thus, it usually requires

AI developers to spend a lot of energy to apply these

methods to their own scenarios, which is very costly.

The ideal structural pruning algorithm should satisfy

the following conditions: the model can be trained

automatically from scratch, no further fine-tuning is

required after pruning, and can achieve high

performance and lightweight. However, the

complexity of neural networks makes achieving the

goal of automated pruning extremely challenging. To

achieve this end, it is necessary to systematically

address three core questions: identifying the parts of

the network that should be pruned, determining how

to prune without damaging the network, and finding

a way to automate these two processes. Successfully

answering these questions could be a significant

stepping stone towards automated pruning.

4 CONCLUSION

This review comprehensively explores neural

network pruning techniques used to compress large

Deep Neural Network models in areas such as image

classification and medical treatment. It discusses two

main types of pruning: unstructured and structured

pruning. Unstructured pruning, known for its

flexibility, can significantly compress models but

may reduce performance and interpretability. In

contrast, structured pruning maintains performance

and stability, making it suitable for embedded devices

and edge equipment. Each type's characteristics make

them suitable for different situations, and all factors

should be considered when choosing a pruning

strategy. The research on pruning impacts the field of

DNN by saving resource consumption and storage

space costs, improving the model deployment range,

enhancing inference speed, and enabling real-time

services. However, the application of pruning faces

some challenges, including decreased interpretability

and domain difference problems. Due to the varying

distribution and characteristics of model data across

different fields, pruning methods trained based on the

weight of data in different domains lack

transferability. Future research on pruning could

focus on enhancing model interpretability, generality,

and automation in pruning processes. Combining

pruning technology with model compression and

optimization techniques, such as knowledge

distillation and quantization, is expected to further

improve model efficiency and performance.

REFERENCES

T. Afouras, et al., IEEE Trans. Pattern Anal. Mach. Intell.

44(12), 8717-8727 (2022)

M.E. Basiri, et al., Future Gener. Comput. Syst. 115, 279-

294 (2021)

S.S. Qutub, et al., BEA: Revisiting anchor-based object

detection DNN using Budding Ensemble Architecture,

CoRR abs/2309.08036

https://arxiv.org/pdf/2309.08036v4.pdf

K. Jinhan, et al., Reducing DNN Labelling Cost using

Surprise Adequacy: An Industrial Case Study for

Autonomous Driving, in Proceedings of ACM

SIGSOFT Conf. Found. Softw. Eng. abs/2006.00894,

1466-1476 (2020)

M. Denil, et al., Adv. Neural Inf. Process. Syst., 2148–2156

(2013)

Y. Le Cun, et al., Conf. Neural Inf. Process. Syst., 598-605

(1989)

S. Han, et al., Deep Compression: Compressing Deep

Neural Network with Pruning, Trained Quantization

and Huffman Coding, in Proceedings of Int. Conf.

Learn. Represent. abs/1510.00149 (2015)

F.N. Iandola, et al., SqueezeNet: AlexNet-level accuracy

with 50x fewer parameters and <0.5MB model size,

arXiv: Comput. Vis. Pattern Recognit. (2017)

A.G. Howard, et al., Mobilenets: Efficient convolutional

neural networks for mobile vision applications, arXiv

preprint arXiv:1704.04861,

https://arxiv.org/pdf/1704.04861.pdf

S. Barra, et al., IEEE/CAA J. Autom. Sinica 7(3), 683-692

(2020)

S. Gu, et al., Convolutional Sparse Coding for Image Super-

Resolution, in Proceedings of IEEE Int. Conf. Comput.

Vis., 1823-1831 (2015)

I. Fedorov, et al., Adv. Neural Inf. Process. Syst. 32, 4978-

4990 (2019)

Y. Wu, et al., IEEE Trans. Neural Netw. Learn. Syst. 33(9),

5057-5069 (2022)

S. Anwar, et al., ACM J. Emerg. Technol. Comput. Syst.

13(3):32:1–32:18 (2017)

G. Fang, et al., Depgraph: Towards any structural pruning,

CoRR abs/2301.12900,

https://arxiv.org/pdf/2301.12900.pdf

M. Pietroń, D. Żurek, J. Comput. Sci. 67 (2022)

K. Xu, et al., Neurocomputing 451, 81-94 (2021)

ICDSE 2024 - International Conference on Data Science and Engineering

180

L. Ning, et al., Autocompress: An Automatic Dnn

Structured Pruning Framework For Ultra-High

Compression Rates, in Proceedings of AAAI Conf.

Artif. Intell. 34, 4876-4883 (2020)

K. Mitsuno, et al., Hierarchical Group Sparse

Regularization for Deep Convolutional Neural

Networks, in Proceedings of IEEE Int. Joint Conf.

Neural Netw. abs/2004.04394 (2020)

Z. Li, et al., SS-Auto: A Single-Shot, Automatic Structured

Weight Pruning Framework of DNNs with Ultra-High

Efficiency, arXiv preprint

arXiv:2001.08839,https://arxiv.org/pdf/2001.08839.pd

J. Guan, et al., Comput. Vis. Pattern Recognit. 13348-

13357 (2022)

L. Chen, Y. Chen, J. Xi, X. Le, Complex Intell. Syst. 1-0

(2021)

T. Zhang, et al., IEEE Trans. Neural Netw. Learn. Syst.

33(5), 2259-2273 (2022)

L. Supic, et al., Comput. Res. Repos. abs/1805.12085

(2018)

Y. Qiu, J. Wang, Z. Jin, H. Chen, M. Zhang, L. Guo,

Biomed. Signal Process. Control 72, 103323 (2022).

H. Li, et al., Real-Time Mobile Acceleration of DNNs:

From Computer Vision to Medical Applications, in

Proceedings of Asia South Pac. Des. Autom. Conf. 581-

586 (2021)

H. Li, et al., Med. Image Comput. Comput. Assist. Interv.

89-97 (2019)

L. Hedegaard, Efficient Online Processing with Deep

Neural Networks, CoRR abs/2306.13474,

https://arxiv.org/pdf/2306.13474.pdf

The Advancements of Pruning Techniques in Deep Neural Networks

181
